SciModeler: A Metamodel and Graph Database for Consolidating

Scientiﬁc Knowledge by Linking Empirical Data with Theoretical

Constructs

Raoul Nuijten

and Pieter Van Gorp

School of Industrial Engineering, Eindhoven University of Technology, Eindhoven, The Netherlands

Keywords:

Metamodel, Scientiﬁc Method, Theory-building, Software Tool, Graph Database, Health Behavior Change.

Abstract:

An important purpose of science is building and advancing general theories from empirical data. This process

is complicated by the immense volume of empirical data and scientiﬁc theories in some ﬁelds. Particularly,

the systematic linking of empirical data with theoretical constructs is currently lacking. Within this article, we

propose a prototypical solution (i.e., a metamodel and graph database) for consolidating scientiﬁc knowledge

by linking theoretical constructs with empirical data. We conducted a case study within the ﬁeld of health

behavior change where the system is used to record three scientiﬁc theories and three empirical studies as well

as their mutual links. Finally, we demonstrate how the system can be queried to accumulate knowledge.

1 INTRODUCTION

Over time, the scientiﬁc method has proven to be an

efﬁcient strategy for accumulating knowledge. This

theory-building process serves to differentiate science

from common sense (Reynolds, 1971). The process

starts with an inductive phase, in which hypotheses

are formed from observations and original theories.

These hypotheses are evaluated empirically and then

either accepted, or rejected. Subsequently, in a de-

ductive phase, empirical data is interpreted to reﬁne

the original theory. Knowledge has accumulated, and

the cycle can repeat itself.

Of course, in some domains, many different–but

related–theories exist for explaining the same phe-

nomenon. Still, if we assume the existence of a

ground truth, these theories will at some point con-

verge to the same equilibrium, if these theories con-

tinue to be reﬁned according to the scientiﬁc method.

However, this may be a rather time-consuming pro-

cess, since especially the execution of empirical stud-

ies and the interpretation of empirical data to reﬁne

original theories tends to take quite some time.

The execution of empirical studies seems hard

to accelerate, but the reﬁnement of original theories

based on empirical data can be advanced by interpret-

ing the results of related empirical studies that were

https://orcid.org/0000-0003-0125-7708

https://orcid.org/0000-0001-5197-3986

performed by others. Of course, scholars have reﬁned

their own theories based on related empirical data for

ages. However, the process is highly redundant and

scarce resources are often spent inefﬁciently in dis-

connected scientiﬁc communities. Especially since

the volume of literature keeps growing at an increas-

ing rate, there is a need to automate literature reviews.

Furthermore, automated reasoning across theories is

critical, not only to analyze results beyond one the-

ory, but also to explore opportunities for merging and

simplifying such theories.

Advances in Natural Language Processing (NLP)

and Machine Learning (ML) have enabled the auto-

mated construction of semantic models from scien-

tiﬁc articles (Tauchert et al., 2020). However, such

approaches build models that are relatively close to

the terminologies of scientiﬁc disciplines. At the

same time, critical details regarding the experimen-

tal setups underneath empirical studies are often lost

in the model-building process. That limits opportu-

nities for reliably combining empirical studies into

more generic theories across scientiﬁc communities.

We do acknowledge that signiﬁcant results have been

achieved already, as evidenced also by commercial

tools such as IBM Watson™ Insights for Medical Lit-

erature (IML) but to the best of our knowledge, it was

not yet studied how one can encode in a transparent

knowledge representation: 1) what exactly makes up

a scientiﬁc theory, and 2) how exactly empirical stud-

ies support or refute one or more theories.

314

Nuijten, R. and Van Gorp, P.

SciModeler: A Metamodel and Graph Database for Consolidating Scientiﬁc Knowledge by Linking Empirical Data with Theoretical Constructs.

DOI: 10.5220/0010315503140321

In Proceedings of the 9th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2021), pages 314-321

ISBN: 978-989-758-487-9

We have encountered this general problem in the

speciﬁc discipline of health behavior change, where a

staggering number of theories have been developed

within communities like behavioral economics and

various subbranches of psychology. While promis-

ing work is being carried out to standardize on the

terminology, the ﬁeld still struggles with too large

taxonomies, with too overlapping constructs (Michie

et al., 2014; Davis et al., 2015; Eldredge et al., 2016).

The result is that empirical studies are poorly coded,

which hampers theory consolidation.

This article presents SciModeler, a metamodel and

graph database to: 1) encode scientiﬁc theories in a

semantic structure; 2) record the outcomes of empiri-

cal studies and their relation to theoretical constructs;

3) query across theories and empirical data to explore

latent relationships; and 4) identify opportunities for

simplifying theories via graph transformations.

