Multi Software Product Lines: A Systematic Mapping Study

Pasquale Ardimento

, Nicola Boffoli

and Giuseppe Superbo

Computer Science Department, University of Bari Aldo Moro, Via Orabona, 4, 70125, Bari, Italy

Keywords:

Multi Software Product Line, Software Product Line, Software Engineering, Mapping Study, Variability

Management.

Abstract:

Even if Software Product Line (SPL) is an established technique in software engineering, there are several

limitations of its use. This is mainly caused by the exponential increase of software systems complexity and

by the high pace of software and hardware evolution. Many of these limitations have been studied and faced

by applying the Multi Software Product Line (MSPL), an extension of the SPL. MSPL is an emerging and

novel technique based on using more than one SPL to derive a functional product system. This paper aims to

characterize the state of the art of MSPL, the main goal is to highlight the reached achievement in this ﬁeld

and then discuss about the open issues or the not covered aspects of this approach. In order to make an overall

analysis inside the research community, a well-deﬁned method of systematic mapping is applied in order to

classify, in a proper scheme, every paper strictly related to this topic. These classiﬁed results could give a valid

hint about lacks which should be investigated further.

1 INTRODUCTION

Nowadays Software Product Line (SPL) is a common

development approach which is used in many con-

text of Software Engineering. As the term of con-

cept exploits, this technique consists in applying all

the traditional product line methods in the software

development sector. So as there are several selectable

components to build a car, also during the develop-

ment of a software system it is possible to choose

existent features/modules from a less speciﬁc plat-

form (Pohl et al., 2005). In this way it is possible

to build several customized systems for a very spe-

ciﬁc context without any additional effort in the de-

velopment stage. Despite all the advantages in costs

and time, there are some critical limitations which are

caused by the complexity of software market environ-

ment. The high pace of software and hardware evo-

lution, the frequent change of requirements and the

large size of systems make conﬁguration and mainte-

nance of a production platform really complex. For

this reason after many year of research, an exten-

sion of this concept was identiﬁed as potential solu-

tion of these limitations: Multiple Software Product

Line (MSPL) (Krueger, 2006). This derived devel-

opment strategy is based in building new systems by

https://orcid.org/0000-0001-6134-2993

https://orcid.org/0000-0001-9899-6747

selecting features/assets from different software prod-

uct lines without altering any functionality of each

SPL platform, which are still independent between

each others. This can be applied in many contexts

as often totally disconnected ﬁelds can share sev-

eral features/assets or they can share some technol-

ogy features in their core functionalities (Marinho

et al., 2013). However as many limitations of SPL

are solved with the introduction of this new approach,

many other issues are introduced with the use of

MSPL. These problems are mainly caused by the lack

of real application as a lot of open issues still make

the management of this technique really hard. For ex-

ample working with software product lines made by

different organisations or companies it is really com-

plex as they can rely on different architecture or they

can be designed in a different way. For this reason

the degree of reuse depends on how many SPLs are

used to derive the ﬁnal product. Additionally there are

no tools available for the management of a MSPL as

most of SPLs tool are extended with MSPL function-

alities which does not guarantee a complete and sat-

isfying management of the MSPL. Developers are so

forced to adapt and to interface SPLs tools to achieve

a satisfying level of usability and maintenance with a

MSPL. Finally it is possible to notice that automating

this entire process is still an open issue as it is really

complex to make decision upon the selection order of

470

Ardimento, P., Boffoli, N. and Superbo, G.

Multi Software Product Lines: A Systematic Mapping Study.

DOI: 10.5220/0009469804700476

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 470-476

ISBN: 978-989-758-421-3

the components available from different SPLs.

The goal of this paper is to achieve an overview of

the ﬁeld of MSPL and the authors, at this aim, choose

to accomplish a systematic mapping of the existent

literature (Kitchenham et al., 2010). In general, a sys-

tematic mapping study structures the type of research,

reports and results that have been published by cate-

gorizing them and yields a visual summary, system-

atic map, of its results. In this work, the map built and

the related discussion of the ﬁndings aim to support

understanding what has been addressed by the MSPL

community for the MSPL domain and to suggest fu-

ture research guidelines in this ﬁeld.

