Malware Detection for IoT Devices using Automatically Generated

White List and Isolation Forest

Masataka Nakahara, Norihiro Okui, Yasuaki Kobayashi and Yutaka Miyake

KDDI Research, Inc., 2–1–15, Ohara, Fujimino-shi, Saitama, Japan

Keywords:

IoT Security, Malware, Anomaly Detection, Machine Learning, White List.

Abstract:

The number of cyber-attacks using IoT devices is increasing with the growth of IoT devices. Since the number

of routes malware infection is increasing, it is necessary not only to prevent infection but also to take measures

after infection. Therefore, high-performance detection techniques are required, but many existing technologies

require large amounts of data and heavy processing. Then, there is a need for a system that can detect mal-

ware infection while reducing the processing load. Therefore, we have proposed an architecture for detecting

malware trafﬁc using ﬂow data of packets instead of whole packet information. We performed the malware

trafﬁc detection on the proposed architecture by using machine learning algorithms focusing on the behavior

of IoT devices, and could detect malware with some degree of accuracy. In this paper, in order to improve

the accuracy, we propose a hybrid system using machine learning and the white list automatically generated

using the rule of Manufacturer Usage Description (MUD). The white list eliminates benign packets from the

target of malware trafﬁc detection, and it can decrease the false positive rate. We evaluate the performance of

proposed method and show the effectiveness.

1 INTRODUCTION

The number of IoT devices has been increasing

rapidly, and they are being used in various ﬁelds such

as industry, agriculture and the home (Hassija et al.,

2019; Mohanapriya et al., 2020; Fortino et al., 2020;

Zulkipli et al., 2017). Accordingly, the target of cy-

ber attacks is changing from traditional IT devices

such as PCs and smartphones to IoT devices (Abdalla

and Varol, 2020). For example, in 2016, Mirai cre-

ated a botnet of more than 2.5 million units and si-

multaneously generated 620 Gbps and 1.1 Tbps Dis-

tributed Denial of Service (DDoS) attacks (Hassija

et al., 2019; Kolias et al., 2017; Antonakakis et al.,

2017). In addition, there are other examples of botnets

built by IoT devices with high power consumption to

attack the power grid, and smart grids are more prone

to cyberthreats. (Soltan et al., 2018; Kimani et al.,

2019; Jung et al., 2019; Ahmed et al., 2019).

As the number of devices increases, these

threats become more signiﬁcant, and countermea-

sures against malware infection become more impor-

tant. Many of these existing security products are spe-

cialized for preventing infection, such as URL block-

ing and intrusion detection. On the other hand, the

number of routes of malware infection is increasing

on daily basis, for example, some IoT devices may

already be infected with malware at the time of pur-

chase, depending on the purchase route. Therefore, in

addition to preventing infection, post-infection detec-

tion is also necessary.

It is also difﬁcult to take security measures for

IoT devices by typical methods such as installing anti-

virus software on each device because the processing

performance of the devices is lower and the number

of devices in use is larger than that of conventional

devices. Therefore, other security measures, such

as managing multiple devices in a centralized archi-

tecture, are being considered (Nguyen et al., 2019).

Centralized architecture generally requires high pro-

cessing resources, but considering the increase of the

number of IoT devices, it is desirable to be able to

take measures with as little processing load as possi-

ble. On the other hand, there are some cases where it

is difﬁcult to detect malware infected devices. For ex-

ample, communication with a Command and Control

(C&C) server before carrying out a DDoS attack is

challenging to distinguish from the original commu-

nication of the device by light-weight processes such

as threshold determination of the number of packets.

Based on the above, we have proposed a system

for post-malware infection detection, in which the

Nakahara, M., Okui, N., Kobayashi, Y. and Miyake, Y.

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest.

DOI: 10.5220/0010394900380047

In Proceedings of the 6th International Conference on Internet of Things, Big Data and Security (IoTBDS 2021), pages 38-47

ISBN: 978-989-758-504-3

communication ﬂow information is aggregated at the

gateway to which the device is connected, and for-

warded to an analysis server to detect the infection

(Nakahara et al., 2020). Our system has an analysis

server outside the local network in order to analyze

the characteristics of the communication from various

perspectives. To lighten the data transfer to the anal-

ysis server, only the ﬂow information of each device

obtained by the gateway is transferred and used for

analysis. Therefore, we used IP Flow Information Ex-

port (IPFIX), a protocol standardized by the Internet

Engineering Task Force (IETF), as the ﬂow informa-

tion (Claise et al., 2013). Using the ﬂow information

deﬁned by IPFIX, this system can be used for gate-

ways. In order to detect the infections in the analysis

server of our system, we have so far applied machine

learning based methods, such as Isolation Forest.

