Bridging the Technology Gap between Industry and Semantic Web:

Generating Databases and Server Code from RDF

Markus Schr

oder

1,2

, Michael Schulze

1,2

, Christian Jilek

1,2

and Andreas Dengel

1,2

Smart Data & Knowledge Services Dept., DFKI GmbH, Kaiserslautern, Germany

Computer Science Dept., TU Kaiserslautern, Germany

Keywords:

Database Generator, Resource Description Framework, Relational Database, Create Read Update Delete,

Representational State Transfer, Application Programming Interface.

Abstract:

Despite great advances in the area of Semantic Web, industry rather seldom adopts Semantic Web technolo-

gies and their storage and query approaches. Instead, relational databases (RDB) are often deployed to store

business-critical data, which are accessed via REST interfaces. Yet, some enterprises would greatly beneﬁt

from Semantic Web related datasets which are usually represented with the Resource Description Framework

(RDF). To bridge this technology gap, we propose a fully automatic approach that generates suitable RDB

models with REST APIs to access them. In our evaluation, generated databases from different RDF datasets

are examined and compared. Our ﬁndings show that the databases sufﬁciently reﬂect their counterparts while

the API is able to reproduce rather simple SPARQL queries. Potentials for improvements are identiﬁed, for

example, the reduction of data redundancies in generated databases.

1 INTRODUCTION

The Resource Description Framework (RDF) (Rai-

mond and Schreiber, 2014) is a well-established data

model in the Semantic Web community. It is used

to express facts about resources identiﬁed with uni-

form resource identiﬁers (URIs) (Berners-Lee et al.,

1998) in the form of statements (subject, predicate

and object). Ontologies (Gruber, 1993) are used

to model domains and to share formally speciﬁed

conceptualizations which can be expressed by using

RDF Schema (RDFS) (Guha and Brickley, 2004).

RDF-based data is typically stored in triplestores

and queried with the SPARQL Protocol and RDF

Query Language (SPARQL) (W3C SPARQL Work-

ing Group, 2013).

In our experience, beyond the Semantic Web and

especially in industry, such technologies are rather

seldom used. A case study for the manufacturing in-

dustry also points out this observation (Feilmayr and

oß, 2016). Instead, relational databases (RDBs) are

commonly used to store important and system critical

data – information systems which are well-researched

over 50 years. By implementing Application Pro-

gramming Interfaces (APIs), a controlled access on

these datasets with Create, Read, Update and Delete

(CRUD) operations are provided for system develop-

Table 1: Comparison of storage and query approaches be-

tween Semantic Web and Industry.

Approach Semantic Web Industry

Storage Triplestore SQL Database

Domain Modeling Terminology in Ontology Database Schema

Data Modeling RDF Statement Assertions Database Records

Identiﬁcation URIs Primary Keys

Query Interface SPARQL SQL / REST API

Exchange Format Result Set / RDF Result Set / JSON

ers. APIs often conform to the Representational State

Transfer (REST) software architecture, utilize the Hy-

pertext Transfer Protocol (HTTP) and exchange data

in the JavaScript Object Notation (JSON) format.

By examining both sides, we observe distinct

solutions regarding storage and query approaches.

Table 1 summarizes and compares these ﬁndings:

while the Semantic Web encourages the use of triple-

stores loaded with ontologies and assertions, industry

prefers databases with deﬁned schemata and records.

Resources are identiﬁed with URIs on the Seman-

tic Web, while database records use primary keys.

Graph-oriented SPARQL queries and their special

result set responses are opposed to relational SQL

queries. On top of databases, additional web services

can provide document-oriented REST APIs returning

JSON documents.

Yet, some enterprises would greatly beneﬁt from

Semantic Web technologies. This also includes re-

Schröder, M., Schulze, M., Jilek, C. and Dengel, A.

Bridging the Technology Gap between Industry and Semantic Web: Generating Databases and Server Code from RDF.

