Pothole Detection under Diverse Conditions using Object Detection

Models

Syed Ibrahim Hassan

, Dympna O’Sullivan

and Susan Mckeever

Department of Computer Science, Technological University Dublin, Ireland

Keywords:

Object Detection, Pavement Inspection, Deep Learning, Machine Learning.

Abstract:

One of the most important tasks in road maintenance is the detection of potholes. This process is usually done

through manual visual inspection, where certiﬁed engineers assess recorded images of pavements acquired

using cameras or professional road assessment vehicles. Machine learning techniques are now being applied

to this problem, with models trained to automatically identify road conditions. However, approaching this real-

world problem with machine learning techniques presents the classic problem of how to produce generalisable

models. Images and videos may be captured in different illumination conditions, with different camera types,

camera angles and resolutions. In this paper we present our approach to building a generalized learning model

for pothole detection. We apply four datasets that contain a range of image and environment conditions. Using

the Faster RCNN object detection model, we demonstrate the extent to which pothole detection models can

generalise across various conditions. Our work is a contribution to bringing automated road maintenance

techniques from the research lab into the real-world.

1 INTRODUCTION

The assessment of road surface (termed road pave-

ment) condition is a crucial task to ensure their us-

ability and provide maximum safety for the public.

The costs involved in maintaining pavements are sig-

niﬁcant – both to road users (over 60% of Irish peo-

ple have had their chosen mode of transport damaged

as a result of striking a pothole according to recent

research) (ALDWORTH, 2018). The UK, councils

allocate 75% funds for the maintenance of the local

road condition and 25% for construction (Radopoulou

and Brilakis, 2015). The two most common surface

materials for road pavement are concrete and asphalt.

Concrete roads are highly durable when compared to

asphalt roads. Although concrete road surfaces last

longer, repairing them is more complex. Holes or

cracks cannot simply be patched–instead, entire slabs

must be replaced. Asphalt paving is cheaper com-

pared to concrete paving. It also creates a smoother

drive, and provides better safety due to better trac-

tion and skid resistance. Asphalt is ideal for rural

road pavements due to the ease of maintenance and

https://orcid.org/0000-0002-0480-989X

https://orcid.org/0000-0003-2841-9738

https://orcid.org/0000-0003-1766-2441

repair, patching is simpler and faster than replacing

entire slabs of roadways on less heavily trafﬁcked ar-

eas such as country roads. But with only a 10-year

lifespan, asphalt must be re-laid or repaired on a much

more regular basis than concrete.

Pavement defects vary depending on the pavement

surface. Pavement defects include cracking caused by

failure of the surface layer. Surface deformation such

as rutting that results from weakness in one or more

layers of the pavement. Disintegration such as pot-

holes caused by progressive breaking up of pavement

into small loose pieces and surface defects, such as

ravelling caused by errors during construction such as

insufﬁcient adhesion between the asphalt and aggre-

gate particulate materials.

In this paper we focus on the detection and local-

ization of potholes which are a common defect on

both asphalt and concrete pavement. Potholes are

a common cause of accidents and therefore require

frequent inspection and timely repair. Pavement in-

spection usually consists of three main steps: 1) data

collection, 2) defect identiﬁcation and 3) defect as-

sessment. The ﬁrst step is largely automatic, carried

out by specially adapted vehicles for surface survey-

ing. However, the other two steps are largely manual.

Images of road pavements are visually inspected by

structural engineers or certiﬁed inspectors who assess

128

Hassan, S., O’Sullivan, D. and Mckeever, S.

Pothole Detection under Diverse Conditions using Object Detection Models.

DOI: 10.5220/0010463701280136

In Proceedings of the International Conference on Image Processing and Vision Engineering (IMPROVE 2021), pages 128-136

ISBN: 978-989-758-511-1

the road condition against the Pavement Condition In-

dex (PCI). PCI is widely used in transportation civil

engineering across the world and many authorities use

it to measure the performance of their road infrastruc-

ture. It provides a numerical index between 0 and 100

which is used to specify general condition of pave-

ments.

An automated defect detection and localization

system could be a valuable tool for improving the per-

formance and accuracy of the pavement inspection

and assessment process as well as reduce the man-

ual overhead of the current process. Such a system

could be used to evaluate images or videos to assess

pavement condition data. Additionally, an automated

pothole detection system could be integrated into ex-

isting road inspection tools to support the inspection

process by detecting road potholes from images ac-

quired during the pavement inspection process.

