Empirical Study about Class Change Proneness Prediction using

Software Metrics and Code Smells

Antonio Diogo Forte Martins, Cristiano Melo, Jos

e Maria Monteiro and Javam de Castro Machado

Federal University of Ceara, Fortaleza, Ceara, Brazil

Keywords:

Machine Learning, Change-proneness Prediction, Software Quality.

Abstract:

During the lifecycle of software, maintenance has been considered one of the most complex and costly phases

in terms of resources and costs. In addition, software evolves in response to the needs and demands of the

ever-changing world and thus becomes increasingly complex. In this scenario, an approach that has been

widely used to rationalize resources and costs during the evolution of object-oriented software is to predict

change-prone classes. A change-prone class may indicate a part of poor quality of software that needs to

be refactored. Recently, some strategies for predicting change-prone classes, which are based on the use of

software metrics and code smells, have been proposed. In this paper, we present an empirical study on the

performance of 8 machine learning techniques used to predict classes prone to change. Three different training

scenarios were investigated: object-oriented metrics, code smells, and object-oriented metrics and code smells

combined. To perform the experiments, we built a data set containing eight object-oriented metrics and 32

types of code smells, which were extracted from the source code of a web application that was developed

between 2013 and 2018 over eight releases. The machine learning algorithms that presented the best results

were: RF, LGBM, and LR. The training scenario that presented the best results was the combination of code

smells and object-oriented metrics.

1 INTRODUCTION

During the development and lifespan of software,

maintenance is considered one of the most arduous

and expensive tasks (Koru and Liu, 2007). Soft-

ware systems evolve in response to the needs and re-

quirements of a dynamic and ever-changing world.

Hence, a change may occur due to bugs, new fea-

tures, code refactoring, or adoption of new technolo-

gies. Throughout its evolution, software becomes

larger and more complex (Koru and Liu, 2007). Thus,

manage and control changes is one of the most con-

cerns of the software development industry. During

a software system evolution, it is impractical for the

development team to focus equally on all parts of the

system (Elish and Al-Rahman Al-Khiaty, 2013).

The quality of software may decrease over time

due to different factors, such as aging, inconsistent

design, and inadequate requirements design. In soft-

ware engineering, the study about code smells is re-

cent and is gaining importance to analyze different

aspects of software quality, because they may point

out problems related to structure, efﬁciency, maintain-

ability, and readability of code (Fowler, 2018). Any-

how, even if a code smell does not represent a bug di-

rectly, because they are not technically incorrect and

do not interfere in the code execution, they should not

be ignored, because they may compromise the soft-

ware quality and then lead to larger problems (Singh

and Chopra, 2013).

In this context, a change prone class can be de-

ﬁned as a class that probably will suffer alterations

for the next software release, representing a part of

low quality of the system. Therewith, the capability

of performing a prediction of a class change prone-

ness may be handy to guide the software development

team, because, with this information, they can better

allocate resources, allowing project managers to focus

their efforts and attention on these classes during the

evolution process of a software system (Elish et al.,

2015).

Although many works make use of machine learn-

ing techniques to predict class change proneness, no

practical guide had been proposed to assist software

engineers in using these techniques properly and be

able to extract correct conclusions from the results.

In (Melo. et al., 2019), the authors, recognizing the

urgency of methodology standardization for the task

140

Martins, A., Melo, C., Monteiro, J. and Machado, J.

Empirical Study about Class Change Proneness Prediction using Software Metrics and Code Smells.

DOI: 10.5220/0009410601400147

In Proceedings of the 22nd Inter national Conference on Enterprise Information Systems (ICEIS 2020) - Volume 1, pages 140-147

ISBN: 978-989-758-423-7

of class change proneness prediction, propose a com-

prehensive practical guide to help make predictions

methodologically correct. The practical guide con-

sists of a list of minimal activities, from proper data

set construction to perform predictions, that must be

executed to optimize the performance of the class

change proneness classiﬁer.

