Overview of Model Interpretation Techniques and Their Applications

Vladislavs Nazaruks

and Jānis Osis

Department of Applied Computer Science, Riga Technical University, Sētas iela 1, Riga, Latvia

Keywords: Model Execution, Model Interpretation, Systems Analysis, Domain Analysis.

Abstract: Model interpretation opens quite wide opportunities for domain analysts and software developers. The main

weakness related to using domain models in software development is a lack of resources in projects and an

invisible value for business stakeholders. Certainly, the doubts that model interpretation will provide

additional resources for projects are objective, but it could allow dealing with the existing ones by increasing

the value of domain modeling and analysis to the business stakeholders. Two main factors can raise this

probability: first, visible execution of models or at least helpful results of this, and second, the opportunity to

modify the model and see how changes affect the behavior of the planned system. This paper overviews

existing model interpretation techniques with the aim to understand possible architectural solutions, their

advantages and weaknesses for certain models. The results of this overview can help researchers those of

starting development of their own model interpreter.

1 INTRODUCTION

A use of models as an executable artifact is a desired

target of the model-driven development. The main

idea of this was proposed in the Object Management

Group’s (OMG) guide on Model Driven Architecture

(MDA) in 2001 (Miller and Mukerji, 2001). It

requires having a formal (computer-understandable)

model as an input. This input model must have

enough details for getting complete source code.

Completeness of the model means that the model is

likely to be complex. Unfortunately, constructing the

complete complex model cannot be done in one

moment; this requires incremental work. Besides,

understanding of such a model is not a trivial activity

(Quante, 2016b). The attempt to create a complete

language is the Unified Modeling Language (UML)

proposed by the OMG (OMG, 2005). At present, the

UML language can be used for its model

interpretation or for code generation. However, its

independence from software development techniques

and platforms, size, incoherence, different

interpretations, lack of causality and frequent

subsetting lead to ambiguous semantics, cognitive

misdirection during the development process,

inadequate capture of system’s properties and so on

https://orcid.org/0000-0003-4335-707X

https://orcid.org/0000-0003-3774-4233

(Osis and Donins, 2017). The mentioned problems

affect the quality of generated code as well as require

additional transformations and mechanisms for UML

model interpretation as discussed in Section 3.2.

In the process of building a complete input model,

it is necessary to be able to “run”, “debug” and “test”

it similarly to debugging and testing the source code.

From one point of view, manual reviews and

sometimes partial prototyping can be successfully

applied, but manual work is slow and does not

exclude human mistakes due to complexity of

models. From the other side, automated model

checking techniques exist like, for instance, those of

used to verify requirements and design for real-time

embedded and safety-critical systems. These

automated model-checking techniques require a use

of formal modeling language, e.g., finite state

machines can be used for “control-oriented” systems

(applied in aerospace, avionics, automotive, etc.)

(Palshikar, 2004). However, the model checking also

requires manual translation of requirements

descriptions into these languages, as well as it is hard

to follow the checking algorithm execution in case of

“data-oriented” systems where business logic is more

important than behavior.

Another opportunity is interpretation or “running”

of models. The goal of this paper is to overview

Nazaruks, V. and Osis, J.

Overview of Model Interpretation Techniques and Their Applications.

DOI: 10.5220/0010534105130520

In Proceedings of the 16th International Conference on Evaluation of Novel Approaches to Software Engineering (ENASE 2021), pages 513-520

ISBN: 978-989-758-508-1

513

existing implementations of model interpretation

techniques and their applications in software

development.

Section 2 presents the considerations that

influence the research flow. Section 3 gives an

overview of existing model interpreters. Section 4 is

dedicated to discussion on the main findings.

Section 5 concludes the paper with main results and

discussion on validity of the research done.

2 RESEARCH QUESTIONS AND

METHOD

Reading literature, one can find that it is possible to

“simulate” a model, to “execute or run” a model, and

to “interpret” a model. Let us look what does it mean.

Simulation of models usually is used for real complex

systems that are hard to be analyzed analytically, e.g.,

day-to-day operation of a bank. “A simulation model

is a parameterised model that is solved on the

computer…” (Arnott, 2012). It uses statistical data

about operation of the real system it describes as well

as autonomously existing events. Execution of

models usually refers to an executable UML model,

which can represent either planned to be built

software or already existing one. A systematic

overview on execution of UML models (Ciccozzi,

Malavolta, and Selic, 2019) indicated two ways of

UML models execution, namely, interpretation and

translation. The authors’ research showed that a large

part of existing UML execution tools uses a

translative approach to a programming language (in

most cases it is Java). The reason is a desire to get

generated production artifacts as the result of

modeling. However, interpretative approaches are

mostly used for validating and improving functional

correctness at the beginning of development.

