Using Binary Strings for Comparing Products from

Software-intensive Systems Product Lines

Mike Mannion

and Hermann Kaindl

Department of Computing, Glasgow Caledonian University, 70 Cowcaddens Road, Glasgow, G4 0BA, U.K.

Institute for Computer Technology, TU Wien, Gußhausstr. 27-29, A-1040, Vienna, Austria

Keywords: Product Line, String Similarity, Metrics.

Abstract: The volume, variety and velocity of products in software-intensive systems product lines is increasing. One

challenge is to understand the range of similarity between products to evaluate its impact on product line

management. This paper contributes to product line management by presenting a product similarity evaluation

process in which (i) a product configured from a product line feature model is represented as a weighted

binary string (ii) the overall similarity between products is compared using the Jaccard Coefficient similarity

metric (iii) the significance of individual features and feature combinations to product similarity is explored

by modifying the weights. We propose a method for automatically allocating weights to features depending

on their position in a product line feature model, although we do not claim that this allocation method nor the

use of the Jaccard Coefficient is optimal. We illustrate our ideas with mobile phone worked examples.

1 INTRODUCTION

Many systems today are software-intensive and it is

often the software features that help make a product

distinctive. A product line comprises products that

share sets of features. A feature is often but not al-

ways a visible characteristic of a product. Some fea-

tures may be shared across all products; some may be

shared across many but not all products; some may be

unique to a single product. Whilst product lines can

generate significant cost-efficiencies, the ongoing

management of their scope and scale is getting harder

as customers increasingly demand personalised prod-

ucts (Deloitte, 2015, Zaggi, 2019). The range of prod-

ucts in a product line and the features in each product

evolve for many reasons including supplier sales and

profit motives, customer demand, customer confu-

sion (Mitchell, 1999), personnel changes, market

competition, brand positioning (Punyatoya, 2014),

mergers and takeovers, or changing legislation. One

challenge of the management task is understanding

which products in the product line are similar to each

other and the extent. This paper addresses that chal-

lenge.

https://orcid.org/0000-0003-2589-3901

https://orcid.org/0000-0002-1133-0529

The research question is: to what extent can prod-

uct similarity within a product line be determined by

a product similarity evaluation process that uses a

weighted binary string to represent product features

and a binary string metric to evaluate similarity

(where 1 represents a feature’s presence, 0 its ab-

sence, and the weight represents its relative im-

portance to the product)? Our interest is in the merits

and difficulties of the overall process. We do not

claim our choices of binary string encoding, weight

allocation method or binary string metric are optimal.

We illustrate the process using a worked example of

a mobile phone product line.

Binary strings offer a straightforward flexible

means to represent product feature configurations.

They map easily to feature selection processes, are

low on storage requirements and enable fast compar-

ison computations with existing similarity metrics

and measuring tools e.g. (Rieck, 2016). The metrics

are based on feature counts and assume each feature

has equal contextual value. However, one outcome is

that two products can be similar to the same degree

even if one product is missing what might be regarded

as essential features, but makes up the feature count

Mannion, M. and Kaindl, H.

Using Binary Strings for Comparing Products from Software-intensive Systems Product Lines.

DOI: 10.5220/0010441002570266

In Proceedings of the 23rd International Conference on Enterprise Information Systems (ICEIS 2021) - Volume 2, pages 257-266

ISBN: 978-989-758-509-8

257

deficit with less important features. One way to ad-

dress this issue is to attach a weight to each feature

signalling its relative importance. For large feature

trees, this is only feasible if the initial allocation is

done automatically. We devised a method for auto-

matic allocation based on a feature’s position in the

product line feature model.

There are many binary similarity (and dissimilar-

ity) metrics. We selected the Jaccard Coefficient (JC)

similarity metric (Jaccard, 1901) because it compares

only the total number of common features in both

products. It was also used in other product line activ-

ities e.g. to identify similar groups of products that

can be manufactured on the same assembly lines

(Yuzgec, 2012, Kashkoush, 2014), for reverse engi-

neering a requirements repository (Li, 2019), for re-

verse engineering software components (Naseem,

2017), to detect adverse interactions when a new fea-

ture is introduced into an ageing software product line

(Khoshmanesh, 2018).

Section 2 discusses some challenges of making

product comparisons. Section 3 presents a similarity

evaluation process using a mobile phone product line

worked example. Section 4 shows a small real-world

iPhone example. Section 5 discusses these ideas.

2 BACKGROUND

Product comparison can have different purposes. One

is to determine how products of the same type differ-

ent for strategic product positioning and branding rea-

sons. This might be competitors’ products or the or-

ganization’s own products. A second purpose might

be to gauge if a product line needs to be reorganised.

A third purpose might be to understand if a product

falls within the legislative and regulatory boundaries

of the countries where the product is being sold. Com-

parison and decision-making criteria vary. They will

often include product similarity but other criteria are

also used e.g. perceived customer value of specific

features, sales, costs of maintenance, prices and prof-

its.

Within product management, different ap-

proaches to product overlap have been developed.

