Detecting Model View Controller Architectural Layers

using Clustering in Mobile Codebases

Dragos¸ Dobrean

and Laura Dios¸an

Faculty of Mathematics and Computer Science, Babes¸ Bolyai University, Cluj-Napoca, Romania

Keywords:

Mobile Applications Software Architecture Analyser, Automatic Analysis of Software Architectures,

Structural and Lexical Information, Software Clustering.

Abstract:

Mobile applications are one of the most common software projects written nowadays. The software architec-

tures used for building those type of products heavily impacts their lifecycle as the architectural issues affect

the internal quality of a software system hindering its maintainability and extensibility. We are presenting a

novel approach, Clustering ARchitecture Layers (CARL), for detecting architectural layers using an automatic

method that could represent the ﬁrst step in the identiﬁcation and elimination of various architectural smells.

Unlike supervised Machine Learning approaches, the involved clustering method does not require any initial

training data or modelling phase to set up the detecting system. As a further key of novelty, the method works

by considering as codebase’s hybrid features the information inferred from both module dependency graph and

the mobile SDKs. Our approach considers and fuses various types of structural as well as lexical dependencies

extracted from the codebase, it analyses the types of the components, their methods signatures as well as their

properties. Our method is a generic one and can be applied to any presentational applications that use SDKs

for building their user interfaces. We assess the effectiveness of our proposed layer detection approach over

three public and private codebases of various dimensions and complexities. External and internal clustering

metrics were used to evaluate the detection quality, obtaining an Average Accuracy of 77,95%. Moreover,

the Precision measure was computed for each layer of the investigated codebase architectures and the average

of this metric (over all layers and codebases) is 79,32% while the average Recall on all layers obtained is

75,93%.

1 INTRODUCTION AND

CONTEXT

Mobile applications and presentational software prod-

ucts represent an important part of the realm of soft-

ware development. We are furthering our work to-

wards creating a system for improving the archi-

tectural correctness of those types of projects. By

respecting an architectural pattern the codebase be-

comes more testable and more extensible in the areas

which are important for the business. In addition to

this, having a well-deﬁned architecture in place helps

the new or inexperienced developers write new code

more easily by having clear architectural guidelines

in place.

In this paper we present Clustering ARchitecture

Layers (CARL), an unsupervised approach for solving

https://orcid.org/0000-0001-7521-7552

https://orcid.org/0000-0002-6339-1622

the same problem using clustering. In order to pave

the way for analyzing more specialized architectures

for which a heuristic approach might not yield best

results as the components are hard to be split into lay-

ers by using various rules and sometimes those rules

cannot be easily inferred as all the codebases have

their own particularities we are focusing on automat-

ing this process by using AI algorithms, most speciﬁ-

cally clustering.

Clustering (Russell and Norvig, 2016) is one of

the most popular unsupervised Machine Learning ap-

proaches for ﬁnding groups (clusters) in a set of data

that exhibit similarities. When talking about software

architectures, the elements composing the architec-

tural layers should have similarities since they fulﬁll

the same role. For instance in the case of Model View

Controller (MVC), data manipulation for the Model

layer, control of the data ﬂow for the Controller layer

and handling the input and output in the View layer.

In this study, we search for the right information

196

Dobrean, D. and Dio¸san, L.

Detecting Model View Controller Architectural Layers using Cluster ing in Mobile Codebases.

DOI: 10.5220/0009884601960203

In Proceedings of the 15th International Conference on Software Technologies (ICSOFT 2020), pages 196-203

ISBN: 978-989-758-443-5

to be passed to the clustering algorithms in order to be

able to separate the elements of the codebase in archi-

tectural layers. Some of the practical applications of

such approach include: education – where developers

and students could learn easily to develop better code,

professional software development – where systems

like mobile CARL can be used for providing insightful

information to the management and to the developers

regarding the architectural health of a codebase.

The following section presents previous work in

the domain of architecture reconstruction using Ma-

chine Learning (ML) and Artiﬁcial Intelligence (AI)

methods as well as details regarding the chosen ar-

chitectural pattern (MVC). Section 3 talks about our

approach CARL. The evaluation process and the con-

ducted experiments together with the results of the

conducted experiments are presented in 4. Section 5

shows the threats to validity of our proposal, while the

last part (Section 6) states our conclusions and some

ideas for further work.

