An Endogenous and Self-organizing Approach for the Federation of

Autonomous MQTT Brokers

Marco Aur

elio Spohn

Federal University of Fronteira Sul, Chapec

o, SC, Brazil

Keywords:

Publish/Subscribe, Broker Federation, MQTT, Internet of Things, Self Organizing Protocols.

Abstract:

Many applications for the Internet of Things (IoT) use the publish/subscribe (P/S) communication paradigm.

Among the most representative protocols, there is MQTT. Its basic architecture relies on a single server/broker:

publishers send data topics to the broker, and then it forwards the data to subscribers. Having a single server

may make things easier for conﬁguration and management; however, there is room for a potential bottleneck,

besides being a single point of failure. Clustering servers usually address scalability in MQTT broker deploy-

ment; however, most solutions are proprietary. Meanwhile, autonomous brokers could be federated together to

scale and increase availability. A self-organizing federation proposal already available in the literature implies

substantial changes to brokers’ inner implementation; furthermore, there has not been any implementation

yet. This work explores an endogenous federation approach: design a supporting agent (called federator) that

realizes the brokers’ federation based on the native P/S mechanism. There are no implied modiﬁcations to

regular/standard brokers, but it requires changes to the client-side (i.e., publishers and subscribers). This work

presents a primary architecture and an initial case study to grasp some fundamentals and beneﬁts of adopting

the proposed solution.

1 INTRODUCTION

The Publish/Subscribe (P/S) approach is widely

adopted by many Internet of Things (IoT) plat-

forms (Al-Fuqaha et al., 2015), being Message Queu-

ing Telemetry Transport (MQTT) (Standard, 2020)

one of the prominent representatives among the P/S

protocols. In MQTT, there is a server (broker) re-

sponsible for managing the relationship between sub-

scribers (i.e., those willing to receive speciﬁc infor-

mation) and publishers (i.e., those eventually making

the information available). It is a consumer/producer

relationship: publishers send information/messages

to the broker; meanwhile, it delivers the data to all

corresponding subscribers.

Developing IoT applications requires efﬁcient

communication capabilities, mainly because most end

nodes have low computing power, storage capacity,

communication, and power source (usually battery

powered). Nodes might not be active all the time,

making asynchronous communication not just a de-

sirable feature but an essential requirement. Com-

munication between IoT entities and the broker is

https://orcid.org/0000-0002-9265-9421

paramount for P/S based applications; otherwise, it

might impact the supported service’s availability.

Even though one expects data topics resulting in

small and not so frequent data packets, the broker

might be a bottleneck for the overall system perfor-

mance, besides being a single point of failure. It is

possible to resort to more than one broker, allowing

us to have some degree of fault tolerance. However,

one should expect to have some management issues

not present in a single broker conﬁguration: brokers

work together so that publications can reach their in-

tended subscribers regardless of their direct connect-

ing broker.

The main advantages of having a federated group

of MQTT brokers are:

• There is no single point of failure: clients can

choose to associate with any federated brokers.

• Load balancing: whenever there is a possibility to

choose among a set of available brokers, and get-

ting what one needs no matter from which broker,

it allows adopting mechanisms for load balancing.

• Exploring virtualized topologies or networks’ ca-

pabilities: full virtualized deployment is realiz-

able by having brokers instantiated in virtual ma-

834

Spohn, M.

An Endogenous and Self-organizing Approach for the Federation of Autonomous MQTT Brokers.

DOI: 10.5220/0010408808340841

In Proceedings of the 23rd International Conference on Enterprise Information Systems (ICEIS 2021) - Volume 1, pages 834-841

ISBN: 978-989-758-509-8

chines or containers. Simultaneously, Software

Deﬁne Networking (SDN) and Network Func-

tion Virtualization (NFV) create an environment

for endless network topologies. Therefore, the

meshes’ redundancy capabilities are quite man-

ageable.

