Codeless Web Testing using Selenium and Machine Learning

Duyen Phuc Nguyen

and Stephane Maag

Samovar, CNRS, T

ecom SudParis, Institut Polytechnique de Paris, France

Keywords:

Codeless Testing, Web Testing, Automation Testing, Selenium, Machine Learning, SVM.

Abstract:

Complexity of web systems lead to development processes always more tough to test. Testing phases are

crucial in software and system engineering and are known to be very costly. While automated testing methods

appear to take over the role of the human testers, the issues of reliability and the capability of the testing

method still need to be solved. In our paper, we focus on the automation of functional tests of websites. A

single web page may contain a huge set of important functionalities leading to the execution of critical web

service operations. Besides, testing all of these functionalities implemented in a web page service is highly

complex. Two current popular research areas for automation web-based testing are Codeless Functional Test

Automation and Machine Learning/Artiﬁcial Intelligence (ML/AI) in test automation. We therefore deﬁne

and implement a framework to ﬁgure out how to automate the web service product under test, the machine can

detect or predict the change and adapt those changes to suitable generic test cases. In our work, we examine

on Selenium and the beneﬁts of using machine learning in automated web application testing.

1 INTRODUCTION

Software systems and their complexity distributed

through diverse components, sometimes virtualized

using different platforms (e.g., Xaas) (Patel et al.,

2016), lead to development processes always more

complicated to test. However, testing phases are cru-

cial in software and system engineering (Kassab et al.,

2017). They are known as very costly necessitating

resources (including time and people) spent to pre-

pare testing architectures, test case scenarios and their

execution. That cost is estimated to be between 40%

and 80% of the total cost of the service/system devel-

opment (Heusser and Kulkarni, 2018). While auto-

mated testing methods appear to take over the role of

the human testers, the issues of reliability and the ca-

pability of the testing method still need to be solved.

In our paper, we focus on the functional tests of web-

sites. A single web page may contain a huge set of

important functionalities leading to the execution of

critical web service operations. Besides, testing all of

these functionalities implemented in a web page ser-

vice is highly complex. For that purpose, several au-

tomation tools are available to help the testers and to

facilitate the execution of testing processes (Hynninen

et al., 2018; Raulamo-Jurvanen et al., 2019). Among

https://orcid.org/0000-0003-3740-3586

https://orcid.org/0000-0002-0305-4712

them, we may cite the well known and adopted tools

in the industry: Selenium and OpenScript. Recently,

it has been shown that Selenium (Selenium, 2020)

is very efﬁcient for testing applications which are

browser based (Jain and Rajnish, 2018). It runs spe-

ciﬁc tests on diverse installed browsers and return re-

sults, alerting you to failures in browsers as they crop

up.

However, automated web-based testing tools like

Selenium still have major drawbacks. Indeed, tests

have to be repetitive and require resources and a lot

of maintenance. A very small change or modiﬁcation

in the content of a web page may cause a test fail.

Furthermore, many tests scripts are manually handled

which increases the costs and time for testing (Shariff

et al., 2019; Ameur-Boulifa et al., 2019). Researchers

and industrials are studying and deﬁning optimized

approaches to deal with this challenge. Two cur-

rent popular research areas for automation web-based

testing are Codeless Functional Test Automation and

Machine Learning/Artiﬁcial Intelligence (ML/AI) in

test automation. In here, algorithms are deﬁned and

implemented to ﬁgure out how to automate the soft-

ware/web service product under test, the machine can

detect or predict the change and adapt those changes

to the suitable test cases. Thanks to codeless testing,

testers can drastically reduce the cost of test automa-

tion creation, test execution, and maintenance. In our

Nguyen, D. and Maag, S.

Codeless Web Testing using Selenium and Machine Learning.

DOI: 10.5220/0009885400510060

In Proceedings of the 15th International Conference on Software Technologies (ICSOFT 2020), pages 51-60

ISBN: 978-989-758-443-5

work, we examine on Selenium and the beneﬁts of

using machine learning in automated web applica-

tion testing. The motivation is to utilize the selenium

framework in the world of automated testing and uti-

lize a machine learning approach for codeless testing,

enabling to test multiple functional web pages with-

out using code.

The main contributions of our paper are:

• Deﬁning a framework named “codeless testing”

by combining Selenium and machine learning

technique,

• Implementing and applying our framework to run

generic test cases in order to test the functionality

search that is present in multiple web pages,

• Through our experiment results, we show that the

success of generic test cases may help to con-

tribute in decreasing implementation and main-

tenance costs of automated tests of functional

browser based applications.

