Preparatory Reﬂections on Safe Context-adaptive Software

(Position Paper)

Dominik Grzelak

and Uwe Aßmann

Software Technology Group, Technische Universität Dresden, Germany

Keywords:

Context-adaptive Software, Formal Models, Software Veriﬁcation, Future Informatic Systems.

Abstract:

Mobile technology and the Internet of Things promise to deepen the interaction between people, services, and

physical devices. Digital solutions for these prospective computing systems are not only radically changing the

user experience but also the software engineering process. Without a doubt, software complexity enormously

increases, and prospective systems become challenging to develop, maintain, and verify. The user’s reliance

on safety-critical software systems is a serious element in any software engineering process where the absence

of bugs must be ensured, and malfunction ruled out. Software that is not safe, i.e., the software’s behavior does

not comply with a speciﬁcation, could cause loss of proﬁts or, in the worst-case, harm people. Software safety

is an ongoing but mostly academic research ﬁeld incorporating formal methods to prove the correctness of a

program using mathematical methods. In this spirit, we examine the promising context-aware computing and

model-driven development paradigms that have directed the development of fog computing and IoT platforms

alike. Furthermore, we aggregate viable requirements for computational context models to be employed both

for computation and also reasoning about the correctness of applications.

1 INTRODUCTION

When we think about complex systems, we may be

inclined to consider only biological, chemical, or

physical instances in the ﬁrst place. Apparently,

present-day and prospective digital anthropomorphic

systems, where we allow us to subsume terms such as

mobile computing, Internet of Things (IoT), fog com-

puting, Tactile Internet or ubiquitous systems for the

sake of convenience, "will challenge our understand-

ing" (Milner, 2009, p. x) to a much greater extent than

before (see also (Baier and Katoen, 2008)). "Context-

aware adaptation is an important feature for pervasive

computing applications" (Grassi and Sindico, 2007,

p. 69), and in this regard, the integration of context

introduces further software engineering challenges,

which are not present in traditional systems (Hen-

ricksen and Indulska, 2006). The reasons are, which

will be apparent in the following (see Sec. 1.1 and

Sec. 1.2), that software systems inherit a new di-

mension of complexity, meaning both functional and

structural (see (Furrer, 2019)), and as an inevitable

consequence, lead to higher development time, hence,

costs. For that reason, software engineers continu-

https://orcid.org/0000-0001-6334-2356

ously trying to shift the boundaries in order to manage

complex systems that we do not yet fully understand.

A lot of work has been done on investigating methods

on how to better cope with the increasing complex-

ity, such as object-oriented programming, modularity,

reusability and formal semantics.

In line with this and from a software engineering

point of view, we wish to address two crucial quali-

ties of ubiquitous systems in this paper, which are, in

our opinion, how to specify and verify the behavior

of ubiquitous systems by means of formal models.

Under these circumstances, we wish to provide an al-

ternative but complementary approach for application

and system development. In this respect, context-

aware computing is introduced in Sec. 2, where we

explain concrete concepts on how to incorporate con-

text information in applications. Therein, we also

present the main features of the model-driven de-

velopment approach in Sec. 2.1, which provides the

"glue" for formal models to be practically applied in

the software world. In particular, we focus on compu-

tational context models that allow not only to spec-

ify and analyze the interactions of systems with their

environment but also to be used for computation and

veriﬁcation (Sec. 3). Finally, we conclude our paper

in Sec. 4.

382

Grzelak, D. and Aßmann, U.

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper).

DOI: 10.5220/0009459503820391

In Proceedings of the 5th International Conference on Internet of Things, Big Data and Security (IoTBDS 2020), pages 382-391

ISBN: 978-989-758-426-8

The main question that this paper raises is how to

improve the overall code quality of context-adaptive

software in ubiquitous systems concerning the cor-

rectness of a program. We must be committed to com-

municate this quality criterion properly. Ideally, we

have a proof of correctness and other software engi-

neers can understand and verify it. Technically, error

checking is much more difﬁcult on large-scale dis-

tributed systems than to check a single function in

a program. The reliance on the functioning of such

systems (cf. (Baier and Katoen, 2008)) is an impor-

tant point to be considered which goes hand in hand

with the objective of bug absence. The presence of

errors in software systems is not only annoying. It

can, in the most trivial scenarios, e.g., simply freeze

the client application, impact the performance, or in-

crease the power consumption of embedded devices,

but can also harm people in the worst case.

In the following, we outline the development of

IoT, before we wish to describe the implications for

software engineering in detail with respect to complex

IoT systems. We begin with some technical insights

from various analyst’s reports (Evans, 2011; Bradley

et al., 2013; Winslow et al., 2018).

1.1 Current Situation

Dave Evans, a former Cisco expert on the IoT, eval-

uated the growth rate of IoT and outlined its current

state as of 2011, before continuing to provide some

rough estimates about the future development and im-

pact of IoT. Therefore, Cisco used research data pre-

sented in (Zhang et al., 2008). At the level of au-

tonomous systems (AS), Zhang et al. examined Inter-

net routing data in six-month intervals for the period

spanning 2001-2006. In their network model, ASs are

connected by links. As two ASs in this model link to

each other, they make decisions based not only on the

physical connection but also on commercial agree-

ments between two systems. The ﬁndings estimated

an exponential growth rate of the Internet in the sense

that it doubles in size every 5.32 years. Then, Cisco’s

methodology of applying this constant to the "num-

ber of connected devices at a point in time" (Evans,

2011, p. 10) yielded their estimates for the number of

devices per people until 2020: Accordingly, based on

data available from U.S. Census Bureau (2010) and

Forrester Research (2003), the author determined that

Note that we are not interested in the value at stake, new

economic value chains, revenues for industries, companies,

manufacturers, or network operators. However, we want to

provide some realistic ﬁgures that reﬂect the growth rate of

IoT to make the complex system dilemma evident and what

apparent effects this will have for software engineering.