The objective of the following paper is, using

the methodology based on the practical guide pro-

posed in (Melo. et al., 2019), build an appropriate

data set to perform class change proneness prediction

with 8 object-oriented metrics and 32 types of code

smells, empirically examine the performance of ma-

chine learning techniques in the task of class change

proneness prediction, and evaluate the techniques in

three scenarios of training: only object-oriented met-

rics, only code smells, and a combination of object-

oriented metrics with code smells.

2 RELATED WORK

In (Kaur et al., 2016), the authors compare the perfor-

mance of object-oriented software metrics and code

smells when used as features to train machine learn-

ing algorithms to perform class change proneness pre-

diction in an imbalanced data set. The authors used

eight machine learning algorithms e to balance the

data set they used SMOTE for over-sampling and

RUS for under-sampling. The authors chose AUC

and F-score metrics to evaluate the performance of

the classiﬁers. According to their experiments, when

trained with code smells, the classiﬁers achieve better

performance than when trained with object-oriented

software metrics. The authors conducted experiments

with both imbalanced and balanced data, and classi-

ﬁers trained with code smells performed better in both

scenarios.

In (Catolino et al., 2019), the authors investigate

the effect of adding a new metric, called the intensity

index of a code smell, to three sets of metrics used to

perform the task of class change proneness prediction

found in the literature. The value assigned to this in-

dex is equivalent to how much the metric evaluated to

detect a code smell exceeds the limit set by the rule,

normalized between 0 and 10. The authors use a clas-

siﬁer that uses the LR algorithm and train it separately

with each set of metrics. After taking these results as a

baseline, they train once again by adding the intensity

index as a feature and evaluate its effect. The chosen

performance metrics were AUC, F-score, sensitivity,

and speciﬁcity. After analysis, the authors state that

performance in class change proneness prediction is

statistically better after adding the intensity index to

the features. In the end, they merge all metric sets

and intensity index into one single data set and retrain

the classiﬁer obtaining the best prediction result.

In (Melo. et al., 2019), the authors propose a prac-

tical guideline to support an object-oriented change-

prone class prediction. The practical guide consists

of good practices that must be adopted to properly

perform class change proneness prediction since the

authors identiﬁed several possibly misleading results

in the literature for not performing activities consid-

ered crucial by them. The authors present in detail all

the activities that must be performed from the data set

design to the class change proneness prediction and,

in the end, carry out a case study replicating the activ-

ities step by step. The authors conclude that the prac-

tical guide can be used as a standard minimum activ-

ity list to develop class change proneness classiﬁers

optimally. The case study performed to validate the

method is based on an extremely imbalanced data set

extracted from commercial software containing eight

object-oriented metrics proposed by (Chidamber and

Kemerer, 1994) and (McCabe, 1976).

3 METHODOLOGY

The methodology of this work was based on the prac-

tical guide proposed in (Melo. et al., 2019). The prac-

tical guide is designed to support class change prone-

ness prediction. It contains a comprehensive step-by-

step that covers all the steps necessary to build a use-

ful data set and the correct way to make predictions.

3.1 Phase 1: Data Set Design

The ﬁrst phase of the practical guide focuses on the

data set design that will be used to perform class

change proneness predictions. This phase consists

of the following steps: Choose Independent Variable,

Choose Dependent Variable, and Collect Metrics.

3.1.1 Choose Independent Variable

We chose the independent variables, also known as

predictors or features, taking into consideration the

metrics found in the literature. The papers that study

class change proneness prediction use the metrics pro-

posed by (Chidamber and Kemerer, 1994) and (Mc-

Cabe, 1976), which are metrics capable of quantify-

ing structural aspects of a class in object-oriented ab-

straction.

We decided to use the following object-oriented

metrics: Class Between Object (CBO), Cyclomatic

Complexity (CC), Depth of Inheritance Tree (DIT),

Empirical Study about Class Change Proneness Prediction using Software Metrics and Code Smells

141

Lines Of Code (LOC), Number Of Children (NOC)

and Weighted Methods per Class (WMC). In addition,

we decided to use code smells as metrics, too, because

they are also a feature of a class.

