Comparison of Manual Evaluation Methods for Assessing the
Accessibility of Websites based on EN 301 549
Gisela Kollotzek
1
, Gottfried Zimmermann
1
, Tobias Ableitner
1
and Anne-Marie Nebe
2
1
Competence Center for Digital Accessibility, Stuttgart Media University, Nobelstr. 10, 70569 Stuttgart, Germany
2
T-Systems Multimedia Solutions GmbH, Competence Center for Digital Accessibility & Software Ergonomics,
Riesaer Str. 5, 01129 Dresden, Germany
Keywords:
Comparative Study, Conformance, Disability, Empirical Evaluation, Expert Evaluation, Guidelines, Web
Accessibility, Accessibility Evaluation Method, WCAG.
Abstract:
The relevance of information technology has increased significantly over the last couple of years and therefore
it is important to provide for universal access to it. Accessibility of public sector websites has become legally
binding through Directive (EU) 2016/2102 for EU member states. Automatic accessibility evaluation methods
can only provide a superficial impression of the accessibility status. Only manual evaluation methods can
facilitate a comprehensive accessibility check. So far, there is no systematic comparison of existing manual
evaluation methods available that is based on real data. In this paper, we define a generic catalog of 22 criteria
for assessing the quality of accessibility evaluation methods and specify individual weights for the criteria.
We then compare two representatives of manual evaluation methods: BIK BITV-Test, as a representative of
conformance-based methods; and BITV-Audit, as a representative of empiric-based methods. We analyze
similarities and differences between these two methods, and identify weaknesses and strengths. Our results
show an advantage of BITV-Audit over BIK BITV-Test, but other weightings could yield different results.
1 INTRODUCTION
In recent years, digitization has increased in all areas
of life. At the same time, the number of people with
disabilities in our society has risen continuously. At
the end of 2019, around 7.9 persons with a disability
degree of 50% or higher lived in Germany. This was
around 136,000 more than at the end of 2017. The
share of persons with severe disabilities in the total
population in Germany was thus 9.5% (Statistisches
Bundesamt (Destatis), 2020). Therefore, accessibility
in information technology has become more impor-
tant over the last few years. It has become legally
binding in the public sector through Directive (EU)
2016/2102. Automated evaluation methods can be
used to assess accessibility but they cannot adequately
evaluate all relevant requirements (Vigo et al., 2013).
A study by Burkard et al. (2021) showed that with var-
ious tested automatic evaluation tools only 15 to 40%
of all existing accessibility problems can be identi-
fied in the evaluated objects. The automatic evalua-
tion methods can only provide a superficial impres-
sion of the accessibility status. However, they cannot
determine whether the website is actually accessible.
Currently, only manual evaluation methods can
ensure a comprehensive accessibility check. These
evaluation methods involve a great deal of time and
the qualification of the evaluators. Therefore, the cre-
ation of accessible content as well as the certification
of accessibility involve a great deal of effort and as-
sociated high costs. Currently, there is still little re-
search in the area of manual evaluation methods com-
pared to automatic evaluation methods. However, the
further development of both types of evaluation meth-
ods is a necessary step for the provision of more ac-
cessible websites.
The underlying research question for our study
looks at the differences and similarities between
conformance-based and empiric-based manual ac-
cessibility evaluation methods for websites. A
conformance-based evaluation method assesses the
degree of fulfillment of a specified set of require-
ments. Therefore, it can tell whether the evalua-
tion object as a whole can be classified as conform-
ing or not conforming to a specified standard. In
the empiric-based evaluation methods, trained eval-
uators or people with disabilities perform the acces-
sibility evaluation from the perspectives of affected
24
Kollotzek, G., Zimmermann, G., Ableitner, T. and Nebe, A.
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549.
DOI: 10.5220/0010647000003060
In Proceedings of the 5th International Conference on Computer-Human Interaction Research and Applications (CHIRA 2021), pages 24-35
ISBN: 978-989-758-538-8; ISSN: 2184-3244
Copyright
c
2021 by SCITEPRESS Science and Technology Publications, Lda. All rights reserved
user groups (e.g., visually impaired users). A benefit
of empiric-based methods is, that it is also possible
to assess how serious the problems found are for the
respective user groups.
This paper provides the following contributions on
accessibility evaluation methods:
We specify a catalog of criteria for the compar-
ison of evaluation methods. These criteria were
determined and weighted in a process involving
accessibility experts.
We define up to six metrics for each criterion to
quantify them. The catalog can be used to analyze
manual evaluation methods.
Based on this catalog of criteria, we compare
two German evaluation methods: BIK BITV-Test
and BITV-Audit. We identify their similarities
and differences as well as their weaknesses and
strengths.
The remainder of this paper is structured as fol-
lows: In Section 2, we introduce the necessary back-
ground. It considers the legal framework conditions
and presents the current state of research in the field
of manual evaluation methods. In Section 3, we take
a more in-depth look at the two manual evaluation
methods selected for comparison. We present the cri-
teria and weighting established by the experts in Sec-
tion 4. In Section 5, we will elaborate on the compar-
ison of the evaluation methods based on the defined
criteria. We discuss the results in Section 6 and fi-
nally provide a conclusion of this paper in Section 7.
2 BACKGROUND
2.1 Laws and Guidelines
2.1.1 Directive (EU) 2016/2102
The European Parliament and the Council of the
European Union adopted Directive (EU) 2016/2102
(European Parliament and Council of the European
Union, 2016) on the accessibility of websites and mo-
bile applications of public sector bodies, also known
as the Web Accessibility Directive, on October 26,
2016. Directive 2016/2102 requires public sector
bodies to provide accessible web services and mo-
bile applications. Aside from technical requirements,
(EU) 2016/2102 also specifies that public sector bod-
ies must provide an accessibility statement for their
websites. The EU Directive 2016/2102 becomes ef-
fective upon transposition into national law by the Eu-
ropean Union member states.
2.1.2 Web Content Accessibility Guidelines 2.1
The Web Content Accessibility Guidelines (WCAG)
represent globally recognized recommendations for
making website content accessible. The World Wide
Web Consortium (W3C) published the most current
version 2.1 on June 5, 2018 (W3C, 2018). The
WCAG have a hierarchical structure, meaning that the
principles are subordinate to the guidelines. These, in
turn, are assigned to the success criteria. Each success
criterion belongs to one of three conformance levels.