DOI: 10.5220/0010186005070514

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 507-514

ISBN: 978-989-758-484-8

507

lated datasets and the way knowledge is modeled. We

see a trend that more and more publicly available

datasets are modeled and/or published in the RDF

format, such as datasets in the Linked Open Data

(LOD) cloud

, DBpedia (Bizer et al., 2009) and Wiki-

data (Vrande

c and Kr

otzsch, 2014). Moreover, it

has been become popular in data integration services

and especially in knowledge services to construct and

maintain knowledge graphs (Hogan et al., 2020) for

selected use cases, for instance, when building a cor-

porate memory (Maus et al., 2013). To embed these

new datasets and technologies in workﬂows and pro-

cesses, corporations would have to spend consider-

able efforts. In order to keep a company’s overhead

to a minimum, we suggest transforming RDF-based

datasets back to storage systems they are more famil-

iar with, namely RDBs. This way, data can be main-

tained by admins without knowledge about Semantic

Web, but with the trade-off of losing the ﬂexibility

of Semantic Web technologies. This implies that this

transformation should be performed only once and

further data changes should be made in the generated

database. For integration purpose, we further recom-

mend that enterprises implement CRUD REST APIs

to provide access and manipulation layers for their

developers. Since such conversions and implementa-

tions are quite tedious and costly when executed man-

ually, a fully automatic way to generate the envisioned

assets would be helpful.

Since related work did not appropriately address

this particular use case, in this paper, we provide a so-

lution to this challenge. A generation procedure is de-

scribed that accepts an arbitrary RDF(S) dataset and

generates an RDB with a CRUD REST API to ac-

cess and modify it. Doing this, raises the following

research questions which are addressed in our experi-

ments:

1. How well do the generated RDBs reﬂect their

RDF dataset counterparts? By using various RDF

datasets, we check if any critical data is missing

in the databases and how they are structured.

2. How well can the generated CRUD REST API re-

produce queries that would have been performed

with SPARQL? To answer this, we try to query

same information with our API compared with

given SPARQL queries.

3. What limitations do the generated databases and

interfaces have? In our experiments, we reveal

and discuss shortcomings of our approach.

For future research, the source code of our algorithm

and the evaluation material is publicly available at

https://lod-cloud.net/

GitHub

This paper is structured as follows: in the next

section (Sec. 2) we investigate procedures and tools

in literature that also transform RDF to RDB. This is

followed by our own approach in Section 3. Section

4 presents the evaluation of our method and answers

the stated research questions. We close the paper with

a conclusion and an outlook in Section 5.

2 RELATED WORK

One can ﬁnd a lot of papers in literature which are re-

lated to the conversion of RDB (and similar formats)

to RDF. However, only few works actually investi-

gated the opposite direction (from RDF to RDB).

An early work (Teswanich and Chittayasothorn,

2007) transforms RDF documents to databases to ap-

ply Business Intelligence (BI) technologies. RDFS-

related information is stored in meta tables, for exam-

ple, in relations like class, property and sub class of.

For each class and object property (regardless of

its cardinality) a table is created. SQL statements

demonstrate how a generated database can be queried.

Similarly, the R2D approach (Ramanujam et al.,

2009) generates databases from RDF data to reuse

visualization tools. The authors suggest several

improvements regarding (Teswanich and Chittaya-

sothorn, 2007): in contrast, their approach still works,

albeit no ontological information is available in the in-

put dataset. Moreover, it considers the cardinality of

properties to avoid the creation of tables, and it also

handles blank nodes.

RDF2RDB

is a Python based tool that converts a

given RDF/XML document into a MySQL database.

The generation approach is also comparable with the

one from (Teswanich and Chittayasothorn, 2007), ex-

cept it does not generate meta tables for RDF schema

information.

RETRO (Rachapalli et al., 2011) focuses on query

translation with the same motivational arguments as

we have about bridging the gap between Semantic

Web and industry. However, their approach does not

physically transform RDF to an RDB. Instead, they

use a ﬁxed schema mapping approach that virtually

maps all predicates from the A-Box statements to re-

lational tables having two columns, namely for sub-

ject and object.

Although R2D and RDF2RDB are comparable to

our approach, we did not ﬁnd any related work that

also takes into account the generation of a suitable

REST interface to access the data.

https://github.com/mschroeder-github/rdf-to-rdb-rest-api

https://github.com/michaelbrunnbauer/rdf2rdb

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

508

3 APPROACH

Our approach is divided into three phases. First, RDF

data is analyzed to receive valuable insights about the

nature of the dataset. Secondly, these ﬁndings are

used to design a suitable database model which con-

sists of tables, columns and data records. Thirdly,

based on the database model, Java source code is gen-

erated to directly provide developers with usable data

classes, a database access layer, a server and its REST

interface.

Figure 1 presents a very small example of the ap-

proach. A simple RDF dataset about persons read-

ing books (on the left in RDF Turtle syntax) is trans-

formed into three tables (in the middle): two of them

represent persons resp. books while the third one

models the many-to-many relation between them. On

the right side, corresponding source code is generated

to automatically implement the REST API. The ready

to use server application can be utilized by develop-

ers to query a book resource which returns a JSON

representation of it.