3.1.2 Choose Dependent Variable

Also known as the label, we chose to be the dependent

variable the change proneness of a class. A class is

said change prone if it has changed from one release

to another, the parameter used to know if this change

occurred is by checking the value of LOC in the two

releases (Lu et al., 2012). If there has been a change,

label 1 is assigned. If not, label 0 is assigned to the

class under analysis.

3.1.3 Collect Metrics

We use in this paper a data set generated from the

source code of a web application that was devel-

oped between 2013 and 2018. We analyzed the class

change proneness of 8 releases of the application.

This application is a collection of modules that man-

age the needs of a company concerning its internal

processes, such as product return control and product

quality management.

The object-oriented metrics of the application is

available in a public GitHub repository (Melo. et al.,

2019)

. The metrics were extracted from the source

code using a Visual Studio plug-in called NDepends

(NDpends, 2018). NDepends is a static analysis tool

for C# code. In addition to other features, this tool

has a speciﬁc one called CQLinq that allows the user

to recover attributes and metrics by writing queries.

The authors wrote and executed the CQLinq queries

to precisely extract all the metrics available in their

data set. The ﬁnal data set is available as a csv ﬁle

containing the metrics of each class in each release.

We performed the code smells extraction using the

Designite tool (Sharma, 2016). This tool detects code

smells in C# code and other relevant metrics, for in-

stance, code smells density and number of classes in

a project. We found 32 types of code smells after an-

alyzing all the classes from all eight releases.

When the Designite tool analyzes a project, in

our case, one release of the application, it generates

object-oriented metrics and code smells reports. The

code smells report is divided into three levels of gran-

ularity: Architecture (namespace), Design (class),

Implementation (method). These reports are exported

as a csv ﬁle being one ﬁle for each level. We devel-

oped Python scripts to organize and join all the ﬁles

in a single csv per release.

https://github.com/cristmelo/PracticalGuide

Although there is a difference in granularity be-

tween the code smells types, the tool always asso-

ciates the code smell occurrence to a class, for in-

stance, if an Architecture code smell is identiﬁed,

the tool is capable of point which classes inside the

namespace are responsible for this occurrence. There-

fore the classes in question will account for one oc-

currence of this code smell. We used the same oc-

currence extraction logic for the Implementation code

smells, since the tool tell us in which class the method

that has a code smell belong.

After we ﬁnish the two data sets, we had to join

the two to build the complete data set with the object-

oriented metrics and code smells for each class. Cre-

ating isolated small data sets for each release facili-

tated the construction of the ﬁnal set, as we ensured

that if a class appears in more than one release, the

object-oriented metrics and code smells were of the

same release for a given class. In the end, we con-

catenated the eight isolated releases data sets forming

a ﬁnal set with all class of all releases with their re-

spective features containing a total of 11576 classes.

3.2 Phase 2: Apply Class Change

Proneness Prediction

The second phase of the practical guide focuses on

developing class change proneness prediction mod-

els. We treated the class change proneness prediction

problem as a classiﬁcation problem and we used algo-

rithms that work via supervised learning. This phase

of the practical guide also indicates what the best per-

formance metrics are, how to present results, and how

to ensure the reproducibility of experiments.

3.2.1 Statistical Analysis

First, we performed a statistical analysis to extract rel-

evant information about how object-oriented software

metrics and code smells behave in the data set built at

the end of Phase 1. Table 1 shows the descriptive sta-

tistical data for object-orientated software metrics.

The information in Table 1 is essential for under-

standing the domain of variables, whether they are

discrete or continuous variables, and notions of their

distributions. We did not include descriptive statisti-

cal data about code smells as they are mostly binary

data. In the paper repository, it is possible to visualize

the data in detail.

After analyzing the data distribution, we could

highlight the large number of zero values that the met-

rics have. In the case of the code smells, the fact that

there are many zeros is that most of these code smells

are already avoided by the use of development tools

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

142

Table 1: Descriptive Statistics.