Although there are few existing model-level

debugging implementations, both translative and

interpretative executions can be combined with the

simulation mechanism based on autonomously

existing events. Simulation of models extends users’

abilities to debug and correct the model itself. Thus,

interpretation of models is just a way how to execute

a model.

A topological functioning model (TFM)

introduced by Jānis Osis in 1969 (Osis, 1969) is a

formal mathematical model that can be used both for

business modeling and software source code

generation (Nazaruka and Osis, 2019; Osis and

Donins, 2017) starting from the automated processing

of textual descriptions of the system’s structure and

functionality (Nazaruka, 2020). However, the

constructed TFM requires experts’ check. In order to

assist this check TFM interpetation can be used. Thus,

we want to understand what is the state of the art in

the field and what model interpretation techniques

could be more beneficial.

In order to achieve the goal stated, a list of

questions has been defined, answers on which should

be found during the overview of the existing

publications. The research questions are as follows:

 What software model interpreters exist?

 What is the purpose for which a model

interpreter is used?

 What input models do they use?

 How model interpretation is implemented?

 What systems characteristics do model

interpreters allow users to check?

 How interaction with a user is implemented? Is

it possible at the run-time?

The information on software model interpreters

published by IEEE, ACM, ScienceDirect and those of

presented in Google Scholar have been searched for a

period from 2000 till 2020. The starting year, 2000,

was selected as the year when Model Driven

Architecture was presented to the public. An

additional filter used was the context, i.e., software

development including embedded and real-time

systems. Besides that, the research works related to

pure code generation from models were omitted.

The keywords used are “model interpretation,”

“model execution,” and “model interpreter.” It must

be said that quite many research works were found,

and selection of those found can illustrate the main

principles of model interpretation.

In order to structure the information found, these

key publications are grouped according to the

interpretable models, i.e., business process models,

UML models and domain specific models.

3 MODEL INTERPRETATION

TECHNIQUES

The general definition of interpreters states (Karsai,

1999): “model interpreters are transformation

programs that walk a graph (the model objects), and

perform actions during this process.” A model

interpreter should have the following components:

model structure, visitors and traversals. The model

structure can be a graph or its textual specification.

Thus, it usually represents a set of nodes and

transitions between them. One of the issues here is

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

514

that the graph may consist of nodes of heterogeneous

types with a certain action related to a certain type.

The common solution is a use of the visitor design

pattern, which implementing Visitor classes can be

assigned to a specific type of a node and be invoked

if needed (Karsai, 1999). In order to capture

information on what node the interpreter need to go

next, traversals are used. Traversals are objects that

contain the traversal code fragments and can also

contain state information. Traversals and visitors are

to be directly linked to each other. However, visitor-

based interpreters have two limitations: coupled

interpreter-logic and generation-logic, as well as a

minimal reuse of code (Hill and Gokhale, 2012).

In the model-driven engineering, a model

interpreter is a software component that operates on

the information captured in a system model to

produce some useful artifact (Edwards, Seo, and

Medvidovic, 2008). Model interpreters may extract

the model structure and properties (Edwards et al.,

2008) or be based on the modifiable pre-developed

meta-model (Shroff, Agarwal, and Devanbu, 2009).

However, universal interpreters that are independent

of the application domain do not exist (Djukić,

Luković, Popović, and Ivančević, 2012).

Cook et al. have investigated many techniques to

define the interpretations of models (Cook, Delaware,

Finsterbusch, Ibrahim, and Wiedermann, 2009).

According to the authors, one common approach is to

use a translator from one modeling language to

another modeling language or to code. Dynamic

interpreters are also common in practice, although

they have received less attention in research

publications. One point of confusion is that the term

“interpreter” is often used to mean “translator” in the

model-driven literature. Here, the term “interpreter”

is also used in its more traditional meaning as a meta-

program that executes a program in the given

language, the same as the authors use in (Cook et al.,

2009). According to the authors, translators have the

advantage that they can produce efficient code and

target any runtime environment. Interpreters are often

easier to write then compilers, but they are typically

slower and do not necessarily integrate easily with

other parts of a system, which may be written in

compiled languages.

