Metrics-driven DevSecOps

Wissam Mallouli

1 a

, Ana Rosa Cavalli

1,2 b

, Alessandra Bagnato

3 c

and Edgardo Montes de Oca

1 d

Montimage EURL, Paris, France

SAMOVAR, Telecom SudParis, Institut Polytechnique Paris, France

SOFTEAM, Paris, France

Keywords:

Continuous Measurements, DevOps, Security, Feedback Loop, Software Quality, Automation.

Abstract:

Due to the modern iterative development practices and new automated software engineering tools and methods

brought by the DevOps agile method, the traditional metrics and evaluation methods are not enough to ensure

software security. Besides, the recent years have seen probably the most continuous and extreme software

security attacks ever recorded against organizations in an assortment of enterprises. Security is presently a

vast range, critical for business achievement. The existing metrics must be redeﬁned, and new security metrics

should be determined based on multiple measures to increase the reliability of the values. Due to the short

cycles of iterative processes in DevOps method, the feedback must come quickly, so the measurement should

be automated and continuous. Due to the massive amount of information, the results must be visualized at a

suitable level of abstraction, which may be different for the various stakeholders. In this paper, we propose a

unique Metric-driven approach to help improve the software engineering processes by increasing the quality,

adaptability and security of software and decreasing costs and time-to-market.

1 INTRODUCTION

The current cybersecurity landscape has evolved to

the point that companies are facing increasingly so-

phisticated attacks (Tounsi and Rais, 2018), more and

more adapted to their speciﬁc products, targeting all

security measures across the application’s software

stack. At the same time, companies are faced with the

need to deliver products to the market at an increas-

ingly rapid rate and to adapt to new customer needs

and requirements. As such, many businesses must

ﬁnd a difﬁcult balance between the speed of software

delivery, dictated by the market they are part of, and

the need to invest effort and time to ensure that each

iteration of their product is hardened from a cyberse-

curity perspective.

The need to deliver software products in a fast

but still controlled and reliable manner has led to

the growth of DevOps teams in most large soft-

ware companies. However, since continuous delivery

must be integrated into security, the DevOps teams

https://orcid.org/0000-0003-2548-6628

https://orcid.org/0000-0003-2586-9071

https://orcid.org/0000-0003-2675-0953

https://orcid.org/0000-0001-6771-0689

have evolved to DevSecOps (Myrbakken and Pala-

cios, 2017). As such, the tool chain used by teams to

automatically test, prepare for deployment and deliver

a software product to the market has been changed to

include security controls. Each step of a software de-

ployment pipeline should, to date, include a series of

controls that ensure that the delivered product passes

a series of security requirements designed to prevent

malicious actors from exploiting them, or at the very

least, to alert all concerned parties when any security

breach occurs.

It is certainly necessary to include security con-

trols as part of the DevOps process, but what is more

important is to ensure that they are appropriate and

relevant for the system deployed. In most cases, De-

vSecOps teams must manually deﬁne the controls to

include in their process. The use of knowledge spe-

ciﬁc to an expert domain in this decision-making pro-

cess adds value, since the controls and validations

implemented are intended to prevent or alert against

the exploitation of known vulnerabilities. However,

the metrics measured to guarantee security (Medeiros

et al., 2017) are, in most cases, standard measures

intended to protect the application against known

threats.

228

Mallouli, W., Cavalli, A., Bagnato, A. and Montes de Oca, E.

Metrics-driven DevSecOps.

DOI: 10.5220/0009889602280233

In Proceedings of the 15th International Conference on Software Technologies (ICSOFT 2020), pages 228-233

ISBN: 978-989-758-443-5

This leads to software applications not protected

against the so-called ”unknown threats” - previously

unknown vulnerabilities which, when exploited, can

lead to problems ranging from loss of system services

to more serious cases such as data leaks. As such,

there is a clear gap that needs to be ﬁlled - develop a

way to discover the metrics that need to be monitored

in the DevSecOps pipeline in order to prevent or alert

when the system behaves in a non-expected manner,

indicating possible security issues.

In this paper, we propose a unique Metric-driven

approach to improve software engineering processes

by increasing the quality, adaptability and security of

software and decreasing costs and time-to-market by:

• Deﬁning innovative metrics and developing meth-

ods and tools for measurement of software engi-

neering activities and artefacts, focusing on secu-

rity, privacy and robustness related metrics, that

will be adopted during the complete software life-

cycle.

