De-identification of Medical Information for Forming Multimodal

Datasets to Train Neural Networks

Margarita Suzdaltseva

, Alexandra Shamakhova

, Natalia Dobrenko

, Olga Alekseeva

Jaafar Hammoud

, Natalia Gusarova

, Aleksandra Vatian

and Anatoly Shalyto

ITMO University, 49 Kronverksky av., St. Petersburg, Russia

Keywords: Medical Information, De-identification, Multimodal Datasets, Named Entity Recognition, Electronic

Healthcare Record, Rule-based Approach.

Abstract: An important source of medical information for forming multimodal datasets to train neural networks is

electronic patient records. In order to process data from electronic health records with a specified purpose, the

number of requirements must be met - first of all, de-identification. This paper discusses the first stage of this

process - searching for named entities in medical texts (which should be replaced or encrypted afterwards). The

problem is solved by an example of semi-structured EHRs in Russian as a fusional, grammatically complex

language. The structure and specificity of EMC typical for Russia is analyzed in detail. A problem-oriented

comparison of approaches to solving the NER problem is carried out. We developed a pipeline for processing of

HER and experimentally showed the advantages of the rule-based method over using specialized libraries. The

achieved Recall and Precision values were 0.990 and 0.980 respectively.

1 INTRODUCTION

In the modern world, when fighting against new

dangerous diseases takes central stage, development

of medicine would be impossible without advanced

technologies. For instance, application of machine

learning algorithms for clinical data analysis demands

complex datasets containing multimodal information

(including anamnesis, medical images, etc.).

Nowadays necessity of such datasets is perceived not

only at the level of individual universities and funds

who develop large datasets (Armato et al., 2011) but

also at the governmental level (EGISZ, 2017).

Current deficit of high-quality medical datasets is

obvious, since there is a lack of annotated, structured

and pre-processed data. At the same time, a large

amount of unstructured data remains unused. In order

to process data from electronic health records (EHR)

https://orcid.org/0000-0002-8136-7925

https://orcid.org/0000-0003-4414-4607

https://orcid.org/0000-0001-6206-8033

https://orcid.org/0000-0001-5976-3393

https://orcid.org/0000-0002-2033-0838

https://orcid.org/0000-0003-4414-4607

https://orcid.org/0000-0002-5483-716Х

https://orcid.org/0000-0002-2723-2077

with a specified purpose, the number of requirements

must be met - in particular, de-identification. In other

words, need for EHR data de-identification occurs

when there is a need for any reuse. This is especially

important when creating free datasets on their basis,

which are the basis for the progress of high-tech

medicine.

2 BACKGROUND AND RELATED

WORKS

Legislation of each country interprets the term of de-

identification differently.

In the USA the law in force is the Health

Insurance Portability and Accountability Act 1996.

Here Protected Health Information (PHI) includes

Suzdaltseva, M., Shamakhova, A., Dobrenko, N., Alekseeva, O., Hammoud, J., Gusarova, N., Vatian, A. and Shalyto, A.

De-identiﬁcation of Medical Information for Forming Multimodal Datasets to Train Neural Networks.

DOI: 10.5220/0010406000002931

In Proceedings of the 7th International Conference on Information and Communication Technologies for Ageing Well and e-Health (ICT4AWE 2021), pages 163-170

ISBN: 978-989-758-506-7; ISSN: 2184-4984

163

health records, health histories, lab test results, and

medical bills and has 18 identifiers, which should be

de-identified. (Alder, 2017). In the European Union

the law in force is the Regulation (EU) 2018/1725 of

the European Parliament and of the Council 2018. In

the Russian Federation, there are two main laws that

should be relied upon when processing text Federal

Law on the Fundamentals of Protection of the Public

Health 2020 and Federal Law on Personal Data 2006

(edition from 24.04.2020).

It is important to mention that all laws describe

not only a list of information which is considered

personal data, but also requirements for their

processing, storage, transfer, etc. Cryptography must

be used as well, but this is not the focus of the paper.