30 success criteria belong to the lowest level (A) and
20 to the middle level (AA). The highest conformance
level (AAA) includes the remaining 28 success crite-
ria. These conformance levels correspond to different
levels of accessibility implementation. As an exam-
ple, for a website to comply with conformance level
AA, all success criteria of level A and level AA must
be met (W3C, 2018).
It is important to note that following WCAG – be-
ing a standard is voluntary, unless regulation pre-
scribes conformance.
2.1.3 EN 301 549
EN 301 549 V2.1.2 (European Telecommunications
Standards Institute, 2018) specifies requirements for
accessibility of information and communication tech-
nologies (ICT). It was “harmonized” with (EU)
2016/2102, i.e., conforming to EN 301 549 v2.1.2
is considered sufficient for fulfilling the technical
requirements of (EU) 2016/2102 (European Parlia-
ment and Council of the European Union, 2018).
EN 301 549 covers all areas of ICT: ICT with two-
way voice communication, ICT with video capabil-
ities, hardware, web, non-web documents, software,
documentation and support services, and ICT provid-
ing relay or emergency service access. Chapter 9 of
EN 301 549 focuses on requirements for websites.
In this context, EN 301 549 is strongly oriented to-
wards WCAG 2.1 AA concerning web content. An-
nex A of EN 301 549 defines in detail the relationship
between the standard and the requirements of Direc-
tive 2016/2102. In particular, table A.1 provides a
list of all requirements for web content from all chap-
ters of EN 301 549, including the requirements of
WCAG 2.1 AA from chapter 9. Version V2.1.2 was
published in August 2018. At the time of writing this
paper, a new version V3.2.1 (European Telecommuni-
cations Standards Institute, 2020) is available, but not
yet harmonized with (EU) 2016/2102. Nevertheless,
in this paper, EN 301 549 refers to the new version
V3.2.1, as it is expected to become the “harmonized”
version eventually.
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
25
2.1.4 Barrierefreie-Informationstechnik-
Verordnung 2.0
1
(BITV 2.0)
BITV 2.0 (German Federal Ministry of Labour and
Social Affairs, 2019) is the regulation for the creation
of barrier-free information technology in accordance
with the Behindertengleichstellungsgesetz
2
(BGG) in
Germany. Version 2.0 replaced the BITV in 2011
and the last amendments were made in May 2019.
Through these latest amendments, it implements the
requirements of Directive 2016/2102, which are not
already included in the BGG.
2.1.5 Relation between Laws and Guidelines
Through harmonization, Directive (EU) 2016/2102
points to EN 301 549 for the technical require-
ments, and includes additional requirements for non-
technical purposes. EN 301 549 adopts the require-
ments of WCAG 2.1 AA for websites, but adds more
requirements of more generic nature in its Annex A.
A website is considered accessible if all the require-
ments specified in Directive 2016/2102 and in EN 301
549 Annex A are met.
Since Directive 2016/2102 is a European Direc-
tive, the member states had to implement it in their re-
spective national law. In Germany, this was achieved
by an amendment of the BGG and by updating BITV
2.0. In Germany, a public sector website is considered
accessible if it meets the requirements as specified in
BITV 2.0.
2.2 Related Work
Lang (2004) looks at three different types of evalu-
ation methods for assessing the accessibility of web-
sites in terms of their effectiveness through a literature
review: automatic evaluation methods, manual evalu-
ation methods, and user studies involving people with
disabilities. The results show that none of the evalu-
ation methods examined can identify all accessibility
problems. Lang concludes that a combination of the
three types of methods is the most effective way to
find the largest possible number of accessibility prob-
lems and thus be able to improve accessibility in the
best possible way.
The study by Mankoff et al. (2005) compares
the evaluation methods already mentioned by Lang
(2004). The comparison considers the following cri-
teria: effectiveness, validity, and the number of prob-
lems found. It turns out that the conformity-based
1
Translated into English: Barrier-free Information
Technology Regulation 2.0
2
Translated into English: Disability Equality Act
evaluation method with screen readers performed by
multiple evaluators is the most successful in finding
different classes of problems. However, Mankoff et
al. indicate that each type of evaluation method has
its respective weaknesses and strengths.
Manual evaluation methods play an important role
in the evaluation of website accessibility. Therefore,
Yesilada et al. (2009) aim to investigate the influence
of expertise on accessibility evaluation. It turns out
that the degree of expertise is an important factor for
the quality of the evaluation. Another important in-
fluencing factor is the selection of the web pages of a
website. A web page sample should be able to repre-
sent the degree of accessibility of the whole website.
Various studies investigate the influence of the sam-
ple selection method and sample size (Velleman and
van der Geest, 2013; Brajnik et al., 2007).
A commonly used type of manual evaluation
method is the conformance-based evaluation method.
Standards and guidelines are the basis of this method
type. These are largely responsible for the quality of
the evaluation. An internationally recognized and fre-
quently used standard is WCAG. Various studies look
at the validity and reliability of WCAG 1.0 as well as
2.0 (Rømen and Svanæs, 2008; Brajnik, 2009; Calvo
et al., 2016). Freire (2012), however, observes that the
guidelines (WCAG 1.0 and WCAG 2.0) do not cover
all issues found by impaired users.
Brajnik (2005) presents a new concept for an
evaluation method based on a heuristic walkthrough,
which is a method for evaluating the usability of a
website. In a later work, Brajnik (2006) investigates
this heuristic walkthrough method, then called the
barrier walkthrough method. For the assessment of
the evaluation methods, Brajnik identifies the follow-
ing criteria: validity, reliability, usefulness, and ef-
ficiency. Brajnik (2008) further defines the follow-
ing criteria for comparing evaluation methods: effec-
tiveness, efficiency, and usefulness. Effectiveness is
broken down more precisely into reliability and va-
lidity. Validity in turn is broken down into the two
criteria correctness and sensitivity. He uses these
criteria (excluding usefulness) to compare two eval-
uation methods: the conformance-based evaluation
(with an Italian standard) and the barrier walkthrough
method. The comparison aims to determine the mer-
its of the barrier walkthrough method, whereas the
conformance-based evaluation method serves as a
control condition. The results show differences in
both evaluation methods for validity and reliability.
