Source Code based Approaches to Automate Marking in

Programming Assignments

Thilmi Kuruppu, Janani Tharmaseelan, Chamari Silva, Udara Srimath S. Samaratunge Arachchillage,

Kalpani Manathunga, Shyam Reyal, Nuwan Kodagoda and Thilini Jayalath

Faculty of Computing, Sri Lanka Institute of Information Technology (SLIIT), Malabe, Sri Lanka

Keywords: Automated Assessments, Whitebox, Machine Learning, Syntax Graph, Static Tools, Literature Review,

Programming.

Abstract: With the embarkment of this technological era, a significant demand over programming modules can be

observed among university students in larger volume. When figures grow exponentially, manual assessments

and evaluations would be a tedious and error-prone activity, thus marking automation has become fast

growing necessity. To fulfil this objective, in this review paper, authors present literature on automated

assessment of coding exercises, analyse the literature from four dimensions as Machine Learning approaches,

Source Graph Generation, Domain Specific Languages, and Static Code Analysis. These approaches are

reviewed on three main aspects: accuracy, efficiency, and user-experience. The paper finally describes a series

of recommendations for standardizing the evaluation and benchmarking of marking automation tools for

future researchers to obtain a strong empirical footing on the domain, thereby leading to further advancements

in the field.

1 INTRODUCTION

1.1 Background and Motivation

Programming assignments are an essential element in

computer programming modules taught at university.

With the growth of class sizes, evaluating

assignments become challenging (Higgins, Gray,

Symeonidis, & Tsintsifas, 2005) and researchers

explore novel methods to automate assessments.

Marking automation has advantages like speed,

consistency, reduced need for post-marking

moderation, better utilisation of human-hours, and

eliminate favouritism and bias from the marking

(Ala-Mutka, 2005). As an illustrative example, the

authors’ university has 10 programming modules in

the undergraduate programs, each with 2

assignments, with an average of 1000 students,

resulting in 20,000 programming assignments per

semester. An average time of 20 minutes was

estimated to mark each programming assignment

which results in 400,000 human hours spent on

marking each academic semester.

Figure 1: Hierarchy of marking automation approaches.

Automatic marking approaches can fall into two

broad categories – Blackbox testing and Whitebox

testing as shown in Figure 1.

Blackbox testing, as per its definition, focuses on

the program producing the expected output for a

given input. A number of Blackbox testing

approaches like Unit Testing exists and is used in a

number of commercial and non-commercial tools

(Rahman, Paudel, & Sharker, 2019) like REPL.it,

GradeScope, Moodle-Extension, Stacscheck by St

Andrews, etc. The major drawback of Blackbox

testing is that (a) programs should be developed with

an interface or API to provide inputs and obtain outputs

(via console, files, methods arguments and return

values, etc.) and (b) to produce an output, the program

should be syntactically correct, and run without errors

– both of which cannot be guaranteed with student

Kuruppu, T., Tharmaseelan, J., Silva, C., Arachchillage, U., Manathunga, K., Reyal, S., Kodagoda, N. and Jayalath, T.

Source Code based Approaches to Automate Marking in Programming Assignments.

DOI: 10.5220/0010400502910298

In Proceedings of the 13th International Conference on Computer Supported Education (CSEDU 2021) - Volume 1, pages 291-298

ISBN: 978-989-758-502-9

291

submissions. On the other hand, Whitebox Testing

assigns a mark by reading the submitted source code,

whether Blackbox testing is possible or not. It is usual

practice in universities to include a marking rubric that

has both a Blackbox and Whitebox component e.g. 50

marks for the program producing the correct outputs

for a given set of inputs, and 50 marks by reading the

source code – looking for correctness, neatness and

good coding practices, etc.

1.2 Contributions and Organisation

The main objective of carrying out this research work

is to study the holistic domain of marking automation

of programming assignments and provide a

panoramic view of the existing research approaches

in the domain. As illustrated in Fig.1, authors will

study only Whitebox testing approaches from four

different aspects, i.e., Machine Learning (ML)

approaches, source graph (SG)-based approaches,

programming languages (PLs) based approaches and

static code analysis (SCA) approaches. As

programming assignments, authors consider a piece

of any computer program provided as students’

answers. This paper does not address parts of the

assignment which have a different component in the

SDLC (e.g. design), where submissions may have

flowcharts, UML diagrams, test reports, coverage

reports, and integration reports etc.

