Framing Early Alert of Struggling Students as an Anomaly Detection

Problem: An Exploration

Eitel J. M. Lauría

School of Computer Science & Mathematics, Marist College, Poughkeepsie, NY, U.S.A.

Keywords: Early Detection, At-risk Students, Anomaly Detection, Learning Analytics, Predictive Modeling, Machine

Learning.

Abstract: This exploratory study analyses the feasibility of implementing an early-alert system of academically

vulnerable students using anomaly detection techniques for cases in which the number of struggling students

is small in comparison to the total student population. The paper focuses on a semi-supervised approach to

anomaly detection where a first stage made up of an ensemble of unsupervised anomaly detectors contributes

features to a second-stage binary classifier. Experiments are carried out using several semesters of college

data to compare the predictive performance of this semi-supervised approach relative to stand-alone

classification-based methods.

1 INTRODUCTION

In the last fifteen years the domain of academic and

learning analytics has flourished, with many

initiatives and projects being put in place to analyze

and monitor the academic performance of students.

Higher education has benefited from these

implementations, that help students improve their

academic performance and their chances of academic

success, as well as aiding academic institutions in

reducing student attrition, an issue that has direct

impact on both the reputation and bottom line of

colleges and universities. Most of these systems use

predictive modeling and machine learning techniques

to build models that help identify academically

vulnerable students using student academic data,

student demographic data, and student activity in the

course (Arnold & Pistilli, 2012; Benablo et al., 2018;

Jayaprakash et al., 2014; Lauría et al., 2016, 2019;

Martins et al., 2019; Romero et al., 2013; Sheshadri

et al., 2019; Zafra & Ventura, 2012).

The early alert of students at risk of poor

performance and academic failure has the virtue of

enabling early intervention, and early intervention

enhances the chances of student success, as has been

repeatedly demonstrated in the literature as well as

through our work (Dodge et al., 2015; Harackiewicz

& Priniski, 2018; Herodotou et al., 2019; Jayaprakash

et al., 2014; Lauría et al., 2013; Lauría & Baron,

2011; Smith et al., 2012; Yao et al., 2019).

Different machine learning algorithms have been

used by researchers to help improve the accuracy of

their models, ranging from traditional statistical

approaches like logistic regression (Campbell, 2007),

to decision trees (Guleria et al., 2014), Support Vector

Machines (Cardona & Cudney, 2019; Pang et al.,

2017), Bayesian methods (Hamedi & Dirin, 2018),

neural nets (Calvo-Flores et al., 2006; Okubo et al.,

2017), the XGBoost algorithm (Chen & Guestrin,

2016; Hu & Song, 2019) and stack ensembles (Lauría

et al., 2018).

All of these approaches have a common theme:

implement a supervised learning framework, where

models learn from past data and supervised learning

is accomplished by labeling the data with the student

performance in the form of numeric or letter grades,

which can give way to regression or multiclass

classification; or more typically through the recoding

of the grades by establishing a minimum satisfactory

threshold, such that students that perform below that

threshold are considered at risk. The task of detecting

struggling students can then be framed as a binary

classification problem. Historically, this is the

approach that has been followed by most institutions

implementing early detection systems. The approach

is valid, relevant, and relatively easy to implement in

those institutions with moderate or large numbers of

academically vulnerable students, as in that case the

proportions of students in good standing and at

academic risk are comparable in size -there is not a

Lauría, E.

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration.

DOI: 10.5220/0010471900260035

In Proceedings of the 13th International Conference on Computer Suppor ted Education (CSEDU 2021) - Volume 1, pages 26-35

ISBN: 978-989-758-502-9

large difference in proportions- and therefore the

success of the implementation is influenced by the

quality of the training data, the accuracy of the

algorithms used to train the models, and their

reliability in terms of the bias-variance trade-off

(successful algorithms try to keep low bias, while

keeping variance at bay).

But in those institutions, like ours, where the

proportion of at-risk students in any given semester is

small or very small compared to the students in good

standing (our College, for example has historically

remained below 7%, with mean values slightly above

5%), the binary classification problem described in

the previous paragraphs has the additional wrinkle of

having to train models with a very high imbalance

between both classes. Searching for potential at-risk

students is like finding a needle in a haystack.

Classifiers naturally tend to identify patterns in the

majority class in detriment of the minority class. The

small amount of training data tied to the minority

class may limit the ability of the classification

algorithms to produce reliable model parameter

estimates (He & Garcia, 2009). Different approaches

have been considered to address this issue, including

the most popular one of balancing the training data

through oversampling the minority class,

subsampling the majority class, or a combination of

both; but the topic of data balancing remains

controversial in the machine learning community

(Provost, n.d.). Still, results have been surprisingly

good considering the difficulty of the problem, but

evidently more research is needed.

