Revisiting Ontology Based Access Control: The Case for Ontology Based

Data Access

Ozgu Can

and Murat Osman Unalir

Department of Computer Engineering, Ege University, 35100, Bornova-Izmir, Turkey

Keywords:

Access Control, Data Access, Privacy, Ontology, Semantic Web, Knowledge Engineering.

Abstract:

Ontology Based Data Access (OBDA) is a semantic paradigm to perform a mapping between an ontology

and a data source for querying heterogeneous data sources. The result of this mapping ensures data access

and data integration. Therefore, OBDA allows to query various datasets and provides data virtualization by

integrating multiple and varied data sources. Ontology Based Access Control (OBAC) enables the realization

of an access control mechanism by using Semantic Web technologies. OBAC allows to model the access

control knowledge and uses domain knowledge to create policy ontologies. This paper revisits the OBAC

approach by considering the OBDA to query legacy data that are stored in different types of data sources. For

this purpose, OBAC is examined within the scope of OBDA and a conceptual model is proposed to extend

OBAC with OBDA to provide data virtualization and to consolidate users’ access privileges. Thus, security

and management of complex information systems could be carried out by using Semantic Web technologies.

1 INTRODUCTION

In recent years, continuous improvements in

information technology and the interconnectedness

of systems led to the rapid growth in data volume.

Moreover, this huge amount of data are continuously

growing as data continues to come from many

sources like social media, the web, sensors, devices

and etc. In the information technology, bringing

information together, extracting information, and

using this extracted information to make strategic

decisions are major challenges. In this context, one

of the main problem is the lack of semantics in data

representation.

In today’s information systems, most of the data

and information are stored in relational databases.

The relational model is the de facto database

system for data accumulation and data processing

applications. In a relational database, data items and

their relationships are organized as a set of tables with

columns and rows. However, relational databases do

not provide the semantic meaning of concepts. For

this purpose, information should be represented with

a conceptualized model and the relationship between

concepts should be speciﬁed accurately (Haw et al.,

https://orcid.org/0000-0002-8064-2905

https://orcid.org/0000-0003-4531-0566

2017). In Semantic Web, information is semantically

annotated and the conceptualization of information

is provided (Martinez-Cruz et al., 2012). The core

of the Semantic Web is ontology. An ontology

which is deﬁned as “a formal, explicit speciﬁcation

of a shared conceptualization (Gruber, 1995)” is a

semantic data schema paradigm and provides the

conceptualization. An ontology deﬁnes concepts and

relationships between these concepts that are used

to describe a domain. Therefore, information is

represented in a machine-readable form and it can

be shared, reused, distributed, and used to make

deductions.

The mapping between a database and an ontology

is considered as a case of data integration (Haw et al.,

2017). In the mapping process, concepts of the

ontology are linked with the relevant entities in the

database. As most of the data and information are

stored and represented in databases, the mapping of

legacy relational data to ontology concepts enables

to retrieve more enriched query results and provide

effective data analytics. The mapping between a

relational database and Semantic Web is as follows:

a record is an RDF node, the ﬁeld (column) name is

RDF property type, and the record ﬁeld (table cell)

is a value (Berners-Lee, 2009). Ontology-Based Data

Access (OBDA) concerns answering queries over the

target ontology by using a source relational database,

Can, O. and Unalir, M.

Revisiting Ontology Based Access Control: The Case for Ontology Based Data Access.

DOI: 10.5220/0010898100003120

In Proceedings of the 8th International Conference on Information Systems Security and Privacy (ICISSP 2022), pages 515-518

ISBN: 978-989-758-553-1; ISSN: 2184-4356

515

a target OWL ontology and a mapping from the

relational database to the ontology (Sequeda, 2017).

Thus, OBDA presents a conceptual representation

of a domain and achieves data virtualization which

integrates data without moving and transforming

them (Xiao et al., 2019). As data virtualization

enables a centralized point of access, it brings

security requirements such as privacy, access control,

authentication, authorization, data integrity, and

effective mechanisms to ensure the security and

the privacy of the data. Ontology Based Access

Control (OBAC) aims to provide an access control

mechanism for the security requirements in Semantic

Web. OBAC allows to create, modify and query

semantically-rich policies (Can et al., 2010; Can,

2009; Can and Unalir, 2010). Therefore, ontology

based policies are speciﬁed over domain knowledge

and access to information is achieved by authorized

entities.

