Enforcing Cardinality Constraint in Temporal RBAC

Sohail Rajdev

1,†

and Barsha Mitra

2,‡

Microsoft, India

Department of CSIS, BITS Pilani, Hyderabad Campus, Hyderabad, India

Keywords:

Temporal RBAC, Temporal Role Mining, Cardinality Constraint, Minimization.

Abstract:

The temporal extensions of the Role-Based Access Control (RBAC) model imposes duration constraints on the

availability of roles by allowing periodic enabling and disabling of roles. For deploying these models, a set of

roles having associated time constraints are required. Such type of roles are termed as temporal roles and the

process of creating them is referred to as Temporal Role Mining. In many real-life scenarios, simply imposing

time constraints on role availability may not be sufﬁcient. The system administrator may need to ensure

different types of constraints reﬂecting speciﬁc organizational policies. In this paper, we propose a cardinality

constraint which restricts the maximum number of temporal roles that a user can activate in a particular time

interval. We name this constraint as Temporal Role Assignment Constraint (TRAC). We formally deﬁne the

problem of mining a minimal set of temporal roles in presence of TRAC as the TRAC Temporal Role Mining

Problem (TRAC-TRMP) and propose an algorithm for solving it. We also present the experimental results

reﬂecting the performance of our proposed approach.

1 INTRODUCTION

Role-Based Access Control (RBAC) model (Sandhu

et al., 1996) has been effectively deployed over the

years for protecting resources from unauthorized ac-

cesses and thus preventing security breaches. For im-

plementing RBAC, a set of roles is required which can

be created by an approach known as role mining (Ene

et al., 2008). RBAC though quite effective, fails to

restrict the accessibility of the permissions present in

a role to a speciﬁc time duration. To handle such re-

quirements, temporally extended RBAC models like

the Temporal Role-Based Access Control (TRBAC)

(Bertino et al., 2001) and the Generalized Temporal

Role-Based Access Control (GTRBAC) (Joshi et al.,

2005) models were proposed. These models allow

the roles to be enabled for ﬁxed time intervals dur-

ing which the permissions associated with the role are

available. Moreover, the GTRBAC model introduces

the concept of role activation which corresponds to

the actual utilization of the permissions by the users.

The role activation duration is either equal to or a sub-

set of the enabling duration.

†

This work was carried out by Sohail Rajdev as an under-

graduate student of the Dept. of EEE of BITS Pilani, Hy-

derabad Campus.

‡

Corresponding Author.

To deploy TRBAC or GTRBAC, a set of roles

having appropriate duration constraints are required.

Such roles are named as temporal roles and the pro-

cess of generating them is termed as temporal role

mining (Mitra et al., 2013). Temporal role min-

ing takes a Temporal User-Permission Assignement

(TUPA) matrix (Mitra et al., 2013) as input. The

problem of mining a minimal set of temporal roles

has been named as the Temporal Role Mining Prob-

lem (TRMP) (Mitra et al., 2013). TRMP is an NP-

complete problem. Heuristic solutions for solving it

has been proposed in (Mitra et al., 2013) and (Mitra

et al., 2016). TRMP aims to derive an exact solution

where the output perfectly matches the input. Instead,

an inexact solution can also be computed such that

after assigning the temporal roles to the users, one

or more of them may not acquire certain permissions

that were originally assigned in the input TUPA. The

TRMP variant that generates such an inexact solution

has been named as the Generalized Temporal Role

Mining Problem (GTRMP) (Mitra et al., 2015) and

has been shown to be an NP-complete problem. The

authors have proposed a greedy algorithm for solving

GTRMP in (Mitra et al., 2015). Other than the num-

ber of temporal roles, other optimization criteria have

also been considered like the Cumulative Overhead

of Temporal Roles and Permissions (CO-TRAP) (Mi-

Rajdev, S. and Mitra, B.

Enforcing Cardinality Constraint in Temporal RBAC.

DOI: 10.5220/0010501506390646

In Proceedings of the 18th International Conference on Security and Cryptography (SECRYPT 2021), pages 639-646

ISBN: 978-989-758-524-1

639

tra et al., 2016) and a Weighted Structural Complexity

(WSC) (Stoller and Bui, 2017).

Several cardinality constraints have been pro-

posed for the RBAC model like the maximum num-

ber of roles that can be assigned to a user (Role-Usage

cardinality constraint), the maximum number of roles

to which a permission can belong (Permission-Usage

cardinality constraint), the maximum number of users

to whom a role can be assigned (User-Distribution

cardinality constraint)and the maximum number of

permissions that can be present in a role (Permission-

Distribution cardinality constraint). A number of

role mining algorithms have been proposed that con-

sider these constraints such as the ones presented

in (Blundo and Cimato, 2012), (Carlo et al., 2018),

(Harika et al., 2015), (Hingankar and Sural, 2011),

(John et al., 2012), (Lu et al., 2013), (Blundo et al.,

2020). The most recent work (Blundo et al., 2020)

consider the Permission-Usage cardinality constraint

and Permission-Distribution cardinality constraint.