approximately 500 million devices connected to the

Internet existed with a world population of 6.3 billion

people in 2003. In 2010, both ﬁgures grew to 12.5

billion devices and 6.8 billion people, which means

that the number of connected devices per person was

1.84 in 2010. Taking only the people connected to

the internet into account, resulted in approximately 2

billion people for 2010, meaning, 6.25 devices could

be assigned per person (Evans, 2011). By the end of

2020, Evans projected 50 billion connected devices,

which makes roughly 6.58 devices per person, assum-

ing a world population of 7.6 billion people.

In the second study (Bradley et al., 2013), other

Cisco-related analysts investigated the main driving

factors and technology trends for the Internet of Ev-

erything (IoE) and, among other topics, the growth

rate of the number of devices connected to the Inter-

net. The authors described that in 2000 there were 200

million devices connected to the Internet, which is in

accordance with the study above. However, the ﬁg-

ures are slightly relativized —the authors stated that

in 2013 10 billion connected devices existed from

approximately 1.5 trillion devices globally available

(Bradley et al., 2013). In their opinion, this number is

expected to grow to 50 billion connected devices until

the end of 2020, which yields 6.25 devices per person.

Further, the authors highlighted the fact that most of

the devices are still unconnected resulting in "approx-

imately 200 connectable things per person" (Bradley

et al., 2013, p. 2). Their estimation, drawn from Cisco

studies in 2013, is that 99.4% of all available IoT de-

vices are still not connected.

The conclusion is consistent with the one of other

analysts (Winslow et al., 2018). They also expect

a continued "growth [. . .] into the next decade [. . .]

shaped by [. . .] the Internet of Things" (Winslow

et al., 2018, p. 1). Projections provided by the an-

alysts show that by 2020 roughly 26 IoT devices

can be assigned per person from approximately 200

billion connected devices (4 times higher than in

(Evans, 2011)), assuming the same world popula-

tion as above. In particular, the authors conclude

that cloud computing concepts alone (which mostly

resemble centralized architectures) are no appropri-

ate and feasible computing models when consider-

ing "the exponential growth of data created at the

edge" (Winslow et al., 2018, p. 6). The authors re-

ported that the amount of data generated at the net-

work edge "will exceed 40 trillion gigabytes by 2025"

(Winslow et al., 2018, p. 3) according to projections

of IDC white paper (Turner et al., 2014). As men-

tioned by the authors, they provide strong evidence

that a substantial amount of data will be generated

and processed in the network edge instead by cloud-

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper)

383

data centers (Winslow et al., 2018) to alleviate the

core limitations of purely cloud-centric IoT platforms

such as bandwidth, connectivtiy, latency and context-

awareness (see (Bonomi et al., b; Bonomi et al., a;

Winslow et al., 2018)).

1.2 Implications on Software

Engineering

Current systems have reached or in some way ap-

proaching a complexity whose consequences are in-

creasingly difﬁcult to control and understand (Murer

et al., 2008; Milner, 2009). Fast software implemen-

tations of business requirements are easily at the ex-

pense of quality (Murer et al., 2008). Furrer (Furrer,

2019) compiles three general key challenges on the

difﬁculty of the systems engineering process, namely,

change, complexity, and uncertainty: (i) The as-

pect change is characterized by changing business re-

quirements, technology updates, or maintenance pro-

cesses (Furrer, 2019). Moreover, the time cycles to

implement necessary changes becoming shorter (Fur-

rer, 2019). Imagine a normal development process,

where a team of developers may submit hundreds of

changes to upstream software each day. As a re-

sult, fast incremental software changes may lead to

code redundancy or violation of architecture princi-

ples to be followed, which are essential for a uni-

form code basis and the communication among team

members. Each change may introduce new incom-

patibilities which additionally increases the complex-

ity; (ii) Complexity issues may arise from incompat-

ibility with other software, either caused by chang-

ing interface speciﬁcations over time or heterogene-

ity of system and software components, to mention

a few. Especially when building a specialized soft-

ware ecosystem, such as in computer-assisted soft-

ware engineering environments (Wasserman, 1990),

tool integration becomes difﬁcult because of many

heterogeneous vendor-speciﬁc tools. Thus, integra-

tion techniques have to be developed, or the usage

of non-proprietary formats has to be promoted, for

example. Generally, complexity can be classiﬁed as

structural (architectural) and functional complexity,

where the former takes the number of individual sys-

tem parts and the intensity of their relationships into

account, whereas the latter is "measured as the size of

the functionality of their parts and interfaces" (Furrer,

2019, p. 24); (iii) Uncertainty involves incomplete re-

quirements (e.g., due to the market) that may lead to

inadequate decision-making processes, and also in-

cludes internal activities during the software’s oper-

ation (Furrer, 2019). Particularly cyber-physical sys-

tems operate in uncertain and unstructured environ-

ments where, however, the system must adequately

function, despite the fast-changing and unpredictable

surrounding (Furrer, 2019). This also applies to con-

text-aware systems (CAS). As previously mentioned,

such a system includes context information to adapt

to changing situations autonomously. Thus, they are

able to make a smart decision to some extent, which

attenuates some problems of uncertainty.

