Stopping DNS Rebinding Attacks in the Browser

Mohammadreza Hazhirpasand, Arash Ale Ebrahim and Oscar Nierstrasz

University of Bern, Switzerland

Keywords:

DNS Rebinding, Browser Security, Web Security.

Abstract:

DNS rebinding attacks circumvent the same-origin policy of browsers and severely jeopardize user privacy.

Although recent studies have shown that DNS rebinding attacks pose severe security threats to users, up to

now little effort has been spent to assess the effectiveness of known solutions to prevent such attacks. We have

carried out such a study to assess the protective measures proposed in prior studies. We found that none of

the recommended techniques can entirely halt this attack due to various factors, e.g., network layer encryption

renders packet inspection infeasible. Examining the previous problematic factors, we realize that a protective

measure must be implemented at the browser-level. Therefore, we propose a defensive measure, a browser

plug-in called Fail-rebind, that can detect, inform, and protect users in the event of an attack. Afterwards, we

discuss the merits and limitations of our method compared to prior methods. Our ﬁndings suggest that Fail-

rebind does not necessitate expert knowledge, works on different OSes and smart devices, and is independent

of networks and location.

1 INTRODUCTION

In a DNS rebinding attack, an attacker uses a custom

DNS server to spoof the IP address of the victim, and

thus obtain read access to the victim’s server. DNS

rebinding attacks have been around for more than 15

years (Dean et al., 1996). Being cost effective and

relatively quick to perform, this attack is capable of

jeopardizing both the victim and the intranet to which

he or she is connected.

To orchestrate a DNS rebinding attack, the at-

tacker runs a malicious website, e.g., attacker.xyz,

with a custom DNS server. Once the victim loads

attacker.xyz, the website establishes a request in the

background to its server. The malicious server re-

turns the private IP address of the victim as a re-

sponse. Consequently, SOP in the victim’s browser is

tricked into believing that the two IP addresses belong

to attacker.xyz and grants read access to the malicious

website.

Web browsers employ same-origin policy (SOP)

to provide isolation for distinct origins (scheme, host,

and port of a URL) to protect users from different

types of attacks, e.g., cross-site request forgery, or

clickjacking (Lalia and Moustafa, 2019). However,

the DNS rebinding attack subverts the SOP and turns

a browser into an open proxy to access the victim’s re-

sources and other nodes inside the victim’s network.

In practice, an attacker executes DNS rebinding to

bypass ﬁrewalls, gain access to either internal ma-

chines in the victim’s private network or the victim’s

resources, fetch sensitive resources, and compromise

vulnerable internal machines.

The DNS rebinding attack can have grave con-

sequences. For instance, a study showed that popu-

lar home routers such as Linksys, Thompson, Belkin,

Dell, and Asus are vulnerable to DNS rebinding,

threating the privacy of millions of users (Heffner,

2010). Tatang et al. analyzed four Internet of Things

(IoT) devices and found three of them are vulnera-

ble to DNS rebinding attacks (Tatang et al., 2019).

They emphasized that most smart home devices heav-

ily rely on the countermeasures implemented in the

router to detect and block such attacks. Similarly,

Dorsey in a whitepaper explained that widely-used

smart devices such as Google Home mini, RokuTV,

Sonos speakers, and home thermostats are control-

lable by the attacker from outside of the victim’s pri-

vate network.

There exist several measures to prevent DNS re-

binding attacks. Modern browsers apply a technique

called DNS pinning in order to cache the ﬁrst re-

solved IP address of a website for a ﬁxed period. Even

though this technique discards the time to live (TTL)

https://medium.com/@brannondorsey/attacking-

private-networks-from-the-internet-with-dns-rebinding-

ea7098a2d325

596

Hazhirpasand, M., Ale Ebrahim, A. and Nierstrasz, O.

Stopping DNS Rebinding Attacks in the Browser.

