Harnessing Hypermedia MAS and Microservices to Deliver Web Scale

Agent-based Simulations

Rem Collier

, Se

an Russell

and Fatemeh Golpayegani

School of Computer Science, University College Dublin, Ireland

Keywords:

Semantic Web, Hypermedia Systems, Agent-based Modelling, Microservices.

Abstract:

This paper presents a vision for a new breed of Agent-Based Simulations that are built on the technology of the

Web. Inspired by the emergence of the recently proposed Hypermedia Multi-Agent Systems concept - which

combines the concepts Hypermedia Systems, Semantic Web and Affordances - we propose a novel approach

to implementing complex agent-based simulations built from suites of loosely-coupled reusable components

in a manner that ensures scalability.

1 INTRODUCTION

Agent-Based Modelling (ABM) is a bottom-up ap-

proach to studying the behaviour of complex sys-

tems (Polhill et al., 2019) that has been successfully

applied in many domains, including: Logistics (Du

et al., 2019), Intelligent Transportation Systems (Gol-

payegani et al., 2018) and Power Systems (Teixeira

et al., 2020). Such systems are modelled as collec-

tions of agents; each one encapsulating private state

and behaviour. Global system behaviours emerge

through interactions between the constituent agents.

A key challenge in this area is the ability to

model systems of increasing complexity. It is ac-

knowledged that such systems are becoming too com-

plex to be captured in a single model (Kitova et al.,

2016). One solution is to use Hybrid Simulation (HS)

(Eldabi et al., 2018). Broadly, HS combine mul-

tiple interconnected sub-simulations, potentially im-

plemented using a diverse set of modelling techniques

(Mustafee et al., 2017). It is increasingly used in Op-

erational Research (Brailsford et al., 2019) and Socio-

Environmental Systems (Turner II et al., 2016).

The development of HS tools and methodologies

is still an open research problem. In (Polhill et al.,

2019), the authors highlight the lack of suitable tools

and frameworks for integrating ABM with other tech-

niques. Interoperability is a particular issue leading

to many existing HS being built using a single tool

https://orcid.org/0000-0003-0319-0797

https://orcid.org/0000-0003-1992-8303

https://orcid.org/0000-0002-3712-6550

(Eldabi et al., 2018).

This paper argues that HS should not be built on

monolithic architectures and homogeneous technol-

ogy stacks, but should instead be implemented as

loosely-coupled collections of reusable components,

written using diverse programming languages and

frameworks, that are designed to be deployed at scale.

In essence, it argues that HS should be implemented

using a microservices architecture (Fowler, 2014).

Section 3 presents a vision of a new framework for

implementing HS based on ABM, where each sub-

simulation is encapsulated as a microservice that uses

REpresentational State Transfer (REST) to serve sim-

ulation semantically enriched state representations.

The agent layer, which consumes this state, is imple-

mented as a Hypermedia MAS (Ciortea et al., 2019b).

Section 4 presents some challenges and opportunities

for further research, and section 5 presents some con-

cluding remarks.

2 THE CURRENT STATE OF

PLAY

There are a range of approaches to implementing

ABMs, and (Abar et al., 2017) provides an excel-

lent review of them. What is clear from the review

is that ABM has traditionally been viewed as a desk-

top computer style of exercise where tools are pro-

vided to support the creation and execution of mod-

els on a single machine. Such tools typically consist

of some mechanism to specify agent types and be-

404

Collier, R., Russell, S. and Golpayegani, F.

Harnessing Hypermedia MAS and Microservices to Deliver Web Scale Agent-based Simulations.

DOI: 10.5220/0010711100003058

In Proceedings of the 17th International Conference on Web Information Systems and Technologies (WEBIST 2021), pages 404-411

ISBN: 978-989-758-536-4; ISSN: 2184-3252

haviours, the environment(s) that the agent inhabits,

any constraints on interaction, and any rules for adap-

tation of behaviour. The main constraint on the use of

such tools to create simulations is often the time taken

for the simulation to be executed, which can lead to

repeated simpliﬁcations of the model until the execu-

tion time is acceptable (Taylor et al., 2020).

2.1 Simulating at Scale

Within the simulation community, two main ap-

proaches have emerged to overcoming the limits of

desktop simulation. The Distributed Simulation (DS)

community (Rashid et al., 2018) focuses on the devel-

opment of techniques that can be deployed on high-

performance computing clusters. This has led to the

development of tools, such as: RePAST HPC (Collier

and North, 2012) and MATSim (W Axhausen et al.,

2016). Taylor (Taylor, 2019) reviews DS through the

lens of Operational Research, highlighting the preva-

lence of bespoke implementations tailored to speciﬁc

scenarios, the lack of model reuse and the need for

well-designed frameworks.

A criticism of DS is the cost and availability of

computing clusters. This led to the emergence of

Cloud Based Simulation (CBS) (Taylor, 2019) which

is concerned with the deployment of simulations in

the cloud. Example ABM tools include: CloudSME

(Taylor et al., 2018), RISE (Al-Zoubi and Wainer,

2013) and Distributed Mason (Cordasco et al., 2018),

a port of Mason (Luke et al., 2004) for the cloud.