Finally, our paper is organized as it follows. In Sec-

tion 2, we present the state of the art about automated

codeless testing techniques and tools. Then in Sec-

tion 3, we depict the basis used in our paper. Our ML

based web testing framework is deﬁned in the Sec-

tion 4 and evaluated in the Section 5 in which relevant

experimental results are presented. We conclude and

give perspectives in Section 6.

2 RELATED WORKS

In the literature, there are several papers introduc-

ing approaches for automation web-based applica-

tions testing by applying machine learning tech-

niques (RJ Bhojan, 2019) (Rosenfeld et al., 2018)

(Nguyen et al., 2018) (Joshi, 2016). Although we

got inspired of these works, none of them has pro-

posed novel codeless web service testing. With the

same observation, codeless testing approaches have

been recently proposed. We may cite (Isha and Re-

vathi, 2019) in which the authors proposed an auto-

mated API testing tool in providing a GUI with sup-

port for codeless testing. However, they do not in-

tend to use any learning techniques that could im-

prove their work and the problematic we are tackling

in our paper. We may note the same lack in (Brueck-

mann et al., 2017). Though the technique proposed is

not entirely codeless, the authors proposed a frame-

work to implement a simple business process by in-

tegrating existing services in a mashup with codeless

engineering processes. However, they still do not in-

tegrate any learning techniques.

Moreover, in the market area, many start-up com-

panies with several tools have entered the market re-

cently, all with the promise of solving the coding skill

conundrum. While no-code or low-code concepts

become a trend (following the recent Google patent

(Arkadyev, 2017)), companies such as Salesforce pro-

mote plug-and-play offers. Some testing tools such

as Testcraft

, Ranorex

, Tricentis

, Leapwork

, etc.

advertise that they can provide this functionality by

building a user-friendly UI on top of the code layer

and also enabling switching between two modes. The

companies promote that testers can still write scripts

and receive detailed feedback but skip the coding part.

However, when it comes to test automation, an issue

is often raised on how codeless is being interpreted.

Moreover, none of these codeless testing tools pro-

posed by those companies are open-source.

In our approach, we cope with these above men-

tioned issues by deﬁning a machine learning based

approach for codeless web automation testing.

3 BASICS

3.1 Selenium

Selenium (Selenium, 2020) is a suite of automation

testing techniques and tools which allows the testers

to run the tests directly on the target browser, drive

the interactions on the required web pages and rerun

them without any manual inputs. Selenium has be-

come very popular among testers because of the var-

ious advantages it offers. With its advent in 2004,

Selenium made the life of automation testers easier,

highly improved the testing time, costs, detected fail-

ures and is now a favorite tool for many automation

testers. Selenium was invented with the introduc-

tion of a basic tool named as JavaScriptTestRunner,

by Jason Huggins at ThoughtWorks to test their in-

ternal Time and Expenses application. Now it has

gained popularity among software testers and devel-

opers as an open-source portable automation testing

framework. Nowadays, Selenium is currently used

in production in many large companies as Netﬂix,

Google, HubSpot, Fitbit, and more. According to

(Enlyft, 2020), there are 42,159 companies that use

Selenium, taking 26.83% market share in software

testing tool (see Figure 1).

The primary reason behind such overwhelming

https://www.testcraft.io/

https://www.ranorex.com/

https://www.tricentis.com/

https://www.leapwork.com/

ICSOFT 2020 - 15th International Conference on Software Technologies

Figure 1: Selenium used by company size.

popularity of Selenium is that it is open source. This

not only helps keep the costs in check but also en-

sures that companies are using a tool that will get

continually updated. Other reasons include the multi-

dimensional ﬂexibility that it offers in terms of script-

ing languages, operating systems, browsers, and in-

tegration with other tools. This widens the scale of

reach and test coverage, enabling enterprises to de-

liver a web application that is highly reliable and

functional. Selenium test scripts can be written in

Java, Python, C#, PHP, Ruby, Perl and .Net. This al-

lows a large number of testers to easily use it without

any language barriers. It can be carried out on Win-

dows, MacOS, and Linux, using any browsers out of

Mozilla Firefox, Internet Explorer, Chrome, Safari,

and Opera. This enables a thorough cross browser

compatibility testing with strong environment sup-

port.

Selenium suite includes three major components

(Figure 2), each tool has its own approach for au-

tomation testing. The testers or developers can choose

tools out of it depending upon the testing require-

ments.

• Selenium IDE.

