Understanding Query Interfaces: Automatic Extraction of Data from

Domain-specific Deep Web based on Ontology

Li Dong, Zhang Huan and Yu Zitong

China Electronic Product Reliability and Environmental Testing Research Institute, Dongguanzhuang Road No.110,

Guangdong province, China

https://www.ceprei.com/

Keywords: Deep Web Mining, Domain Ontology, Schema Extraction, Query Transformation.

Abstract: The resources of many Web-accessible databases, which are a very large portion of the structured data on the

Web, are only available through query interfaces but are invisible to the traditional search engines. Many

methods, which discovery these resources automatically, rely on the different structures of Web pages and

various designing modes of databases. However, some semantic meanings and relations are ignored. Here we

introduce a Web information retrieval system that obtains the knowledge from multiple databases

automatically by using common ontology WordNet. Also, deep Web query results are post-processed based

on domain ontology. That is, given an integrated interface, after inputting a query, our system offers an

ordered list of data records to users. We have conducted an extensive experimental evaluation of the Web

information retrieval system over real documents. Also, we test our system with hundreds of databases on

different topics. Experiments show that our system has low cost and achieves high discovering accuracy

across multiple databases.

1 INTRODUCTION

As the Web resources from the complex WWW

continues to grow at a high speed, the problem of

efficient and accurate mining from such an

environment also keeps growing. One especially

importance facet of this problem is the ability to not

only locate and access data on the Web which is

hidden from typical search techniques, but also

effectively integrate a unified query interface which

accepts the queries from one local form, and fill the

queries back to the local forms from multiple

databases. Indeed, many online network databases,

which have a larger amount of data, are hidden behind

the query interface in Web pages. Instead of

specifying a URL to send an HTTP request to get the

static page information, accessing hidden Web (deep

Web) resources need to submit queries to the query

interface provided by the website. The query interface

is the entrance to get the Web database information.

Even some resources in hidden Web sites have some

links that can be indexed by a traditional search

engine, they may have much more information

accessible only through the query interface, as the

following example illustrates.

Example 1. In the past decade, a database Science

Citation Index Expand

from Institute for Scientific

Information (ISI) makes article information with

high-quality about 8300 major journals across 150

disciplines accessible through the Web. If we query

the database for articles with “deep Web”, then the

database returns 1590 matches. The articles are stored

locally at the database rather than distributing over

the Web. That is, the high-quality articles of SCI can

not be reached by traditional search engines. Even

though some articles can be indexed by static links, it

is because there are navigation bars linking to the

articles whose resource providers are not SCI as well.

In this paper, we concentrate on accessing to a

variety of databases and discovering valuable

information automatically. More specifically, for our

purpose lots of information on a specific domain

across different databases is achievable through

source queries and a unified integrated interface.

Because of the heterogeneity and autonomy of each

database in deep Web (Shestakov, Bhowmick, and

Lim, 2005), completely accurate query

transformation cannot be achieved. So, how to

guarantee the similarity between the returning queries

in local forms and the source queries to the greatest

Dong, L., Huan, Z. and Zitong, Y.

Understanding Query Interfaces: Automatic Extraction of Data from Domain-speciﬁc Deep Web based on Ontology.

DOI: 10.5220/0009514202410248

In Proceedings of the 22nd International Conference on Enterprise Information Systems (ICEIS 2020) - Volume 1, pages 241-248

ISBN: 978-989-758-423-7

241

extent is a challenging work. Many researches on

automatic deep Web discovery have been done

(Madhavan et al. 2007; Hong, He, and Bell 2009; He,

Hong, and Bell 2009; An et al. 2008). He et al (2003;

2005; 2007) presented an interface layout expression

called IEXP according to the location layout of labels

and query control elements in query interface, and

developed an extraction tool called WISE-IExtractor

to get query interface schema. Liu et al. (2010)

proposed an approach which primarily utilizes the

visual features on the deep Web pages to implement

deep Web data extraction, including data record

extraction and data item extraction. He et al. (2004)

built a statistical model which adopted a positive

correlation and a negative correlation mining

algorithm finding out the hidden complex matching

patterns to analyze the frequency and pattern of

attribute names occurring at the same time. Fan et al.