The reminder of this paper is structured as fol-

lows: section 2 describes the research methodology

used for the mapping study carried out in this work,

from establishing the research questions to the result-

ing systematic map. After this, in Section 3 there is

the analysis and discussion of the results extracted

during the mapping study. Section 4 discusses the

threats to validity of our study. Finally, Section 5

summarizes the main contribution of this paper and

discusses some directions that could be investigated

by the research community.

2 RESEARCH METHODOLOGY

To accomplish all the preﬁxed goals, the authors have

adopted Kitchenham’s approach for performing a sys-

tematic mapping study (Kitchenham et al., 2008).

This method is helpful to reach the goals of the pa-

per if there is enough available content for a speciﬁc

topic: all the ﬁnal results exploit which areas need to

be still explored and studied. Figure 1 shows all the

steps of the systematic mapping process.

Figure 1: Mapping Process.

In the follows of the section, steps from 1 to 5 are

described in details and applied to the mapping of the

MSPL literature.

2.1 Deﬁnition of Research Questions

In the ﬁrst step, the scope of this study is character-

ized. According to these initial suppositions it is pos-

sible to develop a schematic guideline of which ques-

tions are going to characterize the research:

• RQ1: Which MSPL life-cycle step affecting vari-

ability is covered by the research community?

• RQ2: Which of the found topics are less covered

and could be considered still ”open issues”?

From the results extracted through the systematic

mapping, we can infer which problems are not tack-

led inside the research works and require more so-

lution proposals. Moreover, after having populated

the classiﬁcation scheme, different facets can also be

combined to answer more speciﬁc research questions:

• RQ3: Concerning each topic, which level of em-

pirical evidence is reached by researchers’s solu-

tions for each speciﬁc problem?

• RQ4: Concerning each topic, which type of in-

novation (metric, tool, model, method, process) is

needed to recognize an issue as ”closed”?

2.2 Conduct Search for Primary Studies

After introducing the systematic mapping method in

general, here it will be applied to the paper context in

order to extract useful information from the research

community. First of all it is necessary to choose a sub-

set of search string according to two of Kitchenham’s

criteria (Kitchenham et al., 2008):

1. Population: Multiple software product line, soft-

ware product line, hierarchical software product

line, nested software product line;

2. Intervention: variability management.

Following this criteria, it is possible to obtain a very

speciﬁc search string. However, since a search bar

of a Web browser has a limit of 150 characters, the

search string was split in 3 sub-strings:

1. ”Multi product line” OR ”Multi Product lines”

OR ”Multi product family” OR ”Multi product

families” OR ”Multi software product line” OR

”Multi software product line” OR ”Multi software

product lines” OR ”Multi software product fam-

ily” returned 595 results from 2010.

2. ”Multi software product families” OR ”Multiple

product line” OR ”Multiple product lines” OR

Multi Software Product Lines: A Systematic Mapping Study

471

”Multiple product family” OR ”Multiple prod-

uct families” OR ”Multiple software product line”

OR ”Multiple software product lines” returned

2170 results from 2010.

3. ”Multiple software product family” OR ”Multi-

ple software product families” OR ”Product line

of product lines” OR ”Nested product lines”

OR ”Hierarchical product line” OR ”Hierarchical

product lines” returned 93 results from 2010.

Basically the search string should select any paper re-

garding the variability management aspect of MSPL.