Examples include a product similarity scale across

different product categories to aid marketing manag-

ers, consumer policymakers, and market researchers

(Walsh, 2010); a model showing how the similarity

between two products can monotonically increase,

monotonically decrease, or have a non-monotonic ef-

fect on cross-price elasticity (Kolay, 2018); and a

neural network to collate product descriptions of the

same retail product on different e-shops but in differ-

ent formats (Ristoski, 2018).

Similarity matching can be seen in the context of

search-based software engineering (Jiang, 2017,

Lopez-Herrejon, 2015). The value of similarity repre-

sentations, algorithms, and metrics was explored in

(Cesare, 2012) for cybersecurity applications, such as

malware classification, software theft detection, pla-

giarism detection and code clone detection. Product

line similarity models and metrics were proposed for

mining variability from software repositories (Kaindl,

2014, Mannion, 2015). In (Vale, 2015) metric thresh-

olds were identified to support the evaluation of soft-

ware product line component quality. A review of

metrics for analyzing software product line variability

is set out in (El-Sharkawy, 2019).

There are different product comparison strategies.

One strategy is to compare only the total number of

common features in both products, though a compli-

cating factor is whether to include or exclude negative

matches i.e. does the absence of features advance the

case for similarity or not? Another strategy is to com-

pare only the total number of features that are differ-

ent between the two products. Another variation is to

compare only selected sets of features e.g. the most

interesting or distinguishing.

The choice of feature representation mechanism is

influenced by different factors including its purpose,

the ease with which it is understood and the complex-

ity of encoding the features into that representation.

For example, if there are a large number of compari-

sons to be made, then there is often a trade-off be-

tween a clear understanding of the representation

structure and the complexity of any processing using

that structure.

After choosing a product comparison strategy, the

next step is to choose a comparison metric. Some

metrics measure similarity, others dissimilarity

(Chen, 2009). Similarity metrics often have as a nu-

merator a function of the total number of features that

are the same in each product. Dissimilarity metrics

often have as a numerator a function of the total num-

ber of features that are different in each product. The

denominator is a function of the total number of fea-

tures but varies depending upon the inclusion or ex-

clusion of features absent in both products.

Similarity metrics continue to emerge from differ-

ent fields and applications e.g. industrial product de-

sign (Shih, 2011), linguistics (Coban. 2015), ecology

(Dice. 1945, Niesterowicz. 2016), population analy-

sis (Jaro, 1989). However, the combination of the ap-

plication context, the range of information and data

types, the choice of information representation mech-

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

258

anisms, and the intended use, have influenced the de-

sign and description of many metrics making it diffi-

cult to form comparative judgements. (Choi, 2010)

compared 76 binary similarity and dissimilarity met-

rics, observing close relationships between some of

them. Of the 76, 59 were similarity metrics (20 of

these excluded negative matches i.e. B

), and 17

were dissimilarity metrics (12 excluded negative

matches).

New similarity metrics were developed for im-

proving learning algorithms in (Yazdani, 2016). An

adaptation of the Hamming distance (Hamming,

1950) was used in (Al-Hajjaji, 2019) to prioritize the

testing order of a subset of products. In (Al-Hajjaji,

2018), test reduction times are a significant, though

not the only, motivating factor, for computing the

similarity between products by adding a measure of

problem-based similarity (e.g. a feature model) to a

measure of solution-based similarity (e.g. code frag-

ments). Several approaches exist for using similarity

metrics to make testing more efficient (Henard, 2014,

Sanchez, 2014, Devroey, 2016, Sahak, 2017).

Table 1: Mobile Phone Product Line and Four Derived Products.

