A Case Study on Performance Optimization Techniques in Java

Programming

Ciprian Khlud

and Cristian Fr

asinaru

Alexandru Ioan Cuza University, Ias¸i, Romania

Keywords:

Java, Runtime Performance, Memory Usage, Garbage Collection, Sequence Analysis, SAM/BAM Files.

Abstract:

Choosing the right programming platform for processor or memory intensive applications is a subject that is

debated in all types of contexts. In this paper we investigate how a state-of-the art implementation, part of a

multi-threaded framework for sequence analysis (elPrep) could beneﬁt from various optimization techniques

dedicated to improving the runtime performance of Java applications. We show that, without changing the

semantics of the algorithm, by using appropriate programming techniques we are able to signiﬁcantly improve

the behavior of the Java implementation to a point that may even alter the conclusions of the original study.

We also show that, by changing the manner in which data is represented, to better ﬁt the particulars of the Java

memory management, we are able to improve the original scoring (based on computing time and memory

consumption) to around one order of magnitude better on the most expensive component (read/write).

1 INTRODUCTION

In the ﬁeld of bioinformatics, DNA sequence anal-

ysis (D

oring et al., 2008) generally consists of pro-

cessing large amounts of data and performing various

operations on it, such as sequence alignment, variant

detection, searches against biological databases, etc.

A large variety of software tools exist for these opera-

tions, most of them having speciﬁc uses cases but with

a common denominator regarding the fact they need

to perform processor and memory intensive tasks: I/O

operations on large ﬁle, compression/decompression,

text processing, etc.

Choosing a programming platform that offers all

the required instruments to handle the speciﬁc chal-

lenges in bioinformatics is important, as pointed out

in a recent study dedicated to migrating an existing

Common Lisp application, called elPrep, to another

platform with better support for memory manage-

ment and concurrency (Costanza et al., 2019). El-

Prep (Herzeel et al., 2019) is a multi-threaded tool for

preparing sequence alignment/map ﬁles (SAM/BAM)

for variant calling in DNA sequencing pipelines. A

key feature of elPrep is the ability to avoid the stan-

dard practice of creating a pipeline consisting of

multiple command line tools invocations, by exe-

https://orcid.org/0000-0001-6211-3199

https://orcid.org/0000-0002-5246-7396

cuting a single pass through a SAM/BAM ﬁle and

keeping data as much as possible in main memory.

In (Costanza et al., 2019) the authors investigated Go,

Java and C++ programming platforms, as an alterna-

tive to Common Lisp. The result of their study con-

cluded that the Go implementation performed best,

using a metric that involved both the RAM usage

and the runtime performance. The benchmarks of the

study showed that Java had a faster runtime, but a sig-

niﬁcantly higher memory usage, while Go offered a

better balance between the two.

As the Java source code for elPrep is available at

https://github.com/exascience/elprep-bench, we

have analyzed key aspects regarding the memory

management and thread synchronization, and propose

a series of improvements that could increase signiﬁ-

cantly the performance of the Java implementation.

2 BACKGROUND

2.1 Garbage Collection

In order to analyze the behavior of memory in-

tensive applications, it is important to understand

how garbage collection works and especially how

Java (Java Platform, Standard Edition, 2019) imple-

ments its garbage collectors.

Khlud, C. and Fr

asinaru, C.

A Case Study on Performance Optimization Techniques in Java Programming.

DOI: 10.5220/0009591200840091

In Proceedings of the 15th International Conference on Software Technologies (ICSOFT 2020), pages 84-91

ISBN: 978-989-758-443-5

The Java Virtual Machine (JVM) (Lindholm et al.,

2014) offers an automatic storage management sys-

tem, called garbage collector (GC) which reclaims

heap storage occupied by objects which are no longer

used. The garbage collection process (Oracle GC,

2019) works typically by splitting the heap into two

regions: a young generation region and an old gener-

ation. All new objects are allocated in the young re-

gion, in a very fast manner, using typically a ”bump-

pointer” strategy. When this region becomes full, a

minor garbage collection occurs and all dead objects

are deleted very quickly. The objects which are still

referenced survive, and then they are moved to the old

generation. This minor collection is always a ”stop

the world” event, meaning that all of the application

threads will be paused until the GC is ﬁnished. In

the old generation, objects are expected to live longer

and they are collected more seldom but with a more

expensive algorithm, called major garbage collection.