This paper mostly discusses the stage of searching for

named entities in medical texts (which should be

replaced or encrypted afterwards).

The most relevant and at the same time legitimate

(verified) data on patients' diseases are accumulated

in the Electronic Health Record (EHR), which are the

most valuable source of information in the formation

of multimodal datasets for training neural networks

(Fifty-eighth, 2005).

Naturally, with the advent of EHR, standards were

also formed (Official, June 2019) – for instance,

openEHR (openEHR, 2020), HL7 (HL7

International, 2016) or ASTM Committee E31

(ASTM International, 2020). In addition to the

general structures of the EHR, there are also standards

for medical terms, for example, ICD, approved by

WHO (World Health Organization, 2020). Russia, as

a member of WHO, claims the adherence to these

standards. However, as practice of Russian healthcare

system and our research show, standards are not met

often. In addition, Russian, as a fusional language, is

characterized by complex grammatical constructions,

flexibility, and our EHR characterized by entities,

which are embedded within another entities. All these

factors make solution of NER more complicated.

Named Entity Recognition (NER) approaches are

widely used in processing of medical information.

Researchers outline the following classification of

traditional approaches to NER (Li et al., 2020): rule-

based approaches, unsupervised learning approaches

and feature-based supervised learning approaches.

Each group is characterized by its specific features,

advantages and disadvantages.

Hand-crafted rules are the basis of rule-based

NER systems, especially for EHR (Quimbaya et al.,

2016). The approach is proved to be useful for

improving recall while having limited impact on

precision, which is especially important for the

purposes of this work (see section 3.2).

The basic approach of unsupervised learning is

clustering. Context similarity is the base of named

entities extraction from the clustered groups in

clustering-based NER systems (Alsudais et al., 2018),

which needs the large corpus statistics. Supervised

learning within NER is normally a multi-class

classification or sequence labeling task. Features

should be carefully designed to represent each

training example, considering annotated data samples

(Liu, 2019). Traditionally implemented models are

Hidden Markov Models (HMM), Maximum Entropy

Models (Martino et al., 2018), Support Vector

Machines (SVM) (Gholami et al., 2017), and

Conditional Random Fields (CRF) (Friedrich et al.,

2019).

Nowadays DL-based NER models are becoming

prevalent since they achieve state-of-the-art results

(Hahn et al., 2020). One of the key advantages of deep

learning compared to feature-based approaches is an

ability to discover hidden features and dependencies

automatically (Yadav et al., 2016). Yet there is a main

difficulty in using deep learning for NER (Khin et al.,

2018): to train a supervised NER system is required

to have big annotated data (Lee et al., 2020). In

general, DL-based NER shows poor results on poorly

structured and poorly formatted texts - for example,

on user-generated text e.g., WUT-17 dataset, the best

F-scores are slightly above 40% (Li et al., 2020)

Different approaches are developed to perform

NER on small data. One of them is Active Learning

Query Strategy (Liu et al., 2019), when the machine

learning de-identification system can actively request

information from beyond the system. The best result

shows a Bi-LSTM+CRF architecture in combination

with MultiBPEmb and Flair Multilingual Fast

embeddings, first trained on English data and then on

Italian (Catelli et al., 2020).

Other example of an approach working with a

small amount of data (200 nursing notes) relies on

lookup tables, decision rules and fuzzy string

matching (Menger et al., 2018; Norgeot et al., 2020).

Hybrid approaches also demonstrate good results

(Zhao et al., 2018; Lee et al., 2017).

It is possible to conclude that effective NER

methods for de-identification are already well-known

and widely described in different papers. However,

their choice and implementation in relation to the

realities of Russia analyzed above remain an open

problem.

In order to potentially adapt to a specific task,

authors learned existing software solutions that can be

used to look for named entities in the Russian-

language text.

