Sentence Boundary Detection in German Legal Documents

Ingo Glaser

, Sebastian Moser and Florian Matthes

Chair of Software Engineering for Business Information Systems, Technical University of Munich,

Boltzmannstrasse 3, 85748 Garching bei M

unchen, Germany

Keywords:

Sentence Boundary Detection, Natural Language Processing, Legal Document Analysis.

Abstract:

Sentence boundary detection on German legal texts is a task which standardized NLP-systems have little or no

ability to handle, since they are sometimes overburdened by more complex structures such as lists, paragraph

structures and citations. In this paper we evaluate the performance of these systems and adapt methods directly

to the legal domain.

We created an annotated dataset with over 50,000 sentences consisting of various German legal documents

which can be utilized for further research within the community. Our neural networks and conditional random

ﬁelds models show signiﬁcantly higher performances on this data than the tested, already existing systems.

Thus this paper contradicts the assumption that the problem of segmenting sentences is already solved.

1 INTRODUCTION

For a human being, the segmentation of a given text

into sentences is a rather easy task. However, when

trying to summarize this segmentation in rules, which

could be utilized by a machine, one quickly realizes

how complex this task actually is. On the other side,

sentence boundary detection (SBD), which is the task

for a machine to detect sentence boundaries, is an im-

portant processing step in almost any natural language

processing (NLP) task. As a result, SBD has a long

history of research (Read et al., 2012) within the com-

munity of NLP.

Many SBD papers exist and reveal high perfor-

mances. (Read et al., 2012) provide an excellent and

comprehensive overview of such systems. Thus, one

could see the problem of SBD as solved. On the other

side, domains such as the legal domain signiﬁcantly

differ from normal texts encountered daily. Content,

structure, and language are vastly different and more

difﬁcult to comprehend. This is not only a problem

for every layman who tries to understand those laws

but also for a software system processing these texts.

There is no universal structure inherent to all texts,

which leads to a performance decrease when process-

ing structurally different documents without a ground

truth.

As already stated, the structure and contents of a

legal text differ from a normal text and even within the

https://orcid.org/0000-0002-5280-6431

legal domain there is a vast variation of documents.

The basic assumptions previously made when deal-

ing with SBD are not always applicable in the legal

domain. For example, it is often deﬁned as an abbre-

viation disambiguation task, which is only a partial

solution in the legal domain. Here a sentence is not

always linked to dots and other characters denoting

an abbreviation.

That is why many researchers reported difﬁcul-

ties with standard NLP tools in the legal domain.

(Wyner, 2010) achieved promising results when ex-

tracting rules from regulatory texts but also encoun-

tered problems with the Stanford Parser while pro-

cessing different phrase structures. ”Linguistic indi-

cators, structure, and semantic interpretations which

interact with domain knowledge” (Wyner and Pe-

ters, 2011) are utilized by legal experts, but a com-

puter is not entirely capable of modelling or utiliz-

ing those pieces of information. The legal domain

poses issues for automation of legal work because a

”large amount of linguistic, domain, and communica-

tive knowledge” (Moens, 2001) is needed for tasks

such as information retrieval. Furthermore, various

research in the ﬁeld of AI&Law, revealed issues with

SBD for the legal domain. (Ashley, 2017) provides a

comprehensive overview of the most recent research

in this area.

For this research, we formulated the research hy-

pothesis, that SBD is not perfectly solved and requires

adaption of existing methods, particularly for the Ger-

812

Glaser, I., Moser, S. and Matthes, F.

Sentence Boundary Detection in German Legal Documents.

DOI: 10.5220/0010246308120821

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 812-821

ISBN: 978-989-758-484-8

man legal domain. One could even generalize this hy-

pothesis across all domains and claim that with rising

complexity there might be a need to re-evaluate previ-

ous sentence segmentation systems on complex texts.

Therefore, we structured our paper as follows. After

this introduction, Section 2 describes the taxonomy of

sentences used in this paper. In Section 3 we describe

and publish a dataset from the German legal domain

to train and evaluate SBD systems. This dataset is not

just used for this purpose, but shall be also used within

the community for further research. Our experiments

are described in Section 4, while the evaluation, in-

cluding an error analysis, is discussed in Section 5.

Finally, this paper concludes with Section 6.

2 LEGAL SENTENCE

BOUNDARY DETECTION

Most of the time, legal documents are structured in

smaller parts such as paragraphs, clauses, and so on.

