Evaluation of Scrum-based Agile Scaling Models for Causes of

Scalability Challenges

Necmettin Ozkan

and Ayca Kolukisa Tarhan

Information Technologies Research and Development Center, Kuveyt Turk Participation Bank, Kocaeli, Turkey

Computer Engineering Department, Hacettepe University, Ankara, Turkey

Keywords: Agile, Software, Scrum, Scale, Model, Framework.

Abstract: Agile Software Development (ASD) community have come up with the idea of scaling and created some

models/frameworks for large-scale set-up. Despite these models, application of agile methods to large projects

remains as a challenging research question for the community. The aim of this work is to evaluate these

Scrum-based scaling models (including SoS, Nexus, LeSS, SAFe, Scrum at Scale, DAD, and RAGE) in terms

of how and to what extent they are able to provide scaling solutions for the identified causes of challenges in

the Agile Manifesto and Scrum Guide, in the context of software development and project management. The

study maps the solution proposals of the models for underlying causes of challenges and justify them with

three experts. To come up with an evaluation, considering the experts’ views, the auditors provide a thorough

perspective on models’ solutions against to the common pain points underlying the manifesto and guide for

scaling. With some exceptions, we see that all of the models try to maintain the pain points associated with

scalability in the core of the ASD.

1 INTRODUCTION

Agile Software Development (ASD) methods were

initially designed and work well for small, co-located

development team settings (Dingsøyr & Moe, 2013;

Costa at al., 2014; Abrahamsson et al., 2003; Hoda et

al., 2010) and there exist claims asserting the ASD

inherently bears inability to scale (Moore & Spens,

2008). In the case of the ASD, experts believe that

large-scale projects are quite different from small-

scale projects regarding issues and challenges that

they face (Dingsøyr & Moe, 2013; Rolland et al.,

2016). Despite the challenges, the charm of being

agile attracts many medium- and even large-sized

organizations (Dingsøyr & Moe, 2014) and more

energy is being put into scaling the ASD across

enterprises (Versionone, 2017). In response to this

need, the ASD community have come up with the idea

of scaling and created some models/frameworks

(hereinafter referred to as the “model”) for large-scale

set-up. Well-known models include SoS (Sutherland,

2001; Schwaber, 2004), Nexus (Schwaber, 2015),

LeSS (Larman & Vodde, 2016), SAFe

https://orcid.org/0000-0001-9876-8728

https://orcid.org/0000-0003-1466-9605

(Leffingwell, 2011), Spotify (Kniberg & Ivarsson,

(2012), Scrum at Scale (Sutherland, 2019), DAD

(Ambler & Lines, 2012), DSDM (DSDM

Consortium, 2014) and RAGE (Thompson, 2016), as

listed on “agilescaling.org”.

The existence of these models does not guarantee

widespread usage or a full spectrum of solutions for

scaling, and the application of agile methods to large

projects remains as a challenging research question for

the community (Dingsøyr & Moe, 2013; Moore &

Spens, 2008). The academic studies providing

evidence on scaling the ASD are still scarce

(Paasivaara & Lassenius, 2014; Meyer, 2014) and it is

challenging to assess whether the scaling models have

indeed properly addressed the issues related to the

scaling (Hobbs & Petit, 2017). In particular, the

number of studies dealing with what kind of causes of

challenges there might be pertaining to the core of the

ASD (referring to what the Agile Manifesto and

Scrum Guide propose) and how the models overcome

the relevant issues is lacking.

The literature on scaling the ASD has been

dominated by consultants (Paasivaara and Lassenius

Ozkan, N. and Tarhan, A.

Evaluation of Scrum-based Agile Scaling Models for Causes of Scalability Challenges.

DOI: 10.5220/0009390403650373

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 365-373

ISBN: 978-989-758-421-3

365

2014; Hobbs & Petit, 2017) and they may easily

evangelize the models with commercial concerns and

it may cause polished success stories and a bias in

evaluation. This calls for a proper independent

evaluation of the subject. The current literature on

scaling also blend issues those coming from the Agile

Manifesto and Scrum Guide (called as the core of the

ASD throughout this study) and implementation-

specific ones. This makes difficult to distinguish the

source of challenges; whether the issue is with how the

Agile Manifesto and Scrum Guide are designed or it

is merely implementation-dependent. This study aims

to become free from implementation-dependent and

context-based challenges by elucidating the factors

that directly affect scalability from design of the

Manifesto and Scrum Guide. This implies the Agile

Manifesto and/or Scrum Guide does not provide

absolute agility, or they are agile at best case for small

scale or a particular context yet not suitable for the

large-scale agility. Thus, our study thus opens gates to

the questioning of the underpinning “sacrosanct”

Agile and Scrum principles for the sake of scaling.

