IoT Fuzzing using AGAPIA and the River Framework

Eduard St

aniloiu

, Rares

Cristea

and Bogdan Ghimis

Department of Computer Science, University Politehnica of Bucharest, Bucharest, Romania

Department of Computer Science, University of Bucharest, Bucharest, Romania

Keywords:

Internet-of-Things, Fuzzing, Speciﬁcation Graph, Testing, Software Engineering Tools.

Abstract:

As the number of Internet of Things (IoT) systems continues to grow, so does the security risk imposed by

interconnecting heterogeneous devices from different vendors. Testing and validating the security of IoT

systems is difﬁcult, especially due to the fact that most of the software is proprietary (closed-source) and the

system’s embedded nature makes it hard to collect data, such as memory corruptions. This paper proposes to

extend the novel AGAPIA language to enable IoT developers to write safer programs that can be tested and

validated with state of the art fuzzers, such as RiverIoT. We present how simple additions can enable AGAPIA

modules to be integrated with the RiverIoT architecture, thus facilitating better device testing. The proposed

approach also enables users, not just developers, to perform system wide, black-box, testing, increasing the

reliability of the system. We show how the abstractions provided by the AGAPIA language enable the fast

development of an Air Quality Monitoring application and how small additions to existing programming

languages can improve the testing and validation of IoT systems.

1 INTRODUCTION

The Internet of Things (IoT) is a system of intercon-

nected devices that can collect data from their sur-

rounding environment and act upon it. IoT has grown

signiﬁcantly in recent years, helping people to work

smarter and improving their quality of life. We can

now ﬁnd smart devices everywhere, from our homes

(smart light bulbs, IP cameras), to our cars (smart sen-

sors, cameras) and cities (weather sensors, pollution

sensors). With the continuous development of net-

work technologies, such as 5G, the number of IoT de-

vices will continue to grow (Li et al., 2018), bringing

even more technology into our lives in a bid to make

everything faster, smarter and more comfortable.

The growing number of IoT devices (and their

vendors) rises privacy and security concerns. In a fast

paced world, where the vendors compete with each-

other to achieve the best time to market for device

development (Wurm et al., 2016), there is a lot of

room for programming errors that can lead to vul-

nerabilities and exploits (English et al., 2019) (Her-

nandez et al., 2014). The typical architecture for an

IoT system is composed of multiple heterogeneous

devices, not necessarily from the same vendor, con-

nected through different protocols over the Internet.

Most of the devices run proprietary ﬁrmware, with

in-house implementations of protocol standards, de-

veloped in a memory unsafe language (such as the C

programming language), making them a lucrative tar-

get for attackers.

Given the closed-source nature of the IoT devices

code, it is difﬁcult for a 3rd party (user, another ven-

dor, etc) to audit and validate the correctness of the

implementation. Because it can not access the code,

the 3rd party must rely on black-box testing, combin-

ing fuzzing techniques with functional testing. Rive-

rIoT (Paduraru et al., 2021) is an open-source frame-

work that enables the fuzzing of end-to-end IoT ap-

plications. In order to provide efﬁcient fuzzing, Rive-

rIoT relies on a JSON speciﬁcation of the Input/Out-

put (I/O) of the devices fuzzed. We’ll discuss this in

greater detail in Section 2.2.

As previously stated, the programming language

used to develop the devices’ ﬁrmware plays a signif-

icant role in the security and robustness of the sys-

tem. IoT systems and their applications are, in fact, a

highly dynamic and modular distributed system. Dis-

tributed programming and synchronization is gener-

ally regarded as a non-trivial task. There are multi-

ple frameworks and high-level languages that address

the issue of distributed programming. The AGAPIA

language (Paduraru, 2014) attempts to increase the

developer productivity and the language expressive-

ness by using a transparent communication model and

simple high level statements. AGAPIA expresses dis-

324

aniloiu, E., Cristea, R. and Ghimis, B.

IoT Fuzzing using AGAPIA and the River Framework.

DOI: 10.5220/0010604503240332

In Proceedings of the 16th International Conference on Software Technologies (ICSOFT 2021), pages 324-332

ISBN: 978-989-758-523-4

tributed applications as modules that expose a clear,

simple and structured I/O interface.

