Dancing Guide: Near Realtime Audio Classiﬁcation of Live Dance

Music on Smartphones

Alexander K. Seewald

Seewald Solutions, L

archenstraße 1, A-4616 Weißkirchen a.d. Traun, Austria

Keywords:

Audio Classiﬁcation, Live Music, Dance Music, Smartphones, Music Genre Classiﬁcation, Near-real-Time.

Abstract:

Between 2008 and 2014 we developed and deployed a live music classiﬁcation system, Dancing Guide, to be

run on Android and iPhones mobile phones in near realtime. Although internet access was needed to send

feedback and classiﬁcations to the server for statistical purposes, the music classiﬁcation system also worked

ofﬂine without any loss in accuracy or speed. This is essential since in most discos and dancing schools,

internet access is spotty at best. During the seven years of the project, the app was available both for iPhone and

Android, initially in German and English, but later – thanks to volunteer translations – also in Czech, Spanish,

French, Italian, Japanese, Korean, Dutch, Polish, Portuguese, Russian and Traditional Chinese. Measured

by user feedback, we achieved an accuracy of roughly 73% at a coverage of 61%. While the accuracy is

comparable to initial estimates using cross-validation, the coverage is much worse. Background noise – which

we did not model – or the limited feature set may have been responsible. We retrained the system several

times, however performance did not always improve, so we sometimes left the previously trained system in

place. In the end, the limited feature set which was initially chosen prevented further improvement of coverage

and accuracy, and we stopped further development.

1 INTRODUCTION

Between 2008 and 2014 we developed and deployed a

live music classiﬁcation system, Dancing Guide

, to

be run on then-current Android and iPhones mobile

phones in near-real-time as an app.

Although inter-

net access was needed to send feedback and classiﬁ-

cations to the server for statistical purposes, the model

was deployed locally and the music classiﬁcation sys-

tem was able to work ofﬂine without any loss in accu-

racy or speed. This was essential since in most discos

and dancing schools internet access is spotty at best.

The motivation for building this system was that it

is very hard for dancing beginners to ﬁnd out which

dance is appropriate for given live music. So we built

Dancing Guide to enable dancing beginners to ﬁnd

out which dance is appropriate for given live music.

During the seven years of the project, the app

was available both for iPhone and Android, initially

Project page: https://dg.seewald.at

In the beginning, we also had a working version

for Nokia and Ericsson mobiles phones using Java ME

(CDLC).

This may have changed in the meantime.

in German and English, but from December 2009

onwards – thanks to volunteer translations – also in

Czech, Spanish, French, Italian, Japanese, Korean,

Dutch, Polish, Portuguese, Russian and Traditional

Chinese. Measured by actual user feedback – surely

the most desirable feedback as it is completely inde-

pendent of training, validation or testing data – we

achieved an accuracy of roughly 73%. We retrained

the system several times, however in some cases per-

formance remained very similar or was even worse

than an earlier system so we sometimes left the previ-

ously trained system in place. In total, the app ran on

3,533 different models of phones.

We do not have reliable user data from 2008 and

2009 since there was a bug in the unique id compu-

tation and many users obtained the same ids. The

number of unique users, feedbacks and feedbacks/u-

nique user from 2010 to 2014 is later shown in Ta-

ble 1. The table also shows accuracy and coverage ac-

cording to user feedback, or alternatively the propor-

tion of outputs where no dance could be recognized (a

trade-off to increase accuracy where low-conﬁdence

dance music predictions are not shown to the user, i.e.

1 − Coverage), and the proportion of recording errors

(i.e. when no audio could be recorded due to hard-

Seewald, A.

Dancing Guide: Near Realtime Audio Classiﬁcation of Live Dance Music on Smartphones.

DOI: 10.5220/0010258508910898

In Proceedings of the 13th International Conference on Agents and Artiﬁcial Intelligence (ICAART 2021) - Volume 2, pages 891-898

ISBN: 978-989-758-484-8

891

ware or software problems, or simply the microphone

being occupied by a call).

Contrary to music identiﬁcation systems who rely

on exact timing of played notes and need databases

containing several billions of songs, our system was

designed to analyze instrumental classical dance mu-

sic played by a live band or orchestra, for example

at Austrian balls or in dancing schools, where music

id systems such as the then current Shazam (Wang,

2003) fail.

In our case music identiﬁcation is not a

reasonable task as every live song is to some extent

unique. We therefore focussed on the more feasible

task of classifying music genre relevant to dance mu-

sic and eventually chose these ﬁve genres.

