From Serverful to Serverless: A Spectrum of Patterns for Hosting

Application Components

Vladimir Yussupov

, Jacopo Soldani

, Uwe Breitenb

ucher

, Antonio Brogi

and Frank Leymann

Institute of Architecture of Application Systems, University of Stuttgart, Germany

Department of Computer Science, University of Pisa, Italy

Keywords:

Application Deployment, Hosting, Patterns, Serverful, Serverless, Cloud Computing.

Abstract:

The diversity of available cloud service models yields multiple hosting variants for application components.

Moreover, the overall trend of reducing control over the infrastructure and scaling conﬁguration makes it non-

trivial to decide which hosting variant suits more a certain software component. In this work, we introduce

a spectrum of component hosting patterns that covers various combinations of management responsibilities

related to (i) the deployment stack required by a given component as well as (ii) required infrastructure re-

sources and component’s scaling rules. We validate the presented patterns by identifying and showing at least

three real world occurrences of each pattern following the well-known Rule of Three.

1 INTRODUCTION

A plethora of available cloud service models en-

ables building cloud applications using components

hosted on various targets that require different man-

agement efforts. For example, cloud consumers can

control lower-level infrastructure layers when hosting

components using Infrastructure-as-a-Service (IaaS).

Another option is to simply select an appropriate

runtime when hosting components on Platform-as-a-

Service (PaaS) or Function-as-a-Service (FaaS). In-

between, Container-as-a-Service (CaaS) offerings fa-

cilitate hosting containerized components.

Such a diversity of hosting options allows ﬂexibly

outsourcing management responsibilities, e.g., host-

ing certain components on provider-managed offer-

ings to minimize management efforts. Further extend-

ing this idea, the serverless computing paradigm (Bal-

dini et al., 2017) focuses on developing applications

comprising provider-managed components. The term

serverless emphasizes a weaker role of processing,

storage, and network resources for cloud consumers,

as providers manage the underlying infrastructure,

e.g., a FaaS platform and components it depends on.

Serverless computing differs from its serverful coun-

terpart in several aspects, namely (i) decoupling of

computation and storage, (ii) code is executed with-

out requiring consumers to allocate resources, and

(iii) ﬁner-grained pricing which focuses on the re-

sources actually consumed (Jonas et al., 2019).

As a result, cloud consumers need to choose from

component hosting variants with different manage-

ment responsibilities. Typical questions that arise are

“How to host a component requiring custom runtime

and scaling rules?”, or “How to host a periodically-

invoked code snippet?”. Unfortunately, currently

there exist no well-structured guidelines for deciding

on component hosting options. One instrument that

can help in such cases is a pattern, since it describes

a proven and abstract solution to a speciﬁc and fre-

quently reoccurring problem (Alexander, 1977). Mul-

tiple pattern languages group solutions for certain do-

mains, e.g., cloud computing (Fehling et al., 2014a),

or enterprise integration patterns (Hohpe and Woolf,

2004). Hence, hosting-speciﬁc patterns could help

making informed decisions about component hosting.

In this work, we introduce component hosting pat-

terns which describe proven solutions for hosting ap-

plication components. They cover different combi-

nations of management responsibilities related to two

aspects: (i) deployment stack and (ii) scaling conﬁg-

uration management. Here, the former describes to

what extent cloud consumers can manage the under-

lying infrastructure and required software dependen-

cies, whereas the latter is related to who is responsi-

ble for allocating infrastructure resources and deﬁn-

ing scaling rules. Furthermore, we show how these

patterns form a spectrum of hosting options, rang-

ing from mainly consumer-managed, “serverful” to

mainly provider-managed, “serverless” variant.

268

Yussupov, V., Soldani, J., Breitenbücher, U., Brogi, A. and Leymann, F.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components.

DOI: 10.5220/0010481002680279

In Proceedings of the 11th International Conference on Cloud Computing and Services Science (CLOSER 2021), pages 268-279

ISBN: 978-989-758-510-4

2 PATTERN PRIMITIVES

In this section, we introduce the pattern primitives re-

lated to the domain of application deployment.

Application. An application is a collection of soft-

ware components interacting with each other and ex-

ternal clients to provide a certain business function-

ality (Lau and Wang, 2007). Software components

are typically installed and run on a speciﬁc infras-

tructure including processing, storage, and network

resources (Messerschmitt, 2007). Depending on the

chosen architectural style, software components can

be coupled differently, e.g., remote procedure calls or

messaging-based integration, which also inﬂuences to

what extent the infrastructure can be shared among

software components of the application.

Software Component. A software component is an

application building block implementing functionali-

ties required by an application (Councill and Heine-

man, 2001; Lau and Wang, 2007). Depending on

their purpose, software components can be general-

purpose or application-speciﬁc. General-purpose

components provide functionalities not speciﬁc to a

given application, e.g., a web server or a message-

oriented middleware. Application-speciﬁc compo-

nents implement part of the application’s business

logic, e.g., a Java-based e-commerce component.

Deployment Artifact. A deployment artifact is a

software component packaged in a format required

by a chosen deployment stack (OASIS, 2015). Exam-

ples of deployment artifacts are Docker container im-

ages packaging software components to host them on

the Docker Engine, or packaging Java applications as

Java Web application ARchives (WARs) to host them

on application servers like JBoss.

Deployment Stack. A deployment stack is a valid

combination of software components and infrastruc-

ture components (i.e., processing, storage, and net-

work resources) that allows hosting a given deploy-

ment artifact. It is important to note that the same

deployment artifact can be hosted on different de-

ployment stacks. For example, a deployment arti-

fact of type “Java ARchive” (JAR) can be hosted

on a FaaS platform by selecting a suitable Java run-

time, or by manually installing the Java runtime on

a virtual machine provisioned using IaaS offerings.

