Performance Comparison of Two Generic MPC-frameworks with

Symmetric Ciphers

Thomas Lor

unser

and Florian Wohner

AIT Austrian Institute of Technology, Vienna, Austria

Keywords:

Multiparty Computation, Applied Cryptography, Privacy, Benchmarking.

Abstract:

Research on multiparty computation (MPC) made substantial progress over recent years. It can be used to pro-

tect the privacy of data and users in modern application scenarios like Blockchain and the Internet of Things

where different stakeholders want to collaborate. In this work we analyze practical aspects of two generic

MPC frameworks, MP-SPDZ and MPyC, to generate new insights into the state-of-the art for generic and

platform independent MPC. We implemented various symmetric ciphers and did extensive benchmarking on

both frameworks to see how universal and generic they are and if they can be used without special knowledge.

We found that the achieved performance cannot be trivially estimated from the algorithms without implement-

ing. The stream cipher Trivium was by far the fastest and most portable in our tests. Contrary to most of

existing literature we also addressed non optimal network settings and found surprising results. The asyn-

chronous architecture of MPyC turned out to make more efﬁcient use of the network layer in scenarios with

higher network latency and loss and could even compensate for the optimizing compiler used by MP-SPDZ.

1 INTRODUCTION

Multiparty computation (MPC) is a technology for

computing on conﬁdential data in a distributed set-

ting, i.e., with multiple nodes holding only fragments

of input data. It can be used to decentralize systems

where typically a central trusted authority is needed

to execute certain functionality. With MPC the func-

tionality is evaluated jointly between multiple parties

such that the correctness of the output is guaranteed

and the privacy of the inputs of the individual parties

is preserved, and only the output of the computation is

learned. The concept has been invented more than 30

years ago, but for a long time it was considered only

of theoretical interest. However, progress in recent

years has led to many interesting applications which

can be realized with practical efﬁciency.

1.1 Motivation

Many of the promising results published in research

papers have been obtained under ideal settings typ-

ically only considering a very limited scope. Addi-

tionally, many of the open source frameworks used to

https://orcid.org/0000-0002-1829-4882

https://orcid.org/0000-0002-8641-7522

generate the results are not very mature. Experiment-

ing with these frameworks, we found it challenging to

correctly and efﬁciently implement certain algorithms

for speciﬁc MPC systems and manual optimization

was often necessary.

To better understand the potential of MPC in real

life application scenarios we analyze the problem of

interfacing with MPC by means of reading data from

encrypted storage (Happe et al., 2017). To the best

of our knowledge, there is so far no empirical study

which tries to identify important parameters in the us-

age of MPC technology in a systematic and platform

independent way. We tried to compare similar MPC

settings and protocols and therefore selected two of

the most actively developed frameworks which run

the same protocols under the hood and support the

same adversary model. For our study we are work-

ing in the honest-majority setting with information

theoretical security and only semi-honest adversaries.

This is the most basic setting which has all major in-

gredients to build more complex scenarios. Computa-

tionally secure protocols for dishonest majorities are

out of scope for this work. It should also be noted

that we do not intend to compare ciphers of equal

security strength. We are aware that stream ciphers

like Trivium do not provide the same security level as

AES, however, our goal is to compare how the two

Lorünser, T. and Wohner, F.

Performance Comparison of Two Generic MPC-frameworks with Symmetric Ciphers.

DOI: 10.5220/0009831705870594

In Proceedings of the 17th International Joint Conference on e-Business and Telecommunications (ICETE 2020) - SECRYPT, pages 587-594

ISBN: 978-989-758-446-6

587

selected MPC frameworks can deal with the differ-

ent structures of the various algorithms and what has

to be considered in the porting of algorithms to MPC

systems.

1.2 Contribution and Structure

We implemented, analyzed, and benchmarked four

different ciphers in two MPC frameworks. We found

that estimating the performance of algorithms for

MPC systems in advance is hard and real perfor-

mance deviated from the expected in many cases. Our

work also shows a performance comparison for net-

works with higher latency or loss, where we identi-

ﬁed some unexpected behavior which suggests that

there is room for improvement. In our study Trivium

turned out to be most versatile cipher, i.e., it supports

the widest range of MPC frameworks, but it has also

the lowest security level. We also provide our imple-

mentations as open source modules

The remainder of the paper is structured as fol-

lows. The related work as well as selected MPC

framework are presented in section 1 below. In sec-

tion 2 the algorithms chosen for implementation for

both frameworks are presented, as well as our ﬁnd-

ings during software implementation and the manual

optimizations which were necessary to achieve good

performance. The performance results achieved are

presented and discussed in section 3. The conclusion

of the paper is then presented in section 4.