1-5. Cha-Cha-Cha, Jive, Samba, Tango, (Vien-

nese/Slow) Waltz

We directly analyze audio data by beat and spectral

features. By this, we can recognize completely new

and unknown songs which have not been imported

into the song database of music id systems yet. Many

adapted and improvised dance songs are within this

category.

2 RELATED RESEARCH

When we started the project in 2008, there was al-

ready some research on dance music genre classiﬁca-

tion. We can still reasonably claim to have been the

ﬁrst to build a near-real-time dance music genre clas-

siﬁcation system that works with short segments

the presence of background noise, and works for live

as well as recorded dance music.

(Wang, 2003) describe an – in 2008 – state-of-the-

art music identiﬁcation system. He used local peaks

in audio spectrograms to compute hashes from peaks

within target zones, yielding two frequency compo-

nents and a time shift. A density-based sampling is

used to get roughly the same number of peaks for

each time span. For a large database of known mu-

sic, all such hashes are computed and stored. To ﬁnd

a sample, all peaks from the sample are searched in

the database, and are checked whether the matched

peaks correspond to the known time shifts. Since

this method is sensitive to the time shifts which will

change for every performance of live music, their

method cannot be applied to the task of live music

Apart from theoretical considerations, we also tested

the Shazam app for several days in an Austrian dancing

school with live music and out of hundreds of played songs,

a single one was correctly identiﬁed, with the wrongly iden-

tiﬁed songs usually not even within the same musical genre.

30s, 5s and 3s (in ﬁnal system) were considered.

dance classiﬁcation even when the underlying music

is stored in the database.

(Arzt and Widmer, 2010) describe a system to au-

tomatically track the position within a music piece in

real-time, using online dynamic time warping. While

this could in principle be used to reconstruct the tem-

poral beat structure – and thus the dance style – from

the audio data, the presented system still needs the

actual score as a MIDI ﬁle to enable this alignment,

which is not normally available in our case. Another

advantage of such a system, could it be extended to

work with arbitrary musical scores, would be to de-

termine not only dance style but also the precise tem-

poral position of the main beat.

(Dixon, 2007) describes a system to track beats

directly from audio with a two-stage process: tempo-

induction to ﬁnd the rate of beats, and beat track-

ing, synchronizing a quasi-regular pulse sequence to

the music. Both use onset detection based on spec-

tral ﬂux. His system has won the MIREX 2006 Au-

dio Beat Tracking Evaluation albeit just by a small

margin, but with a runtime about half as the second-

placed algorithm. In Conclusion and further work, he

notes that it would be easy to modify BeatRoot for

real-time tracking. After the optimizations we have

done to enable processing on platforms with less com-

putational power, we tend to agree. Features derived

from BeatRoot’s output are used as one main compo-

nent in the feature set for our Dancing Guide system.

(Dixon et al., 2003) describes a system for dance

genre classiﬁcation based on estimating periodici-

ties (either via BeatRoot – see above – or auto-

correlation), then reconstructing metrical hierarchies

and estimating tempo at the beat and higher hierar-

chial levels. From this the dancing style is estimat-

ing using a set of simple rules. They found that – for

this speciﬁc task – auto-correlation gives better results

than using BeatRoot. The majority of errors is due

to selecting the wrong metrical level, i.e. choosing a

measure period that is double or half the correct value.

As will be explained later, we prevented this issue by

counting each measure period also in the bin corre-

sponding to double and half the measure period. They

quote dancing style recognition rates between 69%

(using BeatRoot) and 80% (for auto-correlation data)

with a much larger set of fourteen dances, however

without accounting for noisy and distorted recordings

from mobile phone microphones. Their classiﬁcation

is also done for 30s windows and not on 3s windows

as in our case which probably makes the task slightly

easier.

(Chew et al., 2005) introduces a method for music

genre classiﬁcation using a computational model for

Inner Metric Analysis. They show that their method

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

892

can distinguish pieces that have the same tempo and

meter, however their system requires the speciﬁca-

tion of at least one template for each genre – in some

cases two were needed. It is not inconceivable that

for a larger set of dances the templates will have to be

indeﬁnitely extended. They also consider ﬁve gen-

res – Tango, Rumba, Bossa Nova, Merengue, and

National Anthem – but these differ from ours. A

comparison of template with musical piece based on

spectral weights performed more accurately than one

on metric weight. An average accuracy of 70.3% is

quoted. If we consider the second ranked genre as

a match as well, an accuracy just below 80% is ob-

tained. Some of the errors are due to similarities be-

tween the rhythm templates, which therefore need to

be carefully designed. Again the whole piece must be

analyzed before a dancing genre can be estimated.

