Evaluating Random Input Generation Strategies for Accessibility Testing

Diogo Oliveira Santos

, Vinicius H. S. Durelli

, Andre Takeshi Endo

and Marcelo Medeiros Eler

University of S

ao Paulo (EACH-USP), S

ao Paulo, SP, Brazil

Federal University of S

ao Jo

ao Del Rei, Minas Gerais, MG, Brazil

Federal University of Technology - Paran

a, Paran

a, PR, Brazil

Keywords:

Accessibility, Automated, Testing, Tool, Evaluation, Random, Mobile.

Abstract:

Mobile accessibility testing is the process of checking whether a mobile app can be perceived, understood,

and operated by a wide range of users. Accessibility testing tools can support this activity by automatically

generating user inputs to navigate through the app under evaluation and run accessibility checks in each new

discovered screen. The algorithm that determines which user input will be generated to simulate the user

interaction plays a pivotal role in such an approach. In the state of the art approaches, a Uniform Random

algorithm is usually employed. In this paper, we compared the results of the default algorithm implemented by

a state of the art tool with four different biased random strategies taking into account the number of activities

executed, screen states traversed, and accessibility violations revealed. Our results show that the default

algorithm had the worst performance while the algorithm biased towards different weights assigned to speciﬁc

actions and widgets had the best performance.

1 INTRODUCTION

Accessibility evaluation aims at checking whether an

information system can be perceived, understood, or

operated by users with different characteristics, spe-

cially those with any disability (ISO, 2018). This is not

a trivial task since the speciﬁc requirements for a wide

range of users may be vast and diverse. Therefore,

organizations have developed standards like the Web

Content Accessibility Guidelines (WCAG), which de-

ﬁnes guidelines and success criteria written as testable

statements to guide the development of accessible dig-

ital products. Such standards can be used during both

the development and evaluation phases.

Although organizations can rely on well-known

standards, proper accessibility evaluations are costly

and time consuming because ideally it should be con-

ducted by end users and specialists. This poses the

following challenges: (i) the number and diversity of

users required to conduct a proper evaluation may be

prohibitive for many organizations, and (ii) while spe-

cialists can emulate the behavior of many end users,

they usually carry out this activity manually (Paz

and Pow-Sang, 2016), which largely involves inter-

acting with the system under evaluation to inspect

each screen, component, or interaction, often relying

on assistive features such as screen readers.

Recently, in hopes of mitigating costs associated

with accessibility evaluations, researchers have come

up with automated approaches (Siebra et al., 2018;

Silva et al., 2018a; Ag

uero-Flores et al., 2019; Abas-

cal et al., 2019; Fraz

ao and Duarte, 2020). However,

organizations should not solely rely on automated tests

because there are many accessibility violations whose

identiﬁcation entails subjective judgment (Vigo et al.,

2013). For example, it is easy for an automated tool to

check whether the contrast ratio between a text element

and its background color complies with agreed upon

standards (i.e. 4.5/1), but it cannot decide whether

the focus sequence of the elements in a screen is se-

mantically correct for the user. Despite the limitations

inherent to automated approaches, studies suggest that

they can contribute with the evaluation process (Souza

et al., 2019; Antonelli et al., 2019; Mateus et al., 2020).

Several tools tailored to mobile accessibility evalu-

ation have been proposed (Eler et al., 2018; Park et al.,

2019; Alshayban et al., 2020; Siebra et al., 2018; Silva

et al., 2018a; Hao et al., 2014). Particularly, fully auto-

mated approaches generate test inputs to simulate user

interaction and automatically explore the application

under test while accessibility tests are run for each

visited screen. Such approaches are based on uniform

random input generation strategies with the goal of

simulating user interaction (Alshayban et al., 2020;

Santos, D., Durelli, V., Endo, A. and Eler, M.

Evaluating Random Input Generation Strategies for Accessibility Testing.

DOI: 10.5220/0010456100660075

In Proceedings of the 23rd International Conference on Enterprise Information Systems (ICEIS 2021) - Volume 2, pages 66-75

ISBN: 978-989-758-509-8

Eler et al., 2018). In this strategy, a speciﬁc action

is randomly selected from a list of on-screen actions

(i.e., actions that the user can see and interact with on

a given screen). While such an approach lends itself

well to accessibility testing and thus has the potential

to reveal lots of accessibility violations, it does not gen-

erate complex interactions or sensitive data to further

explore the app under evaluation, which may let many

parts of the evaluated applications uncovered (Eler

et al., 2018; Alshayban et al., 2020).

Hence, an interesting question in this matter is

to evaluate whether other random testing strategies

would fare better in the detection of accessibility viola-

tions. Even though different strategies can be applied

to guide test generation for mobile apps so the app

under test can be further explored (e.g. search-based

testing), Random Testing is cheaper and it does not

require instrumentation (modiﬁcation in the app); this

makes it a robust effective strategy to explore a soft-

ware under test (Choudhary et al., 2015; Tramontana

et al., 2019; Pacheco and Ernst, 2007).