Spohn (Spohn, 2020) proposed the ﬁrst self-

organizing solution for the federation of autonomous

P/S brokers, providing the primary mechanisms for

bringing the brokers together and allowing the proper

routing of published topics to their intended targets

regardless of the subscribers’ brokers. Brokers are as-

sumed to be connected through an overlay/virtual net-

work, allowing any possibility in the network topol-

ogy. Brokers ignite the federation process with sub-

scribers by building meshes connecting all the brokers

with subscribers for the same topic. The solution al-

lows setting the mesh degree redundancy, resulting in

a mesh as complex as the underlying network topol-

ogy allows. As a result, mesh member brokers might

be connected through redundant paths, creating the

conditions for an enhanced degree of fault tolerance,

besides the intrinsic load balance possibilities arisen

from having several available brokers.

Nevertheless, no real implementation of the pro-

posed solution is available yet, but the author assumes

a protocol realization requires changes to standard

brokers’ inner implementation. Under other condi-

tions, one could investigate the possibility of realiz-

ing the federation at the application layer based on

the P/S mechanism itself, without requiring any bro-

kers’ changes. In this context, the federator would

play more of a supporting role in the whole process.

This work endeavors to provide the ﬁrst proposal

to implement MQTT brokers’ federation at an appli-

cation level/layer. The remainder of this paper has

the following structure. Section 2 presents some rep-

resentative related work. Section 3 summarizes the

federation of MQTT brokers used as the basis for this

work. Section 4 introduces the proposed endogenous

(i.e., P/S based) federation architecture, while Sec-

tion 5 shows some of its formal properties. In Sec-

tion 6, a case study is presented as a ﬁrst realization of

the proposed architecture, while Section 7 addresses

an initial evaluation scenario. Conclusions and future

works are in Section 8.

2 RELATED WORK

Clustering servers usually address scalability in

MQTT broker deployment; however, most solutions

are proprietary. HiveMQ™ (HiveMQ, 2020) deﬁnes

an MQTT broker cluster as a distributed system act-

ing as a single logical MQTT broker, allowing clients

to interact with the system no matter how many real

brokers are active. SwiftMQ™ (SwiftMQ, 2020)

builds around the concept of Federated Router Net-

work, where each broker is a SwiftMQ router running

a routing engine. Even though the routing process is

dynamic, the solution is not self-organized.

The ﬁrst self-organizing solution (Spohn, 2020)

for the federation of autonomous brokers inherits its

properties from a multicast protocol designed for Mo-

bile Ad Hoc Networks (MANETs). The basic idea

is to have brokers with local subscribers responsible

for building and maintaining a mesh structure around

themselves. Control overhead is kept to a minimum,

having just two control packets: core announcement

and mesh membership announcement. Mesh redun-

dancy is conﬁgurable, paving the way for a degree of

path fault tolerance as long as supported by the un-

derlying topology. Brokers connect through an over-

lay network, while publishers and subscribers behave

as usual (i.e., the brokers’ implementation adheres

to the federation protocol). Therefore, a new vari-

ant/standard for MQTT is required. On the other

hand, this work focus on designing an approach that

does not require any immediate changes to the MQTT

standard. However, the trade-off is on laying the bur-

den on clients (i.e., publishers and subscribers) re-

quired to be aware and adhere to the federation proto-

col by themselves.

Intel proposed Distributed Publish & Subscribe

for the Internet of Things (DPS) (Corp., 2020) as a

distributed implementation of the P/S communication

mechanism. DPS builds a mesh network around sub-

scribers, providing the routing from publishers to sub-

scribers based on subscription topics, with IP multi-

cast support in local subnets. However, DPS does not

provide means for the federation of autonomous bro-

kers (i.e., mesh deployment centers on publishers and

subscribers, without multiple independent brokers).

Park et al. (Park et al., 2018) proposed Direct

Multicast-MQTT (DM-MQTT) as a way to address

MQTT single broker limitations. As the number of

clients connected to the broker increases, there is a

direct impact on the communication delay between

publishers and subscribers. To reduce communication

delays, DM-MQTT employs Software Deﬁned Net-

work (SDN) multicast trees to connect publishers to

subscribers, bypassing the centralized broker. Similar

to DPS, DM-MQTT is not a federation of autonomous

brokers either.