Figure 1 shows three valid deployment stacks for

JAR ﬁles using service offerings from Amazon. The

Stack #1 relies on AWS EC2, Amazon’s IaaS offer-

ing, which allows cloud consumers to customize the

deployment stack by installing any software compo-

nents on the chosen virtual machine. Stack #2 shifts

some management responsibilities to the provider,

since the underlying container engine is provider-

JRE 8

Ubuntu Linux

AWS EC2

Component.JAR (Deployment Artifact)

Stack #1

Container

AWS ECS

Stack #2

JRE 8

AWS

Lambda

Stack #3

JRE 8

Alpine Linux

Figure 1: Different stacks for hosting a JAR on Amazon.

managed. However, cloud consumers are still able

to customize the runtime environment by installing

necessary software components as a part of the con-

tainer. Finally, Stack #3 is managed mainly by Ama-

zon, since cloud consumers only select a compati-

ble provider-deﬁned deployment stack, i.e., enabling

Java8 in this case. Since deployment stacks might

comprise provider-managed or consumer-managed

components, the management efforts needed for the

same deployment artifact differ depending on the cho-

sen deployment stack. Furthermore, a scaling conﬁg-

uration for a given component that deﬁnes infrastruc-

ture resources and scaling rules needs to be managed

too – either by cloud consumers or cloud providers.

Consumer-managed Component. A component in

deployment stack is consumer-managed if cloud con-

sumers, e.g., application developers or operators, are

responsible for managing it, e.g., installation, conﬁg-

uration, and dependency management. For example,

in the Stack #2 from Figure 1, a Java runtime is in-

stalled as a part of a container image hosted on AWS

ECS: while the underlying container engine is man-

aged by the provider, the Java runtime is installed

and conﬁgured by the cloud consumer. Similarly, if

an operating system is consumer-managed as in the

Stack #1 in Figure 1, cloud consumers are respon-

sible for installing and conﬁguring software compo-

nents hosted on it, e.g., a NoSQL database.

Provider-managed Component. A provider-

managed stack component is managed by providers.

For example, a Java runtime selected in PaaS and

FaaS offerings is provider-managed since the provider

is responsible for installing and conﬁguring the de-

ployment stack required to run this runtime.

Scaling Conﬁguration. A scaling conﬁguration is a

combination of component’s scaling rules, e.g., hor-

izontal vs. vertical scaling, and the amount of in-

frastructure resources that is required for hosting a

given software component. As mentioned previously,

a scaling conﬁguration can be consumer-managed or

provider-managed. For example, in the Stack #1

cloud consumers need to deﬁne the size of a virtual

machine and the corresponding scaling rules, whereas

in the Stack #3 the provider is responsible for allocat-

ing resources and scaling hosted functions.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

269

3 APPLICATION COMPONENT

HOSTING PATTERNS

In this section, we introduce the application compo-

nent hosting patterns. Before discussing each pat-

tern, we describe how patterns are aligned with each

other, forming a spectrum of different hosting vari-

ants. Next, we describe how patterns are structured,

and provide the in-detail deﬁnitions for each pattern.

3.1 A Spectrum of Hosting Patterns

Depending on the chosen cloud offering, both cloud

providers and cloud consumers can be responsible

for managing the underlying deployment stack, e.g.,

cloud consumers have more deployment stack man-

agement responsibilities when using IaaS in compar-

ison with PaaS or FaaS. Moreover, the cloud offer-

ing choice also deﬁnes who manages the scaling con-

ﬁguration, e.g., providers are responsible for allocat-

ing infrastructure resources and scaling component

instances in FaaS and certain CaaS offerings. Figure 2

shows a spectrum of component hosting patterns cov-

ering combinations of deployment stack and scaling

conﬁguration management responsibilities. To mark

the spectrum’s extremes, we use the terms server-

ful and serverless which emphasize the stronger or

weaker role of processing, storage, and network re-

sources for cloud consumers, respectively.

The most consumer-managed hosting option

in Figure 2 is the Serverful Hosting Pattern (see Sec-

tion 3.3) as it enables consumers to have full con-

trol over the deployment stack and scaling conﬁgu-

ration including provisioning the desired infrastruc-

ture, installing software components, and deﬁning

component’s scaling rules. A more simpliﬁed option

is the Consumer-managed Container Hosting Pat-

tern (see Section 3.4) in which the deployment stack

required for running containers needs to be man-

aged to a lesser extent, e.g., provider-managed con-

tainer orchestrators which require scaling conﬁgura-

tion to deﬁne infrastructure needed for running con-

tainers. Since container images serve as deployment

artifacts, consumers can customize software compo-

nents in such deployment stacks.

The next three patterns are more related to

serverless-style component hosting as they are

provider-managed in at least one of the aforemen-

tioned aspects. In the Provider-deﬁned Stack Host-

ing Pattern (see Section 3.5), a deployment stack

is provider-managed, but consumers need to man-

age the scaling conﬁguration, e.g., Database-as-a-

Service or PaaS offerings that require deﬁning in-

frastructure resources for respective software compo-

Scaling

Configuration

Management

Responsibilities

Deployment Stack Management

Responsibilities

Serverful

Hosting

Pattern

Serverless

Hosting

Pattern

Cloud

Provider

Cloud

Consumer

Cloud

Provider

Provider-defined

Stack Hosting

Pattern

Consumer-managed

Container

Hosting Pattern

Provider-managed

Container

Hosting Pattern

Figure 2: A spectrum of component hosting patterns cover-

ing different combinations of deployment stack and scaling

conﬁguration management responsibilities.

nents. In the Provider-managed Container Hosting

Pattern (see Section 3.6), consumers no longer man-

age scaling conﬁguration, i.e., providers allocate in-

frastructure resources required for running contain-

ers. Deployment stack management is also reduced:

consumers can only modify the runtime environment

via custom container images. Finally, the Server-

less Hosting Pattern (see Section 3.7) apart from

the provider-managed deployment stack also reduces

the management overhead for scaling conﬁguration,

since providers are responsible for it, e.g., code snip-

pets hosted using Function-as-a-Service (FaaS).

3.2 Patterns Structure

The patterns presented in the next subsections are

structured following the best practices employed

by researchers and practitioners (Alexander, 1977;

Buschmann et al., 2007; Coplien, 1996; Gamma et al.,

1995; Fehling et al., 2014a; Wellhausen and Fiesser,

2011; Richardson, 2018; Endres et al., 2017). Each

component hosting pattern has a name and a catchy

icon to simplify memorability. The problem and con-

text are described in the eponymous paragraphs. In-

ﬂuencing factors that characterize the problem are de-

scribed in the forces paragraph. The solution para-

graph describes a possible solution with a solution

sketch, and the example paragraph discusses a simple

example of this pattern implementation using a ToDo

list application in which a Java application stores and

modiﬁes to-do items in a NoSQL database. The re-

sult paragraph discusses the resulting context after

the pattern is applied, and the known uses paragraph

presents at least three real-world occurrences of the

pattern implementation to demonstrate that the Rule

of Three (Coplien, 1996) holds, hence, making the

introduced pattern valid.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

270

3.3 Serverful Hosting Pattern

Problem: How to host a software

component while retaining control

over all deployment stack components

and the scaling conﬁguration?