Metric Min. Max Avg. Median Std. Dev. Kurtosis Skewness

CBO 0 162 5.73 3 9.57 32.4 4.43

CC 0 488 12.27 7 22.15 103.37 7.99

DIT 0 7 0.73 0 1.60 6.85 2.63

LCOM 0 1 0.14 0 0.27 0.82 1.55

LOC 0 1369 25.40 12 66.49 122.32 9.44

NOC 0 189 0.44 0 5.19 409.06 18.57

RFC 0 413 7.05 1 18.96 79.11 7.31

WMC 0 56 1.23 0 3.24 77.39 7.26

and good programming practices (de Almeida Filho

et al., 2019).

3.2.2 Normalization and Outlier Detection

As stated in Section 3.2.1, the features of the con-

structed data set have very different domains. For

instance, the metric LOC has values between 0 and

1369, while LCOM varies between 0 and 1. When

faced with such situations where metrics are at dif-

ferent scales, it is interesting to normalize the data so

that the models to be trained are not biased because of

this difference.

In this paper, we normalized all the features,

object-oriented software metrics and code smells, us-

ing the min-max normalization technique. When us-

ing this technique, all features will have their mini-

mum value set to 0 and their maximum value set to

About outliers detection and removal, in this pa-

per, because the data distribution shows that there are

many zeros and the averages have low values, we de-

cided not to remove the outliers.

3.2.3 Feature Selection

First, we performed feature selection only on the

object-oriented software metrics. The selected fea-

tures are the same proposed by the practical guide

(Melo. et al., 2019), because they are the same met-

rics from the same analyzed data set. The eight met-

rics were submitted to ﬁve feature selection tech-

niques: Chi-Square, One-R, Information Gain, Sym-

metrical Uncertainty, and Correlation Analysis.

In (Melo. et al., 2019), the authors deﬁned a cri-

terion to choose the features from the results of the

four ﬁrst techniques. They ordered the results and the

best-evaluated metric received 8 points and the worst

1 point. The metrics with the total number of points

higher than half of the maximum were selected. Five

metrics had the total number of points inside the lim-

its, but CBO and RFC have Pearson’s correlation co-

efﬁcient of 0.87, in other words, they are strongly cor-

related, then the chosen metric was CBO because it

had a higher total number of points than RFC. Lastly,

the authors selected four metrics: CBO, WMC, CC,

and LCOM.

In the case of feature selection for code smells,

we performed an analysis using PCA (Abdi and

Williams, 2010). We applied the technique on the

group of code smells of the same level, i.e., the 32

features of code smells found were reduced to only

three features. However, this approach worse results

than using the 32 features. After analysis, we selected

all 32 features as necessary, because each one rep-

resents particular and peculiar characteristics of the

source code.

In the end, the features selected to be used in

the prediction model were the 32 found code smells

and the object-oriented software metrics CBO, WMC,

CC, and LCOM.

3.2.4 Data Balancing Techniques

First, we need to analyze the change prone labels pro-

portion to check if it will be necessary to use any data

balancing technique. As we stated before if a class

has label 1 it is because this class is change prone. If

it is not, it will receive the label 0. Our data set is ex-

tremely imbalanced, 11263 classes have the label 0,

while, only 313 have label 1, i.e., only 2.7% of the

analyzed classes are change prone.

Using an imbalanced data set to train classiﬁcation

algorithms can lead to misclassiﬁcation as the classi-

ﬁer may be biased and not correctly classify instances

of the minority label (Melo. et al., 2019). In real

machine learning problems, most data sets are imbal-

anced and the label of interest for classiﬁcation is usu-

ally minority one.