In this paper, we propose a hybrid method using

a white list and machine learning, in which normal

communications are excluded from anomaly detec-

tion, and other communications are examined using

an Isolation Forest. In the case of IoT devices, it is

possible to detect normal communication by using a

white list, since their operation is limited compared

to that of a PC. Furthermore, the number of data to

be subjected to machine learning is reduced, and it

leads to a reduction in processing load and time. In

this paper, we create the white list using the rules

of Manufacturer Usage Description (MUD) generated

from device communications. MUD is invented in

order to deﬁne the normal behavior of devices (Lear

et al., 2019). It is also standardized by IETF, so this

white list is applicable for general IoT devices. We

demonstrate the effectiveness of the proposed method

by comparing the accuracy of anomaly detection with

and without the white list. The contributions of this

paper are as follows.

• We proposed a lightweight malware infection de-

tection system based on standardized technology.

• The ﬂow information in IPFIX format was used to

reduce the amount of data used for anomaly detec-

tion.

• A new use of the MUD is proposed.

• The accuracy of anomaly detection was improved

by the MUD-based white list.

The rest of this paper is as follows: The related works

and the technologies underlying this paper are de-

scribed on Section 2, our proposed system using white

list and machine learning is described on Section 3,

the evaluation of IPFIX is on Section 4, the evalua-

tion of anomaly detection performance is on Section

5, and the conclusion is on Section 6.

2 RELATED WORKS

In this section, we describe the technology used as a

basis for this research.

2.1 Anomaly Detection

The most common methods for preventing IoT mal-

ware infection are blocking access to malicious sites

and blocking entry to devices. There are many secu-

rity products in the market today to prevent infection.

On the other hand, there are many routes of malware

infection, and it is hard to counteract malware infec-

tions just by prevention alone, so early detection af-

ter infection is required. Therefore, researches on the

detection of post-infection behavior have been con-

ducted.

IoT devices often communicate with the C&C

server before their attack behavior, so detection of

these communications is important from the view-

point of stopping the attack. However, the communi-

cation with the C&C server often does not increase as

much as the attack behavior, and it is hard to distin-

guish it from the original communication of the IoT

device. Therefore, numerous researches have been

conducted on anomaly detection by using various fea-

tures from packets to perform machine learning and

deep learning. For example, researches on the classi-

ﬁcation of normal communication and abnormal com-

munication, scanning of Mirai for infected sites, and

detection of attack behaviors have been conducted us-

ing machine learning techniques such as Support Vec-

tor Machine (SVM), Ada Boost and Random For-

est (Mizuno et al., 2017; Alam and Vuong, 2013;

Ding and Fei, 2013; Doshi et al., 2018; Hasan et al.,

2019; Madeira and Nunes, 2016). In addition, deep

learning-based anomaly detection uses Convolutional

Neural Network (CNN) to classify normal communi-

cation and DDoS attacks by converting binaries into

8-bit sequences and transforming them into grayscale

images (Su et al., 2018).

On the other hand, these methods are not realistic

to use in actual environment because they use entire

packets including payloads and the algorithms them-

selves are highly loaded. In this paper, we propose a

system that uses lighter data for analysis outside the

local network, and we evaluate the accuracy of this

system.

2.2 IP Flow Information Export

IPFIX is a ﬂow information protocol standardized by

the IETF in RFC 7011 (Claise et al., 2013). Since it is

very useful to collect trafﬁc ﬂow at a speciﬁc point in

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest

managing a network, we have proposed this paper to

unify the method of expressing the ﬂow information

and the means of conveying the ﬂow information to

the collection points.

In this paper, it is necessary to aggregate pack-

ets of IoT devices at the gateway. This requirement

is consistent with the purpose of the IPFIX proposal,

and the IPFIX ﬂow information enables packet aggre-

gation in a standard and efﬁcient manner.