Their content is often only loosely linked to the other

parts of the text. Sentences are long and might incor-

porate complex structures such as lists. Even within

one legal document type (such as judgments or laws)

there does not exist a uniform formatting style or

structure. These are all problems a sentence segmen-

tation system has to deal with in order to produce pure

sentences from the mixture of such distinct textual

units. As a result, a corpus constituting German le-

gal documents requires different approaches, partic-

ularly a different notion of sentences, in contrast to

other domains. That includes not only diverse do-

mains, but also different languages as the legal sys-

tem varies heavily between countries. Therefore, in

the following the taxonomy utilized in this paper is

discussed.

A sentence can be seen as “a sequence of tokens

[...] that together form a full stand-alone grammatical

sentence” (Savelka and Ashley, 2017b). Translating

this to the legal domain is not trivial. There are a lot

of different textual structures which do not ﬁt this def-

inition, but still need to be treated as stand-alone or in-

dependent segments of text. Thereby, distinguishing

structural information from normal text is a signiﬁ-

cant challenge.

As a result, we came up with an own taxonomy

of sentences for German legal documents. That tax-

onomy is described in the remainder of this section.

A textual part of a legal document is seen as a sen-

tence if its combination with the next or previous sen-

tence destroys that sentence’s meaning or adds unre-

lated pieces of information. This is the basis of all

the sentence boundary decisions made in the follow-

ing section. This does also align with the critique by

Read et al. (Read et al., 2012), who saw the focus of

sentence boundary detection on sentence terminating

characters as an oversimpliﬁcation.

To deﬁne a rule set for sentence boundaries, the

collected documents were analyzed and the different

types of sentences extracted. The following sentence

categories are heavily inﬂuenced by Savelka and Ash-

ley (Savelka and Ashley, 2017a) but adapted to the

German legal domain. They are motivated by the def-

inition found above and deﬁne the basis for the all the

annotations.

Most of the sentences found in legal documents

are standard sentences, i.e. they have a subject, ob-

ject and verb in the right grammatical order. Addi-

tionally, they are concluded by a sentence-terminating

character such as a period, semi-colon, question or an

exclamation mark.

Another structure very closely related to standard

sentences are linguistically transformed sentences,

which are in some way altered, but still have the basic

building blocks of a standard sentence. By changing

the word order or making other small adjustments,

these sentences can be transformed into a standard

sentence.

There are more complex structures in legal texts,

all collected in the category of special sentences.

Those are linguistic units with stand-alone content

that cannot be incorporated into other sentences. The

following paragraphs describe those different textual

units which are considered sentences in legal docu-

ments if not stated otherwise.

Headlines are one of the most common textual

units found in legal documents. They are used to de-

termine the structure of the text and to show which

parts of the documents are related to another, thus

they convey crucial information to understand the

overall structure of the text.

Citations are often part of judgments and thus

need to be addressed in this paper. They are used

to link different documents and passages. Citations

in the middle of a sentence are not annotated (if they

are not a sentence on their own), otherwise they are

treated normal sentences with additional tokens at the

beginning and the end. Ellipses/Parentheses are an-

notated in the same way.

One of the most obvious structures in legal docu-

ments are lists, which have a wide variety of different

types. Lists of stand-alone sentences or alternative

sentence ends convey no message beyond their own

list entry. Thus, they are annotated as individual sen-

tences. Another variation of lists are enumerations.

They consist of short entries, which lack a verb or a

concluded operation. These lists can be found in sen-

Sentence Boundary Detection in German Legal Documents

813

tences with a variable middle part, e.g. there are dif-

ferent possible subjects or objects for a clause. The

list items are not individual sentences but form one

whole sentence because they do not conclude any ac-

tion. All of those list variations may start with a sen-

tence concluded by a colon which is then individually

annotated. Lists of lists are treated in a recursive way

and the decision on the sentence boundary is based

on the sub-entries. If one entries consist of multi-

ple sentences, each is individually annotated. These

rules follow de Maat (de Maat, 2012) who states that

lists can form “single sentences [...] [though] the list

items are often referenced separately”. This more ﬁne

grained segmentation is motivated despite the fact that

thus incomplete sentences can be created.

Deﬁnitions are a combination of a headline and

(multiple) sentences, thus their individual parts are

annotated accordingly. Data ﬁelds which hold the

information about dates, people, locations, etc. and

case names are similar. Endnotes/Footnotes can also

be seen as a combination of headline and sentences.

Page numbers are, if not already removed from

the text, only annotated if they are found between two

sentences.