DOI: 10.5220/0010310705960603

In Proceedings of the 7th International Conference on Information Systems Security and Privacy (ICISSP 2021), pages 596-603

ISBN: 978-989-758-491-6

of each DNS record, the browsers reset the cached

DNS data in case the victim spends approximately

more than a minute on the attacker’s website. There

exists the Domain Name System Security Extensions

(DNSSEC) speciﬁcation suite to prevent DNS spoof-

ing attacks. For domains owners, DNSSEC provides

a way to authenticate DNS entries in order to ensure

the response has not been altered in transit by an ad-

versary. Notwithstanding authentication, in a DNS

rebinding scenario, the attacker is the owner of the

domain name, e.g., attacker.xyz, and hence, DNSSEC

becomes ineffective. Firewalls, e.g., iptables, at the

entry point of networks can detect such attacks by

deﬁning particular rules. Despite ﬁrewall packet in-

spections, the victim can still be unprotected while

using a virtual private network (VPN) that encrypts

DNS queries. Lastly, none of the aforementioned

techniques can keep a user completely safe from DNS

rebinding attacks.

In this paper, we investigate and discuss the ef-

fectiveness of available countermeasures in protect-

ing users against DNS rebinding attacks, and propose

a preventive measure, called Fail-rebind, based on

lessons learned from drawbacks of the prior preven-

tive measures. To that end, we address the following

research questions: “How can the current preventive

measures be circumvented, and what is the most ro-

bust way to detect and halt DNS rebinding attacks?”

We argue that the preventive shield must be im-

plemented in browsers rather than in the network or

operating system level. To this end, we propose a

Chrome and Firefox plug-in, called Fail-rebind, to

detect, alert, and block the malicious website in the

event of the attack. In our comparison with other

methods, we observe that our proposed solution is

highly reliable, practical in daily use, and can signiﬁ-

cantly increase safety against DNS rebinding attacks.

The remainder of this paper is structured as fol-

lows. In section 2, we explain various types of DNS

rebinding attacks, current attack frameworks, and an

example attack scenario. Then, in section 3 we dis-

cuss the pros and cons of existing countermeasures

introduced in prior research. We propose and evalu-

ate our preventive measure in section 4, and conclude

the paper in section 5.

2 BACKGROUND

We ﬁrst describe various types of DNS rebinding at-

tacks as well as the available attack frameworks. We

then explain how impactful the attack is in a given

scenario, and why we need a robust and reliable pre-

vention measure.

2.1 Attack Types

An attacker can take advantage of DNS rebinding at-

tacks to achieve various goals. Depending on the goal,

the impact of DNS rebinding attacks is classiﬁed into

two main categories, i.e., ﬁrewall circumvention, and

IP hijacking.

2.1.1 Firewall Circumvention

Network administrators consider ﬁrewalls to be an

effective defensive barrier against inbound attacks

against internal machines. However, ﬁrewall circum-

vention techniques, e.g., DNS rebinding attacks, en-

able the attacker to gain access to the victim’s local

resources and internal nodes of the victim’s network.

Attackers are keen on achieving the following objec-

tives:

— Data stealing. Web servers in a private network

might expose conﬁdential documents to legiti-

mate users inside the network. However, the at-

tacker can steer DNS rebinding attacks in such a

way as to read and download sensitive informa-

tion from the victim’s local resources or the nodes

in the victim’s private network.

— Exploitation. With due consideration of the un-

patched victim’s local or remote services in the

victim’s network, the attacker can perform recon-

naissance and exploitation attacks against vulner-

able nodes, e.g., home routers or an internal ma-

chine with an unpatched WordPress website.

2.1.2 IP Hijacking

DNS rebinding threatens both the internal nodes in

the victim’s private network and machines on the in-

ternet. In the following, we explain two types of this

attack threatening external nodes.

— Click fraud. The attacker can mount a click fraud

attack in which users inadvertently click on an

item leading them to browse a malicious target

webpage. In practice, when attacker.xyz is loaded

on the victim’s browser, the attacker can reply to

the second DNS query with an IP address of a

target website, e.g., clicktopay.xyz. Conducting

this attack on a large scale results in thousands

of unique IP addresses visiting clicktopay.xyz to

generate proﬁts (Jackson et al., 2009).

— Bypassing IP-based authentication. Services can

rely on IP-based authentication to impose restric-

tions. However, the attacker can simply defeat

such measures by using DNS rebinding, as the

communication originates from an authorized IP

address (the victim’s browser).

Stopping DNS Rebinding Attacks in the Browser

597

Unfortunately, in all the above scenarios, the tar-

get machine logs the address of victim machine for

illegal activities.

We manually checked how many repositories are

associated with DNS rebinding on GitHub. We

searched for “DNS rebinding” and found 47 reposi-

tories. Of these, two repositories offered protection

in the form of middleware using the Go language and

the Express.js framework, and the rest of the reposito-

ries all introduced attack frameworks mainly written

in JavaScript and Python.