ICT4AWE 2021 - 7th International Conference on Information and Communication Technologies for Ageing Well and e-Health

164

One of the most wide-used libraries for Natural

Language Processing (NLP) in Python is SpaCy

(spaCy, n.d). However, there is no adaptation for

Russian language at the moment. Another well-

known library for NLP is Stanza (Stanza, n.d.). In

contradistinction from SpaCy, this library maintains

Russian. An example of a library developed

specifically for Russian language is Natasha

(natasha, n.d.). Natasha solves basic NLP tasks for

Russian language. But none of these libraries are

trained on medical texts, so their direct use on EHR is

problematic.

As reported earlier, security requirements of the

data stored in considered EHR are fairly strict. In

particular, re-identification, i.e. reverse person

identification based on anonymized data, is

unacceptable In this regard, rule-based NER methods

have significant advantages.

On the other hand, the use of Machine Learning

(and Deep Learning, in particular) requires a

significant amount of properly annotated data (Gligic

et al., 2020).

Thus, the analysis showed that in conditions of a

small amount of available medical data, in relation to

the Russian language and the realities of Russian

healthcare, it is advisable to use a rule-based approach

at first, and then try two existing modules for NER in

Russian based on pretrained models instead of

training our own.

Thereby, the aim of this paper is to develop a

pipeline for processing of semi-structured EHRs on

the example of the Russian language as a fusional,

grammatically complex language. It includes the

following subtasks:

1. Preprocessing of a document for further

named entities search,

2. NER implementation,

3. Evaluation of results.

3 METHODS AND MATERIALS

3.1 Characteristics of Gathered Data

EHR provided for the research have characteristics

and properties which are important to discuss.

For the further processing, a dataset was formed

from different types of electronic medical records in

Russian (e.g. medical examinations results,

anamnesis, discharge summary, observation diaries,

etc.) In total they have characteristics presented in

Table 1.

Table 1: Data characteristics.

e Characteristic

Words 83 666

Characters 587 264

Formats DOC, PDF, JPG

In general, medical records are not meant for

random people, but for other medical professionals.

This fact explains why language used is very specific:

it includes non-standard and uncommon

abbreviations, short forms, fixed expressions,

medical terms, etc. for example: “KOS” —

“Kislotno-osnovnoe sostoyanie organizma” (The

acid-base state of the body), “LPONP” —

“Lipoproteinov ochen' nizkoj ploskosti” (Very low

plane lipoprotein), “Pron-poziciya” (Prone-position),

“zav. IO” — “zaveduyushchij infekcionnym

otdeleniem” (head of the infectious diseases

department), “lech. vrach” — “lechashchij vrach”

(attending doctor).

Also, the considered records (like almost any text)

are prone to typos — one of the key problems of

working with free-text. Mistakes have been found in

the full name form: “Surname NP” (N - name, P -

patronymic, should be written separately and finish

with dots). Typos may occur in the common lexis, for

example, “nastoshchee” — “nastoyashchee”

(nowadays), where can be corrected with models

trained on any texts, as well as in the functional

medical lexis, for instance, “insuflyaciya” —

“insufflyaciya” (insufflation), where such misprints

can be corrected either manually or with the help of

models, trained especially on large volume of medical

texts, which does not exist for Russian language at the

moment.

The prevalent typo in the provided EHR is the absence

of a space between words:

“Soputstvuyushchij:Gipertonicheskaya” (Concomitant:

Hypertensive), “otdeleniem.Prodolzhaetsya”

(office.Continues) (this typo was made once and

copied several times), “vvide” — v vide (in the form

of). If, in the case of a punctuation mark between

words, it is possible to recognize them as separate

words, then in the case of a missing space between

two words, where the second word is with a small

letter and there are no punctuation marks between,

correction is almost impossible.