Mixed cases of all the previous structures are also

possible. The described textual units are only the ba-

sic building blocks found in a legal document. There

is a large amount of variation even within the same

legal document type. In such cases, the smaller seg-

mentation is chosen, e.g. in a list which combines

an enumeration and a list, the individual parts of the

enumeration would also be annotated as sentences to

avoid any inconsistency within the list.

The aim of this paper is not to create the perfect

deﬁnition for a sentence in the legal domain but to cre-

ate a logical, consistent and practical rule set to work

with. This paper sometimes produces textual parts

which cannot be described as complete sentences in

a grammatical way because they are lacking essen-

tial parts of speech. But those segments are needed

for further processing steps, as overall they reduce the

complexity of the given text part.

Table 1 provides a few examples for the different

types of special sentences based on our taxonomy. As

such examples can be quite complex, we provide the

reference to selected norms from the German Civil

Code (BGB).

3 DATASET

In order to get a broad overview about the perfor-

mance of SBD in the (German) legal domain, a di-

verse set of different documents was collected. The

main focus was on judgments and laws with around

20,000 sentences each, but privacy policies (PRVs)

and terms of services (ToS) are also part of the col-

lection. The dataset consists of approximately 52,000

sentences. The judgments and laws are used for train-

ing and the other document types mainly for valida-

tion and testing.

The dataset contains the BGB, the German Consi-

titution (GG), Code of Social Law (SGB) 1 to 3 and

the Criminal Code (StGB), with the BGB being by

far the longest text. We have made this speciﬁc selec-

tion of laws on purpose to capture a broad variety of

different areas of law with it’s distinct linguistic char-

acteristics.

The judgments were collected from the website

Bayern.Recht

, which is a collection of many judg-

ments from Bavarian courts. They are from different

legal domains and courts (Verfassungs-, Ordentliche,

Verwaltungs-, Finanz-, Arbeits- and Sozialgerichts-

barkeiten) and thus have a wide difference in struc-

ture and content. The PRVs of major tech companies

were collected and the ToS of online shops gathered

by Koller (Koller, 2019) are also used. A detailed

statistic on the documents and the number of sentence

boundaries can be seen in Table 2.

The documents are annotated with the help of an

already existing online annotation tool developed by

Savelka (not published yet) and later on with a newly

created graphical user interface which is also used to

display and analyze the classiﬁcation results. The last

non-punctuation token or word in every sentence is

annotated as the end of the sentence. Each document

is saved as a separate JSON ﬁle containing the text

and the sentence boundary annotations with their po-

sition in the text. The annotations, based on the taxon-

omy described in Section 2, were performed by three

researchers. For this purpose an annotation guideline

based on the mentioned taxonom was utilized. Each

researcher annotated 33.33% percent of the whole

corpus, while we randomly selected 10.00% of each

annotator and assigned it additionally to all the other

two annotators. As a result, each annotator annotated

36.66% of the complete corpus and 9.99% were an-

notated three times. Table 3 reports on the numbers

which are relevant for the inter-annotator agreement

for this threefold annotated part of the corpus.

Annotator A is a data science student with three

years of experience in NLP applied to the legal do-

main. Annotator B is a PhD student in NLP with re-

search focus on the application of legal court rulings.

The third annotator C is a legal expert working with

a working experience of 10 years. For this work, we

report the inter-annotator agreement by means of the

See https://www.gesetze-bayern.de/

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

814

Table 1: Some special examples from the sentence taxonomy.

Type Examples

Identical sentence start §55a, §79, §104, §126b, §199(1), §199(3), §212, §271a(2), §286

Variable sentence middle §207(1), §312h, §350, §438, §505a, §575, §595(1)

Enumerations

Standard §58, §75, §81, §101, §197, §204, §207, §271a(5)

Sentences §98, §310, §502(3), §576, §569, §651h(4), §1059a

Deﬁnitions §308, §309

List of lists §204, §207, §305a, §308, §309, §312, §356

Footnotes & Ofﬁcial notes §14, §241a, §247, §271a, §275, §286, §288, §304, §308, §310

Table 2: Statistics on the dataset created per document type.

Document type # Documents # Sentences # Tokens

Laws 13 20,322 498,403

Judgments 131 21,484 518,052

Privacy Policies 11 2,186 53,552

Total 255 52,289 1,245,536

Table 3: Inter-Annotator agreement for the sentence bound-

aries.

