Real-Time Range Query Approximation

by Means of Adaptive Quad Streaming

Simon Keller and Rainer Mueller

University of Applied Sciences, Constance, Germany

Keywords:

Continuous Spatial Range Queries, Mobile Objects, Streaming-based Decentralization, Mobile Environments.

Abstract:

Continuous range queries are a common means to handle mobile clients in high-density areas. Most existing

approaches focus on settings in which the range queries for location-based services are mostly static whereas

the mobile clients in the ranges move. We focus on a category called Dynamic Real-Time Range Queries

(DRRQ) assuming that both, clients requested by the query and the inquirers, are mobile. In consequence,

the query parameters results continuously change. This leads to two requirements: the ability to deal with

an arbitrary high number of mobile nodes (scalability) and the real-time delivery of range query results. In

this paper we present the highly decentralized solution Adaptive Quad Streaming (AQS) for the requirements

of DRRQs. AQS approximates the query results in favor of a controlled real-time delivery and guaranteed

scalability. While prior works commonly optimizes data structures on servers, we use AQS to focus on a

highly distributed cell structure without data structures automatically adapting to changing client distributions.

Instead of the commonly used request-response approach, we apply a lightweight streaming method in which

no bidirectional communication and no storage or maintenance of queries are required at all.

1 INTRODUCTION

Today’s ubiquitous mobile devices in everyone’s

hands and the location sensors they contain lead to

both, demand and potential for location-aware ser-

vices (Kaczor and Kryvinska, 2013). As a con-

sequence of ubiquity, there is an obvious need for

more efﬁciency in spatial queries in terms of given

QoS parameters. And these parameters certainly de-

pend on the type of the application scenarios con-

sidered. There are countless use cases for applica-

tions, often in the area of nearby business or leisure

which provide mobile users with aggregated informa-

tion out of spatial queries (e.g. gas stations, hospitals,

stores/shopping malls) (Moln

ar et al., 2014). In con-

trast to these stationary target objects or clients of a

system, there are mobile ones such as commuters on

a busy train looking for free seats, people requiring

an ad-hoc ridesharing (cab-hailing) in order to man-

age the next two blocks, or ﬁreﬁghters in a smoky

building, forest or disaster event. In these scenarios

the requirement is not to know, who/which are the

next k clients (matching the needs) but which clients

are within a speciﬁc range (range query), in our case

within in a geometrical range (spatial range query)

of d

meters around a dedicated client. Moreover,

not only are the requested clients mobile (e.g. the

requested ﬁreﬁghter colleagues), which is a contin-

uous spatial range query. Also the requesting clients

or inquirers (e.g., a dedicated ﬁreﬁghter looking for

colleagues in restricted visibility) are mobile. We

call this a dynamic real-time range query (DRRQ)

in which not only the query results but the queries

as such change continuously. The application scenar-

ios behind DRRQs involve a certain degree of unpre-

dictability or spontaneity. We call this class of prob-

lems ad-hoc mobility challenges, which obviously in-

creases the complexity of continuous range queries,

but is much closer to reality nowadays when every-

one and everything is mobile. You can easily trans-

fer the described ad-hoc mobility challenges to other

domains or objects (ﬁreﬁghters, autonomous vehicle

controlling/dispatching, supply chains, business pro-

cesses, etc.). Many range query approaches are re-

stricted to either static objects or static queries (e.g.

(Wu et al., 2004c; Kalashnikov et al., 2002; Xuan

et al., 2011)). Others optimize established search al-

gorithms on a centralized single server (e.g. (Mokbel

and Aref, 2008; Al-Khalidi et al., 2013; AL-Khalidi

et al., 2013)). Even already existing distributed ap-

proaches often turn their attention either to the static

variants (e.g. (Wang et al., 2006)) or to optimize well-

known local data structures such as variants of R or B

trees (e.g. (Yu et al., 2019)).

In contrast, we focus on DRRQs and maximize the

degree of distribution deﬁning a very fuzzy or foggy

edge between mobile clients and servers. Even if all

nodes, servers and clients, are involved, their indi-

Keller, S. and Mueller, R.

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming.

DOI: 10.5220/0010246500130024

In Proceedings of the 10th International Conference on Sensor Networks (SENSORNETS 2021), pages 13-24

ISBN: 978-989-758-489-3

vidual local range query processing load is reduced

as much as possible. We largely dispense with local

range query data structures in favor of using a gran-

ular distribution intelligence and a lightweight, fast

communication pattern on a streaming basis. The dis-

tribution fuzziness results in an approximated, not al-

ways completely correct range query result. However,

we will show that this inaccuracy can be optimized

with respect to real-time support and scalability and

is therefore becoming irrelevant.

2 PRECONDITIONS AND

REQUIREMENTS

The discussion of two-dimensional DRRQs in the eu-

clidean space and their preconditions can be enhanced

by a more formal consideration. In the infrastructure

considered, we deﬁne C := {c

= (c

)} as the

set of mobile client nodes (in the following: client

nodes or just nodes). t of c

indicates the point in

time, at which c is considered. c

is its never chang-

ing, system-wide unique identiﬁer. (c

) are the co-

ordinates of c in the two-dimensional euclidean space

at point in time t. S is the set of one or more server

nodes (in the following: servers) and D := C ∪ S the

distributed system. The nodes in C have the ability to

determine their own location (GPS, Bluetooth, Wiﬁ,

etc.) and have a network connection (4G/5G, Wiﬁ,

etc.) to communicate with the servers in S. For deﬁn-

ing a query we use the euclidean norm (or 2-norm) as

metric d.

Following these names and notions, a range query can

now be speciﬁed as a request and response:

Deﬁnition 1. Request Q(c

) and response R(c

)

Q(c

) := query of c

at point in time t

R : C→P (C) with R(c

):={b

∈ C | d(b

) ≤ d

}

Following these deﬁnitions, we are now able to deﬁne

different categories of range queries:

Type 1: Static (Spatial) Range Queries

Node locations are constant (immovable clients)

⇒ R(c

)=R(c

); ∀t,t

∈ R

with c

Queries are constant (immovable inquirers)

⇒ c

; ∀t,t

∈ R

Type 2: Continuous (Spatial) Range Queries

Identical to Type 1 except:

Node locations are variable (moving clients)

⇒ ∃ t,t

∈ R

: c

∧ R(c

)6=R(c

)

Type 3: Dynamic Real-Time Range Queries

Identical to Type 2 except:

Queries are variable (moving inquirers)

⇒ ∃ t,t

∈ R

: c

6=c

We will discuss related approaches for these query

categories in Section 3. Having the considered terms

in mind, the requirements needed for a DRRQ solu-

tion become straightforward. Under the terms of deal-

ing with high-density systems of millions of nodes per

considered area unit (cmp. ITU expectation (Interna-

tional Telecommunication Union lTU, 2015)), every

centralized approach (especially a single, centralized

or replicated server) obviously becomes a bottleneck.

