A Multi-modal Visual Emotion Recognition Method to Instantiate an

Ontology

Juan Pablo A. Heredia

1 a

, Yudith Cardinale

1,2 b

, Irvin Dongo

1,3 c

and Jose D

ıaz-Amado

1,4 d

Computer Science Department, Universidad Cat

olica San Pablo, 04001 Arequipa, Peru

Computer Science Department, Universidad Sim

on Bol

ıvar, 1080 Caracas, Venezuela

Univ. Bordeaux, ESTIA Institute of Technology, 64210 Bidart, France

Electrical Engineering, Instituto Federal da Bahia, 45078-300 Vitoria da Conquista, Brazil

Keywords:

Emotion Recognition, Multi-modal Method, Emotion Ontology, Visual Expressions.

Abstract:

Human emotion recognition from visual expressions is an important research area in computer vision and

machine learning owing to its signiﬁcant scientiﬁc and commercial potential. Since visual expressions can

be captured from different modalities (e.g., face expressions, body posture, hands pose), multi-modal meth-

ods are becoming popular for analyzing human reactions. In contexts in which human emotion detection is

performed to associate emotions to certain events or objects to support decision making or for further anal-

ysis, it is useful to keep this information in semantic repositories, which offers a wide range of possibilities

for implementing smart applications. We propose a multi-modal method for human emotion recognition and

an ontology-based approach to store the classiﬁcation results in EMONTO, an extensible ontology to model

emotions. The multi-modal method analyzes facial expressions, body gestures, and features from the body and

the environment to determine an emotional state; this processes each modality with a specialized deep learn-

ing model and applying a fusion method. Our fusion method, called EmbraceNet+, consists of a branched

architecture that integrates the EmbraceNet fusion method with other ones. We experimentally evaluate our

multi-modal method on an adaptation of the EMOTIC dataset. Results show that our method outperforms the

single-modal methods.

1 INTRODUCTION

In human communication, non-verbal messages con-

tain lots of information, including emotional state, at-

titude, or intentions of the people (Knapp et al., 2013).

Thus, human emotion recognition from visual expres-

sions is an important research area of computer vi-

sion and deep learning owing to its signiﬁcant aca-

demic, scientiﬁc, and commercial potential (Zhang

et al., 2018).

Most of the research related to visual expressions

analysis for emotion recognition refers to facial ges-

tures, leaving those of the rest of the body a little

aside (Lhommet et al., 2015). However, the analy-

sis of other visual factors, such as body posture, the

move of limbs, clothes or breath, or the context, rep-

https://orcid.org/0000-0002-6126-4881

https://orcid.org/0000-0002-5966-0113

https://orcid.org/0000-0003-4859-0428

https://orcid.org/0000-0001-8447-784X

resents an alternative or complement to improve emo-

tion recognition results (Noroozi et al., 2018). In

particular, analyzing the body posture is important,

because it can express emotional states involuntarily

and spontaneously (Knapp et al., 2013; Cowen and

Keltner, 2020). Similarly, the physical environment

or context matters because it can inﬂuence or condi-

tion the people emotional state (Knapp et al., 2013;

Mittal et al., 2020). This context can communicate

about human-object and human-human interactions

that occur indirectly or separately (Cowen and Kelt-

ner, 2020).

In this sense, since people naturally express emo-

tions in simultaneous different ways (i.e., face expres-

sions, hands posture, body posture) that can be condi-

tioned by their context, multi-modal methods are suit-

able and are becoming popular for emotion recogni-

tion (Noroozi et al., 2018; Kaur and Kautish, 2019).

Multi-modal methods, generally based on deep learn-

ing models, simultaneously analyze the different vi-

sual expression and factor modalities to identify hu-

Heredia, J., Cardinale, Y., Dongo, I. and Díaz-Amado, J.

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology.

DOI: 10.5220/0010516104530464

In Proceedings of the 16th International Conference on Software Technologies (ICSOFT 2021), pages 453-464

ISBN: 978-989-758-523-4

453

man reactions in different research contexts (e.g.,

human-computer interaction, healthcare, extracting

opinions about events or objects) (Kaur and Kautish,

2019; Egger et al., 2020).

These multi-modal methods can overcome the

limitations of performing emotion recognition using

only one kind of signal or gesture, getting more robust

results. Nevertheless, they have other limitations for

recognizing emotions, related to the dataset used, the

modality selection, the computational requirements

for a proper execution, and the modalities synthesis

or fusion. The data is a limitation because deep learn-

ing methods need a lot of data for learning. More-

over, most datasets are focused and designed for only

one modality, commonly facial expressions (Kaur and

Kautish, 2019). Therefore, a data pre-processing on

the original samples should be used to obtain the data

of various types (i.e., the modality data); even so, the

presence of all modalities is not guaranteed, which is

a problem that should be solved in the training phase.

The selection of modalities depends on the purpose

of the application and the data available, and typi-

cally, the model demands having all selected modali-

ties to perform ideally. The fusion of modalities is a

very important aspect and must ensure that all avail-

able data are used to the maximum (Soleymania et al.,

2017). The methods for merging the modalities are

based on probabilities (e.g., EmbraceNet (Choi and

Lee, 2019a)), simple or complex trainable decisions

(e.g. Multiplicative Fusion (Liu et al., 2018)), another

learning phase (e.g., Multiple Kernel Learning), and

so on. Most of these methods can be implemented

with any deep learning multi-modal method, but the

same quality of results is not assured for all (Dong

et al., 2020; Egger et al., 2020).

To overcome these limitations, we propose a

multi-modal method able to analyze facial expre-

ssions, body gestures, and features from the body and

the environment from images, to estimate the emo-

tional state of a person. Nevertheless, it is not manda-

tory to analyze all modalities; the model handles the

absence of some of the modalities (e.g., hidden face).

To recognize an emotion, each type of cues is pro-

cessed in a specialized and independent deep learning

model. Then, a fusion method is applied, which con-

sists of a branched architecture that integrates multi-

ple fusion methods. This fusion method, called Em-

braceNet+, extends the EmbraceNet fusion method by

altering its structure and integrating it into an archi-

tecture that allows three EmbraceNets to be used with

any other fusion method.

Since the analysis of human emotions is gener-

ally performed to associate emotions to certain events

or objects and consequently to make decisions or for

further analysis, keeping this information in seman-

tic repositories offers a wide range of possibilities for

implementing smart applications (Bertola and Patti,

2016; Chen et al., 2016; Cavaliere and Senatore,

2019; Graterol et al., 2021).

To support decision making and post-analysis

from the analysis of emotions, we use an emotion

ontology, called EMONTO (Graterol et al., 2021).

EMONTO is an extensible emotion ontology, that can

be integrated with other speciﬁc domain ontologies.

