Memoryless: A Two-phase Methodology for Setting Memory

Requirements on Serverless Applications

Rodrigo da Rosa Righi

, Gabriel Borges, Cristiano Andr

e da Costa

and Vinicius Facco Rodrigues

Applied Computing Graduate Program, Universidade do Vale do Rio dos Sinos, S

ao Leopoldo, Brazil

Keywords:

Serverless, Abstraction, Performance, Memory, FaaS, Microbenchmark.

Abstract:

Serverless computing, also known as Function as a Service, is a new paradigm that aims to separate the user of

the platform from details about any infrastructure deployment. The problem lies in the fact that all the current

Serverless platforms require the user to specify at least the needed memory usage for their Serverless offerings.

Here we have a paradox since the users must be involved in technical issues to run their applications efﬁciently,

both in terms of execution time and ﬁnancial costs. To the best of our knowledge, the state-of-the-art lacks on

providing studies regarding the best memory size for a particular application setting. In this context, this work

presents Memoryless, a computational methodology that is in charge of removing the completion of memory

limits by the user when launching Serverless demands. To accomplish this, we introduce in the literature a two-

pass algorithm composed of a microbenchmark where users inform simple application parameters (ﬁrst pass)

and receive from the hypervisor the memory required to run their demands. In addition to user abstraction,

ﬁnancial cost also drives our research, since commonly this metric is directly proportional to the selected

memory size. We implemented Memoryless using NodeJS, Kubeless, and Kubernetes. The result conﬁrms that

the proposed methodology is capable of lowering the memory needs to run an application while maintaining

expected execution times. This beneﬁts both cloud administrators (who can run more Serverless demands

for different users in parallel) and cloud users, who will pay less on using the cloud, so exploring better the

pay-as-you-go policy.

1 INTRODUCTION

Every major computation revolution surpasses the last

one by adding abstraction layers and novel function-

alities for client applications. Client-server topped the

mainframe usage, while cloud computing topped the

client-server paradigm (Fox et al., 2009; Kanso and

Youssef, 2017; Nguyen et al., 2019). In particular,

cloud differs from client-server applications because

it provides the notion of resource elasticity. The ideas

consist of on-the-ﬂy adding or removing, or yet re-

conﬁguring, resources in such a way their number

best ﬁts a particular moment of the application execu-

tion. In this way, threshold-based cloud elasticity with

rules and action statements is mainstream when think-

ing about the malleability of resources (Nasr, 2019;

Villano, 2020). Using either a graphical interface, a

command-line approach, or an API (Application Pro-

https://orcid.org/0000-0001-5080-7660

https://orcid.org/0000-0003-3859-6199

https://orcid.org/0000-0001-6129-0548

gram Interface), users must handle lower and upper

load thresholds (frequently linked with the CPU usage

metric). Besides, rules and actions must also be ana-

lyzed, which is not trivial for non-cloud experts (Kim

and Lee, 2019).

Today, we are living in the next revolution of

resource management named Serverless computing

(Jonas et al., 2019; Kanso and Youssef, 2017; Kim

and Lee, 2019; Nguyen et al., 2019). Serverless com-

puting is a new architecture paradigm, in which the

user only needs to directly upload the code into a hy-

pervisor and specify how much memory is required

to run that piece of code. The system will allocate

computational resources (for example, CPU) in pro-

portion to the main memory size (Kanso and Youssef,

2017; Nguyen et al., 2019; Winzinger and Wirtz,

2019). The larger the size, the higher the CPU al-

location. Resource usage is measured and billed in

small increments (for example, 100ms) and users pay

only for the time and resources used when their func-

tions are running. The submitted code is known in

Righi, R., Borges, G., André da Costa, C. and Rodrigues, V.

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications.

DOI: 10.5220/0010707500003058

In Proceedings of the 17th International Conference on Web Information Systems and Technologies (WEBIST 2021), pages 84-94

ISBN: 978-989-758-536-4; ISSN: 2184-3252

the industry as Function as a Service (FaaS), to allude

to the fact that only a procedure is being uploaded

to the platform, instead of any compiled or pack-

aged objects (Amazon, 2019). Serverless functions

can be used to run code, build mobile and web ap-

plications, manage containers and handle other cloud

computing tasks (Nguyen et al., 2019). All the in-

frastructure needed to run the code is hidden from the

user. Also, the user pays only for code usage (pro-

cedure calls), i.e., for the period comprised between

starting the code and the ﬁnal execution of the last

piece of code (Kuhlenkamp et al., 2020). Thus, a

large and variable number of resources (usually, con-

tainers) take place to execute a collection of stateless

functions inside a time limit imposed by the cloud

provider. These conditions allow Serverless to im-

plement new microservices architectures and to drive

down the costs related to threshold-based elasticity.

In this last technique, the charging method typically

considers an entire time window, independently of the

user spent only the ﬁrst few seconds on that window

(Jangda et al., 2019; Jonas et al., 2019; Kuhlenkamp

et al., 2020; Winzinger and Wirtz, 2019).