The research paper is structured as follows: in

section II, authors provide a review of four identified

approaches i.e. ML, SG, PLs, and source code analysis.

These are critically evaluated on three main benchmark

criteria i.e. accuracy, efficiency, and user-experience

(UE). The section III provides a ‘meta-review’ based

on cross-literature-comparison to identify the strengths

and weaknesses in the current state-of-the-art, thereby

recognizing the suitability, scope, applicability,

limitations, and research gaps. A discussion of the

findings in sections II and III, providing the authors

interpretation, insights, and arguments is available in

the section IV. Finally, the section V provides

recommendations based on the findings and

discussion, for further advancement of the field.

2 LITERATURE REVIEW

2.1 Machine Learning (Ml)

Approaches

ML is one of the main approaches used to evaluate

the source code marking. Some existing ML

approaches follow the holistic approach. In the study

of (Srikant & Aggarwal, 2014), Linear Ridge

Regression and Support Vector Machine (SVM)

combined with different kernels based on rubric and

hand-graded predictions have been used as the

regression techniques. Also, (Srikant & Aggarwal

2014) uses random forests to determine the closeness

of the logic. The studies used one-class modelling as

the Prediction model. According to the results,

ridge regression showed better cross-validation and

error validation results than SVM regression.

It showed that more than 80% of the predicted grades

are within its corresponding expert rated grades.

Moreover, regression against expert-grades can

provide much better grading than the ubiquitous test-

case-pass based grading and rivals the grading

accuracy in marking.

Some studies provide personalized feedback for

the student submissions using ML, based on factors

like code quality and similarity (Zhou, et al., 2018) or

either fix the code minimally and present feedback for

a given solution against a marking rubric (Singh,

Gulwani, & Solar-Lezama, 2013). In (Zhou, et al.,

2018) similarity model distances were found by

transforming the features derived from the

assignment. (Singh, Gulwani, & Solar-Lezama,

2013) used a two-phase translation solution to

find minimal corrections. The effectiveness of the

tool was 64% of feedback for all incorrect attempts

within 10 seconds on average. The results were more

convincing in (Zhou, et al., 2018) approach that could

be viable for marking automation with its efficiency

and the accuracy rate.

A Rule-based system and linear regression

models had been used to predict the position of

compilation errors and assess uncompilable codes

(Takhar & Aggarwal, 2019). This was achieved using

n-gram based token prediction approach which is

called as Make Compliable (MC), Rule Relaxation

(RR). Then a ML model was developed by combining

MC and RR as RRMC. Performance measurements

were median for MC is 0.73, a higher value than for

RR (which was 0.69). RRMC approach resulted with

a mean of 0.71 correlations offering best results with

reduced time and effort. Another technique was

feature extraction using ML approaches to automate

marking student codes (Russell, et al., 2018). Linear

Support Vector Classification (Linear SVC),

Gaussian Naive Bayes and Multinomial Naive Bayes

have been used as three practical algorithms to

classify exam submissions and a holistic approach to

pick up the pattern from manually marked

submissions. Convolutional Neural Network (CNN)

and Recurrent Neural Network were used for feature

extraction (Russell, et al., 2018). It uses Linear SVC

CSEDU 2021 - 13th International Conference on Computer Supported Education

292

and Naïve Bayes as scoring functions, and it was

found that the Multinomial Naïve Bayes (MNB) over

Gaussian Naïve Bayes (GNB) where the most

accurate prediction gave a hit-rate of 73.39%. MNB

with weighted scoring had a prediction accuracy of

79.03%. Hence, Naive Bayes algorithm shows

promising results. In (Russell, et al., 2018) the best

results achieved using features learned via CNN and

classified with an ensemble tree algorithm.

2.2 Static Code Analysis (SCA) Tools

Striewe & Goedicke (2014) suggested the two

approaches regarding the analysis of source code as

Abstract Syntax Tree (AST) and Abstract Syntax

Graph (ASG). Furthermore, recursive methods can

identify using ASG, based on the inter-dependency

arcs in between operation declaration and its

invocation (Striewe & Goedicke, 2014), (Striewe M.