The next section surveys literature on the key con-

cepts in scientiﬁc theories and empirical studies in or-

der to identify which elements need to be covered by

the metamodel. The third section details the meta-

model that addresses these requirements. In the fourth

section we assess the potential value of the system in

the ﬁeld of health behavior change. We conducted a

case study where the system was used to record three

scientiﬁc theories and three empirical studies as well

as their mutual links. Subsequently, we demonstrate

how the system can be queried to accumulate knowl-

edge. Finally, we discuss the principal results and

weaknesses from this exercise, and provide guidelines

for future work.

2 REQUIREMENTS

2.1 Components of a Scientiﬁc Theory

A theory comprises a set of abstract statements about

reality (Reynolds, 1971). Hence, informal explana-

tions, unfalsiﬁable statements and ideas are impor-

tant but they are not scientiﬁc theories (Popper, 1959,

p. 23). Instead, in a “theoretical system”, “theoret-

ical constructs” are introduced “jointly” (i.e., asso-

ciated to each other) (Hempel, 1952, p. 32), such

that a natural phenomenon and its antecedents are ex-

plained and their relations can be repeatedly tested

and veriﬁed. For this study, we have assumed that

a scientiﬁc theory comprises constructs, and the re-

lationships between these constructs. While some

related works proposed to model theories as claims

within separate models of individual articles (Cic-

carese et al., 2008; Clark et al., 2014), we explored a

graph-based approach where theoretical elements are

modeled centrally and supportive pieces of empirical

data are linked to them.

2.2 Components of an Empirical Study

Several frameworks for developing and reporting em-

pirical studies have proven valuable over time. Partic-

ularly, these frameworks have been used to assist the

deﬁnition of research questions, as well as system-

atic literature surveys (Cooke et al., 2012). Especially

the PICO framework is commonly used in evidence-

based practice (e.g., in Evidence-Based Medicine).

This framework suggests that a well-deﬁned empir-

ical study comprises: 1) a population; 2); an inter-

vention; 3) a comparison; and 4) an outcome. Simi-

lar frameworks were coined to be applied to different

research ﬁelds. For example, the PECO (i.e., Popu-

lation, Exposure, Comparator, and Outcomes) frame-

work was tailored for environmental, public and oc-

cupational health research (Morgan et al., 2018); the

SPICE (Setting, Perspective, Intervention, Compar-

ison, and Evaluation) framework was introduced to

support qualitative research (Booth, 2006), as well as

the SPIDER (Sample, Phenomenon of Interest, De-

sign, Evaluation, Research type) framework (Cooke

et al., 2012); and lastly the ECLIPSE (Expectation,

Client group, Location, Impact, Professionals, Ser-

vicE) framework was introduced to support the ﬁeld

of health management (Wildridge and Bell, 2002).

Across these frameworks, one can identify:

The Population: refers to the community that is tar-

geted within a study (e.g., Dutch high school stu-

dents, or older adults at risk of being overweight,

etc.). This concept is also referred to as the Patient

group, Sample, Perspective, or Client group.

The Setting: (or Location & Timing) describes when

and where an intervention was evaluated (Booth,

2006).

The Expectation: (from ECLIPSE, corresponding

to the Outcome from PECO or the Evaluation of

SPIDER) is the end point of interest. Once this

dependent variable is known, the impact of stud-

ies addressing a similar outcome variable can be

compared. Note that careful recording of this

outcome variable is necessary, as a variable can

sometimes be measured in different ways.

The Intervention: (or Phenomenon of Interest, Pro-

fessionals & Service) indicates the object that is

studies and that is expected to cause a difference

(e.g., the administration of a medical drug).

The Comparison: (or PECO’s Comparator, or SPI-

DER’s Design) is measured against the interven-

tionOften, the comparator is a different interven-

SciModeler: A Metamodel and Graph Database for Consolidating Scientiﬁc Knowledge by Linking Empirical Data with Theoretical

Constructs

315

tion or treatment, or alternatively the absence of

an intervention or treatment.

The Impact: (from ECLIPSE, corresponding to the

Evaluation from SPICE) describes what results

the evaluation yielded (Booth, 2006).

The Research Type: (from SPIDER) captures the

study design that was adopted to evaluate the in-

tervention (Cooke et al., 2012).