Selenium IDE, earlier known as Selenium

recorder, is a tool used to record, edit, debug and

replay functional tests. Selenium IDE is imple-

mented as an extension to the Chrome browser

and add-on in Firefox browser. With Selenium

IDE plugin, the testers can do simple record-and-

playback of interactions with the browser, they

can also export tests in any of the supported

programming languages like Ruby, Java, PHP,

Javascript, etc.

• Selenium Grid.

Selenium Grid allows the testers to run paral-

lel automated tests on multiple machines and

browsers at the same time. The main function

of this tool is to save time. If the test suite is

large, the testers can use Selenium Grid to reduce

the time running. Considering how scripts nor-

mally run slow on a browser, using performance-

improving techniques such as parallel testing can

help with the problem. Testers can also use it to

test one application in different browsers in par-

allel, when one machine is running Firefox, the

other Chrome, and so on. Testers can also cre-

ate different conﬁgurations with Grid, combining

different versions of browsers and operating sys-

tems. Needless to say that when used in large pro-

duction environments, Grid is a huge time-saver.

• Selenium Webdriver.

Selenium Webdriver (which is also known as Se-

lenium 2.0 or 3.0 currently version) is an en-

hanced version of Selenium RC and the most used

tool. Selenium Webdriver is by far the most im-

portant component of Selenium Suite. It pro-

vides a programming interface to create and ex-

ecute automation scripts. It accepts commands

via client API and sends them to browsers. Se-

lenium WebDriver allows testers to choose a pro-

gramming language of their choice to create test

scripts. Test scripts are written in order to iden-

tify web elements on web pages and then desired

actions are performed on those elements. Sele-

nium Webdriver currently supports most popular

browsers (Chrome, Firefox, Opera, etc.). Every

browser has different drivers to run tests. In our

”codeless testing framework”, we use Selenium

Webdriver to conduct the automated tests on mul-

tiple popular web browsers.

Figure 2: Selenium suite components.

3.2 Codeless Testing

Despite the advantages above listed, Selenium still

has limitations. The most challenge of using Sele-

nium in automation testing is steep learning curve.

Testers require high technical skills to accurately

design and maintain test automation. Maintenance

including modiﬁcations and updating Selenium test

code in an efﬁcient way is a very common problem

in automated test. The impact of the changes occur

in the web page or application under test could suf-

fer during its development. Changes or modiﬁcations

from web User Interface (UI) or from its structure to

its elements or its attributes could make the whole

Codeless Web Testing using Selenium and Machine Learning

test suites collapse. For that purpose, one of auto-

mated testing trends, namely Codeless Testing, was

introduced to try resolving those issues.

Codeless Testing for web services refers to the

methodology which utilizes a generic test case to

test multiple websites. This approach allows any

tester without deep programming knowledge to per-

form tests. Organizations started adapting tools and

approaches to simplify test automation and empower

team members who lacked sophisticated program-

ming skills. Codeless tools were originally meant to

help the tester avoid the hours of programming that

are usually necessary to get the most out of testing

logic. While their objective was to address program-

ming complexity, most tools in the market adapted a

no-code approach by avoiding the code, but not really

addressing the logical complexity in testing. A com-

mon misconception is that codeless test automation

tools should completely avoid code. We believe this

is actually a disservice, as very soon users will start

hitting roadblocks. Testing requirements are typically

as vast as application development. It is hard to be-

lieve that all testing requirements could be addressed

with some canned, pre-packaged solution. Some level

of logic development ﬂexibility is required, but in a

way so that the user does not get bogged down by

the syntactical complexities. Note that, though the

name codeless testing, it does not mean it is com-

pletely code free. While a tester can generate most of

the tests code free, certain tests may still need some

coding. Testers can use codeless testing for keeping

up with the deployment needs.

3.3 Support Vector Machines

A support vector machine (SVM) (Vapnik and Vap-

nik, 1998) is a linear classiﬁer deﬁned by a separat-

ing hyperplane that determines the decision surface

for the classiﬁcation. Given a training set (supervised

learning), the SVM algorithm ﬁnds a hyperplane to

classify new data. Consider a binary classiﬁcation

problem, with a training dataset composed of pairs

, y

), . . . , (x

, y

), where each vector x

∈ R

and

∈

{

−1, +1

}

. The SVM classiﬁer model is a hyper-

plane that separates the training data in two sets corre-

sponding to the desired classes. Equation (1) deﬁnes

a separating hyperplane

f (x) = w

x + b = 0 (1)

where w ∈ R

and b ∈ R are parameters that control

the function. Function f gives the signed distance

between a point x and the separating hyperplane. A

point x is assigned to the positive class if f (x) ≥ 0,

and otherwise to the negative class. The SVM al-

gorithm computes a hyperplane that maximizes the

distance between the data points on either side, this

distance is called margin. SVMs can be modeled as

the solution of the optimization problem given by (2),

this problem maximizes the margin between training

points.