3.1 Analysis of RDF

Before the RDF model is analyzed, possible Blank

Nodes in the dataset are skolemized (Mallea et al.,

2011). This means that they are replaced with ran-

domly generated URIs in a consistent manner. That

way further analysis and processing is simpliﬁed

without any semantic change to the RDF model.

Next, for generating the RDB tables and ﬁlling

them with records later, classes and their instances

have to be discovered. They are collected by scan-

ning through the assertion box (A-Box) statements.

In this process, instances having more than one type

(multi-typed instances) are detected. The instances’

properties together with their domains and ranges are

further examined since they will be modeled as ei-

ther table columns or many-to-many tables. We di-

vide the properties into object properties (objects are

resources) and data type properties (objects are liter-

als). In case of object properties, the object’s type is

inspected (range). If the object is not further men-

tioned in the RDF dataset or has no type, it is clas-

siﬁed as a dangling resource. Later, these resources

will be stored in the database as textual URIs (instead

of numeric IDs) because they are not present in the

database as a record. At least, this allows to look

up such resources by following the links. Regarding

data type properties, a suitable SQL storage class is

inferred which can be either text, real, integer or bi-

nary large object. If the literal has a language tag, the

property is assigned to be a special language string

property.

After that, the properties cardinalities are analyzed

to decide if a relationship should be modeled as a for-

eign key column or a many-to-many table. For each

property, based on the given data, it is deduced if it

has a one-to-one, one-to-many, many-to-one or many-

to-many cardinality by scanning through the A-Box

statements. The special rdf:type property is always

assumed to be many-to-many because multiple re-

sources can have multiple types in RDF. Additionally,

all the properties’ domains and ranges are collected.

Note that one predicate can have subjects and objects

with various domains and ranges. To retrieve clear

mappings from domains to ranges, distinct domain-

range pairs are calculated.

3.2 Conversion to RDB

Our generated RDBs follow the type-store approach

mentioned in (Ma et al., 2016). Multi-valued at-

tributes are avoided by using many-to-many tables

when cardinalities require it. We assume that the type-

based structure is easier to grasp for developers than

a horizontal or vertical structure.

Complying with the type-store approach, for each

determined type from the previous step, a table is des-

ignated that will contain all instances of this type in

form of records. We denote such relations as entity

tables. They contain mandatory numeric id-columns

which serve as primary keys. We do not add a uri-

column since the numeric primary key already serves

as an identiﬁer and databases usually do not model

another textual identiﬁer, like a URI, for their records.

An entity table is annotated with its representing

RDF class. All properties matching the class with

their domain are assumed to be a column of this ta-

ble. However, there are two special cases with re-

spect to the cardinality of the properties. In case of

a one-to-many cardinality, the column is placed in

the referring table instead. This is a usual step when

entity-relationship models (ER-models) are instanti-

ated as relations that should satisfy the third normal

form (Kent, 1983). In case of a many-to-many cardi-

nality, no column in an entity table is created. Instead,

an extra table is modeled that contains two columns,

namely to refer to subject and object. If we have a lan-

guage string property at hand, another lang column is

added to store the language tag.

Next, tables are ﬁlled with data records. To do

that consistently, each resource in the RDF dataset is

assigned to a unique numeric ID. A special

res id-

relation records for each URI the mapped ID for later

lookup. Using this information, records of entity ta-

bles obtain distinct IDs for their primary keys. By

Bridging the Technology Gap between Industry and Semantic Web: Generating Databases and Server Code from RDF

509

RDF Dataset Relational Database REST API

public class Book {

private Long id;

private String title;

...

Table: Person

id | name

1 | John

2 | Thomas

Table: Book

id | title

1 | Ash

2 | Claf

Table: reads

person | book

1 | 1

2 | 1

1 | 2

2 | 2

:p1 a :Person;

:name “Thomas“

:reads :b1, :b2 .

:p2 a :Person;

:name “John“

:reads :b1, :b2 .

...

:b1 a :Book;

:title “Ash“ .

:b2 a :Book;

:title “Calf“ .

...

{

“id“: 1,

“title“: „Ash“

}

GET /book/1

Figure 1: Illustrating example of our approach: An RDF dataset about persons reading books (left) is converted to a relational

database (middle). The further generated REST API contains corresponding source code (right) and allows to query the

database with REST calls (indicated by the gray arrow). The response is a JSON representation of the data.

scanning through the outgoing edges of every re-

source, record ﬁelds are allocated with the acquired

objects. For many-to-many tables, all statements with

the corresponding predicate are considered. Those

statements have the following mandatory condition:

the subject’s type matches the given domain and the

object’s type matches the given range. Only those

statements are inserted as appropriate records in the

table. Last, SQL statements are formulated to popu-

late an SQLite

database with the modeled tables and

their records.