Therefore, this paper compares the effectiveness

of ﬁve ﬂavours of random approaches to generate ac-

cessibility tests for mobile applications. More specif-

ically, we implemented four new random algorithms

on top of an open source tool called MATE (Mobile

Accessibility Testing) (Eler et al., 2018). The default

strategy adopted by MATE is a uniform random al-

gorithm in which each event of the mobile app under

test has the same probability of being selected. The

new algorithms are based on biased approaches that

use frequency and weights to assign different proba-

bilities for each event. Results show that the default

strategy adopted by MATE had the worst performance

and an algorithm that selects user input biased towards

speciﬁc actions executed over speciﬁc widgets had the

best performance.

This paper is organized as follows. Section 2

presents basic concepts regarding accessibility and ac-

cessibility testing approaches. Section 3 describes the

tool in which we implemented the ﬁve evaluated strate-

gies to generate test inputs for accessibility evaluation.

Section 4 shows the setup and Section 5 presents the

results and the discussion of our experiment. Finally,

Section 6 brings some concluding remarks.

2 BACKGROUND

Android apps are composed by Activities, components

that offer user interfaces and can be invoked individ-

ually. As such, they work as a container of compo-

nents called widgets, e.g., buttons, text ﬁelds, toggle

switches, etc., which allow the user to interact with the

app and navigate through other activities. An activity

is usually presented to the user as a full-screen window,

but they can also be used as ﬂoating or embedded win-

dows. One single activity may present different widget

conﬁgurations (i.e., different arrangement, states and

colors) as the user interacts with the app.

From a software testing perspective, it is important

to identify the different screen conﬁgurations (screen

states) reached during a test session because it might

represent that different functionalities of the app under

test have been covered (Baek and Bae, 2016). From the

accessibility testing standpoint, different screen states

may present different properties and user interaction

options that might be of interest.

Figure 1 shows four examples of screen states of

the activity New List of an app that provides users with

shopping lists facilities. Screen state A is the entry

point of this activity and presents the user with input

ﬁelds, radio buttons, check boxes and buttons. Screen

state B is different from screen state A because the

input ﬁeld for the shopping list name is not empty any-

more. Screen state C is different from screen state B

because the radio button on the top right corner is acti-

vated. Finally, screen state D is different from screen

state C because the checkbox deadline is checked and

it has additional components (widgets).

Several tools have been proposed to support the

automated testing for mobile accessibility (Silva et al.,

2018a; Siebra et al., 2018). Even though many acces-

sibility barriers can only be detected based on human

judgement (Vigo et al., 2013; Mateus et al., 2020),

supporting tools can increase the productivity of the

evaluation task. Automated tools for accessibility test-

ing can perform static or dynamic analysis. Static

analysis tools can only detect violations on the source

code, but the lion’s share of accessibility violations are

caused by dynamic changes that might happen during

execution.

Dynamic analysis tools can be partially or fully

automated. Partially automated tools rely on man-

ual interaction or test scripts created by developers

or testers to ﬁnd accessibility violations. The limi-

tation of such strategy is that manual interaction is

error prone and labor intensive, because it requires

to navigate through the application while the underly-

ing tool performs accessibility checks. Additionally,

tests cannot be re-executed when the interface changes.

With respect to script-based approaches, their effec-

tiveness is determined by the thoroughness of the test

set. Fully automated approaches generate user inputs

to simulate user interaction while accessibility checks

are executed in each new screen explored.

As far as we know, there are only three fully au-

tomated tools that support accessibility testing and

Evaluating Random Input Generation Strategies for Accessibility Testing

A B

C D

Figure 1: Examples of different screen states of a single

activity.

automatically generate test inputs to navigate through

the application. PUMA is a generic framework that

can be customized for various types of dynamic analy-

ses, such as checks for button sizes (Hao et al., 2014).

Alshayban et. al (2020) developed a tool to assess the

accessibility features of Android applications, which

takes advantage of the accessibility checks provided by

Google’s Accessibility Testing Framework. The acces-

sibility assessment tool has two main parts. One part

simulates user interactions and the other part monitors

the device for accessibility events.

MATE (Eler et al., 2018) is a tool designed with

the goal of automatically exploring applications while

applying different checks for accessibility violations

according to the WCAG 2.1 (Web Content Accessibil-

ity Guidelines). MATE is compatible with the Android

environment (emulators or physical devices) and uses

the UIAutomator structure to interact with the applica-

tion without requiring access to the source code of the

application under test. One of the limitation of this ap-

proach is that the algorithm that generates user inputs

may not generate complex interactions or sensitive

data to further explore the app under evaluation.

3 APPROACH DESCRIPTION

The results of comparing different algorithms that gen-

erates test inputs using different tools may be inﬂu-

enced by the underlying implementation and the en-

gineering choices of the testing tool. Therefore, we

decided to implement the new ﬂavours of random test

generation algorithms we devised for this study on top

of the open source tool called MATE (Eler et al., 2018).

In this section, we provide an overview of how this

tool operates, the types of accessibility violations the

tool can ﬁnd, and the new algorithms we implemented.

3.1 MATE: Mobile Accessibility Testing

MATE automatically generates inputs (e.g. tap, swipe)

to simulate user interaction and run accessibility tests

in each visited screen. The tool runs as a mobile app

in the Android environment and execute the following

steps repeatedly until a time budget is met.

Step 1:

the tool extracts detailed information from the

visual components presented on the device or emulator

screen using the Accessibility Service

API. The infor-

mation available for each visual component can vary,

but they usually include: coordinates in the screen,

component type, content description, label, hint, text,

drawing order, and so forth. This API also allows to

retrieve the events each component or the screen itself

can handle, such as if the component can be taped, or

checked, or scrolled.