AGAPIA is a Domain Speciﬁc Language (DSL)

built on top of the C programming language. Because

of this, (we believe that) it can easily be used with

existing ﬁrmware code to model the IoT system’s in-

teraction and expose the device’s I/O interface.

In this paper, we propose to express IoT devices

as AGAPIA modules, and represent the IoT system’s

interactions as relationships between AGAPIA mod-

ules. By doing so, we have a clear, structured, speci-

ﬁcation of the I/O of a device. We can easily extend

AGAPIA to convert the structured I/O spec to (and

from) JSON, so we can easily use RiverIoT to test

both the device and the IoT system.

The rest of the paper is structured as follows. Sec-

tion 2 details the AGAPIA language and RiverIoT.

Section 3 presents related work. Section 4 presents

the necessary AGAPIA extensions and how to lever-

age AGAPIA’s I/O models with RiverIoT. Section 5

presents an example of how AGAPIA can be used

with an IoT system. Section 6 concludes.

2 BACKGROUND

2.1 AGAPIA

There is a real need for developing a unifying pro-

gramming language that allows developers to quickly

prototype and test their software before deploying it to

an IoT device. The current trend is to write the code

in a low-level programming language, like C, that will

be compiled with specialized compilers (like the Ar-

duino IDE) for each IoT device since the code can be

run on different architectures (like PIC, AVR, ARM).

The problem with writing in a low-level program-

ming language is that it is a tedious and error prone

process, since one must carefully implement the basic

data structures and communication channels. While

this offers a lot of ﬂexibility and control in terms of

instructions granularity, it hinders development. Even

when one has access to a powerful IoT device (like

the Raspberry PI) and can write code in a higher-level

programming language, like Python, a problem still

persists: it is difﬁcult and time consuming to write

correct, distributed programs.

There are papers that investigate a way to pro-

gram using visual objects like (Leonardo, 2013) and

(Boshernitsan and Downes, 2004), but they fall short

on developing for the multiprocessor devices.

AGAPIA (Paduraru, 2015) is a Domain Speciﬁc

Language (DSL) that was designed to simplify the de-

velopment of parallel software using a simpler syntax

for spawning new processes via forks and integrat-

ing with Open-MPI (Gabriel et al., 2004) to deliver a

friendlier distributed and parallel programming expe-

rience.

The main component of an AGAPIA program is

the module that can be thought of a 2 dimensional

block (a square) that can receive information from

both the north and west sides and can pass informa-

tion through both east and south parts (Figure 1). The

inputs and the outputs are optional, so one can deﬁne

modules that generates data (no inputs, only outputs)

or that produce side effects when given certain inputs

(only inputs, no outputs).

Figure 1: An AGAPIA module.

The main job of a module is to transform the given

input(s) into the output(s). The basic way of deﬁning

a module is to deﬁne its interface (the inputs and the

outputs) and based on them one can compose modules

together.

By deﬁning a module in this way, one can com-

pose modules in three ways: vertically, horizontally,

and diagonally (Figures 2, 3, and 4). One can think of

an AGAPIA program as a two dimensional structure

(Banu-Demergian et al., 2013), composed of mod-

ules that talk to one another in order to solve a prob-

lem more efﬁciently. The composition model used by

AGAPIA is multiplexed both in space (Figure 2) and

time (Figure 3) (Paduraru and Stefanescu, 2020).

After deﬁning the interface for each module, one

can write the code for that module in either C or C++

language. The user code for each module can contain

either pure C/C++ code (called here atomic) or can

contain AGAPIA instructions or compositions (Ste-

fanescu and Paduraru, 2016). The difference between

the two modes is that the atomic code must have ac-

cess to all the variables before it is scheduled, whereas

when using AGAPIA instructions one can run code in

parallel.

The AGAPIA team is currently working on pro-

ducing a graphical user interface where one can easily

deﬁne the topology of an AGAPIA program and de-

ﬁne the interface between the modules and after that

can write the module’s code.

IoT Fuzzing using AGAPIA and the River Framework

325

Figure 2: Horizontal module composition.

Figure 3: Vertical module compo-

sition.

Figure 4: Diagonal module composition.

2.2 RiverIoT

RiverIoT is an integrated testing framework that en-

ables end-to-end fuzzing for IoT systems. The frame-

work employs guided fuzzing through state of the art

methods, like concolic execution (Ghimis et al., 2020)

and AI techniques (Paduraru et al., 2019), (Paduraru.

and Melemciuc., 2018), (Paduraru. and Melemciuc.,

2018), (Paduraru et al., 2020).