PLATFORM PRODUCTS

Feature Id No. Feature Variability Type Tree Level Basic Business Leisure Gold

F1 1 Mobile Phone Mandatory 1

✔ ✔ ✔ ✔

F2 2 Profile Settings Mandatory 2

✔ ✔ ✔ ✔

F2.1 3 Audio Mandatory 3

✔ ✔ ✔ ✔

F2.2 4 Display Mandatory 3

✔ ✔ ✔ ✔

F3 5 Connection Settings Mandatory 2

✔ ✔ ✔ ✔

F3.1 6 Mobile Data Mandatory 3

✔ ✔ ✔ ✔

F3.2 7 Wi-Fi Mandatory 3

✔ ✔ ✔ ✔

F3.2.1 8 802.11ac Exclusive-OR 4

✔

F3.2.2 9 802.11ax Exclusive-OR 4

✔

F3.3 10 Bluetooth Mandatory 3

✔ ✔ ✔ ✔

F3.3.1 11 5.0 Exclusive-OR 4

✔

F3.3.2 12 4.0 Exclusive-OR 4

✔

F4 13 Storage Settings Mandatory 2

✔ ✔ ✔ ✔

F4.1 14 4Gb Exclusive-OR 3

✔ ✔

F4.2 15 8Gb Exclusive-OR 3

✔ ✔

F5 16 Screen Settings Mandatory 2

✔ ✔ ✔ ✔

F5.1 17 Basic Exclusive-OR 3

✔

F5.2 18 High Definition Exclusive-OR 3

✔ ✔ ✔

F6 19 Sensors, Device Drivers Mandatory 2

✔ ✔ ✔ ✔

F6.1 20 Front Camera Mandatory 3

✔ ✔ ✔ ✔

F6.2 21 Rear Camera Optional 3

✔ ✔

F6.3 22 GPS Optional 3

✔ ✔ ✔

F6.4 23 Gyroscope Optional 3

✔

F6.5 24 Heart rate Optional 3

✔

F6.6 25 Barometer Optional 3

✔

F6.7 26 Accelerometer Optional 3

✔ ✔

F7 27 Mobile Messages Mandatory 2

✔ ✔ ✔ ✔

F7.1 28 Text Message Mandatory 3

✔ ✔ ✔ ✔

F7.2 29 Voice Message Optional 3

✔ ✔ ✔ ✔

F7.3 30 Video Message Optional 3

✔ ✔ ✔

F8 31 Mobile Calls Mandatory 2

✔ ✔ ✔ ✔

F8.1 32 Video Call Optional 3

✔ ✔ ✔

F8.2 33 Voice Call Mandatory 3

✔ ✔ ✔ ✔

F9 34 Security Mandatory 2

✔ ✔ ✔ ✔

F9.1 35 Passcode Mandatory 3

✔ ✔ ✔ ✔

F9.2 36 Voice Recognition Optional 3

✔

F9.3 37 Fingerprint Recognition Optional 3

✔ ✔ ✔

F9.4 38 Face Recognition Optional 3

✔

F10 39 Games Optional 2

✔ ✔ ✔

F10.1 40 Words For Friends Optional 3

✔ ✔ ✔

F10.2 41 Angry Birds Optional 3

✔ ✔

F10.3 42 Candy Crush Optional 3

✔ ✔

Using Binary Strings for Comparing Products from Software-intensive Systems Product Lines

259

3 PRODUCT SIMILARITY

EVALUATION PROCESS

The product similarity evaluation process we use is

(i) construct a product line feature model (ii) derive

product configurations from the model (iii) represent

each configuration as a binary string - 1s indicate a

feature’s presence, 0s its absence (iv) add a weight to

each feature (v) compare the weighted binary strings

using the JC (vii) explore the significance of specific

features on similarity by modifying the weights.

3.1 Product Line Feature Models

Product line feature models are often represented as

feature trees with additional cross-cutting constraints

(Benavides, 2010). Such models are large when prod-

uct lines have hundreds or thousands of features. De-

composition using sub-trees helps understanding.

Some product lines consist of other product lines e.g.

a camera in a mobile phone. Sometimes, abstract fea-

tures are included in the models to aid modelling and

understanding, but they are not implemented in any

product. Table 1 shows a mobile phone product line

feature model. The Basic phone enables telephone

calls or text messages. The Business phone offers

high-quality communication tools. The Leisure phone

is a communication and entertainment tool. The Gold

phone has the most features. There are several sub-

trees: Profile Settings, Connection Settings, Storage

Settings, Screen Settings, Sensors and Device Driv-

ers, Mobile Messages, Mobile Calls, Security,

Games.

3.2 Product Configuration

A product configuration is a product selected from a

product line feature model. Our concern is with fea-

tures rather than design or implementation assets. We

assume all constraints have been resolved during the

configuration process and a verifiable product selec-

tion made. Example 1 shows the product feature con-

figurations for the four mobile phone products con-

verted to binary strings.

Example 1.

Basic: 111111110101110110110000001110101110000000

Bus: 111111101110110101110100001111111111111100

Leis: 111111110101101101111100011111111110101111

Gold: 111111101110101111111111111111111111111111

Let a string S contain a set of N feature elements e

such that S = e

… e

. We assume all pos-

sible feature and feature attribute selections are repre-

sented in a single string, that N is the same for each

product, and that each feature element is in the same

position in the string regardless of the order of feature

selection during feature model construction. How-

ever, one challenge is the binary string representation

of a feature attribute value when there is a wide range

of values to select from. Consider the feature F5

Screen Settings. Suppose a new feature attribute

ScreenColor has a value selected from a palette of

100 discrete colour values each expressed as an inte-

ger. Representing each colour with a unique string el-

ement is cumbersome. If the range of values for a fea-

ture attribute was a set of real numbers, it would not

be plausible. We address this issue for pairwise prod-

uct comparison, where the first product’s attribute-

value combination is represented as a 1. If the second

product’s attribute-value is the same then it is repre-

sented as a 1, if different as a 0. Examples 2 and 3

illustrate for ScreenColor.

Example 2.

Suppose the ScreenColor attribute for the Basic

Phone and the Business Phone is Blue. This is repre-

sented initially as

Basic: 1111111101011101 (Color, Blue) 10110000001110101110000000

Bus:

1111111011101101 (Color, Blue) 01110100001111111111111100

which can be transformed into

Basic: 1111111101011101 1 10110000001110101110000000

Bus.

1111111011101101 1 01110100001111111111111100

Example 3.

Suppose the ScreenColor attribute for the Basic

Phone is Blue and for the Business Phone is Green.

This would be represented initially as

Basic: 1111111101011101 (Color, Blue) 10110000001110101110000000

Bus.

1111111011101101 (Color, Green) 01110100001111111111111100

which can be transformed into

Basic: 1111111101011101 1 10110000001110101110000000

Bus.

1111111011101101 0 01110100001111111111111100

3.3 Allocating Weights

For weighted binary strings a weight w

can be at-

tached to each element e

in the binary string. Weights

are defined for features in the product line model and

allocated to each feature in each product derived from

the product line model.