2 BACKGROUND

In this paper, we are continuing our work in the area

of mobile software architectures examination and we

are proposing a novel, AI-based, automatic way of de-

tecting the components of each architectural layer in

a mobile codebase. The MVC architecture is used as

the base architectural pattern for our study as it’s one

of the most used and well known presentational archi-

tectural patterns (Daoudi et al., 2019).

2.1 Model View Controller

The MVC is one of the most widespread presenta-

tional architectural patterns. It is used extensively

in all sorts of client applications, web, desktop and

mobile. It provides a simple separation of concerns

between the components of a codebase in 3 layers:

Model – responsible for business logic, View – re-

sponsible for the user’s input and the output of the

application and Controller – keeps the state of the ap-

plication, acts as a mediator between the Model and

the View layer. There are many ﬂavors of MVC in

which the data-ﬂow is different but they all share the

same model of separation. MVC is also the precursor

of more specialized presentational architectural pat-

terns such as Model View View Model (MVVM) or

Model View Presenter (MVP) (Daoudi et al., 2019).

2.2 Related Work

Architecture reconstruction methods are two-folded:

identiﬁcation of architectural modules (by cluster-

ing) and identiﬁcation of architectural rules among

modules. Several approaches were proposed to sup-

port the architecture reconstruction process based on

static analysis. A part of these approaches exploit

the structural information extracted from the code-

base ((Mancoridis et al., 1999), (Mitchell and Man-

coridis, 2008)), another part exploit the lexical in-

formation ((Anquetil and Lethbridge, 1999), (Kuhn

et al., 2007)), while some recent approaches exploit

both of them ((Garcia et al., 2013), (Tzerpos and Holt,

2000), (Le et al., 2015), (Saeidi et al., 2015)). Fur-

thermore, few of them consider the architectural style

of the system under analysis. Because our empirical

validation is performed in the context of three iOS ap-

plications and Apple’s ﬂavour of MVC which can be

viewed as a linear layered architectural pattern, we

describe in what follows several approaches that take

into account the particularities of the layered-based

architecture.

Similar to the general systems case, the ap-

proaches developed for analysing the layer-style

projects take into account either the structural fea-

tures of the codebase ((M

uller et al., 1993), (San-

gal et al., 2005), (Sarkar et al., 2009), (Constantinou

et al., 2011)) or the hybrid (structural and lexical) fea-

tures ((Scanniello et al., 2010), (Belle et al., 2013),

(Belle et al., 2014), (?)).

Muller (M

uller et al., 1993) identiﬁed various

building blocks (e.g., variables, procedures, modules,

and subsystems) by using composition operations that

respect two principles: low coupling and high cohe-

sion. Lattix tool (Sangal et al., 2005) extracted the

inter-module dependencies among the code modules

by conventional static analysis. Sarkar (Sarkar et al.,

2009) proposed a human-assisted approach (in fact a

semi-automatic approach) to identify the intended or-

ganization of the modules into layers by analyzing the

source code. The approach combines the structural as

well as non-structural domain-speciﬁc information to

assign a module to a layer. The k-means clustering

is involved in their approach; there are also proposed

three layering principles that are related to the com-

mon violations of the layered architectures as well as

a set of metrics that measure the violation of these

principles. Constantinou (Constantinou et al., 2011)

investigated how to design metrics that can reveal ar-

chitectural information about a software system and

more speciﬁcally, how architectural layers are corre-

lated to design metrics. In such an approach, the de-

sign metrics do not reﬂect the structural information

Detecting Model View Controller Architectural Layers using Clustering in Mobile Codebases

197

about a codebase.

Scanniello (Scanniello et al., 2010) used the link

analysis algorithm for identifying the layers, and for

each layer, they run a k-means clustering for group-

ing the modules from that layer; a lexical similarity

of two modules is computed by considering the com-

ments and the text associated to the module’s code.

No constraints regarding the layered-style architec-

ture are actually involved in their approach. Belle

(Belle et al., 2013) started by an approach based only

on structural dependencies. Belle improved this ap-

proach by taking into account some lexical informa-

tion (the namespace of a package) (Belle et al., 2014).

