Towards Evolutionary Multi-layer Modeling with DMLA

andor B

acsi

, D

aniel Palatinszky

and M

e Hidv

egi

Department of Automation and Applied Informatics, Budapest University of Technology and Economics,

Muegyetem Rkp. 3., Budapest, Hungary

Keywords:

Multi-layer Modeling, Multi-level Modeling, Graal, Trufﬂe, Virtual Machine, Interpreter, Compiler, DMLA.

Abstract:

State-of-the-art meta-model based methodologies are facing increasing pressure under new challenges origi-

nating from practical applications. In such cases, there is a strong need for approaches that support continuous,

ﬁne-graded, incremental reﬁning of concepts. To address these challenges, our research group started working

on a new modeling framework, the Dynamic Multi-Layer Algebra (DMLA) a few years ago. DMLA follows

a completely new modeling paradigm, referred to as multi-layer modeling. Multi-layer modeling is originated

from multi-level modeling and offers a highly ﬂexible abstraction management approach in a level-blind fash-

ion through its advanced deep instantiation and evolutionary snapshot management. One of the key features

of DMLA is its self-validation mechanism based on a built-in, completely modeled operation language. Our

initial solution had its limitations, since interactive editing was not supported, modelers could interact only

with a single snapshot of the model. To overcome the limitations, we have created a virtual machine and an

interpreter. In this paper, we present the novel architecture of our solution and demonstrate the feasibility of

our approach by a walk-through of the concrete model management steps of an illustrative example to show

the beneﬁts of evolutionary model editing in DMLA.

1 INTRODUCTION

In the software industry, the development of applica-

tions routinely begins with setting up the most rele-

vant design aspects based upon the main requirements

of the given project. Stakeholders and customers try

to specify their needs and expectations at the begin-

ning of the project, but in most cases these initial

requirements change during later phases of the de-

velopment. As the project evolves, the requirements

may change, thus new constraints may reduce the

original ﬂexibility of the software. In many problem

domains, it would be beneﬁcial to support this evo-

lutionary nature of software development by apply-

ing model-based solutions since it allows the appli-

cation of changes on a higher abstraction level with-

out changing the lower, dependant structure. One

way to solve the problem of continuously evolving re-

quirements is the so-called model-driven engineering

(MDE). However, the legacy approaches of MDE and

in particular the ones of applied domain-speciﬁc mod-

eling have often turned out not being either ﬂexible or

https://orcid.org/0000-0002-4814-6979

https://orcid.org/0000-0002-6168-3963

https://orcid.org/0000-0003-2129-7897

precise enough in practice, therefore, there is a need

for new methods and techniques.

As a contemporary trend in MDE, two and/or four

level modeling frameworks are being frequently ex-

tended to an arbitrary number of levels, which could

lead to higher ﬂexibility of expressiveness (Atkin-

son and K

uhne, 2001). For a multi-level modeling

approach to be rigorous enough is indeed a manda-

tory feature for being able to support the continuous

evolution of requirements that Industry 4.0 solutions

are based on. Although the emerging multi-level ap-

proaches may solve the challenge of supporting grad-

ual reﬁnement by providing an unbounded number of

domain classiﬁcation levels, this is only one aspect of

the industrial demands.

Besides being able to describe the static aspect in

a ﬁne-graded way, the other key aspect is introducing

dynamic features to models such as querying, modi-

fying, simulating or executing the model deﬁnitions.

In classic modeling approaches, the workﬂow usu-

ally consists of creating and saving the snapshot of

the meta-model, and then creating the instance mod-

els based on the meta-model. One can only create

the model in a very strict way, without any possi-

bilities for dynamic modiﬁcation like adding, delet-

ing, or modifying model elements continuously. The

344

Bácsi, S., Palatinszky, D. and Hidvégi, M.

Towards Evolutionary Multi-layer Modeling with DMLA.