(2011) proposed a query transformation based on

predicate template. Our contributions are summarized

as follows:

• Domain ontology is built under the guidance of

domain specialists. In order to guarantee the

correctness of ontology, we built the ontology

manually. Besides, in the process of using ontology,

it is updated and improved automatically and

continuously.

• The research on schema extraction from deep

Web query interface is a key step in hidden Web

resources mining. A novel approach to extract

interface schema from deep Web based on domain

ontology is presented, in which a new presentation of

query interface attribute is proposed.

• In addition, it is hard to avoid submitting

repeated attribute information in these queries which

wastes lots of time and energy. Therefore, in order to

visit multiple databases in the same time and get

useful information through comparing and screening

returning results, it is of great significance to match

multiple attributes in different interfaces and integrate

a unified query interface from view of efficiency.

Most traditional integrated methods of deep Web

interface obtain mapping relations based on abundant

statistics. They not only need lots of sample spaces,

but also ignore some semantic relations between

attributes. A two-phase pattern matching approach

based on ontology is defined to achieve matching

between form attributes and knowledge in ontology.

The matching results are used to update the ontology

and simplify the following matching process. An

integrated query interface is generated according to

the obtained mapping relations and schema

information.

• Query transformation, where the query requests

are submitted to multiple destination query interfaces

selected by a specific domain, is a critical component

of deep Web integrated system. This paper presented

a type-driven minimum superset query

transformation based on ontology. The predicate

templates with constraints and four types of predicate

processors are proposed in the query transformation,

in which automatically transforming one query in the

integrated form to the multiple queries in the

destination query forms is achieved.

• Due to the different styles of data records

extracted from multiple databases, post-processing is

an important part to organize, simplify, and convert

these kinds of data records into a unified structure. In

the part of building domain ontology, BIM and

RSEM are adopted to obtain the feature vector of

domain books. In the part of extracting information,

Web pages are first parsed using HTML parser. Then

HTML tree is obtained after getting rid of information

that users do not interested in, such as ads or

navigation and so on. Finally, the relevant data blocks

in HTML tree are extracted, ranked and stored.

2 EXTRACTION OF INTERFACE

SCHEMA

An imperative step of discovering information in

deep Web is interface schema extraction, which finds

out the common characteristics in query interfaces

from two perspectives, the internal code and visual

unit.

Based on the controls in the query interface, texts

associated with controls, and the characteristics of

layout, the tags which locate in <form> and </form>,

are divided into three kinds. The definitions of tags

are as follows:

Definition 1. Control Tag (CT) is used to receive

the query value which is input from users and mainly

described with <input></input> and

<select></select>. CT has formalized representation

of a tuple

{,,, , }CT name type id value location



Definition 2. Text Tag (TT), a string in HTML

form, is used to prompt the content of input

information associated with the control. TT has

formalized representation of a tuple

{, }TT name location



Definition 3. Layout Tag (LT) is used to illustrate

the location of label in the form. They are mainly

represented by <tr>, <td>, <th> and <table>, and

so on. The purpose of layout tag is to fill location in

Control Tag and Text Tag. Location is the

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

242

coordinates that can record the row and column

position of tags.

Users can actually see the query interface from a

visual point of view, and it does not involve the

internal code. We can divide query interface into

three visual units according to three aspects: semantic

interpretation (some label text), input value and

constraint selection.

Definition 4. Text Unit (TU) is usually seen as a

label of query interface attribute, which is used to

demonstrate the semantic meaning of the control

value.

Definition 5. Value Input Unit (VU) refers to a

text box and a drop-down list used for receiving user

input or selecting a value.

Definition 6. Constraint Selection Unit (CU) is

defined as a set of radio buttons or check boxes in

query interface.

Consider the presentation of attributes (a

combination of TU, VU and CU), we define Form

Attribute as follows:

Definition 7. Form Attribute (FA), which shows

the query capability of a query interface, has the

corresponding TU for semantic interpretation, the

VU for inputting query and CU for constraints. The

formalized representation of FA in Equation (1) as

follows:

{,{ },{ }}

FA TU VU CU

(1)

The set of VU may be empty, or have one or more

elements. The set of CU only has two representations,

one is empty, and the other one is the set only has one

CU.

