A Survey Study and Analysis of Task Scheduling Approaches for the

Major Computing Environments

Dalia Kamal A. A. Rizk

, Hoda M. Hosny

, El-Sayed M. El-Horbaty

and Abdel-Badeeh M. Salem

Faculty of Computer Science, The American University in Cairo, Egypt

Faculty of Computer & Info. Sciences, Ain Shams University, Egypt

Keywords: Task Scheduling, Cloud Computing, Grid Computing, Fog Computing, Workflow-based, Static Tasks,

Makespan.

Abstract: Nowadays, task scheduling is the central point of attraction with respect to cloud computing. Retrieve, store,

or compute /analyse data on the cloud are typical types of such tasks. Due to the huge amount of data that are

found on the cloud and the need for deep analysis and heavy computation; the importance of task scheduling

in an appropriate way for execution increases. In this paper, we present diverse types of algorithms for task

scheduling on different environments namely: cloud, grid, and fog under the two widely known types of task

representations (task-based and workflow-based).

1 INTRODUCTION

The infrastructure used to grow frameworks like

healthcare systems, should give high computing

ability, abundant capacity volume, and solid

communication with the goal that the task can be

completed within the time constraint (Sahoo et al.,

2018). Cloud computing is broadly utilized, joined

with the advantages of diminishing expense through

sharing computing and storage resources. Additional

benefits of cloud computing are found in its

reliability, security, and scalability features. The task

scheduling choice should ensure proficient utilization

of cloud infrastructure with least task execution cost

conceivable while guaranteeing the application's

quality of service (QoS) requirements. Different tasks

going to the cloud request a specific kind of Virtual

Machine (VM). Because of the idea of open settings

in the cloud computing, the needs for information

increase rapidly. Accordingly, this issue can be

addressed by appropriate usage of tasks alongside

accessible resources in order to minimize the required

time of execution (Nayak and Padhi, 2019). Most

algorithms developed to assign the suitable task to the

right resource are task dependent where the most

important feature about these scheduling algorithms

is to optimize resource utilization. The makespan is

the most used measuring factor for almost all

scheduling algorithms. It is the total time taken to

execute all tasks by the resources. Although, tasks are

divided into static or dynamic ones, most studied

algorithms dealt with the static tasks only.

Furthermore, algorithms could be executed on

different environments such as: cloud, grid, or fog

computing. Another important aspect that deals with

the scheduling process is that the tasks could be either

task-based or workflow-based.

Section 2 covers the surveyed task-based

representation approaches and associated algorithms.

Section 3 covers the surveyed workflow-based

representation approaches and their algorithms.

Section 4 presents our comparative analysis of the

surveyed approaches and section 5 concludes our

analysis results.

2 TASK-BASED

REPRESENTATION

APPROACHES

Task scheduling is an effective method to accomplish

a performance perfection of the cloud system. The

cloud scheduler should coordinate the heterogeneous

tasks to the best-fit VM instance which is picked

based on the goal of task scheduling like energy, cost,

or time minimization, etc (Sahoo et al., 2018). Task

priority or urgency strategy depends on the weight of

the task that has a remarkable ability for proficient

412

Rizk, D., Hosny, H., El-Horbaty, E. and Salem, A.

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments.

DOI: 10.5220/0010711300003058

In Proceedings of the 17th International Conference on Web Information Systems and Technologies (WEBIST 2021), pages 412-421

ISBN: 978-989-758-536-4; ISSN: 2184-3252

task scheduling and improved output of the system.

There are many strategies to assign a priority to a task

based on a selected algorithm. The following

subsections summarise some of the most widely used

algorithms under those strategies within the various

environments (Cloud, Grid, and Fog).

2.1 Cloud Computing

Task scheduling is an important way for enhancing

the performance of running applications on the cloud.

2.1.1 PCA (2015)

The authors (Al-Sammarraie et al., 2015) here are

presenting a schedule algorithm for enhancing the

usage of the resources along with providing

acceptable cost for the presented services. They

achieved their goal by giving priorities to the tasks

based on their profits. They took into consideration

two important factors of the cloud computing which

are the service performance and cost. Their literature

survey mentioned a lot of readings, but unfortunately,

they just wrote the reference numbers without further

explanation. The only explained algorithms in the

literature survey were for the ones they are going to

use later on for comparison. The proposed algorithm

is called the Performance and Cost Algorithm (PCA)

because it doesn’t only target the minimization of the

cost service for the user and the maximization of the

profit for the provider, but it also targets the

enhancement of the services completion time through

minimization and the resources consumption through

maximization. Therefore, the proposed algorithm

provides cost economical services along with high

performance by taking into account the completion

time as well as the cost-priority. This is accomplished

by optimizing the resource utilization and minimizing

the maksepan.

