An Effective Parallel SVM Intrusion Detection Model for Imbalanced

Training Datasets

Jing Zhao

1,2

, Jun Li

1,2

, Chun Long

1,2

, Jinxia Wei

, Guanyao Du

1,2

, Wei Wan

1,2

and Yue Wang

1,2

Computer Network Information Center, Chinese Academy of Sciences, Beijing, China

University of Chinese Academy of Sciences, Beijing, China

Keywords: Intrusion Detection, Feature Reduction, Parallel SVM, Classification.

Abstract: In the field of network security, the Intrusion Detection Systems (IDSs) always require more research on

detection models and algorithms to improve system performance. Meanwhile, higher quality data is critical

to the accuracy of detection models. In this paper, an effective parallel SVM intrusion detection model with

feature reduction for imbalanced datasets is proposed. The model includes 3 parts: 1) NKSMOTE-a Modified

unbalanced data processing method. 2) feature reduction based on Correlation Analysis. 3) Parallel SVM

algorithm combining clustering and classification. The NSL-KDD dataset is used to evaluate the proposed

method, and the empirical results show that it achieves a better and more robust performance than existing

methods in terms of the accuracy, detection rate, false alarm rate and training speed.

1 INTRODUCTION

In recent years, with the rapid development of the

Internet, the scale of the network and the number of

users have continued to expand, and security

incidents caused by the network have emerged in the

world. For example: A new ransomware virus,

WannaCry, which appeared in May 2017, spread

worldwide in a short period of time, causing adverse

effects on the public infrastructure networks of

governments, enterprises and individuals (Jesse M.

E., 2017). On March 2, 2018, GitHub suffered a

1.35TB traffic attack. On April 17, 2019, a research

report from the Cisco Talos research team stated that

a state-sponsored hacker successfully hijacked the

Domain Name System (DNS) records and stole

certificates from nearly 40 public and private entities

in 13 countries, which caused serious consequences.

According to statistics from relevant departments

(Source: Ponemon Institute and Juniper Networks,

October 2017), 12,172 alerts are generated globally

every week, and 518 alerts are studied every week. It

takes 352.3 hours to track false alarms every week.

Tracking false alarms costs $1,145,000 per year, and

cyber breaches cost $7,000,000 per year.

With the continuous update and mutation of attack

methods in the network, the traditional intrusion

detection methods based on feature matching have

been unable to effectively solve security problems,

especially when the characteristics of attackers are

becoming more and more complex, the traditional

intrusion detection methods show great

disadvantages: 1) low detection rate and high false

alarm rate, 2) poor adaptability, 3) low detection

efficiency. Therefore, intrusion detection methods

based on machine learning are emerging.

Machine learning technology has been widely

used in intrusion detection system for a long time.

Many efficient Machine learning models are used to

classify normal and abnormal traffic in intrusion

detection, such as Support Vector Machine (SVM) (B

M A., 2016), Decision Tree (L M., 2018), K-means

(W L AL., 2017) and Artificial Neural Network

(ANN) (S. S. Roy, 2017).

In a large number of researches using machine

learning to solve intrusion detection problems, the

imbalance between training data and test data often

leads to low efficiency of algorithms. Many

researches in the field of intrusion detection focused

on unbalanced data sets. Hamid et al. proposed a

hybrid method based on coupling discrete wavelet

transforms and ANN （Artificial Neural Network）

for intrusion detection (Y. H., 2018). They eliminated

the imbalance of the instances by SMOTE (Synthetic

Minority Oversampling Technique) based

oversampling of less frequent class and random

under-sampling of the dominant class. S. M. H. B et

Zhao, J., Li, J., Long, C., Wei, J., Du, G., Wan, W. and Wang, Y.

An Effective Parallel SVM Intrusion Detection Model for Imbalanced Training Datasets.

DOI: 10.5220/0009390302250232

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 2, pages 225-232

ISBN: 978-989-758-423-7

225

al. introduced penalized multiple criteria linear

programming (MCLP) to deal with unbalanced

datasets (S. M. H. B, 2016). Aggarwal proposed a

new metric NPR (NP Ratio) used for ranking the

classifiers for IDS to evaluate the detection rate and

false alarm rate caused by unbalanced data (P A.