Step 2:

the tool uses the information retrieved in Step

1 to check whether that screen follows speciﬁc accessi-

bility criteria aiming at ﬁnding accessibility violations.

MATE checks for more than accessibility criteria de-

ﬁned by the WCAG 2.1, such as for Non-text Con-

tent (guideline 1.1.1), which checks whether non-text

components (e.g. images) have a text alternative to

describe their purpose, of for Target Size (guideline

2.5.5), which checks whether actionable components

have at least a size of 44 by 44 pixels.

Step 3:

the tool uses the information on the possi-

ble events the components or the screen can handle

(collected at Step 1) to create a list of actions that

will simulate user interaction, such as “tap on button

add product” or “insert text in the input ﬁeld product

name”. MATE selects an action to be executed using

an algorithm called Uniform Random (UR), that se-

lects a possible action from a list in which each action

has the same probability to be chosen.

The selected action is executed by means of the

UiAutomator

API. The action selected to simulate

user interaction is important because it is used to navi-

gate through the app while accessibility checks are run.

Depending on the actions executed, the tool can ex-

plore more or less functionalities and different screens;

this impacts on the application coverage and the num-

ber of accessibility violations revealed.

https://developer.android.com/reference/android/

accessibilityservice/AccessibilityService

https://developer.android.com/training/testing/ui-

automator

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

Step 4: the tool registers whether the executed action

(in Step 3) moved the app to a screen that had not been

visited before.

3.2 New Algorithms

In this work, we implemented four different ﬂavours

of random algorithms that receive a list of possible

actions that a screen can handle and select one action

based on different strategies. Following we present

the different random approaches each algorithm use,

which were largely inspired in testing tools of general

purposes (Machiry et al., 2013; Su et al., 2017).

Biased Random - New Action (BRNA): all actions

of the list have the same probability of being selected,

as the default algorithm implemented by MATE, but

once an action is selected for a given screen, it is

removed from the list. When the list of actions of a

given screen is empty, the original list is restored.

Biased Random - Fixed Weight (BRFW): some type

of actions have more probability of being selected than

others by assigning different weights to different types

of actions (e.g. tap, type, back). Such weights were

deﬁned based on an investigation in which we tested

30 mobile applications during 30 minutes each using

the Uniform Random algorithm to collect information

of which type of action lead to the exploration of new

screens. Our results are presented in Table 1.

Table 1: Percentage of new states and weights assigned to

each type of event.

Action type New Screen exp. Weight

TAP 65.20% 8

TYPE-TEXT 10.80% 5

SWIPE-DOWN 9.80% 5

MENU 3.1% 3

BACK 3.0% 3

SWIPE-UP 3.0% 3

ENTER 1.7% 2

LONG-PRESS 1.2% 2

SWIPE-RIGHT 1.2% 2

SWIPE-LEFT 1.1% 2

OTHER-TYPES <1% 1

Instead of using the absolute values presented at the

column New screen exploration, we decided to use

the Fibonacci scale to reduce the gap between the

weights assigned to each type of action, similarly to

what is generally done in the software estimation in

agile projects (Dyb

a et al., 2014). In this case, we

decided that the weights would be assigned based on

the percentagem of new screens explored by that action

as follows: 1 (below 1%), 2 (1% to 2%), 3 (3% to 5%),

5 (6% to 10%), 8 (above 11%).

Biased Random - Fixed Weighted Widget-Action

(BRFWWA): some types of actions combined with

some types of components (e.g. tap on a button, tap

on a spinner, or type text in an input box) have more

probability of being selected than others. Some actions

are associated with the screen itself, such as BACK or

even SWIPE actions. Weights were assigned based

on the same investigation mentioned in the descrip-

tion of the Fixed Weighted Action Random algorithm.

Here are the list of assigned weights: TAP on Linear-

Layout(8), ImageButton (8), Button” (8), CheckBox

(8), TextView (5), RadioButton (3), ImageView (3),

FrameLayout (2), RelativeLayout (2), LinearLayout-

Compat (2); TYPE-TEXT in any type of input box (8);

SWIPE-DOWN (8), SWIPE-UP (2), MENU (3), BACK

(3), ENTER (2), all other actions and components (1).

Biased Random - Uniform Variable Weight

(BRUVW): all actions have the same probability of

being selected at ﬁrst because they are all assigned

the same weight: 5. However, the weight assigned for

each type of action (e.g. tap, type, back) is variable

during the execution. Each time an action is selected,

that type of action has its weight reduced in one point.

When the weight reaches 0, it is restored to 5.

4 EXPERIMENTAL DESIGN

Considering that different approaches to generating

inputs for uncovering accessibility violations are

likely to perform differently across various apps, we

set out to examine how ﬁve algorithms perform when

compared with each other. We believe that the results

of our experiment can shed some light into the merits

and limitations of each algorithm. Speciﬁcally, our

analysis is centered on the following research question:

How do the algorithms compare to each other

with respect to their effectiveness?

4.1 Scope of the Experiment

We deﬁned the scope of our experiment by setting

its goals, which were summarized according to the

Goal/Question/Metric (GQM) (Wohlin et al., 2012)

template as follows:

Analyze:

a uniform random algorithm and four adap-

tive random input generation algorithms

for the purpose of: evaluation

with respect to their: effectiveness

from the point of view of: the researcher

in the context of: mobile apps.