2.1.2 TS-GA (2016)

The authors (Hamad and Omara, 2016) of this

manuscript altered the way of execution of the

original Genetic Algorithm (GA) to present a new one

which minimizes the completion time and the cost of

tasks, while maximizes the resource utilization. They

introduced task scheduling as one of the resource

management topics where the algorithm should

consider the huge number of tasks versus the number

of available resources on one side, while on the other

side the point of interest issues to the Cloud user and

provider. Those interest issues could be completion

time and cost from the Cloud user’s side, and resource

utilization from the Cloud provider’s side. They

studied 8 different genetic algorithms that target

modifications in the original GA in order to achieve

better performance from the Cloud either user’s side

or provider’s side. According to the authors, task

scheduling is an optimization problem that has

different parameters as minimum makespan,

resources utilization, and minimum cost and it can be

solved by a heuristic algorithm.

The original Genetic Algorithm (GA) consists of

five steps whereas the proposed Tournament

Selection Genetic Algorithm (TS-GA) consists of six

steps. The TS-GA applies some modifications to the

original GA and introduces a new step which is “Keep

Best Solution”. This final step uses the new

population along with the old one. The first step of

the algorithm in the GA is the “Initial Population”:

which are all individuals that are used in the GA to

find out the ideal solution, then after some operations,

a new generation is developed based on specific

criteria used for the mating chromosomes. The same

step is proposed by the new TS-GA, but with defining

that the initial population is from a random generation

of binary encoding. The second step is the “Fitness

Function”: which is the motivation factor in the GA

as the individual survive or die based on its function

value. The TS-GA used the same step by showing the

method of computation to achieve a reduction in the

completion time for executing all tasks on the existing

resources. The third step in the original Genetic

algorithm is the “Selection”: which is the way to

choose the best chromosomes using different

strategies: roulette wheel, tournament selection,

Boltsmann strategy, or rank selection. The TS-GA

used the tournament selection strategy as its third step

in order to overcome the impediment of the

population size. “Crossover” is the fourth step and it

is the creation of new individuals through the

hybridization operation in the GA. In the proposed

TS-GA, they altered this step to include the parents of

the new individuals to the new population as new

children. The final step in the original GA is the

“Mutation”: which is the evolution operator that

diverse the gene values when a homogeneous state

occurs to the chromosomes. This final step is not

found in the proposed TS-GA; however, it is replaced

by two other steps: “Initialize Subpopulation” and

“Keep Best Solution”. The “Initialize Subpopulation”

is responsible to add the new generated population

after the crossover to the old parent population. While

the “Keep Best Solution” returns the solution chosen

during the crossover process back to the old

population presuming that it has been the satisfying

solution for the fitness function.

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments

413

The authors used the CloudSim toolkit to run their

experimental tests by comparing their proposed

algorithm results against the Round-Robin (RR) and

the original GA. They compared their results using

five parameters: completion time, cost, resource

utilization, speedup, and efficiency. Their results

showed a better performance for all five parameters

using their proposed algorithm.

2.1.3 Pricing Models (2016)

The authors (Ibrahim et al., 2016) presented an

enhancement algorithm to reduce the makespan and

the price of executing independent tasks. According

to the authors, they used the static scheduling as it

takes into account the pre-getting of the needed data

and the pipelining of the various phases of task

execution. Static scheduling also forces minimum

runtime overhead. The main target of their

enhancement algorithm was to allocate users’ tasks to

VMs based on processing power and taking into

consideration the price of the VMs. The authors used

Amazon EC2 and Google as their pricing models.

The authors first calculated the total processing

power for all existing virtual machines (VMs). Then

calculated the total processing power requested by the

tasks. Then the proposed algorithm designated for

each VM a partial amount of the total power

requested based on its power factor. Next, they

calculated the ratio between the needed power by the

allotted users’ tasks and the total processing power of

the available resources. Finally, the algorithm

calculated the execution time and the price of each

task per each VM.

The authors then explained their experimental

environment where they used the CloudSim simulator

to evaluate the proposed enhancement algorithm and

the other algorithms used for comparison. As a

Cloudlets benchmark, they used the formatted

workload generated by the High-Performance

Computing center HPC2N. They compared their

results against the default First Come First Services

(FCFS), the Genetic Algorithm (GA), and the Particle

Swarm Optimization (PSO). The results showed the

efficiency of the enhancement algorithm over other

algorithms by reducing makespan and decreasing the

price of the running tasks.

2.1.4 DPQ-PSO (2017)

The authors (Ben Alla et al., 2017) here proposed a

task scheduling algorithm based on Dynamic

Priority-Queue (DPQ). The proposed algorithm

guaranteed good performance along with task priority

and load balancing while improving the resource

utilization. The proposed DPQ is based on the

Analytic Hierarchy Process (AHP) and Particle

Swarm Optimization (PSO). The authors conducted

their survey over six previous researches that mainly

dealt with prioritization of tasks based on different

perspectives. Accordingly, they believed that an

appropriate task scheduling algorithm should consider

task prioritization depending on multiple criteria.

The authors’ main objectives for their proposed

algorithm were first to calculate the task prioritization

according to the various rules using the AHP. Then

communicate these tasks between dynamic Priority-

Queues according to the choice distribution and the

priority. Finally, the tasks should be scheduled

according to the meta-heuristic algorithm PSO. The

authors used the Analytic Hierarchy Process (AHP)

as it is the most common method for Multi-Criteria

Decision Making (MCDM). The importance of AHP

lies in its sub-dividing a problem into three levels:

objectives, attributes, and alternatives. Moreover,

they chose Particle Swarm Optimization (PSO) as

their meta-heuristic algorithm because they supposed

that it is the best choice against other optimization

algorithms for the sake of its easiness in

implementation and its capabilities of converging to

an acceptable solution.

