View-invariant 3D Skeleton-based Human Activity Recognition based on

Transformer and Spatio-temporal Features

Ahmed Snoun, Tahani Bouchrika and Olfa Jemai

Research Team in Intelligent Machines (RTIM),

National Engineering School of Gabes (ENIG), University of Gabes, Gabes, Tunisia

Keywords:

Human Activity Recognition, 3D Skeleton, Spatio-temporal Features, View-invariant, Transformer.

Abstract:

With the emergence of depth sensors, real-time 3D human skeleton estimation have become easier to accom-

plish. Thus, methods for human activity recognition (HAR) based on 3D skeleton have become increasingly

accessible. In this paper, we introduce a new approach for human activity recognition using 3D skeletal data.

Our approach generates a set of spatio-temporal and view-invariant features from the skeleton joints. Then,

the extracted features are analyzed using a typical Transformer encoder in order to recognize the activity. In

fact, Transformers, which are based on self-attention mechanism, have been successful in many domains in the

last few years, which makes them suitable for HAR. The proposed approach shows promising performance on

different well-known datasets that provide 3D skeleton data, namely, KARD, Florence 3D, UTKinect Action

3D and MSR Action 3D.

1 INTRODUCTION

Many computer vision applications, such as intelli-

gent surveillance, human-computer interaction, and

robotics, rely on Human Action Recognition or HAR

for short. Despite tremendous improvements, pre-

cisely predicting what humans do in unseen videos

remains a difﬁcult task due to a variety of difﬁculties,

such as viewpoint changes, intra-class variation, and

environment distractions. Currently, depth sensor-

based HAR is regarded as one of the most promis-

ing approaches for solving the aforementioned chal-

lenges. Depth sensors that are inexpensive can pro-

vide 3D structural information of the human body,

which is proven useful for the HAR task. Most of

these sensors, in particular, have real-time skeleton

estimation algorithms (Shotton et al., 2013) that are

resistant to distractions in the environment. As a

result, using skeletal data for HAR opens up possi-

bilities for overcoming RGB and depth modalities’

constraints. Therefore, there are two major concerns

that need to be addressed for skeleton-based action

recognition. The ﬁrst problem is ﬁguring out how to

turn raw skeletal sequences into a useful representa-

tion that can capture the spatio-temporal dynamics of

human motions. The second step is to use the mo-

tion representation acquired from skeletons to model

and recognize actions. HAR based on hand-crafted

features and HAR based on deep learning models

are the two primary groupings of previous works on

this topic. The ﬁrst set of approaches extracts hand-

crafted local information from skeletal joints and em-

ploys probabilistic graphical models to represent and

categorize actions, such as the Hidden Markov Model

(HMM) (Lv and Nevatia, 2006), Conditional Random

Field (CRF) (Han et al., 2010), and Fourier Temporal

Pyramid (FTP) (Vemulapalli et al., 2014). Many ap-

proaches for skeleton-based action recognition (Xia

et al., 2012)(Vemulapalli et al., 2014)(Wang et al.,

2014)(Wu and Shao, 2014)(Wang et al., 2016) have

been presented since the ﬁrst study on 3D HAR us-

ing depth data (Li et al., 2010). These approaches

all have one thing in common: they extract geometric

features from the 3D coordinates of the skeletal joints

and use a generative model to describe their temporal

information. Despite the promising results of these

approaches, most of them can be easily affected by

the change of Kinect’s viewpoint. In order to meet

with the view variance problem, we propose in this

paper a view-invariant approach based on the extrac-

tion of spatio-temporal geometric features from 3D

skeleton data after changing the reference point from

the Kinect center to one of the skeleton’s keypoints.

The second group treats skeleton-based action

recognition as a time-series problem and recommends

that the temporal evolutions of skeletons be analyzed

using Recurrent Neural Networks with Long Short-

Term Memory units (RNN-LSTMs). For that mat-

706

Snoun, A., Bouchrika, T. and Jemai, O.

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features.

DOI: 10.5220/0010895300003122

In Proceedings of the 11th International Conference on Pattern Recognition Applications and Methods (ICPRAM 2022), pages 706-715

ISBN: 978-989-758-549-4; ISSN: 2184-4313

ter, many works used RNN-LSTMs to model the

activity and have obtained good results (Du et al.,

2015)(Zhu et al., 2016)(Liu et al., 2016)(Liu et al.,

2017)(Peng et al., 2021). Despite the good perfor-

mance of RNN-LSTMs, recent studies tend to change

them with Transformer (Vaswani et al., 2017), which

has been one of the most important deep learning

introductions for natural language processing (NLP)

in recent years. In addition to NLP, self-attention

mechanism has been shown to be effective for a va-

riety of tasks, including image classiﬁcation (Doso-

vitskiy et al., 2020), generative adversarial networks

(Lin et al., 2018), and speech recognition (Berg et al.,

2021), which proves that this architecture is equally

appropriate for HAR. In this paper, we use a pure

Transformer encoder architecture to analyze the view-

invariant spatio-temporal features extracted from 3D

skeletal data.

This work’s primary contributions can be summa-

rized as follows:

• Transformation of the coordinate system ori-

gin from the kinect center to the head and

spine: we propose a view-invariant approach

for HAR by changing the reference point of the

Kinect camera to the spine and head of the human

skeleton and thus the coordinates of the remaining

keypoints will be relative to the spine and the head

of the skeleton and not the camera and therefore

will not be affected by the change of the kinect’s

view.