1.3 Related Work

The most recent and comprehensive work on com-

paring MPC frameworks was presented in (Hastings

et al., 2019) which tried to give an overview on the

state of the art from a users point of view and does not

focus on a particular technique or scheme. In particu-

lar, no performance benchmark was possible because

of the very different approaches considered. Addi-

tionally, only basic operations in the spirit of ”hello

world” applications were analyzed, as was shown by

the code snippets in the appendix. In our work, we fo-

cus on benchmarking more complex algorithms, sym-

metric ciphers in our case, and MPC with similar pro-

tocols and adversary models but different program-

ming paradigms.

Besides comparing MPC frameworks, this work

was also motivated by the progress made in de-

veloping optimized ciphers for application in mul-

tiparty computation (MPC), fully homomorphic en-

cryption (FHE) and zero-knowledge proof systems

Source code on GitHub: https://github.com/Archistar/

archistar4mpc-cipher, ﬁrst published 29.4.2020.

(SNARKs) (Albrecht et al., 2015), (Albrecht et al.,

2016a), (Rechberger et al., 2018), (Grassi et al., 2019)

and (Albrecht et al., 2019), which are typically only

benchmarked in ideal settings (almost perfect connec-

tivity and fast servers). This somehow contradicts the

idea of generic platform-independent secure compu-

tation, which should be the goal for widespread use

of the technology. In our work we are using these

new cipher designs and compare them with AES and

well-known stream ciphers also considered interest-

ing candidates for MPC. It is not the goal of our work

to absolutely compare the many proposed ciphers, but

to see how good their structure is suited in general for

framework-independent application and this is only a

ﬁrst step towards broader benchmarking activities.

1.4 MPC Frameworks

Various frameworks have been developed over the last

years, speciﬁcally in the open source domain. We

selected two candidate frameworks, MP-SPDZ and

MPyC, which both have the capability to work in the

semi-honest setting with honest majority and use se-

cret sharing based protocols. However, because they

use a fundamentally different programming model it

is interesting to see how they behave for the given

task.

1.4.1 MPyC

MPyC (Schoenmakers, 2018) is a fork of the discon-

tinued VIFF framework (Damg

ard et al., 2009), but

only rarely used for MPC benchmarks. In our opin-

ion, it follows an interesting concept which could lead

to both easy access for programmers and reasonable

performance. It is a Python framework that implic-

itly represents multi-party computations as graphs of

regular Python values, secret-shared values, and oper-

ations on them. By overloading Python’s regular op-

erators, the whole process is made mostly invisible to

the user of the framework. The resulting graph is built

at runtime and evaluated asynchronously, so no static

analysis, and therefore no optimization, is performed.

However, heavily optimized primitives (mostly vector

and matrix operations) are available. The framework

is passively secure in an honest-majority setting.

Code written in the framework can be hand-

optimized with the help of the built-in gather() and

reshare() methods. Applying the ﬁrst method on

a shared value will run all outstanding asynchronous

computations and then unpack the share to return an

element of the underlying ﬁeld. Any further compu-

tations on it will then be performed locally only. Ap-

plying the second method to this value will return a

SECRYPT 2020 - 17th International Conference on Security and Cryptography

588

shared value again. Everything that happens in be-

tween is therefore part of a single round of communi-

cation. Obviously, this can destroy correctness, and it

is left to the programmer to ensure that it does not.

Internally, MPyC makes ample use of this facil-

ity to improve the performance of its built-in methods

and operators, and also to provide efﬁcient vectorized

versions of some common operations. We looked at

four of those operations and compare them to their

unoptimized counterparts in Table 1.

1.4.2 MP-SPDZ

MP-SPDZ (Keller, 2019) is a fork of SPDZ2 which

was originally developed at the University of Bristol

and is based on the SPDZ type of protocols (Damg

ard

et al., 2012b). Since forking, MP-SPDZ has inte-

grated more and more protocols and is now the most

prominent framework used for benchmarking MPC

protocols in general. It supports very ﬂexible use of

different protocols and also separation of online and

off-line phases for performance measurements.