Analyzing the state-of-the-art, we perceive that

works are trying to address the concern related to

easying the use of Serverless applications to non-

expert users. Most of the works tend to attack the

issue called cold start that causes the ﬁrst computa-

tion of a Serverless program to be slow, as shown

by (Abad et al., 2018; Horovitz et al., 2019; Kim

and Cha, 2018; Oakes et al., 2017; Winzinger and

Wirtz, 2019). Albeit there is much progress in this

area, the authors in (Jonas et al., 2019) point us to

broader needs for the Serverless computing platforms.

In particular, the article cites that the users of Server-

less computing still need to specify the memory us-

age of their programs that do not match the concept

behind Serverless computing, where the users should

only worry about their code. Yet, in (Kuhlenkamp

et al., 2020) the authors still cite that the problem of

the user abstraction level is a concern for both the hy-

pervisor and the own user. When a Serverless com-

puting platform bounds the user into specifying some

infrastructure requirements, this, in turn, bounds the

provider to always providing at least that infrastruc-

ture for running the code. Thus, we afﬁrm that today

remains an open gap in the literature regarding the

need for removing barriers to specifying infrastruc-

ture requirements on using the Serverless concept.

In this context, this work proposed a two-pass al-

gorithm named Memoryless, who is in charge of facil-

itating the use of Serverless applications in such a way

users must not worry about ﬁlling up details about

memory size. To accomplish this, this algorithm exe-

cutes microbenchmark where: (i) in the ﬁrst pass we

have an estimation of the needed memory size to rub a

single container in the face of a set of application de-

scription; (ii) in the second phase, we have a launch-

ing of the Serverless application with the parameter

previously discovered as memory limit. In addition

to diffusing the employment of FaaS, Memoryless is

also pertinent to reduce ﬁnancial cost to end-users,

since providers typically charge taking into account

the selected memory requirements. In other words,

Memoryless avoids overestimation in the memory pa-

rameter, so impacting directly in the cost for end-

users. We developed a prototype that uses NodeJS,

Kubeless, and Kubernetes, which are representative

tools when assembling a container-based Serverless

environment. Memoryless contributions are twofold.

• Proposal of two-pass methodology to run Server-

less applications with the most suitable memory

limit, so allowing users for not caring about such

parameter beforehand;

• A proof-of-concept with state-of-the-art technolo-

gies, enabling the proposed methodology as vi-

able to support Serverless infrastructure effort-

lessly.

The remainder of this article will ﬁrst introduce

the related work in Section 2. In this point, our idea is

to present a comparison table, as well as the open gaps

in the literature. Section 3 describes Memoryless, in-

cluding its architecture, functioning and microbench-

mark. Section 4 reveals the evaluation methodology.

A discussion of the results appear in Section 5. Fi-

nally, Section 6 emphasizes the scientiﬁc contribution

of the work and notes several challenges that we can

address in the future.

2 RELATED WORK

In this section, we analyze initiatives in the state-of-

the-art on Serverless usage and applications. Jonas

et al. (Jonas et al., 2019) present an article that cov-

ers the current state of research and industry on the

topic, detailing the main gaps on the Serverless today.

They reveal an analysis of the industry viewpoint, de-

tailing what the industry has to offer for the users of

Serverless. The authors go a step further to analyze

the current state of the Serverless offerings. The au-

thors created several implementations of typical soft-

ware applications in the context of Serverless. They

then compared them, showing a considerable gain in

resource and cost when it comes to high-level appli-

cations. However, they point out that Serverless is not

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications

the right ﬁt for running low-level applications, such

as databases.

Horovitz et al. (Horovitz et al., 2019) present a

technical work that tries to solve the ”cold start” prob-

lem on Serverless today. By provisioning the same

architecture in a Serverless and a usual cloud VM,

it uses machine learning to predict the cost for the

service to operate. It routes the call for the cheaper

instance, be it Serverless or cloud VM. It is impor-

tant to note that this work was made from the per-

spective of the user of Serverless and cloud infrastruc-

tures, different from other found technical jobs. The

proposal is implemented on top of the Fission open-

source Serverless engine. It uses Python Scikit Learn

with Decision Trees to both: (i)estimate when the pro-

cedure calls that would arrive in the system and; (ii)

to route the calls to the VMs, in such a way Serverless

platform would not handle it. The result of the classi-

ﬁcation algorithm then makes fake calls to the Server-

less application to remove the ”cold start” and spin up

a single VM to handle the requests in the meantime.

Oakes et al. (Oakes et al., 2017) aim to raise the

abstraction and the execution speed of Serverless ap-

plications. The idea is to require the user of a Python

Serverless application to deploy, along with his/her

code, a list of the needed packages that the service

depends on. By bringing the need to bundle the appli-

cation onto the hypervisor, this strategy enables the

hypervisor to load the application faster by caching

the packages needed for all users of the Serverless

platform. Thus, we have less FaaS to load into mem-

ory. The model proposed in (Oakes et al., 2017) is

supposed to be security-aware. By forking new pro-

cesses from the running dependencies, it isolates all

the callers from seeing each other’s data should they

share any package. The authors use a copy-on-write-

like directive to avoid package sharing while still al-

lowing for heavy package reuse when the user pro-

vides the code for them to run.

Abad, Boza, and Eyk (Abad et al., 2018) build on

top of the work of Oakes et al. (Oakes et al., 2017)

by inserting a cache hit/miss algorithm, in addition

to an algorithm that is aware of the packages needed

to run a Serverless provision. These changes increase

the performance of dependency management by 66%.