3 CLUSTERING

ARCHITECTURE LAYERS

Clients – presentational software applications — are

usually self-contained and they commonly use mono-

lithic architectures. Generally, their codebase is split

into layers that contain components that serve a com-

mon well-deﬁned purpose. Each of those layers

achieves a macro purpose.

An architectural layer represents the macro pur-

pose of a set of components in the codebase; indi-

vidual components within the layer fulﬁll other mi-

cro purposes in order to make the macro one possi-

ble. For instance, the macro purpose would be the

separation between the UI interaction logic from the

database handling operations. As micro purposes, we

could have for example a component from the Model

layer which notiﬁes other components regarding a

state change – its micro purpose being to notify.

In this study, we are interested in identifying the

architectural layers of the codebase by detecting the

purpose they serve based on the information available

in the codebase. Our analysis is a static one and uses

only the information in the interfaces (API contracts,

public and private method and properties deﬁnition,

inheritance information) of the investigated compo-

nents, without looking at their implementation (the

body of the functions). In addition to this, we do not

analyze the logic of the components or the way the

dependencies are being used.

We start this study with the idea that elements

within the same architectural layer should have simi-

larities like: the same purpose, a similar code or inter-

face, a similar contribution to the system’s ﬂow and in

order to detect those we plan to use an automatic ap-

proach which is characterized by two important prop-

erties: unsupervised and autonomous.

Unsupervised belongs to the Machine Learning’s

perspective and means that the algorithm needs no

prior knowledge of the data it is about to process, not

requiring any ground truth. In the case of software

identiﬁcation, by ground truth, we refer to the labels

manually associated with the components by one or

more human experts in the ﬁeld. This ground truth

information is not involved in the learning process of

identiﬁcation; it is considered only in the validation

phase of the proposed approach, for computing the

performance metrics. To the best of our knowledge,

there is no benchmark dataset of labeled applications

in the mobile domain. The same validation procedure

was followed in a recent study about the identiﬁca-

tion of architectural patterns in Android applications

by using particular and language-dependent heuristics

(Daoudi et al., 2019).

Autonomous implies that there is no developer in-

volvement in the process; by contrast, there are tech-

niques in which the algorithm is directed to the so-

lution by means of developer intervention (those ap-

proaches based on UML (Sangal et al., 2005), for in-

stance). The autonomy of the proposed solution can

be evaluated also in terms of dependencies to partic-

ular libraries, APIs, languages. Even we will exem-

plify and validate our solution in the iOS ecosystem,

the proposed approach is a generic one; it can easily

be implemented on other platforms that deal with pre-

sentational architectures and a framework for building

the user interfaces.

In terms of Machine Learning, the performed

analysis is considered a clusterization problem:

grouping components into clusters without knowl-

edge of the category they belong to. The clustering

process follows three important steps: extract relevant

information (features) from the raw data (known as

instances); use all the features or just some of them

to analyze the similarities among components and to

build a clustering model; the output generated in this

step is, in fact, a division of the data; validate the ob-

tained clusters by using evaluation standards.

We name our approach Clustering ARchitecture

Layers (CARL) and in what follows we will detail all

these steps, emphasizing the particularities of mobile

software clustering.

For evaluating the performance of our approach,

several clustering performance metrics can be used

(Pﬁtzner et al., 2009). Those are based on a pre-

deﬁned classiﬁcation of the items to be grouped that

reﬂects prior information on the data, which is used as

standard and called ground truth (Mutual information,

Rand index, Precision, Recall, F-measure, etc.).

ICSOFT 2020 - 15th International Conference on Software Technologies

198

4 NUMERICAL EXPERIMENTS

MVC was studied and analyzed by practitioners and

academia (Daoudi et al., 2019). Moreover, by using

MVC for validating our approach we open the way

for other studies which might analyze more sophisti-

cated architectural patterns, especially those descend-

ing from MVC.

Our analysis was focused on the iOS platform;

however, the same process can be applied to any other

platform which uses MVC and SDKs for building UI

interfaces. In order to validate our idea we answered

the following research questions.

RQ1: What features from the codebase can be used

in a clustering algorithm?

RQ2: How effective is the proposed categorization

method compared to manual inspections?

RQ3: What are the downsides of clustering a mobile

codebase for detecting architectural layers?

4.1 Analysed Codebases

In order to validate our approach, we have conducted

experiments on three different codebases, both open-

source and private, of different sizes: Wikipedia -

public information application (Wikimedia, 2018),

Trust - public cryptocurrency wallet (Trust, 2018), E-

Commerce - a private application.

