HyperPass: Secure Password Input Platform

Michael Kiperberg

and Nezer J. Zaidenberg

Software Engineering Department, Shamoon College of Engineering, Beer-Sheva, Israel

School of Computer Science, The College of Management, Academic Studies, Israel

Keywords:

Virtual Machine Monitors, Hypervisors, Trusted Computing Base, Security Indicators.

Abstract:

Conﬁdential information, like passwords and credit card numbers, travel from the user’s local machine to a re-

mote server via secure communication protocols. Whereas remote servers are serviced by security specialists,

local machines are more vulnerable to memory attacks and keyloggers. To counter these attacks we propose

a secure password input platform, called HyperPass, which is based on a thin hypervisor. The thin hypervisor

acts as an isolated and secure environment for entering and encrypting user’s conﬁdential information. Hyper-

Pass uses the keyboard’s scroll lock LED as a security indicator. Our evaluation shows that the performance

overhead of HyperPass is insigniﬁcant (≈ 2.79%).

1 INTRODUCTION

Conﬁdential information, like passwords and credit

card numbers, travel from the user’s local machine to

a remote server via secure communication protocols,

like HTTPS (Rescorla et al., 2000). Remote servers

are serviced by security specialists and have many

protection layers, e.g., ﬁrewalls (Sharma et al., 2014),

antiviruses (Gandotra et al., 2014), intrusion detec-

tion systems (Axelsson, 2000). On the other hand,

the user’s local machine, which usually lacks some of

these protection mechanisms, is more vulnerable to

attacks.

The conﬁdential information is at risk between the

moment of pressing a keyboard key until the moment

of encryption by a secure communication protocol.

Keyloggers (Hussain et al., 2016) can intercept the

conﬁdential information while it is being typed by the

user. Software attacks can fetch the conﬁdential infor-

mation from the memory of the target process, e.g., a

web browser. In order to protect the conﬁdential in-

formation, it is required to: (a) safely acquire user’s

input, (b) store the input in an isolated environment,

and (c) encrypt the input before it leaves the isolated

environment.

Requirements (a) and (b) can be easily satisﬁed on

ARM processors using ARM’s TrustZone (Pinto and

Santos, 2019). A software module executing in Trust-

Zone’s isolated environment, the ”secure world”, can

prevent ”normal world” software from accessing to its

internal data.

In addition, ARM’s SoC devices are divided into

two categories: secure and non-secure (Rosenbaum

et al., 2019). A special bit, the ”NS bit”, on the sys-

tem bus is used to tag the security of each transaction.

Transaction issued by secure devices set the NS bit to

0, whereas non-secure devices set this bit to 1. Secure

devices will not handle transactions whose NS bit is

set to 1. The CPU issues a transaction the value of the

NS bit is determined by the current world of the CPU:

a normal world sets the bit to 1 and a secure world sets

it to 0. For example, a security LED, being a secure

device, can be turned off and on only by a software

module executing in the secure world.

On Intel CPUs, comparable memory isolation can

be achieved using virtualization (Neiger et al., 2006)

and enclaves (SGX) (Costan and Devadas, 2016).

However, Intel platforms are lacking built-in mech-

anisms for secure communication with external de-

vices. Fortunately, virtualization can be used to over-

come this deﬁciency. BitVisor (Shinagawa et al.,

2009) was the ﬁrst attempt to use virtualization for

securing a hardware device. Speciﬁcally, BitVisor is

a thin hypervisor that intercepts the communication

between the operating system and a hard disk in order

to implement full disk encryption transparently.

In order to secure user’s input, we propose to use

a thin hypervisor, similarly to BitVisor. Unlike BitVi-

sor, our hypervisor intercepts the communication be-

tween the operating system and the keyboard. When

the user is required to enter a password, the hypervi-

sor turns on the scroll lock LED (Chapweske, 2003),

580

Kiperberg, M. and Zaidenberg, N.

HyperPass: Secure Password Input Platform.

DOI: 10.5220/0010301905800587

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 580-587

ISBN: 978-989-758-491-6

indicating that the input of the user is safe. All at-

tempts to turn on the scroll lock LED from the oper-

ating system are circumvented by the hypervisor. The

scroll lock LED can be seen by the user as a security

indicator.