Many Form Attributes need to combine with each

other by virtue of some semantic relationship. In this

paper, we use domain ontology to guide the

combination of text information in FA

and define

Form Final Attribute in query interface.

Definition 8. Form Final Attribute (FFA) is a

representation of combination between FAs, and the

semantic relations between attributes guided by

ontology. It can be formalized representation in

Equation (2).

{.,{ }, }

FA O c FA Rel

(2)

where

.Oc

is the related concepts in domain

ontology,

{}

is a set of FAs,

Rel

is the semantic

relationship between each pair of

{}

Finally, we give a definition of Interface Schema

which is used to automatically fill out the related

information and then integrate a unified query

interface.

Definition 9. Interface Schema (IS) is not only a

representation of general query interface forms and

the result of extraction of query interface schema, but

also the data processed by deep Web query interface

integration for the follow-up work. It can be

formalized representation in Equation (3).

{, , , ,{ }}

IS url action method name FFA



(3)

where, url is the URL address of the interface,

action is the address in which one program (usually a

CGI script) deals with the form, method is the data

transmission mode, which has two options, GET and

POST, name is the internal name of the form.

Figure 1 shows the schema extraction framework

of deep Web query interface. During the process of

schema extraction, a detailed description contains

five key steps, as described below.

• Locating: Based on some observations and

statistical heuristic rules, we filter out the

<form></form> segments that are not query

interfaces, and try to locate the query interface in Web

pages. Finally, we can get the internal code segments

of query interface.

• Parsing: We obtain attribute information of

each tag node in the query interface based on parsing

the form. Parsing means reading valid data units in

proper order and performing the corresponding

process by identifying the feature of data unit.

• Form Attribute Extraction: Based on the visual

character of layout and string similarity (Lin, Lyu,

and King 2012) of tags and internal controls’ names,

we extract Form Attribute first time.

• Final Form Attribution Extraction: Many

Form Attributes are not independent, and their text

tags have semantic relations. It will be friendlier and

have better semantics if we combine some Form

Attributes who have semantic relations as a query

condition. Through the guiding of domain ontology,

we can add the semantic relations into the process of

combining Form Attributes and then get the Final

Form Attribute.

• Getting Interface Schema: We get Interface

Schema using the set of Final Form Attribute and the

information of form such as name, method and action.

Finally, the extraction of query interface schema is

completed.

Understanding Query Interfaces: Automatic Extraction of Data from Domain-speciﬁc Deep Web based on Ontology

243

HTML D oc ument

Query Interface

heuris tic rules

TU-S ets VU-Sets

CU-Sets

Parser

FA-S ets

Extracting

FFA-S ets

Domain

Ontology

Query Interface

Schema

{author, text, (contains)}

{title, text, (contains )}

{subject, select, (contains)}

Figure 1: The schema extraction framework of deep Web

query interface.

3 HOW TO INTEGRATE A

UNIFIED INTERFACE

We now turn to the central issue of automatically

discovering domain-specific information in deep

Web, that is, integrating a unified ontology-based

query interface on the basis of a two-phase matching

method (direct matching and indirect matching), as

described below.

Direct matching means that the elements in the

form match the information in ontology based on

keywords that refer to the words preprocessed and

stored in word linked list. Direct matching process not

only considers attribute tags, but also considers

attribute values. Different specific domains have

different representations of synonymous attributes,

but they may have the same attribute value. So, the

correct meaning of attributes can be inferred by the

attribute value. Based on this inference, we can get

more possible matches by attribute value after

matching by attribute tags.

However, direct matching can not identify all the

matchable concepts. Under this condition, indirect

matching algorithm identifies matchable concepts by

calculating the similarity between form attribute

elements and ontology concepts. Because one

concept may have several words, we describe two

calculating methods: word similarity measure and

concept similarity measure.

Word Similarity Measure: word similarity is

calculated by common ontology WordNet. In

WordNet, all concepts are represented as single words

instead of phrases. If two words in WordNet are

defined as similar relationship, then the similarity

between them is 1. Otherwise, the similarity between

them is calculated by Equation (4) below:

12 1 2

() ()

(, )

(, )(() ( )1)

pw pw

wdSim w w

SemOverw w hw hw







(4)

where, |p(w

)∩p(w

)| refers to semantic matching

degree of words w

and w

, SemOver(w

, w

) is

semantic distance of w

and w

, h(w) means depth of

word w.

