Automatic Detection and Decryption of AES by Monitoring S-Box Access

Josef Koke

s, Jonatan Mat

ejka and R

obert L

orencz

Department of Information Security, Faculty of Information Technology, Czech Technical University in Prague,

Thakurova 9, Praha 6, Czech Republic

Keywords:

AES, Rijndael, Cipher, Encryption, S-Box, Key Recovery, Plaintext Recovery, Dynamic Analysis.

Abstract:

In this paper we propose an algorithm that can automatically detect the use of AES and automatically recover

both the encryption key and the plaintext. It makes use of the fact that we can monitor accesses to the AES

S-Box and deduce the desired data from these accesses; the approach is suitable to software-based AES im-

plementations, both na

ıve and optimized. To demonstrate the feasibility of this approach we designed a tool

which implements the algorithm for Microsoft Windows running on the Intel x86 architecture. The tool has

been successfully tested against a set of applications using different cryptographic libraries and common user

applications.

1 INTRODUCTION

In modern IT, security is no longer considered an af-

terthought; quite the contrary, security is a manda-

tory feature of many hardware and software products.

In recent months we have seen a major push for in-

creasing security which manifested e.g. in the an-

nouncements by browser manufacturers that they plan

to abolish or at least minimize unsecured web trafﬁc

in near future (DeBlasio, 2020), or in the deprecation

of TLS protocols versions 1.0 and 1.1 from all major

browsers and other applications in early 2020. At the

same time, privacy concerns of the users are on the

rise (Auxier et al., 2019).

While the improvements in security often improve

privacy as well, this is not always the case. In partic-

ular, the increased use of encryption to protect com-

munication from outsiders can also remove control of

the legitimate users over the transmitted data as they

are no longer able to easily monitor the contents of

the network trafﬁc. This is especially dangerous in

case of applications which are considered legitimate

by users but do not provide any means of veriﬁcation

what is being sent over the network. For example,

an operating system or an application may very well

propose to send telemetry data to the developer to im-

prove the user experience, but if the source code of

that software is not available, the user cannot easily

verify what data is actually being collected. The user

could, of course, resort to the techniques of reverse

engineering, but that almost always requires so much

effort as to make this approach prohibitively expen-

sive.

In this paper, we propose an alternative solution to

this problem: We demonstrate an algorithm which can

automatically detect encryption and decryption with

the AES cipher and automatically recover both the en-

cryption keys and the plaintext data. We achieve that

by modifying the control ﬂow of the target application

to monitor accesses to the substitution tables used for

the operation of the cipher and then deducing the ac-

tual plaintext data from these accesses.

2 PRELIMINARIES

In this section we will brieﬂy introduce the common

ways of implementing AES on Intel-based architec-

tures.

2.1 Common Implementations of AES

AES is probably the most commonly used block ci-

pher in the world. It’s design and structure is deﬁned

in (Daemen and Rijmen, 2002) and can theoretically

be implemented according to that as well. It is, how-

ever, common to tailor the implementation to the spe-

ciﬁc features in the target CPU. Note that since the

key-expansion process is generally a one-time oper-

ation or at least is performed much more rarely than

the actual encryption, it is usually not optimized on

the algorithmic level and if any optimization is used

172

Kokeš, J., Mat

ejka, J. and Lórencz, R.

Automatic Detection and Decryption of AES by Monitoring S-Box Access.

DOI: 10.5220/0010255201720180

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 172-180

ISBN: 978-989-758-491-6

at all, it’s left to the compiler and its choice of in-

structions and their ordering. For that reason, we will

only discuss the operations used in the actual encryp-

tion/decryption.

When targeting the Intel architectures (IA-32, In-

tel 64), the following approaches are usually taken:

2.1.1 The Na

ıve Implementation

The na

ıve implementation of AES follows the opera-

tions described in the cipher’s speciﬁcation, i.e. key-

expansion, sub-bytes, shift-rows, mix-columns and

add-round-key, in the designated order and the speci-

ﬁed number of repetitions.

The sub-bytes operation is commonly imple-

mented through a lookup table of 256 values where

the input to sub-bytes is used as an index to the table

and the output value is read from that location in the

table; another such table is used for the inverse of sub-

bytes. That removes the need for calculating inverses

in AES’s Galois ﬁeld.