2.3 Deriving Modeling Requirements

From Section 2.1, one can conclude that theories con-

sist of constructs and relations. While previous for-

malisms already support the encoding of claims of

individual articles, it is worth representing theories

as ﬁrst-class modeling concepts, which can be linked

from individual studies. Regarding the coding of em-

pirical studies, various formalisms have already been

proposed. However, the systematic linking of empir-

ical data with theoretical constructs is lacking. In or-

der to overcome these limitations, we propose a new

metamodel that has two layers: The ﬁrst layer should

support the encoding of scientiﬁc theories (ST) and

the second layer should support the encoding of em-

pirical studies (ES). While the requirements for each

distinct layer follows reasonably simply from Sec-

tions 2.1 and 2.2, we learned that especially the link-

ing of the two layers is non-trivial.

For layer ST, we identiﬁed three information re-

quirements, aimed at representing theories as graphs:

ST1 Record the name of the theory,

ST2 Record the primitive constructs of the theory,

ST3 Record the relations between these constructs.

For layer ES, our synthesis of Section 2.2 leads to:

ES1. Record the (characteristics of) the study pop-

ulation and study sample (i.e., to whom?)

ES2. Record the setting (i.e., place and time) of the

study (i.e., where, and when?)

ES3. Record the expectation of the study (i.e.,

why?)

ES4. Record the interventions and comparison

treatments (i.e., what? what else?)

ES5. Record the impact of the interventions and

treatments on the study sample (i.e., how

well?)

ES6. Record the research type (i.e., how?)

Regarding the interlinking of these two layers, one

would ultimately like to see how speciﬁc elements

of an empirical study relate to speciﬁc elements of

a theory. Regrettably, many empirical studies only

label interventions at the aggregate level of theories.

From our modeling requirements point of view, we

therefore need to support both ways of linking the

empirical layer with the theoretical layer. Further-

more, concrete interventions in empirical studies can

be coded differently according to one’s point of view

(even when aiming to minimize subjectivity). We will

illustrate this challenging issue by means of a case

study in Section 4 but regarding modeling require-

ments, we conclude here that there is a need to sup-

port competing classiﬁcations and leave it up to the

scientiﬁc discourse to decide which classiﬁcation is

the best for a speciﬁc purpose.

ES→ST1. Record the relation between a theoretical

construct and an actual intervention

ES→ST2. Record the argumentation for why this

relation is appropriate

ES→ST3. Record the number of ‘votes’ for a sug-

gested relation

The metamodel presented in the next section is a ﬁrst

attempt to satisfy all requirements that were identiﬁed

thus far.

3 SciModeler: METAMODEL AND

TOOL

3.1 Metamodel

The SciModeler metamodel is distributed via

Figshare (Nuijten and Van Gorp, 2020c). The colored

rectangles in the background demonstrate what

particular requirement is fulﬁlled by the rectangle’s

enclosed entities, attributes and associations.

The orange rectangle captures the entities, at-

tributes and associations that were necessary to sat-

isfy the requirements at layer ST. Particularly, to:

1) record the name of a theoretical framework us-

ing the theory entity [ST1]; 2) record the constructs

within a theoretical framework using the construct en-

tity [ST2]; and record the relations between the con-

structs of a theoretical framework via the relation en-

tity [ST3]. The relation entity has a type attribute that

can have the values: has an inﬂuence on, has a pos-

itive inﬂuence on, has a negative inﬂuence on, is a

component of, and is synonym of.

The blue rectangles depict the entities, attributes

and associations that were necessary to satisfy the re-

quirements at layer ES.

First, the entities population, sample, group, in-

dividual, demographic and characteristic are neces-

sary to record with whom a particular intervention

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

316

was evaluated [ES1]. The population entity captures

information about the audience that was targeted for a

speciﬁc study. The sample entity records ho many

subjects from this population have actually partici-

pated in the study. The group entity distinguishes the

number of participants that were exposed to a spe-

ciﬁc treatment. The demographic entity can be used

to collect additional information about these groups

on different variables. For example, this entity, its at-

tributes and associations, may be used to record that

the average age of a sample was 27. In that scenario,

age is the dimension of the variable associated to the

demographic, the aggregation function of the demo-

graphic is average, and the value of the demographic

is 27. Note that the actual ages (i.e., recorded as char-

acteristics) of the individuals within the sample may

nevertheless be undisclosed.

Second, the context entity is used to record where

and when a study was executed [ES2]. For example, a

study may be executed at a high school (i.e., location)

during the winter of 2018 (i.e., timing).

Third the experiment entity records the rationale

behind a study [ES3]. Particularly, the point of inter-

est, or outcome variable is recorded.

Fourth, the entities treatment, treatment assign-

ment, intervention and platform are used to record

what treatments were assigned, and how these com-

pare to each other [ES4]. The intervention entity

records particularities that are present within all treat-

ments, whereas the treatment entity only records par-

ticularities that are unique for a speciﬁc treatment.

