Problem of Inconsistency in Textual Requirements Speciﬁcation

David

Senk

and Petr Kroha

Faculty of Information Technology, Czech Technical University in Prague, Czech Republic

Keywords:

Textual Requirements Speciﬁcation, Text Processing, Inconsistency, Patterns, Domain Model.

Abstract:

In this contribution, we investigate the inconsistency problem in the textual description of functional require-

ments speciﬁcations. In the past, the inconsistency problem was investigated using analysis of the UML

models. We argue that some sources of inconsistency can be revealed in the very ﬁrst steps of textual re-

quirements analysis using linguistic patterns that we developed. We cluster the sentences according to their

semantic similarity given by their lexical content and syntactic structure. Our contribution focus on revealing

linguistic contradictions (e.g., a combination of passive voice, antonyms, negated synonyms, etc.) of facts

and rules described in different parts of requirements together with contradictions of the internally generated

model.

1 INTRODUCTION

Requirements speciﬁcations, their elicitation and

analysis belong to the very ﬁrst phase of the soft-

ware development, and it is well-known that mis-

takes done in this phase are the most expensive ones.

Using inconsistent information in requirements leads

to the wrong model. After implementation and test-

ing, the resulting program has to be later laboriously

enhanced.

Textual requirements do not always contain con-

sistent information about the system to be con-

structed. The reason is that they might be written by

independent groups of stakeholders who have differ-

ent interests, goals, backgrounds, and/or (incomplete)

knowledge of the domain.

The conﬂicts may erase in the case when more

than one requirement, i.e., a set of requirements

SR, refers to the same object of the domain. It

will be denoted as an overlap between requirements

(Spanoudakis and Finkelstein, 1998). In this paper,

we identify two kinds of the core sources of the in-

consistency of textual requirements. First, semantic

overlaps of requirements sentences, e.g., at least two

contradicting assertions exist that concern the same

subject and the corresponding verb with the object.

Second, the incompleteness of requirements (we dis-

cussed it in our paper (

Senk

r and Kroha, 2019b)).

Our goal is to reveal at least some of the inconsisten-

https://orcid.org/0000-0002-7522-3722

https://orcid.org/0000-0002-1658-3736

cies, and to generate questions or warning messages

that have to be answered by domain experts and an-

alysts. The answers have to be used to edit the text

of requirements. The text of the requirements is the

only source of information. We divided the text anal-

ysis into two phases. The ﬁrst phase builds a UML

model from sentences using the grammatical inspec-

tion (

Senk

r and Kroha, 2018) – see Example 1 in

Section 3.2. The second phase provides an analy-

sis of sentences using our linguistic patterns with the

goal to ﬁnd contradictions in them. Part of it is the

using information already stored in the UML model.

We use the part-of-speech and dependency analysis

of sentences to construct the corresponding oriented

graphs, and we analyze sentences that describe the

same event. We present our patterns that may indi-

cate candidates for inconsistency.

Our paper is structured as follows. In Section 2,

we discuss related work. In Section 3, we describe

sources of inconsistency that we are trying to iden-

tify. Our approach is presented in Section 4. Our im-

plementation is described in Section 5. Used data,

experiments, and results are discussed in Section 6.

In Section 7, we summarize the achieved results and

conclude.

2 RELATED WORK

The problem of inconsistency of requirements spec-

iﬁcation has been investigated since the late '80s

Šenký

r, D. and Kroha, P.

Problem of Inconsistency in Textual Requirements Speciﬁcation.

DOI: 10.5220/0010421602130220

In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 213-220

ISBN: 978-989-758-508-1

213

(Hunter and Nuseibeh, 1998). As basic papers and

surveys, we can denote (Spanoudakis and Zisman,

2001) and (Kamalrudin and Sidek, 2015).

Some works are based on semi-formal speciﬁca-

tions in the form of UML diagrams (Torre et al., 2018)

and use methods of formal speciﬁcations (Schamai

et al., 2016) to check the consistency. However, the

adoption of formal methods is still not widely ac-

cepted by industries (Fanmuy et al., 2012). Other

works use ontologies (Kroha et al., 2009) or OCL

(da Silva and Fernandes, 2018).