One possible consideration, and the one discussed

in this paper, is to regard the minority class as an

anomaly or outlier. Anomaly detection is the task of

detecting patterns that deviate atypically from what is

expected. A typical characteristic of anomalies or

outliers is that they are rare occurrences. Although

anomaly detection can be considered as an extreme

case of imbalanced classification (Kong et al., 2020),

there is not much research that considers the

possibility of shifting the classification paradigm in

highly imbalanced data settings to one of anomaly

detection, or improving it with the aid of anomaly

detection outcomes. The latter approach, especially

useful in the presence of labeled data, uses the

outcomes of unsupervised anomaly detector models -

called anomaly scores- as features to be added to the

labeled training data in a subsequent binary

classification stage, to try to improve the predictive

performance of the classifier. This method has a

recent implementation in the semi-supervised

XGBOD algorithm (Zhao & Hryniewicki, 2018) and

is the subject of this paper.

In this paper we therefore investigate the

following research questions:

 Is a semi-supervised anomaly detection

method a feasible approach for early detection

of academically at-risk students?

 How does this approach compare to stand-

alone classification methods?

The paper makes two main contributions: 1) it

describes a methodology for implementing a two-

stage semi-supervised anomaly detection algorithm

in for early alert of small populations of struggling

students, where an ensemble of unsupervised

anomaly detection algorithms feeds a subsequent

binary classifier; 2) it empirically compares the

predictive performance of this approach with those of

well-established and state of the art classification

algorithms.

We begin with a brief review of the extant

literature on anomaly detection, its applications and

algorithms, focusing on unsupervised anomaly

detection methods currently in use. Then we explain

the semi-supervised methodology we chose to apply

anomaly detection in our specific domain. We follow

with a description of the experimental setup,

including details of the input data, and the algorithms

used in each of the different experiments. We present

and discuss the experiments’ results. Finally, we close

the paper with comments on the limitations of the

research and our conclusions.

2 ANOMALY DETECTION:

ALGORITHMS AND

APPLICATIONS

Anomaly detection has proven to be especially useful

in a broad range of applications, including fraud

detection, intrusion detection, fault detection, and

identification of rare diseases in medical data.

Outstanding values in credit card transactions may

help analysts detect credit card fraud (Sharmila et al.,

2019). Anomalous traffic patterns in network data can

help identify malicious attacks (García-Teodoro et

al., 2009). And the automated analysis of medical

images using outlier detection techniques can help

detect brain tumors (Wang et al., 2020).

As mentioned before, an anomaly or outlier is an

observation that strongly deviates from the normal

expectation. This means that an anomaly detection

method should identify a decision function that

separates normal from anomalous. But the task is

challenging for several reasons: (i) the boundary

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration

between normal and abnormal may not be clear cut;

(ii) the notion and magnitude of an anomaly may be

domain specific; (iii) data may be noisy; (iv) labeled

data for training and validation purposes is usually

scarce.

Numerous anomaly detection algorithms have

been developed, drawn from traditional statistics,

machine learning and lately deep learning. Their

formulation is determined by the problem domain, the

characteristics of the data (structured / unstructured),

and availability of labeled data. It is not the purpose

if this paper to provide a survey of anomaly detection

methods, we refer the audience to (Chandola et al.,

2009). In this paper we will focus on a set of

unsupervised algorithms (unsupervised anomaly

detection is the most common approach as it does not

require labeled training data) and XGBOD as a semi-

supervised technique. The anomaly detection

algorithms considered, given the structured nature

and limited dimensionality of the data are the

following:

 K-nearest neighbors, (Knorr et al., 2000),

referred to as KNN, a distance-based method,

and closely related to the classifier of the same

name. This family of methods assumes that

normal observations occur close to each other

whereas anomalies occur far away from their

closest neighbors.

 Isolation Forest (Liu et al., 2008) uses

recursive partitioning to create a tree structure

to isolate anomalous data points -anomalies

are easier to isolate and therefore have shorter

tree path length. The process is repeated over

multiple random trees and an average path

length is computed, which is used as the

outlier detector decision function.

 Local Outlier Factor, or LOF (Breunig et al.,

2000) computes a score (called local outlier

factor) that measures the local deviation of the

data point with respect to the surrounding

neighborhood, and with it its degree of

anomaly.

 One-class SVM (Schölkopf et al., 2001) is an

unsupervised extension of support vector

machines that learns from a dataset containing

data of only one class, and with it is able to

identify anomalous data (outliers).