In (H

uning et al., 2016), the authors describe

MARS, a cloud-based ABM tool that uses a layered

model adapted from Geographical Information Sys-

tems, where each layer represents a distinct feature of

the simulation. It supports the distribution of models;

each layer is deployed as a separate node and individ-

ual layers can be distributed across multiple nodes.

More recently, the CBS community has started ex-

ploring the intersection of microservices and simula-

tion. Microservices are an architectural style that pro-

mote the decomposition of complex systems into dis-

tributed applications composed of simple services that

are designed to scale (Fowler, 2014; Zimmermann,

2017). In (Taylor et al., 2020), the authors introduce a

microservices framework for the creation of deadline

based simulations. Their prototype implemented an

auto-scaling mechanism that runs multiple REPAST

simulations in parallel to meet deadlines (Anagnos-

tou et al., 2019). This is achieved by modelling each

simulation as a microservice.

Finally, (Pump et al., 2019) describes the only

known project that has used microservices to create

a HS from heterogeneous models. However, as the

authors state, the developed model was bespoke and

tailored to the speciﬁc problem they were addressing.

The adoption of microservices in the design of

simulators is appealing for a number of reasons:

• they promote the development of small, loosely-

coupled systems that maintain their own indepen-

dent state (Dragoni et al., 2018);

• they are deployed within an ecosystem of tools

and components that facilitate rapid and agile de-

velopment techniques, are easy to extend and sup-

port automated management of fault tolerance and

scaling (Richards, 2015); and

• they support the integration of heterogeneous

systems built using diverse technology stacks

(Th

ones, 2015).

This is especially true of Hybrid Simulations, where

bounded context, isolation and loose coupling (Zim-

mermann, 2017) promotes the decomposition of sim-

ulators into discrete components that can be devel-

oped and deployed independently.

The decomposition of simulators into components

offers the potential for their reuse across multiple sce-

narios. Microservices facilitate this through the re-

quirement that all the components adhere to a uniform

interface, engendering the use of diverse technology

stacks. This presents a route towards the development

of hybrid simulations that combine not only different

programming languages and tool sets, but also inte-

grate different simulation techniques.

2.2 Simulating Intelligence

A recent survey on the use of the Belief-Desire-

Intention (BDI) architecture (Rao et al., 1995) in

social simulation (Adam and Gaudou, 2016) high-

lights the potential quality improvements that cogni-

tive architectures bring to simulation. They outline

an emerging trend in social simulation that argues for

the application of the ”Keep It Descriptive, Stupid”

(KIDS) principle over the ”Keep It Simple, Stupid”

(KISS) principle. Their argument is that, with in-

creased computing resources there is less need to use

simplistic agent models in an effort to maximise the

performance of the simulation. A better solution is

to use richer cognitive agent architectures to facilitate

the creation of more nuanced models.

Agent-Oriented Programming (AOP) languages

(Shoham, 1993) offer such rich architectures through

logic based programming constructs that are both

veriﬁable and explainable (Kravari and Bassiliades,

2015). Recently, there has been a resurgence of inter-

est in using AOP for simulation (B

adic

a et al., 2018b;

Lawlor et al., 2018; B

adic

a et al., 2018a; Balabanov

Harnessing Hypermedia MAS and Microservices to Deliver Web Scale Agent-based Simulations

405

et al., 2020). Other work has explored how to sup-

port discrete event simulation using AOP. In (Larsen,

2019a) the authors describe a simulator tool based

on GAMA (Taillandier et al., 2016) that is applied

to Hospital staff planning (Larsen, 2019b). In (Ricci

et al., 2020) an emerging simulation platform based

on JaCaMo (Boissier et al., 2013) is described. Fi-

nally, in (Muto et al., 2020) a Socio-Ecological Sys-

tems approach to modelling the agricultural econ-

omy of the Rancherina River Basin using the BESA

(Gonz

alez et al., 2003) agent toolkit is presented.

2.3 Affordances in Simulation

Recent research suggests that affordances may pro-

vide a more ﬂexible approach to ABM (Kl

ugl, 2015).

The concept of an affordance originates in ecological

psychology as a means of representing the relation-

ship between environmental objects and the potential

actions that an agent (human or otherwise) may per-

form with those objects (Gibson, 1979).

Affordances are information perceived from the

environment that signiﬁes that a particular action may

be performed. They allow for a higher level of ab-

straction in agent-environment interactions, allowing

an agent to reason about the actions it can perform

instead of having hard coded actions in plans.

The use of affordances in ABM parallels the

changing perception of agent-environment interaction

where the environment now viewed as an explicit part

of the MAS (Weyns et al., 2007). This view is be-

ing realised through systems such as EIS (Behrens

et al., 2012) and CArtAgO (Ricci et al., 2007), which

provide an abstraction of the environment that can be

used across agent platforms. CArtAgO has already

been used in simulations systems, JaCaMo-sim plat-

form (Ricci et al., 2020) is based on its use, and also

in combination with affordances in a Web of Things

environment (Ciortea et al., 2018b).