Therefore, it is possible to combine the semantic in-

formation of emotions with other ontologies, that rep-

resent entities to which the emotions can be associ-

ated – e.g., emotions produced by artworks in muse-

ums or by the food in restaurants or by candidates in

government elections.

We experimentally evaluate our multi-modal

method in an adaptation of the EMOTIC

dataset (Kosti et al., 2017; Kosti et al., 2019);

showing that the combination and integration of

various fusion methods allow beating the results from

single-modal methods and even beat those obtained

from using only EmbraceNet as fusion method.

Furthermore, the results obtained are competitive

and similar to those reported from the state-of-the-art

methods: EMOTIC model (Kosti et al., 2019) and

EmotiCon (Mittal et al., 2020).

In summary, the contribution of this work is three-

fold: (i) a multi-modal method to recognize human

emotions from images in any situation, which adapts

to the present modalities (i.e., face expression, body

posture, features from body and context); (ii) Em-

braceNet+, a fusion method that, like EmbraceNet,

can be used in any multi-modal machine learning-

based model; and (iii) the integration of an extensi-

ble emotion ontology (EMONTO) and the approach

to instantiate it; this semantic repository can be com-

bined with other domain ontologies to relate emotions

in any context.

2 RELATED WORK

In this section, we survey some studies on visual emo-

tion recognition using deep learning, common ap-

proaches, and recent achievements on fusion models;

as well as the studies on emotion recognition based

on ontologies.

2.1 Visual Emotion Recognition

The common visual emotion recognition from human

faces began as an exploration of deep learning mod-

els, such as Convolutional Neural Networks (CNN),

ICSOFT 2021 - 16th International Conference on Software Technologies

454

focused on the face image region, as in (Parkhi et al.,

2015). However, now some additional aspects are

considered to improve the results. For instance,

(Zadeh et al., 2019) use a Gabon ﬁlter at the beginning

as an extra feature extractor. Recent deep learning

models, such as Graph CNN (GCNN), have gained

popularity in the analysis of body movements and

postures to detect human emotions.

Moreover, the context analysis started as a recog-

nition of the emotions that an image expresses by it-

self. Currently, the context is used as a complement of

people data for achieving competitive results, even in

situations where the people data is unclear or inappro-

priate. For example, the approach proposed by (Lee

et al., 2019) uses the whole image without the facial

region, by processing the context with an attention-

perception model. This new type of approach is al-

ready considered a multi-modal one.

Most multi-modal methods differ mainly in the

modalities of input data used, and in the method to fu-

sion the modalities. The method proposed by (Kosti

et al., 2019) uses two kinds of data: the whole image

and a sub-image of the person. This model processes

the inputs with two CNN models, whose results are

concatenated and processed again with a Multi-Layer

Perceptron (MLP) neural network. (Mittal et al.,

2020) propose a work that uses up to four different

modalities: the face landmarks, a graph of the human

posture, the whole image without the region delim-

ited by the person, and a depth mask. The human

posture graph is processed by a GCNN model and the

rest of modalities by different CNN models. The fu-

sion of this model consists on merging the results of

facial and postural modalities with the Multiplicative

Fusion technique, then, similar to the work proposed

by (Kosti et al., 2019), it concatenates the remained

three results and use an MLP neural network to get

the ﬁnal prediction. As well as the concatenation,

the Weighted Sum (WS) is commonly used because

it is very simple to apply and does not need many re-

sources (Dong et al., 2020).

The approaches about multi-modal emotion rec-

ognition have proven be effective applications in real-

world data (Zhang et al., 2019). For instance, in

robotic, the studies presented by (Perez-Gaspar et al.,

2016; Chumkamon et al., 2016; Graterol et al., 2021)

are based on a multimodal emotion recognition, un-

derstanding the reality with data coming from the

robots’ sensors, to then make decisions from the data

processed. Other intelligent systems that use the emo-

tion analysis, could be beneﬁted with a multi-modal

method, such as the music recommender proposed

by (Gilda et al., 2017), which selects songs according

to the listener mood, or the abnormal human behav-

ior recognizer presented by (Caruccio et al., 2019),

which uses several contexts, including one related to

the recognition of emotions, to improve the accuracy

of the results.

2.2 Emotion Recognition and

Ontologies

Some studies combine emotion recognition with on-

tologies. However, most of them use the ontologies

to support the classiﬁcation process on recognizing

emotions. Besides that, they are limited, either to a

speciﬁc modality (e.g., text, face, body) or a speciﬁc

source (e.g., text, images, video). For example, the

approaches to recognize emotions from texts in social

media proposed by (Chen et al., 2016; Cavaliere and

Senatore, 2019), are based on their own emotion on-

tologies to support the classiﬁcation process. These

works are not suitable to establish relations between

emotions and objects or events, since they are not able

to represent such entities. An approach to perform

sentiment analysis on social media to relate sentiment

to artworks is proposed by (Bertola and Patti, 2016).

However, the applicability of this approach cannot be

extended to other domains, as our proposal.

Regarding emotions modeling, there are many on-

tologies aimed at representing emotions. However,

most of them are domain dependent or emotion model

dependent, such as the work presented by (Zhang

et al., 2013), whose ontology is dedicated to repre-

sent electroencephalographic (EEG) data and applied

it to detect human emotional states; the framework

presented by (Garay-Vitoria et al., 2019), based on

an emotion ontology, applicable for developing af-

fective interaction systems; or the ontology proposed

by (Lin et al., 2018b) to represent emotions with vi-

sual elements. Other emotion/sentiment ontologies

model an emotion as a main entity which has asso-

ciated modalities, dimensions, categories, and other

features (Grassi, 2009; Lin et al., 2018a), and also

fuzzy concepts (Ali et al., 2017; Dragoni et al., 2018),

but they are still restricted and limited in applica-

bility and extensibility, due to the lack of connec-

tion with entities that can connect values from other

domains (e.g., an object entity can be instantiated

as an artwork in the tourism domain). Based on

the previous limitations, a recent general ontology,

called EMONTO (Graterol et al., 2021), has been pro-

posed to represent several sources, modalities, differ-

ent emotion models, and also be extended with spe-

ciﬁc domain ontologies to represent objects/events to

which sentiment can be related.

Since our aim is to support the development of

further applications able to analyze semantic informa-

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology

455

tion, independently of the domain, the modalities, and

the emotion classiﬁcation, we adopt EMONTO as the

model to store the recognized emotions into a seman-

tic repository.

3 MULTI-MODAL EMOTION

RECOGNITION

The whole pipeline of our proposal consists of four

phases, as shown in Figure 1. The ﬁrst three are

about the multi-modal emotion recognition method:

(i) the extraction of data for each modality; (ii) emo-

tion recognition using independent methods that deal

with each modality; and (iii) the fusion of modalities

to obtain a multi-label classiﬁcation. The last one, is

the phase of instantiation of the semantic repository,

which is developed in Section 4.