Evaluating Random Input Generation Strategies for Accessibility Testing

4.2 Variables Selection

Given that it is challenging to compare algorithms in

terms of their effectiveness, prior to carrying out the

experiment, we needed to come up with an opera-

tionalization of effectiveness. We decided to evaluate

the effectiveness of the algorithms in terms of three de-

pendent variables: (i) activity coverage, (ii) traversed

state coverage, and (iii) the amount of uncovered ac-

cessibility violations.

The independent variables are the algorithms we

set out to examine, Uniform Random (UR), No Repeti-

tion Random, Fixed Weight Random, Variable Weight

Random, and Widget-Action Random. An in-depth de-

scription of these algorithms is presented in Section 3.

The control variables are the (i) time budget allo-

cated for each algorithm to generate user inputs au-

tomatically, (ii) the number of times each algorithm

is executed, and (iii) the execution environment. The

time budget we chose for all algorithms is exactly 30

minutes, which has been used in several studies regard-

ing test generation (Eler et al., 2018; Choudhary et al.,

2015). Due to the inherently random behavior of the

algorithms, they were executed three times and the out-

come used with respect to the independent variables is

the average between the three executions.

The execution environment for each app and each

input generation algorithm was the same: an Intel Core

i7 processor, 16GB RAM. Prior to each execution, the

emulator running the application had all its data erased

and it was rebooted.

In the next subsection we describe the criteria we

adopted to select our study sample.

4.3 Sample Selection

As described in Section 3, the accessibility testing tool

we chose can test applications that run on Android

emulators or actual devices. Although the testing tool

does not require the source code of the application,

having access to deployable ﬁles of the applications

under evaluation makes running experiments that de-

mand several executions more feasible. Therefore, in

the context of our experiment, we selected applications

from a F-Droid,

which is a well-known repository that

indexes more than 3000 Android apps of different cat-

egories, sizes and complexities. This repository has

been used in several studies on testing mobile appli-

cations (Samir et al., 2019; Li et al., 2019; Jha et al.,

2019; Mao et al., 2016; Li et al., 2014; Lamothe and

Shang, 2018; Eler et al., 2018; Silva et al., 2018b).

We applied the following criteria during sample

construction: (i) the application must also be available

https://f-droid.org/

in the ofﬁcial app store of the Android platform, the

Google Play Store, to make sure it is not a toy project;

(ii) the target version of the Android API must be the

28th or a newer version since the testing tool was built

based on the API 28. Only 323 out of 3,168 met the

two selection criteria we set

. Next, we randomly

selected 63 out of these 323 apps to create the sample

for our study. Table 2 shows the apps that comprise our

sample; it includes apps with one to up 90 activities.

5 RESULTS AND DISCUSSION

Activity Coverage.

To measure activity coverage, we

collected how many different activities were explored

for each algorithm. Figure 2 shows that, when we

evaluate activity coverage across all apps of our sam-

ple, the Uniform Random (UR) performed slightly

worse than the other algorithms. However, there are

no signiﬁcant differences between all algorithms.

UR BRUVW BRFWWA BRFW BRNA

Number of Executed Activities

Figure 2: Number of executed activities for each algorithm

across all apps in our sample.

Results seem to be different when we compare the

performance of each algorithm on an app-by-app basis.

Figure 3 shows for how many apps each algorithm

performed best in terms of activity coverage. Since the

number of activities in the apps is low, most algorithms

covered about the same number of activities; hence,

many algorithms were the best with respect to activity

coverage for each app. Notice that the BiasedRandom-

NewAction performed best for 45 apps, followed by

BiasedRandomFixedWeight and BiasedRandomFixed-

WeightWA which yield the best results (i.e., covered

more activities) for 42 apps; and then the Uniform-

Random and BiasedRandomUniformVariableWeight

performed best for 38 apps.

Traversed States.

By looking at the current activity,

the UI elements displayed, and their contents, we can

Data extracted from FDroid on August 27th of 2020.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

Table 2: Mobile apps of our sample.