Concept Similarity Measure: each concept may

consist of several words. Given two concepts: c

and

, for each word in c

, the algorithm calculates the

similarity between c

and each word in c

and stores

the largest similarity. Equation (5) can calculate the

concept similarity.

_max

(, )

()

wdSim w w

cnSimMid c





(5)

where

_max

(, )

wdSim w w





refers to the largest

similarity between word w

in c

and the word in c

. n

means the number of words in c

. Then the similarity

of c

is calculated in the same way. We can get the

final concept similarity with Equation (6) as follows.

() ()

(, )

cnSimMid c cnSimMid c

cnSim c c





(6)

Example 2. Assume that the similarity matrix

(

CSM



) of c

and c

is shown as follows:

11 12

0.19 0.25

0.33 0.55













CSM





According to Equation (5), the similarity of c

and

is described below:

111221222

() (( ( , ) ( , ))/2

(0.33 0.55) / 2 0.44

cnSim mid c wdSim w w wdSim w w

 

221122212

() (( ( , ) ( , ))/2

(0.25 0.55) / 2 0.4

cnSim mid c wdSim w w wdSim w w

 

Then according to Equation (6), the concept

similarity between c

and c

is cnSim(

) = (

()cnSim mid c

)/2=(0.44+0.4)/2

=0.42.

4 AUTOMATIC QUERY

TRANSFORMATION

In this section, we illustrate the function of query

analyzer. The specific work of query transformer is

shown in the next section. Before we describe the

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

244

specific query analyzing process, some basic

concepts are given as follows:

Definition 10. Query Transformation. Given the

query Q

in source query interface S and destination

query interface T, the query set {Q

, …, Q

}(i =

1,2,…) generated in T during the process of query

transformation must satisfy (Zhang, He, and Chang

2004):

• Q

must be an effective query in T.

•

...

QQ Q

must be as close to Qs as

possible at semantic level in order to reduce the cost

of filtering out the query results that do not meet

source query requirements.

Next, the framework of query transformation is

illustrated in Figure 2. And the specific procedures

are described as follow.

Integrated Interface

Get Integrated

Query Instances

Attribute

Matching

Mapping Table

Predicate Tem-

plate Matching

Query Rewriting

Query Submitting

Local Query

Interface Set

Ontology

Guiding

Extracting

Query Interface

Capability Schema

Figure 2: The framework of query transformation based on

ontology.

Local interface schema is obtained by schema

extractor. Under the guidance of ontology, we can get

the matching relations between attributes. Then, an

integrated form schema is generated. The relations

between local interface attributes and integrated

attributes can be recorded in mapping table at the

same time. According to the information in mapping

table, the query interface capability schema can be

found mainly by exclusive attributes in forms. After

users submit queries, we can get the value in database

and store it in ontology. Meantime, the value input by

users is stored in a global data structure as a source

query Q

delivered to the query transformer. Query

transformation is divided into simple query

transformation (1:1 matching) and complex query

transformation (m:n matching). In order to reach the

closest semantic meaning of query transformation, we

design a type-driven minimum superset

transformation algorithm based on ontology which

designs different query transformation strategies

according to the different types. And, the minimum

superset query of destination predicate template is

built under the guidance of ontology to make every

transformation on predicate reach the closest

semantic meaning. According to the obtained query

model, the predicate templates that have been filled

out are combined to one or more effective queries in

local interfaces. An effective URL is submitted

according to the attribute name and filling value

transformed in each query form.

5 POST-PROCESSING QUERY

RESULTS

Ranking query results includes ranking results that

come from multiple databases and combining

different results into an ordered result list which

makes user feel that the results all come from the

same database. The essence of ranking query results

is computing the global similarity of each result and

ranking the results based on the similarity. Global

similarity cannot be obtained by local similarity

because different databases have their own local

calculation methods. Some similarity calculation

methods are proposed in (Lu et al. 2005). In this

paper, we rank the query results based on ontology

similarity and the specific formula for each Web page

record C

is shown in Equation (7).

