Performance-based Refactoring of Web Application: A Case of

Public Transport

Anna Derezinska

and Krzysztof Kwaśnik

Institute of Computer Science, Warsaw University of Technology, Nowowiejska 15/19, Warsaw, Poland

Keywords: Web Application, Performance Evaluation, Quality Improvement, Single Page Application, Web of Public

Transport System.

Abstract: Performance issues are, among other quality attributes, important factors of web applications devoted to

public services. Performance-based refactoring concerns program quality improvement when functional

requirements but also selected non-functional requirements, such as clarity, user-friendliness, and security

issues, remain preserved. We have examined three independent web applications supporting card processing

for public transport widely used in different provinces. Based on the experience, a new web application has

been developed. While using the Single Page Application approach it has been aimed at easing a client

interaction. Further refactoring helped in the performance improvement. The general performance has been

compared to those three applications. Benefits of the refactoring have been evaluated and discussed.

1 INTRODUCTION

Software refactoring has been primarily concerned

with a systematic manipulation of object-oriented

programs in order to improve their quality (Fowler,

2018). The distinguishing feature of any refactoring

approach is preservation of functionality realized by

an application of concern. Refactoring can be aimed

at avoiding unwanted features, as bad smells, but also

at achieving certain goals, for example, applying

design patterns (Kierevsky, 2004). A challenging task

could be refactoring directed at the improvement of

various quality features, in particular an application

performance. This problem has been addressed in our

research and a case study performed. In this paper, an

improvement of the performance measures has been

discussed as primary effects of a web application

refactoring. Other quality attributes, also related to

the SQuaRE model (ISO/IEC, 2010, 2015), have been

studied in (Derezinska and Kwasnik, 2020).

It should be stressed that the refactoring cannot be

applied independently to other nonfunctional

features, for example, security requirements.

Therefore, we have to address the basic issues that

should be preserved in a refactoring process. In the

broader sense, different frozen spots (fixed

https://orcid.org/0000-0001-8792-203X

invariants) and hot spots (changeable features) can be

considered in a refactoring process.

In this paper we focus on web applications that

are devoted to public services. After examining

different applications supporting card processing for

public transport in three different provinces of our

country, we have found several weaknesses.

Moreover, all these application have been based on

the Multi-Page Application model (MPA), whereas

the Single-Page Application model (SPA) supposed

to be more suitable in this domain.

A prototype Public Transport Web (PTW) has

been developed using a different model, SPA instead

of MPA. A set of activities has been performed,

treating PTW as an object in a performance-based

refactoring process. Experiments have been

conducted to evaluate PTW in regard to other

applications, and to compare PTW before and after

refactoring. While focusing on the performance, the

following research questions have been considered:

(i) is really SPA more appropriate, (ii) how much we

can benefit from the performance-based refactoring.

This paper is organized as follows: Section 2

introduces briefly MPA and SPA approaches. Related

work is reported in Section 3. Section 4 describes the

case study. The experimental results are presented

and discussed in Section 5. Finally, Section 6

concludes the paper.

Derezinska, A. and Kwa

snik, K.

Performance-based Refactoring of Web Application: A Case of Public Transport.

DOI: 10.5220/0009797006110618

In Proceedings of the 15th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2020), pages 611-618

ISBN: 978-989-758-421-3

611

2 WEB APPLICATION MODELS

There are two main models of web applications: MPA

(Multi-Page Application) and SPA (Single-Page

Application).

An SPA works inside a browser and does not

require page reloading during use. There are many

advantages of this model. The application resources,

i.e. HTML, CSS and Script files, are loaded once,

therefore, the transmission overhead is reduced. The

development is simpler than for MPA. However, SPA

is exposed to XSS risks (Cross-Site Scripting), which

lowers its security (Gupta and Gupta, 2015).

In the MPA model, each page sends a requests to

the server and updates all its data, consequently it puts

more requirements on performance. In order to limit

the traffic between the browser and the server,

additional methods could be used to prevent

transmission of small amount of data, as e.g. AJAX.