However, the evaluations were performed by less ex-
perienced evaluators and might give different results
for experienced evaluators.
To summarize, the existing work on evaluation
CHIRA 2021 - 5th International Conference on Computer-Human Interaction Research and Applications
26
methods mostly looks at the field on a conceptual
level and presents new evaluation methods. A com-
prehensive systematic comparison using real data pro-
duced by accessibility experts is currently missing.
Therefore, in the following sections, we present our
comparison of two types of manual evaluation meth-
ods: conformance-based and empiric-based methods.
We present our generic catalog of comparison cri-
teria that we developed with experts’ input. It can
be adapted or extended to meet possible future re-
quirements. Based on this catalog, we compare two
concrete evaluation methods: BIK BITV-Test (DIAS
GmbH, 2019) and BITV-Audit (Nebe, 2021).
3 METHODS FOR ASSESSING
THE ACCESSIBILITY OF
WEBSITES
To identify the differences, similarities, advan-
tages, and disadvantages of the different types
(conformance-based vs. empiric-based) of manual
evaluation methods, we select one representative of
each type. There is a variety of evaluation methods.
However, to be able to carry out an expert-based com-
parison, we consider only evaluation methods involv-
ing experts as testers. Apart from that, to provide
comparable assessment results, both representatives
must provide a certificate for complying websites.
We selected the following evaluation methods: the
BIK BITV-Test (conformity-based) and the BITV-
Audit of T-Systems Multimedia Solutions GmbH
(empiric-based). The BIK BITV-Test is the estab-
lished evaluation method in Germany for the confor-
mity assessment of websites. In the context of this
work, we only consider the version as of 2020. Note
that the BIK BITV-Test has been significantly revised
in its current version, March 2021. We choose the
BITV-Audit as a representative of the empiric-based
evaluation methods. The evaluation procedure con-
sists of an accessibility evaluation and a conformance-
based evaluation. In the empirical expert evaluation,
accessibility is considered from the perspective of
people with disabilities. Subsequently, the evaluator
assigns the problems to the conformity criteria and
checks whether any criteria not yet considered have
been violated.
3.1 BIK BITV-Test
The BIK BITV-Test is an evaluation method for as-
sessing the accessibility of websites and web appli-
cations. The BIK project developed this evaluation
method together with accessibility experts, disability
associations, and service providers for websites. The
procedure is fully disclosed. It was first published in
2004 and has been continuously developed since then
(DIAS GmbH, 2020b).
The following standards are the basis of this eval-
uation method: BITV 2.0, EN 301 549 (Section 9
Web), WCAG 2.1 AA. The evaluation method does
not cover the additional requirements of BITV 2.0
which are not included in EN 301 549, such as the
need for an accessibility statement, and the need for a
description in sign language and easy language. Fur-
thermore, the additional requirements of Table A.1
of EN 301 549 are not included in the 2020 ver-
sion. There are also no evaluation steps that imple-
ment the WCAG 2.1 success criteria of conformance
level AAA. This method is not suited to evaluate non-
web documents e.g. PDF documents (DIAS GmbH,
2019).
There are three variants of the BIK BITV-Test:
Development-accompanying BITV-Test, final BITV-
Test, and BITV self-assessment. All three variants
have the same scope of evaluation steps but differ in
the evaluation procedure. While a certification of con-
formity can only be achieved by a final BITV-Test,
the results of the development-accompanying BITV-
Test and the BITV self-assessment may only be used
for internal use (DIAS GmbH, 2020c). In the follow-
ing chapters, reference is made exclusively to the final
BITV-Test.
In the beginning, the expert and the client select
the appropriate evaluation variant depending on the
goal to be pursued with the evaluation. They clarify
which areas and web pages belong to the evaluated
website. Subsequently, the required scope can be es-
timated. The initial evaluator creates the evaluation
data in the BITV-Test tool, assigns a second evalu-
ator, and selects the web pages to be evaluated. A
manual evaluation of the whole website is not feasi-
ble, because such an evaluation would be too costly.
Therefore, a representative web page sample is made.
This selection step is done without the client. The size
of the sample depends on the complexity of the eval-
uation object, i.e., the website under investigation. A
qualified evaluator of the BIK evaluation association,
hereafter referred to as the QA (for “quality assur-
ance”), checks the web page sample and releases it for
evaluation. The initial and second evaluators perform
the evaluation steps independently of each other. Af-
ter each evaluator has completed the evaluation steps,
they discuss their results in a joint meeting. Subse-
quently, the QA carries out the quality assurance of
the found results. If the QA identifies necessary cor-
rections, the first evaluator revises them. Optionally,
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
27
several correction loops can be made here. As soon as
this correction work is completed, the QA can gener-
ate the evaluation report from the BITV-Test tool and
the initial evaluator sends it to the client. The client
can expose a link on their website to the published
report as a certification of accessibility. A success-
ful BITV-Test entitles to an official seal of approval
which can be obtained for compliant websites (DIAS
GmbH, 2019).
3.2 BITV-Audit
The BITV-Audit is an evaluation method for assess-
ing the accessibility of websites, mobile applica-
tions, documents, and desktop software (T-Systems
Multimedia Solutions GmbH, 2020a; Nebe, 2021).
T-Systems Multimedia Solutions GmbH (T-Systems
MMS) used the evaluation method for the first time in
2009. In 2010, the BITV-Audit was accredited for the
first time and has been continuously developed since
then (A. Nebe [T-Systems MMS], personal communi-
cation, April 12, 2021). A detailed description of the
evaluation procedure including the evaluation criteria
is currently not publicly available.
The following laws and standards are the basis of
the BITV-Audit: BITV 2.0, EN 301 549, WCAG 2.1,
EN ISO 9241-171, and ISO 14289-1 (T-Systems Mul-
timedia Solutions GmbH, 2020b).
There are two variants of the evaluation: simpli-
fied audit and in-depth audit. The simplified audit
records vulnerabilities and their severity in a short
protocol with problem descriptions and heuristic so-
lution recommendations based on standard specifica-
tions. The in-depth audit additionally provides a root
cause analysis for each problem, an impact descrip-
tion for each user group, and a detailed recommended
action to solve the problem (T-Systems Multimedia
Solutions GmbH, 2020a). In the following chapters,
reference is made exclusively to the in-depth audit.