An example of an IPFIX record is shown in Ta-

ble 1. The ﬂow information in IPFIX format in-

cludes information such as ﬂow start time, end time,

source and destination IP addresses, MAC address,

port number, protocol, number of bytes, and number

of packets. To generate IPFIX from PCAP, we used

a tool called YAF with the option to use MAC ad-

dresses (Brian et al., 2018). Since packets included

in a series of ﬂows are aggregated, one record of each

ﬂow information is used for anomaly detection, which

reduces the processing load compared to performing

anomaly detection on a packet-by-packet basis, and

also reduces the volume of data transferred from the

gateway to the analysis server. Therefore, this study

uses IPFIX-based ﬂow-informed records of packets

sent from IoT devices for anomaly detection. On the

other hand, the ﬂow information is less available for

anomaly detection compared to the case where the

whole packets are used, so we need to devise ways to

improve the detection accuracy. In this paper, we pro-

pose the combination of white list and machine learn-

ing for improvement of accuracy.

2.3 Manufacturer Usage Description

MUD is an architecture standardized by the IETF in

RFC 8520 to deﬁne the normal behavior of devices

and to protect them from threats (Lear et al., 2019).

It is assumed that the device vendor prepares a rule

ﬁle called a MUD ﬁle, which deﬁnes IP addresses

and port numbers that are permitted to be commu-

nicated in advance. An IoT device equipped with a

MUD mechanism sends the URL of the MUD ﬁle to

the router when it is connected to the network, and

the router downloads the MUD ﬁle. When the de-

vice is operated, the router checks that the rules in the

MUD ﬁle match the information on the destination

and source of the communication, and then forwards

the packets. By allowing only vendor-deﬁned behav-

iors, the device can be protected from malware and

other threats. On the other hand, as the number of in-

fection route and malware types grows, sets of rules

need to be updated, which requires more man-hours

to operate.

There are also several studies on MUDs, e.g., au-

tomatic generation of MUD ﬁles from packets of IoT

devices and their embedding in a Software Deﬁned

Network (SDN) (Hamza et al., 2019). Hamza et al.

have published a tool for generating MUD ﬁles from

packets (Hamza et al., 2018). In this study, we used

this tool to generate MUD ﬁles from packets of IoT

devices to create a white list.

3 PROPOSED SYSTEM

In this section, we describe the system and the algo-

rithm for anomaly detection that is assumed in this

paper.

3.1 System Model

First, the system assumed in this paper is shown in

Figure 1.

In this paper, we assume home network use case

as an example. IoT devices in a home network send

and receive packets to the public network through a

home gateway. Although it is desirable to be able to

detect anomalies at the home gateway, it is not a good

idea to monitor all packets in detail due to the process-

ing load. Therefore, the ﬂow information of IPFIX is

transferred to an external analysis server. The IPFIX

ﬂow information is lighter than that of whole packets

and thus reduces the transmission load to the outside.

The analysis server receives the ﬂow information

and detects anomalies. After a device is connected

to the home network, the ﬂow information is used as

data for learning the device’s intrinsic behavior for a

period of time. The analysis server learns the behav-

ior of each device and creates a classiﬁer. After the

training period, the analysis server detects anomalies

using the received ﬂow information. If there are any

ﬂows that are considered to be anomalies, the home

gateway receives notiﬁcation, and measures such as

stopping communication with the public network are

taken.

3.2 Anomaly Detection using White

Lists and Machine Learning

In this paper, we propose the use of white lists based

on MUD to deﬁne normal communication using ap-

proaches other than machine learning. As described

in Section 2, MUD is an architecture to deﬁne the in-

trinsic behavior of devices and is suitable for model-

ing normal communication. We have been using ma-

chine learning algorithms such as Isolation Forest to

detect anomalies in the analysis server of the proposed

system. Isolation Forest is a tree structured anomaly

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

Table 1: An example of ﬁelds in IPFIX format.

ﬂowEndMilliseconds sourceMacAddress destinationMacAddress sourceIPv4Address destinationIPv4Address

2019-07-01 00:00:38 a1:b1:c1:d1:e1:f1 a2:b2:c2:d2:e2:f2 192.168.1.1 192.168.1.xx

2019-07-01 00:01:02 a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 192.168.1.xx 192.168.1.1

2019-07-01 00:01:02 a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 192.168.1.xx xxx.xxx.xxx.xxx

2019-07-01 00:01:02 a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 192.168.1.xx yyy.yyy.yyy.yyy

2019-07-01 00:01:02 a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 192.168.1.xx 192.168.1.1

sourceTransportPort destinationTransportPort protocolIdentiﬁer packetTotalCount octetTotalCount

60555 137 17 2 156

6074 53 17 1 64

40860 123 6 1 76

42567 80 6 2 226

8 0 1 10 840

Figure 1: System model of home network use case.

detection algorithm (Liu et al., 2008). We have con-

ﬁrmed that we could detect more than 96% of the

malware behavior including communication with the

C&C server even when only the ﬂow information was

used instead of the whole packet.