Context. A software component needs to be hosted

on a custom deployment stack with possibly nested

software layers such that the cloud consumer is able to

deﬁne the infrastructure resources and scaling rules.

Forces. To choose the right deployment stack for a

software component, cloud consumers need to under-

stand the advantages and drawbacks of cloud service

models and the corresponding management efforts.

Other factors such as the chosen architectural style

also affect the suitability of deployment stacks, e.g.,

hosting a monolith with many custom requirements

vs. hosting a ﬁne-grained microservice.

Solution. Host software components on a deploy-

ment stack primarily managed by cloud consumers

which enables hosting all required components, e.g.,

an operating system and a web server on top of it.

Hence, for a given deployment artifact type, the cloud

consumer is responsible for installing an appropriate

operating system and runtime environment. The cho-

sen operating system either runs on a virtual machine,

e.g., using IaaS offerings, or on a physical server, e.g.,

on premises or using bare metal cloud offerings. A

solution sketch in Figure 3 shows a software compo-

nent hosted on a deployment stack in which the cloud

consumer is responsible for hosting the infrastruc-

ture components and managing scaling conﬁguration.

Hence, in the presented solution sketch the user is re-

sponsible for keeping track of all components in the

stack to successfully complete the deployment, e.g.,

installing and running required dependencies.

Example. Figure 3 shows a simpliﬁed Java-based

ToDo list application that stores to-do items in a

NoSQL database hosted on the IaaS offering from

AWS. Most components in the chosen deployment

stack are managed by the cloud consumer. Another

deployment stack variant could use a bare metal cloud

offering instead of IaaS, allowing cloud consumers to

also control the underlying hypervisor.

Result. When applied, this hosting pattern provides

the highest degree of control over the deployment

stack and scaling conﬁguration. The provisioned in-

frastructure and all deployed components are man-

aged and conﬁgured by cloud consumers. This allows

ﬁne-tuning each deployed component in the stack and

enables manual integration with other components

possibly deployed using more provider-managed of-

ferings. However, since providers are not aware of

all installed components in such deployment stacks,

ensuring that the component is running and available

becomes an additional responsibility for cloud con-

sumers. An example of such additional effort would

be providing a healthcheck conﬁguration, e.g., AWS

Elastic Load Balancing allows deﬁning health check

rules that allow it to control instances’ health status.

Known Uses. Multiple IaaS offerings enable imple-

menting this pattern, e.g., AWS EC2 (Amazon Web

Services, 2021c), Azure IaaS (Microsoft, 2021d),

and Google Compute Engine (Google, 2021c)

enable provisioning virtual machines for hosting

components and their dependencies, while cloud

consumers are responsible for scaling conﬁguration.

Moreover, cloud providers offer bare metal servers,

e.g., IBM Cloud Bare Metal Servers (IBM, 2021a)

allows provisioning dedicated physical machines to

set up any number of infrastructure layers for hosting

desired application components that can be managed

by consumers afterwards.

Software Component

Component A

Component Z

Infrastructure

Resources

Infrastructure

Resources

ToDo.jar

Java 8 Runtime

ToDo Collection

Mongo DB 4.4

Ubuntu 16.04 VMs

Openstack AWS EC2

alternatives

a) Solution sketch

b) Deployment stack example

Consumer-managed

stack component

Consumer-managed

scaling configuration

Hosted On

Relationship

Provider-managed

stack component

Figure 3: A solution sketch (a) and an example deployment (b) for the Serverful Hosting Pattern.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

271

3.4 Consumer-managed Container

Hosting Pattern

Problem: How to host a software

component while managing only the

runtime environment it runs on and the

scaling conﬁguration?

Context. A software component needs to be hosted

such that its runtime environment is customizable,

and the cloud consumer is responsible for managing

the component’s scaling conﬁguration.

Forces. Containers help reducing the infrastructure

costs and simplify software deployment. Moreover,

provisioning tasks require additional technical exper-

tise, e.g., network conﬁguration, shifting the focus

from business logic to infrastructure. At the same

time, managing the component’s runtime environ-

ment and scaling conﬁguration might still be desired,

e.g., add pre-installed proprietary libraries and ﬁne-

tune scaling rules for container instances.

Solution. Host software components on a deploy-

ment stack with provider-managed container engines

or container orchestrators that allow managing scaling

conﬁguration. Figure 4 shows the solution sketch in

which a containerized software component is hosted

on a provider-managed container engine. Here,

providers are responsible for deploying and managing

the infrastructure for running containers, e.g., con-

tainer orchestrator such as Kubernetes offered as a

service. The cloud consumer must provide a container

image encompassing the application component and

its dependencies. Moreover, the cloud consumer is

responsible for the scaling conﬁguration including al-

location of infrastructure resources used by container

engine and the deﬁnition of scaling rules.

Example. Figure 4 shows a ToDo list application

from Section 3.3 hosted on the managed Kubernetes

service from AWS. Only the runtime environment

in this deployment stack is managed by the cloud

consumer as a part of the provided container image.

Moreover, the consumer is responsible for the scal-

ing conﬁguration, including the required infrastruc-

ture resources and scaling rules.

Result. After applying this hosting pattern, the lower-

level infrastructure layers in the deployment stack are

managed by providers, although cloud consumers can

manage the scaling conﬁguration and runtime envi-

ronment by deﬁning custom container images with

required dependencies. While the degree of control

is reduced, users are still able to introduce modiﬁca-

tions to the deployment stack and manage the hosted

component, which makes this pattern a less demand-

ing variant for hosting containerized components.

Known Uses. Managed container orchestrators such

as Kubernetes-as-a-Service offerings are available

in multiple public clouds, including such examples

as IBM Cloud Kubernetes Service (IBM, 2021b),

Azure Kubernetes Service (Microsoft, 2021e), and

AWS Elastic Kubernetes Service (Amazon Web Ser-

vices, 2021f). While managed Kubernetes offer-

ings might vary signiﬁcantly feature-wise, the over-

all goal to have a managed Kubernetes cluster al-

lows deploying and running user-provided container

images, hence shifting most management efforts to

container-speciﬁc tasks. Moreover, some CaaS offer-

ings such as AWS Elastic Container Service (Ama-

zon Web Services, 2021e) with the EC2-based pricing

mode allow hosting containers such that consumers

manage the infrastructure resources for running con-

tainers and deﬁne the scaling rules for resulting con-

tainer instances.