In the beginning, the expert and the client define
the framework conditions. Based on this, they se-
lect the appropriate variant of the evaluation method
which can be optionally supplemented by a usability
test. Finally, they determine which web pages and ar-
eas belong to the evaluated website. The evaluator
receives a program introduction from the client. For
simple websites, this step can be omitted. Based on
the website and the agreements made with the client,
the relevant evaluation criteria are automatically se-
lected. Furthermore, the expert makes a representa-
tive web page selection on which the evaluation is
carried out.
The evaluation then consists of two parts: the
accessibility evaluation and the conformance-based
evaluation. The former involves an empirical eval-
uation by experts, in which the accessibility of the
evaluation object is considered from the perspective
of users with disabilities. Five user groups are dis-
tinguished for this purpose: visually impaired, blind,
motor impaired, hearing impaired, and cognitively
impaired users. The expert assigns the problems
found to the conformance criteria of the standards and
laws involved (see above). Finally, the evaluator ex-
amines all criteria that have not yet been considered.
The severity of the impact on the affected user groups
is the basis for the weighting of the problems. There is
a team review with at least one other evaluator. They
discuss all problems found with regard to the problem
cause, weighting, and recommended action. The eval-
uator then prepares the evaluation report. Finally, an
experienced evaluator formally approves it and sends
it to the client. An official seal of approval which can
be obtained for compliant websites (T-Systems Mul-
timedia Solutions GmbH, 2020b).
4 CATALOG OF CRITERIA
4.1 Procedure
For the comparison, we derived a pre-selection of 14
criteria through a literature review. Following this,
experts discussed and revised this pre-selection in a
focus group and supplemented it with further criteria.
The nine-member expert panel consisting of members
of the BIK evaluation association, T-Systems MMS
staff, and other accessibility experts met in a virtual
session. In the end, the outcome was a total of 22
criteria, listed in Table 2.
Following the virtual expert panel, each partici-
pant was sent a spreadsheet containing the 22 criteria.
The experts were allowed to assign as many points
as they liked to each criterion. However, the under-
standing for this was that a criterion received points
in relation to the subjective importance it bore for the
individual experts. If a criterion was considered com-
pletely irrelevant, it would receive 0 points. In the
end, eight of the nine experts assigned a weighting.
The weightings were normalized and then averaged.
4.2 Criteria
The catalog of comparison criteria consists of 22
items. Each criterion has a weight, as determined
by averaging the experts’ individual weights. To be
able to quantify the results, for every criterion, we
define up to six metrics which are equally weighted
CHIRA 2021 - 5th International Conference on Computer-Human Interaction Research and Applications
28
Figure 1: Overview of the 22 criteria divided into 4 groups.
among each other. The total score (TS) of an evalu-
ation method consists of the sum of the products of
the individual criterion scores (CS) and their weights
(W), as seen in equation (1).
T S =
22
criterion=1
CS
criterion
·W
criterion
with 0 T S,CS,W 1
(1)
Based on the experts’ ratings, the following five cri-
teria have the highest weights: “C01: Coverage of
WCAG 2.1 AA” (W = 7.72), “C02: Completeness”
(W = 7.39), “C03: Quality of the evaluation report”
(W = 6.67), “C04: Coverage of additional criteria
from EN 301 549” (W = 6.64), and “C05: Correct-
ness” (W = 6.32). An overview of the 22 criteria and
their weights is shown in Table 2. The criteria can be
divided into the following four groups: Coverage of
different standards, efficiency of the evaluation, qual-
ity of the evaluation and the evaluation findings, and
general conditions of the evaluation procedure. The
mapping is shown in Figure 1.
5 STUDY RESULTS
The procedure descriptions and created evaluation re-
ports are the basis of the comparison of the evalua-
tion methods. Furthermore, accessibility experts pro-
cessed the created evaluation reports. In addition, the
subjective assessments of accessibility experts on spe-
cific aspects, as obtained in interviews, are taken into
account.
5.1 Procedure
In a first step, we selected the websites to be used
as case studies for both evaluation methods: the
website of the Hochschule der Medien
3
(HdM) and
3
translated into English: Stuttgart Media University; ac-
cessible at https://www.hdm-stuttgart.de/
the website of the Bundesfachstelle f
¨
ur Barrierefrei-
heit
4
(BfB). These two websites were selected under
the assumption that they differ in the degree of their
accessibility. This allows us to compare the results for
both a less accessible website and a more accessible
website. We decided that only the two start pages of
the websites should be used as samples to reduce the
scope of the evaluations. The start pages contained
a selection of layouts, navigation menus as well as
other elements. Thus, many evaluation steps were ap-
plicable. An employee of T-Systems MMS carried
out the evaluations since he is officially qualified to
perform both evaluation methods. Each website was
evaluated with both the BIK BITV-Test and the BITV-
Audit. The order of evaluation was alternated to avoid
bias effects.
The three criteria “C02: Completeness”, “C05:
Correctness”, and “C20: Simplicity of evaluation pro-
cedure” are based on a classification of the problems
found by experts into the following four categories:
False positives: The evaluation method identifies
a problem as such, but it is not a real problem.
False negatives: The evaluation method does not
identify a problem as such, but it is a real problem.
True positives: The evaluation method identifies a
problem correctly as a problem.
Mistakes: The evaluation method would identify
a problem as such, but the evaluator does not iden-
tify it when applying the evaluation procedure.
We defined WCAG 2.1 AA as the reference point for
true positives because it is the legal requirement in
the European legislation (European Parliament and
Council of the European Union, 2018). It has also
been shown that the classification of the problems
must additionally be carried out from the user’s point
4
translated into English: Federal Agency
for Accessibility; accessible at https://www.
bundesfachstelle-barrierefreiheit.de/DE/Home/home node.
html
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
29
Table 1: Overview of prepared results of the evaluation reports.