DOI: 10.5220/0010347403440349

In Proceedings of the 9th International Conference on Model-Driven Engineering and Software Development (MODELSWARD 2021), pages 344-349

ISBN: 978-989-758-487-9

need can arise for an iterative, dynamic process where

we can modify the model real-time in an evolutionary

way by stepping between the different abstraction lev-

els of the domain.

The idea of the Dynamic Multi-Layer Algebra

(DMLA) (of Automation and Informatics, ) was born

out of the combination of these two modeling aspects,

namely, multi-level modeling, and dynamic model-

ing. DMLA has two versions regarding dynamism:

an old compiler-based version and a new, interpreter-

based version. In this paper, we introduce the basics

of DMLA, discuss why we needed two versions of ex-

ecution engine and then demonstrate the feasibility of

the new version of DMLA by a walk-through of the

concrete model management steps of an illustrative

example.

The paper is organized as follows: Section 2

presents the background and the related work show-

ing other approaches with or without dynamism. Sec-

tion 3 describes the basics of DMLA while Section

4 presents the short history and current state of the

DMLA workbench. Section 5 presents the illustrative

example and concluding remarks are outlined in Sec-

tion 6.

2 BACKGROUND AND RELATED

WORK

Until recently, the usual way of meta-modeling was

often based on OMG’s Meta Object Facility (MOF)

(OMG, 2005). MOF allows the use four levels instead

of two in order to increase ﬂexibility. Although the

extension is useful, having a ﬁxed number of levels

ties the hands of domain experts since they are forced

to reﬁne the model in a ﬁxed number of steps. The

lack of an arbitrary number of levels between the ini-

tial speciﬁcation and the ﬁnal realization may lead to

the phenomenon called accidental complexity (Atkin-

son and K

uhne, 2008). Multi-level modeling aims

to minimize accidental complexity by taking advan-

tage of an unlimited number of meta-levels in order

to properly allocate the correct amount of abstraction

details to each of them. In the past decades, there have

been a growing number of proposals for frameworks

aimed at supporting multi-level modeling (K

uhne and

Schreiber, 2007; de Lara and Guerra, 2010; Atkinson

and Gerbig, 2016; Clark and Willans, 2012; of Au-

tomation and Informatics, ).

Multi-level modeling approaches usually support

dynamic behavior which requires the deﬁnition of

model-modifying operations like adding a new entity

to the model. A common pattern to fulﬁll this re-

quirement is the introduction of programmable oper-

ations into the model either via an external or internal

language. For example, Melanee (Atkinson and Ger-

big, 2016) and XModeler (Clark and Willans, 2012)

use an external language (variations of OCL), while

DMLA (of Automation and Informatics, ) uses an in-

ternal, modeled approach. Regardless of which ap-

proach we choose, the solution to execute the oper-

ations would be either compilation or an underlying

virtual machine (VM) that is responsible for manag-

ing this behavior.

Following the example, XModeler(Clark and

Willans, 2012) supports a virtual machine (XMF VM)

for this purpose which not only supports modifying

operations on the model, it also supports undoing op-

erations based on transactions. DMLA used to be a

compilation based solution but the newest implemen-

tation - like XModeler - turned towards interpreta-

tion based on a new VM technology by Oracle, called

GraalVM(Oracle, ) which we are discussing later in

Section 4.

3 DYNAMIC MULTI-LAYER

ALGEBRA

The Dynamic Multi-Layer Algebra (DMLA) (of Au-

tomation and Informatics, ) is our multi-layer mod-

eling tool under research. The framework allows the

users to deﬁne and gradually reﬁne the aspects of their

domain language in a self-descriptive, validated envi-

ronment. DMLA consists of two parts: (i) the Core,

containing the formal deﬁnition of modeling struc-

tures and its management functions; (ii) the Boot-

strap, consisting of a set of essential entities that can

be reused in all domains. The main idea behind sep-

arating the Core and the Bootstrap is to improve ﬂex-

ibility, but also to keep the approach formal. This

way, the Bootstrap becomes swappable, thus even

the semantics of valid instantiation can be re-deﬁned.

Namely, each particular bootstrap seeds the metamod-

eling facilities of the generic DMLA formalism.