Using this model is simpler to make Search Engine

Optimization (SEO). However, MPA is less suitable

to build a mobile application.

The SPA approach can be supported by many

libraries that wrap JavaScript language and

implement Virtual DOM (Document Object Model)

(Zou et al., 2014). V-DOM is a local copy HTML

DOM that makes possible to recalculate actualization

data. In this way, operations of the original HTML

DOM can be omitted. The following frameworks of

this kind belong to the most widely used:

React.js – developed and shared by Facebook in

2013. This mostly used framework does not cover all

project utilities and has to be accompanied by

intermediate layer as AJAX engine.

Angular.js – created and maintained by Google. It

is a very comprehensive framework also supporting

solutions of routing or asynchronous web application

model. It requires usage of a domain language -

TypeScript.

Vue.js – created by E. You, drawn on experience

of Angular.js. In this case, usage of TypeScript is not

obligatory.

These frameworks are open source, support

JavaScript, and have been applied in professional

solutions by many companies. An application structure

is more flexible in the case of Vue.js. An advantage of

this framework is also its simplicity.

3 RELATED WORK

The basic catalog of code refactoring transformations

has become popular after the seminal work of

(Fowler, 2018). Notion of refactoring has also been

further associated with different activities.

Various kinds of non-source code refactoring are

surveyed in (Rochimah, Arifiani, and Insanittaqwa

2015). They have focused on refactoring of other

software artifacts, such as UML models,

requirements, software architecture, and refactoring

in code with non-conventional detection techniques.

Refactoring activities that are discussed in this paper,

could be partly classified as refactoring of software

architecture. However, no performance-based or

refactoring aimed directly on a non-functional feature

has been discussed in this survey. Moreover, it is not

a universal remedy on development shortcomings, as

“refactoring activities affect quality attributes in an

inconsistent manner” (Kaur, Kaur and Kaur, 2019).

A great challenge to refactoring is ability to

automate the transformation as much as possible

(Baqais and Alshayeb, 2019). The most of research

refers to automated code refactoring, while some also

to model refactoring. There are also approaches to

search-based refactoring (Mariani and Vergilio,

2017). However, automating of operations discussed

in this paper is still an open issue.

Different activities can be undertaken to improve

performance of a web application.

A set of methods to accelerate a process of an

SPA application has been presented in (Stępniak and

Nowak, 2017). The authors pointed at the beneficial

utilization of the following methods, minification of

JavaScript, removing unused CSS rules and

concatenation of resources. These outcomes are

similar to our findings. The main difference is usage

of another framework, AngularJS, and discussion of

mechanisms specific to this solution.

Also SPA using AngularJS was a subject of

research discussed in (Jadhav, Sawant and

Deshmukh, 2015). The paper presents the main

architectural features of SPA, and SEO (Search

Engine Optimization) in SPA. However, no

performance issues are concerned.

SEO expresses a position that could be reached by

a website in search engines of web browsers

(Gudivada, Rao and Paris, 2015). It is a crucial

feature of many kinds of web applications, especially

those supposed to be widely accessible in e-

community. Any kind of refactoring transformation

should take into account the impact on SEO.

Performance analysis of parallel web applications

has been argued in (Verdu and Pajuelo, 2016). In our

case, no JavaScripts of this kind have been

considered, although, they could be counted to an

extended set of refactoring actions in the future.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

612

Experiments with the Jmeter performance

evaluation tool have been reported (Kiran, Mohapatra

and Swamy, 2015). They confirmed usefulness of the

tool, referred to different technologies, so the detailed

results are not comparable to ours.

The HTTP/2 protocol and its prioritization ability

have been studied in (Wijnants, Marx, Quax, and

Lamotte, 2018). They have found that HTTP/2

prioritization influence web performance, especially

in terms of page load time, though the results depend

strongly on the browser type.

Different evaluation tools have been used to

assess software quality of web application, including

also performance attribute (Kaur, Kaur, and Kaur,

2016), (Martinez-Fernandez et al., 2019). Some of the

tools have also been used in the experiments reported

here. Different metrics could also be applied for this

purposes (Lew, Olsina, Becker, and Zhang, 2012).