Container Engine

Infrastructure Resources

Container

Software Component

Component A

Component Z

Container Container

ToDo.jar

Java 8 Runtime

AWS EKS

Cluster of AWS EC2 VMs

ToDo Collection

Mongo DB 4.4

Alpine Linux

a) Solution sketch

b) Deployment stack example

Consumer-managed

stack component

Consumer-managed

scaling configuration

Hosted On

Relationship

Provider-managed

stack component

Figure 4: A solution sketch (a) and an example deployment (b) for the Consumer-managed Container Hosting Pattern.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

272

3.5 Provider-deﬁned Stack

Hosting Pattern

Problem: How to host a software

component without managing the de-

ployment stack while retaining control

over the scaling conﬁguration?

Context. A software component needs to be hosted

on any compatible deployment stack without other

stack management requirements, but with cloud con-

sumers managing the scaling conﬁguration.

Forces. Often, software components are ready to

be hosted on a standard platform without additional

modiﬁcations, e.g., a Java WAR ﬁle or a database

schema. Provisioning a virtual machine and installing

Java individually would then be an overhead. How-

ever, for availability requirements it can be beneﬁ-

cial to control the scaling conﬁguration, e.g., to ﬁne-

tune scaling rules. This also applies to products such

as databases or message queues for hosting database

schemas and topics, where the underlying infrastruc-

ture resources can be conﬁgured manually.

Solution. Host software components on a provider-

deﬁned deployment stack which is compatible with

the given deployment artifact type and enables cloud

consumers to manage the scaling conﬁguration as

shown in Figure 5. For example, PaaS offerings allow

hosting compatible deployment artifacts on provider-

deﬁned deployment stacks, e.g., a deployment stack

required to run a Java8 application. In such cases, the

deployment stack management is reduced to the point

of selecting a desired option, whereas the scaling con-

ﬁguration is still consumer-managed, e.g., selecting

the amount of virtual machines and managing com-

ponent’s scaling rules. Another example is related to

certain Database-as-a-Service offerings such as AWS

DocumentDB, which allow allocating infrastructure

resources for database-speciﬁc deployment artifacts.

Example. Figure 5 shows a ToDo list application

from Section 3.3 hosted using AWS Beanstalk and

AWS DocumentDB. The desired runtime is selected

from provider-deﬁned options, i.e., the compatible

Java runtime and a MongoDB-compatible document

database. The cloud consumer, however, still is re-

sponsible for managing the scaling conﬁguration.

Result. After applying this pattern, the deployment

stack management is signiﬁcantly reduced, since con-

sumers can directly select a pre-deﬁned runtime for

a given type of deployment artifact. Hence, this de-

ployment variant allows focusing more on the actual

component being hosted instead of managing the un-

derlying deployment stack. However, due to retained

control over scaling conﬁguration, consumers are still

able to inﬂuence the extent to which resources are

used, and the scaling rules can typically be deﬁned

without relying on the provider.

Known Uses. Multiple PaaS offerings enable im-

plementing this pattern, e.g., AWS Elastic Beanstalk

Service (Amazon Web Services, 2021d) and Azure

App Service (Microsoft, 2021a). AWS Beanstalk en-

ables hosting software components developed for var-

ious platforms using pre-deﬁned deployment stacks.

Infrastructure resources required for running to-be-

deployed components must be deﬁned by developers

in a form of AWS EC2 virtual machines represent-

ing required deployment stacks. Similarly, Azure’s

App Service allows hosting software components de-

veloped for multiple different platforms and con-

trol the allocation of underlying infrastructure. Cer-

tain product-speciﬁc offerings also ﬁt into this cate-

gory, e.g., Amazon DocumentDB (Amazon Web Ser-

vices, 2021a) or Oracle’s Database Classic Cloud Ser-

vice (Oracle, 2021) allow managing the resources al-

located for using database-speciﬁc components.

Software Component

Provider-defined Host

Infrastructure

Resources

Consumer-managed

stack component

Consumer-managed

scaling configuration

Hosted On

Relationship

Provider-managed

stack component

ToDo.jar

AWS Beanstalk

AWS EC2

VMs

Java 8 Runtime

ToDo Collection

AWS

DocumentDB

AWS

DocumentDB

Instances

a) Solution sketch b) Deployment stack example

Figure 5: A solution sketch (a) and an example deployment (b) for the Provider-deﬁned Stack Hosting Pattern.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

273

3.6 Provider-managed Container

Hosting Pattern

Problem: How to host a software

component while managing only the

runtime environment it runs on?

Context. A software component needs to be hosted

such that its runtime environment is customizable.

Forces. Managing the entire deployment stack might

not be necessary for cases without speciﬁc customiza-

tion requirements. Instead, cloud consumers might

want to focus on managing only the runtime environ-

ment, e.g., when proprietary libraries are required to

run the software component. In such cases, cloud con-

sumers can also beneﬁt from provider-managed scal-

ing conﬁguration, e.g., infrastructure resources man-

agement and scaling container instances.

Solution. Host software components on a de-

ployment stack with provider-managed container en-

gines that do not require managing scaling conﬁgu-

ration. Figure 6 shows the solution sketch in which

a containerized software component is hosted on a

provider-managed container engine. Management

of runtime environment remains possible via con-

tainer images, but the scaling conﬁguration is now

provider’s responsibility. With provider-managed

scaling conﬁguration, cloud consumers do not need

to manage infrastructure resources based on compo-

nent’s operation mode, e.g., long-running containers

versus stateless tasks execution. For example, in some

CaaS offerings cloud consumers do not need to al-

locate infrastructure resources, and providers are re-

sponsible for scaling containers in and out.

Example. Figure 6 shows a ToDo list application

from Section 3.3 hosted using AWS Fargate, a server-

less container-centric offering from Amazon. The de-

sired runtime is deﬁned as a part of container im-

ages, i.e., the compatible Java runtime and a Mon-

goDB, with provider-managed scaling conﬁguration.

