Implementing Post-quantum Cryptography for Developers

Julius Hekkala

1 a

, Kimmo Halunen

2, 3 b

and Visa Vallivaara

1 c

VTT Technical Research Centre of Finland, Kaitov

ayl

a 1, Oulu, Finland

University of Oulu, Faculty of Information Technology and Electrical Engineering, Oulu, Finland

National Defence University, Department of Military Technology, Helsinki, Finland

Keywords:

Post-quantum Cryptography, Lattice Cryptography, C++, Programming Library.

Abstract:

The possibility of a quantum computer threatens modern public key cryptography. Post-quantum

cryptographic algorithms are designed to protect sensitive data and communications also against an attacker

equipped with a quantum computer. National Institute of Standards and Technology is standardizing post-

quantum algorithms that could replace currently used public key cryptographic algorithms in key exchange and

digital signatures. Lattice-based cryptography is one of the post-quantum algorithm groups with the biggest

potential. Cryptography libraries are used by developers in all kinds of different solutions, but currently the

availability of post-quantum algorithms in open-source libraries is very limited. Implementing post-quantum

algorithms into a software library involves a multitude of challenges. We integrated three lattice-based post-

quantum algorithms into a fork of Crypto++, a C++ cryptography library. We analyzed challenges in the

implementation process and the performance and security of the fork. Especially the complex mathematical

ideas behind the algorithms make implementation difﬁcult. The performance of the algorithms was satisfactory

but analyzing the security of the implementation in more detail is needed.

1 INTRODUCTION

In the modern information society, the security of

communications and data is essential. The people

need to be able to trust that their sensitive data

remains secure in the future. Cryptography is used to

prevent adversaries from accessing this information.

Public key cryptography is commonly used to create

secure connections, e.g. in TLS (Rescorla, 2018), and

to digitally sign documents.

Public key cryptographic algorithms are often

based on mathematical problems that are thought to

be hard to solve. The most notable example of a

public key cryptographic algorithm is RSA (Rivest

et al., 1978), which is based on factoring large

numbers produced by two prime numbers. Another

very commonly used group of algorithms, elliptic

curve cryptography (ECC) (Hankerson et al., 2006),

draws their security from discrete logarithms.

Both of these problems are difﬁcult for modern

computers, and it is easy to answer the increase

of computer performance by increasing key sizes.

https://orcid.org/0000-0002-7558-9687

https://orcid.org/0000-0003-1169-5920

https://orcid.org/0000-0002-9638-244X

Quantum computers, on the other hand, can solve

these problems much quicker. Shor’s algorithm

can be used to solve factoring (Shor, 1997) and

discrete logarithm problems (Proos and Zalka, 2003)

in polynomial time.

If a powerful enough quantum computer is

built, the communications and data secured by

conventional means are no longer secure. Because

it is possible that in the future the attackers will

have quantum computers, it is important to prepare

well in advance. For this purpose, post-quantum

cryptographic algorithms are designed. They

use mathematical problems that are difﬁcult for

classical as well as quantum computers. Different

standardization authorities have started standardizing

post-quantum algorithms, e.g. NIST has an ongoing

process standardizing post-quantum algorithms for

key encapsulation methods (KEM) (Shoup, 2001) and

digital signatures.

Implementing cryptography correctly is difﬁcult.

There are many possible mistakes that can be made

when designing and implementing cryptosystems,

which can then lead to the security of the

https://csrc.nist.gov/projects/post-quantum-

cryptography

Hekkala, J., Halunen, K. and Vallivaara, V.

Implementing Post-quantum Cryptography for Developers.

DOI: 10.5220/0010786200003120

In Proceedings of the 8th International Conference on Information Systems Security and Privacy (ICISSP 2022), pages 73-83

ISBN: 978-989-758-553-1; ISSN: 2184-4356

whole program faltering. That is why most

programs use speciﬁc cryptographic libraries that

were implemented by experts instead of programming

the cryptographic functionality from scratch every

time.

These libraries include interfaces that make

it easier to incorporate cryptography in different

programs, and ideally prevent the misuse of the

cryptographic primitives. A clear drawback is that

the algorithms available for use are the ones that

are implemented in the library. At this time, many

of the most prominent open-source cryptographic

libraries do not offer any post-quantum algorithms.

On the other hand, developers are accustomed to

using certain libraries. Thus it is not very easy

for developers to use post-quantum algorithms in

their programs. For example, the current version

of OpenSSL

does not include any post-quantum

algorithms that are part of the NIST standardization

process.

In this paper we present experiences and ﬁndings

on implementing post-quantum cryptographic

primitives in a programming language library. We

also evaluate the performance of the implemented

primitives. The paper is organized as follows.

The second chapter shines light on post-quantum

cryptography and different post-quantum algorithms.

Then we detail the background of implementing

post-quantum algorithms in cryptographic libraries.

In fourth chapter, we present our work. Fifth

chapter showcases the results and analysis. In the

sixth chapter we discuss the results as well as any

observations made during the integration process.

Finally, seventh chapter concludes this paper.

2 BACKGROUND

Public key cryptography is an essential enabling

component in the modern information society.