Although these concepts generally apply to sev-

eral kinds of systems, there is a substantial differ-

ence when developing context-adaptive software as

opposed to traditional desktop applications that do

not primarily include context information. Additional

quality measures for context-aware systems were pre-

sented in (Henricksen and Indulska, 2006) in the

course of evaluating a case study. From another

perspective, these can be reversed to challenges that

need to be properly treated. Also mentioned is code

complexity, and further maintainability, support for

evolution and reusability.

2 THE ADOPTION OF CONTEXT

INFORMATION IN SOFTWARE

Having arrived here, we are prepared to discuss differ-

ent implementation approaches for incorporating and

manipulating context information in software applica-

tions. First, we introduce the necessary model-driven

paradigm that is, in some way, a canonical software-

related technological foundation for our further elab-

orations.

By recalling the standard phases of a software de-

velopment life cycle, support can come in two forms

(see (Dey, 2001; Hennessy, 2004)) in order to per-

form context-adaptive software engineering. The ﬁrst

approach treats the direct development of the solution

architecture; that is, we decide and agree on the ex-

act implementation approach. The other type of as-

sistance comes from a higher level, and related to

it are model-driven software development practices.

Therein, models are primarily used for the speciﬁca-

tion, implementation, and deployment, mostly sup-

ported by automated processes (such as code gener-

ation and model transformation). Formal languages

or mathematical theories enable this direct model us-

age (Hennessy, 2004). Both main branches on how

to generally adopt context in software are consoli-

dated into a taxonomy and extended with subcate-

gories. The taxonomy is depicted in Fig. 1 and shall

be explained in the following.

Beneﬁcial is the fact that both of these approaches

are not only compatible but also complementary.

Even though general architecture frameworks and dis-

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

384

Adoption of Context

in Software

Indirect

Direct

Architecture

Distributed

Infrastructure

Theories

Modeling Language

Programming

Paradigm

AOP

COP

Modeling Formalism

(Partly) Complementary

Subdivided into

is-a relationship

ROP

Figure 1: Taxonomy of approaches for context adoption in software (reduced version for clarity). AOP refers to aspect-

oriented programming, COP is context-oriented programming and ROP means role-oriented programming. Consolidated and

extended after (Dey, 2001; Hennessy, 2004; Broman et al., 2012). See (Broman et al., 2012) for the differences between

modeling formalism and language.

tributed infrastructures often limit themselves to the

development of particular functionalities or force the

commitment of design principles, the context mod-

eling approach does not introduce any arbitrary data

structure that is neither in conﬂict with initial con-

straints nor requirements.

2.1 Model-driven Engineering

Model-driven engineering (MDE) provides a set of

guidelines and instructions to be applied for the soft-

ware engineering process (Brambilla et al., 2017;

Staab et al., 2010; Bézivin, 2005). Nearly two

decades ago, the Object Management Group intro-

duced the MDE paradigm to "move from code-centric

to model-based practices" (Bézivin, 2005, p. 171). It

comprises two main concepts, namely, models and

transformations. Models are the primary artifacts and

are expressed in some modeling language, e.g., the

Uniﬁed Modeling Language (UML). Transformations

are a means to reconﬁgure the model (i.e., provide op-

erations on models). In MDE everything is regarded

as a model, even the modeling language is speciﬁed

by a meta-model (refer to the four-layer modelling

architecture in (Atkinson and Kuhne, 2003) or see

(Bézivin, 2005)).

Models "are no longer mere (passive) documenta-

tion" (Ehrig et al., 2006, p. 7) utilities and enable the

utilization of sophisticated methods such as syntacti-

cal validation and model checking (see (Ehrig et al.,

2006; Brambilla et al., 2017) and Sec. 3.2). Mod-

els allow to reuse and adapt software (or its com-

ponents) to different situations (e.g., by transforma-

tions), which enables to speed up the development

process, eases maintenance and alleviates common

errors early in the design phase by using formal mod-

els. Moreover, the behavior of a system may be spec-

iﬁed by transformation rules. In this regard, higher-

order graph transformation rules can be employed to

model self-adaptive systems (Machado et al., 2015).

2.2 Context as a Resource

First, we wish to brieﬂy explain the extremely general

term context before we examine the approaches men-

tioned above. No clear boundary exists what the term

context means, hence many loose deﬁnitions exist in

the scientiﬁc literature. However, some key deﬁni-

tions are widely accepted, e.g., (Abowd et al., 1999;

Dey, 2001; Abowd et al., 2002), where we wish to

adopt the one of Dey (Dey, 2001): "Context is any

information that can be used to characterize the situa-

tion of an entity. An entity is a person, place, or object

that is considered relevant to the interaction between

a user and an application, including the user and ap-

plications themselves" (Dey, 2001, p. 5).

In the last decades, considerable efforts have been

undertaken to address this challenge, where context-

awareness has been identiﬁed as a fundamental re-

quirement for the creation of robust, intelligent and

adaptive applications (Schmidt et al., 1998; Abowd

et al., 1999), and have quickly become a multidisci-

plinary research ﬁeld.

2.3 Infrastructures, Architectures and

Programming Languages

The main element of this approach is to use ready-

made "tools" that assist one in managing the various

steps of the software’s development lifecycle. Such

"tools" can facilitate the development, distribution,

and adoption of software for multiple purposes and

platforms. Using architectural frameworks also helps

teams to better communicate through a common tech-

nology. Moreover, they make the maintenance and

development process more ﬂexible and efﬁcient when

changes are introduced and avoids writing repeated

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper)

385

code. Furthermore, they alleviate common mistakes

by providing best practices through their frame of ref-

erence. Architectural frameworks and distributed in-

frastructures manifest themselves in various forms,

e.g., graphical and interactive, tool-based, or APIs.