Unsupervised anomaly detection algorithms are

sensitive to noise. Therefore combining them in an

ensemble typically provides more stable results, an

approach that follows the well-established ensemble

methodology in supervised learning (Lauría et al.,

2018; Zimek et al., 2014). The idea of extracting

representations from the data through anomaly

detection and inserting them as features in a

classification setting was introduced by (Micenková

et al., 2014) and (Aggarwal & Sathe, 2015). The

XGBOD algorithm (Zhao & Hryniewicki, 2018)

follows this same approach and derives its name from

its use of the state of the art XGBoost classifier (Chen

& Guestrin, 2016) in its second stage. In this paper

we use XGBoost, but we also implement Random

Forests (Breiman, 2001) and logistic regression as

alternative second-stage classifiers with the purpose

of widening the analysis of the predictive

performance of this semi-supervised ensemble

technique. We also consider different ways of

combining multiple anomaly scores: averaging,

maximization, straight forward use of all anomaly

scores or feature selection (for details of the algorithm

see section 3).

3 SEMI-SUPERVISED METHOD

We implement a two stage semi-supervised approach

to train the models, with a first stage made up of an

ensemble of anomaly detectors and a second stage

given by a binary classifier.

In training mode: (see Figure 1)

 In Step(i) k anomaly detection algorithms

...

AAare applied on training dataset

trn

and learn anomaly scores and decision

functions algorithms

11 ,

, ...

cdf scdf

 In Step(ii) anomaly scores are chosen using

some criterion

( .. )

csc



: all scores, the

average of the scores, the best anomaly score,

or a feature selection of anomaly scores. In the

original XGBOD paper, the selection of

anomaly scores is made by using a metric that

balances the accuracy and diversity of the

ensemble of anomaly detectors See (Zhao &

Hryniewicki, 2018) for details.

 In Step(ii), data set

trn

D is supplemented with

the selected anomaly scores

( .. )

csc



resulting in

()

[;( .. );]

aug

trn k

sc sc y



D .

 Step(iii) Training Classifier: use data set

()

[;( .. );]

aug

trn k

sc sc y



D as input data to

train model

M using classifier C .

CSEDU 2021 - 13th International Conference on Computer Supported Education

(i) Train Outlier Detectors

Train

[ ; ] ... [ ; ]

trn trn trn k

Xy Xy 





DD AD A

11 ,

ii) Choose anomaly scores

all

mean

Apply where

max

select

( .. )

( .. ),

( ..

( .. )

, ...

.. :

( .. ),

sc sc

cdf scdf

sc sc



















()

() ()

iii) Augment

(iv) Train Classifier

Train (2nd Stage)

[ ; ] [ ; ( .. ); ]

[;( .. );]

trn

aug

trn trn k

aug aug

trn trn k

Xy X sc sc y

Xscscy











 

DD C



 

Figure 1: Training mode.

In prediction mode:

 In Step(i), decision functions

...

df df are

applied on data set

tst

D to compute predicted

scores

psc psc

 In Step(ii) predicted anomaly scores are

chosen using the same criterion

( .. )

psc psc



used during training mode.

 In Step(iii), data set

tst

D is supplemented with

predicted anomaly scores

( .. )

psc psc



resulting in

()

[;( .. );]

aug

tst k

psc psc y



D .

 Step(iv) In it, binary classification model

is applied on data set

()aug

tst

D to make

predictions. The classifier reports predictions

and probability of predictions

( ; )

tst tst

yprob.

4 EXPERIMENT SETUP

In the experiments we investigated whether the semi-

supervised ensemble approach described in section 3

(i) Predict with anomaly detector decision functions

Predict

[ ; ] ... [ ; ]

tst tst trn k

ydf Xy df

 





DD D

()

ii) Choose anomaly scores Apply

iii) Augment

...

.. : ( .. )

[ ; ] [ ; ..

tst

aug

tst tst

sc psc

csc scsc

Xy Xpsc psc













() ()

(iv) Predict with classifier

Predict (2nd Stage)

;]

[ ; .. ; ]

aug aug

tst tst k

Xpsc psc y













DD M

( ; )

tst tst

proby

Figure 2: Prediction mode.

when compared to binary classifiers. The goal is to

learn from the data in order to detect early on in the

semester (6 weeks into a semester of 15 weeks) those

students that are struggling in their course.

4.1 Datasets

For the purpose of this study we used four semesters of

undergraduate 15-week courses, corresponding to Fall

2018, Spring 2019, Fall 2019 and Fall 2020, enriched

with student academic data, some demographics and

course activity metrics collected from the LMS logs.

Data was extracted from four sources: (i) student

demographic and aptitude data; (ii) course related data

and students’ final grades in those courses; c) student

activity data logged by the LMS, corresponding to the

first six weeks of each semester; (iv) a composite score

aggregating grades on assignments, projects, exams

and any other activities contributing to the student’s

final grade in the first six weeks of the semester, logged

by the LMS’s gradebook tool. Data was subsequently

transformed and cleaned into a complete unit of

analysis without missing values.

The LMS activity data (number of LMS logins,

number of access to LMS resources, and total activity

over all LMS tools) was aggregated weekly into

frequency values computed as ratios between the

student activity and the average class activity, to

account for potential variability among different

courses.