3.1 Proper Data Acquisition

The input of the proposed method are images, which

ideally should have at least one person. The process

for obtaining the appropriate data (i.e., body image,

face image, context image, and joint and limb graph)

is as follows:

1. Each person within the image is recognized using

a computer vision model like YOLO (Farhadi and

Redmon, 2018), which provides a list of bounding

boxes with each person’s location.

2. Using the bounding boxes, sub-images of people

are extracted. Moreover, the context image is

getting by removing everything in the bounding

boxes. For each bounding box, a sub-image and a

context image is generated.

3. The sub-images of persons are processed using

two deep learning models. One of them is the HR-

Net (Sun et al., 2019) to human pose estimation

that gives the location of every visible person’s

joint; with these data, the joint and limb graphs

that encode the body gestures are generated. The

other model is the RetinaFace (Deng et al., 2019)

that provides several facial information, however

only the face bounding box is used.

4. Another sub-image is extracted using the face

bounding box, and as well as with the whole im-

age, the face is removed from the person image,

which conform the body image. The face sub-

image is the face image.

The reshaping of the four vectors obtained is

implementation-free, but it must be speciﬁc shapes:

the body and context images (224 × 224 × 3); the

face image (48 × 48); and the joint and limb graphs

(Nchanels × N f rames × N joints or Nlimbs), where

Nchanels is the x and y axises position and the point

conﬁdence, N f rames is the number of frames set to 1,

and N joints and Nlimbsset are the numbers of joints

and limbs, both set to 15 due the HRnet model pre-

trained in MS-COCO.

3.2 Independent Processing

The proposed multi-model method processes each

modality in particular ways:

Facial Modality. It is processed with an adaptation

of the VGG-face model (Parkhi et al., 2015). The

same architecture is used, but the ﬁnal MLP is modi-

ﬁed, since the dimensions of the input images, set to

48 ×48, cause the number of end features to decrease

to 512. Therefore, the fully connected layers become

just one of 512-N neurons – i.e., there are 512 input

neurons and N output neurons, N is the number of

emotions. The new VGG-face consists of ﬁve convo-

lutional blocks and the ﬁnal MLP. The convolutional

blocks have two convolutional layers of 64 ﬁlters, two

of 128, four of 256, and four of 512 ﬁlters. At the end

of each convolutional block, there is a max pooling

layer. Each convolutional layer also contains a batch

Figure 1: Structure of the entire proposal.

ICSOFT 2021 - 16th International Conference on Software Technologies

456

normalization and a ReLU activation function.

Postural Modality. Joint and limb graphs represent

the human posture that capture body gestures and al-

lows analyzing the movement and dynamics of the

body’s limbs. We use the Directed GCNN (DGCNN)

model (Shi et al., 2019) to process this modality. Di-

rect graphs allow the model to learn about the de-

pendency and dynamics of joints and limbs. The

DGCNN model is based on graph-temporal convo-

lutions, which contain DGCNN blocks, bi-temporal

convolutions, a ReLU layer, and a residual layer that

in some cases are bi-temporal convolutions. The bi-

temporal convolution consists of two convolutions

on the temporal dimension. The architecture of this

model is composed of ten layers of graph-temporal

convolution, the ﬁrst four of 64 ﬁlters, the next three

of 128, and the last three of 256 ﬁlters; at the end,

an MLP that outputs the ﬁnal classiﬁcation (Shi et al.,

2019).

Contextual and Body Modalities. For both con-

text and body modalities the same model is used

for their processing: the Attention Branch Network

(ABN) (Fukui et al., 2019). It is based on an atten-

tion mechanism to improve the visual explanation and

image recognition with CNN. The ABN is made up

of three components: a feature extractor, the atten-

tion branch, and the perception branch; the attention

mechanism works as a linker of the three main com-

ponents.

For our proposed method, the idea of removing

the persons from the image to process the context,

presented by (Mittal et al., 2020) in EmotiCon, is fol-

lowed. However, they delete everything within the

person bounding box, losing body features such as

clothing, held objects, or other items. In contrast, we

process the body as another modality. The body is

processed in the same way the context is processed

but removing the face in this case. Thus, our model

can recognize relevant objects or agents that can in-

ﬂuence the emotional state.

3.3 Fusion Method: EmbraceNet+

The fusion method is usually one of the main contri-

butions of multi-modal approaches. In our proposed

fusion method, the EmbraceNet model (Choi and Lee,

2019a) is taken as the basis. EmbraceNet can be ap-

plied to merge intermediate data and then apply an ad-

ditional model, or to merge the ﬁnal results and then,

if it is necessary, apply an additional model. More-

over, thanks to the versatility of EmbraceNet, there

are other ways to implement it, being able to use more

than one EmbraceNet or even with other fusion meth-

ods – e.g., weighted sums or votes that already pro-

cess characteristics and can provide additional rele-

vant information (Dong et al., 2020).

The proposed fusion method, called Embrace-

Net+, is a branched architecture that allows using

more than one EmbraceNet together with other fusion

methods (see Figure 2). It has two EmbraceNets that

deal with intermediate data and ﬁnal outputs from ev-

ery modality, respectively; and then, their results are

the input for a third EmbraceNet, along with other fu-

sion methods. The ﬁrst two EmbraceNets, and each

of the additional fusion methods used, can be viewed

as branches.

Every EmbraceNet is composed by docking lay-

ers and an embrace layer (Choi and Lee, 2019a). The

docking layers have two functions: transform the in-

puts from each modality into a same shape and learn

about the correlation among modalities, they learn

from the features of every modality. Sometimes, the

input vectors already have the same shape, or they

have a few features; thus, an MLP of one layer could

be not enough to get a signiﬁcant improvement re-

Figure 2: EmbraceNet+ Architecture.

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology

457

garding single modality methods. For this reason, we

also propose a modiﬁcation over the docking layers of

the two EmbraceNets that directly process the modal-

ities results. This modiﬁcation consists in adding two

layers to the MLP in docking layer: a fully connected

and a dropout; it is expected that the docking layers

improve their modalities correlation and work as ad-

ditional feature extractors to improve the ﬁnal result.

Thus, the new docking MLP are composed by:

1. A fully connected layer of I

(k)

-D

(k)

x,1

, where (k) in-

dicates the modality coming from the k

modality

and x the container EmbraceNet, x = 1 if it deals

with intermediate data and x = 2 if it is the sec-

ond one. I represents the intermediate data feature

number, in our case everyone is 512 or N(number

of emotions), therefore, all D

∗,1

are also equal and

they are set as D

1,1

= 1024 and D

2,1

= 64.

2. A dropout layer, mainly to avoid an overﬁting in

the training phase. This layer is set with 0.5 as the

factor of drop. The addition of this layer also re-

sponds to the proposed improvements to the orig-

inal EmbraceNet, where a training with random

dropout of modalities is present for strengthen the

method.