Our approach uses informal speciﬁcations written

in natural language. There is some similarity to the

approach described in (Gargiulo et al., 2015). The

difference is that in (Gargiulo et al., 2015), the au-

thors use only RDF triplets representation of the tex-

tual requirements speciﬁcations, whereas we use the

complete text. The knowledge represented in RDF

consists of triplets hsubject, predicate, objecti. How-

ever, it reduces the semantic meaning of most sen-

tences drastically because of the omitted information

carried by omitted words in sentences. We use struc-

ture similar to RDF triplets only to cluster sentences.

Computational linguistics is engaged in a problem

of text entailment (in query answering). The edit dis-

tance of two sentences (text and hypothesis) is used

as a measure. A similar approach to the contradiction

of two sentences is used in (de Marneffe et al., 2008)

– see Section 3.1.1. The difference to our approach is

that linguists do not use the information stored in the

UML model (

Simko et al., 2013) – see Example 1 in

Section 3.2 to check the completeness that can be a

source of inconsistency.

3 SOURCES OF INCONSISTENCY

In our investigation, we distinguish the following

sources of inconsistency: inconsistency caused by se-

mantic overlaps of sentences (Section 3.1), inconsis-

tency caused by incompleteness (Section 3.2), and in-

consistency caused by external information. Because

of the limited scope of this paper, we do not discuss

the last case here. However, we analyze it in our paper

about default consistency rules (

Senk

r and Kroha,

2021).

3.1 Semantic Overlaps as Sources of

Inconsistency

The idea of inconsistency starts from the intuitive con-

cept of contradiction, which means that a statement

and its negation are found to hold simultaneously

(Gargiulo et al., 2015). A semantic overlap between

two sentences occurs if these two sentences express

their statements about the same situation. The prob-

lem is how to reveal the contradiction of statements

because they are often expressed in some “camou-

ﬂaged” forms using synonyms, antonyms, and others

“linguistic tricks” (Section 3.1.1).

3.1.1 The Linguistic Sources of the

Inconsistency

In (de Marneffe et al., 2008), there is a list of con-

tradiction types from a linguistic point of view. We

adapted it for purposes of our patterns as follows:

• using antonyms,

• using a negation,

• using a combination of synonyms together with

changed roles of subject and object, passive voice,

and negation, e.g., “the user can edit a document”

contra “the user cannot correct a document in this

mode” (here, we suppose that the verbs “to edit”

and “to correct” have the same meaning) contra

“a document cannot be corrected by the user”,

• using numerically different data, e.g., “you will

start the function by double click” contra “you

will start the function by one click”,

• using factive contradiction in the sense of

attributes of the subject,

• using lexical contradiction, e.g., “to obtain results

stay joined and wait” contra “to obtain results

restart the application” contra “to obtain results

restart the system”,

• using world knowledge to indicate the contradic-

tion, e.g., “there is public access to your private

data”.

Additionally, some words may change, inﬂuence, or

limit the sense of the sentence, e.g., but, except, how-

ever, instead of, when, so that, that.

3.2 Inconsistency between the Text and

the UML Model

Using the grammatical inspection in the ﬁrst phase

of our process, we construct a skeleton of the UML

model, e.g., classes, attributes and their values, meth-

ods. When we later compare the sentences, in which

the attribute and its values are mentioned, we test

whether all attribute values are mentioned in formu-

lations deﬁning decisions about the object’s behav-

ior. If some of them are not mentioned, then this

incompleteness can cause inconsistency, because it

may happen that the behavior is not deﬁned for the

missing attribute values. Further, we test whether the

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

214

chains of applied methods are the same in sentences

of the similar semantics – see Example 2. In this way,

we can ﬁnd conﬂicts among descriptions of instances,

classes, and relations of the static model, and also

among descriptions of sequence diagram and state di-

agram of the dynamic model. We search for sentences

that describe the same event and compare them. More

details are given in Section 4.1.

In general, we suppose that the textual description

of requirements speciﬁcation contains:

• The sentence S

, in which an attribute value of an

object O is expected to be V

to start a speciﬁc

action A in a speciﬁc context Cont.

• The sentence S

, in which an attribute value of

an object O is expected to be V

to start the same

speciﬁc action A in a speciﬁc context Cont.

Example 1: Attributes of A Button.

Maybe, the following sentences are a part of a require-

ments speciﬁcation:

1. To exit the application, the user has to press the

red button.

2. To exit the application, the user has to press the

square-shaped button.

3. To exit the application, the user has to press the

EXIT-button.

Analyzing these requirements, we can derive that

the class Button has the Button-attribute color, the

Button-attribute shape, and the Button-attribute label.