In this work, the OBAC model is enhanced with

OBDA. The aim is ensuring security and preserving

privacy while providing an efﬁcient processing of data

that exists in different heterogeneous sources. For this

purpose, the OBAC model is revisited with the OBDA

approach. In the proposed revised model: (i) OBDA

provides the abstraction of how data sources are

maintained in the data layer of the system itself (Poggi

and et al., 2008), and (ii) OBAC provides the security

and privacy of data by preventing unauthorized access

requests. Therefore, data virtualization will be

provided by achieving access control.

The remainder of this paper is organized as

follows: in Section 2, the recent studies in the ﬁeld

of ontology-based data access and ontology-based

access control are presented, the proposed conceptual

model is detailed in Section 3. Finally, Section

4 concludes the paper and summarizes the future

directions of the presented study.

2 RELATED WORK

The relation between database and Semantic Web

is a frequently studied impressive topic in the

literature. In order to access the existing data sources

ﬂexibly and efﬁciently, databases are mapped to

ontology representations. In (Haw et al., 2017),

steps to transform relational databases to ontology

representation are outlined and a review of some

of the mapping tools is presented by highlighting

their requirements. A method is proposed in

(Dadjoo and Kheirkhah, 2015) for automatic ontology

construction based on a relational database. The

presented method generates an ontology data model

from the relational database schema. The relationship

between relational databases and the Semantic Web

is investigated in (Sequeda, 2017). In this study, the

speciﬁc research question that is tried to be answered

is “How and to what extent can Relational Databases

be integrated with the Semantic Web?”. A survey is

presented in (Spanos et al., 2012) to review methods

and tools that bring relational databases into Semantic

Web. Moreover, the survey study also explores the

future perspectives of the ﬁeld. Ontology Based Data

Access (OBDA) is a prominent approach to establish

a mapping between a database and an ontology.

Thus, it simpliﬁes the process of data access and

enhances the quality of query results. In (Kharlamov

et al., 2017), data access challenges in the petroleum

company Statoil are presented, and an OBDA based

solution is developed. Similar to this study, OBDA

is applied to the energy technology database within

the technology forecasting information system in

(Mikheev, 2018). In (Hoehndorf et al., 2015), a

framework named Aber-OWL is developed to provide

reasoning services for bio-ontologies by enabling

ontology-based semantic access to biological data.

The developed reasoning infrastructure uses OBDA

to access information. In an EU FP7-funded project

named Optique (Kharlamov et al., 2013; Giese et al.,

2013), an end-to-end OBDA system is developed to

provide scalable end-user access to industrial Big

Data stores. The project focuses on two use cases: the

ﬁrst use case is provided by Siemens and the second

use case is provided by Statoil. In the Semantic Web,

access control is a challenging problem and access to

resources should be controlled to secure the Semantic

Web. An access control mechanism allows to deﬁne,

manage and enforce access conditions for resources.

In (He et al., 2010), the Role-Based Access Control

(RBAC) model is extended to implement an access

control mechanism for Semantic Web services. A

Semantic Based Access Control model (SBAC) is

presented in (Javanmardi et al., 2006) to authenticate

users based on their credentials when requesting

an access right. In (Kagal et al., 2003), a policy

language and a security framework based on this

language to address security issues in Semantic Web

are presented. An Ontology Based Access Control

(OBAC) model is proposed in (Can et al., 2010; Can,

2009; Can and Unalir, 2010) to deﬁne and enforce

semantically rich access control policies. The OBAC

models both the requestor and the requested by using

the Rei policy language (Kagal et al., 2003).

In this work, the goal is to revisit the OBAC model

with the concepts of OBDA to improve security and to

preserve privacy while providing data virtualization.