(Gouyon et al., 2004) describe a system to clas-

sify dance music genre using rhythmic features, pe-

riodicity histogram features, inter-onset interval his-

togram features, and MFCC features computed on the

inter-onset interval histogram. As such it is similar

to (Gouyon and Dixon, 2004). They report an accu-

racy of 82.3% for a Nearest Neighbor classiﬁer us-

ing ground truth tempo, however in our case this is

not available. Adding the 15 MFCC-like descriptors

the accuracy increases to 90.1%. Using computed in-

stead of ground truth tempo – which is not available

in our case – drops the accuracy to 78.9%. We also

use MFCC features in our feature set, however those

are computed from the audio spectrogram. Again the

whole piece must be analyzed before a dancing genre

can be estimated.

(Medhat et al., 2017) applied two neural networks

specially designed for multi-dimensional audio sig-

nal recognition – CLNN and MCLNN – to the ex-

tended ballroom music dataset (which is quite similar

to our dataset). They report a competitive accuracy of

92.13% without any handcrafted features, which also

compares well with other deep learning approaches,

but still lies below the best systems with handcrafted

features. Also, these results were obtained by voting

multiple predictions on each 30s samples and it is un-

clear whether accuracy on shorter 3s samples would

be sufﬁcient for our task.

(Yang et al., 2020) propose PRCNN, a combined

convolutional and recurrent network that combines

feature extraction and time-series classiﬁcation, and

show a slight improvement in accuracy over previous

approaches on the extended ballroom dataset. Similar

to our approach, they also use 3s windows. They re-

port an accuracy of 92.5% on the extended ballroom

dataset. It is implied that the reported accuracies are

from the shorter 3s samples, which would indicate a

major improvement. Given progress in mobile phone

computing performance, it may even be feasible to

run their systen in real-time on a mobile phone.

Concluding, contrary to the system presented in

this paper, none of the described systems are able

to run in near-real-time, except for (Wang, 2003) –

which cannot process live music usefully and would

also need additional information on dancing style for

all indexed songs – and (Arzt and Widmer, 2010) –

which needs the actual score as MIDI ﬁle, which is

usually not available in our setting. Newer systems

such as (Yang et al., 2020; Medhat et al., 2017) may

also be able to run in near-real-time, but have been

published long after our initial work. State-of-the-art

performance at the start of our project was 80% accu-

racy which is also what we will aim for.

3 INITIAL LEARNING

EXPERIMENTS

This section contains everything up to the ﬁrst de-

ployment of the model. While the preprocessing did

not change after the ﬁrst deployment, retraining took

place and we added both feedback from known and

unknown users, as well as additional data, to the train-

ing and validation datasets. The steps taken after de-

ployment can be found in Section 4.

Tenfold cross-validation was used throughout, and

reported accuracy values are at 100% coverage (i.e.

without removing low-conﬁdence predictions) unless

otherwise noted. In later steps we had to resort to con-

ﬁdence thresholding to improve accuracy at a reduced

coverage.

3.1 Datasets

We initially chose the following thirteen dances, how-

ever later had to reduce this set to the ﬁrst ﬁve dances

(after merging Viennese and Slow Waltz).

1-5. Cha-Cha-Cha, Jive, Samba, Tango, (Viennese)

Waltz

6-13. (Slow) Waltz, Rumba, Quickstep, Foxtrot,

Polka, Quadrille, Boogie, Paso Doble

Initially we used prerecorded ballroom dance mu-

sic downloaded from various webpages, but these

were – although recorded in high quality – streamed

in low quality. However, we soon realized that for

best results we must record and process audio data

in uncompressed format. So we obtained a small

set of dance music CDs from small Austrian dancing

schools, containing 28 dance music songs.

Contains multiple deployed models.

Dancing Guide: Near Realtime Audio Classiﬁcation of Live Dance Music on Smartphones

893

Table 1: Unique users and feedback by year.