It allows parties to exchange keys to securely

communicate using encrypted trafﬁc in protocols

like TLS, and allows others to verify that a digital

signature is valid and no changes have been made to

the signed document afterwards.

Quantum computers are able to compute some

tasks more efﬁciently than the classical computers.

Grover’s algorithm (Grover, 1996) makes the brute-

force attack against cryptographic algorithms faster.

This effect can be negated quite easily by doubling

used key sizes in algorithms. This affects all possible

algorithms, but public key algorithms are particularly

https://www.openssl.org

threatened by the quantum algorithms.

Most public key algorithms are based on

mathematical problems that are deemed hard to solve

with a classical computer. These hard problems

include factoring and discrete logarithms. While

there are no known algorithms for classical computers

that would solve them efﬁciently, there are quantum

algorithms that solve them in polynomial time, most

notably Shor’s algorithm (Shor, 1997).

Currently there is no quantum computer powerful

enough that it would break the modern cryptographic

algorithms. Breaking 1024 bit RSA would require

about 2000 qubits, while breaking 160 bit ECC would

require about 1000 qubits (Proos and Zalka, 2003).

Google reported to have built a 53 qubit quantum

computer in 2019 (Arute et al., 2019). Very recently

IBM announced that they have developed a 127 qubit

quantum processor (Chow et al., 2021). Breaking the

algorithms is still quite far away, but if somebody is

able to develop a quantum computer with the required

amount of qubits, the currently common public key

cryptographic algorithms like RSA and ECC will be

vulnerable. Then adversaries will be able to decrypt

any new and also some old encryptions of data.

When the ﬁrst quantum computer is available for

malicious adversaries, any data or communication

also sent before that might become vulnerable, as

perfect forward secrecy is not present everywhere,

e.g. older versions of TLS support ciphers without

forward secrecy. That is why it is important to prepare

for that possibility already.

2.1 Post-quantum Cryptography and

Standardization

Post-quantum cryptography contains algorithms that

run on classical computers but are speciﬁcally

designed in a way that makes them resistant against

attacks with both classical and quantum computers.

There is a multitude of different types of post-

quantum algorithms that are based on different

mathematical problems. Some of the algorithms are

based on coding theory, multivariate polynomials and

hashing. In this paper, we concentrate on lattice-based

post-quantum algorithms.

During the last years, different standardization

authorities have started making ofﬁcial standards for

post-quantum algorithms. NIST (National Institute of

Standards and Technology) started a standardization

process in 2017, and it is currently in the third

round. Anyone was able to submit an algorithm to

the process at the start, and from those submissions,

the ﬁrst round candidates for standardization were

chosen. Each round, when the candidates were

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

published, researchers had chance to try to ﬁnd any

weaknesses in the algorithms. Also, the submitters

were able to make improvements based on the

ﬁndings. At the end of each round, the amount of

algorithms that are candidates for standardization got

smaller.

The NIST post-quantum cryptography

standardization process involves two types of

algorithms - key encapsulation mechanism (KEM)

algorithms and digital signature algorithms. KEM

algorithms are meant to replace public key algorithms

used especially for key exchange, e.g. in TLS. They

consist of three separate parts: a key generation

algorithm, an encryption (encapsulation) algorithm,

and a decryption (decapsulation) algorithm (Shoup,

2001).

At the time of writing this, there are four KEM

algorithms and three digital signature algorithms

among the ﬁnalists, all presented in Table 1. The

KEM algorithms are Classic McEliece which is based

on Goppa codes and CRYSTALS-Kyber, NTRU and

SABER which are based on lattices. The digital

signature algorithms are CRYSTALS-Dilithium and

FALCON which are based on lattices and Rainbow

which is based on multivariate polynomials.

Table 1: The third round algorithms of the NIST post-

quantum cryptography standardization process.

Algorithm Mathematical Problem

Classic McEliece Goppa codes

CRYSTALS-Kyber Lattices

NTRU Lattices

SABER Lattices

CRYSTALS-Dilithium Lattices

FALCON Lattices

Rainbow Multivar. polynomials

2.2 Chosen Algorithms

In this paper, we present work performed with

three of the third round candidate algorithms in the

NIST standardization process. Two KEM algorithms

and one digital signature algorithm were integrated.

The chosen algorithms were CRYSTALS-Kyber (Bos

et al., 2018), SABER (D’Anvers et al., 2018) and

CRYSTALS-Dilithium (Ducas et al., 2018). All

three algorithms are based on lattice problems. The

foundation of lattice problems used in cryptography

is the Shortest Vector Problem (SVP). With some

conditions SVP is an NP-hard problem, i.e. it does not

have a deterministic solution that runs in polynomial

time (Regev and Rosen, 2006).

Regev (2005) presented a problem called LWE

(Learning with Errors) that is based on SVP. Different

variants of LWE have been introduced, e.g. Ring-

LWE (RLWE) and Module-LWE (MLWE). Kyber

and Dilithium base their security on MLWE. SABER

is based on the modular version of the Learning with

Rounding problem, which is different from LWE in

that it is deterministic.

The three algorithms are all potential standards

(Alagic et al., 2020). Since they all are based on

lattice problems, comparison between the algorithms

is more meaningful. Lattice-based algorithms have

become one of the most potential replacements for the

commonly used public key cryptographic algorithms,

as is evident by the share of lattice-based algorithms

present in the third round of the NIST standardization

process. Even though they are relatively young,

researchers are quite conﬁdent in their security.

Another upside of lattice-based algorithms is that the

key or ciphertext size is not massive, like is the case

e.g. in algorithms that are based on multivariate

polynomials.

2.3 Cryptographic Software Libraries

Cryptographic primitives are usually deﬁned in

mathematical notation, with mathematical formulae

and operations. Implementing algorithms in a certain

programming language is always a separate process

from that with its own pitfalls. A mistake in the

implementation will result in a security ﬂaw even

if the system is secure in theory (Lazar et al.,

2014). It can be surprisingly difﬁcult to implement

cryptographic algorithms correctly.

That is why the general rule when needing

cryptography is that there is no need to reinvent

the wheel. There are plenty of open-source

cryptographic libraries that have implemented the

cryptographic primitives and offer a (hopefully) easy-

to-use interface for the developer to integrate them in

different programs. By using a cryptographic library

one has succesfully avoided one of the biggest pitfalls.

If one wants to use common public key

cryptographic algorithms like RSA or elliptic curve

algorithms, there is an abundance of cryptographic

libraries that implement these algorithms. On the

other hand, if one wants to secure their program

against quantum computers, options are very limited.

There are example implementations of the algorithms

and some open-source libraries that speciﬁcally

focus on post-quantum cryptography, like liboqs

developed in the Open Quantum Safe project. The

big and commonly used libraries often include very

few post-quantum algorithms, if any at all.

https://github.com/open-quantum-safe/liboqs

Implementing Post-quantum Cryptography for Developers

2.4 Dangers When using Open-source

Cryptographic Libraries

Even if an algorithm has been designed to be secure, it

does not mean that implementing or using it securely

is easy. Mistakes in the implementation phase,

misunderstandings and other mistakes undermine the

security of the algorithm.

As all cryptography is implemented by people

and people make mistakes, even high proﬁle open-

source libraries have bugs and vulnerabilities. One of

the most well-known vulnerabilities is the Heartbleed

bug, which was a mistake in the TLS implementation

of OpenSSL and allowed adversaries to access critical

information (Durumeric et al., 2014). Variation in the

execution time of functions can lead to timing attacks,

which can be very difﬁcult vulnerabilities to prevent

and detect (Almeida et al., 2016).

Even if the cryptographic algorithms are

implemented correctly in the library, using them is

not necessarily easy. In a study from 2014, out of

the examined vulnerabilities 17 % were caused by

mistakes made in the implementation of the library,

and 83 % were caused by mistakes in the programs

using the library, e.g. by the programs using the

library incorrectly (Lazar et al., 2014). A study from

2013 found out that in over 88 % of the examined

10 000 Android applications in the Google Play

store there was at least one mistake in the use of

cryptographic interfaces (Egele et al., 2013).

These examples prove that smart design and clear

interfaces need to be a priority when implementing

cryptographic libraries. It is quite easy to make

mistakes when using the functionality of the

cryptographic libraries. A common mistake is

not using cryptographically strong random number

generators when generating randomness for an

algorithm (Lazar et al., 2014).

It is not enough that the implementation of

the cryptographic algorithm is correct and secure.

Performance of the implementation is always crucial

in real use, and has a great effect on what algorithms

will be used, especially in cases where the operations

will be performed often. In small IoT devices the

choice of algorithms is very restricted.

2.5 Challenges in Implementing

Post-quantum Cryptographic

Algorithms

In principle, implementing post-quantum

cryptographic algorithms does not fundamentally

differ from implementing any other algorithm.

As post-quantum algorithms run on the classical

computer, unlike quantum cryptography that runs

on a quantum computer, the challenges related to

implementing cryptographic algorithms in general

apply to implementing post-quantum algorithms.

A great challenge in implementing post-quantum

cryptography is the mathematical complexity of the

algorithms. This makes implementing the algorithm

from just the speciﬁcation very difﬁcult for an average

developer (Gaj, 2018). Currently used public key

algorithms are based on mathematical problems that

are much easier to understand.

Another challenge is the often greatly increased

key size and sometimes the ciphertext size. Table

2 presents comparison of key sizes between post-

quantum and commonly used public key algorithms.

Especially the sizes of the private keys of the

post-quantum algorithms are larger on the same

security level as traditional public key algorithms.

When implementing post-quantum cryptography on

hardware, this becomes even more important.

Because post-quantum algorithms use different

operations than e.g. RSA, optimizing the hardware

is more difﬁcult (Gaj, 2018).

Table 2: Comparison of key sizes and ciphertext sizes of

some post-quantum and traditional public key algorithms.

Algorithm Priv. key Public key Output

(bytes) (bytes) (bytes)

Kyber-512 1632 800 768

Kyber-768 2400 1184 1088

Kyber-1024 3168 1568 1568

LightSaber 1568 672 736

Saber 2304 992 1088

FireSaber 3040 1312 1472

RSA-3072 384

384

RSA-7680 960

960

RSA-15360 1920

1920

Curve25519 251 256

Modulo.

It is important that there are implementations of

post-quantum cryptographic algorithms in different

languages and for different problems, so that

replacing algorithms that are not quantum secure

is easier. Table 3 shows the current amount of

implemented asymmetric post-quantum algorithms

in some of the most commonly used open-source

libraries. Of the algorithms in the table not

mentioned before, XMSS is a hash-based post-

quantum signature scheme and NewHope is a lattice-

based KEM algorithm that was removed from the

NIST standardization process after the second round.

Many of the largest open-source cryptographic

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

Table 3: Availability of post-quantum asymmetric

algorithms in selected open-source libraries at the time of

the work.

Library Language Algorithms

OpenSSL C -

LibreSSL C -

Botan C++ McEliece

NewHope

XMSS

Crypto++ C++ -

Bouncy Castle Java NewHope

McEliece

Rainbow...

libraries have not implemented any of the algorithms.

For this, there are most likely quite a few reasons.

The standardization is still ongoing and many are still

awaiting which algorithm will be standardized. Also,

many of the algorithms have undergone changes,

mostly small parameter changes, during the process.

As many of the algorithms are quite young in age, it is

possible that there are still vulnerabilities to be found

that greatly decrease their security.

3 ALGORITHM INTEGRATION

The availability of the NIST post-quantum algorithms

in open-source cryptographic libraries is scarce.

There are example implementations, mostly in C, and

some libraries that specialize in the post-quantum

niche. It would be a lot easier for the end-users

of these algorithms, i.e. developers, researchers and

hobbyists, if the algorithms were included in the

cryptographic libraries they are used to using. That

way the user will not have to learn how to use the new

cryptographic library and how its interfaces work,

reducing the threshold for trying out and adopting

post-quantum algorithms.

We chose Crypto++

as the library under

examination, as it did not have any of the algorithms

from the NIST standardization process before.

According to the Github 2020 The State of the

Octoverse report,

C++ was the 7th most popular

programming language in Github in 2020 and has

been consistently popular over the years. We used the

reference implementations of SABER, Dilithium and

Kyber as a basis and integrated them into a fork

Crypto++.

https://cryptopp.com

https://octoverse.github.com

https://github.com/juliushekkala/cryptopp-pqc

3.1 Goals in the Integration Process

Bernstein et al. (2012) emphasize simplicity

and reliability when designing an API for a

cryptographic programming library. They also

present countermeasures taken when designing

how the library works to prevent vulnerabilities,

e.g. by always reading randomness from the OS

cryptographic random number generator instead of

implementing their own complicated way to generate

randomness. In that context, they also mention

code minimization as an underappreciated goal in

cryptographic software.

Forler et al. (2012) present their cryptographic

API that is resistant against misuse. Namely, it is

designed in a way that avoiding nonce reuse and

plaintext leaking is easier. Green and Smith (2016)

present 10 principles for implementing cryptographic

library APIs in a usable way. Because a cryptographic

library is used by other people than those who

developed it, usability needs to be a focus when

designing the cryptographic API.

When integrating the post-quantum algorithms

into the fork of Crypto++, the following were our

goals:

• Usability. Green and Smith (2016) mention the

API needs to be easy to learn even for users

without cryptographic expertise in addition to

being easy to use. We see these as the most

important aspects in our case. The API needs to

be clear and concise. Changing parameters has to

be easy.

• Conformity of the code with other algorithms of

the library. As far as possible, the structure of the

new algorithms’ code is similar to the algorithms

already present in the library. Also, library

speciﬁc functions are used where applicable.

• Reliability. The algorithms work as speciﬁed and

return the correct outputs.

• Prevent unnecessary code. This can be achieved

e.g. by using library functions where appropriate.

• Performance. Algorithms need to be as fast as

possible, without any unnecessary overhead.

3.2 Realization of the Goals

Because the chosen algorithms, Kyber, Dilithium and

SABER, are quite a bit more complex than traditional

public key algorithms, implementing them based on

just the speciﬁcation is really difﬁcult. That is why

we decided to use the reference implementations

provided by the designers of the algorithms to the

third round of the NIST standardization process.

Implementing Post-quantum Cryptography for Developers

Because the reference implementations were

implemented with C and the language of the

Crypto++ library was C++, choosing to work with

the reference implementations directly as a basis

was very advantageous. This way we were able to

prevent much unnecessary code. We created a fork

of the at the time most current version of Crypto++.

The reference implementations were imported to the

fork and changed from C code to C++ code where

necessary.

A major goal in the implementation process was

that a potential user would be able to use the

implemented post-quantum algorithms, e.g. change

between the different security levels, in a similar way

to other algorithms already present in the library.

Class structure was added, as well as the API through

which the user is able to use the algorithms. The API

speciﬁed by NIST for the reference implementations

works as a basis, as we saw no reason to invent the

wheel anew, in other ways we tried to have the API

work as similarly as other algorithms in Crypto++.

Platform independency was also desirable, at least

that using the fork would be possible on both Linux

and Windows operating systems.

3.3 Challenges in the Integration

Process

Throughout the implementation process, the biggest

issue that needed a lot of consideration was the

question of how the multitude of parameters should

be handled. The C reference implementations manage

the parameters using compile-time constants, and as

that would require the user to compile the library

again if they want to change the security levels of the

post-quantum algorithms, it was not a suitable choice

for us. Two different solutions were used for this

in the implementations. In the implementations of

Kyber and SABER, templates were used to handle the

parameters. A base class of the algorithm was created,

that had two template parameters that were used to

deﬁne all the algorithm parameters. When using the

algorithm, the user would call a subclass of the base

class that creates an instance of the base class with the

correct template parameters.

Using templates is quite an elegant solution,

unless there is a need for a lot of template parameters.

In case of Kyber and SABER it was just two, but for

Dilitihium we would have needed quite a list to make

it work. For code clarity, it was decided to go another

route with Dilithium. With Dilithium we ended up

using just member variables, that are changed by the

subclass creating an instance of the base class. This

caused some additional compulsory changes. In the

reference implementation, polynomials and vectors

have been implemented using structs. The size of

arrays in structs needs to be deﬁned before compiling,

and this was not possible, as there was variation in

the sizes between security levels. Polynomials were

switched to work with std::array and vectors with

std::vector. Even if this caused in turn some changes

in the methods, it was not very difﬁcult, as std::array

and std::vector make it possible to work on their inner

data.

Debugging presented quite a challenge at times.

As the algorithms involve a lot of different

advanced mathematical operations and rely heavily

on randomness, it is not easy to determine whether

the state of the program is correct at some point. We

used the reference implementation with randomness

removed in the debugging process to ﬁnd out where

the execution of the C++ version goes wrong. That

way we were able to ﬁnd bugs created in the

integration process.

Platform independency caused some trouble, as

using variables to deﬁne arrays is possible with GCC

compiler, but not on many others, as it is not in

accordance with the ofﬁcial C++ standard. Because

of this we had to change from using arrays to using

std::vector at many points.

Because the NIST standardization process is

not ﬁnished, the details of the algorithms and the

parameters can change. When we started evaluating

the implementation, the security levels of Dilithium

had radically changed from the version that was

implemented to the work. We had to update Dilithium

to an up-to-date version to evaluate it against the

newest version.

4 RESULTS

The performance of the algorithms integrated to

the fork was analysed by measuring clockcycles

with rdstc() instruction and compared against

the measured performance of the reference

implementations on the same device. All

measurements were done on a laptop (i7-10875H

CPU @ 2.30 GHz x16) running Ubuntu 18.04 and

the programs were initially compiled with G++ using

the predetermined compiler options of Crypto++ and

the reference implementations respectively. Using

different compilers and compiler optimizations will

bring forth differences in the performance.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

4.1 Performance Analysis

When the SABER algorithm ﬁrst was implemented

in the library, the performance was not satisfactory.

Compared to Kyber, the integration had decreased

the performance by much more. The runtime

of the algorithm was double of the reference

implementations, even though not many changes had

been made. After debugging, it was found what

part of SABER was the bottleneck. One design

choice of SABER is to use integers moduli that

are powers of 2 (D’Anvers et al., 2018). While

this makes the other parts of the implementation

simpler, it prevents SABER from using the number

theoretic transform (NTT) that is used in Kyber to

speed up calculations. The polynomial multiplication

algorithm is interchangable and needs to be decided

by the implementers of the algorithm. In the

reference implementation, the authors use Toom-

Cook-Karatsuba multiplication. For the sake of

time and resource management, we used the

construction provided by the authors in the reference

implementation. Even though the same construction

was used with very little changes, the performance

decrease was close to 100 %.

Inspecting the compiler options used in Crypto++

by default and the reference implementation revealed

the cause. After debugging, the compiler option

-march=native used in the reference implementation

was found to be the culprit. With this option enabled,

the compiler will detect the architecture of the

system and automatically optimize the code for that

architecture. Without this option, the compiler was

not able to optimize Toom-Cook-Karatsuba construct

in the way that was intended by the authors of the

algorithm. While changing the compiler options of

the library on Linux was successful, Microsoft Visual

Studio Compiler does not offer similar functionality,

and the optimization has to be done separately for

each type of machine.

Table 4 presents the performance measurements

of the integrated algorithms, with the average runtime

of different versions of the algorithms measured

in CPU clockcycles. The performance of the

integrated C++ versions, both with and without

the -march=native GCC optimization ﬂag, was

compared against the reference implementations.

Without optimization, both KEM algorithms were

slower than the reference implementation, especially

SABER. Optimization improved performance of both

algorithms, but the difference was radical with

SABER, which is emphasized with red and green

colors in the runtime change in Table 4 respectively.

With -march=native enabled, the performance of

SABER was even better than that of the reference

implementation.

In addition to presenting the performance of

Kyber and SABER, table 4 includes Dilithium

performance after updating it to the newest parameter

set. Without any custom optimization, the C++

implementation was very close in performance to

the original C implementation. With -march=native

enabled, the C++ implementation siginiﬁcantly

outperformed the C implementation.

4.2 Security Analysis

The implementation was analyzed with Valgrind

to ﬁnd out possible memory leaks. No memory

leaks were found in the C++ implementation.

Side channel attacks are always a risk when

implementing cryptographic algorithms, especially

when optimization is present. Side channel attack

analysis remains future work.

Naturally, we had to be careful that there are

no possible parts in the algorithm where an attacker

could determine secrets based on execution times.

Constant time functions were used e.g. for comparing

the equality of byte arrays.

5 DISCUSSION

The possible emergence of quantum computers

presents a threat especially to the current public key

infrastructure. As there are systems where data

and communications need to be secure for years of

time, preparing for possible quantum computers is

necessary. Lattice-based algorithms are an emerging

group of post-quantum algorithms that are one

potential replacement for the currently used non-

quantum-resilient algorithms. As they are still

quite young, it is entirely possible that systematic

attacks will be found against them. The current

understanding is that the algorithms of this paper,

Kyber, Dilithium and SABER, are not affected by

serious attacks.

As the NIST standardization process is still

ongoing, it is understandable that many big libraries

have not implemented the algorithms. The algorithms

may still undergo and have undergone changes during

the process, as was the case with Dilithium during

our work. Also, it is always possible that serious

vulnerabilities are found. Like with AES, usually the

standardized algorithm will spread to use and others

will be less relevant. From that perspective, it makes

https://valgrind.org

Implementing Post-quantum Cryptography for Developers

Table 4: Performance of Kyber, SABER and Dilithium on different security levels. The reference implementation performance

is compared ﬁrst against performance when compiling the fork with default options, and then when compiling with

-march=native eanabled. The red and green color are used to emphasize the difference in the performance of SABER with

and without the option.

Algorithm Function CPU cycles CPU cycles Runtime CPU cycles Runtime

(ref. impl.) (C++ default) increase (%) (C++ with opt.) increase (%)

Kyber-512 Key gen. 70527 77452 10 70106 -1

Encaps. 90177 103454 15 93220 3

Decaps. 106539 124722 17 114415 7

Kyber-768 Key gen. 119089 137032 15 124357 4

Encaps. 141759 170474 20 152433 8

Decaps. 162677 196737 21 180212 11

Kyber-1024 Key gen. 181525 213370 18 191942 6

Encaps. 205682 251775 22 226342 10

Decaps. 230457 283941 23 259733 13

LightSaber Key gen. 43321 84330 95 46551 7

Encaps. 56580 106420 88 51789 -8

Decaps. 62496 121883 95 55970 -10

Saber Key gen. 80317 158330 97 80856 1

Encaps. 100271 193770 93 91811 -8

Decaps. 109088 218243 100 97211 -11

FireSaber Key gen. 132859 257348 94 127774 -4

Encaps. 156832 305424 95 143594 -8

Decaps. 169193 340069 101 153203 -9

Dilithium2 Key gen. 216791 201662 -7 175171 -19

Sign. 920338 863546 -6 788545 -14

Verif. 214877 228392 6 201943 -6

Dilithium3 Key gen. 350129 370364 6 321002 -8

Sign. 1382591 1397358 1 1300339 -6

Verif. 338629 364654 8 320600 -5

Dilithium5 Key gen. 532097 550770 4 471764 -11

Sign. 1674901 1697241 1 1569844 -6

Verif. 562763 594885 6 518180 -8

sense not to implement algorithms that will not be

used.

5.1 Biggest Challenges in Implementing

Lattice-based Post-quantum

Cryptography

There is a multitude of challenges affecting

implementing lattice-based post-quantum

cryptography. They are harder to implement than

algorithms that are based on factoring and discrete

logarithms, as the mathematical operations and

theory are much more complex. This makes creating

an efﬁcient and well optimized implementation

quite difﬁcult. Implementing based on just the

speciﬁcation is challenging, and without the reference

implementations as a basis, the implementation would

not have been that successful.

Debugging posed a problem in the

implementation process. It can be hard to ﬁnd

the problematic parts in the implementation as the

implementations are complicated. Because many of

the lattice-based algorithms are not deterministic,

the output is every time different for the same input,

and it requires extra effort to be able to debug the

implementation. In our work we used the reference

implementations in the debugging process, by

determining with that program what the state of the

variables should be in each part of the code. That

way we were able to ﬁnd out where mistakes had

been made. If no such reference implementation is

easily available, debugging becomes tedious.

In general use, the key and output sizes and the

use of memory of lattice-based algorithms are not

a problem. In memory-constrained environments,

though, it is not possible to use every lattice-based

algorithm. Also, some communication protocols are

not suitable for lattice-based algorithms because of

e.g. constraints on the message length.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

5.2 Were the Implementation Goals

Achieved?

In general, the goals we set in 3.1 were mostly

achieved. The library speciﬁc functions were used

wherever possible, and the structure is quite similar

to using other algorithms. Performance was also

satisfactory, especially after compiler optimization.

There were some things, though, that left a bit to be

desired.

One of our goals was to make the algorithms in the

fork as usable as possible. Now, using cryptographic

primitives correctly is never going to be the easiest

thing to do, but as we stayed very close to the structure

of the API speciﬁed by NIST, using the algorithms

is quite simple. It would be possible to evaluate the

usability of the algorithms in the library by using

C++ developers as evaluators. For usability, one

thing that is missing from the current implementation

is handling coding errors, e.g. using too small

buffers. Currently this leads in most cases to just the

compiled executable crashing. Exception handling

would improve the usability, but it is important to

consider the points of code where it could be useful

for the developer in order not to introduce bloated

code.

Another one of the goals was preventing

unnecessary code. Again, we partly succeeded - e.g.

the hash functions in the reference implementations

were as a rule exchanged to using already present

library implementations. With better planning and

carefully designing the class structure more could

have been achieved. Kyber and Dilithium are based

on the same framework and work very similarly,

and the code could have been designed in a way

that they use common code components for e.g.

NTT functionality. In the current implementation

the NTT functionality (essentially being the same)

can be found twice, for each Kyber and Dilithium

separately. This was mostly caused by our process

of integrating each algorithm one by one. A more

careful consideration of the overall picture would

have been beneﬁcial.

One of the points to take into account when

designing a cryptographic API that we mentioned

in 3.1 was misuse resistance. The API in our

implementation is quite resistant against misuse. The

algorithms are designed in a way that the user does

not supply any own nonces to the algorithms, so

nonce reuse will not be an issue. Additionally, the

randomness needed in the algorithms is generated

inside the algorithms and not supplied by the user.

Still, it is quite possible that the users would be able

to use the algorithms wrong, and would need more

testing for deﬁnite results.

While the measured performance of the integrated

algorithms was satisfactory, it would be interesting

to examine it more thoroughly. For example,

the performance of SABER is even better in the

integrated C++ version when using -march=native

than in the original C version. One could try to ﬁnd

out whether this is because of the changes made in

our work or because of some compiler optimization

differences, et cetera.

5.3 Comparison of the Implemented

Algorithms

The NIST post-quantum standardization process is

still underway. Therefore it is meaningful to make

some comparisons between SABER and Kyber,

as both are potential standards (Alagic et al.,

2020). Based on our work, one cannot make

deﬁnite conclusions about which of the algorithms is

ultimately better.

As the difference in the key and output sizes

is small and performance is not radically different,

these should not be the most importnat point in

standardization decisions. From these aspects, both

of the algorithm are suitable for standardization.

Kyber is structurally a lot more complex than

SABER. SABER does put a lot of focus on achieving

as much simplicity in the algorithm as possible, which

probably makes it easier to implement. Kyber is part

of the same framework as Dilithium, which is one of

the candidates to be standardized as a digital signature

algorithm. This is a clear advantage for Kyber.

5.4 Future Work

The implementation can be used to further examine

and evaluate the algorithms. The security of the

algorithms and the implementation can be examined

for example by fuzzing. The fork can be used

to examine the applicability of the algorithms

in different protocols and scenarios. Different

compiler optimizations can be experimented with

and investigated whether they cause side channel

vulnerabilities.

As the algorithms change during the NIST

standardization process, they need to be updated

to keep up with the changes. Maintenance

and improvement of the library is needed, too.

Currently only the reference versions of the algorithm

implementations are integrated to the library, while

all the algorithm submissions also included AVX2

(Advanced Vector Extensions 2) optimized versions.

Implementing Post-quantum Cryptography for Developers

Integrating them would improve the performance on

devices that can use those processor instructions.

Naturally, other post-quantum algorithms can

be implemented into the created fork. Another

challenge would be to implement e.g. a Java version

of the algorithms, as there are no Java reference

implementations available that we know of.

6 CONCLUSIONS

Post-quantum cryptography aims to provide an

answer to the emergence of quantum computers

that threaten especially the public key cryptographic

ecosystem. Lattice-based algorithms are one type of

post-quantum algorithms that are likely to increase

in use in the coming years. We integrated

into a cryptographic library fork three lattice-based

algorithms from the third round candidates of NIST

post-quantum cryptography standardization process,

namely KEM algorithms Kyber and SABER and

digital signature algorithm Dilithium.

We examined the challenges and possible

pitfalls of implementing post-quantum cryptographic

algorithms in software libraries. The mathematical

complexity of the algorithms and difﬁcult to

understand speciﬁcation provide a challenge for

the people implementing the algorithms, and extra

attention is required not to create possible security

issues. If one algorithm is easier to implement

than another, it is an immense advantage, as easier

implementation means less risk of implementation

errors.

ACKNOWLEDGEMENTS

This research was supported by PQC Finland project

funded by Business Finland’s Digital Trust program.

REFERENCES

Alagic, G., Alperin-Sheriff, J., Apon, D., Cooper, D.,

Dang, Q., Kelsey, J., Liu, Y.-K., Miller, C., Moody,

D., Peralta, R., et al. (2020). Status report

on the second round of the NIST post-quantum

cryptography standardization process. https://csrc.

nist.gov/publications/detail/nistir/8309/ﬁnal.

Almeida, J. B., Barbosa, M., Barthe, G., Dupressoir,

F., and Emmi, M. (2016). Verifying Constant-

Time Implementations. In 25th USENIX Security

Symposium (USENIX Security 16), pages 53–70,

Austin, TX. USENIX Association.

Arute, F., Arya, K., Babbush, R., Bacon, D., Bardin, J. C.,

Barends, R., Biswas, R., Boixo, S., Brandao, F. G.,

Buell, D. A., et al. (2019). Quantum supremacy using

a programmable superconducting processor. Nature,

574(7779):505–510.

Bernstein, D. J., Lange, T., and Schwabe, P. (2012). The

Security Impact of a New Cryptographic Library.

In Progress in Cryptology – LATINCRYPT 2012,

pages 159–176, Berlin, Heidelberg. Springer Berlin

Heidelberg.

Bos, J., Ducas, L., Kiltz, E., Lepoint, T., Lyubashevsky,

V., Schanck, J. M., Schwabe, P., Seiler, G., and

Stehl

e, D. (2018). CRYSTALS-Kyber: a CCA-secure

module-lattice-based KEM. In 2018 IEEE European

Symposium on Security and Privacy (EuroS&P),

pages 353–367. IEEE.

Chow, J., Dial, O., and Gambetta, J. (2021). IBM

Quantum breaks the 100-qubit processor

barrier. https://research.ibm.com/blog/

127-qubit-quantum-processor-eagle. Accessed:

2021-11-26.

D’Anvers, J.-P., Karmakar, A., Roy, S. S., and Vercauteren,

F. (2018). Saber: Module-LWR based key exchange,

CPA-secure encryption and CCA-secure KEM. In

International Conference on Cryptology in Africa,

pages 282–305. Springer.

Ducas, L., Kiltz, E., Lepoint, T., Lyubashevsky,

V., Schwabe, P., Seiler, G., and Stehl

e, D.

(2018). CRYSTALS-Dilithium: A Lattice-Based

Digital Signature Scheme. IACR Transactions on

Cryptographic Hardware and Embedded Systems,

2018(1):238–268.

Durumeric, Z., Li, F., Kasten, J., Amann, J., Beekman, J.,

Payer, M., Weaver, N., Adrian, D., Paxson, V., Bailey,

M., and Halderman, J. A. (2014). The Matter of

Heartbleed. In Proceedings of the 2014 Conference

on Internet Measurement Conference, IMC ’14, pages

475–488. Association for Computing Machinery.

Egele, M., Brumley, D., Fratantonio, Y., and Kruegel,

C. (2013). An Empirical Study of Cryptographic

Misuse in Android Applications. In Proceedings

of the 2013 ACM SIGSAC Conference on Computer

& Communications Security, CCS ’13, page 73–84,

New York, NY, USA. Association for Computing

Machinery.

Forler, C., Lucks, S., and Wenzel, J. (2012). Designing

the API for a Cryptographic Library. In Reliable

Software Technologies – Ada-Europe 2012, pages 75–

88, Berlin, Heidelberg. Springer Berlin Heidelberg.

Gaj, K. (2018). Challenges and Rewards of Implementing

and Benchmarking Post-Quantum Cryptography in

Hardware. In Proceedings of the 2018 on Great Lakes

Symposium on VLSI, GLSVLSI ’18, page 359–364,

New York, NY, USA. Association for Computing

Machinery.

Green, M. and Smith, M. (2016). Developers are Not the

Enemy!: The Need for Usable Security APIs. IEEE

Security Privacy, 14(5):40–46.

Grover, L. K. (1996). A fast quantum mechanical

algorithm for database search. In Proceedings of the

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

twenty-eighth annual ACM symposium on Theory of

computing, pages 212–219.

Hankerson, D., Menezes, A. J., and Vanstone, S. (2006).

Guide to elliptic curve cryptography. Springer

Science & Business Media.

Lazar, D., Chen, H., Wang, X., and Zeldovich, N. (2014).

Why does cryptographic software fail? A case study

and open problems. In Proceedings of 5th Asia-Paciﬁc

Workshop on Systems, pages 1–7.

Proos, J. and Zalka, C. (2003). Shor’s discrete logarithm

quantum algorithm for elliptic curves. Quantum

Information & Computation, 3(4):317–344.

Regev, O. (2005). On Lattices, Learning with Errors,

Random Linear Codes, and Cryptography. In

Proceedings of the Thirty-Seventh Annual ACM

Symposium on Theory of Computing, STOC ’05,

page 84–93, New York, NY, USA. Association for

Computing Machinery.

Regev, O. and Rosen, R. (2006). Lattice Problems

and Norm Embeddings. In Proceedings of the

Thirty-Eighth Annual ACM Symposium on Theory of

Computing, STOC ’06, page 447–456, New York, NY,

USA. Association for Computing Machinery.

Rescorla, E. (2018). The Transport Layer Security (TLS)

Protocol Version 1.3. RFC 8446. https://rfc-editor.org/

rfc/rfc8446.txt.

Rivest, R. L., Shamir, A., and Adleman, L. (1978). A

Method for Obtaining Digital Signatures and Public-

Key Cryptosystems. Commun. ACM, 21(2):120–126.

Shor, P. W. (1997). Polynomial-Time Algorithms for Prime

Factorization and Discrete Logarithms on a Quantum

Computer. SIAM Journal on Computing, 26(5):1484–

1509.

Shoup, V. (2001). A Proposal for an ISO Standard for

Public Key Encryption. Cryptology ePrint Archive,

Report 2001/112. https://eprint.iacr.org/2001/112.pdf.

Implementing Post-quantum Cryptography for Developers