• Generation of spatio-temporal features: we ex-

tract spatio-temporal features from the 3D skeletal

data. The spatial features are the 3D coordinates

of the joints relative to both the head and the spine

and the distances between the keypoints and the

head and spine. However, the temporal features

are the movement angles as well as the movement

type of each joint between each two frames.

• Analyzing the extracted features with Trans-

former encoder: we introduce a new HAR sys-

tem based on the transformer encoder and we

demonstrate that fully self-attention architectures

outperform other models in the HAR task.

The remainder of this paper will be as follows:

Section 2 is dedicated to review the works of the lit-

erature. We explain in section 3 the different aspects

of the proposed approach. Section 4 is reserved to

present and discuss the experimental results. Finally,

we conclude and propose future works in section 5.

2 RELATED WORKS

In recent decades, researchers have looked into sev-

eral compact representations of human activity. Jo-

hansson’s experiment from 1975 shown that individ-

uals can perceive activity with very little observers

(Johansson, 1975). A sequence of a person walking

in a dark room with lights mounted to the individ-

ual’s major joints was used by Johansson to explain

his point. Despite the fact that just light specks were

seen, the 3D motion in these clips was clearly dis-

cernible. Therefore, various works in the literature

widely used skeletal data to recognize human activ-

ities. These methodologies are known as skeleton-

based HAR. The input to these systems is made up of

a series of points that represent body joints. Skele-

tons can be represented in the 2D space (Jlidi et al.,

2020)(Snoun et al., 2021) of the image view or 3D

space, such as those generated with Kinetic sensors.

In this work, we focus on 3D pose information since

it gives a better representation of the human pose and

motion.

Devanne et al. (Devanne et al., 2013) suggested

spatio-temporal motion trajectories to model human

actions. The distance between two curves is then rep-

resented using an elastic metric, which is a metric

that is invariant to the speed and time of the action

within a Riemannian form space. Finally, using a k-

Nearest-Neighbor (k-NN) classiﬁer, the action recog-

nition task was viewed as a classiﬁcation in Rieman-

nian space. In (Gan and Chen, 2013), the relative lo-

cations and local spherical angles of the APJ3D repre-

sentation are computed using a selection of 15 skele-

tal joints. Following the key postures selection, they

used an updated Fourier Temporal Pyramid (Wang

et al., 2012) and random forests to classify the ac-

tion. Another technique for modeling joints is HOJ3D

(Xia et al., 2012), which divides the 3D space into

n bins and uses a Gaussian weight function to con-

nect the joints with each bin. Then, using a clustering

approach, a discrete Hidden Markov Model (HMM)

is used to model the postures’ evolution in time. A

human activity can also be described by a mixture

of static skeleton features, which reﬂect the current

frame, successive motion features, which are com-

puted using the current and prior frames, and overall

dynamics features, which take into account the cur-

rent and previous frames (Yang and Tian, 2014). In

(Kim and Kim, 2015), a view-invariant method for

HAR was proposed, it is based on pose estimation

using 3D body pose stream. To model the activi-

ties, the authors extracted motion, structure and hand

positions from joints coordinates. To make their ap-

proach view-invariant, the generated 2D spherical co-

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features

707

ordinates based on polar angle and azimuthal angle,

and they calculated relative positions of left and right

hand by head and torso. The extracted features were

analyzed with a Hidden-state Conditional Random

Field (HCRF) to recognize the activity. The joint’s

spherical coordinates were used also by Taha et al.

(Taha et al., 2015) to describe the skeleton. Then, a

multiclass SVM and a discrete HMM were used to

distinguish activities made up of several actions. Oth-

ers used also a combined machine learning algorithm

to classify actions, such as Gaglio et al. (Gaglio et al.,

2015), who used a multiclass SVM to model postures

and a discrete HMM to describe an action as a suc-

cession of poses. Human activities are also viewed

as a temporal ﬂow of body poses (Theodorakopoulos

et al., 2013), and skeletal data is processed to create

invariant pose representations, which are represented

by eight pairs of angles.

Deep learning and speciﬁcally RNN and LSTM

were widely used in the literature in the aim of HAR.

For example, an end-to-end RNN with handmade sub-

nets was proposed by Du et al. (Du et al., 2015). The

raw locations of body joints are separated into ﬁve

pieces and fed into ﬁve bidirectional RNNs accord-

ing to human structure. The network hierarchically

merged the representations derived by the subnets to

a higher-level representation as the layers number in-

creased. Zhu et al. (Zhu et al., 2013) used LSTM

to analyze the skeletal sequence. The LSTM input

consists of the 3D concatenated locations of skele-

tal joints in a frame for each step. They used a set

of encoded feature vectors to model a feature mani-

fold. Finally, the manifold was used to help and reg-

ularize LSTM supervised learning for action recogni-

tion using RGB video. A 2D Spatio-Temporal LSTM

framework was developed in (Liu et al., 2018) to in-

vestigate the hidden sources of activity-related con-

text information in both the temporal and geographi-

cal domains. They also suggested a trust gate method

that would deal with the depth sensors’ imprecise 3D

joint coordinates. More recently, Noori et al. (Noori

et al., 2019) proposed a HAR approach based on mo-

tion features extracted from skeletal data. Therefore,

they extracted the magnitude and angle of each joint

in the human body. To classify the extracted features,

they used an RNN-LSTM based network.