The platform entity can be used to emphasize that

a set of interventions relies on shared infrastructure.

For example, a marketing intervention may be admin-

istered via a phone call, and different interventions

may use similar infrastructure. As an example from

the software engineering domain, the Eclipse frame-

work could be a platform on which an empirical study

on plug-in development could be based. Lastly, the

entity treatment assignment can be used to assign a

particular treatment to a group of participants.

Fifth, the entity outcome records the impact of a

speciﬁc treatment [ES5]. Particularly, by capturing

the treatment result and the signiﬁcance of that result.

Sixth, the entity source is used to record the scien-

tiﬁc article that describes the research method under-

pinning one or more experiments [ES6].

Finally, the yellow rectangle captures the entities,

attributes and associations that are used to map em-

pirical data onto theoretical constructs (i.e., linking

layer ES and layer ST). The classiﬁcation entity can

be used to associate (parts of) a particular intervention

or treatment with a theoretical construct [ES→ST1].

Since this step relies on interpretation, an explanation

from a reviewer is required [ES→ST2]. Other review-

ers can support a given classiﬁcation, or commit their

own [ES→ST3].

3.2 Recording Data

To instantiate the class diagram and store data, we

have adopted a graph-based approach. A graph-based

approach was chosen, for its ﬂexibility, and extensive

coverage of database systems. Particularly, we have

used Neo4j v4.1.3 to deﬁne the type graph, store ex-

ample instances and evaluate queries, partly because

Neo4j provides extensive tools for visualizing data

and query results as an actual graph.

To record a scientiﬁc theory, or empirical study, a

reviewer would have to examine the original research

article presenting the theory or study. After a reviewer

examined the article, she can write a set of statements

(e.g., using Cypher, Neo4j‘s graph query language) to

commit the theory or study to the database.

For documenting a scientiﬁc theory this exercise

is generally relatively easy, as these theories are often

already visualized as graphs with constructs and rela-

tions. Nevertheless, the exercise of extracting the cor-

rect information from an article presenting an empiri-

cal study may be somewhat more challenging, as the

data is often presented in a mere text-based form. In

order to reliably extract empirical data, we have estab-

lished a workﬂow in which a reviewer can highlight

a particular passage in the PDF-version of the article

that details a certain attribute she wants to record (e.g.,

the sample size that was studied). These quotations

are also recorded in the database such that the source

of a piece of empirical data can easily be traced back

to the original article. Additionally, the data sets that

were obtained within an empirical study are typically

not shared at the individual participant level. Hence,

speciﬁc information about the characteristics of par-

ticular individuals, or the impact the intervention has

had on a particular individual are mostly not revealed

in scientiﬁc outlets. Note that therefore, the entities,

attributes and associations that are displayed below

the red dotted line in the class diagram (Nuijten and

Van Gorp, 2020c) are included for completeness, but

are known to be difﬁcult to extract from most research

articles. Then again, future articles on empirical stud-

ies may cite SciModeler instances as online attach-

ments that document the study setup with greater pre-

cision.

SciModeler: A Metamodel and Graph Database for Consolidating Scientiﬁc Knowledge by Linking Empirical Data with Theoretical

Constructs

317

4 CASE STUDY

4.1 Health Behavior Change as Context

Particularly in the ﬁeld of health behavior change

many scientiﬁc theories are circulating. Still, there

is no consensually agreed theory of health behavior

change. Moreover, the process of developing a con-

sensually agreed theory seems to be rather inefﬁcient

in this ﬁeld, as empirical studies are originating from

unique–but related–theories, without systematically

contributing to each other.

The aim of this case study is to demonstrate how

SciModeler can facilitate the more systematic devel-

opment of scientiﬁc theory on health behavior change,

by facilitating the interpretation of empirical data.

4.2 Method

This case study demonstrates the potential impact of

our proposed system in the ﬁeld of health behavior

change. We portray how three defying theoretical

frameworks within the more generic ﬁeld of behavior

change could be encoded in our system. Additionally,

we illustrate how our system could record valuable

information from three empirical studies on health

behavior change. Subsequently, we discuss how the

theoretical frameworks and empirical studies relate to

each other, and how these relations could be repre-

sented by SciModeler. Finally, we highlight how the

system could be queried to accumulate knowledge.

4.2.1 Selecting Three Theoretical Frameworks

In the context of behavior change, theories seek to ex-

plain why, when and how a behavior does or does

not occur, and the important sources of inﬂuence to

be targeted in order to alter the behavior (Michie

et al., 2014). Theories on behavioral change are

prevalent: The book “ABC of behaviour change the-

ories” reported 83 behavior change theories (Michie

et al., 2014); a scoping review on theories of behav-

ior change identiﬁed 82 distinct theories (Davis et al.,

2015); and the book “Planning health promotion pro-

grams” discussed more than 40 behavior change the-

ories (Eldredge et al., 2016). From these and other

sources, we have compiled a list of 103 unique be-

havior change theories.