To the best of our knowledge, this paper is the ﬁrst

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

516

one that proposes a privacy framework for OBDA that

is based on a fully semantic ontology based access

control model. The proposed model addresses the

issues arising from the security and privacy needs of

the OBDA approach.

3 REVISITING OBAC FOR OBDA

In this work, the OBAC model is revised within the

scope of the OBDA approach. OBAC is an access

control mechanism that is used to secure Semantic

Web based applications. OBDA allows querying a

database that uses an ontology to expose data by

abstracting away from the technical schema-level

details of the underlying data (Kharlamov et al.,

2017). In OBDA, domain knowledge is represented

in the form of an ontology, and data virtualization

is achieved through a mapping between the domain

ontology and the data sources (Poggi and et al., 2008).

When the desired mapping is established, the user can

execute queries on the ontology and retrieve data from

the mapped database (Spanos et al., 2012). Hence,

OBDA presents a conceptual view of data ad the

ontology acts as a mediator between the user and

the data. The aim of revisiting the OBAC model

within the scope of OBDA is to provide a privacy

framework so that ontology-based data access can

be performed in a privacy-aware manner. For this

purpose, OBDA will preserve privacy based on the

OBAC model. Thus, an access control mechanism

will be enforced for the OBDA. Moreover, access

control needs to be managed on different data models

due to polyglot persistency. As the legacy data can

be represented in an ontology, relational database, or

non-relational database, queries should be translated

into a form that will be understood by the legacy data.

This process will be achieved by mapping. Also,

RBAC mechanism will be integrated into the model.

In the RBAC model, permissions are given directly

to roles, not to the user. In the scope of this study, a

query on a relational database should be transformed

from RBAC to OBAC. Thus, each data source will

be queried in its environment. Therefore, the RBAC

model will be mapped to the OBAC model where data

is represented semantically. The overall architecture

of the proposed model is given in Fig. 1.

The proposed model is based on a

materialization-based approach (forward chaining).

In the materialization-base approach (Sequeda,

2017), the input is the database D, the target ontology

is O and the mapping from D to O is M. The legacy

data source is the ABox (A) and the ontology is the

TBox (T ). The SPARQL query Q is executed over

Figure 1: Architecture of the proposed model.

the D, O, and M. The OBAC model is based on Rei

policy ontologies (Kagal et al., 2003; Kagal, 2002).

In the OBAC model, a Permission Per denotes what

an entity can do, a Prohibition Pro states what an

entity can’t do, an Obligation Obl is what an entity

should do and a Dispensation Dis indicates what an

entity need no longer do. Along with the OBAC,

access to the underlying data sources is abstracted

independent of the mapping. The mapping between

a database and an ontology will be achieved by

Ontop (Ontop, 2009) which is an open-source OBDA

framework. Also, Ontop is a query transformation

module. Therefore, queries will be executed by

using the Ontop framework. The proposed model

will adhere to the following bottom-up architecture:

(i) establishing an integrated framework model for

access control and privacy, (ii) evaluation of personal

and organizational identities within the scope of

the multi-tenant model, (iii) conversion of RBAC

entities to OBAC entities for relational data sources,

(iv) realization of an access control independent

of the data model, (v) comparative testing of query

execution in both proactive and reactive structure, (vi)

extending OBAC into a privacy-aware structure, (vii)

implementing the proposed framework with Ontop,

and (viii) evaluation of the proposed framework for a

speciﬁc domain.

4 CONCLUSIONS

In today’s conditions, most of the daily routines

are dependent on information systems. Thus, large

amounts of information are produced and stored

Revisiting Ontology Based Access Control: The Case for Ontology Based Data Access

517

by these systems. Most of these data are stored

and represented in relational databases. In order

to extract semantic information from a database,

inference it and obtain valuable information, the

database needs to be converted to the knowledge

base (Dadjoo and Kheirkhah, 2015). Therefore, the

mapping between databases and ontologies should

be maintained to execute semantic queries and to

discover new relationships by inference. Thus, the

quality of data integration will be improved. On the

other hand, the security and privacy of systems must

be maintained. This work proposes a Semantic Web

based model to improve the security and privacy of

systems that may arise when applying the OBDA

approach. In this work, a conceptual model for

the proposed model is presented. As future work,

the OBAC ontologies will be extended and mapped

with the concepts of the RBAC model. As OBAC

is an access control model, it will be also extended

to preserve privacy. The desired mappings will be

established and queries will be executed by using the

Ontop framework.