Since deﬁning the runtime in container images for

standard products such as databases involves unnec-

essary overhead, it might be simpler for such com-

ponents to directly implement the Serverless Hosting

Pattern discussed in the next subsection.

Result. When applied, this pattern allows conﬁg-

uring the runtime environment by creating custom

container images, while deployment stack manage-

ment efforts are reduced. In addition, with provider-

managed scaling conﬁguration, the infrastructure re-

sources required to run containers are allocated by

providers, including the simpliﬁed scaling rule deﬁ-

nition managed primarily by providers. Components

hosted using this pattern can be combined with com-

ponents hosted using the Serverless Hosting Pattern to

implement serverless applications.

Known Uses. Multiple CaaS offerings en-

able implementing this pattern, e.g., AWS Far-

gate (Amazon Web Services, 2021g), Azure Con-

tainer Instances (Microsoft, 2021b), and Google

CloudRun (Google, 2021b) allow hosting container

images while the deployment stack and scaling con-

ﬁguration is managed by providers, including scaling

containers to zero instances for some offerings. An-

other example is related to more specialized offerings,

e.g., Iron Worker (Iron.io, 2021) enables execution of

containerized background tasks.

Container Engine

Infrastructure Resources

Container

Software Component

Component A

Component Z

Container Container

ToDo.jar

Java 8 Runtime

AWS Fargate

ToDo Collection

Mongo DB 4.4

Alpine Linux

a) Solution sketch

b) Deployment stack example

Consumer-managed

stack component

Consumer-managed

scaling configuration

Hosted On

Relationship

Provider-managed

stack component

Figure 6: A solution sketch (a) and an example deployment (b) for the Provider-managed Container Hosting Pattern.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

274

3.7 Serverless Hosting Pattern

Problem: How to host a software com-

ponent without managing its deploy-

ment stack or scaling conﬁguration?

Context. A software component needs to be hosted

on a compatible deployment stack without further de-

ployment stack or scaling conﬁguration management.

Forces. In certain cases, it is preferable to simply se-

lect a pre-deﬁned runtime environment without man-

aging the deployment stack components and scaling

conﬁguration. For instance, deﬁning a runtime and

managing the scaling conﬁguration might be an over-

head when only a small code snippet needs to be

hosted. Tighter coupling with providers can also sim-

plify integration with other provider-speciﬁc services.

Solution. Host software components on a provider-

deﬁned deployment stack which is compatible with

the given deployment artifact type and does not re-

quire cloud consumers to manage the scaling conﬁg-

uration. Figure 7 shows the solution sketch in which

a software component is hosted on a provider-deﬁned

stack which does not require cloud consumers to man-

age scaling conﬁguration. For example, using public

Function-as-a-Service platforms one can host source

code snippets and conﬁgure them to be invoked when

speciﬁc cloud events occur. Many products such as

databases and message queues are also offered as ser-

vices that do not require managing underlying infras-

tructure resources, e.g., serverless DBaaS offerings.

Another example is Software-as-a-Service (SaaS) of-

ferings, in which components typically require mi-

nor conﬁguration efforts to allow using them, whereas

users are not aware which deployment stacks are used

in the background. For example, consumers can host

static web pages via GitHub Pages by conﬁguring a

repository in a speciﬁc way.

Example. Figure 7 shows a ToDo list application

from Section 3.3 hosted using AWS Lambda and

AWS DynamoDB, serverless FaaS and DBaaS offer-

ings from Amazon. The desired runtime is selected

from the list of available runtime environments, i.e.,

the compatible Java runtime and a NoSQL database

compatible similar to MongoDB.

Result. When applied, this pattern results in a sim-

pliﬁed deployment of a component, where typically

only a deployment artifact compatible with the under-

lying platform and speciﬁc conﬁgurations need to be

provided to start using the component, whereas the

underlying platform is responsible for scaling conﬁg-

uration. Even more control is given up in SaaS offer-

ings, where a particular product can be used by pro-

viding product-speciﬁc conﬁgurations. This hosting

pattern is the least managed option in terms of deploy-

ment stack and scaling conﬁguration management,

which allows focusing more on business logic and de-

sired component interactions. Furthermore, this pat-

tern eases the integration with other provider services,

e.g., trigger FaaS functions using events from DBaaS.

Known Uses. Multiple FaaS offerings includ-

ing AWS Lambda (Amazon Web Services, 2021h),

Azure Functions (Microsoft, 2021c), and Google

Cloud Functions (Google, 2021a) enable implement-

ing this pattern. The hosted code is automatically

scaled based on demand, and also can be integrated

with events originating from other provider services

due to a tighter-coupling with provider’s infrastruc-

ture. Other examples include object storage services

such as AWS S3 (Amazon Web Services, 2021i) or

databases such as Amazon Aurora Serverless (Ama-

zon Web Services, 2021b), which do not require con-

sumers to manage the scaling conﬁguration. Instead,

providers employ pricing models in which consumers

are charged based on how products are used in terms

of computational power, storage, data transfer, etc.

Software Component

Provider-defined Host

Infrastructure

Resources

Consumer-managed

stack component

Consumer-managed

scaling configuration

Hosted On

Relationship

Provider-managed

stack component

ToDo.jar

AWS

Lambda

Java 8 Runtime

ToDo Collection

AWS

Dynamo DB

a) Solution sketch b) Deployment stack example

Figure 7: A solution sketch (a) and an example deployment (b) for the Serverless Hosting Pattern.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

275

4 ON PATTERNS’ VALIDITY

Following the approach in (Endres et al., 2017), we

identiﬁed pattern candidates based on the analysis

of documentation of existing hosting solutions. In

particular, we considered existing application host-

ing approaches and technologies, their documenta-

tions, implementations of the most downloaded arti-

facts in their ofﬁcial repositories, and scientiﬁc publi-

cations as a basis for our knowledge collection. Based

on the found commonalities, we elaborated pattern

candidates, which we iteratively reﬁned to obtain the

proposed deployment patterns, as prescribed by the

guidelines in (Fehling et al., 2014b).

We also validated the proposed patterns based on

the Rule of Three (Coplien, 1996), which states that a

pattern is valid if we can ﬁnd three independent occur-

rences of such pattern in the real world. Table 1 shows

that this is the case for the proposed hosting patterns,

by recapping the known uses of such patterns already

discussed in Section 3.

Table 1: Real-world occurrences of the proposed patterns.

