Who Stores the Private Key? An Exploratory Study about User

Preferences of Key Management for Blockchain-based Applications

Clemens Brunner

, G

unther Eibl

, Peter Fr

ohlich

, Andreas Sackl

and Dominik Engel

Center for Secure Energy Informatics, Salzburg University of Applied Sciences, Salzburg, Austria

AIT, Austrian Institute of Technology, Vienna, Austria

Keywords:

Blockchain, Trust, Key Management, User Study.

Abstract:

Applications based on blockchain technology have become popular. While these applications have clear ben-

eﬁts, users are not yet familiar with their usage, which could hinder further applications of this technology. In

this paper, an online survey with 110 potential users, as a representative of an average citizen, was conducted.

The focus of this survey is to explore their preferences concerning the interaction with blockchain-based ap-

plications by mainly focusing on how to handle private keys. To best of our knowledge this is the ﬁrst study

where average citizens are asked about the preferred management of a private key, which is necessary when

interacting with blockchain-based applications. One of the main results was that about 80% of the participants

would like to have the beneﬁt of data sovereignty despite the cost of being fully responsible to backup their

credentials.

1 INTRODUCTION

Blockchains or distributed ledgers create a globally

unique decentralized database managed without a

central trusted third party. Blockchains have been

suggested as the underlying technology for a large

number of use cases. However, while blockchain con-

cepts (Nakamoto, 2008; Wood, 2017) and applica-

tions based on this technology (Madhusudan et al.,

2019; Sovrin Foundation, 2018) have received a high

level of attention in the scholarly, business and even

political arena, users are not familiar with the optimal

ways to interact with this technology.

Making blockchains accessible to users should es-

sentially start with secure and understandable authen-

tication mechanisms. In the context of blockchain

technology, this is even more the case.

Despite its beneﬁts of offering more sovereignty

through less dependability from a central intermedi-

ary, a decentralized blockchain approach has a main

drawback: The private key needs to be stored securely

by the users themselves. Only the owner of the private

key has full control over the attached data, e.g., cryp-

tographic coins in case of bitcoin.

In case the private key gets lost or compromised,

this can result in a full loss. So far, there is lit-

tle knowledge on users’ attitudes towards the related

beneﬁts and risks. In this paper, conceptual vari-

ants of private key management and password backup

for different decentralized, blockchain-based applica-

tions are explored and assessed regarding their accep-

tance by users. An online-survey was conducted in

which participants can qualify different ways of key

management which are varied by backup responsibil-

ity, application area, and key storage methods.

The rest of the paper is structured as follows. In

Section 2 a description of (de)central controlled ap-

plications, possible use cases of decentralized appli-

cations and different variants to allocate the backup

responsibility of the private key are described. The re-

search questions are presented in Section 3. Section 4

describes the method for the questionnaire. The re-

sults are presented in Section 5 and discussed in Sec-

tion 6. Finally, a conclusion is provided in Section 7.

2 BACKGROUND AND RELATED

WORK

In this section, the process of authentication of users

in centrally controlled application, blockchain-based

applications, use cases for blockchain-based applica-

tions and different variants for managing the backup

responsibility for the private key are described. Please

note, that the management of a private key is usually

Brunner, C., Eibl, G., Fröhlich, P., Sackl, A. and Engel, D.

Who Stores the Private Key? An Exploratory Study about User Preferences of Key Management for Blockchain-based Applications.

DOI: 10.5220/0010173200230032

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 23-32

ISBN: 978-989-758-491-6

 2021 by SCITEPRESS – Science and Technology Publications, Lda. All r ights reserved

done by a software without the knowledge of the end

users or by experts. In blockchain-based applications

the management of the private key should be done by

the end users, in order to be in full control of the data.

2.1 Centrally Controlled Applications

In this paper, “centrally controlled applications” are

deﬁned as all kinds of application, which are hosted

or controlled by one organization. The identiﬁcation

of a user is done by, e.g., a username and/or and

email address. The most common way to perform

the authentication of users is by a password, which

is linked to the user’s identiﬁer. A salted hash of

the password is stored on the application controllers’

server (Gauravaram, 2012). The veriﬁcation of the

password is performed by the application owner. If

the user provides the correct password, the applica-

tion owner enables the user to access the application.

There are several ways to reset a password, e.g., con-

ﬁrming the email address or answering control ques-

tions. If the user provides enough evidence for the

application owner to conﬁrm the user’s identity, the

application owner replaces the old password with a

new one. This password can then be used for future

authentication attempts. One downside of centrally

controlled applications is that the application owner

can modify, delete or change information attached to

users. Another downside is data availability, the ap-

plication owner can decide to stop the application and

delete all information, anytime. In this case, all users

will lose their data.

2.2 Blockchain-based Applications

Blockchains, ﬁrst proposed in (Nakamoto, 2008), are

decentralized append-only databases with a globally

consistent state. Transactions can be used to append

data and valid transactions trigger a new state transi-

tion, which results in a new globally consistent state.