There are two major challenges when fuzzing

embedded devices: 1) the hardware dependence of

the ﬁrmware and 2) the closed-source nature of

the ﬁrmware. Inspired by (Feng et al., 2020) and

(Clements et al., 2020), RiverIoT addresses both of

those issues with emulation. Using an emulator al-

lows RiverIoT to run the ﬁrmware on a general pur-

pose system, without requiring 1) the physical hard-

ware of the IoT device. When a binary is emulated,

the emulator translates each binary instruction into

an intermediate representation before translating it

again into instructions for the host machine architec-

ture. Doing so, RiverIoT can dynamically instrument

the binary instructions without needing the 2) source

code.

Since an IoT system can be logically represented

as a graph of connected components, RiverIoT can

perform fuzz testing at three different levels:

• graph level - changing the nodes and edges inside

the deployed IoT system

• node level - fuzzing each device individually

• interconnection of input/output nodes between

different nodes and their communication (i.e.,

how a node can be inﬂuenced by others producing

its input connection, or the communication chan-

nel between them).

In order to use RiverIoT, one must provide a de-

scription of the graph (nodes and edges) and the I/O

structure that the applications expect, in JSON for-

mat. With this JSON speciﬁcation, the framework can

understand the communication between the different

components and it can start mutating the graph and

generate inputs for the applications.

RiverIoT expects the graph to be able to han-

dle dynamic conﬁgurations at runtime, like changing

nodes and edges. The reason for this is that the frame-

work attempts to simulate issues like device failures,

restarts, repositioning thus testing the resilience of the

system under test.

As it can be seen in the graph speciﬁcation pre-

sented in Listing 1, the model is quite simple and

safe-explanatory. One must deﬁne the IoT applica-

tions (”iot-nodes”) and their communication channels

(”io-edges”). Each application is assigned an ID and

a description of it’s input and output buffers, as exem-

pliﬁed in Listing 2. Each edge, also identiﬁed by an

ID, describes the input and output node (based on the

node’s ID) and the buffer speciﬁcation used for that

node (based on the node’s buffer ID).

{

" configuration - name " : " Generic

Network " ,

" iot - nodes ": {

"1 " : { // B u f f e r d e s c riptio n },

"2 " : { ... }

"io - edge s " : {

"1 " : {

" vout " : 3 , // Output node

" vi n " : 1 , // Input node

" vout - b u f f er " : 1 , // Buffer id

sending the data

" vin - buffer ": 2, // B u f f e r id

recei v i n g the d ata

"2 " : { ... }

}

Listing 1: Compatibility graph speciﬁcation example.

The example in Listing 2 probably contains some

more ﬁelds than one might be expecting, but most of

them are actually there to provide more context to the

ICSOFT 2021 - 16th International Conference on Software Technologies

326

reader. RiverIoT is mostly interested in the ”token-

type” and ”byte-size” ﬁelds. With those two, it can

start generating inputs for the application under test.

{

" de vice - nam e " : " An IP C a m e r a " ,

" option a l " : " false ",

" class " : " camera " ,

" buffers " : {

"1 " : {

" token - del i m itator s " : " " ,

" protoc o l " : " HTTP " ,

" prot ocol - s e t t i n g " : " http : // 1 92. 1

68 . 0. 1 1 2: 8 080 /" ,

" bu ffer - tokens ": [ {

" name " : " Camera c o m m a n d " ,

" de s c r i ption " : " Input that

selects command " ,

" token - typ e " : " string " ,

" byte - size ": 2 56,

" regex - rul e " : " [ a - zA -Z ] +=[a -zA -

Z0 -9] +" , // Option a l

param e t e r to guide f u z z e r

gener a t o r

" option a l " : false

{

" name " : " Camera ISO V a l u e " ,

" de s c r i ption " : " S e n s itivity to

light ",

" token - typ e " : " int " ,

" byte - size ": 4 ,

" option a l " : true

}]

}

Listing 2: Single device buffers’ speciﬁcation.