BIK BITV-Test BITV-Audit
HdM BfB HdM BfB
False positives (WCAG 2.1 AA) 3 2 7 11
False positives (user perspective) 1 3 0 1
False negatives (WCAG 2.1 AA) 12 5 6 3
False negatives (user perspective) 20 17 9 4
True positives (WCAG 2.1 AA) 62 24 68 26
True positives (user perspective) 64 23 75 36
Mistakes 7 7 12 3
of view since these two perspectives can lead to nu-
merous divergent results. The results are shown in
Table 1
A total of 74 problems (the sum of false negatives
and true positives) according to WCAG 2.1 AA and
84 problems from the user’s perspective were iden-
tified on the HdM website. On the BfB website, 29
problems were found according to WCAG 2.1 AA
and 40 problems from the user’s point of view. The
results confirm our assumption that the two websites
differ in their accessibility.
The results of the expert classification show that
ten problems on the HdM website would not be as-
sessed as a problem by WCAG 2.1, but still represent
a usability problem for users. For the BfB website,
there are 13 problems which are not identified as a
problem by WCAG 2.1 but still represent a usability
problem for users. However, there are also two prob-
lems on the BfB website that would be assessed as a
problem by WCAG 2.1 but do not represent usability
or accessibility problems for the users.
For the following four of the total 22 criteria,
the subjective assessment of accessibility experts are
taken into account in the evaluation: “C03: Quality
of the evaluation report”, “C14: Scalability with re-
gard to evaluators”, “C15: Degree of tool support”
and “C20: Simplicity of evaluation procedure”. For
this purpose, we conducted virtual semi-structured
expert interviews in the period from 03/08/2021 to
03/22/2021. The interviews were recorded with the
consent of the experts. All data were stored anony-
mously. A total of six experts participated. Three
members of the BIK evaluation association were in-
terviewed about the BIK BITV-Test and three em-
ployees of T-Systems MMS about the BITV-Audit.
One employee of T-Systems MMS could also partic-
ipate in the interview for the BIK BITV-Test, as he
is also a member of the BIK evaluation association.
The interview partners assigned a value to each item
on a 7-point Likert scale and justified their decision in
a qualitative manner. To avoid bias effects, the items
were presented to the interviewees in differing order.
5.2 Results
The BITV-Audit from T-Systems MMS achieves a to-
tal score of 0.69, the BIK BITV-Test only 0.50. An
overview of the results is shown in Table 2. All results
are rounded to two digits after the period. For both
evaluation methods, the criteria “C18: Potential for
automating the review” and “C19: Future-proofing
for WCAG 3.0” were not evaluated, as no valid quan-
tification could be defined here.
5.2.1 Similarities and Differences of the
Evaluation Methods
In the following, we provide an overview on our find-
ings regarding similarities and differences between
the two methods under investigation.
With a difference (Di f f ) of less than 0.10
between the criterion scores of the two evaluation
methods (Di f f < 0.10), only minor deviations
are observed. The evaluation methods show great
similarities for this criterion.
At a difference (Di f f ) of at least 0.50 between
the criterion scores of the two evaluation methods
(Di f f 0.50), strong deviations are observed.
The evaluation methods show large differences
for this criterion.
For the following four criteria, the evaluation
methods have a lot in common: “C01: Cover-
age of WCAG 2.1 AA” (Di f f = 0.00), “C05:
Correctness”(Di f f = 0.04), “C15: Degree of tool
support” (Di f f = 0.08), and “C20: Simplicity of
evaluation procedure” (Di f f = 0.05).
For the following seven criteria, the evaluation
methods differ greatly: “C04: Coverage of additional
criteria from EN 301 549 Tab. A.1” (Di f f = 0.71;
in favor of BITV-Audit), “C09: Coverage of addi-
tional criteria from BITV 2.0” (Di f f = 1.00; in fa-
CHIRA 2021 - 5th International Conference on Computer-Human Interaction Research and Applications
30
Table 2: Results of all criteria for the BIK BITV-Test and the BITV-Audit.
No. Criterion Weight (in %) BIK BITV-Test BITV-Audit
C01 Coverage of WCAG 2.1 AA 7.72 1.00 1.00
C02 Completeness 7.39 0.75 0.90
C03 Quality of the evaluation report 6.67 0.30 0.79
C04 Coverage of additional criteria from 6.64 0.02 0.74
EN 301 549 Tab. A.1
C05 Correctness 6.32 0.94 0.90
C06 Quality of the sample 5.96 0.73 0.93
C07 Quality assurance 5.58 0.73 0.60
C08 Optional input formats 5.57 0.00 1.00
C09 Coverage of additional criteria from BITV 2.0 5.53 0.00 1.00
C10 Effort 4.77 0.17 0.29
C11 Coverage of additional criteria from 4.70 0.00 1.00
WCAG 2.1 AAA
C12 Range of tested usage constellations 4.19 0.63 0.74
C13 Publicity of the evaluation procedure 4.07 1.00 0.00
C14 Scalability with regard to evaluators 4.04 0.63 0.80
C15 Degree of tool support 3.87 0.52 0.60
C16 License 2.96 0.50 0.00
C17 Certificate 2.90 1.00 0.75
C18 Potential for automating the review 2.90 0.00 0.00
C19 Future-proofing for WCAG 3.0 2.80 0.00 0.00
C20 Simplicity of evaluation procedure 2.44 0.54 0.59
C21 Organizational requirements 1.51 1.00 0.00
C22 Formats of the evaluation report 1.48 0.50 0.25
Total score 100 0.50 0.69
vor of BITV-Audit), “C11: Coverage of additional
criteria from WCAG 2.1 AAA” (Di f f = 1.00; in fa-
vor of BITV-Audit), “C08: Optional input formats”
(Di f f = 1.00; in favor of BITV-Audit), “C16: Li-
cense” (Di f f = 0.50; in favor of BIK BITV-Test),
“C13: Publicity of the evaluation procedure” (Di f f =
1.00; in favor of BIK BITV-Test) and “C21: Organi-
zational requirements” (Di f f = 1.00; in favor of BIK
BITV-Test).
5.2.2 Strengths and Weaknesses of the
Evaluation Methods
In the following, we provide an overview on our
findings regarding strengths and weaknesses of the
two methods under investigation.
With a criterion score (CS) of less than 0.25
(CS < 0.25), less than a quarter of the possible
score is achieved. This criterion is a weakness of
the evaluation method.
With a criterion score (CS) of at least 0.75
(CS 0.75), at least three-quarters of the
possible score are achieved. This criterion is a
strength of the evaluation method.