Non-standard medical abbreviations (combined

with typos) becomes another problem, so the same

phrase “klinicheskim farmakologom” (clinical

pharmacologist) is written in at least three versions:

“klin.farmakologom”, ”klin.farmakologim”,

”kl.farmakologom”. One more issue with

construction is the lack of dots: “atm dav” —

De-identiﬁcation of Medical Information for Forming Multimodal Datasets to Train Neural Networks

165

“atmosfernoe davlenie” (atmosphere pressure). There

are also mistakes in dates: in one of the provided

medical records, one patient has three different dates

of birth. All of the above impacts processing. Even

with the right choice of method and writing the code

correctly, the individual entities could not be

extracted.

As a rule, the EHR from the examined sample

have no strict logical structure. It is still possible to

distinguish individual structural elements in it, like

tables of laboratory results, discharge reports, patient

observation diaries, and other notes in electronic

form. Though, blocks are not ordered, alternate

chaotically, do not have hyperlinks to each other.

Connections are visible on close reading, but medical

card structure does not reflect them. For example, a

test was taken on one of the days of hospitalization,

but the conclusions drawn from its results are at the

other end of the electronic medical record.

Furthermore, understanding the structure of

information was hampered by multiple repetitions of

the same data. Sometimes it was not clear if the result

was similar to the previous one or simply duplicated.

As already noted, although integral EHR are being

actively implemented in large cities of Russia,

electronic medical records without clear structure and

even conventional handwritten medical records are

still in use. Widespread standards OpenEHR и HL7

(and other standards mentioned above) are not met

often. This is also true for the given documents. In

fact, an EHR in this case is a document consisting of

hand-printed medical texts (narrative, statement of

facts), tables (or pictures) with test results in

electronic format. Obviously, data has neither

annotation nor appropriate markup.

All the above factors make it difficult to perform

NER. However, it is undeniable that the EHR

described potentially contain useful information to be

used while preparing a dataset (e.g. for predicting

disease outcome). Nevertheless, de-identification is a

necessary step in medical data reuse. Consequently, it

was required to find an optimal way of realization.

3.2 Metrics and Baseline

We used metrics that are traditional for NER

solutions, namely:

Precision = ; Recall = ;

#( ) #( )

TP TP

TP FP TP FN

Precision Recall

Fscore







All EHR under consideration have been annotated

manually. If surname were obtained in several

grammatical categories, all forms were considered as

different surnames.

It is worth note that in the task of de-identification,

recall is more important, since the main goal is safety

of patient personal data. It is necessary to recognize

all named entities present in the text. A single pass

can lead to re-identification: even one doctor’s

surname left in the text can easily disclose the medical

institution where they work and re-identify patients

(number of patients is probably limited). False

positives are allowed, precision does not have to be

as high. Accordingly, in our task to erase false

positives is better than to leave false negatives

(unrecognized entities).

The risk of re-identification is real and can lead to

serious breaches of patient privacy and

confidentiality. As noted in (Yogarajan et al., 2019),

while designing an automatic de-identification

system, it is important to consider the re-

identification risk and take appropriate measures to

minimize such risk.

As the analysis of the literature shows, many

researchers focus on accuracy (and prioritize raising

accuracy above the standard value of 95%), but it is

also important to analyze de-identified text and take

qualitative factors into consideration. Obviously, in

addition to a quantitative assessment of the results of

de-identification, its qualitative expert assessment

should be carried out, however, it is already expedient

to solve this task after the complex processing of the

EHR text, including the replacement of the identified

TCA, which is beyond the scope of this article.

As a baseline for comparison, we chose a rule-

based system for automatic de-identification of

medical narrative texts for Serbian (Jaćimović et al.,

2015), since it, like Russian, belongs to the group of

Slavic languages and has similar problems.

4 RESULTS AND DISCUSSION

Figure 1: Pipeline of the proposed solution.

ICT4AWE 2021 - 7th International Conference on Information and Communication Technologies for Ageing Well and e-Health

166

The developed pipeline for processing of EHRs is

presented in Figure 1. Area of responsibility of our

article lies within the dashed rectangle.