For large feature trees, the allocation of a weight

for each feature is only feasible if automated but with

manual override. One approach to automatic alloca-

tion is to recognise that the features upon which many

others depend are located in the higher levels of a fea-

ture tree. In Figure 1 the highest level is F1, at Level

1, then F2, F3, F4 are at Level 2, and so on. We can

then add weights to each of the string position varia-

bles in proportion to the Level of the match i.e.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

260

Level 1: weight 1.00

Level 2: weight 0.75

Level 3: weight 0.5

Level 4: weight 0.25

Table 2 shows the weights for each string posi-

tion. The weights are arbitrarily selected but can be

modified. Suppose we compare the Basic and Busi-

ness Phones (N= 42).

Table 2: Level Weights - Mobile Phone Product Line.

Mobile Phone String Position Level Weight

1 1 1

2,5,13,16,19,27,31,34,39 2 0.75

3,4,6,7,10,14,15,17,18,20,21,22,23,24,25,26,

28,29,30,32,33,35,36,37,38,40,41,42

3 0.5

4,5,6,8,9,11,12 4 0.25

Level: 123323344344233233233333332333233233332333

Basic:

111111110101110110110000001110101110000000

Bus:

111111101110110101110100001111111111111100

3.4 Calculating Similarity

Binary string similarity metrics can be described us-

ing a small set of string variables. Table 3 shows four

distinct string variables when comparing two binary

strings B1 and B2 each with N digits. Equations

(1)−(4) show calculations for each string variable,

where PA

is the value of the digit at the ith position

of the binary string representing Product PA, and PB

is the value of the digit at the ith position of the binary

string representing Product PB.

Table 3: String Variables.

the number of binary digits where e

in B1 is 1 and e

in B2 is 1.

the number of binary digits where e

in B1 is 0 and e

in B2 is 0.

the number of binary digits where e

in B1 is 0 and e

in B2 is 1.

the number of binary digits where e

in B1 is 1 and e

in B2 is 0.

= Σ PA

| (PA

=1, PB

=1) (1)

i=0

= Σ PA

| (PA

=0, PB

=0) (2)

i=0

= Σ PA

| (PA

=0, PB

=1) (3)

i=0

= Σ PA

| (PA

=1, PB

=0) (4)

i=0

Example 4.

Consider the Basic and Business phones

Basic: 111111110101110110110000001110101110000000

Bus: 111111101110110101110100001111111111111100

The underlined numbers (features 8, 9, 11, 12, 17,

18, 22, 25, 32, 36, 37, 38, 39, 40) show the differences

between the products. Table 4 shows the value of

each string variable (PA is the Basic phone and PB is

the Business phone).

Table 4: Comparison of Basic and Business Phones.

String Variable Basic v Business

The JC is defined as

JC= (B

) / (B

+ B

)

The JC is intuitive in that the numerator is the total

number of features in each product that do match, and

the denominator is the total number of features that

do match plus the total number of features that do not

match. It excludes negative matches.

Example 5.

JC= 20 / (20 + 11 + 3) = 0.59

Example 5 shows the JC similarity value for the Basic

and Business phones. Note that only 34 of the 42 total

product line features were included in this calculation

because 8 features are absent in both products i.e.

negative matches.

Weighted Binary String Metrics.

Using the weighted features from Table 2, Equations

(1)−(4) are adapted to become Equations (5)−(8).

= Σ w

| (PA

=1, PB

=1) (5)

i=0

= Σ w

| (PA

=0, PB

=0) (6)

i=0

= Σ w

| (PA

=0, PB

=1) (7)

i=0

= Σ w

| (PA

=1, PB

=0) (8)

i=0

Using Equations (5)−(8), B

, B

become

+0.75

+0.5

+0.75

+0.5

+0.75

+0.5

0.75

+0.75

+0.5

+0.75

+0.5

+ 0.75

+ 0.5

+ 0.75

+ 0.5

)

= 12.50

= ((0.5

+ 0.5

0.5

+ 0.5

) = 4

(0.25

+0.25

+0.5

+0.75

+0.5

) = 5.25

= (0.25

+ 0.25

+ 0.5

) = 1.0

Using Binary Strings for Comparing Products from Software-intensive Systems Product Lines

261

Hence, for the Basic and Business phones

= 11.75/(11.75+5.25+1.5)=0.67.

The increase in similarity between the two phones

from 0.59 (Example 5) to 0.67 (Example 6) reflects

the privileging for features higher up the feature tree.

3.5 Benchmarking

String similarity metrics can be used to benchmark

products in a product line and show how this compar-

ison varies over time.

Product Comparison.

Example 6.

Suppose we want to understand the degree of similar-

ity of the Basic, Business and Leisure Phones in com-

parison to the Gold phone as a benchmark. The JC

values in Table 5 reveal how the Business and Leisure

phones compare similarly to the Gold phone and are

different from the Basic phone.

Table 5: Benchmarking Product Comparison.

String Variable Basic v Gold Business v Gold Leisure v Gold

19 30 31

0 2 2

19 8 7

4 1 2

JC 0.45 0.77 0.78

Example 7.