The following five criteria form the weaknesses
of the BIK BITV-Test: “C04: Coverage of additional
criteria from EN 301 549 Tab. A.1” (CS = 0.02),
“C08: Optional input formats” (CS = 0.00), “C09:
Coverage of additional criteria from BITV 2.0” (CS =
0.00), “C10: Effort” (CS = 0.17), and “C11: Cov-
erage of additional criteria from WCAG 2.1 AAA”
(CS = 0.00). The following six criteria form the
strengths of the evaluation method: “C01: Coverage
of WCAG 2.1 AA” (CS = 1.00), “C02: Complete-
ness” (CS = 0.75), “C05: Correctness” (CS = 0.94),
“C13: Publicity of the evaluation procedure” (CS =
1.00), “C17: Certificate” (CS = 1.00), and “C21: Or-
ganizational requirements” (CS = 1.00). The weak-
nesses and strengths of the BIK BITV-Test are shown
in Table 3.
The weaknesses of the BITV-Audit lie in the fol-
lowing three criteria: “C13: Publicity of the evalua-
tion procedure” (CS = 0.00), “C16: License” (CS =
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
31
0.00), and “C21: Organizational requirements” (CS =
0.00). The following ten criteria are the strengths:
“C01: Coverage of WCAG 2.1 AA” (CS = 1.00),
“C02: Completeness” (CS = 0.90), “C03: Quality
of the evaluation report” (CS = 0.79), “C05: Cor-
rectness” (CS = 0.90), “C06: Quality of the sample”
(CS = 0.93), “C08: Optional input formats” (CS =
1.00), “C09: Coverage of additional criteria from
BITV 2.0” (CS = 1.00), “C11: Coverage of additional
criteria from WCAG 2.1 AAA” (CS = 1.00), “C14:
Scalability with regard to evaluators” (CS = 0.80),
and “C17: Certificate” (CS = 0.75). The weaknesses
and strengths of the BITV-Audit are shown in Table
3.
5.2.3 Observed Anomalies on the Websites
In the following, we provide an overview on our
findings regarding anomalies that occur depending
on the accessibility level of the website.
If there is a difference (Di f f
A
) of at least 0.10
between the normalized values of a metric
regarding the two websites HdM and BfB
(Di f f
A
0.10), there are anomalies in the evalu-
ation method. These anomalies occur depending
on the accessibility of the evaluation object.
In the BIK BITV-Test such anomalies could be
observed in at least one metric of the following cri-
teria: “C02: Completeness” (Di f f
A
= 0.18; in favor
of HdM), “C05: Correctness” (Di f f
A
= 0.10; in fa-
vor of HdM), “C03: Quality of the evaluation report”
(Di f f
A
= 0.13; in favor of HdM), and “C20: Sim-
plicity of evaluation procedure” (Di f f
A
= 0.18; in fa-
vor of HdM). In the BITV-Audit, anomalies were ob-
served in at least one metric of the following crite-
ria: “C05: Correctness” (Di f f
A
= 0.21; in favor of
HdM) and “C03: Quality of the evaluation report”
(Di f f
A
= 0.23; in favor of BfB).
6 DISCUSSION
6.1 Catalog of Criteria
In the context of this work, a comprehensive, generic
criteria catalog was created based on the expertise of
diverse accessibility experts. The criteria catalog con-
sists of 22 criteria with a total of 41 metrics and is thus
more comprehensive than existing criteria catalogs in
related work.
Table 2 lists the criteria and their weights. “C01:
Coverage of WCAG 2.1 AA”, “C04: Coverage of
additional criteria from EN 301 549 Tab A.1”, and
“C09: Coverage of additional criteria from BITV 2.0”
have received high weights in the averaged expert
weighting. The requirements of these standards are
mandatory for the public sector in Germany. Because
the underlying standard is decisive for the results of
a conformity check, these criteria could be consid-
ered particularly important. Since checking non-web
documents is included in the standards, this could ex-
plain the high weighting of “C08: Optional input for-
mats”. The high values for “C02: Completeness”,
“C05: Correctness” and “C07: Quality assurance” are
not surprising, as this is about the validity of the re-
sults. The valid statement about the accessibility of
the checked web pages is the goal of a manual evalua-
tion method. The high weight of the “C06: Quality of
the sample” can be explained by the fact that the con-
formity statement of the checked web pages should
be representative of the entire website. It is not fea-
sible to evaluate the whole website, so the selection
of web pages is very important. The “C10: Effort”
is also perceived as an important criterion by the ex-
perts. An evaluation that provides ideal results but is
not feasible in reality is not a good approach. Fur-
thermore, the aim of a manual evaluation is not only
to determine the accessibility of a website but also to
contribute to improving accessibility. Therefore, the
experts may have found the criterion “C03: Quality
of the evaluation report” important.
Finally, the comparison of two testing methods
was performed on real data using this set of criteria.
The results of the comparison show that various di-
mensions of the evaluation methods can be captured
and quantified using the catalog of criteria.
6.2 Implications of the Study Results
Interesting insights can be gained from the results.
One of the most promising is the combination of em-
pirical evaluation and subsequent conformity evalua-
tion. It was shown that conformance-based evaluation
ensures that a diverse base of issues can be fully and
correctly identified. It is important that the evaluation
method covers as many critical standards as possible.
However, the results also show that an empirical eval-
uation approach can further increase completeness.
This can identify problems that are not covered by
the guidelines but are nevertheless problems that in-
hibit access for users with disabilities. The combina-
tion of empirical evaluation with subsequent confor-
mity evaluation, as used by the BITV-Audit, promises
valid results for assessing the accessibility of a web-
site. This approach promises a comprehensive acces-
sibility evaluation, beyond the limits of the standards
and puts the human in the center. The combination
CHIRA 2021 - 5th International Conference on Computer-Human Interaction Research and Applications
32
Table 3: Weaknesses and strengths of the evaluation methods.