Shift-rows is typically implemented as described

as reordering of the bytes in the encryption state.

Mix-columns may either be implemented as

straight table multiplication or optimized by pre-

calculating the necessary multiples for each possible

input value. For encryption, we need multiples of two

and three, for decryption multiples of 9, 11, 13 and

14. That can be done by using 6 pre-calculated tables

with the same structure.

Add-round-key is again usually implemented in a

straightforward XOR, although multiple bytes may be

processed at once using e.g. 32-bit XOR instructions.

An example of this optimized approach can be

found in (Malbrain, 2007).

2.1.2 Implementation using T-tables

Assuming that the target CPU architecture sup-

ports 32-bit instructions, further pre-calculation al-

lows us to optimize the encryption process to just

four lookups and four XOR operations per column per

round, as described in (Daemen and Rijmen, 2002):

Given an input state of A = [a

i, j

],0 ≤ i < 4,0 ≤

j < N

, expanded round key K = [k

i, j

],0 ≤ i < 4,0 ≤

j < N

where N

is the number of columns of A, we

can express the encrypted output state D = [d

i, j

],0 ≤

i < 4,0 ≤ j < N

as:







0, j

1, j

2, j

3, j







∑

i=0

i, j+C

) +







0, j

1, j

2, j

3, j







, (1)

where + is the operation XOR, C

are the respective

left shifts for the i-th row of the state (e.g. 0, 1, 2 and

3 respectively for the 128-bit key version of AES) and

are pre-calculated as:

(x) =







2 · S[x]

1 · S[x]

3 · S[x]







(x) =







3 · S[x]

2 · S[x]

1 · S[x]







(x) =







1 · S[x]

3 · S[x]

2 · S[x]

1 · S[x]







(x) =







1 · S[x]

3 · S[x]

2 · S[x]







(2)

for all possible byte values of x, given that S[x] is the

result of the sub-bytes transformation of x.

The T-tables can be further compressed by ob-

serving that they are in fact rotated versions of each

other and as a result only one of them needs to be pre-

calculated, the others can be obtained from it through

the use of rotation.

Further compression is possible if an unaligned

data access is possible because then the tables can be

stored overlapped.(Rijmen et al., 2000)

2.1.3 Implementation using Bit-slicing

The bit-slicing implementation (K

asper and Schwabe,

2009) is inspired by the hardware-based implementa-

tions of AES: The cipher’s state is represented as a

series of bits and the operations usually performed by

hardware gates are simulated using logical operations.

This approach has several signiﬁcant advantages: it

does not need any pre-calculated tables (the lookups

are replaced by series of logical operations), reducing

memory requirements of the algorithm, the algorithm

takes a constant time in clock cycles as the operation

sequences are ﬁxed regardless of any variations in in-

put data, and timing attacks on memory access are

difﬁcult if not impossible (Matsui, 2006). The chief

disadvantage is the reduced speed of the algorithm, al-

though that can be offset if vector instructions (such as

those provided by the MMX, SSE, SSE2 etc. instruc-

tion sets) are used and we can process multiple blocks

of the cipher in parallel, e.g. in the CTR encryption

mode: we would “slice” bits from eight independent

states into eight 128-bit registers and process them in

parallel.

2.1.4 Implementation using AES-NI

In 2008, Intel introduced a new instruction set exten-

sion for a hardware support of AES encryption and

decryption (Gueron, 2010). It consists of 6 instruc-

tion which provide encryption and decryption of a

single round of AES as well as support for key expan-

sion and the inverse Mix-columns operation. Much

Automatic Detection and Decryption of AES by Monitoring S-Box Access

173

like bit-slicing, this technique provides high security

(e.g. resistance to timing attacks) and low memory

footprint because it does not use any in-memory ta-

bles, and in compared to bit-slicing provides a very

high performance due to its hardware-based imple-

mentation. Another beneﬁt is the very simple imple-

mentation, although care needs to be taken to verify

that the AES-NI instruction set is actually available

at the CPU where the code is running – customarily,

the code would check for the presence of these in-

structions and then branch to either an AES-NI based

version or a traditional version based on one of the

approaches shown above.