We will analyze the impact of some simple tweaks

meant to reduce the impact of GC over the application

performance, such as reducing the unnecessary small

allocations in young region, controlling the scope in

which objects are referenced in order to minimize the

number of times when expensive collection of old re-

gion is triggered, simplifying the object graph and

controlling the amount of memory JVM is allowed

to use.

2.2 Memory Usage

The Java Virtual Machine allocates memory either on

stack or on heap (Lindholm et al., 2014), (Gosling

et al., 2014). An object allocated on the heap has a

header which contains information used for locking,

garbage collection or the identity of that object. The

size of the header depends on the operating system,

and it may be 8 bytes on 32 bit architectures or 16

bytes on 64 bit architectures. Also, for performance

reasons and in order to conform with most of the hard-

ware architectures, JVM will align data. It means

that if we have an object that wraps just one byte, it

will not use 8(object header) + 1(content) = 9 bytes

of memory on the heap, but it will use 16 bytes as it

needs to be aligned to the next 8 byte boundary.

In Java, strings are objects and they are allocated

on the heap. Inspecting the source code of the String

class, one can observe the following instance ﬁelds:

byte[] value, byte coder and int hash. As ex-

pected, a String object keeps a reference to an in-

ternal byte array. However, the other two ﬁelds will

make the size of the object equal to 8 (header) +

4 (value reference) + 1 (coder value) + 4 (hash

value) = 17 bytes. Being aligned to 8 bytes, it will

actually use 24 bytes. When creating many String

instances (like millions of them, as in our case study),

the extra information included in this class will add

up, consuming memory and triggering the garbage

collector more often than necessary.

We will show that replacing the String usage to

the underlying value byte array will improve the per-

formance of the application, and this approach should

be implemented in every scenario that involves pro-

cessing large amounts of text data.

2.3 Memory Compaction

Another important part of working with large data sets

that have to be accessible in memory regards the for-

mat in which they are represented. Choosing the right

format will not only reduce the amount of consumed

memory but it will also reduce the GC cost to copy the

objects between regions and the cost of visiting and

marking them (Schatzl et al., 2011), (Eimouri et al.,

2017).

The most common approach of representing infor-

mation is in row based form, where a row is a record

of some kind and a column is a certain property of

that row. This type of representation is used in most

relational databases management systems, where sets

of rows of the same type form tables.

A column store model (Abadi et al., 2013) ”re-

verses” the orientation of the tables. It stores data by

columns and uses row identiﬁers in order to access

a speciﬁc cell of the table. By storing each column

separately, query performance is increased in certain

contexts as they are able to read only the required at-

tributes, rather than having to read entire rows from

disk and discard unneeded attributes once they are in

memory. Another beneﬁt is that column stores are

very efﬁcient at data compression, since representing

information of the same type inside of a column helps

the data alignment process that we have previously

mentioned.

Let’s consider a simple example, using the class

Point, deﬁned as a pair of two integer ﬁelds x and y.

The basic idea is that instead of having a row-based

model consisting of an array Point[] of instances

(each Point object is a row and its members x and

y are the columns), to use two arrays of integers x[]

and y[], representing the two columns. This way we

can store the same data, minus the object headers cor-

responding to all the Point instances. Not only the

memory consumption will be lower (so the GC will

be triggered less often), but the structure will also take

shorter time to visit, since there are only two objects

now (the two arrays).

Though memory compaction is a very good so-

A Case Study on Performance Optimization Techniques in Java Programming

lution for size reduction, it has the downside of re-

quiring more computational effort in order to work

with multiple properties of the same object. However,

when saving memory is the major concern, and espe-

cially when it comes to hundreds of GB per instance,

the execution slowdown becomes far less important

if we can achieve signiﬁcant reductions in consumed

memory.

