ARKIVO Dataset: A Benchmark for Ontology-based Extraction Tools

Laura Pandolfo

and Luca Pulina

Intelligent System DEsign and Applications (IDEA) Lab,

University of Sassari, via Muroni 23A, 07100 Sassari, Italy

Keywords:

Semantic Web, Dataset, Benchmark, Ontology, Information Extraction.

Abstract:

The amount of data available on the Web has grown signiﬁcantly in the past years, increasing thus the need for

efﬁcient techniques able to retrieve information from data in order to discover valuable and relevant knowl-

edge. In the last decade, the intersection of the Information Extraction and Semantic Web areas is providing

new opportunities for improving ontology-based information extraction tools. However, one of the critical as-

pects in the development and evaluation of this type of system is the limited availability of existing annotated

documents, especially in domains such as the historical one. In this paper we present the current state of affairs

about our work in building a large and real-world RDF dataset with the purpose to support the development

of Ontology-Based extraction tools. The presented dataset is the result of the efforts made within the ARKIVO

project and it counts about 300 thousand triples, which are the outcome of the manually annotation process

executed by domain experts. ARKIVO dataset is freely available and it can be used as a benchmark for the

evaluation of systems that automatically annotate and extract entities from documents.

1 CONTEXT & MOTIVATION

The Web has grown exponentially in size over the

last two decades and today it contains a huge amount

of information resources, such as documents, images,

audios and videos, which can be accessed anywhere

and anytime. Most of this information consists of

unstructured or semi-structured free-text documents

which makes it overly challenging to search or ana-

lyze by users. Therefore, there has been a growing

need for effective and efﬁcient techniques for analyz-

ing free-texts in order to aid users to retrieve struc-

tured information from unstructured documents and

discover valuable and relevant knowledge (Piskorski

and Yangarber, 2013). It is evident that manual anno-

tation of documents cannot be an affordable solution,

since it represents a time-consuming and expensive

task. Moreover, in highly technical and specialized

contexts costly domain expertise is required to decide

on the correct annotation.

For many years, research in the ﬁelds of Informa-

tion Extraction and Natural Language Processing has

been focused on developing techniques able to auto-

matically retrieve – with high precision – structured

information from unstructured and/or semi-structured

https://orcid.org/0000-0002-5785-5638

https://orcid.org/0000-0003-0258-3222

documents. Despite the great progress in these ﬁelds,

computers are still far from being able to have a com-

plete semantic understanding of the human language

(Adnan and Akbar, 2019). Methods to automatically

extract or enhance the structure of various corpora

have been a core topic also in the context of the Se-

mantic Web, in which Information Extraction tech-

niques are especially useful to populate the semantic

knowledge-bases. On the other hand, using Semantic

Web resources, such as ontologies, languages, data,

tools, can be used to guide and improve the Infor-

mation Extraction process (Martinez-Rodriguez et al.,

2020). In particular, the use of ontology for formal

and explicit speciﬁcation domain concepts has been

helpful in Information Extraction, making Ontology-

Based Information Extraction a clear sub-discipline

of knowledge extraction (Wimalasuriya and Dou,

2010). In this ﬁeld, systems exploit ontologies to im-

prove the performance of information extraction, by

supporting and guiding algorithms for efﬁcient and

relevant IE (Konys, 2018). Also, using formal ontolo-

gies allows for applying standard inference engines

for reasoning over extracted entities, thus enabling the

derivation of further information that is not explicitly

contained in texts (de Araujo et al., 2017).

One of the critical aspects in the development of

this type of system is the evaluation phase, which re-

Pandolfo, L. and Pulina, L.

ARKIVO Dataset: A Benchmark for Ontology-based Extraction Tools.

DOI: 10.5220/0010677000003058

In Proceedings of the 17th International Conference on Web Information Systems and Technologies (WEBIST 2021), pages 341-345

ISBN: 978-989-758-536-4; ISSN: 2184-3252

341

quires a ground truth, i.e., a dataset with all the rele-

vant ﬁndings in the documents. Usually, the output of

these tools is assessed by comparing it to the reference

annotation, in order to compute standard quality met-

rics, such as recall and precision. However, it is well-

known that large scale labeled corpus construction is a

laborious and time consuming task (Che et al., 2019)

and, for this reason, there is a limited availability of

existing annotated documents, especially in domains

such as the historical one.