2016). Wang Li proposed an improved NKSMOTE

algorithm to overcome the shortage of SMOTE. A

nonlinear mapping function was used to map samples

to a high-dimensional kernel space (Wang Li, 2018).

Such solutions to unbalanced data sets can improve

the classification accuracy to some extent, but also

significantly increase the complexity of model

training.

No matter which model is used, the steps of

machine learning algorithms for intrusion detection

classification can be divided into two major parts: the

data preprocessing and the model training. If the

metadata and its characteristics can be reduced and

selected in the data preprocessing stage, the model

framework will be more concise, and the

computational efficiency will be improved, and so

that the generalization ability of the model will be

enhanced. Yin et al. proposed a novel classification

algorithm using Ensemble Feature Selections (EFS)

for the imbalanced-class dataset. This algorithm

introduced a penalty-reward mechanism for minority

classes when feature subset objective functions were

designed (H Y., 2016). In (A A A., 2016), the

integration of linear discriminant analysis (LDA) and

principal component analysis (PCA) feature

extraction algorithm was used to alleviate the

imbalance of data.

To solve the above problems, this paper first

creatively propose a simplified NKSMOTE (a

Modified unbalanced data processing method) to

make samples of different categories nearly balanced

in quantity, and then use a feature reduction algorithm

to reduce feature dimensions to improve the accuracy

and efficiency of the intrusion detection. Finally, a

parallel SVM model was designed to realize multi-

classification intrusion detection for unbalanced

datasets.

2 PRELIMINARY

2.1 SMOTE Algorithm

The SMOTE algorithm is a classic oversampling

algorithm (Chawla N V, 2011). This algorithm is

different from the traditional oversampling method. It

is not a simple copy of the sample. The main idea is

to insert new artificial samples into the samples close

to the minority class samples. This can increase the

number of the minority class samples, and can

effectively solve the problem of classification

overfitting. The specific method is as follows:

Suppose

is a set of samples and

is a set of

the minority class samples, where

S⊂

X⊂

Find the

nearest neighbors of the same class for

each

through the oversampling rate

and

interpolate to obtain a new synthesized sample.

(0,1)*( )

new i j j

x rand y x=+ −

(1)

1,2,....

new

represents the sample obtained

after oversampling,

represents the

nearest

neighbors of the same type in

, and (0,1)rand

represents a random number in the region (0,1) .

2.2 Feature Sorting based on

Correlation Analysis

Definition 1. For a discrete feature vector, its

probability distribution can be expressed as

{( ), ( ), , ( )}

px px px

′′ ′

 , then entropy of feature is as

follows:

() ()log ()

Xpxpx

′′

=−



(2)

If all the values of

are the same, then the

entropy of

is 0. Thus, the feature

is useless for

data classification.

Definition 2. For two discrete features

{, , , }

xx x

′′ ′

∈  and

{, , , }

Yyy y∈  , their

joint probability density is

(, ),1 ,1px y i n j m

′

≤≤ ≤ ≤

, and conditional

density is

()

′

, then entropy of

under the

condition

can be expressed as

()

log

(, )

() (,)

px y

HXY px y

′



(3)

The mutual information is generated and derived

from entropy. For two features

and

in one

dataset, the mutual information between them is as

follows:

(;)

() ( )

(, )

(, )log

()( )

IXY

HX HXY

px y

px py

=−

′



(4)

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

226

The mutual information has the following

characteristics:

Symmetry:

(;) (; )

XY IY X=

Monotonic: if

BC⊆⊆

, then (; ) (; )

AC I BC=

The mutual information reflects the amount of

information shared between two random variables.

The greater value of the mutual information, the

greater correlation between the two variables. If the

mutual information between two variables is 0, the

two variables are completely uncorrelated and

statistically independent in probability.