The architecture of their system starts by

receiving tasks and storing them based on their arrival

time in the global queue. Then the AHP prioritize the

tasks and save them in the global priority queue based

on the objective, attributes, or alternative level. The

authors used: task length, waiting time, burst time,

and deadline as their criteria for the attributes level.

Then they used the Dynamic Priority-Queues

algorithm (DPQ) to classify the tasks using a quartile

method into the prioritize levels: low, medium, high.

These prioritized queues reach the scheduler and

according to the PSO module in the DPQ algorithm,

the queues are scheduled for appropriate VMs. The

usage of the PSO guaranteed the execution of tasks

with a minimum makespan and cost of resource

usage, while maximize the resource utilization.

The authors also used the CloudSim as their

evaluator platform for their proposed algorithm and

compared their makespan results to those of FCFS

and PSO alone. The proposed DPQ-PSO algorithm

showed better results in performance and in resource

utilization. This is due to the execution of the high

priority tasks first with high privilege from the VMs.

2.1.5 TCA (2018)

The authors (Sahoo et al., 2018) proposed a task

scheduling algorithm taking into consideration the

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

414

time and cost constraints. Accordingly, they proposed

two versions of their Time and Cost efficient (TCA)

scheduling algorithm. The first takes the best fit into

consideration while the second takes the first fit.

They presented a scheduling algorithm to

minimize both the execution cost and execution time

of a task. The Time and Cost efficient (TCA)

scheduling algorithm takes into consideration the

deadline constraint. They assumed that the cloud

consists of a number of VM where each is featured by

its speed and execution cost. They featured each task

by its arrival time, length or size, and deadline.

Accordingly, they considered the heterogeneity of

both the task and the VM during mapping each task

to an appropriate VM. The scheduler they proposed

consisted of a task priority calculator, a real-time

controller, and a resource allocator. On the arrival of

a new task, the scheduler starts by giving a priority

value to the task based on its deadline and the worst-

case execution time (WC ET). The following step is

to sort these tasks by their priority value. The real-

time controller then chooses which task can comply

with its time constraint or not. In the event that there

is no VM that can complete the task within its time

limit, the real-time controller notifies the resource

allocator to add new VMs. Finally, if the task’s time

limit can be met, at that point the resource allocator

appoints a suitable VM to the task. Therefore, the

real-time controller and the resource allocator

cooperate together to fulfil the task’s timing

prerequisite and afterwards diminish the execution

cost by passing on to the best fit VM.

The presented algorithm is divided into two parts:

the first computes for each task its priority value

through using a calculator module. Then all tasks are

sorted by their priority value in descending order. The

second part of the algorithm is composed of two for

loops nested inside each other; the first one is for each

task in the previous sorted list, the second for loop is

for each VM. Here, the start time, the execution time,

and the finish time are calculated per each VM. Then

for each VM, a check for whether the finish time is

less than or equal the deadline time is met or not. If it

is met, then a utility function is computed. This utility

function is used to choose the best VM from both time

and cost perspectives versus time only or cost only

algorithms. Otherwise, if the finish time of any VM is

not less than the deadline time of the task then a new

VM is added. Finally, a best fit VM is selected for the

current task and then the final combination is saved

in the schedule plan (SCH). Then a new task from the

sorted list is being introduced to be executed.

They examined the presented algorithm through

extensive simulations and experiments. They used 3

measuring factors: guarantee ratio (GR), average cost

(AC) and average execution time (AET) to show the

effectiveness of TCA over some existing

arrangements. The GR is the ratio of the total tasks

sustaining their deadline limits against the whole total

number of tasks. The AC is the average cost needed

to finish a task within the known constraints. Finally,

AET is the average execution time for the whole

system including all the tasks. In conclusion, the

offered algorithm showed best results for the 3

measuring factors against the other two compared

algorithms: Heterogeneous Earliest Finish Time

(HEFT) and the Cost Aware Algorithm (CAA) where

the HEFT depends on the earliest finish time only,

while the CAA depends on the execution time only.

2.1.6 Heuristic Approach (2018)

The authors (Gawali and Shinde, 2018) here are

presenting a hybrid algorithm as they combined five

different technologies to form the proposed heuristic

approach. The five used technologies are: the

“analytic hierarchy process (AHP)”, but they added

some modifications to it. The second and third

technologies used are the “bandwidth aware divisible

scheduling (BATS) + BAR optimization”, but

combined in one algorithm. The fourth technology

they introduced was the “longest expected processing

time preemption (LEPT)”. Finally, they used the

“divide-and-conquer method”. Their targeted

performance metrics which they measured were the

turnaround time and the response time. According to

the authors, the turnaround time is the duration of

time per each task from its submission to its

completion, yet the response time is the required time

to check the request against the readiness of the

resource. They used both the Cybershake and

Epigenomics scientific workflows as their testbeds.

The proposed system started by using the AHP to

arrange the tasks based on their length and their

runtime and then give ranks to these tasks; however,

the authors modified this segment by calculating new

ranks for the succeeding tasks to the current tasks at

the server. The following step in the proposed system

is to allocate the cloud computing resources mainly

the CPU, memory, and bandwidth by using the BATS

algorithm. However, they also modified this section

in order to choose the correct task to be executed next.

This modification was done by using the bar systems

algorithm (BAR) where they also used a bipartite

graph to help in the detection of the next task to be

executed. The third step in the proposed system is the

preemption methodology which is conducted through

the LEPT policy. This policy deals with checking the

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments

415

usage of a virtual machine when there is

accumulation of tasks on this VM, then a preemption

is required in order to redistribute the waiting tasks to

other virtual machines. The final stage in the

proposed system is the divide-and-conquer technique

which takes the waiting tasks in the previous step and

redistribute them among other VMs.

According to the authors, using this presented

heuristic approach, they covered both aspects of task

scheduling and resource allocation simultaneously.

They tested their system against the existing BATS

and IDEA frameworks using the Cybershake and

Epigenomics as their testbeds. The carried

assessments were to evaluate the turnaround time, the

response time, and the utilization of CPU, memory,

and bandwidth. The results of their proposed system

showed justifiable results than the existing BATS and

IDEA frameworks.

2.1.7 Mapping Independent Tasks (2019)

The authors (Nayak and Padhi, 2019) proposed an

algorithm which is intended to manage variable

length tasks by taking the upsides of the distinctive

heuristic algorithms and guarantees ideal task

scheduling with difference accessible resources to

upgrade the quality of the medical services

framework. According to the authors, they knew that

the transferred data in the case of cloud computing is

huge and to guarantee a better service of transferring,

there should be a suitable uninterrupted resource

scheduling algorithm. This procedure satisfies both

the managing of task load along with the dynamic

assignment of task while taking into account the non-

requirement features such as: availability, flexibility,

scalability, and the minimal cost. The scheduling

process begins when the user submits a task to the

scheduler. This task could be either inserting,

processing, or accessing data. Then the scheduler

plans the task to the available resource.

The authors listed with description the performance

metrics for effective load balancing, but they focused

on one specific metrics that they related it to their

algorithm which is the “Makespan (MS)”. It tends to

be characterized as the maximum time needed for the

system to go through the whole data center. It is

directly proportional to load balance; therefore, a less

makespan means a less load balance and this is a

significant quality of acceptable task scheduling

algorithm.

The authors discussed some different algorithms

such as the MinMin and the MaxMin who use the

completion time as their main criteria. The MinMin

algorithm is suitable for small/short tasks as they are

usually assigned to available resources based on the

minimum calculation of completion time. However,

large/long tasks are left unattended due to their long

completion time. On the other hand, MaxMin

algorithm is the opposite of MinMin where it fulfils

the large tasks at the favor of the small ones.

Their proposed algorithm is a mixture model in

order to overcome the starvation problem of the

MinMin and MaxMin algorithms. They execute their

algorithm based on the number of small tasks versus

the number of large tasks. If the number of small tasks

is more than the number of large tasks, then the large

tasks are assigned the resources first in order to

enhance the efficiency and manage the maximum

completion time. Whereas when the number of small

tasks is less than the number of large tasks, then the

small tasks are assigned the resources first in order to

improve the computing performance and to avoid

starvation.

2.2 Grid Computing

Grid systems which are one of the parallel computing

structures, require task scheduling as one of their

most important factors.

2.2.1 MMBLB (2015)

The authors (Daood et al., 2015) here are presenting

a task scheduling algorithm which is based on load

balancing. Their algorithm takes into consideration

that small tasks to be executed on slower resources

while the larger tasks be executed on the faster ones.

They achieve the load balancing of resources

utilization while reducing the total completion time.

According to the authors, the presented algorithm is

an extension to the Min-Min algorithm, and therefore,

they called it: Min-Min Based on Load Balancing

(MMBLB) algorithm. The proposed algorithm also,

changed the completion time matrix to be called:

Expected Sum Completed Time (ESCT).

The proposed algorithm consisted of two phases

where the first phase is the Min-Min algorithm, while

the second phase overcome the disadvantage of the

Min-Min which is improving the load balancing. The

Min-Min algorithm is firstly used to assign the small

tasks for execution on slower resources. Then the

second phase of the proposed algorithm is to

concurrently execute the large tasks on the fastest

resources. This improvement enhances the chance of

simultaneous execution of tasks on resources.

A new performance matrix (ESCT) is also being

introduced in this algorithm which is a modification

of the Expected Complete Time (ECT) matrix that is

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

416

being used by almost all scheduling algorithms. This

ESCT works on both increasing the load balance and

optimizing the makespan outputted from the Min-

Min algorithm. It also works on reducing the usage of

resources by using this ESCT instead of the ECT and

the Expected Execution Time (EET). According to

their outcomes which showed an optimization in the

makespan and an enhancement in the productivity

usage of resources. Consequently, this proved that

their development is producing better results than that

of using Min-Min algorithm alone.

2.3 Fog Computing

Although, Aladwani (Aladwani, 2019) presented a

chapter on a survey about the different task

scheduling algorithms for the cloud computing

environment, the author previously proposed to use

the fog computing especially for healthcare tasks. The

author presumed that there will be latency time during

the process of handling healthcare tasks over the

cloud. The proposed algorithm contains a new

method for Task Classification and Virtual Machines

Categorization (TCVC) based on tasks importance.

Aladwani, classified the tasks to high, medium, and

low important tasks based on the patient’s health

status. She referenced some of the advantages of fog

computing for the IoT applications to support the idea

of using the fog computing along with the healthcare

IoT applications. Moreover, she gave the tasks

scheduling algorithms the following definition: “a set

of rules and policies used to assign tasks to the

suitable resources (CPU, memory, and bandwidth) to

get the highest level possible of performance and

resources utilization”.

The literature review presented by Aladwani,

covered 4 reviews only regarding the tasks scheduling

algorithms in the fog computing. Aladwani, then

moved to the architecture of the healthcare system

where she introduced fog computing layer. She

referenced what each of the three layers

(Devices/Sensors Layer, Fog Computing Layer,

Cloud Computing Layer) consists of and how they

communicate with each other briefly.

Furthermore, in the motivation section of her

research, which was mainly about giving priority to

the tasks based on their importance instead of their

length. She believed that this means unfairness and

load unbalance to tasks that are of higher importance.

The algorithm, Aladwani presented to solve this

problem is to schedule the tasks after arrival into three

groups according to their importance. Then inside

each group, the tasks are resorted according to the

MAX-MIN scheduling algorithm. Finally, each

group of tasks is assigned to the appropriate VMs

group to be executed. According to the proposed

algorithm, the author assumed that the VMs should be

of different capabilities and performance.

Finally, the author showed the simulation that was

conducted on the CloudSim simulator of the proposed

algorithm and its output versus the output of the

MAX-MIN algorithm alone. The comparison

conducted by the author, showed that the proposed

TCVC scheduling algorithm is better than the MAX-

MIN scheduling algorithm alone with regards to the

Average Waiting Time (AWT), Average Execution

Time (AET), and Average Finish Time (AFT).

Unfortunately, Aladwani’s literature review

didn’t justify why fog computing is better than cloud

computing with IoT healthcare applications. It also,

didn’t mention from where or what was the reference

she used for the patient’s health status to accordingly

classify the tasks to high, medium, and low important

tasks. The proposed schedule algorithm classified the

tasks based on critical, important, and general tasks

without giving the reference health information.

Regarding the survey about the different task

scheduling algorithms for the cloud computing,

Aladwani (Aladwani, 2020) chose to work on three

major static algorithms. The three task scheduling

algorithms under investigation were: Fist Come First

Service (FCFS), Short Job First (SJF), and the MAX-

MIN. According to the author, the parameters used

for the measurement of their influence on different

tasks were: algorithm complexity, resource

availability, Total Waiting Time (TWT), Total

Execution Time (TET), and Total Finish Time (TFT).

The author believed that the biggest challenges in

cloud computing are task scheduling and load

balancing. She further divided the scheduling

algorithms into two levels: one at the host and the

other at the Virtual Machine (VM), but the author

focused on the VM level. Accordingly, the author

started mentioning the advantages of all task

scheduling algorithms, then explained how

algorithms work in the cloud computing environment

by being divided into three levels. Cloudlets is the

first level where it is the set of tasks that needs to be

executed, then mapping the different tasks to the

appropriate resources in order to highly utilize the

resource while maintaining a minimum makespan.

The last level in the task scheduling algorithms is the

set of VMs that are used for executing the Cloudlets

tasks which is furtherly divided into two steps that the

author referenced them.

Further on, the author started discussing the

advantages, the disadvantages, and the mechanism of

each of the surveyed algorithms (FCFS, SJF, MAX-

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments

417

MIN). The results for each task scheduling algorithm

are also given when using fifteen tasks against six

VMs with the assumption of different properties for

the VMs. The simulation of these tests was conducted

on the CloudSim simulator. Finally, a comparison for

the TWT and TFT only for the three static task

scheduling algorithms was conducted.

However, throughout the chapter, the calculations

given never showed any values to the parameters:

algorithm complexity, resource availability, and TET

which were mentioned earlier. Another concern in

this chapter, is when discussing the arrangement of

tasks per each VM in the FCFS algorithm. The author

represented the tasks to the VMs differently in the

figure that discusses the “FCFS work mechanism”

from the table that discusses “waiting times of tasks

in FCFS”, where she swapped two tasks when waiting

for the VMs. Accordingly, there were some errors in

the calculations and even in the comparison table.

3 WORKFLOW-BASED

REPRESENTATION

APPORACHES

The following subsections summarise some of the

most widely used algorithms based on the workflow

representation.

3.1 ICTS

The authors (Amoon et al., 2018) proposed a

workflow-based scheduling algorithm for

applications to the virtual machines (VMs) in the

cloud computing environment. The proposed

algorithm is divided into three parts: level sorting,

task prioritization, and then virtual machine selection.

They named the proposed algorithm as ICTS that

stands for Improved Cost Task Scheduling since their

target was to improve the schedule length and to save

the monetary cost simultaneously. They introduced

the directed acyclic graph (DAG) as the

representation used for the workflow in the cloud

computing. This DAG consists of nodes and edges.

They conducted a survey of eight previous researches

regarding the scheduling method in cloud computing.

Accordingly, they found that most of the scheduling

process targets the minimization of makespan while

not taking into consideration the monetary charges.

The algorithm architecture is based on cloud

clients presenting their workflow jobs to be executed

using the cloud interfaces, then these jobs are

subdivided into more basic tasks along with their

dependence. The subdivided jobs/ tasks act as nodes

in the DAG, while their dependence acts as the edges.

Then, the DAG is passed to the Scheduler which is

responsible to assign the tasks to the appropriate

virtual machines to complete the execution process. It

is worth mentioning that the cloud customers pay

according to either the number of used VMs and their

types or the number of needed CPU cycles. The

authors used here the second type which is the

number of needed CPU cycles. Therefore, the authors

believed that their algorithm has faced a major

challenge which is solving the competition between

minimizing the time cost while at the same time

minimizing the monetary costs.

The algorithm is divided into three stages; the first

stage is the level sorting which is conducted through

traversing the DAG from top to bottom grouping

tasks into levels based on their dependency, and then

sorting these levels. The second stage is that for each

level; the tasks are ranked through a computed

equation then sorted in a new task list based on their

decreasing order of ranks. The final stage is that of

VM selection, which is conducted through calculating

the Makespan-on-Cost Ratio (MKCR) for each task

per each virtual machine. Finally, the VM with the

largest MKCR gets its related task. According to the

authors, this arrangement attempts to profit from the

idle time slots between scheduled tasks per each VM

to limit the finish time of a DAG. The authors also

defined the “time complexity” to be the time needed

to appoint each task to a particular VM based on a

special priority.

In conclusion, the authors presented their

evaluation of the proposed algorithm through the

makespan and the monetary costs metrics. They

normalized these metrics through calculated equations

to get the schedule length ratio (SLR) and the monetary

cost ratio (MCR) respectively. They used random

generated number of tasks that ranged from 80 to 400

tasks per a DAG. They compared their performance

results to that of the Hybrid algorithm. As a result, the

ICTS proposed algorithm showed better results for

both SLR and MCR over the different number of

ranges of tasks than the Hybrid algorithm. Their

justification was because the ICTS when calculating

the rank of any task took into account both the

correspondence times between the parent tasks and this

task in addition to the correspondence times between

the same task and its successors. Accordingly, the most

complex tasks in the DAG will be sorted at the top of

the ranked list in the ICTS and thus processed first. On

the other hand, in the Hybrid algorithm, the calculation

of the task’s rank was only for the correspondence

times between a task and its successors only.

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

418

3.2 NMMWS

This paper (Gupta et al., 2018) dealt with generating

a schedule plan for mapping tasks of a workflow to

active virtual machines on a cloud server while

achieving their two goals: minimize the makespan

and maximize the average cloud utilization. The

proposed algorithm used the min-max normalization,

then calculated a dynamic threshold for the

assignment of tasks to virtual machines (VMs). The

workflows they used are of course represented by a

directed acyclic graph (DAG) where the nodes

represent the tasks and the edges represent the data

dependency. The authors stated that: “The problem of

workflow scheduling in cloud computing is to map

each task to a suitable VM and to schedule the tasks

for their execution.” Accordingly, they did an

extensive survey regarding diverse aspects such as:

different scheduling algorithms either for

independent tasks or for workflow applications, least

makespan and maximum cloud resource utilization,

cost optimality, minimum energy consumption, or

maximum reliability. Since the authors used the

workflows scheduling then they used the

communication-to-computation ratio (CCR) value in

order to categorize the workflows into data-intensive

and/or compute-intensive. The lower the CCR, then

the workflow is a compute-intensive; the higher the

CCR, then it is a data-intensive.

The authors used performance parameters for

evaluating the effectiveness of the proposed

algorithm against the other existing algorithms. The

definitions given by the authors for these parameters;

the makespan (MS) and the average cloud utilization

(CU), are as follows:

Makespan (MS): is the complete processing time

of a workflow application.

Average Cloud Utilization (CU): is the average

utilization of all installed VMs on a single cloud

server where the utilization of the VMs is the time

consumption rate of any VM relating to the cloud

server.

The algorithm presumably consisted of the

following “actors”:

1. Workflow manager: who receives a workflow,

then splits it into separate tasks to be

forwarded to the “Global Cloud Manager”.

2. Global cloud manager: acts as the cloud

scheduler which receives the tasks and starts

scheduling them to the VMs.

3. VM manager: is responsible for creating and

deleting VMs.

The authors used matrices to represent the Data

Transfer Time (DTT) and the Estimated Computation

Time (ECT). For the DTT, they used the upper

triangular matrix to represent the time for data

transfer between task nodes. The assumption they did

regarding the DTT was that for any two VMs

belonging to the same cloud server, the DTT is

negligible. For the ECT, which is the execution time

taken per each task on the different VMs can be

calculated through using any estimation routine

technique. Although the authors referenced two types

of these routine techniques, but unfortunately, they

didn’t mention which one they used for their

calculation. Other assumptions taken by the authors

were that the runtime of the tasks should be known

prior, a task per each VM at a particular time, and no

stopping for any task once allocated to a VM.

The main algorithm calls three different sub-

algorithms. The first module of the proposed

workflow scheduling algorithm is the min-max

normalization of the estimated computation time

(ECT) for all tasks. The second sub-algorithm is

responsible for the computation of the Earliest Finish

time (EFT). Then the last module uses the dynamic

threshold value for dividing the tasks in the ready

queue into small and large batches. These batches are

assigned to the VMs in the main algorithm as their

final step. The authors did a profound simulation on

various benchmarks: scientific or real-life workflows

such as: Cybershake, Epigenomic, Inspiral, Sipht, and

Montage. The results of the simulation were

compared against four well-known algorithms

namely: heterogeneous earliest finish time (HEFT),

dynamic level scheduling (DLS), Min-Min, and Max-

Min. According to the results, they reported from the

simulation of the proposed algorithm NMMWS

against the others, it was shown that the NMMWS is

providing far better results for both the makespan and

the average cloud utilization. Finally, the authors did

another hypothetical test using the statistical ANOVA

for validating the results which also showed

remarkable results for their proposed NMMWS.

4 COMPARATIVE ANALYSIS

All the aforementioned scheduling algorithms dealt

with how to arrange tasks for execution in the

different computing environments. Table 1

summarises our comparative analysis of the

characteristics of each approach and its points of

strength.

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments

419

Table 1: Comparison between the studied task scheduling algorithms under the studied approaches.

roach Reference Characteristics Points of Stren

PCA

(AL-Sammarraie

et al., 2015)

The proposed algorithm works on

optimizing the resource utilization as well

as minimizing the maksepan.

Their results of applying the algorithm

and comparing them with previous known

algorithms showed better performance in

makespan and resource utilization.

TS-GA

(Hamad and

Omara, 2016)

The proposed algorithm is a modification

to the original Genetic Algorithm (GA).

The algorithm also contains a new step:

“Keep Best Solution” which uses the new

opulation solution along with the old one.

The results of their proposed algorithm

showed a minimization of completion time

and cost of tasks, and maximization of

resource utilization at the same time.

Pricing

Models

(Ibrahim et al.,

2016)

It deals with the processing power of

virtual machines versus the processing

power required by the users’ tasks as well

as makespan and cost.

They gave evidence of the success of their

novice calculation of the processing power

in addition to the makespan and cost

reduction effectiveness.

DPQ-PSO

(Ben Alla et al.,

2017)

The proposed algorithm is a task

scheduling algorithm which guarantees

good performance while taking into

consideration task priority and load

balancing which together improved the

resource utilization.

Application of the Priority of tasks and

appropriate scheduling while achieving a

minimum makespan and cost of resource

usage and maximum resource utilization.

TCA

(Sahoo et al.,

2018)

Two algorithms: best fit and first fit. The

features required for each task were:

arrival time, length / size, deadline. The

proposed algorithm consists of: task

priority calculator, a real-time controller,

and a resource allocator.

The algorithm considers both the

execution time and the execution cost of a

task. The utilization function chooses the

best fit VM per each task.

Heuristic

Approach

(Gawali and

Shinde, 2018)

The proposed algorithm is a hybrid one

which consists of five technologies

namely: AHP (

Analytic Hierarchy

Process), BATS + Bar, LEPT (Longest

Expected Processing Time), and

“divide -an

-con

uer method”

The compared values for the turnaround

time, the response time, and the utilization

of CPU, memory, and bandwidth showed

major progress as promised.

Mapping

In-dependent

Tasks

(Nayak and

Padhi, 2019)

The proposed algorithm’s target is to

manage tasks based on their variable

length. The claim is that the algorithm

guarantees ideal task scheduling with

difference accessible resources.

The mixture of MinMin and MaxMin

showed higher performance of the overall

system based on Makespan.

MMBLB

(Daood et al.,

2015)

The proposed algorithm addresses the

deficiency of the Min-Min algorithm. It

works on both small and large tasks

simultaneously. They also introduced a

new performance matrix (ESCT).

The proposed algorithm tried to overcome

the weak point in the original Min-Min

algorithm by giving the large tasks

concurrent time as the small tasks and

hence achieves lower makespan.

TCVC

(Aladwani,

2019)

The proposed algorithm uses the Fog

computing instead of Cloud computing.

The algorithm sorted the tasks based on

their importance instead of their length.

Using the CloudSim simulator the results

showed lower Average Waiting Time

(AWT), Average Execution Time (AET),

and Average Finish Time (AFT) from the

output of the proposed algorithm

compared to the MaxMin algorithm.

ICTS

(Amoon et al.,

2018)

It is a workflow scheduling algorithm

which is divided into: level sorting, task

prioritization, and virtual machine

selection.

The proposed algorithm took into account

both the makespan and the monetary costs

metrics and showed improved results in

oth measurements.

NMMWS

(Gupta et al.,

2018)

It is a workflow scheduling algorithm

where they first used the min-max

normalization. Then a dynamic threshold

is calculated for the assignment of tasks to

the virtual machines.

The communication-to-computation ratio

(CCR) value used to categorize the

workflows. The proposed algorithm

showed better

results for both the

makespan and average cloud utilization.

WEBIST 2021 - 17th International Conference on Web Information Systems and Technologies

420

5 CONCLUSION

In this survey, we tried to present and compare the

most widely applied types of static task related

scheduling algorithms under the different

environments: cloud, grid, and fog. We showed the

different representations of tasks under the task-based

and workflow-based approaches. Based on this

analysis, we found that the most effective

measurement factors are: optimization (resource

utilization), makespan, and cost. Other measurement

indicators could be load balancing, processing power,

ESCT, and CCR. The algorithms which paid more

attention to those measurement factors are: TS-GA,

DPQ-PSO, and TCA. Of course, other algorithms

consider either one or more of these factors, but not

all the three factors together. Another important issue

that was noticed through this analysis is that some

algorithms prefer to do task prioritization based on

different aspects. Some use the length of the task such

as the DPQ-PSO and Heuristic Approach algorithms.

Others use the importance of tasks such as TCVC and

ICTS whereas ICTS uses a specific computed

equation to rank the tasks. Another algorithm, the

TCA uses the deadline and the WC ET as their

reference for the prioritization of tasks. The aim of the

above comparison is not to give any ranking to the

methods, but rather to help the developers select the

most suitable algorithm for their appropriate

requirements and needs. Hence, based on the

developer’s preference of the factors’ priority, the

most relevant approach and associated algorithm

would be selected. For example, if resource

utilization is of highest preference, then the task-

based approach may be selected with the PCA

algorithm. Whereas if all three measurement factors

are required with equal priority, then the task-based

approach along with any of the three algorithms

(TS-GA, DPQ-PSO, and TCA) may be applied.

REFERENCES

Aladwani, T. (2019). Scheduling IoT Healthcare Tasks in

Fog Computing Based on their Importance. 16th

International Learning & Technology Conference, 560-

569.

Aladwani, T. (2020). Types of Task Scheduling Algorithms

in Cloud Computing Environment. Chapter at

IntechOpen: 10.5772/intechopen.86873.

AL-Sammarraie, N., Al-Rahmawy, M., Rashad, M. (2015).

A Scheduling Algorithm to Enhance the Performance

and the Cost of Cloud Services. International Journal

of Intelligent Computing and Information Sciences,

15(1), 1-14.

Amoon, M., El-Bahnasawy, N., ElKazaz, M. (2018). An

efficient cost-based algorithm for scheduling workflow

tasks in cloud computing system. Neural Computing

and Applications, 31, 1353- 1363.

Ben Alla, H., Ben Alla, S., Ezzati, A., Touhafi, A. (2017).

An Efficient Dynamic Priority-Queue Algorithm Based

on AHP and PSO for Task Scheduling in Cloud

Computing. Proceedings of the 16th International

Conference on Hybrid Intelligent Systems (pp. 134-

143).

Daood, J., Abuelenin, S., Elmougy, S. (2015). Enhanced

Min-Min Task Scheduling Algorithm Based on Load

Balancing in Grid Computing. International Journal of

Intelligent Computing and Information Sciences, 15(2),

15-29.

Gawali, M., Shinde, S. (2018). Task Scheduling and

Resource Allocation in Cloud Computing Using a

Heuristic Approach. Journal of Cloud Computing:

Advances, Systems and Applications, 7(4), 1-16.

Gupta, I., Kumar, M., Jana, P. (2018). Efficient Workflow

Scheduling Algorithm for Cloud Computing System: A

Dynamic Priority-Based Approach. Arabia Journal for

Science and Engineering, 43, 7945-7960.

Hamad, S., Omara, F. (2016). Genetic-Based Task

Scheduling Algorithm in Cloud Computing

Environment. International Journal of Advanced

Computer Science and Applications, 7(4), 550-556.

Ibrahim, E., El-Bahnasawy, N., Omara, F. (2016). Task

Scheduling Algorithm in Cloud Computing

Environment Based on Cloud Pricing Models. World

Symposium on Computer Applications & Research (pp.

65-71).

Nayak, B., Padhi, S. (2019). Mapping of Independent Tasks

in the Cloud Computing Environment. International

Journal of Advanced Computer Science and

Applications, 10(8), 314-318.

Sahoo, S., Sahu, S., Rath, T., Sahoo, B., Turuk, A. (2018).

TCA: A Multi Constraint Real-Time Task Scheduling

Algorithm for Heterogeneous Cloud Environment.

International Conference on Information Technology

(pp. 132-136).

A Survey Study and Analysis of Task Scheduling Approaches for the Major Computing Environments

421