The Core has a formal description based on Ab-

stract State Machines (ASM) (B

orger and St

ark,

2003). This description deﬁnes the structure of model

elements as 4-tuples i.e. tuples with four elements.

Tuples contain all data of the given entity: the iden-

tiﬁer, along with the meta-identiﬁer of the element as

well as its attributes and values. Besides these tuples,

the Core also deﬁnes basic functions to manipulate

the model, for example, they can create new model

entities or query existing ones. These functions are

deﬁned as ASM functions. Models are represented

by the underlying ASM: the states of the machine are

snapshots of the models: if an entity changes, a new

Towards Evolutionary Multi-layer Modeling with DMLA

345

snapshot and therefore a new state of the ASM is cre-

ated.

Over the Core, one can deﬁne a Bootstrap (Mezei

et al., 2019). The Bootstrap describes the basic build-

ing blocks of every domain model and therefore acts

as a practical base for modeling. A Bootstrap consists

of several entities, (i) it improves the raw entity for-

mat given by the Core to a more practical level (e.g.

by attaching meta-information to references), (ii) in-

troduces constraints to customize validation between

model elements, (iii) deﬁnes the basic rules of valida-

tion, and (iv) has a complete operation language.

The operation language is an essential part of the

Bootstrap, since here, unlike many other modeling

approaches, the rules of valid instantiation are not

encoded in an external programming language (e.g.

Java), but it is modeled by the Bootstrap. All the val-

idation rules and therefore even the deﬁnition of the

instantiation relationship itself are using the operation

language. The operation language models the vali-

dation algorithms by their abstract syntax tree (AST)

representation built from AST-related model entities,

e.g. if or statement.

In order to accelerate the deﬁnition of the tuples

representing the model entities, we have created a

scripting language referred to as DMLAScript. In

practice, the Bootstrap, the domain metamodels and

models are also deﬁned by DMLAScript. Although it

is used to ease the usage of the framework by helping

users describe their domain language in a more famil-

iar way, it does not introduce any new features. DM-

LAScript is merely a syntactic sugar, its scripts are

always translated back to tuples, the primary form of

model entities. The beneﬁts of this scripting language

are most remarkable in deﬁning operations, where

even a single line of DMLAScript code may translate

to a complex set of connected entities.

4 TOWARDS EVOLUTIONARY

MODEL EDITING

When creating the ﬁrst workbench for DMLA, our

primary goal was to create an approach that supports

validated step-wise reﬁnement. Validation was a key

feature here as we wanted to achieve a self-validated,

self-describing meta-modeling approach. Although

the workbench fulﬁlled all of our initial requirements

(Urb

an. et al., 2018), we needed a more advanced so-

lution. We have realized that using the operation lan-

guage only to describe the validation logic is a waste

of opportunities. There are more possibilities in hav-

ing a fully modelled operation language. Therefore,

we summarized our new requirements and decided to

create a new version of the workbench.

Initially, our typical use case was to deﬁne a pre-

liminary version of the target domain via gradual re-

ﬁnement, and then validate it. Then, we repeat the

process several times, reﬁne the domain step-by-step

and validate it every time. In this case, it was not a

problem that the model deﬁnition and the validation

phases are separated. However, in a usual industrial

use case, having an interactive, responsive environ-

ment is a must. Users tend to apply minor modiﬁ-

cations, and expect the model to be up-to-date at all

time. So, instead of having milestones as in the ﬁrst

workbench, we need small steps.

Possibly the most important new demand was to

support other kinds of operations: i) queries, and ii)

operations altering the model. By opening the door

for operations changing the model, we needed a more

dynamic view on our current model, i.e. modiﬁ-

cations were to be reﬂected immediately. The ﬁrst

workbench could support a dynamic view but it would

not be able to process the modiﬁcations as fast as it

would be needed in an industrial scenario since the

compilation required too much time.