3 RESEARCH METHODOLOGY

This section introduces the research methodology for

intrusion detection model ， which includes three

parts: NKSMOTE-a modified unbalanced data

processing method, feature reduction based on

correlation analysis and intrusion detection algorithm

based on Online-SVM.

3.1 S-NK-SMOTE: A Modified

Unbalanced Data Processing

Method

The purpose of S-NK-SMOTE algorithm is to

balance the number of different categories samples.

Our method is a simplification of the NK-SMOTE

(Wang Li, 2018). the processing steps are as follows:

Step1：For all minority class samples

, search

its nearest

samples. Among the

samples, if the

number of minority class samples is greater than the

number of majority class samples,

is a safety

sample; if the number of minority class samples is

less than the number of majority class samples, and if

exist minority class samples,

is a dangerous

sample; if all samples are majority class samples, then

is a noise sample.

Step2：If

is a noise sample, oversampling will

introduce the risk of noise into the dataset, while the

noise samples have certain positive impact on the

classification. In order to reduce the risk of noise,

select a sample

′

randomly from the minority class,

and generate a new sample close to the minority class:

(0.5,1) ( )

new

xrand x x

′

=+ ⋅ − (5)

Step3：If x is not a noise sample, then select 1

sample

′

randomly from its k nearest samples. If

′

belongs to the samples of the majority class, a new

sample close to x is generated as follows:

(0,0.5) ( )

new

x rand x x

′

=+ ⋅ − (6)

′

belongs to the samples of the minority class,

a new sample close to x is generated according to the

following formula:

(0,1) ( )

new

x rand x x

′

=+ ⋅ − (7)

3.2 Feature Reduction based on

Correlation Analysis

After balancing the dataset, high dimensional samples

can easily increase the classifier training time and

computational complexity, meanwhile, overfitting

will inevitably occur. Therefore, representing a subset

of features with effective lower dimension is

significant to improving classification accuracy and

efficiency.

This paper will calculate the correlation between

each feature and classification label and select the

best feature. Detailed steps are as follows:

Step1 ： According to formulas (2) (3) (4),

calculate the correlation between each feature vector

{, , , }

Xxx x

′′ ′

∈ 

（n is the number of samples）

and its corresponding category label

{0, 1}Y ∈ , and

perform standardized compression, the correlation is

expressed as:

(;)

(,)

() ()

IXY

CXY

HX HY

, where

0(,)1CXY≤≤ ,if (,)=1CXY , indicating features

are fully related to category labels，if

(,)=1CXY ,

indicating features are fully unrelated to category

labels.

Step2 ： Sort the features from large to small

according to the correlation. The higher the

correlation, the more information the feature

contains, the more useful it is, and it can more

accurately reflect the specific situation of the sample.

Step3 ： SVM algorithm is used for feature

selection. Considering the accuracy of intrusion

detection is closely related to feature selection, ACC

is used as the criterion for feature selection. The

optimal solution lies in fewer features and higher

accuracy, specific algorithm is as follows:

Suppose we have a dataset with

features, the

features have been sorted from large to small

according to correlation, denoted as

R , the accuracy

R is calculated by SVM. Remove the last

feature of

R to generate a new dataset, denoted as

, the accuracy

R is calculated by SVM, if

CC ACC> then keep

R , otherwise discard it.

An Effective Parallel SVM Intrusion Detection Model for Imbalanced Training Datasets

227

Remove the last feature of

R to generate a new

dataset, denoted as

R , and so on remove the last

tth−

feature of

R , if

1tt

CC ACC

−

> then keep

otherwise discard it. Finally, the dataset

corresponding to the optimal ACC and the most

representative features are selected.

3.3 Intrusion Detection Algorithm

based on Online-SVM

In this section, we will design an Online-SVM based

detection algorithm that can achieve multiple

classification of abnormal samples. The algorithm

includes a training phase and a detection phase.