3. A fully connected layer of D

(k)

x,1

-D

x,2

that mainly

must set each vector in a same shape; then, for

the ﬁrst EmbraceNet is set D

1,2

= 512 and D

2,2

32. The values of each docking layer were set by

experimentation.

The proposed method also has as strength the us-

ing of another fusion strategies. We propose apply-

ing over the modalities results a WS and a concate-

nation, then both are used together with the prior

EmbraceNets output, as the input to the third Em-

braceNet. Before the ﬁrst EmbraceNet output go to

the ﬁnal merge, it is applied an extra MLP of 512-

128, to avoid affecting the training of the ﬁnal fu-

sion because the dramatic difference in the number

of features. Likewise, the docking layers of the ﬁnal

EmbraceNet are not modiﬁed; they are four and their

conﬁgurations are 128-64, 32-64, 32-64, and 8-64, to

deal with the ﬁrst Embracenet, the second one, the

concatenation and the WS, respectively.

Respecting the embrace layers, the original is used

for every EmbraceNet without modiﬁcation. This

layer is based on the multinomial sampling, and it

is deﬁned by the Equation (1), where e

is the em-

braced result for the i

feature; the r

(k)

vector of

modality is obtained by r

(k)

∼ Multinomial(1, p),

where p is a deﬁned probability, there are as many p

as modalities, such that

∑

(k)

= 1; d

(k)

represents

the result of the docking layers. This process ensures

that only one modality contributes to i

component of

the embraced vector. Those probabilities from Em-

braceNets, and of the WS, are set the same for all,

1/n

modalities

, other distributions were probed but a sig-

niﬁcant improvement was not found.

∑

(k)

· d

(k)

(1)

The proposed method deals with missing or wrong

data by using availability values: 1 if there are data for

the modality, 0 otherwise. There are as many values

as modalities. The absence of data is detected in the

initial data passing; for example, for posture modal-

ity, a threshold of conﬁdence is set to determinate if

the posture estimation is favorable. When there is a

0 in availability values, internal probabilities, of each

EmbraceNet and WS, are adjusted, maintaining the

same distribution but without considering the miss-

ing modality. For obtaining the ﬁnal inference, the

output represented as a real number vector is con-

verted to a binary vector, based on thresholds. These

thresholds could be deﬁned in the validation or test-

ing phases, based on the precision-recall curve. The

implementation of the multi-modal model is available

in the GitHub repository https://github.com/juan1t0/

multimodalDLforER.

4 EMOTION ONTOLOGY AND

INSTANTIATION

The data provided by emotion recognition methods,

such as emotion labels, its probabilities, modalities,

Figure 3: EMONTO: An Extensible Emotion Ontology.

ICSOFT 2021 - 16th International Conference on Software Technologies

458

source, as well as the entities to which the emotions

are related, such as Person, Object, Place, are nor-

mally stored for further analysis and decision mak-

ing, which can generate complex networks of knowl-

edge. In this sense, it is evident the necessity of a

well-deﬁned and standard model, such as ontologies,

for representing the huge quantity of knowledge man-

aged by applications that produce real-time values. In

the following, we describe EMONTO (Graterol et al.,

2021), the ontology that is integrated at the end of the

pipeline of our multi-modal emotion recognition pro-

cess.

4.1 EMONTO: An Extensible Emotion

Ontology

EMONTO is an extensible ontology that represents

emotions under different categorization proposals. It

adopts some concepts from several emotion ontolo-

gies (Grassi, 2009; Lin et al., 2018a) to provide

compatibility. Figure 3 shows the main classes of

EMONTO. The central class is emo:Emotion, which

has a category (hasCategory) according to a Cate-

gory class. Currently, EMONTO considers Archety-

pal (Grassi, 2009), Douglas Cowie (Grassi, 2009),

and Robert Plutchik (Plutchik, 1980) emotion cate-

gorizations, which group emotions into 6, 25, and

8 values, respectively. Nevertheless, any other cate-

gorization model can be integrated as a subclass of

emo:Category.

EMONTO has emo:Event as a class that con-

nects emo:Object, emo:Person, and emo:Emotion

entities. An emotional Event is produced by

(isProducedBy) a Person and also it is caused by

(isCausedBy) an Object (e.g., artworks, candidates,

plates). An Event can produce several Emotions.

The entities emo:Object and emo:Person are

general classes that can connect other ontologies,

such as museum and artwork ontologies (Pinto-De la

Gala et al., 2021) as Object or user-proﬁle ontolo-

gies (Katifori et al., 2007) as Person. EMONTO is

extensible and ﬂexible to be easily adopted in sce-

narios where data related to the recognized emo-

tions, need to be stored for further analysis. The

ontology provides the modality (emo:Modality) of

the information used to recognize the emotion (e.g.,

emo:Gesture, emo:Face, emo:Posture), and the

type of annotator (emo:AutomaticAnnotator and e-

mo:HumanAnnotaton). Moreover, datatype proper-

ties emo:hasIntensity and emo:hasConfidence

are associated to the category to express the level of

intensity and conﬁdence (probability score), respec-

tively; ﬂoat values between 0 and 1.0.

4.2 Instantiation of the Emotion

Ontology

Once the emotions are recognized in the previous

phases of the pipeline (see Figure 1), an Event is

created to represent the emotional event, which con-

sists of a set of emotions produced at a certain time.

For example, let’s consider anger and disgust as

the detected emotions (EM0001 and EM0002, respec-

tively) from the Douglas Cowie category; therefore,

an emotional event is created (<EV0001 rdf:type

emo:Event>) and associated to some datatype proper-

ties – e.g., <EV0001 emo:createdAt 1612748699>,

where the object value is a Unix Timestamp (date).

Afterward, the Event is associated to a Person and Ob-

ject (e.g., <EV0001 emo:isProducedBy P0001> and

<0001 emo:isCausedBy O0001>, where P0001 rep-

resents a Person and O0001 represents the Object that

caused the Emotion event EV0001).

Person and Object should be also recognized by

using other models that can be combined with our

multi-modal method in the proper data acquisition

phase. For example, by applying face recognition to

identify registered or new users in the system and ob-

ject detection to recognize speciﬁc objects (e.g., art-

works in museums, plates in restaurants). This work

is focused on the emotion recognition, Person and

Object detection is beyond the scope of this research.