Year #Users #Feedback

#Feedback

#User

Accuracy

by feedback

Coverage

Class unknown

(1-Coverage)

Recording

error

2010

6,031 434,812 72.10 67.29% 68.10% 31.90% 18.25%

2011 22,273 1,810,900 81.30 75.32% 62.37% 37.63% 13.53%

2012 17,851 1,434,549 80.36 72.00% 60.34% 39.66% 9.44%

2013 7,621 646,370 84.81 71.85% 61.37% 38.63% 13.82%

2014 2,239 196,671 87.84 73.15% 61.01% 38.99% 13.12%

2011-2014 49,984 4,088,490 83.58 73.08% 61.27% 38.73% 12.48%

For a realistic setting, we recorded the audio data di-

rectly on the phone in a room with typical ball room

characteristics (parquet ﬂoor, high ceilings, irregular

shaped ceiling reminiscent of chandeliers etc.) while

playing the audio CD from the other side of the room.

Initially samples were recorded at 44.1kHz, but later

we reduced this to 8kHz to improve analysis process-

ing speed.

For the initial dataset we used 28 dance music

songs from dancing school CDs and extracted win-

dows of length 5s from uncompressed recordings via

mobile phone microphones as described above. At

the very beginning we recorded a set of 30s samples,

however the feedback on dancing style would have

taken too long, so we switched after just a few pre-

liminary learning experiments.

We later obtained an additional set of several

dance music segments not previousy known to the

system. These were recorded on a SonyEricsson mo-

bile phone in real-life conditions and contained un-

compressed audio data of 29 pieces with known dance

class, each sample 30s in length, and each was added

to the previously created data set. We then split this

dataset into 2/3 training and 1/3 testing, making sure

that there was no overlap in songs between training

and testing, and extracted all non-overlapping 5s sam-

ples from each set.

3.2 Preprocessing

For preprocessing we initially only used the Marsyas

framework and only the MFCC components at var-

ious windowing sizes, since these also worked well

in related work by others. However, the achiev-

able performance was found inacceptable. So we

added BeatRoot

, an – in 2008 – state-of-the-art beat

tracking system, and computed all reasonable fea-

tures available within Marsyas – BEAT, SVLPCC and

(SVSTFT)MFCC. On the observation that BeatRoot

may confuse beats at double and half rates, we com-

bined all beat estimates with their half and double beat

rates, and created a vector with counts of all beat rates

https://github.com/marsyas/marsyas

http://www.eecs.qmul.ac.uk/

∼

simond/beatroot/

over the chosen window, which we called BRT. The

window size was then reduced from 30s to 5s to en-

able a faster recognition, as waiting for half a minute

was deemed too long for our use-case.

3.3 Wrapper-based Feature Subset

Selection

A combination of all Marsyas features and the Beat-

Root vectors using a linear Support Vector Ma-

chine(Platt, 1999) (learning pairwise models for any

unique set of two classes and ﬁtting logistic models to

residuals to get better conﬁdence estimates) for train-

ing yielded 80.86% accuracy

which could be im-

proved to 82.19% by optimizing the cost parameter.

This was the starting point for our wrapper-based fea-

ture subset selection.

To enable faster processing, we then applied a

manual feature subset selection to ﬁnd the small-

est subset with similar performance. First we in-

dependently removed only one related subset from

the dataset and repeated the training experiments.

Removing BEAT

features yielded an accuracy

of 78.63% which was slightly worse. Removing

SVLPCC yielded slightly better results at 82.48%.

Removing (SVSTFT)MFCC features yielded an even

worse result at 76.23%. Removing BEAT and

(SVSTFT)MFCC features yielded a still worse result

of 72.57%.

Removing SVLPCC and TFTM parts of

SVSTFTMFCC yielded slightly better results at

82.77%. So we concluded that MFCC features

performed best and used MFFC, BEAT and BRT as

our new best set. Additionally removing MFCC 0-3

yielded a much worse accuracy of 76.90%, while

removing MFCC 9-12 yielded 81.52% which is only

slightly worse. So while MFCC bands 0-3 are more

important than the higher frequencies, we left both

in. Additionally removing the low-frequency beat

components of BRT (everything below 0.25 beats per

As we mentioned, all accuracy values were obtained by

ten-fold crossvalidation.

These are beat-tracking features by Marsyas. The set

of features by Beatroot was called BRT.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

894

minute) yielded an accuracy of 82.87% which was

the best accuracy up to that point. Accordingly, it

was kept as new best feature set.