We will discuss this in more detail in Section 4. This

leads us to our ﬁrst requirement:

Requirement A – Scalability: Q(c

) has to be pro-

cessed in sublinear time in n, ∀c

∈C,∀t ∈ R

,n = |C|

In this context, hotspots in which high-density clus-

ters intersect with the range of the query (∃c

∈ C :

|R(c

)| ∈ O(n)) are of particular interest.

The ad-hoc mobility character of these scenarios

(cmp. Section 1) in combination with high-density

areas lead to the supply and demand for continuously

updated information. To be more precise, the mobil-

ity of both requesting and requested nodes (moving

clients and inquirers) in DRRQs requires real-time

behavior in answering the queries as the second re-

quirement for our solution.

Requirement B – Real-time Propagation: ∀c

∈

C, ∀t ∈ R

,∀b

∈ R(c

) : τ(c

) −t

≤ t

with τ(c

) :=

earliest point in time, at which R(c

) is available to c

obviously depends on the application domain and

can either be a hard or a soft deadline. In a ridesharing

scenario a soft deadline of 2000 − 3000ms might be

acceptable whereas in a ﬁreﬁghter’s life-threatening

setting a hard deadline of 300ms is crucial. As a con-

sequence, recomputing all query results from scratch

on every client movement seems to be the wrong ap-

proach in contrast to focusing on the deltas.

3 RELATED WORK

Location-dependent queries have been extensively

studied in the last decade. While a lot of litera-

ture propose general implementations for a spatial

query processing (Mokbel et al., 2004; Gedik and Liu,

2004; Tao and Papadias, 2003), the two most dom-

inant research issues related to this paper are range

queries (Wu et al., 2004c; Wu et al., 2004a; Wu et al.,

2004b; Wu et al., 2005; Kalashnikov et al., 2002)

and nearest neighbor queries (Yang and Chiu, 2017;

Gao et al., 2014; Wu et al., 2007; Mouratidis et al.,

2005a; Mouratidis et al., 2005b) which do not match

our research problem directly but provides inspiring

solutions. Another related ﬁeld are spatial alarms

SENSORNETS 2021 - 10th International Conference on Sensor Networks

(Bamba et al., 2009), as they use similar techniques

to query safe areas. While Continuous Range Queries

(moving clients) are often studied (e.g. (Wu et al.,

2004c; Wu et al., 2004a; Wu et al., 2004b; Yu et al.,

2005; Kalashnikov et al., 2002; Wang et al., 2006)),

a much smaller set of literature is found for support-

ing DRRQs (moving inquirers). We can divide the

literature on moving queries into two categories of

centralized approaches, such as SINA (Mokbel et al.,

2004), SOLE (Mokbel and Aref, 2008), GPAC (Mok-

bel and Aref, 2005) or (Cheema et al., 2010; Al-

Khalidi et al., 2013; AL-Khalidi et al., 2013) and

distributed solutions like MobiEyes (Gedik and Liu,

2006) or Distributed Hybrid Index (Yu et al., 2019).

The latter meet our Requirement A (cmp. Section

2) of horizontal scalability much better. However,

MobiEyes requires a centralized server as a mediator

between mobile clients which could obviously lead

to the already discussed bottleneck and in turn can-

not guarantee free scalability. The Distributed Hy-

brid Index avoids centralization by providing a pre-

deﬁned grid spread over many servers, but adopts

the dynamic character of ad-hoc mobility challenges

solely by a local server-internal height-limited vari-

ant of an R tree (VR tree). Even if update costs are

therefore limited, the tree might degenerate in our

high-density scenarios with hotspots in terms of the

number of leafs and nodes per leaf. We will come

back to this solution later after having described our

approach in detail. Another stream in literature on

range queries takes assumptions about the objects’

movement into account. To optimize query process-

ing, ﬁx road trajectories (Papadias et al., 2003), or

motion adaption, indexing (Gedik and Liu, 2004) is

used which is not really applicable in an emergency

scenario with people in panic whose movements are

not predictable. Yet another stream in literature deals

with computation offloading in order to optimize the

balance between task ofﬂoading to expedite the task

execution and additional communication costs and la-

tency (Kao et al., 2017; Ying Cai et al., 2006; Gedik

and Liu, 2004). This assumption is not always realis-

tic, as clients lack battery capacity and computational

or storage capabilities. Indexing techniques for mov-

ing objects have been proposed and optimized mul-

tiple times in centralized database environments with

grid or cell structures (Yu et al., 2005; Zheng et al.,

2006; Mouratidis et al., 2009;

Sidlauskas et al., 2012;

Wang and Zimmermann, 2008), hash-based schemes

in buckets (Song and Roussopoulos, 2003), and via

tree-based methods (Tayeb, 1998; Prabhakar et al.,

2002;

Saltenis and Jensen, 2002;

Saltenis et al., 2000;

Jensen et al., 2004). Non-uniformity in mobile ob-

ject data is also handled by a hierarchical grid index

structure (Yu et al., 2005) or a binary tree with spatial

operations (Arya et al., 1998). However, the scalabil-

ity aspect in a distributed mobile environment is not

the focus but those works could provide an inspiring

base for indexing clients in our distributed solution.

We distinguish our solution from the approaches

mentioned above as it provides the following unique

properties: (1) Our system can be distributed on an

unlimited number of server nodes, ﬁtting an unlim-

ited volume of clients without the need to know the

whole system, and (2) we do not separate mobile ob-

jects and query consumers but link them and do not

assume that there is an imbalance between a large vol-

ume of mobile objects and only a few queries. (3)

Neither the clients nor the queries are of static nature

and our system works well with random movements

and non-uniformity. (4) Finally our solution outputs

a range query change immediately to the consuming

clients to meet real-time requirements.

4 QUAD STREAMING

The Adaptive Quad Streaming (AQS) approach can

be described in three parts: (1) the distribution

scheme (adaptive cell structure, cmp. 4.1); (2) the

interaction pattern (a streaming-based variant, cmp.