By realizing the new requirements, we started to

work on a new workbench for DMLA. The ﬁrst, and

most important decision was to create an interpreter-

based workbench. There were several reasons behind

this decision. Interpreters offer a natural way to obtain

the inner data structure during execution and there-

fore it is much easier to create an interactive envi-

ronment, where changes in the model are reﬂected

automatically and immediately by the environment.

Moreover, interpretation helped eliminating the long

and slow compilation process and allowed us to de-

bug domains with ease. The virtual machine behind

the interpreter is also much closer to a native imple-

mentation of the underlying Abstract State Machine

formalism than the compiled code produced in the old

workbench.

Creating an interpreter and virtual machine for an

approach like DMLA is a challenging task without a

decent framework. After a long search for the perfect

technology, we have decided to have GraalVM (Ora-

cle, ; W

urthinger et al., 2013) as the base of our new

solution. GraalVM is a new generation of Java virtual

machine. It aims to build upon the old Java VM by

replacing the compiler. The main goal of GraalVM is

to be a universal runtime environment with as close

to native performance as possible. GraalVM also in-

troduces Trufﬂe (Wimmer and W

urthinger, 2012), a

language agnostic API that can be used to describe

custom languages for Graal while also allowing for

interoperability between the implemented languages.

Interoperability is a powerful feature that can be used

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

346

to make function calls from a Graal-based language to

another (e.g., Python to JavaScript) and exchange data

between them. This feature can be considered an ad-

ditional gain, which may be useful in the future, when

we introduce new languages besides DMLAScript to

describe the tuples.

For interpreters, performance is usually a weak

point, however, Trufﬂe supports several optimiza-

tion techniques like cached function call targets, opti-

mized execution for different parameter types, hand-

optimized bytecode. It is also possible to introduce

instrumentation and debugging for the target language

easily.

With the help of GraalVM and interpretation, sev-

eral improvements and new features became possible.

One of the most important features is on-the-ﬂy com-

mand processing by using an interactive command-

line interpreter, which we are demonstrating later in

Section 5. On top of that, operations are no more

limited to validation and queries, modiﬁcation of the

model is also possible.

5 ILLUSTRATIVE EXAMPLE

In this section, we demonstrate interactive model edit-

ing in action by presenting the management steps of

a simpliﬁed model fragment borrowed from the Bi-

cycle Challenge (MULTI, 2018), for which the full

solution (described in DMLAScript) is also available

(Mezei et al., 2018). Originally, the typical work-

ﬂow of solving the Bicycle Challenge was to deﬁne a

preliminary version of the domain via gradual reﬁne-

ment, and then validate it. We did not have an interac-

tive, responsive environment, thus we could not map

the requirements step-by-step, in a natural way. In this

example, we use a simpliﬁed syntax of our command-

line interpreter for the sake of clarity. We reﬁne the

presented model fragment step-by-step based on the

continuously evolving requirements:

REQ1: A conﬁguration (Conﬁg) is composed of

components (Comps).

>addEntity(Config, CEntity)

Config>addSlot(Comps,CEntity.Children)

Config.Comps>addTypeCstr(Comp)

Config.Comps>addCardinalityCstr(0,*)

In DMLA, multi-level behavior is supported by

ﬂuid meta-modeling. Hence, instantiation steps are

independent by design. Each entity in the model can

refer to any other entity along the meta-hierarchy. En-

tities may have attributes referred to as slots (abstract

placeholder for the value), describing a part of the en-

tity, similarly to classes having properties in object-

oriented programming. In this example, we add a

new entity Conﬁg to the model, setting its meta-entity

to CEntity (ComplexEntity), which is the usual entry

point of domain deﬁnition in DMLA. CEntity has a

slot called Children. Children enables the instantia-

tion of custom slots, like Comps in this example. We

add a new slot Comps to Conﬁg, setting its meta-slot

to Children. In DMLA, one may use constraints on

slots, like type and cardinality constraints. Type con-

straint restricts the type of the values to be put in the

slot: addTypeCstr(Comp) adds a type constraint to

slot Comps, thus one can only use instances of Comp

entity there. Cardinality constraint prescribes the al-

lowed number of instances within a given slot. The

cardinality constraint has a minimum and a maximum

parameter. addCardinalityCstr(0,*) adds a cardinality

constraint to slot Comps, which prescribes that Con-

ﬁguration may have zero-to-many number of Compo-

nents.