In an online survey, we have challenged behav-

ioral scientists to express what theories they typically

use in their behavior change initiatives. The survey

was completed by 38 scientists who selected: 1) the

Self-Determination Theory (Deci and Ryan, 1985, 16

mentions), 2) the COM-B system (Michie et al., 2011,

15 mentions), and 3) the Goal Setting Theory (Locke

and Latham, 2002, 14 mentions) as the most useful

theories of behavior change.

4.2.2 Selecting Three Empirical Studies

To model three example empirical studies in the ﬁeld

of health behavior change reliably, we drew from our

own collection of empirical studies. The examples

have quite diverse study setups, demonstrating the ex-

pressiveness of SciModeler and providing a good ba-

sis for illustrating the power of the model as a foun-

dation for query-based information retrieval.

4.3 Results: Proof of Concept

In this section, we demonstrate how to record scien-

tiﬁc theories, how to record empirical studies, how to

map those to theories, and how to query the resulting

graphs for extracting information relevant for accu-

mulating knowledge as well as theory building.

4.3.1 Recording a Theory

The data (i.e., constructs and relations between these

constructs) that was captured for the three selected

theories was taken from the descriptions of these the-

ories in their original research articles. This sec-

tion summarizes the content of each theory and high-

lights how some particularities for each theory were

recorded within SciModeler.

The COM-B System is a theory that proposes

that, in order for a behavior to occur, an individual

must have the capability (i.e., physical or psycholog-

ical) and opportunity (i.e., social or physical) to en-

gage in the behavior, as well as the strength of mo-

tivation (i.e., ‘reﬂective’ or ‘automatic’) to engage

in it must be greater than for any competing behav-

iors (Michie et al., 2011). The model emphasizes

that components can interact: for example, motiva-

tion can be inﬂuenced by both opportunity and capa-

bility, which can in turn inﬂuence behavior. Behavior

can then have a feedback inﬂuence upon a person’s

opportunity, motivation and capability to perform the

behavior again. Online Supplement A1 (Nuijten and

Van Gorp, 2020a) displays how the constructs within

the COM-B system relate to each other, and how

those relations could be captured within SciModeler.

The Self-Determination Theory (Deci and Ryan,

1985, SDT) provides a broad framework to study mo-

tivation, personality and behaviors. Central to the

theory’s explanation of behavior is the distinction be-

tween intrinsic motivation (i.e., motivation due to in-

herent interest or enjoyment) and extrinsic motiva-

tion (i.e., motivation due to external factors or con-

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

318

trols), and people’s basic need for autonomy, com-

petence and relatedness (Deci and Ryan, 1985). The

SDT is a meta-theory comprised of ﬁve mini-theories.

The notion that theories can sometimes be composed

of other theories can be recorded in our system us-

ing the recursive relationship the theory entity has

with itself. Online Supplement A2 (Nuijten and

Van Gorp, 2020a) shows how SciModeler enables to

express such relationships between theories and mini-

theories.

The Goal Setting Theory explains the mecha-

nisms by which goals or intentions inﬂuence task per-

formance (Locke and Latham, 2002). The theory’s

basic premise is that an individual’s conscious ideas

regulate her behavior (i.e., task performance). Ad-

ditionally, performance can be moderated by a num-

ber of factors including the level of commitment, the

importance of the goal, levels of self-efﬁcacy, feed-

back and task complexity (Locke and Latham, 2002).

Furthermore, Locke and Latham model impact of re-

lationships between goals and their impact on satis-

faction, as well as how goals act as mediators of in-

centives. Within the Goal Setting Theory, goal and

intention are used as synonyms. The notion of equiv-

alent constructs can be recorded in our graph using

a relation of type synonym, see Online Supplement

A3 (Nuijten and Van Gorp, 2020a).

4.3.2 Recording an Empirical Study

The information that was captured for the three em-

pirical studies was recorded from the description of

these studies in their original research articles (which

are cited in the next paragraphs). Speciﬁcally, we an-

notated those articles and used a script to translate

the annotation data into Neo4j data import scripts.

The related prototypical infrastructure–including the

example annotated PDF-ﬁles for the graphs in this

section–is available online (Nuijten and Van Gorp,

2020b). This section summarizes the content of each

study and highlights how some particularities for each

study where recorded within SciModeler.