4.1 Preprocessing

In order to preprocess data authors analyzed the

structure of the documents. EHRs contain a variety of

multimodal medical information. Raw data was

received in .doc, .pdf, .jpg formats. High-tech images

tend to be in native formats such as DICOM, however

due to the transfer from a third-party program for

EHR maintenance, scans were in .pdf and .jpg

formats.

Original documents did not have precise logical

structure. In .doc files text (also numbers, tables) was

contained in nested tables. To solve problems

associated with hierarchical nesting structure of a

document, .doc files were converted into .txt with

Python package

textract. This expectedly caused

loss of original structure (e.g. footers and headers),

the appearance of blank lines, etc., but all key

information was saved. .pdf can be easily converted

to any other format. .jpg files were converted to .pdf

at first. It can be performed with Adobe Acrobat or

some other application using OCR to recognize text

on an image. Documents in the .txt format were ready

to be subjected to program processing.

Authors of the paper revealed that texts contained

syntax and grammatical errors, mistakes, typos. Their

number is roughly 87 errors per 10 thousand

characters of text.

Table 2: Entities.

Entity class Amount

erson

(

uni

)

180

anization

(

uni

)

id numbers

(

uni

)

location (unique) 2

date (all) 215

all 427

To be able to evaluate results further, the dataset

was split into train and test in a ratio of 2 to 1. Next,

classes of entities were revealed: person (patient,

doctors, laboratory assistants...), organization

(medical center name, polyclinics), id-numbers

(identity documents; policy number; insurance

number; number of issued certificate of incapacity for

work; EHR number), location (addresses), date

(patient birth date; dates of appointments, observation

diaries, test results). The list of classes was formed in

accordance with Russian Federal Law on the

Fundamentals of Protection of the Public Health

2020. Comparison of entities given in law and entities

which actually contained in EHR allowed to form the

final list of classes (Table 2).

Finally, manual expert markup of the train and test

samples was performed.

4.2 NER Implementation

4.2.1 Iterative Regex

A rule-based approach was chosen as the main one

for de-identification of EHRs in Russian. Authors

used the programming language Python. So, an

iterative approach to search and replacement of

named entities in the text was developed, namely:

necessary regular expressions for each class should

not be used all at once, but in a specific order. At each

iteration we search in the text, that does not store

original forms of entities found at the previous

iteration. This technique may be useful, for example,

if you need to keep the roles of personalities in the

text, which is especially important when forming

complex Multimodal Datasets.

A decision tree reflecting optimal order of entities

(their search and replacement) was built within this

method. The order of iterations authors suggested:

1. Organization & location

2. Id numbers

3. Person (patient)

4. Person (the rest)

5. Date (birthday)

6. Date (the rest)

These regular expressions are used to look for

combinations of first name, last name and patronymic

within rule-based approach. Separate regular

expressions for different forms to record names allow

us to take a position of surname into account and

extract it separately if needed.

The listing of full name extraction with Regex is

given in Appendix.

Dates processing depends on de-identification

purposes. For the purpose of compiling a dataset, the

age can be replaced by the age group (the date of birth

is deleted). If the chronology inside the medical card

is not important to us, the date is replaced with a

quarter of a year. If it is crucial to take into account a

chronology inside one medical card, the date of

patient admission is considered as a starting point for

other dates in the card and they are replaced with a

positive or negative number. If it is decisive to

understand how a batch of health records is

chronologically arranged, then a dictionary of dates is

created, where the start and end dates are customized.

De-identiﬁcation of Medical Information for Forming Multimodal Datasets to Train Neural Networks

167

Deleting of document numbers, passport data,

insurance, policy, addresses and phone numbers,

email addresses is done with regular expressions,

because all these numbers have templates. For

instance, the passport number consists of ten digits.

Besides, such entities have unique symbols: “№”,

“@”, “:” (Colons also appear in other personal data,

hence it is important to keep the chronology of de-

identification).