This means, these sentences as part of the require-

ments are confusing, but they are not inconsistent be-

cause a red, square-shaped button with the label EXIT

may exist, i.e., it is possible to construct an object of

class Button, whose attributes color, shape, and label

have the described values.

Our task is to generate a message saying that there

is a suspicion of inconsistency. In any case, this is a

not preferable style of writing textual requirements.

(End of Example)

Another case, we found, concerns the sequence of ac-

tions that is stored in a sequence diagram. If the chain

of actions differs in different sentences that should

have the same effect, we generate a warning message.

Example 2: A Missing Segment in A Chain of Ac-

tions.

Sentence 1: To edit a ﬁle, the user has to open the

ﬁle, make changes, save the ﬁle (or save the ﬁle as),

and close the ﬁle.

Sentence 2: To edit a ﬁle, the user has to open the

ﬁle, make changes, and close the ﬁle.

(End of Example)

4 PATTERNS AS OUR APPROACH

Our motivation and goal are to identify suspicious tex-

tual formulations that could be the source of inconsis-

tency.

Figure 1: The idea of inconsistency patterns.

The idea of our approach is shown in Fig. 1. The ba-

sic structure is given by subject–verb–object. How-

ever, they can be expressed by related synonyms,

antonyms, direct negation, and numerical data. So,

the spectrum of possible descriptions of one statement

is very rich. Our patterns should reveal it. Practical

examples of data used for experiments are given in

Section 6.1.

4.1 Model Construction and

Semantically Similar Sentences

For our methods, the sentences containing the stan-

dard couple of subject and verb or the to-inﬁnitive

clauses are interesting. We beneﬁt from mapping

such sentences to acts. One reason is that one sen-

tence can represent multiple acts. Our act is a tuple

containing: the original subject of the sentence, the

original verb of the sentence, the original object of the

sentence, an indicator of whether the sentence con-

tains negation, an auxiliary verb if present, an adver-

bial modiﬁer (e.g., automatically) if present, a predi-

cate (e.g., only one, each ) if present, a condition act

if present, what is the point of interest if recognized,

who is responsible for the action if recognized.

To reduce the complexity of the analysis, we de-

ﬁne semantically similar acts as follows:

Problem of Inconsistency in Textual Requirements Speciﬁcation

215

Students may borrow books but not proceedings.

NN* AUX VB NN* CC PART NN*

ccaux dobj neg

nsubj conj

Figure 2: Matched Pattern #1 (Pure Negation).

• C

: acts having the same subject, verb, and object,

• C

: acts having the same subject and verb (passive

mode),

• C

: acts having the same subject (passive mode),

• C

: acts having the same subject and object,

• C

: acts having the same what-part and verb.

To understand the graphical representation of the pre-

sented sentence patterns, we explain it using the pat-

tern in Fig. 3. We use part-of-speech tags provided

by spaCy

(based on Universal Dependencies v2 POS

tag set) where VB is a verb, NN is a noun, etc. Of-

ten, subjects and objects are represented by a compo-

sition of several nouns. Therefore, we introduce the

shortened notation NN*, which means that at least one

noun is required, but there should also be two or more

nouns connected via compound relation. In the ﬁrst

phase, we need to consider the following steps:

• negation recognition – We check the pure nega-

tion of verbs (can–can not–can’t) or compound

nouns via Pattern in Fig. 3. In Fig. 2, there is

this pattern matched as a part of matching stan-

dard subject–verb–object(s) pattern. Besides the

not part, there are other words inﬂuencing the

negation of meaning. Let’s show the pattern of

the word except in Fig. 4 as an example.

not *

PART NN*/VB

neg

Figure 3: Pattern #1 (Pure Negation).

except *

CC NN*

pobj

Figure 4: Pattern #2 (Except).

• coreference recognition – Clustering of sentences

based on subject or object is challenging because

of the coreferences of pronouns. This means that

we are not simply looking for all sentences that

have the same subject or object.

• predicates recognition – We identify parts of sen-

tences that describe predicates – numeric ones

(see Fig. 5) or determiner ones (see Fig. 6). The

determiner should be represented by words like

each, every, all, any, etc. We use the simple ﬁrst-

order logic deﬁnition saying that a predicate is a

https://spacy.io/api/annotation#pos-tagging

statement about the properties of an object that

may be true or false depending on the values of

its variables. Predicates can affect actors of rela-

tions as with relation “borrow” in example sen-

tence in Fig. 7 or aspects and limits of classes via

auxiliary verb “be” (see Fig. 8). Mapped pred-

icates also may indicate cardinalities of relations

between actors or objects. We ﬁnd predicates con-

cerning the same objects and the same attributes.

only one system administrator

ADV NUM NN*

advmod nummod

Figure 5: Pattern #3 (Numeric Predicate).

each system administrator

DT NN*

det

Figure 6: Pattern #4 (Determiner Predicate).