Figure 1 is an example of how the Leisure and Gold

phones increase in similarity over time. Subsequent

analyses might show if this was planned and the im-

pact on profits.

Figure 1: Overall Product Comparison Over Time.

Feature Comparison.

Comparisons can be holistic comparisons, with all

features and partial, with feature subsets. A similarity

metric is computed using only the relevant elements

of the binary string for those features.

Example 8.

To compare the Security features F9 to F9.4 in each

phone, the similarity metric is computed using only

the relevant elements of the binary string i.e. N=5.

Basic: 11000

Business: 11111

Leisure: 11010

Gold: 11111

Table 6: Comparison of Security Features.

Basic v Gold Business v Gold Leisure v Gold

2 5 3

0 0 0

3 0 2

0 0 0

JC 0.4 1.0 0.6

The JC values in Table 6 reveal how the Business

phone is the same as the Gold phone on Security even

though the Leisure phone is slightly more similar

overall to the Gold phone (Table 5).

Product and Feature Comparisons.

Table 7 shows the JCs for weighted binary string rep-

resentations of the three mobile phones when com-

pared to the Gold phone. Whereas the Business and

Leisure phones compare similarly to the Gold phone,

they differ at F3, F4, F9, F10. The shading is illustra-

tive to show how similarity threshold values may help

to highlight these differences. We have arbitrarily se-

lected dark shading for high similarity i.e. a JC >0.75,

light shading for medium similarity i.e. a JC > 0.5 and

<0.75, and no shading for weak similarity i.e. a JC

less than 0.5.

The difference in JC values of the unweighted

overall product comparisons (Table 6) and weighted

overall product comparisons (Table 7) reflects the

privileging for similarity at Levels 1 and 2, and there

being fewer features at Level 4.

As products evolve the significance value of indi-

vidual features changes. In Table 7 the calculations of

the JC

for the Security features assume that Finger-

print Recognition and Face Recognition are set to 0.5

(see Table 1, features 37 and 38) and Table 2. If these

two features were accorded greater significance and

given weights of 1.0. the JC

for F9 would change to

0.33, 1.00. 0.6 (cf. 0.45, 1.00, 0.64) and the JC

for

the product would change to 0.51, 0.80 and 0.82.

Table 7: Comparison of Weighted Security Features.

Feature Jaccard Coefficients

Basic

& Gold

Business

& Gold

Leisure

& Gold

F1 Mobile Phone 1 1 1

F2 Profile Settings 1 1 1

F3 Connection Settings 0.69 1.00 0.69

F4 Storage Settings 0.43 0.43 1.00

F5 Screen Settings 0.43 1.00 1.00

F6 Sensors, Dev Drivers 0.29 0.41 0.65

F7 Mobile Messages 0.78 1.00 1.00

F8 Mobile Calls 0.71 1.00 1.00

F9 Security 0.45 1.00 0.64

F10 Games 0.00 0.56 1.00

0.53 0.79 0.84

0.5

Gold Leisure

2019

Leisure

2018

Leisure

2017

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

262

4 IPHONE EXAMPLE

To sense-check the value of these ideas we applied

them to a small real-world example. Apple has many

different software-intensive iPhone products. Table 8

shows 131 features in a product line of five iPhones:

iPhone 11 Pro Max, iPhone 11, iPhone XS, iPhone X,

iPhone 8, each one assumed to have 64Gb RAM (see

https://socialcompare.com/en/comparison/apple-iph-

one-product-line-comparison, accessed 14.02.21).

We reverse-engineered a product line feature

model from these feature sets. Table 9 shows part of

the iPhone product line feature model. For each of the

5 phones × 131 features i.e. 655 phone/feature com-

binations, a feature selection value (0/1) was made

and a weight allocated. We adopted the weight allo-

cation model used in the worked example.

The (B

) string variables for each pairwise com-

parison were then calculated. Table 10 shows an un-

weighted comparison of the iPhone 11 Pro Max

against the other four iPhones. Table 11 shows the

same comparison but with weights from Table 9 at-

tached to each feature.

Table 8: iPhone Features.

Feature No. of Features

iPhone 1

Dimensions 37

Storage 11

Screen 17

Camera 22

Processor 4

Connection Settings 11

Sensors 5

Security & Safety 11

Battery (Wireless Charging, Capacity) 12

Table 9: iPhone Feature tree.

Feature Feature Tree Level Weight

iPhone Level 1 1

…….

Connection Settings Level 2 0.75

…..

Bluetooth Level 3 0.5

5.0 Level 4 0.25

4.0 Level 4 0.25

Table 10: Comparison of Unweighted iPhone Features.

iP11 v

iP11 Pro Max

iPXS v

iP11 Pro Max

iPX v

iP11 Pro Max

iP8 v

iP11 Pro Max

52 52 51 48

52 51 50 47

13 14 15 18

14 14 15 18

JC 0.66 0.65 0.63 0.57

Table 11: Comparison of Weighted iPhone Features.

iP11 v

iP11 Pro Max

iPXS v

iP11 Pro Max

iPX v

iP11 Pro Max

iP8 v

iP11 Pro Max

28.5 28 28 26.75

15 13.5 13.25 12.25

3.25 4.25 4.25 5.5

3.75 4 4.25 5.25

0.8 0.78 0.78 0.72

Table 10 shows the level of the similarity to the iPh-

one11 Pro Max of all four phones is within a 10%

margin (0.57 to 0.66). Table 11 shows the same pat-

tern but the similarity to the iPhone11 Pro Max of all

four phones is higher (0.72-0.8). Tables 12 and 13

show these comparisons broken down by feature.