Hosting Pattern Real-world Occurrences

Serverful Hosting IBM Cloud Bare Metal Servers,

AWS EC2, Azure IaaS, Google

Compute Engine

Consumer-managed

Container Hosting

IBM Cloud Kubernetes Ser-

vice, Azure kubernetes Service,

AWS Elastic Kubernetes Ser-

vice, AWS Elastic Container

Service (EC2-based pricing)

Provider-deﬁned

Stack Hosting

AWS Beanstalk, Azure App

Service, Amazon Docu-

mentDB, Oracle’s Database

Classic Cloud Service

Provider-managed

Container Hosting

AWS Fargate, Azure Container

Instances, Google CloudRun,

Iron Worker

Serverless Hosting AWS Lambda, Azure Func-

tions, Google Cloud Functions,

IBM Cloud Functions, AWS

S3, Amazon Aurora Serverless

5 DISCUSSION

Following the discussion in Section 3.1, one could ar-

gue that the hosting patterns in which providers man-

age at least one of the discussed dimensions (Sec-

tions 3.5 and 3.6) can also be seen as serverless-

style hosting options. Firstly, services allow-

ing to implement the Provider-managed Container

Hosting Pattern are indeed often called serverless

by cloud providers. For example, AWS Fargate

or Google CloudRun differ from more consumer-

Scaling

Configuration

Management

Responsibilities

Deployment Stack Management

Responsibilities

Serverful

Hosting

Pattern

Serverless

Hosting

Pattern

Cloud

Provider

Cloud

Consumer

Cloud

Provider

Provider-defined

Stack Hosting

Pattern

Consumer-managed

Container

Hosting Pattern

Provider-managed

Container

Hosting Pattern

Serverless Zone

Figure 8: A spectrum of component hosting patterns and the

notion of “serverless zone” encompassing several patterns.

managed container-centric services as they do not

require allocating the underlying infrastructure re-

sources, hence resembling the Serverless Hosting Pat-

tern in this aspect. However, from the perspective

of the deployment stack management, this pattern is

different from the Serverless Hosting Pattern: it of-

fers more freedom to cloud consumers, e.g., FaaS or

certain DBaaS offerings do not really allow modify-

ing the deployment stack

. Secondly, the Provider-

deﬁned Stack Hosting Pattern enables choosing a de-

ployment stack pre-deﬁned by provider (a speciﬁc

Java runtime in a PaaS offering, a database of spe-

ciﬁc version using DBaaS, etc.), thus, also resembling

the Serverless Hosting Pattern. However, this pattern

differs in freedom of the underlying scaling conﬁgu-

ration management. Moreover, cloud service models

enabling to implement it, e.g., PaaS, are less often as-

sociated with the term serverless in the grey literature

and by practitioners (Leitner et al., 2019).

These overlaps among patterns make it not en-

tirely fair to say that a serverless-style hosting can

only be implemented using the Serverless Hosting

Pattern, essentially raising a question of what the

term serverless actually encompasses. Considering

how fast cloud services evolve and how often cloud

providers tend to overlap features in different offer-

ings, introducing a strict deﬁnition of “serverless-

ness” seems non-trivial and rather restrictive. In-

stead, we think that the idea of “serverless-ness” can

be perceived in a fuzzier sense, i.e., the hosting pat-

tern can be considered serverless when at least certain

management requirements are met. Figure 8 shows

the patterns’ spectrum discussed in Section 3.1 with

the so-called “serverless zone” in it, which encom-

passes the patterns with the highest degree of man-

agement in at least one of the dimensions. The idea

Certain FaaS platforms support container images as de-

ployment artifacts, which, essentially, also allows imple-

menting the Provider-managed Container Hosting Pattern.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

276

of such serverless zone could enable having several

distinct patterns that vary in degree of management

related to speciﬁc aspects still perceived as serverless-

style hosting, which in its turn allows ﬂexibly select-

ing component hosting options as well as verifying

whether a given application’s topology conforms to

the serverless architectural style.

Another interesting point worth emphasizing is

how the introduced hosting patterns can be com-

posed with patterns from other pattern languages, e.g.,

microservice patterns or enterprise integration pat-

terns. For example, a well-known API Gateway pat-

tern (Richardson, 2018) can be implemented differ-

ently based on which hosting pattern is chosen. As

a result, when deciding on application’s components

one can think about a composition of patterns, e.g.,

an API Gateway combined with the Serverful Hosting

pattern can be implemented by installing Kong Gate-

way on a Linux-based VM, whereas the API Gateway

combined with the Serverless Hosting pattern can be

implemented by simply using AWS API Gateway ser-

vice. Similar composition reasoning can be applied

when deciding on other pattern compositions too, e.g.,

implementation of a Message Filter pattern (Hohpe

and Woolf, 2004) can be different depending on

which hosting pattern is chosen. However, when

speaking about concrete solutions, the more provider-

managed a hosting pattern is, the more it is coupled

with available provider offerings, essentially, raising

a need for having a knowledge base deﬁning con-

crete solutions for hosting patterns (and pattern com-

positions) to facilitate the overall decision-making

process. For example, the Provider-managed Con-

tainer Hosting Pattern is mainly related to provider-

managed container services such as AWS Fargate,

making it less pervasive than other patterns, at least

in the context of currently-available cloud offerings.

6 RELATED WORK

Cloud-related patterns have been widely studied.

Fehling et al. (Fehling et al., 2014a) introduce cloud

computing patterns supporting developers in building

cloud-native applications, viz., applications built for

running in cloud and structured to fully exploit its po-

tentials. Other examples in this direction (Erl et al.,

2015; Pahl et al., 2018; Davis, 2019) also provide pat-

terns for structuring cloud-native applications. Hohpe

and Woolf (Hohpe and Woolf, 2004) introduce en-

terprise integration patterns (EIPs), which are also

used to structure cloud-native applications (Yussupov

et al., 2020). The above works differ from ours as

they propose patterns for designing cloud applica-

tions, whereas our patterns focus on their hosting.

Similar considerations apply to patterns intro-

duced in the domain of serverless computing. Taibi

et al. (Taibi et al., 2020) and Zambrano (Zambrano,

2018) elicit patterns for architecting serverless appli-

cations. Hong et al. (Hong et al., 2018) present pat-

terns for improve the security of cloud-hosted ser-

vices, based on serverless computing. Hence, these

works also focus on designing cloud applications,

whereas we focus on how to host them.