With the JSON speciﬁcation ready, the framework

can start the fuzzing process. For each node, the

framework will perform guided fuzzing in isolation,

testing each binary program that can be deployed on

a physical device. RiverIoT employs a combination of

symbolic execution (Ghimis et al., 2020) and genetic

algorithms (Paduraru et al., 2017) to fuzz the targets

in a bid to achieve good code coverage while keeping

the runtime performance and overhead acceptable.

3 RELATED WORK

The number of IoT devices has long passed the num-

ber of people on Earth, and with the continuous de-

velopment of network technologies, computing power

and applications, the number of devices is set to keep

growing. As IoT devices become omnipresent in our

lives and homes, it is only natural to become con-

cerned about the privacy and security risks that they

bring into our lives. To address those, we need to dis-

cover the tools that enable us to test and validate com-

plex IoT systems.

Fuzz testing has proven time and time again that it

can detect real-life vulnerabilities in existing systems.

With the growing popularity of IoT, researchers are

starting to focus on fuzz testing IoT devices.

FIRM-AFL (Zheng et al., 2019) is an IoT speciﬁc,

grey-box fuzzer that runs on the AFL

fuzzer. Be-

cause most of the IoT applications ﬁrmware is pro-

prietary, the traditional approach of re-compiling the

source code with fuzzer speciﬁc instrumentation is

not feasible. Instead, FIRM-AFL uses both user-

mode and system-mode emulation to dynamically in-

strument the binary. Combining the two emulation

types enables FIRM-AFL to achieve better perfor-

mance than only using system-mode emulation such

as AFL and AFLplusplus (Fioraldi et al., 2020). How-

ever, the ﬁrmware must run a POSIX compatible op-

erating system for it to work.

Others, like AFLNet (Pham et al., 2020) and IoT-

Fuzzer (Chen et al., 2018) capture valid messages ex-

changed by the applications to build a meaningful ini-

tial seed corpus and then replay and mutate those mes-

sages. AFLNet also builds a graph of dependencies

between messages; doing so it is able to determine

that certain messages are valid only after others: i.e.

when using the FTP protocol, an application must ﬁrst

authenticate before it is able to use any other com-

mand.

Skyﬁre (Wang et al., 2017) is a data-driven seed

generator for fuzzer’s inputs. It consumes an input

corpus and a grammar of highly-structured inputs and

generates a probabilistic context-sensitive grammar

(PCSG) that encapsulates syntax and semantic rules.

Providing AFL with the generated PCSG they have

increased the code line coverage and funcion cover-

age by 20% and 15% respectively. Doing so, their

experiment conﬁrms that providing an input descrip-

tion can lead generic fuzzers to perform big-step mu-

tations based on the grammar. Grammar-based testing

is also the focus of Zeller and Gopinath’s “Building

Fast Fuzzers” (Gopinath and Zeller, 2019), which fo-

cus on improving the throughput of fuzzed inputs.

One of the main challenges of fuzzing IoT devices

is the hardware-dependence of the ﬁrmware. P2IM

(Feng et al., 2020) focuses on providing a framework

that eliminates this challenge and provides a common

interface for off-the-shelf fuzzers to continuously ex-

ecute a ﬁrmware binary. P2IM is generating a periph-

eral model based on the classiﬁcation of the registers

accessed by the ﬁrmware, by watching the read / write

https://github.com/google/AFL

IoT Fuzzing using AGAPIA and the River Framework

327

requests on registers. It accesses memory-mapped

registers through the interfaces exposed by the QEMU

processor emulator. The reliance on QEMU restricts

the number of possible fuzzers that can be used with

the framework to the ones that have QEMU integra-

tion.

HALucinator (Clements et al., 2020) challenges

P2IM’s tightly coupled model, and proposes a de-

coupling model between the hardware and ﬁrmware

of embedded systems. Based on the fact that

ﬁrmware developers regularly develop code using

abstractions, such as Hardware Abstraction Layers

(HALs), HALucinator proposes a framework that im-

plements High-Level Emulation (HLE), by imple-

menting hooks for the HALs’ exposed functions.

Industry efforts have led to the development of

IoT I/O standards, like the MIPI general-purpose set

of standards, (MIPIAlliance, 2020), or the ONVIF

protocol for IP Camera communications (Organiza-

tion, 2020). Having accepted I/O standards and proto-

cols in place enables the interconnectivity of different

IoT devices from different vendors. Standard proto-

cols also enable the use of protocol-based fuzzers like

AFLNet.