In this paper we present the ARKIVO dataset and

the related collections of archival historical docu-

ments from which the dataset originated. This dataset

is the result of the efforts made within the ARKIVO

project and actually it counts about 300 thousand

triples, which are the results of the manually anno-

tation process executed by domain experts. ARKIVO

dataset is freely available and it can be used as a

benchmark for the evaluation of systems that automat-

ically annotate entities, such as places, persons and

organizations, in unstructured documents. Since the

ontology schema of ARKIVO dataset contains OWL

constructs of OWL 2 DL proﬁle (Grau et al., 2008),

it also can be used for ontology benchmarking pur-

poses, considering that there is a lack of expres-

sive ontologies and language element combinations.

Our ﬁnal goal is to achieve the annotation pro-

cess of the archival historical documents semi-

automatically; to do that, we are currently developing

an ontology-based information extraction tool able to

automatically annotate texts and populate the given

knowledge base. The approach that we are going to

use mainly rely on a combination of natural language

process and information extraction techniques with-

out an extensive involvement of domain experts for

the validation of the extracted instances.

The paper is organized as follows. Section 2 pro-

vides a brief overview of the ARKIVO project, while in

Section 3 we describe the ARKIVO dataset as a bench-

mark. The concluding remarks and future research are

provided in Section 4.

2 THE ARKIVO PROJECT

The ARKIVO project stems from the collaboration be-

tween the J

ozef Piłsudski Institute of America and

the University of Sassari with the aim of develop-

ing the semantic layer of the Piłsudski Institute digital

archive (Pandolfo et al., 2019). In the following sub-

sections, we report the main activities implemented to

reach the stated goal.

2.1 Ontology Modeling and Description

One of the ﬁrst steps in the development of the seman-

tic layer for the Piłsudski Institute digital archive was

the design of a new ontology, which provides a com-

mon language to represent not only the hierarchical

structure of archival documents, but also some essen-

tial data embedded within the textual content of these

documents. In fact, the developed ontology represents

the typical archival structure levels, from the concept

of collection, which can contain items or other col-

lections as fonds, to the concept of single item, which

typically is the smallest indivisible unit. Moreover,

the ontology models some (historical) elements refer-

enced in the archival documents and provides a refer-

ence schema for publishing them as Linked Data.

The ontology has been developed according to a

top-down strategy, which consists ﬁrst in identifying

the most abstract concepts of the domain and then

in specializing the speciﬁc concepts. The adopted

methodology, which is closely related to the approach

presented in (Blomqvist et al., 2016), allows to build

simple, modular and reusable ontologies as well as

ﬂexible to future changes and expansions.

The ontology axiomatization is expressed using

OWL 2 DL proﬁle. This widely-known proﬁle was

chosen as modeling language since it allows to en-

code the knowledge as determined to be impor-

tant by domain experts, e.g., it supports constructs

such as universal quantiﬁcation to a class expression,

inverse object properties and disjunctions. More-

over, it also allows us to perform reasoning over

ontology in order to ensure that ontology is con-

sistent (Riboni and Bettini, 2011). Table 1 shows

the number of classes, axioms and properties of the

ontology. The full documentation is available at

https://github.com/arkivoTeam/arkivo, while the on-

tology is available under a Creative Commons CC BY

4.0 license. The latest ontology version builds on and

extends what reported in some previous contributions,

i.e., (Pandolfo et al., 2017; Pandolfo et al., 2018; Pan-

dolfo et al., 2019)

Table 1: Ontology metrics.

Classes 46

Axioms 280,282

Object properties 26

Data properties 34

2.2 Application and Linked Data

We applied the developed ontology to describe 12,848

collections and 28,644 items of archival holdings of

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

342

the Piłsudski Institute of America. The Institute is de-

voted to collecting, safe-keeping and preserving the

documents and other historical memorabilia as well

as to make these resources accessible to researchers

and visitors by providing support to scholars during

archival queries on site. The international character

of the archival resources draws the attention of a large

number of experts coming from different countries.