They provide software engineers with the necessary

frame. We present some examples of recent develop-

ments; the list is not exhaustive.

A software toolkit for mobile sensor-based appli-

cations is presented in (Grzelak. et al., 2019; Grze-

lak et al., 2020). The toolkit is based on the OSGi

standard and modularizes individual components of

an application by using the concept of bundles. Fur-

ther, the toolkit allows adapting an application to the

different locality and connectivity of sensor devices

by altering the deployment of the application’s dis-

tributed components.

In (Jaouadi et al., 2018), a model-based approach

to develop context-aware systems is proposed that

the authors demonstrated by developing a software

framework based on a domain-independent context

meta-model. The framework provides a Java API

"that is capable of capturing the context, observing

it in runtime, discovering events that change it and

triggering actions to adapt appropriately the running

application" (Jaouadi et al., 2018, p. 1170).

In (Kapitsaki and Venieris, 2009), the authors

expound the model-driven development of context-

aware web services. Their approach allows web ser-

vices to adapt to context changes. However, often

the service’s core logic is kept untouched by contexts.

Therefore, it is decoupled from related context man-

agement components, which enables the reuse of ex-

isting functionality and highlighting only on the de-

pendencies that require context information (Kapit-

saki and Venieris, 2009). The approach employs

UML proﬁles to model context adaption of a web ser-

vice.

There is also active research about how context-

dependent behavior manifests itself in programming

languages. In this regard, we introduce context-

oriented programming (COP) with the following def-

inition: "Context-oriented programming proposes a

language-level technique to enable dynamic adapta-

tions by the activation of contextual situations sensed

from the environment. Context activation triggers the

dynamic composition of behavioral adaptations with

the running system." (Cardozo, 2018, p. 1). It can

be thought of as the continuation of procedural and

object-oriented languages (Hirschfeld et al., 2008).

One of the very ﬁrst treatments of context-oriented

programming are (Gassanenko, 1998; Keays and

Rakotonirainy, 2003), providing a generalized notion

of context-oriented programming; further (Hirschfeld

et al., 2008), where the authors present required lan-

guage concept for COP, namely, layers to express dif-

ferent behavioral variations at run-time.

2.4 Context Modeling

Since Mark Weiser’s vision of ubiquitous systems,

many researchers have studied the foundations of con-

text modeling (e.g. (Henricksen et al., 2002; Roman

et al., 2004; Birkedal et al., 2006; Loke, 2016); this

list is not exhaustive). This has resulted in a large

quantity of different model kinds being developed.

Speciﬁcally, context models can be divided into 8

different categories: object-role based models, spa-

tial models, ontology-based models, key-value mod-

els, object-oriented models, markup scheme mod-

els, graphical models, and logic-based models (Bet-

tini et al., 2010; Strang and Linnhoff-Popien, 2004;

Bolchini et al., 2007). We may further classify each

model as informal or formal. Formal context models

are especially useful as they allow reasoning about

contexts. The spectrum of categories clearly shows

the importance of context models in this research area

for future software systems. For the sake of shortness,

we cannot give a comprehensive overview of existing

context models. Instead, we refer the reader to various

surveys and studies conducted so far, e.g., (Henrick-

sen et al., 2002; Strang and Linnhoff-Popien, 2004;

Bolchini et al., 2007; Bettini et al., 2010).

These context models are somewhat diametrical to

each other and clearly show the wide variety and vi-

brant landscape. However, "a complete and compre-

hensive model is still missing" (Chaari et al., 2007,

p. 1975). Shortcomings of some of these context

models are that they are rather rigid and very speciﬁc

(e.g., ﬁxed syntax, operations, and semantics), are not

deﬁned on a meta-model level, only allow the speciﬁ-

cation of the context’s semantics, or do not scale well

because they lack important features such as compo-

sition (Grzelak and Aßmann, 2019). This is in accor-

dance with (Henricksen et al., 2002), where the au-

thors observed that most of the architectural frame-

works (refer to Sec. 2.3) incorporate informal models

that lack the necessary expressive power. Therefore,

in the next section, we return to context models that

can be expressed algebraically and are more suited to

our purpose.

3 MODELING CONTEXT IN

SOFTWARE

We focus on a speciﬁc aspect of models that can be

used not only for the modeling purpose alone but also

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

386

for computation and reasoning. This also helps to

bridge the gap between models and software develop-

ment and thus, veriﬁcation. Therefore, we term these

kinds of models computational context models. Fol-

lowing (Milner, 2009), a model shall not only be used

for the modeling task at hand but also used as a pro-

gramming language. We deﬁne the term as a union of

a context model as explained in Sec. 2.4 and a com-

putational model that can be algebraically expressed

(e.g., by a process algebra).

To give an impression of this subject, we present

some examples. Models that we would like to classify

under the term computational context model are, e.g.,

the plato-graphical model in (Birkedal et al., 2006)

and the socio-technical model in (Benford et al.,

2016). The ﬁrst paper proposes a context model for

the formal modeling of context-aware systems, which

comprises three separate models (world, proxy, and

application) that can be composed at any time to get

the complete view of the system. The second paper

presents in detail the modeling of a pervasive out-

door game which comprises four perspectives (com-

putational, physical, human, and technology). The

authors demonstrate the analysis of complex interac-

tional phenomena and exploration of possible incon-

sistencies among the four perspectives of this formal

model and developed an application.