app #act.s app #act.s

cityfreqs.com.pilfershushjammer 1 net.tjado.passwdsafe 7

com.dosse.speedtest 1 com.adguard.android.contentblocker 8

de.tutao.tutanota 1 com.james.status 8

fr.jnda.android.ipcalc 1 com.menny.android.anysoftkeyboard 8

net.guildem.publicip 1 com.orpheusdroid.screenrecorder 8

net.mullvad.mullvadvpn 1 nitezh.ministock 8

se.tube42.drum.android 1 net.eneiluj.moneybuster 9

androdns.android.leetdreams.ch.androdns 2 net.gsantner.markor 9

btools.routingapp 2 ai.susi 10

cf.fridays.fff info 2 org.secuso.privacyfriendlytodolist 10

com.github.axet.hourlyreminder 2 de.rampro.activitydiary 11

io.github.easyintent.quickref 2 org.connectbot 11

me.tsukanov.counter 2 org.nutritionfacts.dailydozen 11

net.asceai.meritous 2 org.zephyrsoft.trackworktime 11

com.aa.mynotes 3 com.eventyay.organizer 12

com.atelieryl.wonderdroid 3 org.secuso.privacyfriendlyweather 12

com.github.axet.ﬁlemanager 3 com.yacgroup.yacguide.dev 13

com.physphil.android.unitconverterultimate 3 org.kiwix.kiwixmobile 13

eu.roggstar.luigithehunter.batterycalibrate 3 de.tadris.ﬁtness 15

mn.tck.semitone 3 org.openintents.shopping 15

org.billthefarmer.diary 3 org.xbmc.kore 15

org.billthefarmer.notes 3 com.gpl.rpg.AndorsTrail 17

org.billthefarmer.tuner 3 de.danoeh.antennapod 17

org.jitsi.meet 3 au.com.wallaceit.reddinator 18

ru.meeﬁk.busybox 3 de.syss.MifareClassicTool 19

com.darshancomputing.BatteryIndicator 4 org.quantumbadger.redreader 19

info.papdt.blackblub 4 io.github.hidroh.materialistic 23

it.rignanese.leo.slimfacebook 5 com.fsck.k9 29

org.billthefarmer.currency 5 io.pslab 32

uk.co.busydoingnothing.prevo 5 org.epstudios.epmobile 81

com.google.android.stardroid 7 me.ccrama.redditslide 90

name.boyle.chris.sgtpuzzles 7

UniformRandom BiasedRandomFixedWeight BiasedRandomFixedWeightWA BiasedRandomUniformVariableWeight BiasedRandomNewAction

Algorithms

Number of apps in which was the best (activities executed)

Figure 3: Number of apps for which an algorithm is the best

w.r.t. activity coverage.

deﬁne a state of the app. In this part, we counted

the number of unique app states traversed by each

algorithm. Figure 4 shows that the number of different

states reached by the Biased Random - Fixed Weight

Widget-Action algorithm slightly covers more states,

followed by Biased Random - Fixed Weight and Biased

Random - New Action. Algorithms Uniform Random

and Biased Random - Uniform Variable Weight are the

least effective ones in terms of covering screen states.

However, the differences between algorithms are not

signiﬁcant when we consider all apps in our sample.

UR BRUVW BRFWWA BRFW BRNA

100

150

200

250

300

Number of Traversed States

Figure 4: Number of traversed states for each algorithm

across all apps in our sample.

When it comes to each app individually, however, the

Evaluating Random Input Generation Strategies for Accessibility Testing

number of apps for which each algorithm performed

best with respect to screen state coverage is signiﬁ-

cantly different. Figure 5 shows that the algorithm Bi-

ased Random - Fixed Weight Widget-Action is clearly

the one that traverses more states for 31 apps, fol-

lowed by Biased Random - Fixed Weight with 19 apps,

Biased Random - Uniform Variable Weight with 15

apps, Biased Random - New Action with 14 apps, and

ﬁnally Uniform Random with 9 apps. Such results

would seem to indicate that, all random algorithms we

employed managed to traverse more states than the

default implementation of MATE: the Uniform Ran-

dom algorithm. In addition, algorithms that resort to

weights to decide which user input should be gener-

ated next tend to traverse more states. It is noticeable

that more than two algorithms were the best for the

same app when it comes to the screen state coverage;

in that case, all algorithms are counted as the best for

that app.

UniformRandom BiasedRandomFixedWeight BiasedRandomFixedWeightWA BiasedRandomUniformVariableWeight BiasedRandomNewAction

Algorithms

Number of apps in which was the best (visited states)

Figure 5: Number of apps for which an algorithm is the best

w.r.t. screen state coverage.

The ﬁve algorithms were not able to explore many

screen states for many apps due to two reasons mainly:

many apps have only one activity and possibly few

states to be explored; and for many apps the algorithms

could not go through the ﬁrst screen because they were

not able to generate more complex user inputs or pro-

duce sensitive data (e.g. login and password). In such

cases, the results achieved by the algorithms are not

much different. Therefore, we analyzed the results

of two subsets of the whole sample to check whether

results would be different. First, we created a subset

of our sample containing only apps for which the tra-

versed states are equal or greater than the average num-

ber of states explored in the experiment (80). Then,

we created a second subset of our sample containing

only apps for which the traversed states are equal or

greater than the average number of states explored in

the experiment divided by two (40).

Table 3 shows the number of apps for which a par-

ticular algorithm is the best with respect to screen state

coverage considering different samples. The Whole

Sample is the original sample and it has 63 apps; the

#St

average has 26 apps; and #St

average/2 has

35 apps. Considering the Whole Sample, it is notice-

able that more than two algorithms were the winners

with respect to the number of screen state traversed

during the test execution. In that case, more than one

algorithm is deﬁned as the best for that app; that is

why the sum of the ﬁrst second column is more than

the number of apps in the sample. As presented in Fig-

ure 5, Biased Random - Fixed Weight Widget-Action is

clearly the most effective algorithm as it is the best for

half of the apps (49.21%), followed by Biased Random

- Fixed Weight (30.16%), Biased Random - Uniform

Variable Weight (23.81%), Biased Random - New Ac-

tion (22.22%), and Uniform Random (14.29%).

Considering the subset of the sample for which

the algorithms reached at least the average number

of states explored by the whole sample (80); notice

that there is only one best algorithm for each app,

which may imply that differences between algorithms

increase as the number of states explored increases.