In order to identify the fundamental and

underlying pain points in the core of the ASD

inhabiting the scalability, Ozkan and Tarhan (2019a)

is based on. In that study, the following topics of

causes of challenges related to scalability were

determined: physical dependencies, fragmentation,

short and static events, narrow focus on product,

narrow focus on construction, bottlenecks from one to

many relations.

In term of the models, this study focuses only on

Scrum based models, because of its share of use in the

sector (Versionone, 2017). In parallel, a remarkable

number of the aforementioned models is built on

Scrum and/or supports Scrum. Thus, while

considering agile software development in general

terms through values and principles of the manifesto,

Scrum is preferred to study in particular in this paper.

From this point of view, Spotify that does not

specifically follow Scrum or other common

frameworks and DSDM that proposes a generic

approach to agile project management are kept out of

scope in the study. The remaining models (SoS,

Nexus, LeSS, SAFe, Scrum at Scale, DAD, and

RAGE) are all compatible with Scrum and therefore

included in this study. The research question then was

identified as following:

RQ: How and to what extent do Scrum-based

Agile scaling models address the causes of the

challenges related to the core in the context of

software development and project management?

The remaining of this paper is organized as

follows: Section 2 elaborates related work. Section 3

evaluates the models regarding how and to what extent

they resolve the identified causes of challenges. In

doing so, the study maps the solution proposals of the

models and justify them with three experts for

underlying causes of challenges. In Section 4, with

consideration of the experts’ views, the auditors

provide a thorough discussion on models’ solutions

against to the common pain points underlying the

manifesto and Scrum Guide for scaling. Finally, in

Section 5, we present conclusions and future work.

2 RELATED WORKS

Vaidya (2014) reviews three scaling agile frameworks

(SAFe, LeSS and DAD) from the perspective of their

approaches to roles, processes, and other salient

features. Uludağ et al. (2017) provides primary

information about the methodologists, such as who

invented and published the models, the organizations

that were built upon them, and the scaling, agile

approaches involved, for twenty scaling agile

frameworks including ones in this study. It also

provides a maturity assessment based on number of

case studies, documentation support, training, courses,

certifications, community, etc. Alqudah and Razali

(2016) covers six of the models and compares them in

terms of team size, training, certification, names of

methods and practices adopted, level of technical

practices required and organizational type, along with

their common features mostly based on the existing

literature. Kalenda, Hyna and Rossi (2018) provides

generally known descriptive information content for

the six of the models (SAFe, SoS, LeSS, DAD, Nexus,

RAGE). Ozkan and Tarhan (2019b) reviews nine of the

scaling models including ones in this study in terms of

how they provide scaling.

The current literature focuses on the review of the

models yet our study differently aims to provide an

evaluation of the models, characterized by its distinct

attribute: addressing the models against the identified

causes of the challenges in the core, which is beyond

what the current literature exhibits.

3 ASSESSMENT OF THE

MODELS

In the study of Ozkan and Tarhan (2019a), the

following topics of causes of challenges related to

scalability were determined and briefly mentioned

here:

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

366

Physical Dependencies: The face-to-face

communication mandates, naturally, synchronizing

people in terms of time and place. In this case, abilities

relevant to the past and future decline. Addiction to the

place requires the same place at the same time for all

relevant actors of multiple simultaneous teams and

parties. Declined capability of digitalization with

documentation and tool feeds physical dependencies

and weakens the memory and abilities of reaching for

the long future manifesting as a hindrance in achieving

scalable dimensions on the time axis, inhibiting

flexibility and accompanying scalability.

Fragmentation: Self-management that is a central

principle in agile methods can reduce the ability to

coordinate across teams effectively (Ingvaldsen &

Rolfsen, 2012). While a self-sufficient structure is an

advantage, it may cause the teams to become isolated

from central formations.

Short and Static Events: Each customer need is a

whole and it is, sometimes, not literally dividable into

solid, static and short sprint lengths. The same

difficulty prevails for time boxes of events at the

developer side without a proper and enough “thinking”

stage, especially needed for large-size projects when it

calls for a longer time than what the framework forces.

Narrow Focus on Product: Sticking to its history,

Scrum's roots are nourished mainly by the production

lines logic. However, it is difficult to find a proper

place for a product-oriented approach in the field of

Information Technology that is dominated by a

process, service and a project-oriented approach. With

lack of existence of a project notion, project definition

and project manager, Scrum neglects the (scalable)

project space rather, it distributes a whole (project /

epic) on multiple teams of products.