RiverIoT proposes a framework that enables grey-

box fuzzing of IoT binaries. Like others, it uses emu-

lation to overcome the lack of source-code and per-

forms dynamic binary instrumentation to guide the

fuzzing process. It requires a description of the IoT

system, modeled using JSON, that describes the sys-

tem as a graph of nodes and edges. The JSON spec-

iﬁcation also describes the expected structure of the

Input and Output of the applications running on the

nodes. With this speciﬁcation, RiverIoT is capable to

fuzz not only individual nodes, but also fuzz the entire

system by performing graph mutations.

AGAPIA (Paduraru, 2014) was designed to sim-

plify the development of parallel software and to in-

crease the developer productivity by using a trans-

parent communication model and simple high level

statements. The language aims to deliver a friendly

distributed and parallel programming experience.

AGAPIA expresses distributed applications as mod-

ules that expose a clear, simple and structured I/O

interface. AGAPIA is a Domain Speciﬁc Language

(DSL) built on top of the C programming language.

Because of this, we believe that existing ﬁrmware

code can easily be integrated in AGAPIA models, ex-

posing in a structured way the IoT system’s interac-

tion and the devices’ I/O interfaces.

https://www.qemu.org/

4 IMPLEMENTATION

AGAPIA represents distributed applications as a

graph of connected modules with structured I/O in-

terfaces. The structured I/O interfaces and the graph

representation used by AGAPIA ﬁts perfectly with

RiverIoT’s architecture. We propose that we leverage

this structure and build upon it to provide a simple

interface that can interact with RiverIoT’s JSON I/O

description model. We plan on doing so by adding

AGAPIA extensions that convert AGAPIA I/O Sim-

ple Interfaces to and from JSON objects.

4.1 AGAPIA Extentions

4.1.1 Generating Interface Descriptions

The AGAPIA language uses module abstractions to

represent running processes. A module performs I/O

operations by deﬁning at most four interfaces: Input is

received on the North and West interfaces, and Output

is sent on the South and East interfaces. A module’s

interface could be represented as a tuple of interfaces:

(west; north; east; south).

Listing 5 depicts the composition scheme for Sim-

ple Interfaces (SI) and the Module’s Interface (MI), as

deﬁned in the language grammar.

I n t e r f a c e s

SI : : = n i l | i n t | b oo l | f l o a t |

s t r i n g | b u f f e r |

( SI , S I ) | ( SI [ ] )

MI : : = ( SI ) | ( SI ; S I ) | ( SI ; ) ∗

Listing 3: AGAPIA Simple Interface and Module Interface

Grammar.

As it can be observed in Listing 5, a SI can be:

• a basic type, such as nil, int, bool, float

• a stream of characters, string, or of bytes

buffer

• a structure, by combining simple data types, (SI,

SI)

• an array of the above, SI[]

On closer inspection, the structure of a SI is very sim-

ilar to that of a JSON object.

Based on this observation, we add a new AGAPIA

macro: @JSONIFY. The novel deployment macro

will generate a JSON description, compatible with

RiverIoT, from the SI, for each module in the sys-

tem. Given a module with the following MI: (int;

(bool, float); buffer; nil), a JSON similar to

the one in Listing 4 will be generated.

ICSOFT 2021 - 16th International Conference on Software Technologies

328

{

" buffers " : {

"1 " : {

" bu ffer - tokens ": [ {

" token - typ e " : " int " ,

" byte - size ": 4 ,

}]

"2 " : {

" bu ffer - tokens ": [ {

" token - typ e " : " bool " ,

" byte - size ": 4 ,

{

" token - typ e " : " float ",

" byte - size ": 4 ,

}]

"3 " : {

" bu ffer - tokens ": [ {

" token - typ e " : " string " ,

" byte - size ": 1 024 ,

}]

"4 " : {

" bu ffer - tokens ": [ {}]

}

Listing 4: @JSONIFY - Macro Generated JSON Example.

With the generated JSON description of the sys-

tem in place, we can feed it to RiverIoT to start the

fuzzing process.

4.1.2 Device Hardware Requirements

As device ﬁrmware is dependant on the hardware

speciﬁcations where it should be run, we need pro-

vide a way of reporting these requirements to Rive-

rIoT. This is required so RiverIoT will know how to

emulate the correct architecture for the ﬁrmware.