Some of these works consider a single cardinality

constraint and some of them consider multiple con-

straints simultaneously. The authors of these papers

propose different variants of the role mining prob-

lem in presence of one or more of these cardinality

constraints and have proven them to be NP-complete.

The TRBAC model does not support any cardinality

constraints. The GTRBAC model, however, accounts

for a number of cardinality constraints like limiting

the total number of times a temporal role can be ac-

tivated as well as the number of simultaneous activa-

tions of a role.

In recent years, the Attribute-Based Access Con-

trol (ABAC) model (Hu et al., 2015) has become quite

popular. This model takes into consideration the at-

tributes of the subjects and the objects and several

environmental conditions for granting or denying ac-

cess. Several algorithms have been proposed for the

deployment of the ABAC model like (Xu and Stoller,

2015), (Das et al., 2019), (Batra et al., 2021), (Gupta

et al., 2021).

To the best of our knowledge, none of the ap-

proaches for temporal role mining consider any car-

dinality constraint. Moreover, the cardinality con-

straints for GTRBAC do not consider the workload

assigned to the individual users in a certain time in-

terval. In this paper, we propose a new cardinality

constraint which limits the number of temporal roles

that can be activated by a user in a speciﬁc time inter-

val. This constraint will help to uniformly distribute

the workload among the users. In addition to this, the

proposed constraint is also meaningful from a security

point of view. If a user is restricted to activating only

a pre-deﬁned number of roles during a certain time in-

terval, then the user can use only a subset of the total

set of permissions available to her. By restricting the

permissions that can be used during a particular time

duration, a user can be prevented from carrying out

any malicious activity.

Though the concept of role activation is associated

with GTRBAC, the manner in which we handle this

constraint makes it applicable for TRBAC as well. We

name the proposed cardinality constraint as Tempo-

ral Role Assignment Constraint (TRAC). We formally

deﬁne the problem of mining a minimal set of tem-

poral roles in presence of TRAC as the TRAC Tempo-

ral Role Mining Problem (TRAC-TRMP). We analyze

the computational complexity of TRAC-TRMP and

present a heuristic algorithm named as TRAC-Miner

for solving it. Experimental results carried out on syn-

thetic datasets reﬂect the performance of the proposed

approach in terms of the number of roles and the over-

all execution time.

The rest of the paper is organized as follows. Sec-

tion 2 discusses some preliminary concepts related to

TRBAC, GTRBAC and temporal role mining. Sec-

tion 3 presents the proposed cardinality constraint

TRAC, the associated problem deﬁnition for TRAC-

TRMP and its complexity analysis. The approach for

solving TRAC-TRMP is described in Section 4. Ex-

perimental results are presented in Section 5 and Sec-

tion 6 concludes the paper along with insights into

future research work.

2 BACKGROUND

In this section, we discuss some of the basic concepts

related to the temporal extensions of RBAC and tem-

poral role mining.

2.1 Temporal RBAC Models

In order to associate time dependent enabling con-

straints on the availability of roles, two temporal ex-

tensions of RBAC were proposed, namely, TRBAC

(Bertino et al., 2001) and GTRBAC (Joshi et al.,

2005). TRBAC associates duration constraints with

roles by allowing them to be enabled for certain time

intervals and disabling them for the remaining time

intervals. Such roles are referred to as temporal roles

(Mitra et al., 2013). The enabling duration corre-

sponding to each role is speciﬁed in a Role Enabling

Base (REB) using a construct known as periodic ex-

pression (Bertino et al., 2001). Apart from this, the

TRBAC model also introduces the concepts of run-

time requests, role triggers and blocked events. How-

ever, in the current context, we do not discuss about

SECRYPT 2021 - 18th International Conference on Security and Cryptography

640

these since they are not directly relevant.

The GTRBAC model (Joshi et al., 2005) ex-

tends the TRBAC model by introducing temporal

constraints on enabling of roles, user-role and role-

permission assignments, activation constraints, con-

straint enabling expressions, temporal role hierarchies

and temporal separation of duty constraints. More-

over, the GTRBAC model differentiates between the

enabling and the activation of a role. Let a temporal

role r be enabled for a set of time intervals T and is

assigned to users u and u

. For a time interval t ∈ T ,

if atleast any one of u and u

activates r, i.e., uses the

permissions included in r, then r is said to be activated

in t.