Affordances-effect pairs have been utilised in

modelling of human behaviour in complex environ-

ments (Jooa et al., 2013). Affordance ﬁelds have been

used to represent the suitability of potential actions

available to an agent at a given time in path planning

simulations (Kapadia et al., 2009). Affordances have

also been used in trafﬁc simulation (Ksontini et al.,

2015) and simulating the behaviour of tanks in a cap-

ture the ﬂag exercise (Papasimeon, 2010).

Each of these examples represents a bespoke im-

plementation of the concept of affordances in ABM,

each choosing how to represent affordances, how to

ﬁt them into the execution of the agent, and how to

represent them in the language. The beneﬁts of using

affordances in ABM can be greatly enhanced, or the

cost of implementation diminished, by the develop-

ment of a standard representation. This would enable

greater interoperability between agents and simula-

tion systems, between agents and environments, and

between simulation systems.

3 A NEW VISION FOR

SIMULATION AT SCALE

We believe there is a need for Hybrid Simulations that

can scale while being built from reusable components

that are designed for interoperability. The combina-

tion of techniques introduced in this paper represent

a potential pathway to achieving this. Our approach

is inspired by the successes achieved by leading tech-

nology companies, such as Netﬂix and Amazon, who

have met the challenge of deploying their infrastruc-

tures at Web Scale.

Underpinning their success is their adoption of the

microservices architecture (Fowler, 2014). As is high-

lighted in section 2.1, little research has been carried

out into the use of microservices in simulation. While

the approach we propose is focused on the application

of microservices to ABM, we believe that it can be

used to support the creation of simulations that com-

bine diverse modelling approaches.

3.1 Microservices and Simulation

In our view, microservices are ideally suited to the im-

plementation of Hybrid Simulations (HS). The map-

ping of microservices to sub-simulations is in keeping

with the ethos of the approach. In fact, as is discussed

in section 2.1, adopting a microservices perspective

brings a range of additional beneﬁts including mature

tool ecosystems and polyglot computing.

The notion of polyglot computing sits well with

HS as it is expected that such systems will be com-

posed of multiple sub-simulations implemented using

heterogeneous modelling techniques and languages.

However, it does not address how to engender interop-

erability between those sub-simulations. It is our view

that this can be achieved through the adaptation of the

way that Linked Data is currently used in the Web

of Things (WoT) (Guinard and Trifa, 2016). Broadly

speaking, Linked Data is an approach to realising Tim

Berners Lee’s vision of the Semantic Web (Berners-

Lee et al., 2001) through the creation of typed links.

These links are embedded within documents that rep-

resent data from different Web sources. Critically,

Linked Data supports machine readability through the

use of ontologies, encoded and interpreted using Se-

mantic Web technologies (Bizer et al., 2011).

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

406

Within the WoT, Linked Data has been used to

help develop a set of standards, known as Thing De-

scriptions (Charpenay and K

abisch, 2020). These

are machine readable documents that describe the

”things” that have been deployed. They describe the

capabilities of the devices, allowing clients to reason

about how (or whether) to use them. The availability

of such descriptions is driving research into a range

of ”thing” composition techniques, including: thing

discovery (Zhou et al., 2016), Web Mashups (Guinard

and Trifa, 2009), automated composition tools (Noura

and Gaedke, 2019) and even agent-based approaches

(Savaglio et al., 2020). Such descriptions can also be

used with manual composition tools.

Our vision is inspired by this view. We believe

that a Simulation Description that is analogous to

Thing Descriptions would promote interoperability

and reuse of sub-simulations. Such a description

could be used both to specify the nature of the en-

vironment as well as the inputs and outputs associ-

ated with it. The application of semantic meaning to

all data inputs and outputs related to each simulation

would allow for their integration into data processing

pipelines for tasks such as transforming data between

representations or handling (time) scaling issues.

3.2 Microservices and Agent-based

Simulation

In our view, there are two main ways in which ABM

can be integrated with the Hybrid Simulation frame-

work proposed above. One approach is to view them

simply as self-contained sub-simulations that are inte-

grated into larger simulations that are not agent-based.

While there are a number of challenges in achieving

this, it is not the focus of the vision we present in this

paper. In our view, such an approach can be realised

through existing simulation frameworks.

Instead, our vision is oriented towards a second

approach where ABM plays a key role in the overall

simulation. Here, the ABM acts as a central com-

ponent in which agents are linked with multiple sub-

simulations, developed using diverse simulation tech-

niques, whose state is consumed by the agents so that

they may more accurately model the behaviour of the

population they are simulating. Due to the poten-

tial complexity arising from processing multiple state

data streams, we believe that the simple agent mod-

els traditionally used in ABM will be inadequate and

more nuanced models are required. In our view, such

an approach is congruent with the ”Keep It Descrip-

tive, Stupid” principle described in (Adam and Gau-

dou, 2016). The authors use this principle to argue

that the social simulation community needs to adopt

BDI style models, tools and programming languages.