After obtaining additional data and adding it to the

initial training set, the BEAT features within Marsyas

could be removed while still retaining an accuracy

near 80% (79.26%) To enhance averaging of MFCC

features, we also added min, max, range and median

functions which slightly improved results. However

since computing the median necessitates sorting the

value vector this eventually proved to be too slow and

we removed it again. Noting the signiﬁcant confusion

between Viennese Waltz and Slow Waltz, we merged

both classes into Waltz. The ﬁrst 5s segment of each

song also had much higher error due to lead-in, so we

removed that and the last segment for symmetry.

3.4 First Deployed Model

It later turned out that the estimates on runtime of

the analysis code obtained by mobile phone emulator

were far too optimistic. To obtain the needed speed

on mobile phones, we switched the sampling rate

from 44.1kHz to 8kHz and used 3s samples, which

reduced the runtime signiﬁcantly to 7s for each 3s

sample. As this corresponded to 3s recording (dur-

ing which processing can already start) and 4s wait-

ing for the ﬁnal result, this was deemed acceptable

for near-real-time.

These results were conﬁrmed on

a second test phone (Sony Ericsson W959). For a test

on Nokia phones, we also obtained a Nokia E50. The

change in sampling rate and recording length neces-

sitated rerecording all dance music samples on a test

phone. This time we chose the Nokia E50. To enable

automated recording, we used a notebook computer

with active loudspeakers to play back the audio ﬁles

and controlled the local recording on the phone us-

ing bluetooth, and transferred the recorded ﬁle back

to the notebook directly after recording. This speeded

up the local generation of training data signiﬁcantly,

which previously had been a manual process.

We accordingly retrained the linear SVM model

using 8kHz samples with somewhat worse results,

however by setting a conﬁdence threshold at 0.5, we

could still achieve an accuracy of 85.73% albeit with

58.81% of samples missing (i.e. coverage 41.19%).

A parameter optimization of the SVM complexity pa-

rameter did not improve these results at this point, so

we deployed it to our test phones.

Note that this was measured on Nokia and SonyErics-

son phones, and the ﬁrst Android phone was already three

times faster, so that in later versions the feedback was prac-

tically instanteneous.

However, a real-life test with the Nokia E50

yielded only 6 samples out of 18 correctly classi-

ﬁed, while the SonyEricsson had 9 out of 18 samples

correctly classiﬁed (in case of no answer the sam-

ple was repeatedly presented to the system). So we

pooled samples from both mobile phones that were

initially used to record the samples, manually resam-

pling the old 44.1kHz samples and afterwards re-

running the preprocessing within the phone emula-

tor. The idea was to pool multiple mobile phones

and their corresponding microphones to get a more

robust model which abstracts from concrete micro-

phones and therefore yields more stable results. We

continued with this idea during the deployment of the

system towards the ﬁnal model.

However, the results – while much improved –

were still insufﬁcient. Our target was having both ac-

curacy and coverage at around 80%. By inspecting

the confusion between dance classes, the number of

available training samples, and after various exper-

iments, we removed more than half of the classes,

leaving the ﬁve most common: Cha-Cha-Cha, Jive,

Samba, Tango and Waltz. For this set an accuracy of

around 80% with 77.7% coverage could be obtained

after retraining, and this is the model which we de-

ployed for the ﬁrst version.

3.5 Implementation Details

After preprocessing, the main challenge was to port

the MFCC preprocessing of Marsyas as well as

Beatroot to a mobile phone. According to time and

memory measurements for Beatroot and Marsyas on

a mobile phone simulator for Nokia Symbian (Series

60), the initial processing time and memory was

2.48s / 29M for beatroot features (BRT), 0.078s /

12M for SVMFCC, 2.30s / 31M for BEAT features,

and 0.067s / 2.6M for classiﬁcation using the linear

Support Vector Machine, yield 31M maximum

memory consumption and a processing time of 5.09s

per second of sample (i.e. ﬁve times slower than

realtime) when processing 30s samples, which was

acceptable for initial experiments. So we restricted

the test to mobile phones with more than 32M

memory (optimally with 32M free memory at system

start) and with at least 360Mhz processor, which at

that time gave us the Nokia N95 and the Nokia 5700.

A large part of the processing time was consumed

by Beatroot, so we checked again whether the BRT

features were really necessary. However, it turned

out that BRT features were necessary to obtain an

accuracy of at least 80% and performance drops

signiﬁcantly if they are removed.