There are several ways to satisfy requirement

(c): encrypting the conﬁdential information before it

leaves the isolated environment. The most common

approach is to move the communication stack from

the normal environment to the isolated (secure) envi-

ronment (Liu and Cox, 2014; Rubinov et al., 2016),

thus signiﬁcantly increasing the size of the trusted

code and decreasing the overall security. Another ap-

proach attempts to move only the encrypting func-

tionality to the isolated environment (Bugiel et al.,

2010; Li et al., 2014). This approach usually requires

cooperating between the code in normal and secure

environments (Ying et al., 2018).

Following the idea of T-PIM (Hirano et al., 2009),

we propose to use an external proxy-server connected

to the isolated environment using a second commu-

nication line. Speciﬁcally, the isolated environment

encrypts conﬁdential information using the proxy’s

public key and sends it via the second communica-

tion line. The proxy decrypts the conﬁdential infor-

mation and inserts it in the communication ﬂow. The

user ”marks” the place of insertion by entering a pre-

deﬁned code-word.

From the user’s perspective the process of pass-

word entering is very natural. The user opens his

browser and navigates to the login screen of some

portal, which asks for a username and password. In

response the user enters his username and a prede-

ﬁned code-word. A window pops up on the screen

asking for the actual password. The scroll lock LED

is turned on, signifying that it is now safe to enter the

password. The user enters his password and presses

enter. The password is encrypted and sent to the proxy

server, which replaces the code-word with the actual

password and sends the resulting form to the remote

web server. The login succeeds.

The main contributions of this paper are as fol-

lows. We present a novel method for secure in-

put from a conventional keyboard using the scroll

lock LED as a security indicator. We describe a

hypervisor-based system, called HyperPass, which

takes advantage of this input method. HyperPass al-

lows the user to enter his password and other con-

ﬁdential information naturally and securely. Unlike

previously described approaches, HyperPass does not

require any modiﬁcations to existing software nor

does it require execution of additional VMs on the

user’s machine. We present and evaluate a prototype

implementation of HyperPass. Our results show that

the performance overhead of HyperPass is insigniﬁ-

cant (≈ 2.79%).

2 BACKGROUND

Intel introduced virtualization extensions to their

CPUs more than a decade ago (Neiger et al., 2006).

The main reason for introducing these extensions was

enabling the execution of multiple operating systems

simultaneously in an isolated environment, called a

”Virtual Machine” (VM). A special software compo-

nent, called a ”Virtual Machine Monitor” (VMM) or

”hypervisor”, manages the virtual machines. The hy-

pervisor can conﬁgure interception of various events

that occur in the VMs, e.g., execution of privileged

instructions, access to IO ports, triggering of an ex-

ception, access to Model-Speciﬁc Registers (MSRs),

etc. Upon the occurrence of a pre-conﬁgured event, a

”VM-exit” occurs, which transfers the control to the

hypervisor. The information about the occurred event

is stored in a special data structure for the hypervisor’s

inspection.

The hypervisor inspects the information about the

occurred event and handles it accordingly. After com-

pletion of the event handling, the hypervisor performs

a ”VM-entry”, which transfers the control to the VM.

The hypervisor manages the memory via a mecha-

nism called ”Extended Page Tables” (EPT). ETP acts

as a secondary page table, which translates VM’s

physical addresses to real physical addresses. In addi-

tion, the hypervisor can use the EPT to make certain

pages inaccessible by the VM. An attempt to access

these pages trigger and EPT-violation, transferring the

control to the hypervisor.

A hypervisor can intercept a wide range of events.

While interception of some events, e.g., access to IO

ports, can be disabled, others, e.g., execution of the

CPUID instruction, are intercepted unconditionally.

HyperPass uses three types of events: (1) access

to IO ports, (2) execution of the CPUID instruction,

and (3) EPT-violations. The hypervisor can select the

ports that need to be intercepted. Attempts to access

the selected ports will trigger a VM-exit, whereas ac-

cessing other ports will not incur any overhead.

The CPUID instruction is used by many hypervi-

sors, e.g., Xen, KVM, Hyper-V, as a hypercall instruc-

tion (Microsoft, 2012), i.e. an instruction that allows

a software module executing inside a VM to invoke a

function of a VMM. The eax register is used to select

the required function, whereas other registers act as

arguments.