Data in a blockchain is usually publicly and transpar-

ently available and replicated among all blockchain

nodes. Numerous variants of blockchains, e.g.,

(Nakamoto, 2008; Wood, 2017; Larimer, 2017) and

decentralized applications, e.g., (Fromknecht et al.,

2014; Madhusudan et al., 2019; Ben-Sasson et al.,

2014; Sovrin Foundation, 2018; Brunner et al., 2019;

ather et al., 2018) based on blockchains exists. In

the following, the difference of authentication and au-

thorization between centrally controlled applications,

e.g., online banking or Amazon, and decentralized ap-

plications is described.

In this paper, “decentralized applications” refers

to applications based on blockchain technology. Such

applications differ from centrally controlled applica-

tions in the way that the usage of passwords is not

possible, because no application owner exists, who

can conﬁrm the correctness of the password. Decen-

tralized applications which are based on blockchains

use asymmetric cryptography and represent users by

public/private key pairs. Users are then identiﬁed ei-

ther by their public key or an address (which is usu-

ally derived from the public key using a hash func-

tion). The authentication of users and their transac-

tions is done by a signature, created with the users’

private keys. The private key for each user is linked to

this user’s identiﬁer by cryptographic methods. The

veriﬁcation of the signature is done by all blockchain

nodes during the block validation process. There is

no way to reset a private key. If users lose their pri-

vate keys, the users have no way to add new data to

the blockchain or verify that data belongs to them.

Only the user has the possibility to prove owner-

ship, add or update data attached to the user’s iden-

tiﬁer by providing a signature created with the user’s

private key.

In order to avoid that a user is locked out of the

decentralized application, the user needs to backup

the private key. Most blockchain clients force users

to note a mnemonic

or the private key on paper be-

fore they can proceed. It is also possible to use, e.g.,

Shamir secret sharing (Shamir, 1979) for a secure dis-

tributed backup of the private key among trusted par-

ties. For this purpose, the private key is split into n

shares with a threshold t ≤ n. To reconstruct the pri-

vate key at least t of the shares are needed. There are

several ways to backup the private key, but in all cases

it requires additional (maybe unknown) action by the

user.

2.3 Use Cases of Blockchain-based

Applications

In the following, potential blockchain use cases,

based on (Kshetri, 2017; W

ust and Gervais, 2017) are

described. Due to the fact that there are always new

ideas for potential blockchain use cases, this is not an

exhaustive list, rather it should give the reader an idea

of potential use cases.

Digital Cash. Cryptocurrencies, e.g., (Nakamoto,

2008; Wood, 2017; Ben-Sasson et al., 2014) are

the most prominent use case for blockchain-based

applications.

A mnemonic is a sentence of a group of words and

is used in combination with a Key Derivation Functions

(KDF) to deterministically derive a private key.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

Supply Chain Management. The possibility to

avoid trusted third parties and the transparent

and decentralized way of managing paperwork

are reasons why blockchains were proposed to

be used for supply chain management (Apte and

Petrovsky, 2016; Francisco and Swanson, 2018).

Identity and Access Management. For authentica-

tion and authorization of identities, a blockchain

can be beneﬁcial in order to avoid a cen-

trally trusted party which controls those iden-

tities. This can support users’ self-sovereignty

and trustful decentralized authentication mecha-

nisms (Manohar and Briggs, 2018). uPort

and

(Sovrin Foundation, 2018; Al-Bassam, 2017) pro-

vide blockchain-based solutions for this use case.

IoT Security. There are numerous contributions,

e.g., (Christidis and Devetsikiotis, 2016; Won

et al., 2018; Madhusudan et al., 2019; Orman,

2018; Faber et al., 2019), which aim to improve

the security of IoT devices with blockchain-based

applications. For example, using blockchains, a

globally consistent and decentralized Public Key

Infrastructure (PKI) can be established.

Proof of Ownership. Similar to PKI, a blockchain-

based application can be used to proof ownership

of digital data. Additionally, since this data is

time-stamped, it is ordered. Veriﬁcation that a ﬁle

existed at a given point in time is used, e.g., by

MIT

and by (Gr

ather et al., 2018; Brunner, 2017;

Brunner et al., 2019) to issue diplomas.

Trading. Trading of all kind of assets is possible

with blockchain-based applications, such as en-

ergy trading (Mengelkamp et al., 2018; Knirsch

et al., 2019).

2.4 Assigning the Backup Responsibility

To use a decentralized application, the backup of the

private key is essential. There are several ways to

backup a private key, e.g., a note on paper, distribute

shares to trusted parties or storing it on the computer.

But in all these described cases, the user is responsi-

ble for the backup.

There also exist applications which provide an on-

line wallet. An online wallet is provided by a cen-

tral application owner to access decentralized applica-

tions. For example, Bitpanda

is an exchange service

for digital assets, such as bitcoin. In order to provide

a good user experience, they will backup and store the

https://uport.me [accessed: August 2020]

https://blockcerts.org [accessed: August 2020]

https://www.bitpanda.at [accessed: August 2020]

private keys of their users, which are represented by

a username and a password. Bitpanda interacts with

the decentralized application (bitcoin) in the name of

their users. Hence, the users can use, e.g., bitcoin,

without managing their own backup for their private

keys.