3.3.1 Training

When training the algorithm, combine each class of

abnormal data with normal data to generate a

synthesized dataset, and then train an Online-SVM

classifier on the synthesized dataset. Assume that

there exist

different (sub)classes of abnormal data,

denoted as

{, ,, }

tt Att AttL

, we can get

new

synthesized training set and

Online-SVM

classifier. Finally, combine all abnormal data with

normal data to generate the

(1)mth+

synthesized

training set, and train the

(1)mth+

Online-SVM

classifier. Detailed steps during the training phase are

as follows:

Step1：Use the methods provided in section 3.1

and section 3.2 to process

abnormal sample sets

{_, _,, _}

tt T Att T Att TL

and 1 normal sample set

{}Normal

Step2：Generate

1m +

synthesized training sets,

{_, }

tt T Normal

{_, }

tt T Normal

,···,

{_, }

tt T Normal

and

{_, _,, _, }

tt T Att T Att T NormalL

Step3 ： Train

1m +

Online-SVM classifiers,

_Clf Att

_Clf Att ,···,

Clf Att

and

_Clf Normal

respectively.

3.3.2 Testing

The intrusion detection algorithm consists of

1m +

Online-SVM classifiers, and the training sets each

classifier used are different. Therefore, it can be

customized and expanded flexibly.

In order to improve the classification efficiency,

K-means is used to determine which classifier the

testing data input into. Specifically, we use K-means

to calculate the cluster center of all categories of

samples, and then calculate the average distance

between the testing data and each cluster center. At

last we choose the Silhouette Coefficient to evaluate

the result. The Silhouette Coefficient mainly

measures the similarity of a sample and other samples

of its own cluster, and the difference with the sample

and other samples of other clusters. The higher the

Silhouette Coefficient, the better the determine result.

Detailed methods are as follows:

Step1：Calculate the average distance between

sample

and other samples in the same cluster,

called the Dissimilarity of the cluster, expressed as

()ax.

Step2: Calculate the average distance between

sample

and the other samples in other

clusters,

expressed as

{, , , }

xx xH

bb bL

, then the Inter-

cluster Dissimilarity can be expressed as

() min{ , , , }

xxH

bx b b b= L .

Step3: According to ()ax and

()bx

, define the

Silhouette Coefficient of sample

()

1 , () ()

()

() ()

() 0 , () ()

max { ( ), ( )}

()

1, ( ) ( )

()

ax bx

bx ax

xaxbx

ax bx



−<



−



===





−>





(8)

Step4: The Silhouette Coefficient of the current

clustering result is the average of all samples

()

x ,

and the value range is

[1,1]− , the closer to 1+ , the

better the determine result.

Specific detection process is as follows:

Let

()Ki

be the number of cluster centers in class

i , and the

kth−

cluster center in class i be

expressed as

, the specific steps are as follows:

Step1： Calculate the average distance

()dist i

between the sample

to each class:

()

()= ( ) / (), {12 }

dist i x C K i i−∈



，， ...,m+1

Step2 ： Input

to Clf ind− ，

arg min ( )

ind dist i=

Step3 ： If

{, ,, }

ind Att Att Att∈ L

, the

output is

{, }

ind

cls Att Abnormal∈

ind

represents abnormal type.

Step4 ： If

ind Normal= , the output is

{,}

unknown

cls Att Normal∈ . It represents two result:

is a normal sample, or

can be considered as an

unknown attack.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

228

4 EXPERIMENTS

4.1 Experimental Data and

Environment

In this section, the experimental results on several

simulation and real methods are discussed. The

dataset used in the paper is based on the NSLKDD,

which is a modified version of the KDD Cup 99

(Tavallaee, 2009) dataset. The NSL-KDD testing

dataset contain 22544 connection patterns. Each

testing dataset have more number of attacks than that

of in training dataset.

The empirical experiments in our work were all

implemented on a computer with an Intel Core i7-

7700 CPU @ 3.60GHz with 16.0 GB RAM running

Windows 10. The proposed intrusion detection

algorithm was implemented by using Python.

4.2 Experimental Results and Analysis

The parallel SVM algorithm aims to improve the

accuracy for imbalanced datasets. Therefore, to

evaluate the performance of our proposed models and

make expedient comparisons with other detection

methods, we chose accuracy (ACC), detection rate

(DR) and false alarm rate (FAR) as the evaluation

measures. These three measurements are calculated

from the following formula.