These kinds of quantitative results might inform

questions and answers about the product assortment

strategy such as: to what extent do levels of similarity

affect brand reputation, customer confusion, sales,

profits, product roadmaps, pricing strategies and

online vs offline channel mix? what are the similarity

thresholds beyond which these variables are nega-

tively affected? what effect will new product varia-

tions have on the company’s market share?

Table 12: iPhone Features Unweighted.

Feature Similarity to iP Pro Max

iP11 iPXS iPX iP8

iPhone Root 100 100 100 100

Dimensions 38 38 38 46

Storage 56 75 86 86

Screen 40 56 56 40

Camera 71 67 63 50

Processor 100 33 33 33

Connections 100 80 64 64

Sensors 100 100 100 100

Security 75 75 75 56

Battery 60 60 60 60

JC 0.66 0.65 0.63 0.57

Table 13: iPhone Features with Weights.

Feature Similarity to iP Pro Max

iP11 iPXS iPX iP8

iPhone Root 100 100 100 100

Dimensions 58 58 58 63

Storage 73 86 92 92

Screen 60 71 71 60

Camera 78 75 76 63

Processor 100 33 33 33

Connections 100 91 83 83

Sensors 100 100 100 100

Security 87 87 87 65

Battery 78 78 78 78

0.8 0.78 0.78 0.72

Using Binary Strings for Comparing Products from Software-intensive Systems Product Lines

263

5 DISCUSSION

Product Configuration.

Converting product configuration selections to a bi-

nary string is intuitive and simple. Binary strings can

also be helpful when product comparisons must be

made with incomplete information. For example,

when comparing two phones, the differences in the

technical specification of their cameras may be of lit-

tle interest. This can be managed by setting to 0 all

the sub-features of the camera in each phone. The im-

pact of this technique is more effective when the met-

ric excludes negative matches (B

During product configuration, the order of feature

selection will vary by engineer. Feature selection

methods may be significant-feature first, depth-first,

breadth-first, a combination of or none of these. They

may also be influenced by how a product line feature

model is presented visually e.g. tree structure, graph.

In this work, feature selection order is not important

per se provided the features in the configurations of

the products being compared are always in the same

order i.e. the position in the binary string of each fea-

ture element is fixed at the same position for each

product under comparison.

We assume that the product configuration selected

satisfies the constraints of the product line feature

model. To do this is complex, especially for large

product line feature models with cross-cutting con-

straints, but progress is being made (Yi, 2018).

When a new feature is to be added to a product,

the data structure choices are (i) change the product

line feature model and the feature configuration (ii)

change only the product feature configuration. If (i) is

chosen, the constraint that all products will have an

equal number of features will hold. If (ii) is chosen,

the lengths of the binary strings for each phone will

be different. For comparing, the feature must be

added to all phones but given a 0 value.

Example 9.

Suppose we add a new security feature F9.5 IrisRec-

ognition only to the product configuration of the Gold

phone, and add this to the tail of the binary string. The

binary string for Gold will have 6 elements whereas

the other phones will have 5.

Basic: 11000

Business: 11111

Leisure: 11010

Gold: 111111

To simplify the similarity computation, we can add

this element to the other phones but with the value 0.

Basic: 110000

Business: 111110

Leisure: 110100

Gold: 111111

Similarly, when a feature is deleted from some prod-

ucts but is left in others, then for comparison one so-

lution is to leave the feature element in the binary

string but with a value of 0.

In principle, a binary string representation can be

used to benchmark against a competitor’s products.

We recognise there would be a cost to understanding

the competitor’s products, to transcribe them into bi-

nary string representations such that each feature was

mapped to the appropriate string element positions to

enable comparisons, and that the comparisons will

only be as good as the publicly available information

about competitor’s products.

Allocating Weights.

The impact of changing the weight of a single feature

on an overall product JC value will vary with the

number of features in the tree. However, in principle,

a product manager can explore the significance of in-

dividual features and feature combinations on overall

product similarity.

In both the worked and iPhone examples we se-

lected an allocation of weights in which features close

to the root carry more significance. We do not claim

this is optimal. For example, from the perspective of

implementation, one may argue that those closer to

the leaves carry more significance. What is important

is to choose a weights allocation method that is easy

to understand and adjustable.

In the iPhone example, each feature was allocated

a Level and each Level allocated a weight. For a few

hundred features, manual allocation is as efficient as

designing and implementing an automated algorithm.

However, it is untenable for much larger feature sets

and plays to the need for a weights allocation method

that is easy to automate, like the one we proposed.

Calculating Similarity.

The value of a similarity matching algorithm is pro-

portionate to the effort required to set up the data it

relies upon. The calculations of the binary string var-

iables in the similarity metrics in Table 3 are compu-

tationally light.