The listing of dates parsing is given in Appendix.

4.2.2 Pre-trained Models

The next method considered in this section - to use

appropriate pretrained models for NER. Packages

were used with Python language.

Natasha library has a NER module using pre-

trained neural networks. The entity classes person,

location, organization have been filtered.

Stanza library is also NER based on ML. The

entity classes person, location, organization have

been extracted.

Entities date and id numbers have been extracted

only with rule-based approach (regular expressions),

not NER, since the recording of dates is rather strictly

formalized, and id numbers were encountered in a

limited number of contexts.

The Listings of the extraction named entities with

Natasha library, as well as of the txtraction of entity

classes person, location, organization (‘PER’, ‘LOC’,

‘ORG’) with Stanza library are given in Appendix.

4.3 Evaluation

As a result of applying selected de-identification

approaches on test data we got metrics to compare

with the baseline.

Table 3: Metrics.

method \ metrics Recall Precision F-score

Baseline 0,96 0,97 0,97

Rule-

ase

0,990 0,980 0,985

Stanza 0,941 0,842 0,888

Natasha 0,714 0,820 0,760

As you can see from the Table 3, the Rule-based

method showed the best results both in comparison

with the baseline and in comparison with the Pre-

trained models. Noteworthy is the high Recall value

obtained by this method, which almost eliminates the

need for additional manual (expert) verification of de-

identified EHRs.

However, each of the proposed solutions is not

free from disadvantages.With an iterative rule-based

approach, problems arise with every new form of

notation or misspellings in letter case or punctuation

marks.

Natasha's problem is that it does not find non-

standard surnames, at the same time it captures the

names of drugs or substances that are important for

the further use of information.

Stanza successfully coped with the definition of

named entities, has high recall and the percentage of

captured false positive values is relatively small. On

the other hand, if the names of locations and

organizations are extracted, the estimates will

deteriorate significantly. False Positive entities could

be removed with regular expressions.

Thus, there are prerequisites for using a hybrid

approach to improve the efficiency of NER.

5 CONCLUSIONS

The paper discussed the problem of de-identification

of medical information for forming multimodal

datasets to train neural networks (on example of EHR

in Russian). The analysis of the legislation of various

countries in relation to the problem under

consideration is carried out, the difficulties of solving

the NEP problem in relation to EHR in Russia are

revealed, both from the point of view of compliance

with the law and from the point of view of the

specifics of the Russian language. A problem-

oriented comparison of approaches to solving the

NER problem was carried out.

The tasks set in the article have been successfully

solved, namely, the pipeline for processing EHR was

developed. Its main stages are preprocessing, NER

implementation, and final evaluation. A fairly high

efficiency of the proposed solution is shown

experimentally: the achieved Recall and Precision

values were 0.990 and 0.980 respectively.

After the processing described, textual data can be

applied to formation of multimodal datasets

appropriate for training neural networks.

ACKNOWLEDGEMENTS

This work was financially supported by Russian

Science Foundation, Grant 19-19-00696, and Grant

of the President of the Russian Federation for state

support of young Russian scientists - candidates of

science, MK-5723.2021.1.6.

ICT4AWE 2021 - 7th International Conference on Information and Communication Technologies for Ageing Well and e-Health

168

REFERENCES

Armato, S.G., McLennan, G., Bidaut, L. et al. (2011). The

Lung Image Database Consortium (LIDC) and Image

Database Resource Initiative (IDRI): a completed

reference database of lung nodules on CT scans.

Medical Physics, 38(2), 915-31. doi: 10.1118/

1.3528204

EGISZ, Unified state information system in the field of

healthcare 2017 (№ 242-FZ) (Russia)

The Health Insurance Portability and Accountability Act

1996 (HIPAA) (U.S.)

Alder, S. (2017). What is Considered PHI Under HIPAA?