Study 1: TVC (Nuijten et al., 2019). This study

evaluated two design elements of an mHealth solution

– i.e., social proof and tangible rewards – and their

impact on user engagement and argued that the intro-

duction of a sufﬁciently meaningful, unexpected, and

customized extrinsic reward can engage participants

signiﬁcantly. During a four-week campaign, a sample

of 143 university staff members engaged in a health

promotion campaign. Participants were randomly dis-

tributed over one of three treatment groups. Online

Supplement A4 (Nuijten and Van Gorp, 2020a) dis-

plays how this information on the study’s population,

sample, and treatment groups could be recorded in

SciModeler (i.e., by means of the purple, violet, and

blue nodes). Additionally, the demographic informa-

tion about the sample that the study disclosed was

recorded as well (i.e., via the pink and grey nodes).

Study 2: VHC (d’Hondt et al., 2019). This study

evaluated the impact of personalized motivational

messages, as compared to randomized motivational

messages, and argued that personalized messages are

more appreciated than random messages, but also

that personalized messages do not necessarily cause

a change in long term behavior. Online Supplement

A5 (Nuijten and Van Gorp, 2020a) demonstrates how

the general intervention (i.e., motivational messages)

and the two treatments (i.e., personalized messages,

as compared to random messages) can be recorded in

SciModeler (i.e., by means of the red-shaded nodes).

Additionally, the outcomes are recorded in the yellow

nodes, as well as the variables. Finally, the orange-

shaded nodes in the top right of Online Supplement

A5 (Nuijten and Van Gorp, 2020a) depict the exper-

imental point of interest (and the variable that was

explicitly measured for this purpose), as well as how

the intervention was hosted on a particular platform.

Study 3: UCGS (Nuijten et al., 2020). This study

evaluated social comparison as a driver of engage-

ment with an mHealth application in preadolescents

and argued that a team-oriented environment with in-

volvement of a natural role model is more engaging

than an individually-focused setting. To draw this

conclusion, the authors designed a 12-week crossover

experiment, in which they studied three approaches

to implementing behavior change via social compari-

son. Every treatment group received their treatments

in 2-week periods, and hence received every treatment

twice. This advanced study design can be recorded in

our graph as depicted in Online Supplement A6 (Nui-

jten and Van Gorp, 2020a). Particularly, note how

treatment groups (i.e., blue nodes) are linked to the

treatments (i.e., red nodes) through instances of the

treatment assignment entity (i.e., brown nodes). The

attribute order number on the entity treatment assign-

ment is used to distinguish in what order the treat-

ments were assigned to a particular treatment group.

4.3.3 Mapping Theory and Practice

The ﬁnal exercise was to link (elements of) the inter-

ventions and treatments of our empirical studies onto

theoretical constructs. We have ourselves coded our

studies’ interventions and treatments onto four theo-

retical constructs, see Online Supplement A7 (Nuijten

and Van Gorp, 2020a).

SciModeler: A Metamodel and Graph Database for Consolidating Scientiﬁc Knowledge by Linking Empirical Data with Theoretical

Constructs

319

4.3.4 Querying to Accumulate Knowledge

In this section we present three ideas for querying the

graph that can be used to advance scientiﬁc theories.

First, one may query all interventions and treat-

ments that address a particular theoretical construct.

Then, one can evaluate the outcomes these interven-

tions and treatments had on the target variables and

check whether the theory under investigation would

suggest that same outcome. For our case, we may

query all interventions that were associated to the con-

struct relatedness, see query 1a of Online Supplement

A8 (Nuijten and Van Gorp, 2020a). We then ﬁnd that

there are two interventions associated with this con-

struct, also see Online Supplement A7 (Nuijten and

Van Gorp, 2020a). Now we can evaluate whether the

outcomes are to be expected according to our theory

on relatedness, and we may update our theories ac-

cordingly. Note that a user of this system may de-

termine herself what theoretical constructs are inter-

esting to evaluate: she can even jointly evaluate the

empirical impact of multiple constructs, if she be-

lieves several constructs represent the same meaning,

see query 1b of Online Supplement A8 (Nuijten and

Van Gorp, 2020a).

Second, one may query all experiments target-

ing a particular population, or context to evaluate

whether an outcome can be replicated within that pop-

ulation or context, see query 2 of Online Supplement

A8 (Nuijten and Van Gorp, 2020a). Alternatively, one

may query all interventions and treatments that ad-

dress a particular theoretical construct (as suggested

in the ﬁrst example), to evaluate whether suggested

theoretical outcomes also translate to other popula-

tions and contexts.

Third, one may query all experiments that have

used the same platform to evaluate whether a theoret-

ically suggested relationship is reported consistently

with (probably) similar interventions and treatments.