Narrow Focus on Construction: Questions survive in

Scrum for end-to-end solution development, including

pre- and post-development stages, which leads to some

obstacles to the scalability. Without a big picture,

design development is reduced at the Sprint layer

focusing on the low granularity.

Bottlenecks from One to Many Relations: A single

product owner in Scrum may have to serve with an

ability to reach the scalable dimension horizontally

(systems, people, etc.) and vertically (from strategic to

operational tasks), which may create a throat for

scalability.

The authors went through a deep reading over the

primary resources of the models for the related

solutions approaches that the models provide.

Additionally, the first author made interviews with

three experts self-selected by the author to justify the

claims of the models for solving identified causes of

challenges. The interviewee A (IA) is an Agile

transformation coach with SAFe for two years at an

international company centred in Europe with more

than 460K workers globally. The interviewee B (IB) is

an academician holding a PhD degree from Malaysia

on scaling Agile, with an experience on the subject

since 2009. Interviewee C (IC) is an academician

studying a PhD degree in Germany on scaling Agile

for four years. During the interviews, the causes of

challenges were explained to the interviewees and the

solution approaches of the models to them were asked.

IA included SAFe and LeSS specifically, IC does so

for SAFe, LeSS and SoS and IB delivered information

about the all-aforementioned models in general.

All of the interviewees agree on that “Physical

Dependencies” is a challenge in the large-scale

especially in globally distributed environments. Tools

are essential for Agile in today's realities [IA, IB, IC]

as well as processes [IB]. Thus, the Scrum Guide takes

actions and tries to remove the requirement of

colocation in the last version [IA]. However, even tools

used, face-to-face communication and colocation are

needed to build trust in teams [IA]. To support face-to-

face communication, for example, the video

conference can be used for remote teams [IA, IC].

SAFe and LeSS advocates colocation [IA, IC]. For

instance, in SAFe implementations, POs and SMs

travel frequently, and even, if physical boards are

preferred for two distance locations, two physical copy

of the boards are used to synchronize the two sides

[IA]. LeSS places more emphasis on colocation [than

SAFe] [IA]. The main reason for this is to de-scale and

reduce complexity first for a proper scaling [IA]. In

SoS, [IC] adds, the representatives play a critical role

in communication between multiples teams. In this

kind of exponential scaling there may occur loss of

information [IC]. According to IC, the document

approach in the ASD is largely misinterpreted. He

states, “A lot of information hangs on the wall after

meetings with wide participation. This is a

disadvantage for people who cannot attend to the

meeting. The digital version of the information

reminds of its importance in such situations.”

In terms of “Fragmentation”, IB puts forward the

applied practices of the models is based on Scrum of

Scrums. He mentions that to facilitate inter-team

coordination and communication, some models

propose special roles dedicated to certain domain such

as a designer role. IA advocates in SAFe, there is not

much fragmentation in the model because of the

synchronization and communication mechanism. He

adds, “The program layer provides common backlog

and Program Increment supports co-operation and

transparency between teams. He says in LeSS, there is

only one PO to reduce coordination and

Evaluation of Scrum-based Agile Scaling Models for Causes of Scalability Challenges

367

communication overload. IC mentions, “There are

some practices for multiple teams such as

Communities of Practice and dependency

identification in SAFe. LeSS leaves dependency

management more to the team, to stay simple. It

recommends less meetings”. IC adds that inter-team

and intra-team characteristics of the teams should be in

balance, otherwise, team performance may decrease.

He says, “The team's autonomy is not very possible in

case of dependencies. When Agile leaves its comfort-

zone, different factors and unknown situations emerge

and the models focus on finding solutions in this

regard.”

Within the scope of “Short and Static Events”,

according to IA and IC, the ASD models (including

SAFe, LeSS, SoS) advocates events with time-boxes to

deal with complexity and to build a stable cadence for

predictable systems. IC adds that showing small

portion to customers is useful for feedback even though

it is not possible to end up with a demonstrable

increment in each iteration. IB, on the other hand,

states that decomposability is a tough challenge in

Agile, and developers usually hate time boxing. He

says, “MVP and lean practices can be a solution to it.

For instance, instead of sprint, Kanban uses continues

management of the pipeline with no static iterations,

which is more agile in essence. More and more the

models integrate Kanban in their solutions recently.