To give an idea of the importance of the archival ma-

terial, the collections occupy about 240 linear meters,

namely 2 million pages of documents covering mostly

the Polish, European and American history of the late

19th and 20th century. The collections include not

only documents but also photographs, ﬁlms, posters,

periodicals, books, personal memoirs of diplomats,

and political and military leaders, as well as collec-

tions of paintings by Polish and European masters.

Most of the archival documents are written in Polish,

but the number of documents in other languages – in-

cluding Italian, English, Russian, French, Portuguese

– is signiﬁcant.

In the last ﬁve years, the archival collec-

tions have been annotated, digitized, full-text in-

dexed, and gradually put online on the website of

the Institute - archival collections are available at

http://archiwa.pilsudski.org/index.php. The manual

annotation process of the archival collections has been

carried out in two steps. In the ﬁrst step, archive

workers have been manually annotating every docu-

ment with relevant entities, such as title, author, date

of creation, mentioned persons and/or event, etc. In

the second step, the annotations have been methodi-

cally validated by domain experts and stored into the

knowledge base. This process was certainly time and

resource consuming and it was the main obstacle of

this activity.

Taking advantage of the reference schema pro-

vided by the ontology for publishing Linked Data, it

carried out a data integration process of combining

data residing at different sources with the Piłsudski

resources. In this way, the resources of Piłsudski Dig-

ital Archival Collections have been linked to external

datasets of the linked data cloud in order to enrich

the information provided with each resource. We se-

lected, among others, different authority systems such

as Wikidata, DBpedia, and VIAF (Virtual Interna-

tional Authority File), since they are the most com-

mon source of identiﬁers of people, organizations and

historical events.

In Figure 1, we report an example of individuals

and properties stored in the Piłsudski digital archive,

and how these data have been linked to external re-

sources, such as Wikidata (wd preﬁx) and DBpe-

dia (dbo preﬁx). Looking at Figure 1, individual

701.180/6216 of the class Item is related to its ti-

tle and to its date of creation. This item, which is

part of the ﬁle A701.111.003, is linked, via the ob-

ject property mentions, to the person mentioned in it,

i.e., Roosevelt Franklin Delano. Finally, the internal

resource Roosevelt Franklin Delano is linked to other

external instances and data in the linked data cloud.

Figure 1: Example of entities and relationships. Classes

are drawn as labelled ellipses, object properties between

classes are shown as labelled edges, while boxes represent

data properties.

3 ARKIVO DATASET AND

DOCUMENT COLLECTIONS

In this Section, we present the ARKIVO dataset and

the related collections of archival historical doc-

uments from which the dataset originated. The

ARKIVO dataset is the result of the manually annota-

tion process executed by domain experts. The dataset

counts about 300 thousand triples and 181,780 of to-

tal instances – details of number of instances per class

are reported in Table 2.

Table 2: Dataset metrics.

Items 28,644

Collections 12,848

Dates 6,615

Agents 2,093

Places 1,570

The dataset is freely available under a

Creative Commons CC BY 4.0 license at

https://github.com/ArkivoTeam/ARKIVO and it

can be used as a benchmark for the evaluation of

systems that automatically annotate entities, such as

places, persons and organizations, in unstructured

documents. In particular, ARKIVO dataset could

be especially useful to carry out a named entity

extraction and linking task, which refers to identify-

ing mentions of entities in a text and linking them

to a reference knowledge base provided as input

ARKIVO Dataset: A Benchmark for Ontology-based Extraction Tools

343

(Martinez-Rodriguez et al., 2020). During this task,

the entities mentioned are extracted from the text and

then they are linked to a speciﬁc knowledge base.