In the following, and also for the questionnaire,

two variants of using decentralized applications are

differentiated:

Direct Variant. In the direct variant, the users are

responsible for their own backup of their private

key. The users interact direct without an interme-

diary with the decentralized application.

Hybrid Variant. In the hybrid variant users are not

responsible for their backup, they will outsource

it to a third party, named as manager which is

contacted in the usual way using username and

password. There would be no change in usability

for users, when moving from the currently known

centrally owned applications to decentralized ap-

plications. This includes the property that if the

users forget their password to authenticate them-

selves to the manager, they can reset it. This

variant is termed hybrid, because a user uses a

blockchain-based application through a centrally-

controlled application. The manager acts as proxy

and interacts in the name of the user with the de-

centralized application. The private key is in the

hand of the manager.

2.5 Related Work

Authentication has been a serious challenge for sys-

tem usability and acceptance for a long time(Adams

and Sasse, 1999; Bonneau et al., 2012). In (Bon-

neau et al., 2012) an overview of alternatives to a

password for authentication are described and com-

pared. Since authentication for blockchain-based ap-

plications is only possible with digital signatures this

work focuses on the corresponding approach that uses

a private key which needs to be stored. In (Adams

and Sasse, 1999) a web-based questionnaire was con-

ducted to evaluate the users’ behaviors and percep-

tions relating to password systems. Password man-

agers and speciﬁc bitcoin clients have shown to pro-

vide more comfort for customers, but still exhibit un-

solved usability problems as described by (Chaudhary

et al., 2019). A review of previous studies on public

key authentication is presented in (Eskandari et al.,

2015). They summarize that the metaphor and termi-

nology behind public and private keys is often found

confusing and that key migration between devices is

regarded as difﬁcult.

Who Stores the Private Key? An Exploratory Study about User Preferences of Key Management for Blockchain-based Applications

Online studies are increasingly used in HCI re-

search. An overview of their advantages and disad-

vantages can be found in (Petralito, 2019). Advan-

tages over co-located lab-based data gathering meth-

ods are the typically quicker and cheaper conduction,

wider distribution of the participants sample, lower

hurdles of participation and lower infrastructure costs,

the convenient use of randomisation and features for

embedding multimedia.

To best of our knowledge no related questionnaire

exists which asks average users of blockchain-based

applications about preferences of managing their pri-

vate keys.

3 RESEARCH QUESTIONS

In this section, the research questions consisting of

four (three main and one exploratory) questions are

described in more detail.

RQ1. Which variant (direct, hybrid) for the key man-

agement will be preferred, depending on the ap-

plication area?

The main research question asks who should have the

responsibility for the backup of the private key and if

people are willing to transfer the responsibility to an

institution at the cost of also transferring control to

this institution.

RQ2. How does the application area and the institu-

tion inﬂuence the possible preference of the hy-

brid variant?

It is expected that the application area would highly

inﬂuence this preference. It was decided to choose

only three use cases from the application areas, de-

scribed in Section 2.3. The authors excluded cases

which require technical expertise on the topic like IoT

security and opted for the ones which are more com-

mon for the participants: proof of ownership (UC1:

management of diplomas or certiﬁcates), identity and

access management (UC2: management of passports)

and digital cash (UC3: management of money). For

the hybrid variant the possible managers were cho-

sen based on the following expectations: for diplomas

users might prefer the university, for ID document

users trust the government and for ﬁnancial transac-

tions users trust a bank. Therefore, the questionnaire

asks for the trust in all these institutions, plus an ex-

ternal company, for each of the three use cases above.

RQ3. Which method would users of the direct vari-

ant use to store their private key?

Here, it should be assessed, if users are aware of the

need to backup the private key reliably using, e.g.,

technical solutions like password managers or not.

RQ4. Which personal characteristics inﬂuence these

preferences?

The preference for different solutions is likely to de-

pend on user characteristics, which is expected to be

very diverse. Therefore, questions which address po-

tential user inﬂuences, e.g., the current behavior or

the technical knowledge are added. However, due to

the sample size only a ﬁrst, exploratory analysis was

planned in order to generate hypotheses, which per-

sonal characteristics and behavior inﬂuence the deci-

sions above.

4 METHOD

In order to address the research questions above, in

March 2019 an online-study was conducted

However, online studies also have often revealed

limitations, amongst which sample distortion, care-

lessness and insufﬁcient control of attention are the

most severe ones for the purpose of studies in user-

centered security (Petralito, 2019; Fahl, 2016). In or-

der to alleviate these drawbacks in our study, we con-

trolled the sample selection by commissioning a na-

tionally leading online panel provider. Furthermore,

we used a set of control questions in order to assess

the participants’ understanding of the presented con-

cepts, see Section 4.2.