Different types of constraints can be imposed on

temporal role activation. One such type of constraint

is known as cardinality constraint. Cardinality con-

straints on role activation can be of 2 types - total

number of activations of a temporal role and maxi-

mum number of concurrent activations of a temporal

role. The former one speciﬁes the number of times

a role can be activated and the latter one restricts the

number of concurrent activations of a role.

2.2 Temporal Role Mining

Temporal role mining (Mitra et al., 2013) is the pro-

cess of creating a set of temporal roles. These roles

are essential for the deployment of a temporally ex-

tended RBAC model. Temporal role mining takes

as input a set of user-permission assignments each of

which describes the set of time intervals for which a

permission is assigned to a user. Such kind of user-

permission assignments are referred to as temporal

user-permission assignments (Mitra et al., 2013). Mi-

tra et al. have proposed a representation for depict-

ing the temporal user-permission assignments which

is referred to as the Temporal User-Permission As-

signment (TUPA) matrix (Mitra et al., 2013). Each

row of the TUPA corresponds to a user and each col-

umn corresponds to a permission. If user u

is as-

signed permission p

for a set of time intervals T

then the cell of TUPA present in the x-th row and y-th

column contains T

. If however, u

is not assigned

, then the cell contains a φ. An example TUPA ma-

trix for 4 users and 5 permissions is shown in Table 1.

In this matrix, for the sake of brevity, we have shown

only a single interval instead of a set of time inter-

vals for each user-permission assignment. The output

of temporal role mining consists of a set of tempo-

ral roles, a user-role assignment (UA) matrix, a role-

permission assignment (PA) matrix and an REB. The

problem of ﬁnding a minimal set of temporal roles,

a UA, a PA and an REB from an input TUPA has

been deﬁned as the Temporal Role Mining Problem

(TRMP). Several other variants of TRMP have been

deﬁned such as the Generalized Temporal Role Min-

ing Problem (GTRMP) (Mitra et al., 2015), Cumu-

lative Overhead of Temporal Roles And Permissions

Minimization Problem (CO-TRAPMP) (Mitra et al.,

2016) and the variant that minimizes a weighted struc-

tural complexity (Stoller and Bui, 2017). However, to

the best of our knowledge, none of the problems con-

sider any cardinality constraints.

3 MINING TEMPORAL ROLES IN

PRESENCE OF CARDINALITY

CONSTRAINT

In this section, we introduce the concept of perform-

ing temporal role mining in presence of cardinal-

ity constraint and formally deﬁne the corresponding

TRMP variant. We also analyze the computational

complexity of the problem.

3.1 Constrained Temporal Role Mining

The cardinality constraints that we have discussed in

Sub-section 2.1 ensure that resources are accessible to

the requesting users in a fair manner. However, these

constraints may not always ensure a uniform distri-

bution of responsibilities among the users. In any

organization, it is really important to make sure that

some users are not over burdened with responsibili-

ties while others are assigned quite a lesser amount

of workload. In other words, to make the work en-

vironment user-friendly, it is essential to regulate the

number of temporal roles a user can activate simul-

taneously. This is required to make sure that a user

does not juggle too many responsibilities at the same

time. Hence, in this paper, we propose a new cardi-

nality constraint which restricts the number of tempo-

ral roles that can be activated by each user in a given

time interval. We name this constraint as the Tempo-

ral Role Assignment Constraint (TRAC). TRAC en-

sures that in a particular set of time intervals, no user

is allowed activate more than a pre-deﬁned number of

temporal roles. Consequently, at any point of time, no

user is over burdened with too much responsibilities.

In order to enforce TRAC, it is essential to make

sure that in a certain time interval, a user does not ac-

tivate more number of roles than the permissible limit.

Ensuring this in real-life scenarios incurs a lot of over-

head and effort. Therefore, instead of trying to limit

the number of role activations, we can limit the num-

ber of roles enabled for a speciﬁc set of time intervals

Enforcing Cardinality Constraint in Temporal RBAC

641

Table 1: Example TUPA Matrix.

8 am - 9 am φ 7 am - 10 am 8 am - 9 am 7 am - 10 am

φ 4 am - 5 am 8 am - 9 am 4 am - 5 am 7 am - 10 am

7 am - 10 am 4 am - 5 am 8 am - 9 am 7 am - 10 am 8 am - 9 am

4 am - 5 am 4 am - 5 am 7 am - 10 am φ 7 am - 10 am

that are assigned to a user. This effectively will also

limit the number of roles that a user can activate in a

certain time interval. Therefore, for enforcing TRAC,

we shall ensure that the number of temporal roles that

are assigned to each user for a speciﬁc time interval is

restricted to a pre-deﬁned value. As a result, TRAC

can be seamlessly integrated into TRBAC as well as

GTRBAC since TRAC enforcement is not dependent

only on role activations. In addition to uniform work-

load distribution, TRAC will also impose a restric-

tion on the permissions that become available to the

users during a speciﬁc time duration. By restricting

the usable permissions for the users in this manner,

it is possible to ensure that not too many permissions

become available to the users, thereby preventing the

users from carrying out any malicious activity.