According to the results of the emotion recog-

nition method, which are anger and disgust

in the previous example, the emotion entities

are created (<EM0001 rdf:type emo:Emotion> and

<EM0002 rdf:type emo:Emotion>) and associated

to the Event (<EV0001 emo:produces EM0001> and

<EV0001 emo:produces EM0002>). Each emo-

tion has a Category (<EM0001 emo:hasCategory

C0001> and <EM0002 emo:hasCategory C0002>)

which can be Archetypal, Douglas Cowie, or

Robert Plutchik classiﬁcations (<C0001 rdf:ty-

pe ArchetypalCategory>, <C0002 rdf:type Ar-

chetypalCategory>). The datatype properties

emo:hasConfidence and emo:emotionValue are

added to the Category (<C0001 emo:hasConfiden-

ce 0.13>, <C0001 emo:emotionValue "anger">

and <C0002 emo:hasConfidence 0.35>, <C0002

emo:emotionValue "disgust">) with the values

obtained by the emotion recognition method (e.g.,

0.13 and 0.35 as conﬁdence - probabilities; ”anger”

and ”disgust” as emotions). Modality and Annotator

are also instantiated.

Algorithm 1 presents the general process of the

ontology instantiation. First, libraries related to the

RDF management have to be import (line 1), then a

new Graph, which contains the RDF triples is cre-

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology

459

ated (line 2). Namespaces of the ontology are added

(lines 3-5). From line 6 to line 15, new RDF triples

are added to the Graph.

Algorithm 1: Creating RDF triples.

1 import RDF libraries

2 g = Graph()

3 EMO = Namespace(”http://www.emonto.org/”)

//Creating a Namespace.

4 g.add namespace(”emo”, EMO) //Adding the

namespace EMO.

5 g.add namespace(”foaf”, FOAF) //Adding the

namespace FOAF, which is already deﬁned in the

libraries.

6 g.add triple((EMO.EV0001, RDF.type,

EMO.Event)) //Creating an Event.

7 g.add triple((EMO.P0001, RDF.type,

FOAF.Person)) //Creating a Person.

8 g.add triple((EMO.O0001, RDF.type,

EMO.Object)) //Creating a Object.

9 g.add triple((EMO.EM0001, RDF.type,

EMO.Emotion)) //Creating an Emotion 1.

10 g.add triple((EMO.EM0002, RDF.type,

EMO.Emotion)) //Creating an Emotion 2.

11 g.add triple((EMO.EV0001, EMO.produces,

EMO.EM0001)) //Associating EV0001 to

EM001.

12 g.add triple((EMO.EV0001, EMO.produces,

EMO.EM0002)) //Associating EV0001 to

EM002.

13 ...

14 g.add

triple((EMO.C0001, EMO.hasConﬁdence,

Literal(0.13))) //Conﬁdence value.

15 g.add triple((EMO.C0001, EMO.emotionValue,

Literal(”anger”))) //Recognized emotion.

16 ...

Algorithm 2: Obtaining emotions of artwork

Mona Lisa.

1 import RDF libraries

2 g = Graph()

3 g.read(”database emotions.ttl”, format=”ttl”)

4 g.add namespace(”emo”,

”http://www.emonto.org/”)

5 qres = g.query( ”SELECT ?emotion l

6 WHERE {

7 ?emotion a emo:Emotion ;

8 ?emotion emo:emotionValue

9 ?emotion l .

10 ?event a emo:Event ;

11 ?event emo:produces ?emotion ;

12 ?event emo:isCausedBy

13 ?object.

14 ?object a emo:Object ;

15 ?object rdfs:label ”Mona Lisa” .

16 }”)

The semantic repository can be queried later for

speciﬁc information, such as artworks and places in

the tourism domain. For instance, Algorithm 2 re-

trieves the emotions produced by the Mona Lisa art-

work. Libraries related to the RDF manipulation are

imported (line 1); then, a Graph should be initialized

to read the RDF triples (line 2 and line 3); the names-

paces used in the ontology have to be added (line 4);

then, following the SPARQL syntax, a query is per-

formed (lines 5-15).

5 EVALUATION OF THE

MULTI-MODAL METHOD

In this section, we show the performance of our

multi-modal method compared with the EMOTIC

model (Kosti et al., 2019), which was proposed along

with the dataset EMOTIC, and EmotiCon (Mittal

et al., 2020). We detail the procedure carried out to

adequate the dataset used and the achieved results.

5.1 Dataset Adequacy

The EMOTIC database provides the emotion annota-

tions along with the bounding box of the person who

feels the emotion annotated. Therefore, the process of

person recognition and location is omitted.

EMOTIC has 26 labeled emotions as discrete cat-

egories and almost no images have a single category;

that is, the classiﬁcation is a multi-class and multi-

label problem. Some of those discrete categories are

speciﬁc and not common; therefore, they may not

provide relevant information in most real-world ap-

plications. Because of this, we relabel the dataset

by grouping similar emotions into Category Groups

(CG), using the taxonomy proposed in (Plutchik,

1980) and in accordance with the deﬁnition of each

original emotion (Kosti et al., 2017). Those CG are:

Anger, Anticipation, Disgust, Fear, Joy, Sadness, Sur-

prise, and Trust; the original emotions included in

each CG are detailed in Table 1. Besides, the discrete

categories are unbalanced; thus, a weighted random

sampler was used in the training phase, oversampling

some samples of the categories with less presence. In

addition, a random crop function is applied to perform

a data augmentation.

Table 1: Grouping of the original EMOTIC emotions into

eight categories.

Cat. Group Original Emotions

Anger Anger, Annoyance, Disapproval

Anticipation Anticipation, Engagement

Disgust Aversion, Disconnection, Fatigue,

Yearning

Fear Disquietment, Embarrassment,

Fear

Joy Affection, Excitement, Happiness,

Peace, Pleasure

Sadness Pain, Sadness, Sensitivity, Suffer-

ing

Surprise Doubt/Confusion, Surprise

Trust Conﬁdence, Esteem, Sympathy

ICSOFT 2021 - 16th International Conference on Software Technologies

460

Table 2: Results of the AP metric obtained by single-modal

methods.

Cat. Modalities

Group Body Contextual Facial Postural

Anger 13.60 14.11 15.06 1.02

Anticip. 88.46 87.73 85.75 1.68

Disgust 30.34 31.89 24.63 3.25

Fear 17.29 17.06 15.86 9.21

Joy 81.28 81.47 79.80 82.22

Sadness 14.85 14.53 10.82 2.39

Surprise 23.04 22.40 19.99 4.10

Trust 71.43 69.29 57.82 10.50

mAP 42.54 42.31 38.72 14.30

5.2 Results

Our experiments are split in two: (i) comparisons

with the Average Precision (AP) and mean AP (mAP)

metrics with all single-modal and multi-modal

methods; and (ii) an evaluation of the inferences

results, with the classiﬁcation metrics Accuracy

and F1 score. These experiments were performed

with the test set of the adapted EMOTIC database

(which represents the 20% of the samples), which

uses the AP and mAP as the standard to report the

results (Kosti et al., 2017). Regarding the training

phase, the descend gradient algorithm was used

with a learning rate of 0.001; because classiﬁcation

is a multi-class and multi-label problem, the Bi-

nary Cross-entropy loss function with logistic was

used. The training phase was performed in 32 epochs.