To do so, we propose adding another macro,

@RESOURCES, that uses JSON notation to deﬁne the

target architecture and required resources. An exam-

ple is presented in Listing 5.

@RESOURCES{

[ {

” name” : ”ARCH” ,

” t y p e ” : ” t e x t ” ,

” t e x t ” : ”ARM”

}]

}

@JSONIFY

module main

{ l i s t e n a : i n t } / / N o r t h

{ r e a d b : boo l , f : f l o a t } / / West

{

/ / . . s o u r c e co d e f o r program . .

}

{ s pe a k bu f : b u f f e r } / / S o u th

{ w r i t e n i l } / / E a s t

Listing 5: @RESOURCES - Deﬁning HW Requirements

Example.

4.2 RiverIoT to AGAPIA

As previously states, RiverIoT makes use of an I/O

speciﬁcation that states how a node, from an IoT sys-

tem, conveys it’s communication protocol and how it

relates to other IoT nodes.

By extending the AGAPIA language with the

@JSONIFY and @RESOURCES deployment macros,

we’ll have a readily available JSON description of the

IoT system under test.

As depicted in Figure 2, a horizontal composition

of the modules A and B is noted as A # B.

A system modeled as A # B # C, based on the

added extensions, will generate a graph representation

similar to the one in Listing 6

{

" iot - nodes ": {

"A " : {

" buffers " : { // B u f f er

des c r i p tion },

" reso u r c e s ": { // @Re s o u r ces }

"B " : { ... },

"C " : { ... }

"io - edge s " : {

"1 " : {

" vout " : B , // Output node

" vi n " : A , // Input node

"2 " : {

" vout " : C , // Output node

" vi n " : B , // Input node

}

Listing 6: Example of Generated System Graph

Description.

RiverIoT can now create a high level view of the

communication that takes place inside the IoT system

so it can provide guided, meaningful inputs to the de-

vices. Having an overview of the connected nodes

and edges, the framework can also mutate the graph

to test the system’s fault tolerance and dynamism.

IoT Fuzzing using AGAPIA and the River Framework

329

Figure 5: The AGAPIA IoT application architecture. In this

ﬁgure we have the architecture of a distributed IoT applica-

tion using the AGAPIA programming language. The input

for this application consists of a ﬁlename that contains air

pollution related information as well as the number of de-

vices. After the Reader modules convert the data into a use-

ful structure, it passes it to the Dispatcher module. Here the

tasks are distributed to the IoT devices and after the sums

(Σ), the variation (σ

) and the standard deviation (σ) is cal-

culated it will be printed on the screen.

5 EVALUATION: AGAPIA IoT

EXAMPLE

As a real-life IoT experiment we have an example

shared on our Github page. The architecture can be

seen in Figure 6. In this experiment, the Air Quality

Index (AQI) in Seoul was considered. We used the

public Kaggle dataset

. This dataset contains values

of 6 pollutants that were measured and averaged ev-

ery hour between 2017 and 2019.

We can consider that in an IoT scenario these data

are collected by IoT devices scattered around a town

and they periodically communicate with a server, re-

laying their average measurements. We would also

like to have a real-time visualization of this data so

that we can announce the people or institutions in case

of a hazardous event.

Even if this data set contains information spanning

two years, we can consider that the IoT devices pass

the information on much faster (like every minute or

second). In this case, one must have an efﬁcient way

to process this information.

Using the formulas detailed in (Kanchan et al.,

2015) a comparison was made between using pure

MPI code and using the AGAPIA programming lan-

guage. Since AGAPIA is a high-level programming

language we considered that it will run slower than

using a pure C/MPI approach. While we consider

that the performance hit is negligible, we think that

the prototyping ability of AGAPIA programming lan-

guage outweighs the cons.

https://www.kaggle.com/bappekim/air-pollution-in-seoul

File size(MB) Processes Serial(s) MPI(s) AGAPIA(s)

700

2 1.43 0.92 1.00

5 0.62 1.00

1024

2 2.1 1.35 1.50

5 0.9 1.50

Figure 6: Performance comparison between MPI and

AGAPIA based on the (Kanchan et al., 2015) metrics.

For the MPI approach, a basic Scatter/Gather al-

gorithm was used where the master (the server that

has received the readings from the IoT devices) sent

the averaged values of the pollutants back to the IoT

devices in order to calculate the variance and standard

deviation faster. In this case, each device had two re-

sponsibilities. Firstly they must gather the data and

send it every minute, and secondly, when master re-

quests, they must receive data, calculate the mean and

AQI and report back to master.

When using the AGAPIA programming language,

these two responsibilities were merged. Each IoT de-

vice in our cluster is represented by a module, that

can read and process the data as it comes into the IoT

device. In this way, it is easier to think of each IoT

device as a composable module and when needed, the

master can change the module that runs on a range of

devices such that they can help with other computa-

tions.

6 CONCLUSIONS AND FUTURE

WORK

This paper proposes an extension of the AGAPIA

programming language with IoT-aware deployment

macros that enables a fast and simple integration with

a testing framework, such as RiverIoT. The added ex-

tensions generate a JSON speciﬁcation of the entire

system under test (SUT), describing both the graph of

connected IoT devices, as well as their I/O communi-

cation interfaces. By doing so, it provides the testing

framework with a high level view of the entire system,

as well as the expected input and output of each node.

The generated speciﬁcation is read by the orchestrat-

ing component of RiverIoT which decides if it’s going

to perform input generation or graph mutations for the

SUT. Overall, the paper explores how small additions

to existing programming languages can improve the

testing and validation of IoT systems.

ACKNOWLEDGMENT

This work was supported by a grant of Romanian

Ministry of Research, Innovation and Digitization

ICSOFT 2021 - 16th International Conference on Software Technologies

330

UEFISCDI no. 401PED/2020.

REFERENCES

Banu-Demergian, I. T., Paduraru, C., and Stefanescu, G.

(2013). A new representation of two-dimensional pat-

terns and applications to interactive programming. In

International Conference on Fundamentals of Soft-

ware Engineering, pages 183–198. Springer.

Boshernitsan, M. and Downes, M. S. (2004). Visual pro-

gramming languages: A survey. Citeseer.

Chen, J., Diao, W., Zhao, Q., Zuo, C., Lin, Z., Wang,

X., Lau, W. C., Sun, M., Yang, R., and Zhang, K.

(2018). Iotfuzzer: Discovering memory corruptions

in iot through app-based fuzzing. In NDSS.

Clements, A. A., Gustafson, E., Scharnowski, T., Grosen,

P., Fritz, D., Kruegel, C., Vigna, G., Bagchi, S.,

and Payer, M. (2020). Halucinator: Firmware re-

hosting through abstraction layer emulation. In 29th

{USENIX} Security Symposium ({USENIX} Security

20), pages 1201–1218.

English, K. V., Obaidat, I., and Sridhar, M. (2019). Exploit-

ing memory corruption vulnerabilities in connman for

iot devices. In 2019 49th Annual IEEE/IFIP Inter-

national Conference on Dependable Systems and Net-

works (DSN), pages 247–255. IEEE.

Feng, B., Mera, A., and Lu, L. (2020). P2im: Scalable and

hardware-independent ﬁrmware testing via automatic

peripheral interface modeling. In 29th {USENIX}

Security Symposium ({USENIX} Security 20), pages

1237–1254.

Fioraldi, A., Maier, D., Eißfeldt, H., and Heuse, M. (2020).

AFL++: Combining incremental steps of fuzzing re-

search. In 14th USENIX Workshop on Offensive Tech-

nologies (WOOT 20). USENIX Association.

Gabriel, E., Fagg, G. E., Bosilca, G., Angskun, T., Don-

garra, J. J., Squyres, J. M., Sahay, V., Kambadur, P.,

Barrett, B., Lumsdaine, A., Castain, R. H., Daniel,

D. J., Graham, R. L., and Woodall, T. S. (2004). Open

MPI: Goals, concept, and design of a next generation

MPI implementation. In Proceedings, 11th European

PVM/MPI Users’ Group Meeting, pages 97–104, Bu-

dapest, Hungary.

Ghimis, B., Paduraru, M., and Stefanescu, A. (2020). River

2.0: an open-source testing framework using ai tech-

niques. In Proceedings of the 1st ACM SIGSOFT

International Workshop on Languages and Tools for

Next-Generation Testing, pages 13–18.

Gopinath, R. and Zeller, A. (2019). Building fast fuzzers.

arXiv preprint arXiv:1911.07707.