Using following statement one can ﬁnd all interven-

tions and treatments that were hosted using a similar

platform, see query 3 of Online Supplement A8 (Nui-

jten and Van Gorp, 2020a).

Lastly, SciModeler enables its users to perform

automated updates on the graph structures. This paves

the way towards graph transformation systems that

automatically explore which variations of existing in-

dustries support the results of previously coded stud-

ies most naturally, in careful consideration of heuris-

tics like Ockham’s razor (Hoffmann et al., 1996).

5 CONCLUSION & OUTLOOK

We have demonstrated the potential value of SciMod-

eler by means of a case study. Even though the ex-

ample queries were relatively simple, they could de-

liver information which would be very hard to ob-

tain reliably when only reasoning about the original

manuscripts. We have also suggested that this ba-

sic infrastructure paves a way towards automating the

simpliﬁcation and merging of theories. Still, the setup

in which SciModeler was demonstrated has various

limitations, that call for future improvements.

First, populating the SciModeler database is rel-

atively cumbersome such that in its current form it

would suffer from adoption problems. Hence, we aim

to explore the use of ontological languages to ease the

process of recording scientiﬁc theories. For encoding

empirical studies however, we have already proposed

a process that uses PDF annotations to extract data.

Still we aim to explore how existing scientiﬁc tools

for data annotation (Van Gorp et al., 2012) can poten-

tially ease this process, as we envision a future where

authors submit SciModeler data as a direct supple-

ment to their articles. Until then, one may also want

to leverage Natural Language Processing techniques

for automatically mining SciModeler models. Regret-

tably, these algorithms will also suffer from the fact

that many scientiﬁc publications are incomplete and

ambiguous. Particularly, from a peer review of 313

research studies it was observed that over half (54%)

of the studies did not report on the four PICO compo-

nents (Thabane et al., 2009). Regardless of whether

studies are labeled by their original authors, by an-

other scientist, or by an artiﬁcially intelligent agent,

one may want to collect community feedback on the

quality of a SciModeler model. We have anticipated

that by allowing users to review and ‘up-vote’ each

other’s classiﬁcations of experimental interventions

and treatments as theoretical constructs. Future revi-

sions should support that at the level of other entities

and attributes too, such that the truthfulness of a par-

ticular attribute value can be measured by the degree

to which reviewers agree on the information.

A second limitation is that we do not yet pro-

vide an interface for querying the graph, and for ‘up-

voting’ speciﬁc classiﬁcations. To also allow possible

non-expert end users to use the system, we plan to

provide an interface, for instance with a set of default

queries.

A third limitation is that we do not yet share a

substantial database of SciModeler models. We did

already invest signiﬁcant efforts in the coding of 37

empirical studies on health behavior change. In fact,

those efforts were based on more primitive scientiﬁc

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

320

tools such as online spreadsheets and ultimately they

have driven us to the development of SciModeler. Our

aim is to revisit that initial exercise and demonstrate

to the behavior change community how the model-

based approach reported here can be used to develop

a more uniﬁed theory for that ﬁeld. At the same time,

we aim to validate the current metamodel with other

researchers, especially from the ﬁeld of health behav-

ior change. This may yield improvement directions

for our metamodel. For example, researchers may ex-

press the need to actually discuss classiﬁcations, in-

stead of only being able to ‘up-vote’ them.

Finally, at the level of the SciModeler metamodel,

future work is to decompose the text-based node at-

tributes into more ﬁne-grained sub-graph structures.

That would for example enable the query-based re-

trieval of studies that are recorded within the con-

text of a high-school, with a duration of at least eight

weeks per intervention. Until then, the Neo4j’s query

language fortunately offers support for regular ex-

pressions on node attribute values.

REFERENCES

Booth, A. (2006). Clear and present questions: formulating

questions for evidence based practice. Library hi tech.

Ciccarese, P., Wu, E., Wong, G., Ocana, M., Kinoshita, J.,

Ruttenberg, A., and Clark, T. (2008). The SWAN

biomedical discourse ontology. Journal of Biomedi-

cal Informatics, 41(5):739 – 751. Semantic Mashup

of Biomedical Data.

Clark, T., Ciccarese, P. N., and Goble, C. A. (2014).

Micropublications: a semantic model for claims,

evidence, arguments and annotations in biomedical

communications. Journal of Biomedical Semantics,

5(1):28.

Cooke, A., Smith, D., and Booth, A. (2012). Beyond

pico: the spider tool for qualitative evidence synthe-

sis. Qualitative health research, 22(10):1435–1443.

