Generating Commonsense Ontologies with Answer Set Programming

Stefan Jakob, Alexander Jahl, Harun Baraki and Kurt Geihs

Distributed Systems Department, University of Kassel, Wilhelmsh

oher Allee 71-73, Kassel, Germany

Keywords:

Knowledge Representation and Reasoning, Knowledge-based Systems, Ontologies.

Abstract:

The use of commonsense knowledge is essential for the interaction of humans and robots in a smart environ-

ment. This need arises from the way humans naturally communicate with each other, in which most details

are usually omitted due to common background knowledge. To enable such communication with a robot, it

has to be equipped with a commonsense knowledge representation that supports reasoning. Ontologies could

be a suitable approach. However, current ontology frameworks lack dynamic adaptability, are monotonous,

are missing negation as failure, and are not designed for huge amounts of data. This paper presents a new way

to model ontologies based on a non-monotonic reasoning formalism. Our ontology modelling framework,

called ARRANGE, allows for the automatic integration of graph-based knowledge sources to generate on-

tologies and provides corresponding tools. The presented experiments show the applicability of the generated

ontologies and the performance of the ontology generation, the ontology reasoning, and the query resolution.

1 INTRODUCTION

Smart environments have become a part of our every-

day life. In general, they are distributed IT systems

that support humans in their daily chores by providing

information via services or by physically supporting

them via robots. A typical example is a Smart Home.

It contains IoT devices, services either on local Edge

devices or in the Cloud, different kinds of robots, and

humans interacting with its components. Currently,

robots for the Smart Home are mainly built for a sin-

gle purpose, e. g., lawnmowers or vacuum cleaners.

While these robots are particularly suited for their

purpose, the focus in the ﬁeld of service robots is set

on the development of multi-purpose robots (Brady

et al., 2015). To allow the safe cooperation of ser-

vices, robots, and humans, key features like commu-

nication, knowledge representation and sharing, as

well as reasoning, are needed. Since there is a vast

amount of existing communication frameworks, the

focus of this paper is set to knowledge sharing, knowl-

edge representation, and reasoning. A straightforward

solution for knowledge sharing would be the use of a

central database in the smart environment. However,

this would introduce a single-point-of-failure and a

bottleneck to the system. Furthermore, the distance

to the central database would increase the latency and

could cause network congestions if too many parties

access the central point simultaneously. Thus, a cen-

tral database would not scale and not be suited for

large-scale environments like Smart Cities. There-

fore, a distributed multi-agent based knowledge reg-

istry has been proposed in (Jakob et al., 2020). In

brief, the agents organise themselves in a B*-tree.

While the inner nodes of the tree manage the struc-

ture of the tree, forward queries, and incorporate fur-

ther nodes, the leaf nodes maintain the knowledge and

answer queries. The distributed knowledge registry is

based on a non-monotonic reasoning formalism, that

supports efﬁcient knowledge representation, storage,

and reasoning.

A further challenge in a smart environment in

which humans and robots interact is the use of com-

monsense knowledge and the symbolic representa-

tion of the environment. Humans rely on their com-

monsense knowledge to solve everyday tasks (Davis,

2014) and rely on symbols to abstract their environ-

ment. For example, a cup is a symbol for an object,

which can hold liquids, is used for drinking, is often

made of pottery, and has a handle. Hence, a service

robot, which interacts with a human should have ac-

cess to a source of commonsense knowledge, such

as ConceptNet (Speer et al., 2017). These sources

represent knowledge as a graph of symbols, that are

connected by relations. However, these sources are

typically not able to reason about the represented

knowledge. We claim that the combination of non-

monotonic reasoning with such symbols is particu-

larly suited for communication between robots and

humans. A non-monotonic approach allows for the

538

Jakob, S., Jahl, A., Baraki, H. and Geihs, K.

Generating Commonsense Ontologies with Answer Set Programming.

DOI: 10.5220/0010191905380545

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 538-545

ISBN: 978-989-758-484-8

dynamic adaptation of the knowledge during run-

time, which is an important requirement in dynamic

environments. For example, a robot has to its knowl-

edge or retract derived knowledge if human provides

further information.

The main contribution of this paper is, therefore,

a non-monotonic ontology generation method which

supports the dynamic incorporation of commonsense

knowledge. Furthermore, the resulting ontology can

be altered during run-time without any need to rebuild

the complete ontology.

Section 2 introduces the non-monotonic ontology

generation, which is evaluated in Section 3. Related

works are discussed in Section 4. Section 5 sum-

marises the paper and presents future work.