3.3 Generation of REST API Code

To generate source code and ﬁle contents, we uti-

lize the template engine Apache FreeMarker

. In this

phase, two Apache Maven

projects are produced by

our approach: an api project containing data classes

together with the database access layer and a server

project with the RESTful communication logic.

For the api project, every entity table from the

previous part is converted into a Plain Old Java Ob-

ject (POJO)

. The tables’ columns are turned into at-

tributes of the POJO class. All many-to-many tables

that could be joined with the entity table on the ﬁrst

column become attributes of type java.util.List.

In case of a table that originated from a language

string property, a special LangString POJO class

holding string and language tag is used as the at-

tribute’s type.

After the data classes, the database controller class

is generated. For each Java class, a corresponding se-

lect, insert, update and delete method is generated.

These methods internally use SQL to communicate

with the database. In case of the select method, ﬁlter-

ing is supported by using the resource query language

(RQL). For that we parse the syntax

and ﬁlter results

based on given RQL expression.

https://www.sqlite.org/

https://freemarker.apache.org/

https://maven.apache.org/

https://www.martinfowler.com/bliki/POJO.html

https://github.com/jirutka/rsql-parser

The server project has a dependency to the api

project. Thus, it reuses the POJO classes, database ac-

cess logic and provides the RESTful communication.

We use the Spark

framework to implement the server

application. For each Java class (from the API) a cor-

responding REST endpoint is generated. The end-

points are able to interpret and perform HTTP GET,

POST, PUT, PATCH and DELETE requests by uti-

lizing the database controller from the api project. A

converter from POJO to JSON (and vice versa) is pro-

vided to exchange data.

4 EVALUATION

The evaluation of our approach consists of three parts.

First, several diverse and publicly available

RDF(S)

datasets are transformed into RDBs to check the al-

gorithm’s ability to handle different datasets and to

analyze the generated databases. Second, we make

a comparison between the outcome of a similar tool

with our results using the same input dataset. Third,

a SPARQL benchmark is used which provides pre-

deﬁned queries and an RDF dataset generator. Our

re-engineered database is compared with the bench-

mark’s generated SQL database. We also investi-

gate how well our REST API can reproduce given

SPARQL queries. The evaluation section is closed

with a general discussion of the results.

4.1 Datasets

The Linked Open Data (LOD) cloud

is a hub

that refers to all kinds of publicly available RDF-

based resources or endpoints. To test our algorithm,

we randomly selected six rather small RDF datasets

from the LOD cloud. Additionally, a private dataset

from an industrial scenario and a generated one from

http://sparkjava.com/

Except of one private dataset that was obtained from an

industrial scenario.

https://lod-cloud.net/

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

510

the Berlin SPARQL Benchmark (BSBM) (Bizer and

Schultz, 2011) are examined too. Only relatively

small sized datasets with triples around a 5-digit num-

ber of statements are chosen since we are not inter-

ested in testing the time and memory performance of

our approach. Instead, we investigate what effects

various datasets have on the output of our algorithm.

The ﬁndings will be discussed at the end of the evalu-

ation section. Characteristics of the eight datasets and

the resulting RDBs are presented in Table 2. In the

following, we brieﬂy describe each dataset and dis-

cuss the results.

TBL-C

is the RDF representation of Tim

Berners-Lee’s electronic business card. Since

the instance representing himself has two types

(foaf:Person and con:Male), this record is redun-

dantly stored in two tables with identical columns.

Having multiple types causes also the generation of

several many-to-many tables with equivalent data.

The Copyright Term Bank CTB

dataset con-

tains copyright terminology. After the conversion,

four entity tables contain data records: concept, lex-

ical entry, lexical sense and sense deﬁnition. How-

ever, lexical sense does not have any functional prop-

erties, thus containing no columns (except the manda-

tory id column).

The Edinburgh Associative Thesaurus RDF

dataset EAT

(Hees et al., 2016) contains associa-

tions of terms. Despite the large number of statements

(1,674,376), it only has two classes which results in

two tables, namely association with 325,588 records

and term with 23,218 rows.

Pokedex

is an RDF catalog of ﬁctitious mon-

sters of the popular Pok

emon franchise

. The main

table pokemon contains all functional properties and

has 493 entries. All Pok

emon species are listed in the

species table. Because there is a one-to-many rela-

tionship between species (one) and Pok

emon (many),

the property pkm:speciesOf is represented with a col-

umn in the pokemon table.