Note that when a command is executed, the model

changes dynamically, therefore the latest state is al-

ways available in the background. One could even

call a user-deﬁned operation on the model which

would give immediate and up-to-date results.

REQ2: Ncycle is a conﬁguration. Ncycle is

built of components like Wheels(1..3), and Seats(1..2).

Ncycle serves as an abstract entity, which can be con-

cretized later to more speciﬁc bike models (e.g. Bicy-

cle, Tricycle, Unicycle or Tandem bike).

>addEntity(NCycle, Config)

NCycle>addSlot(Wheels, Config.Comps)

NCycle.Wheels>addTypeCstr(Wheel)

NCycle.Wheels>addCardinalityCstr(1,3)

NCycle>addSlot(Seats, Config.Comps)

NCycle.Seats>addTypeCstr(Seat)

NCycle.Seats>addCardinalityCstr(1,2)

In this step, we reﬁne entity Conﬁg, by adding a

new entity NCycle with the more concretized slots and

the narrowed constraints. In DMLA, one may also

divide a slot into several instances similarly to enti-

ties, where we can create several instances of a meta-

entity. The general purpose Comps slot is divided into

a Wheels and a Seats slot. Note that we also narrow

the type and cardinality constraints on both Wheels

and Seats slots considering the new requirement.

REQ3: A Unicycle is a bike model equipped with

exactly one wheel and one seat.

>addEntity(Unicycle, NCycle)

Unicycle.Wheels>addCardCstr(1,1)

Unicycle.Seats>addCardCstr(1,1)

>Validate()

We further concretize entity NCycle by adding

Unicycle to the model. We narrow the cardinality

constraint on both slots to restrict the allowed number

Towards Evolutionary Multi-layer Modeling with DMLA

347

of instances (one wheel and one seat), while the type

constraints remain intact. We also call the validation

of the model to check that what we have done so far

is valid. Validation in DMLA is intuitive: whenever a

model entity claims another entity to be its meta, the

framework automatically validates if there is indeed a

valid instantiation between the two entities. The val-

idation checks the latest state of the model, since the

model always changes dynamically, when a command

is executed. In this case, no model element found to

be contradictory during model validation.

REQ4: There is a demand for special tandem

bikes with two wheels and three seats.

>addEntity(Tandem, NCycle)

Tandem.Wheels>addCardCstr(2,2)

Tandem.Seats>addCardCstr(3,3)

>Validate()

We concretize entity NCycle by adding Tandem

to the model. In order to meet the new requirement

we apply cardinality constraint on both slots to re-

strict the allowed number of instances (two wheels

and three seats). The Tandem entity found to be con-

radictory during model validation, since the valida-

tion mechanism of DMLA ensures that if an existing

cardinality is overwritten (reﬁned), then it should not

relax the original condition. In this example, the orig-

inal maximum parameter of slot Seats is already set to

two in entity NCycle, it cannot be overwritten to three.

This scenario showscases one of the most important

features of the interpreter-based version of DMLA:

by running the validation, we can get an immediate

feedback on the validation errors of latest state of the

model.

Altough we could continue the reﬁnement and the

concretization of this simple model fragment (e.g.

ﬁlling out the slots with concrete values), the aim of

this section is only to present the most basic features

of interactive model editing in the newest workbench

of DMLA.

6 CONCLUSIONS

In this paper, we presented the newest workbench

of DMLA, our multi-layer modeling approach, high-

lighting its features regarding dynamism and evolu-

tionary model editing. Although the paper focused on

DMLA, we believe that our experiences and conclu-

sions are not DMLA-speciﬁc and are worthy of gen-

eral discussion. In the future, we aim to work on the

interactivity of the tool and modernize DMLAScript

to improve the ease of usage. Our other goals con-

cerning DMLA include the optimization of the val-

idation, the visualization of the models, and the in-

troduction of transactions to provide reliable units of

work that allow correct recovery from validation er-

rors and keep the model consistent.