Boundary No Boundary Total Tokens

A 5,229 119,325 124,554

B 5,104 119,450 124,554

C 4,818 119,736 124,554

Kappa coefﬁcient (Cohen, 1960). As we had three

human annotators, we utilized the Fleiss Kappa coef-

ﬁcient (Fleiss, 1971). Based on the annotations shown

in Table 3, p

boundary

is 0.0405 and p

no boundary

0.9594. Therefore, P

equals to 0.9222. In a next step,

for each of the 124,554 tokens the respective P

token

was calculated. As only two possibilities are possible

for each token (either all three annotators agreed, or

one annotator had a different perception) this value is

either 1.0 or 0.33. A discrepancy was found in 411

cases and thus the sum of P

is 124,278.63 resulting

in a P of 0.9978. This numbers were used to calculate

a Fleiss Kappa k of 0.9716.

Hence, the created corpus can be seen as very re-

liable. Additionaly, a manual inspection of the dis-

crepancies has shown that the legal expert ocassion-

ally did not annotate tokens such as headlines, which

represent a sentence boundary according to our guide-

line. This fact is also suggested by the overall lower

number of annotated boundaries by that annotator as

shown in Table 3.

Furthermore, sometimes typographical errors

were encountered and repaired to the extent possible.

In order to allow better processing later on, structural

information linked to a sentences is kept with the sen-

tence, e.g. the clause number in a paragraph is always

part of the ﬁrst sentences of that clause. Thus, it is

possible to reconstruct the original text if desired.

4 EXPERIMENTAL SETUP

SBD is a common pre-processing step which can be

found in almost any NLP framework. The tested,

existing methods in this paper are chosen based on

the reported performance by Read et al. (Read

et al., 2012). OpenNLP

had the best overall per-

formance on the combined dataset without any pre-

processing. The sentence segmentation module from

NLTK (Loper and Bird, 2002) is the only unsuper-

vised approach with a performance levels comparable

to the supervised approaches and a high robustness.

Unfortunately the best reported method on all individ-

ual datasets tokenizer could not be found and conse-

quently not tested, but the reported performance dif-

ference is only marginal. Hence, it was not necessary

to re-implement this method manually. The before-

mentioned methods are used as a baseline. We have

to stress that most older methods focus on sentence

boundaries found on sentence terminating characters,

thus especially NTLK is at a disadvantage in the legal

domain.

For the method chosen in this paper an aggres-

sive tokenizer is used, also utilized in other research

(Savelka and Ashley, 2017b). Words, numbers and

special characters are separated from one another. For

example, abbreviations are split from their terminat-

ing dot, thus making no previous, maybe misleading

See https://opennlp.apache.org/

Sentence Boundary Detection in German Legal Documents

815

assumptions. In this processing step, all escape se-

quences except the newline sequence is removed be-

cause it might indicate the boundary of certain tex-

tual structures such as headlines. These decisions are

motivated by the many ways legal documents can be

structured or written in. In most cases it is not possi-

ble to determine every possible writing style and com-

bination of special characters in advance.

4.1 Conditional Random Fields

As conditional random ﬁelds (CRF) (Lafferty et al.,

2001) are commonly used for sequence modelling,

i.e. assign labels for the items in a possibly correlated

input sequence, this work investigates the applicabil-

ity of such models for sentence boundary detection

in legal documents. The list of tokens provided by

the tokenizer is translated into a list of features for

each individual token by means of feature extractors.

Hereby, the surrounding tokens and their features are

also taken into consideration.

The features for a token are a combination of their

own properties and the speciﬁc properties of the to-

kens in the predeﬁned window around the word or to-

ken. The size of the window is variable for each used

feature extractor. Table 4 shows all extractors and fea-

tures utilized.

Many different combinations of features were

tried. Therefore, based on the average F

score for a

single feature extractor, the respective word window

and feature was selected for further testing. This iter-

ative procedure revealed that the most important fea-

tures were (1) whether the token was a special charac-

ter, (2) the token in lowercase variation, (3) the length

of the token, (4) the token signature, (5) whether the

token starts with an uppercase letter or (6) lower-

case character, and (7) whether the token is a number.

These respective feature extractors were then used to

train the ﬁnal models.

4.2 Neural Networks

We trained different neural networks, inspired from

related work, to predict the sentence boundary prob-

ability. Here we report on the best performing net-

work. As an input it receives the word embeddings of

the possible boundary and its context window, which

are the 7 preceding and subsequent token. If the con-

sidered token is at the beginning or end of a text, the

context window is padded with zero vectors to get a

uniform size. A symmetric window of token is used

as the input for the whole neural network with the

possible sentence boundary in the middle. If a word

is not in the embedding dictionary, its word vector is

set to zero. In this case, averaging the embeddings of

the context around the word to estimate the vector is

also possible, but the neural network already can ac-

cess the whole context around the word. Word2vec

(Mikolov et al., 2013) vectors are used in the paper

because of their simplicity. gensim (

Reh

rek and So-

jka, 2010) is used to train the embeddings with a win-

dow size of 5, a vector size of 100 and a minimal word

occurrence of 2. The whole dataset is used to train the

word embeddings.