Dancing Guide: Near Realtime Audio Classiﬁcation of Live Dance Music on Smartphones

895

By adapting the prototype code to use ﬂoat in-

stead of double we obtained the same speed but sig-

niﬁcantly smaller memory consumption. Instead of

our initial estimate of 31M (obtained by analyzing 30s

samples) we noted our code would work with 1M of

memory (when analyzing 5s samples) and thus extend

the number of mobile phones that are able to run it. It

is likely that using 30s samples for the initial mem-

ory consumption test severely overestimated memory

consumption.

To ensure that our audio capture code works on

as many devices as possible, we obtained a test ac-

count for a mobile phone virtualization company

and checked audio recording capabilities for various

Nokia and SonyEricsson phones. With minor mod-

iﬁcations we were able to run the audio recording

code on all these phones. However as we already

noted our runtime estimates obtained from mobile

phone emulators were too optimistic by a factor of 6.3

(tested on a SonyEricsson K700i). We obtained an-

other test phone (SonyEricsson V630i) and tested var-

ious speed improvements (such as using MathFP, an

integer ﬂoating point emulation platform) but speedup

was minimal. However, reducing the sampling rate

from 44.1kHz to 8kHz and reducing recording time

from 5s to 3s was sufﬁcient to speed up the system to

a point where it was useful again.

About this time Android phones were ﬁnally be-

coming available in Austria. We ported the Java code

to Android and tested the preprocessing engine on the

emulator. We added a more sensible user-interface

and the ability to give feedback on the correctness

of the results via a server-side interface on our web-

server. This became available on 10th November

2009.

By porting the Java code via XMLVM

Objective-C, we also created an iPhone version with

reasonable effort from the same code base. This be-

came available on the 10th March 2010.

4 EVALUATIONS DURING

DEPLOYMENT

During the seven years that the system was available,

we added new languages

, ﬁxed many bugs (as can

be seen by the reduced recording error portion in Ta-

ble 1 from 2010 to 2011), added small improvements,

and also occasionally retrained the system using feed-

back and data from other sources. Since sending raw

http://www.xmlvm.org/overview/

Dec.2009: Spanish, French, Polish, Czech, Traditional

Chinese; Jan.2010: Portugues, Dutch.

audio samples entails privacy issues, the system was

designed to send only the processed vector which con-

tains MFCC and BRT features.

without allowing its

reconstruction. If no internet connection was avail-

able, feedback was temporarily stored and sent out

once the connection became available again. This was

done to ensure that no feedback was ever lost.

In January 2010 we added new dance ﬁles, bring-

ing the total up to about 500 distinct songs, adapted

the recording server to also work for Android phones,

also switching from Bluetooth to Wiﬁ to increase

transfer speed for the ﬁnished recording. With this we

rerecorded all new and old dance ﬁles on the Android

phone using its microphone in a suitable room. This

dataset had 2,694 samples. We estimated an accuracy

of 80.67% at a threshold of 0.65 with a coverage of

75.84% (i.e. 24.16% of samples returned dance class

not recognized). This updated model was deployed

on 15th Jan. 2010.

In March 2010 we added a small set of training

samples which were not previously used and rere-

corded them using the Android test phone. Analyz-

ing feedback from Jan-Mar 2010 only gave one user

with a signiﬁcant number of usable feedback, how-

ever w.r.t. this feedback our new retrained model per-

formed worse so we did not deploy it. At this time we

added test recordings from an actual Viennese ball we

attended to our independent test set.

We then tried to adapt the model using different

threshold for each predicted class, and again used the

feedback samples to evaluate this, however again the

optimized model performed universally worse. We

speculate that the number of songs is sufﬁcient, how-

ever increasing the number of samples by increas-

ing overlap could still improve results. However as

this makes evaluating the system’s performance much

harder we did not follow it up.

As ﬁnal try, we exhaustively tested about 10 mil-

lion thresholds

extensively on the last deployed

model to ﬁnd a set of thresholds with coverage at least

80% (20% class unknown) and accuracy at least 80%.

However it was not possible to get coverage 80% and

accuracy 80% for all ﬁve dance classes. The closest

was 74.71%. But since this model reduced the cov-

erage on the actual ball data to 16.67% (i.e. 5 out of

6 samples output dance class not recognized), we did

not use it. By optimizing accuracy, we then chose a

I.e. he vector which was used as input to the SVM

which output the predicted dance class, and which was di-

rectly computed from the 3s audio samples.

I.e. not the be used for training but just for validation.

The main reason was that the number of samples was still

deemed to be too small.