Unlike earlier techniques, we introduce, in this

paper, an architecture for HAR that is based purely

on the Transformer encoder (Vaswani et al., 2017),

with no convolutional or recurrent layers. To train

the transformer, we used spatio-temporal features

extracted from 3D joints coordinates of the human

skeleton. To deal with the view variance problem, we

generated new joints coordinates relative to the head

and spine of the human body instead of the camera

position. Hence, the activity recognition process will

not be affected by the change of the camera view.

3 METHODOLOGY

The human body is an articulated system of rigid

segments connected by joints, and human action is

thought to be a continuous evolution of the spatial

and temporal conﬁguration of these segments (skele-

tons). Therefore, we design a system based on spatio-

temporal features extracted from the body joints to

recognize human activity. To emphasize, as illus-

trated in Figure 1, the designed system starts with 3D

skeletons as input. Then, we extract spatio-temporal

geometric features from the skeletal data to better

model the spatial and temporal ﬂow of the human

body that represents the activity. The extracted fea-

tures are analyzed later with a Transformer encoder

in order to output the activity label.

3.1 Spatio-temporal Features

Generation

This step consists in generating a vector of view-

invariant spatio-temporal geometric features from

each skeleton of the input sequence. Therefore, Mi-

crosoft’s Kinect API directly provides a set of 3D

joint locations, which may be calculated from depth

images acquired from the Kinect sensor. The 3D po-

sition (x, y, z) of each joint provided by the Kinect

API, on the other hand, is represented using the Carte-

sian coordinate system, with the origin (0, 0, 0) in

the Kinect sensor’s center. As a result, if either the

Kinect sensor or the target object moves, the 3D posi-

tion data of a joint can be simply altered. This means

that the 3D joint coordinates obtained straight from

the Kinect API are extremely sensitive to Kinect’s

view variation, and hence are ineffective characteris-

tics for reliably identifying daily human activities in

a variety of environments. The problem of view vari-

ance is depicted in Figure 2. If the position of Kinect

is changed, the corresponding position value of the

same joint collected by the Kinect sensor will not be

the same (P

= (x

, y

, z

) 6= P

= (x

, y

, z

)).

To prevent the view variance problem, we change

the origin of the coordinate system form the center of

the Kinect sensor to the spine and head of the skele-

ton, as shown in Figure 3. Therefore, the positions

of the different joints will be relative to the spine and

head and no longer to the Kinect sensor. Thus, the

change of this latter’s position will not affect anymore

the reliability of the skeletons coordinates. Here, we

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

708

Figure 1: Overview of the HAR architecture based on spatio-temporal geometric features and Transformer Encoder (left) and

Transformer encoder layer architecture (right).

Figure 2: Illustration of the view variance problem.

chose the head and spine as the new centers of the co-

ordinate system because they have less motion com-

pared to the hands and legs and by consequence, they

are less involved in the human motion. To translate

the coordinate system origin to the head and spine,

we multiplied each joint position (x

, y

, z

) by the

translation matrix as represented in equations 1 and 2.







ˆx

ˆy

ˆz













1 0 0 −x

head

0 1 0 −y

head

0 0 1 −z

head

0 0 0 1







∗













(1)







ˆx

ˆy

ˆz













1 0 0 −x

spine

0 1 0 −y

spine

0 0 1 −z

spine

0 0 0 1







∗













(2)

Once we obtain the set of joints coordinates rela-

tive to head and spine, we compute a set of spatial and

temporal features.

Figure 3: Transformation of the coordinate system origin

from the kinect sensor to the head and spine.

3.1.1 Spatial Features

The best way to model the spatial structure of the

skeleton is to calculate the distance between each

joint of the skeleton and the head in a ﬁrst time and

the spine in a second time as illustrated in Figure

4. Therefore, we calculate the Euclidean distance

between each joint j of each frame t and the head

Figure 4: Spatial features generation. (left) Distances be-

tween each joint and the head. (right) distances between

each joint and the spine.

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features

709

jt head

) and the distance between each joint j of

each frame t and the spine (D

jt spine

) using respec-

tively equations 3 and 4:

jt head

−x

head

)

+ (y

−y

head

)

+ (z

−z

head

)

(3)

jt spine

−x

spine

)

+ (y

−y

spine

)

+ (z

−z

spine

)

(4)

3.1.2 Temporal Features

The temporal features of a joint j in a frame t are ob-

tained by computing the movement angles and move-

ment direction compared to the same joint in the pre-

vious frame t −1, as shown in Figure 5.

Figure 5: Temporal features generation.