(, )

QSimCO



(7)

where n is the number of attributes in ontology. t

is the number of attributes in one data record. The

formula computes the weight Q

for Web page k.

We take Barnes&Noble and Amazon as an

example, suppose we search books about

C language. There are eight attributes in

the data record of Barnes&Noble and ten

attributes in the data record of Amazon. Sim(C,O) of

the former is 0.085 and Sim(C,O) of the

latter is 0.093. So Q

Barnes&Noble

=8/12+0.085=0.752 and

Amazon

=10/12+0.093 =0.926. Consequently, the

content of Barnes&Noble will layout behind the

content of Amazon because of Q

Barnes&Noble

< Q

Amazon

Making use of this ranking algorithm, a snippet of

ranking results is described in Figure 3 as follows.

Understanding Query Interfaces: Automatic Extraction of Data from Domain-speciﬁc Deep Web based on Ontology

245

Figure 3: A snippet of result after ranking.

For the mutual benefit and protection of Authors and

Publishers, it is necessary that Authors provide

formal written Consent to Publish and Transfer of

Consent ensures that the publisher has the Author’s

authorization to publish the Contribution.

The copyright form is located on the authors’

reserved area.

The form should be completed and signed by one

author on behalf of all the other authors.

6 EXPERIMENTS AND RESULTS

There are many query integration methods. Among

them, MetaQuerier is representative and outstanding

from the perspective of effectiveness and efficiency.

Thus, we select MetaQuerier as our baseline

algorithm of interface integration. Based on domain

ontology and common ontology WordNet, pattern

matching is performed in the case that the number of

interface forms is 25, 50, 75 and 100, respectively.

And the comparison matching results are shown in

Table 1.

Table 1 shows that most attributes can match in

the two-phase pattern matching process which is

based on ontology. Because of storing matching

concepts timely and updating ontology continuously,

the number of direct matching is much bigger than the

number of indirect matching, which improves the

accuracy and efficiency greatly.

Table 2 illustrates the comparison matching

results on ten topics in order to reflect the

comprehensive of the method.

Table 1: Interface matching results in domain book.

Table 1:

Interface

matching

results in

domain

bookForm

Number

Attribute

Number

Successful Matching

Number

(ontology-based)

Successful

Matching

Number

(Meta

Querier)

Identified Matching

Number

Precision

(%)

Recall

(%)

F-Measure

(%)

Direct

Matching

Number

Indirect

Matching

Number

ontology

Meta

Querier

ontology

Meta

Querier

ontology

Meta

Querier

ontology

Meta

Querier

25 147 112 28 131 147 145 95.2 90.3 95.2 89.1 95.2 89.7

50 293 215 61 258 290 282 95.2 91.5 94.2 88.1 94.7 89.7

75 411 310 77 355 403 399 96.0 89.0 94.2 86.4 95.1 87.7

100 543 400 113 480 534 527 96.1 91.1 94.5 88.4 95.3 89.7

Table 2: Interface matching results on ten topics.

Topic

Form

Number

Attribute

Number

Successful Matching

(ontology)

Successful

Matching

(Meta

Querier)

Identified

Matching

Number

Precision

(%)

Recall

(%)

F-Measure

(%)

Direct Indirect ontology

Meta

Querier

ontology

Meta

Querier

ontology

Meta

Querier

ontology

Meta

Querier

books 100 543 400 113 480 534 527 96.1

91.1

94.5

88.4

95.3

89.7

airfares 90 449 363 66 374 438 432 97.9

86.6

95.5

83.3

96.7

84.9

hotels 100 665 502 122 584 632 626 98.7

93.3

93.8

87.8

96.2

90.5

articles 100 504 337 154 444 498 492 98.6

90.2

97.4

88.1

98.0

89.2

computers 80 408 314 80 365 399 396 98.7

92.2

96.6

89.5

97.6

90.8

clothing 80 456 317 124 400 450 443 98.0

90.3

96.7

87.7

97.4

89.0

cell phones 100 590 440 135 528 583 580 98.6

91.0

97.5

89.5

98.0

90.3

music records 80 334 256 56 280 322 316 96.9

88.6

93.4

83.8

95.1

86.2

automobiles 100 342 257 60 282 322 318 98.4

88.7

92.7

82.5

95.5

85.5

movies 90 276 181 82 234 267 260 98.5

90.0

95.3

84.8

96.9

87.3

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

246

The method proposed by this paper not only

identifies simple matching but also identifies

complex matching. Table 3 shows the precision of

simple matching and complex matching on different

number of forms.