TP TN

ACC

TP TN FP FN

+++

(9)

TP FP

(10)

FAR

FP TN

(11)

To verify the effectiveness of our proposed

intrusion detection models, we first discuss three

situations in this section: 1) Using Online-SVM

algorithm only. 2) Using NKSMOTE before Online-

SVM. 3) Using NKSMOTE and feature reduction

before Online-SVM. In order to evaluate the

performance of our model, all the experiments were

executed under the 5-class classification, and 10-fold

cross-validation was utilized to reduce the risk of

overfitting. The experimental results are shown in

Table 1-3.

Table 1: Performances of 5-class classification using Online-SVM only.

Attack Types Accuracy (%) DR (%) FAR (%)

Normal 98.89 98.51 0.9

DOS 97.5 97.62 0.98

Probin

98.21 98.1 0.9

R2L 98.16 97.78 0.88

U2R 97.83 97.4 0.7

Total 98.12 97.87 0.9

Table 2: Performances of 5-class classification using NKSMOTE before Online-SVM.

Attack T

es Accurac

(

)

(

)

FAR

(

)

Normal 99.4 99.03 0.65

DOS 98.62 98.49 0.55

Probin

98.98 98.85 0.66

R2L 98.96 98.77 0.512

U2R 98.72 98.8 0.43

Total 98.89 98.8 0.527

Table 3: Performances of 5-class classification using NKSMOTE and feature reduction before Online-SVM.

Attack T

es Accurac

(

)

(

)

FAR

(

)

Normal 99.55 99.43 0.5

DOS 98.32 98.9 0.16

Probin

99.56 99.51 0.23

R2L 99.33 99.43 0.55

U2R 99.18 99.46 0.3

Total 99.53 99.51 0.348

An Effective Parallel SVM Intrusion Detection Model for Imbalanced Training Datasets

229

Table 4: Performance comparison of different intrusion detection methods with NSL-KDD.

Literature Metho

Accurac

(

)

(

)

FAR

(

)

Our metho

Parallel SVM 99.53 99.51 0.348

A M V. B et al.

MCC-MCLP 99.13 99.09 0.55

Y. et al. M

-SVM 98.63 98.97 0.66

Bo Hu et al. DDF 92.70 91.70 0.50

Table 5: Run time of different intrusion detection methods.

Literature Method Training time Testing time

Our method Parallel SVM 103s 10ms

Bo Hu et al. DDF 256s 10ms

Chen et al. XGBoost 198.2s 5.2ms

A. et al Dee

Belief Networ

27330s 11ms

In Table 1, only parallel SVM algorithm is applied

in NSL-KDD. The values of ACC, DR and FAR

under different feature conditions are illustrated.

From the result in Table 1, we can see that the

performance of each classification is stable and

relatively excellent. The result means parallel SVM

algorithm is suitable for multi-classification.

In Table 2, the NKSMOTE is applied to process

unbalanced data, forming new dataset that the

quantity of different categories tends to balance. Then

parallel SVM algorithm is applied in processed NSL-

KDD. From the result in Table 1 and Table 2, we can

get a conclusion that using NKSMOTE algorithm is

very effective. The values of ACC and DR increase

much and the value of FAR decreases obviously.

In Table 3, the NKSMOTE is applied to process

unbalanced data, and the proposed methods

mentioned in 3.2 is used to perform feature reduction.

The results show that when the feature is reduced to

25 dimensions the value of ACC is optimal. Here the

25-dimensional subset consists of feature as <6, 3, 35,

27,4, 26, 23, 33, 38, 5, 34, 24, 39, 29, 36, 12, 37, 24,

32, 2, 40, 31, 1, 27, 28>. From the result in Table 3,

we can get a conclusion that Using NKSMOTE and

feature reduction simultaneously, the results are

optimal. However, Comparing the results of two

tables above, it is found that the NKSMOTE

algorithm is more effective.