Suppose an organization ABC has a temporal

RBAC (TRBAC or GTRBAC) model deployed where

there are a total of 6 roles, r

, r

and r

and

3 distinct sets of time intervals T

, T

and T

. r

and r

are enabled for T

, r

and r

are enabled for T

and r

are enabled for T

. If the value of TRAC is 1,

then a user u will be assigned either one of r

and r

. As a result, the total number

of roles assigned a particular user is also restricted.

3.2 Problem Deﬁnition

We name the temporal role mining problem vari-

ant that ensures the enforcement of TRAC as

the TRAC Temporal Role Mining Problem (TRAC-

TRMP). TRAC-TRMP takes a TUPA matrix and an

integer value, say k, specifying the value of the pro-

posed cardinality constraint, as inputs. It generates as

output a set of temporal roles TR, a UA matrix, a PA

matrix and an REB by minimizing the total number of

temporal roles and at the same time, ensures that no

user is assigned more than k temporal roles enabled

for the same set of time intervals. Moreover, the tem-

poral user-permission assignments obtained by com-

bining the UA, PA and REB match exactly with those

depicted in the input TUPA. The problem deﬁnition is

as follows:

TRAC-TRMP. Given a TUPA matrix and a pos-

itive integer k as inputs, ﬁnd a set of temporal

roles T R, a user-role assignment matrix UA, a role-

permission assignment matrix PA and a role enabling

base REB such that |TR| is minimized, no user is as-

signed more than k temporal roles that are enabled for

the same set of time intervals and the output exactly

matches the input.

Lu et al. have proposed a constrained role min-

ing problem variant known as the User-Oriented Ex-

act RMP (Lu et al., 2015) that minimizes the total

number of roles and makes sure that no user is as-

signed more than a pre-speciﬁed number of roles.

User-Oriented Exact RMP has been shown to be an

NP-hard problem. TRAC-TRMP can be shown to

be an NP-complete problem by proving that given a

solution for TRAC-TRMP, it is polynomial time ver-

iﬁable and showing that a known NP-hard problem

User-Oriented Exact RMP can be reduced to TRAC-

TRMP in polynomial time by assuming that only a

single set of time intervals is present in the TUPA and

the value of the constraint to be a very large positive

integer.

4 HEURISTIC ALGORITHM FOR

SOLVING TRAC-TRMP

Since TRAC-TRMP is an NP-complete problem, we

propose a heuristic algorithm for solving it. Our

method makes use of the role mining algorithm pro-

posed in (Lu et al., 2015) for solving User-Oriented

Exact RMP. This algorithm minimizes the total num-

ber of roles and ensures that no user is assigned more

than k roles. We ﬁrst discuss the steps of the approach

proposed in (Lu et al., 2015). The steps are:.

1. The users with the same set of permissions are re-

moved from the input UPA matrix.

2. The users with exclusive permissions are identi-

ﬁed. Exclusive permissions are the permissions

which are given to only one user. If any user is

found having an exclusive permission, a single

role for the corresponding permission set is cre-

ated and assigned to him/her.

3. The remaining user-permission assignments in the

UPA matrix are used to create candidate roles for

the subsequent steps. A candidate role is created

from each row of the UPA.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

642

4. Role selection is done as per a greedy choice. The

role which covers the maximum number of users

among all the candidate roles is selected.

5. The selected role is assigned to the remaining

users according to the following conditions:

i. If a user is assigned (k - 1) roles after assigning

the selected role, the uncovered permissions of

the user are checked. A temporary role to cover

the set of uncovered permissions is created. It is

checked if this role can be reused, i.e., whether

this role can be given to some other user.

a. If the temporary role can be reused, it is as-

signed to the corresponding users and added

to the set of ﬁnal roles. The UPA matrix is

updated by removing the covered permission

assignments. The control goes back to Step 3.

b. If the role cannot be reused, it is discarded and

all the roles previously given to the user are

revoked. Now, a new single role covering all

the permissions of the user is created and as-

signed to him/her. The UPA matrix is updated

by removing the covered permission assign-

ments and control goes back to Step 3.

ii. If a user has been assigned less than (k - 1)

roles after assigning the selected role, the cor-

responding user-permission assignments are re-

moved from that row of the UPA matrix and the

role selection is continued.