2 ASP ONTOLOGY MODELLING

This section presents the main contribution of this

paper, which is the automatic generation of com-

monsense ontologies with Answer Set Programming

(ASP) (Gelfond and Kahl, 2014). Section 2.1 shows

the ﬁrst step, namely the extraction of the common-

sense knowledge from a hypergraph-based knowl-

edge source like ConceptNet 5 (CN5) (Speer et al.,

2017) and the translation into basic ontology rules.

This is followed by a description of the ontology in-

ference rules in Section 2.2 and the characterization

of facets in Section 2.3. A graphical tool to adjust the

resulting ontology is discussed in Section 2.4.

2.1 Ontology Extraction

The ﬁrst step in the automatic generation of the com-

monsense knowledge is the extraction and translation

of the knowledge from a hypergraph-based knowl-

edge source. The general approach is to provide a

root concept for the ontology and to traverse the hy-

pergraph until no further edges adhere to a given set of

stopping criteria. Algorithm 1 presents this automatic

extraction and translation.

This algorithm receives a root concept c

, a set of

ontology relations R

, a set of relations that represent

synonyms R

, a set of relations denoting properties

, and stopping criteria SC as input. In the ﬁrst step,

an adapted breadth-ﬁrst search (BFS) is applied. Dur-

ing this step, the BFS starts at c

and selects edges,

which are annotated with the relations given in R

and

adhere to the stopping criterion SC

. For example, a

taxonomy could be created by only using the IsA re-

lation of CN5 and relying on the edge weight of CN5

as a stopping criterion. By adjusting SC

, edges could

Algorithm 1: Ontology Extraction.

Input : Root Concept c

Set of Ontology Relations R

Set of Synonymic Relations R

Set of Property Relations R

Set of Stopping Criteria SC

Output: ASP Commonsense Ontology o

asp

1 <C, E>:=

adaptedBreadthFirstSearch(c

, R

, SC

)

2 E := E ∪ getSynonyms(C, R

, SC

)

3 E := E ∪ getProperties(C, R

, SC

)

4 o

asp

:= translate(C, E)

be included into or excluded from the taxonomy. Af-

ter the BFS, sets of all encountered concepts C and

edges E are returned. Since synonyms are an impor-

tant part of natural language, synonyms for all con-

cepts in C are determined and the resulting edges that

adhere to SC

are added to E. One example is shown

in Figure 1. Pup is a synonym for puppy and hence

added in this step. In the third step, the properties of

each concept are extracted using the relations given

in R

. After these steps, the gathered edges in E and

concepts in C are translated into ASP.

1 # e xte rnal cs_is A (" d og " , " pe t " ,136 ) .

2 weight (136 ,668 ,0) : - cs _ i s A ( " dog " ,

" pet " ,136) .

3 # e x ter n al cs_isA (" p u ppy " , " do g " ,139) .

4 weight (139 ,568 ,0) : - cs _ i s A ( " p u ppy " ,

" dog " ,139) .

Listing 1: Excerpt from the Commonsense Ontology.

Listing 1 shows an excerpt from the edges in Fig-

ure 1 translated into ASP. Each edge is represented

by an External Statement and an auxiliary rule. Ex-

ternal Statements are a feature provided by the ASP

solver Clingo (Gebser et al., 2014), which enables

the dynamic adaptation of the truth value of a pred-

icate. Line 1 expresses that it is commonsense (cs )

that a dog is a pet. The External Statement contains

a unique identiﬁer, which is used to link it with the

head of the auxiliary rule. This rule is used to repre-

sent the dynamically adaptable weight, for example,

the edge weight in the case of CN5 since it can be

seen as the reliability of the knowledge represented by

the edge. As long as the External Statement is set to

true, the weight predicate in the head can be derived.

The weight predicate has three values. The ﬁrst is the

unique id. The second is the weight multiplied with

100 since ASP can only handle integer values. The

last value is a timestamp, which will be used in the

ontology inference rules presented in Section 2.2. If

the External Statement is set to false, the weight and

Generating Commonsense Ontologies with Answer Set Programming

539

Synonym 2.0pup IsA 5.68

IsA 2.86

puppy

immature

dog

loyal

friend

IsA 3.17

IsA 6.65

IsA 6.68

dog

IsA 4.56

pet

Has

Property 4.0

animal alive

IsA 1.0

quadruped

IsA 1.0

four

legged

animal

IsA 5.60

poodle

IsA 4.17

beagle

Figure 1: Excerpt from the CN5 Hypergraph.

the External itself will not be derived in the next solv-

ing step.