Additionally, instead of working with the proxy of the

customer (PO), the actual customer and development

team should be intertwined continuously, as

recommended by XP practices, rather than waiting for

the end of the sprint to extensively touch the actual

customer at one shot.”

For the title of “Narrow Focus on Product”, IA

says, “A thinking by means of the project concept is

not preferred since it constitutes an obstacle to team

spirit in agile approaches.” Being product-oriented has

already existed since very long past, it just came back

to the surface with such streams [IC]. Project is not

preferred because it proposes a temporary structure and

the long-term team formations of teams support to

establish a lasting basis of performance and trust [IA,

IC]. SAFe likewise has a product concept [IA]. He

adds, “The “Value Stream” concept in SAFe seeks to

provide a customer perspective. In this respect, product

should be considered as a value stream. SAFe takes

epic as a project. Instead of a solid DoD, good enough

approach is preferred for epics. Based on the cost of

delay, in accordance with the dynamic value of the

developments in the pipeline, a selection is made”.

However, IB concerns about with a narrow focus on

product, challenges may become possible in the

integration phases.

In terms of “Narrow Focus on Construction”, IB

asserts that in the Agile Manifesto, there are no

sufficient indications for DevOps, continuous

integration and such yet some of the models fill this

blankness. IA states, “Scrum implementations are

getting closer to the reality, such as with Sprint 0

adoption. For the pre-development phases, in SAFe

implementations, value stream is identified. Later on,

systems that will be used and who will use these

systems are determined. What are going to do in the

three-month cycles is addressed and translated to

program backlogs.” SAFe provides DevOps,

Continuous Delivery Pipeline, and Continuous

Integration [IA, IC]. SoS does not provide such post-

development activities [IC]. IC adds that “SoS do not

propose architect roles but SAFe does. LeSS advocates

emergent architecture directed by high-mature teams,

which is somewhat optimistic. In general, up-front and

emergent approaches in design should be in balance.

Contemporary architect roles may contribute to

solution for this. Architects may have a role in

determining road maps and general architectures from

a multiple team perspective, especially in large-

projects. It is important that these architectures and

road maps be not in the long horizon, but in shorter

horizon, simple and adaptive.”

For the “Bottlenecks from One to Many

Relations”, IB states that this challenge can be

overcome with SoS mechanism of product owners at

the different layers like second layer PO and Chief PO

at the top. IA adds that while the main responsibility

at Scrum belongs to the product owner, he/she may

also delegate responsibility for the certain operations to

the team; therefore, the focus of the product owner

should be on value always. However, IC puts forwards

that product owners cannot devote enough time to

operational works. He says, “For this reason, there are

applications that try to support product owners with

additional roles. There are many meetings coming with

the models and the meetings are waived first”. In

LeSS, there is only one PO for a product with the

consideration of less dependency existence [IA]. LeSS

proposes APOs as a sub-division product management

[IC]. In SAFe, chief product owner roles are available

[IA]. He adds that “the product owners work with the

program manager and reports to him/her. This

approach exists to approach to classical structures and

to be easily adaptable of the model by such

organizations. In essence, this layered structure is

against the essence of agility.” Compared to SAFe and

LeSS, there is no suggestion regarding this challenge

in SoS [IC].

The challenge topics, challenge items and related

solution proposals of models according to the authors

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

368

and interviewees come together as in the Table 1. The

added items after considering the interviews is marked

by “*” sign. The shares of the interviewees largely

coincide with the findings of the authors. Some

expressions of the interviewees that support the ideas

promoted by the ASD (such as product-oriented

development, short and static events) are known but

have trade-offs as discussed below.

Table 1: Causes of Challenges and Solution Proposals of Models (*added after considering the interviews).

Challenge Challenge Items Solution Proposals of Models

Physical

Dependencies

Depending on meetings and face-to-face

communication on physical platforms

Lack of digitalization within

documentation and tools

DAD: disciplined by documentation

Fragmentation Inter-team coordination and

communication, individual, isolated,

feudalized and self-organizing teams’

environments

SoS, Nexus, LeSS, SAFe, Nexus, Scrum at Scale,

DAD, RAGE: Clusters of teams/roles conducting

common events

LeSS, SAFe, Nexus: Synchronized events and/or

artifacts

SAFe, DAD: Specific teams/roles with specific

responsibilities

DAD: Non-solo development, collective ownership

Short and Static

Events

Fixing maximum duration and the

frequency of the iterations and meetings

Breaking whole business needs down to

small and solid pieces

DAD: Pre- and post-development stages

Creating a potentially shippable product

in each short and static iteration

Starting counting from (sprint) 1 DAD: Sprint 0 and -1

Overall time planning and design of sub-

parts of sprints/teams/software/solution

Narrow Focus on

Product

Production lines logic with a pure product

concept

DAD: Proposing a generic approach to agile project

management

SAFe: Value stream*

Lack of existence of project notion DAD: Proposing a generic approach to agile project