3.1 Business Process Model

Automation

According to (Ferme, Lenhard, Harrer, Geiger, and

Pautasso, 2017), workflow automation relates to the

execution of automated business processes within

Workflow Management Systems (WfMSs). Ferme et

al. (Ferme et al., 2017) think that the most critical part

in WfMSs is the modeling language implementations

that do not satisfy language standards; nevertheless,

there are several proposed standards for the modeling

language. The main part of the WfMSs responsible

for business model running is a process engine. This

is not a new thing now. There are many commercial

and open-source solutions of process engines, e.g.,

IBM’s WebSphere, Windows Workflow Foundation,

JBPM, Bonita, Apache ODE, ActiveBPEL

(ActiveVOS), Oracle BPEL Process Manager (Oracle

BPM), etc. In this part, several of them will be

considered to understand main common principles

implemented in them.

The BPEL engine uses business processes

descriptions as “a series of activities” which are

executed by web services (ARIS BPM Community,

2021). According to the BPEL vendors, a graphical

representation of a BPEL process reduces complexity

of the process flows and allows integrating BPEL

diagrams into the process architecture model. These

graphical models are exported into a BPEL XML

(eXtensible Markup Language) based script. In

essence, the BPEL combines block structures and

allows describing transitions between them as

directed graphs (Juric, n.d.).

The IBM’s WebSphere line’s (IBM, 2011)

process engine takes as a basis high-level XML

process definitions in the BPEL supplemented with

code fragments in Java. The execution and

monitoring of models requires IBM’s WebSphere

Application Server that at present supports

Kubernetes and microservices.

Microsoft also has had its embeddable workflow

engine called Windows Workflow Foundation (WF)

(Microsoft, 2017). The WF is a part of the .NET

framework that allows developing workflow

functionality using XAML-encoded workflow

definitions. This possibility is implemented in the

Workflow Designer (WD), which is a visual designer

and debugger for the graphical construction and

debugging. The basic building blocks in WF are

activities. The developer can select the needed one

from the Activity Designer Library templates and

Visual Studio will create an activity designer

definition in XAML and a code-behind

implementation file. Besides that, it is possible to

model arguments with values, variables for use in

data-binding scenarios and conditional statements,

and expressions (i.e., controls used in workflow

activities to enter and evaluate expressions).

Activities can form the sequential flow or a state

machine workflow, can be grouped and even ordered

according to a hierarchy. In WF, a workflow running

Overview of Model Interpretation Techniques and Their Applications

515

is thread-based. Debugging of the workflows is

possible via Workflow Designer or at the XAML

level.

Process engines mentioned here depend on the

language used for the workflow design and lack

flexibility. Therefore, if someone wants to provide the

flexibility in this context, they should create a process

virtual machine and then some suites for each

potential language.

BMPN models can also be interpreted, e.g., to

ensure modification of processes without recompiling

them completely, as it is demonstrated for smart

contracts (Lopez-Pintado, Dumas, Garcia-Banuelos,

and Weber, 2019). The main difficulty in model-

based smart contracts used for blockchain-based

business process execution is a lack of flexibility

(because they are attached to different versions of the

model) and high deployment costs. The suggested

Caterpillar interpreter supports all three process

modeling perspectives, namely, control-flow, data,

and resources. The idea is to create a new subprocess,

relate it to the existing one and generate code for this

new subprocess. The one issue that remains in this

implementation is a lack of consistency checking.

Another possible solution is described by

Weigold, Kramp and Buhler (Weigold, Kramp, and

Buhler, 2007), where they suggest the ePVM, an

embeddable process virtual machine. It consists of a

lightweight library with basic functionality to state

and control flow managements, process persistence

and transactions, monitoring, inter-process

communication, and communication with the host

application, as well as optional functionality for

workflow systems support, human interaction and

even integration with “not native” process languages.

In the ePVM, a business process is developed using a

programming environment supporting

communicating extended finite state machines

(CEFSM). The CEFSM is implemented as libraries

functions called via API. Thus, the business process

model can be defined by an ordinary JavaScript

function. The process definitions can be also

structured by using packages. Concurrency and

synchronization are provided by a threading

mechanism. Interprocess communication is

implemented by a message-passing mechanism.