On the other hand, there is a problem that there are

many false positives that judge the normal communi-

cation of the device as the behavior of the malware.

One of the reasons for this is that normal communica-

tion is not well modeled, especially for devices with

complex behaviors or those with extremely low nor-

mal communication, such as smart speakers and smart

TVs, or some environment sensors.

Therefore, in order to improve the accuracy of

judging normal communication as normal, we use a

MUD specialized to deﬁne normal communication

of devices. Device vendors are expected to create

MUDs, and other than device vendors, it is also possi-

ble to create MUDs according to the speciﬁcations. In

this study, we generated MUD rules using ”Mudgee,”

a tool for generating MUD ﬁles from packets, which

has been published by Hamza et al. In order to protect

devices from malware threats using MUDs alone, it is

necessary to update the rule ﬁles every time the num-

ber of infection routes and types of malware increase,

and this requires a lot of man-hours to operate. There-

fore, by combining MUD rules that are automatically

generated from packets and anomaly detection by ma-

chine learning, we can ensure security even when the

device vendor cannot operate the MUD successfully.

An example of the generated MUD rules is shown

in Table 2.

Mudgee reads the PCAP ﬁle and generates the

ﬂow information. For each ﬂow included in the ﬂow

information, the MUD rules are generated by adding

each communication direction and protocol to the ac-

cess control list. Although the access control list

can be deﬁned as ”accept” or ”drop”, in the case of

Mudgee, it accepts the destination that appears in the

ﬂow. Some of the rules allow for all sources and des-

tinations. Such rules should not be included in the

white list and are excluded.

In order to improve the detection accuracy, our

system has a dictionary period to deﬁne the normal

behavior of the device separately from the training pe-

riod. For example, the training period is two weeks

and the dictionary period is the ﬁrst week of that pe-

riod. We keep a dictionary of IP addresses that the

device communicated to during the dictionary period,

and create features for machine learning depending on

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest

Table 2: An example of MUD rules.

srcMac dstMac ethType srcIp dstIp ipProto srcPort dstPort priority icmpType icmpCode

a1:b1:c1:d1:e1:f1 a2:b2:c2:d2:e2:f2 0x0800 192.168.1.xx xxx.xxx.xxx.xxx 6 48970 443 810 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 yyy.yyy.yyy.yyy * 6 443 * 750 * *

a1:b1:c1:d1:e1:f1 a2:b2:c2:d2:e2:f2 0x0800 xxx.xxx.xxx.xxx * 6 80 * 750 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 * xxx.xxx.xxx.xxx 6 * 443 855 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 xxx.xxx.xxx.xxx * 6 80 * 750 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 * xxx.xxx.xxx.xxx 6 * 443 855 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 xxx.xxx.xxx.xxx * 6 443 * 750 * *

a2:b2:c2:d2:e2:f2 a1:b1:c1:d1:e1:f1 0x0800 192.168.1.xx xxx.xxx.xxx.xxx 6 56840 443 810 * *

whether the destination address of the communication

during the training period is included in the dictionary

or not. By using the dictionary period, the jitters of

device behavior can be learned. In this paper, we gen-

erated MUD rules by inputting packets of dictionary

periods for each device into the Mudgee.

The ﬂow of anomaly detection using MUD and

machine learning is shown in Figure 2.

Figure 2: Flow of anomaly detection.

First, we check whether the target ﬂow conforms to

the MUD rules of the device. If there is a match, the

ﬂow is considered to be normal. If no match is found,

the ﬂow is input to the classiﬁer and an error is de-

tected. In this paper, we use Isolation Forest, which is

capable of fast and accurate unsupervised learning for

anomaly detection. The unsupervised learning system

is suitable for this system because there is no need to

use the communication data of a malware infection

and the learning can be performed under the same

conditions as the real environment.

4 EVALUATION OF IPFIX

In this section, we evaluate the performance of IPFIX

and show the effectiveness. As the data for anomaly

detection, PCAP is commonly used. Similar to IP-

FIX, the PCAP without TCP/UDP payload can be

used for lightweight analysis. Here, we call it as

PCAP information. So we compare the IPFIX record

and PCAP information in this section.

4.1 Evaluation Data

First, we describe the data used in this paper. As the

data for evaluation, normal communication data of

the IoT device and anomaly communication data after

malware infection are required. For normal communi-

cation, we captured packets from the actual operation

of the IoT device for one month. The list of devices

used is shown in Table 3.