This process is also known as entity disambiguation

since it typically requires annotating a potentially

ambiguous entity mentioned with a link to an identi-

ﬁer that describes a unique entity (Derczynski et al.,

2015). For example, the ARKIVO dataset’s resource

G11499 is linked to its Polish name Wielka Brytania

via the schema:name data property. In order to

provide a disambiguation target, the resource G11499

is linked via the owl:sameAs property to the unique

identiﬁer of Wikidata (wd:Q295688), which has its

own name data property Great Britain. This example

is graphically depicted in Figure 2.

Figure 2: Example of annotated entities and relationships in

the ARKIVO dataset in order to avoid potential ambiguous

entity mentions.

The collections of archival historical docu-

ments from which ARKIVO dataset originated

are available in PDF and published online at

http://archiwa.pilsudski.org/index.php#1. All the

documents have been previously scanned and pro-

cessed by an Optical Character Recognition (OCR)

tool.

In the following, we report a simple example to

explain how the proposed dataset can be used as a

benchmark for named entity extraction. Let suppose

that we extracted entities using any Named Entity

Recognition (NER) tool from a set an archival doc-

uments, including the one represented in Figure 3. In

the depicted excerpt, the entities that our NER tool

should be able to extract are marked in green (person

entities) and in red (place entities) colours.

Figure 3: An excerpt from an archival historical document

stored in the Piłsudski digital archive.

Using ARKIVO as benchmark, we can obtain the ac-

tual named entities in the document by querying the

dataset using the SPARQL query depicted in Figure 4.

In Table 3, we report the obtained names’ entities and

Figure 4: Example of SPARQL query in ARKIVO.

the class to which they belong. Note that the SPARQL

query results refer to the whole document and not to

the only excerpt depicted above.

Table 3: SPARQL Query Results.

Entity Name Entity Class

Ciołkosz, Adam Person

Stalin, J

ozef Person

Starzewski, Jan Person

Chruszczow, Nikita Person

Lloyd, Selwyn Person

Bułganin, Nikołaj Person

Polska Place

Rosja Place

Londyn Place

Finally, considering the lack of expressive ontolo-

gies and language element combinations, ARKIVO

can also be used for ontology benchmarking pur-

poses, such as those presented in (Zamazal, 2020),

since it provides good coverage of the OWL 2 lan-

guage constructs.

4 CONCLUSION & FUTURE

WORK

In this paper we presented the ARKIVO dataset and the

related collections of archival historical documents

from which the dataset originated. The ARKIVO

dataset is the result of the manually annotation pro-

cess executed by domain experts. The dataset is freely

available and it can be used as a benchmark for the

evaluation of Ontology-Based information extraction

systems, also in unstructured documents. Moreover,

ARKIVO can also be used for ontology benchmarking

purposes.

The main obstacle of the whole ARKIVO project

was represented by the manual annotation activity,

which was a very time-consuming process. With this

regard, our current research direction consists in the

development of a semi-automatic ontology-based an-

notation process from texts by exploiting some of the

techniques presented in (Pandolfo and Pulina, 2017;

Pandolfo et al., 2016). The implemented approach

will mainly rely on a combination of natural language

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

344

process and information extraction techniques with-

out an extensive involvement of domain experts for

the validation of the extracted instances.

ACKNOWLEDGEMENTS

We would like to acknowledge the J

ozef Piłsudski

Institute of America for providing us with the rich

archival collections. Also, we would like to thank and

commemorate Marek Zieli

nski, Vice-President of the

Piłsudski Institute of America, for his invaluable con-

tribution to both the intellectual and practical side at

each stage of the work.

REFERENCES

Adnan, K. and Akbar, R. (2019). An analytical study of

information extraction from unstructured and multidi-

mensional big data. Journal of Big Data, 6(1):1–38.

Blomqvist, E., Hammar, K., and Presutti, V. (2016). En-

gineering ontologies with patterns-the extreme design

methodology. Ontology Engineering with Ontology

Design Patterns, (25):23–50.

Che, N., Chen, D., and Le, J. (2019). Entity recognition

approach of clinical documents based on self-training

framework. In Recent Developments in Intelligent

Computing, Communication and Devices, pages 259–

265. Springer.

de Araujo, D. A., Rigo, S. J., and Barbosa, J. L. V. (2017).