Candidates from the whole country (Austria, Eu-

rope) were selected with regard to their compliance

with the main target participant proﬁle characteristics

representative spread of regions, age between 18 and

65, gender, and educational level. Overall, 110 par-

ticipants completed the survey. To generate represen-

tative results, the following characteristics were bal-

anced among the participants: sex, age, residence in

federal state and education level. The time to com-

plete the survey was targeted to be under ten min-

utes, in order to ensure a high attention and answering

quality level. Consequently, the questionnaire struc-

ture was kept comparably simple and short. The study

was executed using the online tool limesurvey

. The

participants received 5 EUR from the panel provider,

after the survey was successfully completed.

The survey was structured as follows: it starts

with a video that explains the research question. Due

to the rather restrictive time constraints, it was de-

cided that it should take no longer than three minutes.

The video is followed by four control questions that

Both the video and the questions are available at

https://www.en-trust.at/downloads/

https://www.limesurvey.org/de/ [accessed: August

2020]

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

check whether the participants understand the prob-

lem. Since the attention and memory of the video

content is expected to decrease with time, the main

research questions were asked directly after the con-

trol questions. Finally, possible inﬂuence factors were

assessed ending with the simplest ones, i.e., the demo-

graphic data.

4.1 Explanation Video

The questionnaire starts with a video that was pro-

duced speciﬁcally for this study using a professional

speaker and a video producer. In this video both the

direct and the hybrid approaches are described. Their

advantages and their disadvantages are explained both

visually and acoustically.

The video is created in a way that participants do

not need any prior knowledge. If possible, technical

concepts like asymmetric cryptography and the use

of key pairs are hidden or simpliﬁed. The private key

was named “access code” and illustrated with a key

symbol, see Figure 1, in order clearly distinguish it

from the username and password approach. There-

fore, in the following, the terms “private key” and “ac-

cess code” are used interchangeably. The language

of the video is German, English subtitles were added

later on

Figure 1: Screenshot of the explanation video for the ques-

tionnaire showing the differences between the direct and the

hybrid variant

The video is divided into six sections. The ﬁrst

section is an introduction about authentication and the

differences between an access code and a password.

The advantages and disadvantages of using a pass-

word are explained in the section centrally controlled

applications. After that, the use cases (UC1, UC2,

UC3) of decentralized applications are explained in

the decentralized applications section. The advan-

tages and disadvantages of the direct variant and the

hybrid variant for the backup responsibility of the ac-

cess code are explained in two sections. Finally, the

Video can be downloaded here https://www.en-

trust.at/downloads/

Icons made by Freepik, Smashicons, SimpleIcons,

Wanicon, Payungked, Geotatah, Recep Kutuk, Surang,

Smalllikeart, Zlatko Najdenovski from www.ﬂaticon.com

last part of the video provides a short summary in or-

der to increase the comprehensibility of the content.

The video ends with an invitation to imagine a future

where only decentralized applications exist that man-

age diplomas, passports and money.

4.2 Control Questions

The survey starts with the following four control

questions:

CQ1. Which variant lets me reset my password? (di-

rect - hybrid - don’t know)

CQ2. Which variant leaves me in full control of my

data? (direct - hybrid - don’t know)

CQ3. If I forget my access code using the direct vari-

ant, can I reset it? (yes - no - don’t know)

CQ4. Which variant leaves full control over my data

at my manager? (direct - hybrid - don’t know)

Since the chance to answer two questions correctly

is 25%, redundancy of the questions was introduced.

Therefore, the questionnaire includes questions about

the advantage of the variants (CQ1 and CQ2) and re-

dundantly at the corresponding disadvantages (CQ3

and CQ4).

4.3 Main Research Questions

To determine the favored storage mode for the pri-

vate key when using the direct variant (RQ3), the fol-

lowing options were proposed: note - save on paper -

password manager - computer - mobile phone - print

- email - share on facebook - other. Multiple answers

were possible. The analogous question was asked for

the password using the hybrid variant only for sake of

potentially needed sanity checks.

To answer RQ1 and RQ2, the participants had

to rate the following ﬁve possibilities for interact-

ing with a decentralized application for all three use

cases.

D. Direct

HC. Hybrid with an external company as manager

HU. Hybrid with the university as manager

HG. Hybrid with the government as manager

HB. Hybrid with the bank as manager

These ratings allow a comparison of the direct and

the hybrid variant (RQ1). For the hybrid variant one

can also determine the preferred managing institution

depending on the use case (RQ2).

Who Stores the Private Key? An Exploratory Study about User Preferences of Key Management for Blockchain-based Applications

4.4 Inﬂuence of Personal

Characteristics

In the next step of the questionnaire, the inﬂuence fac-

tors were assessed.

4.4.1 Questions of the Survey

Beside the usual demographic questions at the end,

ﬁve different groups of questions were considered to

be potentially important for the answers.