Of the 45 attack frameworks, we examined Sin-

gularity, a recently popular and rich DNS rebinding

attack framework, proposed by Doussot et al.

At the

time of writing, this framework has received the high-

est number of stars and forks on GitHub compared

to other DNS rebinding attack frameworks. Singular-

ity offers numerous features such as a custom DNS

server, IP/port scanning, auto exploitation, and DNS

CNAME to evade ﬁrewall restriction and interactively

browse the victim’s internal network. Singularity’s

main contribution is to signiﬁcantly improve the re-

binding time in browsers by 20 times (from 60 sec-

onds to 3 seconds) and introduce three circumven-

tion methods for current protection measures. It is in-

evitable that such advances imply the ineffectiveness

of the current prevention techniques in this domain.

2.2 Motivational Example

Our goal is to demonstrate the grave implication of

DNS rebinding attacks on the privacy of users in a

scenario (See Figure 1). We use a laptop, a Plant

Watering System (PWS) smart device and a mobile

phone as nodes in the network. The mobile phone

has an application in which an HTTP web server is

running to allow users to browse the phone’s picture

gallery. The PWS has a web interface where features

such as auto watering on/off, soil status, and water-

ing history are accessible. We use the iptables ﬁre-

wall to prevent external domains from resolving pri-

vate IP addresses and loopback IP addresses. Our

gateway to the internet is a router conﬁgured with

OpenDNS. The OpenDNS service extends the DNS

by introducing security features such as phishing pro-

tection, content ﬁltering, and DNS rebinding preven-

tion. The client on the laptop uses a secure VPN con-

nection, which encapsulates and encrypts all network

trafﬁc, and sends the user’s data through a tunnel to

a server located on the internet. The VPN connec-

tion forces the DNS lookup procedure to be accom-

plished through the VPN server. On the internet, the

https://github.com/nccgroup/singularity

http://attacker.xyz

(DNS rebinding)

Internet

Router

(OpenDNS)

Laptop

(192.168.10.4)

      Plant watering system

    (192.168.10.5)

Smartphone

 (192.168.10.8)

Firewall

Figure 1: The network scenario of the motivational exam-

ple.

attacker runs a web server with a domain name, i.e.,

attacker.xyz, and a custom DNS server.

Attackers commonly ﬁnd the private IP address

of a victim with the help of the IP leakage in We-

bRTC and carry out IP or port scanning, e.g., loading

images or XMLHttpRequest, in order to ﬁnd active

nodes based on timing thresholds (Hazhirpasand and

Ghafari, 2018). In this scenario, however, the victim

employs a secure VPN connection wherein no private

IP leakage occurs and WebRTC returns the real pub-

lic IP address of the victim. As a result, the attacker

must execute preliminary IP scanning to discover the

victim’s private IP range. Finding the private IP range

can dramatically decrease the success rate of the at-

tack provided that the network administrator sets an

uncommon range of private IP addresses, e.g., ad-

dresses in the IPv4 class A.

In our experiment, we scanned 400 common pri-

vate IP address ranges used by popular routers or net-

work administrators in 40 seconds. When the pri-

vate range is found, the JavaScript program starts to

scan the entire range (1-255), ﬁnd active nodes, and

send the private IP addresses of the active nodes back

to the server. In this scenario, the attacker sets the

IP address of the PWS on the server’s custom DNS

server. Afterward, the malicious page starts fetching

the http://attacker.xyz/ website every 500 millisec-

onds in the background. In our experiment, it took

71 seconds in the Firefox browser to fetch the new

DNS information. This delay in fetching the new IP

address was due to the existence of the DNS pinning

feature in browsers. In addition, the same-origin pol-

icy did not complain as the domain name remained

the same. The malicious website was then allowed

to send POST and GET requests to the PWS web in-

terface. For example, the attacker was able to send a

GET request to turn off the auto watering system.

The failure in the OpenDNS service and the ﬁre-

wall in detecting the attack can be explained by the

fact that the VPN connection encrypts all the trafﬁc

and that DNS server of the VPN server resolves the

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

598

attacker’s website. Moreover, we observe that if the

user spends nearly 2 minutes on the malicious web

page, the existing countermeasure on the browsers

will lose its efﬁcacy.