An EPT-violation occurs when the virtual ma-

chine attempts to access a page that was marked as

HyperPass: Secure Password Input Platform

581

inaccessible by the hypervisor. In response to such

access, the control is transferred to the hypervisor.

The hypervisor can respond by modifying the access

rights and performing a VM-entry.

2.1 PS/2 Keyboards

The current implementation of HyperPass supports

only PS/2 keyboards. This type of keyboards was

selected for the simplicity of its communication pro-

tocol. The communication with the PS/2 keyboards

is managed by a PS/2 controller (Chapweske, 2003).

The PS/2 controller uses two IO ports for its opera-

tion, 0x60 as a data port and 0x64 as a command and

status port. Port 0x64 is used for communication with

the controller itself, e.g., reading and writing its inter-

nal RAM, and for selection of the destination device.

Port 0x60 is used to send and receive data from the

previously selected destination device.

Assuming that the selected destination device is

a PS/2 keyboard, the act of reading from port 0x60

reads the last scan code of the keyboard. A scan code

represents a keyboard event, like pressing or releasing

a key. The scan codes can then be translated into a

character according to a conversion table. Some scan

codes, e.g., presses and releases of shift keys, affect

the translation of other scan codes. For example, in

order to type a capital ’A’, one can produce the fol-

lowing sequence of events: (1) pressing the left shift

key, (2) pressing the ’a’ key, (3) releasing the ’a’ key,

(4) releasing the left shift key. The presses left shift

key causes the pressed ’a’ key to be translated into the

capital ’A’ character.

The act of writing to port 0x60, sends a command

to the keyboard. The commands conﬁgure various as-

pects of a keyboard’s behavior. Some commands are

single byte, others are followed by an argument. For

example, the 0xFF command is a single byte com-

mand, which resets the keyboard. The 0xF3 com-

mand deﬁnes the rate at which a pressed key produces

events. The rate is deﬁned by the byte that follows the

0xF3 byte. Another example is the 0xED command,

which deﬁnes the LEDs state. The lower three bits in

the byte that follows the 0xED command deﬁne the

state of scroll lock (bit 0), number lock (bit 1) and the

caps lock (bit 2) LEDs.

3 THREAT MODEL

We assume that the attacker has full control over the

software of the local machine. In particular, we as-

sume that the attacker is able to execute random code

in kernel-mode. We impose only a single limitation

on the attacker: we assume that the EFI boot order

cannot be changed, i.e. we assume that HyperPass’

EFI application is always the ﬁrst application that is

loaded by the EFI ﬁrmware.

4 SYSTEM DESIGN

HyperPass consists of three components: (a) a thin

hypervisor, (b) a user-mode agent application and (c)

a proxy server. The hypervisor and the agent run on

the user’s local machine, whereas the proxy server

runs on a remote server. Several users can share a

single proxy server.

Figure 1 depicts the interactions between the dif-

ferent components of HyperPass. HyperPass requires

a proxy server between the local machine and a re-

mote server. To understand these interactions, con-

sider the following example, in which a user attempts

to log in to the web portal of his organization. The re-

mote server redirects the user to a login screen (steps

1 and 2 ), which requests a username and a pass-

word. Normally, the user enters his credentials and

they are sent to the remote server. With HyperPass,

the user enters a special code-word in the password

ﬁeld, thus indicating his desire to enter the pass-

word securely. The username and the code-word, as

any other outgoing communication, are sent to a pre-

conﬁgured proxy server (step 3 ). The proxy server

detects the code-word and sends a password request to

the user-mode agent (step 4 ). The user-mode agent

displays the URL of the web portal and the name of

the password ﬁeld. Then, the agent issues a hyper-

call (step 5 ), which causes the hypervisor to turn

on the scroll-lock LED and begin intercepting key-

board strokes. The user veriﬁes that the scroll-lock

LED is on and enters the password. The password is

consumed by the hypervisor one letter at a time un-

til the enter key is pressed, which signiﬁes the end

of the password. The hypervisor encrypts the pass-

word using the proxy’s public key and transmits it to

the user-mode agent (step

6 ), which sends it to the

proxy ( 7 ). The proxy replaces the code-word with

the decrypted password and sends the resulting HTTP

request to the remote server (step 8 ).