• Password-related

• Online behavior

• Technical knowledge

• Afﬁnity to mobile phone usage

• Demographic information

The ﬁrst group of questions are about password usage:

ﬁrst we ask about the self-assessment, how likely the

participants would lose their access code (surely not

- rather not - maybe - rather yes - surely yes). As a

comparison, questions about the behavior of the par-

ticipants about electronically bought tickets (print -

save on mobile phone - get by email - don’t buy elec-

tronically) are asked. Later on follow questions about

how often the participants reset a password using the

password-forgotten method (never - rarely - occasion-

ally - often), how many passwords they use (one - own

passwords for important applications - separate pass-

word for each application) or if they use a password-

manager (don’t know what it is - know but not use it -

use it).

Questions about the online behavior of the users

are added, i.e., how frequently online-applications are

used, is online-booking the ﬁrst option (always - if

possible - mostly - rarely - never) and also how of-

ten the participants use social media platforms (daily

- weekly - monthly - never).

Technical knowledge is assessed by questions for

knowledge about electronic signatures, cryptocurren-

cies, installation of programs or programming skills.

As a side investigation, simpliﬁed questions about

the afﬁnity for different mobile phone usages, e.g.,

if the participants would like to save different docu-

ments on the mobile phone or if they already do it are

added.

Finally, demographic data were assessed: Age,

sex, education, job type.

4.4.2 Methodological Approach

The ﬁnal research question aims at generating hy-

potheses about which factors could inﬂuence the pref-

erences of the variants. Due to the exploratory na-

ture of this part, the found dependencies are described

graphically. Here, ﬁltering participants due to their

understanding of the control questions would assume

that the control questions have the highest impact on

the answers. In order to avoid this assumption the

control questions are treated the same way as other

possible inﬂuence factors. A second beneﬁt of this

approach is the possibility to include all participants.

Therefore, other inﬂuences such as age can be ana-

lyzed with a higher sample size.

For this analysis the three outcome variables con-

sidered are the rating of the direct variant (D) for all

three use cases. While logistic regression could be

used to predict the outcomes and assess the inﬂuence

of variables, this way of analyzing the data would

not correspond to the exploratory goal of this study

which aims at generating hypotheses for future stud-

ies. Instead, pairwise correlations between all vari-

ables (both possible inﬂuence factors and the outcome

variables) were investigated. This kind of analysis can

not only show inﬂuences of variables on the outcome

variables but also show dependencies between inﬂu-

encing variables.

In the ﬁrst step, from the large amount of possi-

ble inﬂuencing factors only the most promising ones

were pre-selected. This was done by performing uni-

variate Chi-Square tests. Only variables that are sig-

niﬁcantly dependent to at least one of the three out-

come variables (considering p-values less than 0.01 as

signiﬁcant) were kept. In order to get valid p-values

all variables were binarized before the application of

the test. The three outcome variables were binarized

by merging the ratings “surely yes” and “rather yes”

into “yes” and merging the answers “surely not” and

“rather not” into “no” and named moneyDirectBin,

passDirectBin and certDirectBin, respectively.

Furthermore, all possible inﬂuence factors were suit-

ably binarized based on the relative frequencies of

their attributes.

In the second step the correlations between all

pairs of 11 variables (8 inﬂuence variables were se-

lected in the ﬁrst step plus the 3 outcome variables,

see Table 1) were assessed using Cramer’s V.

In the last step all these correlation coefﬁcients

were visualized in a correlation plot, see Figure 5,

where a larger and darker circle indicates a stronger

correlation between the corresponding pair of vari-

ables. In order to make it easier to see a structure

in the plot, the variables where rearranged using a hi-

erarchical clustering algorithm.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

5 RESULTS

In a ﬁrst step, the users of interest were selected

from the obtained data

. Although the video con-

tained all needed information and was designed to be

as comprehensible as possible, it cannot be guaran-

teed that all participants understood the content and

gave a well-founded answer to these technically re-

lated questions. Thus, for the subsequent analysis

only the users that answered all four control questions

correctly are considered. It was not surprising that for

an average citizen the technical concepts of asymmet-

ric cryptography and the importance of a backup of

the private key was hard to understand. While 108 of

110 participants stated that they understood the con-

tent, only 43 out of the 110 participants answered all

four control questions correctly, as illustrated in Fig-

ure 2. For the subsequent analyses, only participants

who answers all control questions correctly are se-

lected.

0 % 20 % 40 % 60 % 80 % 100 %

Reset Password

User Full Control

Reset Access Code

Manager Full Control

Correctly answered questions [%]

Figure 2: Percentage of correct answers for each of the four

control questions.

5.1 RQ1: Preference of a Key

Management Variant

The primary research question was whether the direct

or the hybrid variant is preferred. For all three use

cases the direct variant was preferred, see Figure 3.

About 80% of the participants stated that they would

surely or rather use the direct variant. In contrast,

the most preferred hybrid variant reached only about

60%.

5.2 RQ2: Application Area and

Institution Inﬂuences

As illustrated in Figure 3, the preferred parties for the

hybrid variant are as follows: for UC1 (diplomas) the

government and the university are equally preferred,

for UC2 (passport) the government is preferred and

for the UC3 (money) the bank is the most trusted man-

ager. For none of the use cases a (not nearer speciﬁed)

external company is preferred.