3 EXISTING MEASURES

We now introduce and assess how the widely-known

preventive techniques provide inadequate safety for

users. We classiﬁed the proposed solutions into

two broad categories, namely browser-based and

server/network-based solutions. Table 2 provides an

overview of existing preventive solutions and their

drawbacks. In the following, we discuss each of them

in detail.

3.1 Browser-based Solutions

Browsers implement the DNS pinning approach to

block DNS rebinding attacks. DNS pinning protects

both private and public nodes but for a short period.

They cache the IP address of the hostname for a ﬁxed

period when it is loaded. However, browsers cannot

keep such information for a long duration as web ap-

plications may need to switch to another server due

to various reasons, e.g., the denial of service attack or

load balancing. Consequently, they update their cache

after a short period, ranging from several seconds to

minutes. Table 1 presents the average required time to

conduct a successful DNS rebinding attack on differ-

ent browsers. We performed an experiment for each

browser ten times, and employed the FakeDNS server

script.

Despite the short period for DNS pinning, attack-

ers used creative approaches to successfully circum-

vent DNS pinning in browsers. Dai et al. dissected

DNS pinning in order to ﬁnd a way to shorten the

ﬁxed period in browsers (Dai and Resig, 2013). They

exploited DNS pinning by ﬂooding the DNS cache

table on the victim’s browser with numerous invalid

entries to persuade the browser to do a second DNS

lookup. Their tool, called FireDrill, utilizes a Web-

Socket connection to enable the attacker to have an

interactive session with the victim’s browser. Jackson

et al. in a study suggested a number of defenses for

the socket access policies in Flash Player, Silverlight,

and JVM (Jackson et al., 2009). Their solutions were

adapted by Adobe, Microsoft, and Sun in order to pro-

vide a secure socket level access for plugins.

The pinning can be extended with heuristics to en-

hance its defense level. For instance, browsers can

https://github.com/pathes/fakedns

Table 1: Average time of a successful DNS rebinding attack

on different browsers.

Browser Version OS Avg time

Google Chrome 81 Windows 10 2:05s

Chromium 80 Kali Linux 2:11s

Mozilla Firefox 75 Windows 10 1:15s

Mozilla Firefox 68 Kali Linux 1:43s

enforce a policy to allow hostnames to rebind to any

IP addresses within a /24 network, e.g., attacker.xyz

with an IP address of 190.145.12.22 can rebind to

any address with the range 190.145.12.X. Incorporat-

ing such IP-based origins into browsers might have

negative consequences for real-time web applications

whose JavaScript WebSocket or long polling runs for

a long period and might switch to other servers due

to a failover. Unfortunately, since many distributed

DNS services, e.g., Cloudﬂare, have servers across

continents, it adversely affects the trade-off between

availability and security. Furthermore, each browser

currently uses a separate pin database to store DNS

replies. Having a centralized pin database can reduce

the collaborative effort among different browsers to

build a comprehensive defense measure against DNS

rebinding attacks.

A browser-level solution to DNS rebinding is the

NoScript plug-in for the Firefox browser.

This

plug-in is intended to shield users from DNS re-

binding attacks against private nodes. Released in

2005, the plug-in protects users against web-based

attacks such as XSS, CSRF, clickjacking, man-in-

the-middle, and DNS rebinding attacks. The plug-in

blocks any scripts including JavaScript, Java, Flash

and Silverlight by default in Firefox. In our experi-

ment, when we enabled JavaScript on the attacker’s

website, the plug-in did not detect any incoming DNS

rebinding attacks. Consequently, we found this tool

not suitable for day-to-day browsing as it completely

blocks a website’s JavaScript to protect users, which

considerably reduces the functionality of the website.

Johns et al. extend SOP (named eSOP) for the

Chromium Web browser to defend users from DNS

rebinding attacks, and they describe how to utilize the

HTML5 Ofﬂine Application Cache to carry out a re-

liable DNS Rebinding attack (Johns et al., 2013). In

their proposal, a dedicated HTTP server response (X-

Server-Origin) is introduced to transfer the server ori-

gin property in the form of a comma-separated list.

When the attacker sends a request to the victim ma-

chine, eSOP checks the X-Server-Origin header of the

victim and marks the communication as invalid due

to inequality of the attacker’s domain name and the

victim’s server origin, even though the classic (proto-

col/domain/port) SOP is satisﬁed.

https://noscript.net/

Stopping DNS Rebinding Attacks in the Browser

599

Table 2: Preventive measures for DNS rebinding attacks and their drawbacks.