3.1 Requirements

We try to determine useful and necessary require-

ments that a formal computational context model

must include. In accordance with (Strang and

Linnhoff-Popien, 2004; Topcu, 2011; Seshia et al.,

2018), we want to promote the following general re-

quirements: (i) Composability. Supports to build

systems separately and allows a combination later.

This feature enables extensible and modularized ap-

plications and fosters separation of concerns. (ii) Val-

idability. Allows checking whether a model syntac-

tically conforms to a meta-model, thus, ensuring the

completeness. Additional constraints can be included

for more complex validations. (iii) Level of Formal-

ity. Means that a model must be precise in terms of

the speciﬁcation of some tasks. On the other hand, it

must be easy to use in order to be applied by a user

or used as a communication element. (iv) Veriﬁabil-

ity and Reasoning. Denote that a model must have a

formalism that allows performing veriﬁcation of cor-

rectness properties on it and support inferencing of

facts by the derivation of other expressions and facts.

(v) Level of Abstraction. Means that a model must

be implementation-agnostic to be maximally interop-

erable. A high degree of speciﬁcity would make the

use of such a model only available for speciﬁc appli-

cations. (vi) High Level of Expressiveness. Allows

to create various context semantics, process seman-

tics, describe the distribution and communication of

processes at different locations and shall allow the

speciﬁcation of reactive behavior. (vii) Interoper-

ability. Allows a model to be incorporated into exist-

ing systems or to be used in combination with other

models.

3.2 Guaranteeing the Safety of Software

at Design-time

Now, we address the quality criterion "safety" as men-

tioned earlier in the introduction. We present a mech-

anism on how to ensure the safety of software early in

the design phase. Models itself allow, besides model

validation and transformations, further model check-

ing and simulation. A lot of work has been conducted

in this domain, and we wish to refer the reader to (Se-

shia et al., 2018; Hoffmann, 2013; Baier and Katoen,

2008) for a more comprehensive overview of this sub-

ject of model checking. In the following, we give a

brief outline of one particular formal method.

3.2.1 Software Veriﬁcation

Veriﬁcation means to ensure that a program at design-

time or run-time possesses the desired or required

properties according to a speciﬁcation. Using veri-

ﬁcation, one is able to detect errors that may not be

detected by traditional test and analysis techniques

(see (Hoffmann, 2013)) such as unit tests. Formally,

in the process of veriﬁcation, a program (called im-

plementation), is checked against a set of constraints

(called speciﬁcation) (see (Baier and Katoen, 2008;

Hoffmann, 2013)), and we write I |= S . These prop-

erties are necessary to verify that a system is able to

meet the speciﬁcation.

An advantage of some veriﬁcation techniques is

that they can be utilized in an automated manner.

Thus, it found application in industry, in particular,

for safety-critical products as a supporting tool (Hoff-

mann, 2013).

3.2.2 Model Checking

Here, we present a veriﬁcation technique, called

model checking, that is commonly employed in the

industry. Therefore, model checkers are used for this

purpose.

A model checker is a computer program which

evaluates state-transition models, such as Kripke

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper)

387

structures, or other similar models (e.g., labeled tran-

sition systems, wide reactive systems), against a col-

lection of propositions or constraints, that specify

what is required to make the initial assertions of the

speciﬁcation valid.

Well-known model checker tools are, e.g., SPIN

(Holzmann, 1997), GROOVE (Rensink, 2004) and

PRISM (Kwiatkowska et al., 2011). We observe that

model checking is not only a purely academic ﬁeld

but in fact found its application in industry (Hoff-

mann, 2013). For instance, the model checker SPIN

was used for veriﬁcation of algorithms of the Mars

rover Curiosity (Holzmann, 2014). When a simula-

tion is performed using a model checker (assuming

a ﬁnite state space), it generates an output whether

the speciﬁcation is met or not. Therefore, specialized

traversal algorithms are employed (Hoffmann, 2013)

that resolve all possible next states from previous ones

either as long as some criteria are not violated or by

some other constraints (e.g., number of states, transi-

tions, or time limits). Thus, after every iteration, the

state space is extended, and the system evolves. If

the program contains errors, in the course of the sim-

ulation, counterexamples can be generated to provide

assistance for the designer, for instance.

According to (Owicki and Lamport, 1982), in the

case of concurrent programs, one can verify two key

properties: safety properties and liveness properties.

The ﬁrst veriﬁes that a program never enters an unde-

sired state in the sense that a program becomes non-

operational, e.g., because of deadlocks. The second

denotes a desirable state of a program that is eventu-

ally going to happen, e.g., an exclusive resource can

be used by all available processes, or that a program

does not terminate unexpectedly.

Liveness properties imply the notion of time, a

concept of fairness and deadlock freedom is important

for concurrent programs, which includes distributed

systems and real-time systems. For instance, real-

time systems rely on coordinated operations among

their interacting components. Thus, timely coordina-

tion is a key element for the correct functioning of

those systems (Tripakis and Courcoubetis, 1996). In

this regard, one can describe the temporal dynamics

of a program by expressions of linear-time proper-

ties in the speciﬁcation. Linear-time properties rep-

resent valid traces of a transition system that speciﬁes

the desired behavior of a system over time (Baier and

Katoen, 2008). Such temporal propositions are of-

ten speciﬁed using ﬁrst-order logics such as the linear

temporal logic or computation tree logic. We shall not

go into more detail here for the sake of space limita-

tions.