Table 1: Short description of investigated applications.

Application Blank Comment Code Components

Wikipedia 6933 1473 35640 253

Trust 4772 3809 23919 403

E-Commerce 7861 3169 20525 433

Table 1 presents the characteristics of the code-

bases: blank – refers to empty lines, comment – rep-

resents comments in the code, code states the number

of code lines, while components represent the total

number of components in the codebase.

4.2 Evaluation Metrics

For evaluating our approach we asked 2 senior iOS

developers (with over 5 years experience) to manu-

ally label all the components from all the codebases

and we have used the manual inspection as ground-

truth. Having these annotations, accuracy, precision

and recall metrics can be computed (Fawcett, 2006):

• accuracy: Acc =

AllLayers

DetectedCorrectly

allComponents

• precision for the layer X : P

DetectedCorrectly

TotalDetected

• recall for the layer X : R

DetectedCorrectly

GroundTruth

where: N

DetectedCorrectly

is the number of components

detected by the system which belong to the X layer

and are found in the ground truth for that layer;

TotalDetected

is the number of components detected

by the system as belonging to the X layer; N

GroundTruth

is the number of the components which belong to the

X layer in the ground truth.

In (Garcia et al., 2013) the authors deﬁned the

cluster-to-cluster (c2c) metric which is equal to the

Precision metric P

. Precision is the term used in ma-

chine learning, while c2c is commonly used in soft-

ware engineering approaches; however for the current

study they mean the same thing.

4.3 Methodology

We design two stages for our study: a preliminary

stage and a complex stage. In the preliminary phase,

we have considered only a mobile application and we

tried to cluster its components in the corresponding

layers by an incremental process in terms of selected

components’ features as follows:

• Number of Dependencies (F

): how many de-

pendencies a component has with each of the

other codebase’s components; we use F

), for

all components c

(i ∈ {1, 2, . . . , n}) of a codebase;

• Presence of Dependencies (F

): the type of de-

pendencies that it has with each of the other code-

base’s components;

• Name Distance (F

): how many dependencies it

has with each of the other codebase’s components

and the distances between the name of the current

component and the names of the other codebase’s

components;

• Keywords Presence (F

): the features F

are en-

riched by the keyword-based features;

For all these feature subsets, the same clustering algo-

rithm and validation step are applied (see the details

in Section 4.4).

The best subset of features identiﬁed in the pre-

liminary study is used in a second more complex one,

where three applications are investigated (see the de-

tails in Section 4.5). Finally, the ﬁndings are analyzed

and possible improvements are suggested.

For the rest of the study, we are focusing only on

the iOS platform and we are analyzing Swift code-

bases. However, our proposed approach can be eas-

ily extrapolated to other platforms that use SDKs for

building user interfaces and are presentational soft-

ware products.

Since we have analyzed Swift codebases all the

methods deﬁned in extensions of classes deﬁned in

the codebase were added to the extended class and

Detecting Model View Controller Architectural Layers using Clustering in Mobile Codebases

199

the extensions were not taken into consideration when

constructed the features since they represent the same

component. Moreover, all the protocols were also ig-

nored because they only provided blueprints for the

behavior of a component. If the component imple-

ments a protocol then the methods and the behavior

will also be present in the implementing component.

4.4 Preliminary Evaluation

In order to test different approaches and to see which

information from the codebase or what combination

yields the best results, we have chosen a medium-

sized iOS application (20525 lines of code) that uses

the MVC architecture and which was used as a bench-

mark when applying different clustering approaches.

The application used as a benchmark in the approach

section is the E-Commerce one. We have asked an

expert to manually label all the components in the

benchmark application. These labels were used to

calculate the precision and the recall for all the lay-

ers as well as the accuracy in order to compare dif-

ferent approaches. Based on the information used by

the clustering algorithm we describe all three differ-

ent attempts at classifying the components of a code-

base. In all our approaches the features are encoded

into n × |F(c)| matrices. The number of lines (n) cor-

responds to the number of the components in the ana-

lyzed codebase and is constant in all scenarios, while

the number of columns (|F(c)|) varies and is equal to

the number of features considered.

Features based on the Number of Dependencies.