management

Lack of project definition DAD: Proposing a generic approach to agile project

management

Lack of project manager definition DAD: Project Manager role

Narrow Focus on

Construction

Absence of pre-development phase SAFe: Value stream*

DAD: Disciplined by documentation, pre-

development stages such as Sprint 0 and -1

Absence of post-development phase DAD: Delivery of consumable solutions over just the

construction of working software, transition phase

SAFe: Release Management Team (RMT), DevOps

Team, Continuous Delivery Pipeline, Continuous

Deployment, Continuous Integration

Scrum at Scale: The set of modules includes Release

Planning, Release Management, Product & Release

Feedback

RAGE: Release planning, Dev-Ops roles

Absence of general, top-to-bottom,

upfront design without a big picture

SAFe: System Team, Architect roles such as Solution

Architect, System Architect,

DAD: Architect roles, Inception phase with

lightweight visioning activities including such as

Sprint 0 and -1

Evaluation of Scrum-based Agile Scaling Models for Causes of Scalability Challenges

369

Table 1: Causes of Challenges and Solution Proposals of Models (*added after considering the interviews) (cont.).

Challenge Challenge Items Solution Proposals of Models

Bottlenecks from

One to Many

Relations

A single Product Owner to serve for a

large number of customers and a large

number of development teams at the

same time

LeSS, RAGE: Area Product Owner

DAD, SAFe: Chief Product Owner*

Scrum at Scale: Product Owner Team

Product Owner role for managing a wide

range of issues from operation to strategy

of a product

Table 2: Assessment of the Models with the Causes of the Challenges.

Challenges/Models SoS Nexus LeSS SAFe Scrum at

Scale

DAD RAGE

Physical

Dependencies

Not

achieved

Not

achieved

Not

achieved

Not

achieved

Not

achieved

Partially

achieved

Not

achieved

Fragmentation Partially

achieved

Largely

achieved

Largely

achieved

Largely

achieved

Largely

achieved

Largely

achieved

Partially

achieved

Short and Static

events

Not

achieved

Not

achieved

Not

achieved

Not

achieved

Not

achieved

Partially

achieved

Not

achieved

Narrow Focus on

Product

Not

achieved

Not

achieved

Not

achieved

Partially

achieved

Not

achieved

Fully

achieved

Not

achieved

Narrow Focus on

Construction

Not

achieved

Not

achieved

Not

achieved

Fully

achieved

Partially

achieved

Fully

achieved

Partially

achieved

Bottlenecks from One

to Many Relations

Not

achieved

Not

achieved

Partially

achieved

Partially

achieved

Partially

achieved

Partially

achieved

Partially

achieved

* Rated in the following scale; Not achieved: 0-15%, Partially achieved: 16-50%, Largely achieved: 51-85%, Fully achieved: 86-100%

Despite the solution proposals of the models, it is

noteworthy that there are issues remaining as seen at

Table 2, when compared the identified causes of

challenges and solution proposals of models.

Considering this gap, we evaluated whether the

models are capable of solving the stated causes of

challenges in terms of ratio (solution/challenge) and

Table 2 shows the assessment results (relating to RQ).

4 DISCUSSION

With some exceptions, we see that all of the models

try to maintain the pain points associated with

scalability in the core of the ASD. When viewed

horizontally, it is remarkable that the main and

common concentration of the models is what is

mainly on the hand: teams and their coordination

(Fragmentation). The challenges named as Physical

Dependencies, Short and Static Events and Narrow

Focus on Product are hardly touched. When viewed

vertically, it is seen that the number of models that

can respond, partially or fully, to the causes of

challenges mentioned in this study is few.

For the “Physical Dependencies”, the

interviewees are agreed that the requirement of

colocation is a challenge especially in distributed

environments and tools are needed in the context of

global working environments. However, it seems that

the majority of the models still cling to the

fundamental doctrine of the ASD in this regard.

In terms of “Fragmentation”, we see a significant

effort of the models maintaining the self-organizing

team principles. However, the methods proposed by

the models as well as by the majority of the

interviewees have some inherited trade-offs.

Assuming that teams are able to be self-organized,

difficulty in simultaneously standardizing across and

preserving some local flexibility (Levina & Vaast,

2005) arise two opposing forces for the teams.