An Endogenous and Self-organizing Approach for the Federation of Autonomous MQTT Brokers

835

3 FEDERATION OF MQTT

BROKERS

This section presents a brief description of the federa-

tion mechanism presented in (Spohn, 2020). The pro-

posed approach assumes that a set of autonomous bro-

kers connect through an overlay network. Depending

on the underlying topology, it is possible to explore

path redundancy in the resulting mesh structures built

from the federation process.

The fundamental concept is to have subscribers re-

sponsible for organizing the communication subsys-

tem required for the proper routing of publications

to every broker with local subscribers. Brokers with

local subscribers start by advertising themselves as

the core for a new mesh related to the correspond-

ing topic. Core announcements are broadcast to the

whole network, allowing any broker to learn who they

are and how to get to any existing core. There might

be more than one core for the same mesh for a short

period, but eventually, all brokers converge to choos-

ing the core with the smallest ID. The remaining core

has to announce itself periodically, allowing brokers

to keep always the most current information about the

core.

To complete the mesh building process, brokers

with local subscribers must let their parents know

their status by sending a mesh membership announce-

ment (always related to the freshest core announce-

ment). The number of parents depends on the desired

mesh degree redundancy. A mesh member is any bro-

ker with local subscribers or one connecting children

to the core. This way, a mesh membership announce-

ment can cascade back to the core.

With a minimum control overhead, all brokers

learn about any existing mesh through the corre-

sponding core announcements. However, a broker

only is a mesh member if the broker is required. In

their turn, publishers do not need to take part in any

mesh: their host broker learns how to get to any mesh

(guided by the corresponding core) and send publi-

cations towards the core. Once reaching the mesh,

the publication needs to be spread all along with the

mesh.

The proposed federation protocol assumes

changes to the code of the MQTT broker. Therefore,

a new variant/standard must arise to provide all the

brokers’ proper federation mechanisms. In addition

to that, there are several open issues not addressed

in the initial work. There is not a solution for the

relationship between meshes and sets of topics. The

virtual topology directly impacts the overall perfor-

mance, requiring a ﬂexible and efﬁcient solution for

managing the topology.

Node A

Sub_Fed

Pub_Fed

Sub_Fed

Pub_Fed

BROKER

Node B

Figure 1: P/S based federation architecture.

4 P/S BASED ARCHITECTURE

In this work, the proposed architecture builds around

the P/S subsystem without any required changes to

standard MQTT brokers (see Figure 1). The creation

and management of meshes depend on gathering the

information needed to build them. The dissemination

of core and mesh membership announcements pro-

ceed through publications and subscriptions. Routing

of regular data messages/topics happens similarly.

There are basic application-level processes asso-

ciated with every broker to perform the roles needed

to the federation and routing (i.e., control and data

planes):

• Pub Fed: responsible for the publication of con-

trol messages (i.e., core and mesh announce-

ments) and regular routing. There is a direct con-

nection to every neighboring broker for the con-

trol data plane (i.e., control announcements). Data

forwarding will depend on neighboring mesh

membership status.

• Sub Fed: responsible for handling control and

data packets sent from neighboring brokers.

There should be a single instance of such a pro-

cess associated with any federated broker.

The core federation protocol performs through the

proper coordination of the Pub Fed and Sub Fed el-

ements. Core announcements are periodically started

from cores (management and regular cores), spread-

ing through the entire virtual topology; that is, a bro-

ker must handle core announcements no matter the

broker’s mesh status. This way, brokers learn how

to get to any existing core. A broker only takes part

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

836

in the corresponding mesh when the broker has local

subscribers or the broker connects (i.e., is a parent to)

at least one neighbor to the core (learned from a mesh

membership announcement sent from such neighbor).

Cores periodically send new core announcements,

uniquely identiﬁed by their core ID and sequence

number. When brokers receive a new core announce-

ment, they must forward it to its neighboring brokers

(other than the sending broker). Any broker learns

which neighboring brokers lead to the corresponding

core, having as many parents as the allowed mesh re-

dundancy. Once a core announcement reaches a bro-

ker, which is also a mesh member, the broker sends a

mesh membership announcement to its parents. Such

an action occurs for every new core announcement

(i.e., mesh membership announcement carries the in-

formation regarding the corresponding core ID and

sequence number). Brokers with local subscribers,

or connecting neighboring brokers towards the core,

must send a mesh membership to their parents to

properly connect all receiving brokers (i.e., brokers

with local subscribers).