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration

Data was pre-processed and aggregated into a unit

of analysis -students’ data in each course over four

semesters. The binary label for each record in the unit

of analysis was computed by recoding the student’s

final grade in the course: those students with a final

letter grade C or more were considered in good

standing, whereas those students with less than a final

letter grade C were considered academically

vulnerable (at risk) students. Table 1 depicts the file

structure of the unit of analysis.

Table 1: File structure of the unit of analysis.

Predictors Data type

Enrolment Numeric

Online Categorical

e Numeric

GPA Numeric

titude Score

(

SAT/ACT

)

Numeric

Gende

Categorical

Class (Fresh, Soph, Jr, Sr) Categorical

LMS Total Activity (weeks 1-6) Numeric x 6

(

weeks 1-6 + sum

)

Numeric x 6

Content Read

(

weeks 1-6 + sum

)

Numeric x 6

Gradebook Composite Score (wks 1-6) Numeric

Target feature: Academic_Risk (1=at risk; 0=good

standin

The full unit of analysis contained data of all four

semesters (Fall 2018 – Spring 2020) with the following

proportions of good-standing and at-risk students (see

Table 2):

Table 2: Data per semester.

Semester Total

Coun

Percent at

ris

Fall 2018 10809 6.6%

Sprin

2019 14133 6.8%

Fall 2019 11089 6.1%

Sprin

2020 17206 3.0%

4.2 Methods

Each experiment was performed by randomly

selecting a semester and subsequently partitioning the

semester into training and testing data using an 80/20

ratio. We selected 30 randomly chosen (semester,

partition) pairs, creating 30 dataset pairs (training and

testing) to perform experiment runs, using 4 anomaly

detection methods with varying parameters, 3

selection criteria for anomaly scores (all, average,

max) and 3 binary classifiers. We also implemented a

feature selection criterion of the anomaly scores prior

to the XGBoost classifier as presented in the XGBOD

original paper.

Additionally, we trained all three classifiers with

balanced data for comparison purposes (see section

4.2.3). This amounted to a total of 16 experiments

repeated over 30 runs, for a total of 480 experiments

(for details see section 4.3 and Table 3).

4.2.1 Anomaly Detection Algorithms

Four detection algorithms were used in the experiment:

 KNN: K nearest Neighbours with mean,

median and largest distance to the kth

neighbour and with

k=[1,2,3,4,5,6,7,8,9,10,15, ..,100].

 LOF: Local Outlier Factor with k=[1,2,34,5,

6,7,8,9,10,15,..,100].

 IForest: Isolation Forest with number of base

estimators = [10, 30, 50, 70, 100, 150, 200,

250].

 OCSVM: One-class Support Vector Machines

with radial basis kernel and different upper

bound on the fraction of training errors.

A total of 115 anomaly scores were added to each

dataset.

4.2.2 Classifiers

We used three classification algorithms as second stage

classifiers:

 XGB: The XGBoost algorithm

 RF: Random Forests

 LOG: regularized logistic regression.

The XGBoost classifier (Chen & Guestrin, 2016),

a tree-based classification algorithm, is currently one

of the most powerful supervised methods and a

popular choice in Kaggle competitions.

The Random Forests algorithm (Breiman, 2001)

is a well-regarded ensemble learning technique that

builds multiple random CART trees and outputs the

most frequently predicted class.

Logistic regression is the workhorse of traditional

statistics and an effective classifier when dealing with

data that holds both numeric and binary data.

For both XGBoost and Random Forests we fixed

the number of estimators to 600. We did not perform

any further hyperparameter tuning, to reduce the

computational cost of the experiment.

4.2.3 Balanced Data

For comparison purposes, the three classifiers were

also trained with balanced data, after balancing the

proportions of good-standing and at-risk students, for

each of the 30 randomly generated datasets, The

CSEDU 2021 - 13th International Conference on Computer Supported Education

SMOTE algorithm (Bowyer et al., 2011) was used for

balancing the data. SMOTE (Synthetic Minority Over-

sampling Technique) is an oversampling method that

augments the minority class by synthesizing new

minority samples instead of using a simple duplication

of samples.

4.2.4 Computational Details

The models were coded in Python 3.7 using several

libraries. All the unsupervised anomaly detection

algorithms were implemented using the PyOD library

(Zhao et al., 2019). Although PyOD provides a turn-

key implementation of XGBOD, we decided to code

our own version of the algorithm to have better

control and add flexibility to the execution process,

including other second-stage classifiers besides

XGBoost, and different anomaly scores selection

criteria. For the classifiers we used the Scikit-learn

library (Pedregosa et al., 2011), including its API for

XGBoost. The experiments were run on an Intel Xeon

Silver server, 20 cores 3.00GHz, 2 threads per core,

32GB RAM, 1 GPU (Quadro P4000 8GB). Parallel

processing features were used when available for both

the first stage (anomaly detection) and second stage

(binary classification) algorithms to make use of the

multi-core platform and with it reduce the execution

time of the experiments.