Ingvaldsen and Rolfsen (2012) claims that inter-

group coordination is a major challenge when groups

are self-managing and thus, teams’ being self-

organized emerges as a part of the problem when

scaling is required (Rolland, et al., 2016). The

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

370

emergence of dependencies between teams indicates

that the ability of teams to act independently and in a

self-organized manner is not valid. Simply saying, the

goal of being self-organized for each individual team

appears to be in opposition to organizing themselves

with the consideration of other teams. This is

dilemma to overcome for the core in order to support

the large scale.

Regarding the communication perspective,

reminding that team-of-teams issue may be down to

human nature (Lyon & Evans, 2008), it would be

misleading to reduce this issue to the level of formal

mechanisms as proposed by the models. It is an

optimistic approach to solve the communication

issues between teams with the principle of

composition relying on the simplistic view of the

representatives (Rolland, et al., 2016) (dynamic

roles), additional roles (static roles) and/or with a

meetings paradise, as proposed by the models. The

Scrum-of-Scrums meeting is basically the only

practice Scrum offers for inter-team coordination

(Paasivaara & Lassenius, 2011) however, they are

usually inefficient and insufficient for coordinating

teams (Paasivaara & Lassenius, 2014). With the

proposed approach of sending representatives to the

meetings, there are some challenges; the

representative must have the abilities to reach his/her

team's point of view and the boundaries to represent

the cross-functional team in the regarding aspects.

In terms of “Short and Static Events”, even

though the models come with the short iterations and

events with time-boxing to deal with complexity and

to build predictable systems, it can be a source of the

challenge for the large-scale. For instance, the sprint

constraints, with which a single team may have

difficulties, now appear as a common and even bigger

challenge for multiple teams with synchronized sprint

schedules, especially with interdependencies arising

with issues outside the local teams. Similarly,

considered with the time-box limit of sprints, more

meetings of the large-scale solutions may create more

time pressure resulting in the less people participated

in the meetings, as stated by Paasivaara and Lassenius

(2016). Interviewee B advocates MVP and lean

practices, Kanban for continues management of the

pipeline with no static iterations and the actual

customer involvement, as the solutions to short

iterations and time-boxing issues.

For the “Narrow Focus on Product” item, the

models (except DAD) do not prefer a structure with

the project concept, since project is temporary-based

and thus damaging the team spirit. However, the

management of the large-scale initiatives over the

product teams based on static products may require

distributing a whole (of a customer requirement) to

the multiples development teams, if the specific

requirement touches more than one product. This

brings more dependency on static entities (such as

products) and weakens flexibility that reinforces

agility. In the case of Scrum, being depended on the

physical facts and lack of an abstract layer emphasize

the need for project notion to encapsulate and manage

abstract boundaries. We propose using the project

with its unifying and abstracting power. It opens gates

to the possibility of gathering individuals around a

project-specific team, thus removing boundaries

between the product teams during a project rather

than distributing a whole (a project) over teams. Even

with this feature alone, it can be a significant

contributor to solving the inter-team communication

issue, which is the focus of most of the models.

For the “Narrow Focus on Construction” item,

in the core there are no sufficient indications yet some

of the models fill this blankness by adopting Sprint 0,

release management, DevOps, continues delivery,

etc. By definition, we do not consider the preparation

activities the teams conduct before the sprint run as a

solution to this issue. This item covers development-

oriented challenges.

Regarding “Bottlenecks from One to Many

Relations”, the models mainly adds layers and SoS

mechanism for POs, as a linear continuation of the

core.

It seems major factors in the difficulty of the

scalability in the core can rise from two dimensions:

horizontal and vertical. Horizontally, an expansion

spans multiple systems and team boundaries and

vertically (even for a single team), it is the way to

breaking down all incoming customer requirements

throughout the iterations and merging them into the

whole. To cover such an expanded field, most of the

models are satisfied with adding additional roles,

events, artifacts and layers and synchronizing and

integrating sprints of associated teams to provide

coordination between teams. These are what the

Scrum provide: events, roles, artifacts (for a single

team). Thus, the majority of the models provide a

general approach to scaling as a linear continuation of

the core, initially intended for small-scale.

The similar case can be seen in amplifying by

duplication of “the same” (adding more product

owners, product backlogs, meetings etc.) on a

quantitative basis. This is basically because of that

Agile principles seen as axiomatic and sacrosanct,

and tailoring of agile methods is achieved through

adding practices (Rolland, et al., 2016). Addition of

identical or similar practices is easier and default part.