Single-modal Results Comparison. Results from

each modality (body, contextual, facial, and postural)

in terms of every emotion and in average are shown in

Table 2. Concerning the results of AP metrics for each

CG, the best result by modality varies. For Joy, the

postural modality achieved a score of 82.22; however,

this modality has too small values for other groups

of emotions, not even reaching 5.0 score in most of

them. The body modality achieves the best scores in

Trust (71.43), Fear (17.29), Surprise (23.04), Sadness

(14.85), and Anticipation (88.46). For Disgust, the

contextual modality leads with 31.89; and for Anger,

the facial modality has the highest AP score with

15.06. Regarding the mAP metric, the body modal-

ity leads with a score of 42.54, the contextual one is

close with 42.31. Besides, the facial modality scores

38.72 and the postural modality 14.30, the worst one.

This evaluation shows that not all modalities per-

form well with data in the wild, where the presence of

the face or the entire clear posture are not guaranteed.

Thus, the performance of facial and postural modali-

ties is affected, they are below the corporal modality

in 3.82 units and 28.24 units, respectively. The pos-

tural results are not surprising because, in wild data,

postural was expected to be the least expressive emo-

Table 3: Comparisons of the AP metric results between the

proposal and state-of-the-art-methods.

Cat. EMOTIC Model EmotiCon

Ours

Group Max Mean Max Mean

Anger 14.97 11.50 21.92 18.75 17.74

Anticip. 87.53 73.09 91.12 81.62 89.10

Disgust 21.32 13.12 43.12 24.55 31.94

Fear 16.89 11.40 23.65 18.92 18.15

Joy 77.16 46.06 83.26 60.60 82.51

Sadness 19.66 14.18 26.39 17.83 18.11

Surprise 29.63 24.22 35.12 26.25 22.45

Trust 78.35 36.93 68.65 42.18 72.45

mAP 43.19 28.81 49.15 36.34 44.06

tional data source. Likewise, this modality could im-

prove its results using videos because the DGCNN

model is better when using this type of data.

Fusion Results Comparison. The entire proposed

method was compared with the methods in the

state-of-the-art in EMOTIC benchmark, EMOTIC

model (Kosti et al., 2019) and EmotiCon (Mittal et al.,

2020). Due to our adequacy of the dataset, the com-

parison of our results and those reported by the other

methods was carried out with the maximum and the

average value of each CG – e.g., the Trust group

is represented by the maximum and average values

of those reported for the emotions Conﬁdence, Es-

teem, and Sympathy in EMOTIC model and Emoti-

Con. These results are reported in Table 3.

According to maximum AP scores (Max), our

proposal achieves similar results to EMOTIC Model

and EmotiCon in most emotions; however, concern-

ing the mAP score, our model scores 44.06, below

the score of EmotiCon 49.15. Compared with the

EMOTIC Model, the proposed method surpasses the

score in the groups of Joy, Fear, Disgust, Anger, and

Anticipation; although, on mAP, our proposal exceeds

it by almost one unit. For Trust group, the proposal

overcomes the score of EmotiCon, but both are below

EMOTIC Model.

Observing the average values (Mean), our pro-

posal obtains higher mAP scores than EMOTIC and

EmotiCon models: 44.06 vs. 28.81 and 36.34, re-

spectively. With the Joy group, there is a score differ-

ence of almost 20, comparing our method to Emoti-

Con. Only in the Surprise group, the proposal results

are below both models; even, it is below the achieved

by only the body modality. The low performance of

the state-of-the-art methods, with average values, is

explained by the unbalance in the dataset since emo-

tions with low scores lower the group average. More-

over, in the literature it is not speciﬁed whether, for

example, an oversampling technique was used in the

training phase to solve the unbalance.

The last comparison is among the fusion meth-

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology

461

Table 4: Comparisons of the AP metric results between the proposed EmbraceNet+ and other fusion methods. I=intermediate

data, F=ﬁnal outputs.

Cat. Group EmbraceNet EmbraceNet Concat EmbraceNet+ Without Without

(I) (F) +MLP F WS

Anger 16.54 16.52 15.29 17.74 16.26 16.62

Anticipation 89.36 88.63 88.24 89.10 88.97 88.65

Disgust 31.52 30.20 28.05 31.94 29.45 31.32

Fear 17.42 18.23 17.46 18.15 17.66 17.37

Joy 82.25 81.56 80.13 82.51 81.08 82.00

Sadness 16.46 15.78 15.36 18.11 16.13 16.62

Surprise 22.33 22.48 21.76 22.45 22.65 22.40

Trust 73.19 73.30 71.12 72.45 72.88 71.88

mAP 43.63 43.34 42.18 44.06 43.13 43.36

ods with the same metrics, taking the two ways of

using EmbraceNet (the one that uses (I)ntermediate

data and the one that use the (F)inal outputs), a con-

catenation plus an MLP (Concat +MLP), and the Em-

braceNet+ (see Table 4).

To notice the inﬂuence of adding other fusion

methods, we also compare the EmbraceNet+ results

without an extra Concatenation (EmbraceNet+ with-

out F) and without a WS (EmbraceNet+ without

WS) as the additional fusion methods. At the level

of CGs, only with Fear and Anticipation, the Em-

braceNet+ does not achieve the highest AP score, but

the EmbraceNet (F) with 18.23 and the EmbraceNet

(I) with 89.36, respectively. In any other emotion,

EmbraceNet+ has the best results. For Trust and Sur-

prise, the EmbraceNet+ without including the con-

catenation (Without F) achieves better results, with

72.88 and 22.65, respectively.

Our proposal, EmbraceNet+, achieves a slight im-

provement in mAP score over both EmbraceNets,

with a difference of 0.43 with the EmbraceNet (I)

and 0.72 with the EmbraceNet (F). The Concat +MLP

does not achieve the highest result for any emotion;

then, this method is not enough to solve the recog-

nition of emotions as it was presented. If any of

the additional fusion methods are removed, our Em-

braceNet+ does not outperform EmbraceNets, there-

fore, adding these fusion strategies (Concatenation

and WS) provides relevant data for better results. On

the other hand, the modiﬁcations on the docking lay-

ers do not have the expected impact and not work as

an additional feature extractor. This may be because

the difference against normal EmbraceNet and normal

docking layers, is short. However, it still maintains

the correlation between modalities and makes the re-

sults of the docking layers more robust without falling

into overﬁtting thanks to the dropout layer.

Evaluation of Inferences. As explain previously, the

ﬁnal inferences are binary vectors representing the

presence or absence of the emotions and can be evalu-

ated with classiﬁcation metrics, such as accuracy and

F1 score. These inferences were obtained from test

Table 5: Classiﬁcation results in accuracy and F1 metrics.