The practical guide suggests using data under-

sampling and over-sampling techniques to solve

the imbalance problem. Under-sampling tech-

niques: Random UnderSampler (RUS), Edited Near-

est Neighbours (ENN) (Wilson, 1972), and Tomek’s

Empirical Study about Class Change Proneness Prediction using Software Metrics and Code Smells

143

Link (TL) (Tomek, 1976). Over-sampling tech-

niques: Synthetic Minority Over Sampling Technique

(SMOTE) (Chawla et al., 2002), Adaptive Synthetic

Sampling (ADASYN) (He et al., 2008), and Random

OverSampler (ROS). To assist in performing this step

of the practical guide, we used the Python library

Imbalanced-Learn (Lema

ıtre et al., 2017). It is es-

sential to emphasize that balancing techniques should

be applied only to the training set.

3.2.5 Cross-Validation

There are many Cross-Validation techniques, but the

most used, and the one we applied in this paper is

the k-fold Cross-Validation. This technique consists

of split the data set in k equal parts. With these sub-

sets, the model is trained in k different rounds, in each

round, one of the subsets is previously separated as

the test set, and the rest is used for training. At the

end of the k rounds, we calculate the average value of

the results to evaluate the performance of the model.

In our paper, we use ten as value for k, as the practi-

cal guideline suggests (Melo. et al., 2019). To ensure

that the data is split into subsets keeping the labels

proportion, we used the scikit-learn function Strati-

ﬁedKFold.

3.2.6 Tuning the Prediction Model

In this paper, we used the following machine learning

algorithms: Logistic Regression (LR), Support Vector

Machine (SVM), Decision Tree (DT), Random For-

est (RF), K-Nearest Neighbours (KNN), Light Gradi-

ent Boost Machine (LGBM), and eXtreme Gradient

Boost Machine (XGB).

The scikit-learn Python library implements all

the used algorithms, except LGBM and XGB that

have their library. All these algorithms have hyper-

parameters, which, if properly adjusted and well se-

lected, can improve the algorithm results (Melo. et al.,

2019).

In this paper, we used the Grid Search as the

method of search and evaluation of the hyper-

parameters. We chose the vectors arbitrarily, as pre-

viously mentioned, the model tuning process is a trial

and error work.

Since we use Grid Search, it is necessary to

use the nested Cross-Validation technique to esti-

mate the model generalization with the chosen hyper-

parameters, as suggests the practical guide (Melo.

et al., 2019).

3.2.7 Selection of Performance Metrics

For classiﬁcation problems the most commonly used

performance metrics are: accuracy, precision, sensi-

bility, speciﬁcity, F-score and AUC. The confusion

matrix also gives a notion of how the model per-

formed the classiﬁcation.

In the case of this paper, where the data set is im-

balanced, the practical guide (Melo. et al., 2019) rec-

ommends using either F-score or AUC, as they take

into account the correct classiﬁcation of the minor-

ity class. We decided to use AUC as the main per-

formance metric, but the other metrics were also col-

lected.

3.2.8 Ensure the Reproducibility

The practical guide(Melo. et al., 2019) suggests that

the authors of scientiﬁc papers ensure that their work

can be reproduced and used as a basis for future work.

To this end, the data set created at the end of Phase 1,

statistical analysis for code smells and object-oriented

software metrics, Jupyter Notebooks with the experi-

ments already executed and the results of the evalua-

tion of the trained models are organized and available

in a repository on GitHub

4 RESULTS AND DISCUSSION

At the experimentation step, we deﬁned three training

scenarios for the machine learning algorithms. The

ﬁrst trains the algorithms using only object-oriented

software metrics. The second one train the algorithms

using only code smells. Lastly, the third scenario

uses both object-oriented software metrics and code

smells as features. In all three scenarios, all the ex-

periments were performed using the same steps de-

scribed in Section 3.2.

Tables 2, 3, 4 show the 10 best results after the

execution of the nested cross-validation process for

each algorithm using the data set imbalanced, sub-

sampled, and over-sampled having as features the

ones deﬁned for the scenario 1, 2, and 3 respectively.

The values presented are the average value of AUC

after the 10 rounds of nested cross-validation and also

the standard deviation values for the execution.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

144

Table 2: Results for nested Cross-Validation - Only object-oriented software metrics - 10 best classiﬁers.