4.2); (3) the (range query) processing (algorithms,

cmp. 4.3). The scheme applied to the distribution

of servers in our approach results from the following

consideration: Let us assume that the range query is,

as already mentioned in 2, realized straightforwardly

through a request-response interaction pattern using

one centralized server s

for all client nodes. That

means, a client joins the system (i.e., becomes a client

node c

∈ C), later after each movement at time t, it

sends a range query Q(c

) as a request to s

and re-

ceives a result R(c

) ⊂ C as a response from s

. Fi-

nally, c

leaves the system. In consequence, s

knows

all clients that still joined (c ∈ C) and their latest trans-

mitted locations. On each received Q(c

), s

calcu-

lates d(c

),∀b

∈ C and, if d(c

) ≤ d

, sends

updated R(b

) for every previously received Q(b

)

back to node b

, as well as R(c

) back to c

. This

brute-force, any-to-any calculation, obviously result-

ing in complexity O(n

) with n = |C|, cannot fulﬁll

our Requirement A of sublinear processing. There

are many approaches in literature addressing a sub-

linear indexing of mobile nodes in continuous spatial

range queries (e.g. (Wu et al., 2004b; Kalashnikov

et al., 2002; Yu et al., 2019)). But even in the best

case of non-overlapping ranges and constant time for

each query

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming

R(c

) =

0 ∧ σ(Q(c

)) ∈ O(1), ∀Q(c

),∀c

∈C

σ(O(c

)) := time span on server side between

receiving query O(c

) and sending result R(c

)

the processing workload for n → ∞ cannot be man-

aged by a single server alone. For an arbitrary c

∈ C:

∑

∈C

σ(O(b

)) ∈ n · O(σ(O(c

))) = O (n)

It is always possible to ﬁnd a greater n to overload all

vertically scaled server hardware.

Just the opposite extreme to the server bottleneck

would be an approach in which the nodes, as clients,

share the range processing uniformly without a cen-

tralized component. This is obviously a good pre-

condition for scalability. However, the lack of peer-

to-peer communication for coordination and synchro-

nization between clients in a mobile cellular or simply

Internet-based network requires a centralized compo-

nent for mediation. Yet limited resources of mobile

nodes in terms of battery inhibit extensive process-

ing on the clients’ side. Additionally, limited storage

and computation resources of mobile clients might

prevent complex calculations of requests on such de-

vices, even on today’s hardware (Shao and Taniar,

2014).

As a consequence, we aim at a compromise be-

tween both extremes, full server and full client pro-

cessing. Therefore, a horizontal scaling of server

infrastructure in terms of partitioning the processing

load between server and client nodes, minimizing the

communication load and ﬁtting arbitrary client distri-

butions and counts must be the focus. In order to ﬁnd

an optimal load partitioning for servers and clients we

create a self-adapting multidimensional structure built

of cells.

4.1 Adaptive Cell Structure

The ﬁrst step for an adaptive cell structure is the

initial cell X

covering the whole considered two-

dimensional area. As all following cells in the struc-

ture, this cell is a square. X

is assigned to an initial

server s

∈ S (see Figure 1).

Figure 1: Initial Cell.

If a new node joins the system and therewith the ini-

tial cell X

, the cellcount (number of nodes covered

by the cell) might exceed a predeﬁned split thresh-

old. As a consequence, the initial cell X

is divided

into four equally-sized subcells X

(0,1)

,...,X

(0,4)

. X

is called the supercell of X

(0,1)

,...,X

(0,4)

. For a bet-

ter generalization we introduce some deﬁnitions for

these concepts.

A cell X

:= (x

,l) ∈ R

is deﬁned by its upper left

corner (x

) as a coordinate and its edge length l.

is the set of nodes covered by cell X

and |XC

therefore its cell count.

Deﬁnition 2. Cell node set XC

:= {c = (c

) ∈ C |

≤ c

≤ x

+l ∧ x

≤ c

≤ x

+l}

Deﬁnition 3. General indexing notation of cells

is a cell with index u = (n

,...,n

)

Subcells of X

: X

,...,X

with v

= (u,i)

In the indexing notation of X

, the u = (n

,...,n

) de-

scribes its creation history: u = (0) = 0 for the initial

cell, {(0, i) | 1 ≤ i ≤ 4} for its subcells and so on.

This indexing notation is used for understanding only

and not in the implementation of the algorithms of the

system themselves.

Deﬁnition 4. Thresholds & Relaxed Adaption Factor

Relaxed Adaption Factor: R ∈ [0,1]

Split Threshold: C

split

∈ N

Merge Threshold: C

merge

:= bR/4 ·C

split

Using these thresholds, we can now deﬁne the split

and merge rules:

Split Rule for Cell X

= (x

,l) : |XC

| > C

split

→

1. X

(u,i)

:=(x

+l ·i mod 2,x

+lbi/2c,l/2), 1 ≤ i ≤ 4

2. XC

(u,i)

:= {c = (c

) ∈ XC

x ≤ c

≤ x + l ∧ y ≤ c

≤ y + l},X

(u,i)

= (x,y, l)

3. XC

If the cell count |XC

| of X

exceeds the split thresh-

old C

split

, X

will be split into four new subcells

(u,i)

,1 ≤ i ≤ 4, each assigned to a new unused server

from the pool of servers S (see Figure 2). Note, that

the original cell X

and its server s

remain for coor-

dination purposes, but do not contain nodes anymore.

These nodes were divided between the subcells.

Figure 2: Cell splitting and server assignment.

SENSORNETS 2021 - 10th International Conference on Sensor Networks

In the same way, the four cells created during a split

are merged again, if their cell counts underrun the

merge threshold C

merge

Merge Rule for subcells of X

,...,n

)

∀X

,...,n

,i)

: |XC

,...,n

,i)

| < C

merge

→

1. XC

,...,n

)

:= ∪

i=1

,...,n

,i)

2. XC

,...,n

,i)

0,1 ≤ i ≤ 4

3. Delete X

,...,n

,i)

,1 ≤ i ≤ 4

After a merge, the supercell absorbs all nodes of the

merged cells. The servers, to which the subcells were

assigned, are released and available in the serverpool

again. Following this rule, the cell counts of all four

cells have to underrun the threshold. But less strict

rules might be conceivable, e.g. only two cells are

sufﬁcient for a merge.

Before we are able to introduce how this cell struc-

ture is used for the DRRQs, we have to deﬁne the con-

nections between all nodes, servers and clients. Every

cell maintains a maximum of eight links to adjacent

cells, three to the neighbor cells created during the

split (the other quad cells), one to the supercell, and

four to the subcells. Except for the subcell links, all

links are mandatory. In addition, every cell has an un-

sorted simple list with links to the covered clients (see

Figure 3). Please, keep in mind, that we would never

explicitly set, update, or follow these cell links in the

following sections for the sake of clarity. We assume,

that these links are just there.

4.2 Streaming

In contrast to most other approaches, we do not

use the request-response pattern, neither directly nor

implicitly (Yu et al., 2019), for the range queries.

Requests for DRRQs are never created, transferred,

stored, or updated anywhere in the whole system.

Neither is there a need to re-evaluate such a query

in case of location updates of covered nodes nor to

update a query itself on an inquirer’s movement. In-

stead, we use a streaming communication pattern in

which events, as small information chunks, stream

from node to node, whether server or client. For in-

stance, location update events permanently ﬂow from

moving clients over the cells to all other clients af-

fected by their movements.

Each node of the system, server and client, is able

to send arbitrary events to arbitrary receivers using

a service primitive sendEvent: sendEvent <receiver

address> <event>. sendEvent uses one of the outgo-

ing links from the sending node to the next node spec-

iﬁed by address. In addition, each node has as service

primitive receiveEvent forwarding a received event

to a node-internal callback registered for this type of

event. Every event e := (t p,O

,...) is simply a

tuple of undeﬁned length, in which t p ∈ N is the type

of e. O

are arbitrary objects of any type and repre-

sent the information of the event, in which count and

type of the objects O

depend on the type of event t p.

Please note that the events themselves include neither

a sender nor a receiver address. Therefore, a node

receiving an event cannot identify where it originally

comes from. In the following, we describe the differ-

ent event types and their objects:

Deﬁnition 5. Location Update Event (LU

)

e := (0,c

,t, f )

t ∈ R: timestamp at which c

reached its location

∈ C: node that moved to a new location

f ∈ N: ﬂag (0: regular, 1: join, 2: connected)

The location update events (in the following often

simply LU

) are used to inform that a node c

moved

at point in time t to a new location. The new loca-

tion is stored in the node itself (cmp. Section 2). This

is the most important event type in the system. The

events of this type are initially created by the nodes

themselves after they have moved to a new location

(see Figure 3). The ﬂag f of LU

is used to trans-

Figure 3: Location update event streaming.

mit a status intended by the event and is on demand

changed by nodes while ﬂowing over them. A join

status intends that the node speciﬁed in the event is

either new to the system and wants to join it (system

join) or has left a cell and wants to join another cell

(cell join). Later on, we will see that the differenti-

ation between the two join types is not relevant. We

deﬁne c

as Connected Node, if it is connected to s

the sense of, it is covered by the cell X

assigned to s

As we know from Subsection 4.1, every server uses an

unsorted list of links to all its connected nodes. Note,

that a connected node itself also maintains a link (or

a connection) to its server. The link between a con-

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming

nected node and its server is therefore always bidirec-

tional. A connected ﬂag in an LU

indicates, that the

node speciﬁed in the event is already connected to the

server that received the event. A regular ﬂag tells the

receiving node that the client node c

speciﬁed in the

is neither connected to this server nor wants to

join it.

Deﬁnition 6. Connected Event (CON

)

e := (1,s

)

∈ S: server the receiver is now connected to

A node receives a CON

event if it has been con-

nected to (new) server s

. As a consequence, only

client nodes receive this type of event which happens

for one of the following three reasons:

1. New node joins: A new node c

wants to join the

system and therefore already sent an LU

with the

join ﬂag to a node of the system D. After hav-

ing received CON

the node knows that it is con-

nected to D for the ﬁrst time over server s

2. Node moved to non-covered location: A node c

moved to a location where it lost cell coverage by

its original connected cell and therefore joined an-

other server s

whose cell X

covers the node.

3. Cell split: After a cell has been split, the con-

nected nodes are divided between the four sub

cells. This is also realized by a LU

with join

ﬂag which in turn results in a CON

sent by the

individual subcells.

Deﬁnition 7. Merge Request Event (MREQ

)

e := (2,X

)

∈ X: cell X

whose server s

wants to merge

Deﬁnition 8. Merge Acknowledged Event (MACK)

e := (3)

If a cell count underruns the merge threshold C

merge

the server s

of the corresponding cell X

sends a

MREQ to the server of the supercell. If a cell received

MREQs from all four subcells, it initiates a merge ac-

tion and in turn sends a MACK to the servers of the

four subcells to request their closing (cmp. merge rule

in Subsection 4.1).

We will now explain how these streamed events

and the cell structure described above are used in the

algorithms of the system D.

4.3 Algorithms

In the following, the algorithmic parts of the system

D and our Adaptive Quad Streaming approach are de-

scribed in more detail from the servers’ perspective.

However, we start with a client activity since this is

the most straightforward way to introduce the server

algorithms consistently. Following our streaming in-

teraction approach, most algorithms are realized as

callbacks receiving and sending events.

If a new (client) node c

wants to join the system,

it sends a location update event with a join ﬂag to

the server s

of the initial cell X

(cmp. 4.1) using

its sendEvent service primitive. However, s

handles

this initial event just like any other event of this type.

From s

’s point of view, it does not matter whether

the node c

speciﬁed in the event is new to the sys-

tem or just new to its cell. The only interesting as-

pect for s

is that c

wants to join and whether its cell

covers c

. It will then be connected to s

. Oth-

erwise, s

passes this event to the next adjacent cell

in direction to c

’s location. And this is the uniform

behavior of every server. The only difference is that

the path (number of hops) from s

to the server the

node is later connected to might be longer compared

to a usual node’s movement. The reason is that s

the only entry point into the system regardless of the

node’s initial position.

Figure 4 describes the central algorithm in terms

of a callback function (locationUpdateReceived)

handling the scenario mentioned above and all other

cases, in which server nodes received a location up-

date event. In this algorithm, the server s

,...,n

)

ﬁrst

checks the ﬂags of the passed location update event

:= (0,c

,t, f ). If it is not ﬂagged, i.e. a regular

event, than c

neither wants to join nor is connected

to s

,...,n

)

(line 2). In this case, the only remaining

task for s

,...,n

)

is to check, if the node’s range inter-

sects with its cell X

and if so, to inform all connected

nodes b ∈ XC

,...,n

)

about the location update event

(lines 2–4). In case of an LU

ﬂagged as join,

,...,n

)

checks if its cell X

,...,n

)

covers c

. If yes

and if there are no further subcells potentially cover-

ing this node (lines 5–6), then c

will be connected

to s

,...,n

)

. Therefore, s

,...,n

)

adds c

to its un-

sorted list, checks if its cell has now to split (cmp.

Figure 5) and informs c

about now being connected

to s

,...,n

)

(lines 7–9). Before informing all other

connected nodes about c

, LU

is reﬂagged with 0,

since the join of c

is already executed (lines 10–12).

In case of LU

being ﬂagged as connected, s

,...,n

)

checks if c

is still covered by its cell after the move-

ment (lines 13–14). If yes, the LU

is reﬂagged with

0 before informing all other nodes, since no further

reconnection of c

is required (lines 15–17). If no, c

is disconnected from s

,...,n

)

and therefore removed

from the unsorted list of nodes (line 19). In case of

underrunning the merge threshold, s

,...,n

)

requests

a merge from its supercell server s

,...,n

k−1

)

(lines 20–

21). After disconnecting c

from s

,...,n

)

, c

has to

join another cell. Therefore, the LU

is reﬂagged with

SENSORNETS 2021 - 10th International Conference on Sensor Networks

1 before informing all other connected nodes about

this news (lines 22–25). All server- or cell-internal

work is now done. The following lines are for pass-

ing the event to the adjacent neighbors, if they exist

and their cells intersect with c

’s range: (1) subcells

(lines 26–29); (2) the three quad neighbor cells (lines

30–32); (3) the supercell, if c

’s range covers the su-

percell completely (lines 33–34). Please note, that

Data:

,...,n

)

: server that received a LU

,...,n

)

: cell assigned to s

,...,n

)

,...,n

,i)

: potential subcells of X

,...,n

)

,...,n

k−1)

: supercell of X

,...,n

)

1: function LOCATIONUPDATERECEIVED(c

∈ C,t ∈

R, f ∈ N)

2: if f = 0 ∧ rangeIsIntersected(X

,...,n

)

) then

3: for all b ∈ XC

,...,n

)

4: sendEvent(b,LU

)

5: if f = 1 ∧ nodeIsCovered(X

,...,n

)

) then

6: if ¬ exists(X

,...,n

,i)

) then

7: XC

,...,n

)

:= XC

,...,n

)

∪ {c

}

8: splitCheck(X

,...,n

)

9: sendEvent(c

,CON

,...,n

)

10: f:=0

11: for all b ∈ XC

,...,n

)

\ {c

} do

12: sendEvent(b,LU

)

13: if f = 2 then

14: if nodeIsCovered(X

,...,n

)

) then

15: f:=0

16: for all b ∈ XC

,...,n

)

\ {c

} do

17: sendEvent(b,LU

)

18: else

19: XC

,...,n

)

:= XC

,...,n

)

\ {c

}

20: if |XC

,...,n

)

| < c

merge

then

21: sendEvent(s

,...,n

k−1

)

,MREQ

,...,n

)

22: f:=1

23: if rangeIsIntersected(X

,...,n

)

) then

24: for all b ∈ XC

,...,n

)

\ {c

} do

25: sendEvent(b,LU

)

26: if exists(X

,...,n

,i)

) then

27: for all i ∈ {1,...,4} do

28: if rangeIsIntersected(X

,...,n

,i)

) then

29: sendEvent(s

,...,n

,i)

,LU

)

30: for all j ∈ {1,...,4} 6= n

31: if rangeIsIntersected(X

,...,n

k−1

, j)

) then

32: sendEvent(s

,...,n

k−1

, j)

,LU

)

33: if ¬ rangeIsCovered(X

,...,n

k−1

)

) then

34: sendEvent(s

,...,n

k−1

)

,LU

)

Figure 4: Callback processing an LU

event.

the functions rangeIsIntersected, rangeIsCovered,

and nodeIsCovered are not described in detail, since

these are simple functions with the given coordinates

of cells and nodes.

Figure 5 describes how the split threshold is ver-

iﬁed in function splitCheck (line 2) and how the

split of the cell is performed, if required. As a con-

sequence, the subcells for the split are created and

the required servers allocated from the server pool

to which the subcells are assigned (lines 3–6). Af-

terwards, all connected nodes are divided between

the subcells by sending a join-ﬂagged location update

event to this subcell that covers the respective node

(lines 7–11). Keep in mind, that a splitted cell has no

connected nodes anymore.

Data:

,...,n

)

: server that received a LU

,...,n

)

: cell assigned to s

,...,n

)

,...,n

,i)

: potential subcells of X

,...,n

)

1: function SPLITCHECK(X X

,...,n

)

2: if |XC

,...,n

)

| > C

split

then

3: for all i ∈ {1,...,4} do

4: createCell(X

,...,n

,i)

)

5: s

,...,n

,i)

:=allocateServer()

6: assignCellToServer(s

,...,n

,i)

,...,n

,i)

)

7: for all b ∈ XC

,...,n

)

8: LU

:= (0,b,t,1)

9: for all i ∈ {1,...,4} do

10: if nodeIsCovered(X

,...,n

,i)

) then

11: sendEvent(s

,...,n

,i)

,LU

)

12: XC

,...,n

)

Figure 5: Split check for a cell.

In the callback mergeRequestReceived, the server

,...,n

k−1)

received a merge request event MREQ

from subcell server s

,...,n

)

. If the number of

MREQs received from different subcells in total ex-

ceeds the given limit (default is 4, i.e. all four sub-

cells need to request for a merge), then the merge is

executed. For that purpose s

,...,n

k−1)

sends a merge-

acknowledged event (MACK) to the subcell servers.

The server s

,...,n

)

received the MACK event in

callback mergeAckReceived. In turn, it passes all con-

nected nodes back to the server s

,...,n

k−1

)

of the su-

percell by sending join-ﬂagged location update events

for them. Afterwards, it releases itself back to the

server pool. The callbacks mergeRequestReceived

and mergeAckReceived are not described in pseu-

docode syntax due to space restrictions. Please note,

that all event receivers has to ensure, that events are

not directly and redundantly sent back to its receivers

(rebound effect). This can simply be realized by

adding ﬂags or sender addresses to the send and re-

ceived primitives. We have skipped these rebound

parts in the algorithms for the sake of clarity.

Finally, if a (client) node b

receives a location up-

date event LU

:= (0,c

,t,0), it has to check if c

is in

its range: d(b

) ≤ d

. If yes, b

can update its local

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming

data structures accordingly. If no, b

has to drop c

In this case, b

was falsely informed by a location up-

date event and uselessly spent limited local resources

for this check. The question is how often this happens

in terms of probability. We will come back to this in

Section 6.

5 EVALUATION

The major beneﬁt of AQS is the very symmetric and

regular self-adapting structure resulting in several ad-

vantages. Compared to other approaches handling the

dynamic behavior of DRRQs by a more or less static

distribution plus a ﬂexible server-internal data struc-

ture, AQS does not need complex server data struc-

tures and handles the dynamics by using a very ﬂexi-

ble distribution pattern. Compared to DHI (Yu et al.,

2019) for example, we use a simple unsorted list and

an self-adapting cell structure instead of an local R

tree variants and a ﬁxed distribution grid. In con-

trast to DHI, the number of nodes per server (cell

count) and the branching factor (number of network

links to cell neighbors, sub- and supercells) are lim-

ited in AQS. The update costs for a split or merge

are therefore constant and do not inﬂuence cells be-

yond the direct links. Keeping the supercell saves

update costs for neighbor links. The communication

load can be limited due to the very regular cell struc-

tures: before sending an event to an adjacent cell, a

cell can easily check whether the other one covers the

node or its range due to its known coordinates and di-

mensions. Instead of parallelizing the calculation and

maintenance of saved range queries on a streaming

basis, as with DHI (Yu et al., 2019), we completely

renounce the storage of range queries and use stream-

ing in its originally intended sense as a ﬂowing event

data stream from clients to clients. Once, an location

update event from a client reaches the cell level, it

spreads in a waveform-like manner through the cell

structure until the cells transfer it back to their con-

nected nodes affected by the update.

Scalability. The scalability is given by construction

of the adaptive quad cell structure: in the best pos-

sible case of uniformly distributed nodes, the cell

structure splits very regularly with new nodes (system

join). If one cell X

(of capacity m = C

split

) splits into

subcells X

(u,i)

, the path length for the covered nodes

to other nodes might increase by one due to the re-

maining supercell X

. But at the same time, ∪X

(u,i)

provides free capacity for covered nodes of 3m until

the next split due to the uniform distribution. In to-

tal, ∪X

(u,i)

cover 4m nodes and after further k splits,

∪X

(u,i,n

,...,n

)

cover 4

m nodes. As a consequence,

for n → ∞ the cell count (server load) stays limited

and the path length between two client nodes c

and

and therewith the update time of a Q(c

) increases

in a logarithmic manner (base 4), if we use a lim-

ited average latency value per hop on the path. This

assumption also holds for non-uniformly distributed

scenarios since the average cell size decreases expo-

nentially (by splits) in high-density areas whereas the

path length grows logarithmically only. That means

that in these areas, the logarithmic behavior holds,

whereas in other areas with fewer new nodes, the path

length remains equal or grows in a sublogarithmic

manner. The exponentially decreasing cell size leads

to another result.

Approximation. The cell structure approximates the

spatial distribution of the client nodes in terms of cell

granularity. In high-density regions (hotspots), we

have much smaller cells which gradually adapt, i.e.

the nearer the hotspot edges get, the larger the cell

size will be. Much more interesting is the fact that

this way the cell structure approximates the ranges

of the queries in terms of falsely informed clients.

The better our cell structure approximates the shape

of the ranges on average, i.e. the circle lines, the less

clients are falsely informed. In order to motivate this

assumption, consider the fact that our system leads

to a coarsely granulated cell structure in low-density

areas. As a result, the cells approximate the shape

(circle line) of ranges less exactly compared to high-

density areas. But the inﬂuence of these coarse bigger

cells is reduced, since one of these cells cover fewer

nodes compared to areas of this size (covered by sev-

eral cells) in high-density regions. Therefore, even

if big cells inaccurately approximate the circle line

only, the number of falsely informed clients is still

small with respect to C

split

. If the circle line intersects

a cell, whether large or small, there is always only a

limited number of falsely informed nodes in it. As a

result, with an optimized pair of (C

split

merge

), the

range can be approximated as well as possible in or-

der to minimize the falsely informed clients. We will

demonstrate this in our experimental results in the fol-

lowing section.

6 EXPERIMENTAL RESULTS

For our performance test we consciously rely on very

limited hardware in terms of resources (single-board

computers Raspberry Pi 3 B+ with a 1.40 GHz quad-

core ARM processor and 1 GB main memory). As

OS we choose a minimal Unix distribution to reduce

external inﬂuence and run our Java implementation

on the Java Virtual Machine. To test different client

SENSORNETS 2021 - 10th International Conference on Sensor Networks

(a) Uniform

(b) Unequal

Figure 6: Tested client distribution scenarios and resulting

cell structure.

distributions with non-uniformity in high- and low-

density areas, we create three deterministic scenarios

of client movements the positions of which are visu-

alized as snapshots in Figure 6. To achieve compa-

rable results, we always test with a uniform client

distribution (Figure 6a) against a very high-density

hotspot with empty areas on the edge (Figure 6c)

and a less unequal distribution with a non-centered

hotspot (Figure 6b). With an increasing probability

Figure 7: Split threshold inﬂuence on error share and la-

tency.

of the nodes moving back to their spawn point the

further they move away, we ensure, that the distribu-

tion pattern does not change signiﬁcantly with ran-

dom client movement over time. A resulting cell

structure created by AQS is also displayed in Fig-

ure 6 for each of the example distribution scenarios

split

= 40). Obviously, the client distributions are

represented very well by the cell structure in the sys-

tem. Different movement velocities are considered to

get more realistic scenarios. The velocities allow each

client to move randomly, limited to a max. step size of

5% of the whole simulation area’s width or height per

update. We run our tests with |C| = 100‘000 clients in

an area of 1000 × 1000 and a query range of d

= 50.

To achieve comparable simulation results, all clients

update their location in the same time interval, and af-

ter 100‘000 updates a system snapshot is recorded for

the result sets described in the following.

Figure 8: Min/max latency in hotspot scenario.

Effect of Split Threshold C

split

. As already men-

tioned in Section 4.3, the approximation of a range

query leads to falsely sent LU

messages received by

a client node b

. Filtering those messages unnecessar-

ily consumes limited client resources. However, to re-

duce this proportion named error share, the threshold

split

can be decreased which leads to a better approx-

imation of the range query as demonstrated in Figure

7 used with our hotspot scenario. At the same time,

the communication effort increases as more cells must

be addressed while processing a location update with

a smaller C

split

in a deeper cell structure. This is also

shown in Figure 7 as latency representing an aver-

age time between sending an LU

from the updating

client node c

to all receiving client nodes b

. De-

picting additionally the minimum and maximum mea-

sured latency for all LU

s, Figure 8 shows that there

is no measured latency which strongly deviates from

the mean value even in a hotspot scenario. However,

in most real-life scenarios a real-time deadline t

300ms as in the ﬁreﬁghters scenario could easily be

fulﬁlled with the measured latency in our simulation

results, even in worst case.

Figure 9: Scalability with increasing client count.

Scalability with Increasing Client Count. To test

robustness in scalability on high-density clusters of

mobile clients, we record the average latency of LU

while spawning an increasing count of clients (sys-

tem join). This is shown in Figure 9 for our differ-

ent distribution scenarios (C

split

= 40). As we can

see, our solution performs sublinear with respect to

an increasing client count and is not much affected

by a non-uniform client distribution. Nevertheless we

discuss the inﬂuence of client distribution in the next

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming

paragraph.

Figure 10: Distribution effect on latency.

Effect of Hotspots. Hotspots are simulated with our

distribution scenarios described above and visualized

in Figure 6. As a high-density cluster of clients yield

to a deeper cell structure and a higher number of cells

in those areas, the average latency of an LU

event

increases more slowly as the error share decreases.

This can be easily identiﬁed by comparing Figure 10

and Figure 11: the ﬁrst one shows the increasing la-

tency for different split sizes and distribution scenar-

ios whereas the latter visualizes the error share in the

same way.

Reducing the error share in a high-density area is a

highly desirable result, as neighbor links in a ﬁx query

range rise very sharply in high-density hotspots and

challenge client nodes in maintaining many connec-

tions.

Figure 11: Distribution effect on error share.

Throughput in a Cell. While we are dealing with

limited server hardware, the throughput of events han-

dled by a cell within a certain time span is an interest-

ing point. As demonstrated in Figure 12, we could

record an average throughput of ≈ 10/ms in an in-

out-measuring setting. The vertical axis shows the av-

erage amount of events which can be processed by a

cell in one single millisecond whereas the horizontal

axis displays the simulation breakpoints recorded by

us over time while our clients are moving and produc-

ing a variety of different events. In Figure 13 we show

the workload of cell generated by the events (ﬁrst is

uniform, second is unequal, third is hotspot distribu-

tion). We use a uniform client distribution of 100‘000

s of 100‘000 clients. They are nearly equally

spread over all cells regardless of their structure layer.

As we can see, leaf cells handle fewer events com-

pared to other cells as expected due to missing sub-

cells. However, that is advantageous as the leaf cells

Figure 12: Throughput per cell over time.

have to handle their connected client nodes. Main-

taining these communication connections consumes

additional calculation power in mobile environments

(e.g. availability checks of unreliable mobile devices,

network changes, etc.).

Figure 13: Received events per cell per layer (uniform, un-

equal, hotspot).

An even more interesting point is the event work-

load in non-uniform distributions displayed in Fig-

ure 13. We identify the same general behavior of an

equally spread workload in upper cell layers as with

uniform distributions. But in lower cell structure lay-

ers the workload drops dramatically on average. An

explanation could be the many low-density areas in

those scenarios which are near a hotspot and there-

fore splitted in a deeper layer. The important mea-

sured value is the maximum workload received by a

cell which stays equally regardless of the distribution

pattern and indicates that our system does not over-

load any cell as expected.

Effect of Client Velocity. In Figure 14, we evaluate

the inﬂuence of client movement velocity on latency.

The horizontal axis represents the client’s velocity in

random movements which is realized with the step

size displayed on the axis, but in a random angle. Al-

though more cells are involved in high velocity up-

SENSORNETS 2021 - 10th International Conference on Sensor Networks

Figure 14: Inﬂuence of velocity on latency.

dates, the count of cells receiving an LU

(describing

a movement in time from t −1 to t) is limited. In the

worst case, the earlier query result R(c

t−1

) and new

one R(c

) do not intersect at all. This results in a pro-

cessing of all cells which are covered by both queries.

As also shown in Figure 14, AQS is robust enough

to deal with arbitrary client velocities as it hardly has

any inﬂuence on the end-to-end latency.

7 CONCLUSION AND FUTURE

WORK

In this paper we focused on a subclass of contin-

uous spatial range queries, the Dynamic Real-Time

Range Queries (DRRQ). In these queries, both, re-

questing and requested nodes, are mobile, leading

to always changing queries and results. The DR-

RQs address a category of mobile application sce-

narios we call ad-hoc mobility challenges. They

are rapidly gaining importance nowadays as clients

in high-density systems demand ad-hoc information

(movement) updates about other clients nearby in a

unpredictable and therefore real-time manner. In or-

der to address this scalability and real-time require-

ments, we presented Adaptive Quad Streaming (AQS)

as a highly distributed approach for DRRQs. It com-

bines a dynamically self-adapting cell structure with

a lightweight streaming approach. Along with a cell-

per-server assignment it adapts to arbitrary and al-

ways changing clients distributions using a splitting

and merging method and approximates the results of

DRRQs. We have shown in simulations that the error

rate of the approximation decreases more rapidly than

the end-to-end latency (one client’s movement update

to another client) increases with respect to the used

threshold for splitting. With a latency of 150ms we

achieved an error rate of 16% whereas an acceptable

latency of 200ms lowers the error rate to 4.5%. This is

obviously a good quality measure for the approxima-

tion of client distributions and corresponding range

shapes of client queries. AQS strictly limits the num-

ber of clients handled by a cell and server as well as

the number of links to other servers, that way control-

ling the processing and communication load. In con-

sequence, we also showed in our experiments, that the

latency grows logarithmically in the number of nodes

in the system. This is an indicator for the scalability of

AQS, capable to deal with arbitrary high numbers of

clients per area unit. The approximation of client dis-

tributions by dividing the work and communication

load of DRRQs between several servers and (in a very

limited way) also clients can be seen and also visual-

ized as a fuzzy two-dimensional edge between clients

and servers. This might be an interesting theoretical

insight in dynamically adapting edge computing.

Our future work lies in ﬁnding out how to assign a

server’s free capacity more ﬂexibly instead of assum-

ing an unlimited server pool and a one-server-per-cell

assignment in an idealistic manner. Another perspec-

tive might be how to react on imbalances between

processing and communication load as a degeneration

effect among the servers arising over time. A chal-

lenging aspect might be the inﬂuence to the results af-

ter a shift to more than two and also non-spatial client

dimensions, thus representing very realistic and con-

siderably more complex application scenarios.

REFERENCES

AL-Khalidi, H., Taniar, D., Betts, J., and Alamri, S. (2013).

On ﬁnding safe regions for moving range queries.

Mathematical and Computer Modelling.

Al-Khalidi, H., Taniar, D., and Safar, M. (2013). Ap-

proximate algorithms for static and continuous range

queries in mobile navigation. Computing.

Arya, S., Mount, D. M., Netanyahu, N. S., Silverman, R.,

and Wu, A. Y. (1998). An optimal algorithm for ap-

proximate nearest neighbor searching in ﬁxed dimen-

sions. Journal of the ACM.

Bamba, B., Liu, L., Iyengar, A., and Yu, P. S. (2009). Dis-

tributed processing of spatial alarms: A safe region-

based approach. International Conference on Dis-

tributed Computing Systems.

Cheema, M. A., Brankovic, L., Lin, X., Zhang, W., and

Wang, W. (2010). Multi-guarded safe zone: An ef-

fective technique to monitor moving circular range

queries. International Conf. on Data Engineering.

Gao, S., Ji, C., Xu, C., and Yang, N. (2014). Parallel spatial

nearest neighbour query based on grid index. 2014

IEEE Workshop on Electronics, Computer and Appli-

cations, IWECA 2014.

Gedik, B. and Liu, L. (2004). MobiEyes: Distributed Pro-

cessing of Continuously Moving Queries on Moving

Objects in a Mobile System. In Advances in Database

Technology - EDBT 2004. Springer Berlin Heidelberg.

Gedik, B. and Liu, L. (2006). MobiEyes: A distributed

location monitoring service using moving location

queries. IEEE Transactions on Mobile Computing.

International Telecommunication Union lTU (2015). IMT

Vision – Framework and overall objectives of the fu-

ture development of IMT for 2020 and beyond.

Real-Time Range Query Approximation by Means of Adaptive Quad Streaming

Jensen, C. S., Lin, D., and Ooi, B. C. (2004). +Query and

Update Efﬁcient B-Tree Based Indexing of Moving

Objects. In Proceedings 2004 VLDB Conf. Elsevier.

Kaczor, S. and Kryvinska, N. (2013). It is all about services-

fundamentals, drivers, and business models. Journal

of Service Science Research.

Kalashnikov, D., Prabhakar, S., Hambrusch, S., and Aref,

W. (2002). Efﬁcient evaluation of continuous range

queries on moving objects. Lecture Notes in Computer

Science.

Kao, Y. H., Krishnamachari, B., Ra, M. R., and Bai, F.

(2017). HERMES: Latency Optimal Task Assignment

for Resource-constrained Mobile Computing. IEEE

Transactions on Mobile Computing.

Mokbel, M. F. and Aref, W. G. (2005). GPAC: Generic and

progressive processing of mobile queries over mobile

data. Sixth International Conference on Mobile Data

Management, MDM’05.

Mokbel, M. F. and Aref, W. G. (2008). SOLE: Scalable

on-line execution of continuous queries on spatio-

temporal data streams. VLDB Journal.

Mokbel, M. F., Xiong, X., and Aref, W. G. (2004). SINA.

In The 2004 ACM SIGMOD international conference

on Management of data - SIGMOD ’04. ACM Press.

Moln

ar, E., Moln

ar, R., Kryvinska, N., and Gregu

s, M.

(2014). Web intelligence in practice. Journal of Ser-

vice Science Research.

Mouratidis, K., Bakiras, S., and Papadias, D. (2009).

Continuous monitoring of spatial queries in wireless

broadcast environments. IEEE Transactions on Mo-

bile Computing.

Mouratidis, K., Hadjieleftheriou, M., and Papadias, D.

(2005a). Conceptual partitioning: An efﬁcient method

for continuous nearest neighbor monitoring. ACM

SIGMOD Int. Conference on Management of Data.

Mouratidis, K., Papadias, D., Bakiras, S., and Tao, Y.

(2005b). A threshold-based algorithm for continuous

monitoring of k nearest neighbors. IEEE Transactions

on Knowledge and Data Engineering.

Papadias, D., Mamoulis, N., Zhang, J., and Tao, Y. (2003).

Query processing in spatial network databases. 29th

International Conference on Very Large Data Bases.

Prabhakar, S., Xia, Y., Kalashnikov, D. V., Aref, W. G., and

Hambrusch, S. E. (2002). Query indexing and velocity

constrained indexing: Scalable techniques for contin-

uous queries on moving objects. IEEE Transactions

on Computers.

Saltenis, S. and Jensen, C. S. (2002). Indexing of mov-

ing objects for location-based services. International

Conference on Data Engineering.

Saltenis, S., Jensen, C. S., Leutenegger, S. T., and Lopez,

M. A. (2000). Indexing the positions of continuously

moving objects. SIGMOD Record (ACM Special In-

terest Group on Management of Data).

Shao, Z. and Taniar, D. (2014). Range-based nearest neigh-

bour search in a mobile environment. 12th Interna-

tional Conference on Advances in Mobile Computing

and Multimedia, MoMM 2014.

Sidlauskas, D.,

Saltenis, S., and Jensen, C. S. (2012). Par-

allel main-memory indexing for moving-object query

and update workloads. The ACM SIGMOD Interna-

tional Conference on Management of Data.

Song, Z. and Roussopoulos, N. (2003). SEB-tree: An Ap-

proach to Index Continuously Moving Objects. In Mo-

bile Data Management. Springer Berlin Heidelberg.

Tao, Y. and Papadias, D. (2003). Spatial Queries in Dy-

namic Environments. ACM Transactions on Database

Systems.

Tayeb, J. (1998). A Quadtree-Based Dynamic Attribute In-

dexing Method. The Computer Journal.

Wang, H. and Zimmermann, R. (2008). Snapshot location-

based query processing on moving objects in road net-

works. GIS: ACM International Symposium on Ad-

vances in Geographic Information Systems.

Wang, H., Zimmermann, R., and Ku, W.-S. (2006). Dis-

tributed Continuous Range Query Processing on Mov-

ing Objects. In Database and Expert Systems Appli-

cations. Springer Berlin Heidelberg.

Wu, K. L., Chen, S. K., and Yu, P. S. (2004a). Index-

ing continual range queries for location-aware mobile

services. 2004 IEEE International Conference on e-

Technology, e-Commerce and e-Service, EEE 2004.

Wu, K. L., Chen, S. K., and Yu, P. S. (2004b). Indexing

continual range queries with covering tiles for fast lo-

cating of moving objects. International Conference

on Distributed Computing Systems.

Wu, K. L., Chen, S. K., and Yu, P. S. (2004c). Process-

ing continual range queries over moving objects using

VCR-based query indexes. MOBIQUITOUS 2004 -

1st Annual International Conference on Mobile and

Ubiquitous Systems: Networking and Services.

Wu, K. L., Chen, S. K., and Yu, P. S. (2005). On incremen-

tal processing of continual range queries for location-

aware services and applications. MobiQuitous 2005:

Second Annual International Conference on Mobile

and Ubiquitous Systems -Networking and Services.

Wu, W., Guo, W., and Tan, K. L. (2007). Distributed pro-

cessing of moving K-nearest-neighbor query on mov-

ing objects. Int. Conference on Data Engineering.

Xuan, K., Zhao, G., Taniar, D., Rahayu, W., Safar, M., and

Srinivasan, B. (2011). Voronoi-based range and con-

tinuous range query processing in mobile databases.

Journal of Computer and System Sciences.

Yang, K.-T. and Chiu, G.-M. (2017). Monitoring contin-

uous all -nearest neighbor query in mobile network

environments. Pervasive and Mobile Computing.

Ying Cai, Hua, K., Guohong Cao, and Xu, T. (2006). Real-

time processing of range-monitoring queries in het-

erogeneous mobile databases. IEEE Transactions on

Mobile Computing.

Yu, X., Pu, K. Q., and Koudas, N. (2005). Monitoring k-

nearest neighbor queries over moving objects. Inter-

national Conference on Data Engineering.

Yu, Z., Xhafa, F., Chen, Y., and Ma, K. (2019). A distributed

hybrid index for processing continuous range queries

over moving objects. Soft Computing.

Zheng, B., Xu, J., Lee, W.-C., and Lee, D. L. (2006). Grid-

partition index: a hybrid method for nearest-neighbor

queries in wireless location-based services. The VLDB

Journal.

SENSORNETS 2021 - 10th International Conference on Sensor Networks