In this subset, the algorithm Biased Random - Fixed

Weight Widget-Action is still the most effective as it is

the best algorithm for 46.15% of the apps of this sam-

ple subset, followed by Biased Random - New Action

(23.08%), Biased Random - Fixed Weight (15.38%),

Biased Random - Uniform Variable Weight (11.54%),

and Uniform Random (3.85%). When apps with more

states traversed are considered, the percentage of the

apps for which the algorithm Biased Random - Fixed

Weight Widget-Action is the best remained about the

same while it was reduced for the others, especially

for the default algorithm Uniform Random which was

the best for only one app this time.

Considering the subset of the sample for which

the algorithms achieved at least the average number

of states explored by the whole sample divided by

two (40), notice that there is also only one best al-

gorithm for each app. Similarly to the other sample

subset, the algorithm Biased Random - Fixed Weight

Widget-Action is also the most effective as it is the

best algorithm for almost half of the apps (48.57%),

followed by Biased Random - New Action (17.14%)

and Biased Random - Fixed Weight (17.14%), Biased

Random - Uniform Variable Weight (11.43%), and

Uniform Random (5.71%).

Accessibility Violations.

To probe into the viola-

tion detection effectiveness of each algorithms, we

collected the absolute number of unique accessibility

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

Table 3: Number of apps for which an algorithm is the best w.r.t. screen coverage in different sample subsets.

Whole Sample Proportion #St>=average Proportion #St>=average/2 Proportion

BRFW 19 30,16% 4 15,38% 6 17,14%

BRFWWA 31 49,21% 12 46,15% 17 48,57%

BRNA 14 22,22% 6 23,08% 6 17,14%

BRUVW 15 23,81% 3 11,54% 4 11,43%

UR 9 14,29% 1 3,85% 2 5,71%

violations revealed during the exploration of each al-

gorithm. Figure 6 shows that there is no signiﬁcant

difference in the number of accessibility violations

revealed when different ﬂavors of random algorithms

are applied to generate user inputs.

UR BRUVW BRFWWA BRFW BRNA

200

400

600

800

1000

1200

Number of Uncovered Violations

Figure 6: Number of violations uncovered by each algorithm

when applied to all apps in our sample.

Nevertheless, the number of apps for which each algo-

rithm performed the best with respect to accessibility

violations found is different. Figure 7 shows that the al-

gorithm Biased Random - Fixed Weight Widget-Action

clearly generates user inputs that uncovered more ac-

cessibility violations for 27 apps, followed by Biased

Random - Fixed Weight for 16 apps, Uniform Random

for 12 apps, Biased Random - New Action for 9 apps,

and Biased Random - Uniform Variable Weight for

7 apps. Notice that, even though the Uniform Ran-

dom algorithm was the worst algorithm with respect

to state coverage, it was the third in terms of uncover-

ing accessibility violations. It means that the number

of states explored may not correlate with uncovering

more violations. We surmise that this is the case be-

cause uncovering violations depends on the diversity

of the states explored.

Table 4 shows the number of apps for which a

particular algorithm is the best with respect to the

number of accessibility violations found considering

different subsets of our sample: apps for which the

number of states traversed is equal or greater than

the average for the whole sample (80) and half of the

average (40).

Considering the Whole Sample, notice that more

UniformRandom BiasedRandomFixedWeight BiasedRandomFixedWeightWA BiasedRandomUniformVariableWeight BiasedRandomNewAction

Algorithms

Number of apps in which was the best (violations)

Figure 7: Number of apps for which an algorithm is the best

w.r.t. accessibility violations found.

than two algorithms were the best for the same app

with respect to the number of accessibility violations

found. As presented in Figure 7, Biased Random -

Fixed Weight Widget-Action is clearly the most effec-

tive algorithm as it is the most effective for 42.86% of

the apps, followed by Biased Random - Fixed Weight

(25.40%), Uniform Random (19.05%), Biased Random

- New Action (14.19%) and Biased Random - Uniform

Variable Weight (11.11%).

Considering the subset #St

average, the algo-

rithm Biased Random - Fixed Weight Widget-Action is

still the most effective for 42.31% of the apps, followed

by Biased Random - New Action (26.92%), Biased

Random - Fixed Weight (15.38%), Biased Random -

Uniform Variable Weight (11.54%), and Uniform Ran-

dom (11.54%). When apps with more states traversed

are considered, the percentage of the apps for which

the algorithms Biased Random - Fixed Weight Widget-

Action and Biased Random - Uniform Variable Weight

are the best remained about the same while it increased

for Biased Random - New Action and decreased for

Uniform Random and Biased Random - Fixed Weight.

Considering the subset of the sample for which

the algorithms achieved at least the average num-

ber of states explored by the whole sample divided

by two (40), the algorithm Biased Random - Fixed

Weight Widget-Action remains the most effective for

45.71% of the apps, followed by Biased Random -

Evaluating Random Input Generation Strategies for Accessibility Testing

Table 4: Number of apps for which an algorithm is the best w.r.t. accessibility violations found in different sample subsets.

Whole Sample Proportion #St>=average Proportion #St>=average/2 Proportion

BRFW 16 25,40% 4 15,38% 8 22,86%

BRFWWA 27 42,86% 11 42,31% 16 45,71%

BRNA 9 14,29% 7 26,92% 7 20,00%

BRUVW 7 11,11% 3 11,54% 5 14,29%

UR 12 19,05% 3 11,54% 4 11,43%

Fixed Weight (22.86%), Biased Random - New Action

(20%), Biased Random - Uniform Variable Weight

(14.29%), and Uniform Random (11.43%).