Betweenourworlds BOW

is a dataset about ani-

mes which are drawn animations originated from

Japan. Besides having the largest number of state-

ments in our selection (4,041,676), it also has the

largest number of instances with multiple types

(349,195). The main reason is that every anime

is typed with at least dbo:Anime, dbo:Cartoon and

dbo:Work.

http://www.w3.org/People/Berners-Lee/card.rdf

https://lod-cloud.net/dataset/copyrighttermbank

https://lod-cloud.net/dataset/associations

https://lod-cloud.net/dataset/data-incubator-pokedex

https://www.pokemon.com/

https://betweenourworlds.org/ (Release 2020-06)

S-IT

is a dataset generated from the traveling

website about the Salzburg state in Austria in Italian

language. The dataset has been built with WordLift

(Volpini and Riccitelli, 2015), which is a plugin that

annotates website content with linked data. Although,

it has the second lowest number of statements (4,477),

the generated database contains the most tables. This

can be explained by the high number of classes (406)

and resources (81) which are instances of multiple

classes.

Our private RDF dataset IndScn from an indus-

trial scenario consists of meta-data about documents

and their revisions. The conversion went straight for-

ward: 16 classes result in the desired 16 tables with

appropriate many-to-many tables for the properties.

The BSBM

(Bizer and Schultz, 2011) dataset

has been generated with the provided generator tool

(version 0.2). Its domain is about produced, offered

and reviewed products. With a product count param-

eter of 100, 40,177 RDF statements have been gen-

erated. After the conversion, all main entity tables

were created, namely product, product feature, prod-

uct type, person, producer, offer, review and vendor.

4.2 Comparison with RDF2RDB

RDF2RDB

is an open-source tool that converts

RDF to relational databases. The procedure, which

is written in Python 2, reads RDF ﬁles and ﬁlls a

MySQL database with tables and records. We use two

datasets, namely No. 1 and No. 8 in Table 2, to com-

pare exemplarily the behavior of the procedures.

For demonstration purpose, the developer pro-

vides the generated database from Tim Berners-Lee’s

electronic business card

. Since we did also the con-

version of the same dataset (No. 1 in Table 2), we

can compare the resulting databases: RDF2RDB pro-

duced 59 tables, while our procedure made only 18

relations. The main reason for this is that RDF2RDB

converts more properties into many-to-many tables.

It also generated a thing table that sparsely records all

owl:Thing resources with their properties. Another

difference is that RDF2RDB provides a labels-table

and uris-table. In the labels-relation, all URIs from

the dataset are related to their labels to enable label-

based searches. The uris-table lists for each resource

https://lod-cloud.net/dataset/salzburgerland-com-it

https://wordlift.io/

http://wifo5-03.informatik.uni-mannheim.de/bizer/

berlinsparqlbenchmark/

https://github.com/michaelbrunnbauer/rdf2rdb

https://www.netestate.de/Download/RDF2RDB/timbl.

txt

Bridging the Technology Gap between Industry and Semantic Web: Generating Databases and Server Code from RDF

511

Table 2: Characteristics of eight RDF datasets and their generated databases by our approach: the number of RDF statements

(Stmts), classes (Cls), multi-typed instances (MT) and average number of types per MT instance (avgMT). Further, the

number of object property (OP), datatype properties (DP), and properties which have the following cardinality: one-to-one

(OO), many-to-one (MO), one-to-many (OM) and many-to-many (MM). Regarding the database, we show the number of

generated entity tables (ET), many-to-many tables (MMT) and average number of columns per entity table (avgCol).

No. Name Stmts Cls MT avgMT OP DP OO MO OM MM ET MMT avgCol

1 TBL-C 109 5 1 2 26 18 31 19 7 1 5 11 12.2 ± 12.4

2 CTB 10,853 4 0 - 10 5 4 6 1 4 4 7 3.0 ± 1.6

3 EAT 1,674,376 2 0 - 3 3 1 5 0 0 3 1 2.7 ± 2.1

4 Pokedex 26,562 19 0 - 9 29 13 28 5 3 19 40 3.5 ± 6.7

5 BOW 4,041,676 15 349,195 2.9 ± 0.9 7 19 2 9 0 15 15 180 5.3 ± 3.0

6 S-IT 4,477 406 81 14.3 ± 9.0 9 25 18 6 3 7 406 3,056 2.6 ± 1.0

7 IndScn 25,016 16 0 - 24 37 4 34 0 23 16 74 5.7 ± 4.5

8 BSBM 40,177 22 100 2.0 ± 0.0 12 28 16 22 0 2 22 17 13.7 ± 5.5

its class and assigned numeric ID. This table is com-

parable with our res id-relation.