2.2 Ontology Inference Rules

After the generation of ASP rules representing the

commonsense knowledge, inference rules are needed

to create an ontology and allow the application of the

commonsense knowledge to individuals. These in-

ference rules are summarized in a second ASP pro-

gram. It consists of six major parts: weight handling,

commonsense propagation, determination of subsets,

classiﬁcation, facet handling, and Answer Set size re-

duction. Due to limited space, only excerpts from the

weight handling, the commonsense propagation, clas-

siﬁcation, and Answer Set size reduction are shown.

Listing 2 presents an excerpt from these infer-

ence rules. Line 1 is used to determine the current

weight for each translated edge based on the maxi-

mum timestamp (MaxTS). This enables the dynami-

cal adaption of edge weights, for example, by human

interaction. The use of a unique id allows mapping

the resulting predicates to the corresponding edges.

Line 2 and 3 are used to propagate commonsense

knowledge. In Line 2, the predicate is is used to

mark an initial classiﬁcation of an individual (Ind),

e. g., given by a human user or an image classiﬁca-

tion. If the initial classiﬁcation ﬁts a commonsense

knowledge predicate via the FromC variable, further

classiﬁcations can be derived. For example, consid-

ering the initial classiﬁcation is("rex","puppy")

and that it is commonsense knowledge that a puppy

is a dog (Figure 1), it can be derived that rex is a

dog, too. Line 3 shows further commonsense prop-

agation, which is achieved by using already derived

propagations and further commonsense knowledge.

To stop this propagation, the stopping criteria are

used. For example, the edge weights extracted from

CN5. Since these weights represent the reliability of

the edge, only those edges with an increasing weight

one should be used for the propagation to achieve

reliable results. Following lower or equal weights

could result in an exhaustive traversal of the hyper-

graph and, thus, an impractical or cyclic classiﬁca-

tion. Line 4 and 5 are used to represent the ﬁnal

classiﬁcation in a human and machine-readable for-

mat. Therefore, the rules like the one presented in

Line 4 create an internal representation of the clas-

siﬁcation. Based on this internal classiﬁcation, the

rule in Line 5 derives the ﬁnal classiﬁcation annotated

with the highest weight for each classiﬁcation. The

last part of this excerpt is the reduction of the Answer

Set size. Therefore, the #show directive of Clingo is

used, which limits its output to the respective predi-

cates with the given arity. Thus, Line 6 reduces the

output to all classifiedAs predicates, which have

the arity three. Applying these rules on the common-

sense knowledge presented in Figure 1 and the ini-

tial classiﬁcation is("rex","puppy") will result in

the following classiﬁcation: rex is a puppy, a dog, a

loyal friend, and a pet.

1 cu r re n tW e ig h t ( Id ,Weight , M a xTS ) : -

MaxTS = # max { Time S t ep :

weigh t ( Id ,_ , Ti m e Ste p ) } ,

weigh t ( Id , Weight , MaxTS ) .

2 isA ( Ind , ToC , Weigh t ): - is ( Ind , FromC ) ,

cs_is A ( FromC ,ToC , Id ) ,

cu r re n tW e ig h t ( Id , Weight , MaxTS ) .

3 isA ( FromC , ToC , Weight 2 ) : - isA ( FromC ,

InterC , W e i ght 1 ) , cs_i s A ( Inter C ,

ToC , Id ) , cur r e n tW e ig h t ( Id ,

Wei g ht2 , M axTS ) , W eight1 < W e igh t 2 .

4 cl a s s i f ie d A s I n te r n a l ( FromC ,ToC ,

Max W eig h t ) : - M a xW e i gh t = # ma x {

Weigh t : isA ( FromC , ToC , Weig h t ) } ,

isA ( FromC ,ToC , _ ) , is ( FromC , _ ) .

5 cl a ss i fi e dA s ( FromC , ToC , Ma x We i g ht ): -

Max W eig h t = # max { Weigh t :

cl a s s if i e d A s In t e r n a l ( FromC , ToC ,

Weigh t )} , c l a s s if i e d A s In t e r na l (

FromC ,ToC , _ ) .

6 # show c la s si f ie d As / 3.

Listing 2: Excerpt from the Inference Rules.

2.3 Facets

Facets are an important part during the creation of

an ontology since they allow the deﬁnition of types,

values, ranges, sub-properties, and domains. Hence,

they provide the tools to further describe concepts and

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

540

their properties given in an ontology. To demonstrate

the creation of facets, the ontology shown in Figure 1

is expanded with the edge stating that a dog has the

property coat colour. An example set of facets for

the property coat colour is shown in Listing 3.

1 # e x ter n al facet O f ( " colo u r " ,

" c oa t _c o lo u r " ) .

2 # e x ter n al typeOf (" co lour " ,

" c oa t _c o lo u r " ," stri n g ") .