The data and the Python-scripts are available at

https://www.en-trust.at/downloads/

0 % 20 % 40 % 60 % 80 % 100 %

Diplomas

Passport

Money

Positive agreement [%]

Bank

Government

University

External Company

Direct

Figure 3: Comparison of the direct and the hybrid variant

for three different use cases. In order to reduce complex-

ity, for this graphic, the answers are binarized treating the

attributes “surely yes” and “rather yes” as positive agree-

ment.

There is only a small difference between the three

use cases in the sense that for all of them the preferred

institution reaches about 60% positive agreement.

5.3 RQ3: Key Storage Method

For this question multiple answers were possible.

About half of the participants would note the access

code on paper, followed by the equally frequent op-

tions storing on the mobile phone, in a password man-

ager or printing it, as illustrated in Figure 4. Sending

by email and sharing it with a trusted person are the

two least favored options.

0 % 20 % 40 % 60 % 80 % 100 %

Paper

Mobile Phone

Password Manager

Computer

Trusted Person

Preferred method to note the access code [%]

Figure 4: In this ﬁgure the preferred ways for the partici-

pants to backup a private key are illustrated.

5.4 RQ4: Inﬂuence of Personal

Characteristics

For the exploitative part of dependencies all 110 par-

ticipants of the questionnaire were selected. The set

of variables remaining after ﬁltering with the Chi-

squared test is described in Table 1. The ordering of

Who Stores the Private Key? An Exploratory Study about User Preferences of Key Management for Blockchain-based Applications

variables is chosen such that highly correlated vari-

ables should be near each other.

Table 1: Description of signiﬁcant inﬂuence factors.

Name Short Description

CQ2

Which variant leaves me

in full control of my

data?

CQ3

If I forget my access

code using the direct

variant, can I reset it?

storePubTransp

I want to save transport

tickets at my mobile

phone.

usePubTransp

I buy transport tickets

with my mobile phone.

CQ4

Which variant leaves

full control over my data

at my manager?

installMyself

I typically install

programs myself.

useGovAlways

I always contact the

government online.

ageBin

Binarized age: age < 40

or age ≥ 40.

certDirectBin

I would use the direct

variant for UC1.

passDirectBin

I would use the direct

variant for UC2.

moneyDirectBin

I would use the direct

variant for UC3.

The correlation plot in Figure 5 shows that the

three outcome variables are grouped together (bot-

tom up) since there is a large correlation between

them (bottom right part). The variables (ageBin and

useGovAlways) have a high correlation to the three

outputs only, i.e., they are independent on the other

inﬂuencing factors. Besides CQ4 these two factors are

the only variables with a signiﬁcant dependency to

all three outcome questions. While control questions

appear to correlate with the outcomes, these correla-

tions are not clearly the biggest ones. In compari-

son, age unexpectedly appears to be an equally im-

portant inﬂuence factor. Furthermore, control ques-

tion CQ1 does not have a signiﬁcant dependency with

any outcome and is therefore missing in the list. The

remaining variables describe online behavior in gen-

eral. From the variables that describe the skills only

installMyself remains. It is remarkable that eleven

out of twelve participants that use a password man-

ager would use the direct variant for passports (al-

though the inﬂuence of the variable itself was not sig-

niﬁcant).

Figure 5: Correlation between inﬂuencing variables and the

outcome variables. Higher correlations are visualized using

larger and darker circles, only signiﬁcant (p < 0.01) corre-

lations are shown.

Finally, in order to get an idea about the inﬂu-

ence of different factors on the outcome, the effect of

the factors with the highest correlation with the corre-

sponding outcome variable is exempliﬁed in Figure 6

for the passport use case UC2 and shows about 30%

difference between the two possible attributes.

0 % 20 % 40 % 60 % 80 % 100 %

CQ4 correct

Age ≥ 40

Store tickets mobile

Fraction of users that would use the direct method [%]

True

False

Figure 6: The inﬂuence for the question, if a participant will

prefer the direct variant or not, for the passport use case

(UC2) are illustrated. For three inﬂuence factors: control

question 4 (CQ4) answered correctly, participant age is ≥

40 and if participants store their public transport ticket on

their mobile phone the results are split into two groups.

6 DISCUSSION

In the following, we discuss all research questions

separately.

RQ1: The preference of the direct variant was not

expected as such. This holds especially for the money

use case since this use case is already well-established

and online-banking is already common practice (102

of 110 participants state to use online banking “al-

ways” or “often”). There is indication that this pref-

erence of the direct variant might be overestimated.

Firstly, most participants likely have never experi-

enced a situation where documents or money were

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

completely lost due to forgetting an access code. Cur-

rently, in most systems a way to recover from the loss

of access information exists. Therefore, participants

might underestimate the disadvantage. Additionally,

the number of correct answers to the questions regard-

ing full control over the data (CQ2 and CQ4), exceeds

the number of correct answers to the questions regard-

ing the possibility to retain a forgotten password or

access code (CQ1 and CQ3). This could indicate, that

the advantage of the direct variant was more com-

prehensible to the participants than its disadvantage.