4.2.5 Assessment

At prediction times the following predictive

performance metrics were collected:

 ROC_AUC: the AUC (area under the curve)

of the receiver operating characteristics

(ROC) curve, that plots TP rate vs FP rate, is

the most widely used metric to summarize

binary classification performance. Although it

is still the most popular metric in imbalanced

classification it has received criticism in the

case of highly imbalanced settings as it can be

overly optimistic due to unreliability of the

estimates under class rarity (Fernández et al.,

2018).

 PR_AUC: The AUC of the precision-recall

curve assesses the performance of the

classifier on the minority class and can

therefore be more informative of the algorithm

performance than the ROC AUC metric

(Davis & Goadrich, 2006).

 Training and Prediction execution time,

measured in seconds: this could be relevant,

particularly for prediction, as the large

ensemble of anomaly detectors can introduce

a considerable overhead.

Table 3: Predictive Performance Results.

ROC AUC PR AUC TRAIN TIME PREDICT TIME

Mean SE Mean SE Mean SE Mean SE

XGB 0.9511 0.0012 0.5990 0.0219 1.78 0.06 1.35 0.06

XGBOD 0.9502 0.0012 0.5946 0.0229 320.96 21.77 99.35 14.42

ALL_XGB 0.9508 0.0012 0.5959 0.0217 320.31 26.51 99.27 7.78

AVG

XGB 0.9514 0.0012 0.5998 0.0217 322.71 18.00 102.14 12.22

BEST_XGB 0.9510 0.0012 0.5984 0.0219 315.24 21.47 95.19 11.06

SMOTE_XGB 0.9430 0.0014 0.5346 0.0267 2.73 0.12 2.73 0.12

RF 0.9433 0.0017 0.5914 0.0198 3.58 0.02 3.58 0.02

ALL_RF 0.9246 0.0022 0.5523 0.0205 318.25 31.36 105.84 9.44

AVG_RF 0.9435 0.0017 0.5912 0.0202 319.51 29.13 114.39 8.91

BEST

RF 0.9433 0.0017 0.5918 0.0200 329.42 26.86 99.18 11.12

SMOTE_RF 0.9426 0.0014 0.4900 0.0209 4.48 0.07 4.48 0.07

LOG 0.9261 0.0028 0.5178 0.0206 1.12 0.02 1.12 0.02

ALL

LOG 0.8513 0.0075 0.3007 0.0162 315.98 24.03 105.44 11.09

AVG_LOG 0.8861 0.0075 0.3866 0.0213 314.58 26.37 96.24 8.56

BEST_LOG 0.9023 0.0063 0.4501 0.0224 312.50 25.41 103.46 9.34

SMOTE

LOG 0.9343 0.0019 0.5535 0.0211 1.93 0.03 1.18 0.03

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration

4.3 Results and Discussion

Table 3 displays the assessment of mean predictive

performance of the different configurations of the

semi-supervised approach considered (second stage

trained by adding all anomaly scores, by adding the

average anomaly score, by adding only the maximum

anomaly score, and by using the feature selection

criterion on the anomaly scores described in the

XGBOD paper), as well as the mean predictive

performance of the stand-alone classifiers trained

with both the original training data, and after

balancing the training data:

 XGB, RF, LOG: no anomaly detection scores

used by second stage classifier (stand-alone

classifier, original training data)

 ALL_XGB, ALL_RF, ALL_LOG: all

anomaly detection scores were used by the

second stage classifier.

 AVG_XGB, AVG_RF, AVG_LOG: the

average anomaly detection score was used by

the second stage classifier.

 BEST_XGB, BEST_RF, BEST_LOG: the

maximum anomaly detection score was used

by the second stage classifier.

 XGBOD: the XGBOD algorithm with

anomaly score feature selection as proposed

by (Zhao & Hryniewicki, 2018).

 SMOTE_XGB, SMOTE_RF, SMOTE_LOG:

stand-alone classifiers trained after balancing

the original training data (as described in

section 4.2.3).

For the XGBoost algorithm, adding the average

anomaly score slightly improved both ROC_AUC

and ROC_PR: ROC_AUC for AVG_XGB was

0.9514 and PR_AUC was 0.5998, compared to

ROC_AUC=0.9511 and PR_AUC=0.5990 for the

XGBoost stand-alone classifier, trained without

anomaly scores. The other approaches (XGBOD,

ALL_XGB, BEST_XGB) degraded the performance

instead of improving it. All algorithms performed

better in both metrics than the balanced alternative

(SMOTE_XGB). Random Forests had mixed results:

AVG_RF performed slightly better only for

ROC_AUC (0.935 vs 0.9433), but the rest of the

approaches had either the same or worse performance

metrics than RF. All classifiers performed better than

the balanced alternative (SMOTE_RF), except

ALL_RF for the ROC_AUC metric.