Our ﬁrst attempt was to group the components by tak-

ing into account the dependencies between them. The

features associated with a component of the codebase

correspond to the number of dependencies between

that component and all the other components of the

investigated application. In fact, these features of a

component A are stored as vectors of length equal to

the total number of components from the codebase

(n). The i

element in this vector can be either 0

(when no dependency between A and the i

compo-

nent was found) or a positive integer value that repre-

sents the number of dependencies between A and the

component of the codebase. A dependency rep-

resents a link between two components and takes the

form of associations or inheritance relations. The de-

pendencies were extracted by analyzing the method

signatures and properties of the components. For in-

stance, if component A has a property of type B, then

we have a dependency between A and B. It is im-

portant to mention that the matrix of elements is not

symmetric: if component A has a link to a component

B, that does not mean that the component B also has a

dependency on the A component. We call this version

of our approach CARL-F

. The accuracy obtained was

24.82%, the best recall was for the View layer, while

the precision was maxim for the Controller (see Ta-

ble 2). The approach did not yield good results as

we had many components which have the same num-

ber of dependencies (similar features), but they were

not similar in term of concerns and roles that they im-

plement. E.g. we have components from the View

layer which had only one other dependency and, in

the same time, we have items in the Model layer with

only one dependency.

Features based on the Type of Dependencies. In

order to improve the performance of the ﬁrst cluster-

ing attempt we have restricted the dependency-based

features to only two values: 0 if no dependency be-

tween the elements was found or 1 otherwise. This

approach yields better results than the previous one,

as in this approach the direction of the dependencies

matters more than their number. However, we have

chosen not to pursue this path as when we enhanced

the data provided to the clustering algorithms, the re-

sults were not different than using the ﬁrst approach

– features based on the number of dependencies in

combination with the new data. In addition to this, to

provide more data to the clustering algorithm while

using this approach, we would have doubled the width

of the matrices and then we would run into a feature

selection issue. We call this version of our approach

CARL-F

. The accuracy obtained in this scenario was

almost doubled compared to the ﬁrst approach – Ac-

curacy is 46.60% in Table 2.

Hybrid Features based on Dependencies and on

the Component’s Name. To further improve the

clustering of the components more information had

to be provided regarding the application’s elements.

After manually analyzing several mobile codebases,

we have seen that there is a correlation between the

names of the components and the layers in which they

would reside. Usually components from the same

layer have similar names (SellerViewController, Buy-

erViewController – for the Controller layer or Sell-

erItemView, BuyerItemView for the View layer) In or-

der to score the similarity between the names of two

components, the Levenshtein distance (Levenshtein,

1966) was computed. For every component A in the

codebase, we have fused, by addition, the number of

dependencies between A and another component B

and the string distance between the A’s and B’s names.

In this manner, for each component a set of hybrid

(structural and lexical) n features is obtained. This

version is called CARL-F

. With the new information

regarding the distance between the components, the

accuracy was improved to 52.46%– see Table 2.

ICSOFT 2020 - 15th International Conference on Software Technologies

200

Hybrid Features based on Dependencies, on the

Component’s Name and on Keywords. Another im-

portant aspect we have discovered while manually an-

alyzing mobile codebases was the fact that the com-

ponents had certain keywords in their names based on

the layer in which they reside. We have noticed that

for the Controller layer, the controller keyword was

present in a large majority of its components, this is

also true for the View layer with the view keyword.

We have enhanced the feature set from the CARL-

approach by considering for each component two

new elements: one for the controller keyword and one

for the view. A component is actually represented by

n + 2 features. If the name of the component con-

tained the view keyword, a value of 500 was consid-

ered, otherwise the feature was set to 0 (W (c

view

)

is 500 or 0). In the case of the controller, if the name

of the component contained the keyword, a value of

10.000 was used, otherwise, the feature entry was 0

((Kw(c

controller

) is 10.000 or 0). The large num-

bers were chosen in order for this information to be

viewed as stronger (in opposition to the distance be-

tween the names) by the clustering algorithm. The

values of 500 and 10.000 were also chosen because

the elements from the Controller layer, most speciﬁ-

cally ViewController elements that account for a large

majority of all the components in this layer, contained

both keywords. Thus, their chances of being correctly

clustered increased. We call this version of our ap-

proach CARL-F

. The accuracy was improved by us-

ing the above-mentioned information in the clustering

process with over 20% reaching 78.45% (see Table 2)

on the benchmark application.