, 2014). In (Blumenstein, Green, Nguyen, &

Muthukkumarasamy, 2004), the famous code

analysis algorithms known as Abstract Interpretation

for execution path analysis has been introduced. It

produces higher accuracy, but results indicated lower

efficiency ratio. The authors have suggested how the

previous approach can be combined with the classic

analysis algorithm and elevate the level of

performance. Automated Static Analysis Tool

(ASAT) had been considered by couple of tools

proposed by different studies. Gallier (2015)

discussed regarding the logical inference introduced

with the tool called SMT solver. As illustrated in

Rautenberg (2010), horn clauses and logic

programming tools would be precursor to achieve the

most optimum solution by combining abstract

interpretation and the logical inference techniques

(Ala-Mutka, 2005), (Cousot, Cousot, & Mauborgne,

2013), (Vert, Krikun, & Glukhikh, 2013).

Another study (Vert, Krikun, & Glukhikh, 2013)

enumerated the most dominating SCA tools such as

Coverty SAVE Platform, Astree, PC-Lint/Flex Lint,

and Aegies. In addition, study of (Digitek-labs, 2011)

would be beneficial due to its unique feature analysis

considering the dimensions of accuracy and

performance. In the study of (Buyrukoglu, Batmaz, &

Lock, 2016), authors performed a comparative

analysis of SCA tools to check the coding

conventions of Java which explicitly discussed the

single versus multi files analysis and their prevailing

strengthens and weaknesses. Moreover, (Vetr`o,

2014) suggested that the learning approach would be

significant in detecting the raised false positives in the

codebase and successfully removing them using the

approach of Bayesian inference-based learning model

with training a neural network.

2.3 Programming Language based

Approaches

(Blumenstein, Green, Nguyen, &

Muthukkumarasamy, 2004), (Souza, Felizardo, &

Barbosa, 2016) provide an extensive list of

assessment tools used to evaluate programming

assignments and they had presented series of

classification schemas like assessment types (manual,

automatic or semi-automatic), approach (instructor-

centred, student-centred or hybrid), specialization

(tools for contests or for quizzes or for testing) and a

comprehensive analysis of tools (considering the type

of verification, language compatibility,

interoperability with IDEs and LMS, etc.) that assist

evaluation of programming assignments. Another

segmentation is that dynamic analysis of codes

assessing functionality, efficiency, and testing skills

of student’s vs. static checks to analyze and provide

feedback for style, programming errors, software

metrics, and even design (Ala-Mutka, 2005).

In (Blumenstein, Green, Nguyen, &

Muthukkumarasamy, 2004), authors introduced a

system to assess the student programming

assignments which are written using Java and C. To

extend the functionalities of the current system,

authors have introduced a Java framework where new

marker modules could be added manually. The

system GAME caters a better UE by providing a

simple GUI and the evaluation summery. Authors

have increased the flexibility through java

framework. It concluded that system could produce

high accuracy results due to evaluation process of

having specific rubric for assignments. A separate

interpretation of the system will be accessible to the

students to execute in future developments and

collect the feedback.

CourseMarker (Higgins, Gray, Symeonidis, &

Tsintsifas, 2005) can be used to mark command-line

driven Java and C++ programming assignments with

correct configurations. The evaluation happens using

several stages and internal tools as typographical tool

(to check layouts), dynamic tool (solutions compared

against test data), feature tool (check specific

syntaxes such as “if-then-else” blocks), flowchart

tool, object-oriented tool and logic tool (to check

logic circuits) marks at least as well as humans do,

provides on-demand, impartial feedback, and as a

bonus saves hundreds of marking hours for the

academic staff. Another study (Buyrukoglu, Batmaz,

& Lock, 2016) employs semi-automatic code

Source Code based Approaches to Automate Marking in Programming Assignments

293

assessing, considering the program structures like

sequence and iteration. Novice’s code is compared

with the manually marked sample and using code

similarity the rest of the scripts are assessed. Human

markers may also provide feedback. The process

includes a segmentation stage, codifying process,

grouping, and marking.