4.1 Proxy Server

HyperPass uses mitmproxy, an extensible HTTP

proxy server (Boneh et al., 2007). mitmproxy provides

a Python API for add-ons, which can perform differ-

ent monitoring activities on the communication ﬂows.

When a browser is conﬁgured to use a proxy server,

the communication is encrypted using the proxy’s

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

582

User-mode

Kernel-mode

Operating System

Root-mode

Hypervisor

Agent

Firefox

mitmproxy

Remote Server

5 6

Figure 1: Interactions between HyperPass components and other software. The three components of HyperPass, the hypervi-

sor, the user-mode agent and the proxy, are shaded.

public key, thus allowing it to decrypt and analyze the

data.

HyperPass includes an add-on for mitmproxy that

intercepts HTTP requests and analyzes them. The

goal of the analysis is to ﬁnd password ﬁelds that

include a predeﬁned code-word. When such a pass-

word ﬁeld is found, the add-on contacts the user-mode

agent, running on the local machine. The add-on pro-

vides the agent with the name of the password ﬁeld

and the URL to which it was submitted.

The user-mode agent replies with the user-

provided password. The password is encrypted with

the add-on’s public key (which may differ from mitm-

proxy’s public key). The add-on decrypts the pass-

word and replaces the code-word with the decrypted

password. Then, the HTTP request is sent to its desti-

nation.

4.2 Agent

The user-mode agent is implemented as a console ap-

plication, which listens on a UDP socket. When the

proxy server connects to the UDP socket, it sends a

pair consisting of the name of the password ﬁeld and

the URL to which this password ﬁeld should be sent.

The agent displays these the name of the ﬁeld and the

URL to the user and issues a hypercall.

The hypercall requests the hypervisor to enter se-

cure mode. While in this mode, the hypervisor reads

the keyboard strokes and replaces them with the as-

terisk key, which is then displayed by the user-mode

agent.

After entering the password, the user presses the

enter key, causing the agent to issue another hypercall.

The hypervisor reacts to this hypercall by provided

the agent with an encrypted version of the user pass-

word. The encryption is performed using the proxy’s

public key. The agent sends the encrypted password

to the proxy server and continues listening on the

UDP socket.

4.3 Hypervisor

The hypervisor is embedded in an EFI application

(Zimmer, 2009). The application boots before the op-

erating system, initializes the hypervisor and invokes

the operating system bootloader.

The hypervisor intercepts two types of events: (a)

input-output on port 0x60 and (b) execution of the

CPUID instruction. The CPUID instruction is used for

hypercalls. The user-mode agent sets the eax register

to the hypercall index and executes the CPUID instruc-

tion. The instruction is intercepted by the hypervisor,

which examines the value of the eax registers and acts

accordingly. Other registers can be used to pass pa-

rameters.

In the current implementation, the hypervisor im-

plements two hypercalls: HC BEGIN and HC END and

intercepts input and output on port 0x60, the PS/2 data

port. Algorithm 1 presents the pseudo-code of the hy-

pervisor’s VM-exit handler.

Any attempt to set the scroll lock LED is pre-

vented by the hypervisor (lines 10–18). In PS/2 key-

boards, in order to change the state of the LEDs, the

operating system transfers the 0xED command byte,

HyperPass: Secure Password Input Platform

583

followed by a LED conﬁguration byte. The hypervi-

sor intercepts the 0xED byte (lines 12–13) and clears

the scroll lock bit in the following conﬁguration byte

(lines 14–16). In any case, the hypervisor must emu-

late the intercepted operation (line 18).

The password capturing process begins with the

HC BEGIN hypercall, continues with a series of inputs

on port 0x60, and terminated with the HC END hyper-

call. In response to HC BEGIN (lines 1–4), the hypervi-

sor turns on the scroll lock LED, clears the password

and sets the SecureMode variable.

Any attempt to read a key from the keyboard is

intercepted and analyzed by the hypervisor (lines 19–

35). The hypervisor reads the input byte from the key-

board (line 20). If the byte corresponds to a press or

a release of the shift key, the UpperCase variable is

updated accordingly (lines 21–24). If the byte cor-

responds to a release of the backspace key, the last

character of the password is removed (lines 25–26).