3 DATA REPRESENTATION

3.1 The Row-based Model

The data structure used in the original elPrep algo-

rithm is represented by the class SamAlignment, an

object of this type storing one row of a SAM ﬁle. The

class contains the following declarations of instance

variables:

Slice QNAME, RNAME, CIGAR, RNEXT, SEQ, QUAL;

char FLAG; byte MAPQ; int POS, PNEXT, TLEN;

List<Field> TAGS, temps;

For a small BAM ﬁle of 144 MB there will be cre-

ated around 2.1 million SamAlignment instances and

for a 1.27 GB BAM ﬁle there will be created around

17.6 million objects.

For simplicity, let’s disregard TAGS and temps

ﬁelds (which can have different lengths) as it makes

the calculation simpler and analyze the memory con-

sumption in both cases. We suppose also that the JVM

uses 32 bits for representing an object header.

One SamAlignment object contains 8 bytes (ob-

ject header), 6 instances of Slice objects (QNAME,

RNAME, CIGAR, RNEXT, SEQ, QUAL) of 4 bytes each,

3 integer ﬁelds (POS, PNEXT, TLEN) of 4 bytes each,

1 character (FLAG) of 2 bytes, and an additional byte

(MAPQ). So, the total size of the object is 8+ 6 ∗ 4 + 3∗

4 + 1 ∗ 2 + 1 ∗ 1 = 47 bytes, and as it is rounded up to

a multiple of 8, the result is 48 bytes.

In order to save memory, the string representing a

row scanned from the original ﬁle is shared between

multiple objects. All 6 Slice instances contain a ref-

erence to the underlying string and two integers point-

ing to the start index and length. So, a Slice instance

uses 8 (object header) +4 (reference to the string)

+4 + 4 = 20 bytes, being rounded to 24.

As Slice instances point to a String object, the

String itself adds another 24 bytes, as we have al-

ready seen, and the byte array object referenced from

the String adds another 24 bytes (not counting its

content size). Adding all these numbers up, we con-

clude that for representing a SamAlignment object

the JVM needs 48 (the object itself) +6 ∗ 24 (Slice)

+24 + 24 = 240 bytes.

For a 144 MB ﬁle there are 2.1 million entries,

so the memory requirement for storing the graph

of objects and the integer ﬁelds is approximately

504, 000, 000 bytes, which equals to more than 480

MB (not counting the 144 MB actual content of byte

array). For the 1.27 GB BAM ﬁle, the numbers are

much larger as there are a 17.6 million rows. The total

is 4, 224, 000, 000 bytes, representing almost 4 GB.

3.2 The Column-based Model

Let us analyze how much memory can be saved by

switching to a column-based approach. We have de-

ﬁned the following data structures: StringSequence

for representing in a compact manner a col-

lection of strings, DeduplicatedDictionary for

eliminating duplicate copies of repeating strings,

DnaEncodingSequence for storing A,C,G,T,N se-

quences using an encoding of 21 letters per long

and TagSequence for representing tags encoded in

an array of short values. We have also used

the classes CharArrayList, IntArrayList and

ByteArrayList from FastUtil library (Vigna, 2019),

which offers implementations with a small memory

footprint and fast access and insertion.

The new deﬁnition of the data store is described

by the class SamBatch, containing the following:

StringSequence QNAME, QUAL;

DeduplicatedDictionary RNAME, CIGAR, RNEXT;

IntArrayList POS, PNEXT,TLEN;

CharArrayList FLAG;

ByteArrayList MAPQ;

DnaEncodingSequence SeqPacked;

So, instead of having a large number of

SamAlignment instances, we will have a single ob-

ject of type SamBatch which contains references to

the ”columns”, i.e. our data structures holding all the

information of a speciﬁc type.

Regardless of VM bitness, the memory consump-

tion for representing one row of the input ﬁle is

2 ∗ 4 + 3 ∗ 4 + 3 ∗ 4 + 2 + 1 + 4 = 39 bytes. Consid-

ering that no rounding up is necessary, for 2.1 million

rows this sums up to 81, 900, 000 bytes, equivalent to

78 MB. The header sizes of the column objects (11 ∗8

bytes) become negligible in this context.

The basic idea is that instead of storing an array

of String objects, for example: String items[]

= {"abc", "def"}, each consuming memory due

to their headers, we can use a single object of type

String, storing all the characters, and an additional

array for their lengths.