There is a lot of research related to web

application security. Selected threats have to be

considered in the application discussed here, such as

Cross-Site Cripting (XSS) (Gupta and Gupta, 2015),

SQL Injections (Srivastava, 2014).

4 PUBLIC TRANSPORT WEB

In this section, we discuss the case study background,

requirements, architecture, and refactoring.

4.1 Background

City cards are commonly used to integrate services

related to public transport in big cities and whole

regions. They offer modern access to the transport for

citizens and visitors of the area under concern.

Cards of this kind are supported by web

applications, which make possible to buy tickets of

different tariff variants and associate them with the

card. A typical functionality of the web also covers

basic administration features, like registration of new

clients, user login/logout, storing of history of

transactions related to the card, updating of personal

data, collecting of client comments, etc.

We have investigated public transport web

applications that have been independently developed

and applied in three different provinces of Poland:

MKA – for Krakow and other cities of Malopolska

provice, https://mka.malopolska.pl/en,

PEKA – for Poznan and its satellite towns,

https://www.peka.poznan.pl/SOP/login.jspb,

Waw Card – for Warsaw and its satellite towns,

https://www.wtp.waw.pl/en/.

The applications are used by many clients, of

various skill levels. The biggest reference area is of

the Waw Card and includes above two millions of

citizens and commuters.

The applications have been examined observing

their normal operation and using dedicated tools to

website quality evaluation (Derezinska and Kwasnik,

2020). The main drawback of the applications is a

high number of activities required by a client to

acquire rights to travel. Other problems referred to

configuring some kinds of tickets, duplicating of data

introduction, or difficulties of finding necessary

information and links to perform ticket purchasing.

The websites are overwhelmed with many

information of public transport organisation mixed

with client panel and purchasing module. All

applications are also based on the MPA approach.

4.2 Prototype Application

Based on the above experience, a Public Transport

Web (PTW) prototype has been developed that

delivers the basic services similarly to the discussed

applications. The main requirements of ticket

purchasing refer to the following activities:

 Long-term ticket can be bought.

 Parking voucher can be bought.

 A ticket can be configured, specifying travel

zone, period, discount, combining with a

parking voucher, etc.

 Ticket price should be updated according to the

ticket configuration.

 All ticket options should be configured in one

view of the website (no view change

necessary).

 Before ticket purchasing, the complete

configuration and the final price should be

confirmed.

 A feedback about successful or unsuccessful

purchasing should be provided to a user.

Activities supported by an application of this kind

should be simple and straightforwardly operable by

any client type. Client interactions should be quick

and their number limited. A transition between views

should not require loading additional data from a

server. Expected data should be presented to a user

after a delay no longer than 7 sec. This requirement

follows the results of (Dennis and Taylor, 2006).

4.3 PTW Security Requirements

Apart from performance issues, the application

should meet various security requirements. In this

section, we address several topics to be concerned in

Performance-based Refactoring of Web Application: A Case of Public Transport

613

PTW. The identified general problems can be treated

as frozen spots of the current or future refactoring,

while some selected methods or technology could be

still a subject of substitution. Additionally, fulfilling

security requirements could have a considerable

impact on the application performance.

4.3.1 Client Registration

Registration of a client requires delivery of a set of

personal data. Structure of some data, as e-mail

address or telephone number should be verified.

Registration service should be separated from other

events of the application. At least typical security

concerns should also be devoted to processing a client

password, like hiding, encryption, re-typing, strength

verifying, secure transmitting to the data base. In

PTW, a password is encoded with jsSHA (currently

SHA-512) and stored in the data base.

4.3.2 Client Authentication

Client authentication is used for a client verification,

usually based on a login and password but also an e-

mail could be used. In PTW, authentication is

performed by the server, where an encoded password

is delivered. Successful authentication initiates a

client session with a time limit, managed by vue-

session of Vue.js.