3 # e x ter n al va l ue R an g eO f ( " colou r " ,

" c oa t _c o lo u r " ," 0{ black ; grey ;

brown ; white ; bri n d le }1 ") .

4 pr o p e rt y V i ol a t i on ( I n d i v i d ual ,

" c o l our " , " co a t_ c ol o ur " , " To o

many Val u e s " ) : - X = # c ount {

Value : ha s Val u e ( I n dividual , "

colou r " ," c oa t _c o lo u r " ,Value ,_ ) } ,

has V a lue ( I n d i v i d u al , " colo u r " ,"

co a t _c o lo u r " ,_ , _ ) , X > 1 ,

va l ue R an g eO f ( " colou r " ,

" c oa t _c o lo u r " ," 0{ black ; grey ;

brown ; white ; bri n d le }1 ") .

5 # e x ter n al hasV a lue (" rex " , " colo u r " ,

" c oa t _c o lo u r " ," brown " ,0) .

Listing 3: Example Facets.

Line 1 of this example is the actual deﬁnition of the

facet. In this case, the property coat colour has the

facet colour, which has the type string as deﬁned in

Line 2. The range of this value can be restricted. This

is achieved by adding Line 3 and the auxiliary rule in

Line 4. Informally speaking, this External Statement

deﬁnes, that the facet colour has to have at least 0

values and at max 1 value for this facet. Either a set

of values or a range can be deﬁned to further restrict

the facet. The colour is restricted to the values inside

the curly brackets. The auxiliary rule in Line 4 is used

to check if the minimum and maximum cardinality of

the values are satisﬁed by counting the respective val-

ues and comparing the count with the cardinalities. A

restriction to the values is granted by a graphical user

interface, which is presented in Section 2.4. The value

of the coat colour of rex is given alongside a times-

tamp in Line 5. Due to limited space, sub-property

and domain facets are omitted in this example.

2.4 Graphical User Interface

To ease the generation and usage of an ASP ontol-

ogy, ARRANGE (Answer set pRogRAmming oNtol-

oGy gEneration) provides a graphical user interface

(GUI) as shown in Figure 2. It supports the auto-

matic extraction of a commonsense knowledge ontol-

ogy (Section 2.1), generates ontology inference rules

(Section 2.2), and supports the creation of facets (Sec-

tion 2.3).

Figure 2: Graphical User Interface.

On the left side, a list of all concepts that are part

of the ontology is given. By selecting one of these

concepts, all edges connected to it are displayed.

Here, new edges can be added, existing ones can

be edited or deleted. Tabs for facets and individ-

uals are available. The last three tabs provide an

overview of the current ASP ontology, the inference

rules, and the results of a solving step, which is

available via the solver menu. The output of the

solver is twofold. The ﬁrst output is the Answer

Set, which is a set of predicates and can be used

for further reasoning processes. It contains all deriv-

able facets, subset relations, and classiﬁcations. Us-

ing the example presented in the previous sections,

the Answer Set includes, amongst others, the pred-

icates hasPropertyValue("rex","coat colour",

"brown") and classifiedAs("rex","pet",668).

The second output is a graph representation of the

Answer Set, which provides an overview of its pred-

icates. The graph representing the Answer Set of the

example used in the previous sections is shown in Fig-

ure 3. Blue arrows indicate facets, black arrows prop-

erties and green arrows subsets. Red arrows denote

the classiﬁcation, for example, rex is classiﬁed as a

dog with a weight of 568.

3 EXPERIMENTS

The evaluation has been conducted on a Lenovo

workstation equipped with an Intel

Core™ i7-7500U

@ 2.70 GHz Dual-Core processor and 16 GB DDR4-

2133 RAM running Ubuntu 18.04.4 with kernel ver-

sion 4.15.0-112-generic. ConceptNet 5.7 and Clingo

version 5.3.1 with gringo 5.3.1 and clasp 3.3.4 were

used.

3.1 Ontology Extraction and Reasoning

The selection of the root concept as well as the set

of stopping criteria (minimal weights when using

CN5) applied in Algorithm 1 determine the size of

the resulting ontology and the run time of its gener-

ation. Therefore, this section analyses three different

Generating Commonsense Ontologies with Answer Set Programming

541

"colour"

"coat_colour"

facetOf

"string"

typeOf

"1{black;grey;brown;white;bridle}1"

valueRangeOf

"dog"

"loyal_friend"

subSetOf[isA, 665]

"pet"

subSetOf[isA, 668]

"rex"

hasFacet

hasProperty[300]

hasPropertyValue["brown"]

"puppy"

subSetOf[is, 1]

classiﬁedAs[568]

"immature_dog"

classiﬁedAs[286]

classiﬁedAs[665]

classiﬁedAs[668]

subSetOf[isA, 286]

subSetOf[isA, 568]

classiﬁedAs[568]

propertyInheritedFrom[subClassOf,300]

Figure 3: Graph Representation of the Classiﬁcation.

root concepts originating from three different areas:

animal, person, and thing. Additionally, different

minimal weight sets are used.