Automated assessments using a Domain Specific

Language (DSL) called Output semantic-similarity

Language (OSSL) had been proposed in (Fonte &

Cruz, 2013). A Flexible Dynamic Analyzer

architecture with the components like OSSL and its

grammar to specify output specification are

extensively discussed. The approach supports for

partial marking of code scripts and for

interoperability with any automated grading system

that support for Learning Objects. Immediate

evaluation is possible by running the program over a

set of predefined tests and comparing each result (the

actual output produced by the submitted code) against

an expected output specification. Yet, authors had not

conducted a proper evaluation of the approach or the

DSL, which may limit the paper as a conceptual

model.

2.4 Source Graph based Approaches

Graph is a mathematical model that shows

connections between elements where it describes

rules over sets of nodes and edges of a graph. A

program written in a PL can be transformed into a

syntax tree by a parser. When additional information

such as bindings are included in the representation,

the syntax tree is extended into a syntax graph

(Rensink & Zambon, 2009). One study gives a review

of tools useful in automated grading and tutoring in

the context of object-oriented programming with Java

(Striewe & Goedicke, 2014). Authors emphasize on

the necessity of tools being able to process multiple

source files. According to authors, in pre-processing

steps, extending syntax trees to syntax graphs with

additional information helps achieving more flexible

and exercise specific configurations. When such

automated tools are more general, more effort is

necessary to perform specialized tasks. Since learning

scenarios may require very specialized and even

exercise specific checks which are not among the

standard checks offered by program analysis tools,

these authors suggest that integration of several tools

can be more productive.

In (Striewe M. , 2014), the suitability of three data

structures: Strings, Trees and Graphs has been

evaluated. As mentioned,

trees are limited because

they only allow one parent per node hence, they could

not represent different kinds of relations like “is

defined in” and “is called by” between elements. To

check for recursive methods, it is necessary to have

this information. Graph-based representations can be

used to store this information, because they allow an

arbitrary number of connections between nodes.

Therefore, authors concluded that the attributed

graphs are an appropriate representation of any kind

of code analysis. Study used TGraphs to handle

attribute graphs where it designed for efficient

handling and analysing of large graphs. Queries on

this graph format are expressed using a query

language named GReQL. The GReQL for queries on

TGraphs can be extended by user defined functions.

In (Striewe M. , 2014) two solutions have been used

to analyse the syntax graphs: a graph transformation

tool and a graph query engine. As concluded, both

techniques can create pre-defined generic sets of rules

that are independent of specific exercises.

3 THE META-REVIEW

3.1 Machine Learning based

Approaches

Grades for the programming assignments can be

evaluated in many ways, among those, ML is

outweighing the other approaches (Korkmaz &

Correia, 2019). The reason behind this is the ability

of “learning” of the model. It can analyse the new

codes and learn, hence marking structure is up to date

and more accurate. Here, the focus is on the accuracy,

efficiency and configurability of different ML

algorithms found in the literature. Linear ridge

regression, random forests and kernel based SVM,

Naive Bayes (Multinomial Naive Bayes and Gaussian

Naive Bayes), SVM can be identified as most popular

and effective algorithms used in the literature. When

comparing, linear ridge regression largely shows

better cross-validation and error validation results

than random forests and kernel-based SVM (Srikant,

& Aggarwal, 2014). Moreover, regression can

provide much better grading than the test-case-pass

based grading. When the uncompilable codes to be

corrected up to some level where if the exams give

more priority to algorithms and logic, not for the

program syntaxes. In that case linear ridge regression

models were best. However, results also shows that

models built using both, semantic features and test-

cases shows better results. Moreover, developing of

problem independent grading techniques which may

be facilitated by efficient one-class modelling

techniques is shown as a necessity. On the other hand,

CSEDU 2021 - 13th International Conference on Computer Supported Education

294

the proposed algorithms need to train to use for more

diverse problems which is a need in the future.