Its approach is to let users write their programs in

a Python-like language that is then heavily optimized

and compiled to byte-code for a fast virtual machine

implemented in C++. The framework implements a

wide variety of protocols for several different security

models, based on arithmetic as well as Boolean cir-

cuits. Both integer and ﬁxed-point numbers are sup-

ported and security models of honest majority as well

as dishonest majority are supported, even for both

semi-honest and malicious adversaries. In this work

we were only using the shamir-party.x program as

this resembles the same protocol used by MPyC.

2 ALGORITHMS

In the following section we will brieﬂy review the ba-

sic principles and properties of the algorithms we se-

lected for implementation, and discuss our ﬁndings.

The algorithms have been selected because they are

considered to be lightweight or because they were

speciﬁcally proposed as ciphers optimized for appli-

cation in MPC settings based on secret-sharing with a

low circuit depth for multiplication gates. In general,

the algorithms should help to understand how the two

approaches of MP-SPDZ and MPyC are able to op-

timize the processing of the various ciphers and how

suitable the structures of the ciphers are for the re-

spective frameworks.

2.1 AES

The advanced encryption standard is the de-facto

benchmark when it comes to MPC for evaluation of

symmetric ciphers since (Pinkas et al., 2009). It

is particularly challenging for systems operating on

arithmetic circuits, because AES does not lend it-

self well to secure computation over prime ﬁelds

(Damg

ard et al., 2012a). In spite of this, a lot of

progress was made in the evaluation of AES in secret-

sharing based systems with (Araki et al., 2016) claim-

ing the best performance. They report on a cluster

of three 20-core servers with a 10Gbps connection,

which carries out over 1.3 million AES computations

per second, processing over 7 billion gates per second.

However, these results are achieved with a dedicated

protocol for Boolean circuits supporting only three

parties, and a lot of parallelization on the block level,

which can always be achieved. AES implementations

were available in both frameworks and we took them

as baselines for our benchmarks.

2.2 ChaCha20

ChaCha20 (Bernstein, 2008) is a stream cipher and

the successor to Salsa20, and is one of several novel

ciphers recommended for new implementations by

the eSTREAM project (De Canni

ere and Preneel,

2008). It is a typical ARX-cipher, consisting only

of unsigned 32-bit integer additions, ﬁxed-width bit

rotations, and XORs. In the MPC setting, this mix-

ing of integer and logical operations is a problem and

suggests two different implementation strategies: one

would be to represent the data as integers and con-

vert to and from a bit-level representation as needed.

The other, likely more efﬁcient, strategy would be to

use a bit-level representation throughout, and imple-

ment the integer addition as a Boolean circuit. In this

approach, the multiplicative complexity of the cipher

depends on the type of addition circuit used. The pos-

sible complexity for adders ranges from linear (ripple-

carry) to inverse quadratic (carry-select) to logarith-

mic (carry-lookahead). For our implementation, we

tried only ripple-carry and carry-select adders.

In the ﬁrst implementation variant, we use the

equivalent of unsigned 32-bit integers for the addi-

tions, switch to a bit-vector representation for the

XOR and bit rotations, then again back to the inte-

ger representation for the additions, and so on and so

forth. Given the structure of ChaCha20, this necessi-

tates 640 decompositions and 320 recompositions per

block of 64 bytes.

In the other implementation variant, we convert

the input values only at the beginning and end, and

Performance Comparison of Two Generic MPC-frameworks with Symmetric Ciphers

589

therefore have to perform addition on the bit-level.

The simplest way to achieve this is with a ripple-carry

adder that takes one vectorized multiplication of all

bits of the addends plus 30 multiplications with the

carry bit, for a total of 31 communication rounds per

addition. At 336 integer additions per block, this is

obviously very expensive and can easily be improved.

In MP-SPDZ there is a built-in carry-select adder, and

in our implementation, compared to the ripple-carry

adder, it reduced the rounds of communication neces-

sary for one block from 1731 to 811. As expected, this

implementation variant performs better, regardless of

which adder is used. Nonetheless, the results conﬁrm

that ChaCha20 is not a suitable cipher for MPC.