4.3.3 Application Responsiveness

It is preferred that an application accommodates to

desired sizes of all devices it is displayed on. In PTW,

operations on styles are used for this purpose. CSS

scripts are loaded when certain conditions are

fulfilled.

A MobileFirst approach could also be used, when

a website is designed first for a mobile device, and

then for other device types. The website is then

displayed the most quickly on a mobile device.

An alternative solution is development of a

separate web application dedicated for the mobile

devices. In this case, however, the SEO attribute

would be lower, because a single site address is

assessed higher than two adapted sites (Gudivada,

2015). The higher SEO the better is a site position in

a browser and a better client accessibility.

4.3.4 Data Security

There are different security threats related to data

manipulation or interception, that should be taken

into account in PTW.

XSS (Cross-Site Scripting) attacks should be

avoided (Gupta and Gupta, 2015). It concerns

introduction of unwanted JavaScript code to a

webpage from a client site, to get access to sensitive

data (Gupta, Gupta, Gangwar, Kumar, and Meena,

2015). While developing an application based on

Vue.js, Reflected XSS and DOM Based XSS have not

to be taken into account, as no information has to be

made available nor fetched from a client URL.

However, because of usage of a dynamically

refreshed DOM code, other XSS attacks should be

considered. A pure HTML code can be directly

introduced into a view component. This feature (so

called v-html) should not be applied on data delivered

by a user. Moreover, in PTW, the number of data

transmitted by user are strongly limited, which

prevents delivery of complex JavaScrips.

The application should also be resistant against

SQL Injections (Srivastava, 2014). Potential threat

concerns transmission of data to the data base. In PTW,

an additional EntityFramework is used to send values

of queries as parameters to the data base instead of

direct queries, which could have been manipulated.

4.4 PTW Architecture

The PTW prototype has been developed as SPA using

the Vue.js framework. The application is placed on a

Cloud server and consists of the following

components: a view, an intermediate layer and a

database project. The view is created by Vue.js and

communicates with the intermediate layer. The

second component is based on the MVC pattern (Leff

and Rayfield, 2001). It transfers data between the data

base project and the view. The database project

communicates with an external data base (Figure 1).

The MVC project has been implemented using the

.NET framework, the controller actions in C#, and the

view in HTML with VS extensions.

Figure 1: PTW architecture.

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

614

4.5 PTW Refactoring

PTW has been refactored in order to improve its

quality attributes, especially performance. The

refactored application should support the same

functionality and other non-functional requirements;

in particular security constraints and usefulness

facilities, should be preserved or improved. Below,

we review modifications that have been introduced.

Different resources have been combined together

into one request, lowering in this way a total number

of requests (Grigorik, 2013).

The content and appearance of the website have

been modified, in order to better fit to the resolution

of a target device.

Data compression has been performed for the

selected types of files. The gzip compression has been

switched on in the configuration file of the

application that is used by the Cloud server.

Superfluous CSS rules have been deleted, and,

therefore, files to be delivered to a browser have been

reduced. Such reduction can be automatically

performed by browser tools, or an external tool

(Grunt-uncss, 2020).

File minification has been applied to all CSS and

JS files. During this action, unnecessary characters

such as spaces, tabs, blank lines, and comments have

been removed. We used a tool (UglifyJS 3, 2020).

The protocol HTTP/2.0 has been used instead of

HTTP/1. In the primary solution, each request was

queued, which influenced the duration of the website

loading time. The newer protocol provides

multiplexing of requests, therefore, communication

between the server and the browser can be completed

in shorter time (Wijnants Marx, Quax, and Lamotte,

2018). Moreover, usage of this protocol positively

influences the SEO attribute.

The file types have been recognized, namely:

those that have to be loaded directly at the beginning

and which can be postponed and handled

asynchronously. In result, some scripts do not block

the website processing. This has been realized using

async and defer attributes in JavaScript.

All pictures used in the application have been

compressed. The substantial size reduction was

obtained using the tool (WebP, 2020).

Data transmission has been performed with the

https protocol, an encoded version of http, improving

the data transmission security.