Hybrid Features based on Dependencies, on the

Component’s Name, on Keywords and on SDK In-

heritance. In the last scenario, we have enhanced

the CARL-F

method by taking into account informa-

tion regarding the type of the components, also. In

the mobile SDKs, we have components from which

the developers inherit in order to implement certain

parts of the application. In a typical application, all

the elements presented on the screen inherit from an

SDK deﬁned View element. This is also true for a

large number of Controller elements – which handle

both the input received from the user and the state

of the application. We have constructed lists of all

the View and Controller SDK deﬁned elements and

we have provided the clustering algorithm informa-

tion about whether or not a component inherits from

one of those. In addition to the features involves in

CARL-F

approach, we have added two new values:

one for indicating whether or not the component in-

herits from an SDK deﬁned View element and one

for the Controller case. For the View element, value

750 was used if the component inherited from the

View component deﬁned in the SDK and 0 otherwise

(Inh

SDK

, View) was 750 or 0). The second value,

for the Controller element, was 2.000 if there was an

inheritance and 0 otherwise (Inh

SDK

, Controller)

was 2.000 or 0). We call this version of our approach

CARL-F

. The new information further improved the

performance of our clustering algorithm by over 12%,

reaching an accuracy 85.25% (see Table 2) on the

benchmark. The View layer seems to be entirely and

correctly detected, but some components that should

belong to the Controller layer are associated with the

Model layer. This result could be a consequence of

the usage of keywords and SDK’s inheritance rela-

tions dedicated to View and Controller clusters, only.

A clusterization improvement is possible to be ob-

tained by extending the set of keywords (by looking

at the coding conventions and standards used in the

code – manually or through an automated process).

Table 2 presents our ﬁndings on the benchmark

application in the ﬁve feature selection scenarios.

4.5 Empirical Evaluation

After the experiments were run we analyzed the data

and answered the research questions based on the re-

sults obtained. This subsection presents our ﬁndings.

RQ1 - What features from the codebase can be

used in a clustering algorithm? In section 4.4 we

have seen ﬁve different CARL approaches that gradu-

ally used more features extracted from the codebase.

We were interested in detecting the architectural

layers of the codebase. Therefore, ﬁrstly we looked at

the dependencies between the components as struc-

tural features that can be extracted from the codebase.

Based on the number of dependencies we had two ap-

proaches, one where we used the exact number of de-

pendencies between the components and one where

we applied a binary encoding, highlighting the depen-

dency’s presence only.

Another information, a lexical one this time, we

used was the name of the ﬁles and we have discov-

ered similar components have similar names. We

measured the similarity using the Levenshtein dis-

tance. In addition, some keywords were also used

for the View and Controller layer where we have ob-

served that developers follow a naming convention.

Furthermore, the SDK inheritance information pro-

vided to the clustering algorithm further improved

the accuracy. These last characteristics enrich the

dependency-based structural features extracted from

the codebase by semantic information and emphasize

the relationship of a component with the used SDK.

To sum it up, we have used the next information:

Detecting Model View Controller Architectural Layers using Clustering in Mobile Codebases

201

Table 2: Analysis of all the ﬁve versions of CARL on the benchmark application.

Model View Controller Accu-

Precision Recall Precision Recall Precision Recall racy

CARL-F

0.50 0.01 0.22 1,00 1,00 0.10 0.24

CARL-F

0.49 0.93 0.17 0.09 1,00 0.08 0.46

CARL-F

0.62 0.75 0.33 0.53 0.65 0.22 0.52

CARL-F

0.70 0.93 0.84 0.83 0.99 0.56 0.78

CARL-F

0.76 0.99 1,00 1,00 0.99 0.57 0.85

• dependencies between components – the actual

number and a binary version;

• distance between the names of the ﬁles – for iden-

tifying groups of elements that share similarities

between names;

• keywords – whether or not the name of the com-

ponent contained certain keywords;

• SDK inheritance – whether or not the component

inherits from an SDK deﬁned one.