2.3 Trivium

Trivium, based on a nonlinear feedback shift register

(NFSR), is another cipher of the eSTREAM portfo-

lio (De Canni

ere and Preneel, 2008). It has a simple

structure with only bit operations, so that it can be

applied to resource-constrained environments such as

wireless sensors in IoT. The internal state of Trivium

consists of 288 bits. It is initialized by a key and IV

of 80 bits each, with all other bits except for the last

three set to 0. To complete the initialization, 1152

keystream bits are generated and discarded. The gen-

eration of a keystream bit is the same for initialization

phase and regular operation: the state is shifted by in-

serting three new bits, each generated by two XORs

and one AND. The XOR of these new bits is the out-

put bit. We chose Trivium because of this very simple

construction and the low multiplicative complexity it

promised. As detailed, it only takes three multiplica-

tions to produce one output bit, but by construction,

this operation can be parallelized for at least 64 bits.

This means that a fully optimized implementation of

Trivium should be able to generate 8 bytes in a single

communication round.

Thanks to the simplicity of Trivium, we were able

to realize this parallelisation with a (mostly) straight-

forward translation of the speciﬁcation. We imple-

mented the cipher so that it always generates blocks

of 64 bits, by simply running the output function 64

times in a loop. MP-SPDZ was able to generate op-

timal code from this without any additional work on

our part, but for the MPyC implementation, we had to

do some optimizations by hand ﬁnally achieving the

same results that the MP-SPDZ had produced auto-

matically.

72 bits can be computed per round and by turning over

the internal state (288 bits) four times, the cipher can be

initialized in 16 rounds of communication.

2.4 LowMC

LowMC is a block cipher based on a substitution-

permutation network which can be parametrized in

a very ﬂexible way. The number of rounds needed

to achieve the desired level of security is determined

as a function of several parameters. The way this is

done is to consider and try to bound all known attacks

and choose the number of rounds so that the most ef-

fective attack for a particular set of parameters is just

not able to violate the security expectation. The ﬁrst

version of this round ’formula’ was introduced at Eu-

rocrypt 2015 (Albrecht et al., 2015). Soon after, op-

timized attacks were demonstrated and as a result, an

updated round formula for LowMC was proposed by

the designers (Albrecht et al., 2016a).

Implementing LowMC was a surprise in many

ways. It has already been observed by (Albrecht et al.,

2016a) that the high number of XORs entailed by

the matrix operations of LowMC means that they can

no longer be considered free. We found this to be

true to an even larger extent in our setting. Even

though it was clear that the MPyC implementation

could only be done on a bit-level representation with

all the overhead it entails - using one of the recom-

mended parameter sets (256 bits blocksize, 80 bits

keysize, 12 rounds), and keeping in mind that even a

small Python integer weighs in at 26 bytes, the multi-

plication matrices take up almost 50 mega-bytes - we

were still negatively surprised by the resulting perfor-

mance. The MP-SPDZ implementation immediately

performed closer to our expectations, achieving 6 KB

per second.

2.5 MiMC / HADES

Introduced by (Albrecht et al., 2016b), MiMC is a

radically simpliﬁed construction based on the idea to

explore the typical ﬁeld size used in MPC. The num-

bers of rounds is d

log

e (with n mod 2 = 1 as the

chosen block size). The round function just adds the

key and a round constant, then takes the result to the

power of three. To decrypt, the process is performed

in reverse, but with the exponent

n+1

−1

instead of 3.

As decryption is therefore massively more expensive

than encryption, the authors recommend using modes

where it is not needed. Encryption, however, should

be very efﬁcient. Since the design does not contain

any S-boxes and only uses addition and multiplica-

tion, the cipher can be evaluated in a binary ﬁeld with-

out any conversion, and needs only two multiplica-

tions per round. Later, (Grassi et al., 2019) developed

what they call the HADES design. The core idea of

this approach is to apply reduced versions of the non-

SECRYPT 2020 - 17th International Conference on Security and Cryptography

590

linear layer in some rounds. Instantiated for MiMC,

this means that the cipher now operates not on a sin-

gle, but any number of blocks, and in certain rounds,

the exponentiation is only applied to some (in this in-

stantiation: the ﬁrst) of them. Additionally, (Albrecht

et al., 2019) presented a generalized MiMC that can

cope with prime ﬁelds and work on many ﬁeld el-

ements at once and therefore gives good amortized

cost if it can be parallelized. Our work is based on

the initial design (Albrecht et al., 2016b) but can be

naturally extended to the new versions.