6. Steps 3 to 5 are repeated until all user-permission

assignments of the UPA have been covered.

The above algorithm uses a strategy of updating the

UPA after a role is selected and after each updation,

a new set of candidate roles is created. Thus, this ap-

proach uses a dynamic set of candidate roles instead

of a static one. In the rest of the paper, we will refer

to this algorithm as User-Oriented Miner.

We name our proposed approach as TRAC-Miner.

It takes as inputs a TUPA matrix and a value of the

constraint expressed as a positive integer. TRAC-

Miner works in 2 phases. The ﬁrst phase identiﬁes the

unique time interval sets present in the TUPA and seg-

regates out the temporal information corresponding to

each identiﬁed set of time intervals. The segregation

is done by creating a UPA for each distinct time in-

terval set. After segregation, User-Oriented Miner is

applied to each of the individual UPAs along with the

value of TRAC and a set of roles, a UA, a PA and

an REB are obtained. These roles are then input to

the second phase of the algorithm which merges the

roles in order to reduce the size of the role set. The

ﬁnal output consists of a set of temporal roles, a UA,

a PA and an REB with the UA satisfying the value of

TRAC. We next discuss each of the phases in detail.

4.1 Phase 1: Temporal Information

Segregation and Mining

We name the ﬁrst phase of our algorithm as Temporal

Information Segregator and Miner (TIS-Miner. This

phase takes the TUPA and the value of TRAC as in-

puts. First, the redundancy in the TUPA is removed

by deleting the duplicate rows. Then, by scanning the

TUPA, all the distinct sets of time intervals are iden-

tiﬁed. Corresponding to each time interval set, a UPA

matrix having the same number of users and permis-

sions as the TUPA is created. We call each such UPA

as Interval-UPA (INT-UPA). In order to distinguish

the INT-UPAs from one another, INT-UPA created for

a time interval set T

is denoted as INT -UPA

. For

ﬁlling up the cells of INT -UPA

, each corresponding

cell of the TUPA is scanned and the steps mentioned

below are followed.

1. If cell (i, j) of TUPA contains φ, then cell (i, j) of

INT -UPA

contains zero.

2. If cell (i, j) of TUPA contains T

, then cell (i, j) of

INT -UPA

contains one.

3. If cell (i, j) of TUPA contains a time interval set

such that T

is a subset of T

, then cell (i, j) of

INT -UPA

contains one.

4. If cell (i, j) of TUPA contains a time interval set

such that T

is neither equal to nor a subset of

, then cell (i, j) of INT -UPA

contains zero.

After all the INT-UPAs are obtained, the User-

Oriented Miner is applied to each INT-UPA to gen-

erate a corresponding set of roles, a UA, a PA and

an REB. It may be noted here that we use a slightly

modiﬁed version of User-Oriented Miner in the ﬁrst

phase. Since we remove the redundancy in the TUPA

before creating the individual UPAs, we do not apply

Step 1 of User-Oriented Miner to the separate UPAs.

The roles that are computed from each INT-UPA are

enabled for the same time interval set and the REB

thus obtained contains the same enabling duration for

all the roles. The procedure of the ﬁrst phase is shown

in Algorithm 1.

4.2 Phase 2: Merging Temporal Roles

The sets of temporal roles, UAs, PAs and REBs cre-

ated in the ﬁrst phase are input to the second phase.

This phase checks the compatibility every pair of

roles in order to determine whether the two roles can

be merged into a single role. The compatibility check-

ing is done according to the conditions mentioned as

follows.

Enforcing Cardinality Constraint in Temporal RBAC

643

Algorithm 1: TIS-Miner.

Require: INPUT: p x q TUPA, OUTPUT: sets of tempo-

ral roles, UAs, PAs, REBs, S

: set of all unique time

interval sets

Require: TUPA(i, j): cell (i, j) of TUPA

Require: INT -UPA(i, j)

: cell (i, j) of INT-UPA for time

interval set T

Require: R

: set of roles obtained from INT -UPA

Require: UA

: UA matrix obtained from INT -UPA

Require: PA

: PA matrix obtained from INT -UPA

Require: REB

: REB obtained from INT -UPA

1: Remove duplicate rows from TUPA

2: S

← φ

3: for i ← 1 to p do

4: for j ← 1 to q do

5: if TUPA(i, j) = T and T /∈ S

then

6: S

← S

∪ {T }

7: end if

8: end for

9: end for

10: for l ← 1 to |S

| do

11: for i ← 1 to p do

12: for j ← 1 to q do

13: if TUPA(i, j) = φ then

14: INT -UPA(i, j)