3.2 Static Code Analysis Tools

Number of SCA tools exponentially grow with the

advancement of the technology and those support for

different PLs in different scale, and this paper mainly

focuses on their contributions over evaluating

programming assignments. To analyse the source

code there are two approaches that can be used as

AST and ASG and the ASG is an enriched version of

the tree, but it comprises additional arcs (Striewe &

Goedicke, 2014). Compared to the AST, the ASG

contains a couple of advantages as it can easily detect

irrelevant pieces of code, for instance, unused

methods can be identified using the method

declaration nodes and ASG is capable of easily

identifying recursive methods based on the cyclic

dependency arcs in-between method declaration and

method call nodes (Novak & Krajnc, 2010).

Consequently, most SCA tools tend to use ASG as its

main analytical technique. Some studies suggest

generating ASG from AST to increase the accuracy

as a valuable pre-processing step before evaluating

the source code in programming assignments

(Striewe & Goedicke, 2014), (Striewe M. , 2014),

(Gallier, 2015), (Rautenberg, 2010), (Cousot, Cousot,

& Mauborgne, 2013), (Vert, Krikun, & Glukhikh,

2013).

Furthermore, when analysing large volumes of

programming assignments, efficiency and accuracy

are the most significant factors to be considered. But

when increasing the accuracy, the performance factor

would compensate, hence achieving an optimum

performance for the highest precision is the key

concern here. To increase the accuracy, “Abstract

interpretation” is a well-known code analysis

algorithm (Cousot P. , 1996) which analyses every

execution path without violating the reliability of the

analysis. It analyses paths separately to achieve

maximum accuracy, but it degrades the performance

factor in a significant ratio. As a solution the joint

path analysis could be used, which assumes joining

variable values at flow conjunction point. However,

that leads to lower accuracy, but it gains satisfactory

performance level. Another possible approach to

increase the precision while using the joint path

analysis is combining the classic analysis algorithm

(Glukhikh, Itsykson, & Tsesko, 2012). Nevertheless,

this dependency analysis partially compensates on

reducing the level of accuracy because of joining

paths during the analysis. To further optimize the

situation dependency analysis implemented using

logical inference methods and tools such as first and

higher-order logic (Gallier, 2015), SMT solvers, and

Horn clauses and logic programming tools would be

instrumental. Considering the literature Patric Cousot

suggested a mathematical model of integrating

abstract

interpretation with a logical inference as the

Table 1: Emerged Static Code Analysis Tools.

Tool Capability Language support Related work

Coverity

SAVE

1. Provide accuracy 80% - 90%

2. Detects 7 errors per 1000 LOC

3.Understand Patterns and Programming idioms (Design Patterns

intelligence)

4.Seamless integration with any build system

C/C++, Java and C#

(Vert, Krikun, &

Glukhikh, 2013)

Astree

1. Capable of identifying run-time errors

2. capable of analyzing medium-scale industry-based projects.

3. Analyze 100,000 (LOC)

4. The tool can detect dead-code and uses abstract semantic

domains

5. Perform their main analysis procedure from top to bottom

C language

(Cousot, Cousot,

& Mauborgne,

2013)

FlexeLint/

PC Lint

1. This performs data flow/control flow analysis

2. It performs the interprocedurally analysis

3. Tool enhances user experience by user-defined semantic

checking of functional arguments

C/C++ programs

(FlexLint for UNIX,

Mac OS, Solaris

platforms) PC-Lint

for Windows

(Vert, Krikun, &

Glukhikh, 2013)

Aegis

1. Simple dependency analysis to increase the accuracy.

2. Can be used as for defect detection and for decision of other

program engineering tasks

3. Used to analyze many open-source projects

C90 and C++ 98

source code

(Digitek-labs,

2011),

Checkstyle

1.Find naming convention errors

2.Identify whitespaces, line, length specific errors, wrong use of

brackets

Java code

(Ashfaq, Khan,

& Farooq, 2019)

Source Code based Approaches to Automate Marking in Programming Assignments

295

most optimized solution (Ala-Mutka, 2005), (Cousot,

Cousot, & Mauborgne, 2013), (Vert, Krikun, &

Glukhikh, 2013). Currently there are lots of elegant

tools available, depicted in Table 1 as a result of

research and development activities which gains high

accuracy and performance levels.

Problem in most code analysis tools is that those

generate false warnings. It causes a significant drop

in the precision level of the outcome. The literature

attempted to fulfil the gap in removing static analysis

warnings on software quality metrics. A neural

network has been trained and the Bayesian inference-

based learning model (Vetr`o, 2014) used on top of

the extracted byte code, and AST used as the

underlying analysis technique which improves the

prediction of false positive in SCA.

3.3 Programming Language based

Approaches

Literature can be found with classifying student-led

or teacher-led tools considering efficiency and

extensibility has been addressed by LMS or IDE

extension whereas usability has achieved using

automated feedback or verification techniques

(Souza, Felizardo, & Barbosa, 2016). GAME

(Blumenstein, Green, Nguyen, &

Muthukkumarasamy, 2004) tool offers a good UE

with a simple GUI and a summary of the evaluation.

Authors have increased the flexibility of the system

by introducing a Java framework to extend the

functionalities. Since the student answers are

evaluating over a marking schema, accuracy of the

results is high. CourseMaker (Higgins, Gray,

Symeonidis, & Tsintsifas, 2005) can mark at least as

well as humans do, though they have not given any

statistics on the fact. The tool is reliable as it uses

Java’s exception handling mechanisms and provide

impartial feedback on demand while saving time.

Extensibility has been considered by customizing the

exercises or by customizing the marking server,

enabling integration of additional features. In

(Buyrukoglu, Batmaz, & Lock, 2016), humans need

to mark only 32 from a sample of 153 (27%) which

indicates a reduction of human effort. This system

provides feedback to students. But the complete

process of marking highly depends on the question

preparation and teachers need to pay attention to

detail at that stage. DSL based approach (Fonte &

Cruz, 2013) had not carried out a proper evaluation

study. Hence, accuracy of the tool or efficiency had

not been addressed. Yet, authors claim that their

approach is user-friendly and interoperable with any

other system that support to Learning Objects.

3.4 Source Graph based Approaches

In (Striewe & Goedicke, 2014), a review on tools

useful in automated grading and tutoring is

conducted. In reviewing the tools, authors have given

attention on graphs on how to increase the

configurability of the tools when the syntax graphs

are used. Authors have not given an attention

specifically on syntax graphs on the context that how

the syntax graphs affect on the accuracy or efficiency

of a tool. But authors have made a general comment

on how integration of different tools could increase

efficiency. Syntax graphs are an appropriate

representation for the code analysis (Striewe M. ,

2014). It makes the solutions more accurate and

flexible. Authors mention that the attributed graphs

make it efficient to handle large graphs. Also, authors

have used a query language on the graphs, which

provides the configurability on for the user defined

functions. In another study, graph transformation had

been used for source code analysis (Rahman, Paudel,

& Sharker, 2019) which concluded that the graph

transformations improve the accuracy and flexibility

of the solution.

4 DISCUSSION

The existing literature review discussed four major

approaches: ML, SG-based, PL-based, and SCA. The

outcomes were critically evaluated based on the

dimensions: accuracy, efficiency, and user

experience. SG-based approach highlighted that,

syntax graphs provide significant improvement in

accuracy and flexibility. It further emphasized usage

of ASG over AST as a valuable pre-processing step.

PL based approaches suggested some tools that

enhance the user experience, flexibility, and

extensibility factors and few cases on how marking

accuracy is more reliable when compared marking by

a human-counterpart. Similarly, there are some tools

discussed under SCA, how it reached the accuracy

considering the metrices like LOC and types of

errors. Moreover, SCA show strengths and

weaknesses in algorithms to reach highest precision

while keeping the optimum performance. It proposed

a mathematical model that integrates abstract

interpretation with a logical inference as the most

optimized solution. Authors highlight the most

popular algorithms that researchers used in the ML

approaches. Linear ridge regression model could be

predominant due to the unique capability of logic-

based evaluation over syntactical evaluation in

programming assignments. In the literature of ML, it

CSEDU 2021 - 13th International Conference on Computer Supported Education

296

is proposed that the algorithms should be trained for

diverse problems to fulfil the future expectations.

Across these four identified approaches, it was

observed that some critical aspects had not been

considered in the evaluations. Most works (except a

very few (Singh, Gulwani, & Solar-Lezama, 2013))

have not compared their novel approaches against the

obvious baseline condition – what if the same sample

was marked by a human? Also, many had not

considered inconsistencies of accuracy and

unbiasedness in comparison with human marking.