ACKNOWLEDGEMENTS

This study is supported by Ege University Scientiﬁc

Research Projects Committee under the grant number

18-MUH-036.

REFERENCES

Berners-Lee, T. (2009). Relational databases on the

semantic web. https://www.w3.org/DesignIssues/

RDB-RDF.html. Online; accessed 05 November

2021.

Can, O. (2009). Personalizable Ontology Based Access

Control for Semantic Web and Policy Management.

Phd thesis, Ege University, Department of Computer

Engineering.

Can, O., Bursa, O., and Unalir, M.-O. (2010).

Personalizable ontology based access control.

Gazi University Journal of Science, 23(4):465–474.

Can, O. and Unalir, M.-O. (2010). Ontology based access

control. Pamukkale University Journal of Engineering

Sciences, 16(2):197–206.

Dadjoo, M. and Kheirkhah, E. (2015). An approach for

transforming of relational databases to owl ontology.

Int. Journal of Web and Semantic Technology,

6(1):19–28.

Giese, M. et al. (2013). Big Data Computing. Chapman and

Hall/CRC, New York, 1st edition.

Gruber, T.-R. (1995). Towards principles for the design of

ontologies used for knowledge sharing. Int. Journal

of Human-Computer Studies, 43:907–928.

Haw, S.-C., May, J.-W., and Subramaniam, S. (2017).

Mapping relational databases to ontology

representation: A review. In ICDTE’17, pages

54–55.

He, Z. et al. (2010). Using semantic web techniques to

implement access control for web service. In ICICA

2010, volume 105, pages 258–266. Springer.

Hoehndorf, R., Slater, L., Schoﬁeld, P.-N., et al. (2015).

Aber-owl: A framework for ontology-based data

access in biology. BMC Bioinformatics, 16(26).

Javanmardi, S., Amini, M., and Jalili, R. (2006). An access

control model for protecting semantic web resources.

In SWPW’06.

Kagal, L. (2002). Rei: A policy language for the me-centric

project. Techreport.

Kagal, L., Finin, T., and Joshi, A. (2003). A policy based

approach to security for the semantic web. In ISWC

2003, volume 2870, pages 402–418. Springer.

Kharlamov, E. et al. (2013). Optique: Towards obda

systems for industry. In The Semantic Web: ESWC

2013 Satellite Events, volume 7955. Springer.

Kharlamov, E., Hovland, D., Jimenez-Rui, E., et al. (2017).

Ontology based data access in statoil. Journal of Web

Semantics, 44:3–36.

Martinez-Cruz, C., Blanco, I.-J., and Vila, M.-A. (2012).

Ontologies versus relational databases: are they so

different? a comparison. Artiﬁcial Intelligence

Review, 38:271–290.

Mikheev, A.-V. (2018). Ontology-based data access for

energy technology forecasting. In IWCI 2018, volume

158.

Ontop (2009). https://ontop-vkg.org. Online; accessed 05

November 2021.

Poggi, A. and et al. (2008). Linking data to ontologies.

Journal on Data Semantics X., 4900:133–173.

Sequeda, J.-F. (2017). Integrating relational databases with

the semantic web: A reﬂection. In Reasoning Web

2017, volume 10370, pages 68–120. Springer.

Spanos, D.-E., Stavrou, P., and Mitrou, N. (2012). Bringing

relational databases into the semantic web: A survey.

Semantic Web, 3(2):169–209.

Xiao, G., Ding, L., Cogrel, B., and Calvanese, D. (2019).

Virtual knowledge graphs: An overview of systems

and use cases. Data Intelligence, 1(3):201–223.

ICISSP 2022 - 8th International Conference on Information Systems Security and Privacy

518