Algorithm Balancing Tech. AUC (%) Std. Dev. (%)

RF RUS 73.3 2.8

LGBM ROS 72.7 3.3

LGBM RUS 72.5 4.2

LGBM SMOTE 71.7 2.3

LR SMOTE 71.5 3.3

LR ROS 71.4 3.2

XGB RUS 71.3 3.5

LR ADASYN 71.2 3.2

LGBM ADASYN 71.1 3.3

KNN RUS 71 3.9

4.1 Only Object-oriented Software

Metrics

We can observe that classiﬁers using the LGBM al-

gorithm ﬁgure 4 times between the 10 best-evaluated

classiﬁers using the three over-sampling techniques

and the under-sampling technique RUS. The classi-

ﬁer with the better average value of AUC found in our

experiments was RF trained with data under-sampled

by RUS. Classiﬁers based on the LR algorithm trained

with data over-sampled with the three techniques are

also in the 10 best. It is interesting to highlight that

the most straightforward algorithm, KNN, ﬁgure as

the tenth best classiﬁer when trained with data under-

sampled by RUS.

Classiﬁers trained with over-sampled data ﬁgured

more in the 10 best classiﬁers than the ones trained

with under-sampled data in scenario 1. Furthermore,

out of three under-sampling techniques, only RUS

achieved good results.

4.2 Only Code Smells

From the results, we can observe that classiﬁers using

LR with the three over-sampling techniques and the

under-sampling technique RUS are present in the 10

best-evaluated classiﬁers, being the classiﬁer that uses

LR trained with data over-sampled by ROS the best in

scenario 2.

The classiﬁers that use LGBM and over-sampled

data are also present among the best 10 classiﬁers.

The classiﬁer using RF trained with data under-

sampled by RUS is also ﬁguring in the best classi-

ﬁers for this scenario. The classiﬁers that use XGB

trained both with data under-sampled by RUS and

over-sampled by ROS are among the best for scenario

https://github.com/diogofm/TCC-ChangeProneness

Prediction

4.3 Code Smells and Object-oriented

Software Metrics

In scenario 3, the classiﬁer trained with the RF algo-

rithm and using the RUS under-sampling technique

was again the best-evaluated classiﬁer. The classi-

ﬁers trained with the LGBM and LR algorithms us-

ing over-sampling techniques are among the 10 best-

evaluated classiﬁers models, highlighting the over-

sampling technique ROS that made the algorithms

have better performance in our experiments. The al-

gorithm DT ﬁgures for the ﬁrst time among the best

classiﬁers when trained with data over-sampled by

ROS.

4.4 Discussion

As expected, the classiﬁers trained with imbalanced

data did not perform well in our experiments, because

the algorithms would be exposed to a few observa-

tions of the minority class and would not be able

to classify well. Similarly, the TL and ENN under-

sampling techniques did not achieve satisfactory re-

sults, because these techniques are distance-based,

depending on the data set, they do not balance cor-

rectly, and this fact could be veriﬁed in our experi-

ments because when these techniques were used the

data set remained highly imbalanced.

Scenario 2 classiﬁers, trained only with code

smells, achieved the worst performance among the

three scenarios. No classiﬁer reached an average

value of AUC after the 10 rounds of nested cross-

validation greater than 70%, which is the value, gen-

erally, considered to be an acceptable performance

threshold for a classiﬁer.

The classiﬁers trained in scenarios 1 and 3 showed

the best performance in predicting class change

proneness. Object-oriented software metrics when

used to train the classiﬁers, scenario 1, allowed sim-

Empirical Study about Class Change Proneness Prediction using Software Metrics and Code Smells

145

Table 3: Results for nested Cross-Validation - Only code smells metrics - 10 best classiﬁers.