Cat. Group Accuracy F1 score

Anger 0.8667 0.2005

Anticipation 0.7792 0.8686

Disgust 0.6626 0.3268

Fear 0.7375 0.1781

Joy 0.6881 0.7971

Sadness 0.8627 0.2206

Surprise 0.6994 0.2339

Trust 0.6223 0.6694

Average 0.7398 0.4369

and validation datasets; however, the results obtained

are quite similar. Results with the test-set are 0.56%

better than results obtained with the validation set, on

average accuracy. Thus, we only show, in Table 5,

the results with the test-set. The accuracy indicates a

good performance, reaching up to 86% in Anger and

Sadness groups and the lower in the Trust group with

62%, and 73% in average; the accuracy demonstrates

that our model can estimate in a good way the pres-

ence and the absence of emotions. Results accord-

ing to F1 score are like those of AP, because both are

based on the precision and recall.

We also measure the performance of our approach

in terms of total time. In average, it is able to process

one image and estimate the emotions of one person

in 0.182 sec, working with a video card Nvidia Tesla

K80. This time considers the person detection in the

image (0.055 sec), the proper data acquisition (0.088

sec), and the whole processing to achieve a prediction

(0.038 sec). This result of the time execution provides

the opportunity to implement the proposal in real-time

or near-real-time applications, expanding the domains

of applicability.

General Discussion. All results demonstrate the

importance of employing a multi-modal approach

to study emotional states in wild data since single

modality methods remain below multi-modal ones,

with AP and mAP metrics. Furthermore, techniques

such as oversampling and clustering help preventing

poor performance due to imbalance; however, they

are not enough in some cases: scores of emotions with

fewer samples remain low.

ICSOFT 2021 - 16th International Conference on Software Technologies

462

On the other hand, EmbraceNet+ is applicable in

almost all multi-modal approaches to perform classi-

ﬁcation or recognition in any domain. Likewise, the

proposed emotion recognition method can be imple-

mented in other scenarios that require knowing the

emotional state of people. These advantages of our

proposed method for emotion recognition are sup-

ported by the implementation and usage of an ontol-

ogy; the ﬂexibility inherited from the EmbraceNet fu-

sion method and the good performance obtained with

EmbraceNet+, suggest that this novel fusion method

is applicable in real-time or near real-time applica-

tions.

6 CONCLUSIONS

We present a multi-modal method to recognize emo-

tions from images, whose values are stored in an emo-

tion ontology, called EMONTO.

The multi-modal method uses deep learning mod-

els, considering four types of data: face expression,

posture skeleton graph, features of body, and en-

vironmental context. For the fusion of modalities,

we proposed EmbraceNet+, an architecture that inte-

grates three fusion methods: the naive concatenation,

the WS, and the EmbraceNet. Our method achieves

similar and competitive results compared to state-

of-the-art methods for the EMOTIC and EmotiCon

benchmarks. Likewise, EmbraceNet+ can be used to

merge any multi-modal deep learning method. We

also showed how to instantiate EMONTO, using the

emotions from the multi-modal method. EMONTO

contains classes that allows integrating other speciﬁc

domain ontologies, giving our approach the ability

to be applied in multiple scenarios. Our proposed

method offers a wide range of possibilities for schol-

arly research, as accurate connections of the kind can

be used for the design and implementation of smart

applications that exploit semantic web resources, in

real-time or near real-time. Accordingly, we plan to

apply our proposal in real scenarios such as museums

as cases of study.

In future works, we also would explore other vi-

sual data, such as the interactions and proximity in

similar ways (Mittal et al., 2020); additionally, we

plan to explore other ways to use the EmbraceNet and

another type of feature vector (Choi and Lee, 2019b).

ACKNOWLEDGEMENT

This research was supported by the FONDO NA-

CIONAL DE DESARROLLO CIENT

IFICO, TEC-

NOL

OGICO Y DE INNOVACI

ON TECNOL

OGICA

- FONDECYT as executing entity of CONCYTEC

under grant agreement no. 01-2019-FONDECYT-

BM-INC.INV in the project RUTAS: Robots for Ur-

ban Tourism, Autonomous and Semantic web based.

REFERENCES

Ali, F., Kwak, D., Khan, P., Islam, S. R., Kim, K. H.,

and Kwak, K. (2017). Fuzzy ontology-based senti-

ment analysis of transportation and city feature re-

views for safe traveling. Transportation Research Part

C: Emerging Technologies, 77:33 – 48.

Bertola, F. and Patti, V. (2016). Ontology-based affec-

tive models to organize artworks in the social se-

mantic web. Information Processing & Management,

52(1):139–162.

Caruccio, L., Polese, G., Tortora, G., and Iannone, D.

(2019). Edcar: A knowledge representation frame-

work to enhance automatic video surveillance. Expert

Systems with Applications, 131:190–207.

Cavaliere, D. and Senatore, S. (2019). Emotional concept

extraction through ontology-enhanced classiﬁcation.

In Research Conf. on Metadata and Semantics Re-

search, pages 52–63. Springer.

Chen, J., Hu, B., Moore, P., and Zhang, X. (2016).

Ontology-based model for mining user’s emotions on

the wisdom web. In Wisdom Web of Things, pages

121–153. Springer.

Choi, J.-H. and Lee, J.-S. (2019a). Embracenet: A robust

deep learning architecture for multimodal classiﬁca-

tion. Information Fusion, 51:259–270.

Choi, J.-H. and Lee, J.-S. (2019b). Embracenet for activ-

ity: A deep multimodal fusion architecture for activity

recognition. In Adjunct Proc. of the ACM Int. Joint

Conf. on Pervasive and Ubiquitous Computing and

Proc. of the ACM Int. Symp. on Wearable Computers,

pages 693–698.

Chumkamon, S., Hayashi, E., and Koike, M. (2016). Intelli-

gent emotion and behavior based on topological con-

sciousness and adaptive resonance theory in a com-

panion robot. Biologically Inspired Cognitive Archi-

tectures, 18:51–67.

Cowen, A. S. and Keltner, D. (2020). What the face dis-

plays: Mapping 28 emotions conveyed by naturalistic

expression. American Psychologist, 75(3):349.

Deng, J., Guo, J., Yuxiang, Z., Yu, J., Kotsia, I., and

Zafeiriou, S. (2019). Retinaface: Single-stage dense

face localisation in the wild. In arxiv.

Dong, X., Yu, Z., Cao, W., Shi, Y., and Ma, Q. (2020). A

survey on ensemble learning. Frontiers of Computer

Science, pages 1–18.

Dragoni, M., Poria, S., and Cambria, E. (2018). Ontosentic-

net: A commonsense ontology for sentiment analysis.

IEEE Intelligent Systems, 33(3):77–85.