If the byte corresponds to a release of a letter key

(line 27), the byte is converted to a character (line 28)

and its case is ﬁxed, if necessary (lines 29-30). Then

the hypervisor concatenates the character to the pass-

word (line 32) and sets the byte that was read from

the keyboard to a scan code of an asterisk (line 33).

Finally, the hypervisor emulates the intercepted oper-

ation (line 35).

In response to HC END (lines 5–9), the hypervisor

turns off the scroll lock LED, clears the SecureMode

variable (lines 6–7). Then, the hypervisor encrypts

the password using the proxy’s public key and copies

the encrypted password to the user-mode agent.

In the current implementation the public key of the

proxy server is hardcoded in the hypervisor.

5 EVALUATION

5.1 Code Size

An important measure of system security is its code

size. HyperPass is based on a thin hypervisor with

about 2 KSLOCs equipped with an RSA implemen-

tation of 0.3 KSLOCs. In order to show how small

HyperPass is and how large can be a full hypervi-

sor equipped with HTTPS (Rescorla et al., 2000)

support, we present the sizes of some open-source

projects. The lwIP library, which implements the

TCP/IP stack, has 146 KSLOCs. The mbedTLS li-

brary, which implements secure communication pro-

tocols, is 127 KSLOCs. The XEN hypervisor has 600

KSLOCs. The sizes of the projects were obtained us-

ing the GitHub Gloc extensions (Solovev, 2020) for

the Google Chrome browser.

Algorithm 1: Hypervisor’s VM-exit Handler.

1: if CPUID and eax = HC BEGIN then

2: TurnOn(ScrollLockLED)

3: Password := ””

4: SecureMode := True

5: else if CPUID and eax = HC END then

6: TurnOff(ScrollLockLED)

7: SecureMode := False

8: Cipher := Encrypt(Password)

9: MemCpy(ebx, Cipher)

10: else if output on port 0x60 then

11: o := output byte to port 0x60

12: if o is LED control then

13: LedControl := True

14: else if LedControl then

15: LedControl := False

16: Turn off scroll lock bit in o

17: end if

18: EmulateOutput(0x60, o)

19: else if input on port 0x60 then

20: i := input byte from port 0x60

21: if i is shift press then

22: UpperCase := True

23: else if i is shift release then

24: UpperCase := False

25: else if i is backspace release then

26: Password := Password[1,|Password|-1]

27: else if i is letter release then

28: j = ToLetter(i)

29: if UpperCase then

30: j := ToUpper(j)

31: end if

32: Password := Password + j

33: i := ToScanCode(’*’)

34: end if

35: EmulateInput(0x60, i)

36: end if

5.2 Security Evaluation

We assess the security of the proposed system from

two perspectives:

• the inability of an attacker to turn on the scroll

lock LED and

• the inability of an attacker to obtain the password

in its decrypted form.

The keyboard LEDs are controlled by the keyboard

and can be changed only by sending an appropri-

ate command on port 0x60. The command consists

of two bytes: the command byte 0xED followed by

a ﬂag byte that speciﬁes the setting of each of the

three LEDs. The hypervisor intercepts the outgoing

communication on port 0x60. When the 0xED byte

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

584

Table 1: Testing environment conﬁguration.

Host CPU Intel(R) Core(TM) i7-10610U

Host memory 16 GB

Host OS Ubuntu 20.04.1 LTS

VMM VMware Workstation 15.5.6

Guest CPU Intel(R) Core(TM) i7-10610U

Guest memory 8 GB

Guest OS Windows 10 (19041)

is detected, the hypervisor clears the scroll lock bit

(bit 0) of the following byte. Therefore, even an at-

tacker with kernel-mode random code execution abil-

ities cannot turn on the scroll lock LED.

Similarly, the hypervisor intercepts all the input

communication on port 0x60 and masks the scan

codes with the scan code of an asterisk when the scroll

lock LED is on. The original scan codes are translated

to characters and are stored in the hypervisor’s mem-

ory region, which is protected by EPT. Speciﬁcally,

the hypervisor makes its memory regions inaccessi-

ble by the operating system. Any attempt to access

these regions induces an EPT-violation. The hyper-

visor responds to this event by clearing the password

and resetting the machine.