Maybe this also holds for the participants that cor-

rectly answered all control questions. An indication

for this assumptions is that the same analysis done

with the remaining participants yielded rather similar

results.

RQ2: For the hybrid solution, the preferred par-

ties are as expected. Due to the short amount of time

in this study the three use cases were simply treated

as separate. In reality, one could also ask for a min-

imal set of institutions that may relate to more than

one single use case. Based on the result above, see

Figure 3, it would be natural to let the bank provide

access to the money use cases and let the government

provide access to both the certiﬁcate and the passport

use cases.

RQ3: The preferred key storage method is “not-

ing on paper” followed by “printing”, “using a pass-

word manager” and “storing it on a mobile phone”.

This results shows that the average user prefers ana-

log variants (“printing” and “noting on paper”) over

more technical, digital variants (like “using a pass-

word manager” and “storing it on a mobile phone”).

The analog variants have the advantage that the users

control and understand the whole storage process. In

contrast, the digital backup methods are less transpar-

ent and the users additionally have to trust the applica-

tion developers. While nearly every participant has a

smart phone, only slightly more than 20% would use

the smart phone for storing important access codes.

RQ4: When analyzing possible inﬂuence fac-

tors, surprisingly variables that ask for behavior that

are more tightly connected to the research ques-

tions like the amount of passwords or the behav-

ior of noting passwords show no signiﬁcant inﬂu-

ences. For example, participants who estimate them-

selves to lose the access code, were expected to pre-

fer the hybrid variant. However, there was no ev-

idence that this is the case. Figure 5 also shows

a property already stated above: The control ques-

tions about the reset possibility in case of loss of

password and access code (CQ1 and CQ3) corre-

late less with the outcomes than the questions about

which party has full control over the data (CQ2 and

especially CQ4). The variables storePubTransp,

usePubTransp and installMyself have correla-

tions both between themselves and to the control

questions. One could try to interpret them as the

variables describing afﬁnity to usage of modern tech-

niques.

7 CONCLUSION AND OUTLOOK

In this paper an online survey about the preferences of

average citizens concerning the handling of private-

keys of blockchain-based applications was conducted.

While about 80% of the participants of the con-

ducted online survey would use the direct variant that

enables users need to store the private key themselves,

only about 60% would use a hybrid variant where

an external manager is responsible for the backup.

So the participants of the study seem to value data

sovereignty higher than the risk of losing money,

passports or certiﬁcates.

The fact that average citizens, represented by the

survey participants’, are not familiar with technolog-

ical concepts like asymmetric cryptography it would

be crucial for blockchain-based applications to pro-

vide additional explanations and an user-friendly in-

terface for guidance about handling the private key.

Future work might develop easier overall solu-

tions that educate people with awareness phases about

their options and includes or supports several meth-

ods to backup the private key. For example, solu-

tions could be accompanied by additional tools in-

cluding easy to setup and use password managers and

redundant saving strategies. The two variants consid-

ered here are rather extreme cases, other methods that

decrease the needed amount of trust in the manager

could also be developed. A survey about the current

user preferences of actual users of blockchain-based

applications would also be interesting as future work.

ACKNOWLEDGEMENTS

The ﬁnancial support by the Federal State of Salzburg

and by the Austrian Research Promotion Agency

(FFG) under project number 865082 (ProChain) are

gratefully acknowledged.

REFERENCES

Adams, A. and Sasse, M. A. (1999). Users are not the en-

emy. Communications of the ACM, 42(12):40–46.

Who Stores the Private Key? An Exploratory Study about User Preferences of Key Management for Blockchain-based Applications

Al-Bassam, M. (2017). SCPKI: A Smart Contract-based

PKI and Identity System. In Proceedings of the ACM

Workshop on Blockchain, Cryptocurrencies and Con-

tracts, pages 35–40, Abu Dhabi, UAE. ACM.

Apte, S. and Petrovsky, N. (2016). Will blockchain tech-

nology revolutionize excipient supply chain manage-

ment? Journal of Excipients and Food Chemicals,

7(3):76–78.

Ben-Sasson, E., Chiesa, A., Garman, C., Green, M., Miers,

I., Tromer, E., and Virza, M. (2014). Zerocash: De-

centralized Anonymous Payments from Bitcoin. In

Proceedings – IEEE Symposium on Security and Pri-

vacy, pages 459–474, San Jose, CA, USA. IEEE.

Bonneau, J., Herley, C., van Oorschot, P. C., and Stajano, F.

(2012). The Quest to Replace Passwords: A Frame-

work for Comparative Evaluation of Web Authentica-

tion Schemes. In Security and Privacy, 2002. Pro-

ceedings. 2002 IEEE Symposium on, pages 553–567,

San Francisco Bay Area. IEEE.

