tack and defense trees. This results in quantitative
analysis techniques using tools such as Uppaal (Ku-
mar and Stoelinga, 2017) or PRISM (Aslanyan et al.,
2016). In our work, we identified threats and coun-
termeasures but did not organise them in a systematic
attack-defense tree. This could be another comple-
mentary approach to analyse the system security.
6 CONCLUSION AND NEXT
STEPS
In this work, we reviewed a representative sample of
firmware update protocols and identified how they can
cope with security requirements and related attacks.
We highlighted the need of a more formal verifica-
tion approach. We proposed a partial modelling of
the UpKit protocol and could successfully verify key
integrity and freshness properties. Although partial
and anchored in a specific protocol, our results so far
show several commonalities and the modelling and
verification approach can be generalised to most pro-
tocols and security properties. The sketched approach
can also be used to verify security properties on the
MQTT or Uptane protocols. The distributed nature of
the blockchain design requires specific techniques to
get security assurance. They can however be captured
by assumptions to carry out proofs on the interaction
between the device and the blockchain.
In the next steps of our research, we plan to cover
the lasts steps of the UpKit protocol and then to model
the more complex Uptane protocol, including mul-
tiple roles with related keys, secondary ECUs and
the use of a timeserver. We also plan to investigate
more deeply the blockchain-based designs and to bet-
ter structure security requirements, attacks and design
countermeasures using an attack-defense tree.