Previous studies could not be cross compared since

authors had measured different aspects, e.g. some

report on the efficiency of the solution (Striewe &

Goedicke, 2014), (Novak & Krajnc, 2010) some

(rarely) on the user-friendliness and configurability of

the tools proposed (Ala-Mutka, 2005), (Striewe &

Goedicke, 2014), (Novak & Krajnc, 2010), (Ashfaq,

Khan, & Farooq, 2019) and some on the accuracy

(Srikant & Aggarwal, 2014), (Takhar & Aggarwal,

2019), (Novak & Krajnc, 2010). Therefore, it is not

evident enough to conclude whether a solution is

accurate yet inefficient, or accurate and efficient yet

difficult to configure etc. Given the maturity of the

domain and the plethora of marking automation

techniques proposed, a strong empirical footing on

each approach, measured using generic comparable

metrics is overdue.

Lack of generic “test-samples” for evaluating the

efficiency, accuracy and user-friendliness of each

approach is identified a significant challenge.

Currently, each method is evaluated with different

marking samples made up by the authors, which

therefore cannot be cross compared. Another major

limitation in most work (except a few (Srikant &

Aggarwal, 2014), (Takhar & Aggarwal, 2019)) is that

they cannot be seamlessly integrated to existing

educational platforms such as Moodle. Teachers need

to install these tools, while configuring runtime

environments and handling dependencies. Further,

this process may include obtaining the submissions

from the LMS platform, marking them using the tool,

and uploading the marks back to the LMS. Hence,

interoperability and portability of tools is a non-trivial

consideration. Though some studies provide feedback

(Zhou et al., 2018), (Singh, Gulwani, & Solar-

Lezama, 2013) many have not addressed providing

feedback for student improvement. This is essential

and becomes more challenging for human markers

when addressing larger classes.

5 RECOMMENDATIONS

After scrutinizing the literature, authors would like to

contribute with some recommendations for marking

automation. A set of generic “marking-samples” to

evaluate each proposed marking automation

mechanism seems critical. This will provide a strong

empirical footing on the accuracy of each method. As

a baseline condition, these could be marked by a

human for comparison. For further accuracy, a

crowdsourcing approach could be used to obtain the

human-given mark for the “marking samples”.

Secondly, these marking samples need to be

applicable across domains, such as assignments

written in procedural, functional and object-oriented,

as well as covering student-submissions that include

meta-files (e.g. XML, properties, and other

configuration files). Third, it is recommended to

standardize a “recipe” of activities and measurements

for evaluating the UE of each tool for both teacher

and student. It is obvious that a tool which has utility

has more tendency to be used if it is user friendly.

Student feedback is key; hence novel marking

automation tools need to provide feedback with

marks within the same tool, or suite of tools which

work together. Automatic tools emphasize the need

for careful pedagogical design of assessment settings

and these solutions need to be interoperable and

portable.

6 CONCLUSION

This paper addresses how literature had studied

marking automation domain. Strategies had been

analysed on four specific approaches to propose a

series of recommendations to be adhered for future

research in this domain.

ACKNOWLEDGEMENTS

Authors would like to extend their gratitude to Sri

Lanka Institute of Information Technology for

extending support to carry out this research work.

REFERENCES

Ala-Mutka, K. M. (2005). A survey of automated

assessment approaches for programming assignments.

Computer science education, 83-102.

Source Code based Approaches to Automate Marking in Programming Assignments

297

Ashfaq, Q., Khan, R., & Farooq, S. (2019). A Comparative

Analysis of Static Code Analysis Tools that check Java

Code Adherence to Java Coding Standards. 2nd

International Conference on Communication,

Computing and Digital systems (C-CODE). 98-103.

Blumenstein, M., Green, S., Nguyen, A., &

Muthukkumarasamy, V. (2004). Game: A generic

automated marking environment for programming

assessment. International Conference on Information

Technology: Coding and Computing, 2004.

Proceedings. ITCC 2004, 212-216.