Approach Type Drawbacks

DNS pinning Browser Limited pinning time, can be shorten by DNS ﬂooding

DNS pinning -

Extended IP check

Browser

Not applicable in real world scenarios and impose

many limitations

A centralized pin

database

Browser

Necessitates of collaboration between OS and browser

vendors

NoScript plug-in Browser Blocks all javascript contents in a website

eSOP Browser Requires a server header, a custom browser, cannot detect IP/port scanning

INP Browser Requires implementation in browsers, and no detection for IP/port scanning

Brahmasani et al OS - Network Encrypted packets cannot be read - can be only used by desktop computers

dnswall Network Encrypted packets cannot be read

Host header Server Requires manual work, knowledge of hostname, erroneous implementation

Security Proxy Network Lack of implementation, and high overhead

SSL Server

Requires SSL on all nodes, problematic for programs with an invalid SSL

OpenDNS / Dnsmasq Network Encrypted packets cannot be read

Similarly, Afek et al. present a prevention mech-

anism, called Internal Network Policy (INP), to stop

three common attacks including DNS rebinding at-

tacks (Afek et al., 2019). In general, INP acts as a

new browser security policy by preventing access to

internal resources from external entities. They em-

phasize that INP is complementary to SOP, as SOP

only considers cross-origin access and overlooks IP

addresses. They implement a proof-of-concept (PoC)

of INP in the Chromium web browser. They extract IP

addresses after any required DNS resolution, just be-

fore the request is about to be made. In case the desti-

nation IP address has not yet been resolved, there is a

small chance that the DNS rebinding attack can take

place. Their comparison with eSOP reveals that INP

delivers better security as eSOP is incapable of pro-

tecting home routers or machines that are vulnerable

to remote command execution.

3.2 Network-based Solution

Brahmasani et al. propose a two-level defensive solu-

tion analyzing all incoming packets on DNS port (i.e.,

53) (Brahmasani and Sivasankar, 2013). First, they

compare the hostname associated with the canonical

name of each reverse DNS lookup with the original

domain name, and in the second level they check the

HTTP response content of each IP address returned

by the DNS response. However, the solution suf-

fers from the same drawback associated with the en-

crypted packets when the victim uses a VPN connec-

tion.

Bortz et al. propose a remedy to the DNS rebind-

ing problem. They introduce and implement an open-

source DNS resolver, called dnswall, to prevent ex-

ternal hostnames from resolving to an internal IP ad-

dress. The implementation is included in FreeBSD.

https://svnweb.freebsd.org/ports/head/dns/dnswall/

Subsequently, similar means of defense are imple-

mented in other open-source ﬁrewall projects such

as Dnsmasq, OpenWrt, DD-WRT (Fainelli, 2008).

Software ﬁrewalls can also block DNS resolutions to

the loopback interface but this defense is not adequate

as services bind to other network interfaces. Both de-

fensive measures can be inadvertently circumvented

by the victim when using a VPN connection. Fur-

thermore, restricting access to private IP ranges, as

deﬁned in RFC 1918 (Rekhter et al., 1996), is not

necessarily a comprehensive solution. This is due to

the fact that large companies or universities do not al-

ways use RFC 1918 addresses for their internal nodes.

Craig Heffner explained that the attacker can use DNS

rebinding to gain access to private nodes in a local

network, if such machines are conﬁgured both on a

private and a public IP address (Heffner, 2010).

An semi-robust obstacle to DNS rebinding attacks

is to compare the HTTP host header. In DNS rebind-

ing, the attacker cannot spoof a fake host header and

accordingly, the victim’s web application/server is

able to check whether the host header is consistent

with the address of the requested website. This

technique requires developers or server managers to

manually add the security check to their either web

application or web server (See Listing 1). Notably,

security checks can be error-prone or implemented

incompletely on servers with many hostnames, which

allows the attacker to access a subset of the victim’s

data. This technique cannot be employed on servers

or applications with no prior knowledge of their

hostname. Lastly, this technique provides partial

robustness and safety as the attacker can still trigger

request and receive the response from the target

server. This may result in some valuable data leaks

regarding the target defensive strategies.

https://dd-wrt.com/

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

600

Listing 1: The host header check in the entire application.

if ( $ SERVER[

HTTP HOST

] == ”localhost”) {

// Application code runs

} else {

echo ”Something is wrong”;

}

Pandiaraja et al. propose a defensive system,

called Security proxy, through the use of the Ad-

vanced Encryption Standard encryption algorithm

and a hash function (Pandiaraja and Parasuraman,

2015). The Security proxy system provides a secure

environment for DNS queries to be securely commu-

nicated. However, the proposed system is not eval-

uated from the security, performance or feasibility

point of view.