This paper proposes a pothole detection method to

detect and localize potholes on road surface. We

describe the development of a Faster RCNN (Ren

et al., 2016) model for pothole detection which is

trained on a public potholes dataset (Kaggle, 2019)

and tested for its generalizability on a number of other

pavement image dataset(s). The contribution of our

work is threefold: (1) We present an object detec-

tion model that can achieve accuracies of between

70% and 90%, for the task of detecting potholes in

images; (2) We measure the impact of various real-

world conditions on the accuracy of pothole detec-

tion models,and;(3) We publish three re-labelled pub-

lic dataset(s) and contribute a labelled pothole image

dataset to the ﬁeld. The rest of this paper is orga-

nized as follows. In the next section related work on

image processing and machine learning for pothole

detection has been reviewed. In section 3 we describe

experimental work to develop a trained model for pot-

hole detection and the results of testing of this model

on several dataset(s). In Section 4 we present our re-

sults and conclude with a discussion in Section 5.

2 RELATED WORK

With recent advances in deep learning, computer vi-

sion and image processing, research work has been

carried out on pothole detection (Dhiman and Klette,

2019). Pothole detection methods are divided into

three broad areas: vision based (Sawalakhe and

Prakash, 2018) (Koch and Brilakis, 2011) (Ryu et al.,

2015), vibration based (Yu and Yu, 2006) and 3D re-

construction methods (Hou et al., 2007) (Cao et al.,

2020). Vision based methods rely on image or

video data. This approach divides into two main ap-

proaches: image processing and machine learning.

For machine learning, traditional algorithms that have

been applied to this task have relied heavily on hand

crafted features (Daniel and Preeja, 2014) (Hoang,

2018). To overcome these challenges, deep learn-

ing models, with their capability to extract visual fea-

tures automatically from images rather than relying

on hand crafted features, have become more popu-

lar. For example, object detection models are trained

which can perform pothole detection by drawing a

bounding box around the potholes. (Bhatia et al.,

2019) investigate the feasibility and accuracy of ther-

mal imaging in pothole detection. The proposed ap-

proach consists of 3 main steps: (1) data acquisition

under various lightning condition (2) data augmen-

tation, to increase the size of dataset (3) training a

convolutional neural network (CNN) model. They

compare the result of a self-built CNN model with

pre-trained CNN models, with the pre-trained model

achieving an overall detection accuracy of 97.8%.

The main objective of this work is to ﬁnd an efﬁcient

CNN model for pothole detection using thermal imag-

ing. However, the drawback of their system is that

it can only distinguish potholes and non-potholes on

thermal images which are rarely used in road inspec-

tion.

(Ping et al., 2020) developed a pothole detection

system by training on a pre-processed pothole dataset

with four different models and compared the accu-

racy across each model. The method achieved 82%

accuracy on YoloV3 (You Look Only Once: Version

3) (Farhadi and Redmon, 2018). However, the ap-

proach has not been tested on real world examples

and their trained YoloV3 model does not accurately

detect pothole on new images. The authors com-

pare results of four different object detection models

and found that SSD (Single Shot Multi-box Detector)

gives higher accuracy but lower speed in comparison

to the YoloV3 model. YoloV3 provides higher speed

but lower detection accuracy and fails to detect small

potholes. (Gupta et al., 2020) propose a pothole de-

tection and localization system which can detect pot-

holes by drawing a bounding box around potholes.

The research utilizes thermal images and modiﬁed

ResNet50 model and achieves 91.15% average preci-

sion in detecting potholes. However, their method can

only work with thermal images which are rarely used

by pavement inspection companies. In addition, the

method can only detect potholes in images where the

camera distance is relatively close to the pothole. In

our work, we examine the problem of generalizability

of trained models in the domain of road inspection.

From the road inspection prospective, it is important

to use models that consider the variety of conditions

Pothole Detection under Diverse Conditions using Object Detection Models

129

such as different road surfaces, pothole sizes, distance

of pothole from imaging device. (Dharneeshkar et al.,

2020) propose a pothole detection system on their

own collected pothole dataset. The authors trained

different versions of YOLO object detection model

on 1500 images collected using a smartphone cam-

era with a resolution of 1024 x 768. The proposed

method can detect and localize potholes at different

angles and on road surface. Similarly, (Ukhwah et al.,

2019) train different versions of YOLO object detec-

tion model on images from a highway survey vehi-

cle in Indonesia. To train the YOLO model, the au-

thors use 448 grey scale potholes images. The method

demonstrates that it can detect potholes from images

that are acquired by using highway survey vehicles.

The overall average precision achieved by the vari-

ous models was 83.43%, 79.33% and 88.93% respec-

tively.

From a commercial perspective, many vehicles

are now being adapted to include automatic pothole

detection system into their autonomous driving mod-

ules. For example, Jaguar Land Rover are researching

automatic road pothole detection in which their vehi-

cles not only detect potholes but can also identify the

location as well as the severity of the pothole (Jaguar,

2015). Their proposed system can also send warning

messages to the driver. FORD are also developing a

pothole detection system where the system can warn

drivers about the location of potholes (FORD, 2018).

Another commercial application of automatic pothole

detection was proposed by (Bansal et al., 2020). Their

approach is based on vibration-based pothole detec-

tion which combines GPS, Internet of Things (IoT)

sensors including accelerometers and gyroscope and

machine learning. The IoT dataset was trained us-

ing a Support Vector Machine (SVM), Logistic Re-

gression, Na

ıve Bayes, Random Forest and K-Nearest

Neighbours (KNN). Random forest achieved highest

accuracy in detecting potholes 86.8%. The objectives

of the systems are to reduce injuries and deaths, alert

drivers about potholes before driving over them, share

pothole location data with government and civil au-

thorities to repair pothole in timely manner and to

build a real time map which updates according to lat-

est road conditions.

The task of pothole detection has many differ-

ent variations – the variety of potholes, lighting lev-

els, distance of the pothole from camera, shot angle,

imaging device and weather conditions. Therefore, a

useful road maintenance prediction model should be

able to generalise. In our approach we used a pub-

licly available Kaggle dataset (Kaggle, 2019) to train

a prediction model for pothole detection which was

subsequently tested on a number of other dataset(s)

that represent a variety of real-world variations. Our

experimental set up and results are presented in the

next sections.

3 METHODOLOGY

This paper proposes a method for automatically de-

tecting the presence and location of potholes in an im-

age, whilst also considering the variety of real world

conditions that can occur during the automatic pave-

ment assessment process. Using supervised machine

learning, we train an object detection model using an

image dataset containing potholes. We control the

number of each variation in training dataset and then

do controlled testing of these conditions using test

sets because we wish to check how well a model can

generalize to other datasets so it is necessary to con-

trol the variation of training and testing samples.

This section describes the details of preparing

training and testing data, object detection model ar-

chitecture and training and testing steps. The training

dataset used in this research was the Kaggle pothole

dataset, a publicly available dataset with one positive

class (pothole present). The dataset contains 618 im-

ages. Due to the duplication of images in the dataset,

280 unique images were selected for training. Each

image was labelled by drawing a bounding around the

pothole using the LabelImg tool (LabelImg, 2015).

The model was trained under controlled settings and

tested using 4 other datasets described in detail be-

low. Table 1 shows details for the training dataset, in-

cluding four characteristics of training images which

could challenge model generalizability: acquisition

device, distance, distance from camera and lighting

level. The values or categories for each is provided

(e.g. close distance, medium distance and far distance

which means pothole is either close from camera an-

gle or it is too far from camera angle or it is near

(medium) from camera angle). Figure 1 shows the

example of each camera angle.

Table 1: Breakdown of the Kaggle Pothole Dataset used for

Training.

Index Name Description

Training Data Kaggle Pothole

Acquisition Device Smartphone/Digital Camera

Image Size 500 x 500

Distance

Close = 1 meter

Medium = 2∼3 meters

Far = 5∼10 meters

Lighting Level Normal: 228, Low: 52

Total Images 280

IMPROVE 2021 - International Conference on Image Processing and Vision Engineering

130

Figure 1: Example of different camera angles: Top left:

Close, Top right: Medium, Bottom: Far.

3.1 Data Preparation

Training images for our model require the location of

the pothole(s) in each image to be annotated. This

was manually applied to the 280 training images by

creating a bounding box around the area of interest i.e.

a pothole. Below are the steps that were performed for

the training data preparation:

Step 1: Create a dataset using labelImg, gener-

ating XML ﬁles that contain information about object

coordinates, image name, image width and height and

object name.

