An Identity-matching Process to Strengthen Trust in Federated-identity

Architectures

Paul Marillonnet

1,2 a

, Mika

el Ates

, Maryline Laurent

2 b

and Nesrine Kaaniche

3 c

Entr’ouvert, Paris, France

SAMOVAR, T

ecom SudParis, Institut Polytechnique de Paris, France

Security of Advanced Systems, Department of Computer Science, University of Shefﬁeld, U.K.

Keywords:

Identity Matching, Federated-identity Architecture, Identity Management, Citizen-relationship Management,

Trust Enforcement.

Abstract:

To smoothly counteract privilege escalation in federated-identity architectures, the cross-checking of asserted

Personally Identiﬁable Information (PII) among different sources is highly recommended and advisable. Iden-

tity matching is thus a key component for supporting the automated PII cross-checking process. This paper

proposes an efﬁcient identity-matching solution, adapted to a chosen User-Relationship Management (URM)

platform, relying on a French Territorial Collectivities and Public Administrations (TCPA) use case.

The originality of the paper is threefold. (1) It presents an original solution to identity-matching issues raised

by a concrete use case from the Territorial Collectivities and the Public Administration (TCPA), formalizing

concepts such as information completeness, PII normalization and Levenshtein-distance matrix generation. (2)

Implementation guidelines are given to deploy the solution on an operational Publik platform. (3) A precise

security analysis is provided, relying on an original attacker model.

1 INTRODUCTION

To smoothly counteract users overriding their privi-

leges (Zhao et al., 2005; Bugiel et al., 2012) derived

from their Personally Identiﬁable Information (PII)

in Federated-identity architectures, it is now com-

monly assumed that declared PII are cross checked

among several sources. Of course the reliability of

the identity-matching process fully relies on the qual-

ity of the identity attributes provided by the sources,

and the level of trust of the sources.

Thus for qualifying the reliability of a PII, there

is a need to distinguish, from an organizational point

of view, the level of trust that each source is granted,

and, from a technical point of view, the level of

data quality a source is able to provide under a

lighter validation or a stronger certiﬁcation proce-

dure (see for instance their use in the Internet pub-

lic key infrastructure (Zolotarev et al., 2001; Hunt,

2001)). Certiﬁed identity information (i.e. cer-

https://orcid.org/0000-0003-2834-9004

https://orcid.org/0000-0002-7256-3721

https://orcid.org/0000-0002-1045-6445

tiﬁcates) can take the classic form of assertions in

the Security Assertion Markup Language (Organiza-

tion for the Advancement of Structured Information

Standards, 2005) (SAML), which are still used in

federated-identity architectures. Validated identity in-

formation are increasingly expanding through service

providers using OpenID Connect (OIDC) (Sakimura

et al., 2014) protocol (rather than SAML), request-

ing data sources over HTTPS (with server-side au-

thentication only), and the resulting identity informa-

tion contained in the provider’s applicative response

remaining unsigned. In the same vein, information

can be either validated or certiﬁed as in the form of

JavaScript Object Notation (JSON) which are pro-

vided by attributes providers which are mostly appli-

cation programming interfaces (APIs). As a result,

the aforementioned sources mostly provide validated

identity information instead of certiﬁed information.

The use case considered in this paper is the French

Territorial Collectivities and Public Administration

(TCPA), which are encouraged to use such validated

sources of identity information, in order to simplify

citizen online services, thus moving towards the ”Tell

142

Marillonnet, P., Ates, M., Laurent, M. and Kaaniche, N.

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures.

DOI: 10.5220/0009828401420154

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 142-154

ISBN: 978-989-758-446-6

us once” program

This paper presents the necessary measures when

performing identity matching in distributed identity

architectures for a speciﬁc use case. This use case

comes from the domain of user-relationship manage-

ment (URM) in territorial collectivities and public ad-

ministrations (TCPA). This use case requiring spe-

ciﬁc identity-matching procedures has not been pre-

sented in the academic literature so far. In order to

do so, this paper introduces a series of key concepts,

involved in deﬁning the identity-matching process it-

self, as well as formalizing the security analysis given

later on in the article. The security analysis proves the

security suitability of the solution against four types

of identiﬁed threats. Finally, implementation guide-

lines for audience willing to reproduce the ready-for-

production solution on their own are given.

The remainder of the paper is as follows. Sec-

tion 2 describes the related work. Section 3 deﬁnes

the selected use case for territorial collectivities and

public administration (TCPA), motivating the need

for an identity-matching automated process. Sec-

tion 4 describes the different identity- and personally-

identiﬁable-attribute sources relevant to our use case.

Section 5 deﬁnes the identity matching procedure to

follow when combining user data from such sources.

Section 6 gives the aforementioned security analysis

of the identity-matching procedure within the citizen-

relationship management environment, and Section 7

gives the conclusions. Eventually, Section 7 gives a

brief conclusion and provides some perspective to this

ongoing identity-management research.

2 RELATED WORK

Federated-identity architectures and their shortcom-

ings have been widely described in the literature. For

instance, (Camenisch and Pﬁtzmann, 2007, Chap-

ters 1, 2 and 3) provide an analysis on their short-

comings regarding user privacy. However, no aca-

demic contributions studying the provision of iden-

tity and personally-identiﬁable-attributes by several

sources in federated-identity architectures have been

elaborated so far.

Additionally, the management of personally-

identiﬁable-attributes sources, in a privacy-compliant

way, for user-centric architecture has been stud-

ied at large, for instance in (Mortier et al., 2016)

and (de Montjoye et al., 2014). Similarly, the use

of personallaly-identiﬁable attributes for TCPA-based

See the dedicated page on the ofﬁcal French moderni-

sation de l’action publique website (resource in French).

purposes has been proposed in (Papadopoulou et al.,

2015) and (Shadbolt, 2013). However, these four

contributions do not provide solutions for identity-

matching issues that arise when managing such

sources.

More generally, the issues linked to identity-

matching within federated-identity systems involv-

ing personally-identiﬁable-attribute sources have not

been proposed yet. The lack of academic coverage

for this particular subject is notable. This leads us to

stating the main issue, by identifying ﬁrst the use case

and second the useful functional requirements.