HIPAA Journal. https://www.hipaajournal.com/

considered-phi-hipaa/

Alsudais, A. & Tchalian, H. (2018). Clustering Prominent

Named Entities in Topic-Specific Text Corpora. CoRR.

arXiv:1807.10800

ASTM International. (n.d.). Committee E31 on Healthcare

Informatics. Retrieved on September 2, 2020, from

https://www.astm.org/COMMITTEE/E31.htm

Catelli, R., Gargiulo, F., Casola, V., Pietro, G., Fujita, H. &

Esposito, M. (2020). Crosslingual named entity

recognition for clinical de-identification applied to a

COVID-19 Italian data set. Applied Soft Computing,

97(A), ISSN 1568-4946. doi:10.1016/j.asoc.2020.

106779

Federal Law on Personal Data 2006 (№ 152-FZ) (Russia)

Federal Law on the Fundamentals of Protection of the

Public Health 2020 (№ 303-FZ) (Russia)

Fifty-eighth World Health Assembly 2005 (WHA58.28)

https://apps.who.int/iris/bitstream/handle/10665/20378

/WHA58_28-en.pdf?sequence=1

Friedrich, M., Köhn, A., Wiedemann, G., & Biemann, C.

(2020). Adversarial learning of privacy-preserving text

representations for de-identification of medical records.

Paper presented at the ACL 2019 - 57th Annual Meeting

of the Association for Computational Linguistics,

Proceedings of the Conference, 5829-5839.

Gholami, R. & Fakhari, N. (2017). Chapter 27 - Support

Vector Machine: Principles, Parameters, and

Applications. Handbook of Neural Computation, 515-

535, ISBN 9780128113189. doi.org:10.1016/B978-0-

12-811318-9.00027-2

Gligic, L., Kormilitzin, A., Goldberg, P., & Nevado-

Holgado, A. (2020). Named entity recognition in

electronic health records using transfer learning

bootstrapped neural networks. Neural Networks, 121,

132-139. doi:10.1016/j.neunet.2019.08.032

Guidance on De-identification of Protected Health

Information 2012 (U.S.) https://www.hhs.gov/hipaa/

for-professionals/privacy/special-topics/de-

identification/index.html

Hahn, U., & Oleynik, M. (2020). Medical information

extraction in the age of deep learning. Yearbook of

Medical Informatics, 29(1), 208-220. doi:10.1055/s-

0040-1702001

Health Insurance Portability and Accountability Act 1996

(HIPAA) (U.S.)

HL7 International. (2016, May 11). Electronic Health

Records. https://www.hl7.org/Special/committees/ehr/

overview.cfm

Jaćimović, J., Krstev, C., & Jelovac, D. (2015). A rule-

based system for automatic de-identification of medical

narrative texts. Informatica (Slovenia), 39(1)

, 45-53

Khin, K., Burckhardt, P. & Padman, R. (2018). A Deep

Learning Architecture for De-identification of Patient

Notes: Implementation and Evaluation. The 28th

Workshop on Information Technologies and Systems.

arXiv:1810.01570v1

Lee, HJ., Wu, Y., Zhang, Y., Xu, J., Xu, H. & Roberts, K.

(2017). A hybrid approach to automatic de-

identification of psychiatric notes. Journal of

Biomedical Informatics, 75, S19-S27, ISSN 1532-0464,

doi.org:10.1016/j.jbi.2017.06.006

Lee, J., Yoon, W., Kim, S., Kim, D., Kim, S., So, C. H., &

Kang, J. (2020). BioBERT: A pre-trained biomedical

language representation model for biomedical text

mining. Bioinformatics, 36(4), 1234-1240.

doi:10.1093/bioinformatics/btz682

Li, J., Sun, A., Han, J. & Li, C. (2020). A Survey on Deep

Learning for Named Entity Recognition. IEEE

Transactions on Knowledge and Data Engineering.

arXiv:1812.09449v3

Li, M., Scaiano, M., El Emam, K., & Malin, B. A. (2019).