Once the core starts a new mesh, it takes some

time to connect all brokers depending on how far

apart receiving brokers are from each other. Once a

mesh membership announcement reaches a non-mesh

member parent for the ﬁrst time, the parent’s status

transitions to mesh member (i.e., it is an interconnect-

ing broker). The receiving broker must then itself

send a mesh membership announcement to its par-

ents. The process might go on until it reaches the

core or a mesh member broker that has already sent

out the corresponding mesh membership announce-

ment once it received the core announcement previ-

ously. A mesh membership announcement also acts

as a beacon to track the mesh children’s current status.

This approach guarantees that every mesh member

receives one mesh membership announcement from

each child for every new core announcement.

Mesh membership publications happen asyn-

chronously; that is, when a neighbor gets recognized

as a parent for a given mesh, a new mesh membership

can get published to the corresponding neighbor. The

federator must keep control of any recently published

mesh membership, each associated with a unique core

announcement (i.e., code ID and sequence number).

Regular data packets (i.e., topics’ publications)

progress toward the mesh by directing the packet to

the core. If the source broker is not in the mesh, the

packet can reach any particular mesh member other

than the core during the routing process. Regard-

less, once a mesh broker receives the packet, it just

needs to be spread over the remaining mesh members:

the packet advances to the remaining mesh neighbors

(i.e., parents and children) other than the sending bro-

ker. To avoid looping (e.g., when the mesh is a graph

with cycles), a data log must be employed to keep

records of the most recently forwarded data packets.

The size of the log and the minimum time for keeping

the entries should be left as a conﬁguration parameter,

assuming that it depends on the characteristics (e.g.,

topology) of the network and the meshes themselves.

4.1 Applications

The proposed architecture’s main advantage is that it

does not require any changes to standard MQTT bro-

kers. While the burden lies on the application side,

it provides a certain degree of freedom for deploying

and managing in many ways the whole federation in-

frastructure.

With the potential virtualization of any computing

and communication resources (e.g., virtual machines,

containers, software-deﬁned networks, network func-

tion virtualization), the federation itself could re-

sult as a service. Brokers could run in independent

VMs/containers deployed anywhere in a cloud infras-

tructure. The virtual topology could perform as re-

quired by the application, creating the environment

ﬁtted to allow the degree of availability and fault tol-

erance urged by the provided service.

Having the federation protocol incorporated into

the broker itself would likely render better overall

performance, but employing dedicated containerized

brokers associated with every single federator would

be a strategy one could leverage to get improved per-

formance results.

5 FORMAL PROPERTIES

This section presents some formal properties related

to the safety and liveness of the protocol.

Theorem 1. For a virtual network topology with n

brokers and l links, core announcement overhead is

bounded to O(l) publications.

Proof. Core announcements appear as publications to

neighboring brokers in the virtual network. The an-

nouncements have unique identiﬁers (i.e., core ID and

sequence number), avoiding looping. An announce-

ment traverses the same virtual link at most twice,

happening when links connect pairs of brokers at the

same distance to the originating core. Therefore, the

total number of publications resulting from every new

core announcement is at most 2× l, which is of order

O(l).

An Endogenous and Self-organizing Approach for the Federation of Autonomous MQTT Brokers

837

Theorem 2. For a virtual network topology with n

brokers and l links, the mesh structure converges after

a ﬁnite period.

Proof. The protocol converges with no possibility

of deadlocks. Theorem 1 proves that the core an-

nouncement overhead is bounded by O(l) publica-

tions, each one bounded by a well-deﬁned publication

delay. From that, we can assume that all brokers, in-

cluding those with subscribers, get to know the short-

est distance to the core and the corresponding neigh-

bors leading to the core (i.e., parent nodes). Brokers

with local subscribers must send a mesh membership

publication to all parents (bounded to the mesh redun-

dancy), which are known to be closer to the core. In-

terconnecting brokers become mesh members, allow-

ing all the required mesh membership publications

to be published towards the core, accomplishing the

mesh construction process. By deﬁnition, mesh mem-

bership publications are strictly related to unique core

announcements. Given that mesh membership is pub-

lished only once to the broker’s parents, there is no

possibility of deadlock.