Problems. Veriﬁcation operates on the model-level,

which implies that a program must be translated into

some kind of a formal model ﬁrst. This is, at the

same time, one of its limits (Hoffmann, 2013). In

this process, errors can be introduced, which cannot

be detected by the actual program veriﬁcation. In this

regard, we advocate the use of formal modeling ap-

proaches early in the design phase, being able to em-

ploy them further for model-driven techniques. An-

other problem is the so-called state space explosion

problem, where researchers investigated various ap-

proaches to reduce this problem, e.g., program slicing

(Léchenet et al., 2016), symbolic model checking or

the early detection of inﬁnite state traces.

4 CONCLUSIONS

The IoT may offer much in the way of innovation and

will further emerge a vast number of new services,

but will continue to introduce new difﬁculties from

a software engineering perspective. When the com-

plexity of software systems reaches a critical level,

due to the connectedness of our environment, it will

become increasingly important for software engineers

to have an efﬁcient and effective computing model to

use in representing different abstractions of the sys-

tem to implement, deploy and provision applications.

The appliance of model-driven techniques in combi-

nation with formal context models may help to cope

with the complexity of ubiquitous systems, which di-

rectly implies a reduction of the software’s complex-

ity, and thus in return, the development time and costs.

Based on the experiences we gained from sev-

eral research projects (e.g., IoSense

, and CeTI

), we

may conclude that designing context-aware and adap-

tive software employing model-driven techniques is a

valid and reasonable approach. Context-adaptive soft-

ware surely presupposes a context system in one way

or another. One way to achieve this, is to consider

context as part of a platform-independent component

in any application, system, or network.

We argue that it is often easiest to explain the in-

tent of any piece of software using the context of the

environment in which it is deployed. This approach

is applicable for application, system, and infrastruc-

ture design. In our view, one unfortunate aspect is

that context models have not yet been satisfactorily

abstracted to the point that such a software model can

be integrated easily into other systems. An important

decision on the nature of computational models must

http://www.iosense.eu/

https://www.ceti.one/

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

388

be that of the formalism in which they are described.

If the precise terminology is too cumbersome or less

expressive, it is, on the other hand, more advisable to

use a context-oriented programming language or an

architectural framework. However, we strongly advo-

cate using models at a reasonable level of abstraction

to be able to deal with all unknown interactions in

a realistic timeframe in case of internal and external

changes. Hence, the choice of a formal model cannot

be considered in isolation, and decisions are bounded

to trade-offs in each case, which needs to be carefully

weighed (cf. (Cafezeiro et al., 2008)).

To conclude our digression, we wish to suggest hi-

erarchical graph models by following (Milner, 2009;

Bruni et al., 2014), which are also commonly applied

for modeling the software system’s structure. Recent

developments in the domain of process algebra show

that hierarchical models can express the two relevant

dimensions locality and communication, which are

two essential elements in ubiquitous systems (Bruni

et al., 2014).

ACKNOWLEDGEMENTS

Funded by the German Research Foundation (DFG,

Deutsche Forschungsgemeinschaft) as part of Ger-

many’s Excellence Strategy – EXC 2050/1 – Project

ID 390696704 – Cluster of Excellence "Centre for

Tactile Internet with Human-in-the-Loop" (CeTI) of

Technische Universität Dresden.

REFERENCES

Abowd, G. D., Dey, A. K., Brown, P. J., Davies, N., Smith,

M., and Steggles, P. (1999). Towards a Better Under-

standing of Context and Context-Awareness. In Pro-

ceedings of the 1st International Symposium on Hand-

held and Ubiquitous Computing, HUC ’99, pages

304–307. Springer-Verlag.

Abowd, G. D., Ebling, M., Hung, G., Lei, H., and Gellersen,

H. (2002). Context-aware computing [Guest Editors’

Intro.]. IEEE Pervasive Computing, 1(3):22–23.

Atkinson, C. and Kuhne, T. (2003). Model-driven develop-

ment: A metamodeling foundation. IEEE Software,

20(5):36–41.

Baier, C. and Katoen, J.-P. (2008). Principles of Model

Checking. The MIT Press.

Benford, S., Calder, M., Rodden, T., and Sevegnani, M.

(2016). On Lions, Impala, and Bigraphs: Modelling

Interactions in Physical/Virtual Spaces. 23(2):9:1–

9:56.

Bettini, C., Brdiczka, O., Henricksen, K., Indulska, J.,

Nicklas, D., Ranganathan, A., and Riboni, D. (2010).

A Survey of Context Modelling and Reasoning Tech-

niques. Pervasive Mob. Comput., 6(2):161–180.

Birkedal, L., Debois, S., Elsborg, E., Hildebrandt, T., and

Niss, H. (2006). Bigraphical Models of Context-

Aware Systems. In Foundations of Software Science

and Computation Structures, Lecture Notes in Com-

puter Science, pages 187–201. Springer, Berlin, Hei-

delberg.

Bolchini, C., Curino, C. A., Quintarelli, E., Schreiber, F. A.,

and Tanca, L. (2007). A Data-oriented Survey of Con-

text Models. SIGMOD Rec., 36(4):19–26.

Bonomi, F., Milito, R., Natarajan, P., and Zhu, J. Fog Com-

puting: A Platform for Internet of Things and Analyt-

ics. In Bessis, N. and Dobre, C., editors, Big Data and

Internet of Things: A Roadmap for Smart Environ-

ments, Studies in Computational Intelligence, pages

169–186. Springer International Publishing.