We argued for metrics that exclude negative

matches and chose the JC as an example. There are

benefits and limitations of including or excluding

negative matches (see Choi, 2010). Resolving opti-

mal solutions for this application context is a chal-

lenge. However, one criterion will be the degree of

similarity granularity sufficient for the comparison

e.g. if two metrics generate values within 5% of each

other and a 10% margin is sufficient for decision-

making then it may not matter which metric is used.

Benchmarking.

A benefit of product descriptions being represented

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

264

by binary strings is that benchmarking using pairwise

comparisons is straightforward. Another benefit is

that binary string matrices can be formed to enable

multi-comparisons using clustering algorithms that

can help assess the effectiveness of a product line.

One expects a degree of clustering because the pur-

pose of a product line is to leverage development ef-

ficiency gains from commonalties. However, as prod-

uct lines evolve, feature significance values alter. By

modifying feature weights new clusters may emerge

that inform strategic discussions about single or mul-

tiple product lines (Savolainen, 2012).

Benchmarking can also be used as an information

source when evaluating product manager perfor-

mance e.g. when product managers add new features

to increase short-term sales but neglect product dis-

tinctiveness causing customer confusion reducing

long-term sales.

When comparing against regulatory compliance,

a similarity measure is of less value than testing for

the presence of a feature or not, unless a business de-

cision has been taken to exceed minimum compliance

when a dissimilarity metric may be useful. Similarity

assessment may also help during development to

evaluate a candidate configuration from which to cre-

ate a compliant product.

6 CONCLUSION

Product buyers and sellers often make product com-

parisons and decisions. As product lines grow in

scale, scope and complexity, it is difficult to carry out

these comparisons. For an inexperienced product

manager, product comparison tools can help quickly

gain oversight of a product line. Even for experienced

product managers who have a deep understanding of

their product lines, product comparison tools can aid

with scale and scope management.

We described a product similarity evaluation pro-

cess that is based on configuring new products from

a product line feature model. We discussed different

issues for each of the process steps. We represented a

product configuration as a binary string and used a

binary string similarity metric to compare products.

We allocated weights to each feature and recom-

mended that the weights allocation method was easy

to understand and automate. However, changing indi-

vidual weights can reflect the changing significance

of individual features over time. We showed the fea-

sibility of our ideas with a small iPhone example. The

next step is to apply them to a larger more complex

product line. Our application focus was a comparison

of products from the same product line. However, the

technique can be used to compare products from dif-

ferent product lines e.g. competitor products.

REFERENCES

Al-Hajjaji, M., Schulze, M., Ryssel, U., 2018. Similarity of

Product Line Variants. In 22nd Int’l Systems & Soft-

ware Product Line Conf, 226-235.

Al-Hajjaji, M., Thüm, T., Lochau, M., Meinicke, J., Saake,

G., 2019. Effective product-line testing using similar-

ity-based product prioritization, In Softw. & Systems

Modeling, 18, 1, 499-521.

Benavides, D., Segura, S., Ruiz-Cortes, A., 2010. Auto-

mated Analysis of Feature Models 20 years Later: A

Literature Review. In Information Systems, 35, 615-

636.

Cesare, S., Xiang, Y., (Ed.), 2012. In Software. Similarity

and Classification, Springer.

Chen, S., Ma, B., Zhang, K., 2009. On the Similarity Metric

and the Distance Metric. In Theoretical Comp Sci,4,

2365-2376.

Choi, S., Cha, S., Tappert, C., 2010. A Survey of Binary

Similarity and Distance Measures. In Systemics, Cyber-

netics and Informatics, 8, 1, 43-48.

Coban, O., Ozyer, B., Guisah, T., 2015. A Comparison of

Similarity Metrics for Sentiment Analysis on Turkish

Twitter Feeds, Sentiment Analysis. In IEEE Int’l Conf,

333-338.

Deloitte Consumer Review Made-to-order: The rise of

mass personalisation, 2015.

Devroey, X., Perrouin, G., Legay, A., Schobbens, P-Y.,

Heymans, P., 2016. Search-based Similarity-driven Be-

havioural SPL Testing. In 10

Int’l Workshop on Vari-

ability Modelling of Software-intensive Systems

(VaMoS’16), 89-96.

Dice, L., 1945. Measures of the Amount of Ecologic Asso-

ciation Between Species. In Ecology, 26, 3, 297–302.

El-Sharkawy, S., Yamagishi-Eichler, S., Schmid, K., 2019.

Metrics for analyzing variability and its implementation

in software product lines: A systematic literature re-

view, In Info & Softw. Technology,106,1-30.

Hamming, R., 1950. Error Detecting and Error-Correcting

Codes, In Bell Syst. Tech. J., 29, 2, 47–160.

Henard, C., Papadakis, M., Perrouin, G., Klein, J., Hey-

mans, P., Le Traon, Y.L (2014). By Passing the Com-

binatorial Explosion: Using Similarity to Generate and

Prioritize T-Wise Test Conﬁgurations for Software

Product Lines, In IEEE Trans. Softw. Eng., 40, 7, 650–

670.

Jaccard, P., 1901. Distribution de La Flore Alpine dans Le

Bassin Des Dranses et Dans Quelques Régions

Voisines. In Bulletin de la Société Vaudoise des Sci Na-

turelles, 37, 241-272.