Table 3: IoT device list.

Device category No. of Devices

Smart camera 6

Smart speaker 5

IoT gateway 5

Environment sensor 2

Door phone 1

Light 1

Cleaner 1

Remote controller 1

Smart TV 1

Total 23

Here, IoT gateways are devices that integrate and con-

vert the communication of multiple IoT devices.

In order to compare the performance of IPFIX

and PCAP as data for anomaly detection, we con-

verted these collected packets into the IPFIX format

record and PCAP information. These data include

ﬁelds used for anomaly detection such as Timestamp,

source and destination MAC address, IP address, port

number, protocol, and packet length. We compared

data size and number of records for the IPFIX and

PCAP information, and the result is shown in Table 4.

Table 4: Comparison of IPFIX and PCAP information.

IPFIX PCAP information

Data size 49.4 MB 301 MB

Record num 5,319,778 23,763,198

From this result, we can ﬁnd that IPFIX reduces data

size and the number of records. This is because IPFIX

aggregates multiple communications included in one

ﬂow into one record. Thus, the effectiveness of IPFIX

is shown.

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

5 EVALUATION OF ANOMALY

DETECTION

In this section, we evaluate the accuracy of anomaly

detection by the proposed method.

5.1 Evaluation Data

As the data for accuracy evaluation, normal commu-

nication data of the IoT device and anomaly commu-

nication data are required.

Normal communication data is the same as that

used in Section 4. For the anomaly data, we created

packets that imitate the typical behaviors of malware

infection, such as C&C communication, host scan-

ning, and DoS attacks, and converted them into IP-

FIX. For the preparation of the simulated packets, we

prepared a total of 15 patterns based on the captured

packets of DoS attacks, host scans, and C&C server

communication, in which malware samples were col-

lected using honeypots and operated in a secure en-

vironment, and modiﬁed parameters such as commu-

nication interval and number of destinations. The pa-

rameters for each malware behavior are shown in Ta-

ble 5.

We mixed anomaly communications with test data

from one device and evaluated the detection accuracy

for each device.

5.2 Evaluation Flow

The evaluation ﬂow on anomaly detection is shown in

Figure 3.

Figure 3: Evaluation ﬂow.

First, we selected the device to be evaluated. Then,

we generated features from the normal communica-

tion of the device and the malware communication.

The features were generated as 20-dimensional vec-

tors by One hot encoding using the dictionary period

described in Section 3. Descriptions of the features

are shown in Table 6.

For example, whether or not the destination IP ad-

dress is one that appeared in the dictionary period,

and whether or not the number of packets is less

than the threshold. The threshold has ﬁve variations:

average, average+standard deviationσ, average+2σ,

average+3σ, and more than average+3σ of the num-

ber in the dictionary period.

Then, the normal communication is divided into

train data and test data. The data used in this study

includes one month communication data for each de-

vice, and the ﬁrst two weeks are used as train data

and the second two weeks as test data. By mixing

test data with malware data, we can create a malware-

infected state for the device. And then, the classiﬁer

determines whether each record is normal or anoma-

lous. The classiﬁer is created with Isolation Forest

based on the training data. The test data are ﬁrst

checked against the white list generated by the MUD.

The records that match the white list are judged as

normal, and the records that do not match are input

to the classiﬁer to determine whether they are normal

or anomalous. The above operations are repeated for

each device, and the detection results are acquired.

5.3 Evaluation Result

The detection results are obtained by combining the

results of the white list and Isolation Forest. In this

section, we denote the anomaly communication to be

detected as Positive and the normal communication

as Negative. Since white list matching is to determine

whether the communication is normal or not, the re-

sults are divided into True Negative (TN) and False

Negative (FN). The results of the Isolation Forest are

expressed as a mixed matrix including True Positive

(TP) and False Positive (FP) in addition to TN and

FN. Here, TN and FN by the white list are denoted as

T N

and FN

, and the results by Isolation Forest are

denoted as T N

, FN

, T P

and FP

. True Positive Rate

(TPR) and False Positive Rate (FPR) of the white list

and Isolation Forest for one device can be expressed

as follows.

T PR =

T P

+ FN

+ T P

(1)

FPR =

T N

+ T N

+ FP

(2)

In this paper, we show the effectiveness of the pro-

posed method by comparing the evaluation results of

average TPR and FPR of target devices with and with-

out the white list.

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest

Table 5: Malware behavior parameters.