A website can protect itself from being targeted by

DNS rebinding attacks by having an SSL certiﬁcate

on the server side. When an attacker attempts to bind

attacker.xyz to the IP address of a website secured

with SSL, browsers consider the certiﬁcate invalid

due to the mismatched domain name (attacker.xyz).

As a result, once the new IP is set, the background

JavaScript code cannot fetch the source code of the

target website and receives HTTP 302 Found redi-

rect status. In our analysis, browsers return a warning

page indicating the SSL certiﬁcate is not trusted, and

fortunately, the attacker cannot dismiss this error mes-

sage programmatically. We also realized that having

a signed or self-signed certiﬁcate has the same pre-

ventive effect on halting the DNS rebinding attack.

Importantly, SSL can be ineffective when the web

server does not force SSL on all incoming connec-

tions. A recent study has shown that a large number

of websites do not enforce the usage of digital sig-

natures (Van Goethem et al., 2014). This leaves the

opportunity open for attackers to conduct DNS re-

binding attacks aimed at public nodes. Our ﬁnding

conﬁrms that using either the .htaccess ﬁle or HTTP

Strict Transport Security (HSTS) is mandatory. How-

ever, misconﬁguring the HSTS response header in a

way that the web server only returns the header with-

out forcing HTTP to HTTPS connections would ren-

der it ineffective. We examined commonly used web

servers or server software with default conﬁgurations

to observe whether any software forces the use of

HTTPs (See Table 3). The results offer compelling

evidence that no evaluated software forces users to

use a digital certiﬁcate. Furthermore, users might

consider forcing HTTPS over HTTP unnecessary in

a private network.

In Tatang et al. experiment, the Teltonika RUT500

router is capable of detecting DNS rebinding attacks

owing to the activation of the DNS rebinding protec-

tion in Dnsmasq (Tatang et al., 2019). Nevertheless,

Table 3: Forcing to use SSL in different web servers and

server software.

Web server Version Operation System Forced SSL

XAMPP 7.2.33 MacOS No

XAMPP 7.2.33 Windows 10 No

WampServer 3.2.0 Windows 10 No

IIS 10 Windows 10 No

XAMPP 7.2.3 Kali Linux No

LAMP 7.3.2 Kali Linux No

Apache 2.4.41 Kali Linux No

Ngnix 1.16.1 Kali Linux No

they noticed that the user’s localhost is still vulnera-

ble. Similar to OpenDNS, Dnsmasq is unable to de-

tect the attack when the victim uses a VPN connec-

tion.

Lastly, in the preceding approaches, we notice that

network-based solutions require administrative work,

expert knowledge, and their robustness is question-

able, e.g., the SSL method or Host header. On the

other side, browser-based approaches offer a better

level of security, e.g., INP or eSOP.

4 FAIL-REBIND

The aim of this section is to introduce our proposed

approach for halting DNS rebinding attacks and com-

pare our approach with preceding approaches. Given

the lack of robust protection in widely-used browsers,

we have developed a plug-in, named Fail-rebind, for

the Chrome and Firefox browsers

. DNS rebinding

is launched on browsers, even though it goes through

all network devices, e.g., ﬁrewalls, routers. Layers

of encryption render packet inspection infeasible at

the network. On the other hand, analyzing requests

on browsers to halt DNS rebinding is fast and not

complicated, which can beneﬁt the user regardless of

the customized network devices. In the following,

we ﬁrst explain Fail-rebind’s approach in order to de-

tect and halt DNS rebinding attacks, and then evalu-

ate its effectiveness in two different scenarios as well

as comparing Fail-rebind with preceding approaches,

discussed in section 3.

4.1 Approach

We used the web request API in Chrome and Fire-

fox in order to observe and analyze the trafﬁc of each

tab in real-time. The API works similarly and has

a common life cycle for a successful request in both

browsers. Fail-rebind employs the following three

events:

https://github.com/Microsvuln/DNS-Rebinding-

Attack-Prevention

Stopping DNS Rebinding Attacks in the Browser

601

Yes

Is in whitelist?

onHeadersReceived

Yes

Against rule?