The drawback of all versions of this approach,

however, is the large number of rounds required to

obtain adequate security. In our tests, we used a block

size of 127 bits which works out to 82 rounds. With

two multiplications per round, this adds up to 164

communication rounds per block. MiMC is speciﬁed

for GF(2n), but can also be used in GF(p). We chose

the ﬁrst variant, for which no conversion is necessary,

as only XORs and multiplications are performed. Our

ﬁndings indicate that encryption is indeed fast, as ex-

pected. However, the high amount of rounds has a

noticeable impact on performance. Only a few mea-

surements were done on decryption because it was

immediately obvious that the high cost of reversing

the exponentiation made it as slow as predicted.

3 PERFORMANCE EVALUATION

In this section we report our performance comparison

results. We started from an ideal setting with three

nodes and an almost ideal network setting, i.e., all

nodes running on the same physical host. All tests

were done on rather standard hardware, namely a Dell

Latitude E7440 notebook with a Core i7-4600U CPU

running on 2.1 Ghz with 4 cores. In all our tests

we did not try to optimize the overall throughput by

exhausting all hardware resources through massive

block level parallelism, we only intended to measure

the time for one block (or a ﬁxed number of blocks) in

sequential mode. Compared to other works which op-

timize overall throughput by parallelization, we think

it is essential to understand the behavior of a single

block. In particular, we wanted to also understand

how the frameworks behave in practical network set-

tings from LAN conﬁgurations to worldwide deploy-

ments as well as how many nodes can reasonably be

supported for the given task.

3.1 Performance of Basic Operations

As a basis for understanding of the expected perfor-

mance, and as a reference for the actual platform we

use, we provide the actual measured latency for basic

operations in Table 1.

Table 1: Time (ms) for 100 basic operations over vectors a,

b of length n.

n MP-SPDZ MPyC MPyC Vec

map(operator.add, a, b) vector add(a, b)

1 <1 7 14

10 <1 46 19

100 <1 353 71

map(operator.mul, a, b) schur prod(a, b)

1 12 59 60

10 13 258 82

100 17 2309 336

reduce(operator.add, a) mpc.sum(a)

1 <1 <1 9

10 <1 33 12

100 <1 507 18

reduce(operator.mul, a) mpc.prod(a)

1 <1 1 12

10 97 381 163

100 1017 3834 416

In MP-SPDZ, latency for addition is vanishingly

small; for multiplication, it grows slightly (but clearly

sublinearly) with increasing vector size, except for

the multiplicative reduction, which exhibits an almost

exactly linear slowdown with increasing input size.

This may seem surprising at ﬁrst, but is actually to

be expected. Contrary to the other three operations

under test, the multiplicative reduction cannot be per-

formed in one communication round. As it is writ-

ten, the multiplication operations form a linear list, so

one should expect it to scale linearly with input size.

The only optimization possible would be to organize

the multiplications as a tree, so that multiplications on

the same level could be performed in parallel, and the

whole operation would scale logarithmically. Such

an optimization is, however, not trivial to ﬁnd and

prove correct. It is therefore not surprising that the

MP-SPDZ compiler did not perform it.

In MPyC, the unvectorized operations scale about

linearly with vector size. The vectorized operations

are faster, but only the sum is clearly sublinear in

its behavior, scaling somewhat similar to MP-SPDZ’s

vector multiplication; the other operations exhibit a

noticeable slowdown as their input vectors grow in

size.

3.2 Performance of Cipher

Implementations

The benchmarking results of cipher implementations

with an almost ideal network (localhost) is shown in

Performance Comparison of Two Generic MPC-frameworks with Symmetric Ciphers

591

Table 2. In MP-SPDZ AES latency is about 20 times

lower than in MPyC with optimized code. Chacha20,

the lightweight stream cipher, did not perform bet-

ter. In MP-SPDZ it took almost the same time and

in MPyC it took even twice the time of AES. Most

surprisingly LowMC performed worse than expected.