= 0

15: else if TUPA(i, j) = T

and T

⊆ T

then

16: INT -UPA(i, j)

= 1

17: else if TUPA(i, j) = T

and T

6⊆ T

then

18: INT -UPA(i, j)

= 0

19: end if

20: end for

21: end for

22: end for

23: for l ← 1 to |S

| do

24: Apply User-Oriented Miner to INT -UPA

and ob-

tain R

, UA

, PA

and REB

25: end for

1. If two temporal roles are assigned to the same set

of users, have the same permission set and are en-

abled for overlapping or consecutive time interval

sets, a new temporal role is created which has the

same user and permission sets and enabling dura-

tion as the union of time interval sets of the origi-

nal roles.

2. If two temporal roles are enabled for the same

time interval set and have the same user set, a new

temporal role is created with the same user set and

time interval set and with permission set as the

union of permission sets of the original roles.

3. If two temporal roles are enabled for the same

time interval set and have the same permission set,

a new temporal role is created with the same time

interval and permission sets and with user set as

the union of user set of individual roles.

In each of the above cases, the new role is added to the

ﬁnal set of temporal roles and the two individual roles

are removed from the set. This process of merging of

temporal roles was introduced in (Mitra et al., 2013).

4.3 Illustrative Example

We explain the working of TRAC-Miner using the

TUPA matrix of Table 1. The TUPA does not con-

tain any duplicate rows. 3 distinct time intervals are

present in the TUPA - 8 am to 9 am, 7 am to 10 am

and 4 am to 5 am. Time interval 8 am to 9 am is com-

pletely contained inside the interval 7 am to 10 am and

the interval 4 am to 5 am is disjoint from the other

two. Thus, three INT-UPAs, INT -UPA

8 am−9 am

INT -UPA

7 am−10 am

and INT -UPA

4 am−5 am

are cre-

ated and are shown in Tables 2, 3 and 4 respectively.

We assume the value of TRAC to be 2. First, we

process INT -UPA

8 am−9 am

. This UPA does not con-

tain any permission which is exclusively given to only

one user. The candidate roles that are created from

INT -UPA

8 am−9 am

are {p

, p

} and {p

, p

The ﬁrst candidate role can be assigned to two users

and the second candidate role can be assigned to four

users. The second one is selected as per the greedy

choice. This role we shall refer to as r

and is as-

signed to all four users. After these role assignments,

INT -UPA

8 am−9 am

is updated by removing the cov-

ered user-permission assignments. The updated INT -

UPA

8 am−9 am

contains only four ones in the cells (u

), (u

, p

), (u

, p

) and (u

, p

). Only one candi-

date role {p

, p

} is created and is assigned to u

and

. We refer to this role as r

Next, we process INT -UPA

7 am−10 am

. In this

UPA, p

and p

are exclusively given to u

. There-

fore, a role {p

, p

} is created and is assigned to

. We refer to this role as r

. The modiﬁed INT -

UPA

7 am−10 am

now contains ones in cells (u

, p

), (u

, p

), (u

, p

) and (u

, p

). From this

modiﬁed UPA, two candidate roles can be created -

, p

} and {p

}. As per the greedy choice, the sec-

ond candidate role is selected as it can be assigned to

three users - u

, u

and u

. We refer to this role as

. After this role assignments, in the modiﬁed INT -

UPA

7 am−10 am

, the cells (u

, p

) and (u

, p

) contain

one. From this, only a single candidate role {p

} is

created and is assigned to u

and u

. This role is re-

ferred to as r

While processing INT -UPA

4 am−5 am

, it is found

that p

and p

are exclusively assigned to u

and u

respectively. Thus, two roles r

= {p

, p

} and r

, p

} are created, given to u

and u

respectively

and the INT-UPA is updated. After the updation, only

one permission assignment (u

, p

) remains uncov-

ered. So, a role r

containing p

is created and given

to u

. Thus, the temporal roles obtained are as follows

SECRYPT 2021 - 18th International Conference on Security and Cryptography

644

Table 2: INT -UPA

8 am−9 am

1 0 1 1 1

0 0 1 0 1

1 0 1 1 1

0 0 1 0 1

Table 3: INT -UPA

7 am−10 am

0 0 1 0 1

0 0 0 0 1

1 0 0 1 0

0 0 1 0 1

Table 4: INT -UPA

4 am−5 am

0 0 0 0 0

0 1 0 1 0

0 1 0 0 0

1 1 0 0 0

Table 5: Experimental Results for TRAC-Miner.

TRAC Dataset (No. of Users x No. of Permissions)

Value 20 x 20 50 x 50 100 x 100

Roles Time (ms.) Roles Time (ms.) Roles Time (ms.)