Type Cycle

0.33[sec]

1[min]

C&C 1[hour]

12[hour]

24[hour]

Type No. of destIP per sec

100

200

Host scan 500

1000

3000

Type No. of packets per sec

100

500

DoS 1000

1500

3000

Table 6: Feature vectors.

Feature Deﬁnition

Dest IP Destination IP address is included in dictionary data.

Dest IP (24bit) The ﬁrst 24 bits of destination IP are included in dictionary data.

Dest port Destination port is included in dictionary data.

Dest IP&port pair Pair of destination IP and port is included in dictionary data.

Well known port Destination port number is below 1024.

Protocol Protocol is TCP.

Has response It has the same source IP& port pair as the destination IP& port pair.

Response count The number of response packets is larger than the record.

Response length The length of response packets is larger than the record.

Has similar packet There are different packets only for the destination port or source port.

Number of packets The number of packets is below the threshold.

Length of packets The length of packets is below the threshold.

5.3.1 Result of Conventional Method

In this paper, the anomaly detection method based

on machine learning standalone is called the conven-

tional method. Here, we adapted the method used in

our previous work (Nakahara et al., 2020) to IPFIX.

First, Table7 shows the results of the conventional

method without a white list.

Table 7: Results of conventional method.

Prediction

Anomaly Normal

Answer Anomaly 228000 3

Normal 9001 98315

Here, we present the average of the results of all

23 devices used in the evaluation. From the table,

T P

= 228000, FN

= 3, FP

= 9001, T N

= 98315,

and we can calculate that T PR = 0.999, FPR = 0.092.

This result indicates that although almost no malware

is missed, the false positive rate is high (9.2%), which

means that for practical purposes, alerts are often is-

sued even when the device is used normally.

5.3.2 Result of White List Standalone

Here, we consider using only the white list for

anomaly detection. Records that match the white list

are judged as normal and those that do not match are

judged as anomalous.

Table 8 shows the results of the white list-based

proposed method.

Table 8: Results of white list standalone.

Prediction

Anomaly Normal

Answer Anomaly 228003 0

Normal 51974 55341

The number of records captured by the white list was

55341. No record has been mistakenly allowed by

the white list for malware, so results are FN

= 0,

T N

= 55341. Other 279977 records are judged as

anomalous and the actual number of anomalies is

228003, so T P

= 228003, FP

= 51974. Then, we

calculated the average FPR of all devices and the re-

sult is FPR = 0.661.

This may be due to the change in the behavior

of devices between the training and testing periods.

Therefore, we checked the changes in the port num-

ber pairs of the destination IP addresses on which the

MUDs are based between the training and testing pe-

riods. We calculated the ratio of unique pairs of IP

addresses and port numbers in the test period that ap-

peared also in the training period. The result is shown

in 4.

For all devices, the value is greater than or equal to

0.22, and for some devices, it is above 0.90. The av-

erage ratio was 0.647. In this situation, if all commu-

nications that do not match the white list are judged

as anomaly, many false positives will occur. This

shows that the behavior of devices changes frequently

and that white lists alone cannot detect anomalies cor-

rectly.

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

Figure 4: Ratio of changed unique pairs of IP and port.

Based on the above, we consider the hybrid system

using the machine learning and white list.

5.3.3 Result of Proposed Method

Next, Table 9 shows the results of the white list-based

proposed method.

Table 9: Results of proposed method.

Prediction

Anomaly Normal Normal

(iForest) (iForest) (WL)

Answer Anomaly 228000 3 0

Normal 6156 45818 55341

The result of the white list decision is shown in Be-

nign(WL), and the values are the same as the previ-

ous section. The prediction results of Isolation Forest

are shown in Anomaly(iForest) and Normal(iForest).

is still 3, but FP

is decreased from 9001 to 6156.

And the average TPR and FPR of all devices are cal-

culated as T PR = 0.999, FPR = 0.057. The results

show that the false positive detection rate could be re-

duced by about 3.5% without reducing the positive

detection rate.

Figure 5 shows the results of calculating the FPR

for each device for the proposed and conventional

methods.

This ﬁgure shows that the FPR has been reduced in

almost all devices. In particular, we have been able to

signiﬁcantly reduce the FPR in smart speakers, where

the device’s intrinsic behavior is complex, and in

IoT gateways, which aggregate the communication of

multiple devices. Although it was difﬁcult to distin-

guish between normal communication and malware

communication in these devices by machine learning

alone, the white list makes it easier to distinguish be-

tween them by narrowing down the detection targets.