Leaving aside the initialization time it took twice the

time of AES on MP-SPDZ and was 6 times slower

on MPyC. MiMC, the second cipher designed specif-

ically for MPC, performed very well. It could not

achieve a speed-up on MP-SPDZ but performed 10

times faster on MPyC for encryption. Because of its

design, decryption takes substantially more time (be-

tween a factor of 30 and 50), which makes it less at-

tractive for applications. Trivium, another stream ci-

pher under test, performed exceptionally well on both

frameworks. On MP-SPDZ it was more than 5 times

faster and in MPyC with certain manual optimization

we achieved roughly a 20 time speed-up compared

to AES. However, it has to be noted that Trivium in

the standard conﬁguration has only a security level

of 80 bits compared to the other ciphers which pro-

vide at least 128 bits. Nevertheless, the structure of

Trivium seems well suited for MPC implementations

and should be used as a basis for future designs with

stronger security levels.

Table 2: Ms / Byte for encryption in 3-party MPC, no la-

tency.

Cipher MPyC unopt MPyC opt MP-SPDZ

init enc init enc init enc

AES-128 - - - 110 - 5

ChaCha20 - - - 216 - 6

LowMC 764 679 772 637 28 9

MiMC - - - 11 - 5

Trivium 3300 23 780 6 18 <1

3.3 Network Latency and Loss

Besides the basic performance in ideal settings it is

also important to investigate other aspects that are

relevant for the real-world performance of MPC but

sometimes get sidelined: network latency and net-

work loss. One stated reason for not caring (too

much) about it is that it is assumed that performance

degrades linearly with increasing latency. This is in-

deed what we found in our experiments. What was

surprising though was the size of the constant fac-

tor, and that it was signiﬁcantly different between the

frameworks.

We measured the behaviour of the implementa-

tions under increasing network delay and loss. The

measurements were done on the very same hardware

with all processes running on the same host and by

using kernel level netem features to simulate net-

work delay and loss. To make the results easier to

compare, we performed computations that used about

1000 rounds of communication, then normalized the

obtained time to one communication round.

The results of our experiments with variable la-

tency are shown in Figure 1 and Figure 2 for a one-

way delay from 0 to 50 ms. In the ideal zero-latency

setting, a multiplication round takes less than a milli-

second in both MPyC and MP-SPDZ; every 5 ms of

one-way delay (which can be estimated to equal about

10 ms of round-trip delay) adds about 5 ms to MPyC,

but almost 10 ms to MP-SPDZ. This means that the

seemingly superior performance of MP-SPDZ ver-

sus MPyC disappears rapidly with increasing latency.

The situation is slightly, but not fundamentally, dif-

ferent when we look at batched multiplications. Re-

peating the same test with vectors of length 100, with

zero latency we get about 3 ms and again less than one

ms for MPyC and MP-SPDZ respectively, and once

again an increase of about 5 ms vs. almost 10 ms for

5 ms of one-way delay. This means that multiplica-

tions (looked at in isolation) are faster in MPyC than

MP-SPDZ even in low-latency contexts. The break-

even point for Trivium, on the other hand, is around

35 ms in our measurements, which is in a realistic

range for reasonable distributed deployments which

go beyond a single data center implementation.

All this indicates that although the Python based

implementation of MPyC may be slower and seem-

ingly less capable than MP-SPDZ with its impres-

sive optimizing compiler, MPC operations are ul-

timately bound by the network, and MPyC proﬁts

from Python’s highly-optimized asynchronous net-

work stack.

In a second series of experiments we tried to sim-

ulate packet loss. The results are shown in Figure Fig-

ure 3 and the slowdown is comparable to the one we

observed with one-way delay.

0 5 10 15 20 25 30 35 40 45 50

one-way delay (ms)

100

120

time (ms)

MPyC (n=1)

MP-SPDZ (n=1)

MPyC (n=100)

MP-SPDZ (n=100)

Figure 1: Time for one multiplication with increasing net-

work delay.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

592

0 5 10 15 20 25 30 35 40 45 50

one-way delay (ms)

100

120

time (ms)

MPyC

MP-SPDZ

Figure 2: Time per communication round of Trivium with

increasing network delay.

0 1 2 3 4 5 6 7 8 9 10

loss (%)

100

120

time (ms)

MPyC

MP-SPDZ

Figure 3: Time per communication round of Trivium with

increasing network loss.

3.4 Scalability

Although MPC is very appealing, in reality most sys-

tems only support two or three nodes. From an ap-

plication point of view this is often disappointing,

as in many use cases more parties than that want to

collaborate. For example, in a secure auction many

more users are submitting bids and if they are not

MPC nodes in their own right they have to trust the

MPC nodes not to collude, and as shown in (Fram-

ner et al., 2019) non-collusion assumptions are not

well accepted. From the protocol it is clear that the

communication overhead limits the number of nodes

for particular computations. In Figure 4 we show the

results for more parties. Here, MP-SPDZ performs

better with increasing number of parties than MPyC,

which experiences a signiﬁcant slowdown.