We also use the generated BSBM dataset (No. 8

in Table 2) to compare the tool’s outcome with our

result. While RDF2RDB’s database contains 145 ta-

bles, our method generated 41 relations. RDF2RDB

created for each product type a table but used for its

name the product type’s label. As before, a lot of

many-to-many tables are created by the tool. The

entity tables are nearly equal, except that RDF2RDB

decided to model some relations as tables instead of

columns.

In conclusion, RDF2RDB comply more with the

RDF model with the side effect of generating more

tables, especially many-to-many tables. Our version

is more data-driven, thus more properties are mod-

eled as columns since their observed cardinalities al-

low that. In both cases the given facts could be stored

in the databases. However, some more speciﬁc RDF

structures, like RDF containers or Blank Node infor-

mation, is not stored.

4.3 REST Interface Test with BSBM

The Berlin SPARQL Benchmark (BSBM) (Bizer

and Schultz, 2011) provides a dataset generator and

SPARQL queries to enable performance comparisons

of storage systems with a SPARQL endpoint. First,

using the dataset generator, we will examine how

well our approach re-engineers the benchmark’s in-

tended database. Second, we utilize provided queries

to check if our API can reproduce them.

BSBM’s dataset generator can produce, aside

from usual RDF, a SQL description of a database con-

taining equivalent data. In the following, we examine

how close our method can re-engineer this database

only from the RDF dataset. Our generated database

was already described in the previous section (No. 8

in Table 2). The comparison shows that we found

all necessary entity and many-to-many tables. Re-

garding the offer table, our version misses the pro-

ducer column. However, this is not a surprise because

the dataset does not contain any linkage between of-

fer and producer. Concerning the product type-table,

BSBM additionally added a parent and sub class of -

column to model the class hierarchy. Another dif-

ference is the way dates are stored. While BSBM

uses text representations in ISO 8601, our database

uses milliseconds since the UNIX epoch. Because

of multi-typed instances, our procedure created some

unnecessary tables per type as well as some many-to-

many tables. In conclusion, despite small differences,

our re-engineered database is similarly modeled and

contains all intended data.

The benchmark’s main purpose is to provide

queries to test performance of SPARQL endpoints.

With 12 formulated exploration queries

, endpoints

can be queried in various ways by using mainly SE-

LECT queries, a DESCRIBE query and a CON-

STRUCT query. Since they contain substitution pa-

rameters, they are actually templates that can be in-

stantiated in various ways. In our evaluation, we in-

vestigate if our generated REST API can reproduce

these queries by testing them with meaningful substi-

tutions. Our expectation is that the REST API can

retrieve equal information.

In the following, we present for each BSBM query

its REST API call counterpart. For readability and re-

producibility reasons they are available online

. In

some cases more then one call has to be made to join

data in the client appropriately. We omitted calls that

would have been necessary to retrieve further infor-

mation about referred resources, like mostly their la-

bels. The resource query language (RQL) is often

used to mimic SPARQL’s basic graph patterns and

ﬁlter possibilities. We put the responsibility for or-

http://wifo5-03.informatik.uni-mannheim.de/bizer/

berlinsparqlbenchmark/spec/ExploreUseCase/index.html

https://github.com/mschroeder-github/

rdf-to-rdb-rest-api/blob/master/bsbm-queries.txt

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

512

dering the results to the client. The interpretation of

optional information (expressed in SPARQL with the

OPTIONAL keyword) is also up to the developer.

What follows are short explanations how some

queries are reproduced with our API. Regarding

Query 3, the label of the optional ProductFeature2

is checked to be not bound. This is solved in our

case by excluding this feature with RQL’s =out= op-

erator which yields to the same result. In Query 4,

the UNION statement is imitated by a logical or con-

struction (in RQL a ‘,’) whether ProductFeature2

or ProductFeature3 (or both) are the product’s fea-

tures. Concerning Query 5, the SPARQL query con-

tains ﬁlters with arithmetic expressions that can not

be emulated by our RQL engine. Thus, in a second

call (5b), the client will be responsible for ﬁltering

the results to ﬁnd matching products. Using RQL’s

=regex= operator, we reproduce the regular expres-

sion ﬁlter in Query 6. Query 7 demonstrates that

joining data involves multiple REST calls and has to

be done on the client-side. Since data types of lit-

erals are not stored in our database, the currency of

an offer’s price can not be retrieved. With the spe-

cial =lang= operator in RQL, language strings can

be ﬁltered as shown in Query 8. Regarding Query

9, a ﬁrst call determines the reviewer of ReviewXYZ,

while in a second call (not shown in the code), the re-

viewer is retrieved by using the /person endpoint. In

Query 11, also incoming edges of a given OfferXYZ

are queried. Since our REST API can only retrieve

outgoing edges of a resource, this request is only par-

tially reproducible. In case of Query 12, which is a

CONSTRUCT query, the actual construction part lies

in the responsibility of the client.