String dataPool = "abcdef";

int[] endLengths = {3, 6};

ICSOFT 2020 - 15th International Conference on Software Technologies

For such a small array, the save is minor, but for

a large number of items (millions), the memory re-

duction becomes signiﬁcant. Even more important,

the GC work is also reduced, since no matter how

many items are in the dataPool and endLengths

ﬁelds, there are only two objects to visit. The tech-

nique described above was implemented in the class

StringSequence.

If the strings that are to be stored are repeated fre-

quently, we can apply another optimization: instead

of keeping them joined, we will use an indexed col-

lection containing all the distinct strings and an ar-

ray holding one index for each string. For example, {

”abc”, ”def”, ”abc”, ”xyz”, ”abc”} becomes:

table : {abc=>0, def=>1, xyz=>2}

items : [0, 1, 0, 2, 0]

This data deduplication technique (He et al.,

2010), (Manogar and Abirami, 2014) was imple-

mented in the class DeduplicatedDictionary.

When storing strings containing characters from

a restricted alphabet, one optimization that can be

performed is using an array of primitive values,

for example a long[], and encoding each character

into a block of bits. The number of bits required

for a character depends on the size of the alphabet.

DNA sequences use four letters A,C,G,T, but it is

possible for a machine to read incorrectly a symbol

and to return N. In order to represent 5 possible

characters we need at least 3 bits, which as a result

long can store in its 64 bits 21 DNA letters. For

example, encoding the 21 letters string ”AAAACC-

CCGGGGTTTTNNNNA” would produce a single

long value, containing the bits (from right to left, 000

represents A, 001 represents C, and so on):

00001001001001000110110110110100

10010010001001001001000000000000

In the sample ﬁles, one DNA sequence is typically

around 100 letters, so the memory needed in order to

represent it would be 1 int (encoding length) and 5

longs (the content), that is 44 bytes. This reduces the

memory consumption by a factor of two.

Running the smaller input ﬁle (144 MB), we have

estimated that the original elPrep algorithm would use

around three times more memory than the size of the

input SAM ﬁle. However, when trying to process the

larger input ﬁle (1.2 GB), on a 32 GB machine, we

have obtained an OutOfMemoryError, meaning that

the penalty of using too many objects in order to rep-

resent the information was preventing us in loading

the entire data set into memory.

On top of this, there is the cost of tags. In order

to address temps and TAGS we have implemented the

TagSequence class, which is a combination between

StringSequence and DeduplicatedDictionary.

Without detailing all the calculations, in the original

implementation, for the smallest ﬁle (144 MB), con-

taining 2.1 million rows, the JVM will use almost one

gigabyte (1, 001, 700, 000 bytes) just for object book-

keeping. Our model will use much less additional

memory, a 10× saving for object bookkeeping. For

2.1 million entries, the tags memory consumption is

now 50, 400, 000 bytes and the combined value for the

whole model is 132, 300, 000 bytes (about 126 MB).

4 OPTIMIZING I/O OPERATIONS

4.1 Buffering and Synchronization

The elPrep algorithm starts by reading the input ﬁle.

Based on the read information, it creates a large data

set in memory and, in the end, it writes the pro-

cessed data into another ﬁle. In the writing step, the

algorithm creates parallel tasks, which in turn take

all SamAlignment instances and serialize them into

the string format of SAM ﬁles. Especially when the

full data set is loaded into memory, these tasks cre-

ate many small objects that have a negative impact in

terms of memory management. Using a simple tech-

nique of pre-allocating the buffer sizes based on the

speciﬁc context of the problem, we can prevent the

creation of many of these intermediate objects.

The code sequence that captures the writing pro-

cess is presented below:

var outputStream = alnStream

.parallel()

.map((aln) -> {

var sw = new StringWriter();

try (var swout = new PrintWriter(sw))

{ aln.format(swout); }

return sw.toString();

});

An important technique that could improve per-

formance when working with data is buffering

(Oaks, 2014). If we take a closer look at the

StringWriter class we notice that it uses an inter-

nal StringBuffer object for storing its data, which

in turn has an internal primitve buffer which has 16

characters as default. The average length of a row in

the input ﬁle is 325 − 330 characters. As 350 is about

10% larger than the average line, based on the regular

statistical distribution, thus most lines would require

no extra resizes of their corresponding buffers. This

prevents the creation of extra garbage, which in turn

reduces the number of times when GC is executed. In

the following sections, we will denote the algorithm

that employs this technique as PresizedBuffers .