RQ2 - How effective is the proposed categorization

method compared to manual inspections? Using

CARL-F

approach we have obtained an average ac-

curacy of 77,95%, an average precision of 79,32%

and an average recall of 75,93% on all the analyzed

codebases (see Table 3 that presents the results ob-

tained by applying CARL-F

on all the analysed code-

bases). We have observed that on one of the most

complex and largest projects — Wikipedia — we

have obtained an accuracy of 82,40%. In the case

of the worst-performing codebases analyzed with our

method we have found out that the elements did not

have a consistent naming convention. They did not

contain many elements that had similarities between

names or contained one of the used keywords. Our

method works better in cases where the codebase

is consistent with respect to naming conventions for

each architectural layer and is greatly impacted by the

coding standards and the consistencies of the project.

RQ3 - What are the downsides of applying clus-

tering to a mobile codebase for detecting architec-

tural layers? One of the most important downsides

is the fact that by using the proposed approach the

elements are clustered based on their dependencies

which means that a component can be wrongly de-

tected if it was not implemented properly and has for-

bidden or wrong dependencies.

Moreover our method also used the naming con-

ventions and assumes the presence of certain key-

words. While the keywords can be adapted based on

the speciﬁcation of the project, this process will be-

come a more complex and less automated one. In ad-

dition to this, if the codebase does not respect certain

naming conventions the proposed approach will also

not yield good results.

Another downside of the proposed approach is the

fact that the clusters have to be manually inspected for

deciding what type of layer do they represent at least

in the case of more specialised architectures with mul-

tiple layers. In the case of our study we have labelled

the clusters based on the type of the majority of the

elements, but in case of large projects with more ar-

chitectural layers this process might not be automated

and manual intervention might be needed.

5 THREATS TO VALIDITY

After the analysis we have found out that CARL

presents the following threats of validity:

• Internal – we used the Levenshtein distance to

compute the string distance metrics. We have

discovered from trial and error experiments the

predeﬁned scores for the Keywords presence and

SDK inheritance methods. In addition, the choice

of clustering algorithm was made purely based

on trial and error experiments; there might be

other approaches that use different mechanisms

that work better.

• External – the experiments were run on the iOS

platform and on the Swift language, there might

be other SDKs and languages which have partic-

ularities which we have not addressed in this pa-

per. Moreover, we have focused this preliminary

research only on the MVC pattern without taking

much into consideration more complex architec-

tural patterns and their particularities.

• Conclusion – from a results point of view, the

ground truth was constructed by a human experts

which might introduce biased based on their ex-

perience. Furthermore, the analyzed codebases

might also be responsible for some bias and more

experiments should be run.

6 CONCLUSION & FURTHER

WORK

With our study, we have proven that there is potential

in using AI techniques in the domain of software ar-

chitectures on mobile devices. The proposed CARL

ICSOFT 2020 - 15th International Conference on Software Technologies

202

Table 3: CARL-F

results in term of detection quality.

Codebase

Model View Controller Accu-

Precision Recall Precision Recall Precision Recall racy

Wikipedia 0.78 0.83 1.00 0.54 0.83 0.98 0.82

Trust 0.79 0.69 0.38 0.66 0.62 0.57 0.66

E-comm 0.76 0.99 1.00 1.00 0.99 0.57 0.85

method works well given the fact that is an unsuper-

vised method that needs to cluster components for

which is hard to deﬁne numerical metrics that feed

the clustering algorithm.

This method can not be used as a standalone tech-

nique for identifying architectural issues as it does not

take into consideration the constraints of the code-

base, as it is able to split the codebase based on the

various information obtained from its components but

it cannot decide whether a component should actually

be in a certain layer or not.

With the previous idea in mind, we are planning to

develop a hybrid system in which we’ll use a heuristic

approach combined with the clustering for trying to

further improve the system and to be able to detect

more precisely the components of the codebase.

The proposed approach has a large variety of prac-

tical applications, it can be used for improving the ar-

chitectural qualities of codebases or for educational

purposes where beginners could learn to better struc-

ture their code by enforcing them to follow a certain

architectural pattern.

REFERENCES

Anquetil, N. and Lethbridge, T. C. (1999). Recovering soft.

architecture from the names of source ﬁles. Jour-

nal of Soft. Maintenance: Research and Practice,

11(3):201–221.

Belle, A. B., El-Boussaidi, G., Desrosiers, C., and Mili, H.

(2013). The layered architecture revisited: Is it an

optimization problem? SEKE, pages 344–349.