Weaknesses Strengths
BIK
BITV-
Test
- Coverage of additional criteria from
EN 301 549 Tab. A.1
- Coverage of additional criteria from BITV 2.0
- Coverage of additional criteria from
WCAG 2.1 AAA
- Optional input formats
- Effort
- Coverage of WCAG 2.1 AA
- Completeness
- Correctness
- Publicity of the evaluation procedure
- Certificate
- Organizational requirements
BITV-
Audit
- Publicity of the evaluation procedure
- License
- Organizational requirements
- Coverage of WCAG 2.1 AA
- Coverage of additional criteria from BITV 2.0
- Coverage of additional criteria from
WCAG 2.1 AAA
- Completeness
- Correctness
- Quality of the evaluation report
- Quality of the sample
- Optional input formats
- Scalability with regard to evaluators
- Certificate
of conformance testing and empirical evaluation is
also to be pursued in the design of WCAG 3.0 (W3C,
2021).
In addition, detailed evaluation reports with
screenshots and recommended solutions are very im-
portant to create a comprehensive understanding on
the part of the reader and thus facilitate the removal
of the barriers. It is essential to develop user-friendly
tools that efficiently support evaluators in creating
evaluation reports.
Furthermore, the interviews unveiled that the
amount of training required to become an experienced
evaluator should not be underestimated, and conduct-
ing evaluations is not trivial. Good training programs
and a common exchange between evaluators can have
a supporting effect.
The BIK BITV-Test with its tandem procedure has
performed better in quality assurance than the BITV-
Audit. However, this procedure does not seem to lead
to significantly better results in terms of correctness
and completeness. Therefore, the tandem procedure
in the evaluation could be avoided and a comprehen-
sive quality assurance of the results could compensate
for this lack. This would reduce the effort of the eval-
uation procedure. This has already been implemented
in the BIK BITV-Test with the new version (DIAS
GmbH, 2020a).
A central and important aspect in the area of man-
ual evaluation methods is the scalability of the eval-
uation procedures. Websites are becoming more and
more complex and the selection of web pages is cru-
cial for the representativity of accessibility for the
whole website. However, scalability is also critical to
the feasibility of such manual evaluations. The scope
has to be reduced to a manageable size and still pro-
vide a valid statement about the accessibility of the
entire website. The WCAG 3.0 working group is also
concerned with this problem. As shown in the expert
interviews, collaboration in teams can be helpful to
efficiently conduct evaluations of complex websites.
For example, experts for different user groups could
work together on an evaluation. Above all, the level of
tool support must be increased where possible, as well
as the automation of processes and evaluation steps.
Evaluators require tools which will efficiently sup-
port them during performing and documenting evalu-
ations. This should be taken into consideration when
designing a new evaluation method.
6.3 Limitations
In looking at results of our study, the following limi-
tations should be considered. The results of this study
would probably have been more reliable and generic
if these limitations had not been in place.
The identification and weighting of the criteria
were done by accessibility experts, but the metrics
contributing to the criteria do not have an expert-
based weighting. Such weighting could lead to a dif-
ferent result.
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
33
In order to keep the effort for the study in a feasi-
ble frame, we had to cut down on some evaluation pa-
rameters which would have otherwise been performed
in a more comprehensive fashion: (1) The study used
only two websites as evaluation samples. (2) Only
one web page was taken as a sample for each web-
site. For an evaluation that leads to official certifica-
tion, the evaluator has to select a representative sam-
ple of the website. (3) Both websites were evaluated
by only one evaluator. (4) Furthermore, both websites
were information-oriented. The results could differ
for evaluations of complex web applications.
It should also be noted that the evaluator was an
employee of T-Systems, the company that owns the
BITV-Audit. This could have led to a bias towards
this method. On the other hand, the person acting as
QA for the BIK BITV-Test, was an employee of HdM.
In the context of this study, primarily the perspec-
tive of the evaluators and organizations conducting
the evaluations were taken. It could be argued that
by incorporating the client’s perspective to a greater
extend, the results would be more comprehensive.
7 CONCLUSION
In this paper, a systematic comparison of two exist-
ing manual evaluation methods was conducted us-
ing real-world data involving accessibility experts and
two exemplary websites. For this purpose, we cre-
ated a generic catalog of comparison criteria based
on the expertise of various accessibility experts. On
the basis of this catalog, we compared two evaluation
methods in terms of their suitability and effective-
ness: The BIK BITV-Test as one of the best-known
conformance-based evaluation methods in Germany
and the BITV-Audit of T-Systems MMS as an exam-
ple of the empiric-based evaluation methods.
In comparison, the BITV-Audit performs better
than the BIK BITV-Test based on the defined cata-
log and the specific weightings determined by the ac-
cessibility experts involved in the study. However, it
should be noted that no universally valid weighting
can be defined for all possible situations. Therefore, if
necessary, our weights may be replaced by individual
weights and so used to recalculate the comparison for
both methods, on a case-by-case basis. Thus, this pa-
per can assist in deciding which evaluation method is
more appropriate in a particular situation. Addition-
ally, the discussed weaknesses and strengths of each
method can assist in making a decision.
Also, the results show the following major sim-
ilarities between the two evaluation methods: Both
fully cover the WCAG 2.1 success criteria of confor-
mance level A and AA. Furthermore, they have sim-
ilar values in the criteria of tool support and simplic-
ity of the evaluation procedure. Strong differences
are found in the following areas: Coverage of addi-
tional criteria from various standards (EN 301 549,
WCAG 2.1 AAA, BITV 2.0; in favor of BITV-Audit),
the scope of optional input formats (in favor of BITV-
Audit), publicity of the evaluation procedure (in favor
of BIK BITV-Test), licensing conditions (in favor of
BIK BITV-Test), and organizational requirements in
order to gain permission to use the evaluation method
(in favor of BIK BITV-Test).
Moreover, we have observed that WCAG 2.1 does
not consider all usability problems which were iden-
tified through expert assessments.
In this work, we carefully defined a catalog of cri-
teria based on 22 criteria and common standards to-
gether with experts. Nevertheless, it is conceivable
that further criteria and metrics may be of high rele-
vance in the future. The results of this work can al-
ways serve as a basis for possible future extensions in
this area.
REFERENCES
Brajnik, G. (2005). Accessibility assessments through
heuristic walkthroughs. SIGCHI-Italy, page 77.
Brajnik, G. (2006). Web accessibility testing: When the
method is the culprit. In International Conference on
Computers for Handicapped Persons, pages 156–163.
Springer.