Step 2: Convert these XML ﬁles into CSV ﬁle

which store each XML ﬁle details.

Step 3: Convert CSV ﬁle to Tensorﬂow’s own

binary storage format tf-record i.e. train-record and

test-record. TensorFlow’s object detection API re-

quires the data to be in the ‘tfrecord’ format. The

tfrecord format enables splitting, creating batches,

shufﬂing data and providing a uniform format across

network architectures and systems.

Figure 2: Implementation pipeline for pothole detection us-

ing Tensorﬂow object detection.

3.2 Testing Datasets

The focus of this research is to determine how an ob-

ject detection model trained on one dataset (with a

known range of variations) can perform against a va-

riety of conditions via a number of testing dataset(s).

First, we test if the image can distinguish between

positive (contains pothole) and negative (does not

contain a pothole) images. Then we test for a number

of conditions ranging from different image sizes, dif-

ferent image types (stereo images) and different light-

ing conditions.

The details of the 4 test dataset(s) used for test-

ing are described below. Three dataset (s) (Negative

Images (Saxena, 2019), Cranﬁeld (Alzoubi, 2018),

Pothole-600 (Fan et al., 2020)) are publicly available.

The fourth dataset is our own data, collected by ac-

quiring the pothole images from different streets of

Dublin. In each test dataset bounding box labels are

not included, therefore we manually labelled each im-

age by drawing a bounding box around the region of

interest using the LabelImg tool. Table 2 shows the

details of 3 testing dataset(s).

A) Negative Images: This dataset (Saxena, 2019)

provides a number of negative images. Due to the

presence of other objects in images such as vehi-

cles, trees or people, the pavement surface has been

cropped from each image.

B) Cranﬁeld Pothole Dataset (Alzoubi, 2018):

This dataset provides images of potholes on asphalt

pavement. The reason for choosing this dataset for

testing is its small image size i.e. 300 x 300 pixels,

as the model was trained on images of size 500 x 500

pixels.

C) Pothole-600 Dataset (Fan et al., 2020): This

dataset provides pothole images which were acquired

using a stereo camera. The reason for choosing this

dataset for testing is that the camera source and im-

age type are different from the training set, as all im-

ages in the training set are acquired using smartphone

camera or digital camera.

D) Dublin Road Dataset: This dataset was ac-

quired from pavements in Dublin using a smartphone

camera under daylight conditions. In total we col-

lected 40 images with a resolution of 3648 x 2736.

The reason for collecting this dataset is to test images

with normal and low lighting condition. All images in

this dataset were collected during daylight hours, as

acquiring road images is not an easy or practical task

in darker environments. Therefore, an artiﬁcial low

lighting effect have been applied on the same testing

set.

Table 2: Testing dataset details.

Test Dataset Image Size Total Images

Cranﬁeld (Alzoubi, 2018) 300 x 300 50

Cranﬁeld 400 x 400 50

Pothole-600 (Fan et al., 2020) 400 x 400 50

Dublin Roads 3648 x 2736 40

Pothole Detection under Diverse Conditions using Object Detection Models

131

Figure 3: Example images of each testing dataset: Top left:

Pothole-600, Top right: Cranﬁeld Pothole Dataset, Bottom:

Dublin Road Dataset.

3.3 Pothole Detection with Faster

RCNN

To address the object detection problem for pothole

detection we have trained a state-of-the-art object de-

tection model Faster RCNN (Ren et al., 2016). Faster

R-CNN has two stages for detection. In the ﬁrst stage,

images are processed using a feature extractor (e.g.