Hernandez, G., Arias, O., Buentello, D., and Jin, Y. (2014).

Smart nest thermostat: A smart spy in your home.

Black Hat USA, (2015).

Kanchan, K., Gorai, A., and Goyal, P. (2015). A review on

air quality indexing system. Asian Journal of Atmo-

spheric Environment, 9:101–113.

Leonardo, P. (2013). Child programming: an adequate

domain speciﬁc language for programming speciﬁc

robots.

Li, S., Da Xu, L., and Zhao, S. (2018). 5g internet of things:

A survey. Journal of Industrial Information Integra-

tion, 10:1–9.

MIPIAlliance (2020). Mipi white paper: Enabling the iot

opportunity. Technical report, MIPIAlliance.

Organization, O. (2020). Proﬁle m – release candidate.

Technical report, ONVIF Organization.

Paduraru, C. (2015). Research on agapia language, com-

piler and applications. Ph. D. dissertation.

Paduraru., C. and Melemciuc., M. (2018). An automatic

test data generation tool using machine learning. In

Proceedings of the 13th International Conference on

Software Technologies - Volume 1: ICSOFT,, pages

472–481. INSTICC, SciTePress.

Paduraru, C., Melemciuc, M.-C., and Paduraru, M. (2019).

Automatic test data generation for a given set of ap-

plications using recurrent neural networks. In van

Sinderen, M. and Maciaszek, L. A., editors, Software

Technologies, pages 307–326, Cham. Springer Inter-

national Publishing.

Paduraru, C., Melemciuc, M.-C., and Stefanescu, A. (2017).

A distributed implementation using apache spark of a

genetic algorithm applied to test data generation. In

Proceedings of the Genetic and Evolutionary Compu-

tation Conference Companion, pages 1857–1863.

Paduraru, C., Paduraru, M., and Stefanescu, A. (2020). Op-

timizing decision making in concolic execution using

reinforcement learning. In 2020 IEEE International

Conference on Software Testing, Veriﬁcation and Val-

idation Workshops (ICSTW), pages 52–61.

Paduraru, C. I. (2014). Dataﬂow programming using

agapia. In 2014 IEEE 13th International Symposium

on Parallel and Distributed Computing, pages 87–94.

IEEE.

Paduraru, C. I., Cristea, R., and Staniloiu, E. (2021). Rive-

riot - a framework proposal for fuzzing iot applica-

tions. International Conference on Software Engi-

neering ICSE 2021, Workshop on Software Engineer-

ing Research and Practices for the IoT (SERP4IoT),

page to appear.

Paduraru, C. I. and Stefanescu, G. (2020). Adaptive vir-

tual organisms: A compositional model for complex

hardware-software binding. Fundamenta Informati-

cae, 173(2-3):139–176.

Pham, V.-T., B

ohme, M., and Roychoudhury, A. (2020).

Aﬂnet: a greybox fuzzer for network protocols. In

2020 IEEE 13th International Conference on Software

Testing, Validation and Veriﬁcation (ICST), pages

460–465. IEEE.

Stefanescu, G. and Paduraru, C. I. (2016). Self-assembling

heterogeneous interactive systems. In Proceedings

of the International Colloquium on Software-intensive

Systems-of-Systems at 10th European Conference on

Software Architecture, pages 1–7.

Wang, J., Chen, B., Wei, L., and Liu, Y. (2017). Sky-

ﬁre: Data-driven seed generation for fuzzing. In 2017

IEEE Symposium on Security and Privacy (SP), pages

579–594. IEEE.

IoT Fuzzing using AGAPIA and the River Framework

331

Wurm, J., Hoang, K., Arias, O., Sadeghi, A.-R., and Jin, Y.

(2016). Security analysis on consumer and industrial

iot devices. In 2016 21st Asia and South Paciﬁc De-

sign Automation Conference (ASP-DAC), pages 519–

524. IEEE.

Zheng, Y., Davanian, A., Yin, H., Song, C., Zhu, H.,

and Sun, L. (2019). Firm-aﬂ: high-throughput grey-

box fuzzing of iot ﬁrmware via augmented process

emulation. In 28th {USENIX} Security Symposium

({USENIX} Security 19), pages 1099–1114.

ICSOFT 2021 - 16th International Conference on Software Technologies

332