Bonomi, F., Milito, R., Zhu, J., and Addepalli, S. Fog Com-

puting and Its Role in the Internet of Things. In Pro-

ceedings of the First Edition of the MCC Workshop

on Mobile Cloud Computing, MCC ’12, pages 13–16.

ACM.

Bradley, J., Barbier, J., and Handler, D. (2013). More Rele-

vant, Valuable Connections Will Improve Innovation,

Productivity, Efﬁciency & Customer Experience.

Brambilla, M., Cabot, J., and Wimmer, M. (2017). Model-

Driven Software Engineering in Practice: Second

Edition. Morgan & Claypool Publishers, 2nd edition.

Broman, D., Lee, E. A., Tripakis, S., and Törngren, M.

(2012). Viewpoints, Formalisms, Languages, and

Tools for Cyber-physical Systems. In Proceedings

of the 6th International Workshop on Multi-Paradigm

Modeling, MPM ’12, pages 49–54. ACM.

Bruni, R., Montanari, U., Plotkin, G., and Terreni, D.

(2014). On Hierarchical Graphs: Reconciling Bi-

graphs, Gs-monoidal Theories and Gs-graphs. Fun-

damenta Informaticae, 134:287–317.

Bézivin, J. (2005). On the uniﬁcation power of models.

Software & Systems Modeling, 4(2):171–188.

Cafezeiro, I., Viterbo, J., Rademaker, A., Haeusler, E. H.,

and Endler, M. (2008). A Formal Framework

for Modeling Context-Aware Behavior in Ubiquitous

Computing. In Margaria, T. and Steffen, B., editors,

Leveraging Applications of Formal Methods, Veriﬁ-

cation and Validation, Communications in Computer

and Information Science, pages 519–533. Springer

Berlin Heidelberg.

Cardozo, N. (2018). A Declarative Language for Context

Activation. In Proceedings of the 10th International

Workshop on Context-Oriented Programming: Ad-

vanced Modularity for Run-Time Composition, COP

’18, pages 1–7. Association for Computing Machin-

ery.

Chaari, T., Ejigu, D., Laforest, F., and Scuturici, V.-M.

(2007). A Comprehensive Approach to Model and

Use Context for Adapting Applications in Pervasive

Environments. J. Syst. Softw., 80(12):1973–1992.

Dey, A. K. (2001). Understanding and Using Context. Per-

sonal Ubiquitous Comput., 5(1):4–7.

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper)

389

Ehrig, H., Ehrig, K., Prange, U., and Taentzer, G. (2006).

Fundamentals of Algebraic Graph Transformation.

Monographs in Theoretical Computer Science. An

EATCS Series. Springer-Verlag.

Evans, D. (2011). How the Next Evolution of the Internet

Is Changing Everything.

Furrer, F. J. (2019). Three Devils of Systems Engineer-

ing. In Furrer, F. J., editor, Future-Proof Software-

Systems: A Sustainable Evolution Strategy, pages 21–

44. Springer Fachmedien.

Gassanenko, M. L. (1998). Context-Oriented Program-

ming. In euroForth’98, page 10.

Grassi, V. and Sindico, A. (2007). Towards model driven

design of service-based context-aware applications. In

International Workshop on Engineering of Software

Services for Pervasive Environments: In Conjunction

with the 6th ESEC/FSE Joint Meeting, ESSPE ’07,

pages 69–74. Association for Computing Machinery.

Grzelak, D. and Aßmann, U. (2019). Bigraphical meta-

modeling of fog computing-based systems. In Pro-

ceedings of the International Conference on Discrete

Models of Complex Systems (SOLSTICE).

Grzelak., D., Mai., C., and Aßmann., U. (2019). Towards

a Software Architecture for Near Real-time Applica-

tions of IoT. In Proceedings of the 4th International

Conference on Internet of Things, Big Data and Secu-

rity - Volume 1: IoTBDS,, pages 197–206. INSTICC,

SciTePress.

Grzelak, D., Mai, C., Schöne, R., Falkenberg, J., and Aß-

mann, U. (2020). A Software Toolkit for Complex

Sensor Systems in Fog Environments. In van Driel,

W. D., Pyper, O., and Schumann, C., editors, Sen-

sor Systems Simulations: From Concept to Solution,

pages 253–282. Springer International Publishing.

Hennessy, M. (2004). Context-awareness: Models and anal-

ysis.

Henricksen, K. and Indulska, J. (2006). Developing

Context-aware Pervasive Computing Applications:

Models and Approach. Pervasive Mob. Comput.,

2(1):37–64.

Henricksen, K., Indulska, J., and Rakotonirainy, A. (2002).

Modeling Context Information in Pervasive Comput-

ing Systems. In Mattern, F. and Naghshineh, M., ed-

itors, Pervasive Computing, Lecture Notes in Com-

puter Science, pages 167–180. Springer Berlin Hei-

delberg.

Hirschfeld, R., Costanza, P., and Nierstrasz, O. (2008).

Context-Oriented Programming. Journal of Object

Technology, ETH Zurich, 7(3):125–151.

Hoffmann, D. W. (2013). Software-veriﬁkation. In

Hoffmann, D. W., editor, Software-Qualität, eXa-

men.press, pages 333–369. Springer.

Holzmann, G. (1997). The model checker SPIN. IEEE

Transactions on Software Engineering, 23(5):279–

295.