Kim and Cha (Kim and Cha, 2018) bring a two-step

algorithm to lower the latency of the calls to Server-

less. The ﬁrst is a model to allocate a three-state

worker. Here, we have a swarm of ”template work-

ers” (the base images needed for any Serverless func-

tion), which would be converted to a ”Ready worker”

that would run all the pre-running steps to leave the

worker ready to be deployed, which could then be

promoted an ”Active worker” (the actual code exe-

cuting). The second step of the algorithm is a slid-

ing window dynamic prediction to determine when a

”Template worker” would be allocated to a ”Ready

worker” and then to an ”Active worker.”

Hall and Ramachandran(Hall and Ramachandran,

2019) present an interesting take on the Serverless

world. The authors ﬁrst assess the current problems

in Serverless computing, namely the cold start prob-

lem, and pinpoint the main issue with it in the use

of containers to run native code. The authors then

propose a new container-like work by using the V8

engine to run WebAssembly code, which has a faster

initialization time than native code running inside typ-

ical containers. By using existing compilers targeting

WebAssembly from native-targeting languages, there

is a quicker initialization time. However, the main is-

sue lies in the current speed of WebAssembly, which

still is slower than native code.

To analyze and compare the aforementioned

works, we have devised the following guiding ques-

tions:

1. Does the work deal with Serverless?

2. Does the result of the work need to be imple-

mented by the hypervisor?

3. Does the work aim to improve the performance of

the Serverless application execution?

4. Does the work consider memory usage?

5. Does the work use cache to improve the perfor-

mance of the execution?

6. Does the work use machine learning?

7. Does the work aim to ﬁx the ”cold start” problem?

8. Does the practice aim to raise the usage abstrac-

tion for the user of a Serverless platform?

While most of the works were able to answer

questions 1, 2, 3, 5, 6, and 7, no work was able to

answer questions 4 and 8. Then, we envisage a gap in

the state-of-the-art, as presented in Table 1, that offers

an analysis of the works mentioned above. A better

alternative to having the user specify resources would

be to raise the level of abstraction, having the cloud

provider infer resource requirements instead of hav-

ing the developer deﬁne them. Provisioning just the

right amount of memory automatically is particularly

appealing but especially challenging when the solu-

tion must interact with the automated garbage collec-

tion used by high-level language runtimes.

3 MEMORYLESS MODEL

We plan to complete the gap existing in the litera-

ture that consists of the necessity to inform the mem-

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

Table 1: Comparison of the selected works.

Feature

(Jonas et al., 2019)

(Horovitz et al., 2019)

(Oakes et al., 2017)

(Abad et al., 2018)

(Kim and Cha, 2018)

(Hall and Ramachandran, 2019)

Does the work deal with Serverless? 3 3 3 3 3 3

Does the result of the work need to be implemented by the hypervisor? 7 3 3 3 3

Does the work aim to improve the performance of the Serverless application

execution?

3 3 3 3 3

Does the work consider memory usage? 7 7 7 7 7

Does the work use cache to improve the performance of the execution? 7 3 7 7 7

Does the work use machine learning? 3 7 7 7 7

Does the work aim to ﬁx the ”cold start” problem? 3 3 3 3 3

Does the practice aim to raise the usage abstraction for the user of a Serverless

platform?

7 7 7 7 7 7

ory limit when launching a Serverless demand to the

cloud. We agree that the concept of Serverless is up-

and-coming, and to accomplish this, it is important to

provide better abstraction on its usability. In this way,

Memoryless follows this idea by hiding from the user

any details related to memory resource allocation and

management of machine instances in the cloud. In-

stead, they can run code on cloud servers without hav-

ing to conﬁgure or maintain the servers at all. Pricing

is based on the actual amount of resources consumed

by an application, rather than on pre-purchased units

of capacity.

This section ﬁrst presents the design decisions of

Memoryless modeling. Second, we reveal the sys-

tem architecture, highlighting the user interaction. Fi-

nally, the proposed algorithm is described, where we

also highlight the particular points that reside our con-

tribution.

3.1 Design Decisions

We developed Memoryless to able users to launch

Serverless applications without needing to describ-

ing any detail related to memory. Memoryless then

changes the way users from today’s Serverless use

the platform in the following manner: (i) users would

have to submit the expected parameters of their pro-

gram along with their source code; (ii) the hypervisor

can run a proposed microbenchmark to determine the

most suitable memory needs for the Serverless appli-

cation. Thus, Memoryless can be seen as a two-pass

algorithm. The idea in (i) is to receive both the FaaS

(UC) to be run on the Serverless platform and a set of

parameters (PR) in the form of events that trigger the

Serverless program. The Serverless platform should

then start a modiﬁed ’function container’ in (ii) that

should have the ability to query for the used memory

in any given moment in time. We understand that us-

ing a microbenchmark to determine the best value of

the memory brings the following beneﬁts:

• For the user, who will pay exactly what his/her ap-

plication really needs, so avoiding overestimation

of this parameters and an subsequent overcharg-

ing on running a Serverless application;

• For the cloud provider, since more users can

be scheduled concomitantly to use the available

cloud resources.