A Case Study on Performance Optimization Techniques in Java Programming

We will further analyze the usage of the

StringWriter and its StringBuffer helper. To

quote from its documentation, a StringBuffer is a

thread-safe, mutable sequence of characters. Mean-

ing that most of its methods are declared as synchro-

nized in order to control the access to the buffer of

characters in a multi-threaded environment. How-

ever, in our case, each writing thread spawned by the

parallel stream implementation gets its own copy of

a StringWriter so there is no resource contention

that would require synchronization. Instead of using

a StringWriter, it would be better to simply use a

common buffer, with no synchronization. Instead of

creating and storing individual string representations

of all the SamAlignment objects, and writing them

one by one to disk, we add progressively informa-

tion into the buffer. Only when the buffer becomes

full, we write its content on disk. Obviously, all these

steps will be performed in a single thread, but the bot-

tleneck will be less obvious. The class implementing

the byte array is called StreamByteWriter.

4.2 Chunking-batching and Extracting

Parallelism

In the elPrep original algorithm, a SamAlignment ob-

ject is created for each row in the input ﬁle. In order to

extract parallelism, there is an explicit .parallel()

call, a construct that would create a task for each row

that must be processed. These tasks are queued and

executed in a concurrent fashion using threads created

transparently by the Java Stream API.

var alnStream = inputStream.parallel()

.map((s) -> new SamAlignment(s));

In the column-based model, described in sec-

tion 3.2, there is a single SamBatch instance storing

all the data. Because we perform data compaction, the

read operation must take into account the dependen-

cies between rows. Just like in the case of removing

duplicates, in order to process a new row we have to

inspect the values of the previously read rows. There-

fore the reading process cannot be fully parallel per-

row. In order to obtain a better performance than read-

ing using a single thread, we propose a technique that

splits the SamBatch structure in several ”chunks”. In-

stead of having a single large object, we will represent

the data using an array of smaller SamBatch objects.

A sketch of our Compact algorithm is described by

the following pseudo code:

int chunkSize = 20000;

int nbOfThreads=cpuCoreCount * 4;

var samBatches=new ArrayList<SamBatch>();

while (!endOfFile) {

var rowsRead=parallelReadRows(

batchSize, nbOfThreads);

parallelTransformRowsIntoBatches(

samBatches, rowsRead);

}

The readRows method reads chunkSize ∗

nbO f T hreads rows out of the SAM ﬁle for the next

processing step. The actual reading is done using an

appropriate number of threads (based on the CPU

conﬁguration), each thread reading sequentially a

ﬁxed number of rows, calculated taking into account

the nature of the information being encoded. Having

the data split into chunks, we can process in parallel

the mapping between the associated text and the

SamBatch data structure, where we perform data

compaction and deduplication. The techinque of

grouping similar tasks requiring the same resources

in order to streamline their completion is called

batching.

In our case, the advantages of the chunking-

batching approach are multiple. Since a

DeduplicatedDictionary will now have less

than 20000 unique strings, the values needed to

encode the strings could be represented on 2 bytes,

instead of 4. Similarly, we can reduce the tag

size from 4 to 2 bytes. After the algorithm is

fully executed, we will have instead of 2.1 million

SamAlignment objects, about 105 SamBatch in-

stances, each of them having around 4 orders of

magnitude less objects overall. This translates into 2

orders of magnitude less objects. When creating the

output ﬁle, the SamBatch array could be processed in

parallel, with no blocking except the actual operation

of writing to disk.

We have seen that the column-based model saves

memory at the expense of the running time. This opti-

mization, however, reduces the overall execution time

of the read operation, which is now on par with the

original implementation.

When it comes to writing, compared to our

StreamByteWriter algorithm, which is anyway much

faster than the original implementation, the execution

time is drastically reduced from 28 seconds (for the

12 GB BAM ﬁle) to 12 seconds. Preparing the strings

that are to be written in the ﬁle can be done in almost

perfect parallelism, using the available cores.