1 50.4 5.095 208.7 57.850 490.5 273.919

2 48.6 7.469 205.5 153.031 490.1 2231.087

3 49 7.685 205.6 208.221 490.4 3316.691

4 49.6 7.987 204.4 230.684 490.5 3595.979

5 49.6 8.074 204.5 225.124 490.5 3667.727

6 49.6 8.278 204.4 224.390 490.5 3638.085

7 49.6 7.847 204.4 225.117 490.5 3839.822

8 49.6 7.366 204.4 224.866 490.5 3757.121

9 49.6 7.984 204.4 226.600 490.5 3662.941

10 49.6 7.448 204.4 227.881 490.5 3672.839

11 49.6 7.798 204.4 224.221 490.5 3674.013

12 49.6 7.276 204.4 223.821 490.5 3743.931

13 49.6 7.348 204.4 224.335 490.5 3654.852

14 49.6 7.658 204.4 225.088 490.5 3726.158

15 49.6 8.153 204.4 224.392 490.5 3652.173

16 49.6 7.160 204.4 224.393 490.5 3628.246

17 49.6 8.679 204.4 227.264 490.5 3722.950

18 49.6 8.311 204.4 227.258 490.5 3863.396

19 49.6 7.725 204.4 228.005 490.5 3842.728

20 49.6 8.200 204.4 226.234 490.5 4133.534

- r

= ({u

, u

}, {p

, p

}, {8 am-9 am}), r

({u

, u

}, {p

, p

}, {8 am-9 am}), r

= ({u

}, {p

}, {7 am-10 am}), r

= ({u

, u

}, {p

}, {7 am-

10 am}), r

= ({u

, u

}, {p

}, {7 am-10 am}), r

({u

}, {p

, p

}, {4 am-5 am}), r

= ({u

}, {p

, p

{4 am-5 am}) and r

= ({u

}, {p

}, {4 am-5 am}).

The merging step does not reduce the size of the role

set any further.

5 EXPERIMENTAL RESULTS

For evaluating the performance of our proposed ap-

proach, we have synthetically generated three types

of TUPA matrices containing 20 users and 20 per-

missions, 50 users and 50 permissions and 100 users

and 100 permissions. All the matrices have a den-

sity of 20%, i.e., 20% of all the cells of the TUPA

contain non-null entries. We have added the temporal

component by associating a time interval with each

user-permission assignment chosen from a set of ﬁve

equi-probable time intervals. The following relation-

ships exist among the time intervals - disjoint, con-

tained, overlapping and consecutive. Since the TUPA

matrices are randomly generated, we have created 10

matrices for each type of TUPA. We have varied the

value of TRAC from 1 to 20. The algorithm has been

implemented using Python and the experiments were

carried out on a laptop running macOS 10 and hav-

ing 2.9 GHz i5 processor and 8 GB RAM. In Table 5,

we report the average number of temporal roles and

the average execution in milliseconds for the different

datasets. The average is computed over the 10 sam-

ples for each TUPA type and TRAC value combina-

tion.

As can be observed from the table, the number of

temporal roles is higher for lower values of the con-

straint. This is because lower values of constraint

imply stricter restrictions which in turn means more

number of roles need to be created to satisfy the per-

mission requirements of the user. The execution time

is lower for values 1 and 2 of TRAC and is higher

for the subsequent values. The lower execution time

for constraint values 1 and 2 can be attributed to the

fact that role creation for each INT-UPA does not

go through all the steps of User-Oriented Miner, but

rather through only a few of them. Both the num-

Enforcing Cardinality Constraint in Temporal RBAC

645

ber of roles and the execution time become constant

after a certain value of the constraint which is 6 for

our datasets. The reason behind this is, at high val-

ues of TRAC, the scenario becomes equivalent to role

mining without any constraint enforcement. Also, the

number of roles and execution time increases as the

size of TUPA increases.

6 CONCLUSION AND FUTURE

WORK

In this paper, we have formally deﬁned the problem of

mining a minimal set of temporal roles in presence of

a cardinality constraint which restricts the maximum

number of roles that each user can activate in a spe-

ciﬁc set of time intervals. We have shown this prob-

lem to be NP-complete and have proposed a heuristic

algorithm to solve it. The proposed approach works

in two phases, the ﬁrst phase using an existing con-

strained role mining algorithm to mine the time inter-

val speciﬁc UPAs and the second phase merging the

temporal roles obtained from the ﬁrst phase.