Each member can borrow magazines.

DT NN AUX VB NN

auxdet dobj

nsubj

Figure 7: Relation actor predicate.

penalty is same for all users

NN* AUX ADJ ADP DT NN*

attr prep detrelcl

pobj

Figure 8: Pattern #5 (Predicate and Auxiliary Verb).

• condition recognition – Describing actions often

includes a conditional part. The conditional parts

of two sentences may have the same subject–

verb–object. If one sentence considers the posi-

tive case and another sentence considers the nega-

tive case, then there would be a conﬂict generating

a warning because of the negation of the action.

We use these conditional parts as separate condi-

tional acts (affecting standard acts) in the conﬂict

resolution of the standard acts.

4.2 Example: Library Information

System

We use and extend the simple example of Library

information system requirements from (Spanoudakis

and Finkelstein, 1998).

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

216

Example 3: Functional Requirements.

FR 1. Users of the Library information system are

students and staff members.

FR 2. Users borrow books.

FR 3. Holding an item is limited in time.

FR 4. Holding an item beyond the time limit carries

a penalty, which is the same for all users.

FR 5. Students may borrow books but not procee-

dings.

FR 6. Staff members can borrow both books and pro-

ceedings.

FR 7. Students may borrow an item for up to 10 days.

Holding an item beyond this period carries a

penalty of 50 p per day.

FR 8. Staff members can borrow an item for up to

30 days. Holding an item beyond this period

carries a penalty of 10 p per day.

FR 9. Each user except an administrator needs to

change his/her password every three months.

(End of Example)

The purpose of this example is to show the contradic-

tion caused by teaching students. We use it to illus-

trate our approach. When using an algorithm to an-

alyze these textual requirements instead of a human

being analyst (like in (Spanoudakis and Finkelstein,

1998)), we can see the following problems:

1. In FR 1, there are two missing rules. In our

paper (

Senk

r and Kroha, 2021), we call them default

consistency rules. The ﬁrst default consistency rule is

“All information systems need an administrator, who

is a unique, speciﬁc user”. The second default consis-

tency rule is “All libraries need library staff members,

who are speciﬁc users of the library information sys-

tems, too”.

So, the set of users is incomplete, and it has to be

completed. In this case, we model the classes and the

Is-a relation between user (as a superclass) and sub-

classes student and university-staff-member. Then,

we generate a question asking about the completeness

of this relation, i.e., whether the superclass user has

only these two mentioned subclasses. The right an-

swer contains not only the missing administrator and

the missing library staff member but also the missing

teaching students. After the subclasses administrator,

library staff member, and teaching student will be in-

cluded into the requirements, our system TEMOS will

complain of incompleteness because the loan time pe-

riods and penalties are not deﬁned for these three sub-

classes.

2. In FR 2, the formulation “Users borrow books”

is misleading because users not only borrow books.

They hold them and have to return them, too. With-

out this information, the time limit mentioned in FR

4 and the period mentioned in FR 7 and FR 8 makes

no sense. Using linguistic analysis, we ﬁnd that there

are only the verbs “borrow” and “change (the pass-

word)”. Here, we can see the incompleteness as the

source of the inconsistency again.

3. In FR 3, this formulation is understandable to

a human being but not to an algorithm. “Holding an

item” means “holding a borrowed item”. Our sys-

tem generates a message: “The requirements No. 3 is

not understandable”. The domain expert can answer:

“Users borrow books, hold them, and return them.”

4. In FR 5, there is matched Pattern #1 (Pure

Negation) as shown in Fig. 2.

5. In FR 7 and FR 8, we can detect an inconsis-

tency to FR 4. Either all library users pay the same

penalty or different penalty according to their status.

6. In FR 9, there is Pattern #4 (Determiner Pred-

icate) matched twice (“each user” and “every three

months”) and Pattern #2 (Except) is matched once.

5 IMPLEMENTATION

Our tool TEMOS is a single-page web application.