To enable these beneﬁts, we bring the idea that the

cloud provider must do not charge the user when run-

ning a sample application with determined parame-

ters. The output is the most suitable memory size and

the own provider proﬁts on doing this procedure as

clariﬁed earlier. Technically, the platform should then

test for the needed memory by executing the function

UC with the parameters PR and querying the mem-

ory used after each test set be completed. After all the

querying done, the platform gets the maximum used

memory of the execution. This value is used to launch

the Serverless application subquently. Our idea then

is to exchange the low-level representation of mem-

ory to specifying a high-level parameter list. This list

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications

Hypervisor

Development Deployment

User

Creates serverless

application

Deﬁne the memory

needed to deploy the

application

Call deploy

Production

Receives deploy

request

Create a new

container to run the

application

Run the application in

production

Figure 1: Current Serverless model.

would be application-speciﬁc and, more importantly,

more relevant to the business reason for the applica-

tion rather than the technical basis. Also, consider-

ing that the ﬁnal cost is proportional to the allocated

memory, the proposed strategy also goes towards pro-

viding a solution for saving money in such a way we

nave the most suitable memory limit to run a program

in the cloud.

3.2 Architecture

This section presents the Memoryless architecture,

where we present interactions of the user and hyper-

visor in three moments: (i) development; (ii) deploy-

ment; (iii) production. Figure 1 illustrates these actors

and moments in a traditional Serverless model. At the

development stage, users must be involved with mem-

ory details of their applications. Figure 2 depicts the

proposed methodology, where we divide the hypervi-

sor offering in two steps involving Microbenchmark

and Production. The microbenchmark is responsible

for determining how much memory the application

will need to run effectively. The Production Step, in

its turn, is the same as the current Serverless offerings;

but here, the memory requirement will come from the

microbenchmark step rather than from the user. Thus,

the cloud service provider manages the infrastructure

and the software and maps the function to an API end-

point, transparently scaling function instances on de-

mand.

The proposed architecture takes into account the

moment from which the user submits his/her code to

the hypervisor. Then, we have the replacement of the

current requirements of FaaS and memory to FaaS

and parameters. These parameters could be informed

through command-line or by using auxiliary ﬁles that

are uploaded when launching a Serverless applica-

tion. Considering the settings, we agree that the user

must be aware that the fewer parameters the user adds,

the worst will be the return of the microbenchmark.

Hypervisor

Deployment

User

Creates serverless

application

Deﬁne the

parameters and

events the

application will

receive

Create a new

container to run the

application

Get the memory

usage of the

instrumented

container

Call deploy

Creates an

instrumentation

container based on

the application

Receives deploy

request

Call the instrumented

user code with the

provided parameters

Microbenchmark Step

Production

Run the application in

production

Development

Deployment Step

Figure 2: Memoryless architecture.

Therefore, the more diverse and rich the parameters

are, the more accurate the memory number yielded

by the microbenchmark step will be.

The parameters needed to determine the mem-

ory limit on running a Serverless application vary

depending on the implementation of the Serverless

infrastructure. Memoryless model must support all

the parameters that the Serverless infrastructure al-

lows. Assuming that a Serverless provider supports

both HTTP events and an internal event mechanism,

the user must be able to provide examples of such

events so that the microbenchmark step can effec-

tively mimic a real-world usage of the Serverless in-

frastructure. So, the format of such parameters is

implementation-speciﬁc. The parameters must be

stateless and must not depend on one another; in such

a way, the microbenchmark can run calls in parallel

with a different load of events for the Serverless ap-

plication.

The proposed model does not make a distinction

between a call correctly placed or if an error occurred

inside the FaaS. The model will query for the used

memory should the call produce an error or not. The

user should decide whether the error handling mecha-

nism should reﬂect any changes in the memory avail-

able for his/her program or not. Finally, this step of

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

training the Serverless execution to obtain the mem-

ory limit to execute the application is not charged to

the user, i.e, it corresponds to a service offered by the

cloud providers to users to enable them to tune their

applications to consume the most suitable number of

resources. Here, it is pertinent to remember that the

amount of allocated meory is commonly proportional

to the number of containers used to run a Serverless

demand.

3.3 Algorithm Proposal

Algorithm 1 presents the microbenchmark step on the

Memoryless execution. This algorithm needs to re-

ceive three parameters: (i) faas: The function to be

run; (ii) pr: the parameters needed to run the argu-

ment FaaS; (iii) runs, which refers to the number of

times the parameters will be called. While the argu-

ments faas and pr will be provided by the user of the

Serverless platform, the platform itself will have to

decide the maximum load allowed for the item runs.

To test for accurate loads, the platform should set it

to the maximum number of connections and events

available to a single container (before the horizontal

scaling starts).

Algorithm 1: Microbenchmark Step.

Input:

Faas - The Function as a Service

pr - Set of parameters for the FaaS

runs - Times to run the tests

Output

MM - Maximum required memory for the provided

faas

1: i ← j ← 0

2: MU ← {}

3: ic ← createMicrobenchmarkContainer( f aas)

4: for i=0; i ¡ runs; i++ do

5: for j=0; j ¡ num(pr); i++ do

6: inside ic call f aas(pr[ j])

7: memory ←

getCurrentMemoryInContainer(ic)

8: MU ← MU ∪ memory

9: end for

10: end for

11: MM ← Max(MU)

12: return MM

Also, we are assuming that the provider will de-

livery two other functions:

1. createMicrobenchmarkContainer: a function

that upon receiving the FaaS will create a new

container with that FaaS and with instrumentation

abilities, namely the possibility to query for the

total used memory at any given time.