4.4 Discussion

At the beginning of the paper, we stated three ques-

tion that can now be answered based on the evalua-

tion results. When answering the ﬁrst two questions,

we also address limitations of our generated databases

and interfaces.

How well do the generated RDBs reﬂect their RDF

dataset counterparts? The observation of the eight

generated databases (Table 2) shows that the informa-

tion content of a dataset’s A-Box is sufﬁciently re-

ﬂected by its database counterpart, i.e. we did not

miss any critical information. However, it is possible

to express the same information with different rela-

tional models. Compared to RDF2RDB, our proce-

dure created less tables but still more than intended

by BSBM. The evaluation reveals that the handling

of multi-typed instances poses the main challenge.

Since RDF classes directly correspond to RDB tables,

a resource having more then one type is redundantly

distributed among respective tables. It also causes

the generation of more many-to-many tables because

such a table relates one certain domain to one particu-

lar range. That means that unnecessary and unwanted

data redundancies occur.

Another major challenge is the decision for a

trade-off that determines whether a property becomes

a table or a column. If, on the one extreme, every

property has a table counterpart, the number of tables

explodes and joins become inevitable which make

queries more complex. If, on the other extreme, prop-

erties become columns in tables, data redundancy oc-

curs since relations would violate the second normal

form. That is why generation procedures should have

a meaningful (maybe conﬁgurable) trade-off. We de-

cided to infer the cardinality of properties based on

existing A-Box statements to minimize the number

of many-to-many tables. However, this makes the

properties’ cardinalities unchangeable in the database

model. For example, a one-to-many relationship can

not be easily turned into many-to-many relationship

once the database model is deﬁned.

Evaluation also points out smaller issues in our

generator. Tables having only an id column could

be removed because they provide no further informa-

tion. We also noticed that RDF data types are missing

in our database model. In conclusion, our generated

RDBs indeed reﬂect their RDF dataset counterparts

sufﬁciently but contain unnecessary redundant data as

well.

How well can the generated CRUD REST API

reproduce queries that would have been performed

with SPARQL? Many SPARQL operations like aggre-

gates, arithmetic expressions, sub-queries and various

functions are not supported by our rather simple API.

When such queries become more complex, we make

the client responsible to send more requests and to

process the results accordingly. A major issue is that

the API does not provide a join-mechanism. Since

each endpoint represents a class and returns the cor-

responding instances, the join has to be performed by

the client. Another limitation is the inability to re-

trieve a resource’s incoming edges since the underly-

ing database model is not designed for that. Yet, by

using the BSBM benchmark, we showed that our in-

terface could in almost all cases retrieve the same in-

formation as the given SPARQL queries. Hence, our

conclusion is that the API can reproduce rather simple

and common queries, while more complex ones have

to be handled by the client.

Bridging the Technology Gap between Industry and Semantic Web: Generating Databases and Server Code from RDF

513

5 CONCLUSION AND OUTLOOK

Especially in industry, Semantic Web technologies

are rather seldom used. Since corporations would

greatly beneﬁt from available and future RDF-based

datasets, we suggested to bridge the technology gap

by a fully automatic conversion of RDF to RDBs to-

gether with CRUD REST APIs. Our experiments

suggest that in comparison to related work, our re-

engineered databases reﬂect their RDF counterparts

with less tables. Moreover, our generated REST

APIs are able to reproduce rather simple and com-

mon SPARQL queries. We identiﬁed as a remaining

challenge the generation of unnecessary data redun-

dancies because of multi-typed instances.

Future work should ﬁnd an appropriate way to

model the database to reduce the high number of ta-

bles and data redundancies. In this regard, as already

pointed out, algorithms should provide a conﬁgurable

trade-off to decide whether properties become many-

to-many tables or simple columns. Thus, the right set-

ting can be dependent on a particular use case. Since

RDF datasets can change over time, we also suggest

that future procedures provide an update-mechanism

in order to avoid rebuilding the whole database (and

possibly removing already inserted data). Moreover,

to also process larger datasets (like DBpedia), we in-

tend to reduce our algorithm’s memory usage.

ACKNOWLEDGEMENTS

This work was funded by the BMBF project SensAI

(grant no. 01IW20007).