In addition, in some environmental sensors, some fea-

tures, such as the presence or absence of communica-

Figure 5: FPR per device.

tion to the well-known port and the protocol, some-

times generate patterns similar to those of anomaly

communication, and many false positives were gener-

ated.

These results indicate that the combination of

white list and machine learning can improve the false

positive detection rate without reducing the positive

detection rate compared to machine learning.

5.3.4 Result of Customized White List

Finally, in order to increase the number of normal

records captured by the white list, we loosen the rule

of the white list. Here, we created the white list using

only 24 bits of the destination IP address included in

the MUD ﬁle.

Table 10 shows the results of the loose customized

white list method.

Table 10: Results of customized white list method.

Prediction

Anomaly Normal Normal

(iForest) (iForest) (WL)

Answer Anomaly 227975 1 27

Normal 1796 9195 96324

We can see that FP

is decreased to 1796. And the

average TPR and FPR of all devices are calculated as

T PR = 0.999, FPR = 0.032. This is because more

normal records are captured by the customized white

list. On the other hand, as shown in Benign(WL)

where FN

= 27, some records have been mistak-

enly allowed by the white list. These results show that

there is a trade-off between true and false negatives in

the granularity of the white list.

Table 11 shows the results of comparison be-

tween conventional method and two types of pro-

posed method.

This result shows that the white list contributes to

the decrease of the false positive rate and trade-off

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest

Table 11: Comparison of detection results.

TPR FPR

Conventional 0.9999 0.0928

White list 0.9999 0.0570

Customized white list 0.9998 0.0325

between TPR and FPR can be controlled by changing

the granularity of the white list.

6 CONCLUSIONS

In this paper, we proposed a method that combines

a white list created by MUD with machine learning

to detect malware infection in IoT devices. By us-

ing the white list, we can exclude normal commu-

nications that have been misclassiﬁed as malware by

machine learning alone from anomaly detection, and

thus reduce false positives. We evaluated the accuracy

of anomaly detection using a dataset of normal and

malware communications, and conﬁrmed that the pro-

posed method reduced the false detection rate. More-

over, the performance varied by changing the rule of

the white list. Future work includes investigating how

to create more effective white lists, applying them

to other machine learning algorithms, and evaluating

them using more practical datasets.

REFERENCES

Abdalla, P. A. and Varol, C. (2020). Testing iot security:

The case study of an ip camera. In 2020 8th Interna-

tional Symposium on Digital Forensics and Security

(ISDFS), pages 1–5. IEEE.

Ahmed, S., Lee, Y., Hyun, S.-H., and Koo, I. (2019). Unsu-

pervised machine learning-based detection of covert

data integrity assault in smart grid networks utilizing

isolation forest. IEEE Transactions on Information

Forensics and Security, 14(10):2765–2777.

Alam, M. S. and Vuong, S. T. (2013). Random forest

classiﬁcation for detecting android malware. In 2013

IEEE International Conference on Green Computing

and Communications and IEEE Internet of Things and

IEEE Cyber, Physical and Social Computing, pages

663–669. IEEE.

Antonakakis, M., April, T., Bailey, M., Bernhard, M.,

Bursztein, E., Cochran, J., Durumeric, Z., Halderman,

J. A., Invernizzi, L., Kallitsis, M., et al. (2017). Un-

derstanding the mirai botnet. In 26th USENIX Security

Symposium (USENIX Security 17), pages 1093–1110.

Brian, T., Chris, I., Michael, D., Emily, S., Dan, R.,

Matt, C., and the CERT Network Situational Aware-

ness Group Engineering Team (2018). Yaf documen-

tation. https://tools.netsa.cert.org/yaf/yaf.html. Ac-

cessed: 2020-11-17.

Claise, B., Trammell, B., and Aitken, P. (2013). Speciﬁ-

cation of the ip ﬂow information export (ipﬁx) pro-

tocol for the exchange of ﬂow information. https:

//tools.ietf.org/html/rfc7011. Accessed: 2020-11-17.

Ding, Z. and Fei, M. (2013). An anomaly detection ap-

proach based on isolation forest algorithm for stream-

ing data using sliding window. IFAC Proceedings Vol-

umes, 46(20):12–17.

Doshi, R., Apthorpe, N., and Feamster, N. (2018). Ma-

chine learning ddos detection for consumer internet of

things devices. In 2018 IEEE Security and Privacy

Workshops (SPW), pages 29–35.

Fortino, G., Savaglio, C., Spezzano, G., and Zhou, M.