The smallest ontologies have been extracted for a

minimal weight of 2.5. With CN5 as a knowledge

source, this means that at least two veriﬁed sources

were the origin of the edge. Furthermore, only the

minimal weight for the isA relation is changed since

it has the highest number of edges. The remaining re-

lations have a ﬁxed weight of 2.0. The selected root

concept has a big inﬂuence on the size of the extracted

ontology since it determines in which area of the hy-

pergraph the extraction starts. The concept animal

has the highest number of edges (522), the concept

thing has 196 edges, and person the lowest number

of edges (17). Lowering the minimal weight has a

major impact on the size of the ontology since more

edges can be added. Hence, extensive parts of the

hypergraph can be extracted. A minimal weight of

2.0 results in an identical size for all tested root con-

cepts (95353 edges). Lowering the minimal weight

even further results in an additional expansion of the

ontology (201148 edges). Higher minimal weights

are suited to create domain-speciﬁc ontologies while

lower minimal weights will result in more general

commonsense knowledge ontologies.

Besides the size of the ontology, the selection

of the root concept, and the minimal weight affect

the run time of the ontology generation. Again, the

weight for the isA relation is adapted, while the re-

maining weights are ﬁxed at 2.0. The tests have been

executed 20 times and the average has been deter-

mined. The average run time of the ontology genera-

tion mainly depends on the selected minimal weights.

While small ontologies are generated in a few seconds

(animal 142 s, person 4 s, thing 51 s), the genera-

tion for the medium size requires 8097 s for animal,

8199 s for person, and 8142 s thing. The genera-

tion of the largest ontologies takes roughly four hours

(animal 13506 s, person 13341 s, thing 13134 s).

Considering the sizes of these ontologies, the result-

ing run times are acceptable and show the viability

of our approach. On average, the standard deviation

of the measured run times is below 1 %. The genera-

tion of the ontology for the root concept person with

a minimal weight of 2.5 has a standard deviation of

4 %, which is caused by its low run time.

The reasoning process of the presented framework

is divided into seven distinct steps. These include the

adding and grounding of the ontology edges, which

are modelled as External Statements. Since Clingo

assumes External Statements as false after they are

added, they are set to true in the third step. Finally,

the ontology is solved. The queries are ASP programs

themselves, hence, they have to be added, grounded,

and solved, too. In contrast to the ontology, they do

not use External Statements. Table 1 presents the ex-

perimental results for different ontology sizes. The

query used is the classiﬁcation of rex as discussed in

Section 2.2. Again, the values are averaged over 20

measurements.

The lowest run times were measured for a mini-

mal weight of 2.5. Lowering the minimal weight will

result in larger ontologies as explained above. The

measured run times increase linearly with the size of

the measured ontologies, hence, the proposed ontol-

ogy representation is scalable. Adding and grounding

of the ontology have the highest impact on the run

time of the ontology reasoning. This is caused by the

number of ASP rules, which have to be considered.

The run time of the External Statement assignment is

almost neglectable since no reasoning is needed. The

ﬁnal solving step of the ontology reasoning has a low

run time since no complex rules have to be considered

during the ontology reasoning. In general, the run

time of a query is lower than the run time of the ontol-

ogy reasoning. This is caused by the number of rules

that have to be considered in both processes. While

the number of rules increases with the selected mini-

mal weight and root concept, the number of rules for

a query is ﬁxed. Thus, the run time for adding a query

is not inﬂuenced by the ontology size and is almost

identical for all tested combinations. The grounding

and solving steps of a query are affected by the size

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

542

Table 1: Run Time of Ontology Solving and Classiﬁcation Query in [ms].

Min. Weight 2.5 2.0 1.0

Concept animal person thing animal person thing animal person thing

Add Ont. 98.7 9.3 47.6 15730.4 15616.4 15716.7 36300 37003 37020

Ground Ont. 78.9 11.4 30.5 14800.2 14679.5 14769.4 31525 31721.1 31823

Assign Ext. 1.4 0.15 0.6 256.5 247.7 262.9 523.9 520.9 521.7

Solve Ont. 3.9 0.5 1.5 1010.8 1000.3 1005.2 2257.5 2272.3 2271.6

Add Q. 11.6 13.5 11 11.8 11.7 11.8 12.7 13.1 13.1

Ground Q. 78.5 28.5 46.3 9299.6 9331.4 9350.1 19320.3 19566.8 19525.8

Solve Q. 3.5 0.3 1.1 743.1 735.8 740.2 1635.6 1650.1 1637.2

of the ontology. Again, their run times scale linearly

with the size of the ontology. On average, the stan-

dard deviation of all measured run times is lower than

1 % for the largest ontologies and increase to roughly

2.5 % for the smaller ontologies, which is caused by

the low run times. The only outlier is the standard de-

viation of query solving for the concept Person and a

minimal weight of 2.5. Since the measured run time

is extremely low and thus can be inﬂuenced by any

process running on the test system, the standard devi-

ation is roughly 7 %.