3 OUR APPROACH

Our goal is to detect the use of AES automatically

and also automatically recover encryption keys and

plaintexts. We use dynamic analysis to achieve it –

we attach to the analyzed application as a debugger

and then make use of the debugging APIs to moni-

tor data accesses to the precalculated tables and de-

duce both the key and data from them. Obviously,

this approach is only applicable to AES implementa-

tions which make use of these tables, i.e. the na

ıve

implementation or the T-tables implementation.

3.1 Locating Tables

In order to be able to monitor accesses to the tables,

we need to locate them in the target application’s

memory ﬁrst. To do that, we use VirtualQueryEx

function to get the list of memory pages belonging to

the analyzed process, copy these pages to our mem-

ory using ReadProcessMemory and then search them.

Since the tables may be stored in a variety of fash-

ion, we do not compare memory blocks to known val-

ues but rather study the relationships between bytes

– we are looking for multiplications of the original

SubByte table

with common interleaving (1 byte for

SubBytes, 4 bytes for T-Tables and 8 bytes for over-

lapping T-Tables).

With many applications, it is sufﬁcient to perform

the search only once at the beginning of the applica-

tion because the tables are statically compiled into the

application. Some applications, however, build these

tables at least partially dynamically during their run-

time – e.g. to calculate the T-tables from the stati-

cally stored SubBytes table or to load a dynamic li-

brary which contains these tables. To facilitate sup-

1, 2 and 3 for encryption tables and 1, 9, 11, 13 and 14

for decryption tables

port for these applications, we perform the search re-

peatedly using a background thread; currently no per-

formance optimizations are performed for this search,

but it seems likely that some would be applicable.

3.2 Monitoring Access

Once we have located the substitution tables, we need

to monitor access to them. Based on the speciﬁc hard-

ware used, there may be different ways of doing so.

On the Intel architecture, we could use debug registers

(Intel Corporation, 2019) for this purpose, but unfor-

tunately only for memory locations of up to 8 bytes

each could be monitored, which is not enough to de-

tect all accesses – even SubBytes is at least 256 bytes

long, T-tables even longer.

Instead, we decided to make use the concept of

memory paging and memory page protection: Once

we know in which memory pages the substitution ta-

bles reside, we remove all access from these pages

using VirtualProtectEx by adding the PAGE GUARD

ﬂag. When that was done, any access to any location

within the memory page causes a page fault exception

before passing it to the application itself the active de-

bugger – our tool – is notiﬁed about it through a debug

event. Speciﬁcally, we learn of the actual memory lo-

cation and the type of access (read, write, execute)

that caused the fault. We can then verify whether the

access was a substitution table access and if so, pro-

cess it accordingly.

Obviously, we must allow the application to actu-

ally perform the table access so that it can continue

in its execution. We achieve that by temporarily re-

moving the PAGE GUARD ﬂag from the affected mem-

ory page, enabling the single-step (trap) ﬂag in the

thread’s FLAGS register and resuming the thread; after

a single instruction the single-step ﬂag causes another

debugging event which we capture and restore both

the memory protection by adding the PAGE GUARD ﬂag

to the memory page and the standard thread execution

by clearing the single-step ﬂag from FLAGS.

3.2.1 Special Considerations

While the monitoring process is fairly straightfor-

ward, care needs to be taken to facilitate several spe-

cial situations.

In particular, we need to consider the possibility

that the substitution tables are stored in the code seg-

ment rather than data segment, such as in (Polyakov,

2016). In that case an attempt to execute an instruc-

tion from the same memory page will cause a page

fault because the instruction itself cannot be read due

to the protection settings. That can be solved by

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

174

checking whether the access occurred inside a sub-

stitution table or whether it occurred somewhere else

within the monitored memory page, and in such a case

simply removing the protections, single-stepping the

instruction and then restoring the protections. It will

degrade the performance signiﬁcantly but the code

will function as expected.

Unfortunately, that is not the case if the instruction

that accesses the substitution table is located within

the same memory page as the substitution table itself:

In this case, we would fail to detect the table access

because we removed the protection in order to exe-

cute the instruction and will only restore it after the

instruction has completed, i.e. after the table access.

We solve this problem by decoding the instruction in

software using a third-party library and determining

whether it is this particular case; if it is, we emulate

the instruction rather than execute it directly.