REFERENCES

Berners-Lee, T., Fielding, R. T., and Masinter, L. (1998).

Uniform Resource Identiﬁers (URI): Generic Syntax.

RFC 2396, RFC Editor.

Bizer, C., Lehmann, J., Kobilarov, G., Auer, S., Becker, C.,

Cyganiak, R., and Hellmann, S. (2009). DBpedia - A

crystallization point for the Web of Data. Web Seman-

tics: Science, Services and Agents on the World Wide

Web, 7(3):154–165.

Bizer, C. and Schultz, A. (2011). The berlin SPARQL

benchmark. In Semantic Services, Interoperability

and Web Applications - Emerging Concepts, pages

81–103. CRC Press.

Feilmayr, C. and W

oß, W. (2016). An analysis of ontologies

and their success factors for application to business.

Data Knowl. Eng., 101:1–23.

Gruber, T. R. (1993). A Translation Approach to Portable

Ontology Speciﬁcations. Knowledge Acquisition,

5:199–220.

Guha, R. and Brickley, D. (2004). RDF Vocabulary De-

scription Language 1.0: RDF Schema. W3c recom-

mendation, W3C.

Hees, J., Bauer, R., Folz, J., Borth, D., and Dengel, A.

(2016). Edinburgh associative thesaurus as RDF and

dbpedia mapping. In The Semantic Web - ESWC 2016

Satellite Events, Heraklion, Crete, Greece, May 29 -

June 2, 2016, Revised Selected Papers, volume 9989

of LNCS, pages 17–20.

Hogan, A., Blomqvist, E., Cochez, M., d’Amato, C.,

de Melo, G., Gutierrez, C., Gayo, J. E. L., Kirrane,

S., Neumaier, S., Polleres, A., Navigli, R., Ngomo,

A.-C. N., Rashid, S. M., Rula, A., Schmelzeisen, L.,

Sequeda, J., Staab, S., and Zimmermann, A. (2020).

Knowledge graphs. arXiv 2003.02320.

Kent, W. (1983). A simple guide to ﬁve normal forms in re-

lational database theory. Commun. ACM, 26(2):120–

125.

Ma, Z., Capretz, M. A. M., and Yan, L. (2016). Storing

massive resource description framework (RDF) data:

a survey. Knowl. Eng. Rev., 31(4):391–413.

Mallea, A., Arenas, M., Hogan, A., and Polleres, A. (2011).

On blank nodes. In The Semantic Web - ISWC 2011 -

10th Int. Semantic Web Conf., Bonn, Germany, Octo-

ber 23-27, 2011, Proc., Part I, volume 7031 of LNCS,

pages 421–437. Springer.

Maus, H., Schwarz, S., and Dengel, A. (2013). Weaving

Personal Knowledge Spaces into Ofﬁce Applications,

pages 71–82. Springer.

Rachapalli, J., Khadilkar, V., Kantarcioglu, M., and Thu-

raisingham, B. (2011). Retro: a framework for se-

mantics preserving sql-to-sparql translation. The Uni-

versity of Texas at Dallas, 800:75080–3021.

Raimond, Y. and Schreiber, G. (2014). RDF 1.1 Primer.

W3c note, W3C.

Ramanujam, S., Gupta, A., Khan, L., Seida, S., and Thu-

raisingham, B. M. (2009). R2D: A bridge between

the semantic web and relational visualization tools. In

Proc. of the 3rd IEEE Int. Conf. on Semantic Com-

puting (ICSC 2009), 14-16 September 2009, Berkeley,

CA, USA, pages 303–311. IEEE Computer Society.

Teswanich, W. and Chittayasothorn, S. (2007). A transfor-

mation from rdf documents and schemas to relational

databases. In 2007 IEEE Paciﬁc Rim Conf. on Com-

munications, Computers and Signal Processing, pages

38–41. IEEE.

Volpini, A. and Riccitelli, D. (2015). Wordlift: Meaningful

navigation systems and content recommendation for

news sites running wordpress. In Proc. of the ESWC

Developers Workshop 2015 co-located with the 12th

Extended Semantic Web Conference (ESWC 2015),

Portoro

z, Slovenia, May 31, 2015, volume 1361 of

CEUR Workshop Proc., pages 20–22. CEUR-WS.org.

Vrande

c, D. and Kr

otzsch, M. (2014). Wikidata: A Free

Collaborative Knowledgebase. Communications of

the ACM, 57(10):78–85.

W3C SPARQL Working Group (2013). SPARQL 1.1

Overview. W3c recommendation, W3C.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

514