6 CASE STUDY

A case study for the proposed solution was designed

based on the asynchronous P/S libraries provided by

the Eclipse Paho project (Foundation, 2020b). An in-

stance of the federation application handles the in-

teraction with each federated broker, henceforward

named the federator (see Figure 2). We take some

assumptions to provide a ﬁrst working environment

with essential tweaks for usability and performance

analysis:

• The virtual topology is static and known in ad-

vance. There are many solutions for building vir-

tual peer-to-peer (P2P) topologies adaptable to a

real implementation. For the sake of simplicity,

we use a grid topology for exploring path redun-

dancy among brokers.

• There is a set of control topics in use for the proper

federation of brokers. Sub

Fed is responsible for

subscribing to the following topics:

– CORE ANN: For receiving core announce-

ments from neighbors, the payload includes

information regarding the core ID, sequence

number, distance to the core, and the sender’s

ID (i.e., the neighbor’s ID sending the core an-

nouncement).

– MESH MEMB ANN: Carries a mesh mem-

bership announcement; payload includes the

Sub_Fed

Regular Topics

BROKER

FEDERATOR

Neighbor

Pub_Fed

NEW_REGULAR_TOPIC

MESH_MEMB_ANN

CORE_ANN

DATA

Figure 2: Interactions between federation elements.

corresponding core ID, sequence number (i.e.,

linked to the corresponding core announce-

ment), and the sender’s ID.

– NEW REGULAR TOPIC: Any new regular

topic subscription, or ﬁrst publication, must

be followed by a corresponding publication of

topic details so that the proper mesh build-

ing process occurs, including the routing of

topic/data packets over the mesh structure.

– DATA: Encapsulates any other regular topic.

Once reaching a broker with local subscribers,

the payload contains a full regular topic packet,

which can then be published to reach the proper

local subscribers.

There are no modiﬁcations required to MQTT bro-

kers; however, as expected, there is some price

to pay for that: in order to learn about the re-

lated topics which are required to be handled by the

federators, any regular subscription, or ﬁrst publi-

cation, have to be informed to the federator (i.e.,

by publishing the required information through the

NEW REGULAR TOPIC). Applications must com-

ply with this requirement; otherwise, there is no

way to guarantee that publications will reach sub-

scribers associated with different brokers. There-

fore, all federators are required to subscribe to regu-

lar federated topics (learned about from CORE ANN

and NEW REGULAR TOPIC publications) to prop-

erly handle the routing of regular topics to the re-

quired neighboring brokers, which must receive/relay

the publication.

Given that there are some changes needed for reg-

ular applications to work in a federated environment,

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

838

one could say that clients could have all their regular

topic messages encapsulated into DATA topics. Nev-

ertheless, we handle publications the way they happen

regularly. Besides that, the number of expected mes-

sages for an average application usually outgrows the

initial control overhead (i.e., a single publication to

the NEW REGULAR TOPIC is required). This way,

publications are carried by DATA topic messages only

when transferred between federators.

A publisher may be associated with any broker

wherever there is a supporting instance of the feder-

ator. Once a federator receives a regular topic publi-

cation, the federator encapsulates the publication into

a DATA topic publication, processing it the following

way:

• If the federator is not a mesh member for the cor-

responding topic, the federator relays the packet

to one of its parents towards the core.

• If the federator is in the mesh, the federator sends

a publication to every mesh neighboring broker

(i.e., parents and children) other than the sending

broker. That is, the publication spreads only along

with the mesh.

7 EVALUATION SCENARIO

One expects performance enhancements when resort-

ing to multiple brokers. However, there is always

additional control overhead when such brokers per-

form together. In this context, the proposed solution’s

ﬁrst evaluation scenario targets some of the potential

performance beneﬁts. An analysis of fault tolerance

and path redundancy capabilities would require ex-

tensions to the protocol, leaving for future work.

For the evaluation, we have designed the follow-

ing scenario:

• A virtual grid topology with nine nodes: a 3 × 3

grid (see Figure 3).