Belle, A. B., El Boussaidi, G., and Mili, H. (2014). Recov-

ering soft. layers from object oriented systems. 2014

9th Int. Conf. on Evaluation of Novel Approaches to

Soft. Engineering (ENASE), pages 1–12.

Constantinou, E., Kakarontzas, G., and Stamelos, I. (2011).

Towards open source soft. system architecture recov-

ery using design metrics. 2011 15th Panhellenic Conf.

on Informatics, pages 166–170.

Daoudi, A., ElBoussaidi, G., Moha, N., and Kpodjedo,

S. (2019). An exploratory study of MVC-based ar-

chitectural patterns in android apps. Proc. of the

34th ACM/SIGAPP Symposium on Applied Comput-

ing, pages 1711–1720.

Fawcett, T. (2006). An introduction to roc analysis. Pattern

recognition letters, 27(8):861–874.

Garcia, J., Ivkovic, I., and Medvidovic, N. (2013). A com-

parative analysis of soft. architecture recovery tech-

niques. Proc. of the 28th IEEE/ACM Int. Conf. on

Automated Soft. Engineering, pages 486–496.

Kuhn, A., Ducasse, S., and G

ırba, T. (2007). Semantic clus-

tering: Identifying topics in source code. Information

and Soft. Technology, 49(3):230–243.

Le, D. M., Behnamghader, P., Garcia, J., Link, D., Shah-

bazian, A., and Medvidovic, N. (2015). An empirical

study of architectural change in open-source soft. sys-

tems. MSR, 2015 IEEE/ACM 12th Working Conf. on,

pages 235–245.

Levenshtein, V. I. (1966). Binary codes capable of correct-

ing deletions, insertions, and reversals. Soviet physics

doklady, 10(8):707–710.

Mancoridis, S., Mitchell, B. S., Chen, Y., and Gansner,

E. R. (1999). Bunch: A clustering tool for the

recovery and maintenance of soft. system struc-

tures. Proc. IEEE Int. Conf. on Soft. Maintenance-

1999 (ICSM’99).’Soft. Maintenance for Business

Change’(Cat. No. 99CB36360), pages 50–59.

Mitchell, B. S. and Mancoridis, S. (2008). On the evalu-

ation of the bunch search-based soft. modularization

algorithm. Soft Computing, 12(1):77–93.

uller, H. A., Orgun, M. A., Tilley, S. R., and Uhl, J. S.

(1993). A reverse-engineering approach to subsystem

structure identiﬁcation. Journal of Soft. Maintenance:

Research and Practice, 5(4):181–204.

Pﬁtzner, D., Leibbrandt, R., and Powers, D. (2009). Char-

acterization and evaluation of similarity measures for

pairs of clusterings. Knowledge and Information Sys-

tems, 19(3):361.

Russell, S. J. and Norvig, P. (2016). Artiﬁcial intelligence: a

modern approach. Malaysia; Pearson Education Lim-

ited,.

Saeidi, A. M., Hage, J., Khadka, R., and Jansen, S. (2015).

A search-based approach to multi-view clustering of

soft. systems. 2015 IEEE 22nd Int. Conf. on Soft.

Analysis, Evolution, and Reengineering (SANER),

pages 429–438.

Sangal, N., Jordan, E., Sinha, V., and Jackson, D. (2005).

Using dependency models to manage complex soft.

architecture. ACM Sigplan Notices, 40(10):167–176.

Sarkar, S., Maskeri, G., and Ramachandran, S. (2009). Dis-

covery of architectural layers and measurement of lay-

ering violations in source code. Journal of Systems

and Soft., 82(11):1891–1905.

Scanniello, G., D’Amico, A., D’Amico, C., and D’Amico,

T. (2010). Using the kleinberg algorithm and vector

space model for soft. system clustering. 2010 IEEE

18th Int. Conf. on Program Comprehension, pages

180–189.

Trust (2018). Trust wallet iOS application. link.

Tzerpos, V. and Holt, R. C. (2000). ACCD: an algorithm for

comprehension-driven clustering. Proc. 7th Working

Conf. on Reverse Engineering, pages 258–267.

Wikimedia (2018). Wikipedia ios application. link.

Detecting Model View Controller Architectural Layers using Clustering in Mobile Codebases

203