Holzmann, G. J. (2014). Mars code. Communications of

the ACM, 57(2):64–73.

Jaouadi, I., Ben Djemaa, R., and Ben-Abdallah, H. (2018).

A model-driven development approach for context-

aware systems. Software & Systems Modeling,

17(4):1169–1195.

Kapitsaki, G. M. and Venieris, I. S. (2009). Model-

Driven Development of Context-Aware Web Applica-

tions Based on a Web Service Context Management

Architecture. In Chaudron, M. R. V., editor, Models

in Software Engineering, Lecture Notes in Computer

Science, pages 343–355. Springer.

Keays, R. and Rakotonirainy, A. (2003). Context-oriented

Programming. In Proceedings of the 3rd ACM Inter-

national Workshop on Data Engineering for Wireless

and Mobile Access, MobiDe ’03, pages 9–16. ACM.

Kwiatkowska, M., Norman, G., and Parker, D. (2011).

PRISM 4.0: Veriﬁcation of Probabilistic Real-Time

Systems. In Gopalakrishnan, G. and Qadeer, S., ed-

itors, Computer Aided Veriﬁcation, Lecture Notes in

Computer Science, pages 585–591. Springer.

Léchenet, J.-C., Kosmatov, N., and Le Gall, P. (2016). Cut

Branches Before Looking for Bugs: Sound Veriﬁca-

tion on Relaxed Slices. In Stevens, P. and W ˛asowski,

A., editors, Fundamental Approaches to Software En-

gineering, Lecture Notes in Computer Science, pages

179–196. Springer.

Loke, S. W. (2016). Representing and reasoning with the

internet of things: A modular rule-based model for en-

sembles of context-aware smart things. EAI endorsed

transactions on context-aware systems and applica-

tions, 3(8):1–17.

Machado, R., Ribeiro, L., and Heckel, R. (2015). Rule-

based transformation of graph rewriting rules: To-

wards higher-order graph grammars. Theoretical

Computer Science, 594:1–23.

Milner, R. (2009). The Space and Motion of Communicat-

ing Agents. Cambridge University Press, 1st edition.

Murer, S., Worms, C., and Furrer, F. J. (2008). Managed

evolution. Informatik-Spektrum, 31(6):537–547.

Owicki, S. and Lamport, L. (1982). Proving Liveness Prop-

erties of Concurrent Programs. ACM Transactions on

Programming Languages and Systems, 4(3):455–495.

Rensink, A. (2004). The GROOVE Simulator: A Tool for

State Space Generation. In Pfaltz, J. L., Nagl, M., and

Böhlen, B., editors, Applications of Graph Transfor-

mations with Industrial Relevance, Lecture Notes in

Computer Science, pages 479–485. Springer.

Roman, G.-C., Julien, C., and Payton, J. (2004). A Formal

Treatment of Context-Awareness. In Wermelinger, M.

and Margaria-Steffen, T., editors, Fundamental Ap-

proaches to Software Engineering, Lecture Notes in

Computer Science, pages 12–36. Springer Berlin Hei-

delberg.

Schmidt, A., Beigl, M., and Gellersen, H.-w. (1998). There

is more to Context than Location. Computers and

Graphics, 23:893–901.

Seshia, S. A., Sharygina, N., and Tripakis, S. (2018). Mod-

eling for Veriﬁcation. In Clarke, E. M., Henzinger,

T. A., Veith, H., and Bloem, R., editors, Handbook

of Model Checking, pages 75–105. Springer Interna-

tional Publishing.

Staab, S., Walter, T., Gröner, G., and Parreiras, F. S. (2010).

Model Driven Engineering with Ontology Technolo-

IoTBDS 2020 - 5th International Conference on Internet of Things, Big Data and Security

390

gies. In Aßmann, U., Bartho, A., and Wende, C., edi-

tors, Reasoning Web. Semantic Technologies for Soft-

ware Engineering: 6th International Summer School

2010, Dresden, Germany, August 30 - September 3,

2010. Tutorial Lectures, Lecture Notes in Computer

Science, pages 62–98. Springer Berlin Heidelberg.

Strang, T. and Linnhoff-Popien, C. (2004). A Context Mod-

eling Survey. page 8. UbiComp 2004 workshop on

Advanced Context Modelling, Reasoning and Man-

agement.

Topcu, F. (2011). Context Modeling and Reasoning Tech-

niques.

Tripakis, S. and Courcoubetis, C. (1996). Extending

promela and spin for real time. In Margaria, T. and

Steffen, B., editors, Tools and Algorithms for the Con-

struction and Analysis of Systems, Lecture Notes in

Computer Science, pages 329–348. Springer.

Turner, V., Gantz, J. F., Reinsel, D., and Minton, S. (2014).

The Digital Universe of Opportunities: Rich Data and

the Increasing Value of the Internet of Things.

Wasserman, A. I. (1990). Tool integration in software engi-

neering environments. In Long, F., editor, Software

Engineering Environments, Lecture Notes in Com-

puter Science, pages 137–149. Springer Berlin Hei-

delberg.

Winslow, P., Fritzsche, J. M., Stabler, P., Rakers, A., Lueb-

chow, E., and Hilliker, R. (2018). The Edge Of Glory

(or: The Fog Rolls In).

Zhang, G.-Q., Zhang, G.-Q., Yang, Q.-F., Cheng, S.-Q.,

and Zhou, T. (2008). Evolution of the Internet and

its cores. New Journal of Physics, 10(12):123027.

Preparatory Reﬂections on Safe Context-adaptive Software (Position Paper)

391