To verify the effectiveness of our proposed

intrusion detection models, we compare the

performance of MCC-MCLP (A M V. B., 2017),

MK-SVM (Y., 2012) and Dynamic Deep Forest

(DFF) (Bo Hu, 2019) on the NSL-KDD dataset. Table

4 and Figure 1 show the performance of different

intrusion. The results illustrate that our method

provides the highest accuracy rate of 99.53%, the

highest detection rate of 99.51%, and the lowest false

alarm rate of 0.348%. The comparison results show

that the proposed method is superior to other intrusion

detection scheme in detection performance.

Figure 1: Performance comparison of different intrusion

detection models with NSL-KDD.

Table 5 and Figure 2 shows the results obtained by

comparing the run time of different intrusion

detection methods. The performance of our method is

not very well in testing time.

Figure 2: Run time of different intrusion detection methods.

0,2

0,4

0,6

0,8

ACC DR FAR

Our method MCC-MCLP MK-SVM DDF

0,2

0,4

0,6

0,8

ACC DR FAR

Our mehtod MCC-MCLP MK-SVM DDF

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

230

5 CONCLUSIONS

In order to improve the accuracy of the intrusion

detection for imbalanced training datasets, this paper

proposes an effective model, which include 3 parts:

1) NKSMOTE-a modified unbalanced data

processing method. 2) feature reduction based on

correlation analysis, which reduces the original 41-

dimensional feature to a 25-dimensional feature. 3)

parallel SVM algorithm combining clustering and

classification.

The experimental results illustrate that our

proposed detection method can obtain an outstanding

performance with a high ACC, a high DR, a low FAR

and a rapid training speed. However, the results show

that our method has no advantage in testing time

comparing with other newly related works.

Therefore, we will consider to improve the

performance of the proposed method in running time.

ACKNOWLEDGEMENTS

The authors would like to thank the editorial board

and reviewers. This work was supported by the

Construction Project of Network Security System

(XXH13507); the Strategic Priority Research

Program of Chinese Academy of Sciences

(XDC02030600).

REFERENCES

Jesse M. E., 2017. WannaCry, Cybersecurity and Health

Information Technology: A Time to Act. Journal of

Medical Systems, 41(7).

B M A., R R., M C., et al, 2016. A hybrid method consisting

of GA and SVM for intrusion detection system[J].

Neural Computing and Applications, 27(6):1669-1676.

L M., P S., N V D., 2018. A Data Classification Model: For

Effective Classification of Intrusion in an Intrusion

Detection System Based on Decision Tree Learning

Algorithm[J]. Springer, Singapore. 61-66.

W L AL., Z A O., M Z A N., 2017. Multi-level hybrid

support vector machine and extreme learning machine

based on modified K-means for intrusion detection

system[J]. Expert Systems with Applications, 67:296-

303.

S. S. Roy, A. M., R. G., M. S., Obaidat and P. V. K., 2017.

A Deep Learning Based Artificial Neural Network

Approach for Intrusion Detection. International

Conference on Mathematics and Computing[C].

International Conference on Mathematics and

Computing. Springer.

Y. H., F. A. Shah and M. S., 2018. Wavelet neural network

model for network intrusion detection system[J].

International Journal of Information Technology.

S. M. H. B., H. Wang, T. Yingjie and Y. Shi. 2016. An

effective intrusion detection framework based on

MCLP/SVM optimized by time-varying chaos particle

swarm optimization[J]. Neurocomputing, 199(C):90-

102.

P A., S K P., 2016. A Metric for Ranking the Classifiers for

Evaluation of Intrusion Detection System[J].

Proceedings of the Second International Conference on

Computer and Communication Technologies.

Advances in Intelligent Systems and Computing, vol

380. Springer, New Delhi.

Wang Li, 2018. NKSMOTE Algorithm Based

Classification Method for Imbalanced Dataset.

Computer Science. Vol. 45 No.9.

Han, H., Wang, W., Mao, B., 2005. Borderline−SMOTE:

A New Over−Sampling Method in Imbalanced Data

Sets Learning. International Conference on Intelligent

Computing:878-887.