In order to make sure there are no dead times when

using the external device, we have also implemented

the async/await pattern. This allows the program to

perform in advance reading operations, using a ded-

icated thread, while waiting for the data processing

threads to complete their execution. This new algo-

rithm, called Compact/Par, offers a small improve-

ment in the running time, as we will see in the next

ICSOFT 2020 - 15th International Conference on Software Technologies

section, but with the disadvantage of a signiﬁcant in-

crease in code complexity.

5 EXPERIMENTAL RESULTS

5.1 Overview

We have created ﬁve implementations that address the

most expensive parts of the elPrep algorithm, which

are reading, storing all data in the memory and writ-

ing. Except for the original version, which was taken

from elPrep public repository, all other algorithm im-

plementations contain various types of optimization

that are meant to improve runtime performance and

to lower the memory usage, especially on large ﬁles

where GC becomes a limiting factor.

The computer we have used in order to perform

the experiments is a Ryzen 9-3900X, having 12 cores

and using 48 GB of RAM. Since we didn’t have

access to the hardware necessary to run all the tests

in memory, as the original paper, we have used the

smaller SAM ﬁles and ran the same processing re-

peatedly in order to obtain an accurate result of the

running time. For example, running 10 times the al-

gorithm on the smallest input SAM ﬁle, which is ap-

proximately 700 MB, will produce a total running

time of around 70 seconds. Running the algorithm

repeatedly will trigger the garbage collector and this

will be the cause of variations in the collected results,

ranging from around 2 to 3 seconds, when reading the

smallest ﬁle, and 3 to 4 seconds for writing.

The original elPrep benchmarks have been per-

formed on a Supermicro SuperServer 1029U-TR4T

node with two Intel Xeon Gold 6126 processors con-

sisting of 12 processor cores each, clocked at 2.6

GHz, with 384 GB RAM (Costanza et al., 2019). The

authors claim to do the processing of the 8 GB BAM

ﬁle in 6 min:54sec to 7 min:31sec and memory usage

is 330 − 340 GB.

As we didn’t have access to such a performing ma-

chine, we did most of testing with the smallest ﬁle, the

144 MB BAM ﬁle (673.3 MB SAM ﬁle). For the 8

GB BAM ﬁle (27.18 GB SAM) our results will show

only the Compact algorithm but we will make some

inferences over the scaling of the algorithms across

ﬁle sizes and cores.

5.2 Runtime Performance

The following table shows a brief comparison of the

running times obtained by our algorithms, in three

conﬁgurations: 144 MB ﬁle using 4 cores and 12

cores, and 1.2 GB ﬁle using 12 cores.

Table 1: Running time per algorithm in seconds.

144M

(4c)

144M

(12c)

1.2G

(12c)

Original 9.13 3.938 123.91

PresizedBuffers 8.98 4.19 75.1

StreamByteArray 8.09 3.43 64.62

Compact 5.64 3.4 34.5

Compact/Par 5.42 4.68 26.7

Figure 1: Runtime Performance in seconds (1.2 GB BAM).

Comparing 4 cores to 12 cores, we notice that the

Original algorithm scales with a factor of 2.3, Pre-

sizedBuffers by a factor of 2.14, StreamByteArray

scales by 2.36 and Compact would scale by 1.69. So,

at least for the small ﬁle, it seems that using larger

machines will offer a better performance. It is im-

portant to notice that, in its current implementation,

the Compact algorithm has an explicit sequential part

that reduces its scalability. Some potential ﬁxes are

described in section 6, where we describe some tech-

niques aimed at improving the single threaded part.

A more useful way to present the algorithm is to

show how it scales based on input size, and at least

on the 12 core machine, we can see that both compact

algorithms remain roughly in the same speed, so GC’s

runtime cost doesn’t become in impediment:

Figure 2: Seconds per GB by algorithm and ﬁle size.

5.3 Memory Usage

To measure the live data set, we have used Java Visu-

alVM (VisualVM, 2019) which provides a visual in-

terface for proﬁling a running application. Using Vi-

A Case Study on Performance Optimization Techniques in Java Programming

sualVM, we have analyzed the memory consumption

in each scenario and we have estimated the minimum

amount of memory that JVM requires in order to load

a speciﬁc data set.