• Developing Machine Learning and Ariﬁcial In-

telligence (ML/AI) based methods and tools for

analysing real-time data produced by the continu-

ous measurement to enable increasing trust, secu-

rity, and reliability, while at the same time main-

taining the necessary system performance and en-

ergy savings.

• Supporting decision-makers by visualising the re-

sults of continuous measurement at targeted level

of abstraction, i.e. providing different visualisa-

tions for developers, operators, security experts,

managers and other stakeholders. This includes

providing clear and actionable recommendations

for continuous security assurance.

• Proposing an agile development process (i.e. De-

vSecOps) that relies on the developed metrics to

ensure better reliability and resiliency of artefacts.

The rest of paper contextualises the proposed ap-

proach in Section 2, then it details the proposed

methodology and presents a concrete architecture of

such framework in section 3. Section 4 concludes this

paper.

2 CONTEXT AND MOTIVATION

2.1 Metric-driven Software Engineering

Measuring has become a fundamental aspect of soft-

ware engineering (Bagnato et al., 2017). Accurate

measurement is proving to be highly effective in var-

ious domains. For example, measurement is vital

for the provision of high quality decision-support and

prediction systems, in the context of improving soft-

ware development and maintenance. Furthermore, ac-

curate measurement is required for the evaluation and

enforcement of a system’s quality (by highlighting

problematic areas), and in the determination of better

work practices with the aim of assisting practitioners

and researchers in their work.

Software Measurement needs tools that assist in

the evaluation and industrialisation of Software Pro-

cess Improvement in the organizations that develop

them. Software Measurement is, in fact, a key ele-

ment in initiatives such as SW-CMM (Capability Ma-

turity Model for Software), ISO/IEC 15504 (SPICE,

Software Process Improvement and Capability deter-

mination) and CMMI (Capability Maturity Model In-

tegration). The ISO/IEC 90003:2004 standard also

highlights the importance of measurements in man-

aging and guaranteeing quality.

There exist various methods and standards con-

cerning how to carry out measurements in a precise

and systematic manner, of which the most representa-

tive are:

• Goal Question Metric (GQM): the basic princi-

ple of GQM is that measurement must always

be oriented towards an objective. GQM deﬁnes

an objective, reﬁnes that objective into questions

and deﬁnes the measures which attempt to answer

those questions (Koziolek, 2005).

• Practical Software Measurement (PSM): the PSM

methodology is based on the experience obtained

from organizations on the manner in which to best

implement a software measurement program with

guarantees of success (Card, 2003).

• ISO/IEC 15939: this international standard iden-

tiﬁes the activities and tasks which are necessary

to successfully identify, deﬁne, select, apply and

improve software measurement within a general

project or within a business’s measurement struc-

ture.

In addition, the availability of a formal description

language that allows representing the elements which

must be taken into account by the measurement pro-

cess can be considered as important in the decision

making and process improvement.

2.2 Cybersecurity Related Risks

The recent years have seen probably the most con-

tinuous and extreme software security attacks ever

recorded against organizations targeting different

kinds of enterprises. Security has become critical for

business achievement and shown the importance of

Metrics-driven DevSecOps

229

safety and risk management for dealing with the pro-

tection of a company from destructive cyber-attacks

and implementing more and more strict regulations.

Thus, assessing the trustworthiness of a software from

its early stages in its development lifecycle becomes

a must. Many security metrics and indicators, have

been identiﬁed and implemented in several security

tools from requirements to operations. However, a

global view of security practices are not always avail-

able for product owners, developers, operators, man-

agers and other stakeholders (Casola et al., 2017).

2.3 DevOps Agile Process

Today, DevOps is a concept that is gaining serious

traction within organizations – large to small – try-

ing to bridge the gap between development and oper-

ations. DevOps outlines a cyclic approach to various

stages of the software development lifecycle such as

conception, test and deployment of software artefacts.

Speciﬁc tools are used in every stage of the DevOps

cycle to improve the ﬁnal outcome. DevOps is cen-

tred on two core principles, automation and continu-

ous improvement, and has become a crucial part of

software development.

Nowadays, real-time integration, deployment, and

monitoring of applications is a necessity where as-

sessment and feedback are the foundations and em-

bedded in every step. It forms a series of feedback

loops that provide immediate insight and response to

each preceding step in the process and delivers feed-

back from customers and users into the application’s

business value. This automatic and continuous feed-

back process is referred to as Continuous Assessment.