All the initial papers were selected by searching any

content in scientiﬁc virtual libraries. The previous re-

search tokens were applied on one of the richest Web

search engine for scientiﬁc papers, technical reports,

theses and books: Google Scholar. This free access

powerful tool let anyone to customize the research in

terms of time and number citations. In this way it

is possible to select only the relevant content in a spe-

ciﬁc interval of time. In the speciﬁc case of this paper,

time interval for the research is set to 2010 to current

days as the MSLP concept was deﬁned only in these

last years of research. Once the search engine returns

all the results, it is possible to select from them only

the ones coming from sources like ACM, IEEE, Else-

vier, Springer. Additionally it is also possible to se-

lect content from ofﬁcial conferences on that speciﬁc

topic. In this case two of the most related conference

on the paper topic are SPLC (Software Product Line

Conferences), which started in the early 2000s, and

VaMoS (Variability Modelling of Software-Intensive

Systems). During these conferences several work-

shops are held. In SPLC 2013 the organization held

a workshop upon MSLP called MultiPLE2013 from

which it is possible to select valid content. Unfor-

tunately even if during SPLC 2014, MultiPLE2014

was again scheduled, it was cancelled due several rea-

sons. During the analysis all the content coming from

this workshop will be considered part of SPLC as this

workshop was held during this conference.

2.3 Screening of Papers

To reduce the corpus and enable this study’s repro-

ducing, the following inclusion criteria and exclusion

criteria were established.

Inclusion criteria:

• Peer-reviewed studies published in journals, con-

ferences, and workshops.

• Studies are accessible electronically.

• From title, abstract, and keywords we can deduce

if the paper focuses on contributing MSPL.

Exclusion criteria:

• Studies not available in English.

• Studies to be excluded from a systematic peer-

review, such as websites, books, slides, teasers,

curricula, short papers and editorials of less than

two pages.

• Studies where MSPL is mentioned as future ap-

plication, related work, or broad context only.

We applied both the criteria to the following meta-

data: abstract, title and keywords. This step aims at

eliminating only the publications clearly not within

our study’s scope and publications failing on formal

requirements (such as being available in English). It

was necessary to discard most of the documents from

the results of the queries as most of them are not re-

lated with the paper main topic. Anyway, all studies

with any doubt about their relevance to the study topic

were included to be evaluated in the next step on the

base of their full text. At the end of this step we ob-

tained the results shown in table 1 where the main

sources that contribute to the paper goal are listed.

Table 1: Resulting Papers.

PAPERS (2010-2019)

ACM 6

Elsevier 5

IEEE 9

SPLC 11

Springer 6

VaMoS 5

Others 7

TOTAL 49

2.4 Keywording using Abstract

After ﬁltering the relevant content from the entire

research community, the authors read all the collected

paper to make a double check if they are really

relevant to the paper goal and to classify the relevant

ones. The classiﬁcation scheme was made by a set

of categories representing the underlying population.

To exploit all the covered aspects of MSPL by the

research community, the classiﬁcation scheme was

composed of three aspects which are MSPL Topics,

Evidence and Innovation.

Facet 1: Topics of MSPL. Nevertheless as MSPL

differs from SPL, they share the same core idea: vari-

ability management. This crucial aspect means, as

the term suggests, managing variability in software

ﬁnal artifacts. This occurs obviously during the en-

tire lifecycle of the product line as it is really impor-

tant to track every change in variability points in or-

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

472

der to avoid obsolescence inside the SPL (more de-

tails in (Clements and Northrop, 2002)). This task

is even harder in MSPL as more SPLs are involved

in the variability management. These crucial life-

cycle steps of SPL are a good guideline to analyze

how MSPL can be organized in the same way, there-

fore such steps have been chosen as MSPL variabil-

ity topics because they could be considered a strong

landmark for the classiﬁcation of all existent papers

related to MSPL. This facet aims to address the dis-

cussion of RQ1, RQ2 and it is structured as follows:

• Domain Engineering: in the early stages of the de-

velopment of a PL, as in every software life-cycle,

developers collect information from stakeholders

regarding the domain. In this way it is possible to

target which are the common and variant assets,

along with their feature modeling and evaluation

of the product line scoping (a.k.a. domain analy-

sis);