Let j

, y

, z

) be the position of joint j in

frame t and j

t−1

jt−1

, y

jt−1

, z

jt−1

) be the position of

joint j in frame t −1. The movement angle of a joint

j in a frame t (θ

) is calculated using the following

equation:

= cos

−1

(

→

O j

→

O j

t−1

O j

t−1

) (5)

Where O = (0, 0, 0) is the origin of the coordinate

system (head or spine),

O j

+ y

+ z

and

O j

t−1

jt−1

+ y

jt−1

+ z

jt−1

The movement direction is a combination of

three possible directions (Right/left, up/down and for-

ward/backward), for example, a joint j in a frame t

can move right/down/forward. To ﬁnd the movement

direction of a joint j in a frame t, we compare the co-

ordinates (x

, y

, z

) of joint j in a frame t with the

coordinates (x

jt−1

, y

jt−1

, z

jt−1

) of the joint j in the

frame t −1. If x

> x

jt−1

then the movement is right,

else if x

< x

jt−1

then the movement is left, other-

wise there is no movement. The same is applied for

y to determine if the movement is up or down and z

for forward and backward. Finally, we encoded the

movement direction as follows: Right (1), left (2),

up (1), down (2), forward (1), backward (2) and no

movement (0). For instance, if the movement direc-

tion is right/down/forward, the code will be 121.

Once we compute the spatial and temporal fea-

tures, the input vector to the Transformer encoder will

be composed of the transformed 3D coordinates of the

joints relative to the head and spine, the distances be-

tween each joint and the head as well as the spine,

the movements angles between each two frames of

each joint and the movement direction of each joint

between each two frames.

3.2 Transformer Encoder Architecture

In (Vaswani et al., 2017), Transformer networks were

ﬁrst used for machine translation. The encoder and

decoder are the two main elements of the transformer

network. An input sequence (source) is received by

the encoder, which is processed by a stack of identi-

cal layers, including a multi-head self-attention layer

and a fully-connected feed-forward network. The en-

coder’s representation is then used by a decoder to

construct an output sequence (target). For classiﬁ-

cation purpose, it is recommended to use only the

Transformer encoder. Therefore, to classify our in-

put sequence, we use a typical encoder architecture.

As illustrated in the right of Figure 1, the transformer

encoder layer E is composed of multi-head self-

attention and feed-forward blocks. After each block,

Dropout, LayerNorm, and residual connections are

applied. Each feed-forward block is a two-layer per-

ceptron ( f f ) with GeLu (Hendrycks and Gimpel,

2016) as non-linearity. In the proposed implemen-

tation, the ﬁrst layer uses non-linearity and expands

the dimension from D

model

to D

ml p

= 2 ∗D

model

. The

second layer, on the other hand, reduces the dimen-

sion from D

ml p

to D

model

is the length of the

input features vector).

By passing the input via a LayerNorm (LN) be-

fore each module and putting it back with residual

connections, each layer E in the Transformer Encoder

performs the following computation:

E(S) = LN(S + Dropout(MHA(S))) (6)

E(S) = LN(

E(S) + Dropout( f f (

E(S)))) (7)

Where f f (X) = Linear(Dropout(GeLu(Linear(X))))

denotes the feed-forward block explained above,

MHA is the Multi-head self-attention block and S

in the input sequence. In our case, S is a set of

spatio-temporal features vectors extracted from the

skeleton joint as explained in the previous section,

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

710

summed with a positional embedding matrix that

represents the positionality information.

The transformer network’s self-attention mecha-

nism is a critical component. The architecture of the

self-attention mechanism block is shown in Figure 6.

Therefore, a function that expresses a weighted sum

of the values V is called attention A. The weights are

determined by comparing a query Q to a collection

of keys K. The scaling dot-product is the most used

form of the matching function. Attention with the

scaled dot-product matching function (A), which is il-

lustrated in the right of Figure 6, is written in formal

terms as:

A(Q,V, K) = Softmax(

√

)V (8)

Where d denotes the dimension of both queries and

keys.

The Multi-head attention MHA is an extension of

attention that uses independent linear projections h

(Q, K,V ) to create numerous parallel attention func-

tions:

MHA(Q,V, K) = Concat(h

, ..., h

)W (9)

= A(QW

, KW

,VW

) (10)

Finally, the output of the transformer encoder E(S)

is fed into a linear classiﬁcation head (MLP

head

) af-

ter applying a residual connection in order to allow

the gradients to ﬂow through the network directly and

enhance the performance. The computation of the

MLP

head

is as follows:

ˆy = MLP

head

(S + E(S)) (11)

Where ˆy are the output logits, which are passed later

to a Softmax activation function in order to ﬁnd the

ﬁnal activity.

4 EXPERIMENTAL RESULTS

4.1 Used Datasets

The KARD dataset (Gaglio et al., 2015) contains 18

activities divided into 10 gestures and eight actions.

This dataset was collected in an ofﬁce environment

with a Kinect camera placed 2-3 meters away from

the person. The activities were carried out by 10 peo-

ple (nine males and one female). Each person re-

peated each activity three times, resulting in 540 se-

quences. The dataset provides 15 skeleton joints in

world and screen coordinates.

The Florence3D dataset (Seidenari et al., 2013)

includes 9 different activities: waving, drinking from

a bottle, answering the phone, clapping, tightening

lace, sitting, standing up, reading a watch, and bow-

ing. These activities were carried out by 10 different

subjects twice or three times, for a total of 215 se-

quences. The activities were captured in a variety of

settings, and only RGB videos and 15 skeleton joints

are available.

The UTKinect dataset (Xia et al., 2012) con-

sists of ten different subjects (nine males and one fe-

male) performing ten different activities twice. The

dataset includes the following activities: walking, sit-

ting down, standing up, picking up, carrying, throw-

ing, pushing, pulling, waving, and clapping hands.

Since there is one unlabeled sequence, a total of 199

sequences are available, with sample actions ranging

in length from 5 to 120 frames. The dataset con-

tains 20 skeleton joints captured with the Kinect sen-

sor with a rate of 15 fps.

Finally, one of the most commonly used datasets

for HAR is the MSR Action 3D (Li et al., 2010).

It consists of 20 activities performed twice or three

times by 10 subjects. There are 567 skeleton frame

sequences in total; each skeleton is composed of 20

joints. High arm waving, horizontal arm waving,

hammering, hand catching, forward punching, high

throwing, drawing X, drawing tick, drawing circle,

hand clapping, two hand waving, side boxing, bend-

ing, forward kicking, side kicking, jogging, tennis

swinging, tennis serving, golf swinging, and pick-

ing up and throwing are all activities included in the

dataset. The data was collected at 15 fps with a

structured-light depth camera.

4.2 Obtained Results

To validate our approach, we followed the evalua-

tion protocol used by previous works for each of the

above-mentioned datasets.

4.2.1 KARD Dataset

Three different experiments on ﬁve different activities

groups of the dataset were proposed by the collectors

of the KARD dataset (Gaglio et al., 2015). The ex-

periments are as follows:

• Experiment A: Train/Test split: 30/70%

• Experiment B: Train/Test split: 70/30%

• Experiment C: Train/Test split: 50/50%

The dataset’s activities are divided into the following

categories:

• Gestures: horizontal arm waving, high arm wav-

ing, two hand waving, high throwing, drawing x,

drawing tick, forward kicking, side kicking, bend-

ing, hand clapping

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features

711

Figure 6: Multi-head self-attention block (left) and Scaled dot-product attention block (right).

• Actions: catching cap, tossing paper, taking um-

brella, walking, phone calling, drinking, sitting

down, standing up

• Activity Set 1: horizontal arm waving, two hand

waving, bending, phone calling, standing up, for-

ward kicking, drawing x, walking

• Activity Set 2: high arm waving, side kicking,

catching cap, drawing tick, hand clapping, for-

ward kicking, bending, sitting down

• Activity Set 3: drawing tick, drinking, sitting

down, phone calling, taking umbrella, tossing pa-

per, high throwing, horizontal arm waving

Each group was tested three times following the

three evaluation strategies mentioned earlier. The re-

sults of Gestures and Actions categories are reported

in Table 1. According to the results, we notice that

for Gestures, the evaluation protocol B, where the 2/3

of the data is used to train the model and the rest to

test it, outperforms the two other protocols. In fact,

Experiment B outperforms the two other experiments

in all of the groups (see Table 1 and Table 2), which

means giving more data for training helps to improve

the recognition performance. We notice also that the

Actions set seems to be easier to analyze since the

results of the three experiments outperform the three

experiments in the Gestures group. This can be ex-

plained by the fact that in the Actions set most of the

body joints are engaged in the activity, unlike the Ges-

tures where only few joints are engaged.

Table 2 summarizes the results of the Activity Set

tests. It is shown that Activity Set 1 and 2, which seem

to be the simplest ones, have good recognition results

compared to Activity Set 3. The reported results show

also that the proposed approach outperforms the orig-

inal work proposed in (Gaglio et al., 2015), which

is based on the use of a discrete HMM to describe

an activity as a succession of poses and a multiclass

SVM to classify poses. It outperforms also the work

in (Cippitelli et al., 2016), which is based on the ex-

traction of key poses to create a feature vector and

classiﬁcation using a multiclass SVM.

Finally, the “new-person” evaluation protocol is

also performed. This scenario consists in using nine

of the ten persons of the dataset to train the model and

using the remaining person to test. Therefore, since

there is no recommendation on how split the dataset,

we used the 18 activities to perform the “new-person”

scenario. The obtained results are reported in Table

3. We notice that our model outperforms the works

in (Gaglio et al., 2015) and (Cippitelli et al., 2016)

by respectively 11% and 1% in terms of precision and

recall.

4.2.2 Florence 3D Dataset

The leave-one-actor-out setting, which is equivalent

to the previously described ”new-person” setting, is

used to evaluate this dataset. The obtained results us-

ing the proposed transformer approach as well as a

comparison with the works of the state-of-the-art are

drawn in Table 4. The proposed approach achieved an

accuracy equals to 91%. We notice that our accuracy

is less than the accuracy (96.2%) reported in (Taha

et al., 2015). However, the proposed approach out-

performs the other mentioned literature works, such

as the work in (Seidenari et al., 2013), which uses a

bag-of-poses to model the skeleton data, and the work

in (Vemulapalli et al., 2014) which uses Lie Group to

model the human action as a curve.

In fact, the Florence 3D dataset is challenging due

to the high interclass similarity, which means the exis-

tence of similar activities like drink from a bottle and

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

712

Table 1: Accuracy (%) of the proposed approach on the KARD dataset with the dataset split in Gestures and Actions using

different experiments.

Gestures Actions

A B C A B C

(Gaglio et al., 2015) 86.5 93.0 86.7 92.5 95.0 90.1

(Cippitelli et al., 2016) 89.9 95.9 93.7 99.1 99.9 99.4

Transformer (ours) 96.7 100 97.3 98.8 100 100

Table 2: Accuracy (%) of the proposed approach on the KARD dataset with different Activity Sets using different experiments.

Activity Set 1 Activity Set 2 Activity Set 3

A B C A B C A B C

(Gaglio et al., 2015) 95.1 99.1 93.0 89.0 94.9 90.1 84.2 89.5 81.7

(Cippitelli et al., 2016) 98.2 99.0 98.1 99.8 100 99.7 91.6 95.8 93.3

Transformer (ours) 98.8 100 99.17 100 100 100 94.5 98.6 95.0

Table 3: Precision (%) and recall (%) of the proposed ap-

proach on the KARD dataset using the ”new-person” set-

ting.

Precision Recall

(Gaglio et al., 2015) 84.8 84.5

(Cippitelli et al., 2016) 95.1 95.0

Transformer (ours) 96.7 96.3

Table 4: Accuracy (%) of the proposed approach on the

Florence 3D dataset using the ”new-person” setting.

Accuracy

(Seidenari et al., 2013) 82.0

(Vemulapalli et al., 2014) 90.9

(Taha et al., 2015) 96.2

(Cippitelli et al., 2016) 86.1

Transformer (ours) 91.0

answer phone, and also the high intraclass similarity

which means that an action can be performed in dif-

ferent ways by the same person like using once the

left hand and once the right hand to perform the same

activity.

4.2.3 UTKinect Action 3D Dataset

As in the case of the Florence 3D dataset, the work in

(Xia et al., 2012) proposed the leave-one-out cross-

validation (LOOCV) evaluation protocol, which is

similar to the “new-person” protocol. Table 5 shows

the obtained results on this dataset compared to pre-

vious works. The results show that the work in (Vem-

ulapalli et al., 2014) produced the best accuracy, but

their approach is very complex since they model the

skeleton in a Lie group and then, before classiﬁca-

tion with one-versus-all multiclass SVM, they pro-

cess it with Dynamic Time Wrapping to achieve tem-

poral alignments and a special representation known

as the Fourier Temporal Pyramid. In the other hand,

our approach outperforms the original work on this

dataset (Xia et al., 2012) with 3.1% in term of accu-

racy. The key performance constraint with this dataset

is the limited number of frames that some sequences

contain compared to other sequences, which can de-

crease the results dramatically.

Table 5: Accuracy (%) of the proposed approach on the

UTKinect Action 3D dataset using the LOOCV setting.

Accuracy

(Xia et al., 2012) 90.9

(Theodorakopoulos et al., 2013) 90.95

(Zhu et al., 2013) 91.9

(Gan and Chen, 2013) 92.0

(Vemulapalli et al., 2014) 97.1

(Cippitelli et al., 2016) 95.1

(Liu et al., 2017) 92.0

Transformer (ours) 94.0

4.2.4 MSR Action 3D Dataset

In the literature, there is a lot of uncertainty on which

validation parameters should be used with MSR Ac-

tion 3D dataset. Padilla-Lopez et al. (Padilla-L

opez

et al., 2014) suggested employing all feasible com-

binations of 5-5 subject splitting, which consists in

using 252 combinations of 5 persons for training

and 5 persons for testing, or using leave-one-actor-

out (LOAO) protocol, which is similar to the “new-

person” scenario. Here, we considered the “new-

person” protocol since it is used by most of the works

in the literature. According to the results reported

in Table 6, we were able to reach an accuracy of

93%, which is better than all of the previous works.

Therefore, the work in (Azary and Savakis, 2013)

proposed an approach based on skeleton data. How-

ever, Chaaraoui et al. (Chaaraoui et al., 2013) used

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features

713

more advanced techniques, such as the fusion of depth

and skeleton data, or selection of the best set of

joints. More recent works exploits subspace cluster-

ing and temporal pruning to recognize activity (Pao-

letti et al., 2021). The work in (Zhao et al., 2019)

proposed a bayesian hierarchical dynamic model for

action recognition. Finally, a Graph based skeleton

model is used in (Kao et al., 2019) to recognize the

human activity.

Table 6: Accuracy (%) of the proposed approach on the

MSR Action 3D dataset using the LOAO setting.

Accuracy

(Azary and Savakis, 2013) 78.5

(Chaaraoui et al., 2013) 90.6

(Cippitelli et al., 2016) 81.2

(Zhao et al., 2019) 86.1

(Kao et al., 2019) 74

(Paoletti et al., 2021) 88.51

Transformer (ours) 93.0

5 CONCLUSION

In this paper, a view-invariant HAR approach based

on 3D skeleton data has been proposed. A spatio-

temporal features generation step has been imple-

mented. Therefore, after translating the origin of the

skeleton’s coordinate system from the center of the

camera to the head and spine in order to prevent the

view variance problem, we compute the distances be-

tween each joint and the new origins and the move-

ment angles as well as the movement direction of each

joint between each two consecutive frames of the in-

put sequence. The extracted features are then ana-

lyzed by a pure Transformer Encoder in order to rec-

ognize the activity associated to these features. Our

approach shows improvements compared to most of

the state-of-the-art approaches after being tested on

the KARD, Florence 3D, UTKinect Action 3D and

MSR Action 3D datasets. In future works, we aim

to use more sophisticated methods like Graph Neu-

ral Networks since the human skeleton can be eas-

ily modeled as a graph and evaluate bigger and more

challenging datasets such as NTU-RGB-D dataset.

ACKNOWLEDGEMENTS

The authors would like to acknowledge the ﬁnancial

support of this work by grants from General Direction

of scientiﬁc Research (DGRST), Tunisia, under the

ARUB program.

REFERENCES

Azary, S. and Savakis, A. (2013). Grassmannian sparse rep-

resentations and motion depth surfaces for 3d action

recognition. In 2013 IEEE Conference on Computer

Vision and Pattern Recognition Workshops, pages

492–499.

Berg, A., O’Connor, M., and Cruz, M. T. (2021). Keyword

transformer: A self-attention model for keyword spot-

ting. ArXiv, abs/2104.00769.

Chaaraoui, A. A., Padilla-L

opez, J. R., and Fl

orez-Revuelta,

F. (2013). Fusion of skeletal and silhouette-based fea-

tures for human action recognition with rgb-d devices.

2013 IEEE International Conference on Computer Vi-

sion Workshops, pages 91–97.

Cippitelli, E., Gasparrini, S., Gambi, E., and Spinsante, S.

(2016). A human activity recognition system using

skeleton data from rgbd sensors. Computational In-

telligence and Neuroscience, 2016.

Devanne, M., Wannous, H., Berretti, S., Pala, P., Daoudi,

M., and Del Bimbo, A. (2013). Space-time pose rep-

resentation for 3d human action recognition. page

456–464.

Dosovitskiy, A., Beyer, L., Kolesnikov, A., Weissenborn,

D., Zhai, X., Unterthiner, T., Dehghani, M., Min-

derer, M., Heigold, G., Gelly, S., Uszkoreit, J., and

Houlsby, N. (2020). An image is worth 16x16 words:

Transformers for image recognition at scale. CoRR,

abs/2010.11929.

Du, Y., Wang, W., and Wang, L. (2015). Hierarchical recur-

rent neural network for skeleton based action recogni-

tion. 2015 IEEE Conference on Computer Vision and

Pattern Recognition (CVPR), pages 1110–1118.

Gaglio, S., Re, G. L., and Morana, M. (2015). Human activ-

ity recognition process using 3-d posture data. IEEE

Transactions on Human-Machine Systems, 45:586–

597.

Gan, L. and Chen, F.-T. (2013). Human action recognition

using apj3d and random forests. J. Softw., 8:2238–

2245.

Han, L., Wu, X., Liang, W., Hou, G., and Jia, Y.

(2010). Discriminative human action recognition in

the learned hierarchical manifold space. Image Vision

Comput., 28(5):836–849.

Hendrycks, D. and Gimpel, K. (2016). Bridging nonlin-

earities and stochastic regularizers with gaussian error

linear units. CoRR, abs/1606.08415.

Jlidi, N., Snoun, A., Bouchrika, T., Jemai, O., and Zaied,

M. (2020). PTLHAR: PoseNet and transfer learning

for human activities recognition based on body articu-

lations. In 12th International Conference on Machine

Vision (ICMV 2019), volume 11433, pages 187 – 194.

Johansson, G. (1975). Visual motion perception. Scientiﬁc

American, 232 6:76–88.

Kao, J.-Y., Ortega, A., Tian, D., Mansour, H., and Vetro,

A. (2019). Graph based skeleton modeling for human

activity analysis. In 2019 IEEE International Confer-

ence on Image Processing (ICIP), pages 2025–2029.

Kim, H. and Kim, I. (2015). Human activity recognition as

ICPRAM 2022 - 11th International Conference on Pattern Recognition Applications and Methods

714

time-series analysis. Mathematical Problems in Engi-

neering, 2015:1–9.

Li, W., Zhang, Z., and Liu, Z. (2010). Action recognition

based on a bag of 3d points. In 2010 IEEE Computer

Society Conference on Computer Vision and Pattern

Recognition - Workshops, pages 9–14.

Lin, C.-H., Yumer, E., Wang, O., Shechtman, E., and Lucey,

S. (2018). St-gan: Spatial transformer generative

adversarial networks for image compositing. 2018

IEEE/CVF Conference on Computer Vision and Pat-

tern Recognition, pages 9455–9464.

Liu, J., Shahroudy, A., Xu, D., Kot, A. C., and Wang,

G. (2018). Skeleton-based action recognition using

spatio-temporal lstm network with trust gates. IEEE

Transactions on Pattern Analysis and Machine Intel-

ligence, 40:3007–3021.

Liu, J., Shahroudy, A., Xu, D., and Wang, G. (2016).

Spatio-temporal lstm with trust gates for 3d human ac-

tion recognition. ArXiv, abs/1607.07043.

Liu, J., Wang, G., Hu, P., Duan, L.-Y., and Kot, A. C.

(2017). Global context-aware attention lstm networks

for 3d action recognition. In Proceedings of the IEEE

Conference on Computer Vision and Pattern Recogni-

tion (CVPR).

Lv, F. and Nevatia, R. (2006). Recognition and segmenta-

tion of 3-d human action using hmm and multi-class

adaboost. In Leonardis, A., Bischof, H., and Pinz, A.,

editors, Computer Vision – ECCV 2006, pages 359–

372, Berlin, Heidelberg. Springer Berlin Heidelberg.

Noori, F. M., Wallace, B., Uddin, M. Z., and Tørresen, J.

(2019). A robust human activity recognition approach

using openpose, motion features, and deep recurrent

neural network. In SCIA.

Padilla-L

opez, J. R., Chaaraoui, A. A., and Fl

orez-Revuelta,

F. (2014). A discussion on the validation tests em-

ployed to compare human action recognition methods

using the msr action3d dataset. ArXiv, abs/1407.7390.

Paoletti, G., Cavazza, J., C¸ i

gdem Beyan, and Bue, A. D.

(2021). Subspace clustering for action recognition

with covariance representations and temporal prun-

ing. 2020 25th International Conference on Pattern

Recognition (ICPR), pages 6035–6042.

Peng, W., Shi, J., Varanka, T., and Zhao, G. (2021). Re-

thinking the st-gcns for 3d skeleton-based human ac-

tion recognition. Neurocomputing, 454:45–53.

Seidenari, L., Varano, V., Berretti, S., Bimbo, A., and Pala,

P. (2013). Recognizing actions from depth cameras as

weakly aligned multi-part bag-of-poses. 2013 IEEE

Conference on Computer Vision and Pattern Recogni-

tion Workshops, pages 479–485.

Shotton, J., Sharp, T., Kipman, A., Fitzgibbon, A., Finoc-

chio, M., Blake, A., Cook, M., and Moore, R. (2013).

Real-time human pose recognition in parts from sin-

gle depth images. Communications of the ACM,

56(1):116–124.

Snoun, A., Jlidi, N., Bouchrika, T., Jemai, O., and Zaied,

M. (2021). Towards a deep human activity recogni-

tion approach based on video to image transformation

with skeleton data. Multimedia Tools and Applica-

tions, 80:29675–29698.

Taha, A., Zayed, H. H., Khalifa, M. E., and El-Horbaty, E.-

S. M. (2015). Human activity recognition for surveil-

lance applications. In ICIT 2015.

Theodorakopoulos, I., Kastaniotis, D., Economou, G., and

Fotopoulos, S. (2013). Pose-based human action

recognition via sparse representation in dissimilarity

space. Journal of Visual Communication and Image

Representation, 25:12–23.

Vaswani, A., Shazeer, N. M., Parmar, N., Uszkoreit, J.,

Jones, L., Gomez, A. N., Kaiser, L., and Polo-

sukhin, I. (2017). Attention is all you need. ArXiv,

abs/1706.03762.

Vemulapalli, R., Arrate, F., and Chellappa, R. (2014). Hu-

man action recognition by representing 3d skeletons

as points in a lie group. In 2014 IEEE Conference

on Computer Vision and Pattern Recognition, pages

588–595.

Wang, J., Liu, Z., Wu, Y., and Yuan, J. (2012). Mining

actionlet ensemble for action recognition with depth

cameras. 2012 IEEE Conference on Computer Vision

and Pattern Recognition, pages 1290–1297.

Wang, P., Li, W., Ogunbona, P., Gao, Z., and ling Zhang, H.

(2014). Mining mid-level features for action recogni-

tion based on effective skeleton representation. 2014

International Conference on Digital Image Comput-

ing: Techniques and Applications (DICTA), pages 1–

Wang, P., Yuan, C., Hu, W., Li, B., and Zhang, Y. (2016).

Graph based skeleton motion representation and sim-

ilarity measurement for action recognition. In Leibe,

B., Matas, J., Sebe, N., and Welling, M., editors, Com-

puter Vision – ECCV 2016, pages 370–385, Cham.

Springer International Publishing.

Wu, D. and Shao, L. (2014). Leveraging hierarchical para-

metric networks for skeletal joints based action seg-

mentation and recognition. In Proceedings of the

IEEE Conference on Computer Vision and Pattern

Recognition (CVPR).

Xia, L., Chen, C.-C., and Aggarwal, J. K. (2012). View in-

variant human action recognition using histograms of

3d joints. 2012 IEEE Computer Society Conference on

Computer Vision and Pattern Recognition Workshops,

pages 20–27.

Yang, X. and Tian, Y. (2014). Effective 3d action recog-

nition using eigenjoints. Journal of Visual Communi-

cation and Image Representation, 25(1):2–11. Visual

Understanding and Applications with RGB-D Cam-

eras.

Zhao, R., Xu, W., Su, H., and Ji, Q. (2019). Bayesian hier-

archical dynamic model for human action recognition.

2019 IEEE/CVF Conference on Computer Vision and

Pattern Recognition (CVPR), pages 7725–7734.

Zhu, W., Lan, C., Xing, J., Li, Y., Shen, L., Zeng, W.,

and Xie, X. (2016). Co-occurrence feature learning

for skeleton based action recognition using regular-

ized deep lstm networks. page 8.

Zhu, Y., Chen, W., and Guo, G. (2013). Fusing spatiotem-

poral features and joints for 3d action recognition.

2013 IEEE Conference on Computer Vision and Pat-

tern Recognition Workshops, pages 486–491.

View-invariant 3D Skeleton-based Human Activity Recognition based on Transformer and Spatio-temporal Features

715