Table 3: Simple matching and complex matching results.

Form Number Simple Matching(%) Complex Matching(%)

25 96.6 83.5

50 97.2 82.4

75 97.8 83.8

100 98.6 85.3

Table 3 shows that both of them can achieve

higher precision. However, it is harder to identify the

structure of complex matching, so the precision of

complex matching is a litter smaller.

Based on domain ontology and common ontology

WordNet, query transformation is performed in the

case that the number of interface forms is 25, 50 and

75, respectively. And the comparison transforming

results using ontology and NFB are shown in Table 4.

Table 5 illustrates the transforming results on ten

topics to reflect the comprehensive of this method.

To evaluate the feasibility and efficiency of our

post-processing approach, several tests have been

conducted to test our system. Table 6 illustrates the

extracting results over 4 websites in order to reflect

the comprehensive of the method.

7 CONCLUSIONS

This paper presents an automatically discovering

system for retrieving resources across multiple

databases that are accessible in hidden Web. We

provide a comprehensive schema extraction sub-

system for extracting the interface schema, together

with interface integration sub-system for integrating

a unified query interface and query transformation

sub-system for transforming a query in the integrated

form to multiple queries in domain-specific

interfaces. The schema extraction technique involves

two perspectives, internal code and visual unit, which

serve as the foundation for integrating a unified query

interface. In the integration process, finding a

keyword-based matching concept is straightforward.

Table 4: The query transformation results in the case of different number of input forms using ontology and NFB.

Form

Number

Relevant

Query

Transform

Templates

All the Templates

Transformed

All the Templates

Transformed Correctly

Precision

(%)

Recall

(%)

F-measure

(%)

Ontology NFB Ontology NFB Ontology NFB Ontology NFB Ontology NFB

25 146 139 141 129 123 92.8 87.2 88.4 84.2 90.5 85.7

50 284 269 260 247 232 91.8 89.2 87.0 81.7 89.3 85.3

75 407 382 364 354 320 92.7 87.9 87.0 78.6 89.8 83.0

Table 5: The transforming results on ten topics.

Topic

Form

Number

Relevant Query

Transform

Templates

All the templates

transformed

All the templates

transformed

correctly

Precision

(%)

Recall

(%)

F-measure

(%)

books 75 407 382 338

354 324

92.7 95.9 87.0 79.6 89.8 87.0

airfares 90 437 415 386

374 349

90.1 90.4 85.6 79.9 87.8 84.8

hotels 100 494 479 460

435 404

90.8 87.8 88.1 81.8 89.4 84.7

articles 100 658 637 613

616 582

96.7 94.9 93.6 88.4 95.1 91.5

computers 80 387 373 357

342 322

91.7 90.2 88.4 83.2 90.0 86.6

clothing 80 436 421 404

398 361

94.5 89.4 91.3 82.8 92.9 86.0

cell phones 100 575 557 533

538 507

96.6 95.1 93.6 88.2 95.1 91.5

music records 80 327 313 299

287 263

91.7 88.0 87.8 80.4 89.7 84.0

automobiles 100 340 318 307

299 280

94.0 91.2 87.9 82.4 90.8 86.6

movies 90 265 256 212

232 195

90.6 92.0 87.5 73.6 89.0 81.8

Table 6: The extracting results over four different websites.