5.3 Performance Evaluation

HyperPass uses a thin hypervisor whose existence

may degrade the overall system performance. In or-

der to assess this performance degradation, we ran a

benchmarking tool called PCMark (Sibai, 2008) in

three conﬁgurations: (a) without a hypervisor, (b)

with HyperPass’ hypervisor, (c) with Oracle Virtual-

Box (6.1.14) as an example of a full hypervisor, run-

ning the same version of Windows with 8GB of RAM.

The exact conﬁguration of our testing environment is

summarized in Table 1. Table 2 presents the scores

that were given by PCMark in each conﬁguration for

every category and Figure 2 presents the overhead in

percent.

A thin hypervisor and Hyperpass’ hypervisor in-

cur a minor performance degradation (≈ 1.35% and

≈ 2.79% on average, even without taking into account

the Video Conferencing results). The only difference

between the thin hypervisor and HyperPass’ hyper-

visor is the interception of input and output on port

0x60. Because this port is accessed by the operat-

ing system only upon an interrupt from the keyboard,

which is a relatively rare event, our tests show a mi-

nor performance degradation due to this interception.

A full hypervisor, represented by Oracle VirtualBox,

showed a much higher impact on the overall system

performance (≈ 38.6% on average).

6 RELATED WORK

The idea to use an isolated environment for securing

passwords and other sensitive information is not new.

ARM TrustZone (Pinto and Santos, 2019) is an ex-

ample of such an isolated environment, that is widely

used for security applications in the industry and aca-

demic research. Samsung pay (Samsung, 2020) and

Alipay (Alipay, 2020) use TrustZone to secure users’

credit card numbers. Bitcoin Ledger (BitCoin, 2020)

uses TrustZone for transaction conﬁrmation. While in

TrustZone a security LED is turned on thus indicating

to the users that their input is safe.

After receiving the sensitive information, the se-

curity module running in an isolated environment,

needs to send this information to a remote server,

without revealing this information to the normal envi-

ronment. Typically, this problem is solved by moving

some of the communication logic to the isolated envi-

ronment (Liu and Cox, 2014; Rubinov et al., 2016).

For example, VeriUI (Liu and Cox, 2014), a login

page protection system, moves the entire communi-

cation stack and UI framework to the isolated envi-

ronment.

Another approach, which is adopted by TruWal-

letM (Bugiel et al., 2010), Droidvault (Li et al., 2014),

KNOX (Knox, 2013), TruZ-Droid (Ying et al., 2018)

and HyperPass, attempts to lower the size of the

code executing in the isolated environment. This is

achieved by keeping the communication stack and the

UI framework in the normal environment but encrypt-

ing the sensitive information before it leaves the iso-

lated environment.

Unfortunately, TrustZone with its exclusive access

to certain hardware components, e.g., security LEDs,

is not available on x86 processors. However, the In-

tel VT-x (Neiger et al., 2006) technology can be used

to construct an isolated environment in a form of a

hypervisor. Commonly, an existing hypervisor, e.g.,

Xen or KVM (Deshane et al., 2008), is extended to

provide additional security. The security applications

range from system call tracing (Pfoh et al., 2011) and

DRM (Kiperberg et al., 2019) to preventing unau-

thorized code execution (Seshadri et al., 2007; Leon

et al., 2019).

BitVisor (Shinagawa et al., 2009) is a thin hyper-

visor that intercepts accesses to ATA hard disks and

enforces storage encryption. HyperPass uses a simi-

lar method of IO interception for implementing a se-

curity indicator.

T-PIM (Hirano et al., 2009) is most closely related

to HyperPass. T-PIM extends Xen to provide secure

password input. It uses two virtual machines: a work-

ing VM and a trusted VM. The browser runs in the

HyperPass: Secure Password Input Platform

585

Table 2: PCMark scores in four conﬁgurations.