3.2 Comparison to OWL

Let us compare the run time of OWL to the run time

of an ASP ontology created by ARRANGE. We trans-

late the well-known Pizza Ontology

into ASP. Her-

miT with version 1.4.3.456 and Protege 5.5.0 are used

for OWL ontology reasoning. An individual with the

class margherita is created in both formalisms and

a classiﬁcation query is applied. In both cases, new

solver instances have been used for each measure-

ment. The shown results are the average of 20 mea-

surements. The ontology reasoning took 82.15 ms

and query resolution 66.01 ms for the created ASP on-

tologies. In comparison, HermiT required 588.15 ms

for the reasoning step and 154.55 ms for the query

resolution. Hence, the reasoning process of the ASP

ontology is roughly seven times faster than the OWL

reasoning. On the one hand, this is caused by the un-

derlying reasoning technique. While SAT-solvers, as

used in ASP, provide fast results, the tableau algo-

rithm of OWL is generally slower but provides bet-

ter support in case of errors. The ASP query is twice

as fast as the OWL description logic query. Both in-

clude the classiﬁcation of an individual, as well as, all

super- and sub-classes.

OWL is the de facto standard for knowledge rep-

resentation in the Semantic Web and is widely used

to model ontologies. OWL in its full speciﬁcation

https://protege.stanford.edu/ontologies/pizza/pizza.owl

(December 3, 2020)

is based on ﬁrst-order logic and undecidable. Thus,

most applications rely on one of the decidable sub-

sets such as OWL DL. The different speciﬁcations of

OWL have in common that no unique names are as-

sumed, that the resulting ontologies are monotonous,

and, that the open-world assumption holds. Since the

unique name assumption is not given in OWL, distinct

names can be given to one individual. Monotonous

reasoning prevents the loss of already derived knowl-

edge; thus, subsequent adaptations of the ontology

may not contradict derived knowledge. The open-

world assumption restricts the reasoning to statements

that are explicitly modelled in the ontology. De-

fault assumptions that may be overwritten by derived

knowledge cannot be deﬁned.

In contrast to OWL, ASP adheres to the unique

name assumption. On the one hand, this prevents to

model distinct individuals with the same name. On

the other hand, it reduces the overall modelling ef-

fort, since explicitly stating that all occurrences of a

name refer to the same individual is unnecessary. Ad-

ditionally, ASP provides non-monotonous reasoning

and supports the closed world assumption enabling

the deﬁnition of defaults which is particularly use-

ful when modelling commonsense knowledge. Fi-

nally, state-of-the-art ASP solvers like Clingo provide

mechanisms to adapt an ontology dynamically and to

enumerate all possible solutions. Hence, the usage of

ASP is suited to model and reason about common-

sense knowledge.

3.3 Applicability

The application of the ontologies extracted from CN5

provides good classiﬁcations as depicted in Figure 3.

However, considering the excerpt from the CN5 hy-

pergraph shown in Figure 1, the classiﬁcation is miss-

ing the classes, e. g., animal. This is caused by

the classiﬁcation rules presented in Section 2.2, since

they consider edges with increasing weight to prevent

impractical classiﬁcations. To tackle this issue, AR-

RANGE provides two ways. The ﬁrst is the adap-

Generating Commonsense Ontologies with Answer Set Programming

543

tation of the corresponding weight with its GUI. It

provides an overview of all edges that are part of the

ontology and enables the adaptation of all weights

during design time. The second option is applied by

adding an additional rule that adjusts the weight of the

corresponding edge. This rule has to be modelled like

the Lines 2 or 4 of Listing 1 and has to have a higher

timestamp than the current weight rule. For exam-

ple, the weight of the edge between pet and animal

shown in Figure 1 could be set to 7.0. Subsequently,

rex is classiﬁed as an animal and inherits the prop-

erty alive.