Communication with the host application is

organized via host API.

The Event-driven Process Execution Model

(EPEM) supporting process virtual machine called

OncePVM is presented in (Wu, Wei, Gao, and Dou,

2012). By the authors’ opinion, the event-driven

architecture is more preferable for highly concurrent

systems than the thread-driven (or similar to it –

process-driven). The main idea is that a process

description consists of nodes and transitions. Each

node or action contains one or more ports and listens

or produces the dedicated events. Besides, the action

also holds a reference of a context to preserve the

corresponding state. The context maintains all the

requested variations of an executing instance.

Preconditions and postconditions serve as indicators

of the task readiness to start and success of the

completion and are checked by independent actions

called connectors. Thus, connectors could be

modified to adapt different pre/post-conditions and

ensure necessary behavior. The OncePVM has a

triple-layered architecture. The bottom layer consists

of a set of basic services for processing actions,

threads, and objects. The middle layer provides

support for the runtime process execution. The top

layer is dedicated for event queue managements and

even scheduling. Before execution, the process

description (in any process description language) is

parsed into memory objects for each presented

element and then these memory objects are

transformed into executable actions and events. Then

it is possible to start the execution of the process by

deploying the execution objects and managing them

by the runtime engine. Faults are handled as related

fault events.

The interesting workflow-based model interpreter

called InstantApp (Shroff et al., 2009) is dedicated to

web applications. It provides functionality for

runtime modifications of web application forms by

changing the application model stored in a model

repository and cached in memory during runtime.

This interpreter gives a possibility not only to change

the graphical controls in forms but also to modify

business logic associated with them. For handling

changes in business logic, the authors use a “logic

map” which is an extension of Google’s MapReduce.

The logical map is a graph with create, search,

update, merge and reduce nodes. In general,

InstantApp also implements visitor-based pattern but

by using other means: each activity in a logic map is

assigned to an InstantApp form. The interpreter

searches all the activities that the user can perform

while using this form and executes them.

Summarizing, business process and workflow

automation is quite developed nowadays and supports

deployment of different scale applications as well as

new types of application architectures. However,

most of the tools are language dependent excluding

process virtual machines. Nevertheless, the

implementation of virtual machines is more complex,

it is the future of workflows automation.

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

516

3.2 UML Model Interpretation

The various approaches for executing UML models

are analyzed in Gotti and Mbarki’s work (Gotti and

Mbarki, 2016) in order to understand their

particularities and supporting tools. Supporting the

conclusion done by Cook et al. (Cook et al., 2009),

the authors rightly note the UML model execution is

possible either by compiling the model or by

interpreting it.

Model interpretation assumes the presence of a

virtual machine which is an environment where

executable UML models can be read and executed

without generation of executable code from them.

In 2001 the idea of a UML virtual machine was

presented in (Riehle, Fraleigh, Bucka-Lassen, and

Omorogbe, 2001) where authors suggested to avoid

the step of generation of objects from classes but to

interpret them directly. As the authors wrote, all

objects should exist in the same memory space thus

providing the immediate causal connection between a

model and its instances. This was a kind of rapid

prototyping but without direct coding. Such

implementation allows runtime exploration of the

model by a developer. Instructions for this machine

are specified in UML, but the persistent version is in

XMI (XML Interchange) language. The memory

model uses facilities provided by Java, the

implementation language of the virtual machine. The

virtual machine has logical and physical architecture

that assumes that for each object in the logical

architecture a logical class and a physical (Java) class

are to be defined. The proposed virtual machine

allowed using of the restricted UML and OCL

(Object Constraint Language), since UML’s semi-

formal constructs may lead to the unexpected

interpretations. The most formal technique, i.e., UML

state charts, were used as the primary tool for modeling

object behavior. Besides that, the imperative part also

was required, and the authors added “hand-

programmed policy classes.” The advantages of this

solution are rapid user feedback, application

architecture independent execution of the model. The

main weakness was a limited usefulness of the UML.

Gotti and Mbarki indicated that nowadays an

executable UML model usually may consist of three

diagrams – the class diagram, the state chart diagram

and the activity diagrams – plus behavioral

specifications (Gotti and Mbarki, 2016). Executable

elements of UML can be defined using foundational

UML (fUML) and the supplementing Action

language for foundational UML (Alf). Nevertheless,

an executable UML model is first transformed into a

formal control flow graph or a finite state machine

and then analysis of these artifacts is performed. The

analysis checks paths, dead-ends, transitions, etc. The

same principles are implemented in the UML model

interpreter for verification and monitoring of UML

models of embedded cyber-physical systems that

plays a role of synchronous observer automata

(Besnard, Teodorov, Jouault, Brun, and Dhaussy,

2019). For model verification, the authors apply the

OBP2 model-checker to modeled UML state

machines. For runtime monitoring, the observer

monitors the current execution trace of the system.

The UML model interpreter has the action language

which is used to access states in the state chart

diagrams. The action language can specify guards and

effects of transitions and provide C macros to access

UML instances and their attributes.

The systematic overview of solutions suggested

before and after appearing of fUML and Alf

languages were overviewed in (Ciccozzi et al., 2019).

The authors have found 14 interpretive solutions, e.g.,

Moka that is Eclipse Papyrus plug-in, fUML virtual

machine, BridgePoint, etc. All of them focus on the

higher-level execution for simulation and model-

based analysis. The authors concluded that there is no

preferable solution among the overviewed. The level

of readiness of these solutions also differs and the

commercial status does not affect it much

(Ovchinnikova and Nazaruka, 2016, 2017).

3.3 Domain Specific Model

Interpretation

Model-based approaches got visible acceptance in

today’s automotive software system development

(Quante, 2016b). By raising the level of abstraction,

they became more understandable to humans.

However, the degree of complexity increases over

time and limits maintenance and understanding them

as well as increases the corresponding costs. Jochen

Quante has presented the idea of the interpreter for

such automotive software maintenance and

calibration (Quante, 2016b). This interpreter can be

called generic, since for any new modeling language

only the transformation to the intermediate

representation must be added. The interpreter itself is

based on control-flow and dependency graph. It

executes them step-by-step considering branches and

function calls. Concrete operations and decisions can

be delegated either to a visitor (the evaluator) class,

or to abstraction strategies that transform concrete

values into abstract values. The interpreter can detect

which code is never executed and can trace back to

the model level and indicate which parts of the model

are irrelevant, because it investigates all possible

Overview of Model Interpretation Techniques and Their Applications

517

paths. Besides, the interpreter can be used for

extracting formulas from code even symbolically

getting conditional formulas as a result, for concolic

testing (i.e., generating test cases with full path

coverage), and for recording and replay

measurements. Details on the suggested architecture

and functions are presented by Quante in (Quante,

2016a). The potential limitation of architecture of

such model interpreters is that it is hard to modify the

list of points to be visited and the list of points to be

generated (Hill and Gokhale, 2012).

An approach for testing models, generated code

and target interpreters is presented by Djukić et al.,

where they suggest using action reports – special

programs (generators) that conduct synchronization

between the domain-specific model, client

applications and target interpreter (Djukić et al.,

2012). The authors indicate that the limitation of their

approach is a lack of a generated code interpreter,

because then every model modification requires

generation of the application code, its compilation

and rerun of the application. The authors also note

that in case of domain-specific models neither the

source nor the target language needs to be known in

advance. Thus, one of the approaches that can be used

to create a stronger logical relationship between

debugging environments and modeling tools is the use

of patterns specific to each combination of a domain-

specific language and a target platform. The action

reports in the form of metadata is a specification of

transition from one diagram state to another. In its turn,

the target interpreter interprets synchronization

commands defined in the report and sets corresponding

property values in the report definition. The modeling

tool takes this modified report and runs operations on

the graphical interface elements. The transfer of action

report is done by packets.

In order to interpret architecture of computerized

numerical control (CNC) systems (Zhaogang, Di,

Feng, and Suhua, 2007) the authors propose the model

interpreter that generates source code automatically

from models. The models are created in conformity

with the predefined meta-model for CNC systems. The

model interpreter acts like a translator or, in other

words, a compiler of a programming language. When

the model interpreter works as a model translator, it

produces code in the input language of other analysis

or simulation tools, e.g., UPPAAL. Otherwise, it

produces code, static data-structures, configuration

files or customized generic components: these artifacts

can be compiled and linked.

The interesting improvement of the visitor-based

interpreters by using generative programming

techniques is presented by James Hill and Aniruddha

Gokhale (Hill and Gokhale, 2012). The authors call

their model interpretation technique

Metaprogrammable Interpreters for Model-driven

Engineering (MIME). Similarly to (Quante, 2016a),

Hill and Gokhale consider that using the Strategy

design pattern and Parametrized Strategy design

pattern partially addresses the problem of a reuse of

core interpretation logic, but note that it is still not

possible to modify the set of points to be visited. As a

solution they propose the interpreter built on the

parametrized strategy with a use of template

metaprogramming technique. This allows avoiding

points that should not be visited and, thus, the

corresponding code also is not generated.

Another application of model interpreters can be

for self-adaptive systems, where executable runtime

“megamodels” are interpreted and modified at

runtime (Vogel and Giese, 2012). A megamodel is a

feedback loop specification “by means of operations,

the control flow between operations, and the models

that are used by operations” (Vogel and Giese, 2012).

This kind of systems suggests separation of the

domain logic and the adaptation logic. In between

both, a feedback loop (or even a number of feedback

loops) ensures that the adaptation logic dynamically

governs the domain logic according to changes in the

environment or requirements to the domain logic or

to circumstances in the domain logic itself.

4 DISCUSSION

The search for publications on model interpretation

techniques resulted in understanding that there is

plenty such solutions with different purposes and for

different contexts. However, the research done gave

as answers on the questions set in Section 2.

What software model interpreters exist? There are

many solutions that can be considered as model

interpreters. Most of them are language specific. This

means that architecture and implementation of the

process engine is based on the language used for

process specification (design). This leads to inflexible

solutions that is a problem.

What is the purpose for which a model interpreter

is used? The model interpreters may be used for

executing and modifying the workflows (or other

process flow solutions) at the runtime; for supporting

the domain analysis, as well as for simulating,

debugging, testing, executing, and monitoring

domain-specific models of the embedded and real-

time systems.

What input models do they use? The input models

can be specified as workflows in BPMN or BPEL

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

518

languages or other languages developed for the same

field, as process specifications or domain-specific

models in XML and XMI or other XML based or

XML similar language (such as YAML).

How model interpretation is implemented?

Implementations differ from the simplest two layered

solutions to multiple executing engines dedicated to a

certain task, e.g., messaging, process execution,

process monitoring, etc. The one common thing is

that at the physical layer most of them are based on

some kind of finite automata thus providing expected

execution of the designed model.

What systems characteristics do model

interpreters allow users to check? Since model

interpreters support parametrization, it is possible to

check any control flow and data flow related

characteristics. However, the focus is mostly on

functional aspects, and rare solutions consider non-

functional characteristics.

How interaction with a user is implemented? Is it

possible at the run-time? The main principle of the

model interpretation is to support direct interaction

between an application and a user at the run-time

without interrupting it.

Returning to the question on the TFM

interpretation, we can conclude that this obviously is

possible. The TFM is based on the principles of

system theory and algebraic topology. Thus, it can be

translated into any kind of finite automata and

interpreted. The process engines are not suitable for

TFM interpretation since this model combines

processes in one digraph. The process engines will

require additional activities on separating scenarios.

The concept of virtual machines seems more

appropriate. The state chart or finite automata

obtained from the model would contain all possible

states and transitions, thus allowing proper model

debugging and simulation. Besides that, this solution

could be flexible to using different TFM specification

languages.

5 CONCLUSIONS

The aim of the given research was to overview the

state-of-the-art software model interpretation and

opportunities that the current solutions give to model

debugging, testing, simulation, and execution.

The six questions were set and clear answers on

them were achieved. The more advanced solutions

are presented in the field of workflow automation

within business process management systems. This

direction proposes complex industrial interpreters of

models. The main weaknesses of these solutions are

the complexity and dependency on the modeling

language. Plenty solutions are presented in the field

of UML models execution, but only several of them

are interpreters not compilers. The main weaknesses

of these solutions are the degree of their readiness and

uncertainty of the UML itself. Many ad-hoc solutions

exist in the field of embedded and real-time systems,

where domain-specific models require proper

simulation before implementation. The main

weakness here is that each solution is domain and

model dependent.

Future research directions are related to deeper

research on development of the TFM interpreter that

should apply advantages presented and avoid

weaknesses found.

REFERENCES

ARIS BPM Community. 2021. BPEL. Retrieved January

28, 2021, from https://www.ariscommunity.com/ bpel

Arnott, R. 2012. Simulation models for urban economies.

In International Encyclopedia of Housing and Home

(pp. 342–349). Elsevier. https://doi.org/10.1016/B978-

0-08-047163-1.00176-4

Besnard, V., Teodorov, C., Jouault, F., Brun, M., and

Dhaussy, P. 2019. Verifying and Monitoring UML

Models with Observer Automata: A Transformation-

Free Approach. In 2019 ACM/IEEE 22nd International

Conference on Model Driven Engineering Languages

and Systems (MODELS), 161–171. Munich, Germany:

IEEE. https://doi.org/10.1109/MODELS.2019.000-5

Ciccozzi, F., Malavolta, I., and Selic, B. 2019. Execution of

UML models: a systematic review of research and

practice. Software & Systems Modeling, 18(3), 2313–

2360. https://doi.org/10.1007/s10270-018-0675-4

Cook, W. R., Delaware, B., Finsterbusch, T., Ibrahim, A.,

and Wiedermann, B. 2009. Model Transformation by

Partial Evaluation of Model Interpreters. Technical

Report TR-09-09. Retrieved from https://www.

cs.utexas.edu/~wcook/publications.htm

Djukić, V., Luković, I., Popović, A., and Ivančević, V.

2012. Using action reports for testing meta-models,

models, generators and target interpreter in domain-

specific modeling. In 2012 Federated Conference on

Computer Science and Information Systems (FedCSIS),

1365–1372. Wroclaw, Poland: IEEE.

Edwards, G., Seo, C., and Medvidovic, N. 2008. Model

Interpreter Frameworks: A Foundation for the Analysis

of Domain-Specific Software Architectures. Journal of

Universal Computer Science, 14(8), 1182–1206.

Ferme, V., Lenhard, J., Harrer, S., Geiger, M., and

Pautasso, C. 2017. Workflow Management Systems

Benchmarking: Unfulfilled Expectations and Lessons

Learned. In Proceedings of the 39th International

Conference on Software Engineering Companion, 379–

381. IEEE Press. https://doi.org/10.1109/ICSE-

C.2017.126

Overview of Model Interpretation Techniques and Their Applications

519

Gotti, S., and Mbarki, S. 2016. UML executable: A

comparative study of UML compilers and interpreters.

2016 International Conference on Information

Technology for Organizations Development (IT4OD),

1–5. Fez, Morocco: IEEE. https://doi.org/10.1109/

IT4OD.2016.7479251

Hill, J. H., and Gokhale, A. 2012. Using Template

Metaprogramming to Enhance Reuse in Visitor-Based

Model Interpreters. In 2012 IEEE 19th International

Conference and Workshops on Engineering of

Computer-Based Systems, 5–14. Novi Sad, Serbia:

IEEE. https://doi.org/10.1109/ECBS.2012.48

IBM. 2011. IBM100 - WebSphere. Retrieved February 25,

2021, from IBM 100 website: https://www.ibm.com/

ibm/history/ibm100/us/en/icons/websphere/

Juric, M. B., n.d.. ORACLE, A Hands-on Introduction to

BPEL. Retrieved January 28, 2021, from

https://www.oracle.com/technical-resources/articles/

matjaz-bpel.html

Karsai, G. 1999. Structured specification of model

interpreters. In Proceedings ECBS’99. IEEE

Conference and Workshop on Engineering of

Computer-Based Systems, 84–90. IEEE Comput. Soc.

https://doi.org/10.1109/ECBS.1999.755865

Lopez-Pintado, O., Dumas, M., Garcia-Banuelos, L., and

Weber, I. 2019. Interpreted Execution of Business

Process Models on Blockchain. In 2019 IEEE 23rd

International Enterprise Distributed Object Computing

Conference (EDOC), 206–215. Bangkok, Thailand:

IEEE. https://doi.org/10.1109/EDOC.2019.00033

Microsoft. 2017. Windows Workflow Foundation.

Retrieved February 25, 2021, from Microsoft Docs

website: https://docs.microsoft.com/en-us/dotnet/frame

work/windows-workflow-foundation/

Miller, J., and Mukerji, J. 2001. Model Driven Architecture

( MDA ). In Architecture Board ORMSC.

Nazaruka, E. 2020. Processing Use Case Scenarios and

Text in a Formal Style as Inputs for TFM-based

Transformations. Baltic J. Modern Computing, 8(1),

48–68. https://doi.org/https://doi.org/10.22364/bjmc.

2020.8.1.03

Nazaruka, E., and Osis, J. 2019. The Formal Reference

Model for Software Requirements. In E. Damiani, G.

Spanoudakis, and L. Maciaszek (Eds.), Evaluation of

Novel Approaches to Software Engineering. ENASE

2018. Communications in Computer and Information

Science, vol 1023 (pp. 352–372). Springer, Cham.

https://doi.org/10.1007/978-3-030-22559-9_16

OMG. 2005. Introduction to Omg’s Unified Modeling

Language

(UML®). Retrieved March 3, 2021, from

Unified Modeling Language website:

https://www.uml.org/what-is-uml.htm

Osis, J. 1969. Topological Model of System Functioning (in

Russian). Automatics and Computer Science, J. of

Academia of Siences, (6), 44–50.

Osis, J., and Donins, U. 2017. Topological UML Modeling:

An Improved Approach for Domain Modeling and

Software Development. Cambridge, Massachusetts,

USA: Elsevier.

Ovchinnikova, V., and Nazaruka, E. 2016. The validation

possibility of Topological Functioning Model using the

Cameo Simulation Toolkit. In ENASE 2016 -

Proceedings of the 11th International Conference on

Evaluation of Novel Software Approaches to Software

Engineering. SciTePress.

Ovchinnikova, V., and Nazaruka, E. 2017. Lessons learned

on using execution model implementation in sparx

enterprise architect for verification of the topological

functioning model. In ENASE 2017 - Proceedings of the

12th International Conference on Evaluation of Novel

Approaches to Software Engineering. SciTePress.

Palshikar, G. K. 2004. An introduction to model checking -

Embedded.com. Retrieved March 3, 2021, from

https://www.embedded.com/an-introduction-to-model-

checking/

Quante, J. 2016a. A Program Interpreter Framework for

Arbitrary Abstractions. In 2016 IEEE 16th

International Working Conference on Source Code

Analysis and Manipulation (SCAM), 91–96. Raleigh,

NC, USA: IEEE. https://doi.org/10.1109/SCAM.

2016.29

Quante, J. 2016b. Use Cases of a Generic Model Interpreter

in an Automotive Software Setting. In 2016 IEEE

International Conference on Software Maintenance

and Evolution (ICSME), 539–542. Jinan, China: IEEE.

https://doi.org/10.1109/ICSME.2016.81

Riehle, D., Fraleigh, S., Bucka-Lassen, D., and Omorogbe,

N. 2001. The architecture of a UML virtual machine.

ACM SIGPLAN Notices, 36(11), 327–341.

https://doi.org/10.1145/504311.504306

Shroff, G., Agarwal, P., and Devanbu, P. 2009.

InstantApps: A WYSIWYG model driven interpreter

for web applications. In 2009 31st International

Conference on Software Engineering - Companion

Volume, 417–418. Vancouver, BC, Canada: IEEE.

https://doi.org/10.1109/ICSE-

COMPANION.2009.5071040

Vogel, T., and Giese, H. 2012. A language for feedback

loops in self-adaptive systems: Executable runtime

megamodels. In 2012 7th International Symposium on

Software Engineering for Adaptive and Self-Managing

Systems (SEAMS), 129–138. Zurich, Switzerland:

IEEE. https://doi.org/10.1109/SEAMS.2012.6224399

Weigold, T., Kramp, T., and Buhler, P. 2007. ePVM - An

Embeddable Process Virtual Machine. In 31st Annual

International Computer Software and Applications

Conference - Vol. 1- (COMPSAC 2007), 1, 557–564.

IEEE. https://doi.org/10.1109/COMPSAC.2007.110

Wu, D., Wei, J., Gao, C., and Dou, W. 2012. A Highly

Concurrent Process Virtual Machine Based on Event-

driven Process Execution Model. In 2012 IEEE Ninth

International Conference on E-Business Engineering,

61–69. IEEE. https://doi.org/10.1109/ICEBE.2012.20

Zhaogang, S., Di, L., Feng, Y., and Suhua, X. 2007. Model-

based development architecture for embedded CNC

system. In Proceedings of the IEEE International

Conference on Automation and Logistics, ICAL 2007,

154–158. IEEE. https://doi.org/10.1109/ICAL.2007.43

38548

MDI4SE 2021 - Special Session on Model-Driven Innovations for Software Engineering

520