Efficient Active Learning for Electronic Medical

Record De-identification. AMIA Joint Summits on

Translational Science proceedings. AMIA Joint

Summits on Translational Science, 2019, 462–471.

Liu, S., Sun, Y., Li, B., Wang, W. & Zhao X. (2019).

HAMNER: Headword Amplified Multi-span Distantly

Supervised Method for Domain Specific Named Entity

Recognition. Biomedical NER and Relation

Construction. arXiv:1912.01731v1

Martino, A. & Matrion, D. (2018). An introduction to the

maximum entropy approach and its application to

inference problems in biology. Heliyon, 4(4).

doi.org:10.1016/j.heliyon.2018.e00596

Menger, V., Scheepers, F., Wijk, L. M. & Spruit, M. (2018).

DEDUCE: A pattern matching method for automatic

de-identification of Dutch medical text. Telematics and

Informatics, 35(4), 727-736, ISSN 0736-5853,

doi.org:10.1016/j.tele.2017.08.002

Norgeot, B., Muenzen, K., Peterson, T.A. et al. (2020).

Protected Health Information filter (Philter): accurately

and securely de-identifying free-text clinical notes. npj

Digit. Med. 3, 57. doi.org:10.1038/s41746-020-0258-y

Official Website of The Office of the National Coordinator

for Health Information Technology (ONC). (2019,

September 10). What is an electronic health record

(EHR)? https://www.healthit.gov/faq/what-electronic-

health-record-ehr

Official Website of The Office of the National Coordinator

for Health Information Technology (ONC). (2019, June

4). Health IT Standards. https://www.healthit.gov/

topic/standards-technology/health-it-standards

openEHR. (n.d.). What is openEHR? Retrieved on

September 2, 2020, from https://www.openehr.org/

about/what_is_openehr

De-identiﬁcation of Medical Information for Forming Multimodal Datasets to Train Neural Networks

169

Quimbaya, A. P., Múnera, A. S., Rivera, R. A. G.,

Rodríguez, J. C. D., Velandia, O. M. M., Peña, A. A. G.

& Labbé, C. (2016). Named entity recognition over

electronic health records through a combined

dictionary-based approach. Procedia Computer

Science, 100, 55–61.

Regulation (EU) 2018/1725 of the European Parliament

and of the Council of 23 October 2018 on the protection

of natural persons with regard to the processing of

personal data by the Union institutions, bodies, offices

and agencies and on the free movement of such data,

and repealing Regulation (EC) No 45/2001 and

Decision No 1247/2002/EC (EU)

spaCy. (n.d.). Industrial-Strength Natural Language

Processing in Python. Retrieved on September 12,

2020, from https://spacy.io

Stanza. (n.d.). Stanza – A Python NLP Package for Many

Human Languages. Retrieved on September 15, 2020,

from https://stanfordnlp.github.io/stanza/

World Health Organization. (n.d.). International Statistical

Classification of Diseases and Related Health

Problems (ICD). Retrieved on September 2, 2020, from

https://www.who.int/standards/classifications/classific

ation-of-diseases

Yadav, S., Ekbal, A., Saha, S., & Bhattacharyya, P. (2016).

Deep Learning Architecture for Patient Data De-

identification in Clinical Records.

ClinicalNLP@COLING 2016.

Yogarajan, V., Pfahringer, B. & Mayo, M. (2019).

Automatic end-to-end De-identification: Is high

accuracy the only metric? Applied Artificial

Intelligence. arXiv:1901.10583v1

Zhao, YS., Zhang, KL., Ma, HC. & Li, K. (2018).

Leveraging text skeleton for de-identification of

electronic medical records. BMC Med Inform Decis

Mak 18, 18. doi.org:10.1186/s12911-018-0598-6

ICT4AWE 2021 - 7th International Conference on Information and Communication Technologies for Ageing Well and e-Health

170