• Product Derivation: once an abstract view of the

domain is established thanks to the previous step,

it is time to focus on variability in software archi-

tecture modeling and construction. This means

that in order to establish a working PL, it is

mandatory to design different compositions of

common and variant assets according to the re-

quirements collected previously (a.k.a. architec-

ture design);

• Product Conﬁguration: as it occurs in every de-

velopment process, also in the PL life-cycle there

is a step where each ﬁnal product is conﬁgured by

selecting certain parameters and variables accord-

ing to each operative context (a.k.a. implementa-

tion);

• Product Line V&V: in order to guarantee a good

level of quality of the ﬁnal artifact, developers fol-

low several rules and constraints to design optimal

test cases which are always based upon the opera-

tive context of the ﬁnal product (a.k.a. veriﬁcation

and validation);

• Product Line Maintenance: once the product is

released and ﬁnally executed, as it happens for

every software product, there is the most expen-

sive phase of a product life-cycle: maintenance.

In this context maintainers focus on keeping track

of versions, dealing with changes in requirements

at all abstraction levels and correct any issue re-

lated with the use of any ﬁnal artifact (a.k.a. evo-

lution and change).

Facet 2: Evidence. Evidence facet aims to support

the discussion about the RQ3. We adopted the exist-

ing classiﬁcation deﬁned by (Wieringa et al., 2006),

in this way it is possible to categorize all the papers as

follows (each paper was classiﬁed to belong to exactly

one research type):

• Early Research Advanced (ERA) Paper: a paper

with a new way of looking at existing issues, in-

cluding surveys, mapping studies and systematic

reviews.

• Solution Proposal Paper: a novel solution for a

problem is proposed or it can be a signiﬁcant ex-

tension of an existing technique. The potential

beneﬁts and the applicability of the solution can

be explained by means of an illustrative example.

• Validation Paper: novel solutions are investigated

(for example, by means of a controlled experiment

in a laboratory), hypotheses are stated and statis-

tics are shown but they are not evaluated yet in a

real world project.

• Evaluation Paper: solutions are applied in a real

world project and an empirical evaluation is con-

ducted to prove their efﬁcacy in a rigorous way,

based on measures collected in a real context.

• Experience Report: the paper simply reports the

practical experience whether some technique or

methodology is good or bad inside a real context

(industrial or laboratory).

Facet 3: Innovation. To address RQ4, we classiﬁed

the publications according to the innovative solution

proposed to solve a speciﬁc open issue, such classiﬁ-

cation is inspired by (Petersen et al., 2008):

• Overview: which includes surveys, mapping stud-

ies and systematic reviews;

• Process/method: which includes a workﬂow of

activities, rules or procedures about how things

should be done (i.e. how to recognize common

and variant assets);

• Model: deﬁning a formal abstraction of variability

details and related semantics and notations;

• Metric: describing a metric plan to measure vari-

ability at different levels;

• Tool: developing a software tool that support dif-

ferent aspects of MSPL variability.

2.5 Data Extraction and Mapping

Process

As soon as all the related papers were classiﬁed prop-

erly, a systematic map is built (ﬁgure 2). Thanks to

this plot, it is now possible to have statistics about

each category content and sketch an overview of how

the research community covered MSLP topic. By

Multi Software Product Lines: A Systematic Mapping Study

473

looking at the schematic map it is possible to see

which are the most covered subtopics and the ones

that lack of content.

More precisely all the papers characteristics are

categorized in a bubble plot. This plot is made up

of two two-dimensional (x-y) scatter-plots with fre-

quency bubbles for each intersection. The ﬁrst one

connects all the innovation facet with all the steps of

MSPL process. Meanwhile in the second plot there

is the conjunction between evidence facet and steps

of MSPL process. The bubble size is directly propor-

tional to the number of papers that are characterized

by the intersection of any two categories. Finally it

is important to point out that the total number of the

frequencies is not the same as the total number of the

papers as they may have different facet.

3 MAIN FINDINGS

Supported from the systematic map (ﬁgure 2), the ﬁ-

nal results of the systematic mapping process can be

analyzed and discussed in this section in order to ad-

dress the research questions reported in 2.2.