Davis, R., Campbell, R., Hildon, Z., Hobbs, L., and Michie,

S. (2015). Theories of behaviour and behaviour

change across the social and behavioural sciences: a

scoping review. Health psychology review, 9(3):323–

344.

Deci, E. L. and Ryan, R. M. (1985). Intrinsic motivation

and self-determination in human behavior. New York:

Plenum Publishing Co.

d’Hondt, J. E., Nuijten, R. C., and Van Gorp, P. M. (2019).

Evaluation of computer-tailored motivational messag-

ing in a health promotion context. In International and

Interdisciplinary Conference on Modeling and Using

Context, pages 120–133. Springer.

Eldredge, L. K. B., Markham, C. M., Ruiter, R. A., Fer-

nández, M. E., Kok, G., and Parcel, G. S. (2016).

Planning health promotion programs: an intervention

mapping approach. John Wiley & Sons.

Hempel, C. G. (1952). Fundamentals of concept formation

in empirical science. University of Chicago Press.

Hoffmann, R., Minkin, V., and Carpenter, B. (1996). Ock-

ham’s razor and chemistry. Bulletin de la Societe

Chimique de France, 133.

Locke, E. A. and Latham, G. P. (2002). Building a practi-

cally useful theory of goal setting and task motivation:

A 35-year odyssey. American psychologist, 57(9):705.

Michie, S., Van Stralen, M. M., and West, R. (2011). The

behaviour change wheel: a new method for character-

ising and designing behaviour change interventions.

Implementation science, 6(1):42.

Michie, S., West, R., Campbell, R., Brown, J., and Gain-

forth, H. (2014). ABC of behaviour change theories.

Silverback publishing.

Morgan, R. L., Whaley, P., Thayer, K. A., and Schünemann,

H. J. (2018). Identifying the peco: a framework for

formulating good questions to explore the association

of environmental and other exposures with health out-

comes. Environment international, 121(Pt 1):1027.

Nuijten, R. C. and Van Gorp, P. M. (2020a). SciMo-

deler@MODELSWARD: Online Supplements. DOI:

10.6084/m9.ﬁgshare.13347239.

Nuijten, R. C. and Van Gorp, P. M. (2020b).

SciModeler database v1.0.1. DOI:

10.6084/m9.ﬁgshare.13160141.

Nuijten, R. C. and Van Gorp, P. M. (2020c). SciModeler

metamodel. DOI: 10.6084/m9.ﬁgshare.13347275.

Nuijten, R. C., Van Gorp, P. M., Borghouts, T., Le Blanc,

P. M., Van den Berg, P. E., Kemperman, A. D., Ha-

dian Haghighi, E., and Simons, M. (2020). Different

implementations of social comparison as drivers for

health behavior change: Evaluating engagement lev-

els of preadolescent students with an mhealth inter-

vention. Journal of Medical Internet Research. Under

Review.

Nuijten, R. C., Van Gorp, P. M., Kaymak, U., Simons, M.,

Kemperman, A. D., and Van den Berg, P. E. (2019).

Evaluation of the impact of extrinsic rewards on user

engagement in a health promotion context. In 2019

41st Annual International Conference of the IEEE En-

gineering in Medicine and Biology Society (EMBC),

pages 3600–3604. IEEE.

Popper, K. (1959). The logic of scientiﬁc discovery. Rout-

ledge.

Reynolds, P. (1971). A primer in theory construction.

Tauchert, C., Bender, M., Mesbah, N., and Buxmann, P.

(2020). Towards an integrative approach for auto-

mated literature reviews using machine learning. In

53rd Hawaii International Conference on System Sci-

ences, HICSS 2020, Maui, Hawaii, USA, January 7-

10, 2020, pages 1–10. ScholarSpace.

Thabane, L., Thomas, T., Ye, C., and Paul, J. (2009). Pos-

ing the research question: not so simple. Canadian

Journal of Anesthesia/Journal canadien d’anesthésie,

56(1):71.

Van Gorp, P., Vanderfeesten, I., Dalinghaus, W., Men-

gerink, J., van der Sanden, B., and Kubben, P. (2012).

Towards generic mde support for extracting purpose-

speciﬁc healthcare models from annotated, unstruc-

tured texts. In International Symposium on Founda-

tions of Health Informatics Engineering and Systems,

pages 213–221. Springer.

Wildridge, V. and Bell, L. (2002). How clip became eclipse:

a mnemonic to assist in searching for health pol-

icy/management information. Health Information &

Libraries Journal, 19(2):113–115.

SciModeler: A Metamodel and Graph Database for Consolidating Scientiﬁc Knowledge by Linking Empirical Data with Theoretical

Constructs

321