A cache memory has been used to store files. The

appropriate configuration parameters have been

changed to allow storing of the selected types of files.

Adaptations have been performed in order to

better adjust the application to mobile devices.

5 EXPERIMENTS

Various performance features of PTW before and

after refactoring, and performance of the public

transport applications (MKA, PEKA and WAW

Card) have been experimentally evaluated. General

performance and other quality factors could have

been measured on all applications (Sec. 5.1.1). These

kind of experiments are comparable and do not

depend on parameters of a local client computer.

Other experiments referred to performance tests

on PTW variants only (Sec. 5.1.2.) – (Sec. 5.1.4).

They required direct access to an application under

development, not only to its website version available

for a user. Results of tests from Sec. 5.1.2 and 5.1.3

depend on parameters of a local computer. The

experiments have been carried out using a computer

with processor Intel Core i5, 2.30 GHz, RAM 16 GB,

Windows 10x64, and integrated graphics.

Transmission speed of collecting data was about 20

Mb/s. We used the Microsoft Azure cloud service .

5.1 Experiment Results

Experiment results have been delivered by different

tools: Site Analyzer and Website Grader (Sec. 5.1.1),

developer tools of Google Chrome v.74.0.3729.131

(64-bit) (Sec. 5.1.2, 5.1.3), and JMeter (Sec. 5.1.4).

5.1.1 Performance Reported by Quality

Evaluation Tools of Web Applications

Quality of three reference applications, the PTW

prototype, and PTW after refactoring have been

calculated by different quality evaluation tools.

Functionality taken into account in all five

applications covered the same basic requirements

(Sec. 4.2). Two quality evaluation tools returned also

performance among other measured attributes. Site

Analyzer assessed performance with a range from 0

to 100 points. Another tool, Website Grader used a

scale from 0 to max 30 points. The results are given

in Table 1.

Table 1: Comparison of performance.

Web application

Perform. by

Site Analyzer

[max 100]

Perform. by

Website Grader

[max 30]

MKA 61.0 12

PEKA 61.0 12

Waw Car

73.2 14

PTW 73.2 24

Refactored PTW 73.2 30

Performance-based Refactoring of Web Application: A Case of Public Transport

615

5.1.2 General Performance Evaluated by

Developer Tool

Evaluation of quality attributes of the software under

development can also be performed by developer

tools available in a browser, e.g. Chrome. Results of

assessment of the performance attribute of PTW

before and after refactoring are shown in Table 2.

Table 2: Performance by developer tool of Chrome.

Web application Performance by developer tool

of Chrome [max 100]

PTW 7

Refactored PTW 91

5.1.3 Performance of Website Loading

Other performance tests have been carried out to

evaluate mean time that is necessary to present a

website to a user. The measurements were performed

with the developer tool contained in Google Chrome.

All tests were repeated 30 times, and average values

calculated. The results are given in Table 3.

Table 3: Comparison of web loading performance.

Measurement PTW

Refact

PTW

without

cache

Refact

PTW

with

cache

Mean time of DOM

tree loadin

[s]

4.01 0.76 0.40

Mean time of web

loading until starting

of JS execution [s]

5.35 0.96 0.72

Average total loading

time of all web

elements [s]

12.48 1.38 0.88

Average downloaded

data/web size

4.55 mb /

4.55 mb

740 kb /

1.5 mb

15kb /

1.5mb

Average number of

uests

44 42 42

One of the refactoring options was enabling usage

of local cache of browser to store files. Therefore, the

measurements have been conducted twice: without

cache and with cache used.

5.1.4 Performance Testing with Jmeter

Web application performance tests that could identify

workload problems can be performed with the Jmeter

tool (Kiran, 2015). Simulations affecting a server

performance and an application under test can be

executed for different application types and protocols.

For PTW, the performance tests have been

conducted with the following parameters: number of

threads that simulate number of users (7000), rump-

up period, i.e. the time interval during which all the

treads are initiated (500 s), loop count – the number

of repetitions of each thread (5).