We ran the Wilcoxon signed test for both

XGBoost and Random Forests comparing the metrics

of the classifier trained without anomaly scores with

each of the different methods for choosing anomaly

scores, and the tests were not strong enough to

identify significant differences (p>0.4 in all cases).

There were though significant differences in all cases

(p<0.001) between all unbalanced configurations and

the balanced configurations for both XGBoost and

Random Forests (SMOTE).

For logistic regression, the addition of anomaly

scores to the training data generally degraded the

performance metrics. The balanced data approach

also outperformed all other approaches, including

training the model without anomaly scores:

ROC_AUC was 0.9343 for SMOTE_LOG compared

to 0.9261 for LOG. And PR_AUC was 0.5535

compared to 0.5178 for LOG.

Execution time exposes the overhead of running

115 unsupervised anomaly detectors on the data

before training the classifier or using it for prediction.

Table 3 shows that it took about 3 seconds per outlier

detector in training mode and a little less than a

second per outlier detector in predict mode. Instead,

the execution time of the binary classifiers was

negligible in comparison. Training time is not an

actual issue given that training does not typically

happen in real time; but larger execution times in

prediction mode could pose a problem. This is of

course a relatively minor issue as it is dependent on

the hardware platform used to train and implement

the prediction models, but is worth mentioning when

comparing the anomaly detection approach with

binary classification approaches, which do not require

the computation of added anomaly scores.

5 CONCLUDING COMMENTS

In summary, the anomaly detection models did not

seem to be able to learn representations that

efficiently contribute to the second-stage classifiers.

It is a reasonable assumption that the effectiveness of

the semi-supervised approach could be dependent on

the domain in which it is applied. Anomalies are rare

events by definition, but a small proportion of at-risk

students may not necessarily qualify as a set of

anomalies; the difference between good-standing and

struggling students may not be big enough and

therefore those struggling students may not

necessarily qualify as outliers, the patterns of

academic struggle being subtler, which in turn would

require more fine tuning of the thresholds that

determine anomaly scores.

The current research has several limitations. We

did not perform any hyperparameter tuning of the

classifiers to limit the execution time of the

experiments (XGBoost and Random Forest, would

CSEDU 2021 - 13th International Conference on Computer Supported Education

have benefitted from performance tuning). Also, the

study imposed four unsupervised outlier detection

algorithms. They are among the most relevant

algorithms for the type of data considered, and we did

vary their parameters to produce multiple anomaly

outcomes, but still, the choice was limited. Other

algorithms could also be included to increase the

variety of the outlier detectors. Subsampling could be

applied to the data used to train the anomaly detection

algorithms as proposed by (Aggarwal & Sathe, 2015).

And anomaly scores resulting from the anomaly

detection algorithms could be subjected to

dimensionality reduction, consequently inducing

features to be used by the second-stage classifier,

rather than directly adding the anomaly scores as new

features.

The objective of the study is exploratory and has

the purpose of exemplifying the approach applied to

early detection of small populations of students at risk

and providing a proof of concept, as well as

empirically testing its performance. The results are

non-conclusive as to the benefits of this approach, but

nonetheless, the study is an initial application of the

use of a semi-supervised framework int this domain

that combines anomaly detection and binary

classification.

Hopefully, this paper will open a research avenue

for other researchers and practitioners towards new

methods in early detection of academically at-risk

students using machine learning techniques.

ACKNOWLEDGEMENTS

The author would like to thank Ed Presutti and the

rest of the Data Science & Analytics team at Marist

College for their continuous collaboration. Maria

Kapogiannis provided and double checked the

datasets used in the experiments.

REFERENCES

Aggarwal, C. C., & Sathe, S. (2015). Theoretical

Foundations and Algorithms for Outlier Ensembles.

SIGKDD Explor. Newsl., 17(1), 24–47.

Arnold, K. E., & Pistilli, M. D. (2012). Course signals at

Purdue: Using learning analytics to increase student

success. Proceedings of the 2nd International

Conference on Learning Analytics and Knowledge.

Benablo, C. I. P., Sarte, E. T., Dormido, J. M. D., &

Palaoag, T. (2018). Higher Education Student’s

Academic Performance Analysis through Predictive

Analytics. Proceedings of the 2018 7th International

Conference on Software and Computer Applications,

238–242. https://doi.org/10.1145/3185089.3185102

Bowyer, K. W., Chawla, N. V., Hall, L. O., & Kegelmeyer,

W. P. (2011). SMOTE: Synthetic Minority Over-

sampling Technique. CoRR, abs/1106.1813.

Breiman, L. (2001). Random Forests. Mach. Learn., 45(1),

5–32.

Breunig, M. M., Kriegel, H.-P., Ng, R. T., & Sander, J.