The algorithm Biased Random - Fixed Weight

Widget-Action seems to be the most effective consider-

ing both the number of states traversed and the number

of accessibility violations found. Nevertheless, for

most winning algorithms, the difference between the

number of states explored and the accessibility vio-

lations found is not signiﬁcantly different from the

second best algorithm. Another noticeable fact regard-

ing our results is that the Uniform Random, the default

algorithm used to generate user inputs by the under-

lying tool we used in this experiment, has the worst

performance in most cases.

6 CONCLUDING REMARKS

We probed into different strategies for random testing

in the context of automated accessibility testing. To

this end, we proposed four biased algorithms and im-

plemented them on top of state of the art open source

tool MATE (Eler et al., 2018). These algorithms were

compared with the default strategy Uniform Random,

taking into account the number of activities executed,

screen states traversed, and accessibility violations

revealed.

Comparing results for the our sample altogether,

the differences between the results achieved by the

ﬁve algorithms are negligible in most cases. How-

ever, when we look at the results on an app-by-app

basis, the algorithm Biased Random - Fixed Weight

Widget-Action is clearly the most effective at exploring

more screen states and revealing more accessibility

violations. In addition, the default strategy Uniform

Random had the worst performance in most scenarios.

Such results evince that different ﬂavors of ran-

dom algorithms can be explored to achieve better re-

sults with respect to the automated accessibility testing

of mobile apps. As future work, we intend to evalu-

ate how adaptive random strategies, which systemati-

cally generate more diverse test inputs, perform against

the best performing algorithm (i.e., Biased Random -

Fixed Weight Widget-Action) according to our results.

ACKNOWLEDGMENTS

The authors would like to thank some Brazilian re-

search agencies for their ﬁnancial support. Andre

Takeshi Endo is partially ﬁnancially supported by

the grant grant nr. of CNPq, and Marcelo Medeiros

Eler if partially ﬁnancially supported by the grant nr.

18/12287-6 of the S

ao Paulo Research Foundation

(FAPESP).

REFERENCES

Abascal, J., Arrue, M., and Valencia, X. (2019). Tools for

Web Accessibility Evaluation, pages 479–503. Springer

London, London.

uero-Flores, P., Quesada-L

opez, C., Mart

ınez, A., and

Jenkins, M. (2019). Tools for the evaluation of web

accessibility: A systematic literature mapping. In 2019

IV Jornadas Costarricenses de Investigaci

on en Com-

putaci

on e Inform

atica (JoCICI), pages 1–7.

Alshayban, A., Ahmed, I., and Malek, S. (2020). Accessibil-

ity issues in android apps: State of affairs, sentiments,

and ways forward. In Proceedings of the ACM/IEEE

42nd International Conference on Software Engineer-

ing, ICSE ’20, page 1323–1334, New York, NY, USA.

ACM.

Antonelli, H. L., Sensiate, L., Watanabe, W. M., and de Mat-

tos Fortes, R. P. (2019). Challenges of automatically

evaluating rich internet applications accessibility. In

Proceedings of the 37th ACM International Conference

on the Design of Communication, SIGDOC ’19, New

York, NY, USA. ACM.

Baek, Y.-M. and Bae, D.-H. (2016). Automated model-based

android GUI testing using multi-level GUI comparison

criteria. pages 238–249. ACM.

Choudhary, S. R., Gorla, A., and Orso, A. (2015). Auto-

mated test input generation for android: Are we there

yet? (e). In 2015 30th IEEE/ACM International Confer-

ence on Automated Software Engineering (ASE), pages

429–440.

Dyb

a, T., Dingsøyr, T., and Moe, N. B. (2014). Agile Project

Management, pages 277–300. Springer Berlin Heidel-

berg, Berlin, Heidelberg.

Eler, M. M., Rojas, J. M., Ge, Y., and Fraser, G. (2018).

Automated accessibility testing of mobile apps. In

2018 IEEE 11th International Conference on Software

Testing, Veriﬁcation and Validation, pages 116–126.

ICEIS 2021 - 23rd International Conference on Enterprise Information Systems

Fraz

ao, T. and Duarte, C. (2020). Comparing accessibility

evaluation plug-ins. In Proceedings of the 17th Inter-

national Web for All Conference, W4A ’20, New York,

NY, USA. ACM.

Hao, S., Liu, B., Nath, S., Halfond, W. G., and Govindan, R.

(2014). Puma: Programmable ui-automation for large-

scale dynamic analysis of mobile apps. In Proceedings

of the 12th Annual International Conference on Mo-

bile Systems, Applications, and Services, MobiSys ’14,

page 204–217, New York, NY, USA. Association for

Computing Machinery.

ISO (2018). Iso 9241: Ergonomics of human-system inter-

action – part 11: Usability: Deﬁnitions and concepts.

Standard ISO 9241-11:2018, International Organiza-

tion for Standardization, Geneva, CH.

Jha, A. K., Lee, S., and Lee, W. J. (2019). Characterizing

android-speciﬁc crash bugs. In 2019 IEEE/ACM 6th

International Conference on Mobile Software Engi-

neering and Systems (MOBILESoft), pages 111–122.