RQ1: ”Most Covered MSPL Steps”. By looking at

”MSPL topic” of the systematic map it is possible to

notice that: 27 papers (55.10%) focused on domain

engineering; 30 papers (61.22%) focused on product

derivation; 23 papers (46.93%) focused on product

conﬁguration; 9 papers (18.36%) focused on prod-

uct line V&V; 6 papers (12.24%) focused on prod-

uct line maintenance. As it is possible to see from

the statistics domain engineering and product deriva-

tion are the most covered topic in this paper research.

This means that researchers started of course to mine

the topic by starting from the ﬁrst crucial steps of

MSPL development. According to the map in ﬁg-

ure 2 many researchers provided their own innova-

tive contribution in these two topic mainly in terms of

process/method or model. Additionally, it is possible

to observe from the corpus references (see ??) that

these two topics are often covered at the same time,

also product conﬁguration is covered well enough and

with this topic it is possible to ﬁnd a strong relation

to product derivation as they are strictly linked and

studied at the same time. So, we can realize that in

general, steps that in the lifecycle are strongly con-

nected to each other are often dealt simultaneously in

the same paper.

RQ2: ”Less Covered MSPL Topic”. What is not

enough covered by activity research, is for sure the

last two phases of the development cycle: product

line V&V (9 papers, 18.36%) and product line main-

tenance (6 papers, 12.24%). Regardless of the in-

novation and the evidence facets, V&V and mainte-

nance remain the current open issues in the research

ﬁeld, this might suggest that testing, ﬁxing and evolv-

ing a MSPL could be valid topics that can be inves-

tigated more deeply. This lack of content is probably

related to the challenges of domain engineering and

product derivation that are still being discussed. For

this reason it is possible to recognize a priority pattern

among the MSPL topics: once domain engineering

and product derivation are going to have standardized

approaches, research community will probably focus

their attention on the maintenance and testing side (in

fact, such papers have been published only in the last

ﬁve years).

RQ3: ”Level of Empirical Evidence”. Here there

is an average distribution between three of ﬁve facets

as solution proposal, validation papers and evalua-

tion papers are nearly equally distributed: 14 papers

(28.57%) were solution proposal; 16 papers (32.65%)

were validation papers; 13 papers (26.53%) were

evaluation papers. This means that researchers were

focused on testing approaches, trying solving prob-

lems and even conducting empirical validation as 13

papers were evaluation papers. On the other hand

it was possible to retrieve only 2 experience reports

(4.08%) and 4 ERA papers (8.16%): the cause of the

lack of the ﬁrst kind of papers is related maybe to the

lack of real application of MSPL. Meanwhile for the

ERA papers the lack of content is related to the lack

of necessity in writing this typology of paper about

MSPL ﬁeld (number of papers to investigate in this

ﬁeld was low).

RQ4: ”Innovation Needed”. Speaking about in-

novation facet 35 papers (71.42%) provide a new

process/method; 16 papers (32.65%) provide a new

model; 12 papers (24.48%) provide a new tool; 9

papers (18.36%) provide a new metric; 3 papers

(6.12%) provide an overview on the topic. Many re-

searchers have been focused on proposing new pro-

cesses/methods to solve all the open issues regarding

MSPLs. Despite of this, a third of the papers con-

tributed also with a new model that helped this young

development approach to be recognized and used in

the software industry. Additionally many tools and

extensions of theme were proposed to make the use

of this approach less complex. Nonetheless there is

a low quantity of metrics paper as it is still complex

to measure precisely the variability at different lev-

els. Finally overview paper are only two for the same

reason of the low quantity of ERA papers.