2. getCurrentMemoryInContainer: a function

that returns the current memory usage of the con-

tainer speciﬁed.

The last assumption needed for executing the

ideas of Memoryless is that we are working with a

runtime that performs memory management with a

Garbage Collector. In this way, line number 7 of Al-

gorithm 1 will yield all the memory used when ex-

ecuting the Serverless demand. If not working with

a Garbage Collector, then the microbenchmark con-

tainer must record the used memory during line 6,

since at this time we need to know the current used

memory because it is not freed during previous ex-

ecutions. Thus, logically, the second execution will

retiorn more memory if compared to the ﬁrst because

of memory never goes to zero. The high-level pro-

duction step should replace the current infrastructure

by having an action to call the Microbenchmark step

before starting the container. Finally, we must get the

output of Algorithm 1 and run the ﬁnal Serverless ap-

plication.

4 EVALUATION

METHODOLOGY

Today, the literature agrees that there is not a standard

methodology to evaluate Serverless applications (Kim

and Lee, 2019; Kuhlenkamp et al., 2020; Winzinger

and Wirtz, 2019). For example, in (Kim and Lee,

2019) the authors used arbitrary applications in the

ﬁelds of Big Data, Web and security. On the other

hand, Kuhlenkamp et al. (Kuhlenkamp et al., 2020)

explored a synthetic application with three distinct

phases: warm-up, scaling and cool-down. Yet, de-

pendency testing between different application mod-

ules was addressed in a Serverless infrastructure in

(Winzinger and Wirtz, 2019). Therefore, in this

moment we opted by developing our own evalua-

tion methodology, which was focused on analyzing

the memory impact on Serverless deployment. Our

methodology comprises the answer for a collection of

questions and the implementation of a prototype and

experimental memory-targeted applications. The fol-

lowing guiding questions are planned to be used to

evaluate the Momeryless prototype:

EV1 Can the implementation run in a two-pass conﬁg-

uration?

EV2 Can the Microbenchmark step yield the maximum

memory used with the given parameters?

EV3 Can the system assign different memory require-

ments for two applications with distinct memory

usages?

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications

In brief, for any given program, Memoryless

should be able to provide the following software re-

quirements: (SR1) determine the maximum memory

needed for running the program on a single container;

(SR2) use the information obtained in S1 to instanti-

ate a container; (SR3) remove the need from the user

to specify memory limit on FaaS implementations.

The developed prototype has a set of requirements

for the implementation. Regarding the Function as

a Service runtime: (i) it must use garbage collection

as memory management; (ii) there must be an open

API to query the memory usage at any given moment

in time. Regarding the Serverless hypervisor imple-

mentation: (iii) It must be extensible to allow for the

creation of the Microbenchmark step; (iv) It must be

based on containers so it will be possible to create the

microbenchmark Container. Regarding the parame-

ters: (v) the only event parameters supported will be

HTTP events; (vi) the HTTP events shall not carry

any payload. Regarding the FaaS: (viii) there should

be a simple Function as a Service implementation that

queries a database and return data to the caller; (viii)

there shall be a memory-heavy Function as a Ser-

vice implementation that inﬂates its memory until a

given threshold and stays in that threshold while be-

ing called.

The chosen runtime was NodeJS (NODE.JS

FOUNDATION, 2019a), as it provides memory man-

agement via Garbage Collection and it has an API for

querying the memory usage during the execution of

a process (NODE.JS FOUNDATION, 2019b). This

satisﬁes the requirements (i) and (ii). For the im-

plementation, we are using Kubeless (KUBELESS,

2019), since it is an open-source implementation of a

Serverless provider. Being open-source enables us to

change its behavior to implement our model, thus sat-

isfying (iii). It also is built on top of Kubernetes (THE

KUBERNETES AUTHORS, 2019), which is an or-

chestration mechanism for containers, thus meeting

(iv) as well. Following the same ideas from (Horovitz

et al., 2019), here we also use the nodecellar applica-

tion to mimic a simple FaaS that queries a database,

after converting it to be able to run on the platform

Kubeless. This satisﬁes (vii). For (viii), the authors

developed a simple application that randomly gener-

ates strings and stores them into memory, using the

same memory usage API (NODE.JS FOUNDATION,

2019b) to set the memory size used to a speciﬁc limit.

Finally, both sample applications satisfy (v) and (vi).

5 RESULTS

In this section, we present the results obtained when

running the prototype with the evaluation methodol-

ogy details described earlier.

5.1 Winecellar Application

Winecellar (https://www.vinfolio.com/cellar-

management) is a Web application where we

have a collection of wines and operations such

as query, addition and removal are allowed over

such collection. Thus, we deployed the functions

(add, remove and query) of this application in the

Kubeless Serverless implementation. When running

the Winecellar, the microbenchmark step was able

to run 5 thousand calls to the function that read all

the wines stored in the database. The results can be

found in Figures 3a and 4a. The graphs were made

by storing all the values returned at the line 13 of the

Algorithm 1.