VGG, MobileNet) called the Region Proposal Net-

work (RPN) and simultaneously, intermediate level

layers (e.g.,” conv5”) are used to predict class bound-

ing box proposals. In the second stage, these box pro-

posals are used to crop features from the same inter-

mediate feature map, which are subsequently input to

the remainder of the feature extractor in order to pre-

dict a class label and its bounding box modiﬁcation

for each proposal. We also use Inception-V2 architec-

ture as a backbone of Faster RCNN model. Inception

architecture has yielded better results than a conven-

tional CNN architecture. Additionally, Faster R-CNN

model combined with Inception CNN architecture

shows an improvement in detection accuracy. The

choice of this network was motivated by the fact that

it achieves good results on different dataset(s) such as

Microsoft Common Object Context (MS COCO) (Lin

et al., 2014) and PASCAL VOC (Everingham et al.,

2010). Furthermore, it offers a structure that can be

modiﬁed according to speciﬁc task needs. Table 1

shows the details of the Kaggle dataset which is used

to train the object detection model. After training the

model, we tested the trained model using 4 dataset(s)

to investigate various parameters – negative images,

image sizes, images acquired from multiple sources

and lighting levels. In our experiments model training

and testing is done using Python, and the Tensorﬂow

object detection API. In this work we did not use data

augmentation. For training, a NVIDIA GeForce RTX

2070 GPU was used. All experiments are performed

under Windows 10 on Intel Core i7-9750 with 16GB

of DDR4 RAM. The model was trained with Adam

optimizer and L2 regularization, using an initial learn-

ing rate to 0.00001. The modelling process was done

in approximately 2 hours with 20k iterations. During

the training process we observed that after the 20k

iteration, the training loss did not decrease substan-

tially, so we stopped the training and saved the model

parameters for the testing purpose.

3.4 Evaluation Protocol

The performance of the developed model was evalu-

ated on 4 datasets as described in Section 3.2. For

each testing set, results generated from the Faster

RCNN model were compared with the actual ground

truth. Several researchers have proposed differ-

ent evaluation methods for the object detection task

(Padilla et al., 2020) (Zhao et al., 2019). In this pa-

per, Intersection over Union (IoU) (also known as the

Jaccard index), precision and recall are used to eval-

uate trained models. IoU measures the overlap be-

tween the actual ground truth bounding box and the

predicted bounding box. We deﬁned an IoU threshold

of 0.5 which means if the overlap between an actual

and predicted bounding box is <0.50% the model will

consider it as false positive whereas, if the overlap be-

tween actual and predicted bounding box is >0.50%

the model will consider it as true positive. In this way

precision and recall are calculated at 0.5 IoU thresh-

olds. Increasing IoU threshold results in higher pre-

cision but lower recall. Conversely, decreasing IoU

threshold gives higher recall. For example, if we

IoU threshold set to 0.9 then we get higher preci-

sion which means model can detect potholes if the

overlap between actual and predicted bounding box

is >=0.9% the model will consider it as true posi-

tive. Figure 4 shows an example of an actual and pre-

dicted bounding box used for IoU calculation. A high

IoU threshold is not required as the exact placement

of the pothole relative to predicted area just needs to

be enough to say that a pothole exists in the area.

The task does not require precise pothole perimeter

discovery. Figure 5 shows precision and recall re-

sults from experiment 4 at IoU thresholds from 0.5

- 0.9. While precision does not vary greatly at differ-

ent IoU thresholds, relaxing the IoU threshold results

in higher recall values.

IMPROVE 2021 - International Conference on Image Processing and Vision Engineering

132

Figure 4: Example of Intersection over Union (IoU).

4 EXPERIMENTAL RESULTS

In this section we describe a series of experiments

conducted on a variety of dataset(s). We implemented

four experiments - within each, we focus on speciﬁc

variable conditions for are encountered on the pothole

detection task: distinguishing positive and negative

images, variety of image size, images captured with

different devices and variations in lighting level.

4.1 Experiment 1: (Positive and

Negative Images)

This experiment shows the performance of the trained

model on negative images i.e. no pothole on the pave-

ment surface. 50 images were passed to the trained

model and 45 of those images were predicted cor-

rectly. In order to check the reason of wrong detec-

tion we check all images manually and found that the

errors were due to the appearance of shadows on the

road surface where the model considered these dark

patches as potholes.

Table 3: Results of pothole detection on negative images.

Non-pothole Pothole Accuracy

45 5 90%

4.2 Experiment 2: (Smaller Images)

In this experiment we used the Cranﬁeld dataset and

tested with 50 images of size 300 x 300 pixels and 50

images of 400 x 400 pixels. As our model is trained

on images of size 500 x 500, in this experiment we

are investigating how well our trained model can gen-

eralize to detect potholes on smaller images. Initially

we have tested images of size 500 x 500 in order to

check the model performance on the same image size

as those of the training set. We then resize images to

test smaller size images. Table 4 shows that model

achieve almost same results on both smaller size im-

ages, with just a slight improvement on the (trained)

500 x 500 image size.

Table 4: Results of pothole detection on small image.

Model Backbone Image Size Precision Recall

Faster RCNN Inception V2

500 x 500 79% 94%

400 x 400 80% 92%

300 x 300 79% 92%

4.3 Experiment 3: (Images Captured by

Stereo Camera)

The purpose of this experiment is to test the model on

a different image type: stereo images. However the

images in this dataset were varied in terms of the dis-

tance of the pothole from the camera so we also had to

check for any effect caused by this feature. Therefore,

we conducted 2 experiments. In the ﬁrst experiment

we randomly selected 50 images from the dataset and

achieved the results in Table 5.

Table 5: Results of pothole detection on stereo images.

Model Backbone Image Size Precision Recall

Faster RCNN Inception V2 400 x 400 77% 55%

Analysing the results in Table 5, the detection per-

formance of the model is low. To understand this fur-

ther, we conducted a second experiment where we di-

vided the 50 images into two test sets based on dis-

tance - 25 images with a close distance between the

camera and pothole and 25 images with a medium dis-

tance between the camera and pothole. We compared

the results to a test set with 50 non-stereo images di-

vided into two testing sets of 25 images with close

and medium distance to the camera.

Table 6: Results of pothole detection on stereo and non-

stereo images with close and medium distance.

Model Backbone

Testing

Dataset

Distance

No.

Images

Precision Recall

Faster

RCNN

Inception

Stereo

Medium 25 95% 84%

Close 25 65% 52%

Non

Stereo

Medium 25 83% 100%

Close 25 63% 48%

Results in table 6 shows that the image type or

source does not affect detection accuracy, rather the

distance from the pothole to the camera affects the

detection performance. In both experiments it can be

seen that images with medium distance have high de-

tection accuracy compared to those at close distance.

The main reason for this is that our training set con-

tains only a small sample of images where the dis-

tance from the camera to the pothole is close.

Pothole Detection under Diverse Conditions using Object Detection Models

133

4.4 Experiment 4: (Images with

Different Lighting Conditions)

This experiment uses images that were collected

across Dublin city centre in daylight. A total of 40 im-

ages were collected with normal lighting levels. In or-

der to test different lighting conditions, we ﬁrst tested

the original 40 images collected in daylight and then

applied an artiﬁcial low lighting effect to the same 40

images and retested on those. Table 7 shows the re-

sults of experiment 4. Analyzing the results in table

7 the detection performance of the model on normal

images is slightly lower than on low lighting level im-

ages. The reason for low accuracy on normal lighting

images is because the model is unable to detect pot-

holes on two images in the normal lighting dataset.

However, in the low lighting dataset, the model cor-

rectly detected pothole on those two images.

Table 7: Results of pothole detection on Dublin roads

dataset.

Model Backbone Testing Dataset Precision Recall

Faster RCNN Inception V2

Dublin

(Normal Light)

78% 68%

Dublin

(Low Light)

78% 73%

Figure 5: Comparison of Precision and Recall at different

IoU threshold values.

5 DISCUSSION

The process of pothole detection for road mainte-

nance is still largely done though manual visual in-

spection of images or videos acquired using cameras

or professional road assessment vehicles. This is a

time consuming and expensive task. The task is also

complicated by variations in images such as different

image types and sizes, camera types, lighting levels

and distance of the pothole from the camera.

From experiment 1 we found that shadows and

manhole covers on the pavement surface may be iden-

tiﬁed as false positives (i.e. the model falsely identi-

ﬁes then as potholes) and as such this adversely af-

fects the model’s performance. From the second ex-

periment, we conclude that image size is not a major

factor which could affect the detection performance

as results are similar across all sizes. From the third

experiment we conclude that the camera source is not

a major factor affecting model performance. How-

ever, the distance of a pothole from the camera device

has an impact on the detection rate. From experiment

3 we conclude that the model has difﬁcultly in identi-

fying potholes that are close to the camera. From the

4th experiment we notice that lighting effect is not

having a major impact on the detection rate as long as

the distance of the pothole from camera device is not

close.

We believe that our results could be improved by

more labelled training data and more balanced train-

ing samples, particularly with respect to images taken

at different distances from the image capture device.

6 CONCLUSIONS

In this paper we investigated some common issues

which are likely affect the generalizability of any

model for automated pavement assessment. We deter-

mine the variations of images in terms of image size,

distance of pothole from camera angle and lighting

effect.

We trained an object detection model using the

Kaggle pothole dataset. We used Faster RCNN with

Inception V2 as a backbone model for object detec-

tion. To check model generalizability we used a va-

riety of conditions including small image sizes, dif-

ferent image types and lighting effects. We have at-

tempted to identify factors that may impact a gener-

alizable model for pothole detection. These factors

include image size, camera source, lighting levels and

distract from the camera. To investigate these factors,

we conducted four experiments. In each experiment

we explore one condition.

We conclude that distance of a pothole from a

camera device plays an important role when aiming

to create a generalizable model for pothole detection.

A further problem for the pothole detection task is the

presence of other objects in the images (e.g. manhole

covers) that may be falsely identiﬁed as potholes.

Our work is currently limited to detecting a sin-

gle pavement defect- potholes. This can be extended

to detect multiple pavement defects such as cracks,

patches, and ruts. The trained model could be de-

ployed in a number of ways - for ofﬂine detection on

batches of images or on a smartphone or other hard-

ware such as Nvidia Jetson Nano for real time pothole

detection. Regardless of the mode of implementation,

an automatic pothole detection method may help to

speed up and lower the cost of the pavement inspec-

IMPROVE 2021 - International Conference on Image Processing and Vision Engineering

134

tion process which currently relies heavily on manual

human expertise.

In future work we will train with larger dataset(s).

In particular, we will train with more samples of im-

ages containing potholes that are close and far from

the camera. We will also use images that includes pot-

holes as well other objects including shadows, man-

hole as well as other common objects in pavement

imagery. In this work we have focused on open-

source images, but there are speciﬁed images that

are collected through commercial road inspection ve-

hicles and provide more consistent images of pave-

ments which can help to build more robust model spe-

cially for the task of automatic road inspection. Re-

cently other sources such as drone shots and vehicle

windscreen cameras are being used to collect pave-

ment data. Such images often contain a multitude

of objects such as vehicles, trees, trafﬁc signs and

or/people. Such data would require pre-processing to

extract these objects before training for the pothole

detection task. Training object detection models with

larger dataset(s) will require very high computational

power and need more training time. We will also ex-

periment with tuning the hyper parameters and train-

ing the model with other feature extraction networks.

ACKNOWLEDGEMENT

This work was funded by Science Foundation Ireland

through the SFI Centre for Research Training in Ma-

chine Learning (18/CRT/6183).

REFERENCES

ALDWORTH, B. (2018). Road users bearing the cost

of damaged surfaces. https://www.theaa.ie/blog/

road-users-bearing-cost-damaged-surfaces/.

Alzoubi, A. (2018). Potdataset. https://ﬁgshare.com/

articles/PotDataset/5999699/1.

Bansal, K., Mittal, K., Ahuja, G., Singh, A., and Gill, S. S.

(2020). Deepbus: Machine learning based real time

pothole detection system for smart transportation us-

ing iot. Internet Technology Letters, 3(3):e156.

Bhatia, Y., Rai, R., Gupta, V., Aggarwal, N., Akula, A.,

et al. (2019). Convolutional neural networks based

potholes detection using thermal imaging. Journal of

King Saud University-Computer and Information Sci-

ences.

Cao, W., Liu, Q., and He, Z. (2020). Review of pavement

defect detection methods. IEEE Access, 8:14531–

14544.

Daniel, A. and Preeja, V. (2014). Automatic road distress

detection and analysis. International Journal of Com-

puter Applications, 101(10).

Dharneeshkar, J., Aniruthan, S., Karthika, R.,

Parameswaran, L., et al. (2020). Deep learning

based detection of potholes in indian roads using

yolo. In 2020 International Conference on Inventive

Computation Technologies (ICICT), pages 381–385.

IEEE.

Dhiman, A. and Klette, R. (2019). Pothole detection using

computer vision and learning. IEEE Transactions on

Intelligent Transportation Systems, 21(8):3536–3550.

Everingham, M., Van Gool, L., Williams, C. K., Winn, J.,

and Zisserman, A. (2010). The pascal visual object

classes (voc) challenge. International journal of com-

puter vision, 88(2):303–338.

Fan, R., Wang, H., Bocus, M. J., and Liu, M. (2020). We

learn better road pothole detection: from attention ag-

gregation to adversarial domain adaptation. In Euro-

pean Conference on Computer Vision, pages 285–300.

Springer.

Farhadi, A. and Redmon, J. (2018). Yolov3: An incremental

improvement. Computer Vision and Pattern Recogni-

tion, cite as.

FORD (2018). Ford pothole detection system.

https://www.ford.co.uk/shop/research/technology/

safety-and-security/pothole-detection-system.

Gupta, S., Sharma, P., Sharma, D., Gupta, V., and Sambyal,

N. (2020). Detection and localization of potholes in

thermal images using deep neural networks. Multime-

dia Tools and Applications, 79(35):26265–26284.

Hoang, N.-D. (2018). An artiﬁcial intelligence method

for asphalt pavement pothole detection using least

squares support vector machine and neural network

with steerable ﬁlter-based feature extraction. Ad-

vances in Civil Engineering, 2018.

Hou, Z., Wang, K. C., and Gong, W. (2007). Experimen-

tation of 3d pavement imaging through stereovision.

In International Conference on Transportation Engi-

neering 2007, pages 376–381.

Jaguar (2015). Pothole detection technology by jaguar land

rover. https://www.landrover.com/experiences/news/

pothole-detection.html.

Kaggle (2019). Web scrapped road images for pothole

detection. https://www.kaggle.com/sachinpatel21/

pothole-image-dataset.

Koch, C. and Brilakis, I. (2011). Pothole detection in as-

phalt pavement images. Advanced Engineering Infor-

matics, 25(3):507–515.

LabelImg (2015). Tzutalin.labelimg.gitcode. https://github.

com/tzutalin/labelImg.

Lin, T.-Y., Maire, M., Belongie, S., Hays, J., Perona, P.,

Ramanan, D., Doll

ar, P., and Zitnick, C. L. (2014).

Microsoft coco: Common objects in context. In Euro-

pean conference on computer vision, pages 740–755.

Springer.

Pothole Detection under Diverse Conditions using Object Detection Models

135

Padilla, R., Netto, S. L., and da Silva, E. A. (2020). A sur-

vey on performance metrics for object-detection algo-

rithms. In 2020 International Conference on Systems,

Signals and Image Processing (IWSSIP), pages 237–

242. IEEE.

Ping, P., Yang, X., and Gao, Z. (2020). A deep learning

approach for street pothole detection. In 2020 IEEE

Sixth International Conference on Big Data Comput-

ing Service and Applications (BigDataService), pages

198–204. IEEE.

Radopoulou, S. C. and Brilakis, I. (2015). Patch detection

for pavement assessment. Automation in Construc-

tion, 53:95–104.

Ren, S., He, K., Girshick, R., and Sun, J. (2016). Faster

r-cnn: towards real-time object detection with region

proposal networks. IEEE transactions on pattern

analysis and machine intelligence, 39(6):1137–1149.

Ryu, S.-K., Kim, T., and Kim, Y.-R. (2015). Image-based

pothole detection system for its service and road man-

agement system. Mathematical Problems in Engi-

neering, 2015.

Sawalakhe, H. and Prakash, R. (2018). Development of

roads pothole detection system using image process-

ing. In Intelligent Embedded Systems, pages 187–195.

Springer.

Saxena, S. (2019). Pothole detection. https://github.com/

shubhank-saxena/Pothole-Detection.

Ukhwah, E. N., Yuniarno, E. M., and Suprapto, Y. K.

(2019). Asphalt pavement pothole detection using

deep learning method based on yolo neural network.

In 2019 International Seminar on Intelligent Technol-

ogy and Its Applications (ISITIA), pages 35–40. IEEE.

Yu, B. X. and Yu, X. (2006). Vibration-based system for

pavement condition evaluation. In Applications of Ad-

vanced Technology in Transportation, pages 183–189.

Zhao, Z.-Q., Zheng, P., Xu, S.-t., and Wu, X. (2019). Ob-

ject detection with deep learning: A review. IEEE

transactions on neural networks and learning systems,

30(11):3212–3232.

IMPROVE 2021 - International Conference on Image Processing and Vision Engineering

136