Jamshidi et al. (Jamshidi et al., 2015) instead pro-

pose a catalog of patterns for migrating on-premise

applications to the cloud. The catalog of migration

patterns is reﬁned in the subsequent work (Jamshidi

et al., 2017), which also proposes a concrete method

for enacting pattern-based migration of on-premise

application to the cloud. These patterns (Jamshidi

et al., 2015; Jamshidi et al., 2017) differ from our

hosting patterns, as they focus on adapting existing

service-based applications to allow migrating them to

the cloud, rather than on how to actually deploy such

applications. They can, however, be used in conjunc-

tion with the hosting patterns we propose: developers

may ﬁrst exploit migration patterns to enable deploy-

ing applications in the cloud, and then implement our

patterns for hosting the application components.

To the best of our knowledge, the only exist-

ing work organizing knowledge on application de-

ployment into patterns focuses on deployment model

types. Endres et al. (Endres et al., 2017) distinguish

two possible approaches for specifying the deploy-

ment of an application, viz., declarative vs. impera-

tive application deployment. Intuitively, the declar-

ative deployment consists in specifying the desired

state for an application, by relying on a deployment

engine to automatically determining and enacting the

sequence of operations for enforcing such state. The

imperative deployment instead consists in explicitly

specifying the sequence of operations to enact for de-

ploying an applications. These patterns are, hence,

complementary to our hosting patterns: developers

can use our patterns to derive the required deployment

steps for a given component, whose actual speciﬁca-

tion can then be either declarative or imperative, de-

pending on the developers’ needs.

Another important aspect related to patterns is

how to ﬁnd suitable patterns and traverse to related so-

lutions in different interconnected pattern languages.

Falkenthal et al. (Falkenthal and Leymann, 2017) in-

troduce the concept of solution languages which facil-

itate the navigation from the level of patterns to con-

crete solutions, e.g., implementation of a pattern us-

ing speciﬁc technologies. Leymann et al. (Leymann

and Barzen, 2020) propose an approach and tool

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

277

for navigating through different pattern languages in-

spired by the analogy with cartography. Such ap-

proaches can help linking the hosting patterns intro-

duced in this work with other pattern languages such

as cloud computing patterns (Fehling et al., 2014a),

and support the search for concrete solutions.

Finally, it is worth relating our hosting patterns

to the existing works on pattern-based application

deployment. Harzenetter et al. (Harzenetter et al.,

2020) provide a model-based solution for deploy-

ing applications, whose deployment speciﬁcation ex-

ploit cloud patterns to specify application/infrastruc-

ture components in a vendor-agnostic manner. Yus-

supov et al. (Yussupov et al., 2020) use EIPs to gener-

ically specify the integration of application service.

In both cases, abstract patterns are then automatically

replaced by concrete components when the deploy-

ment of an application is actually enacted. Solutions

like (Harzenetter et al., 2020) and (Yussupov et al.,

2020) can hence beneﬁt from the patterns we propose

in this paper. Indeed, such solutions could extend the

set of supported patterns by also including our hosting

patterns, hence making application deployment spec-

iﬁcations even more generic.

7 CONCLUSIONS

In this work, we introduced ﬁve hosting patterns and

the corresponding pattern primitives deﬁning a com-

mon vocabulary for formulating the patterns. The in-

troduced hosting patterns aim to facilitate the decision

making process for choosing the most suitable host-

ing variant for a given software component. We also

positioned the presented patterns in a so-called ap-

plication components hosting spectrum, showing how

they represent different combinations of management

responsibilities related to deployment stack and scal-

ing conﬁguration management. Finally, we validated

the proposed patterns by showing how they fulﬁll the

Rule of Three (Coplien, 1996), viz., by presenting at

least three real-world occurrences of each pattern.

For future work, we plan to devise a decision

support system helping application administrators in

choosing the hosting solution most suited to their

needs. We plan to investigate which are the well-

known advantages and disadvantages of each hosting

pattern, or when it is better to adopt one pattern, e.g.,

by means of a multivocal review. We could then ex-

ploit the obtained knowledge to start devising a de-

cision support system, which could also be enhanced

by exploiting other existing systems to further reﬁn-

ing decisions, e.g., PaaSﬁnder (Kolb, 2019) or FaaS-

tener (Yussupov et al., 2021), if a cloud consumer

needs to decide which PaaS or FaaS platform to use

to deploy a given application. Another interesting re-

search direction is to analyze how our hosting patterns

can be extended based on other dimensions such as

application health management. Furthermore, we in-

tend to deﬁne more precise links between the hosting

patterns and existing pattern languages such as cloud

computing patterns (Fehling et al., 2014a) to simplify

ﬁnding composite solutions using existing approaches

such as Pattern Atlas (Leymann and Barzen, 2020)

and Pattern Views (Weigold et al., 2020).

ACKNOWLEDGMENTS

This work is partially funded by the European

Union’s Horizon 2020 research and innovation

project RADON (825040). We would also like

to thank the anonymous referees, whose feedback

helped improving this paper.

REFERENCES

Alexander, C. (1977). A pattern language: towns, build-

ings, construction. Oxford university press.

Amazon Web Services (2021a). Amazon DocumentDB.

https://aws.amazon.com/documentdb. [Online].

Amazon Web Services (2021b). AWS Aurora. https://aws.

amazon.com/rds/aurora/serverless. [Online].

Amazon Web Services (2021c). AWS EC2. https://aws.

amazon.com/ec2. [Online].

Amazon Web Services (2021d). AWS Elastic Beanstalk.

https://aws.amazon.com/elasticbeanstalk. [Online].

Amazon Web Services (2021e). AWS Elastic Container

Service. https://aws.amazon.com/ecs. [Online].

Amazon Web Services (2021f). AWS Elastic Kubernetes

Service. https://aws.amazon.com/eks. [Online].

Amazon Web Services (2021g). AWS Fargate. https://aws.

amazon.com/fargate. [Online].

Amazon Web Services (2021h). AWS Lambda. https://aws.

amazon.com/lambda. [Online].

Amazon Web Services (2021i). AWS S3. https://aws.

amazon.com/s3. [Online].

Baldini, I. et al. (2017). Serverless computing: Current

trends and open problems. In Research Advances in

Cloud Computing, pages 1–20. Springer.

Buschmann, F. et al. (2007). Pattern-Oriented Software Ar-

chitecture: On Patterns And Pattern Language, vol-

ume 5. John wiley & sons.

Coplien, J. O. (1996). Software patterns.

Councill, B. and Heineman, G. T. (2001). Deﬁnition of a

software component and its elements. Component-

based software engineering: putting the pieces to-

gether, pages 5–19.

Davis, C. (2019). Cloud Native Patterns: Designing

change-tolerant software. Manning Publications.

CLOSER 2021 - 11th International Conference on Cloud Computing and Services Science

278

Endres, C. et al. (2017). Declarative vs. imperative: Two

modeling patterns for the automated deployment of

applications. In Proceedings of the 9

International

Conference on Pervasive Patterns and Applications,

pages 22–27. Xpert Publishing Services (XPS).

Erl, T. et al. (2015). Cloud Computing Design Patterns.

Prentice Hall Press, 1st edition.

Falkenthal, M. and Leymann, F. (2017). Easing pattern ap-

plication by means of solution languages. In Proceed-

ings of the 9th International Conference on Pervasive

Patterns and Applications, pages 58–64.

Fehling, C. et al. (2014a). Cloud computing patterns: fun-

damentals to design, build, and manage cloud appli-

cations. Springer.

Fehling, C. et al. (2014b). A process for pattern identiﬁ-

cation, authoring, and application. In Proceedings of

the 19th European Conference on Pattern Languages

of Programs, pages 1–9.

Gamma, E. et al. (1995). Elements of reusable object-

oriented software. Reading: Addison-Wesley.

Google (2021a). Google Cloud Functions. https://cloud.

google.com/functions. [Online].

Google (2021b). Google CloudRun. https://cloud.google.

com/run. [Online].

Google (2021c). Google Compute Engine. https://cloud.

google.com/compute. [Online].

Harzenetter, L. et al. (2020). Pattern-based Deployment

Models Revisited: Automated Pattern-driven Deploy-

ment Conﬁguration. In Proceedings of PATTERNS

2020, pages 40–49. Xpert Publishing Services.

Hohpe, G. and Woolf, B. (2004). Enterprise integration pat-

terns: Designing, building, and deploying messaging

solutions. Addison-Wesley Professional.

Hong, S. et al. (2018). Go serverless: Securing cloud via

serverless design patterns. In 10th USENIX Workshop

on Hot Topics in Cloud Computing (HotCloud 18).

IBM (2021a). IBM Cloud Bare Metal Servers. https://www.

ibm.com/cloud/bare-metal-servers. [Online].

IBM (2021b). IBM Cloud Kubernetes Service. https:

//www.ibm.com/cloud/container-service/resources.

[Online].

Iron.io (2021). Iron Worker. www.iron.io/worker. [Online].

Jamshidi, P. et al. (2015). Cloud migration patterns:

A multi-cloud service architecture perspective. In

Service-Oriented Computing - ICSOC 2014 Work-

shops, pages 6–19, Cham. Springer International Pub-

lishing.

Jamshidi, P. et al. (2017). Pattern-based multi-cloud archi-

tecture migration. Software: Practice and Experience,

47(9):1159–1184.

Jonas, E. et al. (2019). Cloud programming simpliﬁed: A

berkeley view on serverless computing. arXiv preprint

arXiv:1902.03383.

Kolb, S. (2019). On the Portability of Applications in Plat-

form as a Service. PhD thesis, University of Bamberg,

Germany.

Lau, K.-K. and Wang, Z. (2007). Software component

models. IEEE Transactions on software engineering,

33(10):709–724.

Leitner, P. et al. (2019). A mixed-method empirical study

of function-as-a-service software development in in-

dustrial practice. Journal of Systems and Software,

149:340–359.

Leymann, F. and Barzen, J. (2020). Pattern Atlas. arXiv

preprint arXiv:2006.05120.

Messerschmitt, D. G. (2007). Rethinking components:

From hardware and software to systems. Proceedings

of the IEEE, 95(7):1473–1496.

Microsoft (2021a). Azure App Service. https://azure.

microsoft.com/en-us/services/app-service. [Online].

Microsoft (2021b). Azure Container Instances.

https://azure.microsoft.com/en-us/services/

container-instances. [Online].

Microsoft (2021c). Azure Functions. https://azure.

microsoft.com/en-us/services/functions. [Online].

Microsoft (2021d). Azure IaaS. https://azure.microsoft.

com/en-us/overview/what-is-azure/iaas. [Online].

Microsoft (2021e). Azure Kubernetes Service.

https://azure.microsoft.com/en-us/services/

kubernetes-service. [Online].

OASIS (2015). TOSCA Simple Proﬁle in YAML Version

1.0. Organization for the Advancement of Structured

Information Standards (OASIS).

Oracle (2021). Oracle Database Classic Cloud

Service. docs.oracle.com/en/cloud/paas/

database-dbaas-cloud/index.html. [Online].

Pahl, C. et al. (2018). Architectural principles for cloud

software. 18(2).

Richardson, C. (2018). Microservices patterns. Manning

Publications Company,.

Taibi, D. et al. (2020). Patterns for serverless functions

(function-as-a-service): A multivocal literature re-

view. In CLOSER, pages 181–192.

Weigold, M. et al. (2020). Pattern Views: Concept and

Tooling of Interconnected Pattern Languages. In Pro-

ceedings of the 14th Symposium and Summer School

on Service-Oriented Computing (SummerSOC 2020),

pages 86–103.

Wellhausen, T. and Fiesser, A. (2011). How to write a pat-

tern? a rough guide for ﬁrst-time pattern authors. In

Proceedings of the 16th European Conference on Pat-

tern Languages of Programs, pages 1–9.

Yussupov, V. et al. (2020). Pattern-based modelling, in-

tegration, and deployment of microservice architec-

tures. In 2020 IEEE 24th International Enterprise

Distributed Object Computing Conference (EDOC),

pages 40–50.

Yussupov, V. et al. (2021). FaaSten your decisions: A

classiﬁcation framework and technology review of

Function-as-a-Service platforms. Journal of Systems

and Software, 175.

Zambrano, B. (2018). Serverless Design Patterns and

Best Practices: Build, Secure, and Deploy Enterprise

Ready Serverless Applications with AWS to Improve

Developer Productivity. Packt Publishing.

From Serverful to Serverless: A Spectrum of Patterns for Hosting Application Components

279