Category No Hypervisor Thin Hypervisor HyperPass’ Hypervisor VirtualBox

App start-up 7277 7110 6842 4008

Video conferencing 2129 2307 2301 1197

Web browsing 2067 2012 2007 1390

Spreadsheet 4473 4420 4354 2688

Writing 5005 4928 4871 2870

Photo editing 850 852 847 524

Video editing 903 887 856 650

App start-up

Video conferencing

Web browsing

Spreadsheet

Writing

Photo editing

Video editing

Thin Hypervisor HyperPass’ Hypervisor VirtualBox

Figure 2: Performance degradation in percent in three conﬁgurations with respect to the “No Hypervisor” conﬁguration.

working VM and when a password needs to be en-

tered it is entered in the trusted VM. From the user’s

perspective, the trusted VM acts as a security indica-

tor, when the trusted VM is active, the user’s input

is safe. Similarly to HyperPass, T-PIM uses mitm-

proxy to intercept and manipulate the communication

between the working VM and an external server.

HyperPass differs from T-PIM in two aspects.

• The size of the code executing in an isolated envi-

ronment is much smaller in HyperPass than in T-

PIM. Whereas in HyperPass only the encryption

module is part of the isolated environment, in T-

PIM the isolated environment includes the entire

Linux operating system. As a result, HyperPass is

much more secure than T-PIM.

• Unlike T-PIM, HyperPass does not require an-

other VM for password entering, thus improving

the CPU and memory consumption. Moreover,

HyperPass is implemented as a thin hypervisor,

which further improves its performance compared

to T-PIM.

HyperPass is also advantageous from the perspective

of user experience, since it does not require the user

to switch to another VM to enter a password.

7 CONCLUSIONS

The design of ARM’s TrustZone allows software

modules running in an isolated environment to con-

trol hardware devices in an exclusive manner. Speciﬁ-

cally, turning on the security indicator is possible only

from the isolated environment.

We have shown that a comparable control of the

keyboard LEDs can be achieved using virtualization.

Although the performance degradation due to inter-

ception of PS/2 communication is negligible, it is un-

clear what will be the impact of controlling a USB

keyboard.

We believe that the presented approach can be

used in general for guaranteeing certain invariants in

the state of hardware devices.

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

586

REFERENCES

Alipay (2020). Alipay. https://intl.alipay.com/.

Axelsson, S. (2000). Intrusion detection systems: A survey

and taxonomy. Technical report, Technical report.

BitCoin (2020). BitCoin Ledger. https://www.ledgerwallet.

com/beta/trustlet/.

Boneh, D., Inguva, S., and Baker, I. (2007). SSL MITM

Proxy. http://crypto.stanford.edu/ssl-mitm/.

Bugiel, S., Dmitrienko, A., Kostiainen, K., Sadeghi, A.-

R., and Winandy, M. (2010). TruWalletM: Secure

web authentication on mobile platforms. In Inter-

national Conference on Trusted Systems, pages 219–

236. Springer.

Chapweske, A. (2003). The PS/2 mouse/keyboard proto-

col. electronic ﬁle available: http://www.computer-

engineering.org/ps2protocol.

Costan, V. and Devadas, S. (2016). Intel SGX Explained.

IACR Cryptol. ePrint Arch., 2016(86):1–118.

Deshane, T., Shepherd, Z., Matthews, J., Ben-Yehuda, M.,

Shah, A., and Rao, B. (2008). Quantitative compari-

son of Xen and KVM. Xen Summit, Boston, MA, USA,

pages 1–2.

Gandotra, E., Bansal, D., and Sofat, S. (2014). Malware

analysis and classiﬁcation: A survey. Journal of In-

formation Security, 2014.

Hirano, M., Umeda, T., Okuda, T., Kawai, E., and Yam-

aguchi, S. (2009). T-pim: Trusted password input

method against data stealing malware. In 2009 Sixth

International Conference on Information Technology:

New Generations, pages 429–434. IEEE.

Hussain, M., Al-Haiqi, A., Zaidan, A., Zaidan, B., Kiah,

M. M., Anuar, N. B., and Abdulnabi, M. (2016). The

rise of keyloggers on smartphones: A survey and in-

sight into motion-based tap inference attacks. Perva-

sive and Mobile Computing, 25:1–25.

Kiperberg, M., Leon, R., Resh, A., Algawi, A., and Zaiden-

berg, N. J. (2019). Hypervisor-based Protection of

Code. IEEE Transactions on Information Forensics

and Security, 14(8):2203–2216.