Unlike the original paper, which measures pro-

cess memory size, we have measured live data size.

This is possible due to VisualVM which offers very

precise information regarding the objects consuming

memory.

Table 2: Memory usage per algorithm in MB.

144 MB ﬁle 1.2 GB ﬁle

Original 2326 MB 32025 MB

PreSizedBuffers 2326 MB 32025 MB

StreamByteArray 2275 MB 31463 MB

Compact/Par 606 MB 4689 MB

Figure 3: Live Memory Usage (in GB).

The peak usage was measured by suspending the

program at the moment when the whole ﬁle was read.

We notice that for the 1.2 GB BAM ﬁle, the Original

and Presized Buffers algorithms are using around 32

GB of memory. In order to offer this amount of mem-

ory to JVM we used a machine with 48 GB of RAM.

To further reduce the overhead of GC, 64 GB would

certainly have been better.

5.4 Calculating Performance

The goal of elPrep was to keep both the running time

and the the memory consumption low. The evalua-

tion function was deﬁned as the multiplication of the

average elapsed wall-clock time (in hours) with the

average maximum memory use (in GB), with lower

values (in GBh) being better (Costanza et al., 2019).

We have used the same approach, changing only the

measurement units to MB and seconds.

On the medium ﬁle (1.2 GB BAM) the values are

conclusive from the point of view of scaling the re-

sults. The improvements resulting from our optimiza-

tion techniques are now clearly visible.

Tests performed up-to the 8 GB ﬁle showed that

algorithms scale as expected, GC does not become

Figure 4: Memory x Times Score (Seconds x GB).

a large impediment for the Compact implementa-

tions and the overall performance seems limited only

by other hardware components, such as disk drive

read/write speeds. Both Compact algorithms keep a

steady pace of processing at around 180 MB/second

(under 6 seconds to process every 1 GB of BAM).

StreamByteArray has a sharp loss of speed as GC is

triggered more often, processing data at half speed

when increasing the BAM ﬁle size from 0.144 GB

to 1.2 GB.

6 FUTURE WORK

Batch Reader Scalability.

As we have described in section 4.2, our batch reader

works in two steps: initially, on the main thread, it

extracts from the original ﬁle the rows for the number

of the expected batches, and then it executes in paral-

lel, using all cores, the data compaction step. Before

chunking and batching is done, we split the full byte

array read from ﬁle into distinct List<byte[]> in-

stances. This separation may not be necessary, an al-

ternate approach being to store inside a large byte[]

structure all the information and to use an additional

array of indices in order to retrieve the actual lines of

text. This would reduce the number of allocations and

eventually speed up the execution of the main thread.

Value Types.

When Java speciﬁcations were elaborated, more than

25 years ago, the cost of a retrieving an object from

the memory and executing an arithmetic operation

was approximately the same. On modern hardware

however, the memory fetch operations are up to 1000

times more expensive than arithmetic ones. This is

why, the Project Valhalla (Valhalla, 2019), that is ex-

pected to be integrated in modern JDK releases, in-

troduces new data structures and language constructs

that improve various aspects regarding data manipu-

lation. For example, Value Types provide the nec-

essary infrastructure for working with immutable and

reference-free objects. In our context, this would al-

ICSOFT 2020 - 15th International Conference on Software Technologies

low us to further reduce the memory used by the Com-

pact algorithm by using an efﬁcient by-value compu-

tation with non-primitive types.

7 CONCLUSIONS

This paper addresses the situation when one has to

manipulate a large textual data set by reading it from

a ﬁle, transforming it into objects, processing it and

then writing it back to a ﬁle, and all these operations

must be performed in a single in-memory session.

We have analyzed a modern implementation of an al-

gorithm for processing SAM and BAM ﬁles, elPrep

(Herzeel et al., 2015), (Herzeel et al., 2019), which

must handle input ﬁles up to 100 GB. The conclu-

sion of the elPrep authors was that a Java implemen-

tation for this speciﬁc problem suffers from the mem-

ory management offered by JVM (Costanza et al.,

2019). However, when using an object-oriented pro-

gramming platform, one has to take into considera-

tion all aspects regarding memory allocation offered

by that speciﬁc platform and to adapt its model and

programming techniques.