In conclusion, in the last decade many new ap-

proaches were designed and even used in real use

cases. By looking at these new approaches, it is very

easy to observe that most of them are strictly related

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

474

Figure 2: Topic coverage according to the Innovation and Evidence facet.

to the most common topics among the available pa-

pers on MSPLs: “Processes/Methods” regarding the

innovation facet and “Validation” regarding valida-

tion paper. Hence it is obvious that there is a strong

trend emerging from the research community: ﬁnding

a practical and pragmatical use of the MSPL. In addi-

tion to this, it is also clear that Delta-oriented Multi

Software Product Lines (Damiani et al., 2014), IN-

VAR approach ”plug-and-play” for variability models

(Dhungana et al., 2011) and AGILE product line en-

gineering applied to MSPLs (Hayashi and Aoyama,

2018) are example of practices/processes that have

been tested on real use cases simulations. Most of

the new approaches focuses on the crucial steps of a

solid MSPL: Core Assets Development and Product

development.This underlines that a successful MSPL

can be achieved only if a good basis is established.

4 THREATS TO VALIDITY

To judge the quality of our work it is necessary to dis-

cuss the following threats to the validity of the study.

Construct Validity. The ﬁndings presented in section

3 are valid only for our sample of papers. Hence, we

ensured the inclusion of as many relevant papers as

possible. To achieve this, the research tokens were

applied to the Google Scholar digital library in or-

der to capture venues not published at the other li-

braries. Then, we applied the research tokens also

to the main repositories of resources dealing with the

selected topic. Furthermore, we did not restrict our

search to papers mentioning “Multi Software Prod-

uct Lines” explicitly but also included terms closely

related to MSPL, without narrowing it to the exact

terms. This enabled us to capture related publications

without focusing on the very speciﬁc, partly ambigu-

ous, modeling terminology. Another threat avoided

regards the deﬁnition of the inclusion/exclusion crite-

ria in the screening activity. We decided to consider

the title, abstract, and keywords metadata. We also

decided to include all papers we were uncertain in or-

der to avoid the exclusion of relevant publications due

to the lack of investigation. In the next step, ﬁrst, all

the papers were read and, then, inclusion/exclusion

was decided. Finally, to improve construct validity

in the future we should consider also the papers that

do not use the term “multiple software product line”

even though they are clearly discussing MSPL do-

main modeling techniques, for example among the

main works of this type there are (Bagheri et al.,

2011) (Hubaux et al., 2013) (Urli et al., 2014).

Internal Validity. To mitigate the threat related to

the data extraction performed for screening (inclu-

sion and exclusion criteria) and classiﬁcation, the

authors decided to discuss the problematic papers

among them. The classiﬁcation was performed in

blocks of at most 45 minutes broken up by at least

15-minute breaks in order to avoid the threat arising

from fatigue. The adopted classiﬁcation scheme com-

prises three facets that correspond to the four deﬁned

research questions.

Conclusion Validity. Regarding the conclusions, we

have discussed various issues that could lead to wrong

conclusions in the context of threats to internal and

external validity. For the study’s replicability, we

detailed the complete research method in section 3,

which enables replicating every phase of this mapping

study.

External Validity. Obtained results cannot be gener-

alized to other problems domains.

Multi Software Product Lines: A Systematic Mapping Study

475

5 CONCLUSIONS

In this paper, we present the results from a systematic

mapping study in the ﬁeld of Multiple Software Prod-

uct Lines (MSPL). This paper summarizes interesting

insights into the state of the art with the aims of:

• understanding what are the most covered topics of

the research in MSPL;

• highlighting the open issues that need to be ﬁlled

by future research;

• evaluating the level of empirical evidence reached

by researcher’s solutions addressing the topics,

• identifying which types of innovations are most

needed today

Our classiﬁcation scheme reﬂects the historical back-

ground of multi software product lines in the period

2010-2019 and it follows the taxonomy of the life-

cycle steps of a product line. Our study highlights

how, currently, researchers mainly aim at developing

innovative contributions in terms of methods, mod-

els, and tools. Anyway, as the MSPL ﬁeld is still in

a young stage, most of these papers are only a de-

scription of approaches that are most validated in a

testing scenario. Their efﬁcacy is not still based on

empirical evidence. There are no papers, in fact, that

clearly describe a real validation through detailed ex-

perimental design, data collection process and valid-

ity threats analysis. Therefore, according to our study,

community research is called to bridge the gap of the

evidence-based research, to increase the investigation

of maintenance and V&V of MSPLs and, ﬁnally, de-

ﬁne standard models and metrics to evaluate the efﬁ-

cacy of the MSPLs.