4 CONCLUSIONS

In this work we compared two generic MPC frame-

works based on the same linear secret-sharing proto-

cols, but a fundamentally different software approach.

MP-SPDZ is the most used software framework to

benchmark algorithms and is supposed to perform

3 5 7 9 11

parties

100

200

300

400

500

time (ms)

MPyC 0ms

MP-SPDZ 0ms

MPyC 10ms

MP-SPDZ 10ms

MPyC 20ms

MP-SPDZ 20ms

Figure 4: Time per communication round of Trivium with

increasing number of parties.

best. MPyC on the other hand is very ﬂexible and easy

to use. For our tests we implemented various sym-

metric ciphers from the literature, some of them opti-

mized for MPC, and did extensive testing and bench-

marking on both frameworks. The goal was to under-

stand how universal and generic the available MPC

software is and to which extent they can be used with-

out special knowledge about core protocols.

From our tests we learned that even for the most

versatile software frameworks available and the ba-

sic MPC protocols it is hard to get things right, i.e.

MPC is still far from being usable by software devel-

opers not familiar with the ﬁeld. We showed that the

practical performance cannot be trivially estimated

from the algorithms to be implemented by estimating

the multiplicative depth in advance, often additional

work (e.g. bit decomposition) signiﬁcantly penalizes

the performance of the algorithms and manual opti-

mization is needed. We also found that some of the

algorithms that were speciﬁcally developed to have

lower numbers of multiplications did not perform as

expected, and that some stream ciphers are not well

suited to MPC.

Trivium was found to be the best cipher for

platform-independent application in MPC and we rec-

ommend it for cases where the lower security pa-

rameter is not an issue or it can be combined with

other mechanisms (Sell et al., 2018). Recently, (Can-

teaut et al., 2018) proposed Kreyvium to improve on

this, but an interesting question remains open: can the

Trivium approach be scaled up to generate more than

64 (and maybe even arbitrarily many) keystream bits

per round of communication without weakening secu-

rity or exponentially increasing the size of the internal

state?

Contrary to most of existing literature we also ad-

dressed non-optimal network settings. In our tests we

found that although MP-SPDZ performs by far better

Performance Comparison of Two Generic MPC-frameworks with Symmetric Ciphers

593

in high throughput low latency settings, it gets sur-

prisingly outperformed by MPyC in scenarios with

higher network latency. The asynchronous architec-

ture of MPyC guarantees more efﬁcient use of the net-

work layer in this scenarios which could even com-

pensate for the optimizing compiler used by MP-

SPDZ. However, for the scalability in the number of

parties we found the opposite; here MP-SPDZ be-

haved as expected and MPyC seems to experience sig-

niﬁcant slowdowns.

ACKNOWLEDGEMENTS

This work has received funding from the Austrian

Research Promotion Agency (FFG) through project

FlexProd (GA No. 871395) and from the European

Union’s Horizon 2020 research and innovation pro-

gramme under GA No. 830929 (CyberSec4EU).

REFERENCES

Albrecht, M., Rechberger, C., Schneider, T., Tiessen, T.,

and Zohner, M. (2016a). Ciphers for MPC and FHE.

Cryptology ePrint Archive, Report 2016/687.

Albrecht, M. R., Grassi, L., Perrin, L., Ramacher, S., Rech-

berger, C., Rotaru, D., Roy, A., and Schofnegger, M.

(2019). Feistel Structures for MPC, and More. In

Computer Security – ESORICS 2019, Lecture Notes

in Computer Science, pages 151–171. Springer.

Albrecht, M. R., Grassi, L., Rechberger, C., Roy, A., and

Tiessen, T. (2016b). MiMC: Efﬁcient Encryption and

Cryptographic Hashing with Minimal Multiplicative

Complexity. In Advances in Cryptology - ASIACRYPT

2016, Hanoi, Vietnam, December 4-8, 2016, Proceed-

ings, Part I, pages 191–219.

Albrecht, M. R., Rechberger, C., Schneider, T., Tiessen,

T., and Zohner, M. (2015). Ciphers for MPC and

FHE. In Advances in Cryptology - EUROCRYPT

2015, Soﬁa, Bulgaria, April 26-30, 2015, Proceed-

ings, Part I, pages 430–454.