• Each virtual node is an instance of a Docker con-

tainer (Docker, 2020) running a Mosquitto MQTT

broker (Foundation, 2020a).

• Mesh redundancy has value two, and subscribers

execute at node two and node seven. This way, a

mesh with path redundancy is established having

node two as the core: even though there might

be more than one core for a while, eventually, the

node with the smallest id (i.e., node two) exerts

the core role.

The communication among mesh members’ internal

elements is depicted in Figure 4, while Figure 5 shows

Figure 3: Virtual topology for the evaluation scenario (each

node is a Docker container running a Mosquitto broker).

Broker

Federator

Broker

Federator

Broker

Federator

Broker

Federator

Broker

Federator

Broker

Federator

Figure 4: Resulting mesh: communication among mesh

members’ internal elements.

the parent and children designation. The resulting

mesh includes connecting nodes 1, 4, 5, and 8.

A publisher was instantiated at node six (i.e., one

hop to node seven and four hops to node two) to

explore the shortest and farthest distance to a mesh

member with a subscriber. Publications have 64 bytes

each, and the publishers send them with an inter-

arrival time between 50 and 100 ms (i.e., an average

between 10 and 20 publications/s). We use two pub-

lication settings: one with 500 publications and the

other with 1000 publications. As the primary perfor-

mance metric, we evaluate the average delay for actu-

ally getting the message delivered to each subscriber

An Endogenous and Self-organizing Approach for the Federation of Autonomous MQTT Brokers

839

Parent

Children

CORE

Figure 5: Resulting mesh: parent and children designation.

Table 1: Major parameters for the evaluation scenario.

Parameter Description Value/Range

Link delay virtual link delay 5 ms

Publications’

periodicity

inter arrival time

for publications

[50..100] ms

Topic payload

number of bytes

as topic’s payload

Mesh redundancy

number of parents

for mesh members

(Table 1 summarizes the main conﬁguration parame-

ters).

As expected, results for the federated setting (see

Table 2) show that the delay experienced by the sub-

scriber at node 7 (i.e., the one closer to the pub-

lisher) is almost half the amount registered at node

2. Figure 6 depicts the routing process, showing

that redundant transmissions can happen depending

on race/timing conditions (e.g., it could take place be-

tween brokers 4 and 5 and between brokers 1 and 2).

As mentioned previously, a data log for most recently

received data packets must be employed to avoid any

looping.

To evaluate a single broker scenario, we execute

both subscribers (named A and B) associated with the

same broker. First, we evaluate when the broker is

running at node two, and in the second case, the bro-

ker runs in node seven. It is used the same publication

pattern applied to the federated scenario.

The routing process is relatively straightforward

by choosing the shortest path between node six and

the broker. The results (see Table 3) once again show

that the delay is more considerable for the situation

when the broker is farther away from the publisher.

In addition to that, the aggregate delay for both sub-

S: Subscriber

P: Publisher

Core

Figure 6: Data packets’ routing.

scribers is more extensive when compared to the fed-

erated scenario, mainly because the broker has to han-

dle twice the load on average.

7.1 Discussions

The Docker-based Mosquitto instances were shown

easy to set up and conﬁgure. Given that our solu-

tion does not require any changes to the broker, the

application based approach was able to act right on

the targeted resources. The federation itself is trans-

parent to the brokers, while the virtual infrastructure

built around them allows publications to reach their

intended subscribers.

Even though the initial proposal assumes an indi-

vidual mesh for every single topic, we can once again

resort to PUMA and lean on its multicast group ag-

gregation approach. Therefore, we should foster so-

lutions that bring topic aggregation to the inner mesh

construction and maintenance process. Nevertheless,

it would require improvements to the core and mesh

announcements so that the largest number of targeted

topics can share the same mesh structure.

We might handle federators’ scalability issues

through proper multi-threading management. One

could also pursue a conﬁguration with multiple fed-

erator instances associated with a single broker.

Even though we have not employed any SDN or

NFV resources, it is left for future work to explore

such capabilities. A node entity requires to know its

immediate one-hop neighbors in the virtual topology

to get things started up. It does not matter where

nodes are physically present since they get to com-

municate to their neighboring nodes. Therefore, there

is plenty of space to explore virtual network resources

spanning multiple domains/providers.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

840

Table 2: Federated solution: publication delay (publisher at node 6).

