Tales from the Code #1: The Effective Impact of Code Refactorings on

Software Energy Consumption

Zakaria Ournani

1,2,3

, Romain Rouvoy

2,3

, Pierre Rust

and Joel Penhoat

Orange Labs, Rennes, France

INRIA Lille Nord-Europe, Lille, France

University of Lille, Lille, France

Keywords:

Code Refactoring, Empirical Software Engineering, Software Energy Consumption.

Abstract:

Software maintenance and evolution enclose a broad set of actions that aim to improve both functional and

non-functional concerns of a software system. Among the non-functional concerns, energy consumption is

getting more and more traction in the industry, no matter the software is mobile or deployed in the cloud. In

this context, the impact of code refactorings on energy consumption remains unclear, though. In particular,

while the state of the art investigated the impact of some speciﬁc code refactorings on dedicated benchmarks,

we miss an assessment that those apply to more comprehensive and complex software. To address this threat,

this paper studies the evolution of the energy consumption of 7 open-source software developed for more than

5 years. Then, by focusing on the impact on energy consumption of changes involving code refactorings, we

intend to assess the effects induced by such code refactorings in practice. For all these software systems we

studied, our empirical results report that the code refactorings we mined do not substantially impact energy

consumption. Interestingly, these results highlight that i) structural code refactorings bring energy-preserving

changes to the code, and ii) major energy variations seem to be related to functional and computational code

evolutions.

1 INTRODUCTION

Software energy consumption has gained a substan-

tial signiﬁcance in the last decade, both for research

and industrial contexts (Verdecchia et al., 2017; Pinto

et al., 2016; Rodriguez, 2017; Chowdhury et al.,

2019; Fonseca et al., 2019). Hence, many researchers

and practitioners started caring about the energy ef-

ﬁciency of software, beyond performance and hard-

ware concerns (Cruz et al., 2017; Pinto et al., 2014;

Manotas et al., 2016; Manotas et al., 2013). Being

integrated into mobile or cloud environments, soft-

ware systems are trying to minimize their resource

consumption to reduce battery consumption or opera-

tional cost.

In this context, the impact of software develop-

ment techniques on energy consumption has been ex-

plored by the state of the art—including code compi-

lation, static code analysis, code refactorings—which

is the focus of this paper. Source code refactorings

can be described as the application of acknowledged

rules to improve one or many aspects of a software

system, such as its clarity, maintenance, code smells,

without impacting its functional behavior (Kerievsky,

2004; Abid et al., 2020).

Yet, code refactorings have also been consid-

ered as a mean to improve the performance and/or

energy efﬁciency in a more or less automated

way (Gottschalk et al., 2013; Anwar et al., 2019; Cruz

et al., 2017; Morales et al., 2018; Cruz and Abreu,

2017; Bree and Cinn

eide, 2020). The large major-

ity of the literature that has been published in this

domain—especially for mobile application (Palomba

et al., 2019; Gottschalk et al., 2013; Anwar et al.,

2019; Linares-V

asquez et al., 2014)—based their

study on a predeﬁned set of refactoring rules, design

patterns, or code smells. In most of these studies,

the authors measure and analyze the effect of atomic

code changes on the total energy efﬁciency of the soft-

ware under study, before concluding on their effect.

While this process may deliver interesting insights on

the impact of speciﬁc code refactorings on the en-

ergy consumption of a code snippet, there is still no

guarantee that the identiﬁed code refactorings are fre-

quently applied during the lifespan of a software sys-

tem. Some refactorings could be very advantageous

Ournani, Z., Rouvoy, R., Rust, P. and Penhoat, J.

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption.

DOI: 10.5220/0010517900340046

In Proceedings of the 16th International Conference on Software Technologies (ICSOFT 2021), pages 34-46

ISBN: 978-989-758-523-4

but are rarely applied which limits their impact on the

energy efﬁciency of the software.

In this paper, we thus consider an alternative ap-

proach to study the impact of code refactorings on the

energy efﬁciency of legacy software systems. We fo-

cus on acknowledged refactoring rules mostly issued

from Martin Fowler’s book (Fowler, 1999), which

are mostly structure-oriented rules (such as Extract

Method) dealing with code architecture and organi-

zation for server-side applications rather than imple-

mentation and computation changes (such as Sub-

stitue Algorithm). Instead of selecting a set of code

refactorings a priori and evaluate them against some

dedicated benchmarks, we extract these code refac-

torings from established open-source projects. More

speciﬁcally, we mine the history of code refactorings

that have been applied to these projects in the past,

and we measure the impact of the commits that in-

clude acknowledged code refactorings on the overall

energy consumption. This approach aims to detect the

code refactorings that have been broadly applied, and

their observable impact on energy efﬁciency in prac-

tice. By doing so, we believe that mined code refac-

torings are most likely to reﬂect an effective impact of

code refactoring on energy consumption, compared

to the study of a ﬁxed set of refactoring candidates.

This study, therefore, aims to answer the following

research questions:

RQ 1: How does the energy consumption of software

evolve over time?

RQ 2: How do code refactorings contribute to the

evolution of software energy consumption?

Furthermore, beyond answering these two questions,

the paper comes with a set of contributions that can

be summarized as:

1. Proposing a new empirical approach to study the

impact of source code refactorings on the energy

consumption of software systems,

2. Investigating the contribution of code refactorings

to the global evolution of software energy con-

sumption,

3. Providing a detailed description of the most ap-

plied code refactorings and their impact on energy

consumption,

4. Validating the code refactoring effects on energy

consumption through statistical tests and micro-

benchmarking.

The remainder of this paper is organized as follows.

Section 2 introduces the experimental protocol (hard-

ware, projects, tools, and methodology) we adopted in

this study. Section 3 analyzes several experiments we

conducted to mine the code refactorings and evaluate

their impact on the energy consumption, as well as the

results we observed during these experiments. Sec-

tion 4 discusses the related work about source code

refactoring contributions to reduce software energy

consumption. Finally, Sections 5 and 6 cover the va-

lidity threats and our conclusions, respectively.

2 EXPERIMENTAL PROTOCOL

This section describes our detailed experimental envi-

ronment, encompassing the hardware conﬁguration,

the studied projects/benchmarks and a detailed de-

scription of our experimental methodology.

2.1 Hardware Environment

For all of our experiments, we used a Core i7 ma-

chine (i7-6600U CPU @ 2.60GHz) with a total of 4

processing units to measure the energy consumption

and mine the refactoring rules from the projects un-

der study. The machine ran a 18.04.4 LTS Ubuntu,

with a 4.15.0-88-generic Linux kernel. We also

used OPENJDK, version 1.8.0 242, to run most of

our Java experiments—i.e., run both old and recent

versions—except for the OkHttp project where we had

to use OPENJDK, version 11.0.6. By using the same

machine to conduct all the experiments, we guar-

antee the least energy consumption variation and a

controlled impact of the hardware conﬁguration, as

recommended in (Ournani et al., 2020), especially

to measure small differences in energy consumption.