4 RELATED WORK

The presented related work is divided into two main

categories. The ﬁrst one focusses on the extrac-

tion of ontologies from existing knowledge sources,

while the second category focusses on ASP as on-

tology language and reﬂects upon tool support for

the generation of ontologies. The general idea of

an ontology is to provide a standardised terminology

to represent knowledge which supports the collabo-

ration of different parties. In comparison to other

knowledge sources like databases, data warehouses,

and knowledge graphs, ontologies support the def-

inition of properties, the restriction of values, arbi-

trary logic constraints, and automatic reasoning. Fur-

thermore, ontologies are declarative and do not rely

on customized interpretations. They provide formal

axioms and well-deﬁned semantics, which is essen-

tial for the interaction of agents in heterogeneous and

human-populated environments. However, the afore-

mentioned knowledge sources can serve as a seed for

the creation of an ontology, which is a reason for

extensive research on automatic and semi-automatic

converters.

A common approach to store and manage data is

the use of databases or data warehouses. Databases

and data warehouses contain tables, which consist

of named columns and store data points in the cor-

responding rows. Columns of different tables can

refer to each other and, thus, establishing relations

between them. Relying on this scheme, ontologies

can be generated. There are numerous approaches

that realise this methodology using relational SQL

databases and data warehouses (Zhou et al., 2010;

Kiong et al., 2009; Al Khuzayem and McBRIEN,

2016; da Silva et al., 2016; El Idrissi et al., 2013).

In general, these works build upon a set of predeﬁned

rules which are used to transform a database scheme

into an ontology. This includes the translation of table

names into ontology classes, ﬁeld or column names

into properties, and rows into individuals. Further-

more, semantics are added to the ontology. For exam-

ple, Kiong et al. (Kiong et al., 2009) mark, amongst

others, bridge tables, reference tables, and reference

ﬁelds. Zhou et al. (Zhou et al., 2010) identify these

references automatically and map them to the corre-

sponding relations. Additionally, they set the cardi-

nality of unique, nullable, and not-nullable properties

accordingly. In (Al Khuzayem and McBRIEN, 2016),

further features such as subclass relations and sym-

metric and reﬂexive properties are added.

Although the presented approaches achieve good

results, the expressive power of the resulting ontolo-

gies and the ﬂexibility of their methodology is lim-

ited. Databases usually comprise a small number

of tables and, thus, only a few classes are gener-

ated. Hence, the number of resulting relations is re-

stricted to a few references between tables, if they

are explicitly stated. Furthermore, the generated on-

tology strongly depends on the design decisions for

the database and will mainly consist of individuals in-

stead of classes. ARRANGE, in comparison, gener-

ates ontologies consisting of a vast amount of classes

based on a given hypergraph.

As opposed to these approaches, ARRANGE

automatically extracts a commonsense ontology

from a given hypergraph. Similar to OntoHar-

vester (Mousavi et al., 2013), it relies on a given seed

class to start the ontology extraction but is able to de-

rive subclasses based on the structure of the used hy-

pergraph. ARRANGE supports the manual adaption

of ontology parts during the design time and the run

time of the ontology. Furthermore, ARRANGE en-

ables reasoning, since it utilises ASP.

In general, numerous approaches exist that ex-

tract knowledge graphs, which are hypergraphs, from

a given free text or from semi-structured knowl-

edge (Paulheim, 2017). Many of these may be re-

ﬁned by crowds-based approaches or experts such as

in case of CN5.

However, there is no axiomatic semantics and no

reasoning support. Thus, it is beneﬁcial to transfer the

hypergraph to an appropriate knowledge representa-

tion. In (Kr

otzsch, 2017), Kr

otzsch lists requirements

for such a knowledge representation. One of them

is the existence of negation, which, for example, en-

ables the deﬁnition of a class based on the absence

of information. Description logics such as OWL do

not provide negation as failure, are monotonic, and

adhere to the open-world assumption. Kr

otzsch em-

phasises that description logics do not sufﬁciently ad-

dress these requirements and recommends a declara-

tive symbolic knowledge representation in the context

of a computation paradigm instead of pure represen-

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

544

tation (Kr

otzsch, 2017). ASP with its non-monotonic

reasoning capabilities, different kinds of negation,

support of the closed world assumption, and its sym-

bolic representation is a suitable formalism to tackle

these issues. Hence, ARRANGE uses ASP to repre-

sent commonsense knowledge as ontologies, to sup-

port reasoning, and declarative programming.

OntoDLV (Ricca et al., 2009) uses an extension

to basic ASP (OntoDLP) to model ontologies. For

example, classes are declared by expanding predicate

names with the key phrase class. OntoDLP supports

the deﬁnition of individuals, relations, modules, and

the creation of lists and sets. Besides these constructs,

OntoDLP allows to model taxonomies by adding the

keyword isa enabling the generation of a class based

on inheritance and a set of attributes. Furthermore,

OntoDLV provides a graphical modelling tool to sup-

port the creation of an ontology and allows the incor-

poration of OWL atoms.