The current version of the back-end is written in

Python, and it is powered by spaCy

NLP framework

in version 2.2. We use texts written in English, and

for this purpose, we use the pre-trained model called

en core web lg (available together with spaCy instal-

lation).

The workﬂow of our implemented tool extends the

original one presented in (

Senk

r and Kroha, 2018).

First, we use the base text classiﬁcation provided by

spaCy. It includes tokenization, sentence segmenta-

tion, part-of-speech tagging, lemmatization, depen-

dency recognition, and co-reference recognition.

The next step is to check the text against inaccura-

cies. This check is optional but recommended before

our tool starts to generate the output model. So far,

we tackle the ambiguity and incompleteness issues.

Based on the methods presented in this paper, we im-

plemented the module denoted to acts clustering and

inconsistency revealing.

https://spacy.io

Problem of Inconsistency in Textual Requirements Speciﬁcation

217

The system has only one system administrator.

DT NN AUX ADV NUM NN*

advmoddet nsubj nummod

dobj

Figure 9: Consistency rule from Example 2.

6 DATA, EXPERIMENTS,

AND RESULTS

To test our methods, we need the ﬁrst version of tex-

tual requirements in its “raw” form. Unfortunately,

there are not collections of textual requirements spec-

iﬁcations available that would be large enough. Soft-

ware companies hold them classiﬁed as conﬁdential.

So, our experimental data were of limited size. We

checked the same collection of requirements that we

checked in (

Senk

r and Kroha, 2019a). However, we

did not ﬁnd direct contradictions in these speciﬁca-

tions. Because of that, we constructed a benchmark

described below.

6.1 Data

To test our set of patterns, we needed a large set of tex-

tual requirements sentences to evaluate the precision

and the recall of our method. Moreover, we needed to

know the number of sentences suspicious from incon-

sistency before computing the numbers of true/false

positive and true/false negative cases. The only way

we have seen was to construct benchmark data.

We decided to focus on antonyms; negations;

a combination of synonyms together with swapped

roles of subject and object, passive voice, and nega-

tion; and numerically different data described in Sec-

tion 3.1.1.

We used the text of the user guide describing the

functionality of a known information system that is

used to support stock market trading. The text volume

is 1,108 pages. It consists of 14,114 sentences. We

transformed the rules described in Section 3.1.1 into

linguistic patterns, and we applied the patterns to ﬁnd

semantically overlapping sentences as candidates for

inconsistency (see below).

6.1.1 The List of Antonyms

The list of antonyms used to test the inconsis-

tency: source—destination, ﬁrst—last, all —selected,

open—close, at the front—at the end, send—

receive, numeric—alphabetic, high—low, valid—

invalid, insert —delete, locked—unlocked, unique—

duplicated, chronologically sorted —alphabetically

sorted, able—unable, in only one—in one or more,

private—public, at the bottom—at the top, expanded

list—reduced list, upper-right corner of the win-

dow—upper-left corner of the window, undo com-

mand —redo command, enable—disable, more—

less, appear—disappear, manually—automatically.

6.1.2 The List of Negations

The list of negations used to test the inconsistency:

• simple negations of verb forms (modal verbs, e.g.,

“it is the same”, “it is not the same”, standard

verbs, e.g., “it exists”, “it does not exist”),

• negation of the similar meaning, e.g., “imported

data can’t be modiﬁed” contra “you can modify

the imported data”,

• complex negations of the sentence meaning, e.g.,

“you can display it if you are in the Mode Check-

ing” contra “you can display it at any time”.

6.1.3 The List of Numerically Different Data

The numerical data can be given by digits, by words,

or by other means, e.g., Max-Int. We test the similar

sentences and generate warnings when some suspi-

cious formulations are found. For example: “There

is an unused ﬁeld that should be set to zero.” contra

“There is an unused ﬁeld that should be set to Max-

Int.”

Example 4: A Unique Object.

Sentence 1: The system has only one system ad-

ministrator.

Sentence 2: All system administrators have the

same access rights, but each of them has his/her pass-

word.

Here, Pattern #3 (Numeric Predicate) is matched

as shown in Fig. 9. We generate a warning message,

because “only one system administrator” in the ﬁrst

sentence and “All” and “each of them” (system ad-

ministrators) in the second sentence contradict each

other.

Pattern #4 (Determiner Predicate) is matched two

times. First, it is applied in the part “All system ad-

ministrators”. Second, it is applied in the part “each

of them” when the co-reference to system administra-

tors is resolved.