Therefore, the machine has been conﬁgured accord-

ing to guidelines of (Ournani et al., 2020) to mitigate

the energy consumption variation to the minimum and

produce accurate results that can be faithfully com-

pared.

2.2 Projects under Study

Regarding the subjects of our study, our main crite-

rion was to select established projects with a consider-

able commit history, that have been existing for years,

and with an active community. This study exclusively

focuses on Java projects to limit the search space and

unify our experimental setup, but also because code

refactorings may differ from a language/paradigm to

another. We then tried to diversify our dataset by

considering projects that cover a large spectrum of

features and operations including, JSON and XML

conversions, HTTP client, graph processing, data col-

lections, etc. Because of the longitudinal nature of

our study, we considered projects that have a stable

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

Table 1: List of selected open-source projects.

Project Description # commits 1

commit

OkHttp Java HTTP client 4, 684 05-2011

JGraphT Graph objects and algorithms provider 3, 158 07-2003

XStream XML ↔ Java objects serialization 2, 736 10-2003

JFlex Java lexical analyzer generator 1, 741 02-2003

Gson JSON ↔ Java objects serialization 1, 485 08-2008

Eclipse-Collections Eclipse Java collections 1, 374 12-2015

Google-Http Google HTTP client library for Java 868 05-2011

0 25 50 75 100 125 150 175 200

Refactorings count

0.2

0.4

0.6

0.8

1.0

CDF

Gson

Okhttp

Ghttp

Xstream

Jgrapht

Jﬂex

Collections

Figure 1: CDF of code refactorings per commit.

interface, and in which the main functions are non-

ambiguously identiﬁed, so we can run the same mea-

surements across different generations and versions of

the studied projects.

Based on the above criteria, Table 1 summarizes

the projects that we considered for this study, along

with the number of commits at the time that this pa-

per was written, and the date of the ﬁrst commit. Es-

tablished projects with a higher number of commits

increase the chances to mine a representative set of

commits including code refactorings. All the projects

we selected have been hosted on GitHub since at least

2015. We note that the Git creation date only gives an

overview of how long has the project been on GitHub

and is different from the project creation date. Some

projects, such as Gson, exists on GitHub since March

2015, but we still can checkout commits from 2003.

2.3 Methodology & Tools

Our experimental methodology is a process that in-

cludes extraction, evaluation, and validation steps.

Figure 2 depicts the main steps we followed to an-

alyze each selected project. We start our process

by cloning the public repository of the project from

GitHub. Then, for each commit, we mine the code

refactorings of the project using the REFACTORING-

MINER tool and we summarize them into a JSON

ﬁle. REFACTORINGMINER is an open-source re-

search project (Tsantalis et al., 2018; Tsantalis et al.,

2020) that analyses a project commit by commit and

extracts the type and count of refactorings for each

commit in a JSON format. It helps in detecting and

visualizing 55 different types of refactoring in its ver-

sion 2.0, which is the version we used in this study.

Once we extract the code refactorings that have

been applied per commit on the master branch, we

select the commits to be reproduced to measure their

energy consumption. The selection method takes into

account the refactorings count and types in each com-

mit. We consider commits with at least 20 refac-

torings so we can expect a signiﬁcant impact of the

refactorings on the energy consumption. Figure 1

depicts the cumulative distribution function (CDF)

that shows the frequency of commits per refactorings

count (commits with more than 200 refactorings have

been omitted for clarity). For most of the studied

projects, one can see that 20% of the commits have

more than 20 refactorings. This ensures having a de-

cent number of the most relevant commits that can be

reproduced and evaluated. The commits that contain

only one type of refactoring are very rare, we thus

also consider commits with a mix of code refactor-

ings, and deduce the impact of each refactoring rule

a posteriori.

Then, we rebuild the project Java archive (JAR)

for each of the previously selected commits to be

ready for the test/run phase. To be able to run

and evaluate the compiled JAR, we need to pro-

vide a task to execute for each project. We can-

not trust running the tests provided within projects as

they can substantially change from a commit to an-

other and might include/exclude functionalities that

appear/disappear between commits, which does not

constitute a fair comparison criterion. Instead, we

wrote our own JMH benchmarks for each project,

which is a ”Java Microbenchmark Harness for build-

ing, running, and analyzing nano/micro/milli/macro

benchmarks written in Java and other languages tar-

geting the JVM”.

The purpose of each benchmark is

to test the main functionality of each project to ensure

the same measurement conditions for all commits.

Hence, through JMH benchmarking, we can deliver—

for each project—experiments to compare the energy

consumption of commits, while testing the main func-

tionalities of the project. The main test functional-

ity for Gson and XStream is JSON and XML to Java

objects serialization and deserialization, respectively.

For both OkHttp and Google-Http projects, we con-

sider the core HTTP verbs (GET, POST, DELETE) with

a local server to eliminate any network bias. For

JGraphT, we consider the operations of graph cre-

ation, shortest path computation, max-ﬂow computa-

tion, and discarding random edges. We also tested

JFlex with lexical analyzer generation, and Eclipse-

Collections with the core operations on the different

https://github.com/tsantalis/RefactoringMiner

https://openjdk.java.net/projects/code-tools/jmh/

ICSOFT 2021 - 16th International Conference on Software Technologies

mutable and immutable collections (lists, maps, sets),

inspired from (Pinto et al., 2016; Samir Hasan et al.,

2016). Using JMH for writing benchmarks has many

advantages, such as the easy management of run and

warm-up iterations, and the prevention of dead code

removal from the JIT using the concept of black-

hole (Rodriguez-Cancio et al., 2016).

Once the JMH benchmark was written , we com-

pute the coverage of the project by the benchmark

using Jacoco (https://www.eclemma.org/jacoco).The

purpose is not to cover all of the project classes and

methods, as we only want to test the main functional-

ity of the project. However, the coverage computation

allows us to save all the classes and methods that are

covered by our benchmark. Thus, only the commits

with refactoring on these classes (given by Refactor-

ingMiner) and methods are considered for the evalua-

tion. Of course, this operation requires applying more

checks (using git diff) to ensure that the changes of

the commit x are limited to the extracted refactor-

ings and nothing else susceptible to affect the per-

formance or the energy consumption. Hence, this

step ensures that the selected commits only contains

refactoring that are being stressed by our benchmark.

The next step is to run the benchmarks for each

of the JAR ﬁles compiled from relevant commits. To

highlight the effect that code refactorings may have

on energy consumption, we build and run the com-

mit x that includes the code refactorings, but also the

commit x-1 on the main branch, so we can compare

the energy consumption and infer the impact of refac-

torings.

The percentage of reproduced commits, which

designates the ratio of successfully built and ran com-

mits in regards to the total count of selected com-

mits (Gson: 95%, XStream: 80%, OkHttp V3 & V4:

90%, Google-Http: 15%, JGraphT: 25%, JFlex: 40%,

Eclipse-Collections: 50%). Most of the unsuccessful

projects’ rebuilds are due to deprecated and invalid

references.

During the execution of the experiments, we use

Intel RAPL to acquire the global energy consump-

tion (Khan et al., 2018; Desrochers et al., 2016),

which is one of the most accurate available tools to re-

port the CPU/DRAM global energy consumption. We

thus evaluate the energy consumption of every com-

mit x and we compare it to its x-1 commit. We run ev-

ery JMH benchmark for multiple iterations on a ﬁxed

amount of time (enough time to run the benchmark

at least one), and we extract between 100 and 1, 000

energy measurements depending on the duration of

each iteration. Thus, different commits can run a dif-

ferent amount of iterations within the time allowed to

the JMH benchmark execution. This is why we con-

sider the energy consumption of iterations rather than

the whole benchmark, in order to have a correct es-

timation of the energy consumption for that commit.

Then, we use the bootstrap method (Efron, 2000) to

randomly build 100 subsets from the main set of mea-

surements, and we compute the mean and standard

deviation of these subsets. We end-up with 100 mea-

sures of averages and we use the median of these val-

ues for better accuracy and less bias.

The checked results are then used to build global

statistics of the most efﬁcient refactoring rules across

the selected commits of all projects. We also pay spe-

cial attention to the commits of each project that ex-

hibit the most energy difference, when exceeding a

threshold of 5%. This threshold is computed from the

minimum CPU energy consumption variation and the

computed standard deviation of the experiments (Our-

nani et al., 2020).

This additional check of those commits consists

of applying a more detailed git diff analysis on the

results of the previous step to understand every single

occurrence of the detected refactorings and project the

results and that there is no other changes that may af-

fect the energy efﬁciency. Another check consists of

an extra micro-benchmarking phase, where we pre-

pare and execute the extracted refactorings to conﬁrm

and validate the effect they could have on the energy

efﬁciency of the project/software. We also applied the

Wilcoxon rank sum test (or Student test when possi-

ble) to check the statistical signiﬁcance of the regis-

tered difference in the energy consumption between

the commit x and the commit x-1, with a null hy-

pothesis of the energy consumption of the commit x

and x-1 being equal with a 5% certainty. During our

experiments, we were careful not to fall in the bench-

marking crimes described in (van der Kouwe et al.,

2018), so we can conduct robust and reproducible ex-

periments and evaluations with a focus on energy con-

sumption.

Most of our experimental setup is made available

on GitHub, including all the used JMH Benchmarks,

JSON extraction results, micro-benchmarks, CSV of

measurements, scripts, etc.

3 REFACTORING IMPACT

ANALYSIS

In this section, we aim at answering our research

questions with a clear conclusion on whether refac-

toring has a substantial impact on the evolution of

https://anonymous.4open.science/r/c3d38dca-1ab2-

4814-ba07-b182120c5739

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

Github

project

Clone project

Refactoring

global/detailed

impact

analyses

Extract

refactoring

Build a JAR for

every selected

commit

Write JMH

Benchmarks

Run

benchmarks

Evaluate the

effect of

refactoring

Final

results

Explore Git Diff

to validate the

results

Reproduce and

measure the

refactoring

through micro-

benchmarking

Figure 2: Methodology of refactoring analysis.

software energy consumption over time. We, there-

fore, conducted a set of experiments and validations

to investigate the effect of structural refactoring on the

evolution of software energy consumption.

3.1 Software Energy Consumption

Evolution

The ﬁrst step is to investigate the evolution of soft-

ware energy consumption over time. Figure 3 depicts

the evolution of energy consumption for the projects

Google-Http, XStream, JGraphT, and Eclipse Collec-

tions, for which we run the main releases and report

on the energy consumption measured over time, by

focusing on the main functions stressed by our JMH

benchmarks.

Except for JGraphT, one can observe that energy

consumption tends to decrease over time for most of

the projects. One can mention a 10% decrease in 12

months for the Google-Http project (cf. Figure 3a),

a 10% decrease in 4 years for the Eclipse Collections

project (cf. Figure 3c), and a very substantial decrease

of 50% in 6 years for the XStream project (cf. Fig-

ure 3d).

Then, to have a more concrete look on the evolu-

tion of energy consumption per commit, we select the

Gson project to reproduce the evolution of its energy

consumption along the full commit history. Given the

large number of involved commits, we consider the

full set of commits of the Gson project (12 years)

with a span of 25—i.e., we build, run, and measure

the energy consumption every 25

commits. Figure 4

depicts the evolution of energy consumption for the

Gson project with a total of 57 successfully repro-

duced commits, out of 60. The line plot validates and

conﬁrms the results shown in Figure 3.Most notably,

one can observe a reduction of 82% from the highest

to the lowest consumption commit within 12 years of

the project’s lifespan—i.e., the energy consumption

became 5 times lower. One can also see a more sud-

den energy consumption reduction between commits

600 and 900. This requires further investigation in the

future.

To answer RQ1, we can conclude that software

energy consumption can evolve drastically over

time. For the analyzed target systems, in spite

of ﬂuctuations, the energy consumption has de-

creased non-negligibly for 4 systems and grown

for one.

Given the previous results reported by the litera-

ture, the remainder of this paper aims to closely study

and assess the impact of code refactoring on such ob-

served evolutions.

3.2 Refactoring Rules Impact

To dive into the effective impact that code refactor-

ing may have on software energy consumption, we

further tracked and analyzed the evolution of the en-

ergy consumption on commits where code refactor-

ings were detected. Thus, in our study, we consider

the full commit history of 7 open-source projects,

and we analyze the impact on energy consumption of

commits including code refactorings, as described in

Section 2.

Once we select commits with code refactorings

and rebuild them, we run the JMH benchmarks that

have been prepared for each project to compare the

energy consumption of a commit x that came with the

refactorings and the previous commit x-1 of the mas-

ter branch.

Then, we report on global statistics from the raw

measurements we obtained from each project, thus es-

tablishing a summary of the most used code refactor-

ings and their impact.

3.2.1 Global Code Refactoring Statistics

The purpose of this step is to highlight the most

used/impactful code refactorings. While it is easy to

identify the most used code refactorings by counting

the number of occurrences of each refactoring rule

and the commits they appear in, there is no consen-

sus on how to measure the effective impact of code

refactorings on energy consumption, if any. The large

majority of commits comes with a set of code refac-

ICSOFT 2021 - 16th International Conference on Software Technologies

2019-01-11

2019-03-25

2019-06-04

2019-09-11

2019-12-17

Releases

22.0

22.5

23.0

23.5

24.0

Energy consumption (J)

Energy

(a) Google-Http energy consumption over 11 months.

2018-05-16

2018-11-12

2019-06-03

2020-02-21

2020-06-15

Releases

Energy consumption (J)

Energy

(b) JGraphT energy consumption over 2 years.

2016-04-08

2017-03-06

2017-12-31

2018-05-18

2019-07-12

2020-02-11

2020-08-20

Releases

24.5

25.0

25.5

26.0

26.5

27.0

27.5

Energy consumption (J)

Energy

2014-02-08

2015-02-18

2016-03-16

2017-05-23

2018-10-22

2020-09-06

Releases

3.0

3.5

4.0

4.5

5.0

Energy consumption (J)

Energy

(d) XStream energy consumption over 6 years.

Figure 3: Energy consumption evolution of Google-Http, XStream, JGrapht, and Eclipse Collections.

0 200 400 600 800 1000 1200

Commit number

Energy consumption (J)

Figure 4: Gson energy consumption across for every 25th

commit.

torings of many types, and even if these refactorings

can impact the energy consumption, there is no trivial

way to isolate such an impact for each type of refac-

toring. Thus, we consider 3 indicators to capture the

energy impact of refactoring. The ﬁrst indicator, Im-

pact in Commits (IC), is the ratio between the num-

ber of commits where the refactoring had a positive

or negative impact—i.e., the commit x containing this

refactoring consume more or less energy than the pre-

vious commit x-1—and the total number of commits

containing this refactoring. Equation 1 therefore com-

putes IC for a rule r ∈ R by exploring all the commit

history C of a given project:

IC(r) =

∑

c∈C

count positive negative(c, r)

∑

c∈C

count(c, r)

(1)

This indicator can be then enhanced by taking into

account the occurrences—or weights—of each refac-

toring rule in a commit. In other words, considering

the refactoring weight consists of using the number of

occurrences of each refactoring type within a commit

rather than only counting the commit as 1 if it con-

tains at least a refactoring.

WIC(r) =

∑

c∈C

count positive negative(c, w

)

∑

c∈C

count(c, w

)

(2)

Nevertheless, this indicator is not enough to eval-

uate the energy impact of refactoring. Indeed, in-

cluding the weight of refactorings in commits sup-

poses that all refactorings impact energy consumption

equally, which may not be true, as we assume that the

occurrence of a refactoring r

can have a bigger im-

pact than many occurrences of a refactoring r

The 2

and 3

indicators are δ% and δ|%| that

indicate the mean of the energy consumption of every

commit x containing the refactoring minus the energy

consumption of commits x-1, and the mean of the

absolute value of the energy consumption of every

commit x containing the refactoring minus the energy

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

consumption of commits x-1, respectively, kC

k be-

ing the commits in the commit history C where refac-

toring r occurred.

δ%(r) =

∑

x=1

− E

x−1

)

(3)

δ|%|(r) =

∑

x=1

− E

x−1

(4)

where E

and E

x−1

represent the mean energy con-

sumption of the commit x that includes at least the

refactoring r, and the energy consumption of the com-

mit x-1, respectively. These indicators are comple-

mentary to reﬂect the impact of the code refactorings

on the energy consumption. Therefore, we consider

an aggregate indicator that combines the previous in-

dicators to capture the energy impact of refactorings

across commits. This indicator, named Refactoring

Impact (RI) builds on the previous indicators: the

higher WIC and δ|%|, the most impactful the refactor-

ing r is. However, if the difference δ|%|−δ% is high,

it means that the refactoring r has an unpredictable

effect on the energy consumption and may affect the

energy consumption positively or negatively. This is

a negative effect and could mean that the refactoring

does not have any impact at all. On the other hand,

the more commits we have with the refactoring r, the

more certain we are of the effect that it could have.

Thus, we use the exponential function in Equation 5

so the denominator cannot be null.

RI(r) =

WIC(r) × δ|%|(r)

δ|%|(r)−δ%(r)

× kC

k (5)

Table 2 shows the computed indicators for a total

of 25 mined refactoring rules. We note that the com-

mits that could not be reproduced and those where the

refactorings are parts of classes that are not tested by

our benchmark have already been discarded and not

displayed in Table 2. Before analyzing the results we

excluded all the code refactorings with a low number

of occurrences and/or commits (less than 20 Coun-

txCommits). For example, code refactorings that oc-

curred only a couple of times and/or only in one or

two commits cannot be faithfully studied due to insuf-

ﬁcient data. Then, we highlight (in Cyan) the refac-

toring rules that have the best values for the previous

indicators, which are very likely the refactorings with

the most impact on energy consumption. The 4 refac-

toring rules with the most number of occurrences and

commits, with a minimal IC of 30%, are ”add method

annotation”, ”rename parameter”, ”add class annota-

tion”, and ”move class”. These refactoring rules are

also those that exhibit the highest RI, and thus, are

most likely to be the most impactful on energy con-

sumption. However, we still have to assess that these

refactoring rules have an effective impact on the evo-

lution of energy consumption. Thus, we conducted a

more detailed study on the commits with the highest

impact to validate the effect of code refactorings on

energy consumption.

3.2.2 Diving into the Most Impactful Commits

With the most impactful commits, we refer to com-

mits where we observed the most substantial energy

differences between the commits x and commit x-1.

To select these commits, we ﬁx a threshold of 5% in

energy consumption difference. This threshold was

ﬁxed based on the CPU energy consumption varia-

tion (Ournani et al., 2020) and the standard deviation

of the many executions we ran on the same test, which

is often around 4% to 5%. A total of 7 commits have

been retrieved from the projects Gson, JFlex, Eclipse-

Collections and JGraphT (no other refactoring com-

mit with a minimal impact of 5% has been observed

among the other projects). We note that our exper-

imental setup would highlight any effect that these

refactoring could have caused on energy consump-

tion. Indeed, the execution of a JMH code, which

uses the compiled JAR for the commit x, is composed

of numerous warmup and standard iterations. Each it-

eration itself consists of running the benchmark many

thousands of times for several seconds, so the effect

that difference between the commits x and x-1 could

be noticed, if any.

Table 3 reports on the most impactful commits

including code refactorings. For each commit, we

can see the type and number of refactorings extracted

using REFACTORINGMINER (Tsantalis et al., 2018;

Tsantalis et al., 2020), the measured energy consump-

tion difference, a short description of the refactoring-

related changes that have been observed within the

commits, and the computed p-value of the Wilcoxon

test.

First, the commit ID is the ﬁrst 6 digits of the git

hash that can be used to access the commit and repro-

duce our experiments/results. The energy consump-

tion (EC) difference represents the percentage of dif-

ferences between the average measure of commits x

and x-1 (after applying the bootstrapping as we com-

pute the average of multiple subsets built from the

main set of values). The next 2 columns contain the

extraction results of the REFACTORINGMINER tool.

They include the type and count of each refactor-

ing the tool was able to extract. We notice that the

rules that we identiﬁed as most impactful in the previ-

ous phase (add method annotation, rename parame-

ter, add class annotation, and move class) are—most

of the time—part of the extracted rules in theses com-

mits that have shown the highest differences in energy

ICSOFT 2021 - 16th International Conference on Software Technologies

Table 2: The observed impact of mined refactoring rules.

Refactoring Count CountxCommits IC WIC δ%(r) δ|%|(r) RI

add method annotation 10120 80960 30.77% 43.41% 1.13% 2.14% 7.34

change variable type 101 606 16.67% 14.95% 0.24% 1.32% 1.17

rename parameter 45 180 33.33% 71.69% -0.07% 1.82% 5.12

change parameter type 42 168 11.76% 17.07% -0.03% 1.20% 0.81

change attribute type 26 130 16.67% 9.39% 0.12% 1.35% 0.63

add class annotation 63 216 33.33% 63.53% 1.30% 2.20% 2.77

move class 40 120 30.00% 54.28% 0.77% 2.21% 3.55

change return type 28 112 14.81% 19.93% 0.14% 1.11% 0.88

move method 33 99 21.43% 19.10% 0.59% 1.76% 1.00

rename variable 21 84 25.00% 18.24% 0.46% 1.44% 1.04

move attribute 18 54 25.00% 18.81% -0.07% 1.92% 1.06

extract method 37 37 20.00% 71.87% 0.08% 1.24% 0.88

pull up method 32 32 33.33% 38.90% 0.03% 1.97% 0.75

rename class 6 24 25.00% 13.71% 1.14% 1.51% 0.82

add attribute annotation 8 16 20.00% 15.12% 0.64% 1.14% 0.34

rename attribute 5 15 30.00% 8.77% 0.55% 1.62% 0.42

add parameter 6 12 16.67% 6.55% 0.82% 1.47% 0.19

merge parameter 6 6 100.00% 100.00% 6.00% 6.00% 6.00

extract class 2 4 33.33% 11.14% 0.72% 2.62% 0.57

extract variable 3 3 11.11% 10.52% 0.49% 0.91% 0.10

remove method annotation 1 1 11.11% 0.77% 0.71% 1.40% 0.01

rename method 1 1 11.11% 2.20% 0.32% 1.10% 0.02

modify method annotation 1 1 33.33% 7.99% 2.50% 2.50% 0.20

move & rename method 1 1 20.00% 13.17% -0.32% 2.32% 0.30

merge attribute 1 1 100.00% 100.00% 6.00% 6.00% 6.00

consumption, with add annotation and move class be-

ing the most common. Sometimes, they are the only

detected code refactorings, that we could suspect to

be responsible for the energy consumption variation,

as in commit #b9dfbc of Eclipse Collections.

We apply 3 different validation measures to con-

ﬁrm whether the impact is effectively caused by the

refactoring. The ﬁrst validation is through detailed git

diff checks of the 7 selected commits to assess that

the refactorings have been faithfully applied. We re-

mind that we already made sure that these refactor-

ings only concerns classes and methods that are being

stressed by the JMH benchmarks, and do not contain

other changes that can be responsible for the energy

consumption difference. For example, we do not sus-

pect adding some code documentation to alter the en-

ergy consumption, yet we do suspect changing a data

structure, a loop, or a code snippet to do so.

In the second validation step, we conduct a statis-

tical validation through Wilcoxon rank sum test (as

Student test could not be applied due to variables

not following a Gaussian distribution) to compare the

commits x and x-1 averages. With a risk of 5%, we

reject the null hypothesis of the means of the exe-

cutions of commits x and x-1 being equal. For the

p-value commit #f1074b being higher than 0.05, we

cannot reject the possibility that the average is equal

in both commits. The same goes for the commits

#033164, #b34361, #b9dfbc where we cannot accept

that the means of the commits x and x-1 are statisti-

cally different.

The remaining commits—being #827717,

#45bf2d, and #298b7a—mainly contain the add

annotation and move class refactorings. We thus

achieve our third validation step through ded-

icated micro-benchmarking. We ﬁrst build a

micro-benchmark to check the effect that every

encountered annotation may have(@override,

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

Table 3: A deeper look into the most impactful commits.

Project Commit ID EC diff Refactoring Count Git diff p-value

Gson

#82771f 5.5%

add method annotation 23

Adding @SuppressWarnings("unused") and

@SuppressWarnings("unchecked") to methods,

classes and variables that appear in the call trace of the

JMH code with no other changes that might impact

the energy consumption.

0.018

add class annotation 3

modify method annotation 1

add attribute annotation 1

#45bf2d 6.8%

add method annotation 3

Adding @SuppressWarnings("unchecked") to

methods and moving classes (project reorganization)

that appear in the call trace of the JMH code.

0.000

move class 30

JGraphT

#033164 6%

merge attribute 1

Some code restructuring, reorganization and class

movement that that appear in the call trace of the JMH

code. No other changes suspected of impacting the en-

ergy consumption were detected

0.056

change parameter type 1

rename parameter 9

move method 22

rename class 1

extract class 1

move attribute 15

move class 8

merge parameter 6

change variable type 19

change attribute type 1

#f1074b 5%

add method annotation 1

Adding @Override annotation and the renaming of

some attributes/parameters. However these changes

does not appear in the call trace of the JMH code.

0.2

add class annotation 60

rename class 2

rename attribute 1

change variable type 16

rename parameter 4

JFlex #b34361 5%

add method annotation 53

Adding @Override annotation to methods that appear

in the call trace of the JMH code with no other changes

that might impact the energy consumption.

0.054

move & rename method 1

rename class 1

Eclipse Collections

#b9dfbc 6% add method annotation 9944

Adding @override annotation to methods that ap-

pear in the call trace of the JMH code with no other

changes.

0.4

#298b7a 5% add method annotation 73

Adding @override annotation to methods that appear

in the call trace of the JMH code, but too many changes

unrelated to refactoring were found.

0.01

@SuppressWarnings("unchecked"),

@SuppressWarnings("unused")) and ran hun-

dreds of millions times each, on classes, methods

and variables to check whether it has an effect on the

energy consumption. The results—as expected—did

not have any effect (about 1% difference that we

cannot consider due to CPU energy variations (Our-

nani et al., 2020)) on energy consumption, as

annotations are not supposed to have a substantial

impact on the generated bytecode that would be

executed by the JVM. This would invalidate the fact

that the observed energy consumption difference is

mainly related to the add annotation refactoring in

the commits that only contain this type of refac-

toring, such as #827717, #b9dfbc, and #298b7a.

The second micro-benchmark concerns the move

class refactoring, where we measured the energy

consumption for several scenarios, after moving

some classes/interfaces around and reorganizing

the structure of the micro-benchmark. The results

showed a difference in energy consumption of up

to 8%, with an average standard deviation of 5%.

The move class refactoring—which is often ac-

companied with the rename refactorings—indicates

a code reorganization that might have an impact.

While the observed impact through the JMH exper-

iments or with micro-benchmarking might not be

substantial, it would be beneﬁcial to be aware that

ICSOFT 2021 - 16th International Conference on Software Technologies

restructuring/reorganizing a project could have an

impact on energy consumption, and thus compare the

before/after energy consumptions to track that effect.

Unfortunately, we could not detect any speciﬁc

pattern or guidelines on when the code reorganization

or restructuring would impact positively or negatively

the energy consumption. Hence, we can only faith-

fully retain the commit #45bf2d of the Gson project

among the commits of Table 3, where the 30 move

class refactoring could have been responsible of 2%

of energy consumption difference as the standard

deviation of the measures is 5%.

We ﬁnally conclude that structure-oriented refac-

toring has no substantial impact on the energy con-

sumption of the main functionality of 7 projects that

have been existing for at least 5 years with a total of

16, 046 commits. We argue that it could be applied to

improve the code quality with no negative impact on

software energy consumption. Although, comparing

the energy consumption before and after the changes

is always a good practice to keep track of its evolu-

tion.

To answer RQ2, we conclude that code refactor-

ing rules are mostly ”safe” operations that have

no substantial impact on software energy con-

sumption. Developers should not fear structure-

oriented refactorings, especially regarding how

little is the impact they could have compared

to the real energy consumption evolution of

projects, registered while answering RQ1.

4 RELATED WORK

In this section, we review the state of the art of green

software design efforts related to code refactorings.

Desktop Applications. Achieving software energy

efﬁciency through refactorings has been studied for

desktop applications and server-side applications.

Pinto et al. discuss 12 contributions taken from the

state of the art on the refactoring that can be applied

to improve software energy efﬁciency (Pinto et al.,

2015). This literature review was conducted on the

papers that were published in 8 of the top software

engineering conferences prior to 2015. It summa-

rizes some interesting information and practices re-

lating to CPU ofﬂoading, HTTP requests, I/O opera-

tions, DVFS techniques, etc. Sahin et al. also studied

the impact of 6 refactoring rules on a total of 197 se-

lections found in 9 Java applications. Their results

showed that the impact of applying the refactoring

could be statically signiﬁcant, but is not very consis-

tent across the software and platform versions. They

suggested that knowledge on the energy consumption

impact of refactoring rules could be integrated within

IDEs to help developers building less energy-bleeding

software.

In a more detailed study of the impact of only one

refactoring rule ”inline method” on 3 Java applica-

tions, (W G P Silva et al., 2010) reported that the im-

pact on the execution time and energy consumption

that was expected to be positive, was not always true.

Rather than looking for green refactoring rules

reducing software energy consumption, some prac-

titioners chose to conduct wider studies that ap-

ply on a much larger set of refactorings to cap-

ture a subset of ”green” rules. This is exactly what

the authors of (Jae-Jin Park et al., 2014) pursued:

They prepared C++ micro-benchmarks of 63 refac-

toring techniques/design patterns suggested by Martin

Fowler (10., 1999), then ran experiments and isolated

a set of green refactoring rules based on the micro-

benchmarks for C++.

The authors of (Kumar et al., 2017) focused on

investigating the impact of Java coding practices,

which include primitive data types, operations on

strings, usage of exceptions, loops, and arrays. Us-

ing RAPL (Khan et al., 2018), they measure the

energy consumption of code snippets and micro-

benchmarks and presented some minor observations,

such as string concatenation consuming less than

StringBuilder and StringBuffer, static variables

consume 60% more energy compared to instance vari-

ables, etc.

Mobile Applications. In another context, the reduc-

tion of software energy consumption through refac-

toring actions has also been explored in the con-

text of mobile applications. EARMO proposes

a multi-objective refactoring approach to automat-

ically improve the architecture of mobile applica-

tions (Morales et al., 2018). The authors conducted

an empirical study to measure the negative impact of

8 anti-patterns on 20 open-source applications. They

then used a multi-objective search-based approach,

called EARMO, to correct up-to 84% of the anti-

patterns on the tested applications and increase the

battery lifespan by up-to 29 minutes. However, their

statistical analyses with a signiﬁcance level of 5%

only showed that half of the rules can impact energy

efﬁciency in some cases. Moreover, the CPU/chip en-

ergy variation has not been taken into account for the

signiﬁcance level.

Other works also considered energy efﬁcient

refactoring for mobile applications (Gottschalk et al.,

2013). In particular, the authors of (Rodriguez, 2017)

presented some early experiments on different micro-

benchmarks and discussed many coding aspects with

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

a focus on implementation techniques, such as how to

iterate on a matrix, avoid operations with immutable

data types, evaluating strings, or the use the more

speciﬁc numeric data types to save battery life. An-

war et al. (Anwar et al., 2019) also gave concrete

examples on how to save some battery time through

refactoring. They achieved a maximum of 10% of en-

ergy savings by refactoring the DuplicatedCode and

TypeChecking code smells.

Cruz et al. (Cruz and Abreu, 2017) studied the ef-

fect of 8 of the best performance-based practices on

the energy efﬁciency of 6 Android applications. The

results of the experiments showed that some patterns,

such as ViewHolder, DrawAllocation, WakeLock, Ob-

seleteLayoutParam need to be taken into account for

a better design of energy-efﬁcient applications, with

a reported impact of 4.5% for the Writeily Pro app.

The authors also proposed the LEAFACTOR tool to

improve the energy efﬁciency of Android applications

by automatically refactoring the source code to ﬁx the

above patterns (Cruz et al., 2017). The process was

applied on a set of 140 open-source Android appli-

cations and yielded a total of 222 refactorings, which

were submitted as pull requests, with 16 successfully

merged pull requests. Unfortunately, the paper does

not discuss any further energy enhancements of the

applied LEAFACTOR refactorings on the original ap-

plications. While the reported impact is still rela-

tively small, most of the covered patterns are related

to screen/sensors usage that are very speciﬁc to mo-

bile applications and cannot be generalized.

Beyond the State of the Art. While energy varia-

tion and measurement errors inherently represent a

serious threat to the accuracy of the previous works

considered in this paper, our results do not contra-

dict observations reported in the context of mobile

applications. Indeed, our study focuses on assessing

the energetic impact of structure-oriented code refac-

torings that have been mined from 7 long-existing

Java desktop projects. While the comparison with

other works that focused os a assessing the ener-

getic impact of a set of code refactoring rules on dif-

ferent scenarios may be not completely fair due to

the eventual differences of the considered refactor-

ing rules and type of applications, we still noticed

that the registered impact for server/desktop applica-

tions of structure-oriented refactorings is usually less

than 5% (Jae-Jin Park et al., 2014) (Moreira et al.,

2020) and sometimes not even stable (W G P Silva

et al., 2010). This is highly related to the energy vari-

ation (Ournani et al., 2020). Otherwise, code refac-

torings can have a different impact on mobile ap-

plications as discussed by Palomba et al. (Palomba

et al., 2019), Linares-Vasquez et al. (Linares-V

asquez

et al., 2018) Iannone et al. (Iannone et al., 2020) and

Agolli et al. (Agolli et al., 2017), as they can directly

impact alternative hardware resources, such as the de-

vice display and sensors, with a more effective impact

on energy consumption. Yet, we propose an empirical

methodology to analyze the impact of refactorings on

the energy consumption of any software. We thus be-

lieve that our methodology would deserve to be con-

sidered in the context of server applications in order to

assess more speciﬁc code refactorings applied along

the lifespan of such software systems.

5 THREATS TO VALIDITY

There are a couple of issues that can impact the ac-

curacy of our results. First, our analysis highly de-

pends on the REFACTORINGMINER tool and its abil-

ity to extract every single occurrence of each of the

55 refactorings it supports. Moreover, there are some

other refactorings, not listed among the 55, that have

not been extracted and thus considered in our study,

especially those related to implementation and com-

putation details and those that cannot be discovered

automatically. During our experiments, we use Intel

RAPL to measure energy consumption. It is one of

most accurate tools to measure CPU and DRAM en-

ergy consumption (Desrochers et al., 2016), but only

reports on the global energy consumption, which in-

cludes the OS and the other processes running with

the software system under study. We thus conducted

experiments on a minimal OS setup and disabled

all optional daemons and services, along with other

guidelines and best practices in order to reduce the

error margin and the CPU energy variation to the min-

imum (Ournani et al., 2020).

We also focused on running benchmarks that last

for many seconds (around 150 sec for Gson, 450 sec

for XStream, 330 sec for OkHttp, 290 sec for Google-

Http, 780 sec for JGraphT, 720 sec for JFlex, and

600 sec for Eclipse Collections), so we can obtain

trustful and robust evaluations of the potential impact

of changes between commits with an overall continu-

ous execution time of experiments that exceeded 100

hours.

The manual steps in our study remain the design

of the JMH benchmarks and some checks of the git

diffs. In the ﬁrst case, we tried to write benchmarks

that stress the main purpose or functionality of each

project, so we can ensure that the comparison is based

on the same functionalities that are available on all

commits and versions. While this is moderately easy

for some projects, such as Gson or XStream, it is

much more complicated for other projects, such as

ICSOFT 2021 - 16th International Conference on Software Technologies

Eclipse Collections where many collections and op-

erations are available and can change. We tried in

this case to cover many functionalities that are avail-

able in most commits, even if it requires some ad-

justments and adaptation when projects are restruc-

tured / reorganized between versions. Regarding git

diff, we gave the major importance to the commits

with the most impact, as it is not possible to metic-

ulously check all the changes on all the selected com-

mits. Another threat may be related to our selection

of the commits with the most refactoring to have a

reasonable execution time. Even if selected commits

are most likely to be the most impactful. It results in

a low number of selected commits among the global

set of commits.

6 CONCLUSION

This paper describes an investigation of the effective

impact of code refactoring on software energy con-

sumption. We analysed 7 open-source Java projects

and extracted 55 possible types of refactorings over

all the commits, with more than 10k commits. We

then selected the commits with the most refactorings

and evaluated the impact that could had those refac-

torings on the energy consumption. This process en-

sures the evaluation of the effective impact that refac-

toring has for established projects that have existed

for at least 5 years.

Overall, our results showed that structure-oriented

refactorings have no substantial impact on the en-

ergy consumption on Java server-side software. This

means that structure-oriented code refactorings can

be safely applied to improve the maintainability and

readability of source code with no signiﬁcant penalty

on the energy consumption of Java projects. When it

comes to reducing software energy consumption, we

believe that developers’ efforts should be directed to-

wards other software aspects and implementation op-

timizations rather than structure-oriented refactoring,

such as data structures, used algorithms, I/O,etc.For

the Gson project, we noticed that even the commits

with a lot of refactorings have no effective impact on

the evolution of software energy consumption. How-

ever, the energy consumption of the Json serializa-

tion/deserialization features decreased by 4-fold in 3

years and 5-fold in 12 years. This highlights that the

reduction in energy consumption of the project over

time, is not driven by refactorings.

We believe that our approach can also be used to

study/discover other refactoring rules, and extend our

results to alternative projects, maybe for other lan-

guages than Java. Most importantly, this should mo-

tivate future works to validate that refactorings can be

safely applied with no side effect on energy consump-

tion, yet investigate the commits and the nature of

code changes that increase/decrease energy consump-

tion.

REFERENCES

(1999). Refactoring: Improving the Design of Existing

Code. Addison-Wesley Longman Publishing Co.,

Inc., USA.

Abid, C., Alizadeh, V., Kessentini, M., do Nascimento Fer-

reira, T., and Dig, D. (2020). 30 years of software

refactoring research: A systematic literature review.

CoRR, abs/2007.02194.

Agolli, T., Pollock, L. L., and Clause, J. (2017). Investi-

gating decreasing energy usage in mobile apps via in-

distinguishable color changes. In 4th IEEE/ACM In-

ternational Conference on Mobile Software Engineer-

ing and Systems, MOBILESoft@ICSE 2017, Buenos

Aires, Argentina, May 22-23, 2017, pages 30–34.

IEEE.

Anwar, H., Pfahl, D., and Srirama, S. N. (2019). Evaluat-

ing the Impact of Code Smell Refactoring on the En-

ergy Consumption of Android Applications. In 2019

45th Euromicro Conference on Software Engineer-

ing and Advanced Applications (SEAA), pages 82–86,

Kallithea-Chalkidiki, Greece. IEEE.

Bree, D. C. and Cinn

eide, M.

O. (2020). Inheritance versus

delegation: which is more energy efﬁcient? In ICSE

’20: 42nd International Conference on Software En-

gineering, Workshops, Seoul, Republic of Korea, 27

June - 19 July, 2020, pages 323–329. ACM.

Chowdhury, S. A., Hindle, A., Kazman, R., Shuto, T., Mat-

sui, K., and Kamei, Y. (2019). Greenbundle: an em-

pirical study on the energy impact of bundled process-

ing. In Atlee, J. M., Bultan, T., and Whittle, J., edi-

tors, Proceedings of the 41st International Conference

on Software Engineering, ICSE 2019, Montreal, QC,

Canada, May 25-31, 2019, pages 1107–1118. IEEE /

ACM.

Cruz, L. and Abreu, R. (2017). Performance-based guide-

lines for energy efﬁcient mobile applications. In 4th

IEEE/ACM International Conference on Mobile Soft-

ware Engineering and Systems, MOBILESoft@ICSE

2017, Buenos Aires, Argentina, May 22-23, 2017,

pages 46–57. IEEE.

Cruz, L., Abreu, R., and Rouvignac, J. (2017). Leafac-

tor: Improving Energy Efﬁciency of Android Apps via

Automatic Refactoring. In 2017 IEEE/ACM 4th Inter-

national Conference on Mobile Software Engineering

and Systems (MOBILESoft), pages 205–206.

Desrochers, S., Paradis, C., and Weaver, V. M. (2016). A

validation of dram rapl power measurements. In Pro-

ceedings of the Second International Symposium on

Memory Systems, MEMSYS ’16, page 455–470, New

York, NY, USA. Association for Computing Machin-

ery.

Efron, B. (2000). The bootstrap and modern statistics. Jour-

nal of the American Statistical Association, 95(452).

Tales from the Code 1: The Effective Impact of Code Refactorings on Software Energy Consumption

Fonseca, A., Kazman, R., and Lago, P. (2019). A manifesto

for energy-aware software. IEEE Softw., 36(6):79–82.

Fowler, M. (1999). Refactoring: Improving the Design of

Existing Code. Addison-Wesley, Boston, MA, USA.

Gottschalk, M., Jelschen, J., and Winter, A. (2013). Energy-

Efﬁcient Code by Refactoring. Softwaretechnik-

Trends, 33(2):23–24.

Iannone, E., Pecorelli, F., Nucci, D. D., Palomba, F., and

Lucia, A. D. (2020). Refactoring android-speciﬁc en-

ergy smells: A plugin for android studio. In ICPC ’20:

28th International Conference on Program Compre-

hension, Seoul, Republic of Korea, July 13-15, 2020,

pages 451–455. ACM.

Jae-Jin Park, Jang-Eui Hong, and Sang-Ho Lee (2014). In-

vestigation for Software Power Consumption of Code

Refactoring Techniques. In SEKE.

Kerievsky, J. (2004). Refactoring to Patterns. Pearson

Higher Education.

Khan, K. N., Hirki, M., Niemi, T., Nurminen, J. K., and Ou,

Z. (2018). Rapl in action: Experiences in using rapl

for power measurements. ACM Trans. Model. Per-

form. Eval. Comput. Syst., 3(2).

Kumar, M., Li, Y., and Shi, W. (2017). Energy consumption

in Java: An early experience. In 2017 Eighth Interna-

tional Green and Sustainable Computing Conference

(IGSC), pages 1–8, Orlando, FL. IEEE.

Linares-V

asquez, M., Bavota, G., Bernal-C

ardenas, C.,

Oliveto, R., Di Penta, M., and Poshyvanyk, D. (2014).

Mining energy-greedy API usage patterns in Android

apps: An empirical study. In Proceedings of the 11th

Working Conference on Mining Software Repositories

- MSR 2014, pages 2–11, Hyderabad, India. ACM

Press.

Linares-V

asquez, M., Bavota, G., Bernal-C

ardenas, C.,

Penta, M. D., Oliveto, R., and Poshyvanyk, D. (2018).

Multi-objective optimization of energy consumption

of guis in android apps. ACM Trans. Softw. Eng.

Methodol., 27(3).

Manotas, I., Bird, C., Zhang, R., Shepherd, D., Jaspan,

C., Sadowski, C., Pollock, L., and Clause, J. (2016).

An empirical study of practitioners’ perspectives on

green software engineering. In Proceedings of the

38th International Conference on Software Engineer-

ing - ICSE ’16, pages 237–248, Austin, Texas. ACM

Press.

Manotas, I., Sahin, C., Clause, J., Pollock, L., and Win-

bladh, K. (2013). Investigating the impacts of web

servers on web application energy usage. In 2013

2nd International Workshop on Green and Sustain-

able Software (GREENS), pages 16–23, San Fran-

cisco, CA, USA. IEEE.

Morales, R., Saborido, R., Khomh, F., Chicano, F., and An-

toniol, G. (2018). EARMO: an energy-aware refactor-

ing approach for mobile apps. IEEE Trans. Software

Eng., 44(12):1176–1206.

Moreira, E., Correia, F. F., and Bispo, J. (2020). Overview-

ing the liveness of refactoring for energy efﬁciency. In

Conference Companion of the 4th International Con-

ference on Art, Science, and Engineering of Program-

ming, pages 211–212, Porto Portugal. ACM.

Ournani, Z., Belgaid, M. C., Rouvoy, R., Rust, P., Pen-

hoat, J., and Seinturier, L. (2020). Taming energy con-

sumption variations in systems benchmarking. In Pro-

ceedings of the ACM/SPEC International Conference

on Performance Engineering, ICPE ’20, page 36–47,

New York, NY, USA. Association for Computing Ma-

chinery.

Palomba, F., Nucci, D. D., Panichella, A., Zaidman, A., and

Lucia, A. D. (2019). On the impact of code smells on

the energy consumption of mobile applications. Inf.

Softw. Technol., 105:43–55.

Pinto, G., Castor, F., and Liu, Y. D. (2014). Understanding

energy behaviors of thread management constructs. In

Proceedings of the 2014 ACM International Confer-

ence on Object Oriented Programming Systems Lan-

guages & Applications - OOPSLA ’14, pages 345–

360, Portland, Oregon, USA. ACM Press.

Pinto, G., Liu, K., Castor, F., and Liu, Y. D. (2016). A Com-

prehensive Study on the Energy Efﬁciency of Java’s

Thread-Safe Collections. In 2016 IEEE International

Conference on Software Maintenance and Evolution

(ICSME), pages 20–31, Raleigh, NC, USA. IEEE.

Pinto, G., Soares-Neto, F., and Castor, F. (2015). Refactor-

ing for Energy Efﬁciency: A Reﬂection on the State of

the Art. In 2015 IEEE/ACM 4th International Work-

shop on Green and Sustainable Software, pages 29–

35, Florence, Italy. IEEE.

Rodriguez, A. (2017). Reducing Energy Consumption of

Resource-Intensive Scientiﬁc Mobile Applications via

Code Refactoring. In 2017 IEEE/ACM 39th Inter-

national Conference on Software Engineering Com-

panion (ICSE-C), pages 475–476, Buenos Aires, Ar-

gentina. IEEE.

Rodriguez-Cancio, M., Combemale, B., and Baudry, B.

(2016). Automatic microbenchmark generation to

prevent dead code elimination and constant folding.

In Proceedings of the 31st IEEE/ACM International

Conference on Automated Software Engineering, ASE

2016, page 132–143, New York, NY, USA. Associa-

tion for Computing Machinery.

Samir Hasan, Rachary King, and Munawar Haﬁz (2016).

Energy Proﬁles of Java Collections Classes. In ICSE.

Tsantalis, N., Ketkar, A., and Dig, D. (2020). Refactoring-

miner 2.0. IEEE Transactions on Software Engineer-

ing.

Tsantalis, N., Mansouri, M., Eshkevari, L. M., Mazinanian,

D., and Dig, D. (2018). Accurate and efﬁcient refac-

toring detection in commit history. In Proceedings of

the 40th International Conference on Software Engi-

neering, ICSE ’18, pages 483–494, New York, NY,

USA. ACM.

van der Kouwe, E., Andriesse, D., Bos, H., Giuffrida,

C., and Heiser, G. (2018). Benchmarking Crimes:

An Emerging Threat in Systems Security. CoRR,

abs/1801.02381.

Verdecchia, R., Procaccianti, G., Malavolta, I., Lago, P., and

Koedijk, J. (2017). Estimating energy impact of soft-

ware releases and deployment strategies: The kpmg

case study. In 2017 ACM/IEEE International Sym-

posium on Empirical Software Engineering and Mea-

surement (ESEM), pages 257–266.

W G P Silva, Lisane Brisolara, Corr

ea, U. B., and Carro, L.

(2010). Evaluation of the impact of code refactoring

on embedded software efﬁciency. Unpublished.

ICSOFT 2021 - 16th International Conference on Software Technologies