However, “adding” is apparently simple part of the

Evaluation of Scrum-based Agile Scaling Models for Causes of Scalability Challenges

371

“solution” yet it may not work as expected as stated

in the cases by Paasivaara and Lassenius (2011),

Pawlowski and Robey (2004) and Lyon and Evans

(2008). Most of the models present additional roles

for coordination, yet, the majority of the roles focus

on vertical coordination rather than horizontal

coordination. With a similar approach, dividing the

project into “orthogonal” parts works only if the

complexity is of the additive kind (Meyer, 2014),

which is not a usual case in the large-scale. Briefly, a

solution to large-the scale does not simply imply

“more of the same” found in small-scale agile

projects (Robinson & Sharp, 2010).

Additionally, such add-ons can lead to more

complex systems and networks of interdependencies

(Perrow, 1999), which do not suffice and go against

the very idea of agility itself (Rolland, et al., 2016).

Such a mechanism deepens the scaling problem by

reinforcing hereditary constraints related to

scalability in the core. Shortly saying, complex

interdependencies intrinsic to large-scale agile

projects make laying on practices and principles from

small-scale projects problematic (Rolland, et al.,

2016). Different kind of problems associated with

potential “complex interactions” and “tight coupling”

(Perrow, 2011) should be handled in a different way

(Rolland, et al., 2016).

5 CONCLUSION AND FURTHER

WORK

The models have challenges to scale as they try to

establish their solutions on Scrum that has already

created a “sweet spot” (Reifer, Maurer & Erdogmus,

2003) for itself on the small scale in practice. Leaving

this comfort zone to reach scalable areas, by

upgrading the core or not, is necessary if the agility is

assumed to be the right of organizations regardless of

their size. Such challenges in this work may also lead

to questioning the core in terms of scalability and may

imply a call for an endeavour for re-designing or at

least re-reading of the Agile Software Development

Manifesto and Scrum values and principle with

scalability considerations.

There are two main points that the agile scaling

models claim: providing scaling and maintaining

agility even when providing scaling. Assuming that

the models produce solutions for the large-scale, it is

a separate assertion that the models can remain agile

during doing so, with their quite mechanical and rigid

structures as found in some models, making the actual

agility hardly possible. It should be studied as a future

work how much they offer agility at the last point,

especially with their own additions. We will also in

particular propose new scaling models preserving or

not the core of the ASD, primarily and mainly

designed about two decades ago, in the year of 2001

and we will provide possible updates to the core to

come up with solutions supporting more effective

scalability.

REFERENCES

Abrahamsson, P., Warsta, J., Siponen, M. T., & Ronkainen,

J. (2003, May). New directions on agile methods: a

comparative analysis. In Software Engineering, 2003.

Proceedings. 25th International Conference on (pp.

244-254). IEEE.

Alqudah, M., & Razali, R. (2016). A review of scaling agile

methods in large software development. International

Journal on Advanced Science, Engineering and

Information Technology, 6(6), 828-837.

Ambler, S. W., & Lines, M. (2012). Disciplined agile

delivery: A practitioner's guide to agile software

delivery in the enterprise. IBM Press.

Costa, N., Santos, N., Ferreira, N., & Machado, R. J. (2014,

June). Delivering user stories for implementing logical

software architectures by multiple scrum teams. In

International Conference on Computational Science

and Its Applications (pp. 747-762). Springer, Cham.

Dingsøyr, T., & Moe, N. B. (2013). Research challenges in

large-scale agile software development. ACM

SIGSOFT Software Engineering Notes, 38(5), 38-39.

Dingsøyr, T., & Moe, N. B. (2014). Towards principles of

large-scale agile development. In International

Conference on Agile Software Development (pp. 1-8).

Springer, Cham.

DSDM Consortium (2014). DSDM Agile Project

Framework - Handbook. Ashford, Kent, UK: DSDM

Consortium.

Hobbs, B., & Petit, Y. (2017). Agile methods on large

projects in large organizations. Project Management

Journal, 48(3), 3-19.

Hoda, R., Kruchten, P., Noble, J., & Marshall, S. (2010).

Agility in context. ACM Sigplan Notices, 45(10), 74-

88.

Ingvaldsen, J. A., & Rolfsen, M. (2012). Autonomous work

groups and the challenge of inter-group coordination.

Human Relations, 65(7), 861-881.

Kalenda, M., Hyna, P., & Rossi, B. (2018). Scaling agile in

large organizations: Practices, challenges, and success

factors. Journal of Software: Evolution and Process,

30(10), e1954.