Brajnik, G. (2008). A comparative test of web accessibil-
ity evaluation methods. In Proceedings of the 10th
International ACM SIGACCESS Conference on Com-
puters and Accessibility, Assets ’08, page 113–120,
New York, NY, USA. Association for Computing Ma-
chinery.
Brajnik, G. (2009). Validity and reliability of web acces-
sibility guidelines. In Proceedings of the 11th Inter-
national ACM SIGACCESS Conference on Comput-
ers and Accessibility, Assets ’09, page 131–138, New
York, NY, USA. Association for Computing Machin-
ery.
Brajnik, G., Mulas, A., and Pitton, C. (2007). Effects of
sampling methods on web accessibility evaluations.
In Proceedings of the 9th International ACM SIGAC-
CESS Conference on Computers and Accessibility,
Assets ’07, page 59–66, New York, NY, USA. Asso-
ciation for Computing Machinery.
Burkard, A., Zimmermann, G., and Schwarzer, B. (2021).
Monitoring systems for checking websites on accessi-
bility. Frontiers in Computer Science, 3:2.
Calvo, R., Seyedarabi, F., and Savva, A. (2016). Beyond
web content accessibility guidelines: Expert accessi-
bility reviews. In Proceedings of the 7th International
Conference on Software Development and Technolo-
CHIRA 2021 - 5th International Conference on Computer-Human Interaction Research and Applications
34
gies for Enhancing Accessibility and Fighting Info-
Exclusion, DSAI 2016, page 77–84, New York, NY,
USA. Association for Computing Machinery.
DIAS GmbH (2019). Beschreibung des pr
¨
ufverfahrens.
https://www.bitvtest.de/bitv test/das testverfahren
im detail/verfahren.html. Accessed October 14, 2020.
DIAS GmbH (2020a). Anpassung des bitv-/wcag-
test pr
¨
ufverfahrens 2021. https://www.bitvtest.
de/bitv test/bitv test beauftragen/infos preise/
preise abschliessend.html. Accessed March 04, 2021.
DIAS GmbH (2020b). Bitv-test: Kurzvorstellung.
https://www.bitvtest.de/bitv Test/einfuehrung/
kurzvorstellung. Accessed October 14, 2020.
DIAS GmbH (2020c). Informationen und preise. https:
//www.bitvtest.de/bitv test/bitv test beauftragen/
infos preise.html. Accessed October 14, 2020.
European Parliament and Council of the European Union
(2016). Directive (eu) 2016/2102 of the european par-
liament and of the council of 26 october 2016 on the
accessibility of the websites and mobile applications
of public sector bodies.
European Parliament and Council of the European Union
(2018). Commission implementing decision (eu)
2018/2048 of 20 december 2018 on the harmonised
standard for websites and mobile applications drafted
in support of directive (eu) 2016/2102 of the european
parliament and of the council.
European Telecommunications Standards Institute (2018).
En 301 549 v2.1.2 - accessibility requirements for ict
products and services.
European Telecommunications Standards Institute (2020).
Draft - en 301 549 v3.2.1 - accessibility requirements
for ict products and services.
Freire, A. P. (2012). Disabled people and the Web: User-
based measurement of accessibility. PhD thesis, Uni-
versity of York.
German Federal Ministry of Labour and Social Affairs
(2019). Verordnung zur schaffung barrierefreier infor-
mationstechnik nach dem behindertengleichstellungs-
gesetz (barrierefreie-informationstechnik-verordnung
- bitv 2.0).
Lang, T. (2004). Comparing website accessibility evalua-
tion methods and learnings from usability evaluation
methods.
Mankoff, J., Fait, H., and Tran, T. (2005). Is your web
page accessible? a comparative study of methods for
assessing web page accessibility for the blind. In Pro-
ceedings of the SIGCHI Conference on Human Fac-
tors in Computing Systems, CHI ’05, page 41–50,
New York, NY, USA. Association for Computing Ma-
chinery.
Nebe, A.-M. (2021). Bitv audit. https://gpii.eu/bfit/ag03/
handreichung/pruefverfahren/bitv-audit.html. Ac-
cessed May 16, 2021.
Rømen, D. and Svanæs, D. (2008). Evaluating web site
accessibility: Validating the wai guidelines through
usability testing with disabled users. In Proceedings
of the 5th Nordic Conference on Human-Computer
Interaction: Building Bridges, NordiCHI ’08, page
535–538, New York, NY, USA. Association for Com-
puting Machinery.
Statistisches Bundesamt (Destatis) (2020). 7,9 millionen
schwerbehinderte menschen leben in deutschland.
T-Systems Multimedia Solutions GmbH (2020a). Bitv-
pr
¨
ufmethodik - dakks akkreditierter testprozess ex-
pertenevaluation. Internal document viewed on Oc-
tober 14, 2020.
T-Systems Multimedia Solutions GmbH (2020b). Ver-
fahrensbeschreibung. Internal document viewed on
October 14, 2020.
Velleman, E. and van der Geest, T. (2013). Page sample
size in web accessibility testing: How many pages is
enough? In Proceedings of the 15th International
ACM SIGACCESS Conference on Computers and Ac-
cessibility, ASSETS ’13, New York, NY, USA. Asso-
ciation for Computing Machinery.
Vigo, M., Brown, J., and Conway, V. (2013). Benchmark-
ing web accessibility evaluation tools: measuring the
harm of sole reliance on automated tests. In Proceed-
ings of the 10th International Cross-Disciplinary Con-
ference on Web Accessibility, pages 1–10.
W3C (2018). Web content accessibility guidelines (wcag)
2.1. https://www.w3.org/TR/WCAG21/. Accessed
October 27, 2020.
W3C (2021). W3c editor’s draft 22 march 2021 - w3c ac-
cessibility guidelines (wcag) 3.0. https://w3c.github.
io/silver/guidelines. Accessed April 08, 2021.
Yesilada, Y., Brajnik, G., and Harper, S. (2009). How
much does expertise matter? a barrier walkthrough
study with experts and non-experts. In Proceedings
of the 11th International ACM SIGACCESS Confer-
ence on Computers and Accessibility, Assets ’09, page
203–210, New York, NY, USA. Association for Com-
puting Machinery.
Comparison of Manual Evaluation Methods for Assessing the Accessibility of Websites based on EN 301 549
35