Algorithm Balancing Tech. AUC (%) Std. Dev. (%)

LR ROS 68.8 3.6

LR ADASYN 68.7 4.1

LGBM ROS 68.7 4.4

LR SMOTE 68.6 4.5

RF RUS 68.6 4.3

XGB ROS 67.9 3.8

LR RUS 67.9 4.2

LGBM SMOTE 67.3 4.5

XGB RUS 67.2 4.4

LGBM ADASYN 67.1 3

Table 4: Results for nested Cross-Validation - Object-oriented software metrics and code smells metrics - 10 best classiﬁers.

Algorithm Balancing Tech. AUC (%) Std. Dev. (%)

RF RUS 73.5 3.7

LGBM ROS 73.4 3.1

LGBM RUS 72.8 2.9

LR ROS 72.5 4.2

LR ADASYN 71.5 3.5

LR SMOTE 71.1 4.1

LGBM ADASYN 70.8 3.4

LGBM SMOTE 70.6 3.7

DT ROS 70.6 2.8

LR RUS 70.3 4.1

ple classiﬁers, such as KNN and LR, to achieve good

average value of AUC after the 10 rounds of nested

cross-validation.

The addition of the code smells to the object-

oriented software metrics improved the performance

of some classiﬁers. For instance, the best classiﬁer

in scenario 1 remained the best in scenario 3, the RF

algorithm trained with data under-sampled by RUS.

It had a 0.2% improvement in the average value of

AUC. It is also essential to highlight the performance

improvement of the classiﬁer that uses the DT algo-

rithm trained with data over-sampled by ROS since

when trained only with object-oriented metrics, the

classiﬁer did not even ﬁgure among the 10 best, the

performance increase was of 9.5%.

The fact that the performance of the classiﬁers

trained in scenario 2 was below acceptable threshold

conﬂicts with the results found by (Kaur et al., 2016),

where the authors state that code smells are better pre-

dictors than object-oriented software metrics. Our ex-

periments showed that the code smells collected for

this particular software and detected by the Designite

tool were poor predictors, but when combined with

the object-oriented software metrics, they were able

to achieve a signiﬁcant performance increase.

5 CONCLUSION

In this paper, we presented an empirical study about

the performance of 8 machine learning techniques

while performing the task of class change proneness

prediction. We have proposed three training scenarios

using a data set containing eight object-oriented soft-

ware metrics and 32 types of code smells extracted

from the source code of a web application that had

its development between 2013 and 2018, having eight

releases following the activities of the practical guide

proposed by (Melo. et al., 2019).

From the results of the experiments, we concluded

that using our data set, when training in the scenario

3 that uses both object-oriented software metrics and

code smells combined, the class change proneness

prediction classiﬁers achieve better performance than

when trained with object-oriented metrics and code

smells separate. The classiﬁer that uses RF as the

machine learning technique trained with data under-

sampled by the RUS technique was the best in our ex-

periments achieving the average value of AUC after

the 10 rounds of nested cross-validation of 73.5%, in

scenario 3. Also, in scenario 3, LGBM has presented

good results achieving the average value of AUC af-

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

146

ter the 10 rounds of nested cross-validation of 73.4%

when trained with data over-sampled by ROS tech-

nique.

In summary, for the case of the data set con-

structed during the paper and used for the experi-

ments, code smells alone are not good class change-

proneness indicators as object-oriented software met-

rics. However, when combined, they can lead to good

results, increasing the performance of machine learn-

ing algorithms. Furthermore, the best performing ma-

chine learning techniques, based on the average value

of AUC after the 10 rounds of nested cross-validation

and algorithm simplicity, were RF, LGBM, and LR.

As future work, there are several possibilities and

different approaches to be investigated. From the

point of view of the data set design, one approach

would be adding new software metrics such as evolu-

tionary (Elish and Al-Rahman Al-Khiaty, 2013) and

intensity index of a code smell (Catolino et al., 2019).

Moreover, for the class change proneness prediction,

it is viable to test another machine learning and deep

learning techniques and use more modern and elabo-

rate methods to create synthetic training data.

ACKNOWLEDGEMENTS

This research was funded by LSBD/UFC.

REFERENCES

Abdi, H. and Williams, L. J. (2010). Principal component

analysis. WIREs Comput. Stat., 2(4):433–459.