(2000). LOF: Identifying Density-Based Local

Outliers. Proceedings of the 2000 ACM SIGMOD

International Conference on Management of Data, 93–

104. https://doi.org/10.1145/342009.335388

Calvo-Flores, M. D., Galindo, E. G., & Jiménez, M. P.

(2006). Predicting students’ marks from Moodle logs

using neural network models.

Campbell, J. P. (2007). Utilizing student data within the

course management system to determine undergraduate

student academic success: An exploratory study (UMI

No. 3287222) [Doctoral Dissertation]. Doctoral

Dissertation, Purdue University.

Cardona, T. A., & Cudney, E. a. (2019). Predicting Student

Retention Using Support Vector Machines. 25th

International Conference on Production Research

Manufacturing Innovation: Cyber Physical

Manufacturing August 9-14, 2019 | Chicago, Illinois

(USA), 39, 1827–1833.

Chandola, V., Banerjee, A., & Kumar, V. (2009). Anomaly

Detection: A Survey. ACM Comput. Surv., 41(3).

Chen, T., & Guestrin, C. (2016). XGBoost: A Scalable Tree

Boosting System. CoRR, abs/1603.02754.

http://arxiv.org/abs/1603.02754

Davis, J., & Goadrich, M. (2006). The Relationship

between Precision-Recall and ROC Curves.

Proceedings of the 23rd International Conference on

Machine Learning, 233–240.

Dodge, B., Whitmer, J., & Frazee, J. P. (2015). Improving

undergraduate student achievement in large blended

courses through data-driven interventions. Proceedings

of the Fifth International Conference on Learning

Analytics And Knowledge.

Fernández, A., García, S., Galar, M., Prati, R. C.,

Krawczyk, B., & Herrera, F. (2018). Learning from

imbalanced data sets. Springer.

García-Teodoro, P., Díaz-Verdejo, J., Maciá-Fernández,

G., & Vázquez, E. (2009). Anomaly-based network

intrusion detection: Techniques, systems and

challenges. Computers & Security, 28(1), 18–28.

Guleria, P., Thakur, N., & Sood, M. (2014). Predicting

student performance using decision tree classifiers and

information gain. 2014 International Conference on

Parallel, Distributed and Grid Computing, 126–129.

Hamedi, A., & Dirin, A. (2018). A Bayesian approach in

students’ performance analysis.

Harackiewicz, J. M., & Priniski, S. J. (2018). Improving

Student Outcomes in Higher Education: The Science of

Targeted Intervention. Annual Review of Psychology,

69, 409–435. PubMed.

He, H., & Garcia, E. A. (2009). Learning from Imbalanced

Data. IEEE Transactions on Knowledge and Data

Engineering, 21(9), 1263–1284.

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration

Herodotou, C., Rienties, B., Boroowa, A., Zdrahal, Z., &

Hlosta, M. (2019). A large-scale implementation of

predictive learning analytics in higher education: The

teachers’ role and perspective. Educational Technology

Research and Development, 67(5), 1273–1306.

https://doi.org/10.1007/s11423-019-09685-0

Hu, T., & Song, T. (2019). Research on XGboost academic

forecasting and analysis modelling. Journal of Physics:

Conference Series, 1324, 012091.

Jayaprakash, S. M., Moody, E. W., Lauría, E. J. M., Regan,

J. R., & Baron, J. D. (2014). Early Alert of

Academically At-Risk Students: An Open Source

Analytics Initiative. Journal of Learning Analytics,

1(1), 42.

Knorr, E. M., Ng, R. T., & Tucakov, V. (2000). Distance-

Based Outliers: Algorithms and Applications.

Kong, J., Kowalczyk, W., Menzel, S., & Bäck, T. (2020).

Improving Imbalanced Classification by Anomaly

Detection. In T. Bäck, M. Preuss, A. Deutz, H. Wang,

C. Doerr, M. Emmerich, & H. Trautmann (Eds.),

Parallel Problem Solving from Nature (PPSN XVI) (pp.

512–523). Springer International Publishing.

Lauría, E. J. M., & Baron, J. (2011). Mining Sakai to

Measure Student Performance: Opportunities and

Challenges in Academic Analytics. ECC 2011.

Lauría, E. J. M., Moody, E. W., Jayaprakash, S. M.,

Jonnalagadda, N., & Baron, J., D. (2013). Open

academic analytics initiative: Initial research findings.

Proceedings of the Third International Conference on

Learning Analytics and Knowledge.

Lauría, E. J. M., Presutti, E., & Kapogiannis, M. (2019,

June). Of Stacks and Muses: Adventures in Learning

Analytics at Marist College. LatinX in AI Research at

ICML 2019. https://hal.archives-ouvertes.fr/hal-

02265832

Lauría, E. J. M., Presutti, E., Kapogiannis, M., & Kamath,

A. (2018). Stacking Classifiers for Early Detection of

Students at Risk. Proceedings of the 10th International

Conference on Computer Supported Education -

Volume 2: CSEDU 2018, 390–397.