Publ. Subscriber at Node 2 Subscriber at node 7

500 34.64 ± 3.21 ms 18.65 ± 3.2 ms

1000 34.77 ± 3.17 ms 18.61 ± 3.17 ms

Table 3: Centralized solution: publication delay (publisher at node 6).

Publ.

Broker at Node 2 Broker at Node 7

Delay (ms) Delay (ms)

Sub. A Sub. B Sub. A Sub. B

500 34.59 ± 3.13 42.47 ± 4.37 18.63 ± 3.2 26.69 ± 4.77

1000 34.58 ± 3.23 42.58 ± 4.48 18.47 ± 3.22 26.42 ± 4.56

8 CONCLUSION

The P/S communication paradigm has paved the way

for the development of many IoT applications and

platforms. Communication between clients (i.e., pub-

lishers and subscribers) can occur asynchronously, al-

lowing many devices connected to the server/broker.

Among the available P/S protocols, MQTT plays a vi-

tal role in the development of IoT applications.

Nevertheless, in the centralized MQTT architec-

ture, the broker conﬁgures itself as a single point of

failure, besides being a potential bottleneck. To better

deal with such limitations, one could resort to archi-

tecture with redundant broker deployment. Anyhow,

the emerging environment would require more atten-

tion to the conﬁguration and management of the in-

frastructure.

A protocol for the federation of autonomous bro-

kers is available in the literature. The solution cen-

ters on subscribers’ meshes, and it lets us build and

maintain a routing infrastructure with minimum con-

trol overhead. However, the proposal does not include

any real implementation. In addition to that, the solu-

tion is supposed to require modiﬁcations to the inner

implementation of brokers.

This work explored an endogenous approach for

the federation of MQTT brokers: it proposed the fed-

eration of brokers through an application, named fed-

erator, playing a supporting role together with stan-

dard brokers. The P/S mechanism is itself the primary

communication mechanism employed for achieving

the federation of brokers.

While standard brokers require no modiﬁcations,

applications must adhere to the federation protocol.

Be that as it may, it could be a little price to pay for

the extra degree of freedom when it comes to build-

ing a federation infrastructure. With all the currently

available virtualized computing and communication

resources, one can pick the desired virtual network

topology as needed, all at the application layer. One

could conceive the federation process as a new cloud

service.

Given that there is no available implementation

for the original federation protocol, it is impossible to

compare their solution to ours in terms of overall per-

formance. However, the other beneﬁts (e.g., load bal-

ancing, increased degree of fault tolerance) outweigh

eventual manageable performance issues.

REFERENCES

Al-Fuqaha, A., Guizani, M., Mohammadi, M., Aledhari,

M., and Ayyash, M. (2015). Internet of things: A

survey on enabling technologies, protocols, and ap-

plications. IEEE Communications Surveys Tutorials,

17(4):2347–2376.

Corp., I. (2020). Distributed publish & subscribe for

the internet of things (dps). https://intel.github.io/

dps-for-iot.

Docker (2020). Docker container. ”https://docs.docker.

com/engine/reference/commandline/container/”.

Foundation, E. (2020a). Eclipse mosquitto: An open source

mqtt broker. ”https://mosquitto.org”.

Foundation, E. (2020b). The paho project. ”https://www.

eclipse.org/paho/”.

HiveMQ (2020). Hivemq’s mqtt broker. https://www.

hivemq.com/.

Park, J.-H., Kim, H.-S., and Kim, W.-T. (2018). Dm-mqtt:

An efﬁcient mqtt based on sdn multicast for massive

iot communications. Sensors, 18(9).

Spohn, M. A. (2020). Publish, subscribe and federate! Jour-

nal of Computer Science, 16(7):863–870.

Standard, O. (2020). Mqtt version 5.0. http://docs.

oasis-open.org/mqtt/mqtt/v5.0/mqtt-v5.0.html.

SwiftMQ (2020). Swiftmq platform. https://www.swiftmq.

com/.

An Endogenous and Self-organizing Approach for the Federation of Autonomous MQTT Brokers

841