Yes

Is the IP addr

against rule?

onHeadersReceived

Yes

Is the IP addr

against rule?

Website loaded

onBeforeRequest

Blocked page -

Blacklist the URL

Figure 2: The Fail-rebind’s workﬂow.

— onBeforeRequest: This event is ﬁred when a re-

quest is about to be made, which can be blocked

or redirected.

— onHeadersReceived: This event is ﬁred when an

HTTP(S) response header is received and enables

extensions to add, modify, and delete response

headers. Canceling a request is possible in this

event.

— onResponseStarted: This event is triggered when

the ﬁrst byte of the response body is received. In

this event, modifying and canceling the request is

not possible.

Figure 2 depicts the workﬂow of the Fail-rebind

plug-in. Fail-rebind consists of two components,

namely IP scanning, and DNS rebinding detection.

The IP scanning component ﬁrst detects every attempt

at private IP scanning. The user is able to whitelist his

trusted local domains; therefore, the IP scanning de-

tection module ensures that requests are initiated from

untrusted domains and do not point to any private IP

ranges. If such requests are to be made, they will be

blocked in the onBeforeRequest event and the corre-

sponding website will be blacklisted.

To stop DNS rebinding attacks, we must obtain

the IP address of a request alongside its domain name.

This is accomplished slightly differently in the two

browsers due to the behavior of the web request API.

In Chrome, the IP address of a request can be obtained

in the onResponseStarted event, while in Firefox it

is in the onHeadersReceived event. If the obtained

IP address complies with private IP range rules, the

Table 4: Comparison between fail-rebind and other ap-

proaches.

Desktop

mobile

No Expert

Knowledge

Network

independent

Location

independent

Fail-rebind 3 3 3 3

SSL 3 5 5 5

HTTP Header 3 5 5 5

Security Proxy 3 5 5 5

dnswall 3 5 5 5

Brahmasani et al 5 5 5 5

eSOP 5 3 3 3

INP 5 3 3 3

corresponding tab will be redirected to a custom block

page and the website will be blacklisted.

4.2 Evaluation

To evaluate Fail-rebind, we assess the two plausible

scenarios explained in subsection 2.2. We arm the

Firefox browser with the Fail-rebind plug-in and navi-

gate to the malicious website, i.e., attacker.xyz. Given

that a VPN is used by the user, the malicious website

needs to scan private IP address ranges. When at-

tacker.xyz establishes the ﬁrst request to 192.168.0.1,

Fail-rebind evaluates the request in the onBefor-

eRequest event. As the website and its request are

not in the whitelist, Fail-rebind blocks the request and

adds the website to its blacklist. Finally, the user is

informed of the attack and access to the website is de-

nied.

In another scenario, our assumption is that the at-

tacker.xyz website is already aware of the user’s pri-

vate IP address range. Therefore, the IP address of

the PWS system (i.e., 192.168.10.5) is set as the sec-

ond IP address on the attacker’s DNS server. When

the malicious page establishes continuous requests to

attacker.xyz to defeat DNS pinning in Firefox, Fail-

rebind checks each request’s IP address in the on-

HeadersReceived event. The moment Firefox re-

ceives the new IP address (i.e., 192.168.10.5), Fail-

rebind evaluates the IP address against the built-in

rules. As the received IP address is private, Fail-

rebind blocks the request, blacklists the attacker.xyz

address, and warns the user with a customized er-

ror page. Similar to other existing measures, our ap-

proach can afford protection against DNS rebinding

attacks targeted only at private nodes (ﬁrewall cir-

cumvention) not at public nodes (explained in sub-

section 2.1). We compared Fail-rebind to other ap-

proaches from four signiﬁcant perspectives, explained

in Table 4. The major advantage of our proposed so-

lution is its location-independence compared to some

of the previous methods, e.g., SSL, HTTP header, and

dnswall. This feature allows for abundant ﬂexibility

in surﬁng websites in any location without jeopardiz-

ing the private network’s nodes. Moreover, our pro-

tection mechanism as well as other approaches. e.g.,

ICISSP 2021 - 7th International Conference on Information Systems Security and Privacy

602

SSL, can provide safety for users both in mobile and

desktop browsers. However, in many scenarios, the

victim cannot request all the nodes in their private net-

work to install SSL on their websites but Fail-rebind

protects the victim irrespective of the security of the

nodes in the internal network. A major advantage of

using browser-based solutions, including Fail-rebind,

eSOP, and INP, is that they do require neither ex-

pert knowledge nor special network devices to be in

place. Lastly, however, a user may prefer browsers

where plug-in development is not yet supported, and

accordingly, the user’s activity on one platform may

still have deleterious effects on its network’s nodes.