0.0 to 1.0 in steps of 0.04 for each of the ﬁve classes.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

896

100

0 20 40 60 80 100

Accuracy (%)

Coverage (%)

Estimated by ten-fold crossvalidation

Estimated by feedback

Figure 1: Coverage (X-Axis) vs. Accuracy (Y-Axis) for the

ﬁnal model, estimated by ten-fold CV and by user feedback.

threshold setting with a coverage of only 33.24% but

an accuracy of 89.78% and put it on an iPhone, how-

ever live tests indicated that performance was much

worse than the previous model, so it was again not

deployed.

In June 2010 we received feedback from a test

user at a dancing school for a relatively large num-

ber of dances – 100 in total with 41 correctly iden-

tiﬁed and 59 with prediction errors – and added the

erroneuosly classiﬁed dances to our training set. Af-

ter testing with the validation set, we found that the

performance was slightly better, so we deployed the

retrained system.

On 8th November 2010 we added all feedback

data from June 2010 to that day to the training data

and retrained the system, tested on the validation set,

and deploying the new version on the 10th November.

However the difference in accuracy and coverage ver-

sus the old model was quite small. This dataset had

4,780 samples.

On 13th December 2011 we collected all previous

feedback samples from 8th of November to that day,

yielding 6,985 Android and 4,017 iPhone samples for

retraining. Retraining just on the feedbacks gave an

accuracy of 63.88% for the iPhone (with threshold

0.55 at a coverage of 50%) and 63.08% for Android

(with threshold 0.464 at a coverage of 50%). So – al-

though the feedback was of a similar size as the previ-

ous training set (4,780 samples of which 1,621 were

from feedback) – our old model actually performed

much better than the model trained by user feedback.

After investigating about 400 duplicate input vectors

and assigning the majority class to all of them and

repeating the analysis with the old model, very simi-

lar resolts (62.85% and 61.35%) were obtained. The

old model applied to this new data gives much better

results at 73.52% and 72.58%. User feedback has a

3.13x spread between most and least common class

while our training data has only a 1.10x spread. This

could explain the bad results when training just on

feedback. However as noted in Section 5 equalizing

the class distribution also does not help to get a bet-

ter model. Therefore we did not deploy a new model

then.

From 2011 to 2014 the deployed model was un-

changed. This model had – according to estimates

derived from the training set via tenfold crossvalida-

tion – an expected coverage of 80.66% (i.e. missing

19.34%) and an accuracy of 76.47%. While the ac-

curacy agrees well with the performance according to

user feedback in Table 1 (73.08%) for these years, the

coverage is much lower. This may be since we did not

account for background noise in the mobile phone mi-

crophone recordings, and as such the more noisy sam-

ples fall below the conﬁdence threshold after classiﬁ-

cation twice as often. At a comparable coverage of

59.33%, the ﬁnal model would have had an expected

accuracy of 83.07% – much higher than what we ob-

served – so we can exclude a drift in conﬁdence values

as the cause. For comparison, Figure 1 shows a plot

of coverage versus accuracy at all different thresholds

both for the crossvalidated estimated as well as those

estimated by user feedback from 2011 to 2014 where

the model did not change.

Sadly, as the performance could not be signiﬁ-

cantly improved using feedback and the coverage was

below our expectations, we stopped further develop-

ment in 2012. The app was available on Android and

Apple for several years more but was no longer main-

tained and unique users and feedback numbers contin-

ued to drop. We switched off the server-side interface

in 2020 after having received no more feedbacks for

several months.

5 DISCUSSION

It was quite disappointing that the intended regular

retraining of the system using user feedback did not

work well, and this contributed to the late publication

of this work as well as the eventual cancellation of

the project. However, one point that is obvious – per-

haps only in hindsight – is that the user feedback has

a much more uneven class distribution that the origi-

nal data set or even the extended set used for the ﬁnal

model.

Therefore we revisited this issue and retrained the

system using all feedback before 13th Dec. 2011 af-

ter resampling to roughly equal class distributions.

We prepared a dataset with a spread of 1.28x by

downsampling from the original dataset of all feed-

back up to 13rd Dec. 2011. We obtained an accu-

Dancing Guide: Near Realtime Audio Classiﬁcation of Live Dance Music on Smartphones

897

racy of 65.11% at a coverage of 63.85% (i.e. with

36.15% missing) by tenfold cross-validation, which

is very similar to the previous result. When we ap-

ply this model which was only trained on feedback

on the feedback from 2012, we get again coverage of

61.10% (38.90% missing) with an accuracy of only

49.13%. Even pooling all feedback from 2010 to

2013 and evaluating on 2014 does not improve this.

So, clearly our initial data is more useful than

feedback alone even when we correct for the un-

equal class distribution, perhaps because it did not

include noise. We therefore speculate that the non-

improvement of performance indicates a limitation

of the used feature set rather than lack of training

data. Perhaps orders of magnitude more training data

would be needed to enable higher coverage, or per-

haps the signal-noise-ratio of the audio samples with

background noise is simply too low.

6 CONCLUSION

We have implemented and deployed a system for

dance music genre classiﬁcation, which determined

the correct dancing style with about 73% accuracy

and a coverage of 61% (i.e. reporting an unknown

class in 39% of cases). While the accuracy was as

expected, the coverage was below expectations. The

dancing style was reported in near-real-time – about

4s after recording a 3s sample, and later below 1s –

and was therefore suitable for the intended purpose of

helping novice dancing students to ﬁnd the appropri-

ate dance for a given live or recorded music.

We have deployed the system for seven years, and

it was extensively used from 2011 to 2014 by about

50,000 users, each of which used it about 84 times per

year (7 times per month). Feedback by users agree

well with our previous estimate of the models’ per-

formance, which was most likely due to the fact that

– instead of analyzing the audio samples directly –

we recorded them with a variety of smartphone mi-

crophones in rooms similar to dancing halls, simu-

lating acoustic characteristics albeit not background

noise, before audio analysis. However we neglected

to account for and model realistic background noise

which might explain the observed lower coverage in

the ﬁeld.

While our system was intended for continual

improvement by integrating users’ feedback, this part

did not work well. It may be that the initial feature

set which we chose after extensive experiments was

too restricted to enable a better performance, or the

feedback may be of insufﬁcient quality. The latter

would however be surprising as the accuracy agrees

quite well with pre-deployment estimates.

ACKNOWLEDGEMENTS

We would like to thank all volunteer translators and

all others who have helped to improve our sys-

tem, provided feedback, dance music or test phones,

most notably Andreas H., Gregoire A., Christoph B.,

Ond

rej J., Witono H., Melanie M., Paolo P., Martin P.,

Sonja S., Herbert S. and Arthur K.

REFERENCES

Arzt, A. and Widmer, G. (2010). Towards effective ‘any-

time’music tracking. In

Agotnes, T., editor, Proceed-

ings of the Fifth Starting AI Researchers’ Symposium,

pages 24–29.

Chew, E., Volk, A., and Lee, C.-Y. (2005). Dance music

classiﬁcation using inner metric analysis. In The next

wave in computing, optimization, and decision tech-

nologies, pages 355–370. Springer.

Dixon, S. (2007). Evaluation of the audio beat tracking

system beatroot. Journal of New Music Research,

36(1):39–50.

Dixon, S., Pampalk, E., and Widmer, G. (2003). Classiﬁca-

tion of dance music by periodicity patterns. In Pro-

ceedings of the Fourth International Conference on

Music Information Retrieval, Baltimore (ML), USA.

Gouyon, F. and Dixon, S. (2004). Dance music classiﬁ-

cation: A tempo-based approach. In Proceedings of

the 5th International Conference on Music Informa-

tion Retrieval, Barcelona, Spain.

Gouyon, F., Dixon, S., Pampalk, E., and Widmer, G.

(2004). Evaluating rhythmic descriptors for musical

genre classiﬁcation. In Proceedings of the AES 25th

International Conference, pages 196–204.

Medhat, F., Chesmore, D., and Robinson, J. (2017). Auto-

matic classiﬁcation of music genre using masked con-

ditional neural networks. In 2017 IEEE International

Conference on Data Mining (ICDM), pages 979–984.

IEEE.

Platt, J. (1999). Fast training of support vector machines us-

ing sequential minimal optimization. advances in ker-

nel methods—support vector learning (pp. 185–208).

AJ, MIT Press, Cambridge, MA.

Wang, A. (2003). An industrial-strength audio search algo-

rithm. In Choudhury, T. and Manus, S., editors, ISMIR

2003, 4th Symposium Conference on Music Informa-

tion Retrieval, pages 7–13.

Yang, R., Feng, L., Wang, H., Yao, J., and Luo, S. (2020).

Parallel recurrent convolutional neural networks based

music genre classiﬁcation method for mobile devices.

IEEE Access, Preprint.

ICAART 2021 - 13th International Conference on Agents and Artiﬁcial Intelligence

898