Lamothe, M. and Shang, W. (2018). Exploring the use of

automated api migrating techniques in practice: An ex-

perience report on android. In Proceedings of the 15th

International Conference on Mining Software Reposi-

tories, MSR ’18, page 503–514, New York, NY, USA.

Association for Computing Machinery.

Li, W., Jiang, Y., Xu, C., Liu, Y., Ma, X., and L

u, J. (2019).

Characterizing and detecting inefﬁcient image display-

ing issues in android apps. In 2019 IEEE 26th Interna-

tional Conference on Software Analysis, Evolution and

Reengineering (SANER), pages 355–365.

Li, X., Jiang, Y., Liu, Y., Xu, C., Ma, X., and Lu, J. (2014).

User guided automation for testing mobile apps. In

2014 21st Asia-Paciﬁc Software Engineering Confer-

ence, volume 1, pages 27–34.

Machiry, A., Tahiliani, R., and Naik, M. (2013). Dynodroid:

An input generation system for android apps. In Pro-

ceedings of the 2013 9th Joint Meeting on Foundations

of Software Engineering, ESEC/FSE 2013, pages 224–

234, New York, NY, USA. ACM.

Mao, K., Harman, M., and Jia, Y. (2016). Sapienz: Multi-

objective automated testing for android applications.

In Proceedings of the 25th International Symposium

on Software Testing and Analysis, ISSTA 2016, page

94–105, New York, NY, USA. ACM.

Mateus, D. A., Silva, C. A., Eler, M. M., and Freire, A. P.

(2020). Accessibility of mobile applications: Evalua-

tion by users with visual impairment and by automated

tools. In Proceedings of the 18th Brazilian Symposium

on Human Factors in Computing Systems., IHC ’20.

ACM.

Pacheco, C. and Ernst, M. D. (2007). Randoop: Feedback-

directed random testing for java. In Companion to the

22nd ACM SIGPLAN Conference on Object-Oriented

Programming Systems and Applications Companion,

OOPSLA ’07, page 815–816, New York, NY, USA.

Association for Computing Machinery.

Park, E., Han, S., Bae, H., Kim, R., Lee, S., Lim, D., and

Lim, H. (2019). Development of automatic evalua-

tion tool for mobile accessibility for android applica-

tion. In 2019 International Conference on Systems of

Collaboration Big Data, Internet of Things Security

(SysCoBIoTS), pages 1–6.

Paz, F. and Pow-Sang, J. A. (2016). A systematic mapping

review of usability evaluation methods for software de-

velopment process. International Journal of Software

Engineering and Its Applications, 10:165–178.

Samir, A., Maghawry, H. A., and Badr, N. (2019). Enhanced

approach for maximizing coverage in automated mo-

bile application testing. In 2019 Ninth International

Conference on Intelligent Computing and Information

Systems (ICICIS), pages 402–407.

Siebra, C. A., Correia, W., Penha, M., Mac

edo, J., Quintino,

J., Anjos, M., Florentin, F., Silva, F. Q. B., and Santos,

A. L. M. (2018). An analysis on tools for accessibility

evaluation in mobile applications. In Proceedings of

the XXXII Brazilian Symposium on Software Engineer-

ing, SBES ’18, page 172–177, New York, NY, USA.

Association for Computing Machinery.

Silva, C., Eler, M. M., and Fraser, G. (2018a). A survey

on the tool support for the automatic evaluation of

mobile accessibility. In Proceedings of the 8th Inter-

national Conference on Software Development and

Technologies for Enhancing Accessibility and Fighting

Info-exclusion, DSAI 2018, pages 286–293, New York,

NY, USA. ACM.

Silva, D. B., Eler, M. M., Durelli, V. H., and Endo, A. T.

(2018b). Characterizing mobile apps from a source

and test code viewpoint. Information and Software

Technology, 101:32 – 50.

Souza, N., Cardoso, E., and Perry, G. T. (2019). Limita-

tions of automated accessibility evaluation in a mooc

platform: Case study of a brazilian platform. Revista

Brasileira de Educacao Especial, 25:603 – 616.

Su, T., Meng, G., Chen, Y., Wu, K., Yang, W., Yao, Y., Pu, G.,

Liu, Y., and Su, Z. (2017). Guided, stochastic model-

based gui testing of android apps. In Proceedings of the

2017 11th Joint Meeting on Foundations of Software

Engineering, ESEC/FSE 2017, pages 245–256, New

York, NY, USA. ACM.

Tramontana, P., Amalﬁtano, D., Amatucci, N., and Fasolino,

A. R. (2019). Automated functional testing of mobile

applications: a systematic mapping study. Software

Quality Journal, 27(1):149–201.

Vigo, M., Brown, J., and Conway, V. (2013). Benchmark-

ing web accessibility evaluation tools: Measuring the

harm of booktitle = Proceedings of the 10th Interna-

tional Cross-Disciplinary Confere Sole Reliance on

Automated Tests,nce on web accessibility. W4A ’13,

pages 1:1–1:10, New York, NY, USA. ACM.

Wohlin, C., Runeson, P., H

ost, M., Ohlsson, M. C., Reg-

nell, B., and Wessl

en, A. (2012). Experimentation in

Software Engineering. Springer.

Evaluating Random Input Generation Strategies for Accessibility Testing