The neural network is implemented in PyTorch

and can be seen in Figure 1. It consist of four bidi-

rectional layers of Gated Recurrent Units (GRU, sim-

pliﬁed in Figure 1 to one layer), which are followed

by two linear layers. The GRU uses its standard non-

linear activation function Tanh and between the lin-

ear layers there is one ReLU. The sigmoid function

generates the wanted probability. The hidden dimen-

sion size of the bidirectional GRU is 64 and its output

for each token is concatenated (two hidden states per

token), resulting in a 1920 dimensional vector. This

vector is then reduced to 64 dimensions in the ﬁrst

linear layer.

The Adam algorithm is used for optimization. The

learning rate of 2.5e

−4

is gradually decreased every

ﬁve epochs by half, while the network was trained

for 60 iterations or epochs over the whole training

dataset.

5 RESULTS

The main focus of this evaluation is put on the law

and judgment collections. The other collections are

used as a reference value because they do not consist

of enough sentences to get reliable results for training

and testing. After evaluating each method on those

two collections, their performance is calculated on the

other previously unseen datasets.

To evaluate the neural network and to avoid over-

ﬁtting, the laws and judgments are each split into the

three parts: train, validation and test dataset. The val-

idation and test dataset each consist of 10% of the

texts. Each different model is trained on the train

dataset and after every epoch evaluated on the vali-

dation dataset. The model with the highest F1 score

is saved and at the end of the training tested against

the test dataset. For the dataset the model was trained

on, the test score at the end of the training is reported.

See https://pytorch.org/

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

816

Table 4: The features used as input for the CRF.

Feature Extractor Output

Special Categorizes the different special characters. If a token is not a special character, the

output is ”No”, otherwise ”End” stands for sentence-terminating characters, ”Open”

for opening parentheses, ”Close” for closing parentheses and ”Newline” for newline

characters. In all other cases, such as the paragraph sign, the output is ”S”.

Lowercase Extracts the individual tokens in lowercase. This way, it is possible for the system to

learn certain trigger tokens, which denote the end of a sentence.

Length Extracts the length of every token in the window. Also used to distinguish between

possible abbreviations.

Signature The signature of each token is extracted, which is as a feature a combination of the

length and the type of the token, e.g. numbers, words and special characters. The

token is then translated into the speciﬁc combination of numbers as ”N”, lowercase

characters as ”c”, Uppercase characters as ”C” and special characters as ”S”.

Upper Extractor which outputs the truth value if the token starts with an uppercase letter to

distinguish abbreviations from sentence ends. If the token after the dot is uppercase,

this is a strong indicator for a sentence end.

Lower Same idea as the Upper-extractor, but in this case the output is ”True” for all tokens

that start with a lowercase letter.

Number Extracts wheter the token is a number. Also useful to determine whether the token can

be found on a headline or not.

Figure 1: The neural network architecture used in this paper. A bidirectional GRU followed by a concatenation and two linear

layers.

5.1 Evaluation

The already existing approaches OpenNLP and NLTK

have a low performance, with the OpenNLP model

trained on judgments being slightly better (see Ta-

ble 7). Counter-intuitively, the OpenNLP model

trained on judgments outperforms the model trained

on laws when evaluated on laws. A reason for this

could be the higher complexity of the law texts, indi-

cated by the higher F1 scores on the judgments for

almost all methods (comparing the results for each

method speciﬁcally trained for that dataset). In this

case, OpenNLP might not be capable of modelling

the laws adequately, but can generalize the concept of

Sentence Boundary Detection in German Legal Documents

817

Table 7: Performance evaluation for NLTK and OpenNLP on laws and judgments.

Laws Judgments

F1 Rec Pre F1 Rec Pre

NLTK 73.0 61.2 92.1 69.9 66.4 73.9

OpenNLP Laws 72.9 61.1 90.4 64.4 64.5 64.4

OpenNLP Judgments 74.8 60.3 98.4 78.1 65.6 96.3

sentence boundaries well enough from the judgments.

When visually examining the results obtained

from the existing methods it is evident that most er-

rors are linked to textual structures such as citations,

headlines and lists. These methods shall be used as

the baseline, although it is advised not to use them in

the German legal domain.