We have showed that major improvements can

be obtained by using techniques that are aimed at

reducing the number of created objects. This will

not only save memory but it will also improve run-

time performance by decreasing the overhead of the

Garbage Collector. Using a column-based represen-

tation we have compacted the data set in a man-

ner that boosted the overall score calculated as the

multiplication between used memory and running

time. The penalty incurred by the more elaborate

data model was compensated by a multi-threaded ap-

proach, called chunking-batching, that actually allows

the algorithm to use all available machine cores when

processing the input ﬁle.

Given the hardware differences between the ma-

chine used by the elPrep authors and ours, there are

limits on the testing that could be done with the tech-

niques used by this paper. However, using input ﬁles

ranging in size from 144 MB to 12 GB, we have

proved that our algorithms are scalable and could per-

form as expected for ﬁles of any size, provided the

machine has sufﬁcient memory.

REFERENCES

Abadi, D., Boncz, P., and Harizopoulos, S. (2013). The De-

sign and Implementation of Modern Column-Oriented

Database Systems. Now Publishers Inc., Hanover,

MA, USA.

Costanza, P., Herzeel, C., and Verachtert, W. (2019). Com-

paring ease of programming in C++, Go, and Java for

implementing a next-generation sequencing tool. Evo-

lutionary Bioinformatics, 15:1176934319869015.

oring, A., Weese, D., Rausch, T., and Knut, R. (2008).

Seqan an efﬁcient, generic c++ library for sequence

analysis. BMC bioinformatics, 9:11.

Eimouri, T., Kent, K. B., and Micic, A. (2017). Optimiz-

ing the JVM Object Model Using Object Splitting. In

Proceedings of the 27th Annual International Confer-

ence on Computer Science and Software Engineering,

CASCON 17, page 170179, USA. IBM Corp.

Gosling, J., Joy, B., Steele, G. L., Bracha, G., and Buckley,

A. (2014). The Java Language Speciﬁcation, Java SE

8 Edition. Addison-Wesley Professional, 1st edition.

He, Q., Li, Z., and Zhang, X. (2010). Data deduplication

techniques. volume 21, pages 430 – 433.

Herzeel, C., Costanza, P., Decap, D., Fostier, J., and

Reumers, J. (2015). elprep: High-performance prepa-

ration of sequence alignment/map ﬁles for variant

calling. PloS one, 10:e0132868.

Herzeel, C., Costanza, P., Decap, D., Fostier, J., and Ver-

achtert, W. (2019). elprep 4: A multithreaded frame-

work for sequence analysis. PLOS ONE, 14(2):1–16.

Java Platform, Standard Edition (2019). Java De-

velopment Kit Version 11 API Speciﬁcation.

https://docs.oracle.com/en/java/javase/11/docs/api.

Accessed: 2019-06-01.

Lindholm, T., Yellin, F., Bracha, G., and Buckley, A.

(2014). The Java Virtual Machine Speciﬁcation, Java

SE 8 Edition. Addison-Wesley Professional, 1st edi-

tion.

Manogar, E. and Abirami, S. (2014). A study on data

deduplication techniques for optimized storage. pages

161–166.

Oaks, S. (2014). Java Performance: The Deﬁnitive Guide.

O’Reilly Media, Inc., 1st edition.

Oracle GC (2019). Java Garbage Collection Basics.

https://www.oracle.com/webfolder/technetwork/ tuto-

rials/obe/java/gc01/index.html. Accessed: 2019-06-

01.

Schatzl, T., Dayns, L., and Mssenbck, H. (2011). Optimized

memory management for class metadata in a JVM.

Valhalla, P. (2019). OpenJDK Project Valhalla.

https://openjdk.java.net/projects/valhalla/. Accessed:

2019-06-01.

Vigna, S. (2019). Fastutil 8.1.0. http://fastutil.di.unimi.it/.

Accessed: 2019-06-01.

VisualVM, O. (2019). Java VisualVM.

https://docs.oracle.com/javase/8/docs/technotes/

guides/visualvm/index.html. Accessed: 2019-06-01.

A Case Study on Performance Optimization Techniques in Java Programming