We agree with this sentiment and argue that it is

essential for managing the complexity emerging from

agents interacting with multiple sub-simulations as is

proposed within our vision. In our view, the best way

to deliver this is through the use of Hypermedia MAS.

In (Ciortea et al., 2018a), the authors introduce

the concept of Hypermedia MAS as an approach to

building dynamic, open and long-lived MAS (Vacht-

sevanou et al., 2020) that are designed to inter-operate

seamlessly with the World Wide Web. In (Ciortea

et al., 2019b), this approach is expanded by outlining

a vision in which agents are integrated into the hyper-

media fabric of the web, and that by doing so, enter

into a shared hypermedia environment that is based

on the open standards of the Web. In such an environ-

ment, devices and physical services can be exposed as

ﬁrst class entities. Hyperlinks and hypermedia con-

trols can be used to discover and interact with those

entities or even other agents regardless of their loca-

tion. Such controls can be published through hyper-

media documents that are adapted based on the state

of the underlying entities.

Through these hypermedia documents, agents are

able to discover at run-time the capabilities of the en-

tities in their environment. Presented appropriately,

such a document could be linked to the concept of af-

fordances as described in section 2.3 enabling them

to understand not just what the state of the entity is,

but also what they are currently able to do to that en-

tity. It is important to understand that the concept of

Thing Descriptions, as discussed in section 3.1 is an

example of just such a document.

As described earlier, our vision views ABM as the

integration point for multiple sub-simulations. This is

achieved by viewing the sub-simulations as being part

of the environment. The agents would then interact

with the sub-systems through an agent-environment

interface. In our approach, the environment would

be decomposed into a set of microservices and the

agents would interact via the APIs exposed by these

microservices. There are two possible integration

strategies to achieve this: the use of a single microser-

vice that acts as the intermediary between the agents

and the subsystems - in the microservices world, this

would be considered an API Gateway (Montesi and

Weber, 2016); and the direct integration of the agents

with multiple linked microservices.

We are especially interested in the latter approach

as we believe that it offers a more decentralised and

scalable solution. The view also has many parallels

with the recent work done on applying Hypermedia

MAS to the Web of Things (Ciortea et al., 2019a).

In their approach, the highlight the use of Thing De-

Harnessing Hypermedia MAS and Microservices to Deliver Web Scale Agent-based Simulations

407

scriptions as a means for describing interaction af-

fordances that can be used by the agent to under-

stand its options. We aim to mirror this approach

through the introduction of an Entity Description that

describes the interface between each sub-simulation

and the environment. Agents would use this to con-

ﬁgure themselves as they connect to a sub-simulation.

We term the interface deﬁned by the entity description

to be an Affordance API. Finally, the entity descrip-

tions should be linked to corresponding Simulation

Descriptions as deﬁned in section 3.1.

Mirroring the decomposition of the environment

into a set of microservices, we believe that the agents

should also be deployed across a set of microservices.

A possible solution for achieving this is Multi-Agent

MicroServices (MAMS) approach (Collier et al., 2019;

O’Neill et al., 2020), which has been demonstrated

in the ASTRA agent programming language (Collier

et al., 2015; Dhaon and Collier, 2014).

In summary, this section expands our vision for

a Hybrid Simulation framework to require the use

of Hypermedia MAS to implement the agent com-

ponent of an ABM. Inspired by recent work in the

area of WoT, the agents would interact with sub-

simulations, modelled as environment microservices,

using REST and Linked Data. As with the WoT,

agent-environment interactions are governed through

the use of interaction affordances.

3.3 Illustrating the Vision

To illustrate our vision, we present a sketch of a Hy-

brid Simulation of a shopping centre. The simulation,

whose architecture is presented in Figure 1 aims to

model the occupancy and transit of people through the

shopping centre.

PedSim

SimAPI

TrafSim

SimAPI

Weather

Sim

ShopSim

SimAPI

Sim

Manager

Internal

Aﬀordance

API

External

Aﬀordance

API

Figure 1: Representation of microservice-based Hyperme-

dia MAS Simulation.

As can be seen, the simulation consists of a num-

ber of sub-simulations. The three primary simulations

are: PedSim which models the arrival and departure

of pedestrians on foot; TrafSim which does the same

for pedestrians who travel by vehicle; and ShopSim,

which models the shopping center. The idea here, is

that PedSim and TrafSim act as sinks and sources

of agents (who model the population) that enter/leave

the shopping center (modelled as ShopSim). There

is no requirement that these ﬁrst two simulations be

agent-based; they could be statistical simulations, that

drive the creation of agents inside ShopSim, or they

could themselves be agent-based simulations. An im-

portant challenge to be resolved here, would be how

to support both types of simulation without requiring

any changes to ShopSim. For example, an interme-

diary component could be added that acts as an inter-

face to ShopSim, creating and destroying agents as

appropriate. These simulations themselves, could be

linked to other simulations, for example, in Figure 1,

all three are linked to a weather simulator.