The application has shown to have peak memory

at 36.11 MB, which can be found around call number

4456 on the graph of Figure 3a. Here, we achieved a

median memory usage of 8.96 MB, where more than

half of the calls were situated between 14.83 MB and

21.73 MB, as seen in graph 4a. The return of the Al-

gorithm 1 in this instance was 36.11 MB. The produc-

tion step was then able to deploy a production-ready

container with the FaaS code and a memory limit of

36.11 MB. Without this number, the user possibly will

complete with a higher parameter; for example, 64

MB or more.

We observe that in Figure 3a, there is a trend to

use more and more memory, as the minimum mem-

ory needed to run keeps increasing as the calls keep

being made. This could be an indication of a mem-

ory leak either in the Winecellar application or in the

Serverless provider implementation. Further investi-

gation would be required to determine the exact na-

ture of this behavior. Another factor to investigate

further would be the memory peaks shown in the calls

with numbers equal to 1822, 2179, 2674, 3169, 3268,

and 4456. These peaks clearly show that in these

moments, something is stressing the memory usage

abruptly. Further investigation would be necessary to

pinpoint what the cause such peaks.

5.2 Memory-stress Test Application

The application designed to stress the memory run-

ning inside the containers presented the results shown

in Figure 3b. This application was designed to add a

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

100

199

298

397

496

595

694

793

892

991

1090

1189

1288

1387

1486

1585

1684

1783

1882

1981

2080

2179

2278

2377

2476

2575

2674

2773

2872

2971

3070

3169

3268

3367

3466

3565

3664

3763

3862

3961

4060

4159

4258

4357

4456

4555

4654

4753

4852

4951

Memory Used (MB)

Number of calls to the conta iner

(a) Memory usage for each call in the Winecellar application.

100

150

200

250

300

350

400

101

201

301

401

501

601

701

801

901

1001

1101

1201

1301

1401

1501

1601

1701

1801

1901

2001

2101

2201

2301

2401

2501

2601

2701

2801

2901

3001

3101

3201

3301

3401

3501

3601

3701

3801

3901

4001

4101

4201

4301

4401

4501

4601

4701

4801

4901

Memory Used (MB)

Number of calls to the container

(b) Memory usage in memory-stress test application.

Figure 3: Timeline of memory usage per call for both evaluated applications.

random string into memory in each call until the pro-

cess had 300 MB. If the process had more than 300

MB, the call would not execute anything. This appli-

cation presents us a more interesting scenario to ana-

lyze. The peak of memory usage was 370.22 MB, as

seen in the graph of Figure 3b. We observe that the

median was 313.99 MB, and half of all the calls used

between 304.89 MB and 323.61 MB of memory (see

Figure 4b). The production step was then able to de-

ploy a production-ready container with the FaaS code

and a memory set of 370.22 MB.

Observing the results, we highlight information

regarding the period that declines the memory usage,

which appears close to the calls 2501 and 4501. This

can be explained by the lifespan on the Serverless

container timing out, as the call to create the strings

takes more time than the call to query a database (al-

beit the query has network trafﬁc to fetch from the

database). Thus, after around 2 thousand calls, the

Serverless provider ends up destroying the container

running the function and has to start it again when the

next call is executed.

Another factor to observe refers to the application,

which usually shows a peak memory of 323.61 MB.

This can be explained as 300 MB being the limit in

memory usage: summing the random string in mem-

ory and the heap memory needed by the NodeJS en-

gine to run the function when called. The magnitude

of the offset, from 20 MB to 30 MB, is comparable

to the memory usage shown in Subsection 5.1, where

the memory cost for the NodeJS application is mini-

mal. The sawtooth shape of the graph also indicates

that the memory needed don’t go under 300 MB (as

is speciﬁed by the function), but the runtime keeps

garbage collecting the memory required to run the ser-

vice. Thus, we can then say that around 300 MB is

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications

Memory Used (MB)

(a) Boxplot for memory usage for each call in Winecellar.

100

150

200

250

300

350

400

Memory Used (MB)

(b) Boxplot for memory usage in memory stress test.

Figure 4: Box plot graph of the tested applications.

being used for the runtime stack, and the remaining

memory is being used for the heap of the runtime.

In all instances of the lifespan, the ﬁrst calls al-

ways show some variation in memory usage, such as

in the calls 201 to 601, and calls 2501 to 2801. There-

fore, this could be the result of the heap misbehaving,

and, if run for more calls, the runtime could stabilize.

It is essential to note that this example only has one

parameter P

and one type of call to be run in the Mi-

crobenchmark Step. If there would be more types of

calls and more behaviors testing for this same appli-

cation, the graph could have a better representation

of reality, and the uniformity of the saw-tooth peaks

would be more ﬂuent.

5.3 Tools Shortfalls

We used computing tools that presented some short-

falls. Most notably were the limitations of the Kube-

less implementation. Kubeless lacks a ”scale to zero”

capability, one of the hallmarks of Serverless com-

puting (Jonas et al., 2019). On the upside, it does

not possess a ”cold start” (Jonas et al., 2019) issue

since it never stops executing (thus being pricier).