A Multi-modal Visual Emotion Recognition Method to Instantiate an Ontology

463

Egger, J., Pepe, A., Gsaxner, C., and Li, J. (2020). Deep

learning–a ﬁrst meta-survey of selected reviews across

scientiﬁc disciplines and their research impact. arXiv

preprint arXiv:2011.08184.

Farhadi, A. and Redmon, J. (2018). Yolov3: An incremental

improvement. Computer Vision and Pattern Recogni-

tion.

Fukui, H., Hirakawa, T., Yamashita, T., and Fujiyoshi, H.

(2019). Attention branch network: Learning of atten-

tion mechanism for visual explanation. In Proc. of the

IEEE Conf. on Computer Vision and Pattern Recogni-

tion, pages 10705–10714.

Garay-Vitoria, N., Cearreta, I., and Larraza-Mendiluze, E.

(2019). Application of an ontology-based platform for

developing affective interaction systems. IEEE Ac-

cess, 7:40503–40515.

Gilda, S., Zafar, H., Soni, C., and Waghurdekar, K. (2017).

Smart music player integrating facial emotion recog-

nition and music mood recommendation. In Int. Conf.

on Wireless Communications, Signal Processing and

Networking, pages 154–158. IEEE.

Grassi, M. (2009). Developing heo human emotions on-

tology. In Fierrez, J., Ortega-Garcia, J., Esposito, A.,

Drygajlo, A., and Faundez-Zanuy, M., editors, Bio-

metric ID Management and Multimodal Communi-

cation, pages 244–251, Berlin, Heidelberg. Springer

Berlin Heidelberg.

Graterol, W., Diaz-Amado, J., Cardinale, Y., Dongo, I.,

Lopes-Silva, E., and Santos-Libarino, C. (2021).

Emotion detection for social robots based on nlp trans-

formers and an emotion ontology. Sensors, 21(4).

Katifori, A., Golemati, M., Vassilakis, C., Lepouras, G., and

Halatsis, C. (2007). Creating an ontology for the user

proﬁle: Method and applications. pages 407–412.

Kaur, R. and Kautish, S. (2019). Multimodal sentiment

analysis: A survey and comparison. Int. Jrnl. of Ser-

vice Science, Management, Engineering, and Technol-

ogy, 10(2):38–58.

Knapp, M. L., Hall, J. A., and Horgan, T. G. (2013). Non-

verbal communication in human interaction, chapter

1: “Nonverbal Communication: Basic Perspectives”.

Cengage Learning, Boston, MA.

Kosti, R., Alvarez, J., Recasens, A., and Lapedriza, A.

(2019). Context based emotion recognition using

emotic dataset. IEEE Transactions on Pattern Anal-

ysis and Machine Intelligence.

Kosti, R., Alvarez, J. M., Recasens, A., and Lapedriza, A.

(2017). Emotion recognition in context. In IEEE Conf.

on Computer Vision and Pattern Recognition.

Lee, J., Kim, S., Kim, S., Park, J., and Sohn, K. (2019).

Context-aware emotion recognition networks. In The

IEEE Int. Conf. on Computer Vision.

Lhommet, M., Marsella, S. C., Calvo, R., D’Mello, S.,

Gratch, J., and Kappas, A. (2015). The Oxford Hand-

book of Affective Computing, chapter “Expressing

Emotion Through Posture and Gesture”.

Lin, R., Amith, M. T., Liang, C., Duan, R., Chen, Y., and

Tao, C. (2018a). Visualized emotion ontology: A

model for representing visual cues of emotions. BMC

Medical Informatics and Decision Making, 18.

Lin, R., Liang, C., Duan, R., Chen, Y., Tao, C., et al.

(2018b). Visualized emotion ontology: a model for

representing visual cues of emotions. BMC medical

informatics and decision making, 18(2):64.

Liu, K., Li, Y., Xu, N., and Natarajan, P. (2018). Learn

to combine modalities in multimodal deep learning.

arXiv preprint arXiv:1805.11730.

Mittal, T., Guhan, P., Bhattacharya, U., Chandra, R., Bera,

A., and Manocha, D. (2020). Emoticon: Context-

aware multimodal emotion recognition using frege’s

principle. In Proc. of the IEEE/CVF Conf. on Com-

puter Vision and Pattern Recognition, pages 14234–

14243.

Noroozi, F., Kaminska, D., Corneanu, C. A., Sapinski, T.,

Escalera, S., and Anbarjafari, G. (2018). Survey on

emotional body gesture recognition. IEEE Transac-

tions on Affective Computing.

Parkhi, O. M., Vedaldi, A., and Zisserman, A. (2015). Deep

face recognition. In British Machine Vision Conf.

Perez-Gaspar, L.-A., Caballero-Morales, S.-O., and

Trujillo-Romero, F. (2016). Multimodal emo-

tion recognition with evolutionary computation for

human-robot interaction. Expert Systems with Appli-

cations, 66:42–61.

Pinto-De la Gala, A., Cardinale, Y., Dongo, I., and Ticona-

Herrera, R. (2021). Towards an ontology for urban

tourism. In Proc. of the 36th Annual ACM Symp. on

Applied Computing, SAC ’21, New York, NY, USA.

ACM.

Plutchik, R. (1980). A general psychoevolutionary theory of

emotion. In Theories of emotion, pages 3–33. Elsevier.

Shi, L., Zhang, Y., Cheng, J., and Lu, H. (2019). Skeleton-

based action recognition with directed graph neural

networks. In The IEEE Conf. on Computer Vision and

Pattern Recognition.

Soleymania, M., Garcia, D., Jouc, B., Schuller, B., Chang,

S.-F., and Pantic, M. (2017). A survey of multimodal

sentiment analysis. Image and Vision Computing,

65:3–14.

Sun, K., Xiao, B., Liu, D., and Wang, J. (2019). Deep high-

resolution representation learning for human pose es-

timation. In The IEEE Conf. on Computer Vision and

Pattern Recognition.

Zadeh, M. M. T., Imani, M., and Majidi, B. (2019). Fast

facial emotion recognition using convolutional neural

networks and gabor ﬁlters. In 5th Conf. on Knowledge

Based Engineering and Innovation, pages 577–581.

IEEE.

Zhang, L., Wang, S., and Liu, B. (2018). Deep learning

for sentiment analysis: A survey. Wiley Interdisci-

plinary Reviews: Data Mining and Knowledge Dis-

covery, 8(4):e1253.

Zhang, S.-F., Zhai, J.-H., Xie, B.-J., Zhan, Y., and Wang,

X. (2019). Multimodal representation learning: Ad-

vances, trends and challenges. In Int. Conf. on Ma-

chine Learning and Cybernetics, pages 1–6. IEEE.

Zhang, X., Hu, B., Chen, J., and Moore, P. (2013).

Ontology-based context modeling for emotion recog-

nition in an intelligent web. World Wide Web,

16(4):497–513.

ICSOFT 2021 - 16th International Conference on Software Technologies

464