First, we evaluated the performance of our CRFs.

While we tested many different feature combinations

(see Section 4.1), we encountered that widening the

scope of a feature extractor leads to better results, but

increasing the window over a certain threshold of-

ten degrades the performance of that extractor. Us-

ing more lowercased words as a feature increases the

model performance, but the computational and mem-

ory cost is to high to further increase the viewed

scope. Table 5 reports on the results of the best CRFs

trained on laws and judgments.

The best CRF trained on laws uses the following

features: Special with a window of 10, Lowercase and

Length with a window of 7, Signature with a window

of 5 and Lower, Upper and Number with a window of

Table 5: Performance of the best CRF on laws and judg-

ments.

Laws Laws

F1 Rec Pre F1 Rec Pre

CRF Law 95.4 94.4 96.4 77.3 68.4 89.0

CRF Jug 81.2 76.8 86.0 96.8 96.6 97.0

The best CRF for the judgments has following extrac-

tors: Length, Signature, Lowercase, Special with a

window of 5 and Lower, Upper and Number with a

window of 3.

Particularly the inclusion of special tokens is im-

portant for a good performance on the law documents.

The assumption here is that they are essential for a

better understanding about the overall structure. For

training on judgments, a smaller scope for each ex-

tractor yields the best performance.

Overall the performance of CRF increases signif-

icantly with the inclusion of the Lowercase extractor.

This extractor was introduced by (Savelka and Ash-

ley, 2017a), but they used a smaller scope. A simi-

lar model to the one introduced in their paper is also

Table 6: Performance of the CRFs on terms of service and

privacy policies.

ToS Privacy Pol.

F1 Rec Pre F1 Rec Pre

CRF Law 91.8 86.4 95.7 81.7 81.0 82.3

CRF Jug 81.1 82.4 79.8 84.5 81.6 87.6

tested but produces worse results with an F

score of

95.0% for laws and 96.0% for judgments.

The evaluation for the terms of service and privacy

policies showed a challenge already seen in (Read

et al., 2012). The performance of the SBD system sig-

niﬁcantly decreases when processing unknown doc-

uments, see Table 6 . The F

score for the privacy

policies nearly reaches the baseline value from the

OpenNLP with 84.5%.

CRF are a versatile model, but their performance

levels are bound to the creativity while engineering

the features. As seen during testing, changes to fea-

tures often only have a marginal impact on the overall

performance. Additionally, there are only a limited

number of parameters possible. This is not the case

with a RNN, which will be evaluated next.

As a result, we evaluated the performance of the

created neural network. For this section we trained

models on three different parts of the dataset, one only

on the judgments (Table 8), one for the laws (Table 9),

and one using both as training input (Table 10). For

each such part ﬁve randomly-initialized models were

trained and their performance averaged. The maxi-

mum deviation from the average is also reported.

The best performance of each document type is

marked. As expected, the model trained on a docu-

ment type also yielded the best performance on that

speciﬁc dataset part. There is a performance decline

for the PRVs noticeable, which can at least be partly

explained by their more casual writing style. With an

increase of up to 22 points in the F1 score, a signif-

icant difference can be seen to the existing methods.

We can report performance levels comparable to the

state-of-the-art scores reported by Read et al. (Read

et al., 2012) on the WSJ, the Brown corpus, etc., al-

though it can be argued that the task of ﬁnding a sen-

tence boundary potentially anywhere in a text is sig-

niﬁcantly harder.

In order to evaluate how our neural network

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

818

Table 8: Performance of the neural network only trained

on judgments. Averaged over ﬁve models with maximum

deviation.

F1 Recall Precision

Law 87.80 ±0.60 84.38±1.90 91.59 ±0.77

Jug 98.51 ± 0.19 98.80 ± 0.33 98.23 ± 0.42

ToS 92.88± 0.90 88.25± 1.61 98.02± 0.49

Prv 81.32±0.90 77.02 ±1.43 86.13 ±0.34

Table 9: Performance of the neural network only trained on

laws. Averaged over ﬁve models with maximum deviation.

F1 Recall Precision

Law 97.46 ± 0.18 98.04 ± 0.77 96.89 ± 0.47

Jug 83.77±2.04 77.59 ±3.56 91.11 ±1.64

ToS 91.92± 0.32 90.56± 1.13 93.35± 1.22

Prv 82.55±0.53 83.49 ± 1.12 81.63 ±0.68

performs on normal text the TIGER corpus was

used (Brants et al., 2004) as a source for normal Ger-

man sentences. This corpus is already segmented into

sentences and in order to create a real-life setting we

introduce a simple formatting rule of only allowing a

maximum of eight alphanumeric tokens or words per

line.