Brunner, C. (2017). Eduthereum: A System for Storing Edu-

cational Certiﬁcates in a Public Blockchain. Master’s

thesis, Universit

at Innsbruck.

Brunner, C., Knirsch, F., and Engel, D. (2019). SPROOF: A

platform for issuing and verifying documents in a pub-

lic blockchain. In Proceedings of the 5th International

Conference on Information Systems and Privacy,

pages 15–25, Prague, Czech Republic. SciTePress.

Chaudhary, S., Schafeitel-T

ahtinen, T., Helenius, M., and

Berki, E. (2019). Usability, security and trust in pass-

word managers: A quest for user-centric properties

and features. Computer Science Review, 33:69 – 90.

Christidis, K. and Devetsikiotis, M. (2016). Blockchains

and Smart Contracts for the Internet of Things. IEEE

Access, 4:2292–2303.

Eskandari, S., Barrera, D., Stobert, E., and Clark, J. (2015).

A First Look at the Usability of Bitcoin Key Manage-

ment. In NDSS Workshop on Usable Security (USEC)

2015, number February, San Diego.

Faber, B., Michelet, G., Weidmann, N., Mukkamala, R. R.,

and Vatrapu, R. (2019). BPDIMS: A Blockchain-

based Personal Data and Identity Management Sys-

tem. In Proceedings of the 52nd Hawaii International

Conference on System Sciences, volume 6, pages

6855–6864, Grand Wailea.

Fahl, S. (2016). On the importance of ecologically valid

usable security research for end users and IT work-

ers. PhD thesis, Hannover: Gottfried Wilhelm Leibniz

Universit

at Hannover.

Francisco, K. and Swanson, D. (2018). The Supply Chain

Has No Clothes: Technology Adoption of Blockchain

for Supply Chain Transparency. Logistics, 2(1):2.

Fromknecht, C., Velicanu, D., and Yakoubov, S. (2014).

CertCoin: A NameCoin Based Decentralized Authen-

tication System. Technical report, MIT, Cambridge,

MA, USA.

Gauravaram, P. (2012). Security analysis of salt || password

hashes. In International Conference on Advanced

Computer Science Applications and Technologies

(ACSAT), pages 25–30, Kuala Lumpur, Malaysia.

IEEE.

ather, W., Augustin, S., Sch

utte, J., Kolvenbach, S., Au-

gustin, S., Ruland, R., Augustin, S., and Wendland, F.

(2018). Blockchain for Education: Lifelong Learning

Passport. In Proceedings of 1st ERCIM Blockchain

Workshop 2018, Amsterdam. European Society for

Socially Embedded Technologies (EUSSET).

Knirsch, F., Unterweger, A., and Engel, D. (2019). Imple-

menting a Blockchain from Scratch: Why, How, and

What We Learned. EURASIP Journal on Information

Security, 2019(2):1–14.

Kshetri, N. (2017). Blockchain’s roles in strengthening cy-

bersecurity and protecting privacy. Telecommunica-

tions Policy, 41(10):1027–1038.

Larimer, D. (2017). EOS.IO Technical White Paper. Tech-

nical Report ii.

Madhusudan, A., Symeonidis, I., Mustafa, M. A., Zhang,

R., and Preneel, B. (2019). SC2Share: Smart Contract

for Secure Car Sharing. In International Conference

on Information Systems Security and Privacy, Prague,

Czech Republic.

Manohar, A. and Briggs, J. (2018). Identity Management in

the Age of Blockchain 3.0. In CHI 2018 workshop on

HCI for Blockchain.

Mengelkamp, E., Notheisen, B., Beer, C., Dauer, D., and

Weinhardt, C. (2018). A blockchain-based smart grid:

towards sustainable local energy markets. Computer

Science - Research and Development, 33(1):207–214.

Nakamoto, S. (2008). Bitcoin: A Peer-to-Peer Electronic

Cash System. Technical report.

Orman, H. (2018). Blockchain: The Emperor’s New PKI?

In IEEE Internet Computing, volume 22, pages 23–28.

IEEE.

Petralito, S. (2019). Current challenges in HCI-research:

quantifying open experiences, warranting data qual-

ity, and developing standardized measures. PhD the-

sis, University of Basel.

Shamir, A. (1979). How to Share a Secret. Communications

of the ACM (CACM), 22(11):612–613.

Sovrin Foundation (2018). Sovrin : A Protocol and Token

for Self- Sovereign Identity and Decentralized Trust.

Technical Report January.

Won, J., Singla, A., Bertino, E., and Bollella, G. (2018).

Decentralized Public Key Infrastructure for Internet-

of-Things. In 2018 IEEE Military Communications

Conference (MILCOM), pages 907–913, LAX Mar-

riott. IEEE.

Wood, G. (2017). Ethereum: A Secure Decentralised

Generalised Transaction Ledger. Technical report,

Ethereum.

ust, K. and Gervais, A. (2017). Do you need a

Blockchain. Technical report, International Associ-

ation for Cryptologic Research.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy
