From Quantities in Software Models to Implementation

Steve McKeever

Department of Informatics and Media, Uppsala University, Sweden

Keywords:

Units of Measurement, Quantity Pattern, Libraries, Component based Checking, Testing.

Abstract:

In scientiﬁc and engineering applications, physical quantities expressed as units of measurement (UoM) are

used regularly. If the algebraic properties of a system’s UoM information are incorrectly handled at run-time

then catastrophic problems can arise. Much work has gone into creating libraries, languages and tools to ensure

developers can leverage UoM information in their designs and codes. While there are technical solutions

that allow units of measurement to be speciﬁed at both the model and code level, a broader assessment of

their strengths and weaknesses has not been undertaken. Inspired by a survey of practitioners, we review

four competing methods that support unit checking of code bases. The most straightforward solution is for

the programming language to Natively support UoM as this allows for efﬁcient unit conversion and static

checking. Alas, none of the mainstream languages provide such support. Libraries might seem compelling,

and all popular programming languages have a myriad of options, but they’re cumbersome in practice and

have speciﬁc performance costs. Libraries are best suited to applications in which UoM checking is desirable

at run-time. Lightweight methods, such as Component based checking or Black Box testing, provide many

beneﬁts of UoM libraries with minimal overheads but sacriﬁce coverage and thus robustness. By separating

and analysing the various options, we hope to enable scientiﬁc developers to select the most appropriate

approach to transferring UoM information from their software models to their programs.

1 INTRODUCTION

Ensuring numerical values that denote physical quan-

tities are handled correctly is an essential requirement

for the design and development of any engineering

application. Notorious examples such as the Mars

Climate Orbiter (Stephenson et al., 1999) or the Gimli

Glider incident (Witkin, 1983) attest to this. With ever

increasing digitalisation, and removal of humans in

the loop, the need to faithfully represent and manipu-

late quantities in physical systems is ever increasing.

There are many ways in which this can be achieved,

allowing the designer or programmer to rely on the

checker to ensure correctness and not on themselves

or their colleagues. The software engineering bene-

ﬁts of adopting unit checking and automatic conver-

sion support is indisputable. However, it is not al-

ways clear which approach is best suited for a given

problem, coupled with a general lack of awareness of

solutions, means that implementers often reinvent the

wheel or forgo any kind of checking.

Providing unit support in spreadsheets (Antoniu

https://orcid.org/0000-0002-1970-2884

et al., 2004), Wolfram Mathematica

, simulation tools

and modeling environments has been very effective.

For dedicated workﬂows that support numerical ap-

plications, the cost of annotating cells or variables

with unit information is typically ingrained in the de-

sign process and thus less intrusive than in a more

general setting. Modelica (Modelica, 2020) supports

UoM and checks descriptions before animating them.

Domain speciﬁc languages for the curation and inter-

change of biological models

support UoM informa-

tion and require unit validation before uploading to

repositories.

For general purpose development we have to look

before the advent of object oriented modeling lan-

guages or formal speciﬁcation notations. Adding

units to conventional programming languages goes

back to the 1970s (Karr and Loveman, 1978) and

early 80s with proposals to extend Fortran (Gehani,

1977) and then Pascal (Dreiheller et al., 1986). These

efforts were mostly syntax based. A more viable start-

ing point would be (Hilﬁnger, 1988) that showed how

to exploit Ada’s abstraction facilities, namely opera-

https://www.wolfram.com/mathematica/

sbml.org, cellml.org

McKeever, S.

From Quantities in Software Models to Implementation.

DOI: 10.5220/0010247201990206

In Proceedings of the 9th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2021), pages 199-206

ISBN: 978-989-758-487-9

199

tor overloading and type parameterisation, to assign

attributes for UoM to variables and values. The emer-

gence of Object Oriented programming languages en-

abled developers to implement UoM either through a

class hierarchy of units and their derived forms, or

through the Quantity pattern (Fowler, 1997). There

are a large number of libraries for all popular object

oriented programming languages that support this ap-

proach (McKeever et al., 2019).

Software development typically begins at a more

abstract level through diagrams and rules that fo-

cus on the conceptual model that is to be imple-

mented. By extending the Uniﬁed Modeling Lan-

guage (UML), quantities can be introduced into an

object-oriented modeling platform. Unit checking

and conversion can be undertaken before code is gen-

erated, either through a compilation workﬂow that

leverages Object Constraint Language (OCL) expres-

sions (Mayerhofer et al., 2016) or staged computa-

tion (Allen et al., 2004). Similarly (Gibson and M

ery,

2017) add units to the Event-B modelling language

and leverage the Rodin theorem prover to detect in-

consistencies before compiling to Java. Compara-

ble ideas have been presented for the formal speci-

ﬁcation language Z (Hayes and Mahony, 1995) and

Maude (Chen et al., 2003). More specialised UML

based systems modeling languages such as MARTE

and SysML

also have UoM support (Burgue

no et al.,

2019). These elegant abstractions lift the declaration

and management of units into software models. How-

ever once the code has been generated, UoM informa-

tion might very well be lost unless the workﬂow has

been tailored explicitly. This is the research question

that we address, namely what is the most appropriate

approach to transferring UoM information into soft-

ware. We consider aspects such as ease of use, execu-

tion speed, numeric accuracy, ease of integration and

coverage of unit error detection capabilities. These

aspects reﬂect our study of UoM libraries, survey of

practitioners and preliminary design suggestions sum-

marised in (McKeever et al., 2020).

We lack a deﬁnitive estimate of how frequently

unit inconsistencies occur or their cost. Anecdotally

we can glean that it is not negligible from experiments

described in the literature. When applied to a repos-

itory of CellML models, a validation tool (Cooper

and McKeever, 2008) found that 60% of the descrip-

tions that were invalid had dimensionally inconsistent

units. A spreadsheet checker (Antoniu et al., 2004)

was applied to 22 published scientiﬁc spreadsheets

and detected 3 with errors. A lightweight C++ unit in-

consistency tool (Ore et al., 2017a) was applied to 213

https://www.omg.org/omgmarte/

https://sysml.org

open-source systems, ﬁnding inconsistencies in 11%

of them. A further study (Ore et al., 2017c) using

a corpus of robot software with 5.9M lines of code,

found dimensional inconsistencies in 6% of reposito-

ries. Thus, it seems important to ensure UoM infor-

mation existing in Software Models is supported in

derived implementations.

The decision on which approach to choose, if

at all, will depend more on the requirements of the

project and whether the various components of the

system can support UoM types. Very few program-

ming languages provide Native support for quantities

so this is rarely an option. UoM Libraries are not al-

ways the most effective solution. Lightweight meth-

ods, such as Component based checkers or Black Box

testing, often provide ‘good enough’ detection with-

out the drawbacks. UoM libraries are best suited to

run-time checking where performance is not a key

condition but correctness is.

The rest of this paper is structured as follows. In

Section 2 we provide a brief background to UoM and

the Quantity pattern. In Section 3 we describe the four

means of supporting UoM information in implemen-

tations and in Section 4 we summarise the results of

our comparative study, providing suggestions for de-

velopers as to which method to choose depending on

their requirements.

2 BACKGROUND

The technical deﬁnition of a physical quantity is

a “property of a phenomenon, body, or substance,

where the property has a magnitude that can be ex-

pressed as a number and a reference” (Joint Com-

mittee for Guides in Metrology (JCGM), 2012). Each

quantity is declared as a number (the magnitude of

the quantity) with an associated unit (Bureau Interna-

tional des Poids et Mesures, 2019). For example you

could assert the physical quantity of length with the

unit metre and the magnitude 10 (10m). However, the

same length can also be expressed using other units

such as centimetres or kilometres, at the same time

changing the magnitude (1000cm or 0.01km). Al-

though these examples are all based on the Interna-

tional System of Units (SI), which is the most used

and well known unit system, there exists several other

systems, such as the Imperial system.

Units can be deﬁned in the most generic form as

either base quantities or derived quantities. The base

quantities are the basic building blocks, and the de-

rived quantities are built from these. The base quanti-

ties and derived quantities together form a way of de-

scribing any part of the physical world (Sonin, 2001).

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

200

For example length (metre) is a base quantity, and

so is time (second). If these two base quantities

are combined they express velocity (metre/second or

metre × second

−1

) which is a derived quantity. The

International System of Units (SI) deﬁnes seven base

quantities (length, mass, time, electric current, ther-

modynamic temperature, amount of substance, and

luminous intensity) as well as a corresponding unit

for each quantity (NIST, 2015). Using an Object Ori-

ented language we could create a class hierarchy for

each base type and use a tree structure to construct

derived types. However this would result in hundreds

of units and thousands of conversions. Also showing

two unit deﬁnitions to be equivalent would be non-

trivial.

Fortunately, a normal form exists which makes

storage and comparison a lot easier. Any system of

units can be derived from the base units as a prod-

uct of powers of those base units: base

×base

...base

, where the exponents e

,. .. ,e

are rational

numbers. Thus an SI unit can be represented as a 7-

tuple he

,. .. ,e

i where e

denotes the i-th base unit;

or in our case e

denotes length, e

mass, e

time and

so on. In Java this would be represented as:

class Unit {

private int [7] dimension

private float [7] conversionFactor

private int [7] offset

...

boolean isCompatibleWith (Unit u)

boolean equals (Unit u)

Unit multiplyUnits (Unit u)

Unit divideUnits (Unit u)

}

The dimension array contains the 7-tuple of base

unit exponentials. The attributes conversionFactor

and offset enable conversions from this unit system

to the SI units. The class Unit also deﬁnes oper-

ations to compare and combine units. The method

isCompatibleWith checks whether two units are

compatible for being combined, such as miles and

centimetres. While equals returns true if the units

are exactly the same, which is used when adding or

subtracting quantities. When two quantities are mul-

tiplied then multiplyUnits adds the two dimension

arrays. Correspondingly, divideUnits subtracts

each of the elements of the dimension array.

Using this representation for a unit we can con-

struct the Quantity pattern (Fowler, 1997).

class Quantity {

private float value;

private Unit unit;

....

}

We can include arithmetic operations to the Quantity

class that ensures addition and subtraction only suc-

ceed when their units are equivalent, or multiplica-

tion and division generate a new unit that represents

the derived value correctly. This pattern is the basis

for many UoM Libraries (McKeever et al., 2019) but

can also be described in UML.

The Quantity pattern provides a means of annotat-

ing variable declarations and method signatures with

behavioural UoM speciﬁcations. Bearing in mind the

annotation burden, (Ore et al., 2018) found subjects

choose a correct UoM annotation only 51% of the

time and take an average of 136 seconds to make a

single correct annotation. In a Software Model, enti-

ties annotated in this manner are merely decorative.

Tools can be written to ensure that the models use

quantity information correctly, but they need to be

rendered into the codebase to ensure implementations

are robust with regards to UoMs. In the next Section

we explore the various options for transferring UoM

information faithfully into program code.

3 IMPLEMENTATION OPTIONS

Many constructs in Software Models can be directly

translated into code. A UML class diagram can be

used to build the class structure of an Object Ori-

ented implementation. However with UoM annota-

tions the situation is more complex. Applying UoM

annotations requires an advanced checker to ensure

variables and method calls are handled soundly. Two

units are compatible if they both can be represented

as the same derived quantity. For instance degrees

Celsius is compatible with Fahrenheit. Values in Cel-

sius can be converted to values in Fahrenheit. Sur-

face tension can be described as newtons per meter or

kilogram per second squared, and even though they

equate they represent different quantities. For com-

plex derived units, showing compatibility is not so

straightforward, nor is it clear whether such quanti-

ties should be aligned (Hall, 2020). Managing such

quantities at run-time requires UoMs to become ﬁrst-

class citizens.

Two values can be added or subtracted only if their

units are the same. Multiplication and division ei-

ther add or subtract the two units product of power

representations, assuming both values are compati-

ble. Converting values to ensure compatibility can

create round-off errors. Once a variable has been de-

ﬁned to be of a given unit, then it will remain as such.

Checking that all annotated entities behave according

to these rules ensures both completeness and correct-

ness of the model or program. If a variable or method

call is incorrectly annotated an error will arise. When

From Quantities in Software Models to Implementation

201

Native

Language

Static or

Dynamic

Library

Component

or Interface

Description

Black-Box

Testing

Software Model with UoM

Implemented

through

Figure 1: From a Software Model that includes UoM information to an implementation that supports them.

not all variables or method calls are annotated then

neither completeness nor correctness can be guaran-

teed. All implementation options are affected by the

following three concerns (McKeever et al., 2020):

Lack of Awareness: many developers are totally un-

aware of software solutions that deal with UoM.

Inertia from developers stem from factors like tra-

dition, fear of change and effort of learning some-

thing new.

Technical Internal Factors: many solutions are

awkward and imprecise, introducing a loss of pre-

cision and struggling at times with dimensional

consistencies.

External Factors: modern systems are not built in a

vacuum but form part of an eco-system (Lungu,

2008). It is harder to argue for UoM annotations

when values pass through numerous generic com-

ponents that do not support them, such as legacy

systems, databases, spreadsheets, graphics tools

and many other components that are unlikely to

support UoM without costly updates.

The rest of this section will focus on the technical fac-

tors of each approach.

3.1 Native Language Support

Adding unit checking to conventional imperative,

object-oriented and even functional languages using

syntactic sugaring is beyond the algorithmic scope of

their underlying type checkers. The pioneering foun-

dational work (Wand and O’Keefe, 1991) showed

how to add dimensions to the simply-typed lambda

calculus, such that polymorphic dimensions can be

inferred in a way that is a natural extension of Mil-

ner’s polymorphic type inference algorithm (Milner,

1978). The key feature of UoM is that they cannot

be solved symbolically but equationally using the the-

ory of Abelian groups (Kennedy, 1994). Providing

UoM syntax and an equational checker is what dis-

tinguishes a language with native support. UoM in-

formation is checked at compile-time and can be re-

moved from the generated run-time code. Moreover

unit conversions can be minimised in order to reduce

round-off errors (Cooper and McKeever, 2008).

The only language in the 20 most popular pro-

gramming languages (TIOBE, 2020) that supports

units of measurement is Apple’s Swift language (Ap-

ple, 2020). The only other well-known language to

support units of measurement is F# (Microsoft, 2020)

which has the added beneﬁt of allowing unit variables,

namely undeﬁned unit types, that the compile-time

checker will attempt to resolve. If there is insufﬁ-

cient information then the program will be rejected.

This feature allows a small degree of incompleteness

in language deﬁnitions so the burden of annotation is

mitigated somewhat, but the static checker will de-

rive the missing UoM information so correctness is

ensured. Nonetheless neither Swift nor F# are com-

mon in large software engineering projects.

C++ is still very popular (TIOBE, 2020) and has

a de facto UoM extension that exploits the template

meta-programming feature

. Consequently BoostU-

nits is more than just a library as it supports a staged

computation model, similar to MixGen (Allen et al.,

2004), that is more akin to a language extension and

supports backwards compatibility. None of the other

prominent programming languages have this ﬂexible

compilation strategy. This staged approach is very

similar to native language support and, with appropri-

ate compiler optimisation, no run-time execution cost

is introduced. C++ with the BoostUnits library sup-

ports UoM checking in performance-critical code. In

practice, however, the survey (Salah and McKeever,

2020) found both accuracy and usability issues with

the use of this extension.

Translating a Software Model with UoM informa-

tion into a native language with UoM support ensures

that quantity information is maintained, and that the

implementation more closely represents the speciﬁ-

cation. Even if the original software model was auto-

github.com/boostorg/units

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

202

matically checked, the code will typically be modiﬁed

once in use. Refactoring will have to maintain UoM

information but the compile-time checker will guar-

antee correctness.

Native language support is best suited to safety-

critical applications where a single unit system is

employed, checking must be complete, performed at

compile-time and have no run-time performance cost.

3.2 Static or Dynamic Library Support

As few programming languages support UoM na-

tively, a second approach is to use a library that pro-

vides units of measurement. With advanced abstrac-

tion methods such as classes and generics, develop-

ing libraries that work well with existing code bases

is possible nowadays. Consequently there are many

libraries for all contemporary languages (Bennich-

orkman and McKeever, 2018). The core issue that

these libraries aim to solve is something that is rel-

atively easy to understand and familiar. However as

Bekolay argued “making a physical quantity library

is easy but making a good one is hard” (Bekolay,

2013). Trying to make a more complete library, in-

cluding more units, more operators, effective conver-

sions, good error messages, efﬁcient and accurate is

far more demanding than a robust implementation of

the Quantity pattern (Fowler, 1997; Krisper et al.,

2017).

In practice there are many problems with their use.

They require too much boilerplate code, they’re rarely

idiomatic to their host language, provide poor error

messages, lack support for user deﬁned types and re-

strict underlying storage to a single ﬂoating point rep-

resentation. Certain languages, like Ruby, are less

affective by these shortfalls as they encourage duck

typing and a ﬂexible syntax that facilitates domain

speciﬁc language creation. Nonetheless (McKeever

et al., 2020), concludes that UoM types need to be as

straightforward to use as arithmetic types or at least

as close as possible for adoption to occur.

A strength of libraries is that they can support both

compile-time and run-time error detection. Compile-

time checking can be achieved through static over-

loading, or Java generic instantiations. While run-

time checking is achieved through overriding. An ex-

ample of both styles is shown in (McKeever et al.,

2020). Combining the two semantics, even with the

compact Quantity Pattern representation, would dou-

ble the amount of syntax required and further com-

plicate usage. Dynamically typed languages, such as

Ruby or Python, will by deﬁnition perform quantity

checking at run-time. Run-time support is a key re-

quirement for certain projects: “In our product line,

our users may very well have one ﬁle whose units

are “kg · m

”, another whose units are “g

cc” and

a third whose units are “degrees Celsius”. We there-

fore need to be able to operate on units at run-time,

not compile-time” (Salah and McKeever, 2020).

A weakness of libraries compared to native lan-

guage support is that variables of a Quantity class can

be reassigned at run-time, due to their semantics be-

ing embedded within the dimension array, so that a

meter could become a kilogram. Unit mismatch and

conversion errors can be detected by UoM libraries

but avoiding programming style errors requires fur-

ther discipline that a conventional static checker pro-

vides. Such errors are caused by violations of stan-

dard type systems, such as when an intermediate vari-

able is used with different units. These were found

to account for 75% of inconsistencies in the study of

5.9M lines of code (Ore et al., 2017c).

Their core disadvantage, however, is that their im-

plementation requires boxed values rather than the

standard primitive entities. When units are not part

of the language then there is a cost at both compile-

time and run-time. For applications that carry out

lots of calculations (such as matrix multiplications),

their performance tends to matter more and boxed val-

ues with types would have unnecessary performance

overheads. At ﬁrst glance, a UoM library might seem

easy to use and include in a software project, but the

inner workings of the UoM library often increase the

complexity of a project.

3.3 Component or Interface Description

Support

Both Native language support and Libraries require

all UoM variables and function deﬁnitions to have an-

notations. Lightweight Component or Interface based

approaches aim to liberate the scientiﬁc programmer

from the need to annotate each statement. Interfaces

are the dividing line between the implementation of

a particular functionality and its users. Encapsulating

implementation details, interfaces are a collection of

the externally visible entities and function signatures

of a component. They are used by the compiler to

ensure access is handled correctly. A component im-

plementer would want to further restrict access with

semantic details such as UoM annotations. Ideally, an

interface that solves a particular computational prob-

lem for meters would differ from one that solves the

same problem for miles.

A Component based approach seeks to add UoM

information to the interface in order to enforce

unit consistency when composing components and

thereby reduce dimensional mismatch errors. In

From Quantities in Software Models to Implementation

203

class Distance {

public double add_km(boolean t,

double a, double b) {

return ((t)? a+b : a+(b*1.609));}}

...

public class DistanceTest {

public void test_add_km() {

Distance d = new Distance();

assert(d.add_km(true,10.0,10.0)==20.0);

assert(d.add_km(false,10.0,10.0)==26.09);}}

Figure 2: Java code and JUnit test case for simple addition

of two kilometres, or kilometre and mile distances.

(Damevski, 2009), he argues that units of measure-

ment should be inserted in software component in-

terfaces. There is some anecdotal evidence in the

many quotes of (Salah and McKeever, 2020) to sup-

port this approach. Damevski postulates that unit li-

braries are too constraining and incur an annotation

or migration burden. His algorithm attempts to re-

solve UoM at run-time so that if the types of the called

method’s parameters are compatible with the argu-

ments then unit conversions occur. Consider the C++

class Earth (Damevski, 2009):

class Earth {

void setCircumference(in Meter circumference);

Meter getCircumference();

}

It assigns and queries the earth’s circumference using

meters internally but can be called with kilometres and

the return value bound to a variable of, say, type miles.

Unlike libraries, within the class Earth no further an-

notations are required, nor will it be checked. The

variable circumference will be assigned to a double.

Another lightweight methodology was presented

by Ore (Ore et al., 2017a) that uses an initial pass

to build a mapping from attributes in C++ shared li-

braries to units. The shared libraries contain UoM

speciﬁcations so this mapping is used to propagate

into a source program and detect inconsistencies at

compile-time. Their algorithm leverages dimensional

analysis rules for arithmetic operators to great ef-

fect (Ore et al., 2017b).

A Component based discipline means that the

consequences of local unit mistakes are underesti-

mated. On the other hand, it allows diverse teams to

collaborate even if their domain speciﬁc environments

or choice of quantity systems were, to some extent,

dissimilar. More importantly it would have been suf-

ﬁcient to have caught the Mars Climate Orbiter error.

3.4 Black-Box Testing

A ﬁnal means of ensuring UoM checking is through

automated testing. Black Box Testing mainly fo-

cuses on input and output of software applications

and it is entirely based on software requirements and

speciﬁcations. It seeks to spot incorrect or missing

functions, interface errors, initialisation errors and

errors in data structures. Creating Black Box unit

tests from Software Models is another lightweight ap-

proach. The testing will not be exhaustive, as the

focus would be on the initialisation of variables, the

correctness of assignments and method calls. There

have been many efforts to automatically generate unit

tests from UML descriptions (Cavarra et al., 2002;

Hartmann et al., 2005; Ali et al., 2010; Mussa et al.,

2009), either through behavioural diagrams or with

rule based approaches. However these techniques are

seen to be costly and non-trivial in practice (Kasuri-

nen et al., 2010).

Nonetheless, it is fairly common nowadays to

manually develop tests alongside models, not only for

the purpose of test driven development but also to en-

sure maintainability through refactoring. Including

UoM tests requires no extra tool support and will not

affect the eco-system as shown in Figure 2. Spending

time writing unit tests would equate to adding unit

annotations without the introduction of a library: “I

could use the same time to write tests and that would

really ﬁnd and prevent errors and at the same time not

introduce a crazy complicated library every other de-

veloper in my team would have to deal with.” (Salah

and McKeever, 2020). However, the UoM knowledge

will be localised to each particular unit so the slight

implementation cost comes at the expense of poten-

tially average checking.

4 CONCLUSION

With greater interoperability, industrial use of com-

putational simulations and penetration of digitalisa-

tion through cyber-physical systems; it seems perti-

nent to faithfully represent key properties of phys-

ical systems such as units of measurement in code

bases (Selic, 2015). Beginning with quantity anno-

tated Software Models that could be diagrammatic or

equational, we sought to elucidate the most appropri-

ate method to migrate this information into code. Alas

Native Language support is not available for popular

programming languages. This situation is unlikely to

change as it would require new language deﬁnitions

and expensive compiler rewrites, with an important

criteria of ensuring backwards compatibility with ex-

isting code. It is clear that even the best Libraries cur-

rently cause signiﬁcant performance issues while not

being relevant for most developers. However some

of the dynamic libraries are able to distinguish be-

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

204

Table 1: Contrasting alternative methods of Implementing Unit of Measurements in Software Projects.

Technique Programming Execution Numeric Ease of Unit Error

Ease of Use Speed Accuracy Integration Detection

Native Support Average Very High Very Good Low Very High

Static Library Low Average Good Low High

Dynamic Library Average Low Good Low High

Static Component Based High High Very Good High Average

Dynamic Component Based High Average Good High Average

Black Box Testing Average High Very Good Very High Average

tween quantities which are of the same kind and quan-

tities that are of different kinds but have the same

units. Component based techniques can be under-

taken at both compile-time and run-time. They forgo

completeness and thus correctness to ensure ease of

adoption. Black Box testing based approaches are

currently undertaken manually but offer many of the

advantages of compile-time component based tech-

niques without additional syntax. However, UoM in-

formation will then be embedded within the unit tests

and not part of the code base.

UoM annotations are initially costly for the de-

veloper but relatively stable to program reorganisa-

tion. Refactoring will rarely require UoM annota-

tion changes unless the underlying data structures are

also modiﬁed, thus ensuring maintainability and scal-

ability within potentially safety-critical code. Ap-

proaches that leverage the compiler to optimise unit

conversions without boxed values, such as native sup-

port or static lightweight solutions, will ensure greater

numeric accuracy.

We can summarise the beneﬁts and drawbacks of

each approach in Table 1 using some of the key fac-

tors that we have focused on. Presented in this manner

it becomes clear that static UoM Libraries offer few

compelling advantages over Component or Black Box

based testing. Native language support can offer dis-

tinct advantages as the checking will have greater cov-

erage and can be equational, thereby resolving unit

variables, with the added beneﬁt of compiler optimi-

sations to reduce round-off errors and increase run-

time performance. Although, complex modern soft-

ware tends to favour more lightweight solutions that

integrate seamlessly into existing eco-systems.

Beginning with a Software Model that includes

UoM information we have attempted to show the vari-

ous tradeoffs involved in deciding how best to support

their implementation when taking their software eco-

system into account. Stand-alone safety critical appli-

cations, where all unit information will be known and

supported at compile-time, are very different to the

needs of a rapidly evolving on-line application that

expects to deal with varying UoM input at run-time.

REFERENCES

Ali, S., Hemmati, H., Holt, N., Arisholm, E., and Briand,

L. (2010). Model transformations as a strategy to au-

tomate model-based testing-a tool and industrial case

studies. Simula Research Laboratory, Technical Re-

port (2010-01), pages 1–28.

Allen, E., Chase, D., Luchangco, V., Maessen, J.-W., and

Steele, Jr., G. L. (2004). Object-oriented units of

measurement. In Proceedings of Object-oriented Pro-

gramming, Systems, Languages, and Applications,

OOPSLA ’04, pages 384–403, NY, USA. ACM.

Antoniu, T., Steckler, P. A., Krishnamurthi, S., Neuwirth,

E., and Felleisen, M. (2004). Validating the unit cor-

rectness of spreadsheet programs. In Proceedings

of Software Engineering, ICSE ’04, pages 439–448,

Washington, DC, USA. IEEE Computer Society.

Apple (2020). Swift open source. Online https://swift.org.

Last Accessed on 15th April 2020.

Bekolay, T. (2013). A comprehensive look at representing

physical quantities in python. In Scientiﬁc Computing

with Python.

Bennich-Bj

orkman, O. and McKeever, S. (2018). The next

700 Unit of Measurement Checkers. In Proceedings

of Software Language Engineering, SLE 2018, page

121–132, NY, USA. Association for Computing Ma-

chinery.

Bureau International des Poids et Mesures (2019). SI

Brochure: The International System of Units (SI),

9th Edition, Dimensions of Quantities. Online

https://www.bipm.org. Last Accessed 15th April,

2020.

Burgue

no, L., Mayerhofer, T., Wimmer, M., and Vallecillo,

A. (2019). Specifying Quantities in Software Models.

Information and Software Technology, 113:82 – 97.

Cavarra, A., Crichton, C., Davies, J., Hartman, A., Jeron, T.,

and Mounier, L. (2002). Using UML for Automatic

test Generation. Proceedings of ISSTA.

Chen, F., Rosu, G., and Venkatesan, R. P. (2003). Rule-

Based Analysis of Dimensional Safety. In RTA.

Cooper, J. and McKeever, S. (2008). A model-driven ap-

proach to automatic conversion of physical units. Soft-

ware: Practice and Experience, 38(4):337–359.

Damevski, K. (2009). Expressing measurement units

in interfaces for scientiﬁc component software. In

Proceedings of Component-Based High Performance

Computing, CBHPC ’09, pages 13:1–13:8, NY, USA.

ACM.

From Quantities in Software Models to Implementation

205

Dreiheller, A., Mohr, B., and Moerschbacher, M. (1986).

Programming pascal with physical units. SIGPLAN

Notes, 21(12):114–123.

Fowler, M. (1997). Analysis Patterns: Reusable Objects

Models. Addison-Wesley Longman Publishing Co.,

Inc., Boston, MA, USA.

Gehani, N. (1977). Units of measure as a data attribute.

Computer Languages, 2(3):93 – 111.

Gibson, J. P. and M

ery, D. (2017). Explicit modelling of

physical measures: from Event-B to Java. In Interna-

tional Workshop on Handling IMPlicit and EXplicit

knowledge in formal system development.

Hall, B. D. (2020). Software for calculation with physical

quantities. In 2020 IEEE International Workshop on

Metrology for Industry 4.0 IoT, pages 458–463.

Hartmann, J., Vieira, M., Foster, H., and Ruder, A. (2005).

A UML-based approach to system testing. Innova-

tions in Systems and Software Engineering, 1:12–24.

Hayes, I. J. and Mahony, B. P. (1995). Using Units of Mea-

surement in Formal Speciﬁcations. Formal Aspects of

Computing, 7(3):329–347.

Hilﬁnger, P. N. (1988). An Ada Package for Dimen-

sional Analysis. ACM Trans. Program. Lang. Syst.,

10(2):189–203.

Joint Committee for Guides in Metrology (JCGM) (2012).

International Vocabulary of Metrology, Basic and

General Concepts and Associated Terms (VIM). On-

line https://www.bipm.org/en/about-us/. Last Ac-

cessed 15th April 2020.

Karr, M. and Loveman, D. B. (1978). Incorporation of

Units into Programming Languages. Commun. ACM,

21(5):385–391.

Kasurinen, J., Taipale, O., and Smolander, K. (2010). Soft-

ware Test Automation in Practice: Empirical Obser-

vations. Advances in Software Engineering, 2010.

Kennedy, A. (1994). Dimension Types. In Sannella,

D., editor, Programming Languages and Systems—

ESOP’94, volume 788, pages 348–362, Edinburgh,

U.K. Springer.

Krisper, M., Iber, J., Rauter, T., and Kreiner, C. (2017).

Physical Quantity: Towards a Pattern Language for

Quantities and Units in Physical Calculations. In Pro-

ceedings of Pattern Languages of Programs, Euro-

PLoP ’17, pages 9:1–9:20, NY, USA. ACM.

Lungu, M. (2008). Towards reverse engineering software

ecosystems. In 2008 IEEE International Conference

on Software Maintenance, pages 428–431.

Mayerhofer, T., Wimmer, M., and Vallecillo, A. (2016).

Adding uncertainty and units to quantity types in soft-

ware models. In Software Language Engineering,

SLE 2016, pages 118–131, NY, USA. ACM.

McKeever, S., Bennich-Bj

orkman, O., and Salah, O.-A.

(2020). Unit of measurement libraries, their popular-

ity and suitability. Software: Practice and Experience.

McKeever, S., Pac¸aci, G., and Bennich-Bj

orkman, O.

(2019). Quantity Checking through Unit of Measure-

ment Libraries, Current Status and Future Directions.

In Model-Driven Engineering and Software Develop-

ment, MODELSWARD.

Microsoft (2020). F# software foundation. Online

https://fsharp.org. Last Accessed on 15th April 2020.

Milner, R. (1978). A theory of type polymorphism in pro-

gramming. Journal of Computer and System Sciences,

17:348–375.

Modelica (2020). Modelica and the Modelica Association.

Online https://www.modelica.org. Last Accessed on

15th April 2020.

Mussa, M., Ouchani, S., Sammane, W., and Hamou-Lhadj,

A. (2009). A Survey of Model-Driven Testing Tech-

niques. Proceedings - International Conference on

Quality Software, pages 167–172.

NIST (2015). International System of

Units (SI): Base and Derived. Online

https://physics.nist.gov/cuu/Units/units.html. Last

Accessed October 2nd, 2019.

Ore, J.-P., Detweiler, C., and Elbaum, S. (2017a).

Lightweight Detection of Physical Unit Inconsisten-

cies Without Program Annotations. In Proceedings

of International Symposium on Software Testing and

Analysis, ISSTA 2017, pages 341–351, NY, USA.

ACM.

Ore, J.-P., Detweiler, C., and Elbaum, S. (2017b). Phriky-

Units: A Lightweight, Annotation-Free Physical Unit

Inconsistency Detection Tool. In Software Testing and

Analysis, ISSTA 2017, page 352–355, NY, USA. As-

sociation for Computing Machinery.

Ore, J.-P., Elbaum, S., and Detweiler, C. (2017c). Dimen-

sional inconsistencies in code and ROS messages: A

study of 5.9m lines of code. In Intelligent Robots and

Systems, IROS, pages 712–718. IEEE.

Ore, J.-P., Elbaum, S., Detweiler, C., and Karkazis, L.

(2018). Assessing the Type Annotation Burden. In

Automated Software Engineering, ASE 2018, pages

190–201, NY, USA. ACM.

Salah, O.-A. and McKeever, S. (2020). Lack of Adop-

tion of Units of Measurement Libraries: Survey and

Anecdotes. In Proceedings of Software Engineering

in Practice, ICSE-SEIP ’20. ACM.

Selic, B. (2015). Beyond mere logic: A vision of mod-

eling languages for the 21st century. In Pervasive

and Embedded Computing and Communication Sys-

tems (PECCS), pages IS–9–IS–9.

Sonin, A. A. (2001). The physical basis of dimensional

analysis. Technical report, Massachusetts Institute of

Technology.

Stephenson, A., LaPiana, L., Mulville, D., Peter Rutledge,

F. B., Folta, D., Dukeman, G., Sackheim, R., and

Norvig, P. (1999). Mars Climate Orbiter Mishap In-

vestigation Board Phase 1 Report. Last Accessed on

October 1st, 2019.

TIOBE (2020). The importance of being earnest index.

Online https://www.tiobe.com/tiobe-index/. Last Ac-

cessed on 1st of October.

Wand, M. and O’Keefe, P. (1991). Automatic Dimensional

Inference. In Computational Logic - Essays in Honor

of Alan Robinson, pages 479–483.

Witkin, R. (1983). Jet’s Fuel Ran Out After Metric Conver-

sion Errors. The New York Times.

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

206