3.3 Monitoring Key Expansion

During key expansion, the substitution tables are used

to perform a SubWord operation:











for i < N

i−N

+ r(s(W

i−1

)) +rcon

i/N

for i ≥ N

,i ≡ 0 (mod N

)

i−N

+ s(W

i−1

) for i ≥ N

> 6,i ≡ 4 (mod N

)

i−N

i−1

otherwise

(3)

Here, K

is the i-th column of the master key, N

is the number of columns of the master key, W

is the

i-th column of the expanded key and functions r and

w as well as the constant rcon are deﬁned as follows:

r(w) = r





































s(w) = s































S[w

]

S[w

]

S[w

]

S[w

]







rcon







i−1







, for i ∈ N

(4)

In order to properly recover the key, we need to

make several assumptions:

• While key expansion is being performed, no other

access to substitution tables is performed except

through the SubWord function.

• SubWord calls are performed in order of the

columns in the expanded key.

• Accesses to the substitution tables are the same in

all SubWord calls.

On the other hand, we do not make any assump-

tion on the order in which the bytes in a word are

being substituted – that might be inﬂuenced e.g. by

aggressive optimizations on the part of the compiler

while building the target application. We can, how-

ever, determine the proper ordering by verifying that

the dependencies between columns do exist as ex-

pected.

The dependencies must be calculated separately

for each size of the key. For example, with AES-128

we can make use of columns {x | x = 3+4k,k ∈ N} of

the expanded key which depend on previous columns

as shown in Figure 1. Then:

i−3

i−2

i−1

+ + +

r(s(W

i−4

)) + rcon

(i−3)/4

i−7

i−6

i−5

i−4

+ + +

i−10

i−9

i−8

+ +

i−13

i−12

i−16

Figure 1: Dependency of columns in the expanded 128-bit

key. The grayed boxes describe the ﬁnal expression.

i−4

i−1

i−8

i−5

i−2

i−8

i−2

i−12

i−9

i−6

i−3

i−16

i−13

i−10

i−7

+ r(s(W

i−4

)) + rcon

(i−3)/4

i−16

+ r(s(W

i−4

)) + rcon

(i−3)/4

(5)

To detect these dependencies we then require ﬁve

successive key columns. Since AES-128 performs

10 SubWord operations, we can produce six equa-

tions which describe the dependencies between all

columns:

= W

+ r(s(W

)) + rcon

= W

+ r(s(W

)) + rcon

(6)

If the captured table accesses do not adhere to

these expressions, then we know that the accesses are

not a part of the key expansion process or the assump-

tions above have been violated. We can make use

of this fact by ﬁnding the correct ordering of bytes

Automatic Detection and Decryption of AES by Monitoring S-Box Access

175

in each word by simply trying them all and checking

which leads to satisfying all the expressions.

In this fashion we can can recover every fourth

column of the expanded key W

,...,W

. Then

we can make use of the algorithm of key expan-

sion to calculate the remaining columns, e.g. W

i+3

i+4

for i ∈ 3,7,...,35, W

i+4

+r(s(W

i+3

))+

rcon

(i+4)/4

for i ∈ 0,4, 8 etc., eventually recovering all

the columns of the key.

The key for AES-192 can be recovered in a similar

fashion, although only two equations can be used to

verify that we are indeed performing key expansion:

= W

+ r(s(W

)) + rcon

= W

+ r(s(W

)) + rcon

(7)

With AES-256, the recovery is complicated by the

fact that not all columns which entered SubWord can

be used for the expression of dependencies – we know

the value of W

and W

, but we can not express it

using other columns:

= W

+ s(W

)

= W

+ s(W

)

= W

+ s(W

)

= W

+ r(s(W

)) + rcon

= W

+ r(s(W

)) + rcon

(8)

As a result, we do not have sufﬁcient informa-

tion to calculate the correct ordering of the bytes in

a word; W

and W

allow for 4! = 24 different valid

orderings each, giving us 24

= 576 different keys

which all satisfy the deﬁned expressions. This obsta-

cle can be overcome by deferring the ﬁnal calculation

of the ordering until the encryption phase, behavior

of which will help us detect which speciﬁc key was

actually used.

3.4 Monitoring Encryption

During encryption we will observe substitution table

access in every round of the cipher. Assume the fol-

lowing:

• While encryption is being performed, no other ac-

cess to substitution tables is performed except by

that block’s encryption.