Website Test Number

Relevant

Number

Extracted

Number

Correct Extracted

Number

Precision (%)

Recall

(%)

F-Measure

(%)

www.barnesandnoble.com 158 154 150 143 95.3 92.9 94.1

www.amazon.com 189 180 174 168 96.6 93.3 94.9

www.chaucersbooks.com 137 129 123 118 95.9 91.5 93.7

www.chapters.indigo.ca 147 139 132 124 93.9 89.2 91.5

Understanding Query Interfaces: Automatic Extraction of Data from Domain-speciﬁc Deep Web based on Ontology

247

For the concepts that direct matching process can not

identify, we design a two-phase matching method

that calculating the semantic similarity based on

Levenshtein Distance and WordNet. We also present

a type-driven minimum superset query

transformation method utilized interface capability

schema to rewrite queries. Beside, a creative strategy

(null correspondence) is applied to improve the

efficiency of transforming. Some irrelative parts such

as ads, navigation and flash, are get rid of in the

process of reducing noisy. Basic information is

extracted to simplify final results. Finally, we

propose a ranking algorithm to present users an

ordered list of data records. Our technique is efficient

and scalable. A series of experiments show that the

method proposed in this paper is both accurate and

feasible, which could significantly and semantically

improve and enhance the hidden Web resources

discovering.

REFERENCES

An, Y. J.; Chun, S. A.; Huang, K. C.; and Geller, J. 2008.

Enriching Ontology for Deep Web Search. Lecture

Notes in Computer Science. 5181: 73-80.

Fan, W. F.; Gao, H.; Jia, X. B.; Li, J. Z.; and Ma, S. 2011.

Dynamic constraints for record matching. VLDB

Journal. 20(4):495-520.

Shestakov, D.; Bhowmick, S.; and Lim, E. P. 2005.

DEQUE: Querying the Deep Web. Data and

Knowledge Engineering. 52(3): 273-311.

He, B.; Chang, K. C. C.; and Han, J. W. 2004. Discovering

Complex Matchings across Web Query Interfaces: A

Correlation Mining Approach. In Proceedings of the

10th ACM SIGKDD International Conference on

Knowledge Discovery and Data Mining, 148–157.

Seattle, WA.

He, H.; Meng, W. Y.; and Lu, Y. Y. 2007. Towards Deeper

Understanding of the Search Interfaces of the Deep

Web. Word Wide Web Journal. 10 (2):133-155.

He, H.; Meng, W. Y.; and Yu, C. T. 2005. Constructing

interface schemas for search interfaces of Web

databases. In Proceedings of the 6th International

Conference on Web Information Systems Engineering,

29-42. New York.

He, H.; Meng, W. Y.; Yu, C. T.; and Wu, Z. 2003. WISE-

Integrator: An Automatic Integrator of Web Search

Interfaces for E-commerce. In Proceedings of the 29th

International Conference on Very Large Data Bases,

357-368. Berlin.

He, Z. T.; Hong, J.; and Bell, D. A. 2009. A Prioritized

Collective Selection Strategy for Schema Matching

across Query Interfaces. In Proceedings of the 26th

British national conference on Databases, LNCS 5588.

21-32.

Hong, J.; He, Z. T.; and Bell, D. A. 2009. Extracting Web

Query Interfaces Based on Form Structures and

Semantic Similarity. IEEE 25th International

Conference on Data Engineering. 1-3:1259-1262.

Lin, Z.J .; Lyu, M. R.; and King, I. 2012. MatchSim: a

novel similarity measure based on maximum

neighborhood matching. Knowledge and Information

Systems. 32(1):141-166.

Liu, W.; Meng, X. F.; and Meng, W. Y. 2010. ViDE: A

Vision-Based Approach for Deep Web Data

Extraction. IEEE transactions on knowledge and data

engineering. 22(3): 447-460.

Lu, Y. Y.; Meng, W. Y.; Shu, L. C.; Yu, C.; and Liu, K. L.

2005. Evaluation of Result Merging Strategies for

Metasearch Engines. 6th International Conference on

Web Information Systems Engineering, 53-66. New

York.

Madhavan, J.; Jeffery, S. R.; Cohen, S. I.; Dong, X.; Ko,

D.; and Yu, C. 2007. Web-scale data integration: You

can only afford to pay as you go. In Proceedings of

Conference on Innovative Data Systems Research, 40-

48. New York, NY.:ACMPress.

Zhang, Z.; He, B.; Chang, K. C. C. 2004. On-the-fly

constraint mapping across Web query interfaces. In

Proceedings of the VLDB Workshop on Information

Integration on the Web, 1-6. Toront.

ICEIS 2020 - 22nd International Conference on Enterprise Information Systems

248