Buyrukoglu, S., Batmaz, F., & Lock, R. (2016). Increasing

the similarity of programming code structures to

accelerate the marking process in a new semi-

automated assessment approach. 11th International

Conference on Computer Science & Education

(ICCSE),371-376.

Cousot, P. (1996). Abstract interpretation. ACM Computing

Surveys (CSUR), 324-328.

Cousot, P., Cousot, R., & Mauborgne, L. (2013). Theories,

solvers and static analysis by abstract interpretation.

Journal of the ACM (JACM), 1-56.

Digitek-labs. (2011). Static analysis framework. Retrieved

from digiteklabs: http://www.digiteklabs.ru/en/aegis/

platform/

Fonte, D., & Cruz, D. D. (2013). A flexible dynamic system

for automatic grading of programming exercises. 2nd

Symposium on Languages, Applications and

Technologies, 129-144.

Gallier, J. H. (2015). Logic for computer science:

foundations of automatic theorem proving. Courier

Dover Publications.

Glukhikh, M. I., Itsykson, V. M., & Tsesko, V. A. (2012).

Using dependencies to improve precision of code

analysis. Automatic Control and Computer Sciences,

338-344.

Higgins, C. A., Gray, G., Symeonidis, P., & Tsintsifas, A.

(2005). Automated assessment and experiences of

teaching programming. Journal on Educational

Resources in Computing (JERIC).

Korkmaz, C., & Correia, A. P. (2019). A review of research

on machine learning in educational technology.

Educational Media International, 250-267.

Novak, J., & Krajnc, A. (2010). Taxonomy of static code

analysis tools. 33rd International Convention MIPRO,

418-422.

Rahman, M. M., Paudel, R., & Sharker, M. H. (2019).

Effects of Infusing Interactive and Collaborative

Learning to Teach an Introductory Programming

Course. Frontiers in Education Conference (FIE),

IEEE.

Rautenberg, W. (2010). A concise introduction to

mathematical logic. Springer.

Rensink, A., & Zambon, E. (2009). A type graph model for

Java programs. Formal Techniques for Distributed

Systems, 237-242.

Russell, R., Kim, L., Hamilton, L., Lazovich, T., Harer, J.,

Ozdemir, O., & McConley, M. (2018). Automated

vulnerability detection in source code using deep

representation learning. 17th IEEE International

Conference on Machine Learning and Applications

(ICMLA), 757-762.

Singh, R., Gulwani, S., & Solar-Lezama, A. (2013).

Automated feedback generation for introductory

programming assignments. Proceedings of the 34th

ACM SIGPLAN conference on Programming language

design and implementation, 15-26.

Souza, D. M., Felizardo, K. R., & Barbosa, E. F. (2016). A

systematic literature review of assessment tools for

programming assignments. 29th International

Conference on Software Engineering Education and

Training (CSEET), 147-156.

Srikant, S., & Aggarwal, V. (2014). A system to grade

computer programming skills using machine learning.

Proceedings of the 20th ACM SIGKDD international

conference on Knowledge discovery and data mining,

1887-1896.

Striewe, M. (2014). Automated analysis of software

artefacts-a use case in e-assessment (Doctoral

dissertation).

Striewe, M., & Goedicke, M. (2014). A review of static

analysis approaches for programming exercises. In

International Computer Assisted Assessment

Conference, 100-113.

Takhar, R., & Aggarwal, V. (2019). Grading uncompilable

programs. Proceedings of the AAAI Conference on

Artificial Intelligence, 9389-9396.

Vert, T., Krikun, T., & Glukhikh, M. (2013). Detection of

incorrect pointer dereferences for C/C++ programs

using static code analysis and logical inference. Tools

& Methods of Program Analysis, 78-82.

Vetr`o, A. (2014). Empirical assessment of the impact of

using automatic static analysis on code quality (Ph.D.

dissertation).

Wang, T., Su, X., Wang, Y., & Ma, P. (2007). Semantic

similarity-based grading of student programs.

Information and Software Technology, 99-107.

Zhou, W., Pan, Y., Zhou, Y., & Sun, G. (2018). The

framework of a new online judge system for

programming education. Proceedings of ACM Turing

Celebration Conference-China, 9-14.

CSEDU 2021 - 13th International Conference on Computer Supported Education

298