(2020). Internet of things as system of systems: A

review of methodologies, frameworks, platforms, and

tools. IEEE Transactions on Systems, Man, and Cy-

bernetics: Systems.

Hamza, A., Gharakheili, H. H., Benson, T. A., and Sivara-

man, V. (2019). Detecting volumetric attacks on lot

devices via sdn-based monitoring of mud activity. In

Proceedings of the 2019 ACM Symposium on SDN Re-

search, pages 36–48.

Hamza, A., Ranathunga, D., Gharakheili, H. H., Roughan,

M., and Sivaraman, V. (2018). Clear as mud: gener-

ating, validating and applying iot behavioral proﬁles.

In Proceedings of the 2018 Workshop on IoT Security

and Privacy, pages 8–14.

Hasan, M., Islam, M. M., Zarif, M. I. I., and Hashem, M.

(2019). Attack and anomaly detection in iot sensors in

iot sites using machine learning approaches. Internet

of Things, 7:100059.

Hassija, V., Chamola, V., Saxena, V., Jain, D., Goyal, P., and

Sikdar, B. (2019). A survey on iot cecurity: Applica-

tion areas, security threats, and solution architectures.

IEEE Access, 7:82721–82743.

Jung, O., Smith, P., Magin, J., and Reuter, L. (2019).

Anomaly detection in smart grids based on software

deﬁned networks. In Proceedings of the 8th Interna-

tional Conference on Smart Cities and Green ICT Sys-

tems - SMARTGREENS,, pages 157–164. INSTICC,

SciTePress.

Kimani, K., Oduol, V., and Langat, K. (2019). Cyber se-

curity challenges for iot-based smart grid networks.

International Journal of Critical Infrastructure Pro-

tection, 25:36–49.

Kolias, C., Kambourakis, G., Stavrou, A., and Voas, J.

(2017). Ddos in the iot: Mirai and other botnets. Com-

puter, 50(7):80–84.

Lear, E., Droms, R., and Romascanu, D. (2019). Manufac-

turer usage description speciﬁcation. https://tools.ietf.

org/html/rfc8520. Accessed: 2020-11-17.

Liu, F. T., Ting, K. M., and Zhou, Z.-H. (2008). Isolation

forest. In 2008 Eighth IEEE International Conference

on Data Mining, pages 413–422. IEEE.

Madeira, R. and Nunes, L. (2016). A machine learning ap-

proach for indirect human presence detection using iot

devices. In 2016 Eleventh International Conference

on Digital Information Management (ICDIM), pages

145–150.

Mizuno, S., Hatada, M., Mori, T., and Goto, S. (2017).

Botdetector: A robust and scalable approach toward

IoTBDS 2021 - 6th International Conference on Internet of Things, Big Data and Security

detecting malware-infected devices. In 2017 IEEE

International Conference on Communications (ICC),

pages 1–7. IEEE.

Mohanapriya, A. et al. (2020). Survey on security of iot. In

2020 International Conference on Computer Commu-

nication and Informatics (ICCCI), pages 1–8. IEEE.

Nakahara, M., Okui, N., Kobayashi, Y., and Miyake, Y.

(2020). Machine learning based malware trafﬁc de-

tection on iot devices using summarized packet data.

In IoTBDS, pages 78–87.

Nguyen, T. D., Marchal, S., Miettinen, M., Fereidooni, H.,

Asokan, N., and Sadeghi, A.-R. (2019). D

ıot: A

federated self-learning anomaly detection system for

iot. In 2019 IEEE 39th International Conference on

Distributed Computing Systems (ICDCS), pages 756–

767. IEEE.

Soltan, S., Mittal, P., and Poor, H. V. (2018). Blackiot: Iot

botnet of high wattage devices can disrupt the power

grid. In 27th USENIX Security Symposium (USENIX

Security 18), pages 15–32.

Su, J., Vasconcellos, V. D., Prasad, S., Daniele, S., Feng,

Y., and Sakurai, K. (2018). Lightweight classiﬁca-

tion of iot malware based on image recognition. In

2018 IEEE 42nd Annual Computer Software and Ap-

plications Conference (COMPSAC), volume 2, pages

664–669. IEEE.

Zulkipli, N. H. N., Alenezi, A., and Wills, G. B. (2017).

Iot forensic: Bridging the challenges in digital foren-

sic and the internet of things. In Proceedings of the

2nd International Conference on Internet of Things,

Big Data and Security - IoTBDS,, pages 315–324. IN-

STICC, SciTePress.

Malware Detection for IoT Devices using Automatically Generated White List and Isolation Forest