Jaro, M., 1989. Advances in Record-Linkage Methodology

as Applied to Matching the 1985 Census of Tampa,

Florida. In J. of the American Statistical Association,

84, 414–420.

Using Binary Strings for Comparing Products from Software-intensive Systems Product Lines

265

Jiang, H., Tang, K., Petke, J., Harman, M., 2017. Search-

Based Software Engineering (Guest Editorial). In IEEE

Computational Intelligence Magazine, 12, 2, 23-71.

Kashkoush, M., Elmaraghy, H., 2014. Product Family For-

mation for Reconfigurable Assembly Systems. In Pro-

cedia CIRP 17, 302–307.

Kaindl, H., Mannion, M., 2014. A Feature- Similarity

Model for Product Line Eng, In 14th Int’l Conf on Soft-

ware Reuse, 35-41.

Li, Y., Yue, T., Ali, S., Zhang, L., 2019. Enabling auto-

mated requirements reuse and configuration. In Softw.

& Systems Modelling, 18, 2177–2211.

Lopez-Herrejon, R., Linsbauer, L., Egyeds, A., 2015. A

systematic mapping study of search-based software en-

gineering for software product lines. In Info & Softw.

Tech, 61,33–51.

Mannion, M., Kaindl, H., 2015. Using Similarity Metrics

for Mining Variability from Software Repositories. In

18th ACM Int’l Softw. Product Line Conf, 2, 32-35.

Mitchell, V., Papavassiliou, V., 1999. Marketing causes and

implications of consumer confusion. In J of Product

and Brand Management, 8, 319–339.

Niesterowicz, J., Stepinski, T., 2016. On using Landscape

Metrics for Landscape Similarity Search. In Ecol Indi-

cators, 64,5,20-30.

Punyatoya, P., 2013. Consumer Evaluation of Brand Exten-

sion for Global and Local Brands: The Moderating Role

of Product Similarity. In J. of Int’l Consumer Market-

ing, 25:3,198-215.

Naseem, R., Deris, M., Maqbool, O., Li, J., Shahzad, S.,

Shah, H., 2017. Improved Binary Similarity Measures

for Software Modularization. In Frontiers of Infor-

mation Technology and Engineering, 18, 8, 1082-1107.

Khoshmanesh, A., Lutz, S., 2018. The Role of Similarity in

Detecting Feature Interaction in Software Product

Lines. In Int’l Symposium on Softw. Reliability Eng

Workshops,286-292.

Kolay, S., Tyagi, R., 2018. Product Similarity and Cross-

Price Elasticity, In Review of Industrial Organization,

52,1,85-100.

Ristoski, P., Petrovski, P., Mika, P., Paulheim, H., 2018. A

Machine Learning Approach for Product, Matching and

Categorization. In Semantic Web, 9, 5, 707-728.

Sahak, M., Jawai, D., Halim, S., 2017. An Experiment of

Different Similarity Measures on Test Case Prioritiza-

tion for Software Product Lines. In J. of Telecommuni-

cations, Electronics & Computer Engineering, 9, 3-4,

177-185.

Sanchez, A., Segura, S., Ruiz-Cortes, A., 2014. A Compar-

ison of Test Case Prioritization Criteria for Software

Product Lines. In Int. Conf. on Softw. Testing, Verifica-

tion and Validation,41-50.

Savolainen, J., Mannion, M., Kuusela, J., 2012. In Devel-

oping Platforms for Multiple Software Product Lines,

16th Int’l Software Product Line Conference, 220-228.

Shih, H., 2011. Product Structure (BOM)-based Product

Similarity Measures using Orthogonal Procrustes Ap-

proach. In Computers & Industrial Engineering, 61, 3,

608-628.

Rieck, K., Wressnegger, C., 2016. Harry: A Tool for Meas-

uring String Similarity. In J. of Mach. Learning Re-

search, 17,9,1-5.

Vale, G., Figueiredo, E., 2015. A Method to Derive Metric

Thresholds for Software Product Lines, In 29th Brazil-

ian Symposium on Softw. Engineering, 110-119.

Walsh, G., Mitchell, V-M., Kilian, T., Miller, L., 2010.

Measuring Consumer Vulnerability to Perceived Prod-

uct-Similarity Problems and its Consequences. In J. of

Marketing Management, 26, 1-2, 146-162.

Yazdani, H., Ortiz-Arroyo, D., Kwasnicka, H., 2016. New

Similarity Functions, In 3rd Int’l Conf on Artificial In-

telligence and Pattern Recognition (AIPR), 1-6.

Yuzgec, E., Alazzam, A., Nagarur, N., 2012. A Two-Stage

Algorithm to Design and Assess Product Family. In In-

dustrial and Systems Engineering Research Confer-

ence, 1-9.

Yi, X., Zhou, Y., Zheng, Z., Li, M., 2018. Configuring Soft-

ware Product Lines by Combining Many-Objective Op-

timization and SAT Solvers. In ACM Transactions on

Softw. Eng & Methodology, 26, 4, 1-4.

Zaggi, M., Hagenmaier, M., Raasch, C., 2019. The choice

between uniqueness and conformity in mass customiza-

tion. In R & D Management, 49, 2, 204-221.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

266