In Table 11, we tested each of the models from

above which were trained on the legal documents on

the TIGER corpus. Only focusing on legal documents

introduces performance issues with normal texts. In

order to overcome this problem, we also trained our

neural network on the whole dataset additionally with

the around 50,000 sentences from the TIGER corpus.

To test the effect of these added sentences, one half of

the test and validation data was taken form the TIGER

corpus and the other from our legal dataset. As seen in

Table 12, we can achieve a high performance for both

corpora with a non-legal F1 score of almost 99%.

5.2 Error Analysis

A manual analysis of the errors from the legal doc-

uments was performed by Annotator B. The anal-

ysis showed that 22.6% are wrongly annotated to-

kens, which nonetheless can be interpreted as cor-

rectly classiﬁed by the neural network. These are

either tokens, which were obviously overlooked by

the annotator, or unclear examples, where a decision

could have been made in both directions. As a re-

sult, the performance of our models can be even seen

as slightly better than actually reported. The remain-

ing errors are distributed as follows: 37.7% are re-

lated to lists or enumerations, 13.1% are numbers or

names and only 6.5% are abbreviations. The remain-

ing 21.1% are other errors which do not have a direct

link.

A large portion of the errors are found within or

around lists and enumerations. When looking at these

examples, it is sometimes even for a human not possi-

ble to determine whether there is a sentence boundary

or not based on the given context. Classifying sen-

tence boundaries in such textual structures is some-

times only possible in a more global way, looking at

the list as a whole. Mixed cases and the lists spanning

over many lines further complicates this. In order to at

least partly solve this problem, we propose to increase

the size of the window.

The problem with the numbers and names, is that

they most of the time do not have an embedding. By

using character embeddings we could give the neu-

ral network information, even about words that it has

never seen before. In the following paragraphs we

want to evaluate the inﬂuence of zero embeddings on

the performance of the system.

In this paper, the strategy to deal with unknown

words or tokens was to insert a zero vector as a place-

holder. The neural network should then be able to

infer some meaning about that particular token. We

tested this assumption by extracting all the errors the

neural network produced when evaluated on the le-

gal sentences and Figure 2 a contradiction with this

assumption. A far larger portion of error is encoun-

tered, if at least one token is unknown. And if we en-

counter a context window with many missing tokens,

the probability of making an error is much higher.

When we have six or seven missing tokens this does

not hold true. This is simply the case, because we are

padding the context window at the beginning and end

of the text. 31 out of these 33 cases are found at the

beginning or the end of a text. With 255 documents,

we have over 500 such context windows which heav-

ily inﬂuence the probability.

To summarize this error analysis: We looked at

two error factors for sentence boundaries. On the

one hand the writing style of legal documents with

their long, complex and nested textual structures in-

troduces errors. On the other hand missing statistical

information for unknown tokens at least inﬂuences a

large part of the errors produced by the neural net-

work.

6 CONCLUSION & OUTLOOK

In this paper, we ﬁrstly introduced the problem of

SBD in the German legal domain. Furthermore, we

created and published an annotated dataset consist-

Sentence Boundary Detection in German Legal Documents

819

Table 10: Performance of the neural network trained on the judgments and laws. Averaged over ﬁve models with maximum

deviation.

F1 Recall Precision

Law&Jug 97.82 ± 0.14 98.33 ± 0.63 97.31 ± 0.40

ToS 95.00 ± 0.98 91.78 ± 1.98 98.46 ± 0.33

Prv 83.35 ± 0.30 81.90 ± 1.06 84.84 ± 0.49

Table 11: Performance of the models tested on the TIGER corpus. Averaged over ﬁve models.

F1 Recall Precision

Jug 88.14 ± 0.41 84.80 ± 1.18 91.75 ± 0.51

Law 87.97 ± 0.23 88.25 ± 0.68 87.71 ±0.87

Law&Jug 88.81 ± 0.29 86.93 ± 0.70 90.79 ± 0.74

Table 12: Performance of the models tested on the TIGER and Legal Corpus. Averaged over 5 models.

F1 Recall Precision

Total 98.21 ± 0.11 98.36 ± 0.11 98.05 ± 0.33

Legal 97.48 ± 0.14 97.95 ± 0.28 97.01 ± 0.52

Non-Legal 98.93 ± 0.09 98.77 ± 0.12 99.09 ± 0.15

Figure 2: The inﬂuence of missing/zero embeddings on the errors.

ing of various types of German legal documents

This dataset was then used to train and evaluate

newly developed methods of SBD and to compare

these against existing methods. However, this dataset

is now publicly available and can be used within

the community to perform further research on SBD

within the legal domain.