By integrating security in DevOps, the main pur-

pose is to build on the mindset that ”everyone is re-

sponsible for security”. The goal is to distribute se-

curity decisions with speed and at a scale required so

that those that can act can do so with out sacriﬁcing

other factors of the business process.

With an increased business demand for DevOps,

agile and cloud services, traditional security pro-

cesses have become a major roadblock that some-

times needs to be bypassed all together. Traditional

security operates from the position that once a system

has been designed, its security defects can determined

by the security staff and corrected by the business op-

erators before the system is released. This required

a limited amount of security skills for producing the

outcomes and avoided the need to expand the secu-

rity context of larger systems. But a process designed

this way only work when the business activities are

organised as a waterfall with agreement among all in-

volved parties. Unfortunately, the belief that security

must operate this way is ﬂawed with the introduction

of iteration, creating inherent risks within the system

due to the lack of coordination and cooperation.

In this paper, we target to answer these challenges

by introducing a new Metrics-driven DevOps method-

ology (Forsgren and Kersten, 2018) that allows to

continuously check the quality of a software from de-

sign to operation by gathering different metrics from

different software artifacts. A speciﬁc focus on trust-

worthiness related metrics is performed to ensure re-

liable and resilient products.

3 METRICS-DRIVEN DevSecOps

METHODS

The proposed architecture is based on the state-of-the-

art architecture derived from two projects, in particu-

lar from ITEA3’s MEASURE project

and H2020’s

MUSA Project

The solution (represented in Figure 1) is built

on a centralized platform dedicated for measuring,

analysing, and visualising metrics (mainly quality and

trustworthiness metrics) to extract and derive infor-

mation concerning the software engineering process

(Dahab et al., 2019). This platform:

• Implements methodologies and tools to automat-

ically measure software engineering processes

during the whole software lifecycle by execut-

ing measures deﬁned using the SMM (Structured

Metrics Metamodel) standard and extracted from

a catalogue of formal and platform-independent

measurements;

• Provides methodologies and tools which allow

developing a catalogue of formal and platform-

independent measures with a speciﬁc focus on

trustworthiness;

• Integrates a storage solution for storing and pro-

cessing measurements obtained by capturing met-

rics in a big data context;

• Relies on the visualization tools to expose the ex-

tract results in an easy-to-read fashion, so allow-

ing a quick understanding of the situation to de-

termine the possible actions that can be taken to

improve the diverse stages of the software lifecy-

cle.

• Includes an open API facilitating the integration

of the measurement platform with external tools

and services including other measuring and anal-

ysis tools.

https://itea3.org/project/measure.html

https://www.musa-project.eu/

ICSOFT 2020 - 15th International Conference on Software Technologies

230

Figure 1: The Metrics-Driven DevSecOps Architecture.

The platform activity is organized around its abil-

ity to collect measurement by executing measures

deﬁned by the SMM standard. SMM measures

are auto-executable components, implemented exter-

nally, which can be interrogated by the platform to

collect measurements.

The Metrics-Driven DevSecOps presented in this

paper consists of deﬁning metrics and its support-

ing tools for measuring modern software engineer-

ing activities with respect to trustworthiness, energy

efﬁciency and quality. The measurement process

needs to be automated in order to reduce the devel-

opment time. This can help the DevOps team dur-

ing their decision-making. The measuring methods

and tools rely on predictive and reactive security en-

ablers that can be applied during the development

and operation phases. These enablers include: se-

curity requirements speciﬁcation, secure modelling

(i.e. security-by-design), secure coding, vulnerability

scanning, static and dynamic code analysis, contin-

uous risk analysis, intrusion and anomaly detection,

root cause analysis, and the application of resilience

mechanisms at the design (called remediation mech-

anisms) or at the operation (called countermeasures)

phases.

3.1 Measure Catalogue

The measures rely on an extension of SMM (Struc-

tured Metrics Meta-model) format, an OMG Stan-

dard. A “collect and compute component” provides

services to register a “Metric” deﬁned in speciﬁc ex-

ecutable format derived from the SMM standard us-

ing a communication API. Registered measures are

stored in the Measure Catalogue

. Once registered,

the measure catalogue allows the platform to access:

the measure’s meta-data that contains the informa-

tion required to identify the measure (i.e. an unique

id); the measure’s type (e.g. Direct Measures, Col-

lective Measures, Binary Measures); the information

on the measure’s implementation, which is the format

of data returned by the measure (i.e. Unit) and a list

of conﬁguration points provided by the measure (i.e.

Scope).

3.2 Measure Conﬁguration and

Instances

A Measure is composed of a set of meta-data associ-

ated with an implementation and represents a generic

data collection algorithm that has to be instantiated

and conﬁgured to be applied on a speciﬁc context.

Consequently, in order to be executed by the platform,

it’s required to deﬁne an instance of a registered mea-

sure that ﬁlls the conﬁguration values described in the

measure’s meta-data. As an example, a measure in-

stance contains:

• An identiﬁer for the measure instance.

• Information related to the collection cycle of the

measurement; in other words, when and in what

interval a measurement is to be collected.

Examples of metrics can be found following this link:

https://github.com/ITEA3-Measure/Measures/wiki

Metrics-driven DevSecOps

231

• Information required for identifying the measured

system (i.e. conﬁguration values).

• Information related to the required measure input

and output for a Derived Measure.

• Information related to the data structure returned

by the measure.

Once instantiated, the data related to the measure in-

stances are stored in a centralized database.

3.3 Collecting Measures using the SMM

Engine Measuring Tools

The SMM standard deﬁnes two main types of mea-

sures: (1) the direct measures, which are measures

collected from the physical world, and (2) calculated

measures (e.g. Collective Measures and Binary Mea-

sures), which are measures derived from the direct

measures.

• Direct Measure Collecting. The SMM engine will

invoke the implementation of the direct measure

after having communicated to it the conﬁguration

parameters deﬁned by the measure instantiation.

• Derived Measure Calculation. Using pre-

existent measurements stored in the measurement

database and from direct measures, the SMM En-

gine will provide services to calculate the derived

measures.

The SMM Engine provides services to execute mea-

sures. The execution of a measure can be triggered

manually or can be scheduled and repeated over time.

In the second case, the SMM Engine uses a speciﬁc

scheduling component to organise the executions of

measures. Once collected or calculated, the SMM

engine stores the resulting measurements in the mea-

surement database.

3.4 Measurement Storage

Collected and calculated measurements are to be

stored in a database for future exploitation by the

analysis tools. In this context, it is necessary to deal

with a very large quantity of data. Furthermore, due

to the nature of the measures, ﬂexibility related to

the nature of the data to store in this database is also

needed. In fact, it should not be necessary to make hy-

pothesis on the nature of the measurements returned

by the measurement tools. A measurement can be a

simple value or a complex and structured data. Elastic

Search can be a good candidate to perform this task.

3.5 Analysis Tool and Decision Support

The primary goal of the analysis is to provide a work-

ing environment driven by measures that can help

managers during their decision-making process. It

implements analytic algorithms, to correlate the dif-

ferent phases of software development and to perform

the tracking of metrics and their values. The plat-

form also connects and assures the interoperability

among the tools and deﬁnes actions for improvement

and possible countermeasures. The analysis tools pro-

vide a way to display graphical representations of

the measured information as graphics and produce re-

ports by deﬁning and organizing several dashboards.

Each dashboard presenting a selected pool of mea-

sures using graphics, tables and/or speciﬁc indicators.

The main services offered by this component are:

• Provide a web application which allows the De-

vOps team (including the product owner and the

project manager) to organise and conﬁgure mea-

sures computation.

• Provide a web application which will be able to

present measures execution results and measure-

ments as customisable charts.

• Allow organising these charts with respect to

projects, phases and dashboards, in order to fa-

cilitate modern iterative development practices.

• Integrate consolidated results provided by the

analysis tools.

One of the approach’s innovation consists in

analysing measurement results for identifying what

and how to automatically improve the software qual-

ity or the software engineering process quality. Such

highly automated and easy-to-deploy solution can be

considered a breakthrough solution, as current tools

only support this type of approach with a very lim-

ited scope. The analysis of retrieved measurements

can rely on several algorithms for correlating them

and learning from previous experiences in similar de-

velopment projects. Machine learning (ML) and ar-

tiﬁcial intelligence (AI) can be used to perform clus-

tering, measurement plan scheduling, metrics predic-

tions and recommendations to the DevOps team in or-

der to react to any detected/predicted issues (Dahab

et al., 2019). As a concrete example, if we measure

that one detected risk was classiﬁed as low (e.g., data

breaches) and not mitigated at the design phase, but

during operation, we detect several attacks exploiting

the vulnerability resulting to this risk (data is exﬁl-

trated). A recommendation would be to activate a se-

curity control (e.g., protect data by encrypting it or by

using a secure communication channel).

ICSOFT 2020 - 15th International Conference on Software Technologies

232

4 CONCLUSIONS

The main objectives of Metrics-driven DevOps ap-

proch presented in this paper is to design and de-

velop a centralized platform provided as PaaS to be

deployed on the users premises or in a public/private

cloud for building trustworthy software that rapidly

adapts to changing requirements while maintaining

key qualities indicators (e.g. reliability, availability,

performance, security, privacy). This platform gath-

ers measurements from the different software devel-

opment lifecycle phases and during the production

in order to detect/predict potential issues and pre-

vent them. This veriﬁcation relies on different soft-

ware engineering tools (like risk analysis, intrusion

and anomaly detection etc.) and allows providing real

time recommendations to the DevOps team to im-

prove the security/privacy of their software as well as

resiliency. Different ready-to-deploy security mecha-

nisms are needed to support such a platform.

ACKNOWLEDGEMENTS

This work is partially funded by the ongoing Euro-

pean project ITEA3-MEASURE started in Dec. 1st,

2015 (https://itea3.org/project/measure.html), and the

H2020 ENACT project started in Jan. 1st, 2018

(https://www.enact-project.eu/).

REFERENCES

Bagnato, A., Sadovykh, A., Dahab, S., Maag, S., Cavalli,

A. R., Stefanescu, A., Rocheteau, J., Mallouli, S., and

Mallouli, W. (2017). Modeling OMG SMM metrics

using the Modelio modeling tool in the MEASURE

project. G

enie logiciel, (120):46 – 52.

Card, D. N. (2003). Practical software measurement. In

Clarke, L. A., Dillon, L., and Tichy, W. F., edi-

tors, Proceedings of the 25th International Conference

on Software Engineering, May 3-10, 2003, Portland,

Oregon, USA, pages 738–739. IEEE Computer Soci-

ety.

Casola, V., Benedictis, A. D., Rak, M., and Villano, U.

(2017). A security metric catalogue for cloud applica-

tions. In Barolli, L. and Terzo, O., editors, Complex,

Intelligent, and Software Intensive Systems - Proceed-

ings of the 11th International Conference on Complex,

Intelligent, and Software Intensive Systems (CISIS-

2017), Torino, Italy, July 10-12, 2017, volume 611

of Advances in Intelligent Systems and Computing,

pages 854–863. Springer.

Dahab, S., Maag, S., Mallouli, W., and Cavalli, A. (2019).

Smart measurements and analysis for software quality

enhancement. In van Sinderen, M. and Maciaszek,

L. A., editors, Software Technologies, pages 194–219,

Cham. Springer International Publishing.

Forsgren, N. and Kersten, M. (2018). Devops metrics. Com-

mun. ACM, 61(4):44–48.

Koziolek, H. (2005). Goal, question, metric. In Eusgeld,

I., Freiling, F. C., and Reussner, R. H., editors, De-

pendability Metrics: Advanced Lectures [result from

a Dagstuhl seminar, October 30 - November 1, 2005],

volume 4909 of Lecture Notes in Computer Science,

pages 39–42. Springer.

Medeiros, N. P. D. S., Ivaki, N., Costa, P., and Vieira,

M. (2017). Software metrics as indicators of secu-

rity vulnerabilities. In 28th IEEE International Sym-

posium on Software Reliability Engineering, ISSRE

2017, Toulouse, France, October 23-26, 2017, pages

216–227. IEEE Computer Society.

Myrbakken, H. and Palacios, R. C. (2017). Devsecops: A

multivocal literature review. In Mas, A., Mesquida,

A. L., O’Connor, R. V., Rout, T., and Dorling, A.,

editors, Software Process Improvement and Capabil-

ity Determination - 17th International Conference,

SPICE 2017, Palma de Mallorca, Spain, October 4-5,

2017, Proceedings, volume 770 of Communications

in Computer and Information Science, pages 17–29.

Springer.

Tounsi, W. and Rais, H. (2018). A survey on technical threat

intelligence in the age of sophisticated cyber attacks.

Comput. Secur., 72:212–233.

Metrics-driven DevSecOps

233