• All substitution table accesses are ordered exactly

as the rounds themselves.

• No two rounds overlap.

• The data is being encrypted with the key expanded

in the last monitored Key Expansion phase.

We do not make any assumptions on the order of

accesses within one round.

The ﬁrst input to SubBytes within a round is cre-

ated simply as a sum of the plaintext and the ﬁrst

round key. It is passed through SubBytes and the out-

put is then processed according to the cipher’s speciﬁ-

cations (rows shifted, columns mixed, next round key

added) and forms the input to the second round’s Sub-

Bytes. Repeat the process for the rest of the rounds,

skipping MixColumns in the last round.

With the assumptions above, we know the ex-

panded key, except possibly the ordering in some of

its columns. We can make use of this information to

determine the proper ordering of the states. Given S

the input state of one round’s SubBytes, T the out-

put state of the previous round’s SubBytes and K the

round key, we know that:

S = MixColumns(ShiftRows(T )) + K (9)

Unfortunately, we do not know the ordering of

SubBytes calls for the individual bytes of states S and

T . We can, however, re-formulate and relax the ex-

pression as:

∀x : x ∈ InvMixColumns(S + K) ⇐⇒ x ∈ T (10)

We could now check all 16! possible permutations

of state S and locate the matching one, but that would

require quite a lot of computational power. We can,

however, further relax the expression and apply it to

each column of the state separately:

∀x : x ∈ InvMixColumns(S

+ K

) =⇒ x ∈ T (11)

Now we only need to check 4 ×

16!

(16−4)!

variations

of the ordering of S. For each selection we verify that

all of its bytes appear in T . If that is not the case, then

we know that we are not using the correct key. Oth-

erwise we can apply the same reasoning to the next

(or previous) round and express the condition on the

whole sequence. E.g. if S was the SubBytes output of

the last round and T its input, we can now focus on U

the output of the second-to-last round’s SubBytes, T

its input and L its key. Then:

∀x : x ∈ InvMixColumns(U

+ L

) =⇒ x ∈ V (12)

We can substitute for U and express the left side

as:

InvMixColumns(InvSubBytes(T )

+ L

) (13)

Substitute for T and again express the left side as:

InvMixColumns(InvSubBytes(InvShiftRows(

InvMixColumns(S + K))

+ L

)

(14)

And so on for all n rounds of the cipher, yielding

n − 1 conditions. We can now use these conditions to

ﬁnd the correct ordering of the bytes in each interme-

diate state. Once we recover the ﬁrst state, we can get

the plaintext by adding the ﬁrst round key to it.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

176

In the previous chapter we noted that it may not

be possible to get the correct ordering of the whole

key, e.g. in AES-256. Instead, we only recovered a

set of candidate keys. It’s clear we could use them

all in the state-ordering calculations above, but that

would lead to a signiﬁcant performance penalty. In-

stead, we can perform these calculations just for the

fourth columns of each state, because we have recov-

ered the most information for these: With AES-128,

we know the fourth columns of all round keys ex-

cept for the last, with AES-256 we know the fourth

columns of all round keys except for the ﬁrst and the

last, and with AES-192 we know the fourth columns

of each third round’s key and we can calculate the

others from them. We do not need to know the ac-

tual permutation of the key, because we can test for

all of them if necessary. By applying these keys to the

conditions on states, we can conclusively state which

keys could not have led to the observed substitution

table accesses.

4 RESULTS AND DISCUSSION

In order to demonstrate this approach we created ap-

plication AesSniffer. It is written in C++ and con-

sists of three main parts: A system-dependent li-

brary for performing the debugging and memory ac-

cess work, a system-independent library for recover-

ing keys and plaintexts and a console tool for perform-

ing these tasks on third-party applications. This orga-

nization allows for a simple adaptation of the tool to

different operating systems: while the supplied appli-

cation is intended for Microsoft Windows, it is pos-

sible to adapt it to other OSes by reimplementing the

debugging core and the user interface while keeping

the recovery part unchanged – or improve the recov-

ery part and apply it to all variants of the application.

4.1 Library and Application Tests

The tests were performed using Microsoft Windows

7 SP1 x86 in a virtual machine provided by Ora-

cle VM VirtualBox with AES-NI and SSEx instruc-

tions disabled. Several popular cryptographic li-

braries were tested: OpenSSL

, CryptoPP

, Botan

and WinCrypt

; in all cases a simple application for

encrypting and decrypting a sample block in the ECB

operation mode with a random 128-bit, 192-bit and

https://www.openssl.org/

https://www.cryptopp.com/

https://botan.randombit.net/

256-bit key. As a further test, two existing third-party

applications which use their own implementation of

AES, were tested: 7-Zip

and Putty

; both of these

libraries use the CTR operation mode. Finally, we

tested our application’s ability to recover data sent and

received by PowerShell’s Invoke-WebRequest com-

mand over the HTTPS protocol using the CBC oper-

ation mode.

In all of these cases, the application was success-

ful in recovering both the key and the plaintext, al-

though with some limitations:

4.1.1 OpenSSL

All encryption and decryption of data was success-

fully detected and all keys and data were recovered.

We did encounter 8 unrecognized accesses to the sub-

stitution tables due to the cache prefetch code which

is a part of the OpenSSL implementation.

4.1.2 CryptoPP

The T-tables used by the library are calculated at run-

time from the standard SubBytes tables. While these

tables were eventually found by our application, ac-

cesses to them detected and data and keys recovered,

this process did consume some time during which

some encryption was already performed, leading to

the loss of the early data. We also noticed 256 un-

recognized accesses to the SubBytes table while the

T-tables were being constructed.

4.1.3 Botan

Much like CryptoPP, Botan also calculates the T-

tables at runtime, leading to the loss of early data be-

fore the calculated T-tables could have been found.

Other than that, our application was able to detect all

encryptions and recover both the keys and the data.

4.1.4 WinCrypt

WinCrypt is a part of the Windows family of opera-

tion systems. We were able to recover all keys and

data, but we did encounter an error in the library

shipped with Windows 7 and Windows 8.1: After the

key expansion, four unexpected accesses to the sub-

stitution table were encountered, probably as a result

of an unnecessary SubWord call for the last column

of the expanded key, because the data were success-

fully recovered regardless. In Windows 10, no such

accesses were observed.

https://www.7-zip.org/

https://www.putty.org/

Automatic Detection and Decryption of AES by Monitoring S-Box Access

177

4.1.5 7-Zip

7-Zip supports encryption of the archives using the

AES cipher in CTR mode. We performed a test with

a ﬁle consisting of 32 zero bytes (two AES blocks)

in the “Store” mode (without compression). Our ap-

plication successfully detected two encryptions; both

used the same key and the plaintext were two suc-

cessive counter values (0x01, 0x00, 0x00, 0x00,

... and 0x02, 0x00, 0x00, 0x00, ...), as ex-

pected.

4.1.6 Putty

Putty uses the SSH protocol to encrypt the transferred

data, and AES is one of the supported ciphers in this

protocols. We attempted to recover data from a con-

nection where AES-256 in CTR mode was the agreed-

upon cipher between client and server. Two distinct

key expansions were detected and recovered as well

as a lot of encryptions. After we XORed the recov-

ered plaintexts with the encrypted data captured by

WireShark, we were able to observe data structure ex-

pected in the unencrypted contents of the SSH proto-

col.

4.1.7 PowerShell

PowerShell is a scripting language which, among

other things, supports reading web data using the

HTTPS protocol using the Invoke-WebRequest

command. When we enforced the use of TLS ver-

sion 1.0, the client and server agreed upon using the

AES-128 cipher in CBC mode. Our application suc-

cessfully detected both the key expansion and the en-

cryption as well as decryption of data and we were

able to verify that the recovered plaintext contained

the expected data of the HTTP protocol.

4.2 Performance Tests

During our tests we measured the speed of our ap-

plication in different scenarios using 7-Zip. The tool

was chosen because it allows precise speciﬁcation of

the size of the data as well as precise measurement of

time; at the same time it is a real-world application

and as such can provide a real-world benchmark, un-

like a custom benchmarking application which would

be heavily dependent on the actual organization of the

AES code (e.g. whether the substitution tables were

located in the same memory page(s) as some other

frequently used data or code items). We created ﬁles

of 256, 4096 and 65536 bytes and measured how long

did 7-Zip take processing these ﬁles without compres-

sion but with AES-256 encryption in different scenar-

ios based on our application’s settings. The results

can be seen in Table 1.

It is apparent that the presence of our application

carries a signiﬁcant performance penalty even if no

key- and plaintext-recovery is being done. This is

caused by the fact that on any access to the memory

page containing a detected substitution table causes a

page fault, a number of context switches between the

application, our AesSniffer and the operating system,

and several VirtualProtectEx calls, not to mention

the possible need for using a software decoder of the

affected instruction. While this penalty can be re-

duced if the monitored application used a friendlier

memory layout (e.g. the substitution tables would be

located in dedicated memory pages), the opposite is

also possible – if, for example, the substitution table

occupies the same memory page as a virtual method

table of some frequently used object class, the penalty

could be much more pronounced, even more so if

some frequently used code was located there as well.

Another signiﬁcant increase in the processing time

can be observed if the detection of AES-192 is acti-

vated. The reason for that is that with AES-192 there

are far more possible permutations of the key than

with AES-128 and AES-256 because the columns of

the 192-bit key depend on ﬁve other columns rather

than three columns with 128- and 256-bit keys.

Finally, the size of the data to be encrypted ob-

viously increases the overall time because more ac-

cesses to the substitution table are required – 160 ac-

cesses per block in case of AES-128, 192 accesses per

block in case of AES-192 and 224 accesses per block

in case of AES-256.

While these penalties may seem overwhelming,

it should be noted that they are still far more man-

ageable than other dynamic approaches. We imple-

mented a very simple tracer into our application, one

which forces single-stepping of all instructions with-

out any additional processing (i.e. no AES detection

at all). Encryption of a 256-byte would then take more

than 38900 seconds, or something like 200-times the

worst case of our code with full detections enabled.

If better performance was desired, it is possible

to separate the gathering of data (monitoring accesses

to substitution tables) from the processing of the data

(key and plaintext recovery): While the ﬁrst phase

must by necessity be performed at the time the ac-

cesses are done, the second phase does not need to – it

is quite sufﬁcient to process the data asynchronously,

e.g. in a different thread or even ofﬂine from a record

of the accesses in a ﬁle. That would at the very least

resolve the penalty for using AES-192 which is un-

necessarily incurred synchronously in the current im-

plementation.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

178

Table 1: Performance penalty of AES detection in 7-Zip based on the size of encrypted data and the settings for the detection.

The “Simple Tracer” scenario represents a minimal trap-after-each-instruction implementation without any additional logic.

File size [B] 256 4096 65536

Time to process [s]

Without AesSniffer 0.06 0.06 0.15

AesSniffer, no detection 148.83 150.96 166.93

AesSniffer, only AES-256 150.06 182.26 329.56

AesSniffer, AES-256 and 128 159.52 204.53 347.51

AesSniffer, full detection 199.97 662.81 8138.84

Simple tracer 38964.26 – –

4.3 Limitations

From the presented tests it is obvious that the ap-

proach works in general. However, it does have cer-

tain limitations from the real-world-usage point of

view:

The whole approach is based on a set of assump-

tions which seem to hold true in may real-world li-

braries, but that is certainly no guarantee that it would

hold for all of them. In particular, with better com-

pilers and more aggressive optimization techniques in

them, we may well expect that loop unrolling could

violate the “no mixing of rounds” requirement. Sim-

ilarly, the use of true multithreading for encryption

might violate the condition of blocks being processed

sequentially, although in this case the use of thread

identiﬁers could be added to the processing code to

distinguish table accesses from different threads.

The key- and data recovery process is fairly slow

to the point of being unusable in scenarios where a

large amount of data is being processed, and it is

certainly possible to write code in such a way that

the slowdown might become even more pronounced.

While the speed could be improved in the general

case, against a targeted attack there is little to be done.

The major problem with our approach is that it

is only suitable for AES implementations which use

substitution tables located in the main memory. Bit-

slicing implementations are completely immune to

this approach, as is the usage of AES-NI instructions.

Fortunately, AES-NI can be readily disabled in cur-

rent environments, forcing the AES implementations

to fall back to the software-based implementation.

Also, it might be possible to replace the AES-NI in-

struction codes in memory with an INT3 instruction to

effect a breakpoint and then read the arguments from

the respective registers, although this approach suf-

fers from other issues (i.e. it is difﬁcult if not impos-

sible to avoid false positives and the whole approach

is vulnerable to various anti-debugging techniques).

The bit-slicing implementations seem completely im-

mune even against this option.

It should be noted that even with a traditional soft-

ware implementation of AES, our algorithm may run

into trouble if the substitution tables do not exist in the

actual executable and instead are precalculated during

the program’s runtime. The less time there is between

the precalculation and the use of the tables, the more

likely it is that some encryption may escape the detec-

tion. The applications which only perform one task

and then quit may be particularly prone to this issue.

Research is needed to establish what, if anything, can

be done about it.

5 CONCLUSION

In this paper we proposed to introduce an algorithm

which can automatically detect the use of AES ci-

pher and to automatically recover both the key and

the plaintext. Our approach is based on the observa-

tion that traditional software implementation of AES

make use of precalculated substituted tables which

can be detected in the application’s memory, and that

by evaluating the accesses to these tables we can de-

duce the desired information. While this approach

carries a signiﬁcant performance penalty and does not

work against more hardware-based implementations

such as Bit-slicing or the use of AES-NI, it still suc-

ceeds in a number of situations: We veriﬁed that we

are able to recover key and plaintext with several com-

monly used encryption libraries using our own test

applications, and we demonstrated that we could do

the same with existing third-party applications, two

of which use their own custom implementation of the

AES cipher. It can be expected that other applications

would be vulnerable to this approach as well, partic-

ularly so if they ofﬂoad the encryption work to the

libraries we tested.

At the moment, there is little to be done with the

AES implementations which do not use a substitution

table. However, further research may provide some

ways of overcome this problem. It may well be worth

the while to try to distinguish AES-NI instructions

Automatic Detection and Decryption of AES by Monitoring S-Box Access

179

from the rest of the machine code and non-code data

in the code segment and introduce breakpoints in their

place. That remains to be seen. Similarly, further re-

search may enable us to discover ways of automati-

cally recovering keys and plaintexts of other encryp-

tion algorithms, although the widespread use of AES

seems to make that a lower priority than the support

for AES-NI.

Even though our implementation does not work

against these special cases, it seems to work well

enough in practice. After all, AES-NI can be purpose-

fully disabled, if we desire so, and when that’s been

done, our tool can be used to automatically recover

keys and plaintext data in many real-world scenarios,

giving the users a simple way of observing the en-

crypted trafﬁc which would otherwise be difﬁcult to

replicate. We believe that is a worthwhile contribu-

tion.

ACKNOWLEDGEMENTS

The authors acknowledge the support

of the OP VVV MEYS funded project

CZ.02.1.01/0.0/0.0/16 019/000 0765 “Research

Center for Informatics”.

REFERENCES

Auxier, B., Rainie, L., Anderson, M., Perrin, A., Kumar,

M., and Turner, E. (2019). Americans and privacy:

Concerned, confused and feeling lack of control over

their personal information.

Daemen, J. and Rijmen, V. (2002). The design of Rijndael:

AES – the Advanced Encryption Standard. Springer-

Verlag, Berlin, Heidelberg, 1st edition.

DeBlasio, J. (2020). Protecting users from insecure down-

loads in google chrome.

Gueron, S. (2010). Intel Advanced Encryption Standard

(AES) New Instructions Set. Technical report, Intel

Corporation.

Intel Corporation (2019). Intel 64 and IA-32 Architec-

tures Software Developer’s Manual, Volume 3B: Sys-

tem Programming Guide, Part 2. Intel Corporation.

asper, E. and Schwabe, P. (2009). Faster and timing-attack

resistant AES-GCM. Cryptographic Hardware and

Embedded Systems – CHES 2009, pages 1–17.

Malbrain, K. (2007). Higher performance AES C byte-

implementation.

Matsui, M. (2006). How Far Can We Go on the x64 Proces-

sors? Fast Software Encryption, pages 341–358.

Polyakov, A. (2016). crypto/aes/asm/aes-586.pl. [online].

Rijmen, V., Bosselaers, A., and Barreto, P. (2000). Opti-

mised ANSI C code for the Rijndael cipher.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

180