Also, the lack of debugging capabilities makes it

harder for the user to develop targeting this plat-

form. We also observed the lack of active devel-

opment in (KUBELESS, 2019). The open-source

community seems to have migrated from Kubeless to

the Google-sponsored Knative (THE KNATIVE AU-

THORS, 2019), as it is described as a Kubernetes-

based platform to deploy and manage modern Server-

less workloads. Future works include implementation

and testing of Memoryless on top of Knative instead

of Kubeless and veriﬁcation whether the caveats pre-

sented here are still present.

5.4 Discussion

This section goes back to the questions raised in Sec-

tion 4 to check if the evaluation yields a positive result

and if the speciﬁc objectives were fulﬁlled. For all the

questions, we raise the same three points: (i) Was it

answered? Was it a positive outcome? (ii) Does it

have some drawbacks? Which?; (iii) Is it possible to

ﬁx this drawback? Would it need future work? In Ta-

bles 2, 3, 4 and 5, we have a complete breakdown of

the questions and their answers. Some questions and

evaluation methods are very similar that they were

joined in single table.

6 CONCLUSION

The Serverless computing paradigm is a game-

changer in cloud computing. The current caveat of

having to specify how much memory will a Serverless

application has to use beforehand is indeed against

the current trend of raising the abstraction layer. For

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

Table 2: Answers and drawbacks of EV1 and SR2.

(EV1) Can the implementation run in a two-pass conﬁguration? (SR2) Use the information obtained in SR1 to

instantiate a container that is limited to the needed memory on the application

Answer Yes, the implementation has proven that it can indeed run in a two-pass conﬁguration by extending the current

deployment step to run the implementation ﬁrst and only start the production container after the memory has

been determined.

Drawback A major drawback is the time to start executing the deployment function in production, as the Microbenchmark

Step can take T seconds to run all the Microbenchmark Step, where T = |P

| ∗ P

∗t where |P

| is the number of

parameters received, P

is the precision required by the hypervisor and t is the time in seconds to run the FaaS

application.

Possible so-

lution to

drawback

A solution for future work could be to parallelize the execution of the Microbenchmark Step and the Production

Step so that the Production Step can run with the maximum memory until the Microbenchmark Step is ready to

re-create the production container with the minimal viable memory allocation.

Table 3: Answers and drawbacks of EV2 and SR1.

(EV2) Can the Microbenchmark Stepyield the maximum memory used with the givenparameters? (SR1)

Determine the maximum memory needed for running the program on a single container

Answer Yes, the Microbenchmark Step has proven to be able to yield the correct answer, as can be checked on Figures 3

and 4.

Drawback It only works with garbage collected languages, as it can only synchronously query memory usage, and only a

garbage collected language would still hold irrelevant items in memory.

Possible so-

lution to

drawback

The model could be improved in future works to query the memory usage at a ﬁxed time interval asynchronously,

or it could continuously register the memory usage of the container running the user code during the maximum

memory test and return that value when queried.

Table 4: Answers and drawbacks of EV3.

(EV3) Can the system assign different memory requirements for two applications with distinct memory usages?

Answer Yes, the system can assign different memory limits to different programs, as seen in Section 3.

Drawback None.

Possible so-

lution to

drawback

None.

Table 5: Answers and drawbacks of SR3.

(SR3) Remove the need for the user-speciﬁed memory limit on FaaS implementations

Answer Yes. One of the steps for the model is to remove the need for user-speciﬁed memory limits

Drawback By removing the option for the user to specify the memory the user is losing low-level control over their appli-

cation, but, as seen before, this is the whole intent of the Serverless computing movement.

Possible so-

lution to

drawback

Future works could create a questionnaire and ask users of Serverless computing solutions if they prefer to have

more low-level control over their programs, or they would rather have their infrastructure calculate everything

for them. They only can worry about their application logic.

example, all the recent Serverless offerings, includ-

ing Google Cloud Functions (released by Google in

2017), AWS Lambda (introduced in 2014), and Mi-

crosoft Azure Functions (presented in 2016), present

this drawback mentioned above. In this context, this

article introduced a new proposal named Memoryless

in such a way the memory limit is obtained through

a microbenchmark, which should be offered by the

cloud provider. In particular, we ﬁlled the gap pointed

out by Jonas et al. (Jonas et al., 2019) who present the

need to solve this memory issue to in fact elevate the

use of this computing principle.

By building a prototype of the model and running

two different types of workloads, we can denote that

the proposed model obtained encouraging results be-

ing feasible to launch Serverless effortlessly. We must

also highlight the ﬁnancial cost factor. In a Serverless

computing deployment, the cloud customer only pays

for service usage; there is never any cost associated

with idle, down-time. However, this payment is pro-

portional to the registered memory; then, Memoryless

goes towards saving money since here we will not

have memory overestimation when running Server-

less demands. Finally, our contributions can be em-

ployed to bring to an elastic-cloud platform yet more

applications from different areas, including the In-

ternet of Things, event-triggered computing, mobile

apps, backend procedures, and high-volume of data

treatment.

ACKNOWLEDGEMENTS

The authors would like to thank the Coordenac¸

de Aperfeic¸oamento de Pessoal de N

ıvel Superior -

CAPES (Finance Code 001) and Conselho Nacional

Memoryless: A Two-phase Methodology for Setting Memory Requirements on Serverless Applications

de Desenvolvimento Cient

ıﬁco e Tecnol

ogico - CNPq

(Grant Number 303640 / 2017-0).