Each thread reported its execution time, latency,

size and status, i.e. whether the request was

successfully delivered to the server. The exemplary

results of a testing session are shown in Table 4.

Table 4: Results of performance testing with Jmeter.

Label HTTP Request

#Sam

les 5998

Avera

e 2024

Median 1873

90% line 4177

95% line 4410

99% line 4768

Min 14

Max 6519

Error [%] 40.76 [%]

5.2 Discussion of Results

According to the Website Grader tool, PTW has

better performance that the other web applications

even before refactoring (Table 1). After refactoring

this attribute reached the maximum value (30/30).

Evaluation with another tool (Site Analyzer) also

showed the best result in comparison to other

applications. However, no performance improvement

was reported after refactoring of PTW. Contrasting

this result to other tools, we have doubts whether the

performance results of Site Analyzer are worthwhile.

Measurements conducted by the developer tools

of the Chrome browser showed a very big increase in

performance (from 7 to 91 points), which reached a

level close to maximum (100 points).

Moreover, besides the numeric values, the quality

evaluation tools have returned some hints on the

application improvement. Remarks of Website

Grader and tools from Chrome were beneficial,

whereas those from Site Analyzer were too general

and not practically applicable.

A considerable improvement has been observed

in loading times (Table 3.). The average time of

loading all website elements has dropped from 12.48

s to 1.38 s, or to 0.88 s with the cache support. This

was mainly due to lowering of the site size because of

file minification and compression of picture and other

data. Selection of files to be loaded first resulted in

shortening time delay before starting JavaScript, from

5.35 s to 0.96 s or 0.72 s, accordingly.

The PTW application was placed in the cloud

server and, therefore, some limitations have been

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

616

observed during the performance tests with Jmeter.

The server requests have been successfully handled

up to the limit (almost 6000 users sending requests in

500 s), conforming the sufficient performance. There

was no decline in the website performance observed.

But afterwards, the remaining requests have been

blocked by the server due to the limits exceed. Those

have been classified as error requests in Table 4.

5.3 Threats to Validity

In this section we examine the threats to validity of

this study as described by (Wohlin et al., 2000).

Considering construct validity, we should look at

various tools used in experiments.

Performance of web site loading have been

measured by developer tools supported by the Google

Chrome browser. In order to alleviate generalisation

bias, each experiment has been repeated 30 times with

the same workload, and the final result calculated as

an average value. The tests have been conducted

using Google Chrome, and using a different browser

we can get some diverse outcomes. These

measurements depend also on the connection speed,

which could influence time of getting results.

Additional factors affecting this time are also

parameters of computer on which the experiments

have been carried out, including computer processor,

graphical card, and RAM memory. However, the

essential goal of the measurement was not getting

some absolute values, but comparison of the

application performance before and after refactoring.

A set of performance measurements were

performed using the JMeter tool and an external

server. The tests have been repeated 30 times, to get

an averaged values. The time of a server response

could depend on the traffic intensity on the server, but

the measurement errors were not noticeable. Local

factors, such as parameters of a local computer and of

a transmission connection have no influence of this

kind of measurement.

Evaluations delivered by the quality evaluation

tools (Site Analyzer and Website Grader) should be

at the lowest estimate endangered by measurement

errors. They were assumed to be independent of

external or local conditions. Nevertheless, this sort of

experiments were repeated in different conditions

(different local computers, under different workloads,

during different daytimes, etc.) and the results were

exactly the same, confirming our assumptions.

As for conclusion validity, we should be careful

while discussing the same quality attributes but

provided by different tools. The tools use different

criteria for assessment of the attributes under the

same names. Therefore we have compared the results

provided by each tool separately. Furthermore

internal quality is bounded by the whole process

measurements. Many refactoring activities impact on

the given process as a whole; we were no assessing

effects caused by the activities independently.

External validity is restricted, as the whole

refactoring process undergoes only one application

created in the selected technology.

6 CONCLUSIONS

The web application performance, and other quality

factors, can be considerably improved. The general

performance attribute of our SPA application was

equal or higher than of the three MPA applications.