Our proposed models achieved state-of-the art

performance with regard to SBD. Hence, this research

can be utilized by other researchers to perform more

complex NLP tasks within the legal domain.

Even though we could show that our models per-

form on a very high level and that they therefore could

be utilized in NLP pipelines for various legal tasks,

some limitations exist. We only used simple word

The corpus and codebase is available at the

following repository: https://github.com/sebischair/

Legal-Sentence-Boundary-Detection

embeddings (Word2Vec (Mikolov et al., 2013)) and

trained them on our corpus. For future work, it could

be even more beneﬁcial for the models, to utilize

state-of-the art sequence-to-sequence language mod-

els such as BERT (Devlin et al., 2018).

REFERENCES

Ashley, K. D. (2017). Artiﬁcial intelligence and legal an-

alytics: new tools for law practice in the digital age.

Cambridge University Press.

Brants, S., Dipper, S., Eisenberg, P., Hansen, S., K

onig, E.,

Lezius, W., Rohrer, C., Smith, G., and Uszkoreit, H.

(2004). TIGER: Linguistic linguistic interpretation of

a german corpus. In Journal of Language and Com-

putation, 2, pages 597–620.

Cohen, J. (1960). A coefﬁcient of agreement for nominal

scales. Educational and psychological measurement,

20(1):37–46.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

820

de Maat, E. (2012). Making sense of legal texts. PhD thesis,

University of Amsterdam.

Devlin, J., Chang, M.-W., Lee, K., and Toutanova, K.

(2018). Bert: Pre-training of deep bidirectional trans-

formers for language understanding. arXiv preprint

arXiv:1810.04805.

Fleiss, J. L. (1971). Measuring nominal scale agree-

ment among many raters. Psychological bulletin,

76(5):378.

Koller, D. (2019). Interactive analysis of a corpus of general

terms and conditions for variability modeling. Mas-

ter’s thesis, Technical University of Munich, Munich,

Germany.

Lafferty, J., McCallum, A., and Pereira, F. C. (2001). Con-

ditional random ﬁelds: Probabilistic models for seg-

menting and labeling sequence data.

Loper, E. and Bird, S. (2002). NLTK: The natural language

toolkit. In Proceedings of the ACL Workshop on Ef-

fective Tools and Methodologies for Teaching Natural

Language Processing and Computational Linguistics,

Philadelphia. Association for Computational Linguis-

tics.

Mikolov, T., Sutskever, I., Chen, K., Corrado, G. S., and

Dean, J. (2013). Distributed representations of words

and phrases and their compositionality. In Burges, C.

J. C., Bottou, L., Welling, M., Ghahramani, Z., and

Weinberger, K. Q., editors, Advances in Neural In-

formation Processing Systems 26, pages 3111–3119.

Curran Associates, Inc.

Moens, M.-F. (2001). Innovative techniques for legal text

retrieval. Artiﬁcial Intelligence and Law, 9(1):29–57.

Read, J., Dridan, R., Oepen, S., and Solberg, L. J. (2012).

Sentence boundary detection: A long solved problem?

In Proceedings of COLING 2012: Posters, pages 985–

994, Mumbai, India. The COLING 2012 Organizing

Committee.

Reh

rek, R. and Sojka, P. (2010). Software Framework

for Topic Modelling with Large Corpora. In Proceed-

ings of the LREC 2010 Workshop on New Challenges

for NLP Frameworks, pages 45–50, Valletta, Malta.

ELRA.

Savelka, J. and Ashley, K. D. (2017a). Sentence

boundary detection in adjudicatory decisions in the

united states. Traitement automatique des langues,

58(February):21–45.

Savelka, J. and Ashley, K. D. (2017b). Using conditional

random ﬁelds to detect different functional types of

content in decisions of united states courts with ex-

ample application to sentence boundary detection. In

Proceedings of 2nd Workshop on Automated Semantic

Analysis of Information in Legal Texts, London, Great

Britain. ASAIL.

Wyner, A. Z. (2010). Towards annotating and extracting

textual legal case elements. Informatica e Diritto:

special issue on legal ontologies and artiﬁcial intel-

ligent techniques, 19(1-2):9–18.

Wyner, A. Z. and Peters, W. (2011). On rule extraction from

regulations. In JURIX, volume 11, pages 113–122.

Sentence Boundary Detection in German Legal Documents

821