(End of Example)

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

218

Table 1: Clusters: Numbers, Cardinalities, and False Positives.

False FP FP

Cluster Positives Total -BR -NLP

: The same SUBJECT, VERB, and OBJECT 10 = 8 + 2

#: 881 Cardinalities: 2–97

: The same SUBJECT and VERB 7 = 5 + 2

– passive mode, without OBJECT

#: 167 Cardinalities: 2–69

: The same SUBJECT 2 = 2 + 0

– passive mode, without OBJECT

#: 138 Cardinalities: 2–31

: The same SUBJECT and OBJECT 12 = 11 + 1

#: 883 Cardinalities: 2–97

: The same WHAT-part and VERB 0 = 0 + 0

#: 400 Cardinalities: 2–71

Legend: FP-BR – false positives matched because of too complex sentences or sentences across different contexts,

FP-NLP – false positives matched because of bad recognition of part-of-speech tag and/or dependency.

6.1.4 The Incomplete List of Items

We identify this source of inconsistency using the

UML model that we obtained in the ﬁrst phase of

the processing. In the model, the attribute values are

given by a list of values, but in some sentences, only

a subset of them is mentioned. Often, this is a signal

that a reaction to some state of the system has been

forgotten. In this case, the incompleteness (

Senk

and Kroha, 2019b) is the source of the inconsistency.

6.2 Benchmark Construction

To ﬁnish the benchmark data construction, we used

the words given above in sections 6.1.2, 6.1.2, 6.1.3,

and 6.1.4 to construct similar sentences (similar to the

original) that should have the contradict meaning.

We interlarded the original text with our con-

structed sentences, and we noticed the numbers and

positions of our artiﬁcially constructed sentences that

are in contradiction with the original sentences to

get precision and recall results when evaluating our

method of inconsistency identiﬁcation.

6.3 Experiments and Results

As mentioned in Section 6.1, our original text has

1,108 pages. There were 14,114 sentences found.

Additionally, we constructed sentences (using words

and phrase given above) that contain contradictions to

some of the original sentences. In numbers, they were

added:

• 21 sentences containing the antonyms as the con-

tradiction source – testable in clusters C

, C

and C

• 435 sentences containing the negations as the con-

tradiction source – testable in all clusters,

• 9 sentences containing the numerically different

data – testable in all clusters,

• 32 sentences containing an incomplete list of at-

tribute values.

Doing this, we obtained a new text having 14,611 sen-

tences. As can be seen in the list above, some issues

can be detected directly on the clusters (as proposed

in Sec. 4.1), some only when compared with the in-

ternal model. After applying our method, we have

got the results shown in Table 1. We recognized all is-

sues of our added sentences, but there were, of course,

some false positives. In the result table, we show the

reasons. The ﬁrst category represents false positives

matched because of too complex sentences or sen-

tences in different contexts where the current version

of our acts and patterns are not enough. The second

category represents false positives matched because

of bad recognition of part-of-speech tag and/or de-

pendency provided by the NLP framework.

7 CONCLUSIONS

Textual formulations of requirements speciﬁcation

may contain (and usually contain) some sources of

contradiction that may cause inconsistency. This fact

increases the software development costs because of

the need for repairs during the development, tests, and

maintenance.

In this paper, we described our method that sup-

ports the identiﬁcation of inconsistency in textual re-

quirements speciﬁcation at the very ﬁrst phase of the

Problem of Inconsistency in Textual Requirements Speciﬁcation

219

software development. Using linguistic modules, we

ﬁnd occurrences of patterns that are typical for formu-

lations containing inconsistency. We have used syn-

onyms, antonyms, negations, and numerically differ-

ent data as the most simple linguistic sources of con-

tradiction.

The natural language and the semantics of the

described reality are too rich in possibilities how to

describe it. Consequently, we speak about suspi-

cious formulations and generate warning messages

and questions on domain experts. We do not try to

solve or correct the found inconsistencies automati-

cally.

One of the limits of our method is its scalability,

even though the data from our experiments (see Table

1) obtained for a text volume of 14,611 sentences are

promising. Our plan is to combine our patterns con-

cerning ambiguity, incompleteness, and inconsistency

in a large industrial case study. Further, we suppose

that the situation could change if we had the domain

ontologies to construct consistency rules.

ACKNOWLEDGEMENTS

This research was supported by the grant of

Czech Technical University in Prague No.