Knox, S. (2013). White paper: An overview of samsung

knox.

Leon, R. S., Kiperberg, M., Zabag, A. A. L., Resh, A., Al-

gawi, A., and Zaidenberg, N. J. (2019). Hypervisor-

Based White Listing of Executables. IEEE Security &

Privacy, 17(5):58–67.

Li, X., Hu, H., Bai, G., Jia, Y., Liang, Z., and Saxena,

P. (2014). DroidVault: A trusted data vault for An-

droid devices. In 2014 19th International Conference

on Engineering of Complex Computer Systems, pages

29–38. IEEE.

Liu, D. and Cox, L. P. (2014). Veriui: Attested login for mo-

bile devices. In Proceedings of the 15th Workshop on

Mobile Computing Systems and Applications, pages

1–6.

Microsoft (2012). Requirements for Implementing the

Microsoft Hypervisor Interface. MSDN, [On-

line]. Available: https://docs.microsoft.com/en-

us/virtualization/hyper-v-on-windows/reference/tlfs

.[Accessed Oct 2020].

Neiger, G., Santoni, A., Leung, F., Rodgers, D., and Uhlig,

R. (2006). Intel Virtualization Technology: Hardware

Support for Efﬁcient Processor Virtualization. Intel

Technology Journal, 10(3).

Pfoh, J., Schneider, C., and Eckert, C. (2011). Nitro:

Hardware-based system call tracing for virtual ma-

chines. In International Workshop on Security, pages

96–112. Springer.

Pinto, S. and Santos, N. (2019). Demystifying ARM Trust-

Zone: A comprehensive survey. ACM Computing Sur-

veys (CSUR), 51(6):1–36.

Rescorla, E. et al. (2000). Http over tls.

Rosenbaum, A., Biham, E., and Bitan, S. (2019). Trusted

Execution Environments. PhD thesis, Computer Sci-

ence Department, Technion.

Rubinov, K., Rosculete, L., Mitra, T., and Roychoudhury,

A. (2016). Automated partitioning of android appli-

cations for trusted execution environments. In 2016

IEEE/ACM 38th International Conference on Soft-

ware Engineering (ICSE), pages 923–934. IEEE.

Samsung (2020). Samsung Pay. http://www.samsung.com/

us/samsung-pay/.

Seshadri, A., Luk, M., Qu, N., and Perrig, A. (2007). SecVi-

sor: A tiny hypervisor to provide lifetime kernel code

integrity for commodity OSes. In Proceedings of

twenty-ﬁrst ACM SIGOPS symposium on Operating

systems principles, pages 335–350.

Sharma, R. K., Kalita, H. K., and Issac, B. (2014). Different

ﬁrewall techniques: A survey. In Fifth International

Conference on Computing, Communications and Net-

working Technologies (ICCCNT), pages 1–6. IEEE.

Shinagawa, T., Eiraku, H., Tanimoto, K., Omote, K.,

Hasegawa, S., Horie, T., Hirano, M., Kourai, K.,

Oyama, Y., Kawai, E., et al. (2009). Bitvisor: a

thin hypervisor for enforcing i/o device security. In

Proceedings of the 2009 ACM SIGPLAN/SIGOPS in-

ternational conference on Virtual execution environ-

ments, pages 121–130.

Sibai, F. N. (2008). Evaluating the performance of sin-

gle and multiple core processors with PCMARK

 05

and benchmark analysis. ACM SIGMETRICS Perfor-

mance Evaluation Review, 35(4):62–71.

Solovev, A. (2020). GitHub Gloc. https:

//chrome.google.com/webstore/detail/github-gloc/

kaodcnpebhdbpaeeemkiobcokcnegdki.

Ying, K., Ahlawat, A., Alshariﬁ, B., Jiang, Y., Thavai, P.,

and Du, W. (2018). Truz-droid: Integrating trustzone

with mobile operating system. In Proceedings of the

16th annual international conference on mobile sys-

tems, applications, and services, pages 14–27.

Zimmer, R. (2009). Hale,“UEFI: From Reset Vector to Op-

erating System,” Chapter 3 of Hardware-Dependent

Software.

HyperPass: Secure Password Input Platform

587