min

w,b

k w k

subject to: y

+ b) ≥ 1, i = 1, . . . , l

(2)

All training examples label −1 are on one side of the

hyperplane and all training examples label 1 are on

the other side. Not all the samples of the training data

are used to the determine the hyperplane, only a sub-

set of the training samples contribute to the deﬁnition

of the classiﬁer. The data points used in the algorithm

to maximize the margin are called support vectors.

4 A ML-BASED WEB TESTING

FRAMEWORK

The architecture overview of our codeless testing

framework is illustrated in Figure 3.

Figure 3: Our architecture of codeless testing framework.

As mentioned in the previous sections, our frame-

work is combined of Selenium and a machine learning

algorithm. It is composed by four main components.

• Selenium Webdriver Component.

This is the major module, it plays a role as an en-

gine to drive the browser for automating website

and for testing. As referring in Figure 2, Sele-

nium Webdriver (web, 2020) is the core module

of our testing framework. Selenium WebDriver

plays as a browser automation framework that ac-

cepts commands and sends them to a browser. It

is implemented through a browser-speciﬁc driver.

It controls the browser by directly communicating

with it. The ﬂexibility that Selenium Webdriver

provides is almost unmatched in the test automa-

tion world.

• Scraping Data Component.

We implemented our scraping tool in Python.

Besides, we utilize BeautifulSoup (Richardson,

2020) as a web scraping library to pull data out

of DOM in HTML or XML format.

ICSOFT 2020 - 15th International Conference on Software Technologies

• Processing Data Component.

This component has a role to process the data af-

ter pulling from HTML DOM ﬁle, its main goal is

to clean up and extract the useful data, then trans-

form the cleaned data to the next stage for train-

ing.

• SVM Model.

A machine learning model to recognise and/or

predict the search element pattern which appears

in HTML data of testing website.

4.1 Scraping and Processing Web Data

Figure 4: The structure of our scraping tool.

The general architecture of our scraping tool is

showed in Figure 4. Its main target is exactly as its

name - to collect HTML data and their position in the

DOM tree from the website which is driven by Se-

lenium Webdriver. We use both Selenium Webdriver

and Request library to send a HTTP request to the

URL of the webpage we want to access. We discover

that some websites with heavy render JavaScript will

not response to the request module. Also, some web-

sites can detect the request is performed in an auto-

mated way (not by human browsing but expected to

be a bot) by their tool, it will deny to establish the con-

nection. Selenium Webdriver works ﬁne with almost

all major websites, however the speed is recorded

as very slow since Selenium needs to open the real

browsers to perform tasks. Moreover, using differ-

ent browsers (Chrome, Firefox, Opera, etc.) may

lead to obtain different behaviours of navigation web-

sites. For example, some websites are optimized for

Chrome but not Firefox or vice versa, or some website

may crash down on Microsoft Edge browser. There-

fore, we use both modules Selenium Webdriver and

Request library (Pypi, 2020) to ensure that our scrap-

ing tool can adapt with most of the websites to col-

lect as most as data it can. First, using request library

for speeding up the test, if a request fails, then Sele-

nium Webdriver will easily detect it. Moreover, each

website has its different DOM structure, thousands

of websites will have thousands of DOM structures,

therefore it is a challenge process to retrieve in an au-

tomated way the data from multiple of websites con-

currently. Nevertheless, our scraping tool enables to

scrape and collect variety of websites. Our scraping

tool follows two tasks:

1. Query the website using requests or Selenium

WebDriver and return its HTML content.

2. Using BeautifulSoup (Richardson, 2020) and

LXML (LXML, 2020) libraries to go through the

HTML structure of each website, parse HTML

content and extract the expected data useful to

tested the targeted functionality embedded in the

website.

4.2 Our SVM Model

In considering that web HTML elements are keep

changing dynamically in both structure and attribute

values, it is a very challenging task to adapt test suites

with the websites changes. In our proposed frame-

work, the objective of SVM model is to recognize the

pattern of web elements corresponding to the search

box in each website as illustrated in Figure 5. Specif-

ically, the SVM model will learn the HTML structure

of each website, in case of any modiﬁcation in terms

of web elements, the SVM model will ﬁnd the similar

pattern of HTML web and adjust its model according

to the changes.

Figure 5: SVM model detects search box pattern.

For the next testing step, if the website has

changed, the SVM model detects its changes and

guides the Selenium code to adapt automatically with

it. In this case, the test code will not be broken and

can be reused. More speciﬁcally, the goal of the SVM

is to train a model that assigns new unseen web ele-

ments into a particular category. It achieves this by

creating a linear partition of the feature space into

two categories. In each website, structured data is

extracted for each HTML element, they have to be

turned into proper feature vectors. We use SVM

model to recognize the relevant feature of each web

element corresponding to its density and apply in the

feature importance property of our model. Many fea-

tures and preprocessing steps are performed as part

Codeless Web Testing using Selenium and Machine Learning

of our cross-validation process, and we kept the ones

yielding best performance and moved them in the ﬁ-

nal model. Feature importance gives a score for each

feature attribute, the higher of the score, the more im-

portant or more relevant of the feature is. Therefore,

the weight for each element attribute is assigned ac-

cording to its frequency and informative ranking.

4.3 Data Collection and Analysis

In order to have the dataset for our training SVM

model, we need to gather the large amount of data. By

using the scraping tool described above, we are suc-

cessful to retrieve the data from the list of 5000 web-

sites provided by the Alexa database. This database

contains more than one million URLs on top rank-

ing of Alexa (Helme, 2020). Our tool can scrape any

website that has the search functionality, it pulls down

all the web elements corresponding to the search box.

However, these elements are collected as raw data

in an undesired format, unorganized, and extremely

large. Furthermore, these elements may be different

from one page to another. We need, for further steps,

to use the processing tool to enhance the data quality

and, related to our experiments, in particular to extract

the elements linked to the search box (our testing pur-

pose).

The main steps for preprocessing data are format-

ting and cleaning. Data cleaning is applied to remove

messy data, duplicate data and manage missing val-

ues. Formatting is required to ensure that all vari-

ables within the same attribute are consistently writ-

ten. Once structured data is extracted for each HTML

element, they have to be turned into proper feature

vectors.

After this preprocessing phase, vectors with rele-

vant features is obtained, our training dataset is built.

For that purpose, an important task of labelling is

then performed to classify our vectors depending on

the structure of the ”search box”. We labeled 1000

webpages to provide three classes according to the

three cases detailed in Section 5.1. From this training

dataset, an SVM model has been obtained as above

explained.

5 EXPERIMENTAL STUDIES

AND RESULTS

5.1 Use Case Studies

To test our codeless testing framework, our expe-

riences focus on testing the search-functionality of

websites. To be concrete, let us follow the following

scenario: if the users want to use Google to search for

the term Codeless Testing, they normally open their

favourite browser, let say Chrome, to navigate to the

website of Google. After the ofﬁcial site of Google

page fully loaded, the users need to locate the search

box, then type the search term Codeless Testing. All

of this manual steps performed by human can be com-

pletely replaced those steps by our codeless testing

framework. However, although these steps can be in-

deed easily automated for this scenario, our codeless

testing approach intends to make it generic enough

to test the search functionality on diverse websites.

By analyzing the multiple search activities on various

websites, we group the search scenario in three use

cases:

• Case 1 (Traditional Search): we call it traditional

because the search box is appeared directly in the

website interface, the user can easily locate it and

enter the search query. We studied that 80-90%

search websites are designed in this case 1 (Fig.

6). For example: google, youtube, yahoo, ama-

zon, etc.

Figure 6: Case 1 search type: traditional search.

• Case 2 (Hidden Bar Search): The search bar is

hidden, the users are required extra step by click-

ing the search button to activate/open the search

bar. Once the search bar appears, the user can en-

ter his search query (Fig. 7).

Figure 7: Case 2 search type: hidden search box.

• Case 3 (Pattern/Condition Search): the websites

have many ﬁlters/criteria for search, the users

ICSOFT 2020 - 15th International Conference on Software Technologies

must select the right criteria to proceed. For in-

stance, some hotel or housing websites only al-

low users to select the special search key in their

pattern database (region, type of house, size of

house, price, number of rooms, etc.). Further-

more, particular websites only allow the users to

perform the search on specify content provided in

their database. If the users type a random search

query, or the query does not correspond to a spe-

ciﬁc form, nothing is returned (Fig. 8).

Figure 8: Case 3 search type: ﬁlters/criteria search.

In order to test the search functionality in a website,

we deﬁned three verdicts within our generic test case:

pass, fail, error, as it follows.

• The test is considered as pass if a browser has

fully loaded the website, the “search term” is en-

tered in the search box, the website returns the an-

swer corresponding to the “search term”.

• The test is considered as fail if the browser was

unable to load the website under test and to navi-

gate to the search box.

• The test is considered as error if the website un-

der test does not contain any search box or does

not have the search functionality in its services.

Based on these verdicts and the three above men-

tioned use cases, we deﬁne other verdicts as it fol-

lows:

• When entering “search term” in the search box of

the webpage under test, “search term” has to ap-

pear into the targeted search box, if not, we deliver

the verdict fail.

• The targeted search box has to accept any type of

query as input (number, text, special characters,

etc.). If not, we deliver the verdict error.

• We do not consider webpages where there

are condition/limit/boundary/criteria for the input

search (case 3 as described above). In this case,

we deliver the verdict error.

• If a website requires more than a step rather than

type search term (case 3), we deliver the verdict

error.

• A website has to provide the response for the

search term. If an answer belonging to the class

“no result found or nothing found” is returned, we

deliver the verdict pass.

5.2 Experiments Setup

In the experiment phase, we test our framework on the

dataset as described in Section 5.3.1.

Testbed.

• OS: x86-64 Microsoft Windows 10 Pro, version

10.0.18363, Build 18363

• Processor: Intel Core i7-7500U CPU @

2.70GHzx2

• Memory: 16GB

• SSD: 512GB

• Dataset:

– Metadata: 1.3 Mb in csv format. 1000 rows x 7

columns

– Training set: 70% metadata in npy format

(numpy array)

– Test set: 20% metadata in npy format (numpy

array).

From this training dataset, our tool processed the

SVM model in average 7 minutes using the de-

pendencies below mentioned.

• Browsers are detailed in the Table 1

Table 1: Browser Version.

Chrome 78.0.3904.70 (64-bit)

Firefox 70.0 (64-bit)

Opera 76.0.3809.132

Internet Explorer 11.418.18362

Microsoft Edge 44.18362.387.0 Build 18362

Project Tools.

In order to run the experiments, we setup our system

environment as in the following:

• Python 3.6.8,

• Dependencies: Keras/Tensorﬂow, scikit-learn:

core platform to analyse/process data and training

SVM model,

• Libraries: Selenium, Request HTTP, Beautiful

Soup, LXML,

• Jupyter Notebook App: online web-based plat-

form to visualize the data.

Codeless Web Testing using Selenium and Machine Learning

5.3 Results and Discussions

5.3.1 Automation Testing against Multiple

Websites

To evaluate the efﬁciency of our framework, we con-

ducted the tests using a generic test case through 1000

websites chosen randomly on the list of Alexa de-

scribed above. First, the learning approach has been

processed. A sample of raw data with 10 features has

been scraped (Fig. 9).

Figure 9: Sample of raw data.

The preprocessing phase and speciﬁcally the

cleaning step allowed to obtain the seven features and

one thousand lines of our training dataset. An illus-

tration of these lines are presented in the Fig. 10.

Figure 10: Training dataset sample.

Our testing search functionality has been imple-

mented in Selenium, the testing results are showed in

the table below (Table 2).

Table 2: Testing against 1000 web sites.

Pass Fail Error

Chrome 48% 18% 34%

Firefox 57% 16% 27%

Opera 47% 12% 41%

Internet Explorer 9% 19% 72%

Microsoft Edge 17% 19% 64%

First, we may be surprised by the number of fail

and error verdicts. Nevertheless, the high percentage

of results getting error does not mean that our frame-

work is defective. After analysis, we noted that it is

due to the fact that we did the test on 1000 websites

chosen randomly. Therefore, there are websites that

do not have the search functionality. From Table 2,

we can see that Internet Explorer and Microsoft Edge

perform the worst. It makes sense since Microsoft

has stopped support for Internet Explorer. Microsoft

Edge is replaced as the main and fast browser for the

Windows OS. However, the Selenium Webdriver for

Microsoft Edge is not fully supported and still under

development. We encountered that Internet Explorer

and Microsoft Edge crashed when testing more than

20 websites concurrently.

Figure 11: Automation testing against multiple web sites.

Through our experimental results for automation

testing the search functionality showed in Figure 11,

Firefox performs the best in terms of pass cases.

Chrome is the best browser to handle the verdicts er-

ror. We experienced that Chrome is a good choice

when testing the websites which are rendered heavily

with JavaScript, while Firefox still suffers for those

sites. Opera is fairly good in our test. We were also

surprise with the performance of Opera considered

that it is not as popular as Chrome and Firefox.

5.3.2 Testing with Extension (Add-on)

During our experiments, we noticed that our tests

were interrupted if a pop-up windows suddenly ap-

pears during the test. The pop-up can be of any type

(advertisement, data privacy, etc.) but the main met

one was the pop-up which requires to accept the term

and privacy when browsing the website as seen in Fig-

ure 12. Without clicking the accept button, there is no

way to browse the website further. Considering that

the test is running automated under Selenium code,

there is no interference by manual hand to click the

accept button. Therefore, the tests were most of the

time broken when facing with pop-up windows.

In order to solve this problem, we decided to add

a blocking pop-up extension to the browsers. This led

to a trade-off, adding this extension allows to test pop-

up websites, but in return, the test speeds decreased.

The reason is that we modiﬁed our Selenium scripts

in order to detect such pop-up windows and then to

add such an extension when it occurs. Therefore, the

webdriver had to trigger automatically the extension

ICSOFT 2020 - 15th International Conference on Software Technologies

Figure 12: Pop-up blocks the browser in Yahoo website.

in the targeted browser, reducing at the same time the

performance of our tests (in terms of response time -

obtained verdicts).

For the experiments, we chose two extensions be-

low due to their efﬁciency in blocking pop-up win-

dows, there are more than 10 millions users using

those extensions:

• Ublock: (ubl, 2020) is a free and open-source,

cross-platform browser extension for content-

ﬁltering, including ad-blocking.

• I dont care about cookie: (Kladnik, 2020) This

browser extension removes cookie warnings from

almost all websites and saves thousands of unnec-

essary clicks, very useful for our codeless testing

approach.

Since the above extensions are only fully supported

for Chrome and Firefox, the experiments in this sec-

tion were only run on these two browsers. The tests

were run on 20 random websites concurrently on each

browser in two modes: with extension and without ex-

tension. The Table 3 and Fig. 13 illustrate our results.

Table 3: Verdict results when testing with/without exten-

sions.

With Extension Without Extension

Pass Fail Error Pass Fail Error

Chrome 12 2 6 9 5 6

Firefox 11 3 6 9 5 6

Figure 13: Running time with extensions testing.

Within Table 3, we can note that using extension

to block the pop-up is very effective during the tests.

It helps to enhance the pass case and reduce the fail

one. However, the running time when executing the

tests with addons is reduced (Fig. 13). We also note

that Firefox is more efﬁcient than Chrome in terms

of time performance in both cases (with and without

extensions).

6 CONCLUSION AND

PERSPECTIVES

In this paper, we proposed a framework to test multi-

ple websites in an automation way. The approach is

able to use a generic test case to test a single func-

tionality through multiple websites by leveraging ma-

chine learning technique and selenium on web ele-

ment locators. Our technique can adapt dynamically

to the changes of the website. This framework called

“codeless testing automation” aims to help the tester

in reducing the time and efforts that are commonly

spent to change or modify the test codes. In our exper-

iments, we focus on testing the search functionality of

a web service. The test scenario is the following: us-

ing our framework, without modify the test code, the

framework must be able to test the search functional-

ity of multiple websites. Note that the categorization

of websites is not a matter, the framework enable to

check with any website. From the experiments, the

results show that our framework can be efﬁcient to

perform the automation testing with most of standard

websites by using the generic test case without rewrit-

ing the test code into Selenium.

From this work, we intend several perspectives.

First, we have to tackle all the use cases mentioned

in our paper and in particular the third case in which

constraints are given on the search functionality. Fur-

thermore, we aim at testing several behaviors at the

same time. This aspect will need another testing ar-

chitecture to consider the huge amount of data needed

to be trained and analysed through our framework.

Besides, we expect to propose APIs and generic test

scripts to the community in order to assess our tech-

nique on diverse functional tests. This is will lead to

interesting and relevant comparisons with other ap-

proaches. Finally, other learning techniques such as

neural based mechanisms are studied.

REFERENCES

(2020). Selenium webdriver document. https:

//selenium-python.readthedocs.io/locating-elements.

Codeless Web Testing using Selenium and Machine Learning

html. Accessed: 2020-04-02.

(2020). Ublock blocking popup extension. https://github.

com/gorhill/uBlock. Accessed: 2020-04-02.