SGS20/209/OHK3/3T/18.

REFERENCES

da Silva, A. R. and Fernandes, J. C. (2018). Variabil-

ity Speciﬁcation and Resolution of Textual Require-

ments. In Proceedings of the 20th International

Conference on Enterprise Information Systems, pages

157–168. SciTePress – Science and Technology Pub-

lications.

de Marneffe, M.-C., Rafferty, A. N., and Manning, C. D.

(2008). Finding Contradictions in Text. In Moore, J.,

Teufel, S., Allan, J., and Furui, S., editors, Proceed-

ings of ACL-08: HLT, pages 1039–1047, Columbus,

Ohio. Association for Computational Linguistics.

Fanmuy, G., Fraga, A., and Llorens, J. (2012). Require-

ments Veriﬁcation in the Industry. In Hammami, O.,

Krob, D., and Voirin, J.-L., editors, Complex Systems

Design & Management, pages 145–160, Berlin, Hei-

delberg. Springer Berlin Heidelberg.

Gargiulo, F., Gigante, G., and Ficco, M. (2015). A Seman-

tic Driven Approach for Requirements Consistency

Veriﬁcation. Int. J. High Perform. Comput. Netw.,

8(3):201–211.

Hunter, A. and Nuseibeh, B. (1998). Managing Inconsis-

tent Speciﬁcations: Reasoning, Analysis, and Action.

ACM Trans. Softw. Eng. Methodol., 7(4):335–367.

Kamalrudin, M. and Sidek, S. (2015). A Review on Soft-

ware Requirements Validation and Consistency Man-

agement. International Journal of Software Engineer-

ing and Its Applications, 9(10):39–58.

Kroha, P., Janetzko, R., and Labra, J. E. (2009). Ontolo-

gies in Checking for Inconsistency of Requirements

Speciﬁcation. In 2009 Third International Conference

on Advances in Semantic Processing, pages 32–37,

Sliema, Malta. IEEE Computer Society Press.

Schamai, W., Helle, P., Albarello, N., Buffoni, L., and Fritz-

son, P. (2016). Towards the Automation of Model-

Based Design Veriﬁcation. INCOSE International

Symposium, 26(1):585–599.

Senk

r, D. and Kroha, P. (2018). Patterns in Textual Re-

quirements Speciﬁcation. In Proceedings of the 13th

International Conference on Software Technologies,

pages 197–204, Porto, Portugal. SciTePress – Science

and Technology Publications.

Senk

r, D. and Kroha, P. (2019a). Patterns of Ambiguity

in Textual Requirements Speciﬁcation. In Rocha,

A.,

Adeli, H., Reis, L. P., and Costanzo, S., editors, New

Knowledge in Information Systems and Technologies,

volume 1, pages 886–895, Cham. Springer Interna-

tional Publishing.

Senk

r, D. and Kroha, P. (2019b). Problem of Incom-

pleteness in Textual Requirements Speciﬁcation. In

Proceedings of the 14th International Conference on

Software Technologies, volume 1, pages 323–330,

Porto, Portugal. INSTICC, SCITEPRESS – Science

and Technology Publications.

Senk

r, D. and Kroha, P. (2021). Problem of Inconsistency

and Default Consistency Rules. Prepared to be sub-

mitted.

Simko, V., Kroha, P., and Hn

etynka, P. (Prague, 2013). Im-

plemented Domain Model Generation. Technical Re-

port No. D3S-TR-2013-03, Department of Distributed

and Dependable Systems, Faculty of Mathematics and

Physics, Charles University.

Spanoudakis, G. and Finkelstein, A. (1998). A Semi-

automatic Process of Identifying Overlaps and Incon-

sistencies between Requirements Speciﬁcations. In

Rolland, C. and Grosz, G., editors, OOIS’98, pages

405–424, London. Springer London.

Spanoudakis, G. and Zisman, A. (2001). Inconsistency

Management in Software Engineering: Survey and

Open Research Issues. In Handbook of Software Engi-

neering and Knowledge Engineering: Volume I: Fun-

damentals, pages 329–380. World Scientiﬁc.

Torre, D., Labiche, Y., Genero, M., and Elaasar, M. (2018).

A Systematic Identiﬁcation of Consistency Rules for

UML Diagrams. Journal of Systems and Software,

144:121–142.

ENASE 2021 - 16th International Conference on Evaluation of Novel Approaches to Software Engineering

220