Lauría, E. J. M., Presutti, E., Sokoloff, M., & Guarino, M.

(2016). Crossing the Chasm to Big Data: Early

Detection of at-Risk Students in a Cluster Computing

Environment. Proceedings of the 7th International

Learning Analytics & Knowledge Conference

(LAK’17)- Practitioner Track . Vancouver, Canada.

Liu, F. T., Ting, K. M., & Zhou, Z.-H. (2008). Isolation

Forest. Proceedings of the 2008 Eighth IEEE

International Conference on Data Mining, 413–422.

Martins, M. P. G., Miguéis, V. L., Fonseca, D. S. B., &

Alves, A. (2019). A Data Mining Approach for

Predicting Academic Success – A Case Study. In Á.

Rocha, C. Ferrás, & M. Paredes (Eds.), Information

Technology and Systems (pp. 45–56). Springer

International Publishing.

Micenková, B., Mcwilliams, B., & Assent, I. (2014).

Learning Outlier Ensembles: The Best of Both Worlds

– Supervised and Unsupervised. 1–4.

Okubo, F., Yamashita, T., Shimada, A., & Ogata, H.

(2017). A neural network approach for students’

performance prediction. Proceedings of the Seventh

International Learning Analytics & Knowledge

Conference.

Pang, Y., Judd, N., O’Brien, J., & Ben-Avie, M. (2017).

Predicting students’ graduation outcomes through

support vector machines. 2017 IEEE Frontiers in

Education Conference (FIE), 1–8.

Pedregosa, F., Varoquaux, G., Gramfort, A., Michel, V.,

Thirion, B., Grisel, O., Blondel, M., Prettenhofer, P.,

Weiss, R., Dubourg, V., Vanderplas, J., Passos, A.,

Cournapeau, D., Brucher, M., Perrot, M., & Duchesnay,

E. (2011). Scikit-learn: Machine Learning in Python.

Journal of Machine Learning Research, 12, 2825–2830.

Provost, F. (n.d.). Machine Learning from Imbalanced Data

Sets 101 (Extended Abstract).

Romero, C., López, M.-I., Luna, J.-M., & Ventura, S.

(2013). Predicting students’ final performance from

participation in on-line discussion forums. Computers

& Education, 68, 458–472.

Schölkopf, B., Platt, J. C., Shawe-Taylor, J., Smola, A. J.,

& Williamson, R. C. (2001). Estimating the support of

a high-dimensional distribution. Neural Computation,

13(7), 1443–1471.

Sharmila, V. C., R, K. K., R, S., D, S., & R, H. (2019).

Credit Card Fraud Detection Using Anomaly

Techniques. 2019 1st International Conference on

Innovations in Information and Communication

Technology (ICIICT), 1–6.

Sheshadri, A., Gitinabard, N., Lynch, C. F., Barnes, T., &

Heckman, S. (2019). Predicting Student Performance

Based on Online Study Habits: A Study of Blended

Courses. CoRR, abs/1904.07331.

Smith, V. C., Lange, A., & Huston, D. R. (2012). Predictive

Modeling to Forecast Student Outcomes and Drive

Effective Interventions in Online Community College

Courses. Journal of Asynchronous Learning Networks,

16(3), 51–61. eric.

Wang, N., Chen, C., Xie, Y., & Ma, L. (2020). Brain Tumor

Anomaly Detection via Latent Regularized Adversarial

Network.

Yao, H., Lian, D., Cao, Y., Wu, Y., & Zhou, T. (2019).

Predicting Academic Performance for College

Students: A Campus Behavior Perspective. ACM

Trans. Intell. Syst. Technol., 10(3).

https://doi.org/10.1145/3299087

Zafra, A., & Ventura, S. (2012). Multi-instance genetic

programming for predicting student performance in

web based educational environments. Applied Soft

Computing, 12(8), 2693–2706.

Zhao, Y., & Hryniewicki, M. K. (2018). XGBOD:

Improving Supervised Outlier Detection with

Unsupervised Representation Learning. 2018

International Joint Conference on Neural Networks

(IJCNN).

Zhao, Y., Nasrullah, Z., & Li, Z. (2019). PyOD: A Python

Toolbox for Scalable Outlier Detection. Journal of

Machine Learning Research, 20(96), 1–7.

Zimek, A., Campello, R. J. G. B., & Sander, J. (2014).

Ensembles for Unsupervised Outlier Detection:

CSEDU 2021 - 13th International Conference on Computer Supported Education

Challenges and Research Questions a Position Paper.

SIGKDD Explor. Newsl., 15(1), 11–22.

Framing Early Alert of Struggling Students as an Anomaly Detection Problem: An Exploration