Different refactoring activities have been shown to

positively influence the performance results. The

improvement reported by Chrome was very big (from

7 to 91), and all time characteristics of web loading

increased significantly.

However, the conclusions are limited, as absolute

outcomes vary in accordance to an application

examined and the technology used. They could be

different in the case of various SPA frameworks, as,

for example, React.js, or Angular.js.

While considering this type of refactoring, should

be carefully taken into account which application

features have to be preserved, especially concerning

its security, and other non-functional constraints.

Another big challenge remains possibility of

automating such kind of refactoring. Most of the

operations do not refer to a direct code substitution,

as in the traditional code refactoring, but relate to file

manipulation, often with use of additional tools,

changing of configuration parameters, or protocols.

REFERENCES

Baqais, B.A.A., and Alshayeb, M, 2019. Automatic

software refactoring: a systematic literature review.

Software Quality Journal. 3 Dec. doi: 10.1007/s11219-

019-09477-y

Dennis, A.R. and Taylor, N.J., 2006. Information foraging

on the web: The effects of “acceptable” Internet delays

on multi-page information search behavior. Decision

Support Systems 42(2), 810-824. doi:

10.1016/j.dss.2005.05.032

Derezinska, A., Kwaśnik, K., 2020. Evaluation and

improvement of web application quality – a case study.

In: Zamojski W., Mazurkiewicz, J., Sugier, J.,

Walkowiak, T., and Kacprzyk, J., (eds) New Advances

in Dependability of Complex Systems: Proc. of 15

Performance-based Refactoring of Web Application: A Case of Public Transport

617

Inter. Conf. on Dependability and Complex Systems.

AICS, Springer, Cham. to appear.

Fowler, M., 2018. Refactoring: improving the design of

existing code (2

ed.). Addison-Wesley.

Grigorik, I., 2013. High Performance Browser Networking:

What Every Web Developer Should Know About

Networking and Web Performance. O’Reilly Media.

Grunt-uncss, A grunt task for removing unused CSS from

your projects with UnCSS. [Online] Available from:

https://github.com/uncss/grunt-uncss [Accessed: 23

Feb 2020]

Gudivada, V.N., Rao, D. and Paris, J., 2015. Understanding

Search-Engine Optimization, Computer. 48(10) IEEE,

pp. 43-52. doi: 10.1109/MC.2015.297

Gupta, S. and Gupta, B.B., 2015. Cross-Site Scripting

(XSS) attacks and defense mechanisms: classification

and state-of-the-art, International Journal of System

Assurance Engineering and Management. 8(1), pp.

512-530, doi: 10.1007/s13198-015-0376-0

Gupta, B.B., Gupta, S. Gangwar, S., Kumar, M., and

Meena, P. K., 2015. Cross-Site Scripting (XSS) Abuse

and Defense: Exploitation on Several Testing Bed

Environments and Its Defense. Journal of Information

Privacy & Security; Abingdon 11(2), pp. 118-136. doi:

10.1080/15536548.2015.1044865

ISO/IEC 25010:2011 Systems and software engineering.

Systems and software quality requirements and

evaluation (SQuaRE). System and software quality

models, 2010.

ISO/IEC 25023:2016 Software engineering: software

product quality requirements and evaluation (SQuaRE):

Measurement of system and software quality. 2015.

Jadhav, M.A., Sawant, B.R., and Deshmukh, A., 2015.

Single Page Application using AngularJS.

International Journal of Computer Science and

Information Technologies, 2876-2879. doi:

10.1.1.736.4771

Kaur, S., Kaur, K., and Kaur, K., 2016. Analysis of Website

Usability Evaluation Methods. In: Proceedings of 3rd

International Conference on Computing for

Sustainable Global Development (INDIACom), pp.

1043-1046. IEEE, New York.

Kaur, S., and Singh, P., 2019. How does object-oriented

code refactoring influence software quality? Research

landscape and challenges. Journal of Systems and

Software. 157 (11), Elsevier. doi: 10.1016/j.jss.2019.

110394

Kierevsky, J., 2004. Refactoring to patterns. Addison

Wesley.

Kiran, S., Mohapatra, A., and Swamy, R., 2015.

Experiences in performance testing of web applications

with Unified Authentication platform using Jmeter. In:

International Symposium on Technology Management

and Emerging Technologies (ISTMET), IEEE, pp. 74-

78. doi: 10.1109/ISTMET.2015.7359004

Leff, A., and Rayfield, J.T., 2001. Web-Application

Development Using the Model/View/Controller Design

Pattern. In: Proceedings Fifth IEEE International

Enterprise Distributed Object Computing Conference,

IEEE, pp.118-127, doi: 10.1109/EDOC.2001.950428

Lew, P., Olsina, L., Becker, P., and Zhang, L., 2012. An

integrated strategy to systematically understand and

manage quality in use for web applications.

Requirements Eng. 17, 299-330. doi: 10.1007/s00766-

011-0128-x

Mariani, T., and Vergilio, S. R., 2017. A systematic review

on search-based refactoring. Information and Software

Technology. 83(3) pp. 14-34. Elsevier. doi:

10.1016/j.infsof.2016.11.009

Martinez-Fernandez, S., Vollmer, A. M., Jedlitschka, A.,

Franch, X., Lopez, L., Ram, P., Rodriguez, P.,

Aaramaa, S., Bagnato, A., Choraś, M., and Partanen, J.,

2019. Continuously Assessing and Improving Software

Quality with Software Analytics Tools: a Case Study.

IEEE Access 7. doi: 0.1109/ACCESS.2019.2917403

Rochimah, S., Arifiani, S., and Insanittaqwa, V.F., 2015.

Non-Source Code Refactoring: A Systematic Literature

Review. International Journal of Software Engineering

and Its Applications. 9(6) pp.197-214. doi.

10.14257/ijseia.2015.9.6.19

Srivastava, M., 2014. Algorithm to prevent back end

database against SQL injection attacks. In:

International Conference on Computing for

Sustainable Global Development (INDIACom), IEEE,

pp. 754-757, doi:10.1109/IndiaCom.2014.6828063

Stępniak, W., and Nowak, Z., 2017. Performance Analysis

of SPA Web Systems. In: Borzemski L., Grzech, A.,

Świątek, J., and Wilamowska, Z., (eds) Proceedings of

37th International Conference on Information Systems

Architecture and Technology – ISAT 2016. AiCS vol

521. Springer, Cham, pp. 235-247. doi: 10.1007/978-3-

319-46583-8_19

UglifyJS 3: Online JavaScript minifier. [Online] Available

from: https://skalman.github.io/UglifyJS-online/

[Accessed 31 Jan 2020]

Verdu, J., and Pajuelo, A., 2016. Performance scalability

analysis of JavaScript applications with web workers.

IEEE Computer Architecture Letters. 15(2), pp.105-

108. doi: 10.1109/LCA.2015.2494585

WebP A new image format for the Web. [Online]

[Accessed 31 Jan 2020] Available from:

https://developers.google.com/speed/webp

Wijnants, M., Marx, R., Quax, P., and Lamotte, W., 2018.

HTTP/2 Prioritization and its Impact on Web

Performance. In: Proceedings of the 2018 World Wide

Web Conference, (WWW '18 ) pp. 1755-1764, doi:

10.1145/3178876.3186181

Wohlin, C., Runeson, P., Host, M., Ohlsson, M. C. Regnell,

B. and Wessln, A., 2000. Experimentation in Software

Engineering - An Introduction. Springer. Berlin

Heidelberg.

Zou, Y., Chen, Z., Zheng, Y., Zhang, X., and Gao, Z., 2014.

Virtual DOM coverage for effective testing of dynamic

web applications. In: Proceedings of the 2014

International Symposium on Software Testing and

Analysis, ISSTA 2014. ACM New York, pp. 60-70, doi:

10.1145/2610384.2610399

ENASE 2020 - 15th International Conference on Evaluation of Novel Approaches to Software Engineering

618