Ontology-based information extraction for juridical

events with case studies in brazilian legal realm. Arti-

ﬁcial Intelligence and Law, 25(4):379–396.

Derczynski, L., Maynard, D., Rizzo, G., Van Erp, M., Gor-

rell, G., Troncy, R., Petrak, J., and Bontcheva, K.

(2015). Analysis of named entity recognition and link-

ing for tweets. Information Processing & Manage-

ment, 51(2):32–49.

Grau, B. C., Horrocks, I., Motik, B., Parsia, B., Patel-

Schneider, P., and Sattler, U. (2008). Owl 2: The next

step for owl. Journal of Web Semantics, 6(4):309–322.

Konys, A. (2018). Towards knowledge handling in

ontology-based information extraction systems. Pro-

cedia computer science, 126:2208–2218.

Martinez-Rodriguez, J. L., Hogan, A., and Lopez-Arevalo,

I. (2020). Information extraction meets the semantic

web: a survey. Semantic Web, (Preprint):1–81.

Pandolfo, L. and Pulina, L. (2017). Adnoto: A self-

adaptive system for automatic ontology-based anno-

tation of unstructured documents. In Benferhat, S.,

Tabia, K., and Ali, M., editors, Advances in Arti-

ﬁcial Intelligence: From Theory to Practice - 30th

International Conference on Industrial Engineering

and Other Applications of Applied Intelligent Systems,

IEA/AIE 2017, Arras, France, June 27-30, 2017, Pro-

ceedings, Part I, volume 10350 of Lecture Notes in

Computer Science, pages 495–501. Springer.

Pandolfo, L., Pulina, L., and Adorni, G. (2016). A frame-

work for automatic population of ontology-based dig-

ital libraries. In Adorni, G., Cagnoni, S., Gori, M., and

Maratea, M., editors, AI*IA 2016: Advances in Arti-

ﬁcial Intelligence - XVth International Conference of

the Italian Association for Artiﬁcial Intelligence, Gen-

ova, Italy, November 29 - December 1, 2016, Proceed-

ings, volume 10037 of Lecture Notes in Computer Sci-

ence, pages 406–417. Springer.

Pandolfo, L., Pulina, L., and Zielinski, M. (2017). To-

wards an ontology for describing archival resources.

In Adamou, A., Daga, E., and Isaksen, L., editors,

Proceedings of the Second Workshop on Humani-

ties in the Semantic Web (WHiSe II) co-located with

16th International Semantic Web Conference (ISWC

2017), Vienna, Austria, October 22, 2017, volume

2014 of CEUR Workshop Proceedings, pages 111–

116. CEUR-WS.org.

Pandolfo, L., Pulina, L., and Zielinski, M. (2018). Arkivo:

an ontology for describing archival resources. In

CILC, pages 112–116.

Pandolfo, L., Pulina, L., and Zielinski, M. (2019). Ex-

ploring semantic archival collections: The case of

piłsudski institute of america. In Manghi, P., Candela,

L., and Silvello, G., editors, Digital Libraries: Sup-

porting Open Science - 15th Italian Research Confer-

ence on Digital Libraries, IRCDL 2019, Pisa, Italy,

January 31 - February 1, 2019, Proceedings, volume

988 of Communications in Computer and Information

Science, pages 107–121. Springer.

Piskorski, J. and Yangarber, R. (2013). Information extrac-

tion: Past, present and future. In Multi-source, mul-

tilingual information extraction and summarization,

pages 23–49. Springer.

Riboni, D. and Bettini, C. (2011). Owl 2 modeling and

reasoning with complex human activities. Pervasive

and Mobile Computing, 7(3):379–395.

Wimalasuriya, D. C. and Dou, D. (2010). Ontology-based

information extraction: An introduction and a survey

of current approaches.

Zamazal, O. (2020). A survey of ontology benchmarks for

semantic web ontology tools. International Journal

on Semantic Web and Information Systems (IJSWIS),

16(1):47–68.

ARKIVO Dataset: A Benchmark for Ontology-based Extraction Tools

345