ACKNOWLEDGEMENTS

This work was performed in the frame of FIEK 16-

1-2016-0007 project, implemented with the support

provided from the National Research, Development

and Innovation Fund of Hungary, ﬁnanced under the

FIEK 16 funding scheme.

REFERENCES

Atkinson, C. and Gerbig, R. (2016). Flexible deep mod-

eling with melanee. In Modellierung 2016 - Work-

shopband : Tagung vom 02. M

arz - 04. M

arz 2016

Karlsruhe, MOD 2016, volume 255, pages 117–121,

Bonn. K

ollen.

Atkinson, C. and K

uhne, T. (2001). The essence of multi-

level metamodeling. In Proceedings of the 4th Inter-

national Conference on The Uniﬁed Modeling Lan-

guage, Modeling Languages, Concepts, and Tools,

«UML» ’01, pages 19–33, Berlin, Hei-

delberg. Springer-Verlag.

Atkinson, C. and K

uhne, T. (2008). Reducing accidental

complexity in domain models. Software & Systems

Modeling, 7(3):345–359.

orger, E. and St

ark, R. (2003). Abstract State Machines:

A Method for High-Level System Design and Analysis.

Springer-Verlag New York, Inc., 1st edition.

Clark, T. and Willans, J. (2012). Software language engi-

neering with xmf and xmodeler. In Formal and Prac-

tical Aspects of Domain-Speciﬁc Languages: Recent

Developments, volume 2, pages 311–340.

de Lara, J. and Guerra, E. (2010). Deep meta-modelling

with metadepth. In Vitek, J., editor, Objects, Mod-

els, Components, Patterns, pages 1–20, Berlin, Hei-

delberg. Springer Berlin Heidelberg.

uhne, T. and Schreiber, D. (2007). Can program-

ming be liberated from the two-level style: Multi-

level programming with deepjava. SIGPLAN Not.,

42(10):229–244.

Mezei, G., Theisz, Z., Urb

an, D., and B

acsi, S. (2018). The

bicycle challenge in dmla, where validation means

correct modeling. In Proceedings of MODELS 2018

Workshops, pages 643–652.

Mezei, G., Theisz, Z., Urb

an, D., B

acsi, S., Somogyi, F. A.,

and Palatinszky, D. (2019). A bootstrap for self-

describing, self-validating multi-layer metamodeling.

In Dunaev, D. and Vajk, I., editors, Proceedings of the

Automation and Applied Computer Science Workshop

2019 : AACS’19, pages 28–38.

MULTI (2018). https://www.wi-inf.uni-duisburg-

essen.de/MULTI2018/.

MODELSWARD 2021 - 9th International Conference on Model-Driven Engineering and Software Development

348

of Automation, D. and Informatics, A. DMLA Homepage.

https://www.aut.bme.hu/Pages/Research/VMTS/

DMLA.

OMG (2005). OMG MetaObject Facility.

http://www.omg.org/mof/. Accessed: 2019-03-

20.

Oracle. GraalVM. https://www.graalvm.org/.

Urb

an., D., Theisz., Z., and Mezei., G. (2018). Self-

describing operations for multi-level meta-modeling.

In Proceedings of the 6th International Conference

on Model-Driven Engineering and Software Develop-

ment - Volume 1: MODELSWARD,, pages 519–527.

INSTICC, SciTePress.

Wimmer, C. and W

urthinger, T. (2012). Trufﬂe: a self-

optimizing runtime system. In SPLASH ’12.

urthinger, T., Wimmer, C., W

oß, A., Stadler, L., Du-

boscq, G., Humer, C., Richards, G., Simon, D., and

Wolczko, M. (2013). One vm to rule them all. In

Onward!

Towards Evolutionary Multi-layer Modeling with DMLA

349