Kniberg H. & Ivarsson, A. (2012). Scaling Agile @ Spotify

[Online]. Available: https://blog.crisp.se/wp-content/

.../11/SpotifyScaling.pdf Spotify scaling-agile-spotify-

11.pdf.

Larman, C., & Vodde, B. (2016). Large-scale scrum: More

with LeSS. Addison-Wesley Professional.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

372

Leffingwell, D. (2011). Scaling Agile Framework (SAFe).

[Online] Available: http://

www.scaledagileframework.com/.

Levina, N., & Vaast, E. (2005). The emergence of boundary

spanning competence in practice: implications for

implementation and use of information systems. MIS

quarterly, 335-363.

Lyon, R., & Evans, M. (2008, August). Scaling up pushing

scrum out of its comfort zone. In Agile, 2008.

AGILE'08. Conference(pp. 395-400). IEEE.

Meyer, B. (2014). Agile: The Good, the Hype and the Ugly.

Switzerland: Springer International Publishing.

Moore, E., & Spens, J. (2008, August). Scaling agile:

Finding your agile tribe. In Agile, 2008. AGILE'08.

Conference (pp. 121-124). IEEE.

Ozkan, N., & Tarhan, A. K. (2019a). Investigating Causes

of Scalability Challenges in Agile Software

Development from a Design Perspective. In 2019 1st

International Informatics and Software Engineering

Conference (UBMYK), pp. 1-6. IEEE.

Ozkan, N., & Tarhan, A. (2019b). A Review of Scaling

Approaches to Agile Software Development Models.

Software Quality Professional, 21(4), 11-20.

Paasivaara, M., & Lassenius, C. (2011, September). Scaling

scrum in a large distributed project. In Empirical

Software Engineering and Measurement (ESEM), 2011

International Symposium on (pp. 363-367). IEEE.

Paasivaara, M., & Lassenius, C. (2014). Communities of

practice in a large distributed agile software

development organization–Case Ericsson. Information

and Software Technology, 56(12), 1556-1577.

Paasivaara, M., & Lassenius, C. (2016, August). Scaling

scrum in a large globally distributed organization: a

case study. In Global Software Engineering (ICGSE),

2016 IEEE 11th International Conference on (pp. 74-

83). IEEE.

Pawlowski, S. D., & Robey, D. (2004). Bridging user

organizations: Knowledge brokering and the work of

information technology professionals. MIS quarterly,

645-672.

Perrow, C. (1999). Organizing to reduce the vulnerabilities

of complexity. Journal of contingencies and crisis

management, 7(3), 150-155.

Perrow, C. (2011). Normal Accidents: Living with High

Risk Technologies-Updated Edition. Princeton

university press.

Reifer, D. J., Maurer, F., & Erdogmus, H. (2003). Scaling

agile methods. IEEE software, 20(4), 12-14.

Robinson, H., & Sharp, H. (2010). Collaboration,

communication and co-ordination in agile software

development practice. In Collaborative software

engineering (pp. 93-108). Springer, Berlin, Heidelberg.

Rolland, K.H., et al. (2016). Problematizing agile in the

large: alternative assumptions for large-scale agile

development.In Thirty Seventh International

Conference on Information Systems. Dublin.

Schwaber, K. (2004). Agile Project Management with

Scrum. Microsoft Press, Redmond, Washington, USA.

Schwaber, K. (2015). Nexus Guide. The Definitive Guide

to Nexus: The exoskeleton of scaled Scrum

development. PDF). scrum.org.

Sutherland, J. (2001). Inventing and Reinventing SCRUM

in five Companies. Sur le site officiel de l'alliance agile.

Sutherland, J. (2019). SCRUM@Scale Guide. The

Definitive Guide to Scrum@Scale: Scaling that Works.

Thompson, K. (2016). Rage – recipes for agile governance

in the enterprise. [Online]. Available: https://

www.cprime.com/rage/.

Uludağ, Ö., Kleehaus, M., Xu, X., & Matthes, F. (2017).

Investigating the role of architects in scaling agile

frameworks. In Enterprise Distributed Object

Computing Conference (EDOC), 2017 IEEE 21st

International

(pp. 123-132). IEEE.

Vaidya, A. (2014). Does dad know best, is it better to do

less or just be safe? adapting scaling agile practices into

the enterprise. PNSQC. ORG, 1-18.

Versionone. (2017). 9th annual state of agile survey.

Technical report, Version One.

Evaluation of Scrum-based Agile Scaling Models for Causes of Scalability Challenges

373