REFERENCES

Bagheri, E., Ensan, F., Gasevic, D., Boskovic, M., et al.

(2011). Modular feature models: Representation and

conﬁguration. Journal of Research and Practice in

Information Technology, 43(2):109.

Clements, P. and Northrop, L. (2002). Software product

lines. Addison-Wesley Boston.

Damiani, F., Schaefer, I., and Winkelmann, T. (2014).

Delta-oriented multi software product lines. In Pro-

ceedings of the 18th International Software Product

Line Conference-Volume 1, pages 232–236.

Dhungana, D., Seichter, D., Botterweck, G., Rabiser, R.,

Grunbacher, P., Benavides, D., and Galindo, J. A.

(2011). Conﬁguration of multi product lines by bridg-

ing heterogeneous variability modeling approaches. In

2011 15th International Software Product Line Con-

ference, pages 120–129. IEEE.

Hayashi, K. and Aoyama, M. (2018). A multiple prod-

uct line development method based on variability

structure analysis. In Proceedings of the 22nd

International Systems and Software Product Line

Conference-Volume 1, pages 160–169.

Hubaux, A., Heymans, P., Schobbens, P.-Y., Deridder, D.,

and Abbasi, E. K. (2013). Supporting multiple per-

spectives in feature-based conﬁguration. Software &

Systems Modeling, 12(3):641–663.

Kitchenham, B., Al-Khilidar, H., Babar, M. A., Berry,

M., Cox, K., Keung, J., Kurniawati, F., Staples, M.,

Zhang, H., and Zhu, L. (2008). Evaluating guidelines

for reporting empirical software engineering studies.

Empirical Software Engineering, 13(1):97–121.

Kitchenham, B., Brereton, P., and Budgen, D. (2010).

The educational value of mapping studies of soft-

ware engineering literature. In Proceedings of the

32nd ACM/IEEE International Conference on Soft-

ware Engineering-Volume 1, pages 589–598. ACM.

Krueger, C. W. (2006). New methods in software prod-

uct line development. In Software Product Lines,

10th International Conference, SPLC 2006, Balti-

more, Maryland, USA, August 21-24, 2006, Proceed-

ings, pages 95–102.

Marinho, F. G., Andrade, R. M., Werner, C., Viana, W.,

Maia, M. E., Rocha, L. S., Teixeira, E., Ferreira Filho,

J. B., Dantas, V. L., Lima, F., et al. (2013). Mobi-

line: A nested software product line for the domain

of mobile and context-aware applications. Science of

Computer Programming, 78(12):2381–2398.

Petersen, K., Feldt, R., Mujtaba, S., and Mattsson, M.

(2008). Systematic mapping studies in software en-

gineering. In Ease, volume 8, pages 68–77.

Pohl, K., B

ockle, G., and van Der Linden, F. J. (2005).

Software product line engineering: foundations, prin-

ciples and techniques. Springer Science & Business

Media.

Urli, S., Blay-Fornarino, M., and Collet, P. (2014). Han-

dling complex conﬁgurations in software product

lines: a tooled approach. In Proceedings of the

18th International Software Product Line Conference-

Volume 1, pages 112–121.

Wieringa, R., Maiden, N., Mead, N., and Rolland, C.

(2006). Requirements engineering paper classiﬁcation

and evaluation criteria: a proposal and a discussion.

Requirements engineering, 11(1):102–107.

CORPUS OF REFERENCES

The paper references that belong to

our corpus can be found at the URL:

https://www.uniba.it/docenti/ardimento-pasquale/arti

colo/view or it can be required by sending an email to

the authors.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

476