Araki, T., Furukawa, J., Lindell, Y., Nof, A., and Ohara, K.

(2016). High-Throughput Semi-Honest Secure Three-

Party Computation with an Honest Majority. In Pro-

ceedings of the 2016 ACM SIGSAC Conference on

Computer and Communications Security - CCS’16,

pages 805–817, New York, New York, USA. ACM

Press.

Bernstein, D. J. (2008). ChaCha, a variant of Salsa20.

Canteaut, A., Carpov, S., Fontaine, C., Lepoint, T., Naya-

Plasencia, M., Paillier, P., and Sirdey, R. (2018).

Stream Ciphers: A Practical Solution for Efﬁcient

Homomorphic-Ciphertext Compression. Journal of

Cryptology, 31(3):885–916.

Damg

ard, I., Geisler, M., Krøigaard, M., and Nielsen, J. B.

(2009). Asynchronous Multiparty Computation: The-

ory and Implementation. In Public Key Cryptography

- PKC 2009, Irvine, CA, USA, March 18-20, 2009.

Proceedings, volume 5443 of Lecture Notes in Com-

puter Science, pages 160–179. Springer.

Damg

ard, I., Keller, M., Larraia, E., Miles, C., and

Smart, N. P. (2012a). Implementing AES via an Ac-

tively/Covertly Secure Dishonest-Majority MPC Pro-

tocol. In Security and Cryptography for Networks -

8th International Conference, {SCN} 2012, Amalﬁ,

Italy, September 5-7, 2012. Proceedings, pages 241–

263.

Damg

ard, I., Pastro, V., Smart, N., and Zakarias, S. (2012b).

Multiparty computation from somewhat homomor-

phic encryption. In Lecture Notes in Computer Sci-

ence (including subseries Lecture Notes in Artiﬁcial

Intelligence and Lecture Notes in Bioinformatics).

De Canni

ere, C. and Preneel, B. (2008). Trivium, pages

244–266. Springer Berlin Heidelberg, Berlin, Heidel-

berg.

Framner, E., Fischer-H

ubner, S., Lor

unser, T., Alaqra, A. S.,

and Pettersson, J. S. (2019). Making secret sharing

based cloud storage usable. Information and Com-

puter Security.

Grassi, L., L

uftenegger, R., Rechberger, C., Rotaru, D.,

and Schofnegger, M. (2019). On a Generalization

of Substitution-Permutation Networks: The HADES

Design Strategy. Cryptology ePrint Archive, Report

2019/1107.

Happe, A., Wohner, F., and Lor

unser, T. (2017). The

Archistar Secret-Sharing Backup Proxy. ARES ’17,

pages 88:1–88:8, New York, NY, USA. ACM.

Hastings, M., Hemenway, B., Noble, D., and Zdancewic, S.

(2019). SoK: General Purpose Compilers for Secure

Multi-Party Computation. In 2019 2019 IEEE Sym-

posium on Security and Privacy (SP), pages 479–496,

Los Alamitos, CA, USA. IEEE Computer Society.

Keller, M. (2019). Multi-Protocol SPDZ.

https://github.com/data61/MP-SPDZ, accessed

2020-04-28.

Pinkas, B., Schneider, T., Smart, N. P., and Williams, S. C.

(2009). Secure Two-Party Computation Is Practical.

In Advances in Cryptology - ASIACRYPT 2009, Tokyo,

Japan, December 6-10, 2009. Proceedings, volume

5912 of Lecture Notes in Computer Science, pages

250–267. Springer.

Rechberger, C., Soleimany, H., and Tiessen, T. (2018).

Cryptanalysis of Low-Data Instances of Full

LowMCv2. {IACR} Trans. Symmetric Cryptol.,

2018(3):163–181.

Schoenmakers, B. (2018). MPyC–Python Package for Se-

cure Multiparty Computation. In Theory and Prac-

tice of Multi-Party Computation 2018 - TPMPC 2018,

Aarhus.

Sell, L., Pohls, H. C., and Lorunser, T. (2018). C3S: Cryp-

tographically combine cloud storage for cost-efﬁcient

availability and conﬁdentiality. In CloudCom 2018.

SECRYPT 2020 - 17th International Conference on Security and Cryptography

594