We also contacted the Firefox developers and shared

our ﬁndings. We have discussed possible solutions for

implementing our prototype as a preventive measure

inside the browser.

5 CONCLUSION

As far as user privacy is concerned, the importance

of halting the DNS rebinding attack cannot be over-

stated. We ﬁrst showed that this attack can adversely

affect internal nodes. Then, we evaluated the current

prevention systems and discussed their weaknesses.

We also proposed a browser-based plug-in for two

popular browsers, i.e., Chrome and Firefox. Our ap-

proach functions perfectly under an encrypted con-

nection, detects DNS rebinding attacks at its initial

stages, and does not suffer from the drawbacks of pre-

vious systems. However, as the proposed solution is

a browser-speciﬁc solution, a similar approach needs

to be developed and incorporated into browsers as an

internal component.

ACKNOWLEDGMENT

We gratefully acknowledge the ﬁnancial support

of the Swiss National Science Foundation for the

project “Agile Software Assistance” (SNSF project

No. 200020-181973, Feb. 1, 2019 – April 30, 2022).

REFERENCES

Afek, Y., Bremler-Barr, A., and Noy, A. (2019). Eradicating

attacks on the internal network with internal network

policy. arXiv preprint arXiv:1910.00975.

Brahmasani, S. and Sivasankar, E. (2013). Two level ver-

iﬁcation for detection of DNS rebinding attacks. In-

ternational Journal of System Assurance Engineering

and Management, 4(2):138–145.

Dai, Y. and Resig, R. (2013). FireDrill: Interactive DNS

rebinding. In Presented as part of the 7th USENIX

Workshop on Offensive Technologies.

Dean, D., Felten, E. W., and Wallach, D. S. (1996). Java

security: From HotJava to Netscape and beyond. In

Proceedings 1996 IEEE Symposium on Security and

Privacy, pages 190–200. IEEE.

Fainelli, F. (2008). The OpenWrt embedded development

framework. In Proceedings of the Free and Open

Source Software Developers European Meeting, page

106. sn.

Hazhirpasand, M. and Ghafari, M. (2018). One leak is

enough to expose them all. In International Sympo-

sium on Engineering Secure Software and Systems,

pages 61–76. Springer.

Heffner, C. (2010). Remote attacks against SOHO routers.

Blackhat USA.

Jackson, C., Barth, A., Bortz, A., Shao, W., and Boneh, D.

(2009). Protecting browsers from DNS rebinding at-

tacks. ACM Transactions on the Web (TWEB), 3(1):1–

26.

Johns, M., Lekies, S., and Stock, B. (2013). Eradicating

DNS rebinding with the extended same-origin policy.

In Presented as part of the 22nd USENIX Security

Symposium (USENIX Security 13), pages 621–636.

Lalia, S. and Moustafa, K. (2019). Implementation of web

browser extension for mitigating CSRF attack. In

World Conference on Information Systems and Tech-

nologies, pages 867–880. Springer.

Pandiaraja, P. and Parasuraman, S. (2015). Applying secure

authentication scheme to protect DNS from rebind-

ing attack using proxy. In 2015 International Confer-

ence on Circuits, Power and Computing Technologies

[ICCPCT-2015], pages 1–6. IEEE.

Rekhter, Y., Moskowitz, B., Karrenberg, D., Groot, G. d.,

and Lear, E. (1996). Rfc1918: Address allocation for

private internets.

Tatang, D., Suurland, T., and Holz, T. (2019). Study of DNS

rebinding attacks on smart home devices. In Computer

Security, pages 391–401. Springer.

Van Goethem, T., Chen, P., Nikiforakis, N., Desmet, L., and

Joosen, W. (2014). Large-scale security analysis of the

web: Challenges and ﬁndings. In International Con-

ference on Trust and Trustworthy Computing, pages

110–126. Springer.

Stopping DNS Rebinding Attacks in the Browser

603