REFERENCES

Abad, C. L., Boza, E. F., and van Eyk, E. (2018). Package-

aware scheduling of faas functions. In Companion

of the 2018 ACM/SPEC International Conference on

Performance Engineering, ICPE ’18, pages 101–106,

New York, NY, USA. ACM.

Amazon (2019). Serverless computing – amazon web ser-

vices. https://aws.amazon.com/serverless/. Accessed

on 12/06/2019.

Fox, A., Grifﬁth, R., Joseph, A., Katz, R., Konwinski,

A., Lee, G., Patterson, D., Rabkin, A., and Stoica,

I. (2009). Above the clouds: A berkeley view of

cloud computing. Dept. Electrical Eng. and Com-

put. Sciences, University of California, Berkeley, Rep.

UCB/EECS, 28(13):2009.

Hall, A. and Ramachandran, U. (2019). An execution model

for serverless functions at the edge. In Proceedings

of the International Conference on Internet of Things

Design and Implementation, IoTDI ’19, pages 225–

236, New York, NY, USA. ACM.

Horovitz, S., Amos, R., Baruch, O., Cohen, T., Oyar, T.,

and Deri, A. (2019). Faastest - machine learning

based cost and performance faas optimization. In

Coppola, M., Carlini, E., D’Agostino, D., Altmann,

J., and Ba

nares, J.

A., editors, Economics of Grids,

Clouds, Systems, and Services, pages 171–186, Cham.

Springer International Publishing.

Jangda, A., Pinckney, D., Brun, Y., and Guha, A. (2019).

Formal foundations of serverless computing. Proc.

ACM Program. Lang., 3(OOPSLA).

Jonas, E., Schleier-Smith, J., Sreekanti, V., Tsai, C.-C.,

Khandelwal, A., Pu, Q., Shankar, V., Menezes Car-

reira, J., Krauth, K., Yadwadkar, N., Gonzalez, J.,

Popa, R. A., Stoica, I., and Patterson, D. A. (2019).

Cloud programming simpliﬁed: A berkeley view on

serverless computing. Technical Report UCB/EECS-

2019-3, EECS Department, University of California,

Berkeley.

Kanso, A. and Youssef, A. (2017). Serverless: Beyond the

cloud. In Proceedings of the 2nd International Work-

shop on Serverless Computing, WoSC ’17, page 6–10,

New York, NY, USA. Association for Computing Ma-

chinery.

Kim, J. and Lee, K. (2019). Practical cloud workloads for

serverless faas. In Proceedings of the ACM Sympo-

sium on Cloud Computing, SoCC ’19, page 477, New

York, NY, USA. Association for Computing Machin-

ery.

Kim, Y. and Cha, G. (2018). Design of the cost effective

execution worker scheduling algorithm for faas plat-

form using two-step allocation and dynamic scaling.

In 2018 IEEE 8th International Symposium on Cloud

and Service Computing (SC2), pages 131–134.

KUBELESS (2019). Kubeless. https://kubeless.io/. Ac-

cessed on 21/11/2019.

Kuhlenkamp, J., Werner, S., Borges, M. C., Ernst, D., and

Wenzel, D. (2020). Benchmarking elasticity of faas

platforms as a foundation for objective-driven design

of serverless applications. In Proceedings of the 35th

Annual ACM Symposium on Applied Computing, SAC

’20, page 1576–1585, New York, NY, USA. Associa-

tion for Computing Machinery.

Nasr, . H. M. E. A. E. K. M. M. (2019). An adaptive tech-

nique for cost reduction in cloud data centre environ-

ment. International Journal of Grid and Utility Com-

puting, 10:448–464.

Nguyen, H. D., Zhang, C., Xiao, Z., and Chien, A. A.

(2019). Real-time serverless: Enabling applica-

tion performance guarantees. In Proceedings of the

5th International Workshop on Serverless Computing,

WOSC ’19, page 1–6, New York, NY, USA. Associa-

tion for Computing Machinery.

NODE.JS FOUNDATION (2019a). Node.js. https://nodejs.

org/en/. Accessed on 21/11/2019.

NODE.JS FOUNDATION (2019b). Process — node.js

v13.1.0 documentation. https://nodejs.org/api/

process.html. Accessed on 21/11/2019.

Oakes, E., Yang, L., Houck, K., Harter, T., Arpaci-Dusseau,

A. C., and Arpaci-Dusseau, R. H. (2017). Pipsqueak:

Lean lambdas with large libraries. In 2017 IEEE 37th

International Conference on Distributed Computing

Systems Workshops (ICDCSW), pages 395–400.

THE KNATIVE AUTHORS (2019). Knative. https://

knative.dev/. Accessed on 22/11/2019.

THE KUBERNETES AUTHORS (2019). Production-

grade container orchestraion - kubernetes. https://

kubernetes.io/. Accessed on 21/11/2019.

Villano, V. C. A. D. B. M. R. U. (2020). A methodology for

automated penetration testing of cloud applications.

International Journal of Grid and Utility Computing,,

11(2):267–277.

Winzinger, S. and Wirtz, G. (2019). Model-based analysis

of serverless applications. In Proceedings of the 11th

International Workshop on Modelling in Software En-

gineerings, MiSE ’19, page 82–88. IEEE Press.

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies
