On the Choice of General Purpose Classiﬁers in Learned Bloom Filters:

An Initial Analysis Within Basic Filters

Giacomo Fumagalli

1 a

, Davide Raimondi

1 b

, Raffaele Giancarlo

2 c

, Dario Malchiodi

1,3 d

and Marco Frasca

1,3 e

Dipartimento di Informatica, Universit

a degli Studi di Milano, 20133 Milan, Italy

Dipartimento di Matematica ed Informatica, Universit

a di Palermo, 90133 Palermo, Italy

CINI National Laboratory in Artiﬁcial Intelligence and Intelligent Systems (AIIS), Universit

a di Roma, 00185 Roma, Italy

Keywords:

Learned Bloom Filters, Learned Data Structures, Information Retrieval, Classiﬁcation.

Abstract:

Bloom Filters are a fundamental and pervasive data structure. Within the growing area of Learned Data

Structures, several Learned versions of Bloom Filters have been considered, yielding advantages over classic

Filters. Each of them uses a classiﬁer, which is the Learned part of the data structure. Although it has a central

role in those new ﬁlters, and its space footprint as well as classiﬁcation time may affect the performance of

the Learned Filter, no systematic study of which speciﬁc classiﬁer to use in which circumstances is available.

We report progress in this area here, providing also initial guidelines on which classiﬁer to choose among ﬁve

classic classiﬁcation paradigms.

1 INTRODUCTION

Learned Data Structures is a novel area at the cross-

road of Classic Data Structures and Machine Learn-

ing. They have been initially proposed by Kraska et.

al. (Kraska et al., 2018) and have had a rapid growth

(Ferragina and Vinciguerra, 2020a). Moreover, now

the area has been extended to include also Learned

Algorithms (Mitzenmacher and Vassilvitskii, 2020).

The theme common to those new approaches to Data

Structures Design and Engineering is that a query to a

data structure is either intermixed with or preceded by

a query to a Classiﬁer (Duda et al., 2000) or a Regres-

sion Model (Freedman, 2005), those two being the

learned part of the data structure. To date, Learned In-

dexes have been the most studied, e.g., (Amato et al.,

2021; Ferragina and Vinciguerra, 2020b; Ferragina

et al., 2021; Kipf et al., 2020; Kraska et al., 2018;

Maltry and Dittrich, 2021; Marcus et al., 2020a; Mar-

cus et al., 2020b). Rank/select data structures have

also received some attention (Boffa et al., 2021).

https://orcid.org/0000-0002-2068-9293

https://orcid.org/0000-0001-8171-8302

https://orcid.org/0000-0002-6286-8871

https://orcid.org/0000-0002-7574-697X

https://orcid.org/0000-0002-4170-0922

Bloom Filters (Bloom, 1970), which are the object

of this study, have also been considered, as we detail

next. Historically, they have been designed to be a

data structure able to solve the Approximate Mem-

bership Problem in small space (see Section 2). Due

to their fundamental nature and pervasive use, many

variants and alternatives have been proposed. A good

review in the domain of Internet applications is pro-

vided in (Broder and Mitzenmacher, 2002).

Kraska et al. (Kraska et al., 2018) have proposed

a learned version of such a ﬁlter, in which a query to

the data structure is preceded by a query to a suit-

ably trained binary classiﬁer. The intent is to re-

duce space and reject time. Mitzenmacher (Mitzen-

macher, 2018) has provided a model for those ﬁlters,

together with a very informative mathematical anal-

ysis of their pros/cons and even an alternative pro-

posal. Additional Learned Bloom Filters have been

proposed recently (Dai and Shrivastava, 2020; Vaidya

et al., 2021). It is worth pointing out that, although

they differ in architecture, each of those proposals has

a classiﬁer as its central part.

Somewhat puzzling is that, although the classiﬁer

is the novel part of this new family of Filters and it

is accounted for in theoretical studies (Mitzenmacher,

2018), not much attention is given to which classiﬁer

Fumagalli, G., Raimondi, D., Giancarlo, R., Malchiodi, D. and Frasca, M.

On the Choice of General Purpose Classiﬁers in Learned Bloom Filters: An Initial Analysis Within Basic Filters.

DOI: 10.5220/0010889000003122

In Proceedings of the 11th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2022), pages 675-682

ISBN: 978-989-758-549-4; ISSN: 2184-4313

675

to use in practical settings. Kraska et al. use a Neu-

ral Network, while Dai and Shrivastava and Vaidya et

al. use Random Forests. Those choices are only in-

formally motivated, giving no evidence of superiority

with respect to other possible ones, via a comparative

analysis. Therefore, the important problem of how to

choose a speciﬁc classiﬁer in conjunction with a spe-

ciﬁc ﬁlter has not been addressed so far, even in one

application domain.

Such a State of the Art is problematic, both

methodologically and practically. Here we propose

the ﬁrst, although initial, study that considers the

choice of the classiﬁer within Learned Filters. Since

our study is of a fundamental nature, we consider only

basic versions of the Filters and six generic, if not

textbook, classiﬁer paradigms. The intent is to char-

acterize how different classiﬁers affect different per-

formance parameters of the Learned Filter. The ap-

plication domain is the one of malicious URL deter-

mination, as in previous work. As per literature stan-

dard, our datasets are real and fall within the data size

used by Dai and Shrivastava. However, even so, Ran-

dom Forest classiﬁers do not seem to be competitive

in our setting, needing bigger datasets. Indeed, for the

continuation of this work, we plan to consider much

larger datasets and include also Random Forests. Ad-

ditional application domains will also be considered.

Our results provide a conﬁrmation of some ex-

pected behaviours, like that more complex classiﬁers

tend to yield larger space reduction when used within

a learned Bloom Filter, but also some counterintuitive

perspectives, including that simple linear classiﬁers

might represent very competitive alternatives to their

bigger counterparts, sometimes even better. These re-

sults make more sense if we consider that in a learned

Bloom Filter classiﬁers come up with one or two clas-

sic Bloom Filters, calibrated in turn on the classiﬁer

performance, and accordingly it is their synergy that

determines the overall space reduction, not just the

classiﬁer itself. Finally, a relevant note is also that in

our experiments linear classiﬁers allow two orders of

magnitude faster reject times.

2 APPROXIMATE SET

MEMBERSHIP PROBLEM:

DEFINITIONS AND KEY

PARAMETERS

Deﬁnition. Given S ⊂ U and x ∈ U, where U is

the universe of keys, the set membership problem

consists in ﬁnding a data structure able to determine

if x ∈ S. The approximate set membership instead

allows for a fraction ε of false positives, that is

elements in U \ S considered as members of S. No

false negatives are allowed. That is, elements in S

considered as non-members.

A Paradigmatic Example. Assume that a set of

URLs is given. They can be malicious, i.e., websites

hosting unsolicited content (spam, phishing, drive-by

downloads, etc.), or luring unsuspecting users to be-

come victims of scams (monetary loss, theft of private

information, and malware installation), or otherwise

labeled as benign. The aim is to design a time ef-

ﬁcient data structure that takes small space and that

“rejects” benign URL quickly, as they do not belong

to the malicious set. On occasions, we may have false

positives.

Key Parameters of the Filter. The reject time,

taken as the expected time to reject a non-member of

the set; the space taken by the data structure, since

the cardinality of S may be very large; the false pos-

itive rate ε. Quite remarkably, Bloom provided two

data structures to solve the posed problem, linking the

three key parameters in trade-off bounds. The most

space-efﬁcient of those data structures goes under the

name of Bloom Filter and it is outlined next, together

with two of its learned versions.

2.1 Basic Classic and Learned Bloom

Filters

Classic. Letting |S| = n, a Bloom Filter (BF) is

made up by a bit array v of size m, whose elements

are all initialized to 0. It uses k hash functions

: U −→ {0, 1, . . . , m − 1}, j ∈ {1, . . . , k}, which

can be assumed to be perfect in theoretic studies (see

(Mitzenmacher, 2018)). When a new element x of S is

added, it is coded using the hash functions: each bit in

v in position h

(x) is set to 1, for each j ∈ {1, . . . , k}.

To test if a key x ∈ U is a member of S, h

(x) for each

j is computed, and x will be rejected if there exists

j ∈ {1, . . ., k} such that v[h

(x)] = 0. However, when

the Bloom Filter considers x as a member, it might

be a false positive due to the hash collisions. The

false positive rate ε is inversely related to the space

usage of the bit array. More accurately, the trade-off

formula connecting the key parameters of the Filter is

given in equation (21) in (Bloom, 1970). Analogous

trade-off formulas are also known, e.g., (Broder

and Mitzenmacher, 2002; Mitzenmacher, 2018). In

applications (Broder and Mitzenmacher, 2002), one

usually asks for the the most space-conscious ﬁlter,

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

676

given a false positive rate, being the reject time

a consequence of those choices.

Learned: One Classiﬁer and One Filter. The in-

tent of this data structure, named Learned Bloom Fil-

ter (LBF), is to achieve a given false positive rate, as

in a classic ﬁlter, but in less space, and possibly with

little loss in reject time (Kraska et al., 2018). One

can proceed as follows. A classiﬁer C : U −→ [0, 1] is

trained on a labeled dataset (x, y

), where x ∈ D ⊂ U ,

S ⊂ D, and y

= 1 when x ∈ S, y

= −1 otherwise. The

positive class is thereby the class of keys S. The larger

C(x), the more likely x belongs to S. Then, in order

to have a binary prediction, a threshold τ ∈ (0, 1) is to

be ﬁxed, yielding positive predictions for any x ∈ U

such that C(x) ≥ τ, negative otherwise. To avoid false

negatives in the learned Bloom Filter, that is elements

x ∈ S rejected by the ﬁlter, a classic “backup” Bloom

Filter F is created on the set {x ∈ S|C(x) < τ}. A

generic key x is tested against membership in S by

computing the corresponding prediction C(x): x is

considered as an element of S if C(x) ≥ τ or C(x) < τ

and F does not reject x. x is rejected otherwise. Un-

like a classic Bloom Filter, the false positive rate of

a LBF depends on the distribution of a given query

set

S ∈ U \ S (Mitzenmacher, 2018). Hereafter, we

will refer to ε

= |{x ∈

S|(C(x) ≥ τ)}| as the empir-

ical false positive rate of the classiﬁer on

S, to ε

the false positive rate of F, and to the empirical false

positive rate of the LBF on

S as ε = ε

+ (1 − ε

)ε

Fixed a desired ε, the optimal value of ε

ε − ε

1 − ε

which yields the constraint ε

< ε.

It is to be pointed out that now, false positive rate

ε, space and reject time of the entire ﬁlter are inti-

mately connected and inﬂuenced by the choice of τ.

Another delicate point that emerges from the analy-

sis offered in (Mitzenmacher, 2018) is that, while the

false positive rate of a classic Filter can be reliably

estimated experimentally because of its data indepen-

dence, for the Learned version this is no longer so

immediate and further insights are needed. As an ad-

ditional contribution, an experimental methodology is

suggested in (Mitzenmacher, 2018) and we adhere to

it here.

Learned: Sandwiched Classiﬁer. The intent of

this variant, named Sandwiched Learned Bloom Filter

(SLBF), is to ﬁlter out most non-keys before they are

supplied to the LBF. This would allow the construc-

tion of a much smaller backup ﬁlter F and an overall

more compact data structure (Mitzenmacher, 2018).

The speciﬁcs follow. A Bloom Filter I for the set

S precedes the structure of the Learned Bloom Filter

described in the previous paragraph. The subsequent

LBF is constructed on the elements of S not rejected

by I. Clearly, I might yield a considerable number of

false positives, when a limited budget of bits is dedi-

cated to it. A query x ∈ U is rejected by the SLBF if I

rejects it, otherwise the results of the subsequent LBF

is returned. Denoted by ε

the false positive rate of

the ﬁlter I, the empirical false positive rate of a SLBF

is ε = ε



+ (1 − ε

)ε



. For a desired value of ε,

the following properties hold (Mitzenmacher, 2018):

• ε



1 −



, with FN number of false nega-

tives of C;

• ε



1 −



≤ ε

≤ 1 −

As for the previous learned Bloom Filter variant, the

classiﬁer accuracy affects all the key factors of a

SLBF, namely false positive rate, space and reject

time. Considerations and experimental methodolo-

gies in this case are the same as in the previous case.

3 EXPERIMENTAL

METHODOLOGY

3.1 General Purpose Classiﬁers

The classiﬁers used in our analysis are brieﬂy de-

scribed below. We assume each x ∈ U is repre-

sented through a set of n real-valued attributes A =

, . . . , A

}, and that Y = {−1, 1} is the set of labels,

with -1 denoting the negative class. The training set

is made up by labeled instances D ⊂ U, in the form of

couples (x, y

), with x ∈ D and y

∈ Y .

• RNN-k. A character-level recurrent neural net-

work with Gated Recurrent Units (GRU) (Cho

et al., 2014), having 10-dimensional embed-

ding and k-dimensional GRU. RNN is included

as baseline from literature for the same prob-

lem (Kraska et al., 2018). The parameters to be

learned are the connections weights and unit bi-

ases for all the layers in the model.

Hyperparameters. The hyperparameters here are

the embedding dimension, the GRU size k, the

learning and the dropout rate. No changes in their

conﬁguration has been made with regard to the

setting used in (Kraska et al., 2018), except for

the size of the embedding layer, reduced to 10,

as done in (Ma and Liang, 2020), to comply with

the reduced size of our dataset, and the smaller

size of the overall ﬁlter as well. The embedding

On the Choice of General Purpose Classiﬁers in Learned Bloom Filters: An Initial Analysis Within Basic Filters

677

dimension and k affect the design of the Learned

Filters. Therefore, we refer to them as key

hyperparameters. We use the same terminol-

ogy also for the other classiﬁers used in this study.

• Naive Bayes (NB). A Naive Bayes Classi-

ﬁer (Duda and Hart, 1973) ranks instances based

on Bayes’ rule. It learns the conditional proba-

bilities of having a certain label Y = y

given a

speciﬁcation of the attributes A

Y ← argmax

P(Y = y

)P(A

= x

. .. A

= x

|Y = y

)

∑

P(Y = y

)P(A

= x

. .. A

= x

|Y = y

)

The conditional probabilities on the right are pa-

rameters of the model, and are efﬁciently es-

timated from training data by assuming all at-

tributes are conditionally independent given Y

(naive). To deal with missing attribute conﬁgura-

tions and to avoid zero estimates of some parame-

ters, a regularization yielding smooth estimates is

applied.

Hyperparameters. The only hyperparameter is the

one determining the strength of the smoothing for

missing combinations of the attributes, which is

not a key hyperparameter.

• Logistic Regression (LR). The logistic regres-

sion (Cox, 1958) classiﬁes an instance x =

, . . . , x

) as negative if

P(Y = −1|A = x) > P(Y = 1|A = x),

where

P(Y = −1|X = x) =

exp(w

∑

i=1

)

1 + exp(w

∑

i=1

)

and P(Y = 1|X = x) = 1 − P(Y = −1|X = x).

Here, w = w

, . . . w

are parameters of the clas-

siﬁers, which are estimated from training data. A

regularization is typically applied to impose the

norm of w to be minimized along with the maxi-

mization of the conditional data likelihood.

Key hyperparameters. The model has just one hy-

perparameter, the one determining the strength of

the regularization, which is not key.

• Linear Support Vector Machine (SVM). Linear

SVMs (Cortes and Vapnik, 1995) classify a given

instance x ∈ R

as f (x) = w

·x+b, where · is the

inner product operator, w ∈ R

, and b ∈ R. The

hyperplane (w, b) is learned to maximize the mar-

gin between positive and negative points:

min

w∈R

kwk

+ C

∑

x∈D

s.t. y

f (x) ≥ 1 − ξ

x ∈ D

≥ 0 x ∈ D ,

where ξ

is the error in classifying instance x, and

C is an hyperparameter regulating the tolerance to

misclassiﬁcations. Non-linear SVMs, e.g. with

Gaussian kernel, have been discarded due to their

excessive size, in light of the fact that they need

to store not just the hyperplane, but the also the

kernel matrix.

Hyperparameters. C is the unique hyperparame-

ter for this classiﬁer, and it is not key.

• FFNN-h. A Feed-Forward neural network (Zell,

1994) with the input layer of size n, one hidden

layer with h units, and one output unit with sig-

moid activation. The weights of connections and

the neuron biases are the parameters to be esti-

mated from training data.

Hyperparameters. The learning rate, the activa-

tion function for the hidden layer, and the number

of hidden units h are hyperparameters here, with

the latter being also a key hyperparameter.

3.2 Data and Hardware

Following the literature, we concentrated on URL

data. URLs are divided into benign and malicious ad-

dresses, with the latter typically stored in the ﬁlter.

They are as follows.

• The ﬁrst dataset comes from (UNIMAS, 2021),

and contains 15k benign and 15k malicious URLs.

• The second dataset comes from (Machine Learn-

ing Lab, 2021), in particular as benign we have

chosen 3637 entries in the category legitimate un-

compromised, and as malicious 38419 entries in

the category hidden fraudolent.

As for the training of the classiﬁers, we use both the

mentioned datasets with their division in benign and

malicious. Since the number of benign elements does

not guarantee good training on the NN-based classi-

ﬁers included in this research, we also consider the

following dataset.

• All the 291753 URL available at (BOTW, 2021),

that we take as being benign.

In analogy with (Ma and Liang, 2020), we pro-

cessed the Web addresses as follows.

• Standardization. Common strings like "www."

and "http://" have been removed from each

URL, and URLs have been resized to a length

of 150, by either padding shorter addresses with

a marker symbol or by truncating excess charac-

ters, removing duplicated URLs. The resulting

dataset contains 310329 benign and 43744 mali-

cious URLs.

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

678

Finally, the datasets have been suitably coded for

the input of the classiﬁers employed in this work.

• Input coding for RNN. In analogy with (Ma and

Liang, 2020), URLs have been coded by map-

ping each character to consecutive integers start-

ing from 1 to 128 in order of frequency in the

training set, and to 0 all the remaining charac-

ters, eventually obtaining a 150-dimensional vec-

tor. For their nature, such classiﬁers need an em-

bedding layer taking as input the whole sequence

of characters in the address to execute the training.

• Input coding for other classiﬁers. Here a stan-

dard bag of char coding is adopted, based on the

fact that the remaining classiﬁers are more ﬂexible

on their input format (no embedding needed). In

this coding, each URL is represented with a vector

containing for each distinct character in the train-

ing set its frequency in the URL–we tested both

relative and absolute frequency, with no signif-

icant differences in the classiﬁers’ performance.

The extracted vectors are positional, in the sense

each distinct character is assigned a ﬁxed position

in the vector. This way, addresses are coded with

vector of dimension 79. We point out that other

potential URL codings are applicable, which how-

ever are beyond the scope of this study, since URL

coding is the same for all classiﬁers (except for

RNN), and the aim is to evaluate the role of clas-

siﬁers in this learned data structure.

• Hardware. The experiments were run on a In-

tel Core i5-8250U 1.60GHz Ubuntu machine with

16GB RAM.

3.3 Evaluation Framework

3.3.1 Classiﬁers Screening

Intuition suggests that the better a classiﬁer is at dis-

criminating benign from malicious URLs, the bet-

ter the performance of the Learned Bloom Filter us-

ing it. Nevertheless, the space occupied by the clas-

siﬁer plays a central role, and the trade-off perfor-

mance/space is to be taken into account.

In order to shed quantitative light on this aspect,

we perform classiﬁcation experiments involving the

URLs and the classiﬁers, without the ﬁlter.

• Classiﬁer validation. Classiﬁers’ generalization

capabilities have been evaluated through a 5-fold

cross validation on the whole dataset, and the per-

formance assessed in terms of Accuracy, F1 mea-

sures, and space occupied. The latter includes the

space of both classiﬁer structure and input encod-

ing, stored as a standard in Python via the seri-

Table 1: Cross validation performance of the compared

classiﬁers. For each measure also the standard deviation

across folds is shown.

Classiﬁer Accuracy F1 Space (Kb)

NB 0.909 ± 0.009 0.522 ± 0.003 3.40

SVM 0.929 ± 0.001 0.673 ± 0.003 1.56

LR 0.930 ± 0.001 0.672 ± 0.003 1.61

RNN-16 0.935 ± 0.003 0.751 ± 0.010 9.45

RNN-8 0.925 ± 0.002 0.733 ± 0.005 6.39

RNN-4 0.916 ± 0.009 0.677 ± 0.035 5.51

FFNN-64 0.962 ± 0.001 0.846 ± 0.002 21.80

FFNN-16 0.952 ± 0.001 0.812 ± 0.002 5.63

FFNN-8 0.946 ± 0.001 0.789 ± 0.003 2.94

alization method dump of library Pickle (Python

Software Foundation, 2021). The results averaged

across folds are calculated. In order to have a bi-

nary prediction necessary to compute Accuracy

and F1, in this experiment the best threshold τ is

estimated on the training set to maximize the F1.

• Classiﬁer model selection. The best perform-

ing hyperparameter conﬁguration for each clas-

siﬁer (see Section 3.1) is selected through a 5-

fold (inner) cross validation on the training set.

In order to directly assess the trade-off Accu-

racy/Space, the key hyperparameters of the RNN

and FFNN classiﬁers have been preset to k =

{4, 8, 16} (as done in (Ma and Liang, 2020)), and

h = {8, 16, 64}.

3.3.2 Learned Bloom Filters

Following (Ma and Liang, 2020), both typologies of

learned Bloom Filters have been validated in the fol-

lowing holdout setting. The training regards the con-

struction of the Bloom Filter on the malicious URLs,

which follows a standard approach, but it must also

account for the training of the classiﬁer embedded

in the ﬁlter. Such a task is performed using half of

the benign URL uniformly selected (in addition to

the malicious ones), whereas the rest of benign URLs

constitutes the holdout set used to compute the ﬁlter

performance.

Evaluation. The ﬁlters have been also evaluated in

terms of space, including both classiﬁers and auxil-

iary Bloom Filters space, and reject time. To this

end, as baseline, the space and reject time of the

classic Bloom Filter is also reported. As suggested

in (Mitzenmacher, 2018), we tuned τ to achieve clas-

siﬁer false positive rates ε

that are within the bounds

required, and the performance of the ﬁlter evaluated

for different admissible values of ε

(see Section 2.1).

On the Choice of General Purpose Classiﬁers in Learned Bloom Filters: An Initial Analysis Within Basic Filters

679

Table 2: Size (in Kb) and average reject time (in sec.) of

Bloom Filters storing malicious URLs by varying the false

positive rate ε.

ε 0.001 0.005 0.01 0.02

Space 76.8 58.9 51.2 43.5

Time 1.22 · 10

−6

1.03 · 10

−6

1.02 · 10

−6

1.00 · 10

−6

Table 3: Average reject time in seconds for one query of the

different learned Bloom Filters.

Classiﬁer 0.001 0.005 0.010 0.020

LBF

NB 3.12e-6 3.24e-6 3.01e-6 3.37e-6

SVM 3.35e-6 3.23e-6 3.43e-6 3.58e-6

LR 3.77e-6 3.84e-6 3.95e-6 3.98e-6

RNN 1.64e-3 1.75e-3 1.76e-3 1.77e-3

FFNN 2.27e-4 2.73e-4 2.72e-4 2.73e-4

SLBF

Bayes 4.83e-6 4.90e-3 4.71e-6 5.03e-6

SVM 4.32e-6 4.58e-6 4.41e-6 4.59e-6

LR 4.47e-6 4.64e-6 4.35e-6 4.68e-6

RNN 1.57e-3 1.71e-3 1.71e-3 1.72e-3

FFNN 2.70e-4 2.64e-4 2.63e-4 2.65e-4

3.4 Results

3.4.1 Results of Classiﬁers Screening

In Table 1 we report performance comparison of the

adopted classiﬁers when trained on the whole dataset.

FFNNs and RNNs achieve Accuracy and F1 val-

ues higher that the other competitors, with the for-

mer being preferable w.r.t. RNNs from all the stand-

points (Accuracy, F1 and space/performance trade-

off). These two families of classiﬁers are able to

unveil (unlike NB, SVM and LR) even non linear

relationships between input and output, accordingly

their superior results are not surprising. The re-

maining classiﬁers are competitive in terms of Accu-

racy, less in terms of F1. Their best feature here is

the compactness, being SVM and LR around 1.88×

and 13.97× smaller than the smallest (FFNN-8) and

biggest (FFNN-64) NN-based models, respectively.

This is a central issue in this setting, because the clas-

siﬁer size contributes to the total space of the learned

Bloom Filter using it. To help this analysis, in Table 2

the size of the classical Bloom Filter with different

desired false positive rates ε is shown. A large clas-

siﬁer, like FFNN-64, is practically not usable on this

dataset, since it occupies, for example when ε = 0.02,

till half of the space of the ﬁlter. For this reason, in

the next experiment, evaluating the performance of

learned Bloom Filters, the range of values tested for h

is set to {10, 15, 20, 25, 30}.

3.4.2 Results of Bloom Filters Comparison

Figure 1 depicts overall ﬁlter size when employing

different classiﬁers and when varying both ε and

. Having the classiﬁers FFNN and RNN different

choices for the performance/space trade-off, depend-

ing on the conﬁguration of their key hyperparameters,

here the one leading to the smallest learned ﬁlter has

been reported. Speciﬁcally, k = 16 and h = 20.

A ﬁrst relevant emerging trend is that the choice of

is critical to determine the best gain in space. In the

case of LBFs, for small ε values (ﬁrst two columns),

the best compression corresponds to low values of

suggesting that the classiﬁer precision (lower number

of false positives) is more relevant when we aim at

constructing LBFs with small false positive rates. In-

deed, the ﬁlter size grows with

. On the other side,

this means that when smaller ε values are required, the

best choice is to rely more on the backup ﬁlter to guar-

antee a false positive rate ε (a classiﬁer having a low

produces more false negatives). Only the FFNN-

based LBF with ε = 0.005 already shows a trend ob-

served also for larger ε values (last two columns),

where for most LBFs the overall space decreases till a

certain value of

is attained, then it starts to increase.

This means that the classiﬁer plays a more crucial role

in this cases, as conﬁrmed by the higher space reduc-

tion with respect to the classic Bloom Filter (dashed

line).

SLBFs work differently, and it is not intuitive to

understand the reason of such a difference. We at-

tempt to provide here some potential clues in this di-

rection. A ﬁrst and main difference, except for ﬁlters

relying on NB and LR, for which the best ε

is al-

ways the lowest one (probably due to the poor perfor-

mance of NB and LR), is that now for smaller ε values

the classiﬁers are allowed to produce more false pos-

itives, and conversely for larger choices of ε. Exactly

as opposite to what happens for the LBFs. A possi-

ble explanation resides in the role of the initial Bloom

Filter of the SLBF. Filtering out a portion of nega-

tives allows the classiﬁer to produce less false posi-

tives, thus fostering a different tuning of τ. A second

relevant difference with LBFs is the higher stability in

terms of space with respect to the choice of τ, which

conﬁrms the analyses in (Mitzenmacher, 2018). Over-

all, SLBFs tend to achieve larger size reduction than

LBFs, mainly for smaller values of ε, as a conﬁrm

of previous theoretical (Mitzenmacher, 2018) and em-

pirical (Dai and Shrivastava, 2020) results.

Regarding the impact of individual classiﬁers on

the overall size, in most cases the ﬁlter using a FFNN

compresses the most with respect to the classic Bloom

Filter, in accordance with the results shown in Table 1;

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

680

Figure 1: Size of LBF (ﬁrst row) and SLBF (second row) for different classiﬁer false positive rate. Dashed line is the size of

the corresponding Bloom Filter. From the left, ﬁgures refer to a desired false positive rate ε of 0.001, 0.005, 0.01, 0.02.

however, the SVM is very competitive, mainly when

embedded in the SLBF, being almost indistinguish-

able with FFNN in terms of space gain. Another sur-

prising result is for the LBFs with ε = 0.001, where

the NB allows the best space reduction. Such results

are even more meaningful if we consider the reject

times shown in Table 3: the ﬁlters built using SVMs

and NB are two orders of magnitude faster than those

using FFNNs. Thus, what is counterintuitive is that

non-linear or complex is not necessarily better than

linear and simple when we are declining the charac-

teristics of a classiﬁer to be employed in a learned

Bloom Filter. It is likely such results are tied to the

size of key set, being higher the potential gain of a

learned version vs. its classic counterpart when the

number of keys increases (Dai and Shrivastava, 2020;

Ma and Liang, 2020). This is left to future investiga-

tions.

4 CONCLUSIONS AND FUTURE

DEVELOPMENTS

We have preliminarily investigated the impact of gen-

eral purpose classiﬁers within recently proposed ex-

tension of Bloom Filters, named learned Bloom Fil-

ters. Following (Mitzenmacher, 2018), which empha-

sized how these learned extensions are dependent on

the data distribution, we have conducted an empiri-

cal evaluation in the context of malicious URLs de-

tection, considering a wide range of general purpose

classiﬁers. Previous works on learned Bloom Filters

have not focused on the appropriate choice of the clas-

siﬁer, and simply relied on non-linear models. Our

results have conﬁrmed the suitability of such classi-

ﬁers, but also have afﬁrmed that simpler classiﬁers

(e.g., linear) might be the best choice in some spe-

ciﬁc contexts, especially when the reject time is also

a key factor. Future works in this directions would

extend and further validate the learned Bloom Filters

on different application domains, e.g. Genomics, Cy-

ber security, Web networking, and test the obtained

results against problems with different key set sizes

and distributions, thus allowing to unveil further in-

sights into the role played by the classiﬁers, possi-

bly including even those discarded in this paper for

their excessive space occupancy. Finally, the adop-

tion of succinct representations of the trained classi-

ﬁers, e.g. Neural Networks (Long et al., 2019; Marin

et al., 2021a; Marin

o et al., 2021b), might sensibly

contribute to reduce the size of a learned ﬁlter.

ACKNOWLEDGEMENTS

This work has been supported by the Italian MUR

PRIN project “Multicriteria data structures and al-

gorithms: from compressed to learned indexes, and

beyond” (Prot. 2017WR7SHH). Additional sup-

port to R.G. has been granted by Project INdAM -

GNCS Project 2020 Algorithms, Methods and Soft-

ware Tools for Knowledge Discovery in the Context

of Precision Medicine.

On the Choice of General Purpose Classiﬁers in Learned Bloom Filters: An Initial Analysis Within Basic Filters

681

REFERENCES

Amato, D., Giancarlo, R., and Bosco, G. L. (2021). Learned

sorted table search and static indexes in small space:

Methodological and practical insights via an experi-

mental study. CoRR, abs/2107.09480.

Bloom, B. H. (1970). Space/time trade-offs in hash cod-

ing with allowable errors. Commun. ACM, 13(7):422–

426.

Boffa, A., Ferragina, P., and Vinciguerra, G. (2021).

A “learned” approach to quicken and compress

rank/select dictionaries. In Proceedings of the SIAM

Symposium on Algorithm Engineering and Experi-

ments (ALENEX).

BOTW (2021). Best of the Web – Free Business Listing.

https://botw.org. Last checked on Oct. 18, 2021.

Broder, A. and Mitzenmacher, M. (2002). Network Appli-

cations of Bloom Filters: A Survey. In Internet Math-

ematics, volume 1, pages 636–646.

Cho, K., van Merrienboer, B., G

ulc¸ehre, C¸ ., Bahdanau, D.,

Bougares, F., Schwenk, H., and Bengio, Y. (2014).

Learning phrase representations using RNN encoder-

decoder for statistical machine translation. In Proc.

of the 2014 Conf. on Empirical Methods in Natural

Language Processing, EMNLP 2014, October 25-29,

2014, Doha, Qatar, A meeting of SIGDAT, a Special

Interest Group of the ACL, pages 1724–1734. ACL.

Cortes, C. and Vapnik, V. (1995). Support-vector networks.

Machine learning, 20(3):273–297.

Cox, D. R. (1958). The regression analysis of binary se-

quences. Journal of the Royal Statistical Society: Se-

ries B (Methodological), 20(2):215–232.

Dai, Z. and Shrivastava, A. (2020). Adaptive Learned

Bloom Filter (Ada-BF): Efﬁcient utilization of the

classiﬁer with application to real-time information ﬁl-

tering on the web. In Advances in Neural Information

Processing Systems, volume 33, pages 11700–11710.

Curran Associates, Inc.

Duda, R. O. and Hart, P. E. (1973). Pattern Classiﬁcation

and Scene Analysis. John Willey & Sons, New Yotk.

Duda, R. O., Hart, P. E., and Stork, D. G. (2000). Pattern

Classiﬁcation, 2nd Edition. Wiley.

Ferragina, P., Lillo, F., and Vinciguerra, G. (2021). On the

performance of learned data structures. Theoretical

Computer Science, 871:107–120.

Ferragina, P. and Vinciguerra, G. (2020a). Learned Data

Structures. In Recent Trends in Learning From Data,

pages 5–41. Springer International Publishing.

Ferragina, P. and Vinciguerra, G. (2020b). The PGM-index:

a fully-dynamic compressed learned index with prov-

able worst-case bounds. PVLDB, 13(8):1162–1175.

Freedman, D. (2005). Statistical Models : Theory and Prac-

tice. Cambridge University Press.

Kipf, A., Marcus, R., van Renen, A., Stoian, M., Kemper,

A., Kraska, T., and Neumann, T. (2020). Radixspline:

A single-pass learned index. In Proc. of the Third In-

ternational Workshop on Exploiting Artiﬁcial Intelli-

gence Techniques for Data Management, aiDM ’20,

pages 1–5. Association for Computing Machinery.

Kraska, T., Beutel, A., Chi, E. H., Dean, J., and Polyzotis,

N. (2018). The case for learned index structures. In

Proc. of the 2018 Int. Conf. on Management of Data,

SIGMOD ’18, pages 489–504, New York, NY, USA.

Association for Computing Machinery.

Long, X., Ben, Z., and Liu, Y. (2019). A survey of related

research on compression and acceleration of deep neu-

ral networks. Journal of Physics: Conference Series,

1213:052003.

Ma, J. and Liang, C. (2020). An empirical analysis of the

learned bloom ﬁlter and its extensions. Unpublished.

Paper and code no more available on line.

Machine Learning Lab (2021). Hidden fraudulent urls

dataset. https://machinelearning.inginf.units.it/data-

and-tools/hidden-fraudulent-urls-dataset. Last

checked on Oct. 18, 2021.

Maltry, M. and Dittrich, J. (2021). A critical analysis of

recursive model indexes. CoRR, abs/2106.16166.

Marcus, R., Kipf, A., van Renen, A., Stoian, M., Misra,

S., Kemper, A., Neumann, T., and Kraska, T.

(2020a). Benchmarking learned indexes. arXiv

preprint arXiv:2006.12804, 14:1–13.

Marcus, R., Zhang, E., and Kraska, T. (2020b). CDFShop:

Exploring and optimizing learned index structures. In

Proc. of the 2020 ACM SIGMOD Int. Conf. on Man-

agement of Data, SIGMOD ’20, pages 2789–2792.

Marin

o, G. C., Ghidoli, G., Frasca, M., and Malchiodi,

D. (2021a). Compression strategies and space-

conscious representations for deep neural networks.

In Proceedings of the 25th International Conference

on Pattern Recognition (ICPR), pages 9835–9842.

doi:10.1109/ICPR48806.2021.9412209.

Marin

o, G. C., Ghidoli, G., Frasca, M., and Malchiodi,

D. (2021b). Reproducing the sparse huffman address

map compression for deep neural networks. In Re-

producible Research in Pattern Recognition, pages

161–166, Cham. Springer International Publishing.

doi:10.1007/978-3-030-76423-4 12.

Mitzenmacher, M. (2018). A model for learned bloom ﬁl-

ters and optimizing by sandwiching. In Advances in

Neural Information Processing Systems, volume 31.

Curran Associates, Inc.

Mitzenmacher, M. and Vassilvitskii, S. (2020). Algorithms

with predictions. CoRR, abs/2006.09123.

Python Software Foundation (2021). pickle – python object

serialization. https://docs.python.org/3/library/pickle.

html. Last checked on Oct. 18, 2021.

UNIMAS (2021). Phishing dataset. https://www.fcsit.

unimas.my/phishing-dataset. Last checked on Oct. 18,

2021.

Vaidya, K., Knorr, E., Kraska, T., and Mitzenmacher, M.

(2021). Partitioned learned bloom ﬁlters. In Interna-

tional Conference on Learning Representations.

Zell, A. (1994). Simulation neuronaler Netze. habilitation,

Uni Stuttgart.

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

682