3 PROBLEM STATEMENT

3.1 The TCPA Use Case

The main use case considered in this paper is the en-

rollment of the user’s children to the school restau-

rant of her territorial collectivity in France. The term

collectivity should be understood by the reader in the

French administrative context, i.e. as a subdivision of

the state’s territory which is granted some partial au-

tonomy by the central government. With regard to our

use case, these territorial collectivities are responsible

for the children enrollment to schools that belong to

their territory. Such collectivities usually provide an

online service for parents to pay the school restaurant

fees.

As a result the different actors of the use case are:

• The parent or the legally-responsible of the child

or children. With regards to our use case, the par-

ent is the user of the school restaurant enrollment

online service.

• The user-relation management (URM) online

platform, providing the school restaurant enroll-

ment service.

• The FranceConnect

ofﬁcial federated-identity

service of the French administration.

• The DGFIP

personally-identiﬁable-attribute

source.

• The CNAF

personally-identiﬁable-attribute

source.

As deﬁned in French collectivities, the school restau-

rant fees depend on the parents’ tax information (and

in particular their tax reference revenue document) as

https://franceconnect.gouv.fr/ (resource in French).

https://www.impots.gouv.fr/portail/presentation-de-la-

dgﬁp-overview-dgﬁp (resource in French).

https://www.caf.fr/ (resource in French)

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

143

well as their children’s allowance information (in par-

ticular their familial quotient value). Obtaining such

information enables the collectivities to deﬁne custom

and fair school restaurant fees.

As a result, when enrolling their children to the

school restaurant, the parent ﬁlls an online form

which requires them to provide the following infor-

mation:

1. Their children’s allowance registration number.

2. The postcode of their current main address.

3. Their identiﬁcation number in the French tax sys-

tem.

4. Their last yearly tax receipt.

Items 1. and 2. are required to retrieve the user’s

children’s allowance information thanks to the CNAF

attribute source. Similarly, items 3. and 4. are re-

quired to retrieve the user’s tax information thanks

to the DGFIP attribute source. All four items are re-

trieved through the API Particulier

. Put in place in

2017 by DINUM

, this API offers an access to the two

aforementioned attribute sources through two differ-

ent endpoints, accessible for TCPAs after registration

and obtention of a client-speciﬁc token.

When necessary, the identity matching, either au-

tomated or performed manually by the agent as de-

scribed later in Section 5, happens on the PII provided

by FranceConnect and the API Particulier endpoints.

Generally, when completing online procedures,

citizens are expected to prove their identity. In order

to do so, the enrollment form enables the user to log in

using the FranceConnect federated-identity service.

On the contrary, when that identity federation ser-

vice is not used by users while ﬁlling the form, they

are instead asked to provide a scanned copy of an of-

ﬁcial identity document (e.g. their identity card, driv-

ing license or passport). In this case, a TCPA (human)

agent validates the authenticity of the scanned docu-

ment.

In any case the user identity needs to be validated

as properly matching with the different personally-

identiﬁable attributes provided by the sources. Fail-

ing to adequately address this procedure hinders the

completion of citizen-relationship management.

Stating the main problem also comes with the se-

curity hypotheses of the solution. These security hy-

potheses are strongly linked to the technologies used

either with the identity-matching procedure or more

generally with the citizen-relationship management

software environment itself. These hypotheses are

listed below:

https://particulier.api.gouv.fr/ (resource in French).

https://www.numerique.gouv.fr/dinum/ (resource in

French).

CNAF

DGFIP

Jean Durand

Adeline Dupont

Bernard Dubois

FranceConnect

validated ID

Tax revenue

Family

quotient

In the URM workflow,

the school restaurant

fees are computed

from an inorganic

faked user identity

→&i.e. collusion

URM platform

FranceConnect

Figure 1: A classic collusion case illustrated.

• Server-side SSL/TLS authentication is used, as

for usual Web technologies.

• The identity information is provided by the

FranceConnect service according to the OIDC

protocol.

• The DGFIP and CNAF endpoints are restricted:

they are accessible after registration only, which

involves per-case validation. The endpoints ex-

pose read-only resources according the the Repre-

sentational state transfer architecture style (Field-

ing, 2000).

3.2 Functional Requirements

The use case results in the following list of functional

requirements, necessary for the TCPA to:

• Prove a user’s identity through the information

provided by the available sources.

• Ensure that all the personally-identiﬁable at-

tributes provided by the available sources for a

given user are related to the concerned user and

not anyone else. In particular, the solution must

prevent the collusion cases illustrated in Figure 1.

• Tackle the numerous true positive cases of

identity-matching in an autonomous manner.

• Collect (either true or false) negative cases, as

well as ambiguous cases, that need thorough in-

spection by a TCPA agent.

The following section provides a more thorough

description of the aforementioned identity- and

personally-idenﬁable-attribute sources.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

144

4 IDENTITY SOURCES

4.1 FranceConnect

FranceConnect is the ofﬁcial identity federation ser-

vice of the French administration. The identity infor-

mation it uses comes from the INSEE’s

RNIPP

. It

implements the OpenID Connect (OIDC) (Sakimura

et al., 2014) identiﬁcation layer, itself derived

from the OAuth 2.0 authorization framework (Hardt,

2012). Thus FranceConnect is a production de-

ployment adopting the OIDC protocol speciﬁcations,

where OIDC providers are ofﬁcially registered and

have to conform with one of the three authentication

levels deﬁned by the eIDAS regulation

As a result, the user identiﬁcation ﬂow requires

the following steps:

1. The online service provider sends an authentica-

tion request to the FranceConnect service.

2. The user’s Web browser is redirected to the

FranceConnect identity provider selection inter-

face.

3. Upon selecting one of the FranceConnect

providers, the user authenticates to that provider.

The way the user authenticates varies from

one provider to another (especially when such

providers obey to different eIDAS authentication

levels).

4. A reverse redirection back to the service provider

is performed, allowing the service provider to ob-

tain an ID Token, which characterizes some of the

user’s identity information, including a local fed-

eration identiﬁer for that user.

4.2 DGFIP

As explained in Section 3, the DGFIP attribute source

is a speciﬁc endpoint of the API Particulier, main-

tained by the DINUM. It provides various user tax

information to a service provider, after registration of

the service provider and the obtention of an access to-

ken.

In order to call this endpoint to the DGFIP at-

tribute source, the service provider must register to

the API Particulier. This registration step is necessary

Institut National de la Statistique et des

Etudes

Economiques, i.e. the national instition for statistics and

economical studies.

Registre National d’Identiﬁcation des Personnes

Physiques, i.e. the national register for identiﬁcation of

French-living individuals –see Section 3.

https://www.ssi.gouv.fr/entreprise/reglementation/conf-

iance-numerique/le-reglement-eidas/ (resource in French).

prior to any access to the endpoint, and has not been

automated yet. This step leads to the obtention of

an API key for the newly-registered service provider,

necessary for any further call to the endpoint.

Once this prerequired registration step is com-

plete, addressing requests to this endpoint implies

providing user information (as query-string argu-

ments). This information, considered to be conﬁden-

tial, is made of (i) the user’s identiﬁcation number in

the national tax system and (ii) the reference number

of the user’s most recent yearly tax receipt.

As a result, the user information returned by the

API contains the user tax reference revenue used to

determine the school restaurant fees. It also contains

human-readable PII, enabling a partial veriﬁcation of

the identity of the user.

4.3 CNAF

The CNAF endpoint is also part of API Particulier.

It provides various children’s allowance information

regarding the user.

Similarly to the DGFIP source described in Sec-

tion 4.2, calling this endpoint requires the service

provider to register to the API Particulier, and to

provide as query-string arguments (i) the user’s al-

lowance identiﬁcation number and (ii) the user’s post-

code.

The user information returned by the API contains

the user’s family quotient value, required to determine

the school restaurant fees, as well as human readable

PII.

5 IDENTITY MATCHING

5.1 Motivations for an

Identity-matching Automated

Procedure

For an Advanced Identity-matching Procedure.

Let us consider a ﬁrst naive approach for which the

validation is a straightforward equality testing, i.e. by

directly comparing the values returned by each source

in order to detect potential mismatches.

A naive approach of straightforward equality test-

ing would require to build, for a given identity at-

tribute I, a result vector as follows:

result

= S

(I), ∀ j ∈ {1, . . . , n} (1)

where S

is the j-th available source, j ∈ {1, . . . , n}.

For each identity attribute, the validation process

woud be as follows, for each I in I∗, where I ∗ is the

set of all available PII attributes:

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

145

• If I is provided by a subset of all the available

sources only, ensure that all the elements of the

subset {n

, . . . , n

} – that correspond to valid in-

formation given by the sources S

, . . . , S

pro-

viding I – are identical, i.e. result

= ··· =

result

• More particularly, in the simpler case where I is

provided by all the available sources, ensure that

all the n elements of the result vector are identical,

i.e. result

= · ·· = result

However, adopting this approach will raise false neg-

atives

, especially when slight variations in the in-

formation retrieved across the sources have been no-

ticed. For instance, some sources will strip the accents

out of identity information represented as character

strings, whereas some others will not.

This approach will also raise false negatives in some

cases – for instance when a data transformation is

required before performing any comparison. Thus a

string representation of an address contains a postal

code that can be compared after extraction, to other

sources of information.

Thus there is a clear need for an advanced identity-

matching procedure, relying on cross-checking of as-

serted PII among different sources. Moreover, deter-

mining the cardinality of the set of sources providing

the identity attributes, and using that cardinality value

as part of the identity matching decision process is the

ﬁrst step to the concept of information completeness,

presented later in this article, in Section 5.3.

For an Automated Procedure. Let us consider the

validation of PII by a (human) agent of a collectivity.

The agent can identify slight variations and compare

information presented to him in different formats. In

our TCPA use case, the agent, in order to perform a

single identity-matching step, is displayed informa-

tion from the three sources.

Manual validation of user information is a repet-

itive and time-consuming task for the agents, hence

preventing them to perform more meaningful manner

such as validating complex procedures or providing

citizens with custom case-by-case assistance – espe-

cially considering their thorough knowledge of their

collectivity’s citizen-relationship management proce-

dures.

Most importantly, this manual approach does not

stand anymore if the number of sources increases in a

signiﬁcant manner: for an information repeated under

various forms across n sources, this requires

(n−1)n

validation steps, which rapidly becomes non-viable

That is theoretically matching identities which are de-

tected as mismatches.

and incompatible with a manual systematic validation

by the agent. Indeed, the underlying complexity is in

O(n

). For ﬁve sources, the agent needs to complete

ten comparisons; this number rises to forty-ﬁve com-

parisons for ten sources, and so on. . .

As a result, the need for providing an automated

identity-matching procedure is notable. The follow-

ing Section 5.2 presents the identity matching proce-

dure and deﬁnes a few key concepts to performing

automated identity matching based on data provided

by multiple sources, as described in Section 3.

5.2 Presentation of the Use Case

Identity Matching Procedure

According to the use case deﬁned in Section 3,

the user-relationship management platform, acting as

a service provider to the identity- and personally-

identiﬁable-attribute sources, relies on the identity

provided by the FranceConnect service.

The user-relationship management platform has to

ensure that the identity provided by one of the France-

Connect identity providers matches with the identity

attributes contained in the data returned by the CNAF

and the DGFIP endpoints.

The FranceConnect service returns a “pivot”

identity, containing a set of user attributes (i) a

blankspace-delimited list of the user’s ﬁrst and mid-

dle names, (ii) the user’s family name and (iii) a string

representation of the user’s birthdate.

The CNAF endpoint returns (i) the user’s full

postal address, containing their postcode, (ii) a string

representation of the user’s birthdate (ii) a string rep-

resentation of the user’s full name (i.e. their ﬁrst and

last names).

The DGFIP API returns(i) the user’s current name,

(ii) the user’s birth name, (iii) a string representation

of the user’s ﬁrst and middle names, (iv) a string rep-

resentation of the user’s birthdate and (v) a string rep-

resentation of the user’s postal address, containing the

postcode.

Using all the information provided by these three

sources, our goal is to cover most (if not all) identity-

matching cases with simple algorithms.

5.3 Information Completeness

The following paragraphs deﬁne the different degrees

of completeness of the information provided by the

sources. This concept of information completeness is

necessary to deﬁne the identity-matching process.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

146

Matching

Ambiguous

Non-matching

Sources

(Unnormalized)

PII provisioning

PII normalization

Levenshtein

distance matrix

generation

Matching

algorithm

execution

Human agent

correction,

when

necessary

Levenshtein

distance matrix

Figure 2: Visual summary of the identity matching process

for a complete PII attribute.

5.3.1 Formal Deﬁnitions

• Relation provides.

A relation from the set of sources to the set of avail-

able PII, called provides, is deﬁned for a given source

S ∈ S , where S is the set of all available sources, and

a given identity attribute type t ∈ T , where T is the

set of all available identity attribute types, as follows:

S provides t (2)

meaning that an identity attribute of type t is provided

by S for any given user of the architecture. This def-

inition implies that the set of available PII provided

by a source is the same for any user of the system.

This hypothesis does not hold in some corner cases.

However these corner cases do not invalidate the

identity-matching procedure presented in the article.

• Partial Information.

Partial information is deﬁned as the set T

, respecting

the following property:

∀t ∈ T

, ∃S ∈ S, ¬(S provides t) (3)

where ¬ is the notation used for the logical negation

operator.

5.3.2 Complete Information

Complete information is deﬁned as the logical con-

trary of partial information, i.e. it is the set T

so that:

∀t ∈ T

, ∀S ∈ S, S provides t (4)

5.3.3 Sufﬁcient Partial Information

We need to categorize partial information in a ﬁner

way in order to decide of its role in identity matching.

The ﬁrst category is sufﬁcient partial information, and

is deﬁned as follows.

According to our TCPA use case, PII (i) ﬁrst and

middle names, (ii) last names and (iii) date of birth,

as deﬁned in the end of Section 5.2, are the biggest

possible set of common information accross all the

sources. However, potential mismatches on partial in-

formation, i.e. information that is shared by a strict

subset of all the sources and whose cardinality is at

least 2 can also be detected.

Sufﬁcient partial information is deﬁned as the set

so that:

∀t ∈ T

, ∃S, S

∈ S

S provides t and S

provides t

(5)

5.3.4 Insufﬁcient Partial Information

Some information may be offered by one source only,

in which case it cannot be used as input for the iden-

tity matching process.

In other terms, insufﬁcient partial information is

deﬁned as the set T

so that:

∀t ∈ T

, ∃S ∈ S,

(S provides t ∧(∀S

6= S ∈ S, ¬S

provides t))

(6)

5.4 Validation Algorithm

5.4.1 Format Uniﬁcation

The comparison as well as the detection mechanisms

are based on an ASCII representation of identity in-

formation (i), (ii) and (iii) (see Section 5.2). More

generally, for any given PII type, deﬁning a format-

uniﬁcation procedure is necessary.

As explained in the problem statement (Section 3),

depending on the sources, the identity information

is presented under different formats. That’s why a

format-uniﬁcation step is required before perform-

ing the comparison between the information avail-

able across the sources. For instance, identity in-

formation (iii) – i.e., the date of birth of the user

– string representation differs between the France-

Connect data source (YYYY-MM-DD), the DGFIP data

source (DD/MM/YYYY) and the CNAF data source

(DDMMYYYY).

Similarly, the DGFIP source provides the user’s

postcode of main residence, as part of a longer string

representing the postal address of the user (34 Rue des

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

147

Lilas 75001 Paris). Obviously this postcode needs

to be extracted if needed for comparison to similar

information provided by other sources.

This format uniﬁcation is of course speciﬁc to a

PII type t ∈ T and to a given source S j, j ∈ {1, . . . , n}.

Thus it is deﬁned as a function P

so that:

∀ j ∈ {1, . . . , n}, ∃P

(t)) ∈ C

(7)

where C is the set of comparable elements for PII of

type I, meaning that it is a set of elements of a same

format along with a comparison operator.

5.4.2 Normalization of Unicode Strings

Let us consider the case of a family name that con-

tains non-strictly-Latin characters, e.g. Sm

ıc¸z, has

to undergo this format-uniﬁcation step. This family

name can be present in other sources under the form

of a stricter Latin character set, such as Sm

ıcz, or even

Smicz.

According to the Unicode speciﬁcations (The Uni-

code Consortium, 2011), a normalization form in-

volving a compatibility decomposition is most ap-

propriate. The compatibility decomposition form

(NFKD

) is favored over the canonical form

(NFD

) so as to handle a subset of Unicode known

to be stable. Indeed, the canonical form’s ability to

preserve the visual appearance of the input characters

after normalization is not of interest in our use case,

as the normalized information will not be displayed to

end users or human agents of the platform but rather

be processed against identity matching algorithm in-

stead. Eventually, the relevant normalization process

here only requires decomposition, hence the two other

existing normalization forms – NFC and NFKC forms

both requiring an additional composition step – are

not relevant here.

5.4.3 Distance Computation

Even over a stable Latin alphabet, small variations ap-

pear on names provided by different sources. For in-

stance, cases where the different representations of a

user’s last name across multiple sources differ only

slightly, e.g. Smicz for a source S

and Smics for a

source S

, need to be detected.

As a result, a distance computation procedure is

described in this section. This procedure can be used

in order to detect the aforementioned small variations

in PII across sources. This procedure is based on the

Levenshtein distance algorithm (Levenshtein, 1966),

Normalization form by compatibility decomposition.

Normalization form by canonical decomposition.

computing a value between two strings A and B de-

pending on the minimal number of elementary edit

operations in order to go from string A to string B.

This distance deﬁnes three types of elementary

edit operations on a string of characters within a char-

acter set Σ: (i) inserting a character, (ii) removing a

character and (iii) swapping a character for another

one in Σ.

Accordingly, a path P (A, B) from two strings A

and B is a series of elementary edit operations chang-

ing string A into string B. A and B belong each to Σ∗,

which is the set of all possible strings made from the

character set Σ along with the empty string λ. The

length of this path is the number of edit operation it

describes. It is noted |P |.

As a result, the Levenshtein distance d(A, B) be-

tween two strings A and B is the length of the short-

est path going from string A to string B. The dis-

tance operator over (Σ∗)

→ N is commutative, i.e.

d(A, B) = d(B, A).

Further academical work regarding the Leven-

shtein distance has been published. However, in

our speciﬁc case, the plain Levenshtein distance

algorithm is sufﬁcient. For instance, comput-

ing the Levenshtein distance between Smicz and

Smics is straightforward: this distance is 1. Cases

where the distance is relatively low are consid-

ered. Such cases help to detect variations between

personally-identiﬁable-attribute values across several

sources. One Python software implementation is the

python-levenshtein software module

, providing

a simple API for computing the edit distance between

two strings.

The notion of distance and its application to our

result vectors need to be explained. Each element of a

result vector is ﬁrstly normalized (Section 5.4.2), and

the global distance of a result vector is the following

matrix representation:

M(result

) ∈ M

) where i ∈ {1, . . . , n} is the

source index.

M is made of elements m

i j

, i ∈ {1, . . . , n}, j ∈

{1, . . . , n} so that each m

i j

is either the Levenshtein

distance d(result

, result

) or left empty if result

result

is unavailable (in case of partial information

as deﬁned in Section 5.3).

5.5 Our Use Case’s Speciﬁc Information

A per-information validation procedure for the se-

lected types of PII is described here. In order to ef-

ﬁciently detect these mismatches, the most complete

information is described ﬁrst, followed by increas-

ingly more partial sufﬁcient information.

https://pypi.org/project/python-Levenshtein/

SECRYPT 2020 - 17th International Conference on Security and Cryptography

148

5.5.1 Birth Date

The user’s birth date is considered as complete for our

three sources.

For each source, it is provided in a speciﬁc format:

1. FranceConnect adopts the OIDC ISO 8601:2004

YYYY-MM-DD format (Sakimura et al., 2014, Chap-

ter 5.1).

2. The DGFIP API returns dates according to the

DD/MM/YYYY format.

3. The CNAF adopts yet another format, returning

dates according to the DDMMYYYY format.

Sources are considered trustworthy regarding date

consistency, therefore no semantic date validation is

performed. Django custom template ﬁlters are there-

fore used to perform format uniﬁcation. This tem-

plate ﬁlter is based on the python standard datetime

library. When providing the input format, it makes it

possible for us to compare the several dates provided

by the available data sources.

5.5.2 String Types

String types, as mentioned in Section 5.4.1 are nor-

malized using the unicodedata python module nor-

malization algorithm, set to the NFKD form (Davis

and D

urst, 2001). For each PII among our selected

information (either complete or sufﬁcient-partial), a

result vector whose associated distance matrix is ob-

tained, as explained in Section 5.4.3.

First Name(s). FranceConnect delivers a list of

ﬁrst and middle names. The ﬁrst name is used as com-

plete information, and the remaining middle names

are sufﬁcient partial information as they are retrieved

from both the FranceConnect service and the DGFIP

endpoint. Extracting the ﬁrst name is performed di-

rectly thanks Python’s string manipulation functions.

Last Name. The last name is provided by all three

PII sources and is therefore complete information.

5.5.3 Geographical Information

The postal code from the user’s main address is suf-

ﬁcient partial information, as it is retrieved from both

the DGFIP and the CNAF sources. However, INSEE

code of birth place is insufﬁcient partial: is it returned

only by the FranceConnect service (and only when

the user is born in France).

5.6 Implementation Considerations

This section relies on the Publik URM software suite.

Licensed as AGPLv3 free software, its sources are

available on its project management webpage

This software can either be installed as Debian

packages or directly from sources using an Ansible

playbook. For our experimental setup, a development

instance of the Publik software suite is installed, us-

ing the community documentation

of the software

installation process.

This URM platform is made of three types of soft-

ware entities:

• User-oriented software entities, offering

URM features such as content management,

appointment-making with TCPA agents, or

scanned documents depository.

• Similarly, the URM platform is also made of

agent- and administrator-oriented software enti-

ties, offering form and workﬂow design, or collect

and expose statistics about the platform usage.

• Technical software entities, necessary for the

unity of the URM platform.

5.6.1 Implementation of the Validation Process

in the URM Platform

This section assumes that a running Publik instance is

accessible with administrator privileges in order to set

up the identity-matching procedure.

In order to meet our use case, a school restaurant

online subscription form and its associated workﬂow

are conﬁgured. As explained in Section 3, the online

procedure requires the user to provide their tax

and children allowance information. When such

information is provided, the workﬂow performs an

identity matching validation.

The key features used in the workﬂow are:

• WebService calls, in order to retrieve the identity

information available at the three FranceConnect,

DGFIP and CNAF remote sources.

• Evaluation of Django custom template ﬁlters, in

order to:

1. normalize the information retrieved from these

sources. This normalization includes splitting

the different ﬁelds for a consistent information

comparison, as well as performing Normaliza-

tion Form Canonical Decomposition (NFKD)

https://dev.entrouvert.org/

https://doc-publik.entrouvert.com/dev/

installation-developpeur/ (resource in French).

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

149

over potentially non-ASCII strings. This nor-

malization form means that the Unicode char-

acters of the strings retrieved from the data

sources are translated into a set of characters

known to be stable.

2. compute the distance between elements of a re-

sult vector of normalized PII from our three

identity- and personally-identiﬁable-attribute

sources.

3. display the identity-matching result informa-

tion in a human-readable manner.

Adding template ﬁlters is performed directly accord-

ing to the Django template engine.

A simple procedure that generates the result vec-

tors based on the PII retrieved from the multiple

sources needs to be implemented. The result vector

is built thanks to the following steps:

1. computing the NFKD-normalization on each PII

retrieved.

2. sequentially adding all the normalized elements

into a (Python) list, representing the result vector.

3. generating the symmetrical distance matrix.

@register.filter

def ldistance_matrix(vector):

matrix = []

for i, el_i in enumerate(

vector.split()):

matrix.append([])

for j, el_j in enumerate(

vector.split()):

matrix[i].append(

ldistance(el_i, el_j))

return matrix

This matrix is of course not meant to be displayed

to the user or to the human agent. However, it

needs to be stored for later use as input for deci-

sion algorithms.

4. applying a threshold function

f :

) −→

{”Matching”, ”Non-matching”, ”Ambiguous”}

M((result

), i ∈ {1, . . . , n}) 7−→ s

(8)

where n = |S| is the number of available sources

and s is the matching decision.

For instance, a Python implementation of the al-

gorithm described in Section 5.4.3.

from django import template

@register.filter

def matching_result_strict(matrix):

min_threshold = 1

max_threshold = 3

for i, el_i in enumerate(matrix):

for j, el_j in enumerate(el_i):

if el_j > max_threshold:

return ’Non-matching’

elif el_j > min_threshold:

return ’Ambiguous’

return ’Matching’

5.6.2 Additional Identity Matching Solvability

Parameters

Eventually, and before presenting an example of vali-

dation results (in Section 5.6.3, a couple of deﬁnitions

of parameters that may be used by the implementers

of any such identity-matching solution are given:

1. For an identity matching process involving n dif-

ferent sources, the lowest degree of conﬂict un-

solvability for a sufﬁcient partial information of

type t ∈ T

is the integer x ∈ {2, . . . , n − 1}, where

n = |T | is the number of available sources, such

as if at most x elements of the result vector dif-

fer, the validation is considered unsolvable – and

therefore requires a human agent validation.

2. Similarly, the shortest distance of conﬂict unsolv-

ability for a PII type t ∈ T is the integer y such

as if two elements of the result vector for t have a

relative distance of at most y with each other, the

validation is also considered unsolvable without

an agent validation.

These parameters should be set according to the

quality of the identity- and personally-identiﬁable-

attribute information provided by the sources, the

number of available sources, the number of complete

and partial-sufﬁcient attributes and the degree of par-

tiality of the partial-sufﬁcient attributes.

5.6.3 Example of Validation Results

Matching PII. Following the previously given ex-

ample, the three sources return respectively the values

ıc¸z, Sm

ıcz and Smicz.

Consequently, the result vector as deﬁned in Sec-

tion 5.4.3 is (Sm

ıc¸z, Sm

ıcz, Smicz).

After performing the NFKD-normalization

of the retrieved PII, the normalized vector is

(smicz, smicz, smicz).

Therefore the Levenshtein distance matrix for this

PII vector is:





0 0 0





SECRYPT 2020 - 17th International Conference on Security and Cryptography

150

This Levenshtein distance matrix obviously describes

matching PII.

Potentially Non-matching or Ambiguous PII.

Non-matching PII, e.g. Sm

ıc¸z, Sm

ıcz and Smics, is

considered in this paragraph.

The result vector with this PII is

(Sm

ıc¸z, Sm

ıcz, Smics).

After performing the NFKD-normalization

of the retrieved PII, the normalized vector is

(smicz, smicz, smics).

Therefore the distance matrix for this PII vector is





0 0 1

1 1 0





Depending on the minimum and maximum thresh-

olds, the PII associated with this matrix will either be

ambiguous or non-matching.

A visual summary of the identity matching pro-

cess described in this section is visible in Figure 2.

This ﬁgure illustrates the main steps that take part

in the identity-matching process, for a given PII. For

a given user, this whole identity-matching process is

prone to happen as many times as there are complete

or partial-sufﬁcient information attributes available.

6 SECURITY ANALYSIS

6.1 Model and Requirements

6.1.1 Preliminary Deﬁnitions

We deﬁne a group of users G = {u

, . . . , u

}, k > 2

bringing a set of information:

∗

= {I

, . . . , I

} (9)

where {I

, j

}, j ∈ {1, . . . , v

} is the set of all informa-

tion brought by user u

, h ∈ {1, . . . , k}.

Additionally, four functions type, norm, source

and user are deﬁned, respectively returning the type

of PII I – as deﬁned for our TCPA use case in Sec-

tion 5.5 –, the normalized value of PII I as deﬁned in

Section 5.4.2, the source, and the user from which the

instance of information I is originated.

In particular, type is deﬁned as follows:

type : I

∗

−→ T

I 7−→ t

(10)

where T is the set of all available PII types as deﬁned

in Section 5.5. Thus t is the actual PII type for

information I.

Similarly norm is deﬁned as:

norm : I

∗

−→ Σ

∗

I 7−→ n

(11)

where Σ

∗

is the set of all possible normalized Unicode

strings along with the empty string λ. Thus n

is the

normalized value for PII I.

source is deﬁned as follows:

source : I

∗

−→ S

I 7−→ S

(12)

Thus S is the source providing PII I. This means that

among all available sources in S, S is the source that

provides the particular item of information I ∈ I

∗

–

and the fact that I characterizes a given user u is not

of interest for this deﬁnition.

Eventually, user is deﬁned as:

user : I

∗

−→ G

I 7−→ u

(13)

Thus u is the user bringing PII I.

6.1.2 Attacker Model

Our attacker model considers four different types of

possible attacks:

• Collusion Attack.

This attack is a main concern that motivates the

identity-matching procedure. In our case, user col-

lusion means that a group of user G bring the set of

information I

∗

(as deﬁned in Section 6.1.1) such as:

∀I ∈ I

∗

, ∃S ∈ S, S provides I (14)

The set of information brought by G can be used to

impersonate a ﬁctive user u∗ and obtain privilege es-

calation on the system. In order for the analysis to

stay valid, a realistic hypothese is stated: the group

of users G = {u

, . . . , u

} should not be completely

homonymous regarding the available sources. As in-

formally stated in Section 3, this means that if

∀I, I

inI ∗,

(type(I) = type(I

)∧

source(I) = source(I

)∧

user(I) 6= user(I

))

=⇒ norm(I) = norm(I

)

(15)

then the k colluding users are completely homony-

mous and the identity matching cannot hold. This

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

151

case is considered extremely unlikely, and stating a

hypothesis of non-complete homonymity is reason-

able.

Alternatively, this hypothesis can be stated in ma-

trixial terms. If for each result vector result of a given

PII type t ∈ T , if we have:

∀i ∈ {1, . . . , n}, result



empty if ¬S

provides t

α otherwise

where α is a constant value for result, then the collu-

sion is not preventable.

• Identity/Attribute Theft Attack: on one or several

sources.

This means that a user’s credentials to one or several

identity- or personally-identiﬁable-attribute sources

have been stolen by a rogue user.

This means that a rogue user u

knows a subset of the

credentials {c

, . . . , c

} of an honest user u

, used

for authentication to sources S

, . . . , S

• Man-in-the-Middle Attack: tampering data from

one or several of the sources.

More formally, if I = {i

, . . . , i

} is the set of informa-

tion retrieved from the remote sources S

, . . . , S

, this

means that there is a subset K ⊆ I containing tam-

pered data.

• Impersonation of Sources.

This type of attack is similar to the previous one: its

direct consequence is the citizen relationship manage-

ment platform retrieving potentially-erroneous data

from the remote sources.

6.1.3 Resilience and Security Requirements

Along with the attacker model, a list of security and

privacy requirements are deﬁned:

• Requirement 1. The user should be able to use

the URM platform even in case any of the four

aforementioned attacks is launched.

• Requirement 2. The identity matching should

happen even in case of a degraded quality of the

identity- and personally-identiﬁable-attribute in-

formation served by the sources.

• Requirement 3. Identity mismatches and at-

tempted attacks should be detectable.

6.2 Security and Resilience Analysis

6.2.1 Security Analysis against the Attacker

Model

The resistance of the proposed solution against the at-

tacker model depends on a thorough identity match-

ing across the sources. Therefore this identity-

matching process is at the center of the use case, as it

prevents – either directly or indirectly – all four types

of attacks listed in Section 6.1.2:

1. A thorough identity matching process prevents

user collusion: The group of colluding users

G = {u

, . . . , u

}, k > 2 manages to retrieve in-

formation from the complete set of sources S =

, . . . , S

}. Thus, as explained in Section 6.1.2,

each colluding member in G brings some infor-

mation retrieved from one or several source. The

function g is deﬁned as follows:

g :N −→ N

l 7−→ m

(16)

meaning that the information retrieved from

source S

comes from a colluding user u

∈ G.

In this case the distance matrix is made of the el-

ements m

i, j

, i ∈ {1, . . . , n}, j ∈ {1, . . . , n} so that:

i, j



0 if g(i) = g( j)

d > 0 otherwise

where d is the Levenshtein distance between the

two elements result

and result

of the result vec-

tor (see Section 5.4.3).

Assumption 1. This statement illustrates and con-

ﬁrms the intuitive assumption that the collusion

may be detected if the group of colluding users

contains at least two individuals. We assume

that these two individuals might be homonymous,

but a subset of their PII provided by the remote

sources must differ.

Indeed, the distance matrix M((result

), i ∈

{1, . . . , n}) is made of elements m

i, j

, i ∈

{1, . . . , n}, j ∈ {1, . . . , n} where n = |S| is the

number of available sources, we have:

i, j



empty if result

or result

is missing

0 otherwise

Conclusion 1. Under the assumption 1, the solu-

tion is suited to prevent user collusion: two users

or more performing collusion will lead to a non-

matching distance matrix.

2. Resistance to user identity theft on the citizen-

relationship management platform is also pro-

vided.

An attacker performing a successful identity theft

from a given user u on a subset R ⊂ S =

, . . . , S

} of the remote sources acts in the fol-

lowing manner: For any given source S

, j ∈

{1, . . . , n}, if S

∈ R then the attacker uses the

user’s stolen credentials to obtain their informa-

tion for that source, else the attacker obtains in-

formation that does not belong to u. In the best

SECRYPT 2020 - 17th International Conference on Security and Cryptography

152

case scenario in which R 6= S, the attacker is able

to perform identity theft on a second user u

on a

subset R

⊂ S with R ∪ R

= S .

Assumption 2. For convenience it is also assumed

that R ∩ R

= {}, without invalidating the current

demonstration.

As a result, the distance matrix M computed as

part of the identity matching process contains the

elements m

i, j

, i ∈ {1, . . . , n}, j ∈ {1, . . . , n} so that:

i, j







0 if {S

, S

} ⊂ R

0 if {S

, S

} ⊂ R

d > 0 otherwise

Note that if R = S then the identity theft cannot

be detected.

Assumption 3. As a result, a thorough identity

matching should detect an identity theft attempt

for any subset of sources R so that |R | < |S|.

Conclusion 2. Under the second and third as-

sumptions, identity theft risks are drastically re-

duced. An attacker willing to perform identity

theft would have to obtain the credentials to all

n sources, with n = 3 in our use case: the France-

Connect credentials, the family allowance private

identiﬁcation number and the national tax system

private identiﬁcation information. As long as the

users maintain their credentials carefully, the risk

of the attacker performing identity theft on the

three sources of our use case seems neglectable.

3. Data tampering due to a man-in-the-middle attack

is prevented.

A man-in-the-middle attacker performing a suc-

cessful data tampering on a subset R ⊂ S =

, . . . , S

} of the remote sources acts in the fol-

lowing manner: for any given user u, the PII pro-

vided by any source belonging to R will be mod-

iﬁed so as to create a fraudulent identity of a user

u∗. The objective of the attacker is to tamper the

data provided by the sources belonging to R so as

to create u∗ as a consistent identity.

As a result, the distance matrix M computed as

part of the identity matching process contains the

elements m

i, j

, i ∈ {1, . . . , n}, j ∈ {1, . . . , n} so that:

i, j



0 if {S

, S

} ⊂ R

d > 0 otherwise

Indeed, in the general case, the attacker does not

know what PII attributes are provided by sources

belonging to R

= S \R , where \ is the set differ-

ence operator. The attacker is therefore unable to

tamper PII attributes tamper sources in R in a way

that would match the ones provided by sources in

Assumption 4. This type of attack cannot be pre-

vented if R = S, that is R

= {}, that is if the

attacker is able to tamper data provided by any of

all the available sources. In other terms, this at-

tack can only be prevented if S\R 6= {}.

Conclusion 3. Under the fourth assumption, man-

in-the-middle attacks leading to users’ identity at-

tributes tampering can also be prevented. For in-

stance, (Krawczyk et al., 2013) provides a se-

curity analysis of TLS authentication as used in

HTTPS for our Web-based sources. As discussed

in that analysis of the TLS protocol, the poten-

tial breaches in the implementation of the TLS

layer

are not speciﬁc to our use case. For dis-

cussions regarding these potential breaches, see

for instance the security considerations of the TLS

speciﬁcation document (Request for Comments –

RFC) (Rescorla, 2018, Section 10), edited by the

Internet Engineering Task Force (IETF). The in-

stance of an attacker being able to perform such

an attack on all three sources of our use case is

therefore considered as negligible.

4. As explained in Section 6.1.2, this security re-

quirement also prevents a successful attack led by

impersonating one or several sources. Similarly,

this type of attack cannot be prevented if the at-

tacker is able to impersonate any of all available

sources.

Conclusion 4: Eventually, the solution is also

suited to prevent the impersonation of sources by

the attacker. The possibility for an attacker to im-

personate any of the available sources depends on

the underlying applicative protocol. For that rea-

son, the likelyhood is the same the one studied in

the previous bullet item, i.e. the ability for an at-

tacker to perform a man-in-the-middle attack on

all three sources: in the context of our use case,

the impersonation of all three sources by an at-

tacker is considered as negligible.

6.2.2 Requirements Enforcement Even under

the Attack Model

Similarly, the resilience and security requirements

identiﬁed in Section 6.1.3 can be validated as follows:

• Enforcement of Requirement 1. The solution is

proved resistant against the four types of attacks de-

ﬁned in Section 6.1.2. Additionally, the attacker

model does not include direct attacks on the URM

platform. The resistance against such direct attacks

are not speciﬁc to the application but depend on the

The most popular implementation of TLS being

OpenSSL.

An Identity-matching Process to Strengthen Trust in Federated-identity Architectures

153

Web framework used, i.e. Django – provided that its

development guidelines for security and privacy are

respected. As a result the ﬁrst requirement is assured.

• Enforcement of Requirement 2. With our TCPA

use case involving three identity- and personally-

identiﬁable-attribute sources, the degraded quality of

the information provided by these sources can be ne-

glected. Of course, and as described in that section, a

higher number of sources would increase the trust in

the identity-matching process.

• Enforcement of Requirement 3. Using proper PII

normalization and distance matrix generation meth-

ods allow for the identiﬁcaton and the prevention of

identity mismatches and attempted attacks.

7 CONCLUSION

Identity matching across multiple identity- and

personally-identiﬁable-attribute sources in a

federated-identity environment has become a

challenging concern as the number of ofﬁcial sources

is increasing.

These sources tend to adopt widely accepted

authentication (Sakimura et al., 2014) and autho-

rization (Hardt, 2012) standards. However, these

standards do not offer out-of-the-box solutions for

matching the users’ digital identities and personally-

identiﬁable attributes accross multiple sources, and as

a result identity mismatch errors happen.

The proposed identity matching solution supports

efﬁcient automated processing, that requires human

assistance for a limited number of corner cases. These

corner cases involve interactions with the user for pos-

sible identity veriﬁcation, as well as more subtle and

subjective validation

At the time of writing, the French government

is experimenting the use of FranceConnect data

providers and has published technical documenta-

tion about such providers. These providers, acting

each as a resource server according to the OAuth 2.0

authorization management protocol (Hardt, 2012),

must proceed to identity matching between the iden-

tity conveyed by the authorization server and their

local user base. This experimental identity- and

personally-identiﬁable-attribute ﬂow, if adopted na-

tionally at production level for ofﬁcial online proce-

dures, will shift the duty of identity-matching from

the service providers to these ofﬁcial data providers.

As a consequence, the proposed automated procedure

remains relevant once the aforementioned experimen-

tation will be brought to production level, as it will

need to be ensured by the data providers themselves.

REFERENCES

Bugiel, S., Davi, L., Dmitrienko, A., Fischer, T., Sadeghi,

A.-R., and Shastry, B. (2012). Towards taming

privilege-escalation attacks on android. In NDSS, vol-

ume 17, page 19. Citeseer.

Camenisch, J. and Pﬁtzmann, B. (2007). Federated Identity

Management, pages 213–238. Springer Berlin Heidel-

berg, Berlin, Heidelberg.

Davis, M. and D

urst, M. (2001). Unicode normalization

forms.

de Montjoye, Y.-A., Shmueli, E., Wang, S. S., and Pent-

land, A. S. (2014). openpds: Protecting the privacy of

metadata through safeanswers. PLOS ONE, 9(7):1–9.

Fielding, R. T. (2000). REST: Architectural Styles and

the Design of Network-based Software Architectures.

Doctoral dissertation, University of California, Irvine.

Hardt, D. (2012). The OAuth 2.0 Authorization Framework.

RFC 6749.

Hunt, R. (2001). Pki and digital certiﬁcation infrastructure.

In Proceedings. Ninth IEEE International Conference

on Networks, ICON 2001., pages 234–239.

Krawczyk, H., Paterson, K. G., and Wee, H. (2013). On

the security of the tls protocol: A systematic analysis.

In Canetti, R. and Garay, J. A., editors, Advances in

Cryptology – CRYPTO 2013, pages 429–448, Berlin,

Heidelberg. Springer Berlin Heidelberg.

Levenshtein, V. I. (1966). Binary Codes Capable of Cor-

recting Deletions, Insertions and Reversals. Soviet

Physics Doklady, 10:707.

Mortier, R., Zhao, J., Crowcroft, J., Wang, L., Li, Q., Had-

dadi, H., Amar, Y., Crabtree, A., Colley, J., Lodge, T.,

Brown, T., McAuley, D., and Greenhalgh, C. (2016).

Personal data management with the databox: What’s

inside the box? In Proceedings of the 2016 ACM

Workshop on Cloud-Assisted Networking, CAN ’16,

pages 49–54, New York, NY, USA. ACM.

Organization for the Advancement of Structured Informa-

tion Standards (2005). Security assertion markup lan-

guage (saml) v2.0.

Papadopoulou, E., Stobart, A., Taylor, N. K., and Williams,

M. H. (2015). Enabling Data Subjects to Remain Data

Owners, pages 239–248. Springer International Pub-

lishing, Cham.

Rescorla, E. (2018). The Transport Layer Security (TLS)

Protocol Version 1.3. RFC 8446.

Sakimura, N., Bradley, J., Jones, M., De Medeiros, B., and

Mortimore, C. (2014). Openid connect core 1.0 incor-

porating errata set 1.

Shadbolt, N. (2013). Midata: towards a personal infor-

mation revolution. Digital Enlightenment Yearbook,

pages 202–224.

The Unicode Consortium (2011). The Unicode Standard.

Technical Report Version 6.0.0, Unicode Consortium,

Mountain View, CA.

Zhao, H. V., Min Wu, Wang, Z. J., and Liu, K. J. R. (2005).

Forensic analysis of nonlinear collusion attacks for

multimedia ﬁngerprinting. IEEE Transactions on Im-

age Processing, 14(5):646–661.

Zolotarev, M., Sylvester, P., Zuccherato, R., and Adams,

D. C. (2001). Internet X.509 Public Key Infrastruc-

ture Data Validation and Certiﬁcation Server Proto-

cols. RFC 3029.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

154