Ameur-Boulifa, R., Cavalli, A. R., and Maag, S. (2019).

Verifying complex software control systems from test

objectives: Application to the ETCS system. In Pro-

ceedings of the 14th International Conference on Soft-

ware Technologies, ICSOFT 2019, Prague, Czech Re-

public, July 26-28, 2019, pages 397–406.

Arkadyev, A. (2017). Codeless system and tool for testing

applications. US Patent 9,697,110.

Brueckmann, T., Gruhn, V., Koop, W., Ollesch, J., Pradel,

L., Wessling, F., and Benner-Wickner, M. (2017).

Codeless engineering of service mashups-an experi-

ence report. In 2017 IEEE International Conference

on Services Computing (SCC), pages 402–409. IEEE.

Enlyft (2020). Companies using selenium. https://enlyft.

com/tech/products/selenium. Accessed: 2020-04-02.

Helme, S. (2020). List of top one million websites on alexa

ranking. https://crawler.ninja/ﬁles/https-sites.txt. Ac-

cessed: 2020-04-02.

Heusser, M. and Kulkarni, G. (2018). How to reduce the

cost of software testing. CRC Press.

Hynninen, T., Kasurinen, J., Knutas, A., and Taipale, O.

(2018). Software testing: Survey of the industry prac-

tices. In 2018 41st International Convention on In-

formation and Communication Technology, Electron-

ics and Microelectronics (MIPRO), pages 1449–1454.

IEEE.

Isha, A. S. and Revathi, M. (2019). Automated api testing.

International Journal of Engineering Science, 20826.

Jain, V. and Rajnish, K. (2018). Comparative study of soft-

ware automation testing tools: Openscript and sele-

nium. Int. Journal of Engineering Research and Ap-

plication, 8(2):29–33.

Joshi, N. (2016). Survey of rapid software testing using

machine learning. International Journal of Trend in

Research and Development.

Kassab, M., DeFranco, J. F., and Laplante, P. A. (2017).

Software testing: The state of the practice. IEEE Soft-

ware, 34(5):46–52.

Kladnik, D. (2020). Idontcareaboutcookie blocking popup

extention. https://www.i-dont-care-about-cookies.

eu/. Accessed: 2020-04-02.

LXML (2020). Lxml toolkit. https://lxml.de/. Accessed:

2020-04-02.

Nguyen, D. M., Do, H. N., Huynh, Q. T., Vo, D. T., and

Ha, N.-H. (2018). Shinobi: A novel approach for

context-driven testing (cdt) using heuristics and ma-

chine learning for web applications: An analysis of

chemosensory afferents and the projection pattern in

the central nervous system. In Topographic Organiza-

tion of the Pectine Neuropils in Scorpions. INISCOM.

Patel, M., Patel, M., et al. (2016). Survey paper on analysis

of xaas. International Journal For Research In Ad-

vanced Computer Science And Engineering, 2(2):13–

18.

Pypi (2020). Request library. https://pypi.org/project/

requests/2.7.0/. Accessed: 2020-04-02.

Raulamo-Jurvanen, P., Hosio, S., and M

antyl

a, M. V.

(2019). Practitioner evaluations on software testing

tools. In Proceedings of the Evaluation and Assess-

ment on Software Engineering, pages 57–66.

Richardson, L. (2020). Beautiful soup documentation.

https://www.crummy.com/software/BeautifulSoup/.

Accessed: 2020-04-02.

RJ Bhojan, K Vivekanandan, R. G. (2019). A machine

learning based approach for detecting non- determin-

istic tests and its analysis in mobile application test-

ing. International Journal of Advanced Research in

Computer Science.

Rosenfeld, A., Kardashov, O., and Zang, O. (2018).

Automation of android applications functional test-

ing using machine learning activities classiﬁcation.

IEEE/ACM 5th International Conference on Mobile

Software Engineering and Systems (MOBILESoft).

Selenium (2020). Selenium automates browsers. https://

selenium.dev/. Accessed: 2020-04-02.

Shariff, S. M., Li, H., Bezemer, C.-P., Hassan, A. E.,

Nguyen, T. H., and Flora, P. (2019). Improving the

testing efﬁciency of selenium-based load tests. In

2019 IEEE/ACM 14th International Workshop on Au-

tomation of Software Test (AST), pages 14–20. IEEE.

Vapnik, V. N. and Vapnik, V. (1998). Statistical learning

theory, volume 1. Wiley New York.

ICSOFT 2020 - 15th International Conference on Software Technologies