Catolino, G., Palomba, F., Fontana, F. A., Lucia, A. D.,

Zaidman, A., and Ferrucci, F. (2019). Improving

change prediction models with code smell-related in-

formation. CoRR, abs/1905.10889.

Chawla, N. V., Bowyer, K. W., Hall, L. O., and Kegelmeyer,

W. P. (2002). Smote: Synthetic minority over-

sampling technique. Journal of Artiﬁcial Intelligence

Research, 16:321–357.

Chidamber, S. R. and Kemerer, C. F. (1994). A metrics

suite for object oriented design. IEEE Trans. Softw.

Eng., 20(6):476–493.

de Almeida Filho, F. G., Martins, A. D. F., Vinuto, T. d. S.,

Monteiro, J. M., de Sousa, I. P., de Castro Machado,

J., and Rocha, L. S. (2019). Prevalence of bad smells

in pl/sql projects. In Proceedings of the 27th Interna-

tional Conference on Program Comprehension, ICPC

’19, pages 116–121, Piscataway, NJ, USA. IEEE

Press.

Elish, M., Aljamaan, H., and Ahmad, I. (2015). Three em-

pirical studies on predicting software maintainability

using ensemble methods. Soft Computing, 19.

Elish, M. O. and Al-Rahman Al-Khiaty, M. (2013). A

suite of metrics for quantifying historical changes to

predict future change-prone classes in object-oriented

software. Journal of Software: Evolution and Process,

25(5):407–437.

Fowler, M. (2018). Refactoring: improving the design of

existing code. Addison-Wesley Professional.

He, H., Bai, Y., Garcia, E. A., and Li, S. (2008). Adasyn:

Adaptive synthetic sampling approach for imbalanced

learning. In 2008 IEEE International Joint Confer-

ence on Neural Networks (IEEE World Congress on

Computational Intelligence), pages 1322–1328.

Kaur, A., Kaur, K., and Jain, S. (2016). Predicting software

change-proneness with code smells and class imbal-

ance learning. In 2016 International Conference on

Advances in Computing, Communications and Infor-

matics (ICACCI), pages 746–754.

Koru, A. G. and Liu, H. (2007). Identifying and charac-

terizing change-prone classes in two large-scale open-

source products. Journal of Systems and Software,

80(1):63 – 73.

Lema

ıtre, G., Nogueira, F., and Aridas, C. K. (2017).

Imbalanced-learn: A python toolbox to tackle the

curse of imbalanced datasets in machine learning.

Journal of Machine Learning Research, 18(17):1–5.

Lu, H., Zhou, Y., Xu, B., Leung, H., and Chen, L.

(2012). The ability of object-oriented metrics to pre-

dict change-proneness: a meta-analysis. Empirical

Software Engineering, 17(3).

McCabe, T. J. (1976). A complexity measure. IEEE Trans-

action on Software Engineering.

Melo., C. S., da Cruz., M. M. L., Martins., A. D. F., Matos.,

T., da Silva Monteiro Filho., J. M., and de Cas-

tro Machado., J. (2019). A practical guide to support

change-proneness prediction. In Proceedings of the

21st International Conference on Enterprise Informa-

tion Systems - Volume 2: ICEIS,, pages 269–276. IN-

STICC, SciTePress.

NDpends (2018). [Online; posted 09-November-2018].

Sharma, T. (2016). Designite - A Software Design Quality

Assessment Tool.

Singh, G. and Chopra, V. (2013). A study of bad smells

in code. Int J Sci Emerg Technol Latest Trends,

7(91):16–20.

Tomek, I. (1976). Two modiﬁcations of cnn. IEEE Trans.

Systems, Man and Cybernetics, 6:769–772.

Wilson, D. L. (1972). Asymptotic properties of nearest

neighbor rules using edited data. IEEE Transactions

on Systems, Man, and Cybernetics, SMC-2(3):408–

421.

Empirical Study about Class Change Proneness Prediction using Software Metrics and Code Smells

147