In contrast to OntoDLV, ARRANGE does not rely

on an extended version of ASP and uses the ASP-

Core-2 standard. Additionally, External Statements

provided by Clingo are used to create an ontology,

which can be dynamically altered during run time.

5 CONCLUSIONS

In this paper, we have presented a framework to auto-

matically extract ontologies from a hypergraph-based

knowledge source like CN5. The resulting ontolo-

gies are formulated using the non-monotonic reason-

ing formalism ASP that supports dynamic adaptations

of the ontology during run-time and the deﬁnition of

defaults. The presented experiments proved that the

combination of ARRANGE

with the commonsense

knowledge source CN5 results in an adaptable and ex-

tensive commonsense knowledge ontology. The gen-

eration process itself is conﬁgurable and allows to ex-

tract different parts of the hypergraph.

Due to the size of the resulting ontologies, we plan

in the future work to create an efﬁcient distributed ac-

cess and automatic distribution of individuals based

on the ontology using the distributed and multi-agent-

based knowledge management presented in (Jakob

et al., 2020). This knowledge management will be

evaluated in a search and rescue scenario, which in-

corporates several heterogeneous robots and UAVs.

Furthermore, we extend the comparison to OWL by

translating further ontologies.

https://bitbucket.org/sjakob872/arrange/src/master/,

(December 3, 2020).

REFERENCES

Al Khuzayem, L. and McBRIEN, P. (2016). OWLRel:

Learning Rich Ontologies from Relational Databases.

Baltic Journal of Modern Computing, 4(3):466.

Brady, G., Sterritt, R., and George, W. (2015). Mobile

Robots and Autonomic Ambient Assisted Living. Pal-

adyn: Journal of Behavioral Robotics, 6.

da Silva, T. O., Bai

ao, F. A., and Revoredo, K. (2016). On-

toDW: An Approach for Extraction of Conceptualiza-

tions from Data Warehouses. In ONTOBRAS, pages

83–94.

Davis, E. (2014). Representations of Commonsense Knowl-

edge. Morgan Kaufmann.

El Idrissi, B., Ba

ına, S., and Ba

ına, K. (2013). Automatic

Generation of Ontology from Data Models: A Practi-

cal Evaluation of Existing Approaches. In IEEE 7th

International Conference on Research Challenges in

Information Science (RCIS), pages 1–12. IEEE.

Gebser, M., Kaminski, R., Kaufmann, B., and Schaub,

T. (2014). Clingo=ASP+Control: Extended Report.

Technical report, Knowledge Processing and Informa-

tion Systems.

Gelfond, M. and Kahl, Y. (2014). Knowledge Representa-

tion, Reasoning, and the Design of Intelligent Agents:

The Answer-Set Programming Approach. Cambridge

University Press, Cambridge, USA.

Jakob, S., Jahl, A., Baraki, H., and Geihs, K. (2020). A Self-

Organizing Multi-Agent Knowledge Base. Accepted

for publication at IEEE ICWS 2020.

Kiong, Y. C., Palaniappan, S., and Yahaya, N. A. (2009).

Health Ontology Generator: Design And Implemen-

tation. IJCSNS, 9(2):104.

otzsch, M. (2017). Ontologies for Knowledge Graphs?

In 30th Int. Workshop on Description Logics, volume

1879. CEUR-WS.org.

Mousavi, H., Kerr, D., Iseli, M., and Zaniolo, C. (2013).

Ontoharvester: An Unsupervised Ontology Generator

from Free Text. Technical report, InCSD Technical-

Report 130003, UCLA.

Paulheim, H. (2017). Knowledge Graph Reﬁnement: A

Survey of Approaches and Evaluation Methods. Se-

mantic web, 8(3):489–508.

Ricca, F., Gallucci, L., Schindlauer, R., Dell’Armi, T.,

Grasso, G., and Leone, N. (2009). OntoDLV: An ASP-

based System for Enterprise Ontologies. Journal of

Logic and Computation, 19(4):643–670.

Speer, R., Chin, J., and Havasi, C. (2017). ConceptNet 5.5:

An Open Multilingual Graph of General Knowledge.

In Proceedings of the 31st AAAI Conference on Artiﬁ-

cial Intelligence, pages 4444–4451.

Zhou, S., Ling, H., Han, M., and Zhang, H. (2010). On-

tology Generator from Relational Database Based on

Jena. Computer and Information Science, 3(2):263–

267.

Generating Commonsense Ontologies with Answer Set Programming

545