The agent-based ShopSim simulator is itself de-

composed into two sub-simulations that cover the in-

ternal and external locations of the shopping centre

respectively. The shopping centre itself can be repre-

sented as a graph, with nodes being modelled as end-

point associated with the sub-simulations, and edges

modelled as hyperlinks between nodes. Depending

on the nature of the environment, these hyperlinks

could be either manipulated by the agents themselves,

or used internally by the simulations. For example,

an agent could transition from a corridor to a shop

by submitting a DELETE request to the corridor end-

point and a POST request to the shop endpoint. Alter-

natively, the agent submit an ”enterShop” action to the

corridor simulation resulting in the corridor simulator

transitioning the agent to the shop. Which approach

to use depends largely on the nature of the simula-

tion and whether or not the agent is embodied in the

environment. If the agent has a body, then we believe

that the latter approach is more appropriate as the rep-

resentation of the body would need to be transferred

from one simulation to the other. This brings more

challenges in terms of how to represent the body in

a way that does not limit interoperability, and how to

standardise transitioning agents between simulations.

Another challenge to be addressed is agent-

simulation interaction. Speciﬁcally, we are concerned

with how the agent is made aware of the actions it can

currently perform. As discussed in section 3.2, we be-

lieve this is best achieved through the implementation

of an Affordances API. Both approaches described in

the previous paragraph ﬁt this. For simulations where

the agent is disembodied, we envisage using equiv-

alents of the WoT Thing Description. Alternatively,

in cases where the agent is embodied, the body pro-

vides a context for the agent in the simulation. This

context can be used to identify the potential actions of

the agent, which in turn can be passed to the agent.

Finally, the sim manager is responsible for setting

up or managing the overall simulation. Interaction

with each sub-simulation is through the SimAPI.

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

408

4 CHALLENGES AND

OPPORTUNITIES

Realising the vision presented in this paper raises a

number of challenges that also present opportunities

for the Multi-Agent Systems community. Some of the

key challenges are described below:

Tools for Building Hypermedia MAS: Suitable

tools for building Hypermedia MAS do not currently

exist (Ciortea et al., 2019b). Such tools would need

to be hypermedia friendly and provide mechanisms

to allow agents to reason with and act on semantic

knowledge.

Deﬁning Ontologies for Describing Simulations:

The effective description of simulation components is

critical to enable their composition and reuse. Devel-

opment of a standardised suite of ontologies to sup-

port this is an essential community activity.

Exploring the Methods and Protocols Needed to

Deliver Hybrid Simulation: Before effective stan-

dards can emerge, there is a need to explore how

to combine simulation components: how component

connections should be presented to agents and how

an agent should migrate from one component to an-

other. It is concerned with the creation of the meth-

ods and protocols needed to allow agents to operate

seamlessly across them.

Building Simulations that Can Scale: Being able to

decompose a simulation into constituent microservice

is not enough. There is a need to understand how to do

this in a way that enables scalability. This challenge

is further complicated by the need to consider multi-

ple sub-simulations and the need for mechanisms that

can knit the individual sub-simulations into a larger

whole.

Reusability across Simulation Domains: Under-

standing how to make sub-simulations reusable across

problem domains is another key challenge. This re-

quires the development of standards for deﬁning sim-

ulations and techniques for composing them. Some

discussion on potential approaches is presented in

section 3.1.

5 CONCLUDING REMARKS

This paper presents a vision of a microservices-based

approach to implementing Hybrid Simulations that

include an ABM component that is underpinned by

the recently proposed notion of Hypermedia MAS. We

have illustrated our vision through a simple example

and outlined a number of challenges and opportuni-

ties for future research.

REFERENCES

Abar, S., Theodoropoulos, G. K., Lemarinier, P., and

O’Hare, G. M. (2017). Agent based modelling and

simulation tools: A review of the state-of-art software.

Computer Science Review, 24:13–33.

Adam, C. and Gaudou, B. (2016). Bdi agents in social sim-

ulations: a survey. The Knowledge Engineering Re-

view, 31(3):207–238.

Al-Zoubi, K. and Wainer, G. (2013). Rise: A general simu-

lation interoperability middleware container. Journal

of Parallel and Distributed Computing, 73(5).

Anagnostou, A., Taylor, S. J., Abubakar, N. T., Kiss, T.,

DesLauriers, J., Gesmier, G., Terstyanszky, G., Kac-

suk, P., and Kovacs, J. (2019). Towards a deadline-

based simulation experimentation framework using

micro-services auto-scaling approach. In 2019 Win-

ter Simulation Conference (WSC), pages 2749–2758.

adic

a, A., B

adic

a, C., Buligiu, I., and Ciora, L. (2018a).

Devs modeling and simulation using bdi agents: Pre-

liminary considerations. In Proceedings of the 8th In-

ternational Conference on Web Intelligence, Mining

and Semantics, pages 1–8.

adic

a, A., B

adic

a, C., Ivanovi

c, M., and D

anciulescu, D.

(2018b). Multi-agent modelling and simulation of

graph-based predator–prey dynamic systems: A bdi

approach. Expert Systems, 35(5):e12263.