In future, we intend to design temporal role min-

ing methods capable of enforcing the various cardi-

nality constraints proposed for the GTRBAC model

either in isolation or in combination. Also, it will

be interesting to investigate how role mining metrics

other than the number of temporal roles can be min-

imized in presence of these constraints. Moreover,

the enforcement of cardinality constraints in presence

of an administrative temporal RBAC model can be a

possible future direction of research.

REFERENCES

Batra, G., Atluri, V., Vaidya, J., and Sural, S. (2021). In-

cremental maintenance of abac policies. In 11th ACM

Conference on Data and Application Security and Pri-

vacy, page 185 – 196.

Bertino, E., Bonatti, P. A., and Ferrari, E. (2001). TRBAC:

A Temporal Role-Based Access Control Model. ACM

Trans. on Info. and Sys. Security, 4(3):191–233.

Blundo, C. and Cimato, S. (2012). Constrained role mining.

In Proc. of 8th Int. Workshop on Security and Trust

Management, pages 289–304.

Blundo, C., Cimato, S., and Siniscalchi, L. (2020). Man-

aging constraints in role based access control. IEEE

Access, 8:140497–140511.

Carlo, B., Stelvio, C., and Luisa, S. (2018). Postprocess-

ing in constrained role mining. In Int. Conf. on In-

telligent Data Engineering and Automated Learning,

pages 204–214.

Das, S., Sural, S., Vaidya, J., Atluri, V., and Rigoll, G.

(2019). Vismap: Visual mining of attribute-based ac-

cess control policies. In Int. Conf. on Information Sys-

tems Security, pages 79–98.

Ene, A., Horne, W., Milosavljevic, N., Rao, P., Schreiber,

R., and Tarjan, R. E. (2008). Fast exact and heuristic

methods for role minimization problems. In Proc. of

13th ACM Symposium on Access Control Models and

Technologies, pages 1–10.

Gupta, E., Sural, S., Vaidya, J., and Atluri, V. (2021).

Attribute-based access control for nosql databases. In

11th ACM Conference on Data and Application Secu-

rity and Privacy, pages 317 – 319.

Harika, P., Nagajyothi, M., John, J. C., Sural, S., Vaidya, J.,

and Atluri, V. (2015). Meeting cardinality constraints

in role mining. IEEE Trans. on Dependable and Se-

cure Computing, 12(1):71–84.

Hingankar, M. and Sural, S. (2011). Towards role min-

ing with restricted user-role assignment. In Proc. of

2nd Int. Conf. on Wireless Communication, Vehicular

Technology, Information Theory and Aerospace Elec-

tronic Systems Technology, pages 1–5.

Hu, V. C., Kuhn, D. R., and Ferraiolo, D. F. (2015).

Attribute-Based Access Control. Computer (IEEE),

48(2):85–88.

John, J. C., Sural, S., Atluri, V., and Vaidya, J. (2012).

Role mining under role-usage cardinality constraint.

In Proc. of 27th Int. Info. Security and Privacy Conf.,

pages 150–161.

Joshi, J. B. D., Bertino, E., Latif, U., and Ghafoor, A.

(2005). A Generalized Temporal Role-Based Access

Control Model. IEEE Trans. on Knowledge and Data

Engg., 17(1):4–23.

Lu, H., Hong, Y., Yang, Y., Duan, L., and Badar, N. (2013).

Towards user-oriented RBAC model. In Proc. of 27th

Int. Conf. on Data and Applications Security and Pri-

vacy, pages 81–96.

Lu, H., Hong, Y., Yang, Y., Duan, L., and Badar, N. (2015).

Towards user-oriented RBAC model. J. of Comp. Se-

curity, 23(1):107–129.

Mitra, B., Sural, S., Atluri, V., and Vaidya, J. (2013). To-

ward mining of temporal roles. In Proc. of 27th Conf.

on Data and Applications Security and Privacy, pages

65–80.

Mitra, B., Sural, S., Atluri, V., and Vaidya, J. (2015).

The generalized temporal role mining problem. J. of

Comp. Security, 23(1):31–58.

Mitra, B., Sural, S., Vaidya, J., and Atluri, V. (2016). Min-

ing temporal roles using many-valued concepts. Com-

puters & Security, 60:79 – 94.

Sandhu, R. S., Coyne, E. J., Feinstein, H. L., and Youman,

C. E. (1996). Role-Based Access Control Models.

IEEE Computer, 29(2):38–47.

Stoller, S. and Bui, T. (2017). Mining hierarchical tempo-

ral roles with multiple metrics. J. of Comp. Security,

26(1):121–142.

Xu, Z. and Stoller, S. (2015). Mining Attribute-Based Ac-

cess Control policies. IEEE Transactions on Depend-

able and Secure Computing, 12(5):533–545.

SECRYPT 2021 - 18th International Conference on Security and Cryptography

646