H Y., K G., Z W., 2016. A Classification Algorithm Based

on Ensemble Feature Selections for Imbalanced-Class

Dataset[C]. IEEE 2nd International Conference on Big

Data Security on Cloud (BigDataSecurity), IEEE

International Conference on High Performance and

Smart Computing (HPSC) and IEEE International

Conference on Intelligent Data and Security (IDS).

A A A., M B I R., 2016. Ensemble of binary SVM

classifiers based on PCA and LDA feature extraction

for intrusion detection[C]. IEEE Advanced Information

Management, Communicates, Electronic and

Automation Control Conference (IMCEC).

Chawla N V, Bowyer K W, Hall L O, et al., 2011 SMOTE:

Synthetic Minority Over-sampling Technique[J].

Journal of Artificial Intelligence Research, 16(1):321-

357.

Wang G P, Yang J X, Li R, 2017. Imbalanced SVM-Based

Anomaly Detection Algorithm for Imbalanced Training

Datasets[J]. ETRI Journal, 39(5):621-631.

P. Lakshmi and D. Geetha, 2016. Intrusion Detection

System using Modified Support Vector Machine[J].

International Research Journal of Engineering Science

and Technology, Vol. 1, No. 1.

Jinxia Wei, Chun Long, Wei Wan, Yurou Zhang, Jing Zhao

and Guanyao Du, 2019. An Effective RF-based

Intrusion Detection Algorithm with Feature Reduction

and Transformation[C]. ICEIS 2019.

Aman Mudgal1, Rajiv Munjal2., 2012. Fuzzy K-Means

Based Intrusion Detection System Using Support

Vector Machine. International Journal of Science and

Research (IJSR) ISSN (Online): 2319-7064 Impact

Factor (2012): 3.358.

Huiwen, Wang, Jie, et al, 2017. An effective intrusion

detection framework based on SVM with feature

augmentation[J]. Knowledge-Based Systems.

A D L., 2016. A hybrid approach to reducing the false

positive rate in unsupervised machine learning

intrusion detection[C]. SoutheastCon 2016. IEEE.

An Effective Parallel SVM Intrusion Detection Model for Imbalanced Training Datasets

231

A B., Guven E, 2015. A Survey of Data Mining and

Machine Learning Methods for Cyber Security

Intrusion Detection[J]. IEEE Communications Surveys

& Tutorials, 18(2):1-1.

B I., Yadav A, Soni A K, 2017. Decision Tree Based

Intrusion Detection System for NSL-KDD Dataset[C].

International Conference on Information and

Communication Technology for Intelligent Systems

(ICTIS 2017). Springer, Cham.

Tavallaee M., Bagheri E., Lu W., Ghorbani A. A., 2009. A

detailed analysis of the KDD CUP 99 data set[C],

Tavallaee M , Bagheri E , Lu W , et al. A detailed

analysis of the KDD CUP 99 data set[C]. IEEE

International Conference on Computational

Intelligence for Security & Defense Applications.

A M V. B., A M.B., 2017. A multi-class classification

MCLP model with particle swarm optimization for

network intrusion detection [J]. Sadhana: Academy

Proceedings in Engineering Science.

Y., L., Weidong, L., Guoqiang, W., 2012. An Intrusion

Detection Approach Using SVM and Multiple Kernel

Method[J]. IJACT: International Journal of

Advancements in Computing Technology 4(1), 463–469

(2012).

Bo Hu, Jinxi Wang, 2019. Dynamic Deep Forest: An

Ensemble Classification Method for Network Intrusion

Detection. Electronics 2019, 8(9), 968.

Chen, T.Q.; Guestrin, C, 2016. XGBoost: A Scalable Tree

Boosting System[C]. Proceedings of the 22nd ACM

SIGKDD International Conference on Knowledge

Discovery and Data Mining. ACM.

A., K.; Purdy, C, 2017. Toward an online anomaly intrusion

detection system based on deep learning[C].

Proceedings of the 2016 15th IEEE International

Conference on Machine Learning and Applications

(ICMLA), Anaheim, CA, USA, 18–20 December 2017;

pp. 195–200.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

232