Balabanov, K., Cejrowski, T., Logof

atu, D., and B

adic

C. (2020). Study on population dynamics for triple-

linked food chain using a simulation-based approach.

Evolving Systems, 11(2):215–226.

Behrens, T., Hindriks, K. V., Bordini, R. H., Braubach,

L., Dastani, M., Dix, J., H

ubner, J., and Pokahr, A.

(2012). An Interface for Agent-Environment Interac-

tion. In Collier, R., Dix, J., and Nov

ak, P., editors,

Programming Multi-Agent Systems, volume 6599 of

Lecture Notes in Computer Science, pages 139–158.

Springer Berlin Heidelberg.

Berners-Lee, T., Hendler, J., and Lassila, O. (2001). The

semantic web. Scientiﬁc american, 284(5):34–43.

Bizer, C., Heath, T., and Berners-Lee, T. (2011). Linked

data: The story so far. In Semantic services, inter-

operability and web applications: emerging concepts,

pages 205–227. IGI Global.

Boissier, O., Bordini, R. H., H

ubner, J. F., Ricci, A., and

Santi, A. (2013). Multi-agent oriented programming

with jacamo. Science of Computer Programming,

78(6):747–761.

Brailsford, S. C., Eldabi, T., Kunc, M., Mustafee, N., and

Osorio, A. F. (2019). Hybrid simulation modelling in

operational research: A state-of-the-art review. Euro-

pean Journal of Operational Research, 278(3).

Charpenay, V. and K

abisch, S. (2020). On modeling the

physical world as a collection of things: The w3c

thing description ontology. In European Semantic

Web Conference, pages 599–615. Springer.

Ciortea, A., Boissier, O., and Ricci, A. (2018a). Engineer-

ing world-wide multi-agent systems with hyperme-

dia. In International Workshop on Engineering Multi-

Agent Systems, pages 285–301. Springer.

Harnessing Hypermedia MAS and Microservices to Deliver Web Scale Agent-based Simulations

409

Ciortea, A., Mayer, S., Boissier, O., and Gandon, F.

(2019a). Exploiting Interaction Affordances: On

Engineering Autonomous Systems for the Web of

Things. In Second W3C Workshop on the Web of

Things The Open Web to Challenge IoT Fragmenta-

tion, Munich, Germany.

Ciortea, A., Mayer, S., Gandon, F., Boissier, O., Ricci, A.,

and Zimmermann, A. (2019b). A decade in hindsight:

the missing bridge between multi-agent systems and

the world wide web. In Proceedings of the Interna-

tional Conference on Autonomous Agents and Multia-

gent Systems.

Ciortea, A., Mayer, S., and Michahelles, F. (2018b). Repur-

posing Manufacturing Lines on the Fly with Multi-

Agent Systems for the Web of Things. In Proceedings

of the 17th International Conference on Autonomous

Agents and MultiAgent Systems, AAMAS ’18, pages

813–822, Richland, SC. International Foundation for

Autonomous Agents and Multiagent Systems.

Collier, N. and North, M. (2012). Repast hpc: A platform

for large-scale agent-based modeling. Large-Scale

Computing, 10:81–109.

Collier, R. W., O’Neill, E., Lillis, D., and O’Hare, G.

(2019). Mams: Multi-agent microservices. In Com-

panion Proceedings of The 2019 World Wide Web

Conference, pages 655–662.

Collier, R. W., Russell, S., and Lillis, D. (2015). Reﬂect-

ing on agent programming with agentspeak (l). In In-

ternational Conference on Principles and Practice of

Multi-Agent Systems, pages 351–366. Springer.

Cordasco, G., Scarano, V., and Spagnuolo, C. (2018). Dis-

tributed mason: A scalable distributed multi-agent

simulation environment. Simulation Modelling Prac-

tice and Theory, 89:15–34.

Dhaon, A. and Collier, R. W. (2014). Multiple inheritance in

agentspeak (l)-style programming languages. In Pro-

ceedings of the 4th International Workshop on Pro-

gramming based on Actors Agents & Decentralized

Control, pages 109–120.

Dragoni, N., Lanese, I., Larsen, S. T., Mazzara, M.,

Mustaﬁn, R., and Saﬁna, L. (2018). Microservices:

How to make your application scale. In Lecture

Notes in Computer Science (including subseries Lec-

ture Notes in Artiﬁcial Intelligence and Lecture Notes

in Bioinformatics).

Du, J., Jing, H., Choo, K.-K. R., Sugumaran, V., and Castro-

Lacouture, D. (2019). An ontology and multi-agent

based decision support framework for prefabricated

component supply chain. Information Systems Fron-

tiers, pages 1–19.

Eldabi, T., Brailsford, S., Djanatliev, A., Kunc, M.,

Mustafee, N., and Osorio, A. F. (2018). Hybrid sim-

ulation challenges and opportunities: a life-cycle ap-

proach. In 2018 Winter Simulation Conference (WSC),

pages 1500–1514. IEEE.

Fowler, M. (2014). MicroServices: A deﬁnition of this new

architectural term.

Gibson, J. J. (1979). The Ecological Approach to Visual

Perception. Houghton-Mifﬂin.

Golpayegani, F. et al. (2018). Co-ride: Collaborative

preference-based taxi-sharing and taxi-dispatch. In

2018 IEEE 30th International Conference on Tools

with Artiﬁcial Intelligence (ICTAI), pages 864–871.

IEEE.

Gonz

alez, E., Avila, J., and Bustacara, C. (2003). Besa:

Behavior-oriented, event-driven, social-based agent

framework. In PDPTA, volume 3, pages 1033–1039.

Guinard, D. and Trifa, V. (2009). Towards the web of things:

Web mashups for embedded devices. In Workshop on

Mashups, Enterprise Mashups and Lightweight Com-

position on the Web (MEM 2009), in proceedings of

WWW (International World Wide Web Conferences),

Madrid, Spain, volume 15, page 8.

Guinard, D. D. and Trifa, V. M. (2016). Building the web

of things, volume 3. Manning Publications Shelter Is-

land.

uning, C., Adebahr, M., Thiel-Clemen, T., Dalski, J.,

Lenfers, U., and Grundmann, L. (2016). Modeling &

simulation as a service with the massive multi-agent

system mars. In Proceedings of the Agent-Directed

Simulation Symposium, pages 1–8.

Jooa, J., Kimb, N., Wyskc, R. A., Rothrockd, L., Sone, Y.-

J., Ohb, Y.-g., and Leef, S. (2013). Agent-based sim-

ulation of affordance-based human behaviors in emer-

gency evacuation. Simulation Modelling Practice and

Theory, 32:99–115.

Kapadia, M., Singh, S., Hewlett, W., and Faloutsos, P.

(2009). Egocentric Affordance Fields in Pedestrian

Steering. In Proceedings of the 2009 Symposium on

Interactive 3D Graphics and Games, I3D ’09, pages

215–223, New York, NY, USA. Association for Com-

puting Machinery.

Kitova, O. V., Kolmakov, I. B., Dyakonova, L. P., Grishina,

O. A., Danko, T. P., and Sekerin, V. D. (2016). Hy-

brid intelligent system of forecasting of the socio-

economic development of the country. International

Journal of Applied Business and Economic Research,

14(9):5755–5766.

ugl, F. (2015). Affordance-Based Interaction Design

for Agent-Based Simulation Models. In Bulling,

N., editor, Multi-Agent Systems, pages 51–66, Cham.

Springer International Publishing.

Kravari, K. and Bassiliades, N. (2015). A survey of agent

platforms. Journal of Artiﬁcial Societies and Social

Simulation, 18(1):11.

Ksontini, F., Mandiau, R., Guessoum, Z., and Espi

e, S.

(2015). Affordance-based agent model for road traf-

ﬁc simulation. Autonomous Agents and Multi-Agent

Systems, 29(5):821–849.

Larsen, J. B. (2019a). Going beyond bdi for agent-based

simulation. Journal of Information and Telecommuni-

cation, 3(4):446–464.

Larsen, J. B. (2019b). Hospital Staff Planning with Multi-

Agent Goals. PhD thesis, Department of Applied

Mathematics and Computer Science, Technical Uni-

versity of Denmark.

Lawlor, F., Collier, R., and Nallur, V. (2018). Towards a pro-

grammable framework for agent game playing. arXiv

preprint arXiv:1807.08545.

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

410

Luke, S., Ciofﬁ-Revilla, C., Panait, L., and Sullivan, K.

(2004). Mason: A new multi-agent simulation toolkit.

In Proceedings of the 2004 swarmfest workshop, vol-

ume 8, pages 316–327. Michigan, USA.

Montesi, F. and Weber, J. (2016). Circuit breakers, discov-

ery, and api gateways in microservices. arXiv preprint

arXiv:1609.05830.

Mustafee, N., Brailsford, S., Djanatliev, A., Eldabi, T.,

Kunc, M., and Tolk, A. (2017). Purpose and beneﬁts

of hybrid simulation: contributing to the convergence

of its deﬁnition. In 2017 Winter Simulation Confer-

ence (WSC), pages 1631–1645. IEEE.

Muto, T. J., Bolivar, E. B., and Gonz

alez, E. (2020). Bdi

multi-agent based simulation model for social ecolog-

ical systems. In International Conference on Practi-

cal Applications of Agents and Multi-Agent Systems,

pages 279–288. Springer.

Noura, M. and Gaedke, M. (2019). Wotdl: web of things de-

scription language for automatic composition. In 2019

IEEE/WIC/ACM International Conference on Web In-

telligence (WI), pages 413–417. IEEE.

O’Neill, E., Lillis, D., O’Hare, G. M., and Collier, R. W.

(2020). Explicit modelling of resources for multi-

agent microservices using the cartago framework. In

Proceedings of the 19th International Conference on

Autonomous Agents and MultiAgent Systems.

Papasimeon, M. (2010). Modelling agent-environment in-

teraction in multi-agent simulations with affordances.

Phd, Defence Science and Technology Organisation,

Air Operations Division.

Polhill, J. G., Ge, J., Hare, M. P., Matthews, K. B., Gi-

mona, A., Salt, D., and Yeluripati, J. (2019). Crossing

the chasm: a ‘tube-map’for agent-based social simu-

lation of policy scenarios in spatially-distributed sys-

tems. GeoInformatica, 23(2):169–199.

Pump, R., Koschel, A., and Ahlers, V. (2019). Applying

microservices principles to simulation tools. In Ser-

vice Computation, 11th International Conference on

Advanced Service Computing.

Rao, A. S., Georgeff, M. P., et al. (1995). Bdi agents: from

theory to practice. In Icmas, volume 95.

Rashid, Z. N., Zebari, S. R., Sharif, K. H., and Jacksi, K.

(2018). Distributed cloud computing and distributed

parallel computing: A review. In 2018 International

Conference on Advanced Science and Engineering

(ICOASE), pages 167–172. IEEE.

Ricci, A., Croatti, A., Bordini, R., H

ubner, J., and Boissier,

O. (2020). Exploiting simulation for mas program-

ming and engineering-the jacamo-sim platform. In 8th

International Workshop on Engineering Multi-Agent

Systems (EMAS 2020).

Ricci, A., Viroli, M., and Omicini, A. (2007). CArtAgO:

A Framework for Prototyping Artifact-Based Envi-

ronments in MAS. In Weyns, D., Parunak, H., and

Michel, F., editors, Environments for Multi-Agent Sys-

tems III, volume 4389 of Lecture Notes in Computer

Science, pages 67–86. Springer Berlin Heidelberg.

Richards, M. (2015). Microservices vs. service-oriented ar-

chitecture. O’Reilly Media.

Savaglio, C., Ganzha, M., Paprzycki, M., B

adic

a, C.,

Ivanovi

c, M., and Fortino, G. (2020). Agent-

based internet of things: State-of-the-art and research

challenges. Future Generation Computer Systems,

102:1038–1053.

Shoham, Y. (1993). Agent-oriented programming. Artiﬁcial

intelligence, 60(1):51–92.

Taillandier, P., Bourgais, M., Caillou, P., Adam, C., and

Gaudou, B. (2016). A bdi agent architecture for the

gama modeling and simulation platform. In Interna-

tional Workshop on Multi-Agent Systems and Agent-

Based Simulation, pages 3–23. Springer.

Taylor, S., Anagnostou, A., Abubakar, N., Kiss, T., Deslau-

riers, J., Terstyanszky, G., Kacsuk, P., Kovacs, J., Kite,

S., Pattison, G., et al. (2020). Innovations in simula-

tion: Experiences with cloud-based simulation exper-

imentation. In Winter Simulation Conference 2020.

Taylor, S. J. (2019). Distributed simulation: state-of-the-

art and potential for operational research. European

Journal of Operational Research, 273(1):1–19.

Taylor, S. J., Kiss, T., Anagnostou, A., Terstyanszky, G.,

Kacsuk, P., Costes, J., and Fantini, N. (2018). The

CloudSME simulation platform and its applications:

A generic multi-cloud platform for developing and ex-

ecuting commercial cloud-based simulations. Future

Generation Computer Systems, 88:524–539.

Teixeira, B., Santos, G., Pinto, T., Vale, Z., and Corchado,

J. M. (2020). Application ontology for multi-agent

and web-services’ co-simulation in power and energy

systems. IEEE Access, 8:81129–81141.

ones, J. (2015). Microservices. IEEE software,

32(1):116–116.

Turner II, B., Esler, K. J., Bridgewater, P., Tewksbury, J.,

Sitas, N., Abrahams, B., Chapin III, F. S., Chowd-

hury, R. R., Christie, P., Diaz, S., et al. (2016). Socio-

environmental systems (ses) research: what have we

learned and how can we use this information in future

research programs. Current opinion in environmental

sustainability, 19:160–168.

Vachtsevanou, D., Junker, P., Ciortea, A., Mizutani, I., and

Mayer, S. (2020). Long-lived agents on the web: Con-

tinuous acquisition of behaviors in hypermedia envi-

ronments. In Companion Proceedings of the Web Con-

ference 2020, pages 185–189.

W Axhausen, K., Horni, A., and Nagel, K. (2016). The

multi-agent transport simulation MATSim. Ubiquity

Press.

Weyns, D., Omicini, A., and Odell, J. (2007). Environment

as a ﬁrst class abstraction in multiagent systems. Au-

tonomous Agents and Multi-Agent Systems, 14(1).

Zhou, Y., De, S., Wang, W., and Moessner, K. (2016).

Search techniques for the web of things: A taxonomy

and survey. Sensors, 16(5):600.

Zimmermann, O. (2017). Microservices tenets. Computer

Science-Research and Development, 32(3-4).

Harnessing Hypermedia MAS and Microservices to Deliver Web Scale Agent-based Simulations

411
